INSTRUCTION MANUAL
VHF P25 TRANSCEIVER
TK-5210
UHF P25 TRANSCEIVER
TK-5310
700/800MHz P25 TRANSCEIVER
TK-5410
© B62-2155-00 (K, K2, K3, K4, K5, K6, K7)
09 08 07 06 05 04 03 02 01 00
Terminal Descriptions
Universal connector
It is possible to use a resin-based cover for the Universal connector.
No. Name
1 SSW Ext/Int Speaker Switch Input Hi: INT, Low: EXT I
2 SP+ BTL Output + for External Speaker Standard load 8 Ω O
3 SP- BTL Output – for External Speaker Standard load 8 Ω O
4 MSW Ext/Int MIC Switch Input Hi: INT, Low: EXT I
5 EMC External MIC Input Impedance: 1.8 kΩ I
6 ME External MIC GND – –
7 PTT External PTT Input Low: PTT ON I
8 PF Programable Function Key Input Input voltage: 0 V - 3.3 V I
9 OPT Aux I/O Port (for EXT Option)
10 E GND GND
11 5V 5V
12 TXD Serial Data Output Baud rate: 115200 bps max O
13 RXD Serial Data Input Baud rate: 115200 bps max I
14 NC Not used – –
Description
Antenna Terminal
50 Ω impedance
Specification I/O
I: 0 V - 3.3 V
O: Standard load 25 kΩ
5V power supply output
Max output current: 140 mA
I/O
−
O
Thank You
We are grateful you have chosen Kenwood for your land
mobile radio applications.
Models Covered bY This Manual
The models listed below are covered by this manual:
• TK-5210 (K/K2/K3/K7): VHF P25 Transceiver
•
TK-5310 (K/K2/K3/K4/K5/K6/K7): UHF P25 Transceiver
•
TK-5410 (K2/K3): 700/800MHz P25 Transceiver
noTiCes To The user
◆ Government law prohibits the operation of unlicensed radio
transmitters within the territories under government control.
◆ Illegal operation is punishable by fine and/or imprisonment.
◆ Refer service to qualified technicians only.
SAFETY: It is important that the operator is aware of and
understands hazards common to the operation of any transceiver.
Firmware Copyrights
The title to and ownership of copyrights for firmware embedded in
Kenwood product memories are reserved for Kenwood Corporation.
i
This device made under license under one or more of the following
US Patents: 4,590,473; 4,636,791; 4,716,407; 4,972,460; 5,148,482;
5,185,796; 5,271,017; 5,377,229; 5,502,767.
The IMBE™ voice coding Technology embodied in this product
is protected by intellectual property rights including patent rights,
copyrights, and trade secrets of Digital Voice Systems, Inc. This voice
coding Technology is licensed solely for use within this Communications
Equipment. The user of this Technology is explicitly prohibited from
attempting to decompile, reverse engineer, or disassemble the Object
Code, or in any other way convert the Object Code into a humanreadable form.
The AMBE+2™ voice coding Technology embodied in this product
is protected by intellectual property rights including patent rights,
copyrights and trade secrets of Digital Voice Systems, Inc. This
voice coding Technology is licensed solely for use within this
Communications Equipment. The user of this Technology is
explicitly prohibited from attempting to extract, remove, decompile,
reverse engineer, or disassemble the Object Code, or in any other
way convert the Object Code into a human-readable form. U.S.
Patent Nos. #5,870,405, #5,826,222, #5,754,974, #5,701,390,
#5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511,
#5,491,772, #5,247,579, #5,226,084 and #5,195,166.
ii
One or more of the following statements may be applicable:
FCC WARNING
This equipment generates or uses radio frequency energy.
Changes or modifications to this equipment may cause harmful
interference unless the modifications are expressly approved in the
instruction manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is made.
INFORMATION TO THE DIGITAL DEVICE USER REQUIRED BY
THE FCC
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can generate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that the
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer for technical assistance.
iii
The RBRC Recycle seal found on Kenwood
nickel-cadmium (Ni-Cd) battery packs indicates
Kenwood’s voluntary participation in an industry
program to collect and recycle Ni-Cd batteries
after their operating life has expired. The RBRC
program is an alternative to disposing Ni-Cd
batteries with your regular refuse or in municipal
waste streams, which is illegal in some areas.
For information on Ni-Cd battery recycling in your area, call (toll
free) 1-800-8-BATTERY (1-800-822-8837).
