Kubota U17-3 Tier4 Operator's Manual
PRINTED IN JAPAN
English (Australia)
Code No. RA238-8130-3
©
KUBOTA Corporation 2008
U
17
-
3
1BAABBKAP0260
MODEL U17-3
LIST OF ABBREVIATION
Abbreviations
API
ASTM
CECE
DIN
EN
FOPS
Front
Hi
ISO
JIS
L
Lo
L/min
MIL
ROPS
rpm
SAE
Description
American Petroleum Institute
American Society for Testing and Materials, USA
Commitee for European Construction Machinery
German Institute for Standards, Federal Republic of
Germany
European Standard
Falling Object Protection System
“Front” means the front view towards the boom and
dozer
High speed
International Organization for Standardization
Japanese Industrial Standard
Volume (Liter)
Low speed
Liter per minute
Military Standards
Roll-over Protective Structures
Revolutions Per minute
Society of Automotive Engineering
U17-3
English (Australia)
AQ . B . 7 - 7 . 2 . AK
GENERAL SYMBOLS
3
Safety alert Symbol
T
Warning lamp “Fuel level too low”
System lamp
l
Warning lamp “Engine Oil pressure”
g
Warning lamp “Battery charge”
Warning lamp “Auto Idle (AI) Lamp”
Indicator lamp “Glow”
7
Working light switch
5
Horn
Z
Wiper/Washer switch
R
Diesel
E
Hydraulic fl uid
W
Gear oil
Grease
j
Fast
k
Slow
Excavator - Overhead movement toward
the front
Excavator - Overhead movement toward
the rear
æ
Boom up
…
Boom down
≥
Arm up
≤
Arm crowd
‘
Bucket crowd
The instruments and operation elements have been marked with a series of symbols in order
to simplify the operation of your excavator. These symbols are listed below with the respective
descriptions.
“
Bucket dump
”
Boom swing (left)
’
Boom swing (Right)
Dozer raise
Dozer lower
Operation direction of control lever
Operation direction of control lever
V
Read operator’s manual
c
Engine stop control lamp
Lock
Unlock
Reducing / Increasing track width
FOREWORD
You are now the proud owner of a KUBOTA excavator. This excavator
is a product of KUBOTA quality engineering and manufacturing. It is
made of the fi ne materials and under rigid quality control systems. It
will give you long, satisfactory service. To obtain the best use of your
excavator, please read this manual carefully. It will help you become
familiar with the operation of the excavator and contains many helpful
hints about excavator maintenance. It is KUBOTA’s policy to utilize as
quick as possible every advance in our research. The immediate use of
new techniques in the manufacture of products may cause some small
parts of this manual to be outdated. KUBOTA distributors and dealers
will have the most up-to-date information. Please do not hesitate to
consult with them.
3
SAFETY FIRST
This symbol, the industry’s “Safety Alert Symbol”, is used throughout
this manual and on labels on the machine itself to warn of the
possibility of personal injury. Read these instructions carefully. It is
essential that you read the instructions and safety regulations before
you attempt to assemble or use this unit.
3
DANGER : Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
3
WARNING : Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious
injury.
3
CAUTION : Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate
injury.
IMPORTANT : Indicates that equipment or property damage
could result if instructions are not followed.
NOTE : Gives helpful information.
