Kenwood FVZ201ELF2, FVZ201ERF2 PARTS LIST

Download
Page 1
FVZ201ELF2/ERF2

EXPLODED VIEW (UNIT)

BA
A
M3x3
B
M2x2
C
M5x6
D
M2.6x3
E
M2.6x5
F
M3x5
G
φ2x6
H
φ3x5
1
:
N09-6131-05
:
N09-6132-05
:
N34-5006-48
:
N35-2603-48
:
N35-2605-48
:
N35-3005-48
:
N82-2006-48
:
N83-3005-41
C
C
*
*
200
F
VDM1
x2
F
D
F
F
D
H
x2
F
x2
C
F
F
2
D
D
FC2
FC1
E
240
E
x3
NAVI BOARD
(W02-)
3
WH1
(X25-)
G
(A/2)
G 743
(X89-)
A
F
215
B
E
E
(X25-) (B/2)
WH2
F
B
F
F
PA1
Parts with the exploded numbers larger than 700 are not supplied.
Illustration is FVZ201ERF2.
*
29
Page 2

FVZ201ELF2/ERF2

PARTS LIST

✽ New parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert.
A
Ref. No.
N d d
Parts No. Description
e
w
FVZ201ELF2/ERF2
200 2B A01-2815-12 METALLIC CABINET PA1 3A
FC1 2A E39-0551-15 FLAT CABLE (50PIN) FC2 2A E39-0585-05 FLAT CABLE (32PIN) WH1 3A E39-0552-05 WIRING HARNESS (3PIN) WH2 3A E39-0553-15 WIRING HARNESS (5PIN)
215 2B F09-1234-05 CAP
✽
A64-3046-13 PANEL ASSY
Desti-
nation
A
Ref. No.
C31 C92-1791-05 ELECTRO 220UF 6.3WV C34 CK73GB1H102K CHIP C 1000PF K C35 CC73GCH1H221J CHIP C 220PF J C37,38 CC73GCH1H221J CHIP C 220PF J C39 C92-0671-05 ELECTRO 10UF 16WV
C41,42 CC73GCH1H101J CHIP C 100PF J C43 CK73GB1H103K CHIP C 0.010UF K C45 CK73GB1H102K CHIP C 1000PF K C46 CK73GB1H103K CHIP C 0.010UF K C47 CC73GCH1H221J CHIP C 220PF J
N d d
Parts No. Description
e
w
Desti-
nation
A2B B2BN09-6132-05 MACHINE SCREW (M2X2,BIND) C1B D2A E3AN35-2605-48
F3B G3AN82-2006-48
240 3A✽W02-3398-15 NAVI BOARD VDM1 2A X92-4750-00 MECHANISM ASSY (DVS-3030)
✽
N09-6131-05 MACHINE SCREW (M3X3)
✽
N34-5006-48 TRUSS HEAD MACHIN SCREW
✽
N35-2603-48
✽
N35-3005-48
BINDING HEAD MACHINE SCREW BINDING HEAD MACHINE SCREW
BINDING HEAD MACHINE SCREW BINDING HEAD TAPTITE SCREW

SWITCH UNIT (X25-9740-00)

C10 CK73GB1C104K CHIP C 0.10UF K CN10 E41-0362-05 PIN ASSY
CN11 E40-5168-05 PIN ASSY R1,2 RK73GB2A102J CHIP R 1.0K J 1/10W S1,2 S70-0884-05 TACT SWITCH D1 RD5.6S ZENER DIODE A10 W02-3382-05 ELECTRIC CIRCUIT MODULE

DAUGHTER UNIT (X89-2622-72)

C1 C92-0040-05 CHIP-ELE 47UF 16WV C2,3 CC73GCH1H221J CHIP C 220PF J C5 CC73GCH1H220J CHIP C 22PF J C6 C92-1791-05 ELECTRO 220UF 6.3WV C9 CC73GCH1H221J CHIP C 220PF J
C10 CK73FB1C334K CHIP C 0.33UF K C11 CK73FB1C105K CHIP C 1.0UF K C12 CC73GCH1H101J CHIP C 100PF J C13 CK73FB1C105K CHIP C 1.0UF K C14 C92-1791-05 ELECTRO 220UF 6.3WV
C15,16 CC73GCH1H221J CHIP C 220PF J C18 C92-1791-05 ELECTRO 220UF 6.3WV C19 CK73GB1H103K CHIP C 0.010UF K C20 CC73GCH1H221J CHIP C 220PF J C21 CC73GCH1H101J CHIP C 100PF J
C22,23 CK73FB1A225K CHIP C 2.2UF K C24 CK73GB1C104K CHIP C 0.10UF K C25,26 CC73GCH1H221J CHIP C 220PF J C28 CK73GB1C104K CHIP C 0.10UF K C29 CC73GCH1H221J CHIP C 220PF J
C30 CC73GCH1H471J CHIP C 470PF J
E1 : FVZ201ELF2 E2 : FVZ201ERF2
C48 CK73GB1C104K CHIP C 0.10UF K C50 CC73GCH1H221J CHIP C 220PF J C53 CK73GB1C104K CHIP C 0.10UF K C54,55 CK73GB1H472K CHIP C 4700PF K C56 CC73GCH1H221J CHIP C 220PF J
C57 CK73GB1H222K CHIP C 2200PF K C58 CK73GB1C104K CHIP C 0.10UF K C59 C92-0671-05 ELECTRO 10UF 16WV C60 CK73FB1C334K CHIP C 0.33UF K C61 CK73GB1H103K CHIP C 0.010UF K
