JVC LT-37X898, LT-42X898, LT-47X898 User Guide

LCD Flat Television Users Guide

For Models:

LT-37X898
LT-42X898
LT-47X898

Illustration of LT-42X898 and RM-C1400

Important Note:

In the spaces below, enter the model and serial number of your television (located at the
rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this
guide. Keep this user’s guide in a convenient place for future reference. Keep the carton
and original packaging for future use.

Model Number:

Serial Number:

LCT2329-001A-A

0807TNH-II-IM

Important Safety Precautions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock. Do not

remove cover (or back). No user serviceable
parts inside. Refer servicing to qualified service
personnel.

The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid Improper installation and never position the unit where good ventilation is unattainable.

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair
it yourself or remove the rear cover.

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this TV set for a long period of time, be sure to disconnect both the

power plug from the AC outlet and antenna for your safety.

* To prevent electric shock do not use this polarized plug with an extension cord, receptacle or

other outlet unless the blades can be fully inserted to prevent blade exposure.

• As an “ENERGY STAR®” partner,
JVC has determined that this
product or product model meets the
“ENERGY STAR
efficiency.

®

” guidelines for energy

2

IMPORTANT RECYCLING INFORMATION

This product has a fluorescent lamp that contains mercury. Disposal

of these materials may be regulated in your community due to

environmental considerations. For disposal or recycling information,

please contact your local authorities or for USA, the Electronic Industries

Alliance: http://www.eiae.org

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's

instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold

with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.

3

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

16) Avoid improper installation and never position the unit where good ventilation is impossible.
When installing this TV, distance recommendations must be maintained between the set
and the wall, as well as inside a tightly enclosed area or piece of furniture. Keep to the
minimum distance guidelines shown for safe operation.

150 mm

200 mm

150 mm

200 mm

50 mm

17) Cautions for installation

— Do not tilt the TV towards the left or right, or towards the back.

— Install the TV in a corner on the floor so as to keep cords out of the way.
— The TV will generate a slight amount of heat during operation. Ensure that sufficient

space is available around the TV to allow satisfactory cooling.

18) Make enough room for inserting and removing the power plug. Place the TV as close
to the outlet as possible. The main power supply for this TV is controlled by inserting or
removing the power plug.

19) Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

20) When this TV is connected to the wall outlet, it is always on standby even when all the LED

lamps are not lit. To shut down the TV, unplug the TV from the wall outlet.

FCC Notice:

Caution: Changes or modifi cations not expressly approved by party responsible for

compliance could void the user's authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/TV technician for help.

4

Warnings

We have an important note for customers who subscribe to basic cable services (do not have
a separate cable box) and plan to use their JVC TV remote control to select channels.

Once you run the Auto Tuner Setup (which detects and programs all the channels your TV is
receiving through the RF input), every channel number available from your cable company
will appear in your television’s Channel Summary and they will all be marked as available for
scanning. Even though every channel is detected and appears as available, you will only be
able to view those that you specifi cally subscribe to from your cable company. This will likely
mean there are blank channels between those channels you wish to scan or “surf”.

We apologize for any inconvenience this may cause but it is important to note that this is
not a malfunction of your television. If you want to sequentially scan those channels you
subscribe to without blank ones in between, you can contact your cable company for their
cable box and remote.

Avoiding Ghost Images

Displaying fi xed images for extended periods of time can leave a subtle but temporary ghost
image on your screen. To avoid this, mix your viewing pattern.

Examples include, but are not limited to the following:

• Stock-market report bars

• Shopping channel logos and pricing

displays

• Video game patterns or scoreboards

• Bright station logos

• Internet web sites or other computer-style

images

• DVD discs, video tapes, laser discs

• Broadcast, cable, satellite channels or

digital television tuners/converters

TV on

For example...

TV off

XYZ XYZ

5

Warnings

Caring for the Cabinet

Normally, light dusting with a soft, non-scratching duster will keep your TV clean.

If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly
moistened with water. You can add a few drops of mild liquid detergent to the water to help
remove spots of oily dirt.

• DO NOT allow liquid to enter the TV through the ventilation slots.

• DO NOT use strong or abrasive cleaners on the TV.

• DO NOT spray liquids or cleaners directly on the TV’s surface.

• DO NOT rub or scrub the TV harshly. Wipe the set gently with a soft cloth.

