JVC UX-G30UW User Manual

MICRO COMPONENT SYSTEM

UX-G35 UX-G33 UX-G30

—Consists of CA-UXG35 and SP-UXG35

—Consists of CA-UXG33 and SP-UXG33

—Consists of CA-UXG30 and SP-UXG30

INSTRUCTIONS

GVT0171-005A

[US, UB, UW, A]

Warnings, Cautions and Others

CAUTION—

Disconnect the mains plug to shut the power off completely (the STANDBY lamp goes off). When installing the apparatus, ensure that the plug is easily accessible. The button in any position does not disconnect the mains line.

• When the unit is on standby, the STANDBY lamp lights red.

• When the unit is turned on, the STANDBY lamp goes off. The power can be remote controlled.

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

CAUTION:

2. personnel.

CAUTION:

CAUTION

• Do not block the ventilation openings or holes. (If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

• Do not place any naked flame sources, such as lighted candles, on the apparatus.

• When discarding batteries, environmental problems must be considered and local rules or laws governing the disposal of these batteries must be followed strictly.

• Do not expose this apparatus to rain, moisture, dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

button!

Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service

Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical instruments.

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

Caution: Proper Ventilation

To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:

1. Front: No obstructions and open spacing.

2. Sides/Top/Back: No obstructions should be placed in the areas shown by the dimensions below.

3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm

or more.

Front view Side view

15 cm

SP-UXG35/SP-UXG33/SP-UXG30

1 cm

CA-UXG35/CA-UXG33/CA-UXG30

1 cm

SP-UXG35/SP-UXG33/SP-UXG30

15 cm

10 cm

15 cm

CA-UXG35/CA-UXG33/CA-UXG30

15 cm

[European Union Only]

G-1

Contents

Introduction ............................................................... 2

Connections ................................................................ 3

Before Operating the System.................................... 6

Daily Operations—Playback .................................... 7

Listening to the Radio ..................................................................8

Playing Back a Disc .....................................................................9

Playing Back a Tape .................................................................. 10

Playing Back a Portable Audio Device...................................... 10

Daily Operations—Sound&Other Adjustments... 11

Adjusting the Volume ................................................................11

Adjusting the Sound................................................................... 11

Changing the Display Brightness............................................... 12

Adjusting the Audio Input Level ............................................... 12

Setting the Clock........................................................................ 12

Turning Off the Power Automatically .......................................12

Advanced Disc Operations...................................... 13

Programming the Playing Order—Program Play ......................13

Playing at Random—Random Play ...........................................14

Playing Repeatedly—Repeat Play .............................................14

Prohibiting Disc Ejection—Child Lock..................................... 14

Recording Operations ............................................. 15

Recording on a Tape ..................................................................15

Synchronized Disc Recording.................................................... 15

Timer Operations .................................................... 16

Setting the Timer........................................................................ 16

Additional Information ........................................... 18

Learning More about This System............................................. 18

Troubleshooting .........................................................................19

Maintenance ............................................................................... 20

Specifications ............................................................................. 21

Parts Index.................................................................................. 21

Introduction

Remote ONLY

Main Unit

ONLY

Precautions

Installation

• Install in a place which is level, dry and neither too hot nor too cold—between 5°C and 35°C.

• Install the System in a location with adequate ventilation to prevent internal heat buildup inside the System.

DO NOT install the System in a location near heat sources, or in a place subject to direct sunlight, excessive dust or vibration.

• Leave sufficient distance between the System and the TV.

• Keep the speakers away from the TV to avoid interference with the TV.

Power sources

• When unplugging the System from the wall outlet, always pull on the plug, not the AC power cord.

DO NOT handle the AC power cord with wet hands.

Moisture condensation

Moisture may condense on the lenses inside the System in the following cases:

• After starting to heat the room

• In a damp room

• If the System is brought directly from a cold to a warm place

Should this occur, the System may malfunction. In this case, leave the System turned on for a few hours until the moisture evaporates, unplug the AC power cord, then plug it in again.

How to Read This Manual

• Button and control operations are explained in the table below.

•

Some related tips and notes are explained later in the sections “Learning More about This System” and “Troubleshooting,” but not in the same section explaining the operations content has some information).

2 sec.

( indicates that the

Indicates that you press the button

briefly

Indicates that you press the button

briefly and repeatedly

option you want is selected.

Indicates that you press one of the buttons.

Indicates that you button for specified seconds.

• The number inside the arrow indicates the period of press (in this example, 2 seconds).

• If no number is inside the arrow, press and hold until the entire procedure is complete or until you get a result you want.

Indicates that you turn the control toward the specified direction(s).

until an

press and hold

the

Others

• Should any metallic object or liquid fall into the System, unplug the AC power cord and consult your dealer before operating any further.

DO NOT disassemble the System since there are no user serviceable parts inside.

• If you are not going to operate the System for an extended period of time, unplug the AC power cord from the wall outlet.

If anything goes wrong, unplug the AC power cord and consult your dealer.

Indicates that this operation is only possible using the remote control.

Indicates that this operation is only possible using the buttons and controls on the main unit.

Connections

PHONES

AUX

Supplied accessories

After unpacking, check to be sure that you have all the following items:

• FM antenna (1) • Remote control (1)

• AM loop antenna (1) • Batteries (2)

• AC plug adapter (1) (not supplied for Hong Kong region and Australia)

If any item is missing, consult your dealer immediately.

Do not connect the AC power cord until all other connections have been made.

Rear view

From AM/FM antenna

See page 4.

