Karcher K 4.650 User Manual

Operating Instructions
Before first use of the unit Please read these Operat­ing Instructions and act in accordance with them
Register and win!
www.kaercher.com
59639020 (11/10)
234
Contents
General information . . 6
Proper Use . . 6 Environmental protection . . 6 Warranty . . 6 Symbols in the operating instructions . . 6 Symbols on the machine . . 6
Safety instructions . . 7
Safety Devices . . 8 Prerequisites for the appliance's stability . . 8
Operation . . 9
Scope of delivery . . 9 Description of the Appliance . . 9 Before Startup . . 9 Water supply . 10 Start up . 11 High pressure operation . 11 Working with detergent . 12 Interrupting operation . 12 Finish operation . 12
Transport . 12
When transporting by hand . 12 When transporting in vehicles . 12
Storage . 13
Storing the Appliance . 13 Frost protection . 13
Maintenance and care . 13
Maintenance . 13 Care . 13 Spare parts . 13
Troubleshooting . 14
Technical specifications . 14
– 5
General information
Dear Customer,
Please read and comply with
these original instructions prior to the initial operation of your appliance and store them for later use or subsequent own­ers.
Proper Use
This high-pressure cleaner is designed for domestic use only:
to clean machines, vehicles, buildings,
tools, facades, terraces, garden equip­ment etc. using a high-pressure water jet (and detergents if required).
with accessories, replacement parts
and detergents approved by KÄRCH­ER. Observe the instructions provided with these detergents.
Environmental protection
The packaging material can be recy-
cled. Please do not place the packag­ing into the ordinary refuse for disposal, but arrange for the proper recycling.
Old appliances contain valuable ma-
terials that can be recycled. Please
arrange for the proper recycling of old appliances. Please dispose your old appli­ances using appropriate collection sys­tems.
Notes about the ingredients (REACH)
You will find current information about the ingredients at:
http://www.karcher.de/de/unternehmen/ umweltschutz/REACH.htm
Warranty
The warranty terms published by the rele­vant sales company are applicable in each country. We will repair potential failures of your appliance within the warranty period free of charge, provided that such failure is caused by faulty material or defects in man­ufacturing. In the event of a warranty claim please contact your dealer or the nearest authorized Customer Service centre. Please submit the proof of purchase. (See address on the reverse)
Symbols in the operating instruc-
tions
Danger
Immediate danger that can cause severe injury or even death.
Warning
Possible hazardous situation that could lead to severe injury or even death.
Caution
Possible hazardous situation that could lead to mild injury to persons or damage to property.
Symbols on the machine
High-pressure jets can be
dangerous if improperly used. The jet must not be directed at persons, ani­mals, live electrical equipment or at the appliance itself.
Frost can destroy the not completely
drained appliance. Store the appliance in a frost resistant room during winter.
– 6
