KRUPS KM3108 Latteccino Instruction Manual

LATTECCINO

www.krups.com

p k

g m

l e

Fig.1 Fig.2 Fig.3

Fig.4 Fig.5 Fig.6

Fig.7 Fig.8 Fig.9

Fig.10 Fig.11 Fig.12

Fig.13 Fig.14 Fig.15

Fig.16 Fig.17 Fig.18

Fig.19 Fig.20 Fig.21

Fig.22 Fig.23 Fig.24

Fig.25 Fig.26 Fig.27

Fig.28

English

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons including the following:

■ Read all instructions.

■ Do not touch hot surfaces. Use handles or knobs.

■ To protect against fire, electric shock and injury to persons, do not immerse

cord, plugs or machine in water or other liquid.

■ Close supervision is necessary when any appliance is used by or near children.

■ Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleanning the appliance.

■ Do not operate any appliance with a dammaged cord or plug or after the appliance malfunctions, or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or adjustement.

■ The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock or injury to persons.

■ Do not use outdoors.

■ Do not let cord hang over edge of table or counter, or touch hot surfaces.

■ Do not place on or near a hot gas or electric burner, or in a heated oven.

■ Always attach plug to appliance first, then plug cord into the wall outlet.

To disconnect, turn any control to the "off" position, then remove plug from wall outlet.

■ Do not use appliance for other than intended use.

■ The container is designed for use with this appliance. It must never be

used on a range top.

■ Do not set a hot container on a wet or cold surface.

■ Do not use a cracked container or a container having a loose or weakened

handle.

■ Do not clean container with cleansers, steel wool pads, or other abrasive material.

■ Scalding may occur if the lid is removed during the brewing cycles.

■ Before connecting the appliance, check that the supply voltage of your

installation corresponds to that of the appliance and that the socket is earthed.

Any connection error will cancel the warranty.

■ Any intervention other than cleaning and usual maintenance by the customer must be carried out by an approved service centre.

■ If the power cord or plug is damaged, do not use the appliance. To avoid

English

any danger, have the power cord replaced by the manufacturer, its aftersales service, an approved service centre or similarly qualified persons. Do not put the appliance, power cord or plug in water or any other liquid.

■ Do not leave the power cord in reach of children.

■ Do not unplug the appliance by pulling on the power cord.

■ Do not use the jug over an open flame or on electric cooker plates.

■ Do not put water in the appliance if it is still hot.

■ Always close the lid (a) while the coffee maker is in operation.

■ All appliances are subject to strict quality control. Practical trials are carried

out with appliances selected at random, which explains any evidence of use.

■ The glass jug is safe to use in the microwave and dishwasher.

■ Do not use the jug without its lid.

■ The milk frother and jug are water-resistant, but should not be washed in

the dishwasher. Make sure that you clean the milk frother after each use to avoid the accumulation of milk and residue.

■ While the machine is in operation, do not touch the milk jug because it has a high temperature and could cause burns.

■ Splashes of milk can cause burns. Only use the milk jug with its lid.

■ The milk jug should only be used with the base supplied with it. Do not

use the base to heat any item other than the milk jug supplied with your appliance.

■ After switching on your coffee maker, never put your hand on the hotplate when you are removing the jug from the its support. While in operation, this plate has a very high temperature, which could cause burns.

SAVE THESE INSTRUCTIONS.

CAUTION

This machine is intended for household use only. Any servicing other than cleaning and user maintenance should be performed by the nearest authorized Krups Service Center. Visit our website at www.krupsusa.com in the USA or www.krups.ca in Canada or contact your respective country's Consumer Service department for the service center nearest to you, or contact your respective country’s Consumer Service department. To reduce the risk of fire or electric shock, do not attempt to disassemble the machine. Repair should be done by an authorized Krups Service Center only.

SHORT CORD INSTRUCTIONS

A. A short power cord or a detachable power cord is provided to reduce the risks of becoming

entangled in or tripping over a longer cord accidentally.

English

B. Longer detachable power cords or extension cords are available and may be used if care is exercised

in their use.

C. If a long detachable power cord or an extension cord is used:

1) the marked electrical rating of the detachable power cord or extension cord should be at least as great as the electrical rating of the appliance.

2) If the appliance is of the grounded type, the extension cord should be a grounding type 3-wire cord.

3) the longer cord should be arranged so that it will not drape over the counter where it can be pulled on by children or tripped over accidentally. The appliance may have a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug.

