PRINTER OPTIONS
DF-30
PARTS CATALOGUE
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 1
DF-30 Parts Catalogue
Table of Contents
3DF-30 Overall (Fig.0)
5Attachment Parts (Fig.1)
7External Covers/Panels #1 (Fig.2a)
9External Covers/Panels #2 (Fig.2b)
11Stapler Tray Main Body #1 (Fig.3a)
13Stapler Tray Main Body #2 (Fig.3b)
16Stapler Tray Main Body #3 (Fig.4)
18Tray Drive Assembly (Fig.5)
20Tray Assembly (Fig.6)
22Swing Guide Assembly (Fig.7)
24Stapler Tray Assembly #1 (Fig.8a)
27Stapler Tray Assembly #2 (Fig.8b)
29Upper Feed Assembly (Fig.9)
31Center Guide Assembly (Fig.10)
33Stapler Assembly (Fig.11)
35PCB Assembly Location (Fig.12)
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
’Ref No.’
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
Reference number which corresponds to the parts in the figure
Part code which identifies the part’Part code’
A brief description of the part’Part description’
Quantity of the part used in the printer or option’Quantity’
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 2
08-001
09-001
07-001
10-001
05-001
06-001
11-001
Fig.0 - DF-30 Overall
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 3
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
TRAY DRIVE ASSY5SNSADF30E0505-001
TRAY ASS’Y5SNSADF30E0606-001
SWING GUIDE ASS’Y5SNSADF30E0707-001
STAPLER TRAY ASS’Y5SNSADF30E0808-001
UPPER FEEDER ASS’Y5SNSADF30E0909-001
CENTER GUIDE ASS’Y5SNSADF30E1010-001
STAPLER ASS’Y5SNSADF30E1111-001
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 4
13-003
01-008
13-001
01-002
13-002
01-004
01-005
01-004
51-001
51-002
51-003
01-007
01-006
01-003
Fig.1 - Attachment Parts
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 5
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
ATTACHMENT PARTS5SNSADF30E0101-001
GUIDE5SNSP001179301-002
RAIL GUIDE5SNSP001179601-003
SCREW TRAY M45SNSP001179701-004
CABLE INTERFACE5SNSP001179801-005
GROUND ADAPTOR UNIT5SNSP001180101-006
BRACKET5SNSP001180201-007
CABLE AC Japan5SNSP001230501-008
CABLE AC France5SNSP001230901-008
CABLE AC USA5SNSP001230601-008
CABLE AC UK5SNSP001230701-008
CABLE AC AUSTRALIA5SNSP001230801-008
CABLE AC GERMANY5SNSP001230901-008
TRAY ASSY5SNSADF30E1313-001
TRAY5SNSP001179913-002
SHEET REFLECTING5SNSP001180013-003
UNIT RAIL5SNSADF30E5151-001
RAIL5SNSP001179451-002
SCREW STEPPED M45SNSP001179551-003
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 6
02-003
02-004
20-002
20-001
20-004
02-002
20-003
23-008
23-005
23-004
23-010
23-003
23-007
23-009
23-002
23-001
19-005
19-004
19-001
19-003
19-002
19-006
23-006
Fig.2a - External Covers/Panels #1
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 7
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
EXTERNAL COVERS PANELS5SNSADF30E0202-001
GUIDE HURDLE TOP5SNSP001180302-002
CAP COVER FRONT5SNSP001180402-003
CAP COVER REAR5SNSP001180502-004
PLATE SHUTTER5SNSADF30E1919-001
DAMPER5SNSP001182019-002
DAMPER SHUTTER5SNSP001182119-003
GASKET5SNSP001184619-004
PLATE SHUTTER5SNSP001184919-005
CLAMP CABLE5SNSP001229219-006
SLIDE GUIDE ASS’Y5SNSADF30E2020-001
GUIDE SLIDE5SNSP001182620-002