CN1 E41-0401-05 J1 E56-0843-05 J3 E58-0867-15 RECTANGULAR RECEPTACLE J4 E11-0635-05 MINIATURE PHONE JACK J5 E11-0634-05 MINIATURE PHONE JACK
J6 E58-0906-05 RECTANGULAR RECEPTACLE L1 L92-0315-05 CHIP FERRITE
L2-4 L92-0340-05 CHIP FERRITE H2AN83-3005-41 PAN HEAD TAPTITE SCREW CP1 R90-0727-05 MULTI-COMP 120 X4
R1 RK73EB2E101J CHIP R 100 J 1/4W R2 RK73EB2E202J CHIP R 2.0K J 1/4W R3 RK73EB2E102J CHIP R 1.0K J 1/4W R4 RK73EB2E101J CHIP R 100 J 1/4W
R5 RK73EB2E223J CHIP R 22K J 1/4W R6 RK73EB2E202J CHIP R 2.0K J 1/4W R7 RK73EB2E102J CHIP R 1.0K J 1/4W R8 RK73GB2A471J CHIP R 470 J 1/10W R10 RK73EB2E223J CHIP R 22K J 1/4W
R20 RK73EB2E151J CHIP R 150 J 1/4W R21 RK73GB2A392J CHIP R 3.9K J 1/10W R24 RK73GB2A103J CHIP R 10K J 1/10W R25 RK73GB2A473J CHIP R 47K J 1/10W R27 RK73GB2A473J CHIP R 47K J 1/10W
R28 RK73GB2A682J CHIP R 6.8K J 1/10W R29 RK73EB2E620J CHIP R 62 J 1/4W R30 RK73GB2A223J CHIP R 22K J 1/10W R34 RK73GB2A102J CHIP R 1.0K J 1/10W R35 RK73EB2E121J CHIP R 120 J 1/4W
R38 RK73GB2A223J CHIP R 22K J 1/10W R39 RK73GB2A103J CHIP R 10K J 1/10W R41 RK73EB2E620J CHIP R 62 J 1/4W R42 RK73EB2E681J CHIP R 680 J 1/4W
FLAT CABLE CONNECTOR (32PIN) CYLINDRICAL RECEPTACLE (13PIN)
Indicates safety critical components.
30
30
Page 3
PARTS LIST
✽ New parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert.
A
Ref. No.
R44,45 RK73GB2A103J CHIP R 10K J 1/10W R46 RK73GB2A102J CHIP R 1.0K J 1/10W R47 RK73GB2A223J CHIP R 22K J 1/10W R49 RK73GB2A223J CHIP R 22K J 1/10W R50 RK73GB2A103J CHIP R 10K J 1/10W
N d d
Parts No. Description
e
w
Desti-
nation
FVZ201ELF2/ERF2
DAUGHTER UNIT (X89-2622-72)
A
Ref. No.
C125-127 CK73GB1H104K CHIP C 0.10UF K C128 C92-1811-08 ELECTRO 47UF 35WV C129,130 CK73GB1H104K CHIP C 0.10UF K C132,133 CC73GCH1H681J CHIP C 680PF J C134 C92-1776-05 ELECTRO 470UF 16WV
N d d
Parts No. Description
e
w
Desti-
nation
R51 RK73EB2E750J CHIP R 75 J 1/4W R52 RK73EB2E223J CHIP R 22K J 1/4W R53 RK73EB2E471J CHIP R 470 J 1/4W R54 RK73EB2E223J CHIP R 22K J 1/4W R55,56 RK73GB2A223J CHIP R 22K J 1/10W
R57 RK73EB2E620J CHIP R 62 J 1/4W R58 RK73GB2A223J CHIP R 22K J 1/10W R59 RK73GB2A472J CHIP R 4.7K J 1/10W R60 RK73EB2E223J CHIP R 22K J 1/4W R61,62 RK73GB2A471J CHIP R 470 J 1/10W
R64 RK73GB2A472J CHIP R 4.7K J 1/10W R67 RK73EB2E223J CHIP R 22K J 1/4W R68,69 RK73EB2E221J CHIP R 220 J 1/4W R70,71 RK73EB2E151J CHIP R 150 J 1/4W R72,73 RK73EB2E223J CHIP R 22K J 1/4W
R74 RK73GB2A472J CHIP R 4.7K J 1/10W R75 RK73EB2E223J CHIP R 22K J 1/4W R76 RK73EB2E101J CHIP R 100 J 1/4W R77 RK73EB2E151J CHIP R 150 J 1/4W
D1-5 RD6.8MW ZENER DIODE D7 RD5.6S ZENER DIODE D9-12 RD5.6S ZENER DIODE D15 DAN202U DIODE IC1 BA05FP ANALOGUE IC
IC2 TC74VHCT08AFT MOS-IC IC3 NJM2118V ANALOGUE IC IC4 TC74HC132AFE MOS-IC Q1 DTC143EU A DIGITAL TRANSISTOR Q2 DTA114EUA DIGITAL TRANSISTOR
Q3 2SA1576A TRANSISTOR Q4 2SC4081 TRANSISTOR Q6 DTC143TU A DIGITAL TRANSIST OR Q8,9 DTC143TU A DIGIT AL TRANSIST OR

NAVI BOARD (W02-3398-15)

C101,102 CK73GB1H104K CHIP C 0.10UF K C105,106 CK73GB1H104K CHIP C 0.10UF K C107,108 C90-5512-08 ELECTRO 1000UF 25WV C109 CK73GB1H103K CHIP C 0.010UF K C110 C92-1811-08 ELECTRO 47UF 35WV
