KRUPS F654 User Manual
www.krups.com
F654
ENGLISHFRANÇAIS
ESPAÑOL
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:13 Page1
2
When using electrical appliances, basic safety
precautions should always be observed, including the
following:
• Read all instructions.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against a risk of electrical shock, do not
immerse cord, plug, or base unit in water or other
liquid.
• Close supervision is necessary when any appliance is
used by or near children.
• Unplug from outlet when not in use and before
cleaning. Allow to cool before putting on or taking off
parts and before cleaning the appliance.
• Do not operate appliance with a damaged cord or plug
after the appliance malfunctions, is dropped or
damaged in any manner. Return appliance to the
nearest authorized KRUPS Service Center for
examination, repair or adjustment (see Guarantee of
Performance. p. 10).
• The use of accessory attachments not recommended
or sold by KRUPS may result in fire, electric shock or
injury.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter, or
touch hot surfaces.
• Do not place on or near gas or electric burner or in a
microwave or heated oven.
• Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
• To disconnect, remove plug from wall outlet.
• Do not use appliance for other than intended use.
IMPORTANT
SAFEGUARDS
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:32 Page2
3
ENGLISH
• Do not leave appliance unattended.
SAVE THESE
INSTRUCTIONS
CAUTION
This appliance is for household use. Any servicing other
than cleaning and user maintenance should be
performed by the nearest authorized KRUPS Service
Center (see Guarantee of Performance. p. 10).
• Do not immerse base in water.
• To reduce the risk of fire or electric shock, do not open
base of the appliance. There are no user serviceable
parts inside. Repair should be done by an authorized
KRUPS Service Center only.
Regarding your Cord Set:
A. A short power-supply cord is provided to reduce risks
resulting from becoming entangled in or tripping over a
longer cord.
B. Longer extension cords are available and may be used if
care is exercised in their use.
C. If a long extension cord is used, (1) the marked electrical
rating of the extension cord should be at least as great as
the electrical rating of the appliance, (2) if the appliance is
of the grounded type, the extension cord should be a
grounding-type 3-wire cord, and (3) the longer cord should
be arranged so that it will not drape over the counter top
or table top where it can be pulled on by children or tripped
over.
D. This appliance has a polarized plug (one blade is wider
than the other). As a safety feature, this plug will fit in a
SPECIAL CORD SET INSTRUCTIONS
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page3
4
polarized outlet only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician. Do not attempt to defeat this safety
feature.
DESCRIPTION
a
On/Off light
b
Ready light
c
Closure latch
d
Non-stick coated plates
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page4
5
ENGLISH
• Read the operating instructions carefully before using your
appliance for the first time. Krups will not assume any
responsibility if the appliance is not used in accordance with
the operating instructions.
• Check that your appliance‘s voltage matches your electrical supply.
• Position your appliance on a stable, horizontal, temperature-
resistant surface.
• Do not leave or use the appliance in a damp place.
• Allow the appliance to cool after each use.
• Do not touch the non-stick plates while the appliance is in
operation.
• This Krups appliance is exclusively designed for making waffles.
Thank you for purchasing the Krups 4-Slice Belgian Waffle Maker.
This product belongs to the Krups line of high quality, top-performing
appliances. This waffle maker allows you to make 4 crispy waffles
in just 4 minutes and offers the following features:
• Extra thick cooking plates for making real deep-pocket Belgian
waffles.
• Non-stick coated plates prevent waffles from sticking and makes
cleaning easy.
• On/Off light indicates at a glance that appliance is on.
• Ready light indicates waffle maker is preheated and ready to bake.
• Cool touch thermo-insulated handle for safer operation.
• Latch holds unit together during upright storage.
SAFETY RECOMMENDATIONS
FEATURES
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page5
6
• Clean the plates with a damp sponge and wipe dry.
• After lightly greasing the plates, (with butter, margarine, vegetable
oil or non-stick cooking spray) close the appliance and plug it in.
The lights (a) and (b) will light up.
• Let it heat for a few minutes to eliminate the new-product odor.
• If after several uses the waffles begin to stick, re-coat the plates.
• Close the appliance and plug it in.
The lights (a) and (b) will light up (1).
• When the appliance has reached the right
temperature, the ready light (b) will go off (2).