COVER SLIDE FRONT5SNSP001182720-003
COVER SLIDE REAR5SNSP001183320-004
GUIDE HURDLE UNIT5SNSADF30E2323-001
SHUTTER HURDLE5SNSP001181823-002
SPRING LEAF5SNSP001181923-003
GUIDE HURDLE LOWER5SNSP001182223-004
PLATE HURDLE5SNSP001182323-005
CABLE5SNSP001228623-006
PHOTO-INTERRUPTER5SNSP001182423-007
PLATE HURDLE 25SNSP001182523-008
SPRING LEAF5SNSP001184123-009
PLATE5SNSP001184223-010
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 8
17-007
17-001
02-009
17-003
17-006
17-002
16-003
02-010
16-002
17-005
17-004
02-006
18-002
14-002
14-001
18-003
14-003
18-005
18-001
02-010
18-004
22-002
22-003
15-002
02-011
02-010
22-001
15-001
14-003
02-010
16-001
02-007
02-005
02-008
21-004
21-006
21-002
21-007
Fig.2b - External Covers/Panels #2
21-002
21-001
21-007
21-005
21-003
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 9
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
COVER CASTER5SNSP001180602-005
COVER FRONT5SNSP001180702-006
COVER LOWER FRONT5SNSP001180802-007
COVER LOWER REAR5SNSP001180902-008
COVER REAR5SNSP001181002-009
SCR RS M4*85SNSP001228702-010
LABEL5MVVSDF30*0102-011
LATCH FRONT5SNSADF30E1414-001
LATCH FRONT5SNSP001185114-002
MAGNET5SNSP001184314-003
LATCH REAR5SNSADF30E1515-001
LATCH REAR5SNSP001185215-002
COVER DOOR5SNSADF30E1616-001
LABEL OPERATION5SNSP001181116-002
COVER FRONT5SNSP001185016-003
TOP DOOR ASS’Y5SMSADF30E1717-001
WASHER5SNSP001228517-002
SPRING COMPRESSION5SNSP001181217-003
SPRING TORSION5SNSP001181317-004
LATCH5SNSP001181417-005
PIECE PRESSURE5SNSP001181517-006
TOP DOOR5SNSP001184717-007
TOP COVER ASS’Y5SNSADF30E1818-001
SPRING TORSION5SNSP001181618-002
ARM SENSOR5SNSP001181718-003
TOP COVER5SNSP001184818-004
FILM5SNSP001228918-005
RIGHT GUIDE ASS’Y5SNSADF30E2121-001
ROLLER A5SNSP001183421-002
HINGE5SNSP001183521-003
LATCH5SNSP001183621-004
RIGHT GUIDE5SNSP001183721-005
SPRING TORSION5SNSP001183821-006
SPRING TORSION5SNSP001183921-007
SPRING TENSION5SNSP001184021-008
LATCH REAR UNIT5SNSADF30E2222-001
FLAG SENSORE5SNSP001184422-002
SPRING TENSION5SNSP001184522-003
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 10
03-003
03-025
03-026
03-069
03-012
03-013
27-006
27-002
03-069
03-002
27-010
03-069
27-009
03-069
27-003
27-001
27-007
03-005
03-006
03-071
03-069
03-019
03-010
03-009
03-069
03-028
03-069
03-069
03-008
03-027
03-069
03-004
03-069
03-069
03-032
03-016
03-069
26-003
26-002
24-005
24-007
24-004
03-069
26-001
24-006
24-002
03-069
03-069
27-008
24-001
03-069
27-005
24-006
24-004
24-005
03-069
25-001
25-007
24-002
03-069
Fig.3a - Stapler Tray Main Body #1
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 11
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
STAPLER TRAY MAIN BODY 15SNSADF30E0303-001
SPRING LEAF5SNSP001185403-002
MOUNT SLIDE5SNSP001185503-003
HOLDER SLIDER5SNSP001185603-004
HOLDER5SNSP001185703-005
MOUNT SENSOR5SNSP001185803-006
SPRING LEAF5SNSP001186003-008
SPRING COMPRESSION5SNSP001186103-009
BRACKET5SNSP001186203-010
DUCT SWENSOR5SNSP001186403-012
SENSOR5SNSP001186503-013
CLIP CABLE5SNSP001186803-016
PHOTO-INTERRUPTER5SNSP001182403-019
CABLE SENSOR5SNSP001187803-025
