Kodak EasyShare

DX4530 zoom digital camera

User’s Guide

www.kodak.com

For interactive tutorials, www.kodak.com/go/howto

Eastman Kodak Company 343 State Street Rochester, New York 14650

All screen images are simulated © Eastman Kodak Company, 2003 Kodak, EasyShare, Max, and Retinar are trademarks of Eastman Kodak

Company. P/N 6B8563

Front View

Product Overview

1 2 3 5

1 Shutter button 7 Light sensor 2 Mode dial 8 Lens 3 Flash button 9 DC In (for optional 3V AC adapter) 4 Flash unit 10 Lens cap strap post 5 Viewfinder window 11 Microphone 6 Self Timer light 12 Wrist strap post

Back View

Product Overview

1 Viewfinder 8 Grip 2 Ready light 9 Review button 3 Flash button 10 Camera screen (LCD) 4 Mode dial 11Menu button 5 Shutter button 12 4-way control 6 Zoom (Wide Angle and Telephoto) 13 OK button 7 Share button 14 Delete button

532

Side View

Product Overview

1 Audio/Video Out 2 Door to:

m Slot for optional SD/MMC card m USB port (for computer connection)

iii

Product Overview

Top, Bottom View

AUTO

OFF

765

1 Speaker 5 Battery door 2 Flash button 6 Tripod socket 3 Mode dial 7 Dock connector door 4 Shutter button 8 Lens cap strap post

421 3

1 Getting Started ...................................................................1

Install Software First................................................................1

Need This User Guide in Larger Print? .................................1

What Can I Do With My Camera?...........................................2

What Can I Do With My Pictures and Videos?...................2

Package Contents..................................................................... 3

Attaching the Wrist Strap .................................................... 4

Attaching the Lens Cap Strap............................................. 4

Adding Optional Lenses .......................................................... 4

Loading the Battery................................................................. 5

Mode Dial Settings................................................................... 6

Turning On the Camera............................................................. 7

Setting the Date and Time .................................................... 8

Checking Camera Status Icons ............................................ 9

Inserting an SD/MMC Card...................................................10

Choosing Internal Memory or SD/MMC Card.................... 11

Important Battery Information........................................... 13

2 Taking Pictures .................................................................15

Taking Pictures in Auto Mode ..............................................15

Taking Pictures in Sport Mode ............................................16

Taking Pictures in Night Mode ............................................. 17

Taking Pictures in Landscape Mode...................................18

Taking Pictures in Close-up Mode ....................................... 19

Liveview—Framing with the Camera Screen...................20

Quickview—Reviewing the Picture Just Taken ................ 21

Using the Auto Focus Framing Marks ............................. 22

Using the Optical Zoom.........................................................23

Using the Digital Zoom.......................................................... 23

Using the Flash........................................................................ 24

Putting Yourself in the Picture...........................................26

Setting Exposure Compensation ....................................... 27

Setting Long Time Exposure................................................28

Setting Picture Quality.........................................................29

Placing the Date on Pictures ..............................................30

Setting the Orientation Sensor.......................................... 31

3 Taking Videos ................................................................... 33

Taking a Video...........................................................................33

Quickview—Reviewing the Video Just Taken ...................34

Using the Optical Zoom.........................................................34

Putting Yourself in the Video .............................................. 35

4 Reviewing Pictures and Videos ....................................37

Viewing Pictures and Videos ................................................ 37

Playing a Video .........................................................................38

Deleting Pictures and Videos ..............................................38

Review Menus ...........................................................................39

Magnifying Pictures ...............................................................39

Protecting Pictures and Videos From Deletion.............40

Running a Slide Show ..............................................................41

Copying Pictures and Videos............................................... 43

Displaying Video Date............................................................ 44

Viewing Picture/Video Information ..................................... 44

5 Tagging Pictures and Videos ....................................... 45

When Can I Tag My Pictures and Videos?........................ 45

Tagging Pictures for Printing..............................................46

Tagging Pictures and Videos for Emailing........................47

Tagging Pictures and Videos as Favorites ..................... 48

6 Customizing Your Camera Settings .........................49

Accessing Setup Mode/Menus........................................... 49

Setup Menus............................................................................ 49

Changing the Print Quantity Default ...............................50

Turning Off Quickview .............................................................50

Turning On Liveview In Still Modes .......................................51

Turning Off the Shutter Sound ............................................51

Setting Video Out................................................................... 52

Selecting a Language ............................................................ 52

Formatting Internal Memory or SD/MMC Card ............ 53

Viewing Camera Information ................................................ 54

vii

7 Installing the Software ................................................. 55

Windows System Requirements ........................................55

Mac OS X System Requirements.......................................56

Mac OS 8.6 and 9.x System Requirements ..................56

Install the Software ............................................................... 57

8 Connecting to the Computer ...................................... 59

Connecting to the Computer...............................................59

Printing Pictures From Your Computer .......................... 60

Printing From an Optional SD/MMC Card...................... 60

Ordering Prints Online .......................................................... 60

9 Using the Optional Camera Dock II ............................61

Camera Dock Package Contents.........................................61

Installing the Camera Insert ...............................................62

Connecting the Camera Dock ............................................. 63

Installing the Battery in the Camera ...............................64

Docking the Camera ...............................................................65

Charging the Battery ........................................................... 66

Transferring Pictures and Videos ...................................... 67

Caution When Using a Tripod............................................... 67

Earlier Camera Dock Model ................................................. 68

viii

10 Troubleshooting .............................................................69

Troubleshooting—Camera...................................................69

Troubleshooting—Camera Dock II ..................................... 82

11 Getting Help ....................................................................85

Helpful Web Links ....................................................................85

Help in this Manual ................................................................ 85

Software Help ..........................................................................85

Telephone Customer Support .............................................86

12 Appendix ...........................................................................89

Camera Specifications..........................................................89

Original Factory Settings—Camera ................................. 91

Upgrading Your Software and Firmware ......................... 92

Tips, Safety, Maintenance ................................................... 92

Storage Capacities................................................................93

Locating Pictures and Videos on a Card......................... 94

Card File Naming Conventions ............................................ 94

Power-Saving Features......................................................... 95

Optional AC Adapter ............................................................. 95

Regulatory Information......................................................... 95

1 Getting Started

Install Software First

Install the software from the Kodak EasyShare software CD before connecting the camera (or optional camera dock) to the computer. Failure to do so may cause the software to load incorrectly.

See the Quick Start Guide or Installing the Software, page 55.

Need This User Guide in Larger Print?

1 See www.kodak.com/go/dx4530support. 2 Navigate to the Manuals section. 3 Click View as PDF to open the User’s Guide. 4 On a Windows OS-based computer or Mac OS 8.6 or 9.x:

m From the File menu, select Print. m In the Print window, select Fit to Page.

On Mac OS X:

m From the File menu, select Page Setup. m Change Scale to 200%.

5 Print as usual.

Chapter 1

What Can I Do With My Camera?

Capture Still Pictures —Use Auto mode to enjoy point-and-shoot operation. Use Sport, Night, Landscape, and Close-up modes to expand your capabilities.

Capture Videos with Sound —Capture videos as QuickTime movies. Review —Display, protect, and delete pictures and videos; tag for albums. Share —Share pictures (print, email, save as Favorites) and videos

(email, save as Favorites). Set Up —Customize your camera functions (see page 49).

What Can I Do With My Pictures and Videos?

Install the software from the Kodak EasyShare software CD, then:

Transfer—Transfer pictures and videos to your computer. Share—Print pictures, order prints online, email pictures and videos. Print—(see page 60) Print pictures directly to your home printer or Kodak

EasyShare printer dock 4000. Order prints online from Ofoto (www.ofoto.com). Or purchase an optional Kodak secure digital (SD) card or multimedia card (MMC) and:

m Automatically print to any printer with an SD/MMC slot m Make prints at an SD/MMC-capable Kodak picture maker kiosk

www.kodak.com/go/picturemaker

m Take the card to your local photo retailer for professional printing

Organize—Use Favorites to organize and retrieve pictures on a computer. Edit—Add special effects to your pictures, make a custom slide show, fix

red-eye, crop, rotate, and much more. For details, click the Help button in the Kodak EasyShare software. Some Mac

operating systems may support limited Kodak EasyShare software features.

Package Contents

Chapter 1

1 Camera 5 Custom camera dock insert (for EasyShare printer

dock 4000 or EasyShare camera dock II) 2 CRV3 or equivalent* 6 Lens cap with strap 3 USB cable 7 Audio/Video cable 4 Wrist strap

Not shown: User’s Guide, Quick Start Guide, Kodak EasyShare software CD. (In some countries, the User’s Guide is provided on a CD only. Contents may change without notice.)

* If your camera was packaged with a Kodak EasyShare camera dock II, a Kodak EasyShare Ni-MH rechargeable battery and AC power adapter are included. For details, see page 61.

Chapter 1

Attaching the Wrist Strap

1 Thread the wrist strap as shown.

2 Thread the long loop through the short

loop. Pull until secure.

Long loop

Short loop

Attaching the Lens Cap Strap

1 Thread the lens cap string through the lens

cap strap post.

2 Thread the lens cap through the loop. Pull

until secure. Use the lens cap to protect the lens when

camera is not in use.

Adding Optional Lenses

Lenses are available. Purchase accessories at a dealer of Kodak products. See

Lens threads

www.kodak.com/go/dx4530accessories

Chapter 1

Loading the Battery

1 Turn the Mode dial to Off. 2 On the bottom of the camera, slide the

battery door and lift to open.

