Kyocera Basio 3 User guide

Download

Page 1

Basic Manual

Contents

Getting Ready

Basic Operation

Safety precautions

Appendix

Page 2

Preface

• KYOCERA TV

• Checkup card (KYV43NXD)

Thank you for buying the "BASIO3" (simply called the "product" or "main unit" from here on). Before using the product, be sure to read the "Basic Manual" (this manual) to ensure correct use.

List of Packaged Items

Before your start using the product, make sure that you have all the following packaged with the product.

• Desktop holder

Main unit

(KYV43PUA)

• 取扱説明書 (Instruction Manual) (Japanese)

• かんたんマニュアル (Kantan Manual) (Japanese)

* KYOCERA TV Antenna Cable 04, desktop holder, and Checkup card are

not water/dust resistant.

The following items are not included in the package.

・AC adapter ・microSD memory card ・USB Type-C cable ・Earphones

Antenna Cable 04 (04KYHSA)

• IC Card Tray Ejecting Tool (sample)

Page 3

◎ Purchase a specified charger (sold separately).

(Phone button)

(Home button)

(Volume DOWN button)

◎ The battery is built into the product. ◎ Illustrations of cell phones in this manual are only for

reference. They may look different from the actual product.

Regarding Notations Used in This Document

■ Note on Button Illustrations

In this manual, buttons are represented by simplified as shown below.

Operating Instructions

■"Basic Manual" (This Manual)

Handles only basic operations for main features.

(Mail button)

(Volume UP button)

(Power button)

(Camera button)

Page 4

■ Description of Operations for Selecting

Some icons etc. are omitted in this manual.

Item/Icon/Button etc.

Notations used for operation procedures in this manual are as follows.

Description Explanation

→ "DIALPAD" [1] [4] [1]

tab → [

CALL

]

In sleep mode,

(Power button)

• Tapping is to select a button or icon displayed on the screen by lightly tapping it with your finger.

Press A. And after tapping

→

"DIALPAD" tab, tap "

", then tap "CALL" at the

and " end. In sleep mode, press F (Power button).

", " "

■

Notes on Illustrations/Screenshots

In this manual, screenshots and operations for the product with au Nano IC Card 04 attached are described. Screen illustrations shown in this manual may look different from the actual screens. Note that part of the screen etc. may be omitted

Actual screen

Notations used in

this manual

Page 5

◎ In this manual, screenshots for body color "Gold" are

provided as examples.

◎ In this manual, "au Nano IC Card 04" is abbreviated as

"au IC card".

◎ In this manual, "microSD™ memory card (commercially

available)", "microSDHC™ memory card (commercially available)" and "microSDXC™ memory card" are abbreviated as "microSD memory card (commercially available)" or "microSD".

◎ All of the indicated amounts exclude tax unless otherwise

specified.

◎ Company names and product names referred to in this

manual are trademarks or registered trademarks of respective companies. The TM, ® marks may be omitted in this manual.

◎ In this manual, the operations with vertically oriented

screens are provided as examples. With horizontally oriented screens, descriptions for menu item/icon/ onscreen button may be different.

◎ Menu items, layers and icons described in this manual

may be different according to functions being used and conditions.

Page 6

Preface ........................................................................... ii

List of Packaged Items ................................................. ii

Operating Instructions ................................................. 1

Regarding Notations Used in This Document ............ 1

Contents ..................................................4

Contents

Getting Ready ..........................................6

Names and Functions of Parts .................................... 6

au IC Card .................................................................... 10

Internal Shared Storage .............................................. 14

Using microSD Memory Card .................................... 14

Charging ...................................................................... 16

Turning the Power On/Off ...........................................21

Switching to English Display ..................................... 22

Start Screen ................................................................. 22

Making Initial Settings ................................................ 23

Making Initial Settings for au-mail ............................. 24

Basic Operations ..................................26

Using Touch Panel ...................................................... 26

Using Touch Keys ....................................................... 27

Home Screen ............................................................... 27

Using the Home Screen.............................................. 28

Activating the Apps .................................................... 32

Monitoring the Product's Status ................................33

Checking Your Phone Number ................................... 34

Setting Silent Mode ..................................................... 35

Setting Airplane Mode ................................................ 35

Using Screen Memo.................................................... 35

Setting Direct Buttons ................................................36

Character Entry ........................................................... 37

Making a Call ............................................................... 38

Receiving a Call .......................................................... 38

Setting Step-up Ring Volume ..................................... 38

Displaying Menu ......................................................... 39

Setting Home Screen .................................................. 39

Saving Battery Consumption ..................................... 39

Using the Camera ....................................................... 40

Safety Precautions ................................41

When Using the Product ............................................ 41

Safety Precautions (Observe Strictly) .......................43

Handling Precautions ................................................. 55

Notes on Water and Dust Resistance ........................ 62

Notes on Using Bluetooth

Function ....................................................................... 68

Security Code/PIN Code ............................................. 70

Notes on Data Communication Charges .................. 72

Notes on Applications ................................................ 72

Setting the App Permissions ..................................... 73

Cell Phone Etiquette ....................................................74

/Wireless LAN (Wi-Fi®)

Appendix ................................................75

Updating Software ...................................................... 75

Troubleshooting .......................................................... 76

After-Sales Service ..................................................... 78

Page 7

SIM Unlock................................................................... 82

Related Accessories ................................................... 83

Main Specications .................................................... 83

Specic Absorption Rate (SAR) of Cell Phones ......85

Export Administration Regulations ........................... 87

Intellectual Property Rights ....................................... 87

Contents

Page 8

⑱

⑨

⑬

⑳

㉑

⑱

⑭ ⑮

Front buttons

⑧

Getting Ready

Names and Functions of Parts

③

⑥ ⑦

⑧ ⑨

Front buttons

①④②

⑤ ⑩

⑪ ⑫

⑬

⑭ ⑮

⑯

⑰ ⑱

⑲

⑳

㉑

㉒㉓

㉔㉕

㉖

㉗

㉘

㉚

㉙

Page 9

■How to open the card slot cover

Insert a fingernail a small way into one of the corners marked ○ pull open the cover. Be careful not to insert your fingernail all the way. Doing so may damage the rubber seal under the cover.

and

① microSD memory card slot ② au IC card slot ③ Noise cancelling microphone

Detects ambient sound when cancelling noise. Do not

cover with fingers, etc. during a call.

④ Earphone microphone terminal

Used for connecting KYOCERA TV Antenna Cable 04,

earphones (commercially available), or other accessories.

⑤ Card slot cover ⑥ In camera (lens) ⑦ Earpiece (receiver)

Hear the other party's voice on call, play sound of

answer memo, etc. with SMART SONIC RECEIVER (▶ P. 9).

⑧ Mouthpiece (microphone)

Relays your voice to the other party. Also use to record

audio. Take care not to cover the microphone with your fingers during a call or recording a video.

⑨

Phone button

Make/receive calls. Flashes when there is a missed call.

⑩ Incoming light/charging light

Flashes according to settings for new call. Lights red during charging.

⑪ Proximity sensor / Light sensor

The proximity sensor ensures that the touch panel does

not accidentally respond.

Light sensor detects the ambient light level to adjust the

display brightness.

⑫ Infrared port

Send/receive data by infrared communication.

⑬ Display (touch panel)

⑭

Mail button

Use for sending and checking au-mail/SMS. Flashes to

notify of received au-mail/SMS.

⑮

Home button

Return to the home screen.

⑯ External connection terminal

Use for connecting Type C Common AC Adapter 01

(sold separately), etc.

⑰ Speaker

Ringtones, alarms, etc. sound from here.

⑱ Strap eyelet

⑲

Volume up / down button

Adjusts sound volume. Press and hold l (Volume

down key) for at least one second to set "Silent mode" (▶ P. 35).

Getting Ready

Page 10

⑳ F Power button

Power ON/OFF, activate/deactivate sleep mode, etc.

󰼼 k Camera button

Use as focus lock/shutter for photos.

󰽇 Built-in Bluetooth

/ Wi-Fi® antenna*

󰽈 Built-in sub-antenna* 󰽉 Photo / Flash light 󰽊 Out camera (lens) 󰽋 Built-in GPS antenna* 󰽌 Camera slide cover

Protects the out camera lens. Slide down to activate the

camera.

󰽍 NFC antenna*

Getting Ready

Pass the supplied Checkup card over this area to give

your smartphone a checkup.

󰽎 Built-in main antenna* 󰽏 Charging terminals

Use when charging with the desktop holder.

* The antenna is built into the product. Covering the antenna

with your hand might affect communication quality.

◎ The back cover of the product is not removable.

Removing the back cover with force may cause damage or malfunction.

◎

The battery is built into the product and it is not removable. To force stop and reboot the product, refer to "Forcing the Product to Shut Down and Restart" (▶P. 22)

Page 11

Front Buttons

To make calls, display the home screen, and create mail more conveniently, the product has front buttons (A (phone button), Q (home button), T (mail button)) below the display. You can also press A/Q/T to wake the product from sleep mode. Pressing the buttons while in sleep mode displays the following.

: Activates the phone app.

: Displays the home screen.

: Displays the mail app selection screen.

• A flashes when a call is arriving and for missed calls. Press A while flashing to answer a call or check history.

• T flashes when au-mail or SMS is received. Press

while flashing and tap "auメール" / "SMS" to check

received mail.

About SMART SONIC RECEIVER

The product features a SMART SONIC RECEIVER, which relays sound by vibrating the display. The receiver does not have any holes, but can be used in a usual manner.

■ Touching to Your Ear

Hold the receiver area up to your ear as shown so that your ear is covered, blocking surrounding sound and increasing audibility. Move the product up and down, left and right to suit your hearing and surroundings.

Earpiece (receiver)

Getting Ready

◎ The front buttons can be made inoperable when the

display is turned off to prevent erroneous operation.

Mouthpiece (microphone)

Page 12

◎ Take care not to cover the mouthpiece (microphone) of

IC (metal) part

au Nano IC Card 04

◎ When commercially available earphones are connected,

◎ Do not cover the display with stickers or films

◎ Audibility depends on the individual. ◎ Audibility also depends on surroundings.

Getting Ready

the product with your fingers during a call.

voice sound can be switched to the one via earphones not using SMART SONIC RECEIVER.

(commercially-available protective films or privacy protectors). Doing so may affect audibility.

au IC Card

Your phone number etc. is recorded on the au IC card. The product is compatible with au Nano IC Card 04.

◎ Note that mishandling the au IC card might cause

malfunction or damage, be careful not to do the followings.

• Do not touch the IC (metal) part of the au IC card.

• Check the correct insert direction.

• Do not forcefully attach/remove the card.

◎ If the au IC card is not attached correctly or the au IC cad

has any abnormality, the error message is displayed.

◎ Do not lose the removed au IC card. ◎ Do not insert your au IC card with an conversion adapter

attached. Doing so may cause malfunction.

(Back) (Front)

Page 13

When au IC Card is Not Inserted

If the au IC card is not inserted, the following operations are unavailable. And "

• Making*/Receiving a call

• Sending/Receiving SMS

• Initial settings and sending/receiving for au-mail

• PIN code setting

• Checking your phone number and email address of the product

Besides the items above, necessary functions such as your phone number are also unavailable.

* Emergency calls such as 110 (Police), 119 (Fire and Ambulance) and 118

(Regional Coast Guard Headquarters) are unavailable. However, unless the signal strength is "out of range" in GSM/UMTS/LTE roaming area when you call, emergency calls are available. (Since emergency call numbers vary depending on countries, they may be unavailable.)

" appears on the status bar.

Setting Restriction on Use with a PIN Code

In using your au IC card, you can change the PIN code and lock the SIM card to restrict use by other persons and protect your valuable personal information (▶P. 71 "PIN Code").

Attaching/Removing au IC Card

■ Cautions on Attaching/Removing

• Attach/Remove the au IC card after turning off the product.

• When attaching/removing the au IC card, be sure to unmount the microSD memory card first.

Getting Ready

Page 14

■ Attaching au IC Card

• When installing your au IC card, be sure to use the supplied IC Card Tray Ejecting Tool (sample).

Turn the power off and open the card slot

cover

Hook the IC Card Tray Ejecting Tool

(sample) on the edge of the tray and pull

it out

IC Card Tray

Getting Ready

Ejecting Tool (sample)

Put the au IC card on the tray with the

3

position of the card's notch adjusted,

then insert the tray straight into the au IC

card slot (lower side)

After the tray is inserted, hook the IC Card Tray Ejecting Tool (sample) on the edge of the tray and press it all the way.

• Insert the card with the IC (metal) part facing up.

• To avoid the au IC card from getting onto the tray, do not insert it with excessive force. Do not apply excessive force and insert it all the way straight into the slot. If the tray does not fit into the slot, do not press it with force. Pull the tray out and insert it again with the front edge raised. The au IC card cannot be recognized if the card gets onto the tray.

Tray

microSD memory card slot (upper side)

au IC card slot (lower side)

Close the card slot cover

4

Notch

Edge of tray

Page 15

■ Removing au IC Card

• When removing your au IC card, be sure to use the supplied IC Card Tray Ejecting Tool (sample).

Turn the power off and open the card slot

cover

Hook the IC Card Tray Ejecting Tool

(sample) on the edge of the tray and pull

it out

IC Card Tray Ejecting Tool (sample)

Tray

Remove the au IC card, then insert the

tray straight into the au IC card slot (lower

side)

After the tray is inserted, hook the IC Card Tray Ejecting Tool (sample) on the edge of the tray and press it all the way.

microSD memory card slot (upper side)

au IC card slot (lower side)

Close the card slot cover

Edge of tray

Notch

Getting Ready

Page 16

Internal Shared Storage

The product can save data to the main unit memory and microSD memory card.

The main unit memory

microSD memory card

◎ Data may be saved to the main unit memory depending

Getting Ready

Save data that apps and each app use and media files such as images captured by screenshot.

Save media files, etc.

on some apps even if a menu or message is displayed.

Using microSD Memory Card

Attaching/Removing microSD Memory Card

■ Attaching microSD Memory Card

Open the card slot cover of the product

Conrm the direction of the microSD

memory card and slowly insert it into the

slot until it clicks

When inserting the card into the product, confirm the card is locked with snaps. Be aware that the card may fly out if you release your finger before the card is locked. Be careful about it.

au IC card slot (upper side)

microSD memory card slot (lower side)

Page 17

Close the card slot cover

◎ The microSD memory card has a back and front side/top

and bottom orientation. Trying to insert the card forcefully may cause the card to become permanently lodged or cause damage.

Removing microSD Memory Card

When removing the microSD memory card, always unmount the card first to prevent corruption of data (data erasure).

Home screen → [ツール (Tools)] →

[Settings] → [Storage] → "UNMOUNT" in

"SD card"

Open the card slot cover of the product

Slowly push the microSD memory card

toward the slot until it clicks

Pull out the microSD memory card with fingers on when you hear "click". Keep your fingers on while the microSD card comes out of the slot. Be aware that the card may fly out if you release your finger while pressing hard.

Slowly pull the microSD memory card

Slowly pull out the card as straight as possible. Depending on the microSD memory card, it is difficult to pull out from the slot due to the failure of unlocking. In that case, remove the card by pulling lightly with your fingers.

Close the card slot cover

Getting Ready

Page 18

◎

Do not touch the terminal part of microSD memory card.

