KODAK EASYSHARE

W820/W1020 wireless

digital frames

Extended user guide

www.kodak.com

For help with your digital frame, www.kodak.com/go/digitalframesupport

Eastman Kodak Company Rochester, New York 14650 © Eastman Kodak Company, 2008

All screen images are simulated.

Kodak and EasyShare are trademarks of Eastman Kodak Company.

Eastman Kodak Company is an authorized licensee of the CompactFlash trademark.

P/N 4F8181_en

Front View

Back/Right View

1 LCD screen

2 Touch border (tap/slide)

3 Touch border (tap only)

4 Lights

5 Raised guide

NOTE: When screen icons appear, Lights turn on at touch-sensitive

points near the raised guide.

To use the touch border, see page 3.

1 Audio In

2 Audio Out

3 DC-In (12V)

4 Speakers (2)

Product features

www.kodak.com/go/support

Back/Side View

1 Power button 5 Volume button

2 Wall mounting holes 6 Memory card slot - CF, MD

3 Rotating/extending stand (see page 1) 7 USB connector (to camera/USB device)

4 Memory card slot - SD, MMC, MS, xD 8 USB connector (to computer)

ii www.kodak.com/go/support

Table of contents 1

1 Getting started ......................................................................................1

Setting up your frame.................................................................................... 1

Turning on/off your frame.............................................................................. 2

Using your frame’s Quick touch borders......................................................... 3

Setting your language ................................................................................... 4

Connecting to your wireless network .............................................................4

2 Setting up for wireless operation ..........................................................5

Connecting to your wireless network .............................................................5

Installing the software: PCs only .................................................................... 9

Verifying computer/device connections ........................................................10

Setting up access to the Gallery and Web media .......................................... 11

3 Viewing on your frame ........................................................................19

Enjoying your pictures immediately! ............................................................ 19

Inserting a memory card .............................................................................. 19

Connecting a digital camera or other USB device ......................................... 20

Viewing the Home screen............................................................................ 21

Accessing your pictures and videos.............................................................. 22

Viewing pictures and videos ........................................................................ 23

Playing a slide show.................................................................................... 24

Viewing thumbnails (multi-up)..................................................................... 25

Viewing a single picture .............................................................................. 25

Viewing pictures by filename ....................................................................... 26

4 Doing more with your frame ...............................................................27

Playing music ..............................................................................................27

Playing a video............................................................................................28

Printing pictures.......................................................................................... 29

Copying on your frame ................................................................................ 31

Deleting pictures ......................................................................................... 32

Selecting multiple pictures........................................................................... 33

www.kodak.com/go/support iii

5 Using wireless mode ...........................................................................34

What are the wireless features of my frame? ............................................... 34

Setting up your frame for wireless operation ................................................34

Wireless networking and the Internet .......................................................... 34

Viewing pictures/videos wirelessly ...............................................................35

Viewing Gallery/Web media content ............................................................ 36

Automatically receiving My Friends Albums.................................................. 38

Sharing pictures wirelessly...........................................................................40

Copying wirelessly to/from your computer.................................................... 42

6 Changing settings and more ...............................................................46

Changing frame settings ............................................................................. 46

Settings menus ........................................................................................... 46

Setting the clock and timer .......................................................................... 49

Upgrading your firmware............................................................................. 50

Adding a matte and faceplate .....................................................................52

Mounting your frame on the wall ................................................................52

Changing your frame orientation ................................................................. 53

Maintaining your frame and mattes ............................................................. 54

Learning more about your frame.................................................................. 54

7 Troubleshooting and support ..............................................................55

Frequently asked questions .........................................................................55

Picture frame problems ............................................................................... 56

Picture frame/computer communications ..................................................... 58

Screen messages ......................................................................................... 59

8 Appendix .............................................................................................61

Digital frame specifications..........................................................................61

Important safety instructions .......................................................................63

Upgrading your software and firmware........................................................ 64

Additional care and maintenance ................................................................ 64

Limited warranty .........................................................................................64

FCC compliance and advisory ......................................................................66

iv www.kodak.com/go/support

1 Getting started

Welcome to your KODAK EASYSHARE W820/W1020 wireless digital frame. Viewing your pictures couldn’t be simpler!

Setting up your frame

Setting up the stand

Your frame displays pictures in landscape orientation. To change to portrait orientation, see page 53.

Stand (pull to adjust the frame angle for best viewing)

When displayed with the stand extended, the frame rests at a 68-90

° angle.

www.kodak.com/go/support 1

Getting started

Attaching the power cable

CAUTION: Do not use this power cable with other devices, including digital

cameras.

Turning on/off your frame

Your power cable may look different from the one pictured. Use the plug that accommodates your type of power outlet.

Power button - press and hold (for about 2 seconds), then release

With the power cable still plugged in, your frame retains information (like the time) if you turn it off.

2 www.kodak.com/go/support

Using your frame’s Quick touch borders

IMPORTANT:

The screen is not touch-sensitive. Do not touch. Lights appear on the border to show you where to touch.

CAUTION: Only use your finger to touch the borders. Using sharp or metal

objects may damage the border or screen.

Getting started

Tou ch t ip s

Tap and slide on the Quick

Touch Borders* only.

Tap a border to display the icons.

Tap C lo se to dismiss them.

Tap the light

Tap lights next to

buttons

(No sliding here)

Home Play slide show

OK Done

Close closest to a button to select it.

Slide to highlight menus, pictures, videos, options.** Tap O K to se le ct them.

Don’t hover,

borders can be

Tap lights below buttons

Slide on bottom border only

*Quick Touch

Borders

sensitive.

Slide to scroll:

Scroll through images—Like turning the pages of a book, slide left ← to go forward, slide right → to go back. For faster scrolling through larger numbers of pictures, touch and hold (3 seconds), then slide to the end of the border.

Scroll through menus—Slide right → to scroll down, slide left ← to scroll up.

* Tap below small arrows at the ends of the scroll bar to move the highlight one picture, menu, or item at a time.

www.kodak.com/go/support

Getting started

Setting your language

The language screen appears the first time you turn on your frame.

■ Slide (or tap below slider arrows) on the lights at

the bottom border to highlight your language, then

Save

tap Save. NOTE: Slide left/right on the lights to move up or down the list.

To change the language at a later time:

Slider arrows

■ Tap (Home) → (Settings) → Language.

The language screen appears.

Slide to highlight your language, then tap Save.

To use the Quick Touch Borders, see page 3.

Connecting to your wireless network

After you set your language, your frame scans for available wireless networks. See

Connecting to your wireless network, page 5.

4 www.kodak.com/go/support

2 Setting up for wireless

operation

If you have problems with your wireless setup or connection, see

Troubleshooting starting on page 55. Or open EASYSHARE Digital Display Software on your computer (see page 9) and click Tools automated troubleshooting wizard.

Connecting to your wireless network

To allow your frame to access the contents of your computer wirelessly, connect your frame to your wireless home network.

NOTE: If you are not sure you have a wireless network, ask the person who set up your computer.

1 First time—If this is the first time you turned on your frame, tap the light next to

Save after you set your language, (see page 4).

The Scanning for available wireless networks screen appears.

→ Wireless Troubleshooter. Follow the

www.kodak.com/go/support 5

Setting up for wireless operation

Available wireless networks are listed.

NOTE: If the scan finds multiple networks, your home network (with the highest% signal strength) is usually listed first and highlighted. Or, to select another network, slide or tap below the arrows to highlight a network, then tap OK.

Slider

Slider arrows

You can slide to highlight Exit without connecting then select OK (or tap Back) to dismiss the screen and go to the Home screen, (see page 21).

If you want to connect later and start enjoying your pictures now, insert a memory card or connect a camera or other USB device with pictures (see page 19).

Later—To connect later, tap Home

→ Settings . Slide to highlight

Network then tap Select. Highlight Scan for wireless networks then tap OK. Then follow the screen prompts and continue with step 2 below.

If your wireless network is not found, slide to highlight My network not shown, then select OK. Check that your router is on and your frame is close to the router, then select Scan again. If your wireless network is still not found, your network does not broadcast SSIDs. You then need to enter the network SSID (sometimes called the network name) manually:

■ Select Enter SSID, then select OK.