CONNECTOR SNAP TIGHT5SNSP001187903-026
MICROSWITCH5SNSP001188003-027
MICROSWITCH5SNSP001188103-028
PLATE GEAR5SNSP001188703-032
SCREW RS M4*8*5SNSP001228703-069
CLIP CABLE5SNSP001193103-071
UNIT BOTTOM FRAME FRONT5SNSADF30E2424-001
CASTER5SNSP001188524-002
CASTER5SNSP001193624-004
BOLT5SNSP001193724-005
SCREW5SNSP001229524-006
BOTTOM FLAME FRONT5SNSP001230124-007
UNIT BOTTOM FRAME REAR5SNSADF30E2525-001
BOTTOM FLAME REAR5SNSP001230225-007
UNIT BOTTOM FRAME SUB5SNSADF30E2626-001
ADJUSTER5SNSP001193426-002
FLAME SUB5SNSP001193526-003
UNIT FRAME5SNSADF30E2727-001
FRONT SUPPORT5SNSP001229627-002
REAR SUPPORT5SNSP001229727-003
MOUNT RAIL5SNSP001188627-005
STOPPER F5SNSP001193227-006
BOTTOM SUPPORT5SNSP001229827-007
GUIDE REINFORCEMENT5SNSP001229927-008
STOPPER R5SNSP001193327-009
HINGE DOOR5SNSP001187227-010
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 12
03-050
03-055
03-036
03-042
03-060
03-069
03-069
03-061
03-068
03-070
03-067
03-043
03-045
03-042
03-073
03-034
27-003
29-001
03-037
03-054
03-059
28-002
28-001
03-038
03-044
03-056
03-023
03-069
03-063
29-002
03-022
03-024
03-033
03-041
03-069
03-020
03-049
03-047
03-032
30-003
03-019
03-062
03-052
30-002
03-068
03-069
03-053
03-058
03-057
03-068
03-051
03-052
03-066
03-064
03-069
03-048
03-021
03-069
03-007
03-014
03-069
03-046
03-017
03-014
03-007
03-069
03-039
52-001
52-004
03-015
52-002
03-031
03-016
52-003
29-003
03-070
03-016
03-030
03-018
03-069
29-004
03-017
03-074
03-029
03-016
03-035
03-019
03-070
30-001
03-040
03-011
Fig.3b - Stapler Tray Main Body #2
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 13
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
SPRING LEAF5SNSP001185903-007
SCREW5SNSP001186303-011
MICROSWITCH5SNSP001186603-014
CABLE SWITCH5SNSP001186703-015
CLIP CABLE5SNSP001186803-016
CLIP CABLE5SNSP001186903-017
CLAMP5SNSP001187003-018
PHOTO-INTERRUPTER5SNSP001182403-019
PLATE SHAFT5SNSP001187303-020
CABLE POWER5SNSP001187403-021
CABLE SENSOR5SNSP001187503-022
CONNECTOR 2P5SNSP001187603-023
CONNECTOR SNAP TIGHT5SNSP001187703-024
PHOTO-INTERRUPTER5SNSP001182403-029
CLIP CABLE5SNSP001188303-030
CLIP CABLE5SNSP001188403-031
GUIDE CABLE5SNSP001188803-033
SHAFT ROLLER PAPER FEED5SNSP001188903-034
SPRING TENSION5SNSP001189003-035
GEAR 45T/55T5SNSP001189103-036
SHAFT ROLLER 15SNSP001189303-037
SHAFT ROLLER5SNSP001189403-038
DEFLECTOR5SNSP001189503-039
ARM DEFLECTOR5SNSP001189603-040
BELT TIMING5SNSP001189703-041
HOOK5SNSP001189803-042
ARM REVERSE5SNSP001189903-043
PLATE GROUND5SNSP001190003-044
GUIDE CENTER5SNSP001190103-045
COVER SWITCH5SNSP001190203-046
FLAG SENSOR5SNSP001190303-047
MOUNT SENSOR5SNSP001190403-048
GEAR 20T/42T5SNSP001190703-049
GEAR 24T/36T5SNSP001190803-050
GEAR 17T/27T5SNSP001190903-051
GEAT 17T/23T5SNSP001191003-052
GEAR 16T/36T5SNSP001191103-053
GEAR 18T/24T5SNSP001191203-054
GEAR 26T5SNSP001191303-055
GEAR 28T5SNSP001191403-056
GEAR 23T5SNSP001191503-057
GEAR 18T5SNSP001191603-058
GEAR 20T5SNSP001191703-059
SPRING TENSION5SNSP001191803-060
SPRING TENSION5SNSP001191903-061
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 14
QuantityDescriptionPart CodeRef No.