CONTENTS
3
SAFE OPERATION ..................... 1
DEALER SERVICE ...........................13
TECHNICAL DATA ...........................14
Operating Instructions
DESCRIPTION OF
MACHINE PARTS ........................15
INSTRUMENT PANEL AND
CONTROL ELEMENTS ...............16
BEFORE START ...............................18
DAILY CHECKS ............................18
TILTING THE SEAT ......................18
OPENING AND
CLOSING OF PARTS ..............18
HANDLING THE SAFETY
DEVICES .................................21
OPERATION OF THE ENGINE ........22
STARTING THE ENGINE ............22
STARTING THE ENGINE
UNDER COLD CONDITIONS ....27
STOPPING THE ENGINE .............27
STARTING WITH
AN AUXILIARY BATTERY ......28
EXCAVATOR OPERATION ..............29
CONTROL OBSERVATIONS
DURING OPERATION ............29
RUNNING-IN OF
THE NEW EXCAVATOR ........29
STARTING ..................................29
TWO PATTERN SELECTION
SYSTEM (TPSS) ......................31
OPERATION OF THE BOOM .......32
OPERATION OF THE ARM ..........32
OPERATION OF BUCKET ...........33
SWIVEL (UNIT SWING)
OPERATION ............................33
BOOM SWING OPERATION ......34
BOOM SWING PEDAL ................34
OPERATION OF
TRACK WIDTH CHANGE
AND DOZER ...........................35
SERVICE PORT OPERATION ......37
DRIVING .....................................37
TURNS .......................................39
UP AND DOWNHILL
TRAVELLING ..........................41
PARKING ON A SLOPE ...............41
IMPORTANT INFORMATION ON
EXCAVATOR OPERATION ......42
TRANSPORTING THE EXCAVATOR
ON A TRUCK ...............................43
LIFTING OF THE EXCAVATOR ........45
Care and Maintenance
MAINTENANCE ..............................47
MAINTENANCE INTERVALS ......47
DAILY CHECKS ............................49
REGULAR CHECKS AND
MAINTENANCE WORK ..............54
EVERY 50 SERVICE HOURS ......54
EVERY 200 SERVICE HOURS ....56
EVERY 250 SERVICE HOURS .....56
EVERY 500 SERVICE HOURS .....59
EVERY 1000 SERVICE HOURS ...62
EVERY 1000 SERVICE HOURS OR
ONCE A YEAR .........................63
EVERY 2000 SERVICE HOURS ....63
ANNUAL SERVICING ................64
BIENNIAL SERVICING ...............64
OTHER SERVICING ....................65
OTHER ADJUSTMENTS AND
REPLACEMENTS .......................66
PURGING OF THE FUEL
SYSTEM .................................66
ADJUSTMENT OF TRACKS ........66
EXCHANGE OF BUCKET TEETH
AND SIDE CUTTERS
[JPN BUCKET VERSION] ........68
FUSES .........................................70
TROUBLESHOOTING .....................71
OPERATION UNDER COLD
WEATHER CONDITIONS ...............75
PREPARATION FOR OPERATION
IN COLD WEATHER ...............75
PROCEDURE AFTER
DONE WORK ..........................75
LONG STORAGE ............................76
RECOMMENDED OILS ...................78
MAIN DIMENSIONS ......................79
LIFTING CAPACITY ........................80
1
The best insurance against accidents is to
abide by the safety regulations.
Read and understand this section carefully,
before operating the excavator.
Every user, however experienced, should
carefully read and understand this section
and those of the attachments and accessories
before taking the excavator into operation.
The owner is obliged to inform the operators
of these instruction in detail.
Keep this manual in the storage place. (See
"Keeping the Operator's Manual" in the
BEFORE START section.)
1. BEFORE OPERATION
1. Make yourself acquainted with the
excavator and be aware of its limits.
Read this operator’s manual carefully
before starting the excavator.
2. Obey the danger, warning and caution
labels on the machine.
3. For your safety, ROPS/FOPS (Roll-Over
Protective Structures, Falling Objects
Protective Structures.) with a seat belt
is installed by KUBOTA. Always use the
seat belt when the machine is equipped
with a ROPS/FOPS.
If ROPS is loosened or removed for
any reason, make certain all parts are
reinstalled correctly. Tighten mounting
bolts to proper torque. Do not use the
seat belt if there is no ROPS.
Do not modify structural members of
ROPS by welding, drilling, bending,
grinding or cutting, as this may weaken
the structure. If any component is
damaged, replace it. Do not attempt
repairs.
4. The seat belt must be inspected regularly
and replaced if frayed or damaged.
3
SAFE OPERATION
(1) Seat belt
2
6. Track can be set at the narrow width 39in.
(990mm) and the standard width 49in.
(1240mm).
(for details see “OPERATION OF TRACK
WIDTH CHANGE AND DOZER”)
Do not operate in narrow track width
39in. (990mm), it makes risk of the
excavator tipping over, operate always
in standard track width 49in. (1240mm),
except to pass through narrow space on
a even ground.
