Kodak Flash Supermatic Shutter Service Manuals

■ DECEMBER 1949

*i¥<w xefiain....

S. M. No. 1-1490

H AS H

SUPER MAT 1C

SHUTTERS

• For Kodak Medalist II Camera

• With Kodak Ektar f/4.7 127mm., f/3.7 105mm.,
and f/7.7 203mm. Lenses

TABLE OF CONTENTS H

Kodak Flash Supermatic Shutter for

Kodak Medalist II Camera

TROUBLE C H A R T

DISASSEMBLY AND REASSEMBLY.............................................................. 7

Diaphragm Control Ring .....................................................................7

Speed Control Ring

Winding Lever .......................................................... 7

Cover C om p le te ............................................................................. 8

Winding Gear, Clutch Assembly, and Star Wheel A s sem bly ................. 8

Trigger Assembly and Bulb Lever Assem b ly

Retard Gear Train .......................................................................... 9

Main Drive A ssem b ly..........................................................................10

Flash Contact Parts.............................................................................11

Flash Synchronization . . . ...................................... 11

Flash Shutter Contact Conversion K it

Shutter B lad es................................................................................... 13

................................................................................

.....................

7

................

..........................

9

12

Kodak Flash Supermatic Shutter with

Kodak Ektar f/4 .7 127mm, f/ 3. 7 105mm, and f/7 . 7 203mm Lenses

Page

No.

3

TROUBLE C H A R T
DISASSEMBLY AND REASSEMBLY

Speed Control Ring ..........................................................................19

Winding Lever .................................................................

Cover C om p lete................................................................................20

Winding Gear, Clutch Assembly, and Star W heel Assembly ......................

Trigger, Time Lever Assembly, and Bulb Lever A ssembly

Retard Gear Train.............................................................................21

Main Drive Assembly . . . ......................

Flash Contact P arts

Flash Synchronization..........................................................................23

Flash Shutter Contact Conversion K it
Shutter B lad es

• Capitalized words in the text indicate nomenclature which appears on illustrations. Such
nomenclature, when not followed by a direct figure reference, will be found on the figure
indicated in the last preceding figure reference.

....................................................

................................................................

i ....................................... 21

.............................................................

....................................................

..........................................................

15

..............................

19

...

19

. 20

20

22

.2 4

26

KODAK FLASH SUPERMATIC SHUTTER

FOR THE KODAK MEDALIST II CAMERA

TROUBLE CHART

TROUBLE

Solenoid will not work
flash shutter

Synchronizer scale
does not operate

Shutter does not trip
easily

No Kodatron contact The BLADE CONTROLLER

Shutter blades remain
open on high speeds

Shutter does not set

Scale rivet pulled out.

Bind in the operating DISK,
figure 11, at the bearing NUT.

Possible burr on TRIGGER and
collar ASSEMBLY,figure 5.

CONTACT STUD, figure 14, is
not touching the CONTACT
SPRING, figure 8.

Plate blade studs missing on
mechanism plate.

Split shutter blades.

Loose studs on the shutter

blades.
The TRIGGER LATCH, figure 5,

is not returning to its proper
position after the shutter has
been released.

CAUSE

Shutter not designed for use with a solenoid.

REMEDY

Fit new rivet and readjust the scale.

Clean thoroughly. Use powdered graphite.
Blow off excess.

Burnish the trigger and collar assembly at
the point where it contacts the MAIN DRIVE
ASSEMBLY, figure 7, when in a set position.

Adjust the contact spring so that it touches
the contact stud on the blade controller when
the blades are almost fully opened. It is
possible to make the adjustment after re
moving the front lens mount.

Replace and restake the studs carefully to
avoid swelling the top of the studs.

Replace the shutter blades.
Replace the shutter blades.

The trigger latch may be bent and binding
on the speed index plate or cover.

It may be necessary to reduce the tension
on the TRIGGER LATCH SPRING, figure 3.

The winding lever does
not hold when the shut
ter is set

Shutter speeds slow

Copyright, 1949, Eastman Kodak Company
T.M. Reg. U.S. Pat. Off.

The winding gear pinion is loose
on the gear.

The CLUTCH ASSEMBLY, fig

ure 4, is slipping.

The latch point on the contact
LEVER COMPLETE, figure 8,
is damaged.

Retard gears dirty.

The MAIN DRIVE SPRING, fig
ure 7, is weak.

Replace the pinion gear assembly.

Replace the clutch assembly.

Replace the contact lever complete.

Remove and clean the retard gears.
Replace the main drive spring.

3

TROUBLE

CAUSE

REMEDY

Shutter speeds slow
(cont'd)

Shutter speeds fast

Shutter blades buckle NOTE: The following conditions

Shutter blades binding.

Excessive retard sector travel.

Blade controller with contact
stud binding.

Insufficient retard sector
travel.

Insufficient pallet engagement
(on speeds 1/10 second or
slower).

Gear train dirty.
Too much tension on the main

drive spring.

may contribute to blade buckle
singly or in combination.

Remove and clean the shutter blades. If
necessary, replace the blades.

Swedge the SPEED CONTROL RING, figure
2, at the area controlling the slow speed.
(See figure 1.)

Re-form the diaphragm retainer plate to
allow more clearance between the plate
and the mechanism plate. Be sure the

blade controller is flat.
File the speed ring at the area controlling

the fast speed. (See figure 1.)

1. Remove material on the speed control
ring in the area of contact with the pallet
bracket stud.

2. Checkfor bind of the PALLET BRACKET,
figure 6, against the retard gear PLATE
COMPLETE.

Clean the gear train thoroughly.
Replace the main drive spring.

Loose studs on shutter blades

or MECHANISM PLATE,figure

12.

BLADE CONTROLLER with
contact stud, figure 13, not flat.

Shutter blades not flat.
Mechanism plate not flat.
Blade controller too loose or

too tight on the central hub of

the mechanism plate.
Too much play between the

mechanism plate and the dia

phragm retainer PLATE WITH
WINGS ASSEMBLED, figure 13,
due to retainer plate being
bowed.

Burr or roughness on diaphragm
retainer plate with wings as
sembled.

4

Replace the shutter blades. Restake the
studs on the mechanism plate carefully to
avoid swelling the top of the studs.

Straighten or replace the blade controller.

Replace the blades.
Replace the mechanism plate.
Replace the blade controller.

Replace the diaphragm retainer plate with

wings assembled.

Replace the plate.

TROUBLE

CAUSE

REMEDY

Shutter blades buckle

(cont'd)

Shutter operates
instantaneously
on B (bulb)

Both flash settings are
below the millisecond
tolerances (fast).

Both flash settings are
above the millisecond
tolerances (slow)

Blades opening too far.

Blades closing too far.
No clearance between the blade

controller latch and the BLADE
CONTROLLER LUG, figure 14,
when the shutter is in the tripped
position.

The lug on the side of the rec
tangular opening in the trigger
is out of adjustment.

The tension is too great on the

WINDING GEAR SPRING, figure

4.

There is not enough tension on
the winding gear spring.

The winding lever may be bind
ing around the central opening of
the cover or on the speed INDEX
PLATE, figure 2.

File and burnish the blade controller LATCH

at point "A". (See figure 7.)
Swedge mechanism plate at "B", figure 14.
Swedge the mechanism plate at point "C,"

figure 14, such that this point acts as a
stop for the SETTING LEVER with stop
stud, figure 12.

Bend the lug on the trigger in or out until

proper adjustment is achieved.

Relieve the tension slightly on the winding
gear spring. However, there must be enough
tension on the spring to permit the winding
lever to carry through on both the F and M
flash settings.

Place the winding gear spring under slightly
greater tension. Care should be taken dur
ing this adjustment not to disturb the trigger
latch.

Try lubricant, or replace the WINDING
LEVER, figure 2.

The F (short stroke) is
within the millisecond
tolerances but the M
(long stroke) is fast

Constant flash short

Both flash settings are
extremely fast

THE FLASH RETARD PALLET,
figure 3, is not meshing properly
with the winding lever.

The flash retard pallet may be
binding on the speed index plate.

Cracked contact insulating
BLOCK, figure 8.

The contact spring may be bent
and touching either the contact
lever or the cover.

The trigger latch may not be
falling into the slot on the cover.
This allows the shutter blades
to open too soon.

With special Tool No. 657, turn the eccentric
post so that the pallet will mesh firmly in
the teeth of the winding lever. Make certain
the post is tight on the cover after making
this adjustment.

The index plate will be marked at the bind
ing point. File the plate at this point to
allow clearance for the pallet.

Replace the contact insulating block. The
shutter should be checked independently of
the camera. If the shutter is working prop
erly, refit it to the camera. If the short
persists, check the case insulating bushing
NUT, figure 8, to see that it or any part of
the contact wire is not touching the focusing
tube or light guard.

Re-form the contact spring.

Add more tension to the trigger latch spring.

5

TROUBLE CAUSE

REMEDY

Both flash settings are
extremely fast (cont'd)

The end of the trigger latch is
bent back, toward the trigger.
When the latch falls into the
slot on the cover, the bent latch

will permit the trigger to go

down far enough to trip the
shutter blades.

Re-form the end of the trigger latch by
bending it slightly toward the winding gear.

After the shutter has been assembled, it can
be checked to see if the shutter blades will
open before the winding lever opens them.

1. Set the shutter.

2. Set the winding lever.

3. Holding the winding lever down, release
the shutter. The shutter blades should not
open while the winding lever is down.

6

DISASSEMBLY AND REASSEMBLY

DIAPHRAGM CONTROL RING

The sequence of disassembly is as follows:

1. Front lens mount, using Tool No. 501-0.

2. Diaphragm control ring RETAINER WITH
SYNCHRO SCALE, figure 2.

3. Diaphragm control RING SPRINGS (one or
two).

4. DIAPHRAGM CONTROL RING.

The sequence of reassembly is as follows:

1. Diaphragm control ring, fitting the notch
opposite the pointer over the projectinglever
on the DIAPHRAGM RING, figure 2.

2. Diaphragm control ring springs (one or two).

3. Diaphragm control ring retainer with syn
chro scale.

4. Front lens mount, using Tool No. 501-0.

SPEED CONTROL RING

The sequence of disassembly is as follows:

1. Diaphragm control ring, paragraphs 1-4
above.

2. DIAPHRAGM CLICKSTOPSPRING, figure 2.

3. Speed and diaphragm INDEX PLATE and the

SPEED ring CLICK STOP SPRING.

4. SPEED CONTROL RING.

CAUTION: If the WINDING LEVER
is disturbed, the flash timing will
have to be readjusted.

The sequence of reassembly is as follows:

1. Speed control ring with shutter in tripped

position. Be sure the projecting lug on the
BULB LEVER ASSEMBLY, figure 5, the

studs on the retarding SECTOR WITH STUD,
figure 6, and the PALLET BRACKET with
stud assembly are resting against the inside
edge of the speed control ring and are not
underneath the ring.

