JVC KW-V215DBT User Manual

KW-V41BT/KW-V215DBT/KW-V21BT/KW-V11

MONITOR WITH DVD RECEIVER

INSTRUCTION MANUAL

MONITOR MIT DVD-RECEIVER

BEDIENUNGSANLEITUNG

MONITEUR AVEC RÉCEPTEUR DVD

MODE D’EMPLOI

MONITOR MET DVD-ONTVANGER

GEBRUIKSAANWIJZING

ENGLISH

DEUTSCH

FRANÇAIS

NEDERLANDS

CONTENTSCONTENTS

BEFORE USE............................................................ 2

How to reset your unit.................................................... 3

INITIAL SETTINGS .................................................. 4

BASICS .................................................................... 5

Component names and functions ............................. 5

Common operations .......................................................6

Common screen operations ......................................... 8

Selecting the playback source ..................................... 9

DISCS .................................................................... 10

USB........................................................................ 14

iPod/iPhone ......................................................... 15

APPs ...................................................................... 18

TUNER ................................................................... 19

DIGITAL RADIO (DAB)

(Only for KW-V215DBT)....................................... 23

OTHER EXTERNAL COMPONENTS ...................... 27

Using external audio/video players—AV-IN ........27

Using a rear view camera ............................................27

How to read this manual:

• Illustrations of KW-V41BT are mainly used for explanation. The displays and panels shown in this manual are examples used to provide clear explanations of the operations. For this reason, they may be different from the actual displays or panels.

• This manual mainly explains operations using the buttons on the monitor panel and touch panel. For operations using the remote controller ( RM-RK258: optional accessory), see page 45 .

• < > indicates the various screens/menus/operations/settings that appear on the touch panel.

• [ ] indicates the buttons on the touch panel.

• Indication language: English indications are used for the purpose of explanation. You can select the indication language from the < Settings> menu. (Page44)

• Updated information (the latest Instruction Manual, system updates, new functions, etc.) is available from <http://www.jvc.net/cs/car/>.

BLUETOOTH (Only for KW-V41BT/KW-V215DBT/

KW-V21BT) ...........................................................28

SETTINGS .............................................................. 36

Sound adjustment .........................................................36

djustment for video playback .................................37

Changing display design .............................................39

Customizing the Home screen ..................................40

Customizing the system settings .............................40

Setting menu items ....................................................... 42

REMOTE CONTROLLER ........................................45

CONNECTION/INSTALLATION ............................ 47

REFERENCES ......................................................... 51

Maintenance ....................................................................51

More information ........................................................... 51

Error message list ...........................................................55

Troubleshooting .............................................................55

Specifications ...................................................................58

BEFORE USEBEFORE USE

IMPORTANT

To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe WARNINGS and CAUTIONS in this manual. Please keep the manual in a safe and accessible place for future reference.

V WARNINGS: (To prevent accidents and damage)

• DO NOT install any unit or wire any cable in a location where;

– it may obstruct the steering wheel and gearshift

lever operations.

– it may obstruct the operation of safety devices

such as air bags.

– it may obstruct visibility.

• DO NOT operate the unit while driving. If you need to operate the unit while driving, be sure to look around carefully.

• The driver must not watch the monitor while driving.

The marking of products using lasers

The label is attached to the chassis/case and says that the component uses laser beams that have been classified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no danger of hazardous radiation outside the unit.

BEFORE USEBEFORE USE

Information on Disposal of Old Electrical and Electronic Equipment and Batteries (applicable

for countries that have adopted separate waste collection systems)

Products and batteries with the symbol (crossedout wheeled bin) cannot be disposed as household waste. Old electrical and electronic equipment and batteries should be recycled at a facility capable of handling these items and their waste byproducts. Contact your local authority for details in locating a recycle facility nearest to you. Proper recycling and waste disposal will help conserve resources whilst preventing detrimental effects on our health and the environment. Notice: The sign “Pb” below the symbol for batteries indicates that this battery contains lead.

For Israel

For KW-V11

Declaration of Conformity with regard to the EMC Directive 2004/108/EC Declaration of Conformity with regard to the RoHS Directive 2011/65/EU Manufacturer:

JVC KENWOOD Corporation 3-12 Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, Japan

EU Representative:

JVC Technical Services Europe GmbH Konrad-Adenauer-Allee 1-11, D-61118 Bad Vilbel, Germany

V Cautions on the monitor:

• The monitor built into this unit has been produced with high precision, but it may have some ineffective dots. This is inevitable and is not considered defective.

• Do not expose the monitor to direct sunlight.

• Do not operate the touch panel using a ball-point pen or similar tool with a sharp tip. Touch the buttons on the touch panel with your finger directly (if you are wearing a glove, take it off).

• When the temperature is very cold or very hot...

– Chemical changes occur inside, causing

malfunction.

– Pictures may not appear clearly or may move

slowly. Pictures may not be synchronized with the sound or picture quality may decline in such environments.

For safety...

• Do not raise the volume level too much, as this will make driving dangerous by blocking outside sounds, and may cause hearing loss.

• Stop the car before performing any complicated operations.

Temperature inside the car...

If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.

R How to reset your unit

If the unit fails to operate properly, press the reset button.

KW-V41BT

KW-V215DBT KW-V21BT KW-V11

ENGLISH 3

INITIAL SETTINGSINITIAL SETTINGS

Initial setup

When you power on the unit for the first time or reset the unit, the initial setting screen appears.

• You can also change the settings on the

<Settings> screen. (Page42)

KW-V41BT

KW-V215DBT/KW-V21BT/KW-V11

<Angle>* (Page7)

(Page43)

<R-CAM Interrupt>

(Page43) <Panel Color>* (Page39)

<User Customize>*

(Page39)

Adjust the panel angle.

