JVC NXPN10, LVT2011-002B User Manual
COMPACT COMPONENT SYSTEM
SYSTEME DE COMPOSANTS COMPACT
NX-PN10
INSTRUCTIONS
MANUEL D’INSTRUCTIONS
LVT2011-002B
[C]
Warnings, Cautions and Others
Mises en garde, précautions et indications diverses
CAUTION
The button in any position does not
disconnect the mains line.
Disconnect the mains plug to shut the power off
completely (the STANDBY lamp goes off).
The MAINS plug or an appliance coupler is used
as the disconnect device, the disconnect device
shall remain readily operable.
• When the system is on standby, the STANDBY
lamp lights red.
• When the system is turned on, the STANDBY
lamp goes off.
The power can be remote controlled.
ATTENTION
La touche , dans n’importe quelle position, ne
déconnecte pas le système du secteur.
Déconnectez la fiche de secteur pour mettre
l’appareil complètement hors tension (le témoin
STANDBY s’éteint).
La fiche secteur ou un coupleur est utilisé comme
dispositif de déconnexion de l’appareil, et
l’appareil déconnecté doit être prêt à être utilisé.
• Quand le système est en attente, le témoin
STANDBY est allumé en rouge.
• Quand le système est sous tension, le témoin
STANDBY s’éteint.
L’alimentation peut être télécommandée.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or
moisture.
ATTENTION
Afin d’éviter tout risque d’électrocution,
d’incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne
pas ouvrir le coffret de l’appareil.
2. Ne pas exposer l’appareil à la pluie ni à
l’humidité.
For U.S.A.
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
Changes or modifications not approved by JVC
could void the user’s authority to operate the
equipment.
G-1
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT
EXCEED THE CLASS B LIMITS FOR RADIO
NOISE EMISSIONS FROM DIGITAL
APPARATUS AS SET OUT IN THE
INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED
“DIGITAL APPARATUS,” ICES-003 OF THE
DEPARTMENT OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE
LES LIMITES DE BRUITS
RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMIRIQUES DE CLASSE B
PRESCRITES DANS LA NORME SUR LE
MATERIEL BROUILLEUR; “APPAREILS
NUMERIQUES”, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
CAUTION
Battery shall not be exposed to excessive heat
such as sunshine, fire or the like.
ATTENTION
Les piles ne doivent en aucun cas être
exposées à une chaleur excessive (lumière du
soleil, feu, etc.).
CAUTION
• Do not block the ventilation openings or
holes.
(If the ventilation openings or holes are
blocked by a newspaper or cloth, etc., the
heat may not be able to get out.)
• Do not place any naked flame sources, such
as lighted candles, on the apparatus.
• When discarding batteries, environmental
problems must be considered and local rules
or laws governing the disposal of these
batteries must be followed strictly.
• Do not expose this apparatus to rain,
moisture, dripping or splashing and that no
objects filled with liquids, such as vases, shall
be placed on the apparatus.
ATTENTION
• Ne bloquez pas les orifices ou les trous de
ventilation.
(Si les orifices ou les trous de ventilation sont
bloqués par un journal un tissu, etc., la
chaleur peut ne pas être évacuée
correctement de l’appareil.)
• Ne placez aucune source de flamme nue,
telle qu’une bougie, sur l’appareil.
• Lors de la mise au rebut des piles, veuillez
prendre en considération les problèmes de
l’environnement et suivre strictement les
règles et les lois locales sur la mise au rebut
des piles.
• N’exposez pas cet appareil à la pluie, à
l’humidité, à un égouttement ou à des
éclaboussures et ne placez pas des objets
remplis de liquide, tels qu’un vase, sur
l’appareil.
G-2
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. Sides/Top/Back: No obstructions should be placed in the areas shown by the dimensions below.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a
stand with a height of 10 cm or more.
Attention: Aération correcte
Pour prévenir tout risque de décharge électrique ou d’incendie et éviter toute détérioration, installez
l’appareil de la manière suivante:
1. Avant: Bien dégagé de tout objet.
2. Côtés/dessus/dessous: Assurez-vous que rien ne bloque les espaces indiqués sur le schéma cidessous.
3. Dessous: Posez l’appareil sur une surface plane et horizontale. Veillez à ce que sa ventilation
correcte puisse se faire en le plaçant sur un support d’au moins dix centimètres de hauteur.