Caring for the Screen

The screen is treated with an electrostatic-proof coating. When it gets dirty, wipe it gently with a
soft cloth. If the screen is very dirty, wipe it down with a cloth dipped in a diluted kitchen cleaner
and thoroughly wrung-out. Then wipe immediately after with a clean, dry cloth.

Do not apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the screen.
These will remove the coating layer and cause discolorations.

Do not push or hit the screen. This could cause scratches on the screen surface and image
distortions.

Tidying the cables

A cable holder which keeps your connection cables tidy is attached to the back of the stand.

6

Warnings

Disconnecting the stand

If you disconnect the stand, attach the bottom cover and the screw (supplied) into the hole.

1) Place the TV face down on a soft cloth on a table.

2) Remove the four screws from the back of the TV.

3) Pull out the stand from the TV.

4) Cover the hole with a bottom cover and tighten the screw.

Note:

• To re-install the stand, reverse the procedure from 4) to 1).

7

Table of Contents

Important Safety Precautions . . 2

Warnings . . . . . . . . . . . . . . . 5

Quick Setup . . . . . . . . . . . . . . 9

Unpacking your TV . . . . . . . . . . . . 9

TV Models . . . . . . . . . . . . . . . . 10

TV Remote Control . . . . . . . . . . . 11

Getting Started . . . . . . . . . . . . . 12

The Remote Control . . . . . . . . . . 12

Connecting Your Devices . . . . . . . 13

Interactive Plug In Menu . . . . . . . . 24

Onscreen Menus . . . . . . . . . 27

Using the Guide . . . . . . . . . . . . . 27

Onscreen Menu System . . . . . . . . . 28

Initial Setup . . . . . . . . . . . . . 30

HDMI Size . . . . . . . . . . . . . . . . . 30

Video-1 Audio . . . . . . . . . . . . . 30

Noise Muting . . . . . . . . . . . . . . 31

Front Panel Lock . . . . . . . . . . . . 31

Video Input Label . . . . . . . . . . . 32

Position Adjustment . . . . . . . . . . . . 33

Power Indicator . . . . . . . . . . . . . 33

Illumination . . . . . . . . . . . . . . . . 34

Language . . . . . . . . . . . . . . . . 34

Closed Caption . . . . . . . . . . . . . 34

Auto Shut Off . . . . . . . . . . . . . . 37

XDS ID . . . . . . . . . . . . . . . . . . 37

Auto Tuner Setup . . . . . . . . . . . . 37

Channel Summary . . . . . . . . . . . . 38

V-Chip . . . . . . . . . . . . . . . . . . 40

Set Lock Code . . . . . . . . . . . . . 46

Auto Demo . . . . . . . . . . . . . . . 47

Digital Setup . . . . . . . . . . . . . . . 47

V5 Input . . . . . . . . . . . . . . . . . 49

Picture Adjust . . . . . . . . . . . . . 50

Picture Settings . . . . . . . . . . . . . 50

Color Temperature . . . . . . . . . . . . 50

Color Management . . . . . . . . . . . . 51

Dynamic Gamma . . . . . . . . . . . . . 51

Smart Picture . . . . . . . . . . . . . . 51

Natural Cinema . . . . . . . . . . . . . . 52

Digital VNR . . . . . . . . . . . . . . . 52

MPEG NR . . . . . . . . . . . . . . . 53

Smart Sensor . . . . . . . . . . . . . . 53

Sensor Effect . . . . . . . . . . . . . . . 53

Theater Pro II . . . . . . . . . . . . . . . 53

Reset . . . . . . . . . . . . . . . . . . 54

Sound Adjust . . . . . . . . . . . . . 55

Sound Settings . . . . . . . . . . . . . 55

Turn On Volume . . . . . . . . . . . . . 55

Volume Limit . . . . . . . . . . . . . . 55

Reset . . . . . . . . . . . . . . . . . . 55

Clock/Timers . . . . . . . . . . . . . . . . 56

Set Clock . . . . . . . . . . . . . . . . 56

On/Off Timer . . . . . . . . . . . . . . . 57

Button Functions . . . . . . . . . . 58

Power . . . . . . . . . . . . . . . . . . 58

Number Buttons . . . . . . . . . . . . . 58

Tune . . . . . . . . . . . . . . . 58

Sub Channel . . . . . . . . . . . . . 58