2. Speed ring click stop spring. The crimped
side of the spring should face toward the
back of the shutter.

3. Speed and diaphragm index plate.

4. Diaphragm click stop spring.

5. Diaphragm control ring, paragraphs 1-4
above.

WINDING LEVER

The sequence of disassembly is as follows:

1. Diaphragm, control ring, paragraphs 1-4
above.

2. Speed control ring, paragraphs 2-4, above.

3. WINDING LEVER, figure 2.

The sequence of reassembly is as follows:

1. Apply a thinfilm of grease (Texaco Unitemp-
RCX169 Grease) to the teeth of the winding
lever.

2. Set the shutter.

3. Winding lever, with the sixth or seventh
tooth from the left meshed with the WIND
ING GEAR, figure 4. Place the WINDING
GEAR SPRING in tension by giving two and
one-quarter strokes to the winding lever,
lifting and replacing the lever after the first
and second strokes. This should be the

DIAPHRAGM RING

COVER COMPLETE

WINDING LEVER

SHUTTER RETAINING RING

SPEED CONTROL RING

SPEED CLICK STOP SPRING

RING SPRING

RETAINER WITH SYNCHRO SCALE

DIAPHRAGM CONTROL RING

DIAPHRAGM CLICK STOP SPRING

Figure 2

7

approximate setting for the flash synchro
nization of the shutter.

8. SHUTTER RETAINING RING, figure 2.

9. COVER COMPLETE, figure 3.

CAUTION: Do not touch the TRIGGER

LATCH, figure 5, as it may release

the winding gear spring tension.

Trip the shutter and lightly hold the wind
ing lever down around the central collar on
the cover. As the shutter is tripped, the
end of the latch should fall into the slot on
the cover. If it does not, add more tension
on the TRIGGER LATCH SPRING, figure 3.
Check for a bind between the trigger latch
and the TRIGGER ASSEMBLY, figure 5, at
the point of attachment. The winding lever
should contact the trigger latch; push the
latch out of the slot in the cover and open the
shutter blades. After the shutter has been
tripped, the latch should return to a position
where it is resting on the ledge just above
the small slot in the cover.

After the trigger is depressed, allow it to
return to its proper position very slowly. If
there, is too much tension on the trigger
latch spring, it will tend to retard the action
of the latch and the trigger.

4. Speed control ring, paragraphs 1-5, page 7.

COVER COMPLETE

The sequence of disassembly is as follows:

1. Diaphragm control ring, paragraphs 1-4,
page 7.

2. Speed control ring, paragraphs 2-4, page 7.

3. Winding lever, paragraph 3, page 7.

4. TRIGGER LATCH SPRING, figure 3.

5. TRIGGER LATCH, figure 5.

6. High speed spring CAM, figure 7, and the
HIGH SPEED SPRING.

7. FLASH RETARD PALLET, figure 3.

The sequence of reassembly is as follows:

1. Cover complete.

2. Set the shutter.

3. Trigger latch, with the long bent end of the
latch contacting the inner edge of the contact
LEVER COMPLETE, figure 8. Be sure the
latch does not bind.

4. Trigger latch spring; do notfasten securely.
Lift the loose end of the spring over the
trigger latch until it is at a point half way

between the latch and the central collar.
Then secure the spring. Place the spring
against the outside edge of the trigger latch.
The latch should be burnished and a thin
film of grease (Texaco Unitemp-RCX169
Grease) applied at the point of spring contact.

5. Shutter retaining ring.

6. Winding lever, paragraphs 1-3, page 7.

7. Flash retard pallet, on the eccentric stud.

Pull down the winding lever slowly and see
that the pallet falls into every tooth of the
lever. If it does not, turn the eccentric stud
until the pallet is closer to the lever, using
Tool No. 657. Care should be taken not to
get the pallet too close to the lever, as this
will cause the action of the lever to be rough.

8. High speed spring and the high speed spring

cam.

9. Winding lever, paragraph 4, page 8.

WINDING GEAR, CLUTCH ASSEMBLY, and STAR
WHEEL ASSEMBLY

The sequence of disassembly is as follows:

1. Diaphragm control ring, paragraphs 1-4,

page 7.

2. Speed control ring, paragraphs 2-4, page 7.

3. Winding lever, paragraph 3, page 7.

4. Cover complete, paragraphs 4-9, page 8.

8

5. WINDING GEAR, figure 4, and the WINDING
GEAR SPRING.

6. CLUTCH ASSEMBLY.

7. STAR WHEEL assembly.

The sequence of reassembly is as follows:

1. Winding gear and the winding gear spring
on the WINDING GEAR STUD, figure 14.

2. Star wheel assembly.

3. Clutch assembly, with a thin film of grease
(Texaco Unitemp-RCX169 Grease) on the
underside of the assembly. The top gear
on the clutch assembly should turn freely
only in a clockwise direction when the lower

gear of the clutch assembly is held tight.

4. Cover complete, paragraphs 1-9, page 8.

TRIGGER ASSEMBLY AND BULB LEVER ASSEM
BLY

The sequence of disassembly is as follows:

1. Diaphragm control ring, paragraphs 1-4,
page 7.

2. Speed control ring, paragraphs 2-4, page 7.

3. Winding lever, paragraph 3, page 7.

4. Cover complete, paragraphs 4-9, page 8.

5. Unhook the MAIN DRIVE SPRING, figure 7,
from the MAIN DRIVE SPRING STUD, figure

14.

6. TRIGGER SCREW, figure 5, TRIGGER
SPRING, TRIGGER WASHER.

7. TRIGGER ASSEMBLY, bulb lever SPACERS,
BULB LEVER ASSEMBLY, and BULB LE
VER SPRING.

The sequence of reassembly is as follows:

1. One bulb lever spacer on the BULB LEVER
STUD, figure 14.

2. With the bulb lever spring underneath, hold
the trigger assembly with the oval hole up
and insert the bulb lever assembly between
that part of the trigger which is operated by
the cable release and the upper part of the
trigger. Insert the projecting lug on the
bulb lever through the rectangular opening
on the trigger.

3. Remaining bulb lever spacer between the
top of the trigger and the top of the bulb
lever assembly.

4. With the hooked end of the bulb lever spring
turned in a clockwise direction, guide the

parts down over the bulb lever stud. Insert
the hooked end of the bulb lever spring into
the small hole in the side of the case.

5. Trigger washer, trigger spring, and trigger
screw. Lift the long end of the spring over
the end of the main drive spring stud, and
rest it against the stud.

6. Hook the loose end of the main drive spring
onto the main drive spring stud.

7. Cover complete, paragraphs 1-9, page 8.

RETARD GEAR TRAIN

The sequence of disassembly is as follows:

1. Diaphragm control ring, paragraphs 1-4,

page 7.

2. Speed control ring, paragraphs 2-4, page 7.

3. Winding lever, paragraph 3, page 7.

4. Cover complete, paragraphs 4-9, page 8.

5. Retard GEAR PLATE SCREW, figure 6,

near the retarding SECTOR WITH STUD.

6. Retard gear plate ANTI-BACKLASH

SPRING.

9

7. Unhook the retard PALLET BRACKET
SPRING. Remove the remaining retard
gear plate screw.

8. Retard gear PLATE COMPLETE.

9. Retard GEAR WITH NO. 2 PINION assembly.

10. Retard GEAR WITH NO. 3 PINION assembly.

11. ESCAPEMENT WHEEL with No. 4 pinion
assembly.

12. Retard PALLET.

13. PALLET BRACKET with stud assembly and
the pallet bracket spring.

NOTE: If the retard gears are dirty,
clean all the parts of the gear train
and the retard gear bearing holes in
the mechanism plate thoroughly.

14. Retarding SEC TOR SCREW. Unhook the re

tarding SECTOR SPRING.

15. Set the shutter.

16. Retarding sector with stud and the retarding
sector spring.

The sequence of reassembly is as follows:

1. Retarding sector with stud and the retard
ing sector spring, with the long end of the
spring at the top.

2. Retarding sector screw.

3. Place the long end of the sector spring
against the inner side of the blade controller
LATCH SPRING BUSHING,figure 7.

4. With the short end of the pallet bracket
spring down, place the spring inside the
pallet bracket with stud assembly. Allow

the long end of the spring to extend out toward
the case. Place the pallet bracket and the
pallet bracket spring on the PALLET
BRACKET SPRING STUD, figure 14. ’The
long end of the spring should rest against
the case.

5. Retard pallet.

6. Escapement wheel with No. 4 pinion assem

bly.

7. Retard gear with No. 3 pinion assembly.

8. Retard gear with No. 2 pinion assembly.

9. Retard gear plate complete, with the teeth
of the gear facing the shutter blades.

10. Retard gear plate screw, near the pallet
bracket.

11. Lift up the gear end of the gear plate until
the teeth of the retarding sector with stud
pass freely under the gear. Place the re
tarding sector so that when the gear teeth
are meshed the outer edge of the sector

will be approximately 1/8 inch from the

shutter case.

12. Retard gear plate anti-backlash spring, on

the RETARD GEAR PLATE STUD, figure 14.

Line up the opening in the spring with the

hole in the gear plate. Replace but do not

tighten the remaining gear plate screw. The

spring should be parallel to the shutter case.
Holding the spring in this position, tighten
the gear plate screw. Hook the end of the
anti-backlash spring on the retard plate
gear LUG, figure 6.

13. Place the long end of the pallet bracket
spring against the inside edge of the lug on
the retard gear plate complete.

14. Cover complete, paragraphs 1-9, page 8.

MAIN DRIVE ASSEMBLY

The sequence of disassembly is as follows:

1. Diaphragm control ring, paragraphs 1-4,
page 7.

2. Speed control ring, paragraphs 2-4, page7.

3. Winding lever, paragraph 3, page 7.

4. Cover complete, paragraphs 4-9, page 8.

5. Unhook the LATCH SPRING, figure 7, from
the main drive LATCH.

6. Unhook the MAIN DRIVE SPRING from the
main drive spring stud.

7. Set the shutter.

8. MAIN DRIVE ASSEMBLY, to which is at
tached the main drive spring.

The sequence of reassembly is as follows:

1. Apply a thinfilm of grease (Texaco Unitemp-

RCX169 Grease) in the slot on the main
drive assembly where it engages the stop
stud on the SETTING LEVER, figure 12; on
the MAIN DRIVE STUD, figure 14; on the
LATCH, figure 7, at the point of contact with
the LATCH SPRING, and on the latch where

it contacts the RETARDING SECTOR STUD,
figure 14. This area of the latch should be
burnished before applying the lubricant.

2. Main drive assembly on the main drive stud,
being sure to fit the setting lever stop stud
into the assembly.

3. Close the shutter blades. Push the latch
toward the BLADE CONTROLLER LUG.
The cutout portion of the latch will come to

rest around the lug. Place the loose end of
the latch spring against the vertical lug on
tip of the latch.

