KENWOOD KCL95 Users guide

TYPE KCL95

instructions

2

English

´¸∂w

2 - 17

٣٤- ١٨

3

4

KENWOOD WORLD APP

A

B

C

D

To Use Your Cooking Chef Connect – Manual Operation

E	F	G	H
I	J	K	L
				Manual Mode
			0 2 : 0 3	Min	Off
			To pause, push dial
M	N	O

Using Preset Programmes

P

Q

R

All in One Dishes

Fruit Compote

Slow Cook

Chunky Soup

Steam

S To Use The Weighing Function

g

oz

Manual Mode

0 g

0 2 : 0 3

Min

Off

g

200

To pause, push dial

Zero

T To Use Your Steamer Attachment

+

500ml

	U	Tool Height Adjustment						V	To Fit and Use Your Splashguard Assembly

W To Fit and Remove Your Stir Assist Clip

X Assembling The High Temperature Creaming Beater

Safety

Ο Read these instructions carefully and retain for future reference.

Ο Remove all packaging and any labels.

Ο If the plug or cord is damaged it must, for safety reasons, be replaced by Kenwood or an authorised Kenwood repairer in order to avoid a hazard.

important note - electronic medical implants

Ο Like all induction heating products, this appliance generates short-range magnetic fields. If any user or person in close proximity has a pacemaker or other active implants, please consult a doctor before use, concerning any possible incompatibility to prevent any risk to health.

Ο Switch off and unplug the appliance before fitting or removing tools/ attachments, after use and before cleaning.

Ο Keep body parts, hair, jewellery and loose clothing away from moving parts and fitted attachments.

Ο Never put your fingers etc., into the hinge mechanism.

Ο Never leave the appliance on unattended when in a non cooking mode.

ΟWhen leaving the appliance unattended in the cooking mode, pay close attention to the following:

{ensure the instructions are followed with regards to temperatures and maximum quantities to process;

{make sure the unit and cord are positioned out of reach of children and away from the edge of the work surface;

{check the progress on a regular basis to ensure enough liquid is added and food is not overcooking.

Ο Never use a damaged appliance. Get it checked or repaired: see ‘Service and Customer Care’.

Ο Never use an unauthorised attachment or more than one attachment at once. Ο Never exceed the maximum capacities and when using the induction heater

never exceed the 3 litre maximum fill level marked on the inside of the bowl. Ο When using an attachment, read the safety and usage instructions that come

with it.

Ο Take care when lifting this appliance as it is heavy. Ensure the head is locked and that the bowl, tools, outlet covers and cord are secure before lifting.

Ο When moving the appliance always pick up by the pedestal base and mixer head. Do not lift or carry the appliance by the bowl handle.

Ο Never let the cord hang down where a child could grab it. Ο Never let the power unit, cord or plug get wet.

Ο Be careful when handling or touching any part of the appliance when being used in the cook mode or after cooking, IN PARTICULAR THE BOWL, SPLASHGUARD AND TOOLS as they will remain HOT long after the appliance has been switched off. Use the handles to remove and carry the bowl.

Use oven gloves when handling the hot bowl and hot mixing tools.

Ο The symbol marked on the product indicates a surface that can become hot during use.

Ο Take care when removing bowl tools after extended use as they may get hot. Ο The underside of the bowl will remain hot long after the heating has stopped. Use caution when handling and use the work surface protection mat when

placing the bowl on heat sensitive surfaces.

Ο Be careful of steam escaping from the mixer bowl particularly when opening the lid in the splashguard or when raising the mixer head.

Ο If transferring hot food from the mixer to the blender, always allow the ingredients to cool to room temperature before placing in the blender.

Ο Only use the bowl and tools supplied with this appliance. Never use the bowl with any other heat source.

Ο Never operate the appliance in the cook mode with the bowl empty. Ο Never insert anything through the air vents.

Ο When using this appliance ensure it is positioned on a level surface away from the edge. Make sure it is at least 10 cm from walls and ensure that the vents are not blocked. Do not position below overhanging cupboards.

2

Ο For the correct and safe operation of the induction cooker ensure that the bowl base and temperature sensors are clean and dry before cooking.

Ο Metallic objects such as knives, forks, spoons and lids should not be placed on the bowl pedestal/induction area as they can get hot.