3 Insert the CRV3 battery as shown. 4 Close the battery door.

Important Battery Information

CRV3

See page 13 for other types of batteries you can use in your camera. If you purchased the Kodak EasyShare camera dock II, see page 64 for details

on installing the Kodak EasyShare Ni-MH rechargeable battery. See page 95 for information on the optional Kodak 3-volt digital camera AC

adapter.

The CRV3 battery is not rechargeable. For acceptable battery life, and to make

sure your camera operates dependably, do

not use alkaline batteries.

NOTE: If AA batteries were included with your

camera, insert them as shown.

Chapter 1

Mode Dial Settings

AUTO

OFF

Icon Mode Purpose

Off Turns off the camera.

Off

Auto For general picture-taking. Automatically sets

Sport For subjects that are in motion. Shutter speed is fast.

Night For night scenes or low light conditions. Captures

Landscape For distant subjects. Flash does not fire unless you

Close-up For subjects 2.8 to 28 in. (7 to 70 cm) from the lens

Video Captures video with sound. Flash does not fire.

exposure and focus. Flash fires if needed.

Flash fires if needed.

close and background subjects. Flash fires if needed. In dark scenes, the shutter speed is set between 1/30 and 1/2 second. Place camera on a flat, steady surface or tripod to avoid camera shake.

turn it on.*

in wide angle, or 11 to 28 in. (28 to 70 cm) in telephoto. Flash does not fire.

* To turn on the flash, see page 24.

Chapter 1

Turning On the Camera

Ready light Mode dial

AUTO

Changing the Display

To Do This Turn Liveview on so that the camera

screen can be used as a viewfinder Change the Liveview setting so that it

is on whenever the camera is on Turn the status area back on after it

times out

Turn off the camera

1 Remove the lens cap.

If you do not remove the lens cap, it comes off automatically when you turn on the camera.

2 Turn the Mode dial from Off to any other

position.

The ready light blinks green while the camera performs a self-check.

When the ready light glows steady green, the camera is ready to take pictures (or videos, if the mode dial is set to ).

In Still and Video modes, a status area appears on the camera screen.

Press the OK button. To turn it off, press the OK button again.

See page 51.

Press .

1 Turn the Mode dial to Off.

The camera completes operations that are in process.

2 Replace the lens cap.

Chapter 1

Setting the Date and Time

Setting the Date & Time, First Time

The Date and Time have been reset message appears the first time you turn on the camera or if the battery is removed for an extended time.

1 SET DATE & TIME is highlighted. Press the

OK button. (Select Cancel to set the date and time at a

later time.)

The Date & Time screen appears.

Setting the Date & Time, Anytime

4 Press to adjust the date and time. Press to advance to the

next setting.

5 When finished, press the OK button. 6 Press the Menu button to exit the menu.

The setting remains until you change it.

NOTE: Depending on your computer operating system, Kodak EasyShare

software may allow your computer to automatically update the camera clock when you connect the camera. See the Kodak EasyShare software Help for details.

2 Go to step 4 below, Setting the Date & Time,

Anytime.

1 Turn on the camera. Press the Menu button.

2 Press to highlight Setup, then press

the OK button.

3 Press to highlight Date & Time, then

press the OK button.

The date format is YYYY/MM/DD. The time is displayed in a 24-hour format.

Chapter 1

Checking Camera Status Icons

tatus

Icons

Screen Icon

Status Icons (Top of Camera Screen)

Status icons depict enabled features and settings:

To check the current camera settings, turn the Mode dial from Off to any mode.

For flash icons, see page 24. For Share icons, see page 45.

Date stamp Long time

exposure

Best Best (3:2)

Better Good

Quality Pictures remaining Current Storage location

Exposure compensation

015

015015

Self Timer Flash mode

Internal memory

Memory Card

Screen Icons (Bottom of Camera Screen)

Screen icons depict the current mode or a battery concern:

Auto Sport Night Landscape Close-up Review Video

Share Low battery Exhausted battery (blinking)

Chapter 1

Inserting an SD/MMC Card

Your camera has 32 MB of internal storage for pictures and videos. Optional SD/MMC cards provide removable, reusable storage.

CAUTION:

CAUTION:CAUTION:

The card can only be inserted one way; forcing it may damage the camera or card. Do not insert or remove a card when the green ready light is blinking; doing so may damage your pictures, card, or camera.

Notched corner of card

To remove the card, push it in, then release it. When the card is partially ejected, pull it out.

See page 93 for storage capacities. Purchase accessories at a dealer of Kodak products. See www.kodak.com/go/dx4530accessories

To insert an SD/MMC card:

1 Turn off the camera.

2 Open the card door.

3 Orient the card as shown.

4 Push the card into the slot to seat the

connector.

5 Close the door.

Chapter 1

Choosing Internal Memory or SD/MMC Card

The camera offers two options for storing pictures and videos:

Internal Memory —store pictures and videos in internal memory. SD/MMC Card —store as many pictures and videos as you like,

depending on the size of the card. Purchase accessories at a dealer of Kodak products. See www.kodak.com/go/dx4530accessories. For storage capacities, see page 93.

Managing Your Storage Location Setting

1 Turn on the camera. 2 Press the Menu button. 3 Press to highlight Image Storage , then press the OK button.

4 Press to highlight an option, then

press the OK button: Auto (default)—the camera uses the card

if one is in the camera. If not, the camera uses internal memory.

Internal Memory—the camera always

5 Highlight Continue, then press the OK button again.

The setting remains until you change it and applies to all camera functions.

6 Press the Menu button to exit the menu.

uses internal memory, even if a card is installed.

Chapter 1

Checking Your Storage Setting

In Still and Video modes, the storage location icon that appears in the status area indicates the camera’s storage location. To check the location, either:

Picture or video location

m Turn the Mode dial from the Off position, or

m In any capture mode, press .

—Memory Card —Internal Memory

Checking a Picture or Video’s Location

In Review mode, the storage location icon that appears with a picture indicates the location of the picture or video and the camera setting.

Picture or video location

Press the Review button.

—Picture or video is stored on a card —Picture or video is stored in internal

memory

Chapter 1

Important Battery Information

Choose the replacement battery that fits your needs—and get the best performance.

Kodak Battery Replacement Types/Battery Life

Your camera can use the following types of batteries. Actual battery life may vary based on usage.

CRV3 lithium battery

(included with camera)

AA (2) lithium batteries

Ni-MH rechargeable battery pack* (per charge)

AA (2) Ni-MH rechargeable batteries (per charge)

Kodak Max digital camera batteries, AA (2)

0 500

* Included with the Kodak EasyShare camera dock II

and printer dock 4000

165 - 205

100 - 140

Battery Life (Approx. Number of Pict

365 - 455

265 - 365

ures)

We do not recommend or support alkaline batteries. For acceptable battery life, and to make sure your camera operates dependably, use the replacement batteries listed above.

For information on batteries, see

www.kodak.com/global/en/service/batteries/batteryUsage.jhtml

Chapter 1

Extending Battery Life

m Limit the following activities that quickly deplete battery power:

– Reviewing your pictures on the camera screen (see page 37) – Using Liveview (see page 20) – Using Quickview (see page 21 and page 34). – Excessive use of the flash

m Purchase an optional Kodak 3-volt AC adapter to power your camera (see

page 95).

m Purchase an optional Kodak EasyShare camera dock II (see page 61). The

camera dock II powers your camera, transfers pictures, and is a battery charger for its included Kodak EasyShare Ni-MH rechargeable battery pack.

m Purchase an optional Kodak EasyShare printer dock 4000 (see page 61).

The printer dock 4000 powers your camera, makes 4 x 6 prints with or without a computer, transfers pictures, and is also a battery charger for its included Kodak EasyShare Ni-MH rechargeable battery pack.

m Dirt on the battery contacts can affect battery life. Wipe the contacts with a

clean, dry cloth before loading batteries in the camera.

m Battery performance is reduced at temperatures below 41° F (5° C).

Carry spare batteries when using your camera in cold weather, and keep them warm. Do not discard cold batteries that do not work; when they return to room temperature, they may be usable.

Battery Safety and Handling

m Do not allow batteries to touch metal objects, including coins. Otherwise, a

battery may short circuit, discharge energy, become hot, or leak.

m For rechargeable battery disposal information, see the Rechargeable

Battery Recycling Corporation Web site at www.rbrc.com.

2 Taking Pictures

The camera is ready to take pictures when you turn it on—even if you are in Review, Share, or Setup. (In Video mode, the camera captures video.) Before you take a picture, make sure your picture storage location is set the way you want it (see page 11).

Taking Pictures in Auto Mode

Use Auto for general picture-taking. Exposure, focus, and flash are automatic.

1 Turn the Mode dial to .

The camera screen displays a mode description. To interrupt it, press .

2 Use the viewfinder or camera screen to

frame your subject. (To turn the camera screen on or off, press the OK button.)

3 Press the Shutter button half-way to set

Ready light

4 When the ready light glows green, continue pressing the Shutter button

completely down to take the picture.

The ready light blinks green while the picture is saved. The ready light blinks orange while the flash is recharging (or if there is an auto-exposure or auto-focus error).

Default flash setting: Auto or Red-eye Available flash settings: Auto, Flash Off, Fill Flash, Red-eye Camera returns to default: When you change modes or turn off the

the exposure and focus. (Otherwise, the picture could be too dark, light, or blurry.)

camera.