Select an external

component connected to the iPod/AV-IN terminal to play. Select [ON] when connecting the rear view camera.

Select the color of the buttons on the monitor panel. Select the display design.

2 Finish the procedure.

Clock settings

1 Display the Home screen.

KW-V41BT KW-V215DBT/KW-V21BT/

KW-V11

2 Display the <Settings> screen.

(Page43)

(Page44)

Activate or deactivate the display demonstration. Select the text language used for on-screen information.

• Set <GUI Language>

to display the operation buttons and menu items in the selected language ([Local]: initially selected) or English ([English]).

The Home screen is displayed.

• [AV Off] is selected initially. Select the

playback source. (Page9)

*1 Only for KW-V41BT. *2 Only for KW-V215DBT/KW-V21BT/KW-V11.

3 Display the <Clock> screen.

INITIAL SETTINGSINITIAL SETTINGS

4 Set the clock time.

<Radio Data System>*

<DAB>*

<OFF> Sets the clock manually. (See

When selecting <OFF>: Adjust the hour (1), then adjust the minute (2).

• Press [Reset] to set the minute to “00”.

Synchronizes the clock time with

FM Radio Data System .

Synchronizes the clock time with the digital radio (DAB).

below.)

BASICSBASICS

Component names and functions

V Caution on the volume setting:

Digital devices produce very little noise compared with other sources. Lower the volume before playing these digital sources to avoid damaging the speakers by sudden increase of the output level.

KW-V41BT

5 HOME/ button

• Displays the Home screen. (Press) (Page 8)

• Turns on the power. (Press) (Page 6)

• Turns off the power. (Hold) (Page 6)

6 / button

• Displays the <Hands Free> screen. (Press)

(Page 31)

• Activates the voice dialing. (Hold) (Page 33)

7 DISP/DISP OFF button

• Switches the screen. (Press) – The screen switched to depends on the

< Navigation Input> setting (Page43 ).

• Turns off the screen. (Hold) (Page 7)

• Turns on the screen. (Hold) (Page 7)

8 M (Eject) button Ejects the disc (Tilts the monitor panel fully).

(Page 10)

9 Reset button Resets the unit. (Page 3)

* You can change the color of the buttons on the monitor panel.

(Page 39)

5 Finish the procedure.

*1 Only for KW-V41BT/KW-V21BT/KW-V11. *2 Only for KW-V215DBT.

1 Screen (touch panel) 2 Monitor panel* 3 VOLUME –/+ button

Adjusts the audio volume. (Page 7) 4 ATT button Attenuates the sound. (Page 7)

ENGLISH 5

BASICSBASICS

KW-V215DBT/KW-V21BT/KW-V11

KW-V215DBT/ KW-V21BT

1 Reset button Resets the unit. (Page 3)

2 Loading slot 3 M (Eject) button

Ejects the disc. (Press) (Page 10) 4 Volume +/– button Adjusts the audio volume. (Page 7)

5 USB input terminal (Page 49 ) 6 Monitor panel 7 Screen (touch panel)

KW-V11

button

• Switches the screen. (Press) – The screen switched to depends on the

< Navigation Input> setting (Page43).

• Turns off the screen. (Hold) (Page 7)

• Turns on the screen. (Hold) (Page 7)

9 HOME/ button

• Displays the Home screen. (Press) (Page 8)

• Turns on the power. (Press) (See the right

column.)

• Turns off the power. (Hold) (See the right

column.)

p For KW-V215DBT/KW-V21BT: / button

• Displays the <Hands Free> screen. (Press)

(Page 31)

• Activates the voice dialing. (Hold) (Page 33)

For KW-V11: SRC button Displays the source control screen. (Page 9) q EQ button Displays the <Equalizer> screen. (Page 36)

Common operations

R Turning on the power

KW-V41BT KW-V215DBT/KW-V21BT/

KW-V11

R Turning off the power

KW-V41BT KW-V215DBT/KW-V21BT/

KW-V11

(Hold)

BASICSBASICS

R Adjusting the volume

To adjust the volume (00 to 35)

KW-V41BT

Press + to increase, and press – to decrease.

• Holding the button increases/decreases the volume continuously.

KW-V215DBT/ KW-V21BT/ KW-V11

R Turning on/off the AV source

You can activate the AV function by selecting a source.

On the Home screen:

R Adjusting the panel angle (only for

KW-V41BT)

1 Display the <Angle Adjust> screen.

On the Home screen:

• Press [K] repeatedly to change the page on

the <Display> menu screen.

To attenuate the sound (only for KW-V41BT)

The ATT indicator lights up.

To cancel the attenuation: Press the same button again.

R Turning off the screen

KW-V41BT KW-V215DBT/KW-V21BT/

To turn on the screen: Press and hold the same button on the monitor panel, or touch the display.

(Hold)

KW-V11

(Hold)

• You can also activate the AV function by selecting a source on the Home screen.

To turn off the AV source:

2 Select an angle (0 – 6).

• To set the current position as the power off

position, select [Memory] for <Off Position>.

ENGLISH 7

BASICSBASICS

Common screen operations

❏ Common screen descriptions

You can display other screens any time to change the source, show the information, or change the settings, etc.

Source control screen

Performs source playback operations.

• The operation buttons vary depending on the selected source.

Gesture control on the source control screen:

You can also control playback by moving your finger on the touch panel as follows (for some sources, the gesture control is not available).

• Sliding the finger towards up/down: Functions same as pressing [ ]/[ ] .

• Sliding the finger towards left/right: Functions same as pressing [S]/[T].

• Moving your finger clockwise or counter- clockwise: increases/decreases the volume.

Home screen

Displays the source control screen/settings screen and changes the picture source.

