Thank you for purchasing the Korg TRITON proX, TRITON pro, or TRITON music workstation/sampler. To ensure trouble-free enjoyment, please read this manual carefully and use the
instrument as directed.
About this manual
The owner’s manuals and how to use
them
The TRITON proX, TRITON pro, and TRITON come
with the following owner’s manuals.
• Basic Guide
• Parameter Guide
• Voice Name List
Basic Guide
First read this manual carefully to gain a basic understanding of the instrument and to learn basic operation.
“Introduction” explains the function of each part, how
to make connections, basic operation, and gives an
overview of each mode.
“Quick Start” explains basic topics (hearing the demo
songs, selecting sounds, convenient functions for performance). If you wish to begin playing immediately,
read this section first.
“Basic Functionality” contains mode-by-mode expla-
nations of what you need to know to edit sounds,
record on the sequencer, and record samples. This section also explains how to use the arpeggiator, effects,
and MIDI.
“Appendices” explains how to install the Korg MIDI
Driver that you will need when connecting the instrument to the TO HOST connector or to a computer, and
lists the specifications etc.
Parameter Guide
The Parameter Guide contains explanations and other
information regarding the operations of the parameters and settings on the TRITON proX, TRITON pro,
and TRITON. The explanations are organized by
mode, page, and tab. Explanations and other information on the effects and their parameters are also provided for each effect.
Refer to this guide when an unfamiliar parameter
appears in the display, or when you need to know
more about a particular function.
Voice Name List
This lists the multisamples and drumsamples that are
built into the TRITON proX, TRITON pro, and TRITON, and the factory preset combinations, programs,
drum kits, and user arpeggio patterns.
Refer to these lists when you wish to know more about
the preloaded sounds.
Conventions in this manual
References to the TRITON proX, TRITON pro, and
TRITON
The TRITON proX, TRITON pro, and TRITON are collectively referred to in this manual as the TRITON.
Switches and knobs [ ]
References to the switches, dials, and knobs on the
TRITON’s panel are enclosed in square brackets [ ].
References to
LCD display screen.
Parameters in the LCD display screen “ “
Parameters displayed in the LCD screen are enclosed
in double quotation marks “ “.
Boldface type
Parameter values are printed in boldface type.
Content that is of particular importance is also printed
in boldface type.
Procedure steps
Steps in a procedure are listed as
p.
☞
■
These indicate pages or parameter numbers to which
you can refer.
Symbols
These symbols respectively indicate cautions, advice,
and MIDI-related explanations.
Example screen displays
The values of the parameters shown in the example
screens of this manual are only for explanatory purposes, and may not necessary match the values that
appear in the LCD screen of your instrument.
MIDI-related explanations
CC# is an abbreviation for Control Change Number.
In explanations of MIDI messages,
brackets [ ]
buttons or tabs indicate objects in the
1
2
3
...
1
2
3
...
, ,
numbers in square
always indicate hexadecimal numbers.
Data handling
Unexpected malfunctions may result in the loss of
recorded data, so we recommend that you copy or
backup important data to an external drive (hard disk
or removable disk) or DAT recorder. Please be aware
that Korg will accept no responsibility for any damages which may result from loss of data.
Also, when digitally recording copyrighted audio
material from a DAT or CD etc., you must obtain permission for use. Please be aware that Korg will accept
no responsibility for any copyright violations which
may occur through your use of this product.
* Other trademarks and corporate names are the reg-
istered trademarks and trademarks of their respective holders.
iii