Front
Face
Side
Côté
G-3
Contents
Introduction.................................................2
Precautions ................................................................2
Getting Started............................................3
Connections................................................................4
Canceling the Display Demonstration (Demo)..........6
Turning on the Power Automatically
(Motion Sensor) ..................................................6
Basic Operations .........................................7
Main Unit ...................................................................7
Remote Control ..........................................................9
Playing Back from iPod Devices.............. 12
Connecting iPod.......................................................13
Operations ................................................................14
Listening to FM Broadcasts.....................17
Basic Operations ......................................................17
Playing Back from Other Equipment..... 19
Connecting Other Equipment...................................19
Operations ................................................................19
Setting the Clock and Timer....................20
Setting the Clock......................................................20
Using Timer .............................................................20
Troubleshooting ........................................23
Specifications.............................................24
1
Introduction
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and
to obtain the best possible performance from the unit.
Precautions
Installation
• Install in a place which is level, dry and neither too hot nor too cold—between 5°C and 35°C.
• Install the unit in a location with adequate ventilation to prevent internal heat buildup inside the
unit.
DO NOT install the unit in a location near heat sources, or in a place subject to direct
sunlight, excessive dust or vibration.
• Leave sufficient distance between the unit and the TV.
• Keep the unit away from the TV to avoid interference with TV.
Power Sources
• When unplugging the unit from the wall outlet, always pull on the plug, not the AC power cord.
DO NOT handle the AC power cord with wet hands.
Internal Heat
For safety, observe the following carefully:
• Make sure there is good ventilation around the unit. Poor ventilation could overheat
and damage the unit.
• DO NOT block the ventilation openings or holes. If they are blocked by a newspaper
or cloth, etc., the heat may not be able to get out.
Others
• Should any metallic object or liquid fall into the unit, unplug the AC power cord and consult your
dealer before operating any further.
DO NOT disassemble the unit since there are no user serviceable parts inside.
• If you are not going to operate the unit for an extended period of time, unplug the AC power cord
from the wall outlet.
If anything goes wrong, unplug the AC power cord and consult your dealer.
2
Getting Started
• In this manual, operations using the remote
control are mainly explained; however, you
can use the buttons and controls on the unit
if they have the same (or similar) name and
marks.
• In this manual, “iPod” means both iPod and
iPhone devices. When iPhone device is
especially mentioned, “iPhone” is used in
this case.
Supplied Accessories
After unpacking, check to be sure that you have
all the following items. The number in
parentheses indicates the quantity of each piece
supplied.
• Remote control (1)
• Lithium coin battery CR2025 (1) (The battery
has been installed when shipped from the
factory.)
• FM antenna (1)
• AC power cord (1)
• AC adaptor (1)
If anything is missing, consult your dealer
immediately.
CAUTION:
To avoid risk of fire and to prevent damage.
• Do not use AC adaptors except the supplied
AC adaptor.
• Do not use the supplied AC adaptor for other
equipment.
Prepare the Remote Control
When you use the remote control for the first
time, pull out the insulation sheet.
Front side
Replacing the battery in the remote control
Insert the battery into the remote control by
matching the polarity (+ and –) correctly.
• If the range or effectiveness of the remote
control decreases, replace the battery.
Rear side
Lithium coin battery
(product number:
CR2025)
WARNINGS:
• Store the battery in a place where children
cannot reach. If a child accidentally swallows
the battery, consult a doctor immediately.
• Do not recharge, short, disassemble or heat
the battery or dispose of it in a fire. Doing any
of these things may cause the battery to give
off heat, crack, or start a fire.
• Do not leave the battery with other metallic
materials. Doing this may cause the battery to
give off heat, crack, or start a fire.
• When throwing away or saving the battery,
wrap it in tape and insulate; otherwise, the
battery may start to give off heat, crack, or
start a fire.
• Do not poke the battery with tweezers or
similar tools. Doing this may cause the battery
to give off heat, crack, or start a fire.
• Dispose of battery in the proper manner,
according to federal, state, and local
regulations.