◎ Do not pull out the microSD memory card forcefully.

Doing so might cause a fault or loss of data.

◎ After using the product for a long time, the removed

microSD memory card may become warm. This is not a malfunction.

Getting Ready

Charging

The internal battery is not fully charged at the time of purchase. Charge the battery before using the product. When the red light turns into green, the charging will be completed.

◎ The AC adapter and desktop holder are not water

resistant. Never charge the product if it becomes wet.

◎ The product may become warm while charging or during

other operations, this is not abnormal.

◎ When temperature of environment or the product is

extremely high or low, charging may be stopped. Charge the battery at room temperature as much as possible.

◎ Charging the product while using the camera function,

the charging time may take longer than usual.

◎ Doing various operations with the specified charger (sold

separately) connected, the battery life may get short due to the short time charging/discharging.

◎ Make sure the connection is correct if the charging light

of the product blinks in red. If the charging light continues to blink, immediately stop charging, and contact an au shop or Repair and Delivery Support Center.

◎ Keep a metal accessory or conductive materials (metal

pieces, pencil lead, etc.) from coming in contact with the connection terminal and prevent them from getting inside.

Page 19

Charging with a Specied AC Adapter

How to charge the product using Type C Common AC Adapter 01 (sold separately) is described here. For information on the specified AC adapter (sold separately), see "Related Accessories" (▶P. 83).

Connect the power plug of Type C

Common AC Adapter 01 (sold separately)

to an outlet (100V - 240V AC)

Insert the USB Type-C plug of Type C

Common AC Adapter 01 (sold separately)

straight into the external connection

terminal

Make sure that the charging light turns into red. When the battery power turns on, " bar. When charging is complete, the charging light turns into green.

" appears on the status

Getting Ready

Type C Common AC Adapter 01 (sold separately)

Page 20

When charging is complete, pull out the

USB Type-C plug of Type C Common AC

Adapter 01 (sold separately) straight from

the external connection terminal

Connect the power plug of Type C

Common AC Adapter 01 (sold separately)

to an outlet

◎ Note that applying unnecessary force with an external

Getting Ready

device connected to the external connection terminal may cause damage.

◎ When the battery is charged in the case that the batteries

run out, charging light may not turn to green soon, but charging is started.

Charging with the Desktop Holder

How to charge the product using the supplied desktop holder connected with Type C Common AC Adapter 01 (sold separately) is described here. For information on specified charging equipment (sold separately), refer to "Related Accessories" (▶P. 83).

Plug the USB Type-C plug of Type C

Common AC Adapter 01 (sold separately)

straight into the external device port on

the desktop holder

Insert it straight in the direction shown.

Type C Common AC Adapter 01 (sold separately)

Page 21

Connect the power plug of Type C

Common AC Adapter 01 (sold separately)

to an outlet (100V to 240V AC).

Type C Common AC Adapter 01 (sold separately)

Hold the product with its display

frontward, and place in the desktop holder

with the charging terminals downward

Make sure that the charging light turns into red. When charging is complete, the charging light turns into green.

Charging light

Desktop holder

Getting Ready

Page 22

When charging is complete, remove the

product from the desktop holder

Charging light

Getting Ready

Desktop holder

Remove the power plug of Type C

Common AC Adapter 01 (sold separately)

from the outlet

Charging with PC

How to charge the product connecting to USB port that supports PC charging with the USB Type-C cable (commercially available) is described here.

Connect the USB Type-C cable

(commercially available) to the USB

port of PC when the PC is completely

activated.

Insert the USB Type-C plug of the USB

Type-C cable (commercially available)

straight into the external connection

terminal

Make sure that the charging light turns into red. When charging is complete, the charging light turns

into green

• When a screen such as new hardware search appears on PC, select "Cancel".

Page 23

USB port of PC

When charging is complete, remove

USB Type-C cable (commercially available)

the USB Type-C cable (commercially

available) from the external connection

terminal and PC.

◎ When the battery is charged in the case that the batteries

run out, charging light may not turn to green soon, but charging is started.

◎ The charging time may take longer than charging with a

specified AC adapter. And the charging time also varies depending on your PC.

Turning the Power On/Off

Turning the Power On

Press and hold F (Power button) until

the charging light turns on

The start screen appears (▶P. 22).

• For the first time you turn on the product, the initial setting, "au Initial Setting" activates. You need to set as required. For details, refer to "Initial Settings" in the packaged "Setting Guide".

◎

When logos are being displayed on the screen, do not touch the screen because the initial setting of the touch panel activates. Doing so may prevent the touch panel from working properly.

◎ You can skip completing "au Initial Setting" when first

starting up the product and complete it later.

Turning the Power Off

Press and hold F (Power button) for at

1

least 1 second

[Power off] → [OK]

Getting Ready

Page 24

Forcing the Product to Shut Down

《

Start Screen

》

①

②

and Restart

You can force the product to power off and reboot when the screen does not respond, or the power cannot be turned off.

Press and hold F (Power button)

1

and r (Volume up key) for at least 11

seconds

◎ If you turn off the product forcibly and restart, an unsaved

Getting Ready

data will be lost. Do not perform except when the product does not respond.

Switching to English Display

Switch the language displayed on the screen to English.

Home screen → [ツール (Tools)] → [設定

1

(Settings)] → [言語と入力 (Languages & input)] → [言語 (Languages)]

[English]

The message "起動中のアプリ、メール送受信、ダウンロードなどが終了される場合があります。" (Apps, mail transmission/

reception, and downloads may be terminated.) appears, confirm the content and then tap [OK].

Start Screen

The start screen is displayed when you turn the product on or cancel the sleep mode.

Switching to the Home Screen from the Start Screen

You can switch to the home screen with the following operations when the start screen appears.

Slide the bottom of the screen to the left

1

The home screen appears (▶P. 28). Or, the previous screen which the product turns to sleep mode appears.

① Clock display ② Notications

不在着信などのお知らせを表示します。

Double-tap a notification to activate notified app.

•

Page 25

Sleep Mode

Press F (Power button) while the backlight is turned on or perform no operation for a certain period, the screen goes off temporarily and the product enters sleep mode. Doing the following operation, cancel the sleep mode.

In sleep mode, press F (Power button)

◎ To change the time to enter sleep mode, home screen →

[ツール (Tools)] → [Settings] → [Display] → [Sleep], and select the time.

◎ When you press F (Power button) to display the

screen in sleep mode, do not touch the screen. Doing so may prevent the touch panel from working properly.

Making Initial Settings

The first time you turn on the product after purchase, a screen for configuring initial settings appears. Follow the onscreen instructions to set functions.

• To skip any of the settings, tap "SKIP", "NEXT", etc., and follow the onscreen instructions.

Check that "English" is displayed and tap

1

[LET'S GO]

• Tap "日本語（日本）" , select "English", then the region.

Congure the product

You can copy your Google account, apps, and other settings from an Android terminal you already use.

Set a Wi-Fi® network

• If not using a mobile network or Wi-Fi® network, tap

[Don't use any network for setup] → [CONTINUE], enter a name, and go to step 5. Continue by following the onscreen instructions.

Congure your Google account

Congure your smartphone protection

Check your Google Service settings

Congure the Google assistant

Congure other settings

Getting Ready

Page 26

Check consent for location information

Congure "au Initial Setting" as required

󱫒

Setting an au ID

By setting an au ID, you can use various services provided by au such as "auかんたん決済" (au Simple Payment Service) which allows you to purchase applications available with au Smart Pass and Google Play.

Home screen → [ツール (Tools)] →

1

[Settings] → [au Settings Menu] → [au ID]

Getting Ready

Follow the onscreen instructions to set

an au ID

If you have already obtained an au ID, set the au ID you have. If you do not have an au ID, register a new one. Follow the onscreen instructions.

Making Initial Settings for au-mail

au-mail is a service allowing you to exchange au-mail between your cell phone and a PC.

• Product operation for using au-mail is subject to change without notice.

1

2 3 4

→ [au-mail]

Download au-mail. Follow the onscreen instructions.

Read the contents → [Agree]

[NEXT] [閉じる] (Close)

If a confirmation screen appears, follow the onscreen instructions.

Changing au-mail Address

1

2 3 4

→ [au-mail] → [

Address/Setting Filter] → [Eメールアドレスの変更へ] (Change e-mail address)

Enter the security code → [送信] (Send) [承諾する] (Accept)

Enter characters in the editable portion of au-mail address (before @) → [送信]

(Send) → [OK] → [閉じる] (Close)

] → [Change

Page 27

◎ In the editable portion of au-mail address, enter up to 30

singlebyte alphanumeric characters including ".", "-" and "_". Note that "." cannot be entered consecutively or used as the first or last character of the portion. "0" also cannot be used as the first character.

Getting Ready

Page 28

Basic Operations

Using Touch Panel

The product's display is a touch panel that can be used by touching directly.

• Operating the touch panel in the following ways may cause no response or misoperation.

- With gloves on

- With fingernails

- With something placed on the screen

- With films (commercially-available protective films or

privacy protectors) or stickers on touch panel

- With water droplets or condensation on the display

- With wet or sweaty fingers

Basic Operations

- Under water

■ Tap/Double-tap

Lightly touch a screen and then immediately release your finger. Tapping a screen twice in the same position is called double-tap.

■ Long-touch

Keep touching an item.

■ Slide

When content is partially hidden, lightly touch the screen and slide in the desired direction.

■ Flick

Touch the screen and flick up/down/ left/right.

Page 29

■ Zoom in/Zoom out

home screen

With two fingers on the screen, widen your fingers (zoom in) or close them (zoom out).

■ Drag

To move an item, icon, etc., lightly touch the screen and slide it to the desired position.

Using Touch Keys

The following touch keys are displayed at the bottom of the screen.

Display Description BACK Returns to the previous screen. CAPTURE Saves an image of the currently displayed

RECENTS Opens the recent apps screen.

screen (screen shot). ▶P. 35 "Using Screen Memo"

Home Screen

Home screen consists of several screens, and can be toggled by sliding/flicking left or right. Press Q to display the main home screen.

Main

Basic Operations

Page 30

Using the Home Screen

《

Home screen (time of purchase)

》

In addition to the layout at time of purchase of icons in the home screen, you can also select from "Basic" and "For beginner" layouts. The home screen is arranged as follows at the time of purchase.

① ②

③

④

Basic Operations

④

⑤ ⑥

Main home screen

① Status bar ② Quick search box ③ Time/weather/step count ④ Applications/folders

Icons/folders for pre-installed applications are

displayed.

⑤ Direct buttons ⑥ Indicator

④

◎ In this manual, operations from the default home screen

layout are explained.

Main Apps/Folders on the Home Screen

Frequently used apps are displayed on the home screen. Other apps are organized in folders. Select an app/folder to use by sliding/flicking the home screen right to left.

Icon name

Phone

Enter a phone number and make a call from the call history.

Mail

au-mail*

This is a service to send/receive mails using (@ezweb. ne.jp) address.

SMS

This is an app to exchange messages by au phone number.

Camera

Capture still images/movies.

サービスTOP (Service TOP)

This App provides daily news, coupon and special information for au users.

Page 31

Icon name

Play Store

Search for and install apps.

Google

Search within the product and Web pages by keyword.

Chrome

View Web pages.

Gmail

This is a mail service provided by Google.

Maps

Display your current location, and search for other locations and routes.

YouTube

Play movies and search for movies by keyword input.

Drive

View/edit files saved to Google Drive.

Play Music

Play music and play lists.

Play Movies & TV

Rent movies at Google Play and watch saved movies.

Duo

This is Google instant messaging service.

Photos

Display/edit captured images and movies, and back up to Google+™.

Voice Search

Use Google Voice Search.

Icon name

Internet

Use the Internet.

Contacts

写真/動画 (Photos/Movies)

Photos/Movies

Display a list to play photos/videos in internal storage/ microSD memory card. Manage photos/videos in albums.

Screen Memo

Save an image (screen shot) of the currently displayed screen or view a saved image.

Alarms

Use alarms.

Calculator

Use Calculator.

Calendar

Use a calendar.

Notepad

Use a notepad.

Pedometer

Use the pedometer.

ウォーキング (Walking)

This app increases motivation for those wanting to walk for their health.

Device Checkup

Pass the supplied Checkup card over the product to activate a smartphone checkup and check the condition of the product.

Basic Operations

Page 32

Icon name

Video for mastering

View a video on how to use the product.

使い方練習 (Practice using the product)

Practice operating your smartphone.

Show Notification

Open the notification panel.

テレビde写真 (Photos on TV)

Display photos, etc. saved to the product wirelessly on TV by connecting a テレビde写真 (Photos on TV) receiver (sold separately) to a TV.

Family Album Mitene

Easily share and organize photos and videos you captured. Enjoy sharing with family how everyone has grown.

Simple settings

Configure basic settings.

Basic Operations

Inquiry

Make an inquiry to au.

My au

You can check your daily usage, points and monthly billing of au services with this application. You can also change your rate plan, apply for optional services and so on.

ツール (Tools)

Infrared

Send/receive data using the infrared communication.

Sound Recorder

Use Sound Recorder.

Use a notepad.

Icon name

Timer

Use a timer.

StopWatch

Use a stopwatch.

Flashlight

Use the Flashlight.

World Clock

Use world clocks.

Eco Mode

Set to minimize the battery consumption.

File Commander

View, copy/move data.

OfficeSuite

View files such as Word, Excel.

Downloads

Manage downloaded data.

Settings

Set and manage various functions from the setting menu.

au Wi-Fi Connect

It is an application to conveniently assist connection to au's publicly available wireless LAN service, "au Wi-Fi SPOT" and au's indoor Wi-Fi router, "Wi-Fi HOME SPOT".

Weather

Check weather information for the current location and area that you set.

Page 33

Icon name

コミュニケーション (Communication)

Facebook

Facebook is a free app by registration of real names to keep up with your friends - to see what they're up to, share updates, photos, and videos, and chat and have group conversations.

Messenger*

Messenger is a free app to instantly reach the people in your life with messages (text and voice), group and video chats, calls. Can also send photo, videos, and stickers.

Instagram*

Instagram is an app that lets you easily connect with your family, friends and people around the world through sharing photos and videos.

Twitter

Twitter is a free app that lets you connect with people, express yourself, and discover more about all the things you love.

auサービス (au Services)

auスマートパス (au Smart Pass)

au Smart Pass Premium and au Smart Pass is one of the most wonderful apps which provides you an enjoyable, safe and practical Smartphone Life.

ニュースパス (News Pass)

News curation app.

au Market

You can install Android-based applications offered with au Smart Pass service.

Icon name

au WALLET

"au WALLET App" is useful for the user of au. When you use it, you can do the following things.

• au WALLET points you have

• information of "au Easy Payment" In addition, when you use au WALLET Prepaid card and Credit card, you can do the following things.

• benefits of au WALLET cards [au WALLET Prepaid card]

• charging the card

• checking its inquiry [au WALLET Credit card]

• checking billing statements

• purchase history, and so on

au WALLET Market

au WALLET Market is a service that allows you to buy "uncompromising products" via e-commerce and au shops. It also helps you become a better shopper by easily finding fine products through internet and shops.

Wowma! for au

On Wowma Mobile App, you can enjoy the online shopping and find more than 28 million of products from apparel, electronics, housewares, furniture and grocery & gourmet food.

