Kohler LBPR1019 Specifications

Purist
Features
Includes faceplate with handle, shower arm and flange.
Single handle controls both on/off activation and temperature settings.
Cross handle.
For use with any KOHLER showerhead (sold separately).
Complements Purist faucets and accessories.
Material
Premium material construction with metal handle ensures reliability and durability.
KOHLER finishes resist corrosion and tarnishing.
Installation
Trim only; requires valve to complete installation (sold separately).
Required Products/Accessories
K-304/K-P304 Series Rite-Temp® Valves
or
K-8304/K-P8304 Series Rite-Temp® Valve & Cartridge Kits
or
K-8300/K-P8300 Series Rite-Temp® Valve Body Rough-ins K-8305/K-P8305 Series Rite-Temp® Cartridges
or
K-2971-KS 3/4" Pressure-balancing Valve
Recommended Products/Accessories
K-23723 Faucet cleaner
Optional Products/Accessories
K-10350 Deep rough-in kit K-10351 Test cap for K-8300 Series valve bodies
Codes/Standards
ASME A112.18.1/CSA B125.1 ADA
KOHLER® Faucet Lifetime Limited Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
CP Polished Chrome SN Vibrant® Polished Nickel
BGD
Vibrant® Moderne Brushed Gold
BN Vibrant® Brushed Nickel BV Vibrant® Brushed Bronze
BL Matte Black
2MB
Vibrant® Brushed Moderne Brass
®
Rite-Temp® Shower Valve Trim
K-TLS14422-3
1-800-4KOHLER (1-800-456-4537) Kohler Co. reserves the right to make revisions without notice to product specifications. For the most current Specification Sheet, go to www.kohler.com. 10-15-2021 16:32 - US/CA
Purist
1-3/4" (44 mm)
1/2" NPT
*If 3-1/2" (89 mm) to 4-1/4" (108 mm) use deep roughing-in kit.
Finished Wall
K-8300 Valve Series
K-2971-KS, K-304 Valves
Ø 6-1/2" (165 mm)
7-15/16" (202 mm) Typical
2-11/16" (68 mm)
4" (102 mm)
Technical Information
All product dimensions are nominal.
Notes
Install the product according to the installation guide.
NOTICE: Risk of product damage. Long screws for installing trim can damage the K-2971-KS valve. Consult the trim installation guide to verify if the thin wall installation kit (88526) is needed.
ADA compliant when installed to the specific requirements of these regulations.
®
Rite-Temp® Shower Valve Trim
K-TLS14422-3
1-800-4KOHLER (1-800-456-4537) Kohler Co. reserves the right to make revisions without notice to product specifications. For the most current Specification Sheet, go to www.kohler.com. 10-15-2021 16:32 - US/CA
