KODAK VISION3 500T Color
Negative Film 5219 / 7219 / SO-219

TECHNICAL DATA /

COLOR NEGATIVE FILM

The first in a new family of films, VISION3 500T Film gives
you more control and flexibility at every phase of the
filmmaking process—from capture through post, in both
digital and traditional workflows.

VISION3 500T Film retains the overall look and image
structure of KODAK VISION2 Films—then adds technical
innovations that provide improved exposure latitude—at
both ends of the curve. Proprietary, advanced Dye Layering
Technology (DLT) gives you noticeably reduced grain in
shadows, so you can shoot at higher speeds, with less light,
in darker corners, and know you can capture an amazing
amount of shadow detail with noticeably lower grain.

VISION3 500T Film also features extended highlight
latitude, so you can follow the action into bright light-in a
single shot-without worrying about blown-out details.
When the film is scanned and digitized, you'll find you can
recover two stops of highlight detail. This technology is
enabled by the use of sub-micron imaging sensors.

VISION3 500T Film fits seamlessly into your digital
workflow. And when scanning low-light scenes, VISION3
500T Film yields higher signal-to-noise ratios for
unprecedented image quality.

BASE

KODAK VISION3 500T Color Negative Films 5219 and
7219 have an acetate safety base with rem-jet backing.

KODAK VISION3 500T Color Negative Film SO-219 has
an ESTAR Safety Base with rem-jet backing

STORAGE

Store unexposed film at 13°C (55°F) or lower. For extended
storage, store at -18°C (0°F) or lower. Process exposed film

promptly. Store processed film according to the
recommendations in ANSI/PIMA IT9.11-1998: for
medium-term storage (minimum of ten years), store at

10°C(50°F) or lower at a relative humidity of 20 to 30

percent; for extended-term storage (for preservation of

material having permanent value), store at 2°C (35°F) or

lower at a relative humidity of 20 to 30 percent. For active

use, store at 25°C(77°F) or lower, at a relative humidity of

50 +/- 5 percent. This relates to optimized film handling
rather than preservation; static, dust-attraction and
curl-related problems are generally minimized at the
higher relative humidity. After usage, the film should be
returned to the appropriate medium- or long-term storage
conditions as soon as possible.

For more information about medium- and long-term
storage, see ANSI/PIMA IT9.11-1998, SMPTE RP131-2002,
and KODAK Publications No. H-1, KODAK Motion Picture
Film and No. H-23, The Book of Film Care.

November 2007 • H-1-5219t

EXPOSURE INDEXES

Tungsten (3200K) - 500 Daylight1 - 320

Use these indexes with incident- or reflected-light
exposure meters and cameras marked for ISO or ASA
speeds or exposure indexes. These indexes apply for meter
readings of average subjects made from the camera
position or for readings made from a gray card of
18-percent reflectance held close to and in front of the
subject. For unusually light- or dark-colored subjects,
decrease or increase the exposure indicated by the meter
accordingly.

COLOR BALANCE

These films are balanced for exposure with tungsten
illumination (3200K). You can also expose them with
tungsten lamps that have slightly higher or lower color
temperatures (+/- 150K) without correction filters, since
final color balancing can be done in printing. For other light
sources, use the correction filters in the table below.

Light Source

Tungsten (3000 K) WRATTEN Gelatin No.

Tungsten (3200 K) None 500

Tungsten photoflood
(3400 K)

Daylight (5500 K) WRATTEN Gelatin No. 85 320

White-Flame Arcs WRATTEN Gelatin No.

Yellow-Flame Arcs Color Compensating 20Y 320

OPTIMA 32 None 500

VITALITE WRATTEN Gelatin No. 85 320

Fluorescent, Cool

†

White

Fluorescent, Deluxe
Cool White

Metal Halide WRATTEN Gelatin No. 85 320

*

These are approximate corrections only. Make final corrections during

printing.

†

These are starting-point recommendations for trial exposures. If the kind of

lamp is unknown, a KODAK Color Compensating Filter CC 40R can be used
with an exposure index (EI) of 250.

†

KODAK Filters

on Camera

WRATTEN Gelatin No. 85

+ 10M

WRATTEN Gelatin No.