Player (LISMO)

Music Player makes Uta Pass APP more powerful and useful.

Basic Operations

Page 34

Icon name

サポート (Support)

取扱説明書 (Instruction Manual)

This app allows you to check detailed instructions installed in the product.

Kyocera site

Check detailed product instructions with video and images.

Data Storage App

You can back up various data in your smartphone to cloud storage or SD card. You can also migrate your data between your phones with this app.

あんしんフィルター for au (Anshin filter for au)

This is an application which limits the access to the inappropriate applications and web pages so that your child can use a device safely.

故障紛失サポート (Repair and Delivery Service)

Basic Operations

This app provides total support for customers whose smartphones are troubled. (in Japanese only)

au Disaster Measures

This is an application in which you can use Disaster Message Board, Emergency Rapid Mail (Earthquake Early Warning and Disaster and Evacuation Information and Tsunami War ning and Emergency Warning) and Disaster Voice Messaging Service.

* Downloading/installing is required to use.

◎ Using the function from each app may incur

communication charges depending on the function.

◎ In addition to apps listed here, those you have already

been using or have subscribed for may be displayed.

◎ Icon names are subject to change without notice.

Activating the Apps

Some functions activated by tapping app icons may incur communication charges.

Home screen → Tap an app/folder to

activate

• If you tap a folder, tap an app to activate from the app list in the folder.

Page 35

Monitoring the Product's Status

Viewing Icons

Notification icons for missed calls, new mail, and running operations are displayed on the left of the status bar, and status icons for product status are displayed on the right.

■ Main Notication Icon

Icon Description

Missed call New mail message (SMS) New mail message (au-mail) New mail message (Gmail) Emergency rapid mail Snooze alarm or alarm ended without canceling Notification of calendar Music (Player (LISMO)) During a call or receiving a call High audio quality call with a device supporting au VoLTE Answering memo Internal memory low File receiving request from other Bluetooth® device Send/upload data

Icon Description

Receive/download data Installed completely Notification of updating installed apps Software update USB tethering Wi-Fi® tethering Bluetooth® tethering Wi-Fi® tethering or Bluetooth® tethering is used with USB tethering Screenshot completed microSD memory card is mounted

■ Main Status Icon

Icon Description

Time Battery level

100%/ empty/ charging

Signal strength/Signal condition (LTE/WiMAX 2+)

level 4/ out of range/ in communication

LTE/WiMAX 2+ available*/ roaming

(Communication mode according to the

network is also shown) Airplane mode is set SIM card uninserted

Basic Operations

Page 36

Icon Description

Wi-Fi® signal strength

level 4/ level 0 Alarm setting Silent mode (Vibrate) Silent mode (Mute) Silent mode (Drive) Bluetooth® function in use

standby/ connected Answering memo set

Answering memo: set/ full NFC (Checkup) in use VPN connection GPS in use

Basic Operations

* The 2 networks, "LTE" and "WiMAX 2+", are available in Japan.

Date saver set

In any case of the screen display is "4G". The Company determines the network less congested to connect due to busy network conditions.

Notication Panel

In the notification panel, you can check notifications and activate apps. Also, frequently used functions can be set ON/OFF immediately.

Slide down the status bar

The notification panel is displayed.

◎ To hide the notification panel, tap "CLOSE" or slide the

notification panel up.

◎ To delete notifications, flick the notifications left/right. Tap

"CLEAR ALL" to delete all notifications.

Checking Your Phone Number

Home screen → [ツール (Tools)] →

[Settings] → [Prole]

The Profile screen appears.

Page 37

Setting Silent Mode

Silent Mode Setting Screen

》

Set to the Silent mode so as not to disturb others around you in public places.

Press and hold l (Volume down key)

1

for at least one second

• The Silent mode is set/canceled.

Changing Silent Mode Type

Press

down key) when the Silent mode is set

[Vibrate] / [Mute] / [Drive]

• Pressing l (Volume down key) changes the Silent mode type.

(Volume up key)/l (Volume



Setting Airplane Mode

When Airplane mode is set to ON, wireless functions are disabled (telephone, data communication, wireless LAN

), Bluetooth®).

(Wi-Fi

Press and hold F (Power button) for at

1

least 1 second → [Airplane mode]

When Airplane mode is set to ON, " " appears in the status bar.

• Alternatively, from the home screen → [ツール (Tools)] → [Settings] → [More] → Turn the Airplane mode to "ON" to set the Airplane mode.

Using Screen Memo

You can tap "CAPTURE" at the bottom of the screen to save an image (screen shot) of the currently displayed screen or view a saved image.

Capturing a Screen Memo

In a screen you want to capture,

1

[CAPTURE]

[Save this screen]

The displayed screen is saved.

Basic Operations

Page 38

Checking Screen Memos

Home screen → [写真/動画 (Photos/

1

Movies)]

[Screen Memo] → Tap a screen memo

The screen memo is displayed.

◎ To delete a screen memo, display the screen memo and

select [MENU] → [Delete] → [OK].

Setting Direct Buttons

You can register people you call frequently to the (direct

Basic Operations

buttons) at the bottom of the home screen to make calling simple.

• Register numbers and mail addresses beforehand to Contacts.

• People you registered are displayed under the buttons.

Home screen → Tap an unregistered

1

direct button

[ADD] → Tap a person to register

Using Direct Buttons

■ Calling with the Direct Buttons

Tap a registered direct button in the home

1

screen

[PHONE] → Talk

[END CALL]

■ Sending Mail/SMS with the Direct Buttons

Tap a registered direct button in the home

1

screen

[EMAIL] → Enter subject/text → [送信

(Send)]

■ Sending SMS

[SMS] → Enter text → [SEND]

Page 39

Character Entry

Use the software keyboard to enter characters. The software keyboard appears when an entry field is selected on a character entry screen to save a contact, create a mail, etc.

Switching Software Keyboards

Available software keyboards are as follows.

Keitai input

Standard input

■ Switching from keitai input to standard

input

1

■ Switching from standard input to keitai

input

1

Enter characters with a keitai-type 10-key keyboard, cursor key, and function display.

Keys are arranged in the same order as conventional computer keyboards. Select from 10-key, QWERTY, and 50-key keyboards.

Keitai input screen → [MENU] → [Standard input]

Smartphone input screen → [設定 (Settings)] → [Keitai input]

Character Entry Screen Layout

①

②

③

④ ⑤

⑧ ⑧

Character Entry Screen (QWERTY)

《

① Character entry field ② Normal conversion candidate list / predictive

conversion candidate list

Predictive conversion candidates appear as characters

are entered.

" to expand the candidates display area. Tap

• Tap " " to return to the original display.

③ Software keyboard ④ Shift key

Tap to switch between small characters, big characters

(lock), and big characters.

You can tap this when entering full-width numeric /

half-width numeric in QWERTY keyboard to change enterable symbols.

⑥ ⑦

》

Basic Operations

Page 40

⑤ Input mode key

Switch character input modes. Tap to display the next character in green and toggle

the input mode.

あ: Hiragana/Kanji A: Half Alphabet 1: Half Numeric

⑥ Delete key ⑦ OK key or Enter key

: Confirm the entry. : Insert a line break at the cursor position.

• Display changes depending on the app and current item being entered.

⑧ Cursor keys

◎ If you cover the screen by your face etc. while dialing/

calling, the display turns off for preventing false operation.

◎ Note that even if you cover the microphone, the sound

can be conveyed to the other party.

Receiving a Call

Incoming call screen →

The call starts.

Talk → [END CALL]

Making a Call

Basic Operations

→ "DIALPAD" tab

The phone number input screen is displayed.

Enter a phone number

When calling to fixed-line phones, enter the area code first even if the recipient is in the same city.

[CALL] → Talk → [END CALL]

Press r (Volume up key)/l (Volume down key) during a call to adjust volume (other party's voice).

Setting Step-up Ring Volume

Set to notify by a stepped-up ring when receiving a call within 10 minutes from the same number.

Home screen → [ツール (Tools)] →

[Settings] → [Call] → Turn [Step-up ring

volume] "ON"

• It is set to ON at the time of purchase.

Page 41

Displaying Menu

There are two types of methods to display a menu screen; by tapping "MENU", " field or item.

"or " " and by long-touching entry

Setting Home Screen

Switch the home apps of the product.

Home screen → [Simple settings] →

[Home Screen]

The home screen menu is displayed.

Sort apps Rearrange apps, folders, and

Home layout pattern settings

Direct button settings

Add widgets Add widgets to the widget screen. Edit widget

screen Delete shortcut Delete shortcuts.

shortcuts in the home screen. Change the arrangement of the home

screen. ▶P. 36 "Setting Direct Buttons"

Move or delete widgets.

Saving Battery Consumption

Use "Eco Mode" to set sleep time of backlight, screen brightness etc. so that you can save the battery power. When the battery power is low, set "Data communication" to OFF and limit communications only for calling to extend available

time

Home screen → [ツール (Tools)] → [Eco

Mode] → [ON] / [OFF]

• Tap [MENU] → [Detail set] to customize functions

restricted by Eco Mode.

Basic Operations

Page 42

Using the Camera

Slide the camera slide cover down

Slide down

Camera

Basic Operations

button

3

/ [Shoot]

Captured data is saved automatically.

• You can also navigate home screen → [Camera] to

• Activating the camera with the camera slide cover

Tap the screen

2

The camera focuses where you tapped.

• Long-touch the monitor screen or half-press k to

Camera".

activate

closed causes an alert to appear. Open the camera slide cover to display the shooting screen.

lock focus.

Page 43

Safety Precautions

When Using the Product

• Before you start using the product, make sure to read the "Safety Precautions" in this manual to ensure correct use.

• Before you assume that the product is malfunctioning, perform "トラブル診断 (Trouble check)". (Displayed language is Japanese only.)

Home screen → [サポート (Support)] → [故障紛失サポー

ト (Repair and Delivery Service)] → [トラブル診断 (Trouble

diagnosis)] (Displayed language is Japanese only) or, check for possible remedies in the following site "トラブル診断" (Japanese) of au homepage:

https://www.au.com/trouble-check/

• Communication is not possible even inside the service area in places where the signal does not reach (e.g. tunnels and basements). Also, communication may not be possible in poor reception areas. Communication may be interrupted if you move into a poor reception areas during communications.

• Since this product uses radio waves, the possibility of communication intercepts by third parties cannot be eliminated (though the LTE/WiMAX 2+/GSM/UMTS system has highly secure confidential communication features).

• VoLTE (LTE network) by au is used when connecting with emergency call receiving agencies within Japan. You cannot connect using 3G (circuit-switched network).

• The product is compatible with au World Service. Each network service described in this manual varies depending on the area and service content.

• Since the product is a radio station under the Radio Law, you may be asked to temporarily submit the product for inspection in accordance with the Radio Law.

• The IMEI information of your cell phone is automatically sent to KDDI CORPORATION for maintenance and monitoring operational status of your cell phone.

• If you are using the product overseas, check the relevant laws and regulations of the country/region you visit beforehand.

• The Company is not liable for any damages arising from earthquakes, lightning, storms, floods or other natural disasters, as well as fires, actions by third parties, other accidents, intentional or mistaken operation by the customer, or use under other unusual conditions outside the responsibility of the Company.

• The Company is not liable for any incidental damages (change/disappearance of described content, loss of business income, disruption of business, etc.) arising from use or inability to use the product.

• The Company is not liable for any damages arising from failure to observe the described content of this manual.

Safety Precautions

Page 44

• The Company is not liable for any damages arising, for example, from malfunction caused by combination with connected devices or software not related to the Company.

• Captured image data or downloaded data may sometimes be altered or lost due to faults, repair or other handling of the product. The Company is not liable for any damage or lost income resulting from recovery of these data.

• It is recommended you keep a copy of important data in your PC's hard disk, etc. Whatever the cause of the defect or malfunction may be, the Company assumes no responsibility for alteration or loss of saved data.

• Contents saved in the product, such as contacts, mails and favorites, might be altered or lost by an accident, fault, repair or mishandling. Be sure to keep a copy of important contents. Note that the Company assumes no responsibility for any damages or lost profits resulting from altered or lost contents.

Safety Precautions

• Note that content data (both charged or free content) saved on the product cannot be returned to the customer when the product is replaced for repair of a fault, for example.

• The product uses liquid crystal for its display. The main display response speed may become slow when the ambient temperature is low, which is due to the characteristics of liquid crystal and is not a malfunction. The main display response speed will return to normal at room temperature.

• Although the display used on the product is made using high-precision technology, some pixels (dots) might be lit or out at all times. This is not a malfunction.

• You are recommended to store copies of individual data such as photos/movies you took and music in your PC by sending each file as mail attachment, etc. Note, however, that you may not be able to make copies of some copyrighted data even by the above-mentioned means.

• Do not discard the product together with regular trash. Please cooperate in the collection of the product when the product is no longer needed to protect the environment and effectively use resources. The product (including optional parts) is collected at au shops and other places.

* "The Company" as appears in this manual refers to the following

companies:

Sold by: KDDI CORPORATION・OKINAWA CELLULAR TELEPHONE

COMPANY Manufactured by: KYOCERA Corporation

◎ Reproduction of the content of this manual in part or in

whole is prohibited.

◎ The content of this manual is subject to change without

notice.

◎ Every effort has been made in the preparation of this

manual. Should you notice any unclear points, omissions, etc., feel free to contact us.

Page 45

Safety Precautions (Observe Strictly)

DANGER

WARNING

CAUTION

■

Before using the product, thoroughly read this "Safety Precautions" for proper use.

■ These precautions are intended to protect you and

others around you. Read and follow them carefully to avoid injury, damage to the product or damage to property.

■ The signs below differentiate between the levels

of danger that can occur if the product is not used within the specied guidelines.

This sign denotes that "death or serious injury from improper use".

This sign denotes that "death or serious injury improper use".

This sign denotes that "minor injury may result from improper use".

*1 Serious injury: This refers to loss of sight, injury, burns (high- and low-

*2 Minor injury: This refers to injuries, burns (high- and low-temperature),

*3 Physical damage: This refers to extended damage to buildings, furniture,

temperature), electric shock, broken bones, injuries with residual aftereffects from poisoning, etc., and injuries requiring hospital admission for treatment or long term hospital attendance as an outpatient.

electric shock, etc. that do not require hospital admission for treatment or long-term hospital attendance as an outpatient.

livestock, or pets.

may directly result

may result from

or damage to property*3

■ Explanation of Graphic Symbols Used

in This Manual

Indicates an action that is not allowed.

Indicates that disassembly is not allowed.

Indicates that use in a place where the product is likely to get wet or allowing the product to get wet is not allowed.

Indicates that handling with wet hands is not allowed.

Indicates an action based on instructions that must be done.

Indicates that the power plug must be disconnected from the power outlet.

Safety Precautions

Page 46

■

DANGER

Precautions Common to the Main Unit, Internal Battery, Charger, au IC Card, KYOCERA TV Antenna Cable 04, IC Card Tray Ejecting Tool (Sample), Peripheral Devices

Do not use, store or leave the product in hot places (e.g. by the re, near a heater, under a kotatsu or futon, in direct sunlight, in a car in the hot sun).

Doing so may cause fire, burns, injuries, or electric shock.