Ο As with all induction cooking appliances do not place credit cards, magnetic media or sensitive electronic equipment near to the appliance when in use.

Ο Do not use the appliance for deep frying foods.

Ο Always ensure food is thoroughly cooked before eating. Ο Do not exceed 250ml when cooking with oil.

Ο Food should be eaten shortly after cooking or allowed to cool quickly and then refrigerated as soon as possible.

ΟMisuse of your appliance can result in injury.

ΟDo not use excessive force when pressing the touch screen and never use a sharp object to operate it.

Ο Do not use the whisk for heavy mixtures (e.g. creaming fat and sugar) as you could damage it.

Ο The power-supply cord is used to reduce risk resulting from becoming entangled in or tripping. Extension cords may be used if care is exercised in their use. If an extension cord is used: 1) The marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance; and 2) The cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped

over unintentionally. If the appliance is of the earthed type, the extension cord should be a earthing-type 3-wire cord. The electrical rating of the appliance is listed on the bottom of the unit.

Ο Appliances can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved.

Ο Children should be supervised to ensure that they do not play with the appliance.

Ο This appliance shall not be used by children. Keep the appliance and its cord out of reach of children.

Ο Only use the appliance for its intended domestic use. Kenwood will not accept any liability if the appliance is subject to improper use, or failure to comply with these instructions.

Ο The maximum rating is based on the mini chopper/mill attachment that draws the greatest load. Other attachments may draw less power.

Ο This appliance is not intended to be operated by means of an external timer or separate remote-control system.

Steamer attachment

ΟThis attachment produces steam which can burn you.

ΟDo not get burnt by steam coming out of your steamer basket, especially when removing the splashguard or lifting the feed chute lid.

ΟTake care when handling parts; any liquid, condensation, steamer part or Stand mixer part will be very hot. Use oven gloves.

ΟUnplug the appliance before fitting or removing parts or cleaning.

Food safety

ΟCook meat, poultry, fish and seafood thoroughly. And never cook them from frozen.

ΟDo not reheat cooked food in your steamer.

Important – Plug and Fuse Information Before plugging in

Ο Make sure your electricity supply is the same as the one shown on the underside of your appliance. Ο The wires in the cord are coloured as follows:

Green and Yellow = Earth Blue = Neutral

Brown = Live

Ο If the plug supplied with your appliance has a fuse fitted it is rated 10A. If the fuse fails it must be replaced with one of the same rating. Ο If the plug or cord requires replacing a new cord set should be fitted by an Authorised Kenwood Repairer.

Ο WARNING: THIS APPLIANCE MUST BE EARTHED.

3

Note:

Ο For non-rewireable plugs the fuse cover MUST be refitted when replacing the fuse. If the fuse cover is lost then the plug must not be used until a replacement can be obtained. The correct fuse cover is identified by colour and a replacement may be obtained from your Kenwood Authorised Repairer (see Service).

Ο If a non-rewireable plug is cut off it must be DESTROYED IMMEDIATELY. An electric shock hazard may arise if an unwanted nonrewireable plug is inadvertently inserted into a 13A socket outlet.

Ο This appliance conforms to EC Regulation 1935/2004 on materials and articles intended to come into contact with food. Ο This appliance is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.

Before using for the first time

ΟWash the parts: see ‘Care and Cleaning’.

Know Your Kenwood Cooking

Chef

If you own attachments featuring the Bar Connection System you will need to use the KAT002ME adaptor to connect

these to the Twist Connection System on your Stand mixer.

Key

Attachment outlets

1 High speed outlet (HSO)

2 Slow speed outlet (SSO)

3 Bowl tool socket

4Stir tool socket

Mixer

5 High speed outlet cover

6Mixer head

7 Slow speed outlet cover

8 Cooking chef bowl

9 Head - lift lever

10 Control dial

11 On/Off switch

12Display screen

13Work surface protection mat

14Drain hole

15Bowl pedestal/induction area

16Air vents

17Temperature sensors

18Heat shield

19Rubber seal (removable)

20	Splashguard
21	Feed chute lid

22K-beater

23High temperature creaming beater

24Whisk

25Dough tool

26Stir tool

27Stir assist clip

28High temperature spatula

29Dough scraper

30Spanner

For more information visit www.kenwoodworld.com/twist.