• To display the Home screen, press HOME on the monitor panel.

• You can arrange the items to display on the Home screen. (Page 40)

Common operating buttons:

1 Displays all the sources. (Page9) 2 Displays the <Settings> screen. (See below.) 3 Changes the playback source. (Page 9)

<Settings> screen

Changes the detailed settings. (Page 42)

Common operating buttons:

1 Selects the menu category. 2 Returns to the previous screen. 3 Changes the page. 4 Displays the current source control screen.

❏ Touch screen operations

1 Displays the video control menu while playing a

video.

2 Displays the source control screen while playing

a video.

• The operation buttons disappear when the screen is touched or when no operation is done for about 5 seconds.

3 Goes to the previous chapter/track.* 4 Goes to the next chapter/track.*

* Not available for video from an external component. Dragging your

finger to the left or right functions in the same way as touching.

BASICSBASICS

Selecting the playback source

1 Display the Home screen.

KW-V41BT KW-V215DBT/KW-V21BT/

KW-V11

2 Display [All] screen, then select the source.

[Tuner] Switches to the radio broadcast.

(Page 19 )

[ DAB]*1 Switches to the digital audio

broadcast (DAB). (Page23)

[Disc] Plays a disc. (Page 10) [USB] Plays files on a USB device.

(Page 14)

[iPod] Plays an iPod/iPhone. (Page 15) [ BT Phone]*

[BT Audio]*

[AV-IN]*

Displays the <Hands Free> screen.

(Page 31)

Plays a Bluetooth audio player.

(Page 35)

Switches to an external component

connected to the iPod/AV-IN terminal on the rear panel. (Page 27)

[Apps]*

Switches to the App screen from

the connected iPod touch/iPhone. (Page 18)

[AV Off] Turns off the AV source.

(Page 7)

[Camera] Displays the picture from the rear

view camera. (Page 27)

* 1 Only for KW-V215DBT. *2 Only for KW-V41BT/KW-V215DBT/KW-V21BT.

Appears only when <AV Input> is set to [AV-IN].

(Page43)

Appears only when <AV Input> is set to [iPod]. (Page43)

R Selecting the playback source on the

Home screen

• You can change the items (other than [Settings])

to display on the Home screen. (Page40)

ENGLISH 9

DISCS DISCS

Playing a disc

• If a disc does not have a disc menu, all tracks on it will be played repeatedly until you change the source or eject the disc.

• For playable disc types/file types, see page 52.

R Inserting a disc

Insert a disc with the label side facing up.

KW-V41BT

KW-V215DBT/ KW-V21BT/KW-V11

The source changes to “DISC” and playback starts.

• The DISC IN indicator lights up while a disc is inserted.

• If “ ” appears on the screen, the unit cannot accept the operation you have tried to do.

– In some cases, without showing “ ,”

operations will not be accepted.

• When playing back a multi-channel encoded disc, the multi-channel signals are downmixed to stereo.

R Ejecting a disc

KW-V41BT KW-V215DBT/KW-V21BT/

• When removing a disc, pull it horizontally.

• You can eject a disc when playing another AV source.

• If the ejected disc is not removed within 15 seconds, the disc is automatically inserted again into the loading slot to protect it from dust.

Closing the monitor panel (only for KW-V41BT)

After removing the disc, press M on the monitor panel. The monitor panel closes.

KW-V11

Playback operations

When the operation buttons are not displayed on the screen, touch the area shown on the illustration.

• To change settings for video playback, see page 37.

R Indications and buttons on the source

control screen

For video playback

23 4 561

Playback information

• The information displayed on the screen differs depending on the type of disc/file being played back.

1 Media type 2 Playback mode (Page13) 3 File type 4 DISC IN indicator 5 Current playback item information (title no./

chapter no./folder no./file no./track no.)

6 Playing time

DISCSDISCS

Operation buttons

• Available buttons on the screen and operations differ depending on the type of disc/file being played back.

[Mode] Changes the settings for disc

[ ] [ ]

] [ ]

[

[ ]

[o] [IW] [S] [T]

[Title ] [Title ]

For audio playback

playback on the <DVD Mode> or <DISC Mode> screen. (Page13)

Selects a folder. Selects playback mode.

(Page13) Displays the folder/track list. (See

the far right column.)

Stops playback. Starts/pauses playback.

• Selects a chapter/track. (Press)

• Reverse/forward search. (Hold) Selects a title.

34 786 9521

Playback information

• The information displayed on the screen differs depending on the type of disc/file being played back.

1 Media type 2 Track/file information

• Pressing [ H] scrolls the text if not all of the text

is shown.

3 Playback mode (Page13) 4 File type 5 Current playback item information (folder no./file

no./track no.)

6 Playback status 7 DISC IN indicator 8 Playing time 9 Jacket picture (Shown while playing if the file has

tag data that includes the jacket picture)

Operation buttons

• Available buttons on the screen and operations differ depending on the type of disc/file being played back.

[Mode ] Changes the settings for disc

playback on the <DISC Mode> screen. (Page13)

[ ] [ ] [

] [ ]

Selects a folder. Selects playback mode.

(Page13)

[

]

[IW] [S] [T]

Displays the folder/track list. (See the right column.) Starts/pauses playback.

• Selects a track. (Press)

• Reverse/forward search. (Hold)

R Selecting a folder/track on the list

2 Select the folder (1), then the item in the

selected folder (2).

• Repeat the procedure until you select the desired track.

• If you want to play all tracks in the folder, press [I] on the right of the desired folder.

• You can change the page to display more items by pressing [ J]/[ K].

• Press [

• Press [ ] to return to the upper layer.

] to return to the root folder.

ENGLISH 11

DISCSDISCS

R Video menu operations

You can display the video menu screen during video playback.