Channel +/- . . . . . . . . . . . . . 58

Volume +/- . . . . . . . . . . . . . 59

Muting . . . . . . . . . . . . . . . . . . 59

D/A (Digital/Analog) . . . . . . . . . . . . 59

Input . . . . . . . . . . . . . . . . . . . 59

Return+/TV . . . . . . . . . . . . . . . 60

Light . . . . . . . . . . . . . . . . . . 60

Menu . . . . . . . . . . . . . . . . . . 60

OK . . . . . . . . . . . . . . . . . . . 60

Back . . . . . . . . . . . . . . . . . . . 60

Favorite . . . . . . . . . . . . . . . . 61

Aspect . . . . . . . . . . . . . . . . . 62

Guide . . . . . . . . . . . . . . . 63

Sound . . . . . . . . . . . . . . . . . . 64

ML/MTS . . . . . . . . . . . . . . . . . 64

Video Status . . . . . . . . . . . . . . . 65

C.C. . . . . . . . . . . . . . . . . . . . 65

Sleep Timer . . . . . . . . . . . . . . . 66

Display . . . . . . . . . . . . . . . . . 66

Twin . . . . . . . . . . . . . . . . . 67

Swap . . . . . . . . . . . . . . . . . 67

Select . . . . . . . . . . . . . . . . . 68

Freeze . . . . . . . . . . . . . . . . . 68

Mode . . . . . . . . . . . . . . . . . . 68

External device control buttons . . . . . 68

Remote Programming . . . . . . 69

OSD Information . . . . . . . . . . 75

Weak Signal . . . . . . . . . . . . . 75

No Program . . . . . . . . . . . . . . 75

Invalid Signal . . . . . . . . . . . . . 75

Troubleshooting . . . . . . . . . . 76

Specifications . . . . . . . . . . 78

Warranty . . . . . . . . . . . . . 79

Authorized Service Center . . . 80

Notes . . . . . . . . . . . . . . . 81

8

Quick Setup

Unpacking your TV

Thank you for your purchase of a JVC LCD Flat Television. Before you begin setting up your
new television, please check to make sure you have all of the following items. In addition to
this guide, your television box should include:

Television x 1

Remote Control x 1

POWER

D/A

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

123

456

789

+

RETURN

TUNE

TV

0

– CH + – VOL +

LIGHT MUTING

B

U

A

N

C

OK

E

K

M

F

A

T

V

C

O

E

R

P

I

T

S

E

A

DVR

STATUS

VIDEO

SOUND

GUIDE

SUB CH C.C. DISPLAY

SUB T.

TV/VCR

TWIN SLEEP ML/MTS

SWAP SELECT FREEZE

RM-C1400

TV

AA Batteries x 2

+

+

AA Alkaline

AA Alkaline

–

–

Note: Your television
and/or remote
control may differ
from the examples
illustrated here.

Cover x 1 Screw x 1

We recommend that before you start using your new television, you read this entire User’s
Guide so you can learn about your new television’s many great features. If you’re anxious to
start using your television right away, a quick setup guide follows on the next few pages.

9

Quick Setup

TV Models

Before you connect your television to another device, please refer to the proper diagrams for
your specific TV and remote. These will help assist you in understanding how to connect your
television to another device, as well as use the remote to set up your television.

Rear Panel Diagram

PC

I

N

(

D

-S
U

B)

INPUT 5

V

I
D

E

O

R

­A
U

D

I
O

-

INPUT 4

INPUT 3

FOR HDMI 1

UDIO OUT

AUDIO OUT

UDIO OUT

L

Y

P

R

P

B

V

I
D

EO

R

­A
U

D

I
O

­L

Y

P

R

P

B

S

­V

I
D

EO

V

I
D

EO

R

­A
U

D

I
O

­L

AU

D

I
O I

NP

U

T

R

L

R

­A
U

D

I
O

­L

N
I
C
P
)
B
U
S

­D
(

INPUT 5

O
E
D

I
V

L

­O

I

D

U

A

-

R

Y

R

P

B

P

INPUT 4

O
E
D

I
V

L

­O

I

D

U

A

-

R

Y

R

P

B

P

INPUT 3

O

E
D

I
V

­S

O
E
D

I
V

SERVICE

DIGITAL AUDIO

ONLY

OPTICAL OUT

L

­O

I
UD

A

R-

INPUT 5 INPUT 2 INPUT 1

RS-232C

T

U

P

N

I

O

I

D

U

A
L

R

FOR HDMI 1

UDIO OUT

L

­O

I

UD

A

R-

AUDIO OUT

AUDIO OUT

RS-232C

SERVICE

DIGITAL AUDIO

ONLY

INPUT 5 INPUT 2 INPUT 1

OPTICAL OUT

Notes:

• The terminal labeled "SERVICE ONLY", is exclusively used to update the
software version.