The on-screen keyboard appears.

■ Enter the SSID in the text box (see page 7). Tap Done when finished.

The person who set up your network can help you with this information. Or, tap Back then tap Help me connect for more information.

6 www.kodak.com/go/support

Setting up for wireless operation

2 With your home network highlighted, tap OK to connect to your home network.

The Connecting (or the wireless network security screen, if enabled) appears.

Or, tap Exit to go to the Home screen without connecting. (See page 21.)

Enter security key (if you have wireless network security enabled)

You are prompted to enter your security key (WEP or WPA) using the on-screen keyboard. Slide along the bottom of the touch border (or tap below the slider

arrows) to highlight a character then tap (Select) to enter it in the text box. Tap Done when finished.

Backspace - erases text

Done

Touch tips

Right border - tap only

On the bottom border, keep sliding (or tapping slider arrows) left/right to go to the

Text box

Slider

Slider arrows

Select

previous or next row.

If you do not have security enabled, go to step 3. (We recommend that you enable your network security to prevent others from accessing your wireless home network.)

NOTE: The screen identifies your security as either

WEP

security key can be either:

WEP

WPA

5 or 13 characters (0-9, A-Z, some special characters, case sensitive)

www.kodak.com/go/support

Setting up for wireless operation

10 or 26 characters (0-9, A-F, not case sensitive). A

WPA

key is 8-63 characters, case sensitive. The person who set up your network can provide you with this information. You have successfully connected your frame to your network!

IMPORTANT:

Do not select Scan now yet. (See page 10.)

3 If you haven’t done so already, install the KODAK EASYSHARE Digital Display

Software on your PC (see page 9) so you can set up and customize your frame right from your computer wirelessly. For MAC OS users, see page 13.

8 www.kodak.com/go/support

Setting up for wireless operation

Installing the software: PCs only

IMPORTANT:

The CD that was packaged with your frame contains two applications that work well independently, but also work together for the best experience with your frame:

■ KODAK EASYSHARE Digital Display Software —manage your frame right

from your computer, copy between your frame and computer (page 42), and set up your frame for access to KODAK Gallery and Web content (page 11).

■ KODAK EASYSHARE Software —organize, edit, and share your pictures.

IMPORTANT:

CD packaged with your frame.

For MAC OS users, do not install the software on your computer. See

page 13 to open your frame’s Configuration Web page in your browser.

We recommend that you install both. If you already have EASYSHARE Software on your computer, upgrade to this special version for additional features.

1 Insert the CD into your computer.

2 Follow the on-screen instructions to install the

software.

■ Click Typical to install EASYSHARE Digital

Display Software and to update a previous version of EASYSHARE Software.

■ If you do not have a previous version of

EASYSHARE Software on your computer, you can click Custom and choose both applications for a new installation.

The software icons appear on your desktop when the installation is complete.

3 Double-click to open EASYSHARE Digital

Display Software if it doesn’t open automatically.

When prompted, take a few minutes to electronically register your frame and software for exclusive tips and offers. To register later, visit www.kodak.com/go/register.

www.kodak.com/go/support

Setting up for wireless operation

Verifying computer/device connections

After installing the software (page 9) and setting up access to Web content (page 11), return to your frame (see page 7) then:

1 Tap Sc an now.

The Scanning screen appears as the frame scans your network and then lists available computers and other picture sources that your frame can access wirelessly.

NOTE: Select Scan later to connect and use your frame later to view content on your computer, wirelessly.

To verify later, tap → Settings → Network → Verify

computer connection.

If your computer is listed, your wireless setup is successful. Tap Done.

If your computer is not listed, tap Scan again or tap Help for options.

2 Tap Done to close the window and return to the Home screen.

Your frame can now access the content on your host computer, wirelessly. Your computer appears as a picture source icon on your frame (see page 21).

NOTE: If you have more than one frame on your wireless network, give them unique names using the

→

on-screen keyboard so you can tell them apart. Go to Home menu see page 48.

10 www.kodak.com/go/support

Settings → Device configuration

(Home)

Setting up for wireless operation

Setting up access to the Gallery and Web media

IMPORTANT:

On your computer, use KODAK EASYSHARE Digital Display Software (page 9) to set up access to the KODAK Gallery and RSS (Really Simple Syndication) feeds such as publicly posted images, news, weather, sports, finance, etc. Or, use the Settings option to customize your frame right from your computer.

WINDOWS OS users

1 Make sure the frame and computer are connected to your wireless network

(page 5) and your computer is connected to the Internet.

2 Click on your desktop to open EASYSHARE Digital Display Software.

3 Right-click on the frame graphic in the Drag and Drop Zone then select Device

Settings.

For Mac users, do not load the EASYSHARE Digital Display Software on your computer. See page 13 to open your frame’s Configuration Web page in your browser.

4 From the drop-down menu, select your frame.

www.kodak.com/go/support

Setting up for wireless operation

Your frame’s Device Settings Configuration Web page opens in your browser.

5 Click the following for on-screen setup instructions:

■ KODAK Gallery—connect to your existing Gallery account or to a new one

■ Web Media—add RSS (photo) feeds, Flickr, and news, weather, and sports

from FrameChannel

■ Settings—customize your frame with general settings right from your

computer. (For more options, see page 46.)

Overview

KODAK Gallery

Web Media

Settings

Save

6 Click Save (at the bottom of the screen). NOTE: The KODAK Gallery icon appears on the Homescreen when you click Save and your RSS feeds

appear in alphabetical order on the Web media page in this software application and on your frame (see page 21). See page 36 to view Gallery and Web media content on your frame.

12 www.kodak.com/go/support

Setting up for wireless operation

MAC OS users

Instead of installing the software on your MACINTOSH computer, open the Configuration window right from your browser and start setting up access to Web content and customizing your frame from your computer (see page 11).

1 Make sure the frame is connected to your wireless network (page 5) and your

computer is connected to the Internet.

2 On the frame, tap Home

3 Retrieve the IP address (format: XXX.XXX.X.XXX) from the frame’s Network

Settings screen.

4 Open a browser (for example, INTERNET EXPLORER, MOZILLA FIREFOX, SAFARI,

etc.) on your computer.

5 Enter the IP address in the browser’s address window, then press Enter.

Enter the IP address here

The KODAK Displays and Devices Configuration window opens in your browser.

6 Go to step 5 on page 12 to start configuring your frame.

→ Settings → Network, then tap Select.

www.kodak.com/go/support

Setting up for wireless operation

How to connect to your Gallery account

Perform this one-time setup on your frame to connect it to your existing Kodak Gallery account.

1 Follow the steps on page 11 to access the Kodak Gallery configuration page.

2 If you don’t have a Gallery account, click Set one up now. Follow the on-screen

instructions, or visit www.kodakgallery.com.

3 Select your country/region from the drop-down menu.

2 3

4 5

4 Enter the email address that is associated with your Gallery account, then enter

your Gallery password.

5 Select a Picture Mail automatic notification setting.

6 Click Save (at the bottom of the page).

Congratulations, you have completed your Gallery setup! KODAK Gallery appears as a choice on the Home screen or under Web media . See page 36.

14 www.kodak.com/go/support

Setting up for wireless operation

How to add or edit a Web feed

Set up a sample RSS (Really Simple Syndication) feed for viewing right on your frame, or add a new feed. You can edit sample feeds which may include:

■ Flickr: Interestingness - public postings of frequently changing photos from Flickr.

Add tags from your computer using the digital display software. See the software Help for more information.

■ FrameChannel: News

■ FrameChannel: Weather

■ FrameChannel: Sports

■ FrameChannel: Finance

■ FrameChannel: All

■ Flickr: Get more

Follow the steps starting on page 11 to access the Web media configuration page in the software application.

NOTE: Sample and new feeds that are on the Web media configuration page are added also on your

frame’s Home screen and Web media list. (See page 36.)

To add a new feed:

1 Click Add.

The Add/Edit page appears.

2 Select FrameChannel or Flickr site from the drop-down menu.

Or, to add a feed from any site:

■ Select Other.