85C + 10R

*

82B

None 500

85B

Note: Consult the manufacturer of high-intensity
ultraviolet lamps for safety information on ultraviolet
radiation and ozone generation.

1. With a KODAK WRATTEN Gelatin Filter No. 85.

Exposure

Index

320

200

200

320

©Eastman Kodak Company, 2007

DARKROOM RECOMMENDATIONS

Do not use a safelight. Handle unprocessed film in total
darkness.

EXPOSURE TABLE - TUNGSTEN LIGHT

At 24 frames per second (fps), 170-degree shutter
opening:

Lens Aperture f/1.4 f/2 f/2.8 f/4 f/5.6 f/8 f/11 f/16

Footcandles
Required

510204080160320640

Use this table for average subjects that contain a
combination of light, medium, and dark colors. When a
subject includes only pastels, use at least 1/2 stop less
exposure; dark colors require 1/2 stop more exposure.

Lighting Contrast -

The recommended ratio of key-light-plus-fill-light to fill
light is 2:1 or 3:1. However, you may use 4:1 or greater when
a particular look is desired.

RECIPROCITY CHARACTERISTICS

You do not need to make any filter corrections or exposure
adjustments for exposure times from 1/1000 of a second
to 1 second. In the 10-second range, increase exposure 1
stop and use a KODAK Color Compensating Filter CC 10R.

PROCESSING

Process in Process ECN-2.

Most commercial motion-picture laboratories provide a
processing service for these films. See KODAK Publication
No. H-24.07, Processing KODAK Color Negative Motion
Picture Films, Module 7 available online at http://
www.kodak.com/US/plugins/acrobat/en/motion/
support/processing/h247/h2407.pdf, for more
information on the solution formulas and the procedure for
machine processing these films. There are also
pre-packaged kits available for preparing the processing
solutions. For more information on the KODAK ECN-2 Kit
Chemicals, check Kodak's Motion Picture Films for
Professional Use price catalog.

IDENTIFICATION

After processing, the product code numbers 5219 (35
mm), 7219 (16 mm), or SO-219 (16, 35, and 65 mm;
edgeprint shows 0219) emulsion, roll, and strip number
identification, KEYKODE Numbers, and manufacturer/film

identification code (EJ) are visible along the length of the
film.

LABORATORY AIM DENSITIES (LAD)

To maintain optimum quality and consistency in the final
prints, the laboratory must carefully control the color
timing, printing, and duplicating procedures. To aid in color
timing and curve placement, negative originals should be
timed relative to Laboratory Aim Density (LAD) Control
Film supplied by Eastman Kodak Company.

2

The LAD
Control Film provides both objective sensitometric control
and subjective verification of the duplicating procedures
used by the laboratory.

In the LAD Control Method,

3

the electronic color
analyzer used for color timing is set-up with the LAD
Control Film to produce a gray video display of the LAD
patch, corresponding to 1.0 neutral density (gray) on the
print. The negative printing original is then scene-to-scene
timed. There are specific LAD values for each type of print
or duplicating film that the original can be printed on. For
print films, the LAD patch is printed to a neutral gray of 1.0
visual density. For duplicating films, the specified aims are
at the center of the usable straight-line portion of the
sensitometric curve of the film.

Due to normal variations in exposure and processing of
color negative films, particular scenes may not print
exactly at the same printer lights as the LAD Control Film.
The LAD Control Film is intended as a set-up tool for
electronic color analyzers and printers. It is NOT a
reference that every scene must match. Normal
film-to-film and scene-to-scene exposure variability is
accommodated by the color timing (grading) process, on
an electronic color analyzer set up with the LAD Control
Film. Normally exposed and processed color negatives will
typically print well within the range of an additive printer
setup with the LAD Control Film, although SIGNIFICANT
or UNEXPECTED departures from this center point
balance may indicate an exposure/filtration problem with
the cinematography or with the process control. Some
specialized films and/or specialized negative processing
techniques (push-processing, pull-processing,
"skip-bleach" processing, etc.) may require more extreme
adjustment from the LAD printing condition to attain
desired results.

More information is contained in KODAK Publication
H-61, Laboratory Aim Density, available online at
http://www.kodak.com/US/en/motion/support/
lad.jhtml.