If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in anyway.

DESCRIPTION

Coffee maker a Lid b Water tank c Water level indicator d Filter holder e Carafe f Carafe hotplate g Button to turn on coffee cycle

Milk frother h Milk jug lock/unlock button i Milk jug j Milk frother lid k Milk jug heating plate l Hot milk start button m Milk Frother start button p Thermal sensor

Accessories n Measuring spoon o Spoonful of Easy Latte Macchiato

RECOMMENDATIONS

Befor e using your appliance for the first time

■ Remove all packaging, stickers and accessories from inside and outside the appliance - fig.1.

■ Run the filter coffee maker once without adding coffee using the equivalent of one Carafe of water to rinse

it (maximum 1 litre).

■ Wash the milk jug and the accessories with hot soapy water.

During use

■ Do not move the appliance during operation.

■ Do not unlock the milk jug while the appliance is heating.

■ While the machine is in operation, do not touch the milk jug or the glass Carafe as this could cause burns

- fig.2.

At the end of the cycle

■ Unlock the milk jug before picking it up.

■ Use the handle provided.

■ To open the lid, pull it upwards - fig.3.

■ Place the lid gently on a flat surface - fig.4.

English

CHOICE OF INGREDIENTS

Coffee

Opt for coffee that is suitable for filter coffee makers. Most commercially available ground filter coffee can be found in most good supermarkets. Avoid special espresso ground coffee because it can be too strong and bitter for this type of preparation. Close the packet of ground filter coffee carefully after use. To ensure the coffee stays fresh during storage, seal the packet of coffee after removing as much air as possible. Once opened, the packet of coffee should be kept in the fridge.

What variety of coffee should I choose?

■ For full-flavoured coffee

Go for pure Arabica coffee for use in filter coffee machines or coffee mainly made up of Arabica blends. Traditionally roasted coffee is preferred because its flavour offers more complexity and finesse.

■ For strong coffee

Choose a blend of Robusta and Arabica beans for a more robust tasting coffee.

Milk

■ This appliance allows you to froth and/or heat milk in two different ways in terms of frothing and temperature.

■ You may use skimmed, semi-skimmed or whole milk.

■ The use of special milk (enriched, soya, etc.) may give less satisfactory results particularly in terms of the

quality of the froth.

■ We always recommend using fresh, cold milk for best results.

Your ideas

■ To flavour your drinks, you can use syrup, (hazelnut, vanilla, caramel, cookies n’cream, gingerbread, etc.).

■ You can use caramel or chocolate toppings to garnish your drink.

■ Chocolate or coloured vermicelli, chocolate flakes, toasted hazelnuts and mini-marshmallows will give your

drinks a decorative touch.

Note: do not put ingredients such as syrup, dessert toppings or pieces of chocolate, etc directly into the milk jug.

MAKING COFFEE

You can make the coffee separately from the milk or at the same time. To do this:

■ Open the lid (a) - fig.5.

■ Fill the water tank with cold water (b) - fig.6.

■ Place a No. 4 filter paper in the filter holder - fig.8. Check that the filter holder is correctly in place. If this

is not the case, insert the filter holder vertically them fold down the handle - fig.7.

■ Measure in the required quantity of coffee - fig.9.

Dosage : We recommend using one level measuring spoon (n) of coffee per large cup.

■ Close the lid - fig.10.

■ Press to start the cycle. The button remains lit all the time while the coffee is being prepared - fig.11.

■ Your coffee maker comes with an automatic keep warm function.

automatically switch off after 30 min.

■ If you do not want to use the keep warm function, press at end of the brewing cycle.

■ The button is no longer lit and the coffee maker will switch off.

At the end of the brewing cycle, it will

English

Do not exceed the maximum quantity of water shown on the tank water level indicator. Once the cycle has ended, wait for a few minutes before making a second pot of coffee. Do not try to make more coffee, if the Carafe already contains some coffee.

■ Your coffee maker is fitted with a drip stop function allowing you to serve coffee before the end of the cycle. Once your coffee has been served, replace the jug to avoid any overflowing.

CLEANING YOUR COFFEE MAKER

To clean your coffee maker

■ Unplug the appliance.

■ Open the lid.

■ Remove the used filter paper:

- either by taking it out directly.

- or by lifting the filter holder out by the handle - fig.12 (if you remove the filter holder, make sure that you replace it correctly as in fig. 7).