■ In a new window on your computer, navigate to the RSS photo feed on the

Internet.

■ Copy the complete RSS photo feed URL from the site then paste it into the

www.kodak.com/go/support

Setting up for wireless operation

URL box on the Add/Edit page.

3 Enter a name for photo feeds from FrameChannel and Flickr sites.

For feeds from other sites, a system-generated name you can change is assigned automatically.

4 Click Save at the bottom of the page.

2 3

16 www.kodak.com/go/support

Setting up for wireless operation

5 To view additional photos by keywords (tags), select a photo-sharing site (Flickr or

FrameChannel) from the drop-down menu.

6 Enter a tag (Flickr) or choose a category (FrameChannel) for the types of photos

you want to see.

NOTE: The photo-sharing site automatically sends pictures matching the keyword directly to your frame.

If you don’t have a FrameChannel account, click the link to create one. Follow the on-screen instructions.

www.kodak.com/go/support

Setting up for wireless operation

7 Assign a photo feed name.

8 Click Save at the bottom of the page.

Congratulations, you have completed your photo feed setup! The newly added feed also appears on the Web media page in the software application and on your

frame’s Home screen and Web media list. (See page 36.)

IMPORTANT:

Feeds that don’t have photos and are text only won’t play on your frame. Preview, edit, or delete feeds right on the Web media configuration page in the software application.

To preview a feed, click next to the feed name.

To ed it a f ee d, click next to the feed name. Choose a new category

(FrameChannel) or a enter a new tag (Flickr), see 6. Assign a new name, if necessary.

To delete a feed, click next to the feed name. A confirmation message appears for the deletion. Click Delete.

Preview

Edit

Delete

18 www.kodak.com/go/support

3 Viewing on your frame

Enjoying your pictures immediately!

■ To view your pictures or play a slide show,

insert a memory card, or connect a camera or other USB device (see page 20).Your pictures play automatically.

If your frame has pre-loaded sample pictures, they start playing automatically.

To maximize your frame’s internal memory, delete the pre-loaded samples. Access them on My Frame (page 21), then see page 32 to delete them.

If you are at the Home screen, see page 21 to start your slide show. To change the order, see page 26.

Inserting a memory card

To insert a card, push the card firmly into the slot until it stops.

To remove a card from:

top card slot - push in the card to release it side card slot - pull out the card

Important: Do not insert a micro or mini memory card without an adapter.

www.kodak.com/go/support 19

Secure Digital

MultiMedia Card

Memory Stick

CompactFlash MicroDrive

Viewing on your frame

Connecting a digital camera or other USB device

USB cable included with your USB device

USB devices: camera, flash drive, card reader, computer, etc. (sold separately)

20 www.kodak.com/go/support

Viewing the Home screen

Start at the Home screen to:

■ access your pictures, videos, and music

■ view Gallery and Web content on your frame

■ customize your viewing through the Settings screens

1 Tap (Home). If the buttons are not visible, tap

the Quick Touch Borders.

2 Tap the border below one of the icons along the

bottom of the screen.

3 Tap (Close) to dismiss the icons.

Home screen icons:

Pictures and videos (see Accessing your pictures and videos, page 22)

Music (see Playing music, page 27)

Kodak

Gallery (see Setting up access to the Gallery and Web media, page 11)

Viewing on your frame

Web media (see Setting up access to the Gallery and Web media, page 11)

Settings—customize frame settings such as slide show durations and transitions, viewing options, screen brightness, clock, and timer. For details, see page 11 and the extended user guide at www.kodak.com/go/digitalframesupport.

www.kodak.com/go/support

Viewing on your frame

Accessing your pictures and videos

1 Tap (Home), then (Pictures and

Picture source icon

Picture sources:

My Frame—the frame’s 512 MB internal memory. Copy your pictures into My Frame from a memory card or other device.

Memory card—appears when you insert a card (page 19). The l ab el and i co n ind ic ate the type of card.

Camera—appears when you connect a digital camera via USB cable (page 20).

USB drive—appears when you insert a USB flash drive (page 20).

Home PC—appears if you are connected to a wireless network computer (see

page 5). Display pictures that are stored on the computer.

My Sli de show —ap pea rs when you save a f avo rite sl ide show so urce fo r qu ick acc ess anytime (see page 24).

Videos).

All connected sources are displayed.

2 Slide or tap below the arrows to highlight a picture

source, then:

■ Tap (Play slide show) to start a slide show

of the pictures in the highlighted source.

■ Or, tap OK to view thumbnails, folders, etc.

22 www.kodak.com/go/support

Viewing on your frame

Viewing pictures and videos

View pictures and videos from any connected picture source (see page 22).

IMPORTANT:

View a single picture and thumbnails

To view a single, full-screen picture, highlight it in thumbnails view, then tap OK.

To turn off the icons and other screen text, tap Close. NOTE: If the screen icons are unavailable, tap the touch border.

To view your pictures as thumbnails:

■ Tap (Ho me) → (Pictures and Videos). Slide to highlight a picture

source, then tap OK.

■ Or, from a slide show or single view, tap (Thumbnails).

Tips when viewing the thumbnail screen:

– To navigate through the thumbnails, slide your finger left/right along the slider at

the bottom, or tap below the slider arrows to move one picture at a time. To move even faster through the thumbnails, touch and hold until the screen changes (about 3 seconds).

For wireless access, make sure you set up your frame to work with your

(see

page 5

wireless home network

wirelessly, page 35.

). See also

Viewing pictures/videos

– To play a whole folder of images, highlight the folder then tap (Play slide

show).

– To play a video from thumbnails view, highlight a video thumbnail ( ). Tap OK

or (Play slide show).

www.kodak.com/go/support

Viewing on your frame

Playing a slide show

There are two ways to start a slide show on your frame:

■ Turn on the frame, then insert a card or connect a USB device—a new slide show

starts automatically, replacing a currently running slide show or single view picture.

■ Highlight a picture in thumbnails view (see page 25), or highlight a picture source

on the Pictures and Videos screen., then tap (Play slide show). See page 3 to scroll forward/backward quickly.

NOTE: Music and videos in the same picture source play automatically during a slide show.

To add music to a slide show, see page 27. Or tap Slide show options > Background music. To prevent music from playing automatically, tap Home > Settings > Viewing Options > Music auto-play > Off.

1 Turn off the frame and printer.

2 Make sure your frame is disconnected from the

printer.

3 Turn on the frame, then change your connection

mode on your frame from Computer to Printer. See

page 30.

4 Reconnect your frame to the printer, using the USB

cable.

Printing to a PictBridge enabled printer

1 Turn on the printer. Turn on the frame.

2 From a slide show (tap the touch-sensitive border to pause the slide show and

display the icons) or from single view:

■ Tap (Actions), then (Print).

Printing begins.

If you are in thumbnails (multi-up) view:

■ Slide to select a picture, or see page 33 to select multiple pictures.

■ Tap (Actions).

If you selected multiple pictures to print, the pictures and number of selected pictures appear on the screen.

■ Tap (Print), then Yes to start printing.

NOTE: Remember to change your connection mode back to Computer when you are done (see page 30).

www.kodak.com/go/support

Doing more with your frame

Manually changing USB connection mode

The connection mode must match the device you connect the frame to: Computer or Printer. The default is Connect to computer. You can change the connection mode manually.

1 Disconnect the printer or computer from the frame.

2 On the frame, tap (Home).

3 Tap (Settin gs).

4 Slide to highlight Device configuration, then tap OK.

5 Highlight USB connection mode, then tap OK.

6 Slide to highlight the mode you want to connect to, printer or computer, then tap

OK.

7 Reconnect the device (printer or computer) that matches the connection mode in

step 6.

30 www.kodak.com/go/support

Doing more with your frame

Copying on your frame

Copy pictures from your current viewing location to other connected devices (see

page 20).

CAUTION: Removing a card or disconnecting a device while copying may

damage your card, pictures, or device.

1 Highlight a picture to copy:

In thumbnails view, slide or tap below the slider arrows to find a picture; or, display a picture in single view (see page 25).

2 Tap (Actions).

3 Tap (Copy), then OK.

4 Tap the destination you want to copy to, then tap

OK.