4. Main drive spring.

5. Cover complete, paragraphs 1-9, page 8.

FLASH CONTACT PARTS

The sequence of disassembly is as follows:

1. Diaphragm control ring, paragraphs 1-4,
page 7.

2. Speed control ring, paragraphs 2-4, page 7.

3. Winding lever, paragraph 3, page 7.

4. Cover complete, paragraphs 4-9, page 8.

5. CONTACT WIRE BUSHING, figure 8, the

contact WIRE, and the connector screw NUT.

6. CASE INSULATING BUSHING and the CON

NECTOR SCREW.

7. CONTACT SPRING.

8. Contact insulating BLOCK.

9. Contact LEVER COMPLETE.

The sequence of reassembly is as follows:

1. Contact insulating block.

2. If a new contact lever is to be used, place

the contact LEVER LATCH SPRING, figure
8, on the contact LEVER BUSHING, with the
long end of the spring at the bottom. Lift the
long end of the spring and rest it against the
outside edge of the spring lug on the contact
lever latch. Form the short end of the spring
around the vertical part of the contact lever

tail. Then place the CONTACT LEVER

SPRING on the contact lever bushing. Bend

the last 1/8 inch of the long end of the con

tact lever spring clockwise, with respect to

the bushing, at least 15 degrees.

3. Contact lever complete on the contact lever

stud. The ends of the contact lever spring
should face in, toward the shutter blades.

CONTACT WIRE BUSHING CONTACT LEVER SPRING

\ CASE INSULATING BUSHING

WIRE \ \ LEVER LATCH SPRING

BLOCK

NUT

CONTACT SPRING

CONNECTOR SCREW

Figure 8

LEVER COMPLETE

LEVER BUSHING

Turn the long end of the spring in a clock
wise direction to place it in tension, and
rest it in the groove in the case. Form the
short end of the spring around the vertical
part of the contact lever tail.

CAUTION: The contact lever tail is
burnished and must remain in that
condition.

4. Contact spring.

5. Case insulating bushing with the flat side fac
ing the outer rim of the case.

6. Connector screw and connector screw nut.

7. Contact wire bushing and contact wire.

8. Release the shutter and at the same time
retard its opening action by placing one

finger against the shutter SETTING LEVER,
figure 12. Observe whether the BLADE
CONTROLLER CONTACT STUD, figure 14,
makes slight contact with the contact spring
stud before the blades are fully open. If the
spring does not touch the stud, bend the end
of the spring toward the stud.

9. Cover complete paragraphs 1-9, page 8.

FLASH SYNCHRONIZATION

After the shutter is assembled, it must be
checked to see if the winding lever will always trip
the shutter blades when the trigger is released very
slowly. Set the shutter and the winding lever. Re

lease the shutter, allowing the winding lever to
return slowly. The winding lever must trip the
shutter blades.

The shutter must be checked to see if the shutter

blades will open while the latch is still in the slot
in the cover plate. To check for this condition, set
the shutter and the winding lever. While holding the
winding lever in the fully wound position, depress
the trigger. The shutter blades should not open
while the winding lever is being held down. If they
do, refer to the Trouble Chart. (Both flash settings
extremely fast; see page 5).

Check the operation of the winding lever safety
latch. When the shutter is not set, the winding lever
must be locked in the unwound position. After the
shutter has been actuated with the winding lever, the
lever must return fully and become locked in the

unwound position.

The flash settings on the shutter should be timed

with reliable shutter testing equipment. The toler
ances of the delayed action in the shutter for syn
chronization with the flash bulbs are as follows:

F (short stroke)* 3 1/2--5 1/2 milliseconds.
M(long stroke)* 12--16 milliseconds.

*From instant of contact until the shutter blades

first begin to show light.

1 1

FLASH SHUTTER CONTACT CONVERSION KIT

A more satisfactory operation of the shutter has
been achieved by a change in the design of the
flash contact parts. The old-style parts, which
are to be discarded, are no longer available. They
are to be replaced by the parts furnished in the
Flash Shutter Contact Conversion Kit No.121352 —
Supplement to Parts List No. 1-1490.

OLD-STYLE FLASH CONTACT PARTS

The sequence of disassembly is as follows:

1. CONTACT WIRE BUSHING, figure 9, the
contact WIRE, and the connector screw NUT.

2. CASE INSULATING BUSHING and the CON

NECTOR SCREW.

3. CONTACT SPRING.

4. CONTACT BRACKET with contact point
ASSEMBLY.

5. Contact insulating BLOCK.

6. Contact LEVER COMPLETE.

7. DETENT SPRING AND ROLLER SCREW,
DETENT SPRING AND ROLLER WASHER,

DETENT SPRING AND ROLLER ASSEMBLY

DETENT SPRING AND ROLLER SCREW

DETENT SPRING AND ROLLER WASHER

CONTACT ESCAPEMENT WHEEL

CONNECTOR SCREW

CONTACT SPRING

BLOCK

CONTACT BRACKET ASSEMBLY

LEVER COMPLETE ^

WIRE

c *

CASE INSULATING BUSHING

NUT

CONTACT WIRE BUSHING

Figure 9

and DETENT SPRING AND ROLLER AS-
EMBLY.

8. CONTACT ESCAPEMENT WHEEL.

new -stItle flash cont ac t par ts

The sequence of assembly is as follows:

1. Contact insulating block.

2. Place the contact LEVER LATCH SPRING,
figure 8, on the contact LEVER BUSHING,
with the long end of the spring at the bottom.

Lift the long end of the spring and rest it
against the outside edge of the spring lug on
the contact lever latch. Form the short end
of the spring around the vertical part of the
contact lever tail. Then place the CONTACT

LEVER SPRING on the contact lever bushing.
Bend the last 1 /8 inch of the long end of the
contact lever spring clockwise, with respect
to the bushing, at least 15 degrees.

3. Contact lever complete on the contact lever
stud. The ends of the contact lever spring
should face in, toward the shutter blades.
Turn the long end of the spring in a clock
wise direction to place it intension, and rest
it in the groove in the case. Form the short
end of the spring around the vertical part of

the contact lever tail.

CAUTION: The contact lever tail is
burnished and must remain in that
condition.

4. Contact spring.

5. Case insulating bushing with the flat side
facing the outer rim of the case.

6. Connector screw and connector screw nut.

7. Contact wire bushing and contact wire.

8. Cock and release the shutter and at the same

time retard its opening action by placing one
finger against the shutter SETTING LEVER,
figure 12. Observe whether the BLADE

CONTROLLER CONTACT STUD, figure 14,

makes slight contact with the contact spring
when the blades are fully open. If the spring

does not touch the stud, bend the end of the
spring toward the stud.

9. STAR WHEEL ASSEMBLY, figure 4.

10. Replace the cover complete and the winding
lever.

11. Cock the shutter; then press the trigger
to release the shutter. At the same time
hold the winding lever to prevent its return.
The trigger latch must drop into the slot on
the cover with a distinct snap. If it does not,
check for a bind between the trigger and the

trigger latch or between the trigger latch
and the cover complete. If no bind exists,
increase the tension on the trigger latch
spring. A slight downward pressure on the
trigger latch spring is desirable. There

12

4. Cover complete, paragraphs 4-9, page 8.

5. Winding gear, clutch assembly, and star
wheel assembly, paragraphs 5-7, page 8.

6. Trigger assembly and bulb lever assembly,
paragraphs 5-7, page 9.

7. Retard gear train, paragraphs 5-16, page 9.

8. Main drive assembly, paragraphs 5-8, page

10.

9. Flash contact parts, paragraphs 5-9, page

11.

10. Rear lens mount.

11. Shutter operating disk bearing NUT,figure 11.

12. Shutter operating DISK and the shutter
operating disk SPACER.

13. Blade controller LATCH SPRING BUSHING,
figure 7, and the LATCH SPRING.

14. MECHANISM PLATE, figure 12.

15. Diaphragm retainer PLATE WITH WINGS
ASSEMBLED, figure 13.

16. Shutter blades.

17. BLADE CONTROLLER.

must be approximately .005-inch clearance
between the contact lever tail and that por

tion of the trigger latch which engages the
tail. The contact points must be in contact.
If there is no clearance or if there is exces

sive clearance the spacing maybe controlled
by bending the contact lever tail in or out.

Allow the winding lever to go to the "at

rest" position. Depress the trigger and
watch to see that the flash contacts do not

close. If they close, hold the end of the con

tact lever tail toward the shutter case, place
a screwdriver blade against the vertical

portion of the contact lever tail near the con
tact lever stud, and apply pressure toward

the shutter blades at this point.

With the shutter tripped there must be
approximately .005-inch clearance between
the contact latch spring lug and the side of

the contact lever. This is to assure full

pressure of the contact lever latch into the
star wheel.

While pressing the trigger down fully,
watch the contacts to make sure that they
do not close at any time. If they close, the

contact lever tail on the contact lever has

been bent too far and it should be moved

back slightly. If necessary, the winding
lever should be stoned at point "A",figurelO.
Corner "B" must be square.

The sequence of reassembly is as follows:

1. If necessary, clean the shutter blades thor
oughly. Hold the blades carefully to avoid
bending and clean their surfaces with a soft
cloth. Fingerprints on the blades will cause
corrosion.

2. Blade controller.

SPACER NUT

DISK

Figure 11

SHUTTER BLADES

The sequence of disassembly is as follows:

1. Diaphragm control ring, paragraphs 1-4,
page 7.

2. Speed control ring, paragraphs 2-4, page 7.

3. Winding lever, paragraph 3, page 7.

13

MECHANISM PLATE

BLADE

BLADE WITH DOUBLE

BLADE BUSHING

BLADE
CONTROLLER

BLADE WITH STUD

BULB LEVER STUD

MAIN DRIVE

SPRING STUD

CONTACT ■
LEVER STUD ' ° '

BLADE CONTROLLER

CONTACT STUD

PLATE WITH W ING S

ASSEMBLED

DIAPHRAGM W ING

Figure 13

MAIN DRIVE STUD

RETARDING SECTOR STUD

1

| 'S- , B

__ /

sta r w h ee l stud Figure 14

______

PALLET BRACKET SPRING STUD

WINDING GEAR STUD

CLUTCH STUD

, BLADE CONTROLLER LUG

RETARD GEAR PLATE STUD

3. BLADE WITH DOUBLE BLADE BUSHING
and stud, with the hole in the blade over the
stud on the mechanism plate near the BLADE

CONTROLLER LUG, figure 14. Refer to

figure 15 for positioning of the shutter blade,

4. Proceeding counterclockwise, replace four
BLADES WITH STUD, figure 13, allowing the
wide end of each blade to overlap the narrow
end of the preceding blade.

5. BLADE, over the blade with double blade
bushing and stud. The back of the mechanism
plate should appear as shown in figure 16.