CAUTION:
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent
type.
Insulation sheet
3
Connections
Do not connect the AC power cord until all other connections have been made.
Connecting the Antenna
FM antenna (supplied):
Extend it so that you can
obtain the best reception.
Rear side
For better FM reception
Disconnect the supplied FM antenna and
connect to an outdoor FM antenna using a 75
wire with coaxial type connector.
Ω
Outdoor FM antenna
(not supplied)
FM 75Ω COAXIAL
terminal
(on the rear panel)
NOTES:
• Make sure the FM antenna does not touch any other terminals, connecting cords or the AC power
cord. Also, keep the antenna away from metallic parts of the unit, connecting cords and the AC
power cord. This could cause poor reception.
AM band is not received with this unit.
4
Connecting the Video Cord to View a Video/Picture from iPod
When viewing a video/picture from iPod on your TV, use a composite video cord (not supplied) to
connect the VIDEO OUT jack on the unit and the composite video input on your TV.
• After you have connected the unit, change the video input mode on your TV. For details, also refer
to the instruction manual for your TV.
Video cord (not supplied)
To video input
Rear side
Connecting the Power Cord
Rear side
AC adaptor
(supplied)
Plug in the AC power cord
AC power cord
(supplied)
To a wall outlet
only after all connections
are complete.
5
Canceling the Display Demonstration (Demo)
When you connect the AC power cord for the first time, the display demonstration starts
automatically.
• When you operate the unit, the display demonstration stops temporarily. If no operation is done
for about 2 minutes, the unit starts the display demonstration again.
Button
On the unit
Hold down until “DEMO OFF” appears on the display.
• To activate again, hold down DEMO until “DEMO ON” appears on the display.
• When ECO mode is activated (P.10), the display demonstration does not function.
Operation
Turning on the Power Automatically (Motion Sensor)
When you move your hand or an object closer to Motion sensor (P.7), the unit turns on
automatically.
• iPod starts playback or an FM broadcast is received if you selected either of them last time.
• Motion Sensor works even if ECO mode is activated.
Button
On the unit
Press to activate Motion Sensor. “ M.S ON” appears on the display.
• When you select Clock as the display information or the unit is on standby,
“ ” is shown on the display (see page 10).
• To deactivate, press MOTION SENSOR. “M.S OFF” appears on the display.
NOTE:
• If the AC power cord is unplugged, Motion Sensor does not work.
• Deactivate Motion Sensor in the following cases to prevent the unit from turning on automatically:
– when you do not use the unit for a long time
– when you use Timer
Operation
6
Main Unit
Basic Operations
Illumination panel
(P.10)
STANDBY
lamp
Dock A
(P.13)
Display (P.8)
Operating on the Main Unit
Buttons Operations
Turns on or off (standby) the power.
Dock B
(P.13)
Motion
sensor
(P.6)
Remote
control
sensor
Activates or deactivates Motion Sensor (P.6).
7
Buttons Operations
Activates or deactivates the display demonstration (P.6).
Adds the powerfulness to the sound (P.11).
Stops the timer sound and restarts it 5 minutes later (P.22).
• iPod (P.14):
Press: Reverse skip/forward skip.
Hold down: Reverse search/forward search.
• FM (P.17): Tunes in to a station.
• Changes the source to iPod /iPod (P.14).
• Starts playback and pauses for iPod (P.14).
Changes the source to FM (P.17) or
AUDIO IN (P.19).
FM
AUDIO IN
Adjusts the volume level (VOL MIN/VOL 0 to VOL MAX/VOL 30).
Display Information
Symbols Description
iPod
iPod
Lights up when iPod is connected to dock A.
A
Lights up when iPod is connected to dock B.
B
SHUFFLE Lights up when Shuffle Play applies to both iPod and iPod (P.15).
S.TURBO Lights up when Sound Turbo is activated (P.11).
MHz Lights up when FM frequency is indicated.
8
Symbols Description
ST Lights up when FM stereo broadcast is received.
MONO Lights up when FM monaural reception mode is activated.
TUNED Lights up when an FM station of sufficient signal strength is tuned in.
FM Lights up when FM is selected as the source.
1/2/3 • Lights up when Timer is set (P.21).