The picture is copied.

5 Tap (Close) to close the menu.

To copy multiple pictures, see page 33.

NOTE: To copy wirelessly between your frame and computer, see page 42.

www.kodak.com/go/support

Doing more with your frame

Deleting pictures

CAUTION: Removing a card or disconnecting a device while deleting may damage your card, pictures, or device.

1 Highlight a picture to delete:

In thumbnails view, slide or tap below the slider arrows to find a picture; or, display a picture in single view.

To select multiple pictures, see page 33.

2 Tap (Actions).

3 Tap (Delete), then tap Yes to confirm.

The picture is deleted.

4 Tap (Close) to close the menu.

To delete multiple pictures, see page 33.

32 www.kodak.com/go/support

Doing more with your frame

Selecting multiple pictures

Use the multi-select feature to copy or delete two or more pictures or to play a slide show of selected pictures.

1 In thumbnails view (see page 25), slide or tap below the slider arrows to find a

picture, then tap (Select).

A check mark appears on the selected picture.

2 Continue selecting pictures.

To remove a check mark, tap (Unselect) while the picture is highlighted.

Select/Unselect all

Select all

■ In thumbnails view (page 25), tap (Select

All).

Unselect all

■ To remove all check marks, tap Unselect All.

www.kodak.com/go/support

5 Using wireless mode

For more information on wireless setup, operation, and networks, see Setting up for

wireless operation, page 5 or visit www.kodak.com/go/wifisupport or www.wi-fi.org.

What are the wireless features of my frame?

Connect to your home wireless network and:

■ Display pictures on your frame directly from your computer hard drive (see

page 35).

■ Display Web content you set up (see page 36).

■ Display pictures from your

■ Automatically receive pictures from your friends and family at the Gallery (see

page 38).

■ Copy pictures wirelessly from your frame to your computer (see page 42).

■ Automatically upgrade your firmware from the Internet (see page 50).

Setting up your frame for wireless operation

See Installing the software: PCs only, page 9 and Connecting to your wireless

network, page 5 for detailed instructions about your software application and setting

up your frame.

Do you have security enabled on your wireless network? If so, have your network name and security key (WEP or WPA) available, see page 7.

Kodak

Gallery account (see page 37).

Wireless networking and the Internet

Some wireless functions on your frame, including viewing pictures on (see page 37), require access to the Internet.

34 www.kodak.com/go/support

Kodak

Gallery

Using wireless mode

Viewing pictures/videos wirelessly

Wirelessly view pictures and videos from your computer right on your frame using the KODAK EASYSHARE Digital Display Software.

Before you proceed:

1 Make sure you install the software packaged with your frame (page 9). Connect to

your wireless home network (page 5), then verify your computer connection (page 10).

Your frame can now access the content on your host computer, wirelessly. Your computer appears as a picture source icon on your frame (see page 21).

NOTE: If you have more than one frame on your wireless network, give them unique names using the

on-screen keyboard so you can tell them apart. Go to Home menu., see page 48.

2 On your frame, tap (Home) → (Pictures and Videos).

3 Highlight Home PC , then tap OK.

It may take up to 10 seconds for your Network Computer to appear on the Home screen.

If your network computer is not listed on the Home screen, go to troubleshooting help on page 55.

→

Settings → Device configuration

NOTE: The first time you connect, a message may appear on your computer screen alerting you to a new

device. Follow the prompts to "allow" the frame on your computer (see page xxx).

4 Highlight the category of pictures you want to view, then tap OK.

All Pictures and Videos displays every picture and video that your computer is sharing, without showing folders. The categories are established by the EASYSHARE Digital Display Software (see page 42).

www.kodak.com/go/support

Using wireless mode

5 Pictures are displayed as thumbnails. See Chapter ,

Viewing pictures and videos for all the ways you

can enjoy your pictures, videos, and music on your frame.

Viewing Gallery/Web media content

■ Play slide shows of Kodak Gallery albums (see page 37).

■ Play slide shows of RSS (Really Simple Syndication) feeds you set up (see page 37).

■ Receive pictures from your friends and family at the Gallery (see page 38).

1 See page 11 to set up your frame for Web access.

2 Tap (Home) to display the Home screen.

3 Tap one of these Web sources:

KO DAK Gal lery—a ppe ars if you s et u p ac cess to KOD AK G allery (see page 11). Display your Gallery albums and My Friends’ Albums. This icon ( ) indicates someone has shared pictures with you at the Gallery! See page 38.

Web media—list of Flickr and FrameChannel RSS photo feeds you set up (see

page 11).

Feeds you set up as favorites for easy access (see page 11) appear on the list and as shortcuts on the Home screen.

Preloaded feeds (such as news, weather, sports, finance, etc.) that you can edit using the EASYSHARE Digital Display Software (see page 11).

36 www.kodak.com/go/support

Using wireless mode

Viewing Kodak Gallery pictures

View Gallery pictures and albums wirelessly right on your frame.

IMPORTANT:

NOTE: Connection to

First, set up access to Kodak Gallery, see page 11.

Kodak

Gallery is currently limited to customers in the United States, Canada, and

Europe.

To see all pictures from the Gallery:

Kodak

1 Tap (Home), highlight (

Gallery), then tap OK.

2 Highlight Play all, then tap OK to see the pictures as thumbnails. Or, tap (Play

slide show) to view them as a slide show.

See Chapter 3, Viewing on your frame for all the ways you can enjoy your Gallery pictures on your frame.

NOTE: Features not supported from the Gallery at this time: viewing videos, printing and deleting pictures.

Viewing Web feeds on your frame

Wirelessly view preloaded RSS feeds or ones you added (see page 15) of frequently changing Web content such as public photos, news, weather, sports, finance, etc.

1 From the Home screen:

■ Highlight a feed (such as news, weather, sports, etc.). Tap OK, then tap

(Play slide show) to play it.

OR,

■ Highlight (Web media), then tap OK to find more feeds. To start a slide

show, highlight a feed option from the list, then tap (Play slide show).

2 To pause a slide show, tap the touch border during the slide show.

To restart it, tap (Play slide show).

To hide the controls and view full screen, tap (Close).

www.kodak.com/go/support

Using wireless mode

Automatically receiving My Friends Albums

Your wireless frame uses when a friend shares pictures with you at the new pictures, right on your frame, even before you see the email on your computer!

Kodak’s

Picture Mail feature to notify you automatically

Kodak

Gallery. Play a slide show of the

To see the shared pictures right away:

■ When the notice appears on the frame screen,

tap below View now.

A slide show of the new pictures plays on your frame. If there are multiple albums you haven’t viewed yet,

select a marked album from the Gallery list and tap OK.

To see the shared pictures later: 1 When the notice appears on the frame screen,

slide to choose Dismiss.

2 To see the new pictures, tap (Home), highlight

(

Kodak

Gallery), then tap OK.

3 With My Friends’ Albums highlighted, tap OK.

4 To view a My Friends album as a slide show,

highlight the album, then tap (Play slide show). Or, tap OK to see the pictures as thumbnails.

To view all pictures in My Friends’ Albums as a slide show, highlight Play all, then tap (Play slide show).

38 www.kodak.com/go/support

Using wireless mode

Turning off auto-receive and notification

You can turn off auto-receive and/or notification from your friends’ albums at the Gallery from the Home screen (see below) or from the Configuration Web page (see

page 14).

1 Tap Home , then Settings . Then tap OK.

2 Tap KODAK Gallery then tap Select.

3 Highlight KODAK Picture Mail, then tap Select.

4 Choose from these options:

Auto-receive with notification ON—(default) you automatically receive your

friends’ albums and the notice appears on the frame.

Auto-receive ON—you automatically receive your friends’ albums, but the notice does not appear on the frame. You know when your friends send you pictures because the email icon still appears on the KODAK Gallery on the Home screen , and on unviewed My Friends’ Albums in your Gallery account .

Auto-receive OFF—you don’t automatically receive your friends’ albums on your frame. To view them, see Viewing Kodak Gallery pictures, page 37.

www.kodak.com/go/support

Using wireless mode

Sharing pictures wirelessly

Select pictures or an album on your frame then share them wirelessly via Email. First, add the person’s email address to your share list and assign an optional nickname.

