JVC KW-AVX726, KW-AVX725, KW-AVX724, KW-AVX626, KW-AVX625 Instructions Manual

DVD RECEIVER WITH MONITOR

INSTRUCTIONS

For canceling the display demonstration, see page 10.

For installation and connections, refer to the separate manual.

KW-AVX726/KW-AVX725/KW-AVX724/
KW-AVX626/KW-AVX625/KW-AVX624

Thank you for purchasing a JVC product.

Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best

possible performance from the unit.

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to

qualified service personnel.

3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical

instruments.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.

How to read this manual

• < > is used to indicate the variable screens/

[European Union only]

Cautions on the monitor:

• The monitor built in this unit has been produced
with high precision, but it may have some
ineffective dots. This is inevitable and is not
malfunction.

• Do not expose the monitor to direct sunlight.

• Do not operate the touch panel using a ball-point
pen or similar tool with the sharp tip.

Touch the buttons on the touch panel with your

finger directly (if you are wearing a glove, take it
off).

• When the temperature is very cold or very hot...

– Chemical changes occur inside, causing

malfunction.

– Pictures may not appear clearly or may move

slowly. Pictures may not be synchronized with
the sound or picture quality may decline in such
environments.

menus/operations/settings that appear on the
touch panel.

• [ ] is used to indicate the buttons on the touch
panel.

• ( page number) is used to indicate the
reference page number of the related topics/
operations/settings.

• Operation index: To locate easily the desired
operations/functions. ( 59)

• Indication language: English indications
are used for the purpose of explanation. You
can select the indication language from the
<AV Menu>. ( 13)

For safety...

• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.

• Stop the car before performing any complicated
operations.

Temperature inside the car...

If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.

2

How to reset your unit

CONTENTS

How to read this manual .............................. 2

How to reset your unit ................................. 3

How to forcibly eject a disc ........................... 3

INTRODUCTIONS

Playable disc type ........................................ 4

• Your preset adjustments will also be erased (except the

registered Bluetooth device). ( 24, 35)

How to forcibly eject a disc

Back

• You can forcibly eject the loaded disc even if the disc is

locked. To lock/unlock the disc, 27.

• Be careful not to drop the disc when it ejects.

• If this does not work, reset your unit.

Basic operations ........................................... 5

• Using the monitor panel/touch panel ......... 5

• Using the remote controller (RM-RK252) .... 7

Preparation .................................................. 10

AV MENU

AV Menu operations .................................... 11

OPERATIONS

Listening to the radio ................................... 26

Disc operations ............................................. 27

• Operation buttons on the screen ................ 29

• Operations using the remote controller

(RM-RK252) ................................................ 30

USB operations (for

KW-AVX725/KW-AVX724

KW-AVX726/

) ....................... 34

EXTERNAL DEVICES

Using the Bluetooth® devices ....................... 35

• Connecting a new Bluetooth device ........... 35

• Using the Bluetooth cellular phone ............ 36

• Using the Bluetooth audio player ............... 38

WARNINGS:
(To prevent accidents and damage)

• DO NOT install any unit or wire any cable in a
location where;

– it may obstruct the steering wheel and gearshift

lever operations.

– it may obstruct the operation of safety devices

such as air bags.

– it may obstruct visibility.

• DO NOT operate the unit while driving.

If you need to operate the unit while driving, be

sure to look around carefully.

• The driver must not watch the monitor while
driving.

Listening to the CD changer ......................... 38

Listening to the iPod/iPhone ....................... 39

• When connected with the USB cable .......... 39

• When connected with the interface

adapter ....................................................... 40

Using other external components ................ 41

• AV-INPUT .................................................... 41

• EXT-INPUT .................................................. 42

REFERENCES

Maintenance ................................................ 43

More about this unit .................................... 44

Troubleshooting ........................................... 52

Specifications ............................................... 56

Operation index ........................................... 59

3

Playable disc type

Disc type Recording format, file type, etc Playable

DVD

• DTS sound cannot be
reproduced.

DVD Recordable/Rewritable
(DVD-R/-RW *2, +R/+RW *3)

• DVD Video: UDF bridge

• DVD-VR

• DivX/MPEG1/MPEG2/JPEG/
MP3/WMA/WAV: ISO 9660 level
1, level 2, Romeo, Joliet

Dual Disc DVD side

CD/VCD Audio CD/CD Text (CD-DA)

DVD-Video *
Region Code: South East Asia, Hong Kong region: 3
Australia: 4
India: 5
Ex.:

DVD-Audio/DVD-ROM

DVD-Video

DVD-VR

DivX/MPEG1/MPEG2

JPEG

MP3/WMA/WAV

AAC/MPEG4/DVD+VR/DVD-RAM

Non-DVD side

1

VCD (Video CD)

DTS-CD/SVCD (Super Video CD)/CD-ROM/
CD-I (CD-I Ready)

CD Recordable/Rewritable
(CD-R/-RW)

• ISO 9660 level 1, level 2, Romeo,
Joliet

*1 If you insert a DVD Video disc of an incorrect Region Code, “Region code error” appears on the screen.
*2 DVD-R recorded in multi-border format is also playable (except for dual layer discs). DVD-RW dual layer discs are not

playable.