FILM-TO-TAPE TRANSFERS

When you transfer the film directly to tape, you can set up
the telecine using KODAK Telecine Analysis Film (TAF)

2 KODAK VISION3 500T Color Negative Film 5219 / 7219 / SO-219 • H-1-5219t

2. Direct any inquiries to one of the regional sales offices.

3. Use of the LAD Control Method is described in the paper, "A Simplified

Motion-Picture Laboratory Control Method for Improved Color
Duplication," by John P. Pytlak and Alfred W. Fleischer in the October 1976
SMPTE Journal.

supplied by Eastman Kodak Company. The TAF consists of

Characteristic Curves

a neutral density scale and an eight-bar color test pattern
with a LAD gray surround.

The TAF gray scale provides the telecine operator
(colorist) with an effective way to adjust subcarrier
balance and to center the telecine controls before timing
and transferring a film. The TAF color bars provide the
utility of electronic color bars, even though they do not
precisely match the electronically generated color bars.
Using the TAF will help obtain optimum quality and
consistency in the film-to-tape transfer. For more
information regarding TAF, see KODAK Publication No.
H-9, TAF User's Guide.

IMAGE STRUCTURE

The modulation-transfer and diffuse rms granularity
curves were generated from samples of 5219 Film exposed
with tungsten light and processed as recommended in
Process ECN-2 chemicals. For more information on
image-structure characteristics, see KODAK Publication
No. H-1, KODAK Motion Picture Film available online at
http://www.kodak.com/US/en/motion/support/h1.

Modulation Transfer Function

The "perceived" sharpness of any film depends on various
components of the motion picture production system. The
camera and projector lenses and film printers, among other
factors, all play a role. But the specific sharpness of a film
can be measured and is charted in the Modulation Transfer
Function Curve.

CURVES

Sensitometric Curves

-4.0 -3.0 -2.0 -1.0 0.0 1.0

3.0

Exposure: 3200K Tungsten 1/50 sec
Process: ECN-2
Densitometry: ECN-2

2.0

Density

1.0

0.0

-8 -7 -6 -5 -4

TI2647F

The curves describe this film's response to red, green,
and blue light. Sensitometric curves determine the change
in density on the film for a given change in log exposure.

Note: The exposure scale for VISION3 5219 / 7219 Film is
longer than previous VISION and VISON2 Films. Because
of the extended highlight latitude of and because we need
to measure in this region, we expanded the exposure scale
from a zero to four increment to a zero to five scale. In
addition to the longer exposure scale, we are plotting
twenty-one steps instead of twenty.

LOG EXPOSURE (lux-seconds)

-3 -2 -1 0 1 2 3 4 5 6 7 8
Camera Stops

B

G

R

4

rms Granularity:

Refer to curve.

Read with a microdensitometer, (red, green, blue) using

a 48-micrometer aperture.

The "perception" of the graininess of any film is highly
dependent on scene content, complexity, color, and
density. Other factors, such as film age, processing,
exposure conditions, and telecine transfer may also have
significant effects.

NOTICE: The sensitometric curves and data in this
publication represent product tested under the conditions
of exposure and processing specified. They are
representative of production coatings, and therefore do
not apply directly to a particular box or roll of photographic
material. They do not represent standards or specifications
that must be met by Eastman Kodak Company. The
company reserves the right to change and improve

KODAK VISION3 500T Color Negative Film 5219 / 7219 / SO-219 • H-1-5219t 3

Modulation-Transfer Function Curves

200

100

70
50

30

20

R

G

B

10

7

5

RESPONSE (%)

Exposure: 3200K Tungsten

3

Process: ECN-2

2

Densitometry: Status M

1

1001 2 3 4 5 10 20 50 200 600

TI2647B

SPATIAL FREQUENCY (cycles/mm)

This graph shows a measure of the visual sharpness of
this film. The x-axis, "Spatial Frequency," refers to the
number of sine waves per millimeter that can be resolved.
The y-axis, "Response," corresponds to film sharpness.
The longer and flatter the line, the more sine waves per
millimeter that can be resolved with a high degree of
sharpness—and, the sharper the film.