• For governing the usage of the RS-232C terminal, consult your dealer.

Side Panel Diagram

10

INPUT MENU C H VOL

OK BACK

POWER

TV Remote Control

POWER

D/A

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

123

456

789

TUNE

RETURN

TV

0

– CH + – VOL +

LIGHT MUTING

Quick Setup

+

U

N

OK

E

M

F

A

V

O

R

I

T

E

DVR

STATUS

VIDEO

SOUND

SUB CH C.C. DISPLAY

SUB T.

TV/VCR

TWIN SLEEP ML/MTS

SWAP SELECT FREEZE

RM-C1400

B

A

C

K

T

C

E

P

S

A

GUIDE

TV

RM-C1400

Notes:

• For information on remote control buttons, see pages 58 - 68.

• SUB CHANNEL and GUIDE buttons are for digital channels. If your TV is connected to an
ATSC antenna or Digital Cable, you can use these buttons.

• This remote control is capable of operating many external device brands. See page 69 - 74
for how to program the remote control.

11

Quick Setup

Getting Started

These quick setup pages will provide you, in three easy steps, with the basic information you
need to begin using your new television right away. If you have questions, or for more detailed
information on any of these steps, please consult other sections of this manual.

Step 1 – The Remote Control

Before you can operate your remote control, you first need
to install the batteries (included).

Raise the latch on the remote's back cover to remove.
Insert two batteries, carefully noting the "+" and "–"
markings. Place the "–" end in the unit first. Snap the
cover back into place.

When you change the batteries, try to complete the
task within three minutes. If you take longer than
three minutes, the remote control codes (ex. VCR,
DVD) may have to be reset. See pages 69 - 74.

Basic Operation

Turn the television on and off by pressing the POWER button at the top right corner
of the remote. If this is the first time you are turning on the TV, the interactive
plug in menu appears.

• At first, to watch your TV, select the TV mode by pressing the MODE button on
the remote control before you turn the TV power on.

• See page 58 to 68 for details regarding the remote control buttons.

Using Menu Buttons

To use the menu functions, press the MENU button. Next,
select a menu using the four arrow keys. The four arrow keys
are used only for menu selections.

U

N

E

M

DVR

OK

F

A

V

O

R

I

T

E

12

S

A

POWER

T

C

E

P

B

A

C

K

Quick Setup

Step 2 - Connecting your devices

To make these connections, you will use plugs like the ones illustrated below.

Coaxial Cables

Component Cables

Composite Cables

Audio Cables

Used to connect an external
antenna or cable TV system to your
TV.

S-Video Cable

Used to make video connections
with S-Video VCRs, Camcorders
and DVD players.

Notes:

• The following connection diagrams are examples.

• After you are finished connecting your devices, plug the power cord into the nearest power
outlet and turn on the TV.

• If you follow these diagrams and the television does not work properly, contact your local

cable operator.

• To connect a DVD player, see VCR Connection.

• If you have a satellite television system, refer to the satellite TV manual.

Used to connect audio/video
devices like VCRs, DVD players,
stereo amplifiers, game consoles,
etc.

No VCR Connection

Cable or Antenna

Output

TV Rear Panel

Coaxial Cable

13

Quick Setup

VCR • DVD Connection

Notes:

• Green, blue and red are the most common colors for DVD cables. Some models may vary
colors. Please consult the user’s manual for your DVD player for more information.

• Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete
one set of connections (DVD or audio output) before starting the other to avoid accidentally
switching the cables.

• You may also connect the DVD player to Input 1.

Diagram #1

P

C

I

N

(D

-S
U

B

)

INPUT 5

V

I

D

EO

R

­A

U

D

I
O

­L

Y

P

R

P

B

INPUT 4

V

I

D

E

O

R

­AU

D

I
O

­L

Y

P

R

P

B

INPUT 3

S

­VID

E

O

V

I

DEO

R

­AU

D

I
O

-L

AUDIO INP

UT

R

L

FOR HDMI 1

UDIO OUT

R

­A

U

D

I
O

­L

AUDIO OUT

UDIO OUT

TV Rear Panel

AUDIO OUT

R L

DVD Player

OR

R L V

IN

OUT

OUT

IN

OUT

Y

Green

P

B

Blue

P

R

Red

VCR

Cable or Antenna

Output

Coaxial Cable

TV Rear Panel

Note:

• If this connection setup does not work for you, try the connection setup on page 15.