Chapter 2

Taking Pictures in Sport Mode

Use this mode when the subject is in motion. In Sports mode, the shutter speed is set between 1/30 to 1/1700 second.

1 Turn the Mode dial to .

The camera screen displays a mode description for a few seconds. To interrupt the description, press

2 Press the Shutter button half-way to set

the exposure and focus.

3 When the ready light glows green, continue

Ready light

Default flash setting: Auto Available flash settings: Auto, Flash Off, Fill Flash, Red-eye Camera returns to default: When you change modes or turn off the

pressing the Shutter button completely down to take the picture.

The ready light blinks green while the picture is saved.

camera.

Chapter 2

Taking Pictures in Night Mode

Use this mode for night scenes or low light conditions. The flash illuminates close subjects. A longer exposure captures more detail of background subjects. The shutter speed is set between 1/30 to 1/2 second, depending on available light.

1 To avoid blurry pictures, place the camera

on a flat, steady surface or use a tripod.

2 Turn the Mode dial to .

The camera screen displays a mode description for a few seconds. To interrupt the description, press .

3 Press the Shutter button half-way to set

the exposure and focus.

4 When the ready light glows green, continue

Ready light

Default flash setting: Auto Available flash settings: Auto, Flash Off, Fill Flash, Red-eye Camera returns to default: When you change modes or turn off the

pressing the Shutter button completely down to take the picture.

The ready light blinks green while the picture is saved.

camera.

Chapter 2

Taking Pictures in Landscape Mode

Use this mode to capture subjects further than 57.4 ft (17.5 m), such as landscape scenes. The shutter speed is set between 1/8 to 1/1700 second.

1 Turn the Mode dial to .

The camera screen displays a mode description for a few seconds. To interrupt the description, press .

2 Press the Shutter button half-way to set

the exposure.

3 When the ready light glows green, continue

Ready light

Default flash setting: Off Available flash settings: Auto, Flash Off, Fill Flash, Red-eye Camera returns to default: When you change modes or turn off the

pressing the Shutter button completely down to take the picture.

The ready light blinks green while the picture is saved.

camera.

Chapter 2

Taking Pictures in Close-up Mode

Use this mode to capture subjects this close to the lens:

m Wide angle: 2.8 to 28 in. (7 to 70 cm) m Telephoto: 11 to 28 in. (28 to 70 cm)

The shutter speed is set between 1/8 to 1/1700 second.

1 Turn the Mode dial to .

The camera screen displays a mode description for a few seconds. To interrupt the description, press .

2 Press the Shutter button half-way to set

the exposure and focus.

3 When the ready light glows green, continue

Ready light

Default flash setting: Off Available flash settings: Auto, Flash Off, Fill Flash, Red-eye Camera returns to default: When you change modes or turn off the

pressing the Shutter button completely down to take the picture.

The ready light blinks green while the picture is saved.

camera.

Chapter 2

Liveview—Framing with the Camera Screen

When you turn on Liveview, the camera screen displays a live image of what the lens sees. Use the camera screen to frame your subject.

Mode dial

To change the Liveview setting so that it is on whenever the camera is on, see

page 51.

Using the Viewfinder

Parallax marks

Auto focus zone

1 Turn the Mode dial to any Still position.

The camera screen displays a mode description for a few seconds. To interrupt the description, press .

2 Press the OK button to turn on Liveview.

3 Frame your subject in the camera screen.

4 Press the Shutter button half-way to set

the exposure and focus, then continue pressing completely down to take the picture.

5 To turn off Liveview, press the OK button.

NOTE: Liveview quickly depletes battery power.

To conserve battery power, turn off Liveview and use the Viewfinder to frame your subject.

When using the viewfinder to capture close subjects (3 feet or less), keep the subject below the parallax marks. For even more accurate framing results, turn on Liveview. (Liveview depicts what the lens “sees.”)

Chapter 2

Quickview—Reviewing the Picture Just Taken

After you take a picture, the camera screen displays a Quickview of that picture for approximately 5 seconds. While the picture is displayed, you can:

Delete Share

To save battery power, you can turn off the Quickview feature. (See page 50.)

m Review it: If you take no action, the picture

is saved.

m Share it: Press the Share button to tag the

picture for print, email, or as a Favorite. (See Tagging Pictures and Videos, page 45.)

m Delete it: Press the Delete button while the

picture and are displayed.

Chapter 2

Using the Auto Focus Framing Marks

For the best possible pictures, the camera attempts to focus on foreground subjects (even if the subjects are not centered in the scene).

NOTE: Auto Focus framing marks appear only when the camera screen is

turned on. The framing marks do not appear in Landscape mode.

1 In any Still mode (except Landscape), press the OK button.

The camera screen turns on.

2 Press the Shutter button half-way to set the exposure and focus. 3 The Auto Focus framing marks depict the main focus area or areas. If the

camera is not focusing on the desired subject, release your finger, recompose the scene, and repeat Step 2.

While Shutter Button is Pressed Half-way

Center focus

Center wide focus

Side focus

Center and side focus

Left and right focus

4 Continue pressing the Shutter button completely down to take the

picture.

Chapter 2

Using the Optical Zoom

Use optical zoom to get up to 3X closer to your subject. When you turn on the camera, the lens extends to the Wide Angle position. Optical zoom is effective when the lens is no closer than 24 in. (0.6 m) to the subject. When using optical zoom in Close-up mode, stay at least 11 in. (28 cm) from the subject.

Wide angle Telephoto

1 Use the viewfinder or camera screen to

frame your subject.

2 Press the Telephoto (T) button to zoom in.

Press Wide Angle (W) button to zoom out.

The lens extends or retracts. The viewfinder or camera screen displays the zoomed image.

3 Press the Shutter button half-way to set the exposure and focus, then

continue pressing completely down to take the picture.

NOTE: The lens retracts when the camera is turned off.

Using the Digital Zoom

Use Digital Zoom to get an additional 3.3X magnification beyond Optical Zoom. IMPORTANT: You may notice a decrease in printed image quality

1 Press the OK button to turn on Liveview. 2 Press the Telephoto (T) button to the Optical Zoom limit. Release the

button, then press it again.

The camera screen displays the zoomed image and the magnification level.

3 Press the Shutter button half-way to set the exposure and focus, then

continue pressing completely down to take the picture.

when using Digital Zoom.

Chapter 2

Using the Flash

Use the flash when you take pictures at night, indoors, or outdoors in heavy shadows. You can change the flash setting in any Still mode; the default flash setting is restored when you exit the mode or turn off the camera.

Flash Range

m Wide angle: 2 to 11.2 ft (0.6 to 3.4 m) m Telephoto: 2 to 6.6 ft (0.6 to 2.0 m)

Turning On The Flash

Flash Setting

1 Press the button repeatedly to scroll

through the flash options.

2 Press the OK button.

The flash icon that is displayed on the camera screen status bar (page 9) is the active option.

Auto Flash—flash fires when the lighting conditions require it.

Off—flash never fires.

Fill—flash fires every time you

take a picture, regardless of the lighting conditions.

Red-eye—flash fires once so the subject’s eyes become accustomed to the flash, then fires again when the picture is taken. (If the lighting conditions require flash but do not require Red-eye reduction, the flash may fire only once.)

Chapter 2

Flash Settings In Each Mode

Icon Mode Default

Auto Auto or

Sport Auto

Night Auto

Landscape Off

Close-up Off

Long Time Exposure

Video Off None Flash cannot be

Flash Setting

Red-eye

Off

Available Flash Settings

Auto, Flash Off, Fill Flash, Red-eye

Other Flash Screen Information

When choosing a flash setting, the current camera settings are displayed in the bottom portion of the screen.

Camera Returns to the Default Flash Setting

When you change modes or turn off the camera

turned on

Chapter 2

Putting Yourself in the Picture

The Self Timer creates a 10-second delay between the time you press the Shutter button and the time the picture is taken.

Turn on the Self Timer:

1 In any Still mode, press the Menu button.

2 Press to highlight Self Timer ,

then press the OK button.

3 Press to highlight On, then press the

OK button.

4 Press the Menu button to exit the menu.

Take the picture:

1 Place the camera on a flat surface or use a

tripod.

2 Compose the scene. Press the Shutter

button half-way to set the exposure and focus, then continue pressing completely down. Move into the scene.

The red Self Timer light blinks slowly for 8 seconds (then quickly for 2 seconds) before the picture is taken.

The Self Timer turns off after the picture

Self Timer light

is taken or if you change modes.

Chapter 2

Setting Exposure Compensation

Use Exposure Compensation to control how much light enters the camera. This setting is useful for taking pictures in very large rooms, under low light, without a flash.

Adjust the exposure by plus or minus 2 steps in 1/2-step increments. NOTE: Exposure Compensation cannot be used with Long Time Exposure.

1 In any Still mode, press the Menu button. 2 Press to highlight Exposure Compensation , then press the OK

button.

3 Press to select the Exposure

Compensation setting.

m If pictures are too light, decrease the

value.

m If pictures are too dark, increase the

value.

4 Press the OK button to accept the change. 5 Press the Menu button to exit the menu. 6 Use the camera screen to frame your

subject. Press the Shutter button half-way to set the focus, then continue pressing completely down to take the picture.

This setting remains until you change the Mode dial or turn off the camera.

Chapter 2

Setting Long Time Exposure

Use Long Time Exposure to control how long the shutter stays open. Settings are: None, 0.7, 1, 1.5, 2, 3, and 4 seconds.