Kenwood’s involvement in this program is part of our commitment
to preserve our environment and conserve our natural resources.
The RBRC Recycle seal found on Kenwood nickel
metal hydride (Ni-MH) battery packs indicates
Kenwood’s voluntary participation in an industry
program to collect and recycle Ni-MH batteries
after their operating life has expired. The RBRC
program is an alternative to disposing Ni-MH
batteries with your regular refuse or in municipal
waste streams, which is illegal in some areas.
For information on Ni-MH battery recycling in your area, call (toll
free) 1-800-8-BATTERY (1-800-822-8837).
Kenwood’s involvement in this program is part of our commitment
to preserve our environment and conserve our natural resources.
The RBRC Recycle seal found on Kenwood
lithium-ion (Li-ion) battery packs indicates
Kenwood’s voluntary participation in an industry
program to collect and recycle Li-ion batteries
after their operating life has expired. The RBRC
program is an alternative to disposing Li-ion
batteries with your regular refuse or in municipal
waste streams, which is illegal in some areas.
For information on Li-ion battery recycling in your area, call (toll
free) 1-800-8-BATTERY (1-800-822-8837).
Kenwood’s involvement in this program is part of our commitment
to preserve our environment and conserve our natural resources.
iv
PreCauTions
• Do not charge the transceiver and battery pack when they are wet.
• Ensure that there are no metallic items located between the
transceiver and the battery pack.
• Do not use options not specified by
• If the die-cast chassis or other transceiver part is damaged, do not
touch the damaged parts.
• If a headset or headphone is connected to the transceiver, reduce
the transceiver volume. Pay attention to the volume level when
turning the squelch off.
• Do not place the microphone cable around your neck while near
machinery that may catch the cable.
• Do not place the transceiver on unstable surfaces.
• Ensure that the end of the antenna does not touch your eyes.
• When the transceiver is used for transmission for many hours, the
radiator and chassis will become hot. Do not touch these locations
when replacing the battery pack.
• Do not immerse the transceiver in water.
• When water gets into the microphone opening or the speaker
grill, the voice level may become incoherent or distorted. Lightly
shake the transceiver to remove the water from the speaker and/or
microphone before operating the transceiver.
• Always switch the transceiver power off before installing optional
accessories.
Kenwood.
v
Turn the transceiver power off in the following locations:
• Near explosives or blasting sites.
• In aircrafts. (Any use of the transceiver must follow the
instructions and regulations provided by the airline crew.)
• Where restrictions or warnings are posted regarding the use of
radio devices, including but not limited to medical facilities.
• Near persons wearing pacemakers.
Turn the transceiver power off in the following locations,
unless the model is specifically qualified for such use
(Intrinsically Safe such as approved by Factory Mutual, CSA):
• In explosive atmospheres (inflammable gas, dust particles,
metallic powders, grain powders, etc.).
• While taking on fuel or while parked at gasoline service stations.
• Do not disassemble or modify the transceiver for any reason.
• Do not place the transceiver on or near airbag equipment while
the vehicle is running. When the airbag inflates, the transceiver
may be ejected and strike the driver or passengers.
• Do not transmit while touching the antenna terminal or if
any metallic parts are exposed from the antenna covering.
Transmitting at such a time may result in a high-frequency burn.
• If an abnormal odor or smoke is detected coming from the
transceiver, switch the transceiver power off immediately,
remove the battery pack from the transceiver, and contact your
Kenwood dealer.
• Use of the transceiver while you are driving may be against
traffic laws. Please check and observe the vehicle regulations
in your area.
• Do not expose the transceiver to extremely hot or cold
conditions.
• Do not carry the battery pack (or battery case) with metal
objects, as they may short the battery terminals.
vi
CONTENTS
UNPACKING AND CHECKING EQUIPMENT....................................1
uPPlied aCCessories ......................................................... 1
s
PREPARATION ...................................................................2
aTTerY PaCk PreCauTions ....................................................2
b
nsTalling/ reMoving The (oPTional) baTTerY PaCk ...........................7
i
nsTalling The (oPTional) anTenna ............................................8
i
nsTalling The belT CliP ....................................................... 8
i
nsTalling The CaP over The universal ConneCTor............................9
i
nsTalling The (oPTional) sPeaker/ MiCroPhone or headseT .................9
i
GETTING ACQUAINTED ....................................................... 10
isPlaY (k2/k3/k5/k6/k7 Models onlY) ................................... 13
d
PROGRAMMABLE FUNCTIONS ............................................... 15
BASIC OPERATIONS ........................................................... 18
wiTChing Power on/ oFF ................................................. 18
s
djusTing The voluMe ....................................................... 19
a
eleCTing a Zone and Channel .............................................. 19
s
ransMiTTing ................................................................ 20
T
eCeiving .................................................................... 22
r
SCAN ............................................................................. 24
eMPorarY Channel loCkouT ................................................ 24
T
rioriTY sCan ............................................................... 25
P
Can reverT ................................................................. 25
s
Can PrograMMing (k2/k3/k5/k6/k7 Models onlY)
s
<Tk-5210/ Tk-5310
FleetSync: ALPHANUMERIC 2-WAY PAGING FUNCTION
<TK-5210/ TK-5310 ONLY> ...................................................
