Kohler KTS144234CP Specifications
Features
CSA B651
OBC
•
Includes face plate with handle.
•
Single handle controls both on/off activation and temperature
setting.
•
Supplied with ADA compliant metal lever handle.
•
Complements the Purist faucet and accessory collections.
Material
•
Premium material construction with metal handle ensures
reliability and durability.
•
KOHLER finishes resist corrosion and tarnishing, exceeding
industry durability standards.
Installation
•
Trim set requires valve to complete installation.
Purist
®
Rite-Temp® Valve Trim
K-TS14423-4
Required Accessories
K-304/K-P304 Series Rite-Temp® Valves
or
K-8304/K-P8304 Series Rite-Temp® Valve & Cartridge Kits
or
K-8300/K-P8300 Series Rite-Temp® Valve Body Rough-ins
K-8305/K-P8305 Series Rite-Temp® Cartridges
or
K-2971-KS 3/4" Pressure-balancing Valve
Optional Accessories
K-10350 Deep Rough-In Kit For K-8305 Cartridges
K-10351 Test Cap For K-8300 Series Valve Bodies
Codes/Standards
ASME A112.18.1/CSA B125.1
ADA
ICC/ANSI A117.1
CSA B651
OBC
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
Polished ChromeCP
Vibrant® Polished NickelSN
Vibrant® Moderne Brushed GoldBGD
Vibrant® Brushed NickelBN
Vibrant® Brushed BronzeBV
Matte BlackBL
Vibrant Rose GoldRGD
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
11-14-2017 11:32
Ø 6-13/16"
Purist
®
Rite-Temp® Valve Trim
K-TS14423-4
Technical Information
All product dimensions are nominal.
Notes
Install the product according to the installation
guide.
NOTICE: Risk of product damage. Long screws
for installing trim can damage the K-2971-KS
valve. Consult the trim installation guide to verify
if the thin wall installation kit (88526) is needed.
ADA, OBC, CSA B651 compliant when installed
to the specific requirements of these regulations.
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
11-14-2017 11:32