6. Diaphragm retainer plate with wings assem
bled, with the cutout slot in the outer edge
of the retainer plate over the opening in the
mechanism plate for the PALLET BRACKET

with stud assembly, figure 5. After the dia

phragm retainer plate is secured, the shutter

blades should operate freely.

7. Open the shutter blades. Close the dia
phragm wings and run the side of a screw
driver blade around the central opening in
the mechanism plate. This will open the
diaphragm wings uniformly to the maximum
aperture.

8. The shutter CASE, figure 12, diaphragm
RING, and the SETTING LEVER with stop
stud should be thoroughly cleaned. Apply a
thinfilm of grease (Texaco Unitemp-RCX149
Grease) in the recess in the case occupied
by the setting lever. Then wipe this area
lightly with a clean cloth.

9. Diaphragm ring. Turn the ring until the
projecting arm is near the cable release nut.

10. Setting lever with stop stud, with the setting
lever SPRING extending through the opening
in the case with the stop stud near the cable
release nut.

11. Mechanism plate. See that the circular pro
jections on the ends of the diaphragm wings

are in position in the slots in the diaphragm

ring. After the plate is secured, the dia

phragm ring, the setting lever, and the shut
ter blades should operate freely. Secure the
loose end of the setting lever spring.

12. Blade controller latch spring bushing and

latch spring.

13. Shutter operating disk spacer and shutter
operating disk.

14. Shutter operating disk bearing nut.

15. Flash contact parts, paragraphs 1-8, page 11.

16. Main drive assembly, paragraphs 1-4, page

10.

17. Retard gear train, paragraphs 1-13, pages
9 and 10.

18. Trigger assembly, and bulb lever assembly,
paragraphs 1-6, page 9.

19. Winding gear, clutch assembly, and star
wheel assembly, paragraphs 1-4, page 9.

20. Rear lens mount.

14

KODAK FLASH SUPERMATIC SHUTTER

With Kodak Ektar f/ 4 .7 127mm, f/3 .7 105mm,

and f/ 7 .7 203mm Lenses

TROUBLE CHART

TROUBLE

Solenoid will not work
flash shutter

Synchronizer scale
does not operate

Shutter does not trip
easily

No Kodatron contact

Shutter blades remain
open on high speeds

Shutter does not set The TRIGGER LATCH, figure

Scale rivet pulled out.

Possible burr on TRIGGER,
figure 20.

BLADE CONTROLLER CON

TACT STUD, figure 20, is not

touching the CONTACT SPRING,

figure 21.

Plate blade studs missing on

mechanism plate.
Split shutter blades. Replace the shutter blades.
Loose studs on shutter blades. Replace the shutter blades.

20, is not returning to its proper
position after the shutter has
been released.

CAUSE

Shutter not designed for use with a solenoid.

REMEDY

Fit new rivet and readjust the scale.

Burnish the trigger at the point where it

contacts the MAIN DRIVE ASSEMBLY, fig

ure 7, when in a set position.

Adjust the contact spring so that it touches
the contact stud on the blade controller when
the blades are almost fully opened. It is
possible to make the adjustment after re
moving the front lens mount. There must be
no contact when the blades are held open
with the blade arrestor.

Replace and restake the studs carefully to
avoid swelling the top of the studs.

The trigger latch is bent and binding on the
speed index plate or cover.

It may be necessary to reduce the tension
ontheTRIGGER LATCH SPRING, figure 19.

The winding lever does

not hold when the shut

ter is set

Shutter speeds slow Retard gears dirty. Remove and clean the retard gears.

The winding gear pinion is loose
on the gear.

The CLUTCH ASSEMBLY, fig
ure 4, is slipping.

The latch point on the contact
LEVER COMPLETE, figure 21,
is damaged.

The MAIN DRIVE SPRING, fig
ure 7, is weak.

Replace the pinion gear assembly.

Replace the clutch assembly.

Replace the contact lever complete.

Replace the main drive spring.

15

TROUBLE

CAUSE

REMEDY

Shutter speeds slow
(cont’d)

Shutter speeds fast

Shutter blades binding.

Excessive retard sector travel. Swedge the speed control RING, figure 18,

Blade controller binding. Re-form the diaphragm retainer plate to

Insufficient retard sector travel. File the speed control ring at the area con

Insufficient pallet engagement

(on shutter speeds 1/10 second
or slower).

Gear train dirty.
Too much tension on the main

drive spring.

Remove and clean the shutter blades. If
necessary, replace the blades.

at the area controlling the slow speed (see

figure 17).

allow more clearance between the plate and
the mechanism plate.

Be sure the blade controller is flat.

trolling the fast speed (see figure 17).

Remove the material on the speed control
ring in the area of contact with the pallet

bracket stud.
Check for bind of the PALLET BRACKET,

figure 6, against the retard gear PLATE
COMPLETE.

Clean the gear train thoroughly.
Replace the main drive spring.

Shutter blades buckle

NOTE: The following conditions
may contribute to blade buckle
singly or in combination.

Loose studs on shutter blades
or MECHANISM PLATE, figure

23.
BLADE CONTROLLER with

contact stud,figure 13, not flat.
Shutter blades not flat.
Mechanism plate not flat.
Blade controller too loose or

too tight on the central hub of the

mechanism plate.

Too much play between mecha
nism plate and diaphragm re
tainer PLATE WITH WINGS
ASSEMBLED, figure 13, due to
retainer plate being bowed.

Burr or roughness on diaphragm
retainer plate with wings as
sembled.

Replace the shutter blades. Restake the
studs on the mechanism plate carefully to
avoid swelling the top of the stud.

Straighten or replace the blade controller.

Replace the blades.
Replace the mechanism plate.
Replace the blade controller.

Replace the diaphragm retainer plate with
wings assembled.

Replace the plate.

16

TROUBLE

CAUSE REMEDY

Shutter blades buckle

(cont’d)

Shutter operates in
stantaneously on B

(bulb)

Both flash settings are
below the millisecond

tolerances (fast)

Both flash settings are
above the millisecond
tolerances (slow)

Blades opening too far.

Blades closing too far.

No clearance between the blade
controller latch and the BLADE

CONTROLLER LUG, figure 26,
ped position.
The lug on the side of the rec

tangular opening in the trigger
is out of adjustment.

The tension is too great on the
WINDING GEAR SPRING, figure

4.

There is not enough tension on
the winding gear spring.

The winding lever may be bind
ing around the central opening
of the cover or on the speed
INDEX PLATE, figure 18.

File and burnish the blade controller LATCH
at point “A” (see figure 7).

Swedge the mechanism plate at point “B”

(see figure 26).

Swedge the mechanism plate at point “ C”,
figure 26, such that this point acts as a stop
for the SETTING LEVER with stop stud,
figure 23.

Bend the lug on the trigger in or out until
proper adjustment is achieved.

Relieve the tension slightly on the winding
gear spring. However, there must be enough

tension on the spring to permit the winding

lever to carry through on both the F and M

flash settings.
Place the winding gear spring under slightly

greater tension. Care should be taken dur
ing this adjustment not to disturb the trigger
latch.

Try lubricant or replace the WINDING
LEVER, figure 18.

The F (short stroke)
is within the milli

second tolerances but

the M (long stroke) is

fast

Constant flash short

Both flash settings are
extremely fast

FLASH RETARD PALLET as
sembly, figure 19, not meshing
properly with the winding lever.

The flash retard pallet may be
binding on the speed index plate.

The contact spring may be bent

and touching either the contact
lever or the cover.

The trigger latch may not be
falling into the slot on the cover.
This allows the shutter blades
to open too soon.

The end of the trigger latch is
bent back, toward the trigger.
When the latch falls into the slot
on the cover, the bent latch will

permit the trigger to go down
far enough to trip the shutter
blades.

With special Tool No. 657, turn the eccen
tric post so that the pallet will mesh more
firmly in the teeth of the winding lever.
Make certain the post is tight on the cover
after making this adjustment.

The index plate will be marked at the bind

ing point. File the plate at this point to al
low clearance for the pallet.

Re-form the contact spring.

Add more tension to the trigger latch spring.

Re-form the end of the trigger latch by

bending it slightly towards the winding gear.
After the shutter has been assembled, it can

be checked to see if the shutter blades will
open before the winding lever opens them.

1. Set the shutter.
17

TROUBLE

CAUSE

REMEDY

Both flash settings are
extremely fast (cont’d)

Shutter will not flash
lamps when all-metal

flasholderis in contact

with camera, but will,
when flasholderis held
away from camera

Breakdown in the insulation of
ground strap.

2. Set the winding lever.

3. Holding the winding lever down, release
the shutter. The shutter blades should not
open while the winding lever is down.

There should be a resistance of 10,000 ohms
between the connector pin nearest the blade
arrestor button and any other spot on the

shutter case. If not, replace the groxfnd
strap, together with the resistor.

18

DISASSEMBLY AND REASSEMBLY

SPEED CONTROL RING

The sequence of disassembly is as follows:

1. Front lens mount, using Tool No. 501-0.

2. Diaphragm pointer TIP, figure 18.

3. Set the synchronizer scale at “M.”

4. Speed and diaphragm INDEX PLATE, by
turning the plate counterclockwise until the
three projections in the center of the plate
fit into the three cutouts on the outside edge
of the central collar.

5. Speed control RING.

CAUTION: If the WINDING LEVER
is disturbed, the flash timing will
have to be adjusted.

The sequence of reassembly is as follows:

1. Speed control ring, with shutter in tripped
position. Be sure the projecting lug on the

BULB LEVER ASSEMBLY, figure 20, the
studs on the retarding SECTOR WITH STUD,

figure 6, and the PALLET BRACKET with

stud assembly are resting against the inside
edge of the speed control ring and are not

underneath the ring.

2. Speed and diaphragm index plate, by lining
up the three projections in the center of the
plate with the three cutouts on the outside
edge of the central collar. Turn the plate

clockwise until it is properly positioned.

3. Diaphragm pointer tip.

4. Front lens mount.

WINDING LEVER

The sequence of reassembly is as follows:

1. Apply athinfilm of grease (Texaco Unitemp-
RCX169 Grease) to the teeth of the winding
lever.

2. Set the shutter.

3. Winding lever, with the sixth or seventh
tooth from the left meshed with the WIND
ING GEAR, figure 4. Place the WINDING
GEAR SPRING in tension by giving two and
one-quarter strokes to the winding lever,
lifting and replacing the lever after the first
and second strokes. This should be the ap
proximate setting for the flash synchroniza

tion of the shutter.
CAUTION: Do not touch the TRIGGER

LATCH, figure 20, as it may release

the winding gear spring tension.