elCall (seleCTive Calling) ................................................. 28
s
TaTus Message (k2/k3/k5/k6/k7 Models onlY) .......................... 29
s
horT Messages............................................................. 31
s
ong Messages .............................................................. 31
l
ePorT ................................................................. 31
gPs r
DTMF (DUAL TONE MULTI FREQUENCY) CALLS ......................... 32
aking a dTMF Call ....................................................... 32
M
uTodial (k2/k3/k5/k6/k7 Models onlY) ................................. 33
a
onlY> ................................................ 26
28
vii
sTun Code <Tk-5210/ Tk-5310 onlY> .................................... 33
TRUNKING CALLS .............................................................. 34
aking a TelePhone Call ................................................... 34
M
eCeiving a TelePhone Call ................................................. 35
r
aking a sTaTus Call ....................................................... 35
M
EMERGENCY CALLS ........................................................... 36
SCRAMBLER (FM) <TK-5210/ TK-5310 ONLY>/ ENCRYPTION (P25) ...
eCure (enCrYPTed) TransMission .......................................... 37
s
eleCTing The sCraMbler Code .............................................. 37
s
eleCTing The enCrYPTion keY ............................................... 38
s
eleTing The enCrYPTion keY (k2/k3/k5/k6/k7 Models onlY) ............ 38
d
assword ProTeCTion (k2/k3/k5/k6/k7 Models onlY) ................... 38
P
37
SIGNALING ...................................................................... 39
uieT Talk (QT)/ digiTal QuieT Talk (dQT)................................ 39
Q
PTional signaling <Tk-5210/ Tk-5310 onlY> ........................... 40
o
VOICE OPERATED TRANSMISSION (VOX) .................................. 41
ain level ............................................................. 41
voX g
PeraTion .............................................................. 42
voX o
CLOCK (K2/K3/K5/K6/K7 MODELS ONLY) .................................. 43
loCk adjusTMenT ........................................................... 43
C
ADVANCED OPERATIONS ..................................................... 44
BACKGROUND OPERATIONS ................................................. 51
iMe-ouT TiMer (ToT) ...................................................... 51
T
aTTerY saver ............................................................... 51
b
ow baTTerY warning ...................................................... 52
l
ignal sTrengTh indiCaTor (k2/k3/k5/k6/k7 Models onlY) .............. 52
s
oMPander .................................................................. 53
C
usY Channel loCkouT (bCl) .............................................. 53
b
uT oF range ................................................................ 53
o
iTe Trunking ............................................................... 54
s
onTrol Channel hunT ...................................................... 54
C
oiCe annunCiaTion .......................................................... 54
v
PTT id ......................................................................
54
VGS-1 OPTIONAL VOICE GUIDE & STORAGE UNIT ....................... 55
oiCe reCorder (k2/k3/k5/k6/k7 Models onlY) .......................... 55
v
oiCe guide .................................................................. 56
v
viii
UNPACKING AND CHECKING EQUIPMENT
Note: The following unpacking instructions are for use by your
Kenwood dealer, an authorized Kenwood service facility, or the
factory.
Carefully unpack the transceiver. We recommend that you
identify the items listed in the following table before discarding
the packing material. If any items are missing or have
been damaged during shipment, file a claim with the carrier
immediately.
Supplied AcceSSorieS
Belt clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
• Screws for belt clip (3 x 8 mm)
Universal connector cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
• Dressing screw
• Packing (preassembled)
Quick reference card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Instruction manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Belt clip + screws
Universal connector cap
+ Dressing screw
1
PREPARATION
BAttery pAck precAutionS
Do not use battery packs or battery chargers not recommended
by Kenwood.
◆ Do not recharge the battery pack if it is already fully charged.