*3 It is possible to play back finalized +R/+RW (Video format only) discs. “DVD” is selected as its disc type when a

+R/+RW disc is loaded. +RW double layer discs are not playable.

CD-DA

VCD (Video CD)

DivX/MPEG1/MPEG2

JPEG

MP3/WMA/WAV

AAC/MPEG4

Caution for DualDisc playback

The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore, the
use of Non-DVD side of a DualDisc on this product may not be recommended.

4

Basic operations

Using the monitor panel/touch panel

Display <AV Menu> screen, ( 11)

Display the <Source Menu> screen, (

Display/exit the Short Cut icons, (

SOURCE

CD

MP3

FLAT

3:00

AM

6)

7)

01 01

Folder Name
File Name

Track Title
Artist Name
Disc Title

USB cable from the rear of the unit, (

0:02:26

34) *

1

1 Resets the unit ( 3).
2 • Turns on the power.

• Attenuates the sound (if the power is on).

• Turns off the power. (Hold)

3 Changes the display information. *
4 • Adjusts the volume.

•

Bluetooth PHONE

the incoming calls. *

5 Remote sensor
6 Touch panel (see the following pages).

• Most of the touch panel operations are explained

unless mentioned otherwise.

• The screen will turn off if no operation is

done for about 10 seconds (depends on the
<Illumination> setting). ( 16)

7 Motion sensor
8 Displays <AV Menu> screen.

: Adjusts the volume of

3

2

9 • Selects the source. *

TUNER
USB

=

AUDIO

•

Bluetooth PHONE

<Dial Menu> screen. *5 (Hold)

p •

KW-AVX726/KW-AVX725/KW-AVX724

:
– Selects “
– Switches the setting between “HEAD MODE”

•

KW-AVX626/KW-AVX625/KW-AVX624

AV-IN : Selects “

*1 – *5 : 6

=

*1/

iPod

Bluetooth PHONE

=

USB/

and “iPod MODE” (Hold)

4

DISC (DVD/VCD/CD)

*1 =

CD-CH/iPod/EXT-IN

=

Bluetooth

AV-IN

= (back to the beginning)

: Displays the

iPod

” as the source.

AV-IN

” as the source.

Continued on the next page

=

:

:

5INTRODUCTIONS

q • Displays <Open/Tilt> screen. *

6

[Open] : Opens the monitor panel.
[Eject] : Ejects the disc.
[Close] : Closes the monitor panel.
[Tilt +] : Tilts open the monitor panel.
[Tilt –] : Tilts close the monitor panel.

• Ejects the disc and display <Open/Tilt>

screen. (Hold)

• Closes the monitor panel when the panel is

opened.

w Monitor panel

<Source Menu> screen

You can also select the source using the touch
panel.

SOURCE

TUNER

FLAT

ST

3:00

AM

1FM1 87. 5 MHz

ABC Radio

BAND

*1 For

KW-AVX726/KW-AVX725/KW-AVX724

2

*

Available display information varies among the

playback sources. (

50)

.

*3 This adjustment does not affect the volume level of

other sources.

*4 Available sources depend on the external components

you have connected, media you have attached, and
the <Input> settings you have made. ( 15, 16)

*5 Only when Bluetooth phone is connected.
*6 Shaded items cannot be used.

You can also adjust the
volume by moving your
finger on the touch panel
as illustrated.

Caution on volume setting:

Digital devices (CD/USB) produce very little noise
compared with other sources. Lower the volume before
playing these digital sources to avoid damaging the
speakers by sudden increase of the output level.

Source Menu

Current source Exit

Touch panel and button illumination

Dependable on the <Illumination> setting.
( 16)

• Turned off:
When no operation is done for about 10 seconds.

• Turned on again:
– When you touch the touch panel or move your

hand nearby.
– When you use the remote controller.
– When a call/SMS comes in (for Bluetooth

cellular phone).
– When the signal from the rear view camera

comes in.

• Always turned on:
– When <AV Menu> screen is displayed.
– When <Source Menu> screen is displayed.
– When <Open/Tilt> screen is displayed.
– When <Illumination> is set to <Normal>.