C111 CK73GB1H103K CHIP C 0.010UF K C112 C92-1807-08 ELECTRO 220UF 35WV C113,114 CC73GCH1H471J CHIP C 470PF J C115,116 CK73GB1H104K CHIP C 0.10UF K C117 CK73FB1C334K CHIP C 0.33UF K
C118 C93-1325-08 CHIP C 1UF K C119 C92-1810-08 ELECTRO 47UF 6.3WV C120-122 CK73GB1H104K CHIP C 0.10UF K C123 CK73FB1C334K CHIP C 0.33UF K C124 C93-1325-08 CHIP C 1UF K
E1 : FVZ201ELF2 E2 : FVZ201ERF2
C135 C92-1808-08 ELECTRO 1500UF 6.3WV C136,137 CK73GB1H104K CHIP C 0.10UF K C139,140 CK73GB1H104K CHIP C 0.10UF K C141 CK73GB1H103K CHIP C 0.010UF K C142 CK73GB1H104K CHIP C 0.10UF K
C143,144 CC73GCH1H681J CHIP C 680PF J C145 C92-1808-08 ELECTRO 1500UF 6.3WV C146 C92-1806-08 ELECTRO 1000UF 10WV C147-153 CK73GB1H104K CHIP C 0.10UF K C154 C92-1776-05 ELECTRO 470UF 16WV
C155,156 CK73GB1H104K CHIP C 0.10UF K C157 C92-1809-08 ELECTRO 100UF 16WV C159 C93-1325-08 CHIP C 1UF K C160 C90-5511-08 ELECTRO 270UF 16WV C162 C93-1325-08 CHIP C 1UF K
C216 C93-1327-08 CHIP C 10UF 16WV C218 CK73GB1H103K CHIP C 0.010UF K C219 C93-1325-08 CHIP C 1UF K C220 CK73GB1H103K CHIP C 0.010UF K C221 C93-1325-08 CHIP C 1UF K
C251 CK73GB1H472K CHIP C 4700PF K C252 C92-1805-08 ELECTRO 22UF 16WV C253 C93-1325-08 CHIP C 1UF K C254,255 CK73GB1H102K CHIP C 1000PF K C256 CK73GB1H103K CHIP C 0.010UF K
C263 CK73GB1H472K CHIP C 4700PF K C264,265 CK73GB1H104K CHIP C 0.10UF K C266,267 CK73GB1H472K CHIP C 4700PF K C301 CK73GB1H104K CHIP C 0.10UF K C303,304 CC73GCH1H221J CHIP C 220PF J
C307 CK73GB1H104K CHIP C 0.10UF K C309,310 CK73GB1H104K CHIP C 0.10UF K C312 CK73GB1H104K CHIP C 0.10UF K C320 CK73GB1H392K CHIP C 3900PF K C321 C93-1325-08 CHIP C 1UF K
C322 CK73GB1H392K CHIP C 3900PF K C323 CK73GB1H102K CHIP C 1000PF K C326 CK73GB1H104K CHIP C 0.10UF K C329 CK73GB1H392K CHIP C 3900PF K C331 CK73GB1H104K CHIP C 0.10UF K
C332 C93-1327-08 CHIP C 10UF 16WV C333 CK73GB1H104K CHIP C 0.10UF K C334 C93-1325-08 CHIP C 1UF K C521 CK73HB1C103K CHIP C 0.010UF K C522-527 CC73HCH1H100D CHIP C 10PF D
C528 CK73HB1C103K CHIP C 0.010UF K C529,530 CK73HB1A473K CHIP C 0.047UF K C531 CK73HB1H102K CHIP C 1000PF K C532 CK73HB1C103K CHIP C 0.010UF K C533 CK73HB1A473K CHIP C 0.047UF K
Indicates safety critical components.
31
Page 4
FVZ201ELF2/ERF2
PARTS LIST
✽ New parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert.
A
Ref. No.
C534 CK73HB1H102K CHIP C 1000PF K C535 CK73HB1A473K CHIP C 0.047UF K C536-543 CK73HB1C103K CHIP C 0.010UF K C544 C93-1325-08 CHIP C 1UF K C546 CC73HCH1H100D CHIP C 10PF D
N d d
Parts No. Description
e
w
Desti-
nation
NAVI BOARD (W02-3398-15)
A
Ref. No.
C742 CC73GCH1H471J CHIP C 470PF J C743 C93-1327-08 CHIP C 10UF 16WV C744 CK73GB1H104K CHIP C 0.10UF K C745 CK73GB1H472K CHIP C 4700PF K C746 CC73GCH1H471J CHIP C 470PF J
N d d
Parts No. Description
e
w
Desti-
nation
C548,549 CC73GCH1H470J CHIP C 47PF J C551 CC73GCH1H221J CHIP C 220PF J C552 C93-1327-08 CHIP C 10UF 16WV C553 C92-1825-08 C554,555 CK73GB1H103K CHIP C 0.010UF K
C556,557 CC73GCH1H101J CHIP C 100PF J C561 CK73GB1H104K CHIP C 0.10UF K C562 CK73GB1H103K CHIP C 0.010UF K C641 CK73GB1H104K CHIP C 0.10UF K C642 CC73GCH1H270J CHIP C 27PF J
C643 CC73GCH1H470J CHIP C 47PF J C644 CK73GB1H104K CHIP C 0.10UF K C645 CK73GB1H103K CHIP C 0.010UF K C646 CK73GB1H104K CHIP C 0.10UF K C647,648 C93-1327-08 CHIP C 10UF 16WV