Diffuse rms Granularity Curves

3.0

Process: ECN-2

2.0

DENSITY

1.0

0.0

0.0 1.0

TI2647C

Blue Density
Green Density
Red Density
Blue Grain
Green Grain
Red Grain

G

R

3.0

LOG RELATIVE EXPOSURE

B

G

R

0.10

0.05

0.04

B

4.0 5.02.0

0.03

0.02

0.01

0.006

0.005

0.004

0.003

0.002

.001

To find the rms Granularity value for a given density, find
the density on the left vertical scale and follow horizontally
to the characteristic curve and then go vertically (up or
down) to the granularity curve. At that point, follow
horizontally to the Granularity Sigma D scale on the right.
Read the number and multiply by 1000 for the rms value.

Note: This curve represents granularity based on modified
measuring techniques.

4

4.0

3.0

*

2.0

LOG SENSITIVITY

1.0

0.0

TI2647D

These curves depict the sensitivity of this film to the
spectrum of light. They are useful for determining,
modifying, and optimizing exposure for blue- and
green-screen special-effects work.

1.8

1.6

1.4

1.2

1.0

0.8

GRANULARITY SIGMA D

0.6

0.4

DIFFUSE SPECTRAL DENSITY

0.2

0.0

-0.2
400 450 500 550 600 650 700 750 800

TI2647E

These curves depict the spectral absorptions of the dyes
formed when the film is processed. They are useful for
adjusting or optimizing any device that scans or prints the
film.

Note: Cyan, Magenta, and Yellow Dye Curves are
peak-normalized.

Spectral Sensitivity Curves

Yellow-

Forming

Layer

Effective Exposure: 1/25 sec
Process: ECN-2
Densitometry: Status M
Densitry: 0.2>D-min

WAVELENGTH (nm)

*Sensitivity = reciprocal of exposure (erg/cm ) required

to produce specified density

Magenta-

Forming

Layer

Cyan-

Forming

Layer

2

Spectral Dye Density Curves

Process: ECN-2; D-mins subtracted

Midscale Neutral

Cyan

Magenta

WAVELENGTH (nm)

Yellow

Minimum Density

700 750650600550500450400350300250

4. Sensitometric and Diffuse RMS Granularity curves are produced on
different equipment. A slight variation in curve shape may be noticed.

4 KODAK VISION3 500T Color Negative Film 5219 / 7219 / SO-219 • H-1-5219t

SIZES AVAILABLE

Standard Products Available

Identification No.

65 mm SP332 305 (1000) P Emulsion In KS-4740 (KS-1866)

35 mm SP417 30 (100) S-83 100-ft. spool BH-4740 (BH-1866)

35 mm SP718 61 (200) U BH-4740 (BH-1866)

35 mm SP718 122 (400) U BH-4740 (BH-1866)

35 mm SP718 305 (1000) U BH-4740 (BH-1866)

16 mm SP449 30 (100) R-90 100-ft. spool 2R-7605 (2R-2994)

16 mm SP451 122 (400) T 2R-7605 (2R-2994)

16 mm SP578 122 (400) S-153 400-ft. spool 2R-7605 (2R-2994)

16 mm SP445

16 mm SP455 30 (100) R-90 100-ft. spool Winding B 1R-7605 (1R-2994)

16 mm SP457 122 (400) T Winding B 1R-7605 (1R-2994)

16 mm SP458 244 (800) Z Winding B 1R-7605 (1R-2994)

16 mm SP462N 15 (50) R-236 50-ft.spool 2R-7605 (2R-3000)

S8 mm SP464 15 (50) Super 8 cartridge

*

for AATON A-MINIMA Cameras

*

Length in

Metres (Feet)

61 (200) A Winding A 1R-7620 (1R-3000)

Core Description Perforations

MORE INFORMATION

Outside the United States and Canada, please contact your Kodak representative.

You can also visit our web site at www.kodak.com/go/motion for further information. You may want to bookmark our

location so you can find us easily the next time.