IMPORTANT:

Adding a new email address

1 Choose a picture source then tap (Actions).

Make sure you install the software that came with your frame (see page 9) and connect your frame to your wireless home network (see page 5).

2 Tap (S hare)

→ Add name.

3 Use the keyboard to enter the email address, then tap Save.

Enter the email address

Slide along the bottom of the touch border (or tap the slider arrows) to highlight a character then tap (Select). The character appears in the text box. Tap Save

when finished.

Backspace - tap

Tex t b ox

Slider arrow

Slider

Slider arrow

(or hold to move quickly)

Save

Select

4 Assign a nickname (optional) to the new email address.

40 www.kodak.com/go/support

Using wireless mode

Sharing your pictures

1 Highlight a picture to share:

In thumbnails view (page 25), slide or tap below the slider arrows to find a picture; or, display a picture in single view (page 25).

2 Tap ( Act ions).

3 Tap (S hare).

A share list of email addresses and nicknames you created appear. The album name and number of pictures to share are also displayed.

4 Slide to highlight an email address. Or, highlight Add name to add a new email

address to your share list (see page 40). Tap (Share).

To send the pictures to more than one address, highlight each address then tap

(Select). Tap (Select all) to send to everyone on your list.

A progress bar of the number of shared pictures and the upload destination appears. If the destination is your Gallery account, the entire album is uploaded.

www.kodak.com/go/support

Using wireless mode

Copying wirelessly to/from your computer

The KODAK EASYSHARE Digital Display Software (included on the CD that was packaged with your frame) lets you drag and drop (copy) pictures, videos, and music wirelessly between your frame and computer or other connected devices (page 20).

Before you proceed:

1 Make sure you install the software packaged with your frame (page 9). Connect to

your wireless home network (page 5), then verify your computer connection (page 10).

Your frame can now access the content on your host computer, wirelessly.

NOTE: If you have more than one frame on your wireless network, give them unique names so you can tell

them apart. Go to Home

2 Set the USB connection mode on your frame to Computer (see page 30).

3 Double-click (KODAK EASYSHARE Digital Display Software icon) on your

desktop to open the software.

The frame, memory card, and connected devices (see page 20) appear in the Drag and Drop Zone.

→

Settings → Device configuration menu, see page 48.

42 www.kodak.com/go/support

Using wireless mode

Click here to create a slide show

Pictures/videos on your computer

My Devices:

- your wireless frame

- connected USB devices

Click Help for more info

Select pictures here (Viewer Pane)

Drag and drop here (Drag and Drop Zone)

4 Click My Devices to see the folders on your frame and connected devices

(page 20).

The frame appears as removable drives—one drive for each picture source on the frame’s picture source: internal memory (My Frame), and any inserted memory cards or connected devices.

5 Click Pictures and Videos or My Devices to find pictures, videos, etc. you want to

copy.

6 In the Viewer pane, select the pictures, videos, etc., then drag and drop them to

the new location in the Drag and Drop Zone (for example, the frame’s internal memory, a memory card, computer, or connected USB device).

7 Go to the copy location to view your copied pictures, videos, etc. or to play a slide

www.kodak.com/go/support

Using wireless mode

show on your frame. NOTE: The slide show order of play for available sources is: memory card, USB device, internal memory. NOTE: To maintain the slide show order during playback, see page 26 and select Filename, A - Z.

Copying pictures from EASYSHARE software

It’s easy to copy pictures/videos from My Collection to your frame.

1 Install the software that came with your frame (see page 9).

2 Set the USB connection mode to Computer (see page 30).

3 Double-click (KODAK EASYSHARE Software) on your desktop to open the

software.

4 Click My Collection, then select the pictures in the Viewer pane. Drag and drop

them into the Picture tray.

5 In the menu bar, select File

The frame appears as removable drives—one drive for each connected picture source in

the frame: internal memory, memory cards, USB devices.

→ Copy to.

My Collection

Select pictures here Drag and drop to here (Picture tray)

44 www.kodak.com/go/support

Using wireless mode

6 Browse to the frame location to which you are copying.

7 Select

Best For Digital Picture Frame

to resize the picture you are copying. Full

resolution is unnecessary and quickly fills up the frame’s memory.

8 Click Copy. Pictures are copied to your frame.

9 Go to the copy location to view your copied pictures on your frame and to play a

slide show.

www.kodak.com/go/support

6 Changing settings and more

Changing frame settings

The options in the Settings menu let you customize and configure your frame.

1 Tap (Home), then (Settings).

2 Slide or tap below the slider arrows to highlight a setting, then tap OK.

3 Follow the on-screen instructions. Tap OK to accept your selections.

4 Tap (Back) to exit.

Settings menus

Setting Options

Upgrade firmware

This option is only displayed if the upgrade file (.img) is available on the frame (memory card, flash drive, internal memory, etc.).

Upgrade firmware—load the latest version of firmware on your frame (page 50).

Exit—return to the Home screen.

46 www.kodak.com/go/support

Changing settings and more

Setting Options

Slide show options Slide duration—specify how long each picture is displayed

in a slide show, from 3 seconds to 1 hour. (The default is 5 seconds.)

Transitions—specify the transition style between pictures in a slide show. See screen for options. The default is Random.

Shuffle—plays the images in random order. Slide show starting point—when pictures are sorted from

oldest to newest (see page 26), specify where a slide show starts automatically (from picture dated 1 week back, or from oldest picture).

Brightness—slide to adjust the screen brightness according to your lighting conditions.

Frame orientation—display your frame in landscape (default) or portrait orientation.

Screen Fit or Fill— Fit entire image (default). Show the entire picture.

Black borders may appear around the image. Fill the screen .The picture fills the entire screen; some

of the picture may be cut off (cropped). Music auto-play—choose to play music automatically

during a slide show. (Music files must be in the same location as your pictures.)

Audio priority—when you are playing music (page 27), choose whether or not to play the audio portion of a video. Play music (default). Music continues to play, video plays but its audio is muted. Play video soundtrack. Music stops playing while the video, with audio, plays.

Clock and timer On/Off schedule—set your frame to turn on and off at a

specified time every day (page 49). Set time—manually set the clock to the current time

(page 49).

www.kodak.com/go/support

Changing settings and more

Setting Options

KODAK Gallery Specify your country, email address, and password.

First, install the software (page 9) and set up access to the Kodak Gallery (page 11).

Network Set up your frame for wireless operation. See page 5.

Device configuration Frame name—use the on-screen keyboard to assign a name

to your frame. This name is referenced when connecting to your wireless network.. If you have more than one frame on your wireless network, give them unique names so you can tell them apart.

RSS feeds—simple sites you set up to view on your frame using the digital display software. Edit RSS feeds from your computer using the software. See page 11.

Frame connections—choose how your frame works with other devices. Share frame content: choose to turn off or allow devices (such as computers or other wireless frames) to access your frame contents; Remote setup: specify whether or not to allow your frame to be set up from your computer; Remote copy: turn off or allow copying to your frame from your computer; Remote copy destination: specify a default destination on your frame (internal memory, SD card, etc.) to save your copied pictures.

USB connection mode—Before you connect a USB computer or printer, choose Connect to computer (default) or Connect to printer. See page 30.

Language Choose your language (page 4).

Automatic resizing Choose to turn on or off automatic resizing of your pictures

when copying. Full resolution is unnecessary for viewing and quickly fills up the frame’s memory. Choose full resolution for printing.

About Check your frame model, serial number, and firmware version.

48 www.kodak.com/go/support

Changing settings and more

Setting the clock and timer

Manually setting the clock

1 Tap (Home), then (Settings).

2 Highlight Clock and timer, then tap Select.

3 Highlight Set time, then tap Select.

4 Slide to set the hour. Tap the Next arrow to highlight the next setting (minutes),

then slide to adjust it.

5 Tap Save to accept your changes.

Getting the time from the Internet

1 Tap (Home), then (Settings).

2 Highlight Clock and timer, then tap Select.

3 Highlight Get time from Internet, then tap Select.

4 Highlight Turn on then tap Select.

5 Highlight a Time Zone then tap Save to accept your changes.

Setting automatic on/off

Set your frame to turn on and off at a specified time every day. NOTE: Set the clock before enabling auto on/off.