• The operation buttons disappear when the screen is touched or when no operation is done for about 5 seconds.

For video playback except VCD

• Available buttons on the screen and operations differ depending on the type of disc/file being played back.

[Zoom ] Displays the picture size selecting

screen. (Page38)

[Aspect] Selects the aspect ratio. (Page38) [Pict Adjust] Displays the picture adjustment

screen. (Page37)

[Audio] Selects the audio type. [Subtitle] Selects the subtitle type. [Angle] Selects the view angle. [Menu] Displays the disc menu (DVD). [Top Menu] Displays the disc menu (DVD). [Highlight] Switches to the direct disc menu

mode. Touch the target item to select.

• To restore the screen, press DISP (for KW-V41BT)/

(for KW-V215DBT/KW-V21BT/KW-V11) on the monitor panel.

[ Cursor] Displays the menu/scene selecting

screen.

• [J] [K] [H] [I]: Selects an item. – For DivX®: [H] [I] skips back or

forward by about 5 minutes.

• [Enter]: Confirms the selection.

• [Return]: Returns to the previous

screen.

For VCD [Menu ] Displays the disc menu. [Direct] Displays/hides the direct selecting

buttons. (See below.)

[Audio] Selects the audio channel (ST: stereo,

L: left, R: right).

[Return] Displays the previous screen or menu. [Zoom] Displays the picture size selecting

screen. (Page38)

[Aspect] Selects the aspect ratio. (Page38)

ict

[P Adjust]

Displays the picture adjustment screen. (Page37)

• To deactivate the PBC function, stop playback, then use the direct selecting buttons to select a track number.

To select a track directly on a VCD

• When you enter a wrong number, press [Direct/ CLR] to delete the last entry.

DISCSDISCS

R Selecting playback mode

Selects Random playback mode.

[ ]

Selects Repeat playback mode.

[ ]

• Available playback modes differ depending on the type of disc/file being played back.

• You cannot activate the repeat mode and the random mode at the same time.

• Each time you press the button, the playback mode changes. (The corresponding indicator lights up.)

– Available items differ depending on the type of

disc/file being played back.

CHAP Repeats current chapter. TITLE Repeats current title.

SONG Repeats current track. F OLDER Repeats all tracks of the

F OLDER Randomly plays all tracks of

ALL Randomly plays all tracks.

To cancel Repeat/Random playback: Press the button repeatedly until the indicator disappears.

current folder.

the current folder, then tracks of the next folder.

Settings for disc playback

R Setting items

• Available items shown on the <DVD Mode> or <DISC Mode> screen differ depending on the

type of disc/file being played back.

<Down Mix> When playing back a multi-channel

Select the initial disc menu language. (Initial: English ) (Page54)

Select the initial audio language. (Initial: English ) (Page54)

Select the initial subtitle language

or turn subtitles off (Off). (Initial: English ) (Page54)

disc, this setting affects the signals reproduced through the front and/or rear speakers.

• Dolby Surround: Select this to

enjoy multi-channel surround sound by connecting an amplifier compatible with Dolby Surround.

• Stereo (initial): Normally select

this.

You can change the dynamic range while playing Dolby Digital software.

• Wide: Select this to enjoy a

powerful sound at a low volume level with its full dynamic range.

• Normal: Select this to reduce the

dynamic range a little.

• Dialog (initial): Select this to

reproduce movie dialog more clearly.

< Screen Ratio>

Select the monitor type to watch a wide screen picture on the external monitor.

16:9 (Initial)

4:3 LB 4:3 PS

<File Type>* Select the playback file type when a

disc contains different types of files.

• Audio: Plays back audio files.

• Still Image: Plays back picture files.

• Video: Plays back video files.

• Audio&Video (initial): Plays back

audio files and video files.

* For playable file types, see page 52.

If the disc contains no files of the selected type, the existing files are

played in the following priority: audio, video, then still picture.

ENGLISH 13

USB USB

Connecting a USB device

You can connect a USB mass storage class device such as a USB memory, Digital Audio Player etc. to the unit.

• For details about connecting USB devices, see page 49 .

• You cannot connect a computer or portable HDD to the USB input terminal.

• For playable file types and notes on using USB devices, see page 53.

When a USB device is connected...

The source changes to “USB” and playback starts.

• All tracks in the USB device will be played repeatedly until you change the source.

To disconnect the USB device safely:

Press [M], then disconnect the USB device after “No Device” appears.

Playback operations

When the operation buttons are not displayed on the screen, touch the area shown on the illustration.

• To change settings for video playback, see page 37.

R Indications and buttons on the source

control screen

2563 71 4

Playback information

• The information displayed on the screen differs depending on the type of file being played back.

1 Track/file information

• Pressing [ H] scrolls the text if not all of the text

is shown.

2 Playback mode (See the right column.) 3 File type 4 Current playback item information (folder no./file

no.)

5 Playback status 6 Playing time 7 Jacket picture (Shown while playing if the file has

tag data that includes the jacket picture)

Operation buttons

• Available buttons on the screen and operations differ depending on the type of file being played back.

[Mode] Changes the settings on the <USB

Mode> screen. (Page15)

[M] [ ]

[ ]

]

[

Disconnects the USB device safely.

Selects a folder.

Selects random playback mode.*

1 *2

• F OLDER: Randomly plays all

tracks in the folder.

• ALL: Randomly plays all tracks.

[

]

Selects repeat playback mode.*

1 *2

• SONG: Repeats the current track.

• F OLDER: Repeats all tracks in the

current folder.

]

[

[IW] [S] [T]

Displays the folder/track list. (Page15) Starts/pauses playback.

• Selects a track. (Press)

• Reverse/forward search. (Hold)

* 1 To cancel random or repeat mode, press the button repeatedly until

the indicator disappears.