NOTE: Long Time Exposure cannot be used with Exposure Compensation.

1 To avoid blurry pictures, place the camera on a flat, steady surface or use a

tripod.

2 In any Still mode, press the Menu button. 3 Press to highlight Long Time Exposure , then press the OK

button.

4 Press to highlight an option.

5 Press the OK button to accept the change.

6 Press the Menu button to exit the menu.

7 Use the camera screen to frame your

subject. Press the Shutter button half-way to set the focus, then continue pressing completely down to take the picture.

This setting remains until you change the Mode dial or turn off the camera.

Available flash settings: Auto, Flash Off, Fill Flash, Red-eye Default flash setting: Off Camera returns to default: When you change the mode dial or turn off

the camera.

Chapter 2

Setting Picture Quality

Use the Quality setting to select a picture resolution.

1 In any Still mode, press the Menu button.

2 Press to highlight Quality , then

press the OK button.

3 Press to highlight an option:

Best (5.0 MP)—for printing up to 20 x 30 in. (50 x 75 cm); pictures are highest resolution and largest file size.

appears on the status bar.

Best (3:2) (4.5 MP)—for

4 Press the OK button. 5 Press the Menu button to exit the menu.

This setting remains until you change it.

printing up to 20 x 30 in. (50 x 75 cm); ideal for printing to the Kodak EasyShare printer dock 4000 and other printing solutions; optimal setting for 4 x 6 in. (10 x 15 cm) prints.

appears on the status bar.

Better (3 MP)—for printing up to 11 x 14 in. (28 x 36 cm); pictures are medium resolution with smaller file size.

appears on the status bar.

Good (1.2 MP)—for emailing or screen display; pictures are lowest resolution and smallest file size.

appears on the status bar.

Chapter 2

Placing the Date on Pictures

Use the Date Stamp setting to imprint the date on your pictures.

1 Make sure the camera clock is set to the correct date (page 8). 2 In any Still mode, press the Menu button. 3 Press to highlight Date Stamp , then press the OK button.

4 Press to highlight an option, then

press the OK button.

5 Press the Menu button to exit the menu.

The current date is printed in the bottom right corner of new pictures. This setting remains until you change it.

Chapter 2

Setting the Orientation Sensor

If you rotate the camera to take a picture (for example, a portrait shot), the Orientation Sensor rotates the picture so that it is displayed correct side up during Quickview and Review.

The Orientation Sensor is turned on as the default. You can turn it off so that pictures are displayed in their original orientation.

NOTE: When your subject is above or below you (such as pictures of an object

in the sky, on the ground, or when pointing down at small objects on a table), turn off the Orientation Sensor so that pictures are not rotated unnecessarily.

1 In any Still mode, press the Menu button. 2 Press to highlight Orientation Sensor , then press the OK

button.

3 Press to highlight On or Off, then

press the OK button.

4 Press the Menu button to exit the menu.

This setting remains until you change it.

3 Taking Videos

Use the Video mode to take videos or to customize video-taking settings. Before you take a video, make sure your picture storage location is set the way you want it (see page 11).

NOTE: Zoom and flash are not available in Video mode.

Taking a Video

1 Turn the Mode dial to Video .

A live image, the status bar, and the approximate recording time available appear on the camera screen.

2 Use the viewfinder or camera screen to

frame your subject.

NOTE: To conserve battery power, press the OK

button to turn off the camera screen.

3 Press the Shutter button using the method that you prefer:

m Press and release—press the Shutter button completely down and

release within 2 seconds. Press the Shutter button again to stop recording.

m Press and hold—continue pressing and holding the Shutter button

completely down. Release the Shutter button to stop recording.

The ready light blinks green and the red Self Timer light glows red while the camera is recording. Recording stops when you release the shutter button or when the current storage location is full.

NOTE: See page 93 for video storage capacities.

Chapter 3

Del

Quickview—Reviewing the Video Just Taken

After you take a video, the camera screen displays the first frame of the video for approximately 5 seconds. While the frame is displayed, you can:

ete

m Play it: Press the OK button. Press OK again

are

to pause the video. Press to adjust the volume.

m Share it: Press the Share button to tag the

video for email or as a Favorite (see

page 45).

m Delete it: Press the Delete button while the

video and are displayed. To save battery power, you can turn off the

Quickview feature (see page 50) so that the

video is not displayed on the camera screen after you take it.

Using the Optical Zoom

Use Optical Zoom to get up to 3X closer to your subject. Optical zoom is effective when the lens is no closer than 24 in. (0.6 m) to the subject.

NOTE: You can change Optical Zoom before (but not during) video recording.

1 Use the viewfinder or camera screen to

frame your subject.

2 Press Telephoto (T) to zoom in. Press Wide

Angle (W) to zoom out.

The viewfinder or camera screen displays the zoomed image.

3 Press the Shutter button to take the video.

Wide Angle

Telephoto

Chapter 3

Putting Yourself in the Video

The Self Timer creates a 10-second delay between the time you press the Shutter button and the time video recording begins.

Turn on the Self Timer:

1 Turn the Mode dial to Video , then

press the Menu button.

2 Press to highlight Self Timer ,

then press the OK button.

3 Press to highlight On, then press the

OK button.

4 Press to highlight an option, then

press the OK button: Unlimited—records until you stop

recording or until storage is full. Seconds—records for the specified time

or until storage is full.

5 Press the OK button to return to the menu. 6 Press the Menu button to exit the menu.

NOTE: If the current storage location does not have adequate space, some

video length options are not displayed. See page 93 for video storage capacities.

Self Timer

light

Chapter 3

Take the video:

1 Place the camera on a flat surface or use a

tripod.

2 Compose the scene, then press the Shutter

button completely down. Move into the scene.

The red Self Timer light blinks slowly for 8 seconds, quickly for 2 seconds, then stays on while the video is recording.

3 To stop recording before the specified time,

press the Shutter button.

The Self Timer turns off after you take the video.

4 Reviewing Pictures and

Videos

Press the Review button to view and work with pictures and videos that are stored in internal memory or on a card. Remember, press the Shutter button to take a picture anytime, even in Review.

Viewing Pictures and Videos

1 Press the Review button.

The camera screen displays the last

Review

picture or video taken.

The icons displayed with each picture indicate the applied features. See

Checking Camera Status Icons, page 9.

2 Press to scroll backward or forward

through pictures and videos. (For fast scrolling, press and hold . Fast-scrolling images appear in the center of the screen.)

3 Press the Review button to exit Review.

NOTE: Pictures taken at the Best (3:2) quality

setting are displayed at a 3:2 aspect ratio, as shown, with a black bar at the top of the screen.

Chapter 4

Playing a Video

m To play a video, press the OK button. To

pause, press the OK button during playback.

m To adjust the volume, press during

playback.

m To rewind a video, press during playback.

To play the video, press the OK button.

m To go to the previous or next picture or

video, press while no video is

playing.

Deleting Pictures and Videos

1 Press the Review button. 2 Press to locate a picture or video, then press the Delete button.

3 Press to highlight an option, then

press the OK button: PICTURE or VIDEO—deletes the

displayed picture or video.

EXIT—exits the Delete screen. ALL—deletes all pictures and videos from

your current storage location.

NOTE: Protected pictures and videos cannot be

OK Delete

4 After deleting, press to stay in delete mode and scroll to different

pictures and videos. To exit Delete, press the Delete button.

deleted in this manner. Remove protection before deleting (see

page 40).

Review Menus

Magnify (page 39) Copy (page 43)

Chapter 4

Protect (page 40) Video Date Display

Image Storage(page 11) Picture Info(page 44)

Slide Show (page 41) Setup Menu (page 49)

(page 44)

Magnifying Pictures

Use the Magnify feature to zoom in to different areas of a picture.

1 Press the Review button, then locate a picture.

2 To magnify at 2X, press the OK button. (Or

press the Menu button, highlight Magnify, then press the OK button.) To magnify at 4X, press the OK button again.

The picture is magnified. The Magnify icon and the magnification value are displayed.

3 Press to navigate to different parts of the picture. 4 Press the OK button to redisplay the picture at the 1X (original) size. 5 Press to locate a different picture, or press the Review button to exit

Review mode.

Chapter 4

Protecting Pictures and Videos From Deletion

1 Press the Review button, then locate the picture or video to protect. 2 Press the Menu button.

Protect icon

4 To remove protection, press the OK button again. 5 Press the Menu button to exit the menu.

CAUTION:

CAUTION:CAUTION:

Formatting internal memory or SD/MMC card deletes all (including protected) pictures, videos, and email addresses.

3 Press to highlight Protect , then

press the OK button.

The picture or video is protected and cannot be deleted. The Protect icon appears with the protected picture or video.

Chapter 4

Running a Slide Show

Use the Slide Show to display your pictures and videos on the camera screen. To run a slide show on a television or on any external device, see page 42.

Starting the Slide Show

1 Press the Review button, then press the Menu button. 2 Press to highlight Slide Show , then press the OK button.

3 Press to highlight Begin Show, then

press the OK button.

Each picture and video is displayed once, in the order in which you took them. Then the camera returns to the menu.

4 To cancel the Slide Show, press the OK

button.

Changing the Slide Show Display Interval

The default interval setting displays each picture for 5 seconds. You can increase the display interval to up to 60 seconds.

1 On the Slide Show menu, press to

highlight Interval, then press the OK button.