SPRING TENSION5SNSP001192003-062
GEAR 27T/PULLEY 48T5SNSP001192103-063
GEAR 30T5SNSP001192203-064
SOLENOID5SNSP001192503-066
COLLAR SPRING5SNSP001192703-067
BUSHING5SNSP001192803-068
SCREW RS M4*85SNSP001228703-069
CLIP CABLE5SNSP001193003-070
CLIP CABLE5SNSP001193803-072
FRONT SIDE PLATE5SNSP001194003-073
CENTER REINFORCEMENT5SNSP001230003-074
COVER SPRING5SNSP001192927-003
UNIT GUIDE REVERSE5SNSADF30E2828-001
GUIDE REVERSE5SNSP001192428-002
UNIT PLATE REAR5SNSADF30E2929-001
REAR SIDE PLATE5SNSP001193929-002
MOTOR STEPPING DC24V5SNSP001192329-003
SOLENOID5SNSP001189229-004
UNIT POWER5SNSADF30E3030-001
SWITCHING REGULATER5SNSP001185330-002
COVER POWER SUPPLY ASS’Y5SNSP001192630-003
GUIDE PAPER FEED5SNSADF30E5252-001
SHEET5SNSP001190652-002
SHEET5SNSP001229452-003
STAY GUIDE5SNSP001190552-004
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 15
04-003
04-007
33-002
04-006
33-003
04-004
34-001
04-005
04-009
04-011
04-008
34-004
34-006
34-005
04-002
34-003
31-002
04-007
35-002
35-004
32-001
34-002
35-005
35-002
31-001
35-001
04-012
31-003
35-006
35-003
04-010
Fig.4 - Stapler Tray Main Body #3
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 16
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
STAPLER TRAY MAIN BODY 25SNSADF30E0404-001
BELT5SNSP001194204-002
GEAR 15T/32T5SNSP001194304-003
CLIP CABLE5SNSP001194404-004
COVER CABLE5SNSP001194504-005
CABLE SENSOR5SNSP001194804-006
PHOTO-INTERRUPTER5SNSP001182404-007
CABLE SWING UNIT5SNSP001196204-008
CONNECTOR 2P5SNSP001196304-009
CONNECTOR 3P5SNSP001196404-010
BUSHING5SNSP001196604-011
CLIP CABLE5SNSP001196704-012
GUIDE STAPLE5SNSADF30E0131-001
SHEET5SNSP001195531-002
GUIDE STAPLE5SNSP001195431-003
GUIDE BELT5SNSADF30E3232-001
PLATE GUIDE5SNSP001196832-002
HOOK GUIDE5SNSP001229032-003
MICROSWITCH UNIT5SNSADF30E3333-001
PLATE SWING5SNSP001194633-002
CABLE SENSOR5SNSP001194733-003
UNIT ROLLER5SNSADF30E3434-001
ROLLER DELIVERY5SNSP001195634-002
CAM SHUTTER5SNSP001195734-003
GEAR 22T5SNSP001195834-004
GEAR 18T5SNSP001195934-005
BUSHING5SNSP001196034-006
UNIT GUIDE STAPLE5SNSADF30E3535-001
ROLLER5SNSP001194135-002
MOUNT SENSOR5SNSP001195135-003
SPRING TORSION5SNSP001195335-004
FLAG SENSOR5SNSP001195035-005
PHOTO-INTERRUPTER5SNSP001196535-006
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 17
05-006
05-010
05-004
05-001
05-010
05-011
05-008
05-002
05-006
05-007
05-005
05-009
05-003
05-012
05-013
05-015
05-014
05-016
Fig.5 - Tray Drive Assembly
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 18
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
TRAY DRIVE ASSY5SNSADF30E0505-001
BRACKET DRIVE5SNSP001196905-002
CAM5SNSP001197005-003
SHAFT TRAY5SNSP001197105-004
BUSHING5SNSP001197205-005
GEAR 48T5SNSP001197305-006
SPRING COMPRESSION5SNSP001197405-007
MOTOR DC24V5SNSP001197505-008
GEAR 22T5SNSP001197605-009
BUSHING5SNSP001197705-010
BRACKET DRIVE SMALL5SNSP001197805-011
WASHER5SNSP001197905-012
PHOTO-INTERRUPTER5SNSP001198005-013
CABLE MAIN5SNSP001231005-014
FERRITE CORE5SNSP001231105-015