Trip the shutter and lightly hold the wind
ing lever down around the central collar on
the cover. As the shutter is tripped, the end

of the latch should fall into the slot on the
cover. If it does not, add more tension on the
TRIGGER LATCH SPRING, figure 19. Check

for a bind between the trigger latch and the

TRIGGER, figure 20, at the point of attach

ment. The winding lever should contact the
trigger latch; push the latch out of the slot
in the cover and open the shutter blades.
After the shutter has been tripped, the latch
should return to a position where it is rest
ing on the ledge just above the small slot in

the cover.

After the trigger is depressed, allow it to

The sequence of disassembly is as follows:

1. Speed control ring, paragraphs 1-5 above.

2. WINDING LEVER, figure 18.

BLOCK

Figure 18

FLASH RETARD PALLET

Figure 19

19

return to its proper position very slowly. If

there is too muchtension on the trigger latch

spring, it will tend to retard the action of the
latch and the trigger.

4. Speed control ring, paragraphs 1-4, page 19.

COVER COMPLETE

The sequence of disassembly is as follows:

1. Speed control ring, paragraphs 1-5, page 19.

2. Winding lever, paragraph 2, page 19.

3. TRIGGER LATCH SPRING, figure 19.

4. Lift up the loose end of the TRIGGER LATCH,
figure 20, sufficiently to clear the COVER
COMPLETE, figure 19. Move the end of
the latch until it is clear of the CASE,
figure 18.

5. High speed spring CAM, figure 7, and the
HIGH SPEED SPRING.

6. FLASH RETARD PALLET assembly, figure

19.

7. COVER COMPLETE.

The sequence of reassembly is as follows:

1. Cover complete.

2. Set the shutter.

3. Trigger latch, with the long bent end of the

latch contacting the inner edge of the contact
LEVER COMPLETE, figure 21. Be sure the

latch does not bind.

4. Trigger latch spring; do not fasten securely.
Lift the loose end of the spring over the
trigger latch until it is at a point half way
between the latch and the central collar.
Then secure the spring. Place the spring
against the outside edge of the trigger latch.
The latch should be burnished and a thin film
of grease (TexacoUnitemp-RCX169 Grease)
applied at the point of spring contact.

5. Winding lever, paragraphs 1-3, page 19.

6. Flash retard pallet assembly on the eccen
tric stud.

Pull down the winding lever slowly and
see that the pallet falls into every tooth of
the lever. If it does not, turn the eccentric
stud until the pallet is closer to the lever,

using Tool No. 657. Care should be taken

not to get the pallet too close to the lever, as
this will cause the action of the lever to be
rough.

NOTE: Be sure the eccentric stud is

tight on the cover. If any adjustment
is made to the stud, it should be an
chored securely in position on the
cover complete.

7. High speed spring and the high speed spring
cam.

8. Winding lever, paragraph 4, page 19.

WINDING GEAR, CLUTCH ASSEMBLY, AND STAR
WHEEL ASSEMBLY

The sequence of disassembly is as follows:

1. Speed control ring, paragraphs 1-5, page 19.

2. Winding lever, paragraph 2, page 19.

3. Cover complete, paragraphs 3-7 above.

4. WINDING GEAR, figure 4, and the WINDING

GEAR SPRING.

5. CLUTCH ASSEMBLY.

6. STAR WHEEL ASSEMBLY.

The sequence of reassembly is as follows:

1. Winding gear and the winding gear spring

on the WINDING GEAR STUD, figure 26.

2. Star wheel assembly.

3. Clutch assembly, with a thin film of grease
(Texaco Unitemp-RCXl69 Grease) on the

underside of the assembly. The top gear

of the clutch assembly should turn freely
only in a clockwise direction when the lower

gear of the clutch assembly is held tight.

4. Cover complete, paragraphs 1-8 above.

20

TRIGGER, TIME LEVER ASSEMBLY, AND BULB
LEVER ASSEMBLY

The sequence of disassembly is as follows:

1. Speed control ring, paragraphs 1-5, page 19.

2. Winding lever, paragraph 2, page 19.

3. Cover complete, paragraphs 3-7 above.

4. Unhook the MAIN DRIVE SPRING, figure 7,
from the MAIN DRIVE SPRING STUD, figure

26.

5. TRIGGER SCREW, figure 20, TRIGGER
SPRING, and TRIGGER WASHER.

6. TRIGGER, TIME LEVER ASSEMBLY, TIME

LEVER SPRING, BULB LEVER ASSEMBLY,

and BULB LEVER SPRING.

The sequence of reassembly is as follows:

1. With the bulb lever spring underneath, hold
the trigger with the oval hole up and insert
the bulb lever assembly in the opening on
the trigger. Place the time lever assembly

and the time lever spring between the top
of the trigger and the top of the bulb lever
assembly with the spring facing up. Grasp

the three parts by inserting one prong of a

pair of tweezers down through the center of
the holes. With the longer ends of the time
and bulb lever springs turned in a clockwise
direction and the shorter ends resting against
the lugs on the levers, guide the parts down
over the TIME AND BULB LEVER STUD,
figure 26. The long ends of the springs

should rest against the case.

2. Trigger washer, trigger spring, and trigger

screw. Lift the long end of the spring over
the end of the MAIN DRIVE SPRING STUD,
and rest it against the stud.

3. Hook the loose end of the main drive spring
onto the main drive spring stud.

4. Cover complete, paragraphs 1-8, page 20.

RETARD GEAR TRAIN

The sequence of disassembly is as follows:

1. Speed control ring, paragraphs 1-5, page 19.

2. Winding lever, paragraph 2, page 19.

3. Cover complete, paragraphs 3-7, page 20.

4. Retard GEAR PLATE SCREW, figure 6, near
the retarding SECTOR WITH STUD.

5. Retard gear plate ANTI -BACKLASH SPRING.

6. Unhook the retard PALLET BRACKET
SPRING. Remove the remaining retard gear
plate screw.

7. Retard gear PLATE COMPLETE.

8. Retard GEAR WITH NO. 2 PINION assembly.

9. Retard GEAR WITH NO. 3 PINION assembly.

10. ESCAPEMENT WHEEL with No. 4 pinion
assembly.

11. Retard PALLET.

12. PALLET BRACKET with stud assembly and
pallet bracket spring.

NOTE: If the retard gears are dirty,
clean the retard gear bearing holes

in the mechanism plate and all the

parts of the gear train thoroughly.

13. Retarding SECTOR SCREW. Unhook the re
tarding SECTOR SPRING.

14. Set the shutter.

15. Retarding sector with stud and the retarding

sector spring.

The sequence of reassembly is as follows:

1. Retarding sector with stud and the retarding

sector spring, with the long end of the spring

at the top.

2. Retarding sector screw.

3. Place the long end of the spring against the
inner side of the blade controller LATCH
SPRING BUSHING, figure 7.

4. With the short end of the pallet bracket spring
down, place the spring inside the pallet
bracket with stud assembly. Allow the long
end of the spring to extend out toward the
case. Place the pallet bracket and the pallet
bracket spring on the PALLET BRACKET
SPRING STUD, figure 26. The long end of
the spring should rest against the inside of

the case.

5. Retard pallet.

6. Escapement wheel with No. 4 pinion as
sembly.

7. Retard gear with No. 3 pinion assembly.

8. Retard gear with No. 2 pinion assembly.

9. Retard gear plate complete, with the teeth
of the gear facing the shutter blades.

10. Retard gear plate screw near the pallet
bracket.

11. Lift up the gear end of the gear plate until
the teeth of the retarding sector with stud
pass freely under the gear. Place the re
tarding sector so that when the gear teeth
are meshed the outer edge of the sector will
be approximately 1/8 inch from the shutter
case.

12. Retard gear plate anti-backlash spring on

the RETARD GEAR PLATE STUD, figure 26.

Line up the opening in the spring with the
hole in the gear plate. Replace, but do not
tighten, the remaining gear plate screw. The
spring should be parallel to the shutter case.
Holding the spring in this position, tighten

the gear plate screw. Hook the end of the

anti-backlash spring onto the retard plate
gear LUG, figure 6.

13. Put the pallet bracket spring in tension by

placing the Jong end of the spring against
the inside edge of the lug on the retard gear
plate complete.

14. Cover complete, paragraphs 1-8, page 20.

MAIN DRIVE ASSEMBLY

The sequence of disassembly is as follows:

1. Speed control ring, paragraphs 1-5, page 19.

2. Winding lever, paragraph 2, page 19.

3. Cover complete, paragraphs 3-7, page 20.

4. Unhook the LATCH SPRING, figure 7, from
the main drive LATCH.

5. Unhook the MAIN DRIVE SPRING from the
MAIN DRIVE SPRING STUD, figure 26.

6. Set the shutter.

7. MAIN DRIVE ASSEMBLY, figure 7,to which
is attached the main drive spring.

2 1

The sequence of reassembly is as follows:

1. Apply a thinfilm of grease (Texaco Unitemp-
RCX169 Grease) in the slot on the main drive
assembly where it engages the stop stud on

the SETTING LEVER, figure 23; on the MAIN

DRIVE STUD, figure 26; on the LATCH,
figure 7, at the point of contact with the
LATCH SPRING, and on the latch where it
contacts the RETARDING SECTOR STUD,

figure 26. This area of the latch should be

burnished before applying the lubricant.

2. Main drive assembly on the main drive stud,
being sure to fit the setting lever stop stud
into the assembly.

3. Close the shutter blades. Push the latch
toward the BLADE CONTROLLER LUG, fig
ure 26. The cutout part of the latch will
come to rest around the lug. Place the loose

end of the latch spring against the vertical

lug on the tip of the latch.

4. Main drive spring.

5. Cover complete, paragraphs 1-8, page 20.

FLASH CONTACT PARTS

The sequence of disassembly is as follows:

1. Speed control ring, paragraphs 1-5, page 19.

2. Winding lever, paragraph 2, page 19.

3. Cover complete, paragraphs 3-7, page 20.

4. CONNECTOR PINS, figure 21, using Tool
No. 635.

5. Connector BLOCK, figure 18, by removing
the two connector block screws.

6. Disengage the RESISTOR from the mecha
nism plate.

7. CONTACT STRIP CONNECTOR SCREW

8. Holding the CONTACT SCREW, figure 21,
with Tool No. 262, remove the CONTACT
SCREW NUT, using Tool No. 503L. Remove
the contact screw.

9. CONTACT SPRING, to which is fastened the
GROUND CONTACT STRIP and the resistor.
Remove the case insulator WASHER and the
case INSULATOR.

10. Contact LEVER COMPLETE.

11. Shutters of the flash receptacle type are
disassembled as follows: Using Tool No.
503J, remove the TERMINAL NUT, figure 22,
on the end of the PLUNGER ASSEMBLY. Re
move the case INSULATOR WASHER, the

plunger assembly, and the terminal body

insulating SLEEVE. On the contact end of

the CONTACT SPRING, remove the CON
TACT SCREW NUT, using Tool No. 503L.
Remove the CONTACT SCREW, the contact
spring, the case INSULATOR WASHER, and
the case INSULATOR. Then remove the
contact LEVER COMPLETE.