Do not put the product into or near a heating cooking device such as a microwave oven or IH cooker, or high-pressure container such as a pressure cooker.

Doing so may cause fire, burns, injuries, or electric

Safety Precautions

shock.

Do not put sand, dirt, or mud on the product or put it on them directly. Do not touch the product with hands to which sand or others adhere.

Doing so may cause fire, burns, injuries, or electric shock. For details on water/dust resistance, refer to the following. ▶P. 62 "Notes on Water and Dust Resistance"

Do not charge when the product is wet with water (drinking water, perspiration, seawater, urine of pet animals, etc.).

Doing so may cause fire, burns, injuries, or electric shock. For details on water resistance, refer to the following. ▶P. 62 "Notes on Water and Dust Resistance"

Do not subject the product to strong pressure or break the product. Especially when bringing the product putting in a pocket of clothes, do not let the product hit against surroundings or being put between the objects.

Doing so may cause fire, burns, or injury due to battery damage. * Examples to avoid

・ Sitting or squatting with the product put in a pocket of

trousers or skirt

・ Putting the product in a pocket of outer wear and catching

them in a door or a door of car

・ Stepping on the product on a soft object such as a sofa,

bed, or bedding, or on a floor

Do not disassemble or modify in that manner.

Doing so may cause fire, burns, injuries, or electric shock.

Do not let the product get wet with water (drinking water, perspiration, seawater, urine of pet animals, etc).

Doing so may cause fire, burns, injuries, or electric shock. For details on water resistance, refer to the following. ▶P. 62 "Notes on Water and Dust Resistance"

Page 47

Do not put water (drinking water, perspiration,

WARNING

seawater, urine of pet animals, etc.) into the charging terminal or the external connection terminal.

Doing so may cause fire, burns, injuries, or electric shock. For details on water resistance, refer to the following. ▶P. 62 "Notes on Water and Dust Resistance"

Use the optional products specied by au.

Not doing so may cause fire, burns, injuries, or electric shock.

Do not drop, trample, or throw the product or give a strong force or vibration to it.

Doing so may cause fire, burns, injuries, or electric shock.

Do not allow conductive materials (metal pieces, pencil lead, etc.) to come in contact with the charging terminal or the external connection terminal, and do not allow dust to get inside.

Doing so may cause fire, burns, injuries, or electric shock.

Do not cover or wrap the product with bedding, etc. while using or charging the product.

Doing so may cause fire or burns.

If charging is not completed after the specied charging time, stop charging.

Overcharging may cause fire, burns, or injuries.

Make sure to turn off the product or stop charging before you get close to places like a gas station where a ammable gas or dust can be generated.

Using the product in places where a flammable gas can be generated may cause an explosion or fire.

Perform the following operations while using, charging, or keeping the product if there are odors, noise, smoke, overheating, discoloring, deformation, or other abnormalities.

・ Remove the power plug from the wall outlet. ・ Turn the product off.

Not doing the above operations may cause fire, burns, injuries, or electric shock.

Safety Precautions

Page 48

CAUTION

Do not use the damaged product.

DANGER

Doing so may cause fire, burns, or injuries.

Do not leave the product on unstable or sloping surfaces. Be careful especially when the product is set to vibrate.

The product may fall and cause injuries.

Do not use or store the product in humid or dusty places, or places that get hot.

Doing so may cause fire, burns, or electric shock. For details on water/dust resistance, refer to the following. ▶P. 62 "Notes on Water and Dust Resistance"

When children use the product, do not let them use incorrectly without instruction by an adult for proper use.

Doing so may cause injuries.

Safety Precautions

Do not store the product within the reach of small children.

Doing so may cause accidental swallowing, injuries, or electric shock.

Be careful when using the product continuously for a long time or charging as it gets hot. Also, avoid touching the product for a long time by falling asleep unintentionally.

The product or specified charger (sold separately) may become hot when using for a long time such as applications, calling, data communication, watching videos, or while charging. Depending on your physical predisposition and physical condition, contacting with a high temperature part may cause skin redness, itching, rash, or low-temperature burns.

■ Main Unit

Do not throw the product into re or apply heat.

Doing so may cause fire, burns, or injuries.

Do not apply excessive force such as sticking a nail into the product, hitting it with a hammer, or stepping on it.

Doing so may cause fire, burns, or injuries.

If the substance inside the main unit comes into contact with your eyes or mouth, immediately rinse the area with clean water, and then see a doctor right away.

Not doing so may cause loss of sight or poor physical condition due to the influence of the substance, etc. inside the main unit.

Page 49

WARNING

Do not send data by infrared communication with the infrared port pointing toward eyes.

Doing so may adversely affect on eyes.

Do not operate to point the infrared port toward some other infrared household appliance when using infrared communication function.

Doing so may cause an accident, etc because of malfunction of infrared device.

Do not light or ash the lighting part of the light close to person's eye. Be especially careful to keep a sufficient distance from small children.

Not doing so may cause vision disturbance. Also, it may cause an accident such as injuries due to dizziness or startling.

Do not light or ash the light to point at the eyes of someone driving a car etc.

Doing so may interfere with driving and cause an accident.

Do not watch a repeatedly ickering screen for a long time.

Doing so may cause muscle spasms or loss of consciousness, etc.

Do not allow water or other liquids (drinking water, perspiration, seawater, urine of pet animals, etc.), metal pieces, ammable material or foreign object into the au IC card/microSD card slot on the product. Do not mistake the place and direction of the au IC card or the microSD memory card.

Doing so may cause fire, burns, injuries, or electric shock.

Do not expose the camera lens to direct sunlight for an extended period.

Doing so may cause fire, burns, or injuries by the lightcollecting mechanism of the lens.

Turn off the product or set it to Airplane mode before going aboard an airplane.

Since using the product on airplanes is restricted, follow the instructions given by the respective airlines. The product's signals may adversely affect on-board electronic equipment. If you commit a prohibited act while using the product on an airplane, you might be punished by law.

Follow the instructions given by the respective medical institution regarding the use of the product in a hospital.

Turn off the product in areas where the use of the product is prohibited. The product's signals may affect electronic equipment and electronic medical equipment.

Safety Precautions

Page 50

Safety Precautions

When using the handsfree call, ringtone is ringing, or in the standby mode, be sure to keep the product off of the ears. Also, when playing games, video, or music with an earphone microphone connected to the product, adjust the volume to the proper level.

When using the handsfree call, loud noise sounds from the product. Even in the standby mode, ringtone and vibrator may work suddenly. Using continuously for a long time with too loud volume may cause a hearing loss, etc. And, if you cannot hear the sound around you clearly, it may cause an accident.

If you have a weak heart, be careful when setting the ringtone vibration and incoming volume.

Sudden ringtone vibration and ringtone surprise you, it may cause harmful effect on heart.

To use electronic medical equipment, check with electronic medical equipment manufacturer or vendor to determine how devices are affected by radio waves before using.

Not doing so may cause harmful effect on electronic medical equipment etc.

Turn the product off near high-precision electronic control equipment or electronic equipment using low-power signals.

Not doing so may cause the equipment to fail or malfunction. * Examples of electronic equipment to avoid A hearing aid, an implanted pacemaker, an

implanted cardioverter-defibrillator, other electronic medical equipment, or other automatic control devices, etc. To use an implanted pacemaker, an implanted cardioverter-defibrillator, or other electronic medical equipment, check with electronic medical equipment manufacturer or vendor to determine how devices are affected by radio waves before using.

When the display or camera lens is accidentally broken, be careful of broken glass or exposed internal parts of the product.

Not doing so may cause burns, injuries, or electric shock with damaged parts or exposed parts.

If the internal battery leaks or gives off a strange smell, immediately discontinue use and remove the product from the vicinity of open ames.

Not doing so may cause leaking fluid to ignite or explode.

Be careful not to let your pet bite the product.

May cause internal battery to ignite, burst, heat, or leak, and may cause fire, burns, or injuries.

Page 51

CAUTION

Do not swing the product around by holding the KYOCERA TV Antenna Cable 04, strap, etc.

Doing so may cause injuries or other accidents.

If the display breaks and the uid etc. leaks out from inside, do not let the uid contact with the skin on your face or hands or clothes.

Doing so may cause eye or skin problems. If the substance inside the display comes into contact with your eyes or mouth, or on skin or clothes, immediately rinse the area with clean water. If the fluid etc. enters your eyes or mouth, immediately see a doctor after rinsing.

Do not discard the old product together with regular trash.

Doing so may cause fire, burns, or injuries. Also, may cause environmental disruption. Bring them to a sales outlet such as au Shop. If your local municipality has a battery recycling program, dispose of them as provided for.

If uid etc. leaks out from the internal battery, do not let the uid contact with the skin on your face or hands, or clothes etc.

When removing the au IC card, be careful with the tip of the IC Card Tray Ejecting Tool (sample) not to injure yourself (ngers, etc.).

Touching the tip of the IC Card Tray Ejecting Tool (sample) may cause injuries.

To use the product in car, check with automobile manufacturer or dealer to determine how vehicle devices are affected by radio waves before using.

In rare cases, using the phone in some vehicle models can cause the vehicles electronic equipment to malfunction. In that case, stop using the product immediately.

If you develop skin problems, stop using the product immediately, and see a doctor.

Itching, rashes, eczema, etc. sometimes occurs depending on your physical constitution and condition. For material of each part▶P. 54 "Material List"

When opening/closing the camera slide cover, take care not to get your nger or any other part of your body caught.

Doing so may cause injuries.

Make sure that there are no adhered metal pieces (cutter blade, staples, etc.) as the speaker and out camera (lens) of this product use parts that are magnetic.

Adhered metal pieces may cause injury.

Safety Precautions

Page 52

Use the product in a well-lighted area and put

WARNING

some distance between you and the display when watching the display.

Using the product in dark places or near eyes may affect your vision.

■ Charger

Do not use if the cord of the specied charger (sold separately) is damaged.

Doing so may cause fire, burns, or electric shock.

Do not use the specied charger (sold separately) and desktop holder in a humid place such as a bathroom.

Doing so may cause fire, burns, or electric shock.

Do not touch the specied charger (sold separately) if you hear thunder.

Safety Precautions

Doing so may cause electric shock.

Do not short the charging terminal while it is connected to an outlet. Do not allow any part of your body such as your hands or ngers to come into contact with the charging terminal.

Doing so may cause fire, burns, or electric shock.

Do not place heavy objects on the cord of the specied charger (sold separately), or do not pull the cord with excessive force.

Doing so may cause fire, burns, or electric shock.

When you plug/unplug the specied charger (sold separately) into/from the outlet, do not contact metal straps or other metal objects with the jack.

Doing so may cause fire, burns, or electric shock.

Do not connect a transformer for overseas travel (travel converter) to the specied charger (sold separately).

Doing so may cause ignition, overheating, or electric shock.

Do not apply excessive force on the connection part with the specied charger (sold separately) connected to the product.

Doing so may cause fire, burns, injuries, or electric shock.

Do not use an AC adapter for use abroad (travel converter).

Doing so may cause ignition, overheating, electric shock, etc.

Do not touch the cord, charging terminal, power plug of the specied charger (sold separately), or desktop holder with wet hands.

Doing so may cause fire, burns, or electric shock.

Page 53

Use the product at the specied power supply

CAUTION

voltage. When charging the product overseas, use the specied charger (sold separately) for global use.

Incorrect power supply voltage may cause fire, burns, or electric shock. AC adapter : 100 V AC (Connect to an AC outlet for internal household use) AC adapter for global use : 100 V AC - 240 V AC (Connect to an AC outlet for internal household use)

Wipe off dust on the power plug.

Not doing so may cause fire, burns, or electric shock.

Fully plug the specied charger (sold separately) into the outlet.

Not doing so may cause fire, burns, or electric shock.

When you disconnect the power plug from an outlet, do not pull the cord of the specied charger (sold separately) with excessive force. Instead, grasp the adapter to disconnect.

Pulling the cord of the specified charger (sold separately) may damage the cord and cause fires, burns, electric shock, etc.

When plugging/unplugging the specied charger (sold separately) into/from the product, do not pull the cord with excessive force. Instead, plug/unplug it straightly toward the jack to connect.

Not doing so may cause fire, burns, injuries, or electric shock.

Stop using the product immediately if you notice deformation of the charging terminal. Also, stop using the product after recovering the original form of the terminal.

Short-circuiting of the charging terminal may cause fire, burns, injuries, or electric shock.

When the specied charger (sold separately) is not to be used for a long time, disconnect the power plug from the outlet.

Not doing so may cause fire, burns, or electric shock.

Immediately remove the power plug from the outlet if water or other uids (beverage, perspiration, seawater, urine of pet animals, etc.) get on the adapter.

Doing so may cause fire, burns, or electric shock.

Always remove the power plug from an outlet when cleaning the equipment.

Not doing so may cause fire, burns, or electric shock.

Do not touch the specied charger (sold separately) for a long time when connected to an outlet.

Doing so may cause burns.

Safety Precautions

Page 54

■ au IC Card

CAUTION

WARNING

CAUTION

Be careful of the cut surface when handling an au IC card as it may damage a part of your body such as ngers, etc.

The cut surface may be sharp, and it may cause injuries.

■ KYOCERA TV Antenna Cable 04

The KYOCERA TV Antenna Cable 04 is not water resistant. Do not expose to water or other liquid. Never use where directly exposed to water, pet urine, etc., in humid environments such as bath rooms, or with wet hands.

Doing so may cause overheating, fire, electric

Safety Precautions

shock, or short-circuiting, or corrosion resulting in malfunction.

Do not let dirt adhere to the plug of the KYOCERA TV Antenna Cable 04.

Doing so may cause malfunction.

Insert/remove the plug of the KYOCERA TV Antenna Cable 04 straight in/from the earphone microphone terminal.

Not doing so may cause malfunction.

Remove the KYOCERA TV Antenna Cable 04 when not viewing TV.

Making calls, etc. with the KYOCERA TV Antenna Cable 04 still attached may allow it to hit yourself, others, or surrounding objects, causing injuries or other accident.

If use of the KYOCERA TV Antenna Cable 04 causes any skin abnormality, immediately discontinue use and see a doctor. Itching, rashes, eczema, etc. sometimes occur depending on your physical constitution and condition.

For material of each part ▶P. 54 "Material List"

Page 55

■ IC Card Tray Ejecting Tool (Sample)

WARNING

CAUTION

WARNING

The tip part of IC Card Tray Ejecting Tool (sample) is sharp. Do not point it at yourself or others.

Doing so may damage yourself or others, causing injury or loss of sight.

If you develop skin problems by using IC Card Tray Ejecting Tool (sample), stop using the product immediately, and see a doctor. Itching, rashes, eczema, etc. sometimes occurs depending on your physical constitution and condition.

For material of each part▶P. 54 "Material List"

Store the tool out of reach of small children.

Not doing so may cause accidental swallow, suffocation or injuries.

■ Use near Medical Instruments and

Inside Medical Facilities

Wearers of medical equipment such as implanted pacemakers or debrillators must carry and use the product at least 15 cm away from the implanted device.

Radio waves may affect the performance of electronic medical equipment.

When using electronic medical devices as home medical treatment other than an implanted pacemaker and an implanted cardioverterdebrillator outside medical facilities, check individually with the manufacturer of the electronic medical equipment regarding the inuence of radio waves.