Connecting to Kenwood World App

Refer to Illustrations A – D

The Kenwood World App will allow you to control your appliance through your smart phone or tablet.

1Plug in and press the On/Off switch on the side of the power unit.

2Select Settings > WiFi > Connect and follow the instructions on the touch screen.

PIN number

Ο	This will be required when prompted by the Kenwood
	World App.
Ο	The appliance can only be connected when the PIN
	Number is shown on the display screen. If the PIN is
	entered incorrectly, follow the instructions on the app and
	retry.
Ο	To display the unit’s PIN number, select Settings
	> WiFi > Connect and follow the instructions on the display
	screen (only when connected to WiFi).

Note:

WiFi

Operates with IEEE802.11 b, g and n at 2.4 GHz only, and connects to networks using WPA2-PSK

Compatibility

Kenwood World App compatible with latest versions of iOS and Android.

Factory reset

Important

ΟWhen disposing of the appliance, it is important to factory reset it to protect your personal data.

ΟSelecting this option will erase all WiFi data stored on the appliance and restore it to factory settings.

ΟTo factory reset your appliance, select Settings >Factory Reset.

Steamer Attachment

31 Handle supports

32Supporting ring

33Folding handles

34Removeable tray

35Egg holders

Note: Slow Speed outlet attachments

The slow speed outlet on your Stand mixer model features the Twist Connection System. It is designed to accept Twist Connection System attachments.

When purchasing new attachments for the slow speed outlet you should check compatibility with your Stand mixer. All Twist Connection System attachments can be identified by the product code which starts with KAX and also by the Twist logo

which is visible on packaging.

To Set Up Your Cooking Chef Connect

Refer to Illustrations E – I

	IMPORTANT
Ο	Make sure the induction area, temperature sensors and
	external surface of the bowl base are clean. Failure to do
	this will affect the heat sensor, resulting in poor cooking
	performance.
Ο	Check that all the outlet covers including the heat shield
	are fitted. If they are not correctly fitted the heating
	function will not operate.

1Plug in and press the On/Off switch.

2Turn the head-lift lever clockwise and raise the mixer head until it locks.

3Push the heat shield upwards onto the underside of the mixer head until fully located. The heat shield must never be used without the rubber seal fitted correctly.

4

Ο If using the Cooking Chef Connect without heat, it is not necessary to fit the heat shield unless using the splashguard. Refer to ‘To Fit and Use Your Splashguard Assembly’ section.

4Fit the bowl to the base.

5Place the required tool in the bowl tool socket or stir tool socket if using the stir tool, locating the pin in the groove and then turn to lock into position.

Ο To remove a tool, reverse step 5 above. (Always use oven gloves to remove tools after cooking).

6To lower the mixer head, raise it slightly, then turn the head lift lever clockwise.

Lower into the locked position.

Stir Tool – when using the stir tool the stir assist clip can also be used to assist the mixing action, see ‘to fit and remove your stir assist clip'. The stir tool can also be used with the whisk. Do not use the stir tool with the dough tool.

To Use Your Cooking Chef Connect - Manual

Operation

1 Add the relevant ingredients to be cooked/mixed.

2Set the required time, speed and temperature.

Note: To use the machine as a mixer without heat, select 'Off' when setting the temperature.

Turn the control dial anti-clockwise to use stir intervals and pulse.

Turn the control dial clockwise to use continuous speeds.

3Press the control dial to start.

4To stop the unit at any time, press the control dial. If in cooking mode, take care as the unit will be hot.

Ο If the bowl temperature exceeds 60°C, for safety reasons the speed is automatically limited even if a higher speed has been selected. The speed will not automatically increase when the temperature drops below 60°C. The speed must be turned to the Off position first and the desired speed reselected.

High speed, high temperature mode (HSHT)

To mix at high speed at temperatures of 60°C and above

Ο	Select time (if applicable), speed and temperature of
	60°C or above.
Ο	A warning will pop up on the display screen advising that
	you are entering HSHT mode
Ο	Once the warning has been read and undestood, press
	yes to confirm that you are happy to enter HSHT mode.
Ο	Press the control dial to start.

This function MUST ONLY be used with the whisk and/ or stir tool. You should not exceed the maximum cooking

capacity of 3 litres and you must ensure the splashguard is fitted. The machine must not be left unattended.

5Once a programme has finished, the unit will beep 3 times.