When you drag your finger on the touch panel, it
functions in the same way as touching [5 / ∞ /

4 / ¢].

6

Short Cut icons

Using the remote controller

You can easily access some frequently used
functions by using the Short Cut icons.

SOURCE

TUNER

FLAT

ST

AM

3:00

Short Cut window appears.

• To exit from the window, press the button again.

SOURCE

TUNER

FLAT

ST

AM

3:00

Press a Short Cut icon.

Setup

Beep
Telephone Muting

Illumination
Motion Sensitiv.
Initialize

Back

1FM1 87. 5 MHz

ABC Radio

1FM1 87. 5 MHz

Normal

Proximity/Motion

Proxi/Motion-LCD

Touch Panel

Touch Panel - LCD

(RM-RK252)

Installing the batteries

BAND

R03/LR03/AAA

Insert the batteries into the remote controller by
matching the polarity (+ and –) correctly.

BAND

Caution:

• Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.

• Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.

If the effectiveness of the remote controller
decreases, replace the batteries.

The corresponding screen is displayed.

Available icons vary among the sources.

Displays <Illumination> menu.

( 16)

Changes the sound mode. ( 17)

Turns on or off Track/Chapter
Repeat. ( 20)

Displays <Aspect> menu.

( 13)

Activates <Voice Dialing>
function. ( 23)

Displays <Redial> menu. (

23)

Before using the remote controller:

• Aim the remote controller directly at the remote
sensor on the unit.

• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).

The following describes all the available operations
for all the sources.

• USB/

iPod operations are only applicable for

KW-AVX726/KW-AVX725/KW-AVX724

.

• To easily locate the available operations between
different type of files,

30, 31.

Continued on the next page

7INTRODUCTIONS

1 button

• Turns the power on if pressed briefly or
attenuates the sound when the power is on.

• Turns the power off if pressed and held.

2 5/∞ buttons

•

•

TUNER
DISC/USB

: Selects the preset stations.

:
– DVD-Video: Selects the title.
– DVD-VR: Selects the program/Playlist.
–

USB

/other discs (except VCD/CD): Selects the

folders if included.

•

CD-CH

:

– Selects the folders if included.

•

iPod

:

– 5 : Enters the main menu (then 5 / ∞ /

4 / ¢ work as menu

selecting buttons.)
5 : Returns to the previous menu.
∞ : Confirms the selection.
–

∞ : Pauses or resumes playback.

4 / ¢ buttons

•

TUNER

:

– Searches for stations automatically if pressed

briefly.

– Searches for stations manually if pressed and

held.

•

DISC/USB/CD-CH

:
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed and

held.

•

iPod

:
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed and

held.

•

iPod

:
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed and

held.
In menu selecting mode:
– Selects an item if pressed briefly. (Then, press

∞ to confirm the selection.)

– Skips 10 items at a time if pressed and held.

•

Bluetooth AUDIO

:

– Reverse skip/forward skip if pressed briefly.

3 VOL (volume) + / – buttons

• Adjusts the volume level.

Bluetooth PHONE

•

:

– Adjusts the volume of the incoming calls.

2nd VOL (volume) buttons

• Not applicable for this unit.

4 * ASPECT button

• Changes the aspect ratio of the playback

pictures.

8

5 PHONE button

Applicable only when a Bluetooth phone is

connected.

• Displays <Dial Menu> screen.

• Displays <Redial> menu if pressed and held.

• Answers incoming calls.

6 * SETUP button

• Not applicable for this unit.

7 * TOP M (menu) button

• DVD-Video: Shows the disc menu.

• DVD-VR: Shows the Original Program screen.

• VCD: Resumes PBC playback.

8 OSD (on-screen display) button

• Shows the on-screen bar.

• Does not function as “*.”

9 SHIFT button

• Functions with other buttons.

p DISP (display) button

• Changes the display information.

q 1 / ¡ buttons

•

DISC/USB/ iPod

: Reverse search/forward

search.

t * RETURN button

• VCD: Returns to the PBC menu.

y * MENU button

• DVD-Video: Shows the disc menu.

• DVD-VR: Shows the Playlist screen.

• VCD: Resumes PBC playback.

u * % / fi buttons

• DVD-Video: Makes selection/settings.

•

CD-CH

: Changes discs in the magazine.

@ / # buttons

• DVD-Video: Makes selection/settings.

• DivX/MPEG Video: Skips back or forward by
about 5 minutes.

ENT (enter) button

• Confirms selection.

i DUAL button

• Not applicable for this unit.