Film s Film for the Cinematographer

Image Structure KODAK Motion Picture Film

Storage KODAK Moti on Picture Film

Processing Manual for Processing KODAK Motion Picture Films, Process

LAD LAD—Laboratory Aim Density

Tr a n s f e r KODAK Telecine Analysis Film User’s Guide

KODAK Publication No. H-5

KODAK Publication No. H-1

KODAK Publication No. H-1

The Book of Film Care

KODAK Publication No. H-23

ECN-2 Specifications, Module 7

KODAK Publication No. H-24.07

KODAK Publication No. H-61

KODAK Publication No. H-822

KODAK Telecine Exposure Calibration Film User’s Guide

KODAK Publication No. H-807

KODAK VISION3 500T Color Negative Film 5219 / 7219 / SO-219 • H-1-5219t 5

KODAK VISION3 500T Color Negative Film 5219 / 7219 / SO-219

FOR DIRECT ORDERING IN THE UNITED STATES AND CANADA: 1-800-621-FILM

KODAK SHOOTSAVER Film Delivery Service (U.S. only) 1-800-404-2016

Kodak Locations

NORTH AMERICA REGION
UNITED STATES
Hollywood, California

6700 Santa Monica Boulevard
Los Angeles, California
90038-1203
Tel: [phone]
Orders: 1-800-621-FILM

New York, New York

360 West 31st Street
New York, New York
10001-2727
Tel: [phone]
Orders: 1-800-621-FILM

CANADA

Kodak Canada Inc.
6 Monogram Place
2nd Floor
Toronto, Ontario
Canada M9R 0A1
Te l : 4 16 -7 6 1- 46 4 6
Orders: 1-800-621-FILM
Fax: [phone]
Toll Free Fax: [phone]

Kodak Canada Inc.
4 Place du Commerce, Suite 100
Ile des Soeurs
Verdun, Quebec
Canada H3E 1J4
Orders: 1-800-621-FILM
Fax: [phone]

Kodak Canada Inc.
3700 Gilmore Way
Burnaby, BC
Canada V5G 4M1
Orders: 1-800-621-FILM
Fax: [phone]

EUROPEAN, AFRICAN AND
MIDDLE EASTERN REGION
Kodak Business Centre

Hemel One, Boundary Way
Hemel Hempstead
HP2 7YU
England, UK
Tel: + 44 1442 846945
Fax: + 44 1442 846 594

Eastman Kodak SARL

29-31 Route de L'Aeroport
Le Grand Saconnex
Case Postale 271
1215 Geneva 15
Switzerland
Tel: [phone]
Fax: [phone]

LATIN AMERICA REGION

1900 NW 97 Ave.
Miami, Florida 33172 USA
Tel: [phone]
Fax: [phone]
www.kodak.com/go/latinmotion

MEXICO

Kodak Mexicana S.A. de C.V.
Blvd. Adolfo Ruiz Cortinez 3642, Piso 14
Col. Jardines del Pedregal
Del. Alvaro Obregon
CP 01900 México, D.F, Mexico.
Tel: [phone]
Fax: [phone]
www.kodak.com/go/latinmotion

BRAZIL
KODAK BRASILEIRACOM. PROD.
PARA IMAGEME SERVIÇOS LTDA

Rodovia Presidente Dutra ­Km154.7

Sao José dos Campos-SP
CEP 12240-427, Brazil
Tel: [phone]
Tel: [phone] (Kodak Sao Paulo)
Tel: [phone] (Kodak Rio de
Janeiro)
Fax [phone]
www.kodak.com/go/latinmotion

VENEZUELA

Kodak Venezuela S. A.
Av. Francisco deMiranda
Centro Lido, Torre B, Piso 7, Of. 71A y
72B
El Rosal, Caracas-Venezuela
Tel: [phone]
Fax: [phone]
www.kodak.com/go/latinmotion

PERU

Kodak Américas, Ltd.
Avenida Larco # 1301, Piso 14,
Miraflores
Lima, Perú
Tel: [phone]
Fax: [phone]
www.kodak.com/go/latinmotion

ARGENTINA

EI Business Center
Bonpland 1930-32
CP 1414 Buenos Aires, Argentina
Tel: [phone] /
54-911-5932-9503
Fax: [phone]
www.kodak.com/go/latinmotion

CHILE

Kodak Chilena S.A.F.
Edificio Torre Oriente
Av.Alonso de Córdoba# 5151, Piso 14
Comuna Las Condes
Santiago, Chile
Te l : 5 6. 99 .2 20 .5 60 9
www.kodak.com/go/latinmotion