Radio waves may affect the performance of electronic medical equipment.

Make sure that the product will not emit any signals (turn off power, put it in Airplane mode, etc.) if within 15 cm of those around you, such as where crowded and you cannot move freely.

Since there may be people with an implanted pacemaker or an implanted cardioverter-defibrillator nearby. Radio waves may affect the performance of electronic medical equipment.

Safety Precautions

Page 56

When using the product in medical facilities, be sure to observe the regulations of the facility.

Radio waves may affect the performance of electronic medical equipment.

Material List

■ BASIO3 main unit

Part Material Surface

Exterior case (main display), Camera slide cover

Exterior case (bottom, back), phone button / home button / mail button, card slot cover, volume up / down key, camera button, camera panel

Display, Out camera

Safety Precautions

(lens)

Power button Aluminum alloy Anodized

Charging terminals Copper alloy Gold plating

Photo / Flash light PMMA resin ⊖ IC Card Tray POM resin ⊖

PA resin UV cured

PC resin UV cured

Chemically strengthened glass

Treatment

acrylic coating

Antifouling

aluminum

(with Ni plating)

■ Desktop holder (KYV43PUA)

Part Material Surface

Exterior ABS resin ⊖ Hook, lever POM resin ⊖ Terminals Copper alloy Gold plating

Rubber feet Urethane foam ⊖

Treatment

(with Ni plating)

■ KYOCERA TV Antenna Cable 04 (04KYHSA)

Part Material Surface

Plug Copper alloy Gold plating

Cord TPO ⊖

Treatment

(with Ni plating)

■ Checkup card (KYV43NXD)

Part Material Surface

Exterior PET Varnishing

Treatment

■ IC Card Tray Ejecting Tool (sample)

Part Material Surface

Exterior PA resin ⊖

Treatment

Page 57

Handling Precautions

These precautions are provided to prevent product faults and to ensure that performance can be fully demonstrated. Thoroughly read these precautions to ensure correct use.

Precautions Common to the Main Unit, Internal Battery,

■

Charger, au IC Card, KYOCERA TV Antenna Cable 04, IC Card Tray Ejecting Tool (Sample), Peripheral Devices

● Do not apply excessive force to the product during use.

Be sure not to put the product into a tightly packed bag or place a heavy object on the product in a bag. Sitting on the product in your pocket might damage the display or internal circuit board resulting in a malfunction.

Keeping an external connection device connected to the

external connection terminal or earphone microphone terminal might damage the connector resulting in a malfunction. Such damage and malfunction are not covered by the warranty, even if there is no external damage.

● To ensure the waterproof property (equivalent to IPX5 and

IPX8) or the dustproof property (IP5X) of the product, use the product with the card slot cover tightly closed. Note that the waterproof property is not guaranteed in usage condition. Do not allow water to get inside the product, or splash water on a specified charger (sold separately) or optional accessories. Do not open/close the card slot cover in the rain or with any water on the surface of the product. Doing so may cause water intrusion resulting in internal corrosion.

Malfunctions determined to be caused by such water

intrusion are not covered by the warranty.

● Do not use the product in extremely hot, cold or humid

places.

(Use within an ambient temperature range of 5℃ to 35℃

and humidity range of 35% to 85%.)

- Charger

- Peripheral devices

● Do not use the product in extremely hot, cold or humid

places.

(Use within an ambient temperature range of 5℃ to 35℃

and humidity range of 35% to 90%. Temporary use at 36℃ to 40℃ is allowed.)

- Main unit

- au IC card (attached to the main unit)

● Do not use in places subject to lots of dust or vibration.

Doing so may cause malfunction.

● Clean the external connection terminal and earphone

microphone terminal with dry cotton swabs, etc. every now and then. Soiling may result in a poor connection. Do not exert a strong force to clean each of the terminals to prevent deformation.

every

Safety Precautions

Page 58

●

Clean the product with a soft dry cloth (such as the type for eyeglasses). Forceful rubbing with a dry cloth may scratch the display. The display may be stained if splash or smear is left attached to the surface. Wiping the product using alcohol, thinner, benzene, detergent, etc. might erase the printing on the outer cover or cause malfunction.

● Use as far away as possible from land-line phones, TVs and

radios. Use nearby might affect them.

● The product may become warm while charging or during

other operations, depending on the situation, but this is not abnormal.

● Do not place near corrosive chemicals or in places

where corrosive gas is generated. Doing so may cause malfunction.

● Do not use outside when you can hear thunder. Doing so

might risk lightning strikes and electric shock.

● Be sure to use only the specified peripheral devices. Use of

other peripheral devices might cause malfunction.

● Do not put the product in a cooking apparatus such as

Safety Precautions

microwave oven or a pressure vessel. Doing so may cause malfunction.

The customer is not allowed to disassemble, modify or

●

the product. Doing so may cause malfunction. Modification of the product is in violation of the Radio Law and Telecommunications Business Law.

used

repair

● Do not allow any part of yourself (fingers, etc.) conductive

foreign objects (metal fragments, pencil leads, etc.) to come into contact with or get inside the connection terminal, earphone microphone terminal, etc. to avoid the connection terminal, earphone microphone terminal, etc. from shortcircuit. Doing so may cause malfunction.

● In the event that the product gets wet while charging,

immediately disconnect the power plug of the specified charger (sold separately).

● Do not use the product while driving a car or motorbike,

riding a bicycle or walking. Use of a cell phone while driving a car or motorbike is prohibited by law. Use of a cell phone while riding a bicycle may be punishable by some regulat ions.

● Using or charging the product in a bag or while it is covered

with bedding might cause malfunction.

● When using a specified charger (sold separately) or external

device, insert/remove the connector straight to/from the terminal. Make sure the orientation of the connector. Unless it's correct, it may cause a fault.

● Do not expose the camera lens to direct sunlight for an

extended period. Doing so may cause malfunction.

● Do not use, store, or leave the product in places subject to

direct sunlight (e.g. in a car), places that get hot, places that get extremely cold, and in humid or dusty places. Doing so may cause malfunction.

● Do not leave the product on unstable or sloping surfaces.

Be careful especially when the product is charging or set to vibrate. The product may fall and cause malfunction.

Page 59

● For charging the product, do not exceed the rating of an

outlet or wiring device when using a power bar, etc.

■ Main Unit

● The battery is built into the product and it is not user

replaceable. For information on battery replacement, contact an au shop or Customer Service Center.

Do not forcefully press, tap or intentionally subject the display

●

to strong impact. Doing so might cause scratching or damage.

● Do not forcefully press your fingernails, sharp objects, or

hard objects against buttons or display surface. Doing so may cause scratching or damage.

The touch panel is designed to be lightly touched by

fingers. Avoid pressing forcefully or using sharp objects (fingernail, ballpoint pen, pin, etc.).

The touch panel might not respond to the following types of

operation. These may also result in malfunction.

・ with fingernails ・ with another object placed on the operation area ・ with a protective film or sticker adhered ・ under water ・

with any water or condensation on the touch area

・ with wet or sweaty fingers

● Never use the modified product. Use of a modified device

violates the Radio Law and Telecommunications Business Law.

The product has acquired such certification as conformity

with technical regulations for a specified radio station based on the Radio Law and conformity with technical regulations for a terminal device based on the Telecommunications Business Law, and the "Technical Conformity Mark " can be confirmed internally in the product.

Home screen → [ツール (Tools)] → [Settings] → [About

phone] → [Compliance information]

If the modification is made to the internal components, the

certifications of conformity with technical regulations will become invalid. Never use the product without these certifications valid. Doing so violates the Radio Law and Telecommunications Business Law.

● Take care not to place magnetized items such as magnetic

cards, speakers and TV sets near the product as it might cause malfunction.

Putting strong magnetism close to the product might cause

false operation.

● Do not bring magnetized cards such as cash cards, credit

cards and prepaid cards closer to the product. Doing so may result in loss of recorded information.

● When you put the product in your pocket or bag, take care

so that the display does not come in contact with metal objects or other hard objects. Not doing so may cause scratching or damage. Straps with metal or other hard parts that may come in contact with the display may cause scratching or damage.

Safety Precautions

Page 60

●

When suddenly brought into a warm place from a cold or when in a humid location, or when used where temperature suddenly changes (e.g. near the air discharge port of an air conditioner), water droplets (i.e. condensation) sometimes are formed inside the product. Note that when used under conditions such as this, humidity might cause corrosion or a fault.

● Camera lens or inside of the display may mist over

(dew formation) because of usage environment such as temperature or humidity. This is not malfunctioning or abnormal.

● Environment for easily generating dew formation on the

camera lens or inside of the display

In the following cases, such as large temperature change or

high humidity, camera lens or inside of the display mist over because of usage environment.

・ Bring the product from a high temperature land into a low

temperature water.

・ Bring the product from a cold place into a warm place

such as an indoor.

・ Open/Close the card slot cover, etc. in a high humidity

Safety Precautions

environment.

● How to reduce condensation Do not use the product in places that get hot and humid, and

sandy or dusty places. Leave the product with the card slot cover opened for a while until the condensation is cleared when the ambient temperature is held constant.

● While writing/reading data to/from a microSD memory card,

do not subject the product to vibration or impact, or turn off the power. Doing so may cause data loss or malfunction.

place,

● Do not cover the sensor with your finger or put a sticker on

it. May hinder the sensor from detecting the ambient light level and functioning correctly.

● Do not put a sticker, etc. on the proximity sensor. May cause

the sensor to malfunction and make the display always turned off while receiving a call or during a call and make it impossible to operate the product.

● Any soiling on the proximity sensor may cause misoperation.

Wipe the sensor with a soft, dry cloth.

● Keep the card slot cover closed when using the product.

Using the product with the cover opened can allow dust, liquid, etc. to enter and cause malfunction.

● Do not allow liquids, metal objects, or other foreign objects

to get inside of the au IC card or microSD memory card slot. Doing so may cause malfunction.

● Do not give strong impact on the product such as dropping,

throwing, stomping. Doing so may cause malfunction.

● Do not place the product directly on sand at a beach, etc.

If sand or other small particles get inside the mouthpiece

(microphone) or speaker, etc., it may cause the volume to drop or malfunction.

● Do not allow objects to be caught in the camera slide

cover or subject it to excessive force. Doing so may cause malfunction or breakage. Handle with caution.

Page 61

■ Touch Panel

● Any soiling on the display surface may cause false

operation. Wipe the display with a soft, dry cloth.

● Putting stickers or sheets (e.g. commercially available

protective films, peep prevention sheets) on the display might cause incorrect operation of the touch panel.

● When carrying the product in your pocket or bag, take

care not to put the touch panel close to metals or other conductive materials, as it might cause false operation of the touch panel.

■ Internal Battery

(The internal battery of the product is a lithium-ion battery.)

The internal battery is not fully charged at the time of purchase. Charge the battery before using the product. Also charge the battery after long periods of disuse before using the product.

● Use in very hot or cold environments, for example, when left

in an automobile with the windows closed in summer, will cause the battery capacity to drop and shorten the available battery usage time. This will also shorten the internal batter y's service life. Try to use the internal battery as much as possible at room temperature.

● The internal battery is a consumable accessory. If the

performance of an internal battery does not recover (e.g. the usable time after each charge has become extremely short), the internal battery is at the end of service life, so stop using the product. Since the battery is built into the product, au shops keep your product and replace the battery for a fee. Please note that you may not be able to use the product for a certain period. Please understand. Note that the length of service life varies depending on the usage condition, etc.

After the internal battery is charged, battery power

●

decreases bit by bit even if the product is not used. The internal battery may be discharged if the product is not used for a long time. We recommend charging the battery before use.

Safety Precautions

Page 62

● The internal battery may swell up as it approaches the end

of its battery life. This is due to the properties of lithium-ion batteries, and is not a problem in terms of safety.

■ Charger

● Do not wrap the cord of the specified charger (sold

separately) around the adapter unit. Do not forcibly bend the specified charger's (sold separately) plug or the connection between the connector and power cord. Do not place heavy objects on the cord of the specified charger (sold separately) or USB connection cable, or do not pull the cord with excessive force. Doing so may cause malfunction.

● When unplugging the power plug of the specified charger

(sold separately) from the power outlet, hold and pull the power plug. If you pull the cable, it might be damaged.

● Do not use the desktop holder in a vehicle. It may fall and

hinder driving, can result in an accident. The desktop holder assumes use indoors on a stable surface.

■ au IC Card

● Do not forcibly remove or insert the au IC card. Be careful

Safety Precautions

not to exert excessive force when inserting the card into your au cell phone.

● You are responsible for any damage caused by inserting

your au IC card into some other IC card reader/writer, etc.

● Do not put stickers, etc. on the au IC card.

● Do not insert the au IC card inserted in a card adapter.

Doing so may cause malfunction.

● Do not damage the card (use in a hot place, throw into fire,

contact the metal part with foreign object, give an impact, bend, apply a load, moisten, etc.). Doing so may cause data loss or malfunction.

■ IC Card Tray Ejecting Tool (Sample)

● Do not apply excessive force to IC Card Tray Ejecting Tool

(sample). Doing so may cause malfunction or damage.

■ Camera

● When photographing important occasions, take a trial shot

and check the shot image to make sure it is correctly shot.

● Do not shoot in areas where shooting is prohibited.

■ Copyrights and Rights of Portrait

● You are not allowed to copy, distribute, publish, modify or

edit the data you shot, recorded or downloaded using the product without consent of the copyright holder, except for personal use, under the copyright law.

In addition, do not use or modify portraits or names of other

individuals without their consent, as it may infringe on rights of portrait.

Note that shooting and recording might be restricted at

some live performances, shows and exhibitions even for personal use.

● Be careful about the copyright and portrait right when

posting photos you shot, etc. on Internet homepages.

Page 63

■ Backup Content On the Product

● Please back up important content registered to the product

or downloaded to the product from an outside source. Content recorded to memory on the product sometimes disappears or is altered by unexpected factors, such as static electricity or a fault, repair, mishandling, etc.

■ FCC Certication Information

● The product is certified by Federal Communications

Commission (FCC)

The product's FCC ID is JOYEA23. You can view this certification in the following way. How to confirm: Home screen → [ツール (Tools)] → [Settings] → [About

phone] → [Compliance information]

Safety Precautions

Page 64

Notes on Water and Dust Resistance

The product has a waterproof property equivalent to IPX5*1

, as well as a dustproof property equivalent to

and IPX8

on the condition that the card slot cover is completely

IP5X attached (by Company test methods). Before using the product, thoroughly read "Important precautions before use" to ensure correct use. Failure to follow the contents described in these sections may cause the intrusion of water, sand or other foreign material, resulting in overheating, ignition, electric shock, injury or a fault.

*1 IPX5 equivalent means that the product will maintain its operability as a

phone even if it is sprayed with water from a 6.3 mm diameter nozzle at

a distance of about 3 meters for more than 3 minutes at a rate of about

12.5 liters per minute from any direction.

*2 IPX8 equivalent means that the product will maintain its operability as

a phone with no water getting inside the main unit even if it is gently

submerged in a tank of still tap water at room temperature to a depth of

1.5 meter for about 30 minutes.

Safety Precautions

*3 IP5X means that the product will have and safely maintain functionality

as a phone after being removed from a test device filled with particles up

to 75 μm in diameter and agitated for 8 hours. (This does not mean that

the product completely prevents the intrusion of particles.)