7. Do not use the excavator under the
infl uence of alcohol, medication as well
as other substances. Fatigue is also
dangerous.
8. Check the surroundings carefully before
using the excavator or when attachments
are being attached.
Pay attention to the overhead clearance
with electric wires.
Check for pipes and buried cables.
Check for hidden holes, hindrances, soft
underground and overhangs.
During excavator use do not allow any
persons within the working range.
9. Do not allow other persons to use
the machine before having informed
him on the exact operation and work
instructions, and be assured that the
operator’s manual has been read and
understood.
10. Do not wear baggy, torn or too large
clothing when working with the
excavator. Clothing can get caught in
rotating parts or control elements which
can cause accidents or injuries. Wear
adequate safety clothing, e.g. safety
helmet, safety shoes, eye protection,
ear protection, working gloves, etc., as
necessary and as prescribed by law or
statutes.
(1) Helmet
(2) Clothing fi t for work
(3) Tight seams
(4) Good grip shoewear
(5) Well fi tting cuffs
(6) Working gloves
(7) Straw hat
(8) Towel
(9) Baggy trousers
(10) Loose cuffs of the shirt
(11) Baggy shirt
(12) Rubber sandals
3
11. Do not allow passengers to get on any
part of the excavator seat throughout
operation.
12. Check mechanical parts for correct
adjustments and wear. Exchange worn
or damaged parts immediately.
13. Keep your excavator clean. Heavy
soiling, grease, dust and grass can
infl ame and cause accidents or injuries.
14. Use only KUBOTA authorized
attachments.
15. Before starting the excavator, be
absolutely sure that the excavator has
been fi lled with fuel, lubricated, greased
and undergone other maintenance
work.
16. Do not modify the excavator, otherwise
it could lead to unforeseen safety
problems.
17. Make sure attachments, particulary
those utilizing quick attach systems, are
securely mounted.
2. STARTING OF THE EXCAVATOR
1. Get into and out of the machine safely.
Always face the machine. Always use
handrails and available steps and keep
yourself well balanced. Do not hold any
of the control Ievers and switches. Do
not jump on or off the machine, whether
stationary or in motion.
2. Start and control the excavator only from
the operator’s seat. The driver should not
lean out of his seat when the engine is
running.
3. Before starting the engine, make sure
that all control levers (including auxiliary
control levers) are in their neutral
positions.
4. Do not start the engine by jumping
the starter connections. Do not try to
circumvent using the starter switch,
otherwise the engine could start suddenly
and the excavator could move.
5. Make sure that the dozer is on the front
side. (The dozer must be raised.) If the
levers are activated with the dozer on the
rear end, the driving direction is in the
opposite direction of the drive levers.
4
6. Do not run the engine in closed or badly
ventilated rooms. Carbon monoxide is
colourless, odourless and deadly.
7. Keep all safety equipment and covers
in place. Replace damaged or missing
safety device.
8. Precautions against tipping over. In order
to secure safe operation, keep away from
steep slopes and embankments. Do not
swing the bucket downwards. Lower the
dozer during digging. Keep the bucket as
low as possible while driving upwards.
Turn slowly on slopes (do not fast). Do
not keep the excavator near the edges
of trenches and banks, as the earth
can give away due to the weight of the
excavator.
9. Watch out at all times where the
excavator is being moved to. Keep an
eye out for hindrances.
10. Keep enough distance from trench and
bank edges.
Safety for children
Tragedy can occur if the operator is not
alert to the presence of children. Children
generally are attached to machines and the
work they do.
1. Never assume that children will remain
where you last saw them.
2. Keep children out of the work area
and under the watchful eye of another
responsible adult.
3. Be alert and shut your machine down if
children enter the work area.
4. Never carry children on your machine.
There is no safe place for them to
ride. They may fall off and be run over
or interfere with your control of the
machine.
5. Never allow children to operate the
machine even under adult supervision.
6. Never allow children to play on the
machine or on the attachments.
7. Use extra caution when backing up. Look
behind and down to make sure the area
clear before moving.
8. When parking your machine, if at all
possible, park on a fi rm, fl at and level
surface; if not, park across a slope. Lower
the bucket and dozer to the ground,
remove the key place the control lock
levers in the locked position from the
ignition before you leave.