C652 CK73GB1H103K CHIP C 0.010UF K C684 CK73GB1H103K CHIP C 0.010UF K C687 CK73GB1H103K CHIP C 0.010UF K C701 CC73GCH1H100D CHIP C 10PF D C702 CK73GB1H103K CHIP C 0.010UF K
C703 CK73GB1H104K CHIP C 0.10UF K C704 CK73GB1H472K CHIP C 4700PF K C705 CK73GB1H104K CHIP C 0.10UF K C706 CK73GB1H472K CHIP C 4700PF K C707 CC73GCH1H471J CHIP C 470PF J
C708 CK73GB1H104K CHIP C 0.10UF K C709,710 CK73GB1H472K CHIP C 4700PF K C711 CC73GCH1H100D CHIP C 10PF D C712 CK73GB1H103K CHIP C 0.010UF K C713 CK73GB1H104K CHIP C 0.10UF K
TANTALUM
C 4.7UF 25WV
C749 CK73GB1H102K CHIP C 1000PF K C750 CC73GCH1H100D CHIP C 10PF D C751 C93-1325-08 CHIP C 1UF K C752 CK73GB1H472K CHIP C 4700PF K C753 CC73GCH1H471J CHIP C 470PF J
C754 CK73GB1H472K CHIP C 4700PF K C755 C93-1325-08 CHIP C 1UF K C756 CK73GB1H472K CHIP C 4700PF K C757 CC73GCH1H471J CHIP C 470PF J C758 CK73GB1H472K CHIP C 4700PF K
C759 C93-1325-08 CHIP C 1UF K C760 CK73GB1H472K CHIP C 4700PF K C761 CC73GCH1H471J CHIP C 470PF J C762 CK73GB1H472K CHIP C 4700PF K C763 C93-1325-08 CHIP C 1UF K
C764 CK73GB1H472K CHIP C 4700PF K C765 CC73GCH1H471J CHIP C 470PF J C766 CK73GB1H472K CHIP C 4700PF K C767 CC73GCH1H100D CHIP C 10PF D C770,771 CC73HCH1H100D CHIP C 10PF D
C772,773 CK73GB1H103K CHIP C 0.010UF K C774-776 CC73HCH1H100D CHIP C 10PF D C778-780 CC73HCH1H100D CHIP C 10PF D C781 CK73GB1H102K CHIP C 1000PF K C782 CK73GB1H103K CHIP C 0.010UF K
C783 CK73GB1H102K CHIP C 1000PF K C784 CK73GB1H103K CHIP C 0.010UF K C785 CK73GB1H102K CHIP C 1000PF K C786 CK73GB1H472K CHIP C 4700PF K C787-789 CC73HCH1H100D CHIP C 10PF D
C714,715 CK73GB1H472K CHIP C 4700PF K C716,717 CC73GCH1H471J CHIP C 470PF J C718 CC73GCH1H100D CHIP C 10PF D C719 CK73GB1H472K CHIP C 4700PF K C720 CC73GCH1H100D CHIP C 10PF D
C721 CK73GB1H472K CHIP C 4700PF K C722 CK73GB1H104K CHIP C 0.10UF K C723 CC73GCH1H100D CHIP C 10PF D C724-726 CK73GB1H104K CHIP C 0.10UF K C727,728 CC73GCH1H100D CHIP C 10PF D
C730,731 CK73GB1H104K CHIP C 0.10UF K C732,733 CK73GB1H103K CHIP C 0.010UF K C734 C93-1325-08 CHIP C 1UF K C735 C93-1327-08 CHIP C 10UF 16WV C736 C93-1325-08 CHIP C 1UF K
C737 CC73GCH1H471J CHIP C 470PF J C738 CK73GB1H472K CHIP C 4700PF K C739 C93-1327-08 CHIP C 10UF 16WV C740 CK73GB1H104K CHIP C 0.10UF K C741 CK73GB1H472K CHIP C 4700PF K
E1 : FVZ201ELF2 E2 : FVZ201ERF2
32
C790,791 C93-1327-08 CHIP C 10UF 16WV C793 CK73GB1H104K CHIP C 0.10UF K C794 C93-1325-08 CHIP C 1UF K C795 CK73GB1H102K CHIP C 1000PF K C902 CK73GB1H103K CHIP C 0.010UF K
C954 CK73GB1H682K CHIP C 6800PF K C957 CK73GB1H152K CHIP C 1500PF K C958,959 CK73GB1H473K CHIP C 0.047UF K C960 CK73GB1H103K CHIP C 0.010UF K C961 CK73GB1H104K CHIP C 0.10UF K
C962 CC73GCH1H151J CHIP C 150PF J C963 CC73GCH1H101J CHIP C 100PF J C964-967 CK73GB1H104K CHIP C 0.10UF K
CN100 E58-0976-08 RECTANGULAR RECEPTACLE CN110 E41-2005-08 PIN ASSY CN320 E41-2006-08 FLAT CABLE CONNECTOR CN350 E41-2003-08 FLAT CABLE CONNECTOR CN400 E58-0921-08 RECTANGULAR RECEPTACLE
CN600 E41-2004-08 PIN ASSY
Indicates safety critical components.
Page 5
PARTS LIST
✽ New parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert.
A
Ref. No.