• Open the appliance and pour the waffle batter
into each plate, taking care not to overfill (3).
USING YOUR APPLIANCE
BEFORE YOU START
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page6
7
• Lower the top part (4).
• Do not close the appliance with the latch.
The hinge allows extra space to allow the
waffles to expand.
Note: During cooking, the ready light (b) will go on and off periodically
to assure a constant cooking temperature.
The cooking time is about 4 to 6 minutes and varies depending on
the type of batter being used.
We recommend that you adjust the degree of crispiness to your own
taste. The volumes and cooking times mentioned here are a general
guideline.
• Once the cooking is
complete, open the product
carefully with the locker,
remove the waffles with a
wooden or plastic spatula
(5).
• Avoid the use of metallic or sharp-edged utensils because they
could damage the coating on the plates.
• If you wish to make more waffles, close the lid and wait until the
ready light (b) goes off before cooking a new batch.
• After use, unplug the appliance and allow it to cool.
• Thicker batters will produce waffles that are crispier on the outside
and moist on the inside.
• Be careful not to over-mix the batter, this will produce dense,
chewy waffles.
• Serve waffles immediately after baking; if left to sit they will absorb
moisture and become soggy.
HELPFUL HINTS
ENGLISH
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page7
8
Waffle batter:
Makes 8 waffles
2 1/2 cups sifted all-purpose flour, 4 tablespoons sugar, 2 teaspoons
baking powder, 1/2 teaspoon salt, 3 eggs, 2 cups milk, 1/2 cup
vegetable oil.
• Sift together flour, sugar, baking powder and salt.
• In a bowl, beat the egg yolks, add the milk and then add the sifted
dry ingredients.
• In a small bowl, beat the egg whites to a thick foam and add them
gently to the preparation. Your batter is ready. Cook your waffles
following the instructions.
• Serve your waffles hot, immediately after cooking, with butter,
syrup, honey, jam, fresh fruits or try one of the sauce recipes
included in this book.
Crispy waffles with hot chocolate and vanilla ice cream
Makes 8 waffles
2 1/2 cups sifted all-purpose flour, 2 cups milk, 1/2 cup butter,
2 eggs, 2 tablespoons sugar, 4 teaspoons baker’s yeast, 1 glass
cognac (any brandy may be substituted), 1/2 teaspoon salt, vanilla
ice cream, chocolate syrup.
• Allow the yeast to rise by letting it sit 25 minutes in a glass of water
with the sugar.
• Mix this preparation with the eggs and melted butter.
• Then add the milk, flour, cognac and salt, mixing until the batter is
fluid.
• Allow the batter to sit for 3 hours at room temperature before
cooking.
• Before serving, garnish with 2 scoops of vanilla ice cream and
drizzle with warmed chocolate syrup.
They may also be eaten with sugar and jam.
RECIPES
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page8
9
Maple-Blueberry Sauce
1/4 cup brown sugar, 1 tablespoon cornstarch, 1/2 cup maple syrup,
1/2 cup water, 2 cups fresh or frozen blueberries,
1 tablespoon lemon juice, 1/8 teaspoon nutmeg.
• In a saucepan, combine brown sugar and cornstarch. Gradually
blend in maple syrup and water.
• Cook, stirring, until thick and bubbly, about 1 minute. Stir in
blueberries, lemon juice and nutmeg. Cool slightly. Pour over
waffles. Top with whipped cream, if desired.
Cherry Sauce
8 3/4 oz. can of dark sweet pitted cherries, 2 tablespoons cornstarch,
2 tablespoons port wine.
• Drain cherries, reserving syrup. In a small saucepan, blend
cornstarch, reserved syrup and port wine. Bring to a boil and cook
1 additional minute, continuing to stir. Stir in cherries. Cool mixture
slightly. Spoon 3-4 tablespoons of sauce over each serving of
waffles. Top with whipped cream, shaved semisweet chocolate
and a maraschino cherry.
• Before each cleaning, unplug the appliance and let it completely
cool.
• Never immerse the appliance in water or place it under running
water.
• To clean the outside of the appliance, use a damp sponge and
dry it carefully.
• To clean the plates, use a damp sponge and wipe dry.
• You may use very little liquid detergent to clean plates, but be sure
to remove any residue as it might alter the taste of the waffles.