1 Tap (Home), then (Settings).

2 Highlight Clock and timer, then tap Select.

3 Highlight On/Off schedule, then tap Select.

The current time is displayed and the hour field is highlighted.

4 Set the Turn on time. Slide to adjust the hour. Tap the Next arrow to highlight the

next setting (minutes), then slide to adjust it. Repeat to set Turn off time. NOTE: Make sure the on time is earlier than the off time or the frame turns off itself.

www.kodak.com/go/support

Changing settings and more

5 Tap Enable, then Save when you’re done.

Your frame will now automatically turn on and off at the times you specified.

NOTE: Make sure the power button on the frame is On. See page 2.

If your frame loses power, the clock time returns to the factory setting and the automatic on/off times, if set, are disabled. To reset the clock and re-enable your on/off times, see Resetting the clock after losing power, page 58.

Upgrading your firmware

Firmware is the software that runs on your frame. To check for the latest version, visit

www.kodak.com/go/digitalframedownloads.

Manually upgrade firmware

Download the firmware to your computer, then upgrade your frame:

1 On your computer, go to www.kodak.com/go/digitalframedownloads.

2 Follow the screen directions to download the frame firmware to your computer.

3 Copy the IMG file to the root directory of a memory card or USB flash drive, then

insert into the frame. See page 31 for copying files.

4 Tap (Home), then (Settings).

5 Highlight Firmware Upgrade, then tap OK to begin the upgrade.

IMPORTANT:

When the upgrade is complete, your frame automatically restarts. If it doesn’t, press the

power button on the frame to Off, then back to On.

Do not turn off the frame or remove the memory card or USB flash drive during the upgrade!

50 www.kodak.com/go/support

Changing settings and more

Automatically upgrade firmware from the Internet

When the frame is connected to your wireless network, you can automatically upgrade the firmware from the Internet whenever a new version is available.

A message appears on your frame when a new firmware version is detected from the Internet.

Upgrade right away

■ Install now—Select, then press OK to start the upgrade.

When the upgrade is complete, your frame automatically restarts. If it doesn’t, press the

power switch on the frame to Off, then back to On.

IMPORTANT:

Upgrade later

■ Remind me later—Select, then press OK.

The upgrade message disappears, then appears again the next time you turn on the

frame.

■ No thanks—Select, then press OK.

The upgrade message disappears. To change your mind and upgrade to this version, see

Manually upgrade firmware, page 50.

A new message appears when the next firmware version is available.

Do not turn off the frame during the upgrade!

www.kodak.com/go/support

Changing settings and more

Adding a matte and faceplate

Customize your frame with a decorative matte and/or faceplate (packaged with some frames). Additional mattes and faceplates are available for purchase (see page 54).

When you are not using the matte, reapply it to the liner and store in a plastic bag to

Frame

keep the adhesive backing clean.

Matte

Faceplate

Mounting your frame on the wall

Use wall-anchoring hardware (not included) to anchor your frame securely to your wall.

Wall mounting

holes

Clip (use to reroute, secure, and center the power cable)

Power cable

To change to portrait orientation, turn your frame 90° and use the wall mounting holes at the top.

52 www.kodak.com/go/support

Changing settings and more

Changing your frame orientation

Change the frame orientation setting if you change to portrait orientation.

Change the stand position and angle:

■ Rotate the stand

the frame angle

NOTE: When displayed with the stand extended, the frame rests at a

68-90

Change the frame orientation setting: 1 Tap (Home)

2 Slide to highlight (Viewing options), then tap

OK.

3 Slide to highlight Frame orientation, then tap OK.

4 Slide to highlight Portrait, then tap OK

5 Tap to exit.

Your frame is set up now to display pictures in portrait

orientation.

90 °, then pull it out or push it in to adjust

angle.

→ (Settings).

www.kodak.com/go/support

Changing settings and more

Maintaining your frame and mattes

IMPORTANT:

Gently wipe the frame, LCD, or matte with a clean, dry, lint-free cloth (included). For fingerprints on the frame, apply light pressure.

Always disconnect the power before cleaning. Do not use water, cleaning solutions, or other adhesives on the frame or any of its parts.

Learning more about your frame

www.kodak.com/go/digitalframes Purchase frame accessories, including decorative

faceplates and custom mattes

www.kodak.com/go/digitalframesupport Extended user guide

Interactive troubleshooting and repairs Interactive tutorials Frequently asked questions Downloads Product registration

54 www.kodak.com/go/support

7 Troubleshooting and support

For step-by-step product support, visit www.kodak.com/go/digitalframesupport and select Interactive Troubleshooting & Repairs.

Frequently asked questions

I already have KODAK EASYSHARE Software on my computer. Do I have to install it again?

The CD that was packaged with your frame contains a special version of EASYSHARE Software that lets your computer share pictures with your frame. Install it to upgrade to this special software version, see page 9.

I lost my Internet connection in the middle of my setup. What should I do?

Reconnect to the Internet and repeat the installation and setup, starting on page 5.

I can’t find my network. Why?

■ Is your network set up to broadcast SSID? If so, you must enter your wireless

network information manually. The person who set up your network can help you

with this information.

■ Does your network have security enabled (WEP or WPA)? If so, see page 7.

I can’t find my network computer. Why?

■ Make sure your router and your computer are on.

■ Make sure your computer is on your wireless network. See the documentation that

came with your router and your computer.

■ Is your frame allowed to share content with your computer?

www.kodak.com/go/support 55

Troubleshooting and support

I didn’t connect to my network the first time I turned on my frame. Can I do it now?

Yes, you can.

1 Tap Ho me

→ Settings . Slide to highlight Network then tap Select.

2 Highlight Scan for wireless networks then tap OK.

3 Continue with step 1 on page 5.

Picture frame problems

If... Try one or more of the following

Frame cannot connect to the wireless network —“Wireless network not found” appears.

Frame does not turn on.

■ Make sure you have a wireless router and that it is broadcasting

the SSID, or enter the SSID manually.

■ Make sure you are within the operating range of the network.

Move the frame into the same room with the router.

■ Make sure your frame is using the latest firmware. Check

www.kodak.com/go/digitalframesupport for updates.

■ If your network security is enabled, see page 7 to enter your

security key (WEP or WPA). The person who set up your network can help you with this information.

■ Make sure the power cable that was included with your frame is

connected securely (see page 2).

■ Unplug the power cable for 5 seconds, then reconnect the cable.

Press and hold the power button (for about 2 seconds), then release.

56 www.kodak.com/go/support

Troubleshooting and support

If... Try one or more of the following

Nothing happens when a memory card, camera, or USB device is connected.

Touch border doesn’t work.

Frame freezes up or doesn’t work properly.

Music doesn’t play.

You set automatic on/off but the frame doesn’t turn on and off at the specified times.

■ Insert a certified SD/MMC/MS/xD/CF/MD card with images into the

designated card slot, then push to seat it (see page 19). In the top card slot, make sure the card is seated flush with the top.

■ Make sure the USB cable that was included with your camera or

USB device is connected securely (see page 20).

■ Make sure the file format of your pictures and videos are

supported. (See page 61).

NOTE: Do not insert a SANDISK Memory Stick, PRO DUO Card or other micro or mini

memory card without an adapter.

NOTE: Pictures may take a longer time to display when: the picture/video files are

large; when using a large capacity memory card or other connected device.

■ Use your finger to make your selections on the touch-sensitive

borders (see page 3). Lights on the border show you where to touch.

IMPORTANT:

■ Unplug the power cable for 5 seconds, then reconnect the cable.

Do not slide on the right border (tap only).

Press and hold the power button (for about 2 seconds), then release.

■ Unplug the power cable from the frame. Wait 5 seconds, then

reconnect the cable. Press and hold the power button (for about 2 seconds), then release.

■ Press the Volume and Power buttons at the top of the frame (see

page ii) at the same time, then tap Yes to reset the frame.

(Resetting your frame does not erase your saved files.)