Operation of the product in every possible condition during actual use is not guaranteed. Malfunctions determined to be caused by mishandling by the customer are not covered by the warranty.

Important Items to Remember before Use

◦

Close firmly the card slot cover of the product.

resistance is effective when completely sealed.

◦ Never open or close the card slot cover if your hand or the

product is wet.

◦ Do not let the product submerged into or get wet with the

liquids (seawater, water from a swimming pool, hot water of

hot spring, water containing soap, detergent, bath powder,

alcohol, soft drink, seasoning, etc.) other than tap water. Also,

do not use it in a place where it gets wet with pet urine.

If the product gets splashed, immediately rinse it off with tap

water.

◦ Do not place the product directly on sand at a beach, etc.

Sand or other small particles might get inside the mouthpiece

(microphone) or speaker, causing the volume to drop. If sand

gets inside the product, it might cause overheating or a fault.

◦ Sand or other small particles getting inside the camera slide

cover may cause opening/closing to become gritty and cause

scratching noise.

◦ Do not use the product underwater. ◦ Do not use or leave the product in a humid place such as a

bathroom or kitchen for an extended period of time.

● Moisture may still remain after draining. While this will not

affect use, you should not leave the product next to items you

do not want to get wet. Product may wet clothing, inside of

carry bag, etc.

Water

Page 65

● Drain any water in the mouthpiece (microphone), speaker,

etc. that may be affecting audibility.

● Product is not designed to resist water pressure. Avoid

exposing to high water pressure or submersing in water for a

long period.

● Do not wash the product in a washing machine or ultrasonic

bath.

● Do not immerse the product into a bathtub. Product is not

designed to be heat resistant.

● The rapid changes of temperature may cause condensation,

resulting in malfunction. Wait until the product reaches room

temperature before you bring the product from a cold place

into a warm bathroom.

● The product does not float on water.

● Card slot cover

• Close firmly the card slot cover of the product, and make

sure the cover is completely closed. Any minute particles

becoming lodged between contact surfaces (a single hair,

etc.), no matter how small, can cause seepage.

•

Do not wear gloves while opening/closing the card slot cover of

the product, Any minute particles becoming lodged between

contact surfaces (a single hair, etc.), no matter how small,

can cause seepage. Before closing the cover, wipe any water,

soiling, etc. with a dry, clean cloth, no matter how small.

• Any deterioration or damage with the card slot cover will affect

water resistance.

How to close the card slot cover

① After stowing the cover hinge, press on the cover with the flat part of your finger. ② Rub your finger over the cover in the

direction of arrow to ensure that the cover is not partially open.

①

②

Safety Precautions

Page 66

● If any liquid other than plain water gets on the product

• If anything other than water (seawater, washing detergent,

alcohol, etc.) gets on the product, immediately rinse with

water.

• Wash with slightly weak running water (less than 6 liters/

minute) with tap water (5℃ to 35℃) at a position about 10 cm

away from the faucet or shower.

• If the product gets soiled, wash by hand without using a brush,

etc., holding the product so that the card slot cover does not

open.

• To wash the slide on the camera slide cover, immerse in a

basin of water free of minerals and impurities with the cover

opened, and swish to wash.

● After the product gets wet

•

After becoming wet, drain water and wipe the product with a dry,

clean cloth.

• In cold regions, any water on the product may freeze. Using

the product with frozen water may cause malfunction. Do not

leave water drop on the product.

Safety Precautions

● Rubber seal

• The rubber seal around the card slot cover is important in

maintaining water resistance. Do not scratch or remove it.

• Be careful not to pinch the rubber seals when closing the

card slot cover. Trying to close the cover with a seal pinched

can scratch the seal and affect water resistance. Any minute

particles becoming lodged between contact surfaces (a

single hair, etc.), no matter how small, can cause seepage.

• Any liquid other than water (alcohol, etc.) on the product can

affect product durability.

• Do not insert pointed objects in the card slot cover. Doing so

may damage/deform the product or scratch the seal, allowing

water seepage.

• Parts used for maintaining water resistance should be

replaced every 2 years regardless of their appearance.

Contact your nearest au shop for replacement.

● Heat resistance

• Do not submerge the product in hot water or get it wet with

hot water. Do not use the product in saunas or expose it to

hot air from hair dryer etc. Product is not designed to be heat

resistant.

● Dust resistance

• If dust gets on the product, immediately rinse with water

and completely remove any dust before using the product.

Sliding the camera slide cover with dust on the product may

cause sliding components not to operate correctly or other

malfunction.

● Shock

• The product is not resistant to shock. Do not drop or otherwise

subject the product to shock. Do not poke the earpiece

(receiver), mouthpiece (microphone), speaker, etc. with a

pointed object. Doing so may damage/deform the product

and allow water seepage.

Page 67

Precautions on Charging

Optional accessories are not water/dust resistant. Note the

following before and after charging.

• Never charge the battery if the product is wet. Doing so may

cause fire, burns, injuries, electric shock, etc.

• Make sure the product is not wet. To charge the product after

it has gotten wet, drain water well and wipe with a dry, clean

cloth before inserting the USB Type-C plug into the external

connection terminal or placing in the desktop holder.

• Check that no water or foreign objects are in the external

connection terminal before use.

• Do not touch the specified charger (sold separately) or

desktop holder with wet hands. Doing so may cause electric

shock.

• Do not expose the specified charging equipment (sold

separately) or desktop holder to water. Do not use it near

water, such as in a bathroom, shower room, kitchen, or

washroom. Doing so may cause fire, burns, electric shock, or

malfunction. Do not bring it into a bathroom, etc. even when

you are not charging with them. Doing so may cause fire,

burns, electric shock, or a malfunction.

How to Drain Water

If the product gets wet, be sure to drain the speaker and

mouthpiece (microphone).

Water remaining in those parts might wet your clothes or bag, or the

sound might become hard to hear.

Follow the steps below to drain water.

Wipe water thoroughly on the surface of

the product with a clean dry lint-free cloth

Safety Precautions

Page 68

Shake the product

① Hold the product firmly and shake it in the direction of

arrows until water does not come out.

* When shaking the product, stay alert to your

surroundings.

* Be careful not to have the product pop out, and hold

it firmly to drain water.

Charging terminals:

20 times or more

Safety Precautions

Earphone microphone

terminal ･ card slot cover:

20 times or more

Buttons:

20 times or more

Strap attachment

･mouthpiece (microphone)

･external connection

terminal:

20 times or more

With camera slide cover

opened and closed:

20 times or more each

② Wipe drained water.

* The mouthpiece (microphone) , speaker, external

connection terminal, earphone microphone terminal,

and buttons are particularly hard to drain water

from.

With those parts facing down, press them against

the cloth to wipe off any water.

③ Place the product on a dry towel or cloth, then leave it

at room temperature for a while.

Page 69

Press the product gently against a

clean dry lint-free cloth, and wipe off

water remained in the gaps such as in

the mouthpiece (microphone), speaker,

external connection terminal, earphone

microphone terminal, etc.

Leave the product for 1 hour or more at

room temperature to dry after removing

drained water thoroughly

Even after you take these procedures, water may remain on the

product. Do not place the product near things that you do not

want to wet.

Also, take care not to wet your clothes, bag, etc.

Safety Precautions

Page 70

Notes on Using Bluetooth®/ Wireless LAN (Wi-Fi®) Function

• The Bluetooth® function of the product conforms to domestic standards of Japan, FCC standards, and has been certified.

• Use of the Bluetooth or regions. If you use the product overseas, check the relevant laws and regulations of the country/region you visit.

• The wireless LAN (Wi-Fi to domestic standards of Japan, FCC standards, and has been certified.

• Use of the Wireless LAN (Wi-Fi countries or regions. If you use the product overseas, check the relevant laws and regulations of the country/ region you visit.

• The 2.4 GHz band used by wireless LAN (Wi-Fi Bluetooth® devices is operated by various other

Safety Precautions

For this reason, the communication speed and connectable range may be decreased, or disconnection may occur, due to interference from other devices.

• Do not use this product in places where electromagnetic waves are generated or near electric products, AV and OA equipment, or other magnetized devices.

• Subjecting this product to magnetic or electrical noise might increase noise and prevent it from performing communications. (This product is particularly susceptible

to noise when it is used near a microwave oven.)

function is limited in some countries

) function of the product conforms

) function is limited in some

) and

devices.

• Using this product near a TV, radio or similar appliance might cause reception interference and disrupt TV images.

• Searching might not be successful if there are multiple wireless LAN (Wi-Fi

) access points near to the product

or the same channel is being used.

• Since using the product on airplanes is restricted, follow the instructions given by the respective airlines.

• The communication speed and connectable range vary depending on the distance between communication devices, obstacles and the devices used.

Cautions on Using 2.4 GHz Band

The frequencies used by the Bluetooth® and/or Wireless LAN (Wi-Fi band. In this frequency band, other similar wireless stations, in-plant wireless stations for mobile unit identification that require a license for use, such as factory production lines, specific small power wireless stations that do not require licenses, amateur wireless stations (collectively called "other wireless stations" from here on) are operated in addition to home electrical appliances such as microwave ovens, devices for industrial, scientific and medical devices.

1. Before using the product, make sure that "other wireless

) function of the product are in the 2.4 GHz

stations" are not in operation nearby.

Page 71

2. In the event that instances of radio wave interference have occurred between the product and "other wireless stations", immediately either relocate the product or stop operation of the device (stop emission of radio waves).

3. If unsure or require assistance, contact an au shop or Customer Service Center.

◎ Connections between the product and all other Bluetooth®

and wireless LAN (Wi-Fi confirmed. Therefore, connections with all Bluetooth wireless LAN (Wi-Fi

◎ This product supports security features for wireless

communications that are compliant with the Bluetooth and wireless LAN (Wi-Fi security may not be sufficient depending on the usage environment and configuration. Be careful when making data communication using Bluetooth function (Wi-Fi

◎ Wireless LAN (Wi-Fi

freely connected anywhere within the radio wave range, as it uses radio waves for exchanging information. However, not making security settings allows the risk of malicious use by third parties. While at the customer's discretion and responsibility, it is recommended that you make security settings before using the product.

◎ The Company assumes no responsibility for leakage of

data or information that may occur during Bluetooth wireless LAN (Wi-Fi

◎ Since Bluetooth

the same frequency band, using the both functions at the same may cause radio wave interference resulting in decreased communication speed or disconnection from the network. If connection fails, stop using either of the

Bluetooth

and wireless LAN (Wi-Fi®) functions.

) devices have not been

) devices are not guaranteed.

) standard specifications, but the

) has the advantage that it can be

) communication.

and wireless LAN (Wi-Fi®) functions use

or wireless LAN

Bluetooth® and wireless LAN (Wi-Fi®) functions of the product use frequencies in the 2.4 GHz band.

and

Safety Precautions

Page 72

• Bluetooth® function: 2.4FH1/XX1

2.4FH1/XX1

This product uses the 2.4 GHz band. FH-SS is used as

the modulation scheme. The interference distance is about 10 m or less.

• Wireless LAN (Wi-Fi

) function: 2.4DS4/OF4

This product uses the 2.4 GHz band. DS-SS and OFDM

are used as the modulation schemes. The interference distance is about 40 m or less.

This means that all bandwidths are used, and that band

of mobile unit identification devices can be avoided.

Available channels vary depending on countries. For use in an airplane, check with the airline company in

advance.

Cautions on Using 5 GHz Band

Safety Precautions

The frequencies used by the Wireless LAN (Wi-Fi®) function of this product are in the 5 GHz band. Outdoor use of 5.2 GHz band and 5.3 GHz band is prohibited under the Radio Law. The used channels of the product are as follows.

• W52 (5.2 GHz band / 36, 38, 40, 42, 44, 46, 48 ch)

• W53 (5.3 GHz band / 52, 54, 56, 58, 60, 62, 64 ch)

• W56 (5.6 GHz band / 100,102,104,106,108,110, 112,116, 118,120,122,124,126,128,132,134, 136,140 ch)

Security Code/PIN Code

Security Code

The product has various security codes that you can use. The available security codes are as follows. Do not forget the various security codes that are set as they are necessary for various operations and contracts. Be sure to change the initially set number to your own number.

● Security code

Example of usage

Initial value

● Setting security for the start screen

Example of usage

Initial value

* Be sure to change the initially set number to your own number.

① To do remote operation of voice mail and call

forwarding services from a landline phone

② To use Customer Service Center and to do

various inquiries, applications, and modifications on the au homepage

A four digit number chosen by the customer and noted on the application form

Activating/deactivating the security

According to initial setting at the time of purchase

Page 73

PIN Code

■ PIN Code

To prevent unauthorized use of the au IC card by a third party, you can set the product to require PIN code entry every time the power is turned on. You also need to enter PIN code when setting whether PIN code entry is required. If PIN code is incorrectly entered three times consecutively, the PIN code will be locked. You can unlock the PIN code using PUK code.

• At the time of purchase, the PIN code is "1234", and entry is not required. You can change the PIN code to any 4- to 8-digit number and the product to require entry if necessary.

• To use the product with a PIN code required, be sure to change the PIN code to your own number you have chosen.

■ PUK Code

In case PIN code is locked, you can unlock it by entering PUK code.

PUK code is an 8-digit number given at the time of

• which is printed on the back side of the plastic card on which your au IC card is attached.

• After entering PUK code, you need to set a new PIN code.

• If PUK code is incorrectly entered ten times consecutively, contact an au shop, PiPit or Customer Service Center.

• PIN code is not reset by initializing the product.

purchase,

【Password entry field】

Google account ID

Google account password

au ID account ID

au ID account password

Facebook account ID

Facebook account password

* Strictly manage your account and password to prevent a third party from

obtaining them.

@gmail.com

Security (start screen) Lock: Lock No.

Security (start screen) Lock: Password

Security (start screen) Lock: Pattern

Safety Precautions

Page 74

Notes on Data Communication Charges

• Since constant Internet connection is possible with the product, data communication may be performed automatically by some applications, resulting in high data communication charges. Therefore, subscription to a data flat-rate service/data communication charge discount service is recommended.

• To browse homepages, download applications, communicate using applications, send/receive mails and configure various settings with the product, connection to the Internet is required, to which data communication charge applies.

* Data communication charge does not apply if connected by wireless

LAN (Wi-Fi®).

Safety Precautions

Notes on Applications

• Be sure to check the security of the application, then install it at your own risk. Some applications might cause virus infection, damage various data, and send out your location information, usage history or personal information stored in your cell phone via the Internet.

• The Company assumes no responsibility for any problems that might be caused by applications you have installed. In such case, you may be charged a repair fee even during the warranty period. The Company assumes no responsibility for any disadvantage

• brought to you or any third party by applications you have installed.

• Some applications require that a microSD memory card be inserted.

• Some applications prohibit the product from entering sleep mode while they are active, or rapidly drain the battery while running in the background.

• Operation procedures and screen appearances of the applications preinstalled in the product and those installed by you are subject to change without notice as a result of version upgrade. Note that there may be differences with descriptions in this manual.

Page 75

Setting the App Permissions

The first time you launch an app/function that accesses the functions or information of the product, a confirmation screen for requesting access permission appears. If a confirmation screen appears, confirm the content and proceed.