CN710 E41-2002-08 PIN ASSY L101 L33-1171-08 CHOKE COIL
L102,103 L33-1855-05 CHOKE COIL 100UH L104 L33-1955-08 CHOKE COIL L105 L33-1855-05 CHOKE COIL 100UH L521 L33-1951-08 CHOKE COIL 39UH
L522 L33-1952-08 CHOKE COIL 100UH L523 L33-1951-08 CHOKE COIL 39UH L731 L92-0330-05 CHIP FERRITE X101 L78-0823-08 RESONATOR 4MHz X701 L78-0884-08 RESONATOR
X702 L78-0886-08 RESONATOR 32.768KHz R101,102 RK73EB2E392J CHIP R 3.9K J 1/4W
R103 R92-3450-08 R104 R92-3437-08 CHIP R 34.8K J 1/10W R105 RK73EB2E103J CHIP R 10K J 1/4W R106 RK73EB2E223J CHIP R 22K J 1/4W
R107 R92-3446-08 CHIP R 8.06K J 1/10W R108 R92-3424-08 CHIP R 10K J 1/10W R109 R92-3443-08 CHIP R 49.9K J 1/10W R110 R92-3452-08 CHIP R 180 J 1W R111 R92-3429-08 CHIP R 150K J 1/10W
R112 RK73EB2E223J CHIP R 22K J 1/4W R113 R92-3434-08 CHIP R 24.9K J 1/10W R114 R92-3448-08 CHIP R 8.66K J 1/10W R115 RK73EB2E103J CHIP R 10K J 1/4W R116 R92-3424-08 CHIP R 10K J 1/4W
R117 R92-3425-08 CHIP R 100K J 1/4W R118 R92-3441-08 CHIP R 46.4K J 1/10W R119 R92-3425-08 CHIP R 100K J 1/4W R120 R92-3429-08 CHIP R 150K J 1/4W R121,122 R92-3434-08 CHIP R 24.9K J 1/10W
R123 R92-3433-08 CHIP R 22.6K J 1/10W R124 RK73GB2A104J CHIP R 100K J 1/10W R125 R92-3430-08 CHIP R 18.2K J 1/10W R126 R92-3425-08 CHIP R 100K J 1/10W R127 RK73GB2A104J CHIP R 100K J 1/10W
R130 RK73GB2A104J CHIP R 100K J 1/10W R131-133 R92-3434-08 CHIP R 24.9K J 1/10W R134 RK73GB2A104J CHIP R 100K J 1/10W R135 R92-3428-08 CHIP R 15K J 1/10W R136 R92-3434-08 CHIP R 24.9K J 1/10W
R137 RK73GB2A104J CHIP R 100K J 1/10W R138 R92-3434-08 CHIP R 24.9K J 1/10W R139 R92-3426-08 CHIP R 12.1K J 1/10W R140,141 RK73GB2A104J CHIP R 100K J 1/10W R142 RK73HB1J000J CHIP R 0.0 J 1/16W
R143 R92-3434-08 CHIP R 24.9K J 1/10W R144 RK73GB2A104J CHIP R 100K J 1/10W R145,146 R92-3434-08 CHIP R 24.9K J 1/10W R147 RK73EB2E222J CHIP R 2.2K J 1/4W R148 RK73EB2E102J CHIP R 1.0K J 1/4W
R149 RK73EB2E331J CHIP R 330 J 1/4W
E1 : FVZ201ELF2 E2 : FVZ201ERF2
N d d
Parts No. Description
e
w
12.08096MHz
Desti-
nation
FVZ201ELF2/ERF2
NAVI BOARD (W02-3398-15)
A
Ref. No.
R150,151 RK73HB1J470J CHIP R 47 J 1/16W R152 RK73HB1J223J CHIP R 22K J 1/16W R153 RK73HB1J103J CHIP R 10K J 1/16W R154 RK73HB1J223J CHIP R 22K J 1/16W R155,156 R92-3451-08 CHIP R 3.3 J 1/10W
R157 RK73HB1J222J CHIP R 2.2K J 1/16W R158 R92-3432-08 CHIP R 22.1K J 1/10W R159 R92-3476-08 CHIP R 4.75K J 1/10W R160 R92-3432-08 CHIP R 22.1K J 1/10W R161 R92-3427-08 CHIP R 13K J 1/10W
R162 RK73HB1J222J CHIP R 2.2K J 1/16W R163 RK73HB1J102J CHIP R 1.0K J 1/16W R164 RK73EB2E331J CHIP R 330 J 1/4W R165 RK73EB2E222J CHIP R 2.2K J 1/4W R166 RK73EB2E102J CHIP R 1.0K J 1/4W
R167,168 RK73HB1J470J CHIP R 47 J 1/16W R169 RK73HB1J103J CHIP R 10K J 1/16W R170 RK73HB1J223J CHIP R 22K J 1/16W R172 RK73HB1J473J CHIP R 47K J 1/16W R173 RK73HB1J104J CHIP R 100K J 1/16W
R175,176 R92-3451-08 CHIP R 3.3 J 1/10W R177-180 R92-3423-08 CHIP R 1K J 1/10W R181 RK73HB1J104J CHIP R 100K J 1/16W R182 R92-3461-08 CHIP R 16K J 1/10W R183 R92-3445-08 CHIP R 5.09K J 1/10W
R184,185 R92-3434-08 CHIP R 24.9K J 1/10W R186 R92-3447-08 CHIP R 8.25K J 1/10W R187 RK73HB1J331J CHIP R 330 J 1/16W R188,189 RK73HB1J102J CHIP R 1.0K J 1/16W R190 RK73HB1J472J CHIP R 4.7K J 1/16W
R191,192 RK73HB1J104J CHIP R 100K J 1/16W R195 RK73HB1J102J CHIP R 1.0K J 1/16W R202 RK73HB1J223J CHIP R 22K J 1/16W R203 RK73HB1J104J CHIP R 100K J 1/16W R205 RK73HB1J222J CHIP R 2.2K J 1/16W
R207 RK73HB1J000J CHIP R 0.0 J 1/16W R209 RK73HB1J471J CHIP R 470 J 1/16W R238,239 RK73HB1J223J CHIP R 22K J 1/16W R240 RK73HB1J000J CHIP R 0.0 J 1/16W R241 R92-3436-08 CHIP R 3.01K J 1/10W
R242-244 R92-3423-08 CHIP R 1K J 1/10W R251,252 R253,254 RK73EB2E122J CHIP R 1.2K J 1/4W R256 RK73EB2E122J CHIP R 1.2K J 1/4W R257 RK73EB2E272J CHIP R 2.7K J 1/4W
R258 RK73HB1J472J CHIP R 4.7K J 1/16W R259 RK73EB2E272J CHIP R 2.7K J 1/4W R260,261 RK73HB1J563J CHIP R 56K J 1/16W R263 RK73EB2E223J CHIP R 22K J 1/4W R264 RK73HB1J223J CHIP R 22K J 1/16W
R265 RK73HB1J103J CHIP R 10K J 1/16W R266 RK73HB1J104J CHIP R 100K J 1/16W R267 RK73HB1J393J CHIP R 39K J 1/16W R268 RK73HB1J105J CHIP R 1.0M J 1/16W R269 RK73HB1J102J CHIP R 1.0K J 1/16W
N d d
Parts No. Description
e
w
✽
R92-3477-08 CHIP R 10K J 1/4W
Indicates safety critical components.