2 Select a display interval.

To scroll through the seconds quickly, press and hold .

3 Press the OK button.

The interval setting remains until you change it.

Chapter 4

Running a Continuous Slide Show Loop

When you turn on Loop, the slide show is continuously repeated.

1 On the Slide Show menu, press to

highlight Loop, then press the OK button.

2 Press to highlight On, then press the

OK button.

When you start a slide show, it repeats until you cancel it by pressing the OK button or until battery power is exhausted. The Loop setting remains until you change it.

Displaying Pictures and Videos on a Television

You can display pictures and videos on a television, computer monitor, or any device equipped with a video input. (Image quality on a television screen may not be as good as on a computer monitor or when printed.)

NOTE: Ensure that the Video Out setting (NTSC or PAL) is correct (see

page 52).

1 Connect the audio/video cable (included)

Video out

NOTE: The slide show stops if you connect or disconnect the cable while a slide

show is running.

from the camera video-out port to the television video-in port (yellow) and audio-in port (white). Refer to your television user’s guide for details.

The camera screen turns off; the television screen acts as the camera display.

2 Review pictures and videos on the television

screen.

Chapter 4

Copying Pictures and Videos

You can copy pictures and videos from a card to internal memory or from internal memory to a card.

Before you copy, make sure that:

m A card is inserted in the camera. m The camera’s picture storage location is set to the location from which you

are copying. See Choosing Internal Memory or SD/MMC Card, page 11.

Copy pictures or videos:

1 Press the Review button, then press the Menu button. 2 Press to highlight Copy , then press the OK button.

3 Press to highlight an option:

PICTURE or VIDEO—copies the current picture or video.

EXIT—returns to the Copy screen. ALL—copies all pictures and videos from

your selected storage location to the other location.

4 Press the OK button.

A progress bar monitors the copy process until copy is complete. (For information on picture numbering, see page 94.)

NOTE:

m Pictures and videos are copied, not moved. To remove pictures and videos

from the original location after they are copied, delete them (see page 38).

m Tags that you applied for print, email, and Favorites are not copied.

Protection settings are not copied. To apply protection to a picture or video, see page 40.

Chapter 4

Displaying Video Date

To display the capture date and time (only during video playback on the camera):

1 Press the Review button, then press the Menu button. 2 Press to highlight Video Date Display, then press the OK button.

3 Press to highlight an option, then

press the OK button.

4 Press the Menu button to exit the menu.

The capture date and time appear during video playback on the camera. This setting remains until you change it.

Viewing Picture/Video Information

1 Press the Review button, then press the Menu button.

2 Press to highlight About, then press

the OK button.

Information about the picture or video is displayed.

3 To view information on the next or previous

picture or video, press . Press the Menu button to exit the menu.

5 Tagging Pictures and Videos

The Share button lets you “tag” your pictures and videos. When they are transferred to your computer, you can share:

Tagged Pictures

m By print m By email m As Favorites, for easy organization on your computer

Tagged Videos

m By email m As Favorites

Share icons

Print (page 46)

Email (page 47)

Favorite (page 48)

When Can I Tag My Pictures and Videos?

Press the Share button to tag pictures and videos:

m Just after you take them, during Quickview (see page 21 and page 34) m After pressing the Review button (see page 37)

NOTE: Tags remain until removed. If a tagged picture or video is copied, the

tag is not copied. For details on organizing, printing, or emailing, click the Help button in the Kodak EasyShare software.

Chapter 5

Tagging Pictures for Printing

* To tag all pictures in the storage location, highlight Print All, press the OK button, then indicate the number of copies as described above. Print All is not available in Quickview.

To remove the print tagging for all pictures in the storage location, highlight Cancel Prints, then press the OK button. Cancel Prints is not available in Quickview.

Printing Tagged Pictures

To print digital pictures, see page 60.

1 Press the Review button, then locate a

picture.

2 Press the Share button. Press to

highlight Print , then press the OK button.*

3 Press to select the number of copies

(0-99). Zero removes the tag for that picture.

4 Press the OK button. Press the Share button

to exit the Share menu.

The Print icon appears on the status bar. The default quantity is one. (To change the default, see page 50.)

Chapter 5

Tagging Pictures and Videos for Emailing

First, use Kodak EasyShare software to create an email address book on your computer. Then, copy up to 32 email addresses to the camera’s internal memory. See the Quick Start Guide or Kodak EasyShare software Help for details.

4 To remove a selection, highlight a checked address and press the OK

button. To remove all email selections, highlight Clear All.

5 Press to highlight Exit, then press the OK button.

Your selections are saved.

6 Press the Share button to exit the Share menu.

Emailing Tagged Pictures and Videos

When you transfer the tagged pictures and videos to your computer, the Kodak EasyShare software email screen opens and lets you immediately send the pictures and videos to the addresses you specified.

For details on address books and emailing, click the Help button in the Kodak EasyShare software.

1 Press the Review button, then locate a

picture or video.

2 Press the Share button. Press to

highlight Email , then press the OK button.

3 Press to highlight an email address,

then press the OK button. To send the picture to more than one person, repeat step 3 for each address.

Selected addresses are noted with a check mark; the email icon appears on the status bar.

Chapter 5

Tagging Pictures and Videos as Favorites

1 Press the Review button, then locate a

FPO

Using Favorites On Your Computer

When you transfer tagged pictures and videos to your computer, you can retrieve, organize, and label them by subject, date, event, or any category you choose.

For details, click the Help button in the Kodak EasyShare software.

picture or video.

2 Press the Share button. Press to

highlight Favorite , then press the OK button.

The Favorite icon appears on the status bar.

3 To remove the tag, press the OK button

again.

4 Press the Share button to exit the Share

menu.

6 Customizing Your Camera

Settings

Use Setup to customize camera settings according to your preferences.

Accessing Setup Mode/Menus

1 In any mode, press the Menu button. 2 Press to highlight Setup , then press the OK button.

Setup Menus

Default Print Quantity (page 50)

Quickview (page 50) Language (page 52)

Liveview (page 51)Format (page 53)

Shutter Sound (page 51) About (page 54)

Date & Time Set (page 8)

Video Out (page 52)

Chapter 6

Changing the Print Quantity Default

The Default Print Quantity setting determines the value that is displayed on the Share Print screen (page 46). The default value is 1.

1 Press the Menu button. 2 Press to highlight Setup , then press the OK button. 3 Highlight Default Print Quantity , then press the OK button.

4 Press to indicate the new default

quantity, then press the OK button.

5 Press the Menu button to exit the menu.

This setting remains until you change it.

Turning Off Quickview

After you take a picture or video, Quickview displays it on the camera screen for approximately 5 seconds (see page 21 and page 34). To save battery power, turn off Quickview.

1 Press the Menu button. 2 Press to highlight Setup , then press the OK button. 3 Press to highlight Quickview , then press the OK button.

4 Press to highlight Off, then press the

OK button.

5 Press the Menu button to exit the menu.

The picture is not displayed on the camera screen after you take it. To see the picture or video, press the Review button. This setting remains until you change it.

Chapter 6

Turning On Liveview In Still Modes

The Liveview feature lets you use the camera screen as a viewfinder (see

page 20). Press the OK button to turn the camera screen on and off.

NOTE: Liveview quickly depletes battery power; use it sparingly. The

Liveview default setting is On in Close-up and Video modes.

1 Press the Menu button. 2 Press to highlight Setup , then press the OK button. 3 Press to highlight Liveview , then press the OK button.

4 Press to highlight On, then press the

OK button.

The live image is displayed whenever the camera is on. Press the OK button to manually turn it off and on.

5 Press the Menu button to exit the menu.

This setting remains until you change it.

Turning Off the Shutter Sound

1 Press the Menu button. 2 Press to highlight Setup , then press the OK button. 3 Press to highlight Shutter Sound , then press the OK button.

4 Press to highlight Off, then press the

OK button.

No sounds plays when a picture is taken.

5 Press the Menu button to exit the menu.

This setting remains until you change it.

Chapter 6

Setting Video Out

Video Out matches the camera’s video signal to the standard for your location. Video Out must be set correctly to run a slide show on a television or other external device (see page 41).

1 Press the Menu button. 2 Press to highlight Setup , then press the OK button. 3 Press to highlight Video Out , then press the OK button.

4 Press to highlight an option:

NTSC—used in most countries except those in Europe and China. The United States and Japan use NTSC.

PAL—used in Europe and China.

5 Press the OK button to accept the change.

6 Press the Menu button to exit the menu.

This setting remains until you change it.

Selecting a Language

You can display menus and screen messages in different languages.

1 Press the Menu button. 2 Press to highlight Setup , then press the OK button. 3 Press to highlight Language , then press the OK button.

4 Press to highlight an option, then

press the OK button.

5 Press the Menu button to exit the menu.

Text is displayed in the selected language. This setting remains until you change it.

Chapter 6

Formatting Internal Memory or SD/MMC Card

CAUTION:

CAUTION:CAUTION:

Formatting erases all pictures and videos, including those that are protected. Removing a card during formatting may damage the card.

1 Press the Menu button. 2 Press to highlight Setup , then press the OK button. 3 Press to highlight Format , then press the OK button.

4 Press to highlight an option:

MEMORY CARD—deletes everything on the card; formats the card.

CANCEL—exits without making a change. INTERNAL MEMORY—deletes everything

in 32 MB internal memory.