Example: When 写真/動画 (Photos/Movies) is activated

Apps permission conrmation screen →

[DENY] / [ALLOW]

Tap "ALLOW", allow the use of function normally. When you use multiple function, follow the same operations for each function.

Setting for Each App/Function

■ Setting for each app

Home screen → [ツール (Tools)] →

[Settings] → [Apps]

Select app → [Permissions] → Set

function

■ Setting for each function

Home screen → [ツール (Tools)] →

[Settings] → [Apps]

[MENU] → [Advanced] → [App

permissions] → Select function → Set app

◎ If you do not permit, app/function may not be activated or

use of function may be limited.

◎ For some apps/functions, an explanation screen for the

permission appears. The confirmation screen may also appear multiple times, or the display may differ. Confirm the displayed content and follow the onscreen instructions.

◎ In this manual, description of confirmation screens may

be omitted.

Safety Precautions

Page 76

Cell Phone Etiquette

■ Use of Cell Phones is Not Allowed in the

Following Places!

• Do not listen to music, watch videos while driving a car or motorbike, or riding a bicycle. Use of cell phones while driving a car or motorbike is prohibited by law. (Use of cell phones while riding a bicycle may also be punishable by law.) In addition, stay alert to the traffic around you even when walking. Surrounding sounds might not be heard clearly, and gazing at the screen may distract your attention causing a traffic accident. Be especially careful at railroad crossings, station platforms and pedestrian crossings.

• Since using the product on airplanes is restricted, follow the instructions given by the respective airlines.

Safety Precautions

■ Be Considerate of People around You

• Do not make calls in theaters, museums, libraries, and other similar places. Turn power off or turn on manner mode so as not to disturb others around you with your ringtones.

• In a city area, use in a place where you do not bother people walking.

• It is extremely dangerous to walk while looking at the screen of the cell phone. Do not suddenly stop to talk on/ operate the cell phone or do so while walking.

• Move to a place where you do not disturb others while you are in shinkansen, a hotel lobby, etc.

• Be careful not to be loud while talking.

• Be careful of sound leakage from earphones in trains or other places with many people around you.

• Ask permission if you take photos with your cell phone camera.

• When using the camera, follow common rules of etiquette regarding camera use.

• There may be a person with a cardiac pacemaker nearby at a place filled with people such as in a crowded train. Turn on "Airplane mode" or turn the cell phone off in such places.

• When a medical institution has laid down designated areas where use of the product is prohibited or is not allowed to be brought in, abide by the instructions of that medical institution.

Page 77

Appendix

Updating Software

You can update the product to the most recent software for optimal performance and to get the latest enhancements. There are several methods to update the software.

• Use this product to download and update the software.

• Use Wi-Fi

■ Notes on Software Update

• You are charged for data communication when

• When software update is necessary, you will be informed

• It is recommended to back up your data before updating

update the software.

connecting to the Internet from the product using data communication. Especially for OS update, large data communication occurs. You are recommended to use WiFi

on au homepage, etc. For details, contact an au shop or Customer Service Center (call toll-free 157). In addition, users of the product will receive a notice from au, when software update is necessary to improve the functionality of the product.

software.

functions of this product to download and

• If software update has failed or stopped, perform the same procedure again.

• Update may be unavailable during international roaming.

• If the software update fails, it may become impossible to operate the product. If this happens, bring it to an au shop or PiPit (not accepted by some shops).

• Any operations are not available during software update. Calling 110 (Police), 119 (Fire/Ambulance), 118 (Maritime rescue) and 157 (Customer Service Center) is not available. Alarm does not work, either.

Appendix

Page 78

Downloading Software into the Product to Update

Downloading updated software via the Internet directly from the product is available.

Home screen → [ツール (Tools)] →

[Settings] → [About phone] → [Software

update]

From here on, follow the onscreen instructions.

◎ Note that depending on the terms of your subscription

contract, communication charges may be incurred for the product to automatically search for available networks.

◎ After a software/OS update, the product cannot revert to

the previous version software.

Troubleshooting

Before you assume that the product is malfunctioning, confirm the following contents and perform "トラブル診断"

Appendix

in "故障受付" app. Home screen → [サポート (Support)] → [故障紛失サポー

ト (Repair and Delivery Service)] → [トラブル診断 (Trouble

diagnosis)] (Displayed language is Japanese only)

Trouble Detail

Cannot turn on power

Cannot charge the product

Cannot operate/ The screen does not respond/ Cannot turn off the power

The power is turned off automatically

The power is turned off while the wake-up logo is displayed

Cannot make calls

Is the internal battery charged? P. 16

(Power button) pressed and held until the charging light turns on

Is the specified charger (sold separately) correctly used for charging?

Is the product at a high or low temperature? The product may stop charging depending on a temperature.

Is the specified accessory (adapter etc.) used for charging?

Are the desktop holder or charging terminals soiled?

Press and hold F (Power button) and r (Volume up key) at the same time for at least 11 seconds.

Is the internal battery adequately charged? P. 16

Is the internal battery adequately charged?

Is the power turned on? P. 21 Is the au IC card inserted? P. 11

Page

P. 21

P. 17

P. 16

P. 17

P. 18

P. 22

P. 16

Page 79

Trouble Detail

Cannot receive calls

" (out of service

area) appears

Cannot operate button/touch panel

" appears

A message indicating that charging is necessary is displayed

Is the signal good enough? P. 33 Is the product within the service

area? Is the power turned on? P. 21 Is the au IC card inserted? P. 11 Is the product within the service

area or where signal is good enough?

Is the built-in antenna covered with finger, etc.?

Is a card inserted other than the au IC card?

Is the power turned on? P. 21 Turn off the power and then turn it

on again. Is the au IC card inserted?

The battery is almost empty.

Page

P. 33

P. 6

P. 10

P. 21

P. 11

P. 16

Trouble Detail

The battery can only be used a short time

When making a call, there is a busy signal and the call does not connect

Display is dark Is the temperature of the product

Cannot hear/hard to hear the other party's voice

Settings made for specified contacts do not work

Is the battery adequately charged?

• Charge until the red charging

indicator turns green.

Does the internal battery have adequate service life remaining

Is the product left in the place for a long period where " service area) appears?

Stop using/disabling unused apps or functions.

Is the product within the service area or where signal is good enough?

The wireless line is extremely busy or the party is calling. Retry later.

or battery high? The display may become dark depending on the temperature of the product.

Place your ear hole to the receiver.

Is the caller ID notified? If the caller does not notify the caller ID, ringtone setting in Contacts is not effective. Group's incoming settings in Contacts is not effective, either.

" (out of

Page

P. 16

P. 59

P. 33

－

P. 33

－

P. 9

Appendix

－

Page 80

If you cannot find the solution to your problem in the above items, refer to the au Customer Support site "トラブル診断 (Trouble check)" on the website shown below. (Displayed language is Japanese only.)

https://www.au.com/trouble-check/

After-Sales Service

■ When Asking for Repair

For repair, contact Repair and Delivery Support Center.

During the warranty period

Outside the warranty period

* The warranty period is one year from the day when you purchase the

product.

Appendix

Repairs will be done based on the terms of services of the free-of-charge repair warranty.

We shall repair the product for a charge as requested by the customer if repair renders it usable.

◎ Before handing the product for repair, make a backup of

the contents of memory since they may disappear during repair. Note that the Company shall not be liable for any damages and loss of income should the contents of memory be altered or lost.

◎ Recycled parts that meet the Company's quality

standards are sometimes used for repair.

◎ au cell phones collected by Replacement cell phone

delivery service which you used before are recycled to cell phones for replacement after repairs. Also parts replaced by au after-sales service are collected and recycled by the Company. They are not returned to customers.

◎ For the products that are processed, modified,

analyzed (including altering the software, analyzing (including rooting), reverse-engineering, decompiling, or disassembling), or repaired by repair offices other than the company specified, they are not covered by the warranty or repair may be refused.

◎ The battery built into the product is not covered by the

free-of-charge repair warranty except for events arising from defects in battery materials and manufacturing.

◎ Accessories such as the desktop holder, KYOCERA TV

Antenna Cable 04, Checkup card, and IC Card Tray Ejecting Tool (sample) are not covered by the free-ofcharge repair warranty.

Page 81

■ Performance Parts for Repair

The Company retains performance parts for repair of the product main unit and its peripherals for 4 years after discontinuation of production. Performance parts for repair refers to parts required for maintaining the functions of the product.

■ Terms of Services of Free-of-Charge

Repair Warranty

1. When you apply for repair, inform us of your serial number (IMEI number). You can check the main unit or the sticker attached on the packaging box for the serial number (IMEI number).

2. Repairs will be done based on the terms of services of the free-of-charge repair warranty when the product is used correctly based on the instruction manual and the product is malfunctioning.

3. Repairs will be charged in the following cases even during the warranty period. (Also, the product cannot be repaired in some cases.)

① When the product is not used correctly based on

the instruction manual. ② When the product is malfunctioning or damaged due to modification and repair. ③ When the product is repaired by repair offices other than the company specified. ④ When the product is malfunctioning or damaged due to a handling fault or accident. Or when there are some traces that the product is damaged by falling, water or humidity. ⑤

When the product is malfunctioning or damaged due to earthquakes, storms, floods or other natural disasters, as well as fires, salt, abnormal voltage, etc.

4. Repairs may be refused depending on the damage condition of devices.

5. Note that the company shall not be liable for any damages and loss arising from the product malfunction. The Company assumes no responsibility for any

6. when the product is connected with an unspecified device.

7. On-site repair is not available.

8. This warranty is valid only in Japan.

* The warranty guarantees that free-of-charge repairs will be done based

on the terms of period and conditions indicated above. Therefore, the warranty does not limit your legal rights against persons in charge of the warranty and other operators.

accidents

■ Repair and Delivery Service

An after-sales service membership program on a monthly basis called "Repair and Delivery Service" (monthly fee: 380 yen, tax excluded) is available for using your au cell phone for a long time without worries. This service expands coverage for many troubles including malfunction, theft and loss. For details of this service, check on the au homepage or contact Repair and Delivery Support Center.

Appendix

Page 82

◎ You can apply for membership only at the time of

purchasing your au cell phone.

◎ Once you cancel the membership, you cannot reapply for

it until you purchase an au cell phone next time.

◎ Note that when changing the model or purchasing an

extra cell phone, this service only covers the most recently purchased au cell phone.

◎ When an au cell phone is handed over to you or someone

else, the Repair and Delivery Service membership is also handed over to the successor of the cell phone.

◎ When you get a new au cell phone by changing the model,

purchasing an extra cell phone, etc., the "Repair and Delivery Service" membership for the old au cell phone is automatically canceled.

◎ Service contents are subject to change without notice.

Appendix

■ au IC Card

The au IC card is lent to you by au. In case of loss or damage, the card will be replaced at your expense. When malfunction is suspected, or in case of theft or loss, contact an au shop or PiPit.

■ au After-Sales Service Information

Service contents

Replacement cell phone delivery service

Spontaneous failure

Partial damage, water soak, irreparable damage, theft and loss

Repair and Delivery Service

Member

1st year

2nd year and later

Free

Refer to the table of the service

charge in

"Replacement

cell phone

delivery

service"

(Member)

service charge.

Non-

member

N/A

Page 83

Holding over and repair

Service contents

1st

Spontaneous failure

Water soak and irreparable damage

year 2nd

year and later

Theft and loss N/A

Repair and Delivery Service

Member

Non-

member

Free Free

Free of charge

(three-year

warranty)

Customer

charge

Upper limit

5,000 yen Customer

charge

10,000 yen

Charge amounts are all tax excluded

Actual

costPartial damage

N/A

(By model

replacement)

■ "Replacement Cell Phone Delivery

Service" (Member) Service Charge

Applicable condition 1st 2nd

Normal

Applied both "WEB 割引" (Discount for

web app)

/"代用機な

し割引 " (Discount for nonuse of substitute)

Applied only "代用機なし割引 " (Discount for nonuse of

substitute)

*1 Customers in 3rd year (25 months) of subscription or all subscription

lines in a family discount plan to which the customer belongs are eligible. Customers using a data communication device or tablet are eligible if they are subscribing to a set discount plan (WIN Single Set Discount Service or Smartphone Set Discount) and the subscription for the line covered under the set discount is in its 3rd year.

*2 WEB割引 (Discount for web app): If you apply "交換用携帯電話機お届

けサービス (Replacement mobile phone deliver y service)" from the au homepage, 500 yen will be discounted from service charge.

"代用機なし割引" (Discount for nonuse of substitute) is applied

automatically as the substitution is not available for "WEB割引 (Discount for web app)".

*3 代用機なし割引 (Discount for nonuse of substitute): If you do not use the

substitution when using "交換用携帯電話機お届けサービス" (Replacement mobile phone delivery service), 500 yen will be discounted from service charge.

For details, refer to au homepage.

Long Benefit

Long Benefit*1

5,000 yen/

3,000 yen

4,000 yen/

2,000 yen

4,500 yen/

2,500 yen

Charge amounts are all tax excluded

8,000 yen/

Long Benefit*1

6,000 yen

7,000 yen/

Long Benefit*1

5,000 yen

7,500 yen/

Long Benefit*1

5,500 yen

Appendix

Page 84

Online Replacement Service (available 24 hours a day) (Japanese)

* From the PCs and smartphones only (in Japanese only)

(https://www.au.com/support/service/mobile/trouble/repair/

application/

)

Replacement cell phone delivery service

◎ If you have a problem with your au cell phone, call us to

have a replacement one (of the same model and color*) delivered to your specified address. Please return your old faulty au cell phone within 14 days after the cell phone for replacement is delivered to you.

* If a same-model/-color cell phone cannot be provided, a cell

phone for replacement will be provided in a model and color that we specify .

◎ You can use this service up to twice within one year

starting from the day when you first use this service. If you have not used this service over the past one year at the time of your application for this service, the application will be regarded as your first time. If you have, the application will be regarded as your second time.

* For details, refer to au homepage.

◎ If reissuance of an au IC card is required at the same

time as using this service due to theft or loss, a separate au IC card reissue charge of 1,900 yen is incurred.

Holding over and repair

Appendix

◎ Damages and malfunctions intentionally caused by the

customer as well as those due to modification (e.g. disassembly, change of parts, painting, etc.) by the customer are not covered by this service.

◎ You cannot receive a refund for replacement of the outer

casing due to stains, scratches, paint removal, etc. on the outer casing.

SIM Unlock

This product can be SIM-unlocked. SIM-unlocking the product allows other-carrier SIM cards to be used with it.

• Requests can be made for SIM-unlocking on the au homepage or at an au shop.

• When using non-au SIM card, some services, functions, etc. may be unavailable. The Company is not liable for any operations.

• To set up your phone after unlocking SIM lock, from the home page, [ツール (Tools)] → [Settings] → [About phone] → [SIM card status] → [SIM STATUS UPDATE].