• 1/2/3 icon flashes while Timer is working.
SLEEP Lights up when Sleep Timer is activated (P.11).
Remote Control
P.11
P.20, P.22
P.14, P.20, P.22
P.14, P.17, P.18
P.15, P.18 – 21
P.15
P.11
Operating on the Remote Control
Basic operations
Buttons Main operations
Turns on or off (standby) the power.
P.10
P.15, P.17
P.14, P.17, P.18,
P.20 – 22
, P.17 – 19
, P.14
P.11
, P.11
9
Buttons Main operations
Changes the display information.
• For iPod A/iPod B/AUDIO IN:
Source name
Day of the week
Clock
• When the unit is turned off:
Clock
•For FM:
Frequency
Day of the week
Clock
Changes the source to FM (P.17) or AUDIO IN (P.19).
• Changes the source to iPod /iPod (P.14).
• Starts playback and pauses for iPod (P.14).
Adjusts the volume level (VOL MIN/VOL 0 to VOL MAX/VOL 30).
Drops the volume in a moment.
• To restore the volume, press again or adjust the volume level.
To dim the display and illumination panel—DIMMER
You can change the brightness of the display and illumination panel.
Press repeatedly.
DIM 1
DIM 1: Dims the display and illumination panel.
DIM 2: Dims the display much more than “DIM 1” and turns off the illumination panel.
• Dimmer is canceled when you turn off the unit.
DIM 2
DIM OFF
(Canceled)
Day of the week
To activate ECO mode
Activating ECO mode allows you to reduce power consumption by turning off the display while on
standby.
Press while the unit is on standby. “ECO ON” appears on the display for a while.
• The clock is not shown on the display when the unit is on standby.
• To cancel the mode, press ECO/DIMMER again. “ECO OFF” appears for a while then the clock
is shown on the display.
• The battery of iPod is not charged in ECO mode.
10
To turn off the unit after a certain period of time—Sleep Timer
(
)
Press repeatedly to specify the time (in minutes) as follows:
10 20
OFF
Canceled
• To check the time remaining before the shut-off time, press SLEEP once. If you press the button
repeatedly, you can change the shut-off time.
30 60 90
180
150
120
To emphasize the sound—Sound Turbo
You can add the powerfulness to the sound.
Press to activate Sound Turbo.
“S-TURBO” appears for a while and S.TURBO lights up on the display.
• To cancel, press SOUND TURBO again. “OFF” appears on the display.
To adjust the tone
You can adjust the bass and treble levels.
Select the item you want to adjust.
1
BASS
Adjust the bass or treble level (–5 to +5).
TREBLE
Canceled
2
11
Playing Back from iPod Devices
You can connect 2 iPod devices to the unit and enjoy sound and video from them.
Compatible iPod Models:
iPod model Audio Video
iPod nano 1GB/2GB/4GB
iPod nano (2nd Generation) 2GB/4GB/8GB
iPod nano (3rd Generation) 4GB/8GB
iPod nano (4th Generation) 8GB/16GB
iPod mini 4GB
iPod mini (2nd Generation) 4GB/ 6GB
iPod (4th Generation) 20GB/40GB
iPod photo (4th Generation) 20GB/30GB/40GB/60GB
iPod video (5th Generation) 30GB/60GB/80GB
iPod classic 80GB/120GB/160GB
iPod touch 8GB/16GB/32GB
iPod touch (2nd Generation) 8GB/16GB/32GB
iPhone 4GB/8GB/16GB
iPhone (3G) 4GB/8GB/16GB
*1
Only for still picture.
*2
To view a video/picture from iPod touch on your TV, update iPod touch software to the latest
version. (Additional charges may apply.)
If iPod does not play correctly, update iPod software to the latest version.
• For details about updating iPod, check on the Apple web site <http://www.apple.com>.
• JVC does not assure the compatibility of iPod released after April 2009 with this unit.
√
√
√√
√
√
√
√
√√
√√
√√
√√
√√
√√
√√
—
—
√
—
—
—
*1
*2
• “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been
designed to connect specifically to iPod or iPhone, respectively, and has been certified by
the developer to meet Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory standards.
• iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc.,
registered in the U.S. and other countries.
12
Loading...
