KRUPS KP1010 User Manual

www.krups.com

03

21

05

Home café KP1000/1010

English 4

Instructions for Use
Limited Warranty

Français 15

Mode d’emploi
Garantie

summary.PM6.5 7/04/05, 10:383

3

English

Home cafe KP1000 US.PM6.5 18/04/05, 14:284

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and/or
injury to persons including the following :

1. Read the instructions carefully before using your appliance for
the first time: use that does not comply with the instructions
will release Krups from any responsibility.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against fire, electric shock and injury to persons, do
not place cord, plugs or appliance in water or other liquid.

4. Close supervision is necessary when any appliance is used near
children. Keep appliance out of reach of children.

5. Unplug from outlet when not in use and before cleaning. Allow
to cool before putting on or taking off parts, before cleaning
the appliance, and before storing.

6. Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or has been damaged in any
manner. Return appliance to the nearest KRUPS Service Center
for examination, repair or adjustment.

7. The use of accessory attachments not recommended by KRUPS
may result in fire, electric shock or injury to persons.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot
surfaces.

10. Do not place on or near a hot gas or electric burner, or in a
heated oven.

11. Before unplugging the appliance, check that it is not switched
on (light off).

12. Do not use the appliance for other than intended use.

13. Do not pour liquids other than water and descaling solutions
specified in this manual into the water tank.

14. Do not operate the coffee maker without water.

15. Make sure that the upper lid is properly locked before starting
the brew process.

4

16. Do not unlock the upper lid while coffee is being prepared.

Home cafe KP1000 US.PM6.5 18/04/05, 14:285

17. This appliance is for household use only. Any servicing, apart
from cleaning and maintenance mentioned in the manual,
should be carried out by a Krups approved service center.

The cord should be arranged so that it does not hang over the
work top or table, in order to prevent children being able to pull on
it or someone accidentally tripping and falling.

SAVE THESE INSTRUCTIONS

SHORT CORD INSTRUCTIONS

A. The length of the cord has been chosen to reduce the risk of

accidents.

B. Extensions are available and may be used with care.
C. If you use an extension,

1) If you use an extension, its electric capacity must be equal to
or greater than that of the appliance,

2) The extension and the cord should be arranged so that they
do not hang over the work top or table, in order to prevent
children being able to pull on them or someone accidentally
tripping and falling.

D. This appliance has a polarized plug (one blade is wider than

other). To reduce risks of electric shock, this plug is intended to
fit into a polarized outlet only one way. If the plug does not fit
fully into the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to modify the
plug in any way.

5

Description

Home cafe KP1000 US.PM6.5 18/04/05, 14:286

A Drip tray
B Drip tray plate
C Upper lid
D Lock button
E Tank lid
F Tank
G Spray head
H Coffee pod holder (one left-hand and one right-hand)
I Specialty pod holders (one left-hand and one right-hand)
J Water filter holder
K Water filtration change indicator
L Water filter (Duo filter)
M On/Off button
N Indicator light
O Brew button
P Brew selection control

Before first use

Read all instructions carefully.

• Remove all packaging.

• Rinse all components completely.

• Run through one brewing cycle.

• Fill the tank (F) with cold drinking water up to the “max” mark.

• Unlock the upper lid (C) using the button (D).

• Lift the upper lid.

• Position 2 coffee pod holders without the pods.
This machine is designed exclusively to be used with Home Cafe pods.

6

• Close and lock the upper lid (C) .

Home cafe KP1000 US.PM6.5 18/04/05, 14:287

• Place a container on the drip tray.

• Turn the Brew Selection Control (P) to the setting for two 9-oz cups.

• Press the on/off button (M).
The indicator light blinks slowly and then glows consistently when the coffee machine is ready.

• Press the brew button (O).

The indicator light blinks once and brewing starts, the container will be filled with hot water
rinsing the system. Discard the hot water. Your Home Cafe is now ready for use.

You can interrupt the brewing cycle by pushing the brew button. The brewing will stop and go
directly to the steam phase (purge). The indicator light will glow steadily at the end of this
phase.

If, during the brewing, you stop your machine by pressing the on /off button (M), your coffee
machine will stop. You will not have a steam (purge). Wait two minutes before opening the
brew head.

Immediately clean the spray heads and the seals using a damp cloth, then thoroughly wash
the pod holders.

If you change the volume during brewing by turning the selector (P) the new volume will be
used.

If your coffee machine is equipped with a Water Filtration

The Water Filtration is a double action anti-chlorine and anti-scaling filter.
The filter’s anti-chlorine action allows the most subtle flavors of the coffee to be released. The

level of chlorine in tap water very often prevents the flavor of the coffee from fully developing.
The anti-scaling action means that descaling operations are less frequent.
The components of the “Duo Filter” (plant-based active charcoal and anti-scaling resin) comply

with all food legislation.
The filter can be disposed of with household waste.

• Remove the “Duo Filter” (L) from its plastic bag. Rinse it under tap water for 1 minute.

• Lift the lid of your tank and remove the filter support (J).

• Release the lower part of this support and insert the filter in its housing.

• Replace the filter support in the coffee maker: your coffee maker is ready for use.

7

Note: An indicator is located on the upper part of the filter support to remind you when to

Home cafe KP1000 US.PM6.5 18/04/05, 14:288

change the “Duo Filter” (K):

• indicate the number corresponding to the month when the “Duo Filter” (L) is to be changed
on the indicator,

For example: If you insert the “Duo Filter” at the beginning of January, you should change it at
the beginning of May or June depending on the hardness of the water in your area.

Preparing Coffee

Do not use ground coffee or torn pods, as you risk damaging your coffee machine.
Do not put a regular coffee pod in the specialty pod holder.

• Fill the tank with fresh cold drinking water to the desired level.

(Never put milk or any other than water in the tank.)

• Press the on/off button (M) to start your appliance.

The indicator light blinks while the appliance is warming up.

• Unlock the upper lid (C) using the button (D).

• Lift the lid.

8