• For details, refer to au homepage. (Japanese)

(

https://www.au.com/support/service/mobile/ procedure/simcard/

)

(in Japanese only)

Page 85

Related Accessories

■

Desktopholder(KYV43PUA)

■

KYOCERATVAntennaCable04(04KYHSA)

■

Checkupcard(KYV43NXD)

■

TypeCCommonACAdapter01(0601PQA)(soldseparately)

■

Micro-BtoType-Cadapter(0601PHA)(soldseparately)

■

CommonACAdapter05(0501PWA)(soldseparately)

■

CommonACAdapter03(0301PQA)(soldseparately)

■

CommonACAdapter03Navy(0301PBA)(soldseparately)

■

CommonACAdapter03Green(0301PGA)(soldseparately)

■

CommonACAdapter03Pink(0301PPA)(soldseparately)

■

CommonACAdapter03Blue(0301PLA)(soldseparately)

■

テレビde写真(PhotosonTV)receiver(0603RKA)(sold separately)

■

auCarryingCaseGBlack(0106FCA)(soldseparately)

* Use requires a Micro-B to Type-C adapter (sold separately).

◎ Accessories can be purchased from au online shop. http://onlineshop.au.com (in Japanese only)

Main Specications

■MainUnit

Display Approx. 5.0 inches, approx. 16.77 million

Weight Approx. 150g Dimensions

(W × H × D) Internal memory

Continuous

call time

Continuous standby time

Continuous tethering time

Maximum number of WiFi tethering connection devices

Charging times (estimate)

Camera imaging element CMOS Effective out-camera pixels Approx. 13 million pixels

colors, Transparent TFT 1,920 × 1,080 dots (FHD)

Approx. 71 × 144 × 9.9mm (thickest part 10.1 mm)

In Japan Approx. 1,260 minutes Overseas (GSM/

UMTS/LTE) In Japan Approx. 580 hours Overseas (GSM/

UMTS/LTE) Approx. 780 minutes

10 devices

Type C Common AC Adapter 01 (sold separately)

ROM: Approx. 32 GB RAM: Approx. 3 GB

Approx. 730 minutes

Approx. 690 hours

Approx. 160 minutes

Appendix

Page 86

Effective in-camera pixels Approx. 5 million pixels Wireless LAN (Wi-Fi Bluetooth®

function

Appendix

) function

Compatible version

Output Communication

range Supported

Bluetooth

profile

IEEE802.11a/b/g/n/ac compatible Bluetooth® standards Ver.4.2

compatible Bluetooth® standards Class 1 Within 10 m with no obstacles

in the range GATT (Generic Attribute Profile)

SPP (Serial Port Profile) A2DP (Advanced Audio Distribution Profile) AVRCP (Audio/Video Remote Control Profile) HSP (Headset Profile) HFP (Hands-Free Profile) OPP (Object Push Profile) PBAP (Phone Book Access Profile) HID (Human Interface Device Profile) PAN (Personal Area Networking Profile) PAN-NAP (Personal Area Networking-Network Access Point) PAN USER (Personal Area Networking-User) HOGP (HID over GATT Profile) SCMS-T Bluetooth SSP MAP (Message Access Profile) DUN (Dial-Up Networking

Profile)

Bluetooth® function

1Seg continuous watching time Approx. 8 hours

*1 Since the storage is shared by data and apps, storage space may be

reduced depending on the usage of apps.

*2 Charging time may be longer when used connected to the desktop

holder.

*3 It is confirmed that the product and all Bluetooth® devices are compliant

with Bluetooth® standards designated by Bluetooth SIG, and they are authenticated. However, procedures may differ or data transfer may not be possible depending on the device's characteristics or specifications.

*4 It changes according to objects obstructing devices and signal

reception.

*5 Specifications provided in Bluetooth® standards for making

communication between Bluetooth®-compatible devices in accordance with their intended use.

*6 Supported for some car navigation systems only. See the au homepage

for usage.

Frequency bands

2.4GHz band

■Desktopholder(KYV43PUA)

Weight Approx. 77g Dimensions

(W × H × D)

Approx. 162 × 39 × 48mm

■KYOCERATVAntennaCable04(04KYHSA)

Length Approx. 136.4mm Weight Approx. 5g

Page 87

◎ The continuous talk time and continuous standby time

may drop to less than half depending on the battery charging status, usage environment such as temperature, reception condition at the location where the product is used, and the function settings.

Specic Absorption Rate (SAR) of Cell Phones

This model KYV43 cell phone complies with Japanese technical regulations for exposure to radio waves and international guidelines on radio wave protection. This cell phone has been designed in observance of the Japanese technical regulations regarding exposure to radio

(*1)

and limits to exposure to radio waves

waves recommended by equivalent international guidelines. These international guidelines were set out by the International Commission on Non-Ionizing Radiation Protection (ICNIRP), which is in collaboration with the World Health Organization (WHO), and the permissible limits include a substantial safety margin designed to assure the safety of all persons, regardless of age and health condition. The Japanese technical regulations and international guidelines define the limits using a unit of measurement known as the Specific Absorption Rate (SAR), which represents the average amount of radio frequency energy absorbed by the human body. The SAR limit for cell phones is 2.0 W/kg. The highest SAR value for this cell phone when tested for use at the ear is 0.875W/kg value for this cell phone when tested for use on the body is

0.511W/kg

(*2)

. There may be slight differences in SAR levels among individual products, but they all satisfy the limit. The actual SAR of this cell phone while talking on the

(*2)

. The highest SAR

Appendix

Page 88

phone can be well below that indicated above. This is due to automatic changes in the power level of the cell phone to ensure it only outputs the minimum power required to communicate with a base station. Therefore in general, the closer you are to a base station, the lower the power output of the cell phone is. This cell phone can be used in positions other than against your head. Use a carrying case or similar accessory that holds the phone at least 1.5 cm separated from the body and ensure no metal parts are located between you and the cell phone. Under these conditions, this cell phone satisfies Japanese technical regulations and international guidelines for radio wave protection. The World Health Organization has stated that "a large number of studies have been performed over the last two decades to assess whether mobile phones pose a potential health risk. To date, no adverse health effects have been established as being caused by mobile phone use". . If you would like to know more detailed information, please refer to the WHO website.

(

http://www.who.int/docstore/peh-emf/publications/ facts_press/fact_english.htm

Appendix

Please refer to the websites listed below if you would like to

)

know more detailed information regarding SAR.

○ Ministry of Internal Affairs and Communications

website

(

http://www.tele.soumu.go.jp/e/sys/ele/index.htm

)

○ Association of Radio Industries and Businesses

website

(

http://www.arib-emf.org/01denpa/denpa02-02.html) (in Japanese only)

○ au homepage

(

https://www.au.com/english/

*1 Technical regulations are defined by the Ministerial Ordinance Related to

Radio Law (Article 14-2 of Radio Equipment Regulations).

*2 This includes the wireless function that can be used simultaneously.

)

For the following content, refer to the "取扱説明書（詳細版） (Full Instruction Manual)" (Japanese) available on the au homepage.

• FCC Notice

• OpenSSL License From your PC:

(

https://www.au.com/support/service/mobile/guide/

)

manual/

Page 89

Export Administration Regulations

This product and its accessories may be subject to the Japan Export Administration Regulations ("Foreign Exchange and Foreign Trade Law" and its related laws). In addition, U.S. Reexport Regulations (Export Administration Regulations and the related laws and regulations) may apply to this product and its accessories. To export and re-export this product and its accessories take the required measures on your responsibility and at your expenses. For details on the procedures, contact the Ministry of Economy, Trade and Industry, the U.S. Department of Commerce.

Intellectual Property Rights

Trademarks

Company names and product names referred to in this manual are trademarks or registered trademarks of the respective companies.

Google and Google logo, Android and Android logo, Google Play and Google Play logo, Play Music and Play Music logo, Play Movies & TV and Play Movies & TV logo, Gmail and Gmail logo, Google Maps and Google Maps logo, Google Drive and Google Drive logo, Google Maps Navigation and Google Maps Navigation logo, Google Chrome and Google Chrome logo, Google Voice Search and Google Voice Search logo, YouTube and YouTube logo are trademarks or registered trademarks of Google, LLC

Microsoft®, Windows® and Windows® 7/Windows® are registered trademarks of Microsoft Corporation in the U.S.A. and other countries. The official name for Microsoft® Windows® is Microsoft®

Windows

Operating System.

, Microsoft® Excel®, Microsoft® PowerPoint®,

Microsoft

8.1/Windows® 10

Appendix

Page 90

Windows Media®, and Exchange® are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries.

Microsoft

Word and Microsoft® Office are product names of

Microsoft Corporation in the United States.

QR code is a registered trademark of DENSO WAVE INCORPORATED.

microSD, microSDHC and microSDXC logos are trademarks of SD-3C, LLC.

Bluetooth

and logo are registered trademarks owned by the Bluetooth SIG, Inc., and KYOCERA Corporation is licensed to use those trademarks.

WiMAX is a trademark of WiMAX Forum.

Wi-Fi®, WPA®, Wi-Fi CERTIFIED logo, Wi-Fi Protected Setup logo, Wi-Fi Direct Alliance. Wi-Fi CERTIFIED™ and Wi-Fi Protected Setup are trademarks of Wi-Fi Alliance.

Facebook and Facebook logo are trademarks or registered trademarks of Facebook, Inc.

Twitter and Twitter logo are trademarks or registered trademarks of Twitter, Inc., and are used under license.

Appendix

Instagram is a trademark of Instagram, LLC in the U.S. and other countries.

, and Miracast® are registered trademarks of Wi-Fi

Reserved.

THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NONCOMMERCIAL USE OF A C ONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD ("MPEG4 VIDEO") AND /OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY O THER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG L A, LLC. SEE HTTP://WW W.MPEGLA.COM.

(1)

ACCESS, the ACCESS logo, and NetFront are registered trademarks or trademarks of ACCESS CO., LTD. in the United States, Japan and/or other countries.

(2) This software is based in part on the work of the

Independent JPEG Group.

"SMART SONIC RECEIVER" is a registered trademark of KYOCERA Corporation.

"もじチェン " by LIM Corporation LTD. is used for switching font. "もじチェン " is a registered trademark of LIM Corporation LTD. The product contains fonts provided by LIM Corporation LTD. The product contains fonts provided by Morisawa Inc.

Page 91

"PhotoSolid", the function to avoid blurring still images, is a product of Morpho, Inc. "PhotoSolid" is a registered trademark of Morpho, Inc. "MovieSolid", the function to avoid blurring videos, is a product of Morpho, Inc. "MovieSolid" is a registered trademark of Morpho, Inc. "PhotoScouter", the scene detection technology, is a product of Morpho, Inc. "PhotoScouter" is a registered trademark of Morpho, Inc. "Morpho Rapid Effect", the image effect technology, is a product of Morpho, Inc. "Morpho Rapid Effect" is a trademark of Morpho, Inc. Morpho HDR is adopted for HDR (High Dynamic Range) technology. "Morpho HDR" is a trademark of Morpho, Inc.

Qualcomm Quick Charge is a product of Qualcomm Technologies, Inc., and Qualcomm is a registered trademark of Qualcomm in the United States and other countries.

USB Type-C

All other company names and product names are trademarks or registered trademarks of respective companies.

is a trademark of USB Implementers Forum.

License

Users of the product are authorized to use software installed into the product described in this instruction manual. Pay attention to the following points when using the software. (a) The software installed on this product or part of it may not be

altered, delivered, modified, analyzed, reverse-engineered,

derived, and any such actions are prohibited. (b) Illegally importing the software or a par t of it is prohibited. (c) This Software is provided without implied warranties

of merchantability, fitness for a particular purpose and

noninfringement of third party rights. Note that the existing license agreement takes priority for usage of GNU General Public License (GPL), GNU Library/Lesser General Public License (LGPL) included in software, software based on other open source software license and software that KYOCERA Corporation is licensed. For information on the Open source software, refer to "Open Source Software" as follows;

Appendix

Page 92

■ Open Source Software

Note that the existing license agreement takes priority for usage of GNU General Public License (GPL), GNU Library/L esser General Public License (LGPL) included in software, software based on other open source software license and softw are that KYOCERA Corporation is licensed. The exact terms of GPL, LGPL and some other licenses are reproduced in "About phone" in this product. For details, refer to KYOCERA homepage. This pro duct include s sof tware copyrighted by KYOCERA Corporation and licensed sof tware. Copyright of the soft ware designed and developed complying with the open source s oftware s tandard belongs to KY OCERA Corporation or the third parties, distribution, reproduction, transformation and transmission over public lines without consent of KYOCERA Corporation are prohibited, unless you are authorized or permitted by Copyright Law.

■ Recording Diagnosis and Usage

Condition Data

KYOCERA Corporation asks for users' cooperation in order to improve the quality of products and services. KYOCERA Corporation records and saves data of failure diagnosis and the usage conditions (application usage by users, log elated to error, detail information of application usage by users (specified

Appendix

functions, usage frequency, memory/battery status)) in the product in order to track and cope with diagnosis events such as unexpected shutdown or system error for the purpose of improvement of quality and services. Those information may be collected upon repair request by user after obtaining the user agreement.

Page 93

For inquiries, call:

Customer Service Center

For general, charge, operations (toll free)

Business hours 9:00 to 20:00 (7 days a week)

From ﬁxed-line phones:

0077-7-111 157

Pressing "zero" will connect you to an operator, after calling "157" on your au cellphone.

In case above numbers are not available (for free),

0120-977-033

0120

977-699

For service canceling procedure in case of loss or theft

Business hours 24-hour (7 days a week)

From ﬁxed-line phones: From au cell phones:

-7-

113

0077

In case above numbers are not available (for free),

0120-925-314

Repair and Delivery Support Center

For loss, theft or damage

Business hours 9:00 to 20:00 (7 days a week)

From ﬁxed-line phones/au cell phones,

0120-925-919

From au cell phones:

area code not required

(except Okinawa)

(Okinawa)

(toll free)

113

area code not required

(toll free)

濡れた状態での充電は、異常な発熱・焼損などの原因となり大変危険です。

Cell phone and P HS operators collect and re cycle unused telephones, bat teries and battery chargers at sto res bearing the logo regardless of bra nd and manufacturer to protect the enviro nment and reuse valuable resources.

November 2017, 1st Edition Sales: KDDI CORPORATION •OKINAWA CELLULAR TELEPHONE COMPANY Manufactured by: KYOCERA Corporation

Kyocera Basio 3 User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Preface

List of Packaged Items

Regarding Notations Used in This Document

Operating Instructions

Contents

Getting Ready

Names and Functions of Parts

au IC Card

Internal Shared Storage

Using microSD Memory Card

Charging

Turning the Power On/Off

Start Screen

Switching to English Display

Making Initial Settings

Making Initial Settings for au-mail

Basic Operations

Using Touch Panel

home screen

Using Touch Keys

Using the Home Screen

Activating the Apps

Monitoring the Product's Status

Checking Your Phone Number

Setting Silent Mode

Setting Airplane Mode

Using Screen Memo

Setting Direct Buttons

Character Entry

Receiving a Call

Making a Call

Setting Step-up Ring Volume

Displaying Menu

Setting Home Screen

Saving Battery Consumption

Using the Camera

Safety Precautions

When Using the Product

Safety Precautions (Observe Strictly)

Handling Precautions

Notes on Water and Dust Resistance

Notes on Using Bluetooth®/ Wireless LAN (Wi-Fi®) Function

Security Code/PIN Code

Notes on Data Communication Charges

Notes on Applications

Setting the App Permissions

Cell Phone Etiquette

Appendix

Updating Software

Troubleshooting

After-Sales Service

SIM Unlock

Related Accessories

Export Administration Regulations

Intellectual Property Rights