Desti-
nation
33
Page 6
FVZ201ELF2/ERF2
PARTS LIST
✽ New parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert.
A
Ref. No.
R271 RK73HB1J103J CHIP R 10K J 1/16W R272 R92-3431-08 CHIP R 200 J 1/10W R273 R92-3435-08 CHIP R 301 J 1/10W R274 RK73HB1J103J CHIP R 10K J 1/16W R275 RK73HB1J104J CHIP R 100K J 1/16W
N d d
Parts No. Description
e
w
Desti-
nation
NAVI BOARD (W02-3398-15)
A
Ref. No.
R571 RK73HB1J472J CHIP R 4.7K J 1/16W R572 RK73HB1J223J CHIP R 22K J 1/16W R611 RK73HB1J000J CHIP R 0.0 J 1/16W R646,647 RK73HB1J000J CHIP R 0.0 J 1/16W R648 RK73HB1J222J CHIP R 2.2K J 1/16W
N d d
Parts No. Description
e
w
Desti-
nation
R277 RK73HB1J103J CHIP R 10K J 1/16W R278 RK73HB1J224J CHIP R 220K J 1/16W R279 RK73HB1J000J CHIP R 0.0 J 1/16W R281 RK73EB2E102J CHIP R 1.0K J 1/4W R301 RK73HB1J163J CHIP R 16K J 1/16W
R303 RK73HB1J163J CHIP R 16K J 1/16W R306 RK73HB1J822J CHIP R 8.2K J 1/16W R308 RK73HB1J563J CHIP R 56K J 1/16W R309 RK73HB1J822J CHIP R 8.2K J 1/16W R311 RK73HB1J563J CHIP R 56K J 1/16W
R322 RK73EB2E102J CHIP R 1.0K J 1/4W R330 RK73HB1J000J CHIP R 0.0 J 1/16W R332 RK73HB1J103J CHIP R 10K J 1/16W R333 RK73HB1J102J CHIP R 1.0K J 1/16W R336 RK73HB1J133J CHIP R 13K J 1/16W
R337 RK73HB1J222J CHIP R 2.2K J 1/16W R338 RK73HB1J273J CHIP R 27K J 1/16W R339 RK73HB1J000J CHIP R 0.0 J 1/16W R340,341 RK73HB1J133J CHIP R 13K J 1/16W R342 RK73HB1J122J CHIP R 1.2K J 1/16W
R343 RK73HB1J822J CHIP R 8.2K J 1/16W R344 R92-3435-08 CHIP R 301 J 1/10W R345 R92-3431-08 CHIP R 200 J 1/10W R348 RK73HB1J104J CHIP R 100K J 1/16W R359-361 RK73HB1J102J CHIP R 1.0K J 1/16W
R465 R92-3442-08 CHIP R 47.5K J 1/10W R501,502 RK73EB2E101J CHIP R 100 J 1/4W R504,505 RK73HB1J000J CHIP R 0.0 J 1/16W R517 RK73HB1J223J CHIP R 22K J 1/16W R521 R92-3424-08 CHIP R 10K J 1/10W
R649 RK73HB1J102J CHIP R 1.0K J 1/16W R650 RK73HB1J471J CHIP R 470 J 1/16W R651 RK73HB1J222J CHIP R 2.2K J 1/16W R652-655 RK73HB1J100J CHIP R 10 J 1/16W R690
R691 R92-3435-08 CHIP R 301 J 1/10W R692,693 RK73HB1J000J CHIP R 0.0 J 1/16W R700,701 RK73HB1J473J CHIP R 47K J 1/16W R702 RK73HB1J102J CHIP R 1.0K J 1/16W R711,712 R92-2052-05 CHIP R 0 OHM J 1/10W
R713 RK73HB1J220J CHIP R 22 J 1/16W R714 RK73HB1J223J CHIP R 22K J 1/16W R716 RK73HB1J220J CHIP R 22 J 1/16W R717 RK73HB1J000J CHIP R 0.0 J 1/16W R718 RK73HB1J105J CHIP R 1.0M J 1/16W
R719 RK73HB1J331J CHIP R 330 J 1/16W R720 RK73HB1J000J CHIP R 0.0 J 1/16W R729 RK73HB1J223J CHIP R 22K J 1/16W R730 RK73HB1J123J CHIP R 12K J 1/16W R731 RK73HB1J103J CHIP R 10K J 1/16W
R733 RK73HB1J000J CHIP R 0.0 J 1/16W R736 RK73GB2A106J CHIP R 10M J 1/10W R737 RK73HB1J472J CHIP R 4.7K J 1/16W R739-741 RK73HB1J102J CHIP R 1.0K J 1/16W R742 RK73HB1J102J CHIP R 1.0K J 1/16W
R743 RK73HB1J220J CHIP R 22 J 1/16W R751 RK73HB1J000J CHIP R 0.0 J 1/16W R752 RK73HB1J222J CHIP R 2.2K J 1/16W R753 RK73HB1J000J CHIP R 0.0 J 1/16W R754-757 RK73HB1J820J CHIP R 82 J 1/16W
✽
R92-3480-08 CHIP R 576 J 1/10W
R522 R92-3439-08 CHIP R 40.2K J 1/10W R523,524 R92-3210-05 CHIP R 30 J 1W R525 RK73HB1J223J CHIP R 22K J 1/16W R526 R92-3424-08 CHIP R 10K J 1/10W R527 R92-3438-08 CHIP R 37.4K J 1/10W
R528 R92-3424-08 CHIP R 10K J 1/10W R529 R92-3427-08 CHIP R 13K J 1/10W R530 RK73HB1J124J CHIP R 120K J 1/16W R531,532 RK73HB1J473J CHIP R 47K J 1/16W R534 RK73HB1J000J CHIP R 0.0 J 1/16W
R535 RK73HB1J102J CHIP R 1.0K J 1/16W R536,537 RK73HB1J105J CHIP R 1.0M J 1/16W R539-542 RK73HB1J105J CHIP R 1.0M J 1/16W R547 RK73HB1J101J CHIP R 100 J 1/16W R548 RK73HB1J220J CHIP R 22 J 1/16W
R549 RK73HB1J101J CHIP R 100 J 1/16W R550 RK73HB1J220J CHIP R 22 J 1/16W R552 RK73HB1J000J CHIP R 0.0 J 1/16W R557 RK73HB1J472J CHIP R 4.7K J 1/16W R558,559 RK73HB1J103J CHIP R 10K J 1/16W
E1 : FVZ201ELF2 E2 : FVZ201ERF2