3. AFTER OPERATION
Before leaving the machine,
Bring the excavater on a fi rm, fl at and
level surface.
Lower the attachments and the dozer
blade on the ground.
Stop the engine.
Lock all control levers.
Remove the key.
(1) lock lever for control lever (A) “Lock”
(Left side) (B) “Unlock”
5
4. SAFE LOADING AND TRANSPORT
OF THE EXCAVATOR
1. Observe all regulations concerning the
transport of excavators on public roads.
2. Use adequately long and robust ramps
when loading on a truck. (for details see
“TRANSPORTING THE EXCAVATOR ON
A TRUCK”)
3. Do not change the running direction
and to avoid a tipping over, do not try to
swing the attachment crosswise to the
loading ramps.
4. After loading of the excavator on a truck,
engage the swing lock pin.
Lower the attachment on the loading
plane and release the pressure from the
hydraulic system.
Block the tracks with blocks and wire
down the excavator. After loading the
excavator on a truck, tie down the
undercarriage of the excavator with a
strong steel wire on the truck.
(1) Swing lock pin (A)”Unlock”
(B)”Lock”
5. Do not brake abruptly with the excavator
loaded. Mortal accidents could happen.
6. If the excavator is used to tow another
machine, the load must be smaller than
the strength of the hook.
7. Do not use hooks on the roof of canopy
for lifting the excavator.
5. MAINTENANCE
Before doing maintenance work on the
excavator, place the machine on a fi rm, fl at
and level surface, Iower the attachments on
the ground, stop the engine then remove
the key and release the cylinder pressure
by actuating the levers. When dismantling
hydraulic parts, make sure that the hydraulic
oil has cooled down suffi ciently to avoid
burns.
Start maintenance work carefully, e.g. loosen
screws slowly so that oil will not squirt out.
1. Before doing work on the engine, the
exhaust system, the radiator and the
hydraulics, let the excavator cool down
suffi ciently.
2. Turn off the engine at all times when
fi lling with fuel. Avoid spilling and overfi lling of fuel.
3. Smoking is prohibited while tanking
and handling the battery! Keep sparks
and fi re away from the fuel tank and
battery. Flammable gases escape from
the battery, especially during charging.
4. Do not use or charge the refi llable
type battery if the fl uid level is below
the LOWER (lower limit level) mark.
Otherwise, the battery component parts
may prematurely deteriorate, which
may shorten the battery's service life
or cause an explosion. Check the fl uid
level regularly and add distilled water as
required so that the fl uid level is between
the UPPER and LOWER levels.
5. Read and follow “STARTING WITH AN
AUXILIARY BATTERY” in “OPERATION
OF THE ENGINE”, when starting with an
auxiliary battery.
Max. drawbar pull at
coupling hook
Max. vertical load at
coupling hook
32.3 kN (3290 kg)
2.7 kN (270 kg)
6
6. To avoid short-circuiting the battery,
always remove the earth cable fi rst and
attach the plus cable fi rst.
7. Keep a fi rst-aid box and a fi re extinguisher
at hand at all times.
8. Do not open the radiator cap before the
radiator has cooled down suffi ciently.
First loosen the cap to the fi rst stop and
allow the system enough time to release
the remaining pressure. Then loosen the
cap completely.
9. Leaking hydraulic fl uid has enough
pressure to penetrate the skin and cause
serious injuries. Leakages from pin
holes can be totally invisible. Do not use
the bare hand for checking on possible
leakages. Always use a piece of wood or
cardboard. It is strongly recommended
to use a face mask or eye protection.
Should injuries occur with leaking
hydraulic fl uid, contact a doctor
immediately. This fl uid can cause
gangrene or serious allergic reactions.
10. To avoid leakage of battery acid which
contains heavy metals, do not throw the
battery away.
11. Observe all laws and regulations
concerning the disposal of used oil,
coolants, solvents, hydraulic fl uids,
battery acids and batteries.
12. To avoid fi re, do not heat the hydraulic
components (tanks, pipes, hoses,
cylinders) before they are drained and
washed.
13. Use a face mask or eye protection to
protect the eyes and respiratory system
against dust and other foreign particles.