• If baked-on batter remains on the plates, we recommend using
vegetable oil to soften diluted liquid detergent the remaining batter
and to wait 5 minutes before wiping it off.
• Never use abrasive pads or scouring powder.
To store: Close the appliance and lock with the latch and store it
vertically to save space.
CLEANING AND STORING
ENGLISH
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page9
10
• Check to make sure it is plugged in.
If your appliance still does not work, contact an authorized Krups
Service Center.
This fine KRUPS product is manufactured according to a rigid
code of quality standards, and with minimum care, should give
years of satisfying service.
However, should the need arise for repairs of for replacement
parts within or after the warranty period, please call our
CONSUMER SERVICE DEPARTMENT: (800) 526-5377 24-hours
a day, 7 days a week You will be provided with specific
instruction on how to get your product repaired, as well as the
name and address of your nearest authorized KRUPS Service
Center. Consumer Service Department will also be able to
answer any general product questions you may have.
Before calling the Consumer Service Department, please have
the type number of your KRUPS appliance available. You must
have this information before calling our Consumer Service
Department so that we may better answer your questions. The
type number can be located by looking at the bottom of your
appliance.
This product type is #654
Any general correspondence can be addressed to:
KRUPS North America
P.O. Box 3900
Peoria, IL 61612
GUARANTEE OF PERFORMANCE
WHAT TO DO IF YOUR APPLIANCE DOES
NOT WORK PROPERLY
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page10
11
ENGLISH
www.krups.com
With a strong commitment to the environment, most of Krups
products are repairable during and after the warranty period.
Before returning any defective products to the point of
purchase, please call Krups consumer service directly at the
phone number below for repair options. Your help to sustain the
environment is appreciated!
The Warranty
This product is guaranteed by Krups for a period of 2 years against
any manufacturing defect in materials or workmanship, starting from
the initial date of purchase.
The manufacturer's warranty by Krups is an extra benefit which does
not affect consumer's Statutory Rights.
The Krups warranty covers all costs related to restoring the proven
defective product so that it conforms to its original specifications,
through the repair or replacement of any defective part and the necessary labor. At Krups’s choice, a replacement product may be provided instead of repairing a defective product. Krups’s sole obligation
and your exclusive resolution under this warranty are limited to such
repair or replacement.
Conditions & Exclusions
The Krups warranty only applies within USA, Canada & Mexico, and
is valid only on presentation of a proof of purchase. The product can
be taken directly in person to an authorized service centre or must
be adequately packaged and returned, by recorded delivery (or equivalent method of postage), to a Krups authorized service centre. Full
address details for each country’s authorized service centre are listed
on the Krups website (www.krups.com
) or by calling the appropriate
telephone number listed below to request the appropriate postal address.
Krups shall not be obliged to repair or replace any product which is
not accompanied by a valid proof of purchase.
LIMITED WARRANTY
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page11
12
This warranty will not cover any damage which could occur as a result of misuse, negligence, failure to follow Krups instructions, use
on current or voltage other than as stamped on the product, or a
modification or unauthorized repair of the product. It also does not
cover normal tear and wear, maintenance or replacement of consumable parts, and the following:
- scaling (any de-scaling must be carried out according to the instructions for use);
- water damage, dust or insects into the product;
- mechanical damages, overloading
- damages or bad results due to wrong voltage or frequency
- accidents including fire, flood, lightning, etc
- professional or commercial use
This warranty does not apply to any product that has been tampered
with, or to damages incurred through improper use and care, faulty
packaging by the owner or mishandling by any carrier.
The Krups manufacturer's warranty applies only for products purchased and used in USA, Canada & Mexico. Where a product purchased in one country and then used in another one:
a) The Krups guarantee duration is the one in the country of usage
of the product, even if the product was purchased in another
listed country with different guarantee duration.
b) The Krups guarantee does not apply in case of non conformity
of the purchased product with the local standards, such as voltage, frequency, power plugs, or other local technical specifications
c) The repair process for products purchased outside the country
of use may require a longer time if the product is not locally sold
by Krups
d) In cases where the product is not repairable in the new country,
the Krups guarantee is limited to a replacement by a similar
product or an alternative product at similar cost, where possi
-
ble.
KR_GAUFRIER_F654_NAFTA_NC00119156_Mise en page 1 23/05/13 10:33 Page12
Loading...