14

Diagram #2

P

C

IN

(D

-S

U

B

)

INPUT 5

V

I

D

EO

R

-

A

U

D

I

O

-

L

Y

P

R

P

B

INPUT 4

V

I

D

E

O

R

-

AU

D

I

O

-

L

Quick Setup

Cable or Antenna

Output

Y

P

R

P

B

INPUT 3

S

-

VID

EO

V

I

DEO

R

-

AU

D

I

O

-L

AUDIO INP

UT

R

L

FOR HDMI 1

UDIO OUT

R

-

A

U

D

I

O

-

L

AUDIO OUT

UDIO OUT

TV Rear Panel

AUDIO OUT

R L

DVD Player

OR

R L V

OUT

IN

Two-Way Splitter

OUT OUT

Y

Green

P

B

Blue

P

R

Red

(Not supplied)

OUT

IN

IN

OUT

VCR

Coaxial Cable

TV Rear Panel

15

Quick Setup

I

Connecting to a Camcorder

You can connect a camcorder to your television by using the input jacks located on the back
of the TV.

V

I

D

EO

R

-

A

U

D

IO

-

TV Rear Panel

CAMCORDER

1) Connect a yellow composite cable from the camcorder VIDEO OUT to the VIDEO IN on the
back of the TV.

2) Connect a white cable from the camcorder LEFT AUDIO OUT to the LEFT AUDIO IN on the
back of the TV.

3) Connect a red cable from the camcorder RIGHT AUDIO OUT to the RIGHT AUDIO IN on
the back of the TV.

L

Y

P

R

P

B

INPUT 4

VI

DEO

R

-

AU

D

I

O

-

L

Y

P

R

P

B

INPUT 3

S

-

V

IDE

O

V

I

DEO

R

-

AU

D

I

O

-

L

16

Quick Setup

Connecting to an External Amplifier

P

R

P

B

INPUT 3

S

-

V

ID

E

O

V

I

DEO

R

-

AU

D

I

O

-

L

AUD

I

O

I

NPUT

R

L

FOR HDMI 1

UDIO OUT

R

-

A

U

D

I

O

-

L

AUDIO OUT

UDIO OUT

1) Connect a white cable from the LEFT AUDIO OUTPUT on the back of the TV to the
LEFT AUDIO INPUT on the amplifier.

2) Connect a red cable from the RIGHT AUDIO OUTPUT on the back of the TV to the
RIGHT AUDIO INPUT on the amplifier.

Notes:

• Refer to your amplifier’s manual for more information.

• You can use AUDIO OUTPUT for your home theater system.

• If you have a device connected to INPUT-1, INPUT-2 or INPUT-5 (set "V5 INPUT" in the

INITIAL SETUP menu to "HDMI"). You will not be able to hear any audio from the AUDIO
OUT on the back of the TV.

TV Rear Panel

Speaker

Speaker

Amplifier

17

Quick Setup

A

Connecting to a Digital TV Receiver

By connecting a Digital TV Receiver, high definition pictures can be displayed on your TV in
their digital form.

R

­AU

D

I
O

-L

A

UD

IO INP

UT

R

L

FOR HDMI 1

UDIO OUT

LR

TV Rear Panel

RS-232C

INPUT 5 INPUT 2 INPUT 1

TV Rear Panel

SERVICE

ONLY

DIGITAL AUDIO

OPTICAL OUT

R

­A

U

D

I
O

­L

AUDIO OUT

UDIO OUT

AUDIO OUT

DIGITAL OUT

DTV Decoder

fter the connections have been made,

tighten the screw to secure the cables.

HDMI to DVI Cable

1) Connect the HDMI to DVI Cable from the DIGITAL OUT on the back of your DTV decoder to
the HDMI INPUT-1 on the back of the TV.

2) Connect a red cable from the DTV decoder RIGHT AUDIO OUT to the RIGHT AUDIO INPUT
HDMI AUDIO IN "R" on the back of the TV.

3) Connect a white cable from the DTV decoder LEFT AUDIO OUT to the LEFT AUDIO INPUT
HDMI AUDIO IN "L" on the back of the TV.

• Personal computer compatibility cannot be guaranteed.

• Use an HDMI to DVI cable (commercially available) in order to digitally connect the television

with a DTV decoder.

Notes:

• If 480p signals (640x480 or 720x480) are displayed on the screen, the horizontal balance

may be slightly shifted. Access the “HDMI SIZE” in the INITIAL SETUP menu to adjust it.
(Refer to page 30.)