The sequence of reassembly is as follows:

1. If a new contact lever is to be used, place
the contact LEVER LATCH SPRING, figure
21, on the contact LEVER BUSHING, with
the long end of the spring at the bottom.

Lift the long end of the spring and rest it
against the outside edge of the spring lug on
the contact lever latch. Form the short end

• 22

CONTACT LEVER SPRING

LEVER LATCH SPRING

LEVER COMPLETE

.. CONTACT SCREW

✓INSULATOR WASHER

o

^ INSULATOR

1

CONTACT SCREW NUT

PLUNGER ASSEMBLY

TERMINAL NUT

CONTACT SPRING

C *— INSULATOR WASHER

--------

II

SLEEVE

- I

Figure 22

of the spring around the vertical part of the

contact lever tail. Then place the CONTACT
LEVER SPRING on the contact lever bush

ing. Bend the last 1/8 inch of the long end

of the spring clockwise, with respect to the

bushing, at least 15 degrees.

2. Contact lever complete on the CONTACT
LEVER STUD, figure 26. The ends of the

contact lever spring should face in, toward
the shutter blades. Turn the long end of the

spring in a clockwise direction to place it

in tension, and rest it in the groove in the
case. Form the short end of the spring
around the vertical part of the contact lever
tail.

CAUTION: The contact lever tail is
burnished and must remain in that
condition.

3. Contact spring. Place the case insulator

washer between the shutter case and the con
tact end of the contact spring and insert
the contact screw. Secure the spring by re
placing the case insulator and the contact
screw nut. Tighten the nut by holding the
contact screw with Tool No. 262, and turn
the nut with Tool No. 503L.

4. Ground contact strip connector screw.

5. Connector block.

6. Connector pins.

7. Resistor.

8. If the shutter is of the flash receptacle

plunger type, insert the threaded end of the

plunger assembly in the collar end of the
terminal body insulating sleeve. Then in

sert the assembled parts in the terminal
body. Place the case insulator washer on the
end of the plunger. Position the end of the
contact spring over the opening in the shut

ter case and push the threaded end of the
plunger through the opening in the spring.

Fasten the plunger with the terminal nut.

Insert the case insulator in the hole in the

side of the shutter case, near the stud on the

blade controller, with the collar end of the
insulator facing out. Replace the case insu
lator washer over the opening on the inside
of the shutter case. Position the contact end

of the contact spring against the washer and
insert the contact screw. Secure the screw
with the contact screw nut, using Tool No.

503L, holding the screw with Tool No. 262.

9. Trip the shutter and at the same time retard
its opening action by placing one finger
against the shutter SETTING LEVER, figure

2 3. Observe whether the BLADE CONTROL -

LER CONTACT STUD, figure 26, makes

slight contact with the contact spring just
before the blades are fully open. If the
spring does not touch the stud, bend the end
of the spring toward the stud.

10. Cover complete, paragraphs 1-8, page 20.

FLASH SYNCHRONIZATION

After the shutter is assembled, it must be

checked to see if the winding lever will always

MECHANISM PLATE SETTING LEVER

PLATE WITH WINGS ASSEMBLED SETTING LEVER SPRING

Figure 23

23

trip the shutter blades when the trigger is released
very slowly. Set the shutter and the winding lever.
Release the shutter allowing the winding lever to

return slowly. The winding lever must trip the
shutter blades.

The shutter must be checked to see if the shut

ter blades will open while the latch is still in the

slot in the cover plate. To check for this condition,

set the shutter and winding lever. While holding
the winding lever in the fully wound position, depress
the trigger. The shutter blades should not open

while the winding lever is being held down. If they
do, refer to the Trouble Chart. (Both flash set
tings extremely fast, see page 17.)

Check the operation of the winding lever safety
latch. When the shutter is not set, the winding lever
must be locked in the unwound position. After the
shutter has been actuated with the winding lever,

the winding lever must return fully and become
locked in the unwound position.

The flash settings on the shutter should be
timed with reliable shutter testing equipment. The
tolerances of the delayed action in the shutter for
synchronization with the flash bulbs are as follows:

F (short stroke)* 3 1/2—5 1/2 milliseconds
M (long stroke)* 12 — 16 milliseconds

♦From instant of contact until the shutter blades

first begin to show light.

DETENT SPRING AND ROLLER ASSEMBLY

: -

DETENT SPRING AND ROLLER SCREW

DETENT SPRING AND ROLLER WASHER

CONTACT ESCAPEMENT WHEEL

FLASH SHUTTER CONTACT CONVERSION KIT

A more satisfactory operation of the shutter has
been achieved by a change in the design of the flash
contact parts. The old-style parts, which are to be
discarded, are no longer available. They are to be
replaced by the parts furnished in the Flash Shutter
Contact Conversion Kit No. 121351 — Supplement
to Parts List No. 1-1490.

OLD-STYLE FLASH CONTACT PARTS

The sequence of disassembly is as follows:

1. CONNECTOR PINS, figure 24, using Tool
No. 635.

2. Connector BLOCK, figure 18.

3. Disengage the RESISTOR from the mecha
nism plate.

4. Contact LEVER COMPLETE.

5. Ground CONTACT STRIP CONNECTOR
SCREW.

6. Holding the CONTACT SCREW, figure 24,
with Tool No. 262, remove the CONTACT

SCREW NUT, using Tool No. 503L. Remove
the contact screw, the case insulator WASH

ER and the CONTACT SPRING. Remove the
resistor from the contact lever complete.

7. DETENT SPRING AND ROLLER SCREW,
DETENT SPRING AND ROLLER WASHER
and DETENT SPRING AND ROLLER ASSEM
BLY.

8. CONTACT ESCAPEMENT WHEEL.

9. Shutters of the flash receptacle type are

disassembled as follows: Using Tool No.

503J, remove the TERMINAL NUT, figure
25, on the end of the PLUNGER ASSEMBLY.

Remove the case INSULATOR WASHER, the
plunger assembly, and the terminal body
insulating SLEEVE. On the contact end of
the CONTACT SPRING, remove the CON
TACT SCREW NUT, using Tool No. 503L.

\ RESISTOR

£) Wk

CONTACT SCREW

INSULATOR

CONTACT SCREW NUT

24

LEVER COMPLETE

CONTACT STRIP

CONNECTOR SCREW

CONNECTOR PIN

WASHER

CONTACT SPRING

CONNECTOR PIN ‘

Figure 24

Remove the CONTACT SCREW, the contact
spring, the case INSULATOR WASHER, and
the case INSULATOR. Remove the contact
LEVER COMPLETE.

NEW-STYLE FLASH CONTACT PARTS

The sequence of assembly is as follows:

1. Place the contact LEVER LATCH SPRING,
figure 21, on the contact LEVER BUSHING,
with the long end of the spring at the bottom
and facing the shutter blades. Lift the long
end of the spring and rest it against the out
side edge of the spring lug on the contact
lever latch. Formthe short end of the spring
around the vertical part of the contact lever
tail. Then place the CONTACT LEVER
SPRING on the contact lever bushing. Bend
the last 1/8 inch of the long end of the spring
clockwise, with respect to the bushing, at
least 15 degrees.

2. Contact lever complete on the CONTACT
LEVER STUD, figure 26. The ends of the
contact lever spring should face in, toward
the shutter blades. Turn the long end of the
spring in a clockwise direction to place it in
tension, and rest it in the groove in the case.
Form the short end of the spring around the
vertical part of the contact lever tail.

CAUTION: The contact lever tail is
burnished and must remain in that
condition. If the contact lever touches
the bulb lever assembly, approximate
ly .010 inch should be removed from
the end of the lever.

3. Contact spring of the connector pin type
shutter. Place the case insulator washer
between the shutter case and the contact end
of the contact spring and insert the contact
screw. Secure the spring by replacing
the case insulator and the contact screw nut.
Tighten the nut by holding the contact screw
with Tool No. 262, and turn the nut with Tool
No. 503L.

4. Ground contact strip connector screw.

5. Connector block.

6. Connector pins.

7. Secure the looped wire end of the resistor
to the mechanism plate. Solder the other
end of the resistor to the ground contact
strip.

8. If the shutter is of the flash receptacle
plunger type, see figure 22. Fit the contact
lever spring and the contact lever as de
scribed in paragraphs 1 and 2 above. Insert
the threaded end of the plunger assembly in
the collar end of the terminal body insulating
sleeve. Then insert the assembled parts in

the terminal body. Place the case insulator
washer on the end of the plunger assembly.
Position the end of the contact spring over
the opening in the shutter case and push the
threaded end of the plunger assembly through
the opening in the spring. Fasten the plunger
with the terminal nut.

Insert the case insulator in the hole in the
inside of the case, near the stud on the blade
controller, with the collar end of the insu
lator facing out. Replace the case insulator
washer over the opening in the outside of
the shutter case. Position the contact end of

the contact spring against the washer and
insert the contact screw in the opening in
the spring. Fasten the screw with the con
tact screw nut, using Tool No. 503L, while
holding the screw with Tool No. 262.

9. Trip the shutter and at the same time retard
its opening action by placing one finger
against the shutter SETTING LEVER, figure

23. Observe whether the BLADE CONTROL
LER CONTACT STUD, figure 26, makes
slight contact with the contact spring just
before the blades are fully open. If the
spring does not touch the stud, bend the end
of the spring toward the stud.

10. STAR WHEEL ASSEMBLY, figure 4.

11. Replace the cover complete and the winding
lever.

12. Cock the shutter; then press the trigger to
release the shutter. At the same time hold

the winding lever to prevent its return. The
trigger latch must drop into the slot on the
cover with a distinct snap. If it does not,
check for a bind between the trigger and the
trigger latch or between the trigger latch and
the cover complete. If no bind exists, in
crease the tension on the trigger latch spring.
A slight downward pressure on the spring
is desirable. There must be approximately

MAIN

TIME AND BULB

LEVER STUD

MAIN DRIVE
SPRING STUD

CONTACT

LEVER STUD

BLADE CONTROLLER

CONTACT STUD

STAR

STUD

RETARDING SECTOR STUD

ILADE CONTROLLER

RETARD GEAR

PLATE STUD

PALLET BRACKET

SPRING STUD

WINDING GEAR STUD

CLUTCH STUD

w h ee l st u d Figure 26

LUG

25

.005 inch clearance between the contact
lever tail and that part of the trigger latch
which engages the tail. The contact points
must be in contact. If there is no clearance
or if there is excessive clearance, the
spacing may be controlled by bending the

contact lever tail in or out.

Allow the winding lever to go to the “at

rest” position. Depress the trigger and

watch to see that the flash contacts do not
close. If they close, hold the end of the con
tact lever tail toward the shutter case,
place a screwdriver blade against the verti
cal position of the contact lever tail near the
contact lever stud, and apply pressure to

ward the shutter blades at this point.