CLAMP CABLE5SNSP001231205-016
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 19
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 20
06-007
06-004
06-009
06-002
Fig.6 - Tray Assembly
06-006
06-007
06-006
06-007
06-002
06-005
06-008
06-007
06-008
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
TRAY ASS’Y5SNSADF30E0606-001
GUIDE SLIDE A5SNSP001198106-002
GUIDE SLIDE B5SNSP001198206-003
CROSSMEMBER TRAY5SNSP001198306-004
FRAME TRAY FRONT5SNSP001198406-005
FRAME TRAY REAR5SNSP001198506-006
ROLLER5SNSP001198606-007
ROLLER5SNSP001198706-008
PLATE GUIDE5SNSP001198806-009
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 21
07-010
39-007
36-001
07-012
07-005
07-011
07-010
36-002
36-003
39-004
07-007
07-004
39-007
36-002
37-002
37-001
07-012
07-005
07-011
07-003
39-001
07-014
39-005
39-003
39-002
07-016
40-003
40-002
07-015
07-008
39-002
40-001
40-003
40-002
38-001
40-001
39-006
41-002
41-003
07-006
41-002
41-003
07-015
07-009
07-013
07-017
Fig.7 - Swing Guide Assembly
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 22
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
SWING GUIDE ASS’Y5SNSADF30E0707-001
LEVER SWING5SNSP001199007-003
SPRING RETAINER5SNSP001199107-004
HOLDER ROLLER5SNSP001199207-005
SHAFT5SNSP001199307-006
SHAFT ROLLER5SNSP001199407-007
GEAR 21T5SNSP001200707-008
GEAR 21T5SNSP001200807-009
ROLLER5SNSP001200907-010
ROLLER5SNSP001201007-011
SPRING COMPRESSION5SNSP001201107-012
SPRING TENSION5SNSP001201207-013
SPRING TENSION5SNSP001201307-014
BUSHING5SNSP001201407-015
SOLENOID5SNSP001201507-016
COLLAR SPRING5SNSP001201607-017
SPRING COMPRESSION5SNSP001231907-018
ARM STOP FRONT T315SNSADF30E3636-001
WEIGHT5SNSP001231336-002
ARM FRONT5SNSP001198936-003
ARM STOP REAR5SNSADF30E3737-001
ARM REAR5SNSP001199537-002
PLATE DRIVE5SNSADF30E3838-001
GEAR PLATE5SNSP001199638-002
GEAR5SNSP001231438-003
SHAFT 15SNSP001231538-004
SHAFT 25SNSP001231638-005
SHAFT 35SNSP001231738-006
GUIDE SWING5SNSADF30E3939-001
ELIMINATOR STATIC CHARGE A5SNSP001199839-002
ELIMINATOR STATIC CHARGE B5SNSP001199939-003
PLATE GROUNDING5SNSP001200039-004
PLATE GROUNDING5SNSP001200139-005
PLATE GROUNDING5SNSP001200239-006
ELIMINATOR STATIC CHARGE C5SNSP001200339-007
SWING GUIDE5SNSP001199739-008
PLATE5SNSADF30E4040-001
DAMPER SHUTTER5SNSP001200540-002
DAMPER SHUTTER5SNSP001200440-003
SHAFT5SNSADF30E4141-001
RUBBER5SNSP001200641-002
STAND5SNSP001231841-003
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 23
08-033
08-018
08-039
08-019
45-001
46-002
46-005
46-003
46-004
08-017
46-001
08-009
08-032
08-039
08-002
08-038
08-039
08-008
44-001
08-003
08-036
08-004
43-002
08-028
43-003
43-001
08-013
08-030
08-012
08-035
08-027
08-030
08-014
08-015
08-010
08-022
08-015
08-011
Fig.8a - Stapler Tray Assembly #1
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 24
08-035
08-023
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
STAPLER TRAY ASS’Y5SNSADF30E0808-001
SHAFT DELIVERY ROLLER5SNSP001201708-002
LINK SHUTTER A5SNSP001201808-003