• When you do the above connection, set "VIDEO-1 AUDIO" in the INITIAL SETUP menu to

"ANALOG". See "VIDEO-1 AUDIO", page 30.

• The Analog Audio input can only be used with the HDMI INPUT-1.

• When setting the “VIDEO-1 AUDIO - ANALOG/DIGITAL” menu setting on the TV, please note

that this setting only effects the HDMI INPUT-1 jack and that if you use a DVI to HDMI adapter
this connection must be made to the HDMI INPUT-1 along with analog audio cables.

18

Quick Setup

Connecting to an HDMI Compatible Device

By connecting an HDMI compatible device, high definition pictures can be displayed on your
TV in their digital form. Some HDMI devices can include DVD players, D-VHS or other HDMI
compatible device.

HDMI (High Definition Multimedia Interface) is the first industry supported, uncompressed, all
digital audio/video interface. HDMI provides an interface between any audio/video source,
such as a set-top box, DVD player, A/V receiver or an audio and/or video monitor, such as a
digital television (DTV).

TV Rear Panel

SERVICE

DIGITAL AUDIO

ONLY

RS-232C

INPUT 5 INPUT 2 INPUT 1

OPTICAL OUT

HDMI Compatible Device

LR

AUDIO OUT

DIGITAL OUT

HDMI Cable

1) Connect the HDMI Cable from the DIGITAL OUT on the back of your DTV or HDMI device to
the HDMI INPUT-1 on the back of the TV.

Notes:

• When you do the above connection, set "VIDEO-1 AUDIO" in the INITIAL SETUP menu to
"DIGITAL". See "VIDEO-1 AUDIO", page 30.

• Some decoders may not respond depending on the equipment that is connected to the HDMI.

• If the HDMI output device signal is changed (for example, 480i/60Hz is changed to
480p/60Hz), the screen may turn green and there may be some distortion for a short time
until the signal becomes stable.

• This TV can accept 480i, 480p, 720p, 1080i and 1080p signals via HDMI.

• This JVC television can accept a variety of HD signals, including 720/60p, 1080/60i and
1080/60p. It does not accept a 1080/24p signal. Please note that in some cases, a Blu-ray
or HD-DVD may only offer the choice of 1080/60i or 1080/24p. In this case, it is necessary
to choose the 1080/60i output. Please refer to your Blu-ray/HD-DVD manual for complete
details on choosing the correct output.

19

Quick Setup

Connecting to an amplifier using your optical output

You can connect an amplifier that has an optical digital input terminal by using an optical digital
cable from the optical output. The signal that is output can be PCM or DOLBY DIGITAL.

TV Rear Panel

RS-232C

SERVICE

ONLY

INPUT 5 INPUT 2 INPUT 1

DIGITAL AUDIO

OPTICAL OUT

Amplifier

1) Connect the optical cable from underneath the television to the back of the amplifier.

Notes:

• This terminal can only output digital audio.

• In order to use the optical output connection, select PCM or DOLBY DIGITAL on Digital
Sound in the DIGITAL SETUP Menu. See page 48.

• Refer to your owners manual on using your amplifier.

• You cannot output sound from your Optical Output connection if the audio source is from
your HDMI device.

20

Quick Setup

R

Connecting to an AV Receiver using your television's
V3 Smart Input

By connecting your AV Receiver to your television's V3 Smart Input, you can watch picture
sources from many different devices, without having to change or use the other input
connections on your TV. This allows you to free up the other input connections so you can
connect more devices to your television.

TV Rear Panel

AV Receiver

MONITOR

OUT

P

R

P

B

Y

MONITOR OUT

1) Connect an S-Video Cable from the AV Receiver's MONITOR OUT to the S-Video INPUT-3

on the back of the TV.

2) Connect a Yellow Composite Cable from the AV Receiver's MONITOR OUT to the VIDEO

INPUT-3 on the back of the TV.

3) Connect a Green Component Cable from the AV Receiver's Y MONITOR OUT to the Y

VIDEO INPUT-3 on the back of the TV.

4) Connect a Blue Component Cable from the AV Receiver's PB MONITOR OUT to the PB

VIDEO INPUT-3 on the back of the TV.

5) Connect a Red Component Cable from the AV Receiver's P

VIDEO INPUT-3 on the back of the TV.