*2 You cannot activate the repeat mode and the random mode at the

same time.

USBUSB

R < USB Mode> settings

Setting <File Type> [Audio] Plays back audio files. [Still Image] Plays back picture files. [Video] Plays back video files.

[Audio&Video]

(Initial)

• For playable files, see page 53. If the USB device contains no files of the selected type, the existing files are played in the following priority: audio, video, then still picture.

Setting <Screen Ratio>

Select the monitor type to watch a wide screen picture on the external monitor.

[16:9] (Initial) [4:3 LB] [4:3 PS]

Setting <Drive Select>

Press [Next]. Switches between internal memory and the memory source of the connected device (such as mobile phone).

Plays back audio files and video files.

R Selecting a folder/track on the list

2 Select the folder (1), then the item in the

selected folder (2).

• Repeat the procedure until you select the desired track.

• If you want to play all tracks in the folder, press [I] on the right of the desired folder.

• You can change the page to display more items by pressing [ J]/[ K].

• Press [ ] to return to the root folder.

• Press [ ] to return to the upper layer.

iPod/iPhone iPod/iPhone

• To use iPod touch/iPhone Apps, see page 18.

Preparation

R Connecting iPod/iPhone

• For details about connecting iPod/iPhone, see page 49 .

• For playable iPod/iPhone types, see page 53.

Connect your iPod/iPhone using the appropriate cable according to your purpose.

• To listen to music:

– For iPod/iPhone except for iPod nano (7th

Generation)/iPod touch (5th Generation)/iPhone 5S/iPhone 5C/iPhone 5: USB 2.0 cable (accessory of iPod/iPhone)

– For iPod nano (7th Generation)/iPod touch (5th

Generation)/iPhone 5S/iPhone 5C/iPhone 5: KS- U62 (optional accessory)

• To watch video and listen to music: USB Audio

and Video cable for iPod/iPhone—KS-U59 (optional accessory)

– You cannot connect iPod nano (7th Generation)/

iPod touch (5th Generation)/iPhone 5S/iPhone 5C/iPhone 5 with KS-U59 .

ENGLISH 15

iPod/iPhoneiPod/iPhone

R Selecting preference settings for iPod/

iPhone playback

When the source is “iPod”...

<Audiobooks> Select the speed of audio

<Artwork> Shows/hides artwork of iPod.

R Setting <AV Input> for iPod/iPhone

playback

Select an appropriate input setting for <AV Input> according to the connection method of the iPod/ iPhone.

1 Turn off the AV source.

On the Home screen:

books.

Display the <Input> setting screen.

[AV-IN] Select this when the iPod/iPhone

[iPod] Select this when the iPod/iPhone

is connected using KS-U62 (optional accessory) or the USB 2.0 cable (accessory of iPod/iPhone).

is connected using KS-U59 (optional accessory).

Playback operations

When the operation buttons are not displayed on the screen, touch the area shown on the illustration.

• To change settings for video playback, see page 37.

R Indications and buttons on the source

control screen

256 71 34

Playback information

1 Song/video information

• Pressing [ H] scrolls the text if not all of the text

is shown.

2 Playback mode (Page17) 3 File type 4 Track no./Total track number 5 Playback status 6 Playing time 7 Artwork (Shown if the song contains Artwork)

• To change the Artwork display, see the far left column.

iPod/iPhoneiPod/iPhone

Operation buttons [Mode] Changes the settings for iPod/iPhone

[

]

[

]

[IW] [S] [T]

* 1 To cancel random mode, press the button repeatedly until the

indicator disappears.

*2 Resume playback is unavailable for video files.

playback on the <iPod Mode> screen. (Page16) Selects random playback mode.*

• ALL: Functions the same as Shuffle

Songs.

• ALBUM: Functions the same as

Shuffle Albums.

Selects repeat playback mode.

• SONG: Functions the same as

Repeat One.

• ALL: Functions the same as Repeat

All.

Displays the audio/video file list. (See

the right column.) Starts/pauses playback.

• Selects an audio/video file.*2 (Press)

• Reverse/forward search. (Hold)

R Selecting an audio/video file from the

2 Select the menu ( : audio or : video)

(1), a category (2), then a desired item (3).

• Select the item in the selected layer until a desired file starts playing.

• If you want to play all items in the layer, press [I] on the right of the desired item.

Audio menu:

Video menu:

• You can change the page to display more

items by pressing [ J]/[ K].

• Press [ ] to return to the root folder.

• Press [ ] to return to the upper layer.

• Available categories differ depending on the type of your iPod/iPhone.

ENGLISH 17

APPs APPs

You can use Apps of the connected iPod touch/ iPhone on this unit.

• You cannot use Apps with iPod touch (5th Generation)/iPhone 5S/iPhone 5C/iPhone 5.

• For Apps you can use on this unit, visit <http://www.jvc.net/cs/car/>.

Preparation

1 Connect iPod touch/iPhone using KS-U59 .

(Page 49 )

2 Select [iPod] for <AV Input>. (Page16)

Using an App

When the operation buttons are not displayed on the screen, touch the screen to show them.

• To change settings for video playback, see page37.

R Playback operations

1 Start the App on your iPod touch/iPhone. 2 Select “ Apps” as the source.

On the Home screen:

R Operation buttons on the source

control screen

[I] [W] [S] [T]

[IW]

Starts playback.

Pauses playback.

• Selects an audio/video file. (Press)

• Reverse/forward search. (Hold) Starts/pauses playback.

• You can operate some functions of the App on the touch panel.

• For some applications such as navigation applications, the operation buttons and information are not shown. You can perform the operations on the touch panel, such as scrolling the map.

– If “

” appears on the screen, the unit cannot

accept the touch operation you have tried to do.