5 Press the OK button. 6 Press to highlight Continue Format, then press the OK button.

When the formatting is complete, the Setup menu appears.

Chapter 6

Viewing Camera Information

1 Press the Menu button. 2 Press to highlight Setup , then press the OK button.

3 Press to highlight About , then

press the OK button.

The camera model and the current firmware version appear.

4 Press the Menu button to exit the menu.

7 Installing the Software

NOTE: This product was designed and manufactured to existing industry

standards as of this product's release date. Future hardware and operating systems may or may not support this Kodak product. If you experience compatibility issues between this product and future hardware products or operating systems, contact your hardware or operating system manufacturer or retailer.

Windows System Requirements

m Personal computer running Windows 98, 98SE, ME, 2000, or XP OS m 233 MHz processor or greater (300 MHz recommended for Windows

2000 and XP)

m 64 MB of available RAM (128 MB recommended) m 100 MB of available hard disk space m CD-ROM drive m Built-in USB port m Color monitor with a minimum resolution of 800 x 600 pixels; High Color

(16-bit) or True Color (24-bit) recommended

m Internet access for online printing and emailing

Chapter 7

Mac OS X System Requirements

m Macintosh computer with a G3 or G4 processor m Mac OS 10.1.2, minimum m 128 MB of available RAM m 200 MB of available hard disk space m CD-ROM drive m Built-in USB port m Color monitor with a minimum resolution of 800 x 600 pixels; thousands

or millions of colors recommended

m Internet access for online printing and emailing

Mac OS 8.6 and 9.x System Requirements

m PowerPC-based Macintosh computer m Mac OS 8.6/9.x m 64 MB of available RAM m 200 MB of available hard disk space m CD-ROM drive m Built-in USB port m Color monitor with a minimum resolution of 800 x 600 pixels; thousands

or millions of colors recommended

m Internet access for online printing and emailing

NOTE: Mac OS 8.6 and 9.x do not support the Share button functions. Mac OS

X is recommended for full functionality.

Chapter 7

Install the Software

For information on the software applications included on the Kodak EasyShare software CD, click the Help button in the Kodak EasyShare software.

NOTE: If you computer is running Windows 2000, Windows XP Pro, or

Mac OS X operating system, you need administrator privileges to install software. See your computer user’s guide.

CAUTION:

CAUTION:CAUTION:

Install Kodak EasyShare software BEFORE connecting the camera or optional camera dock to the computer. Failure to do so may cause the software to load incorrectly.

1 Before you begin, close all software

applications that are open on your computer (including anti-virus software).

2 Place the Kodak EasyShare software CD into

the CD-ROM drive.

3 Load the software:

Windows OS-based computer—if the install window does not appear, choose Run from the Start menu and type d:\setup.exe where d is the drive letter that contains the CD.

Mac OS 8.6 or 9.x—on the install window, click Continue.

Mac OS X—double-click the CD icon on the desktop, then click the Install icon.

Chapter 7

Follow the on-screen instructions to install the software.

m Windows OS-based computers—select Complete to automatically

install the most commonly used applications. Select Custom to choose the applications you wish to install.

m Mac OS 8.6 or 9.x—select Easy to automatically install the most

commonly used applications.

m Mac OS X—follow the on-screen instructions.

NOTE: When prompted, take a few minutes to electronically register your

camera and software. This lets you receive information regarding software updates and registers some of the products included with the camera. You must be connected to your Internet service provider to register electronically.

To register later, see www.kodak.com/go/register.

5 If prompted, restart the computer. If you turned off anti-virus software,

turn it back on. See the anti-virus software manual for details.

8 Connecting to the Computer

CAUTION:

CAUTION:CAUTION:

Install Kodak EasyShare software before connecting the camera or optional dock to the computer. Failure to do so may cause the software to load incorrectly.

Connecting to the Computer

You can transfer pictures and videos from the camera to the computer using either the provided USB cable or the optional Kodak EasyShare camera dock or camera dock II. See page 61 for connecting with a camera dock.

Transferring Pictures With the USB Cable

1 Turn off the camera. 2 Plug the labeled end of the USB cable

into the labeled USB port on your computer. See your computer User’s Guide for details.

3 Plug the other end of the USB cable into the

labeled USB port on the camera.

An optional 3-volt AC adapter is available to save battery power (see page 95).

4 Turn on the camera.

Kodak EasyShare software prompts you through the transfer process.

NOTE: You can also use a Kodak multi-card reader or Kodak SD multimedia

card reader-writer to transfer your pictures. Purchase accessories at a dealer of Kodak products. See www.kodak.com/go/dx4530accessories.

Chapter 8

Printing Pictures From Your Computer

For details on printing pictures from your computer, click the Help button in the Kodak EasyShare software.

Printing From an Optional SD/MMC Card

m Automatically print tagged pictures when you insert your card into a printer

with an SD/MMC slot. See your printer User’s Guide for details.

m Make prints at an SD/MMC-capable Kodak picture maker. (We suggest

contacting a location prior to visiting.)

m Take the card to your local photo retailer for professional printing.

Ordering Prints Online

Kodak EasyShare print service (provided by Ofoto www.ofoto.com) is just one of the many great online print services offered in the Kodak EasyShare software. You can easily:

m Upload your pictures. m Edit, enhance, and add borders. m Store pictures, and share them with family and friends. m Order high-quality prints, photo greeting cards, frames, and albums—and

have them delivered to your door.

9 Using the Optional Camera

Dock II

The Kodak EasyShare camera dock II makes it easy to transfer your pictures and videos to the computer.

The camera dock is also a rapid battery charger for the included Kodak EasyShare Ni-MH rechargeable battery, and supplies power to the camera. (Only the battery can be recharged in the camera dock.) To keep the battery charged, store your camera in the camera dock.

Purchase accessories at a dealer of Kodak products. See

www.kodak.com/go/dx4530accessories.

CAUTION:

CAUTION:CAUTION:

Install the software from the Kodak EasyShare software CD before connecting the camera or dock to the computer. Failure to do so may cause the software to load incorrectly.

Camera Dock Package Contents

1 AC power adapter, 7V

Some AC adapters may be different from the one pictured.

2 Kodak EasyShare Ni-MH rechargeable

battery

3 Universal insert 4 Camera dock 5 Quick Start Guide (not shown)

Chapter 9

Installing the Camera Insert

Kodak EasyShare digital cameras are packaged with a custom camera insert, which is used to fit the camera to the camera dock.

1 Place the front tabs on the custom insert

into the slots in the camera dock cavity.

2 Fit the insert down into the cavity and snap

the insert into place.

If You Do Not Have the Custom Insert

If you do not have the custom insert that was included with your camera, use the universal insert that is included with the camera dock II.

NOTE: The universal insert works with all Kodak EasyShare cameras. However,

it may not match the perfect fit that the custom camera insert provides. Take extra care when placing the camera in the camera dock so that the dock connector and pins are not damaged.

Purchase accessories at a dealer of Kodak products. See

www.kodak.com/go/dx4530accessories.

Chapter 9

Connecting the Camera Dock

After the Kodak EasyShare software is loaded (see page 55), connect the camera dock to your computer and to an external power source. You need:

m The USB cable included with your camera m The AC power adapter, 7V included with the camera dock

CAUTION:

CAUTION:CAUTION:

Use only the 7V AC adapter included with the camera dock. Other adapters may cause damage to your camera, camera dock, or computer. Make sure the camera is not in the camera dock when connecting the dock to power and to the computer. Do not plug the 7V adapter into the camera.

1 Plug the labeled end of the USB cable

into the labeled USB port on your computer. See your computer User’s Guide for details.

2 Plug the other end of the USB cable into the

square USB connector on the back of the camera dock.

3 Plug the 7V AC adapter into the round

power connector on the back of the camera dock and into a power outlet.

Your AC adapter may be different from the one pictured or may have additional

plugs. Use the plug that accommodates

your type of power outlet.

Leave the camera dock connected to the computer for easy transferring of pictures and videos and for charging the battery.

Chapter 9

Installing the Battery in the Camera

The camera dock will only charge the Ni-MH battery (not other batteries).

1 Turn off the camera.

2 Open the battery door.

3 Install the battery as shown.

CAUTION:

CAUTION:CAUTION:

The battery can only be inserted into the camera as shown. If the battery does not install, reposition it and try again. DO NOT FORCE IT; doing so can damage your camera.

4 Close the battery door.

IMPORTANT: The battery is not charged when you receive it. See

page 66 for charging instructions.

Chapter 9

Docking the Camera

To transfer pictures and videos from the camera to the computer, or to charge the battery:

1 Tur n off the camera. 2 On the camera bottom, slide the connector

cover open.

Dock connector door

3 Place the camera in the camera dock and

push down to seat the connector.

The Power/Transfer light glows green when the camera is properly seated.

The camera is now powered by the

Connector

Powe r/ Transfer light

NOTE: If a Kodak EasyShare Ni-MH rechargeable battery is installed in the

camera, the camera dock immediately begins charging.

camera dock instead of the camera batteries.

Chapter 9

Charging the Battery

The battery is not charged when you receive it.

1 Tu rn off the camera. 2 Make sure the battery is installed in the camera (see page 64). 3 Place the camera in the camera dock (see page 65).

m Charging begins immediately. m The three green charging lights monitor the charging status:

Charging Lights on Dock II

battery low battery partially charged battery fully charged

m Full charging takes about 2.5 hours. After the battery is fully charged,

leave the camera in the camera dock to maintain the full charge.

m Charging stops if you turn on the camera. If the camera is left in the

camera dock with the power on, charging resumes when the camera enters Auto Power-off (see page 95).

