Kyocera PF-8 Part List

PRINTER OPTIONS

PF-8

PARTS CATALOGUE

PRINTER OPTIONS - Parts Catalogue KYOCERA PF-8 Page 1

PF-8 Parts Catalogue

Table of Contents

Introduction

The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:

Reference number which corresponds to the parts in the figure’Ref No.’

Part code which identifies the part’Part code’

A brief description of the part’Part description’

Quantity of the part used in the printer or option’Quantity’

Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.

3Paper feeder for FS-400 (Fig.1)

PRINTER OPTIONS - Parts Catalogue KYOCERA PF-8 Page 2

PRINTER OPTIONS - Parts Catalogue KYOCERA PF-8 Page 3

01-040M

01-040B

01-005

01-040T

Fig.1 - Paper feeder for FS-400

01-040F

01-040G

01-040S

01-040P

01-040Q

01-040W

01-040K

01-040L

01-040E

01-040J

01-040R

01-040C

01-040W

01-040D

01-034

01-012

01-040I

01-034

01-008

01-040H

01-007

01-011

01-034

01-009

01-023

01-010

01-006

01-016

01-018

01-017

01-004

01-014

01-015

01-022

01-003

01-020

01-019

01-013

01-030

01-040A

01-001

01-002

01-040N

01-040S

01-040O

QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.

1PAPER FEEDERPF-801-000

1BASE FEEDER5MVB886SH03901-001
2FOOT5MVX321RH00101-002

1COVER LEGAL5MVX862SH00201-003

1BASE DRIVE5MVB885SH02601-004
1LID FEEDER5MVX873SH01301-005
1ACTUATOR EMPTY5MVX332SB01501-006
1ACTUATOR CASS5MVX522SB01601-007
1SHAFT FEED5MMT811SN00101-008
1GEAR Z325MVG148DW00301-009
1BUSHING SBK5MMM176CJ00501-010

1ROLLER FEED ASSY5AAVROLL*02801-011

1BUSH POM5MVM122DB00301-012
1PLATE DRIVE5MMX654SW0101-013
1WORM WHEEL5MVG147DW00101-014
1DRIVE MOVER5MVX322NW00301-015
1GEAR Z205MVG127DW00301-016
1WASHER MOVER5MMS766LD00201-017
1SPRING MOVER5MMW111LD00201-018
1GEAR WORM5MVG115DB00201-019

1DC MOTOR5EZND1204001*0101-020

1FILM DRIVE5MVS621EF00101-022
1LABEL SERIAL5MVVSPF8***101-023
1CONN CORD ASSY5AACCNNE8GEA01-030

1PW BOARD UNIT5AAYPF8***0301-034
1CASSETTE ASSY5AAVCASET19101-040

1BASE CASSETTE5MVB886SH03801-040A
1PLATE BOTTOM5MVB882SH00601-040B
1PLATE BOTTOM A5MMS851SD00101-040C
1GUIDE PAPER SIDE R5MVX764SH00601-040D
1PINION5MVG126DW00101-040E
1COVER RACK5MVS861SH00101-040F
1SEPARATOR5MVB642SH01501-040G
1GUIDE PAPER REAR5MVX761SH00201-040H
1REAR STOPPER5MVX631SH00501-040I
2SPRING CASSETTE5MMW552LD00101-040J
1SPRING SEPARATOR5MMW411LD00101-040K
1PAD SEPARATOR5MVS617WK00301-040L
1PAD FRICTION5MVS637WK00101-040M
1LOCK CASSETTE R5MVX322DW00201-040N
1SPRING LOCK R5MMW161LD01601-040O
1LOCK CASSETTE L5MVX322DW00301-040P
1SPRING LOCK L5MMW161LD01701-040Q
3TP T.T. SCREW(+)5MBTP43005WZ01-040R

PRINTER OPTIONS - Parts Catalogue KYOCERA PF-8 Page 4

QuantityDescriptionPart CodeRef No.

2CS STOP RING5MBCS3025XSP01-040S
1GUIDE PAPER SIDE L5MVX764SH00501-040T
2CS STOP RING5MBCS4025XSP01-040W
1SEPARATOR ASSY5AAVSEPRT01001-040L/G

PRINTER OPTIONS - Parts Catalogue KYOCERA PF-8 Page 5