• You can also play back the audio/video using iPod/iPhone itself instead of the unit.

R Switching to the App screen while

listening to another source

• Select [iPhone] for <Navigation Input> beforehand. (Page43)

KW-V41BT KW-V215DBT/KW-V21BT/

KW-V11

TUNER TUNER

Listening to the radio

R Indications and buttons on the source

control screen

1327456 p89

Tuner reception information

1 STEREO/MONO indicator

• The STEREO indicator lights up when receiving an FM stereo broadcast with sufficient signal strength.

2 NEWS indicator 3 AF indicator 4 TI indicator 5 Seek mode 6 LO indicator (Page20) 7 Preset no. 8 RDS indicator: Lights up when receiving a Radio

Data System station.

9 EON indicator: Lights up when a Radio Data

System station is sending EON signals.

p The station frequency currently tuned in q Band w Text information

• Pressing [H] scrolls the text if not all of the text is shown.

• Pressing [Radio Text] between Radio Text, Radio Text Plus, and PTY code.

switches the information

Operation buttons [P1] – [P6] • Selects a stored station. (Press)

• Stores the current station. (Hold)

[Mode]

Changes the settings for tuner reception on the <Tuner Mode> screen. (Pages20 and 22)

[SSM ] *

[TI]*

Presets stations automatically. (Page20) Activates/deactivates TI standby reception mode. (Page21)

[MONO]* Activates/deactivates monaural

mode for better FM reception. (Stereo effect will be lost.)

• The MONO indicator lights up while monaural mode is activated.

[Text] Changes the display information.

(See the right column.)

[PTY]*

Enters PTY search mode. (Page21)

[AM] Selects the AM band. [FM] Selects the FM band.

[Seek] Changes the seek mode.

• AUTO1: Auto Search

• AUTO2: Tunes in stations in the memory one after another.

• MANUAL: Manual Search

[S] [T]

Searches for a station.

• The search method differs according to the selected seek mode. (See above.)

Appears only when FM is selected as the source.

R Changing the display information

The preset list containing the station names for FM Radio Data System (when a PS signal is coming in) is

displayed.

• Press [Text] again to display the text information

for the station currently being received.

ENGLISH 19

TUNERTUNER

R Tuning in FM stations only with strong

signals—Local seek

[ON] Select this to tune in only to stations

with sufficient signal strength. The LO indicator lights up.

[OFF] Deactivate the function.

R Reducing interference during FM

reception

[Auto] Increases the tuner selectivity to

reduce interference between adjacent stations. (Stereo effect may be lost.)

[Wide] Subject to interference from adjacent

stations, but sound quality will not be degraded and the stereo effect will remain.

Presetting stations

R Storing stations in the memory

You can preset 6 stations for each band.

Automatic presetting — SSM (Strong-station Sequential Memory) (For FM only)

(Hold)

Local stations with the strongest signals are found and stored automatically.

Manual presetting

1 Tune in to a station you want to preset.

(Page 19)

2 Select a preset number.

(Hold)

The station selected in step 1 is stored.

TUNERTUNER

R Selecting a preset station

FM Radio Data System features

R Searching for FM Radio Data System

programs—PTY Search

You can search for your favorite programs being broadcast by selecting the PTY code.

R Activating/deactivating TI/News

Standby Reception

TI Standby Reception

2 Select a PTY code.

(Hold)

• You can change the page to display more

items by pressing [J]/[K].

PTY Search starts. If there is a station broadcasting a program of

the same PTY code as you have selected, that station is tuned in.

The unit is in standby to switch to Traffic Information (TI) if available. (The TI indicator lights up in white.)

• If the TI indicator is lit in orange, tune into another station providing Radio Data System signals.

To deactivate TI Standby Reception: Press [TI]. (The TI indicator turns off.)

• The volume adjustment for Traffic Information is automatically memorized. The next time the unit switches to Traffic Information, the volume is set to the previous level.

• For KW-V215DBT: The TI Standby Reception can also be activated or deactivated from “DAB” source control screen. (Page25)

ENGLISH 21

TUNERTUNER

News Standby Reception

The unit is in standby to switch to News Program if available. (The NEWS indicator lights

up.)

• If the NEWS indicator flashes, tune into another station providing Radio Data System signals.

To deactivate News Standby Reception:

Select [OFF] for <NEWS Standby>. (The NEWS indicator turns off.)

• The volume adjustment while receiving News is automatically memorized. The next time the unit switches to News, the volume is set to the previous level.

R Tracing the same program—Network-

Tracking Reception

When driving in an area where FM reception is not sufficient enough, this unit automatically tunes in to another FM Radio Data System station of the same network, possibly broadcasting the same program with stronger signals.

• When shipped from the factory, Network-Tracking Reception is activated.

To change the Network-Tracking Reception setting

[AF] Switch to another station. The

program may differ from the one currently received (the AF indicator lights up).

[AF Reg] Switch to another station

broadcasting the same program (the AF indicator lights up).

[OFF] Deactivate the function.

• The RDS indicator lights up when the Network-Tracking Reception is activated and an FM Radio Data System station is found.

R Automatic station selection—Program

Usually when you select preset stations, the preset station is tuned in. If the signals from the preset FM Radio Data System station are not sufficient for good reception, this unit, using the AF data, tunes in to another station broadcasting the same program that the original preset station is broadcasting.

To activate Program Search

• The unit takes some time to tune in to another station using program search.

To deactivate Program Search: Select [OFF] for <Program Search>.

DIGITAL RADIO (DAB) DIGITAL RADIO (DAB) (Only for (Only for KW-V215DBTKW-V215DBT))

About DAB (Digital Audio Broadcasting)

What is DAB system?