­AU

D

I

O

­L

Y

P

R

P

B

INPUT 3

S

­VID

EO

V
I

DEO

R

­AU

D

I

O

-L

AUDIO INP

UT

R

L

FOR HDMI 1

UDIO OUT

R

­A

U

D

I

O

­L

AUDIO OUT

UDIO OUT

R MONITOR OUT to the PR

Notes:

• Please refer to your AV Receiver instruction manual for more information on connecting your
speakers and other devices like a DVD player.

• Use your AV Receiver's remote to switch to the different devices you have connected.

• Some AV Receivers may not respond when the V3 Smart Input function is turned on.

• If you have video connections for each input device connected to your AV Receiver, you
should not connect them using both S-Video and Composite connection at the same time
when you are using V3 Input as the V3 Smart Input. In this case we recommend using the
S-Video connection.

21

Quick Setup

Connecting to the computer

This TV can be used as a computer screen. Use a commercially available D-SUB cable to
connect the TV's PC INPUT terminal to the computer's analog RGB output terminal. If you
want to listen to the sound from the computer, use a commercially available RCA cable to
connect the INPUT-5 audio input terminal to the computer's audio output terminal.

P

C

IN

(D

-S

U

B

)

INPUT 5

V

I

D

E

TV Rear Panel

Computer

Notes:

• When you do the above connection, set "V5 INPUT" in the INITIAL SETUP menu to "PC".

See page 49.

• Refer to your computer manual for a detailed explanation of the connections concerning your

computer.

• Use cable with ferrite cores and no longer than of 3 m to avoid electromagnetic disturbance.

• Make sure that the connectors are facing the correct way when connecting.

• After connecting, tighten the two screws to fix the connectors in place.

O

R

-

A

U

D

I

O

-

L

Y

P

R

P

B

INPUT 4

V

I

D

EO

R

-

AU

D

I

O

-

L

Y

P

R

P

B

INPUT 3

Looking at the images from a computer

After starting the computer, press the V5 button on the remote control. You can listen to the
sound when the sound from the computer is connected to the INPUT-5 AUDIO input terminal.

22

Table of signals for each type of computer

Quick Setup

Resolution

640 x 480
(VGA)

1024 x 768
(XGA)

Vertical
Frequency
(Hz)

60.0

60.0

Horizontal
Frequency
(kHz)

31.5

48.4

• Only the above formats are supported.

• Even with the above formats at 60 Hz, some problems may be experienced depending on
the quality of the synchronous signal. (Depending on the quality, some pictures may not be
displayed correctly).

• Apple Macintosh* computers are not supported.

When a picture is not displayed

With some computers, some problems can be solved by changing the settings. Check the
computer's refresh rate and set it to 60Hz. Computers that cannot set the refresh rate to 60
Hz, cannot be used with this TV. Refer to the computer's instruction manual.

*Apple Macintosh is a registered trademark of Apple Inc.

Note:

• If you are inputting a PC signal that is invalid, "Invalid Signal" will appear on the TV screen.
It appears when the input is PC and it is a single screen.

23

Quick Setup

Step 3 – The Interactive Plug In Menu

When you turn your television on for the first time the interactive plug in menu will appear. The
plug in menu helps you to get your TV ready to use by letting you set your preferences for:

• The language in which you want the onscreen menus to appear.

• Setting the TV’s clock to the correct time so your timer functions will work properly. You can
choose “AUTO” or “MANUAL” for setting the clock.

• The auto tuner setup of which channels you wish to receive.

We recommend you complete the interactive plug in items before you start using your
television.

Notes:

• The interactive plug in menu setting does not appear if your TV has been turned on before.
In this case use the onscreen menus to perform these settings. See pages 34, 56, 37.

• If you press the Menu button while setting up the interactive plug in menu, it will skip over it.

Language

After the “JVC INTERACTIVE PLUG IN MENU” has been displayed, the TV automatically
switches to the LANGUAGE settings. You can choose to view your onscreen menus in three
languages: ENGLISH, FRANÇAIS (French) or ESPAÑOL (Spanish).

LANGUAGE/LANGUE/IDIOMA

ENGLISH

NEXT

SELECT OPERATE EXIT

MENU

24

è

To choose a language:

ENGLISH, FRANÇAIS or ESPAÑOL

†

To NEXT (To set clock)

(Continued...)

Quick Setup

Auto Clock Set

Before you use any of your TV’s timer functions, you must first set the clock. You may
precisely set your clock using the XDS time signal broadcast by most public analog
broadcasting stations. If you do not have this in your area, you will have to set the clock
manually. See manual clock set below. To set the clock using the XDS signal:

è

SET CLOCK

MODE

TIME

TIME ZONE

D.S.T.