With the shutter tripped, there must be
approximately .005 inch clearance between
the contact lever latch spring lug and the

side of the contact lever. This is to assure

fullpressure of the latchintothe star wheel.

While pressing the trigger down fully,
watch the contacts to make sure they do not
close at any time. If they close, the con
tact lever tail on the contact lever has been
bent too far and it should be moved back
slightly. If necessary, the winding lever
should be stoned at point “A ” figure 10.
Corner “B” must be square.

SHUTTER BLADES

The sequence of disassembly is as follows:

1. Speed control ring, paragraphs 1-5, page 19.

2. Winding lever, paragraph 2, page 19.

3. Cover complete, paragraphs 3-7, page 20.

4. Winding gear, clutch assembly, and star
wheel assembly, paragraphs 4-6, page 20.

5. Trigger assembly, time lever assembly,

and bulb lever assembly, paragraphs 4-6,
page 20.

6. Retardgear train,paragraphs4-5,page 21.

7. Main drive assembly, paragraphs 4 -7 , page 21.

8. Flash contact parts, paragraphs 4-1 1, page 22.

9. Rear lens mount.

10. Blade controller LATCH SPRING BUSHING,
figure 7,and the LATCH SPRING.

11. MECHANISM PLATE, figure 23.

12. Diaphragm retainer PLATE WITH WINGS

ASSEMBLED.

13. Shutter blades.

14. BLADE CONTROLLER, figure 13.

The sequence of reassembly is as follows:

1. If necessary, clean the shutter blades thor-
oughly. Hold the blades carefully to avoid

bending and clean their surfaces with a soft

cloth. Fingerprints on the blades will cause
corrosion.

2. Blade controller.

3. BLADE WITH DOUBLE BLADE BUSHING
and stud, figure 13, with the hole in the
blade over the stud on the mechanism plate,
nearthe BLADE CONTROLLER LUG, figure

26. Refer to figure 15 for positioning of the
shutter blade.

4. Proceeding counterclockwise, replace four
BLADES WITH STUD, figure 13, allowing

the wide end of each blade to overlap the

narrow end of the preceding blade.

5. BLADE, over the blade with double blade

bushing and stud. The back of the mecha
nism plate should appear as shown in figure

16.

6. Diaphragm retainer plate with wings assem
bled, with the cutout slot in the outer edge
of the retainer plate over the opening in the
mechanism for the PALLET BRACKET with
stud assembly, figure 6. After the retainer

plate is secured, the shutter blades should

operate freely.

7. Open the shutter blades. Close the dia

phragm wings and run the side of a screw
driver blade around the central opening in
the mechanism plate. This will open the dia
phragm wings uniformly to the maximum
aperture.

8. The shutter CASE, figure 23, diaphragm
POINTER and the SETTING LEVER should
be thoroughly cleaned. Apply a thin film of
grease (Texaco Unitemp-RCX169 Grease) in
the recess in the case occupied by the set
ting lever. Then wipe this area lightly with
a clean cloth.

9. Diaphragm pointer. Turn the pointer until

the projecting arm is nearthe cable release

nut.

10. Setting lever, with one end of the SETTING
LEVER SPRING attached to the lever and

the loose end of the spring resting against
the side of the shutter case.

11. Mechanismplate. See that the circularpro-

jections on the ends of the diaphragm wings
are in position in the slots in the pointer.
After the plate is secured, the diaphragm
ring, the setting lever, and the shutter
blades should operate freely. Secure the
loose end of the setting lever spring to the
case stud.

12. Blade controller latch and latch spring.

13. Flash contact parts, paragraphs 1-9, page 22.

14. Main drive assembly, paragraphs 1-4,page 22.

15. Retard gear train, paragraphs 1-13, page 21.

16. Trigger assembly, time lever assembly and
bulb lever assembly, paragraphs 1 -3 , page 21.

17. Winding gear, clutch assembly, and star
wheel assembly, paragraphs 1-4, page 20.

18. Rear lens mount.

26

TOOL NO. 501-0 TOOL NO. 503-J TOOL NO. 635 TOOL NO. 503-F

Figure 27

12-49-GLP-B

EASTMAN KODAK COMPANY

ROCHESTER 4, N. Y.

lithographed in the United States of America

NOVEMBER 1950

PARTS LIST No. 1-1490D

KODAK FLASH SUPERMATIC SHUTTER

FOR KODAK ME DA LIS T II C AM ERA

This parts list supersedes the section of parts list No. 1-1490 which
covered the shutter for the Kodak Medalist II Camera.

The illustrations and parts list are in the sequence of disassembly.

V _

jgg

MS

V lf i t

-

ml

ADAPTER RING INSERT, OLD MODEL— HE25466
(USE WITH LENS CAP— HE28035)

FRONT LENS CAP, NEW MODEL— HE25094 / FRONT LENS ASSEMBLY— RETURN SHUTTER

(USE WITH ADAPTER RING INSERT— HE31394) / TO ROCHESTER FOR REPLACEMENT

FRONT LENS CAP, OLD MODEL— HE28035 ADAPTER RING INSERT, NEW MODEL— HE31394 Figure 1
(USE WITH ADAPTER RING INSERT— HE25466) (USE WITH LENS CAP— HE25094)

DIAPHRAGM INDEX PLATE AND SCALE ASSEMBLY, NEW MODEL— 107153

DIAPHRAGM CONTROL RING AND POINTER

REAR VIEW

ASSEMBLY, NEW MODEL— 102249

DISCONTINUED— REPLACE WITH:

PLATE ASSEMBLY, NEW MODEL— 107153
RING ASSEMBLY, NEW MODEL— 102249

DIAPHRAGM INDEX PLATE AND SCALE ASSEMBLY, OLD MODEL— 96801

2

Copyright .1 951, Eastman Kodak Company
T.M. Reg. U.S. Pat. Off.

REAR VIEW

REAR VIEW

NUT, OLD MODEL— 96883

SCALE ASSEMBLY, OLD MODEL— 96797

SPRING— 78971

DISCONTINUED— REPLACE WITH:

PLATE ASSEMBLY, NEW MODEL— 107153
RING ASSEMBLY, NEW MODEL— 102249

DIAPHRAGM CONTROL RING AND POINTER
ASSEMBLY, OLD MODEL— 80917

Figure 2

REFER TO FIGURE 3A

SPRING— 78971 SPEED AND DIAPHRAGM INDEX PLATE— 96227

SCREW (21— 102998

WINDING LEVER— 96218

SPEED CONTROL RING— 78954

Figure 3

PALLET— 94310
(FOR AVERAGE TIME LAG SHUTTERS)

WINDING LEVER STOP SCREW — 104954

,SPEED CONTROL RING STOP SCREW — 75431

SPACING WASHER (AR)— 43004

TRIGGER LATCH SCREW— 80500

TRIGGER LATCH SPRING— 94798

SCREW— 102957

TRIGGER LATCH— 96219

FLASH RETARD PALLET ASSEMBLY— 100258

(FOR LESS THAN AVERAGE TIME LAG SHUTTERS)

Figure 4

3

MAIN DRIVE SCREW (0-80 THREAD)— 102997

SPRING— 60828

SAFETY LATCH SPRING— 56914

COVER SCREW, SHORT— 102978

.COVER SCREW, LONG (2)— 102979

AND GEAR ASSEMBLY— 95380

NO. 4 ESCAPEMENT WHEEL
AND PINION ASSEMBLY— 95381

NO. 2 RETARD PINION
AND GEAR ASSEMBLY— 95379

REFER TO FIGURE 5A

SPRING— 103643

Figure 5

SPRING— 102647

Sr I y W \

a- h / •’

GEAR PLATE ASSEMBLY— 107460

RETARD PALLET— 67763

PALlET BRACKET ASSEMBLY— 121106

SCREW (21— 83470

Figure 6

BUSHING— 104287

SPRING— 62720

MAIN DRIVE
LATCH ASSEMBLY

MAIN DRIVE SPRING— 79878

-99532

SCREW— 102948

SPRING— 56911

SCREW— 96226

SCREW — 102954

FIGURE 12A

Figure

7

BULB LEVER ASSEMBLY— 78979

SPACER— 78967

.e rr '

SPRING— 78970

SPACER— 7 89 67 "

SCREW— 106258

CONTACT SPRING— 106256

TRIGGER SCREW — 102955

TRIGGER SPRING— 96881

'WASHER— 56847

ASSEMBLY— 80918

Figure 8

INSULATING BLOCK— 106257

BUSHING— 96225

NUT— 100283

NEW MODEL PARTS

SCREW— 102957

SPRING— 94306

SPRING— 102823

CONTACT LEVER ASSEMBLY-

106411

Figure 9

W ---------*

OLD MODEL PARTS

*DISCONTINUED— REPLACE WITH KIT

NO. 121352— REFER TO FIGURE 13

STAR WHEEL ASSEMBLY— 104217

STAR WHEEL SC REW — 101984

STAR WHEEL ASSEMBLY, OLD MODEL, DISCONTINUED,

REPLACE WITH KIT NO. 121352— REFER TO FIGURE 13

DELAYED ACTION PINION WITH GEAR
ASSEMBLY, NEW MODEL— 102767

DELAYED ACTION PINION WITH GEAR
AND POST ASSEMBLY, OLD MODEL— 94400

CLUTCH SCREW, OLD MODEL— 101984

CLUTCH ASSEMBLY— 56924

DISC— 96229

REAR LENS ASSEMBLY— RETURN SHUTTER
TO ROCHESTER FOR REPLACEMENT

Figure 9A

Figure 10

SCREW— 104286

SPACER— 78976

NUT— 78977

Figure 11

CASE ASSEMBLY— 96788 BLADE CONTROLLER AND STUD ASSEMBLY, OLD MODEL—
(FOR COMPONENT PARTS REFER TO FIGURE 12B) DISCONTINUED REPLACE WITH PART No. 94298

DIAPHRAGM CONTROL RING— 78953

SCREW (5)— 55321

SPRING— 60832

DIAPHRAGM RETAINER PLATE
AND W IN G S ASSEMBLED— 73432

BLADE— 75907

BLADE ASSEMBLY— 861

BLADE CONTROLLER AND STUD ASSEMBLY

NEW MODEL— 94298

MECHANISM PLATE ASSEMBLY
(REFER TO FIGURE 12A)

SETTING LEVER ASSEMBLY— 80924 W ING (5)— 60816

RETARD SECTOR AND STUD ASSEMBLY, OLD MODEL— 95377

MECHANISM PLATE ASSEMBLY, OLD MODEL, DISCONTINUED, REPLACE WITH:

MECHANISM PLATE ASSEMBLY, NEW MODEL— 122993
DELAYED ACTION PINION AND GEAR ASSEMBLY, NEW MODEL— 102767
RETARD SECTOR ASSEMBLY, NEW MODEL— 121107
KIT N O — 121352

BLADE AND STUD ASSEMBLY (4)— 73426 Figure 12

RETARD SECTOR AND STUD ASSEMBLY, NEW MODEL— 121107

MECHANISM PLATE ASSEMBLY, NEW MODEL— 122993

Figure 12A

CASE ASSEMBLY— 96788

Figure 12B

7

Kit No. 121352

This kit contains the necessary parts for replacing the old-model contacts or the old-model
star wheel. This kit is also necessary when replacing the old-model mechanism plate.