DAB (Digital Audio Broadcasting) is one of the digital radio broadcasting systems available today. It can deliver digital quality sound without any annoying interference or signal distortion. Furthermore, it can carry text and data. In contrast to FM broadcast, where each program is transmitted on its own frequency, DAB combines several programs (called “services”) to form one “ensemble.” The “Primary component” (main radio station) is sometimes accompanied by a “secondary component” which can contain extra programs or other information.

Listening to Digital Radio

R Indications and buttons on the source

control screen

Tuner reception information

1 Preset no. 2 Seek mode 3 TI indicator 4 DAB reception indicator

• The DAB indicator lights up when receiving an DAB broadcast.

• The MC indicator lights up when receiving an DAB multi component.

5 RDS indicator: Lights up when receiving a Radio

Data System station.

6 Channel no. 7 Signal strength 8 Text information

• Pressing [<] scrolls the text if not all of the text is shown.

• Pressing [Now Playing] switches the information. Each time you press the button, the information and the button switch between [Audio Quality], [PTY], [Artists],

[Title], [Now Playing], and [Next Program].

Operation buttons [P1] – [P15] • Selects a stored service. (Press)

[P>] Displays other preset numbers.

6734512

[ Mode] Changes the settings for DAB

[TI] Activates/deactivates TI standby

[DLS] Displays Dynamic Label Segment

[ Text] Changes the display information.

]

[

[PTY] Enters PTY search mode. (Page25) [ Seek] Changes the seek mode.

[S] [T]

• Stores the current service. (Hold)

reception on the <DAB Mode> screen. (Page26)

reception mode. (Page25)

Screen (text messages the station sends).

(Page24) Displays the <List Type Select> screen. (Page24)

• AUTO1: Auto Search

• AUTO2: Tunes in the services in the memory one after another.

• MANU: Manual Search

Searches for an ensemble, service, and component.

• The search method differs according to the selected seek mode. (See above.)

ENGLISH 23

DIGITAL RADIO (DAB) DIGITAL RADIO (DAB)

R Changing the display information

The preset list of service labels is displayed.

• Press [ Text] again to display the text information

for the service or component currently being received.

R Selecting a service from the list

1 Display the <List Type Select> screen.

2 Select the list type.

<Preset List> Selects from the preset list.

• To preset the services, see page25.

<Service List> Selects from the service names

(Service List).

3 Select a service from the list.

On the <Preset List>

• You can change the page to display more

items by pressing [ J]/[ K].

On the <Service List>

• You can change the page to display more

items by pressing [ J]/[ K].

• Press [A–Z] to search for the initial letter. Pressing [A–Z] displays the <A –Z Search> screen. Select the initial to start the search.

– If you want to search with non-alphabetical

characters, press [Other].

• Press and hold [ ] to update the <Service List>.

DIGITAL RADIO (DAB) DIGITAL RADIO (DAB)

Presetting services

R Storing services in the memory

You can preset 15 services.

1 Select a service you want to preset.

(Page 23)

2 Select a preset number.

• If you want to select a preset number between

P6 – P15, press [P>] to display those numbers.

(Hold)

The service selected in step 1 is stored.

Radio Data System features

R Searching for Radio Data System

programs—PTY Search

You can search for your favorite programs being broadcast by selecting the PTY code.

2 Select a PTY code.

(Hold)

• You can change the page to display more

items by pressing [ J]/[ K].

PTY Search starts. If there is a service broadcasting a program of

the same PTY code as you have selected, that service is tuned in.

• Only English/Spanish/French/German/Dutch/ Portuguese are available for the text language here. If another language has been selected in <Language> (Page44), the text language is set to English.

R Activating/deactivating TI Standby

Reception

The unit is in standby to switch to Traffic Information (TI) if available. (The TI indicator lights up in white.)

• If the TI indicator is lit in orange, tune into another station providing Radio Data System signals.

To deactivate TI Standby Reception: Press [TI]. (The TI indicator turns off.)

• The volume adjustment for Traffic Information is automatically memorized. The next time the unit switches to Traffic Information, the volume is set to the previous level.

• The TI Standby Reception can also be activated or deactivated from “TUNER” source control screen. (Page21 )

ENGLISH 25

DIGITAL RADIO (DAB) DIGITAL RADIO (DAB)

Settings for Digital Audio Radio

You can set the Digital Radio related items.

R Setting items

<Priority> • ON (initial): If the same service is

provided by Digital Radio during Radio Data System reception,

the unit automatically switches to Digital Radio. If the same service is provided by Radio Data System when reception of the service being provided by Digital Radio becomes poor, the unit automatically switches to Radio Data System.

• OFF: Deactivates.

< PTY Watch> If the service of the set program

type begins with the ensemble being received, the unit switches from any source to Digital Radio for service reception. Select the type of program using [H] and [I].

If the service of the announcement item you activated begins with the ensemble being received, this unit switches from any source to the announcement received.*

Set [ON] for the announcement items you need.

• News flash/Transport

flash/Warning/Service/ Area weather flash/ Event announcement/ Special event/Programme

information/Sport report/ Financial report

– To deactivate all

announcements, select [All OFF].

• ON (initial): Prevents audio break when switching from Digital Radio to Analog Radio.

• OFF: Cancels.

<Related Service>

* The volume adjustment while receiving Announcement is

automatically memorized. The next time the unit switches to Announcement, the volume is set to the previous level.

• ON: When the current selected DAB service network is not available and found the related service, the unit offers to switch to the related service.

• OFF (initial): Cancels.

OTHER EXTERNAL COMPONENTSOTHER EXTERNAL COMPONENTS

Using external audio/video players—AV-IN

When the operation buttons are not displayed on the screen, touch the area shown on the illustration.

• To change settings for video playback, see page 37.

