Amplifier Power Harness
Subwoofer Power Harness
PRAMCQ13
Designed for 2013 – 20 17 Dodge® Ram vehicles with base audio
Not Compatible with 2018 and newer Dodge® Ram vehicles
Subwoofer
Amplifier
Subwoofer
Harness
Subwoofer
Amplifier
Alternate Amplifier
Bracket
Amplifier Harness
©2018 Stillwater Designs
PRAMCQ13-20180606
Wire Ties x 6
Bolt (only for solid rear bench seat)
Screw
Fuse x 2
2
Power H arness Routing
Fig 1
Insert terminals first.
any position.
Then
retainer
Fig 3
Insert
first
Then depress
Fig 4
Fig 2
1. Disconnect negative battery cable
2. Make sure the supplied fuses are not installed in the fuse holders of the subwoofer and
3. Route the both power harnesses toward the driver’s side factory firewall grommet and secure
4. Make a small incision in the grommet and pass the both power harnesses into the cabin. Fig.
5. Install the white three pin power connector on the amplifier power harness. Close the
6. Install the black two pin power connector on the subwoofer power harness by first inserting
amplifier power harness and connect the harnesses to the stud pictured in Fig. 1. Torque
stud nut to 14Nm (124in-lbs)
with the supplied wire ties.
2
retainer. Fig. 3
Note: The terminals are keyed so that they only install one way. If the terminal
doesn’t want to slide completely into the connector, it may need to be rotated 180
degrees. It does not matter which red wire goes in what position of the connector.
the terminal fully into the connector and then depressing the blue retainer. Fig. 4
Note: Make sure the blue retainer in the center of the connector is not depressed –
it should be flush with the front of the connector. If the retainer is depressed, the
terminal will not fully seat in the connector body. Make sure the terminal is installed
into position 1 on the connector body. There should be a block-out plug installed in
position 2 in order to prevent the terminal from being installed into the wrong
position on the connector.
close
terminal
Any wire can be in
blue retainer
3
Fig 8
Radio Removal – With Floor Console 2013-2015
Fig 5
Fig 6
Fig 7
Note: If vehicle is not equipped with a floor mounted center console, proceed to
step 11
7. Remove the rubber liner from the front of the console and remove the two screws beneath it.
Fig. 5
8. Using a panel removal tool, carefully pry up on the trim ring around the shifter and remove.
Fig. 6
9. Lift up on top console trim to remove. Fig. 7
Radio Removal – With Floor Console 2016-up
10. Remove the rubber liners in both storage trays.
Remove the three screws indicated in Fig. 8
Note: Do not attempt to remove the trim ring
as indicated in Fig. 6 on 2016 and newer
consoles