LINK SHUTTER B5SNSP001201908-004
LEVER SENSOR5SNSP001202308-008
PLATE GEAR5SNSP001202408-009
LEVER STOP FRONT5SNSP001202508-010
LEVER STOP REAR5SNSP001202608-011
PLATE SUPPORT FRONT5SNSP001202708-012
PLATE SUPPORT REAR5SNSP001202808-013
CROSSBAR STOP5SNSP001202908-014
LINK5SNSP001203008-015
GEAR 15T/23T5SNSP001203508-017
GEAR 15T5SNSP001203708-018
GEAR 50T5SNSP001203808-019
SPRING TORSION5SNSP001204108-022
SPRING TORSION5SNSP001204208-023
STOP FRONT5SNSP001204908-027
STOP REAR5SNSP001205008-028
SPRING TENSION5SNSP001205208-030
BUSHING5SNSP001206008-032
BUSHING5SNSP001206108-033
SCREW5SNSP001206308-035
SPRING5SNSP001206408-036
CLIP CABLE5SNSP001206708-038
SCREW RS M4*85SNSP001228708-039
SPRING LEAF5SNSADF30E4343-001
RUBBER5SNSP001205443-002
SPRING LEAF5SNSP001205343-003
PLATE5SNSADF30E4444-001
PLATE STOPPER5SNSP001232444-003
GEAR55SNSP001232544-004
GEAR75SNSP001232644-005
GEAR25SNSP001232744-006
SHAFT25SNSP001232844-007
SHAFT55SNSP001232944-008
SHAFT65SNSP001233044-009
SHAFT75SNSP001233144-010
SHAFT555SNSP001233244-011
SWING SHAFT GS5SNSP001227744-012
SHAFT35SNSP001227844-013
LEVER SWING5SNSADF30E4545-001
LEVER SWING5SNSP001203445-002
BOSS PLATE SWING5SNSP001232045-003
SHAFT5SNSP001232145-004
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 25
QuantityDescriptionPart CodeRef No.
UNIT LEVER SWING5SNSADF30E4646-001
GEAR 15T/34T5SNSP001203646-002
WASHER5SNSP001203146-003
SPRING LEAF5SNSP001203346-004
SLIDER5SNSP001206546-005
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 26
08-029
08-025
08-005
08-007
42-005
42-001
42-004
08-026
42-002
08-031
08-016
08-024
08-038
42-003
08-038
08-038
47-002
08-021
47-003
47-004
08-020
08-034
47-002
47-005
08-006
Fig.8b - Stapler Tray Assembly #2
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 27
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
PLATE5SNSP001202008-005
SHUTTER5SNSP001202108-006
LEVER SHUTTER5SNSP001202208-007
MOUNT SENSOR5SNSP001203208-016
GEAR 12T/36T5SNSP001203908-020
SPRING TORSION5SNSP001204008-021
CLIP CABLE5SNSP001204608-024
SOLENOID5SNSP001204708-025
MOTOR DC24V5SNSP001204808-026
PHOTO-INTERRUPTER5SNSP001205108-029
RING RETAINING5SNSP001205908-031
WASHER5SNSP001206208-034
CLIP CABLE5SNSP001206708-038
PLATE TRAY REAR5SNSP001206608-040
TRAY STAPLER5SNSADF30E4242-001
SEAL5SNSP001204442-002
STAPLER TRAY5SNSP001204342-003
PLATE HOLD5SNSP001232242-004
RUBBER5SNSP001232342-005
UNIT MOUNT MOTOR5SNSADF30E4747-001
MOUNT MOTOR5SNSP001205547-002
CLIP CABLE5SNSP001205647-003
MOTOR STEPPING5SNSP001205747-004
PHOTO-INTERRUPTER5SNSP001182447-005
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 28
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 29
Fig.9 - Upper Feed Assembly
09-004
09-003
09-005
09-002
09-004
09-003
48-001
48-004
48-003
48-002
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
UPPER FEEDER ASS’Y5SNSADF30E0909-001
ROLLER A5SNSP001206809-002
ROLLER B5SNSP001206909-003
ROLLER C5SNSP001207009-004
SPRING TORSION5SNSP001207109-005
SPRING ROLLER HOLDER5SNSP001207509-006