NEXT

SELECT OPERATE EXIT

AUTO

--

: --

ATLANTIC

ON

MENU

--

Notes:

• D.S.T. can be used when it is set to ON in the SET CLOCK menu.

• Only when the MODE is set to AUTO, the Daylight Saving Time feature automatically adjusts
your TV’s clock for Daylight Saving.

• The real time and D.S.T. may not be set correctly depending on the broadcasting signal and
receiving conditions. In this case, set your clock manually and turn D.S.T. to OFF.

• You will have to reset the clock after a power interruption. You must set the clock before
operating any timer functions.

To choose AUTO

†

To TIME ZONE

è

To select your time zone: (Atlantic, Eastern,

Central, Mountain, Pacific, Alaska or Hawaii)

†

To move to D.S.T. (Daylight Savings Time)

è

To turn D.S.T. ON or OFF

†

To NEXT (To Auto Tuner Setup)

Manual Clock Set

To set your clock manually (without using the XDS signal), choose MANUAL. If you choose
AUTO, see auto clock set above.

è

SET CLOCK

MODE
TIME

TIME ZONE

D.S.T.

START CLOCK

SELECT OPERATE EXIT

MANUAL

--

: --

ATLANTIC

MENU

--

ON

To choose MANUAL

†

è

†

è

†

è

To TIME

To set the hour

To minute

To set the minute

To TIME ZONE

To select your time zone: (Atlantic, Eastern,

Central, Mountain, Pacific, Alaska or Hawaii)

†

To move to D.S.T. (Daylight Savings Time)

è

To turn D.S.T. ON or OFF

†

To START CLOCK

Note:

• You will have to reset the clock after a power interruption. You must set the clock before
operating any timer functions.

(Continued...)

25

Quick Setup

Auto Tuner Setup

In auto tuner setup, the TV automatically scans through all available channels, memorizing the
active ones and skipping over blank ones or channels with weak signals. This means when you
scan (using the C

HANNEL +/– buttons) you will receive only clear, active channels.

AUTO TUNER SETUP

START

SELECT OPERATE EXIT

MENU

è

AIR TUNER MODE

†

After Analog Auto Tuner Setup is finished, Digital Auto
Tuner Setup starts.

To choose CABLE or AIR (or SKIP when
you skip Auto Tuner Setup)

To START

NOW

PROGRAMMING !

Now Programming...

20

48

When the setup is finished, "THANK YOU ! SETUP IS NOW COMPLETE" is displayed. Your
quick setup is now complete. You can now begin watching your television, or you can continue
on in this guide for more information on programming your remote control, or using the
JVC onscreen menu system to customize your television viewing experience.

Notes:

• If you want to cancel the Auto Tuner Setup, press the MENU button.

• Noise Muting will not work during Auto Tuner Setup.

• If you choose SKIP, it finished without doing the Auto Tuner Setup.

Cable Box and Satellite Users: After your auto tuner setup is complete, you may, (depending
on the type of hookup), have only 1 channel, usually 3 or 4 in the auto tuner memory. This is
normal.

26

Onscreen Menus

Using the Guide

Certain symbols are used throughout this guide to help you learn about the features of your
new television. The ones you will see most frequently are:

π†

Up and Down arrows mean:

• Move vertically in a main menu screen

• Move through a submenu screen

• Move to the next letter, number, or other choice in a submenu

è

Left and right arrows mean:

• Select a highlighted menu item

• Select an item in a submenu

• Select numbers in certain menu options

The “press button” icon means you should press the button named on your remote

control. (Button names appear in S

The “helping arrow” icon points to the highlighted or selected item in a menu.

To bring up the onscreen menu, press the MENU button on the remote control. The item that
appears in green is the one currently selected. If you use the Menu button on the TV’s side
panel instead of the remote, an additional menu screen showing VIDEO STATUS and ASPECT
will appear between INITIAL SETUP and PICTURE ADJUST. The “INTERACTIVE PLUG IN
MENU” will appear the first time the TV is plugged in.

MALL CAPITAL LETTERS.)

PREVIOUS

AUTO TUNER SETUP

CHANNEL SUMMARY

V-CHIP

SET LOCK CODE

AUTO DEMO

NEXT PAGE

SELECT OPERATE EXIT

INITIAL SETUP

ON

(4/5)

MENU

Note:

• Menus shown in this book are illustrations, not exact replications of the television’s onscreen
displays.

27