■ Make sure the volume is turned up (see page ii).

■ If your frame has songs you purchased, they may be protected files.

Convert the files to standard (unprotected) AAC or MP3 formats.

■ Make sure you Enabled the on/off setting after you set the times,

then press OK (not Back). See page 49.

■ If your frame loses power, the clock returns to the factory setting

and auto on/off times are disabled. See Resetting the clock after

losing power, page 58.

www.kodak.com/go/support

Troubleshooting and support

Resetting the clock after losing power

If you turn off the power on the frame or otherwise lose power for half a day or more, the clock time returns to the factory setting and the automatic on/off times, if set, are disabled.

■ When you turn the frame back on, the set time screen appears on the frame.

■ Slide to set the hour. Tap the left/right arrows to highlight the previous or next

setting (hour and minutes), then slide to adjust the setting.

■ Tap O K.

The Home screen appears. The time is reset and the automatic on/off times (if set) are

re-enabled. It is not necessary to reset the on/off times.

NOTE: If you exit the set time screen without setting the time, you can manually reset the clock and

re-enable the automatic on/off times (see page 49). It is not necessary to reset the on/off times.

Picture frame/computer communications

If... Try one or more of the following

Cannot copy pictures to my computer.

Cannot see my frame as a removable drive.

Cannot copy pictures from KODAK EASYSHARE Software.

■ Make sure your frame and computer are on.

■ Make sure to install the software that was packaged with

your frame (see page 9) and copy pictures between your frame and computer using the EASYSHARE Digital Display Software (page 42).

■ Make sure the USB cable is securely connected (page 20).

■ Make sure the power button on the frame is On (page ii).

■ Make sure your frame and computer are on.

■ Make sure the USB cable is securely connected (page 20).

■ Make sure to install the software that was packaged with

your frame (page 9).

■ From My Collection in EASYSHARE Software, make sure the

pictures are in the Picture Tray.

58 www.kodak.com/go/support

Troubleshooting and support

If... Try one or more of the following

Cannot copy pictures from one device to another even though the copy destination is not full.

Storage devices that have FAT (File Allocation Table)16 formatting can only store up to 512 files in its top level (root) directory. To make sure all your pictures copy properly, format the copy destination to FAT32 before copying to it:

1 Connect the device to your computer. 2 Open My Computer and locate the device. 3 Right-click on it and choose Format. 4 From the File system drop-down menu, choose FAT32 then

click Start.

Caution: Formatting deletes all pictures and videos, including protected files.

Screen messages

Screen message Try one or more of the following

Create file failed. The device (memory card, USB drive, camera, etc.) you are

trying to copy to is protected.

■ See your device documentation to remove write

protection.

■ Insert or connect a different device.

Printer unavailable. Unable to connect to printer.

Printing error.

Time out occurred while printing.

■ Make sure your printer is on and the USB cable is

securely connected (page 29).

■ Make sure you changed your USB connection mode

from computer to printer (page 30).

■ Make sure your printer is on and the USB cable is

securely connected (page 29).

■ Check your printer for more info.

■ Check cables and printer supplies. Print again.

www.kodak.com/go/support

Troubleshooting and support

Screen message Try one or more of the following

Write failed. Select another location.

Unable to create file. Device write protected or full.

Disk full.

The frame was unable to copy the picture.

■ Insert a different card or device (page 19).

The frame was unable to copy the picture.

■ Insert a different card or device (page 19).

■ Remove write protection, unlock card.

■ Delete pictures from card.

Error attempting to open file or directory.

Error duplicate filename.

Error occurred while closing a file.

■ Turn off the frame, then turn it back on. Press and

hold the power button (for about 2 seconds), then release. If the problem persists, contact customer support help, at

www.kodak.com/go/digitalframesupport.

Error invalid filename

Error reading from file.

Error writing from file.

Error writing a file.

Error writing to a file.

File Copy Failed!

Internal error.

Parameter is invalid.

Unknown error.

60 www.kodak.com/go/support

8 Appendix

Digital frame specifications

For more specifications, visit www.kodak.com/go/digitalframesupport.

KODAK EASYSHARE W820/W1020 wireless digital frames

Color display

W820 20.3 cm (8 in.) diagonal digital LCD, 800 x 480 pixels, 4:3 or 16:9 aspect

ratio,

17.6 x 10 cm (6.9 x 3.9 in.) viewable area

W1020 25.4 cm (10 in.) diagonal digital LCD, 800 x 480 pixels, 16:9 aspect ratio,

23.5 x 14.6 cm (9.3 x 5.8 in.) viewable area

Internal storage capacity

W820, W1020 512 MB

Power

Leader Electronics Inc. AC adapter, model MU18-2120150-A1, 12-volt, 1.5 amp. Europe: Phihong AC adapter, model PSA 18R-120P (See page 63 for more information.)

Communication with computer

USB 1.0 cable

Wi-Fi wireless network compatibility

W820, W1020 Yes

Other features

PictBridge support

Picture formats JPEG, EXIF 2.2

Yes

www.kodak.com/go/support 61

Appendix

KODAK EASYSHARE W820/W1020 wireless digital frames

Video formats MOV, AVI, MPG, MPEG (Video formats created with digital cameras are

certified for Kodak digital frames. Videos created with or copied from other sources may not play on the frame.)

Music format MP3

Memory cards MMC (MultiMedia Card); SD/SDHC (Secure Digital/Secure Digital High

Capacity); Memory Stick, xD; CF; MD

Tripod mount 1/4 inch

Temperature Operating: -4 to 140

Storage: -22 to 185

Size W820: 28.5 x 21 x 3.8 cm (11.2 x 8.3 x 1.5 in.)

W1020: 33 x 24 x 3.8 cm (13 x 9.5 x 1.5 in.)

°F (-20 to 60°C)

°F (-30 to 85°C)

62 www.kodak.com/go/support

Appendix

Important safety instructions

CAUTION: Do not disassemble this product; there are no user-serviceable parts inside. Refer servicing to qualified service personnel. Do not

expose this product to liquid, moisture, or extreme temperatures. The use of controls, adjustments, or procedures other than those specified herein may result in exposure to shock and/or electrical or mechanical hazards. If the LCD breaks, do not touch the glass or liquid. Contact Kodak customer support.

CAUTION: When using this product, it should be installed and operated with

a minimum distance of 7.9 in. (20 cm) for 2.4 GHz operations between the radiator and your body. This transmitter must not be collocated or operate in conjunction with any other antenna or transmitter.

■ The use of an accessory that is not recommended by Kodak may cause fire, electric

shock, or injury. For approved accessories, visit www.kodak/go/accessories.

■ Use only a Leader Electronics Inc. AC adapter, model MU18-2120150-A1, 12-volt,

1.5 amp.

In Europe, use only a Phihong AC adapter, model PSA 18R-120P.

Use of other AC adapters may damage the frame and void your warranties.

■ Use only a USB-certified computer equipped with a current-limiting motherboard.

Contact your computer manufacturer if you have questions.

■ When displayed with the stand extended, the frame rests at a 68 - 90 degree

angle.

■ Do not place frame near naked flame sources such as lighted candles or heaters.

■ Excessive sound pressure from earphones and headphones may cause hearing

loss.

www.kodak.com/go/support

Appendix

Upgrading your software and firmware

Upgrade to the latest versions of the software included on the KODAK EASYSHARE Software CD and the frame firmware—www.kodak.com/go/digitalframedownloads. See page 50 for upgrading firmware.

Additional care and maintenance

■ Wipe the frame and the LCD gently with a soft, lint-free cloth (included). Do not

use cleaning solutions unless designed specifically for LCD screens. Do not allow

chemicals, such as suntan lotion, to contact painted surfaces.

■ Service agreements are available in some countries. Contact a dealer of Kodak

products for more information.

■ For digital frame disposal or recycling information, contact your local authorities. In

the US, visit the Electronics Industry Alliance Web site at www.eiae.org or visit

www.kodak.com/go/digitalframesupport.

Limited warranty

Kodak warrants Kodak consumer electronic products and accessories (“Products”), excluding batteries, to be free from malfunctions and defects in both materials and workmanship for one year from the date of purchase. Retain the original dated sales receipt. Proof of the date of purchase will be required with any request for warranty repair.