GUIDE UPPER5SNSADF30E4848-001
GUIDE UPPER5SNSP001207248-002
LABEL OPEERATION5SNSP001207348-003
LABEL 15SNSP001207448-004
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 30
10-004
10-003
49-003
10-007
10-002
10-005
10-007
10-006
49-002
49-001
Fig.10 - Center Guide Assembly
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 31
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
CENTER GUIDE ASS’Y5SNSADF30E1010-001
ROLLER A5SNSP001206810-002
SPRING TORSION5SNSP001207110-003
SHAFT STAPLER ROLLER5SNSP001207910-004
GEAR 20T5SNSP001208010-005
GEAR 16T5SNSP001208110-006
BUSHING5SNSP001208210-007
GUIDE CENTER5SNSADF30E4949-001
GUIDE CENTER5SNSP001207649-002
LABEL 25SNSP001207749-003
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 32
11-015
11-028
11-023
11-007
50-004
11-027
11-028
11-009
11-012
11-032
50-006
11-030
11-016
50-005
50-001
11-017
11-012
50-003
11-022
11-009
50-002
11-028
11-029
11-008
11-020
11-021
11-013
11-011
11-006
11-018
11-022
11-005
11-020
11-014
11-010
11-026
11-029
11-024
11-031
11-009
11-031
11-020
11-009
11-003
11-004
11-025
11-002
11-019
11-025
Fig.11 - Stapler Assembly
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 33
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
STAPLER ASS’Y5SNSADF30E1111-001
GUIDE STAPLER5SNSP001208311-002
PLATE RACK5SNSP001208411-003
PLATE GUIDE5SNSP001208511-004
COVER SENSOR5SNSP001208611-005
BELT TIMING5SNSP001208711-006
CAM STOP5SNSP001208811-007
COVER PCB5SNSP001208911-008
SCREW STEPPED M35SNSP001209011-009
GEAR 44T/PULLEY 16T5SNSP001209111-010
GEAR 16T/PULLEY 40T5SNSP001209211-011
ROLLER5SNSP001209311-012
ROLLER5SNSP001209411-013
FLANGE PULLEY5SNSP001209511-014
CATCH MAGNET5SNSP001209611-015
MOTOR STEPPING5SNSP001209711-016
CABLE STAPLER5SNSP001209811-017
CABLE STAPLER5SNSP001209911-018
CONNECTOR 3P5SNSP001210011-019
SCREW RS M3*65SNSP001195211-020
PHOTO-INTERRUPTER5SNSP001182411-021
TWO-STEP SCREW M35SNSP001210211-022
MOUNT STAPLER5SNSP001210311-023
BRACKET STAPLER5SNSP001210411-024
CLAMP CABLE5SNSP001210511-025
GROMMET CORD5SNSP001210611-026
CONNECTOR 9P5SNSP001210711-027
CONNECTOR PWB ASS’Y5SNSP001210911-028
SCREW5SNSP001228711-029
MOUNT5SNSP001211411-030
ROLLER5SNSP001211511-031
CLAMP CABLE5SNSP001211611-032
UNIT STAPLER5SNSADF30E5050-001
COVER STAPLER5SNSP001211050-002
LEVER LOCK5SNSP001211150-003
STAPLER5SNSP001211250-004
PLATE GROUNDING5SNSP001211350-005
CABLE STAPLER 25SNSP001210850-006
CATRIDGE STAPLE5SNSP001228050-007
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 34
12-002
12-005
12-003
12-006
12-004
Fig.12 - PCB Assembly Location
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 35
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
PCB ASSEMBLY LOCATION DIAGRAM5SNSADF30E1212-001
FINISHER DRIVER PCB ASS’Y5SNSP001211712-002
SWITCH PWB ASS’Y5SNSP001211812-003
CONNECTOR PCB ASS’Y5SNSP001211912-004
CONNECTOR PCB ASS’Y5SNSP001212012-005
INTERFACE PCB ASS’Y5SNSP001207812-006
PRINTER OPTIONS - Parts Catalogue KYOCERA DF-30 Page 36
Loading...