Doing so may cause the life of the battery pack to shorten or the
battery pack may be damaged.
◆ After charging the battery pack, disconnect it from the charger.
If the charger power is reset (turned ON after being turned
OFF), recharging will start again and the battery pack will
become overcharged.
◆ Do not use the transceiver while charging the battery pack.
We recommend you switch the transceiver power OFF while
charging is taking place.
◆ Do not charge the battery pack when the battery pack or
transceiver is wet, to avoid the risk of fire or damage. Wipe
the water from the battery pack or transceiver using a dry cloth
before charging.
◆ Do not short the battery terminals or dispose of the battery by
fire.
◆ Never attempt to remove the casing from the battery pack.
■ Charging the Battery Pack
For charging procedures, refer to the battery charger
Instruction Manual.
2
Information concerning the battery pack:
DANGER
The battery pack includes flammable objects such as organic solvent.
Mishandling may cause the battery to rupture producing flames or
extreme heat, deteriorate, or cause other forms of damage to the
battery. Please observe the following prohibitive matters.
Do not disassemble or reconstruct battery!
•
The battery pack has a safety function and protection circuit to
avoid danger. If they suffer serious damage, the battery may
generate heat or smoke, rupture, or burst into flame.
Do not short-circuit the battery!
•
Do not join the + and – terminals using any form of metal (such
as a paper clip or wire). Do not carry or store the battery pack
in containers holding metal objects (such as wires, chainnecklace or hairpins). If the battery pack is short-circuited,
excessive current will flow and the battery may generate heat
or smoke, rupture, or burst into flame. It will also cause metal
objects to heat up.
Do not incinerate or apply heat to the battery!
•
If the insulator is melted, the gas release vent or safety function
is damaged, or the electrolyte is ignited, the battery may
generate heat or smoke, rupture, or burst into flame.
Do not use or leave the battery near fires, stoves, or other
•
heat generators (areas reaching over 80°C/ 176°F)!
If the polymer separator is melted due to high temperature,
an internal short-circuit may occur in the individual cells and
the battery may generate heat or smoke, rupture, or burst into
flame.
Avoid immersing the battery in water or getting it wet by
•
other means!
If the battery becomes wet, wipe it off with a dry towel before
use. If the battery’s protection circuit is damaged, the battery
may charge at extreme current (or voltage) and an abnormal
chemical reaction may occur. The battery may generate heat or
smoke, rupture, or burst into flame.
3
• Do not charge the battery near fires or under direct
DANGER
sunlight!
If the battery’s protection circuit is damaged, the battery may
charge at extreme current (or voltage) and an abnormal
chemical reaction may occur. The battery may generate heat or
smoke, rupture, or burst into flame.
Use only the specified charger and observe charging
•
requirements!
If the battery is charged in unspecified conditions (under high
temperature over the regulated value, excessive high voltage
or current over regulated value, or with a remodelled charger),
it may overcharge or an abnormal chemical reaction may occur.
The battery may generate heat or smoke, rupture, or burst into
flame.
Do not pierce the battery with any object, strike it with an
•
instrument, or step on it!
This may break or deform the battery, causing a short-circuit.
The battery may generate heat or smoke, rupture, or burst into
flame.
Do not jar or throw the battery!
•
An impact may cause the battery to leak, generate heat
or smoke, rupture, and/or burst into flame. If the battery’s
protection circuit is damaged, the battery may charge at an
abnormal current (or voltage), and an abnormal chemical
reaction may occur.
Do not use the battery pack if it is damaged in any way!
•
The battery may generate heat or smoke, rupture, or burst into
flame.
Do not solder directly onto the battery!
•
If the insulator is melted or the gas release vent or safety
function is damaged, the battery may generate heat or smoke,
rupture, or burst into flame.
Do not reverse the battery polarity (and terminals)!
•
When charging a reversed battery, an abnormal chemical
reaction may occur. In some cases, an unexpected large
amount of current may flow upon discharging. The battery may
generate heat or smoke, rupture, or burst into flame.
4
• Do not reverse-charge or reverse-connect the battery!
DANGER
The battery pack has positive and negative poles. If the battery
pack does not smoothly connect with a charger or operating
equipment, do not force it; check the polarity of the battery. If
the battery pack is reverse-connected to the charger, it will be
reverse-charged and an abnormal chemical reaction may occur.
The battery may generate heat or smoke, rupture, or burst into
flame.
Do not touch a ruptured and leaking battery!