From the speakers

See page 5.

Voltage selector (models other than Hong

Kong region and Australia)

Before plugging in, confirm the position the voltage marker points at. See page 5.

To a wall outlet

Plug in the AC power cord only after all connections are complete.

• If the wall outlet does not match the AC plug, use the supplied AC plug adapter (not supplied for Hong Kong region and Australia).

Front view

From the analog audio output of portable audio devices

See page 5.

AM/FM antenna

To assemble the AM loop antenna

To connect the AM loop antenna

FM antenna (supplied)

Extend it so that you can obtain the best reception.

AM loop antenna (supplied)

Turn it until the best reception is obtained.

For the better AM/FM reception

Outdoor FM antenna (not supplied)

AM loop antenna (supplied)

Keep it connected.

Vinyl-covered wire (not supplied)

Extend it horizontally.

• Disconnect the supplied FM antenna, and connect to an outdoor FM antenna using a 75 Ω wire with coaxial type connector (IEC or DIN45325).

• Make sure the antenna conductors do not touch any other terminals, connecting cords, or the power cord. Also, keep the antennas away from metallic parts of the System, connecting cords, and the AC power cord. This could cause poor reception.

• If the AM loop antenna wire is covered with vinyl, remove the vinyl to expose the tip of the antenna by twisting the vinyl.

DOWN

PHONES

AUX

Speakers

To connect the speaker cords

Make sure that both speakers are connected correctly and firmly.

1 Hold 2 Insert 3 Release

To connect a portable audio device

AUX jack

Stereo mini plug cord (not supplied)

Red

From left speaker

Black

From right speaker

Red

• When connecting the speaker cords, match the polarity of the speaker terminals: red cord to (+) and black cord to (–).

• If the speaker cords are covered with vinyl, remove the vinyl to expose the tip of the speaker cord by twisting the vinyl.

• DO NOT connect more than one speaker to each terminal.

• DO NOT allow the conductor of the speaker cords to be in touch with the metallic parts of the System.

To adjust the voltage selector (models other

than Hong Kong region and Australia)

Use a screwdriver to rotate the voltage selector so that the voltage marker is pointing to the same voltage as where you are plugging in the unit. (See also the back cover page.)

Portable audio device

• By using QP Link (Quick Portable Link), you can easily start playing back a portable audio device on this unit. See page 10 for details.

• If an external device is not equipped with a stereo mini plug audio output, use a plug adapter to convert the stereo mini plug to the corresponding plug of the audio output.

Preparing the remote control

R03(UM-4)/AAA(24F)

• Dispose of batteries in the proper manner, according to federal, state, and local regulations.

DO NOT recharge, short, disassemble, heat the battery or dispose of it in a fire.

When using the remote control

Point the top of the remote control toward the remote sensor as directly as possible. If you operate it from a diagonal position, the operating range (approx. 5 m) may be shorter.

Voltage marker

DO NOT plug in before setting the voltage selector and all connection procedures are complete.

Before Operating the System

The indications on the display tell you a lot of things while you are operating the System. Before operating the System, be familiar with when and how the indicator illuminates on the display.

12 3

PRGM RND FM AM ST MONO

1 MP3

S.TURBO AHB PRO A.STBY QP Link

9pq

Indications on the main display

• While listening to radio:

• While selecting TAPE or AUX:

Band

Frequency

S.TURBO

QP Link

Source name

S.TURBO

QP Link

• While playing a CD/MP3*:

S.TURBO

QP Link

Track number

Elapsed playing time

• While disc play is stopped:

CD:

MP3:

S.TURBO

QP Link

Total track number

S.TURBO

QP Link

Group number

Total playing time

Track number

* When you start or stop playing an MP3 disc, the group

(folder) number, group (folder) name, track (file) number, track (file) name (and ID3 Tag) will be shown before the elapsed playing time appears.

SLEEP

REC

123

REC

Disc operation indicators

• PRGM (Program Play): lights when Program Play mode is activated.

• RND (Random Play): lights when Random Play mode is activated.

•

Repeat Play: –: lights when One Track Repeat is activated. –: lights when All Track Repeat or One Group

Repeat is activated.

MP3 indicator

• Lights when an MP3 track is detected.

Radio reception indicators

• FM: lights while receiving an FM stereo station. – ST (stereo): lights while an FM stereo station with

sufficient signal strength is tuned in.

– MONO: lights while receiving an FM stereo station in

monaural.

• AM: lights while receiving an AM station.

Timer indicators

•: lights when Daily Timer or Recording Timer is on standby; flashes while working or being set.

• 1/2/3: lights when a Daily Timer (1, 2, or 3) is on standby; flashes while working or being set.

• REC: lights when the Recording Timer is on standby; flashes while working or being set.

• SLEEP: lights when Sleep Timer is activated.

S.TURBO (Sound Turbo) indicator

• Lights when Sound Turbo is activated.

AHB PRO (Active Hyper Bass Pro) indicator

• Lights when AHB Pro is activated.

QP Link (Quick Portable Link) indicator

• Lights when QP Link is activated.

A.STBY (Auto Standby) indicator

• Lights when Auto Standby is activated.

• Flashes for about 3 minutes before Auto Standby turns the System off.

Main display

REC indicator

• Lights while recording.

Tape operation indicators

• 3

: – Lights when TAPE is selected as a source. – Flashes slowly during playback and recording. – Flashes quickly while fast-forwarding a tape.

• 2

: flashes quickly while fast-reversing a tape.