NOTE: The camera dock only charges the provided Kodak EasyShare Ni-MH

rechargeable battery. If you place the camera in the camera dock with any other type of batteries, rechargeable or not, no charging takes place. For further Troubleshooting information, see page 69.

Chapter 9

Transferring Pictures and Videos

To transfer pictures and videos from your camera to your computer:

1 Place the camera in the camera dock. The

camera can be on or off.

If the battery is being charged, charging pauses, then resumes after pictures and

Connect Power/Transfer light

videos are transferred.

2 Press the Connect button.

The Power/Transfer light blinks green while the pictures are transferring.

3 For details on printing and emailing, see the Quick Start Guide or the

Kodak EasyShare software Help.

NOTE: After transferring pictures and videos, leave the camera in the camera

dock. Eight minutes after the transfer is complete, the camera dock resumes charging as necessary.

Caution When Using a Tripod

Do not connect a tripod to the camera dock. Remove the camera from the camera dock and connect the tripod directly to the camera.

Chapter 9

Earlier Camera Dock Model

If you have the Kodak EasyShare camera dock, not the camera dock II, the functionality is exactly the same as described in this chapter. The only difference is that the earlier camera dock has one indicator light.

Indicator light status: Steady green—camera is properly seated

in the camera dock. Blinking green— pictures and videos are

Indicator light

transferring.

Steady red—battery is charging. Blinking red—error condition.

IMPORTANT: When using the earlier camera dock, several

discharge/recharge cycles may be necessary so that the battery holds a full charge.

10Troubleshooting

When you have questions about your camera or camera dock II, start here. Additional technical information is available in the ReadMe file located on the Kodak EasyShare software CD. For updates to Troubleshooting information, see www.kodak.com/go/dx4530support.

Troubleshooting—Camera

Camera Problems

Problem Cause Solution

Camera does not turn on.

Pictures remaining number does not decrease after taking a picture.

Battery is not properly installed.

Battery is not charged.

Lens cap is on, preventing lens from extending.

The picture does not take up enough space to decrease the number.

Remove and reinstall the batteries (page 5).

Replace (page 5) or recharge the batteries (page 66).

Remove the lens cap.

The camera is operating normally. Continue taking pictures.

Chapter 10

Problem Cause Solution

Rechargeable Ni-MH battery pack has a short life.

There is dirt on the battery contacts.

The battery needs to be conditioned.

Wipe the battery contacts with a clean, dry cloth before loading batteries in the camera.

1 Place the camera on the

camera dock. (See page 61.)

2 For:

EasyShare camera dock—

When the charge light turns green, remove the camera from the dock. After a minimum of 5 minutes, place the camera back on the dock.

EasyShare camera dock II—

When all 3 lights turn green, remove the camera from the dock. After a minimum of 5 minutes, place the camera back on the dock

3 Repeat steps 1 and 2 until the

combined charge time equals a minimum of 2 hours.

Camera does not turn off; lens does not retract.

Alkaline batteries were installed in the camera.

Do not use alkaline batteries. Turn the Mode dial off, remove the alkaline batteries, and replace with an approved battery type (page 13).

If the Mode dial is not off when you replace the batteries, the camera may not turn back on. In that case, turn the Mode dial off, then back on.

Chapter 10

Problem Cause Solution

Shutter button doe s not work.

Stored pictures are damaged.

Part of the picture is missing.

Camera is not turned on.

The camera is processing a picture; the ready light (near the viewfinder) is blinking.

The card or internal memory is full.

The card was removed when the ready light was blinking.

Something was blocking the lens when the picture was taken.

Your eye or the picture was not centered correctly in the viewfinder or camera screen.

Turn on the camera (page 7).

Wait until the light stops blinking before attempting to take another picture.

Transfer pictures to your computer (page 59), delete pictures from the camera (page 38), switch storage locations (page 11), or insert a card with available memory (page 10).

Make sure the ready light is not blinking before removing the card.

Keep hands, fingers, or other objects away from the lens when taking pictures.

Leave space around subject when centering picture in viewfinder or camera screen.

Chapter 10

Problem Cause Solution

In Review mode, you do not see a picture (or the expected picture) on the camera screen.

In Review mode, pictures are displayed as black screens.

Picture orientation is not accurate.

Camera freezes up when a card is inserted or removed.

The camera may not be accessing the correct storage location.

Lens cap is on, preventing lens from extending.

The camera sensed that it was rotated or tilted while the picture was taken.

Camera detects an error when the card was inserted or removed.

Check the picture storage location setting (page 11).

Remove the lens cap.

Set the Orientation Sensor (page 31). Turn off the Orientation Sensor when your subject is above or below you (such as in the sky or on the floor).

Turn the Mode dial off, then back on. Make sure the camera is turned off before inserting or removing a card.

Chapter 10

Problem Cause Solution

Picture is too dark. Flash is not on or

did not function. The subject is too

far away fo r the flash to have an effect.

The subject is in front of a bright light (backlit).

Lighting condit ion is too dark.

Picture is too light. The flash is not

needed. The subject was too

close when the flash was used.

The light sensor is covered.

Lighting condit ion is too bright.

Turn on the flash (page 24).

Move so there is no more than 11.2 ft (3.4 m) between the camera and the subject; 6.6 ft (2.0 m) in Telephoto.

Use Fill flash (page 24) or change your position so the light is not behind the subject.

Increase Exposure Compensation (page 27) or Long Time Exposure (page 28).

Change to Auto flash (page 24).

Move so there is at least 2.0 ft (0.6 m) between the camera and the subject.

Hold the camera so your hands or other objects do not cover the light sensor.

Decrease exposure compensation (page 27).

Chapter 10

Problem Cause Solution

Picture is not clear. The lens is dirty. Clean the lens (page 92).

Slide show does not run on external video device.

Subject too close when taking picture.

Subject or the camera moved while the picture was taken.

The subject is too far away fo r the flash to be effective.

Video Out setting is incorrect.

External device is set incorrectly.

Move so there is at least 2.0 ft (0.6 m) between the camera and the subject, or at least 2.8 in. (7.0 cm) in Close-up mode.

Hold the camera steady while taking the picture.

Move so there is no more than 11.2 ft (3.4 m) between the camera and the subject; 6.6 ft (2.0 m) in Telephoto.

Adjust the camera Video Out setting (NTSC or PAL,

page 52).

Refer to the external device’s user’s guide.

Chapter 10

Camera/Computer Communications

Problem Cause Solution

The computer cannot communicate with the camera.

Cannot transfer pictures to computer. The Add New Hardware Wizard cannot locate drivers.

Camera power is off. Turn on the camera

Battery is not charged. Replace (page 5) or recharge

Some Advanced Power Management utilities on laptops can turn off ports to save battery life.

USB cable is not securely connected.

Software is not installed. Install the software

The Battery Monitor or similar software runs constantly.

Software is not installed on computer.

(page 7).

the batteries (page 66). See the Power Management

section of your laptop user’s guide to disable this feature.

Connect cable to camera and computer port (page 59).

(page 55). Close that software before

starting the Kodak EasyShare software.

Disconnect USB cable (i f using camera dock, disconnect cable and remove camera from dock). Install Kodak EasyShare software (page 55).

Chapter 10

SD/MMC Cards and Internal Memory

Problem Cause Solution

The camera does not recognize your SD/MMC card.

Camera freezes up when a card is inserted or removed.

Memory card full. Storage is full. Transfer pictures and videos to

Card may not be SD/MMC certified.

Card may be corrupt. Reformat the card (page 53).

No card is inserted in camera or card is not fully inserted.

Camera detects an error when the card was inserted or removed.

The maximum number of files or folders is reached (or other directory concern).

Purchase a certified SD/MMC card (page 10).

Caution: Formatting erases all pictures and videos, including protected files.

Insert a card into the card slot, then push to seat the connector (page 10).

Turn the Mode dial off, then back on.

Make sure the camera is off when inserting or removing a card.

the computer, then delete them from the camera.

Transfer pictures and videos to the computer, then format the card or internal memory (page 53).

Caution: Formatting a card erases all pictures and videos, including protected files. (Formatting internal memory also erases email addresses. To restore addresses, see Kodak EasyShare software Help.)

Chapter 10

Camera Screen Messages

Message Cause Solution

No images to display There are no pictures in

Memory card requires formatting

Memory card cannot be read (Please format card or insert another card)

Internal memory requires formatting

Internal memory cannot be read (Please format internal memory)

No memory card (Files not copied)

Not enough space to copy files (Files not copied)

Read only card, change to internal memory to capture

the current storage location.

Card is corrupted or formatted for another digital camera.

Camera internal memory is corrupted.

No card in the camera. Your pictures were not copied.

There is not enough space in the location you are copying to (internal memory or the card).

Card in the camera is write-protected.

Change your picture storage location setting (page 11).

Insert a new card (page 10) or format the card (page 53).

Format the internal memory (page 53).

Insert a card.

Delete pictures from the location you are copying to (page 38), or insert a new card.

To take a picture, insert a new card or change storage location to internal memory (page 11).

Chapter 10

Message Cause Solution

Card is protected (Reset switch on card)

Card is locked (Insert a new card)

Card is unusable (Insert a new card)

Recording stopped. Record in internal memory (Card speed is slow)

Memory card is full (Cannot save Share tagging)

Internal memory is full (Cannot save Share tagging)

Date/Time entry screen appears automatically

Switch on SD card is in write-protect position.