Limited warranty coverage

Warranty service is only available from within the country where the Products were originally purchased. You may be required to ship Products, at your expense, to the authorized service facility for the country where the Products were purchased. Kodak will repair or replace Products if they fail to function properly during the warranty period, subject to any conditions and/or limitations stated herein. Warranty service will include all labor as well as any necessary adjustments and/or replacement parts. If Kodak is unable to repair or replace a Product, Kodak will, at its option, refund the

64 www.kodak.com/go/support

Appendix

purchase price paid for the Product provided the Product has been returned to Kodak along with proof of the purchase price paid. Repair, replacement, or refund of the purchase price are the sole remedies under the warranty. If replacement parts are used in making repairs, those parts may be remanufactured, or may contain remanufactured materials. If it is necessary to replace the entire Product, it may be replaced with a remanufactured Product. Remanufactured Products, parts and materials are warranted for the remaining warranty term of the original Product, or 90 days after the date of repair or replacement, whichever is longer.

Limitations

This warranty does not cover circumstances beyond Kodak's control. This warranty does not apply when failure is due to shipping damage, accident, alteration, modification, unauthorized service, misuse, abuse, use with incompatible accessories or attachments (such as third party ink or ink tanks), failure to follow Kodak 's operation, maintenance or repacking instructions, failure to use items supplied by Kodak (such as adapters and cables), or claims made after the duration of this warranty. Kodak makes no other express or implied warranty for this product, and disclaims the implied warranties of merchantability and fitness for a particular purpose. In the event that the exclusion of any implied warranty is ineffective under the law, the duration of the implied warranty will be one year from the purchase date or such longer period as required by law. The option of repair, replacement, or refund is Kodak's only obligation. Kodak will not be responsible for any special, consequential or incidental damages resulting from the sale, purchase, or use of this product regardless of the cause. Liability for any special, consequential or incidental damages (including but not limited to loss of revenue or profit, downtime costs, loss of the use of the equipment, cost of substitute equipment, facilities or services, or claims of your customers for such damages resulting from the purchase use or failure of the Product), regardless of cause or for breach of any written or implied warranty is expressly disclaimed.

www.kodak.com/go/support

Appendix

Your rights

Some states or jurisdictions do not allow exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. Some states or jurisdictions do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. This warranty gives you specific rights, and you may have other rights which vary from state to state or by jurisdiction.

Outside the United States and Canada

In countries other than the United States and Canada, the terms and conditions of this warranty may be different. Unless a specific Kodak warranty is communicated to the purchaser in writing by a Kodak company, no warranty or liability exists beyond any minimum requirements imposed by law, even though defect, damage, or loss may be by negligence or other act.

FCC compliance and advisory

KODAK EASYSHARE W820/W1020 wireless digital frames

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed or used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) reorient or relocate the receiving antenna; 2) increase the separation between the equipment and the receiver; 3) connect the equipment to an outlet on a circuit different from that

66 www.kodak.com/go/support

Appendix

to which the receiver is connected; 4) consult the dealer or an experienced radio/TV technician for additional suggestions.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Where shielded interface cables have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulation.

FCC and Industry Canada

This device complies with Industry Canada RSS-210 and FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Hereby, Eastman Kodak Company declares that this Kodak product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

This digital picture frame (W820 or W1020) transmits in 10 dBm. In France, the power level is limited to 10dBm in outdoor environments, per regulations. When in France, use the wireless functions of this device indoors only.

www.kodak.com/go/support

Appendix

Canadian DOC statement

DOC Class B Compliance—This Class B digital apparatus complies with Canadian

ICES-003.

Observation des normes-Classe B—Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Waste Electrical and Electronic Equipment labeling

EU: It is the final user’s responsibility to discard this equipment into an approved, segregated collection scheme to enable its suitable treatment/disposal and to improve human/environmental protection. For more information, see your retailer, local authority, or

www.kodak.com/go/recycle.

Australian C-Tick

N137

MPEG-4

Use of this product in any manner that complies with the MPEG-4 visual standard is prohibited, except for use by a consumer engaging in personal and non-commercial activities.

Russian GOST-R

Eastman Kodak Company Rochester, New York 14650

68 www.kodak.com/go/support

China RoHS

Appendix

Korean Class B ITE

www.kodak.com/go/support

Appendix

Licensing

Supply of this product does not convey a license nor imply any right to distribute content created with this product in revenue-generating broadcast systems (terrestrial, satellite, cable and/or other distribution channels), streaming applications (via Internet, intranets and/or other networks), other content distribution systems (pay-audio or audio-on-demand applications and the like) or on physical media (compact discs, digital versatile discs, semiconductor chips, hard drives, memory cards and the like). An independent license for such use is required. For details, please visit

http://mp3licensing.com.

70 www.kodak.com/go/support

Index 1

about, frame, 48 appendix, 61 automatic on/off, 47, 49

battery

safety, 63 button

macro/landscape, ii

cables

USB, connecting, 20 camera, connecting, 20 changing picture locations, 22 clock and timer, setting, 47, 49 computer

copying to/from, 42

help with communicating, 58 connection mode, 30 copying

from EASYSHARE Software, 44

to/from computer, USB, 42

deleting pictures and videos, 32 displaying slide show, 24 disposal, recycling, 64 doing more with your frame, 27

EASYSHARE Software

copying pictures from, 44

error messages, 59

fast forward video, 28 firmware

checking version, 48

upgrading, 46, 64 flash drive, connecting, 20 frame, picture

changing orientation, 1

checking model, firmware, serial

number, 48 setup, 1 specifications, 61 troubleshooting, 56

help

communicating with computer, 58 frame, 56

home

changing picture locations, 22 screen, 22

internal memory

capacity, 61

internet

requirements for wireless, 34

www.kodak.com/go/support 71

Index

landscape, set orientation, 47 language

setting, 48 setting first time, 4

macro/landscape button, ii multi-up view, 25

on/off, setting auto, 47, 49 orientation setting, 1, 47

PictBridge enabled printer, 29 pictures

copying connected, 42 copying from EASYSHARE

Software, 44 deleting, 32 location, changing, 22 selecting more than one, 33

play/pause, video, 28 portrait, set orientation, 47 power

specifications, 61

printer connection mode, 30 printing, PictBridge printer, 29

recycling, disposal, 64 regulatory compliance, 66 rewind video, 28 running slide show, 24

safety information, 63 screen

cleaning, 64

error messages, 59 selecting multiple pictures, 33 serial number, checking, 48 setting

auto on/off, 47, 49

language, 48

language first time, 4

time, 47

viewing options, 47

wireless operation, 34 setup

picture frame, 1

wireless network, 34 slide duration, setting, 47 slide show

running, 24 slide transitions, setting, 47 software

upgrading, 64 source, picture location, 22 specifications, frame, 61 stop

video, 28 storage capacity, internal memory, 61

thumb drive. See flash drive., 20 thumbnails, 25 time, setting, 47 transitions, slides, setting, 47

72 www.kodak.com/go/support

troubleshooting

error messages, 59 frame, 56

upgrading

firmware, 46

software and firmware, 64 USB connection mode, 30 USB device, connecting, 20

viewing

full screen picture, 23, 25

pictures, wireless network, 35

thumbnails, 25

warranty, 64 wireless

features on frame, overview, 34

setup, 34

viewing pictures, 35

Index

www.kodak.com/go/support 73

Kodak EASYSHARE W820, EASYSHARE W1020 User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Insert the CD into your computer.

3 Tap (Close) to dismiss the icons.

1 Turn off the frame and printer.

2 Tap (Actions).

3 Tap (Copy), then OK.

5 Tap (Close) to close the menu.

3 Highlight Home PC , then tap OK.

1 See page 11 to set up your frame for Web access.

2 Tap (Home) to display the Home screen.

3 Tap one of these Web sources:

3 With My Friends’ Albums highlighted, tap OK.

3 Slide to highlight Frame orientation, then tap OK.

4 Slide to highlight Portrait, then tap OK

5 Tap to exit.