ASIA PACIFIC REGION
AUSTRALIA
Melbourne

Kodak (Australasia) Pty. Ltd.
181 Victoria Parade
Collingwood, Victoria, 3066
Australia
Tel: [phone]
Fax: [phone]
E-mail:[e-mail]
www.kodak.com.au/go/motion

Sydney

Level 4, 68-72 Waterloo Road
North Ryde, NSW2113
Australia
Tel: [phone]
Fax: [phone]

CHINA (Peoples Republic)
Kodak (China) Limited
Beijing Liaison Office

9th Floor, Beijing Kerry Centre
1 Guanghua Road
Chaoyang District
Beijing 100020 China
Tel: [phone]
Fax: [phone]

Shanghai Liaison Office

Building 8 Jinqiao Office Park
No 27 Xin Qiao Road
Pudong, Shanghai 201206 China
Tel: [phone]
Fax: [phone]

Guangzhou Liaison Office

10F, Office Tower
China Hotel by Marriott
Liu Hua Road
GuangZhou 510015 China
Tel: [phone]
Fax: [phone]
www.kodak.cn/go/motion

HONG KONG
Kodak (Hong Kong) Ltd.

13/F, Cityplaza Four
12 Taikoo Wan Road
Taikoo Shing
Hong Kong
Tel: [phone]
Fax: [phone]
www.kodak.com.hk/go/motion

INDIA
Kodak India Private Limited

3rd Floor, Kalpataru Synergy
Off Western Express Highway
Vakola, Santacruz (East)
Mumbai 400 055 India
Tel: [phone]
Fax: [phone]

www.kodak.co.in/go/motion

INDONESIA
PT. Interdelta Tbk (Kodak Motion
Picture Authorized Distributor in
Indonesia)

Tel: [phone] ext. 250
Mobile: [phone]
Email:[e-mail]

JAPAN
Kodak Japan Ltd.

Tokyo Sumitomo Twin Building (East)
27-1, Shinkawa 2-chome, Chuo-ku
Tokyo 104-0033
Japan
Tel: [phone]
Fax: [phone]
e-mail:[e-mail]
www.kodak.co.jp/go/motion/

KOR EA
Kodak Korea Ltd

7th Floor. Yakult Building
28-10, Jamwon-dong, Seocho-gu
Seoul 137-904
Korea
Tel: [phone]
Fax: [phone]
wwwkr.kodak.com/go/motion

MALAYSIA

5th Floor, Block A
Peremba Square
Saujana Resort, Sec. U2
40150 Shah Alam
Selangor
Malaysia
Tel: [phone]

Fax: [phone]

NEW ZEALAND

Kodak New Zealand Ltd.
Suite 4B
125 The Strand
Parnell 1010
Auckland
New Zealand
Tel: [phone]
Fax: [phone]
www.kodak.co/nz/go/motion

PAK IS TAN

Kodak Ltd Pakistan Branch
5th Floor Bahria Complex 2
M.t.Khan Road
Karachi
Pakis tan
Tel: [phone] & 561 1402
Fax: [phone]

PHILIPPINES

Kodak Philippines Ltd.
2247 Chino Roces Avenue
Makati City
Philippines 1231
Tel: [phone] (trunkline) or 632
813 7916 (direct line)
Fax: [phone]

SINGAPORE

Kodak (Singapore) Pte Ltd
151 Lorong Chuan (Lobby A)
#05-01, New Tech Park
Singapore 556741
Tel: [phone]
Fax: [phone]

TA IW AN

Kodak Taiwan Limited
Shin Kong Life Neihu Technology
Building
3F-1, No.301, Sec. 2, Tiding Blvd.
Neihu District
Taipei 11493
Taiwan, R.O.C.
Tel: [phone]
www.kodak.com.tw/go/motion

THAILAND

Kodak (Thailand) Ltd.
Floors 6 - 8th Kasemsap Bldg.
89/1 Moo 14, Vibhavadee-rangsit Rd.
Chatuchak
Bangkok 10900
Thailand
Tel: [phone]

KODAK VISION3 500T Color

Kodak, Eastman, Keykode, Vision, and Wratten are trademarks.
Negative Film 5219 / 7219 / SO-219
KODAK Publication No. H-1-5219t

New 11-07
Printed in U.S.A.
