KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
VS-161H
16x1
P/N: 2900-000665 Rev 3
HDMI Switcher
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
3 Overview 3
3.1 About HDMI—General Description 3
3.2 About HDCP—General Description 4
3.3 Defining the VS-161H 16x1 HDMI Switcher 5
4 Installing in a Rack 7
5 Connecting the VS-161H 16x1 HDMI Switcher 8
5.1 Connecting to the VS-161H Using the RS-232 Connection 9
5.2 Connecting to the VS-161H Using Ethernet 10
6 Operating the VS-161H 16x1 HDMI Switcher 14
6.1 The PC and DVD Modes 14
6.2 Acquiring the EDID 15
6.3 Locking and Unlocking the Front Panel 16
6.4 Resetting the Device to Factory Default Values 16
6.5 Upgrading the Firmware 16
7 Technical Specifications 17
8 Default Communication Parameters 18
9 Kramer Protocol 2000 19
Figures
Figure 1: VS-161H 16x1 HDMI Switcher Front and Rear Panels 5
Figure 2: Connecting the VS-161H 16x1 HDMI Switcher
Figure 3: Crossed Cable RS-232 Connection
Figure 4: Straight Cable RS-232 Connection with a Null Modem Adapter
Figure 5: Local Area Connection Properties Window
Figure 6: Internet Protocol (TCP/IP) Properties Window
VS-161H - Contents i
8
10
10
12
13
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Video Products.
Congratulations on purchasing your Kramer VS-161H 16x1 HDMI Switcher. Th is
product is ideal for:
• Conference room presentations
• Rental and staging
Note: The Kramer VS-161H is identical to the VS-161HDMI, just the name has
changed by replacing the suffix “HDMI” by “H” (according to the HDMI Guideline).
VS-161H - Introduction 1
i
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
• Review the contents of this user manual
Use Kramer high performance high resolution cables
Use only the power cord that is supplied with this device
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
• Use only good quality connection cables to avoid interference, deterioration
in signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
• Do not secure the cables in tight bundles or roll the slack into tight coils
• Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
• Position your VS-161H away from moisture, excessive sunlight and dust
2 VS-161H - Getting Started