14. Securely support excavator with stands
or suitable blocking before working
underneath. For your safety, do not
work under any hydraulically supported
devices. They can settle, suddenly leak
down, or be accidentally lowered.
15. Do not crawl under the excavator if the
excavator is only supported by the boom
and arm or the dozer. The excavator can
tip over or lower itself due to hydraulic
pressure loss. Always use safety struts
or other appropriate supports.
16. KUBOTA uses no parts which are lined
with asbestos. Do not use these kind of
parts even if they can be installed.
7
(1) Code No. RA238-5748-2 (2) Code No. RA228-5733-1
6. DANGER, WARNING AND CAUTION LABELS
8
(1) Code No. RC418-5753-2
(2) Code No. RA228-5762-1
(3) Code No. RD517-5795-2
[Both sides]
9
(1) Code No. RC418-5728-4
(2) Code No. RC418-5727-4
(3) Code No. RD809-5736-1
(5) Code No. RA228-5751-2
1BAAAARAP1000
(4) Code No. RD809-5738-2
10
(1) Code No. RC108-5718-1
(3) Code No. RD148-5736-1
Diesel fuel only No fi re
(2) Code No. RA228-5728-2
[Both sides]
(4) Code No. RA228-5776-1
(5) Code No. 68328-5735-1 [Both sides]
(6) Code No. RC108-5796-1
[Both sides]
(7) Code No. RB419-5796-2
[Both sides]
11
7. CARE OF DANGER, WARNING AND CAUTION LABELS
(1) Keep danger, warning and caution labels, clean and free from obstructing material.
(2) Clean danger, warning and caution labels with soap and water, dry with a soft cloth.
(3) Replace damaged or missing danger, warning and caution labels with new labels from your
KUBOTA dealer.
(4) If a component with danger, warning and caution label (s) affi xed is replaced with new
part, make sure new label (s) is (are) attached in the same location (s) as the replaced
component.
(5) Mount new danger, warning and caution labels by applying on a clean dry surface and
pressing any bubbles to outside edge.
(1) Code No. RB238-5737-1 (2) Code No. RC418-5737-2
(3) Code No. TC030-4958-1
(4) Code No. RC108-5754-1
1BAAAAQAP0860
13
DEALER SERVICE
Your KUBOTA dealer is always ready to
help so that your excavator offers the best
performance. After having carefully read
this manual, you will realize that much of
the routine maintenance can be done by
yourself. Your KUBOTA dealer is responsible
for servicing and the delivery of spare
parts. When ordering spare parts from your
KUBOTA dealer, always mention the serial
number of the excavator and the engine.
Note these numbers right away in the
supplied lines.
Model Serial No.
Excavator
Engine
Dealer's name
(To be fi lled in through the owner)
(1) Serial No.
(1) Engine serial No.
14
TECHNICAL DATA
NOTE:
Above dimensions are based on the machine with rubber trucks and JPN bucket.
JPN = made in Japan
Specifi cations subject to change without notice.
∗ With unloaded digging bucket.
∗ Firm compacted soil.
∗ Operators must exercise extra caution and follow instructions in the operator's manual.
∗ Worse condition or heavier attachment to the above will decrease climbing angle.
