know your Kenwood kitchen machine
before using your Kenwood appliance
●
Read these instructions carefully and retain for future
reference.
●
Remove all packaging and any labels.
safety
●
Switch off and unplug before fitting or removing
tools/attachments, after use and before cleaning.
●
Keep your fingers away from moving parts and fitted
attachments.
●
Never leave the machine on unattended.
●
Never use a damaged machine. Get it checked or repaired:
see ‘service and customer care’.
●
Never let the cord hang down where a child could grab it.
●
Never let the power unit, cord or plug get wet.
●
Never use an unauthorised attachment or both outlets at the
same time
●
Never exceed the maximum capacities.
●
When using an attachment, read the safety instructions that
come with it.
●
Take care when lifting this appliance as it is heavy. Ensure the
head is locked and that the bowl, tools, outlet cover and cord
are secure before lifting.
●
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
●
Children should be supervised to ensure that they do not play
with the appliance.
●
Only use the appliance for its intended domestic use.
Kenwood will not accept any liability if the appliance is subject
to improper use, or failure to comply with these instructions.
2
![](/html/18/18c1/18c160b66283a07bf93b69b378ce509ead3e08301bbd199cf5b9df34274680a8/bg3.png)
know your Kenwood kitchen machine
before plugging in
●
Make sure your electricity supply is the same as the one shown on
the underside of your machine.
important - UK only●The wires in the cord are coloured as follows:
Green and Yellow = Earth,
Blue = Neutral,
Brown = Live.
●
The appliance must be protected by a 13A approved (BS1362) fuse.
●
WARNING: THIS APPLIANCE MUST BE EARTHED.
Note:
●
For non-rewireable plugs the fuse cover MUST be refitted when
replacing the fuse. If the fuse cover is lost then the plug must not be
used until a replacement can be obtained. The correct fuse cover is
identified by colour and a replacement may be obtained from your
Kenwood Authorised Repairer (see Service).
●
If a non-rewireable plug is cut off it must be DESTROYED
IMMEDIATELY. An electric shock hazard may arise if an unwanted
non-rewireable plug is inadvertently inserted into a 13A socket outlet.
●
This appliance conforms to EC directive 2004/108/EC on
Electromagnetic Compatibility and EC regulation no. 1935/2004 of
27/10/2004 on materials intended for contact with food.
know your Kenwood kitchen machine
햲 mixer head
햳 attachment outlet
햴 outlet cover
햵 bowl
햶 tool socket
햷 on/off and speed switch
햸 mixer ready indicator light
햹 mixer body
햺 head release lever
햻 K beater
햽 whisk
햾 dough hook
햿 spatula
헀 splashguard
헁 spanner
햻
햽
햲
햳
햴
햵
햶
햺
햹
햸
햿
햷
햾
헀
헁
3
![](/html/18/18c1/18c160b66283a07bf93b69b378ce509ead3e08301bbd199cf5b9df34274680a8/bg4.png)
the mixer
the mixing tools and some of their uses
K beater●For making cakes, biscuits, pastry, icing, fillings, éclairs and
mashed potato.
whisk●For eggs, cream, batters, fatless sponges, meringues,
cheesecakes, mousses, soufflés. Don’t use the whisk for heavy
mixtures (eg creaming fat and sugar) – you could damage it.
dough hook●For yeast mixtures.
to use your mixer
1 Lift the head release lever at the back of the appliance
and at the same time lift the head until it locks in the raised
position .
to insert a tool 2 Push up until it stops then turn .
3 Fit the bowl onto the base. Place the handle directly over the
unlock symbol , then gently turn the bowl clockwise until the
handle is directly above the lock symbol . DO NOT USE
excessive force and DO NOT overtighten .
4 Lift the head release lever at the back of the appliance and at the
same time lower the mixer head .
5 Plug into the power supply and the mixer ready indicator light
will glow.
6 Switch on by turning the speed switch to the desired setting.
to remove a tool 7 Turn and remove.
important
●
If the mixer head is raised during operation, the machine will stop
working straight away. To re-start the mixer, lower the mixer head,
turn the speed switch to the off position, wait a few seconds and
then re-select the speed. The mixer should resume operating
straight away.
●
Whenever the mixer head is raised the mixer ready indicator light
will go out. When the head is lowered, the light will glow indicating
the mixer is ready to use.
hints●Switch off and scrape the bowl with a spatula when necessary.
●
Use the fold position for slow incorporation of ingredients such
as when mixing flour and fruit into cake mixes. Simply turn the
switch to . The mixer will operate on slow speed for
approximately 21⁄2 revolutions and then pause. This will be repeated
for a further 20 operations and then stop after which time the
switch should be returned to the off ‘O’ position.
●
Eggs at room temperature are best for whisking.
●
Before whisking egg whites, make sure there’s no grease or egg
yolk on the whisk or bowl.
●
Use cold ingredients for pastry unless your recipe states
otherwise.
●
When creaming fat and sugar for cake mixes, always use the
fat at room temperature or soften it first.