•
If the electrolyte liquid from the battery gets into your eyes,
wash your eyes out with fresh water as soon as possible,
without rubbing your eyes. Go to the hospital immediately. If
left untreated, it may cause eye-problems.
• Do not charge the battery for longer than the specified
time!
If the battery pack has not finished charging even after the
regulated time has passed, stop it. The battery may generate
heat or smoke, rupture, or burst into flame.
Do not place the battery pack into a microwave or high
•
pressure container!
The battery may generate heat or smoke, rupture, or burst into
flame.
Keep ruptured and leaking battery packs away from fire!
•
If the battery pack is leaking (or the battery emits a bad odor),
immediately remove it from flammable areas. Electrolyte
leaking from battery can easily catch on fire and may cause the
battery to generate smoke or burst into flame.
Do not use an abnormal battery!
•
If the battery pack emits a bad odor, appears to have different
coloring, is deformed, or seems abnormal for any other reason,
remove it from the charger or operating equipment and do not
use it. The battery may generate heat or smoke, rupture, or
burst into flame.
5
■ Using the Li-ion Battery Pack
• Charge the battery pack before using it.
• To keep the battery discharge at a minimum, remove the
battery pack from the equipment when it is not in use. Store
the battery pack in a cool and dry location.
• When storing the battery pack for a long period:
1 Remove the battery pack from the equipment.
2 Discharge the battery pack, if possible.
3 Store the battery pack in a cool (below 25°C/ 77°F) and dry
location.
■ Characteristics of the Li-ion Battery Pack
• As the battery pack is charged and discharged repeatedly, the
battery capacity decreases.
• Even if the battery pack is unused, the battery pack degrades.
• It takes a longer time to charge the battery pack in cooler
areas.
• The life of battery pack is shortened when it is charged and
discharged in hotter areas. When the battery pack is stored in
a hot location, the battery pack degrades quicker. Do not leave
the battery pack in vehicles or near heating appliances.
• When the battery pack operating time becomes short, even
if it is fully charged, replace the battery pack. Continuing to
charge and discharge the battery pack may result in electrolyte
leakage.
6
inStAlling/ removing the (optionAl) BAttery pAck
1 Match the guides of the
battery pack with the
corresponding grooves on the
upper rear of the transceiver,
then firmly press the battery
pack to lock it in place.
2 Lock the safety catch to
prevent accidentally pressing
the release latch and
removing the battery pack.
3 To remove the battery pack,
lift the safety catch, press the
release latch, then pull the
battery pack away from the
transceiver.
Note:
◆ To lift the battery pack safety catch, use a piece of hardened
plastic or metal, such as a screwdriver, that is no more than
6 mm wide and 1 mm thick. It is imperative that you place the
implement under only the lip of the safety catch so that you do
not damage the release latch.
◆ Before charging a battery pack that is attached to the
transceiver, ensure that the safety catch is firmly closed.
7
Optional
antenna
inStAlling the (optionAl) AntennA
Binding screws
Belt clip
Screw the antenna into the
connector on the top of the
transceiver by holding the
antenna at its base and turning
it clockwise until secure.
inStAlling the Belt clip
If necessary, attach the belt clip
using the two supplied 3 x 8 mm
binding screws.
Note: If the belt clip is not
installed, its mounting location
may get hot during continuous
transmission or when left sitting in
a hot environment.
Do not use glue which is designed
to prevent screw loosening when
installing the belt clip, as it may
cause damage to the transceiver.
Acrylic ester, which is contained
in these glues, may crack the
transceiver’s back panel.
8
inStAlling the cAp over the univerSAl connector
Universal
connector cap
Dressing
screw
Optional
Speaker/ Microphone
1 If you are not using an
optional speaker/ microphone
or headset, install the cap
over the universal connector.
2 Secure the cap in place using
the dressing screw.
inStAlling the (optionAl) SpeAker/ microphone or heAdSet
1 Insert the guide of the
speaker/ microphone or
headset connector into
the groove of the universal
connector.
2 Secure the connector in place
using the attached screw.
Note: When not using an optional
speaker/ microphone or headset,
install the cap over the universal
connector.
9
GETTING ACQUAINTED
A
B
C
6
M
IC
Microphone
Speaker
There are 3 model types available:
K/K4 models: Basic models.
K2/K5/K7 models:
Equipped with a display and 4-key keypad (
K3/K6 models: Equipped with a display and full keypad.
The above illustration displays the K3/K6 models.
A, B, <C, and D>).
10
Loading...