Ο Note: If no time has been set, the heating and stirring processes will automatically end once the timer has reached 8 hours.

6To stop the heating process, change the temperature to ‘OFF’. To stop the unit at any time press the control dial. Important – If at any time the mixer head is raised during an operation, the heating process will pause and the bowl tool will stop and will not restart when the mixer head is lowered. To restart the mixer, lower the mixer head and press the control dial.

Using Preset Programmes

Refer to Illustrations P – R

1Select the Preset Menu.

2Choose the preset you wish to use.

3Follow the instructions on the display screen.

4To stop the unit at any time, press the control dial. Take care as the bowl and tools will be hot.

After Cooking

Ο	Be careful when handling or touching any part of the
	appliance when being used in the cooking mode or after
	cooking, IN PARTICULAR THE BOWL AND TOOLS as
	they will remain HOT long after the appliance has been
	switched off.
Ο	Use the two side handles to remove and carry the
	bowl. Use oven gloves when handling the hot bowl
	and hot tools.
Ο	The underside of the bowl will remain hot long after
	the heating has stopped. Use caution when handling
	and use the work surface protection mat provided
	to protect heat sensitive surfaces.
Hints and Tips
Ο	Some recipes, in particular those with a high water
	content, will not be able to reach a cooking temperature
	above 100°C (as this is the boiling point of water).
Ο	When adding ingredients to the bowl during cooking,
	turn the speed down and add the ingredients slowly and
	evenly.
Ο	To heat sauces quickly use a continuous stir setting.
Ο	If using the splashguard during cooking, always
	remove it before lifting the mixer head. Be aware of
	condensation formed on the splashguard and heat
	shield.
Ο	When lifting the mixer head lift it slowly to allow any
	liquid on the underside of the heat shield to flow back
	into the bowl.
Ο	Four stir delay functions are available which enable
	you to select the appropriate amount of stirring for
	individual recipes. Some recipes will require constant
	stirring to stop ingredients from sticking to the
	bottom of the bowl, whereas others will benefit from
	intermittent stirring to maintain the texture of the food.

To Use The Weighing Function

Refer to Illustrations S

1	Select the weighing function	on the touch screen.
2	Fit the bowl.

3Zero the scale.

4Weigh the ingredients.

5To change between units tap the unit button on the weighing screen.

Note: Always place the appliance on a dry flat, stable surface prior to weighing. Do not apply pressure to the mixer or bowl whilst weighing as this will affect the accuracy of the scales.

The weighing function can be used with the mixer head in either the down or up position.

5

Preset Usage Chart

The default settings can be adjusted to suit your recipe, where available. Non-adjustable settings are indicated by the icon.

When “Heating” is shown on the display screen, the timer will not start counting down until the correct temperature has been reached.

Preset	Recommended Tool Default Settings	Keep Warm Stage Recipe Ideas / Uses
	(adjustable)
Egg White Whisking	1 min 15 secs		Egg whites for chocolate mousse
	(1 mins – 5 mins)
	Max
	(Min – Max)
	OFF
Sponge Cake	1 min		Victoria Sponge, Cupcakes
	(30 secs – 5 mins)
	1 – Max
	(1 – Max)
	OFF
Dough Kneading	10 mins		Bread Rolls, Pizza
	(5 mins – 30 mins)
	Min to 1
	(min – 1)
	OFF
Dough Proving	1 hrs		Proving yeasted doughs
	(20 mins – 1 hr)
	OFF
	30˚C
	(25˚C – 35˚C)
Chocolate Melting	10 mins		Chocolate Mousse
	(3 mins – 1 hr)
	60˚C
Swiss Meringue	10 mins		Base for Buttercream frosting
	Max
	40˚C
Italian Meringue	4 mins		Lemon Meringue Pie
			Baked Alaska
	HSHT 6
	60˚C – 85˚C
Fruit Compote	20 mins	30 mins	Cake Fillings, Dessert toppings
	104˚C	62˚C
Popcorn	10 mins		For fresh homemade popcorn
	OFF
	180˚C