Model name
U17-3
Canopy
Water cooled 4 cycle diesel engine with 3 cylinder
KUBOTA D902
2300
9.1
1.4 (2.1)
2.6 (4.1)
58 (30)
65 (1.13)
58 (1.01)
5.0 (19)
39.0/48.8 X 10.2 (990/1240 X 260)
3.7
26
[0.26]
2702
(18.6)
[190]
7.13 (27)
3704 (1680)
898 (54.8)
12.7 (17.0)
KUBOTA EXCAVATOR
Type
Operating weight
(including operator's)
Type
Engine
Performance
Model name
Total displacement
cc (cu.in)
Engine power
SAE gross
Rated speed
Unit swing speed
Travel
speed
Ground
pressure
(With operator)
Max. displacement
(Theoretical)
Max. pressure
Climbing angle
Dozer
Fuel tank capacity
Left
Boom swing angle
Pressure
connection
for
attachments
Right
Fast
Slow
Width X Height
lbs.(kg)
kW(Hp)
rpm
rpm
mph (km/h)
mph (km/h)
psi
(kPa)
[kgf/cm
2
]
%(deg)
in.(mm)
deg (rad)
deg (rad)
US gal (L)/min
US gal (L)
psi
(MPa)
[kgf/cm
2
]
15
DESCRIPTION OF MACHINE PARTS
DEPICTED CONTENTS
(1) Arm
(2) Bucket cylinder
(3) Bucket link
(4) Bucket
(5) Swing bracket
(6) Dozer cylinder
(7) Dozer
(8) Arm cylinder
(9) Boom
(10) Working light
(11) Canopy (Rops / Fops)
(12) Operator’s seat
(13) Boom cylinder
(14) Drive sprocket
(15) Track roller
(16) Front idler
16
INSTRUMENT PANEL AND CONTROL ELEMENTS
Instrument Panel, Switches
DEPICTED CONTENTS
(1) Horn switch
(2) Starter switch
(3) Warning lamp
(4) LCD display
(5) Working light switch
(6) Display selector switch
(7) Working light
17
Control Pedals and Levers
DEPICTED CONTENTS
(1) Drive lever (left)
(2) Control lever for front attachments (left)
(3) Lock lever for attachment control
(4) Service port pedal
(5) Drive lever (right)
(6) Control lever for front attachments (right)
(7) Two travel speed switch
(8) Control lever for dozer or track width
(9) Throttle lever
(10) Boom swing pedal
(11) Track width change / dozer select lever
18
BEFORE START
DAILY CHECKS
In order to avoid damage, it is important to
check the condition of the excavator before
starting.
3
CAUTION
To avoid personal injury:
Do maintenance work on the
excavator only on even ground
with the engine off and the
safety devices in the “Lock”
position.
Checks
Walk around the excavator and check for
visual damage and wear.
Check coolant level. (See regular checkpoints
in “MAINTENANCE”.)
Check fuel level.
Check engine oil level.
Check hydraulic fl uid level.
Check air fi lter for clogging.
Check all control lamps, indicators, engine
rpm's counter and hour meter.
Check the light system.
Check the seat belt and the Rops/Tops safety
device.
Check the condition of the danger, warning
and caution labels. (See "DANGER,
WARNING AND CAUTION LABELS" in "SAFE
OPERATION" .)
TILTING THE SEAT
3
CAUTION
To avoid personal injury:
Lock the lever for attachment
control when tilting the seat.
To tilt the seat forward, pull the seat tilting
lock lever and tilt the seat forward.
(1) Seat tilting lock lever (A) “Tilting forward”
(2) Lock lever for (B) “Lock”
attachment control
OPENING AND CLOSING OF
PART S
Opening / Closing the Rear
Bonnet
3
CAUTION
To avoid personal injury:
Do not touch the exhaust
muffl er or the exhaust pipe;
serious burns can occur.
1. Put the starter key in the key slot and
turn it clockwise to the vertical position.
The rear bonnet will be unlocked. Press
the button, and the rear bonnet can be
opened sideways.
When the rear bonnet is opened, the rear
bonnet will be locked with the lock lever.
19
2. To close the rear bonnet, make sure the
left bonnet is locked, unlock the lock
lever and push the rear bonnet until it
clicks into position. To lock the bonnet,
turn the starter key counterclockwise to
the horizontal position.
(1) Key (A) “Lock”
(2) Rear bonnet (B) “Unlock”
(3) Button
(1) Lock lever (A) “Lock”
(B) “Unlock”
IMPORTANT:
Do not run the machine with the bonnet
open. The bonnet may get damaged.
Opening/closing the left bonnet
1. Remove the rubber mat off the left
bonnet side. Then undo the step fi xture.
(1) Rubber mat
(2) Left bonnet
2. To open the left bonnet, do this: open the
rear bonnet fi rst and then turn the wing
nut, located as shown below, to unlock
the left bonnet.
(1) Left bonnet
(2) Rear bonnet
(3) Wing nut
3. To close the left bonnet, do this: push it
back into position, apply the lock fi xture
in place and hand-tighten the wing nut.
4. Spread the rubber mat back in its original
place.
Loading...