■ Clean with a soft cloth or damp sponge, some hot water and a little mild dish soap .

■ Do not clean the appliance while it is still hot - fig.14.

■ Never immerse the appliance in water or any other liquid. - fig.15.

Dishwasher

■ The filter holder and the glass Carafe are dishwasher-safe.

DESCALING YOUR COFFEE MAKER

■ Descale your coffee maker:

- Every 40 cycles

■ If in doubt, ask the local water authority in your area to find out how hard your water is.

■ You can use:

- Either one sachet of descaler suitable for use in kettles or coffee makers diluted in 2 cups of water.

- Or 2 cups of commercially available white vinegar which can be purchased from your local hardware store.

■ Pour the prepared descaling solution into the water tank (b) and start the coffee maker (without coffee).

■ Leave the equivalent of one cup to drip into the Carafe (e), then switch off.

■ Leave to work for one hour.

■ Start the coffee maker up again to finish the cycle.

■ Run the coffee maker 2 or 3 times with the equivalent of one Carafe of fresh tap water to rinse it.

The warranty will not be honored for non- working coffee makers when descaling is not being carried out regularly.

USING THE MILK JUG

■ Check that the milk jug is unlocked - fig.16.

■ Pick up the jug by the handle provided for this purpose - fig.17.

■ Remove the lid and place it on a flat, stable, heat-resistant surface.

■ Pour the milk into the jug without exceeding the maximum level making sure you reach the minimum level.

The maximum and minimum levels of milk are shown by markings inside the pot (Maximum: 250mL, Minimum: 170mL) - fig.18.

■ Put the lid back on the jug - fig.19.

■ Position the milk jug on the hotplate (k) provided for this purpose - fig.20.

■ Check that the milk jug is correctly positioned on the hotplate.

■ Lock the milk jug by turning the button to the padlocked position

- fig.21.

English

Drinking chocolate

GourmetLight

Unsweetened cocoa sweetened cocoa Chocolate bars

■ You can use drinking chocolate with more or less sugar. To do this, we recommend adding it directly to the milk jug. You will obtain a tasty combination without any risk of it overflowing.

■ If you want an authentic hot chocolate, you can use a bar of chocolate. To do this, first of all melt the chocolate in the microwave or in an oven proof dish over pan of hot water as a bain marie. Prepare the milk separately and mix the chocolate and milk together in your cup. Do not put pieces of chocolate directly in the milk jug.

Hot Milk

■ To start heating, press the button.

■ The button lights up and the appliance starts up automatically.

■ When the milk is ready, the button switches off automatically after 6 min maximum.

■ Your appliance is fitted with a sensor that automatically regulates the temperature of the milk inside the

milk jug. Your milk will be heated to the optimum temperature and without risk of overflowing.

■ The frother rotates to give the milk an even temperature.

■ To serve the milk, unlock the jug.

■ Use the handle to pick up the milk jug - fig.22.

■ Remove the lid and place it on a flat, stable, heat-resistant surface.

■ Pour your hot milk.

Frothy Hot Milk

■ To start heating, press the button.

■ The button lights up and the appliance starts up automatically.

When the milk is ready, the button switches off automatically after 6 min.

■

■ Your appliance is fitted with a sensor that automatically regulates the temperature of the milk inside the

milk jug. You will obtain smooth, frothy milk at the correct temperature.

■ To serve the milk, unlock the jug.

■ Use the handle to pick up the milk jug.

■ Remove the lid and place it on a flat, stable, heat-resistant surface.

■ Pour your hot milk.

Tip: you can use a spoon to distribute the milk froth over the cup. Note: wait for 2 minutes after a milk cycle has finished before starting a new cycle.

CLEANING THE MILK FROTHER

■ Push the rod upwards.

■ Unscrew the end-piece of the frother rod - fig. 25. Be careful not to lose the end-piece.

■ Remove the rod by sliding it out - fig. 26.

■ Run the lid and the rod under the tap to clean them - fig. 27.

■ Fit the rod back on the lid and screw the end-piece on tightly so as to make the assembly ready for use

again - fig. 28.

Dishwasher

■ The milk jug and milk frother lid are not dishwasher-safe.

■ It is advisable to wash the milk jug and the milk frother lid with hot water, mild dish soap and a soft sponge

straight after use for easy cleaning.

■ Do not use abrasive products for cleaning they will damage the appliance.