6

	Preset Usage Chart – Continued
	Preset	Recommended Tool	Default Settings	Keep Warm Stage		Recipe Ideas / Uses
			(adjustable)
	Steam		20 mins			Salmon en Papillote
			(15 mins – 45 mins)
			OFF
			100˚C
	All in One Dishes		40 mins	30 mins		Bolognese
				2
			103˚C – 140˚C	62˚C
	Chunky Soup		20 mins	30 mins		Minestrone, Broths
				2
			103˚C – 140˚C	62˚C
	Slow Cook		2 hrs	30 mins		Beef bourguignon
				2
			98˚C – 140˚C	62˚C
	Recipe		Steamer Attachment
	Prune Marinade		Refer to Illustration		T
	200g Clear Runny Honey		Ο	When using your steamer basket, always keep your
	40g Soft Prunes			Cooking Chef away from walls and overhanging cupboards:
	40ml Water
				the steam could damage them.
			Ο	Season food after cooking, this will help to prevent spots
	1 Place all ingredients into the mini chopper/mill. Refrigerate			or pitting occurring on the stainless bowl.
	overnight.
			1	Place the removable tray on a flat surface ensuring that the
	2 Fit the attachment to the Stand mixer.
				handles are folded inwards.
	3 Switch to pulse for 4 seconds.
			2	Fit the supporting ring onto the tray ensuring that the
	4 Use as required.
				handle supports	on the ring fit next to the V shaped cut
				outs in the tray.
			3	Fold out the handles and clip onto the handle supports.
			4	Place the food to be cooked onto the tray. Vegetables
				should be thoroughly cleaned and peeled as required.
			5	Add the required amount of water to the bowl (see
				cooking chart). Filtered water is best as it reduces
				limescale and spotting.
			6	Place the assembled steamer into the bowl – it will find its
				own height.
			7	Fit the heatshield to the mixer head.
			8	Fit the bowl and steamer basket to the Stand Mixer.
			9	Lower the mixer head and then fit the splashguard.
			10	Select the steam pre-set and adjust the cooking time (as
				per the Recommended Cooking Chart). Press the control
				dial to start
			11	Allow to cook for the required time.
			12	Remove the splashguard.
			13	Lift the mixer head.

7

14Lift out the steamer basket by the handles – take care to prevent them folding inwards.

15Place the steamer basket on a large plate or other suitable container.

16Unclip the handles and fold in towards the centre. Lift off the supporting ring and fold out the handles.

17Remove the food.

	important
	Be careful when handling anything: any liquid,
	condensation, steamer part or Stand Mixer part will be
	very hot. Use oven gloves.
Ο	Do not attempt to fit a mixing tool when using the steamer
	basket.
Ο	Do not cook food in the mixer bowl whilst using the
	steamer basket.

Hints and Tips

Ο	Liquid left in the bowl is good for making soup or stock.
	Be careful it will be very hot.
Ο	Leave gaps between pieces of food.
Ο	Stir large amounts half way through cooking.
Ο	Similar sized pieces of food cook more evenly.
Ο	If steaming more than 1 type of food, if something needs
	less time, add it later.
Ο	If you lift the feed chute lid or remove the splashguard,
	steam will escape and cooking may take longer.
Ο	Food will continue cooking when your Stand Mixer
	switches off, so remove food immediately.
Ο	If your food’s not cooked enough, reset the time. You
	may need to top up with water.
Ο	The cooking times are a guide only. Always check that
	food is thoroughly cooked before eating.
Ο	Do not allow the unit to boil dry, top up with water as
	necessary.

Display Screen Explained

Tap this icon to open the settings menu.

Tap this icon to open the pre-set programmes menu.

Tap this icon to weigh ingredients into the bowl.

Shows the time selected in hours (h), minutes (m) and seconds (s).

		Shows the stir interval selected.
		If an intermittent speed (2 Æ 4) is selected, the outer ring will progressively increase and
		the appliance will stir when it is full.
		Shows the temperature selected.
		A pulsing red background indicates the machine is in heating mode.
		A solid red background indicates the machine has reached the set temperature.
		Indicates that a setting (time, speed or temperature) cannot be adjusted.
	Status Information	Text here shows status information.
		Indicates that the bowl, its contents and any parts being used are hot. Please handle with
		care.
		Indicates that the appliance is connected to a WiFi network.
		Indicates that the appliance is in the high speed high temperature mode (HSHT)
		Turn the control dial anti-clockwise to use stir intervals and pulse.
		Turn the control dial clockwise to use continuous speeds min - max.

8