34
R758 RK73HB1J000J CHIP R 0.0 J 1/16W R763 RK73HB1J220J CHIP R 22 J 1/16W R764,765 RK73HB1J103J CHIP R 10K J 1/16W R766 RK73HB1J102J CHIP R 1.0K J 1/16W R767 RK73HB1J222J CHIP R 2.2K J 1/16W
R768 RK73HB1J473J CHIP R 47K J 1/16W R769,770 RK73HB1J102J CHIP R 1.0K J 1/16W R771 RK73HB1J222J CHIP R 2.2K J 1/16W R773-777 RK73HB1J000J CHIP R 0.0 J 1/16W R778 RK73HB1J222J CHIP R 2.2K J 1/16W
R781 RK73HB1J103J CHIP R 10K J 1/16W R782 RK73HB1J104J CHIP R 100K J 1/16W R783 RK73HB1J103J CHIP R 10K J 1/16W R835 RK73HB1J000J CHIP R 0.0 J 1/16W R954,955 R92-3428-08 CHIP R 15K J 1/10W
R958 RK73HB1J000J CHIP R 0.0 J 1/16W R959 R92-3428-08 CHIP R 15K J 1/10W R960,961 RK73HB1J473J CHIP R 47K J 1/16W R962 R92-3481-08 CHIP R 0 J 1/4W R965 R92-3432-08 CHIP R 22.1K J 1/10W
Indicates safety critical components.
Page 7
PARTS LIST
✽ New parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert.
A
Ref. No.
R967,968 R92-3432-08 CHIP R 22.1K J 1/10W R969 R92-3442-08 CHIP R 47.5K J 1/10W R970 RK73HB1J683J CHIP R 68K J 1/16W R971 RK73HB1J223J CHIP R 22K J 1/16W R972 RK73HB1J000J CHIP R 0.0 J 1/16W
N d d
Parts No. Description
e
w
Desti-
nation
FVZ201ELF2/ERF2
NAVI BOARD (W02-3398-15)
A
Ref. No.
IC254 TC7WU04FU IC (INVERTOR) IC255 TC7W53FU IC (2-CHANNEL MULTIPLEXER) IC256 TC7SET08FU IC (IC) IC301 TA75S01F IC (OP AMP) IC306 TA75S01F IC (OP AMP)
N d d
Parts No. Description
e
w
Desti-
nation
R975 RK73HB1J000J CHIP R 0.0 J 1/16W R977 RK73HB1J000J CHIP R 0.0 J 1/16W R980 RK73HB1J101J CHIP R 100 J 1/16W RA551-556 RA558 R90-1536-08 CHIP R 22 J 1/32W
RA701-703 RA711 R90-1540-08 CHIP R 22K J 1/32W RA712 R90-1539-08 CHIP R 2.2 J 1/32W RA713 R90-1540-08 CHIP R 22K J 1/32W RA714 R90-1539-08 CHIP R 2.2 J 1/32W
RA715 R90-1540-08 CHIP R 22K J 1/32W RA716 R90-1539-08 CHIP R 2.2 J 1/32W RA717-721 RA751-754 RA755-770
RA771,772 RA908 R90-1538-08 CHIP R 150 J 1/32W RA951,952
D101 30D4 DIODE D102 EP05DA40 DIODE D103 U5ZA27C (TE24L) ZENER DIODE D104,105 RD16S ZENER DIODE D106 RD16FM ZENER DIODE
D107 1SS352 DIODE D108 1SS357 DIODE D109-112 EC20QS06 DIODE D113,114 1SS357 DIODE D115 EC20QS06 DIODE
D116 1SS357 DIODE D211 EP05DA40 DIODE D251 EP05DA40 DIODE D252 1SS352 DIODE D253 EP05DA40 DIODE
D301 1SS352 DIODE D521 1SS352 DIODE D522 1SS362 DIODE D781 1SS352 DIODE F521 L78-0887-08 FILTER
IC101 TC75W56FU IC IC102 S-80818ANNP IC IC103,104 BA9743AFV IC IC105 S-81233SGUP IC IC106 MB89935B IC
R90-1536-08 CHIP R 22 J 1/32W
R90-1536-08 CHIP R 22 J 1/32W
R90-1540-08 CHIP R 22K J 1/32W R90-1537-08 CHIP R 82 J 1/32W R90-1535-08 CHIP R 18 J 1/32W
R90-1538-08 CHIP R 150 J 1/32W R90-1538-08 CHIP R 150 J 1/32W
IC309 TC7SET08FU IC (IC) IC310 TA75S01F IC (OP AMP) IC502 TC7SET08FU IC (IC) IC521 - GPS RECEIVER IC522 L78-0885-08 IC
IC523 TA75W393FU IC IC524-526 TC7WU04FU IC (INVERTOR) IC551 TC7SH00FU IC IC561 TC7SH08FU IC (2ch AND GATE) IC641 CXA2106R IC
IC642 TC7SH00FU IC IC684 TC75S51FU IC IC701 - CORE1 IC731 S-817A15ANB IC IC732,733 TAR5S25 IC
IC734 S-817A15ANB IC IC751 TC7SB66FU IC IC752-755 HY57V281620HCI IC IC781 M5M5V416BTP70H IC IC782,783 TC7SH00FU IC
IC784 MBM29LV160BE90 IC IC951 SN65C1168NS IC IC952 TC7SET08FU IC (IC) IC954 TC7SET00FU IC IC955,956 TC7SET08FU IC (IC)
IC957 TC7SET00FU IC T101 2SA1576 TRANSISTOR T102 2SJ327Z FET T103,104 DTC144EU A DIGITAL TRANSISTOR T105,106 FMY6 TRANSISTOR
T107,108 HAT1038RJ FET T109 DTC143EU A DIGIT AL TRANSIST OR T110,111 FMY6 TRANSISTOR T112 2SA1576 TRANSISTOR T113 2SB1690K TRANSISTOR
T305 UMX18N TRANSISTOR T306 UMD3N TRANSISTOR T307 DTC143EU A DIGIT AL TRANSIST OR T309 DTC143EU A DIGIT AL TRANSIST OR T319 DTA143EU DIGIT AL TRANSIST OR
BAT10 W09-0741-08 BATTERY
IC107 UPC2409AHF IC IC108 UPC2905T IC (5V VOLTAGE REGULATOR) IC109 TC7SET08FU IC (IC) IC111 TC7SH00FU IC IC212 TAR5S30-TE85L IC