Card is write-protected. To take a picture, insert a

Card is slow, corrupted, or unreadable.

Card cannot be used in the camera.

There is no space remaining.

This is the first time you turned on the camera; or the batteries have been removed for an extended period of time; or the batteries are exhausted.

Reset the switch as shown on camera screen.

new card or change storage location to internal memory (page 11).

Insert a new card (page 10).

Change storage location to internal memory (page 11).

Insert a new card (page 10), transfer pictures (page 59), or delete pictures (page 38).

Insert a card (page 10), transfer pictures (page 59), or delete pictures (page 38).

Reset the clock (page 8).

Chapter 10

Message Cause Solution

Unrecognized File Format

High camera temperature. (Camera will be turned off.)

Memory Card is full There is no more space

Internal Memory is full There is no more space

No Address Book in Camera

Other error code An error is detected. Turn the Mode dial off,

Camera cannot read the picture format.

The internal temperature of the camera is too high for the camera to operate. The viewfinder light glows red and the camera turns off in five seconds.

on the card in the camera.

in the camera’s internal memory.

Address book has not been copied from the computer to the camera.

Transfer the unreadable picture to the computer (page 59), or delete the picture (page 38).

Leave the camera off for several minutes, then turn it back on.

If the message reappears, repeat the sequence above until the message does not appear.

Delete pictures from the card (page 38), insert a new card, or change storage location to internal memory (page 11).

Delete pictures from the internal memory (page 38) or change storage location to Auto and insert card (page 10).

Create and copy address book from the computer. See Kodak EasyShare software Help.

then back on. If the error appears again, call for service.

Chapter 10

Camera Ready Light Status

Ready light

Problem Cause Solution

Ready light does not turn on and the camera does not work.

Ready light glows steady green.

Ready light blinks red. Batteries are low or

Camera is not turned on.

Batteries are exhausted.

Mode dial was on when batteries were reloaded.

Camera is on; ready to take a picture or video.

exhausted.

Card is too slow for Video mode.

Turn on the camera (page 7).

Replace (page 5) or recharge the batteries (page 66).

Turn Mode dial off, then back on.

The camera is operating normally.

Replace (page 5) or recharge the batteries (page 66).

Change your storage location to internal memory (page 11), or use a different card.

Chapter 10

Problem Cause Solution

Ready light glows steady red.

Ready light blinks green.

Ready light blinks yellow.

Camera’s internal memory or card is full.

Camera processing memory is full.

Your card is read-only.

Camera is starting up or picture is being saved.

Flash is not charged. Wait. Resume picture taking

Auto exposure or auto focus are not locked.

Transfer pictures to your computer (page 59), delete pictures from the camera (page 38), switch storage locations (page 11), or insert a card with available memory (page 10).

Wait. Resume picture taking when the light turns green.

Change your storage location to internal memory (page 11), or use a different card.

Camera is operating normally.

when the light stops blinking and turns green.

Release the Shutter button and recompose the picture.

Chapter 10

Troubleshooting—Camera Dock II

Camera Dock II Problems

Problem Cause Solution

Pictures are not transferred to the computer

AC adapter or USB cable is not securely connected.

Software is not installed.

Computer needs to be restarted.

Camera was removed from the camera dock during picture transfer.

Connect button was not pressed.

Check the connections (page 63).

Install the software (page 55).

Restart the computer and try again.

Replace the camera on the camera dock and press the Connect button.

Press the Connect button.

Chapter 10

Camera Dock II Light Status

Battery charging lights

Power/Transfer light

Camera Dock Power/Transfer Light Light Status Cause Comment

Light glows steady green

Light blinks green Pictures and videos are being

Light is off Camera is not properly

Camera Dock Charging Lights Light Status Cause Comment

No lights

One green light

Two green lights

Camera is properly seated in the camera dock.

The camera and camera dock are operating normally.

transferred to the computer.

Remove the camera and

seated in camera dock.

Charging has not started.

re-seat it (page 65).

The camera is not seated in the camera dock (page 65).

Camera is turned on. Turn off to begin charging.

Rechargeable battery is not installed in camera.

Battery is low. The camera is charging.

Battery is partially charged.

Chapter 10

Camera Dock Charging Lights Light Status Cause Comment

Battery is fully charged. Charging resumes when

Three green lights

Camera Dock Error Light Light Status Cause Comment

Battery is installed

One blinking red light

incorrectly. The battery or connector

pins are damaged. The camera and battery have

been exposed to very high or low temperatures.

necessary.

Reinstall the battery (page 64).

Check for damage.

Slowly return the camera and battery to room temperature.

11 Getting Help

Helpful Web Links

Help with Windows operating system and working with digital pictures

Help with your Kodak EasyShare DX4530 zoom digital camera

Download the latest camera software and firmware

Optimize your printer for truer, more vibrant colors

Get support for cameras, software, accessories, more

Purchase camera accessories www.kodak.com/go/dx4530accessories Register your camera www.kodak.com/go/register

www.kodak.com/go/pcbasics

www.kodak.com/go/dx4530support

www.kodak.com/go/dx4530downloads

www.kodak.com/go/onetouch

www.kodak.com/go/camerasupport

Help in this Manual

See Troubleshooting, page 69 for help with problems you may have with your camera, camera/computer connections, camera dock, or SD/MMC cards.

Software Help

Refer to the Quick Start Guide or Kodak EasyShare software Help.

Chapter 11

Telephone Customer Support

If you have questions concerning the operation of the software or camera, you may speak with a customer support representative.

Before You Call

Please have the camera or camera dock connected to your computer, be at your computer, and have the following information available:

Operating system __________________________________________ Processor speed (MHz) _____________________________________ Computer model __________________________________________ Amount of memory (MB) ____________________________________ Exact error message you received_______________________________ Version of installation CD________________________ Camera serial number______________________________________

Telephone Numbers

Australia 1800 147 701 Austria/Osterreich 0179 567 357 Belgium/Belgique 02 713 14 45 Brazil 0800 150000 Canada 1 800 465 6325 China 800 820 6027 Denmark/Danmark 3 848 71 30 Ireland/Eire 01 407 3054 Finland/Suomi 0800 1 17056 France 01 55 1740 77 Germany/Deutschland 069 5007 0035 Greece 00800 441 25605 Hong Kong 800 901 514 India 91 22 617 5823 Italy/Italia 02 696 33452 Korea 00798 631 0024 Netherlands/Nederland 020 346 9372 New Zealand 0800 440 786 Norway/Norge 23 16 21 33 Philippines 1 800 1 888 9600 Portugal 021 415 4125 Singapore 800 6363 036 Spain/Espana 91 749 76 53

Chapter 11

Sweden/Sverige 08 587 704 21 Switzerland/Schweiz/Suisse 01 838 53 51 Taiwan 0 080 861 008 Thailand 001 800 631 0017 UK 0870 243 0270 United States 1 800 235 6325 Outside the United States 585 726 7260 International Toll Line +44 131 458 6714 International Toll Fax +44 131 458 6962

For the most up-to-date listings, see

www.kodak.com/US/en/digital/contacts/DAIInternationalContacts.shtml

Kodak DX4530 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Front View

Product Overview

Back View

Side View

Top, Bottom View

Table of Contents

1 Getting Started

Install Software First

Need This User Guide in Larger Print?

What Can I Do With My Camera?

What Can I Do With My Pictures and Videos?

Package Contents

Attaching the Wrist Strap

Attaching the Lens Cap Strap

Adding Optional Lenses

Loading the Battery

Mode Dial Settings

Turning On the Camera

Changing the Display

Setting the Date and Time

Setting the Date & Time, First Time

Setting the Date & Time, Anytime

Checking Camera Status Icons

Status Icons (Top of Camera Screen)

Inserting an SD/MMC Card

Choosing Internal Memory or SD/MMC Card

Managing Your Storage Location Setting

Checking Your Storage Setting

Checking a Picture or Video’s Location

Important Battery Information

Kodak Battery Replacement Types/Battery Life

Extending Battery Life

Battery Safety and Handling

2 Taking Pictures

Taking Pictures in Auto Mode

Taking Pictures in Sport Mode

Taking Pictures in Night Mode

Taking Pictures in Landscape Mode

Taking Pictures in Close-up Mode

Liveview—Framing with the Camera Screen

Using the Viewfinder

Quickview—Reviewing the Picture Just Taken

Using the Auto Focus Framing Marks

Using the Optical Zoom

Using the Digital Zoom

Using the Flash

Flash Range

Turning On The Flash

Flash Settings In Each Mode

Other Flash Screen Information

Putting Yourself in the Picture

Setting Exposure Compensation

Setting Long Time Exposure

Setting Picture Quality

Placing the Date on Pictures

Setting the Orientation Sensor

3 Taking Videos

Taking a Video

Quickview—Reviewing the Video Just Taken

Using the Optical Zoom

Putting Yourself in the Video

Viewing Pictures and Videos

Playing a Video

Deleting Pictures and Videos

Review Menus

Magnifying Pictures

Protecting Pictures and Videos From Deletion

Running a Slide Show

Starting the Slide Show

Changing the Slide Show Display Interval

Running a Continuous Slide Show Loop

Displaying Pictures and Videos on a Television

Copying Pictures and Videos

Displaying Video Date

Viewing Picture/Video Information

5 Tagging Pictures and Videos