You can connect an external component to the iPod/AV-IN terminal. (Page 49 )

Preparation:

Select [AV-IN] for <AV Input>. (Page43)

• <AV Input> can be changed only when

<Navigation Input> is set to [OFF]. (Page43)

R Indications and buttons on the source

control screen

Playback information

1 AV-IN name

Operation buttons [Mode] Changes the AV-IN name.

• Press [H] or [I] to select an AV-IN name.

R Starting playback

1 Connect an external component to the

iPod/AV-IN terminal.

• To connect an external component, see page 49 .

2 Select “AV-IN”as the source. (Page9) 3 Turn on the connected component and

start playing the source.

Using a rear view camera

• To connect a rear view camera, see page 49 .

• To use a rear view camera, a REVERSE lead connection is required. (Page 48 )

R Activating the rear view camera

1 Display the <Input> setting screen.

On the Home screen:

R Displaying the picture from the rear

view camera

The rear view screen is displayed when you shift the gear to the reverse (R) position.

• To erase the caution message, touch the screen.

• You can change the setting of the picture using

[Zoom]/[Aspect]/[Pict Adjust]. (Page37)

To display the picture from the rear view camera

manually

On the Home screen:

To exit the rear view screen: Press HOME on the monitor panel.

To deactivate: Select [OFF] for <R-CAM Interrupt>.

ENGLISH 27

BLUETOOTH BLUETOOTH (Only for (Only for KW-V41BT/KW-V41BT/KW-V215DBT/KW-V215DBT/KW-V21BTKW-V21BT ) )

Information for using Bluetooth®

devices

Bluetooth is a short-range wireless radio communication technology for mobile devices such as mobile phones, portable PCs, and other devices. Bluetooth devices can be connected without cables and communicate with each other.

Notes

• While driving, do not perform complicated operations such as dialing numbers, using the phonebook, etc. When you perform these operations, stop your car in a safe place.

• Some Bluetooth devices may not connect to this unit depending on the Bluetooth version of the device.

• This unit may not work for some Bluetooth devices.

• Connecting conditions may vary depending on your environment.

• For some Bluetooth devices, the device is disconnected when the unit is turned off.

Bluetooth Information: If you wish to receive more information about Bluetooth, visit the following JVC web site: <http://www.jvc.net/cs/car/>

Connecting Bluetooth devices

R Registering a new Bluetooth device

When you connect a Bluetooth device to the unit for the first time, pair the unit and the device. Pairing allows Bluetooth devices to communicate with each other.

• The pairing method differs depending on the Bluetooth version of the device.

– For devices with Bluetooth 2.1: You can pair the

device and the unit using SSP (Secure Simple Pairing) which only requires confirmation.

– For devices with Bluetooth 2.0: You need to

enter a PIN code both on the device and unit for pairing.

• Once the connection is established, it is registered in the unit even if you reset the unit. Up to 5 devices can be registered in total.

• Only one device for Bluetooth phone and one for Bluetooth audio can be connected at a time.

• To use the Bluetooth function, you need to turn on the Bluetooth function of the device.

• To use the registered device, you need to connect the device to the unit. (Page30)

Auto pairing

When <Auto Pairing> is set to [ON], iOS device (such as iPhone) is automatically paired when connected via USB. (Page44)

Pairing a Bluetooth device using SSP (for Bluetooth 2.1)

When the Bluetooth device is compatible with Bluetooth 2.1, a pairing request is sent from an available device.

1 Search “JVC KW-V” from your Bluetooth

device.

2 Confirm the request both on the device

and the unit.

256950

• Press [Cancel] to reject the request.

BLUETOOTHBLUETOOTH

Pairing a Bluetooth device using a PIN code (for Bluetooth 2.0)

1 Display the <Bluetooth Setup> screen.

On the Home screen:

• Press [ K] repeatedly to change the page on

the <System> menu screen.

2 Change the PIN code.

• If you skip changing the PIN code, go to step

• The PIN code is initially set to “0000”.

• The maximum number of digits in the PIN code is 16.

• Press [Clear] to delete the last entry.

3 Search “JVC KW-V” from your Bluetooth

device.

4 Select “JVC KW-V” for your Bluetooth

device.

JVCKW-V

• If the PIN code is required, enter “0000” (initial).

PINcode

0000

When pairing is complete, the device is listed on <Paired Device List>.

• To use the paired device, connect the device on <Paired Device List>. (Page30)

ENGLISH 29

BLUETOOTHBLUETOOTH

R Connecting a registered Bluetooth

device

1 Display the <Bluetooth Setup> screen.

(Page29)

3 Select the device you want to connect

(1), then select what you want to use the device for (2).

[ TEL (HFP)]: for mobile phone [Audio (A2DP)]: for Bluetooth audio player

• Selectable items depend on the device you are operating.

• If you connect a device while another device is connected, the device previously connected is disconnected and the connection for the newly connected device is established.

• When a Bluetooth mobile phone is connected, the signal strength and battery level are displayed when the information is acquired from the device.

To disconnect

Select [TEL (HFP)] or [Audio (A2DP)] to disconnect the Bluetooth device being used for that function on the <Paired Device List> screen (see the left column).

R Deleting a registered Bluetooth device

1 Display the <Bluetooth Setup> screen.

(Page29)

3 Select a device to delete (1), then delete

the registration (2).

A confirmation message appears. Press [Yes].

Using the Bluetooth mobile phone

R Receiving a call

When a call comes in...

• Call information is displayed if acquired.

• Phone operation is not available while the picture from the rear view camera is displayed. (Page27 )

To reject a call

When <Auto Response> is set to [ON] (Page35)

The unit answers the incoming call automatically.

R Ending a call

While talking...

+ 212 hidden pages