IC251 TD62604F IC
E1 : FVZ201ELF2 E2 : FVZ201ERF2
Indicates safety critical components.
35
Page 8
FVZ201ELF2/ERF2

SPECIFICATIONS

Navigation Section
Antenna....................................................................................... Micro-strip patched antenna
Receiver channel ........................................................................... Digital 8-channels parallel
Receiving frequency.......................................................................... 1575.42MHz (C/A code)
Receiving sensitivity................................................................................. Less than -130dBm
Positioning method............................................. Hybrid (GPS + Wheel Pulse + Gyro Sensor)
General
Operating voltage................................................................................ 14.4V DC (11V to 16V)
Consumed current........................................................................................... Less than 2.5A
Operational temperature range ....................................................................... -10°C to +55°C
Storage temperature range ............................................................................. -30°C to +85°C
Video output level (75Ω)..................................... 1Vp-p (Composite) / 0.7Vp-p (Analog RGB)
Audio output level (10kΩ) ........................................................................................... 1.2Vrms
Size
Navigation unit ................................................................. 163.0 (W) x 50 (H) x 160.5 (D) mm
Mass
Navigation unit ............................................................................................ 1100g (2.59 LBS)
6-7/16(W) x 2 (H) x 6-5/16 (D) in.
follows a policy of continuous advancements in development.
For this reason specifications may be changed without notice.
KENWOOD CORPORATION
2967-3, Ishikawa-machi, Hachioji-shi, Tokyo, 192-8525 Japan
KENWOOD USA CORPORATION
P.O. Box 22745, 2201 East Dominguez Street, Long Beach, CA 90801-5745, U.S.A.
KENWOOD ELECTRONICS CANADA INC.
6070 Kestrel Road, Mississauga, Ontario, Canada L5T 1S8
KENWOOD ELECTRONICS LATIN AMERICA S.A.
P.O. Box 55-2791 Paitilla, Plaza Credicorp Bank Panama, Piso 9, Oficina 901, Calle 50, Panama, Rep. de Panama
KENWOOD ELECTRONICS BRASIL LTDA.
Alameda Ministro Rocha Azevedo No. 456, Edificio Jaú, 10o Andar, Cerqueira César, Cep 0140-001, São Paulo-SP-Brasil
KENWOOD ELECTRONICS UK LIMITED
Kenwood House, Dwight Road, Watford, Herts, WD18 9EB, United Kingdom
KENWOOD ELECTRONICS DEUTSCHLAND GMBH
Rembrücker-Str. 15, 63150 Heusenstamm, Germany
KENWOOD ELECTRONICS FRANCE S.A.
13, Boulevard Ney, 75018 Paris, France
KENWOOD ELECTRONICS BELGIUM N.V.
Leuvensesteenweg 248 J, 1800 Vilvoorde, Belgium
KENWOOD ELECTRONICS ITALIA S.p.A.
Via G. Sirtori 7/9, 20129 Milano, Italy
KENWOOD IBÉRICA S.A.
Bolivia, 239-08020 Barcelona, Spain
KENWOOD ELECTRONICS AUSTRALIA PTY. LTD. (A.C.N. 001 499 074)
16 Giffnock Avenue, Centrecourt Estate, North Ryde, N.S.W. 2113, Australia
KENWOOD ELECTRONICS (HONG KONG) LTD.
Unit 3712-3724, Level 37, Tower 1, Metroplaza, 223 Hing Fong Road, Kwai Fong, N.T., Hong Kong
KENWOOD ELECTRONICS GULF FZE
P.O. Box 61318, Jebel Ali, Dubai, U.A.E.
KENWOOD ELECTRONICS (THAILAND) CO., LTD.
2019 New Pechburi Road, Bangkapi, Huaykwang, Bangkok, 10320 Thailand
KENWOOD ELECTRONICS SINGAPORE PTE. LTD.
1 Genting Lane, #07-00, Kenwood Building, Singapore, 349544
KENWOOD ELECTRONICS (MALAYSIA) SDN BHD
#4.01 Level 4, Wisma Academy Lot 4A, Jalan 19/1, 46300 Petaling Jaya, Selangor Darul Ehsan, Malaysia
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