STAR WHEEL ASSEMBLY— 104217

CONNECTOR WIRE— 98594

Figure 13

TOOL (JEWELERS SCREWDRIVER BLADE FOR ADJUSTING
THE FLASH RETARD PALLET STUD)— RF657

TOOL (FOR REMOVING THE FRONT LENS)— RF501-0

TOOL (BLOCK FOR HOLDING SHUTTER FIRMLY WHILE
THE FRONT LENS IS BEING REMOVED)-RF501-W

TOOL (JEWELERS SCREWDRIVER BLADE FOR CONNECTOR
SCREW NUT AND THE MAIN DRIVE SCREW)— RF611

Figure 14

FIG. PART NUMBER

PART NAME

N o.

REQ D .

1 HE28035
1
1-
1

HE25094 Cap - Front lens, new model 1
HE25466 Insert - Adapter ring, old model

HE31394 Insert - Adapter ring, new model

Cap - Front lens, old model

1 Front Lens Assembly - Return shutter to Rochester for replacement

1
2 96801
2
2 96797

87025 Screw - Diaphragm index plate

Diaphragm Index Plate and Synchronizer Scale Assembly, Old Model 1

107153

Diaphragm Index Plate and Synchronizer Scale Assembly, New Model

Synchronizer Scale Assembly, Old Model
2 106316 Synchronizer Scale Assembly, New Model
2 96883
2 101808
2 101810
2

101809 Stud - Synchronizer scale operating knob, new model
2 102249
2

3

3

2,3

3
3A

86602 Spring - Diaphragm control ring

102998 Screw - Speed and diaphragm index plate

96227
78971
78954 Ring - Speed control

78974 Ring - Shutter retaining, old model
3A 109817
3

96218 Lever - Winding

4 94310
4 100258
4 43004
4 104954
4 75431

4,5

4

102957

94798
4 96219

4 80500

5

5

5

102978
102979 Screw - Cover, long

56914 Spring - Safety latch
5 93073
5 102997
5

5A

5A
5A

60828

100014
122619

87024
5A 66163
5A
5A

66173

99801
5A 35625
5A 99803
6

83470
6 107460
6
6
6
6
6
6

6

7

12A

103643

67763

121106
102647

95379

95381

95380

102954

95377

12A 121107

7
7
7
7

56911

62720

104287

99532

Nut - Synchronizer scale stud, old model
Knob - Synchronizer scale operating, new model
Spring - Synchronizer scale operating knob, new model

Diaphragm Control Ring and Pointer Assembly, New Model

Plate - Speed and diaphragm index
Spring - Speed control ring tension

Ring - Shutter retaining, new model
Pallet - Flash retard (For average time lag shutters)

Flash Retard Pallet Assembly (For less than average time lag shutters)
Washer - Speed index anchor stud spacing
Screw - Winding lever stop
Screw - Speed control ring stop
Screw - Trigger latch spring-(l), Safety latchspring-(l), Contact lever-(l)
Spring - Trigger latch
Latch - Trigger
Screw - Trigger latch
Screw - Cover, short

Cam - High speed spring
Screw - Main drive (0-80 Thread)
Spring - Main drive
Cover Assembly, Old Model
Cover Assembly, New Model
Stud - Speed index plate anchor
Stud - Delayed action safety latch
Latch - Delayed action safety
Stud - Pallet
Rivet - Delayed action pinion bracket
Bracket - Delayed action pinion
Screw - Retard gear plate
Retard Gear Plate and No. 1 Pinion Assembly
Spring - No. 1 Sector
Pallet - Retard
Pallet Bracket and Stud Assembly
Spring - Pallet bracket
No. 2 Retard Pinion and Gear Assembly
No. 4 Escapement Wheel and Pinion Assembly
No. 3 Retard Pinion and Gear Assembly
Screw - Retard sector
Retard Sector and Stud Assembly, Old Model
Retard Sector and Stud Assembly, New Model
Spring - Retard sector
Spring - Blade controller latch
Bushing - Blade controller latch spring
Main Drive Latch and Bushing Assembly

1
1

1
1
3

1
1
1
1
1
1
1

1
2
2
1
1
1
1
1
1
1
1

AR

1
1
3
1
1
1
1
2
1
1
1
1
1
1
2
1
1
1
2
1
2
1
1
1
1
1
1
1
1
1

1
1
1
1

FIG.

PART NUMBER

PART NAME

N o.

REQ D .

9

FIG. PART NUMBER

PART NAME

N o.

REQ D .

7 79878

8 102955
8 96881

8

8 80918

8

8

, 8

9,9A
9,9A
9,13
9,13

56847

78967
78979
78970

102957

94306
102823
106411

Spring - Main drive

Screw - Trigger
Spring - Trigger
Washer - Trigger
Trigger Assembly
Spacer - Bulb lever
Bulb Lever Assembly
Spring - Bulb lever
Screw - Contact lever
Spring - Contact lever
Spring - Contact lever latch, new model
Contact Lever Assembly, New Model

9,9A,13 96226 Screw - Connector

9,13

9,13 106258

9,13 106256
9,13 106257

102948

Screw - Contact strip, new model
Screw - Contact insulating block, new model
Spring - Contact, New Model
Block - Contact insulating, new model

9$A,13 96225 Bushing - Case insulating
9,9A, 13 100283 Nut - Connector screw

10
10 102767
10 94309
10 101984
10

94400

56924

No. 1 Delayed Action Pinion with Gear and Post Assembly, Old Model
No. 1 Delayed Action Pinion and Gear Assembly, New Model
Spring - No. 1 Delayed Action Pinion and Gear Assembly
Screw - Clutch Assembly, Old Model-(l), Star Wheel Assembly-(l)
Clutch Assembly

10,13 104217 Star Wheel Assembly

11

Rear Lens Assembly - Return shutter to Rochester for replacement

11 78977 Nut - Shutter operating disc bearing

11 96229

11

78976 Spacer - Shutter operating disc bearing

Disc - Shutter operating

11 102956 Screw - Mechanism plate to case, short
11

104286

Screw - Mechanism plate to case, long

12A Mechanism Plate Assembly, Old Model (Discontinued, replace with New

Model Mechanism Plate Assembly 122993, New Model Delayed Action

Pinion and Gear Assembly, 102767 and Kit No. 121352)
12A 122993 Mechanism Plate Assembly, New Model
12 94298

Blade Controller and Stud Assembly, New Model
12 86130 Blade with Double Blade Bushing and Stud Assembly
12

75907 Blade
12 73426 Blade and Stud Assembly
12
12 60816
12
12 78953
12
12
12
12B
12B 60831
13
13

13 121352

73432 Diaphragm Retainer Plate and Wings Assembly

Wing - Diaphragm

55321

Screw - Diaphragm retainer plate to mechanism plate

Ring - Diaphragm control j
60832 Spring - Setting lever
80924

Setting Lever Assembly
96788 Case Assembly
83434

Nut - Cable release 1

Stud - Setting lever spring
56891
98594

Bushing - Connector wire

Wire - Connector

Kit - (For replacing Old Model Star Wheel, Old Model Mechanism Plate

Assembly, and the Old Model Flash Contact Parts) 1

14 RF501-O

14

RF501-W

Tool (For removing the Front Lens) 1

Tool (Block for holding shutter firmly while the Front Lens is being

removed)

14 RF611

Tool (Jeweler’s Screwdriver blade for Connector Screw Nut and Main

Drive Screw)

14 RF657

Tool (Jeweler’s screwdriver blade for adjusting the Flash Retard Pallet

Stud)

1
1

1
1
1

2

1
1
1
1
1
1
1
1

1
1
1
1
1
1
1

1
2
1
1
1
1
1
1
2
1

1
1
1
1
1

4
1
5
5
1
1
1
1

.1

1
1

1
1

1

1 0

FIG.

PART NUMBER

PART NAME

N o.

REQ D .

PART NUMBER

PARTS

LIST

PAGE

NUMBERS

FIGURE

No.

Numerical List

PART NUMBER

PARTS

LIST

PAGE

NUMBERS

FIGURE

No.

PART NUMBER

PARTS

LIST

PAGE

NUMBERS

FIGURE

No.

RF501-O

RF501-W

10

10 14 80917 9 2
RF611 10
RF657 10

HE25094
HE25466

9

9
HE28035 9
HE31394

9

35625 9 5A
43004

55321

9 4 87025

10 12 93073
56847 10
56891

10 13

56911 9 7

14 80500 9 4

14 80918 10 8
14 80924 10 12

1

83&34 8 10 12B 101984 10 10

1 83470 9 6
1 86130 10 12
1

86602 9 2
87024 9 5A

8 94298 10

94306 10 9,9A
94309

56914 9 5 94310 9

56924

10

60816 10 12

60828 9 5

10 94400 10

94798 9 4

95377
60831 10 12B 95379
60832 10 12 95380
62720 9 7
66163
66173
67763

73426 10

73432

9
9 5A 96219 9

9

12

10

12

5A
6

95381

96218 9 3

96225 10

96226

96227
75431 9 4 96229 10
75907
78953

10

10 12 96797
78954 9 3
78967

10

78970 10

12 96788 10

96801

8 96881 10

8

96883
78971 9 2,3 98594
78974 9 3A
78976

10

11
78977 10 11
78979

10 8 100014 9

99532
99801
99803

78978 10 7 100258

100283
101808 9
101809 9
101810 9

102249 9
102647 9
102767 10

102823 10
9
9 5

1 102948

102954 9

12

102955

102956 10

10

10

102957 9,10 4,5,

4 9,9A

10 102978

102979 9 5
9
9
9 6
9 6

12A 102997 9 5

6

102998 9

103643

104217 10 10,13

104286 10 11

4 104287

9,9A,13

10 9,9A,13

9 3

11
12

9 2

104954

106256

106257

106258 10
106316 9 2
106411

9 2 107153

107460
121106 9 6

121107
121352 10 13
122619
122993

9

10

9 7
9 5A

9

8

2 109817

13

5A
5A

9 4

10

9,9A,13

2
2

2

2
6

10

9,13

10

9,13

7

10

8

11

9

5

3

9

6

9 7

9 4

10 9,13

10

9,13
9,13

10

9,13
9 2
9

6

9 3A
9 12A
9

5A

10 12A

3-51-G L-B

EASTMAN KODAK COMPANY

ROCHESTER 4, N. Y.

Lithographed in the United States of America

EASTMAN KODAK COMPANY

ROCHESTER 4, N.Y.