• Does not function as “#.”

o DIRECT button

•

DISC/USB

: Enters direct search mode for
chapter/title/program/playlist/folder/track
when pressed with SHIFT button ( 31).

w SOURCE button

• Selects the source.

e 3 (play) / 8 (pause) button

•

DISC/USB/ iPod

•

Bluetooth PHONE

•

Bluetooth AUDIO

r (end call) button

•

Bluetooth PHONE

: Starts playback/pauses.

: Answers incoming calls.

: Starts playback.

: Ends the call.

BAND button

•

TUNER

: Selects the bands.

7 (stop) button

•

DISC/USB/ iPod

•

Bluetooth AUDIO

: Stops playback.

: Pauses.

CLR (clear) button

•

DISC/USB

: Erases the misentry when pressed
with SHIFT button.

SURROUND button

• Not applicable for this unit.

* Functions as number buttons when pressed with SHIFT

button.

–

DISC/USB

: Enters chapter/title/program/playlist/
folder/track number after entering search mode by
pressing SHIFT and DIRECT. ( 31)

–

TUNER

: (Number 1 to 6) : Enters preset station

number.

9INTRODUCTIONS

Preparation

Canceling the display demonstration and setting the clock

~ Turn on the power.

Ÿ Display <AV Menu> screen.

or

! Display <Setup> screen.

AV Menu

BAND

@ Set the clock.

Setup

Demonstration
Wall Paper
Color
Scroll
Dimmer

Dimmer Time Set

Back

Setup

Time Set
Time Format
OSD Clock

Back

Setup

Time Set
Time Format
OSD Clock

Bright

Blue

AutoOnce

Auto

7 AM6 PM

1 : 00

12Hours 24Hours

Off

3 : 45

AM

PM

⁄ Cancel the demonstration.

Select [

Off

Setup

Demonstration
Wall Paper
Color
Scroll
Dimmer

Dimmer Time Set

Back

].

Metal

Blue

Auto

Back

Back

¤ Finish the procedure.

Back

AutoOnce

7 AM6 PM

10 INTRODUCTIONS

AV Menu operations

You can use the <AV Menu> for most of the
operations and settings. The available menu items
shown on the touch panel, depends on the selected
source.

• Non-available items will be shaded.

The following steps are one of the fundamental
procedures.

• You can perform the operations/change the settings
by following these steps unless mentioned otherwise.

~ Turn on the power.

Ÿ Display <AV Menu> screen.

! Press the desired icon/item to perform

the desired operations/settings.

Moves to the preceding
menu page

Setup

Demonstration
Wall Paper
Color
Scroll
Dimmer

Dimmer Time Set

Back

Returns to the previous
screen.

Moves to the succeeding
menu page

Indicates the next hierarchy
level/setting item exists

Bright

Blue

AutoOnce

Auto

7 AM6 PM

Indicates the remaining
time before the current
screen exit automatically.

or

AV Menu

Setup : 12 – 16
Equalizer : 17
Sound : 18
Mode : 19 – 21
List : 21 – 22
Bluetooth : 23 – 25

BAND

• Some of the settings do not open the sub-setting
screen, but just selecting an option will change the
setting.

Exit

• To exit from the setting, press [

].

Continued on the next page

11AV MENU

Menu item Selectable setting/item

Initial: Underlined

Demonstration

♦

♦

Off
On

: Cancels.
: Activates the demonstration on the screen. To stop it

temporarily, touch the screen. (

Wall Paper You can select the background picture of the screen.

♦

Bright, Future, Horizon, Plain

Color You can select the color of the background picture.

♦

Blue, Light-Blue, Red, Orange, Yellow, Green, Purple, Dark-Blue,

Dark-Green, Brown, Light-Brown, Black

Scroll

♦

♦

♦

Off
Once
Auto

: Cancels.
: Scrolls the displayed information once.
: Repeats scrolling (at 5-second intervals).

• Touching the information bar scrolls the text regardless of the setting.

♦

Dimmer

Display

Dimmer Time Set

Off

♦

On

♦

Auto

♦

Dimmer Time Set

Sets the Dimmer On (

: Cancels.
: Activates dimmer.
: Dims the monitor when you turn on the headlights. *
: Activates the Dimmer Time setting (see below).

)/Off ( ) times.

10)

1

Dimmer Level You can select the brightness for dimmer.

♦

01 (bright), 02 (middle), 03 (dark)

Bright You can adjust the brightness of the screen.

♦

–15 to +15; Initial 00

Picture Adjust *

2

You can adjust the following to make the screen clear and legible for watching
the playback picture. The setting will be stored—one for “

iPod

” (common) and the other for “

AV-IN

.”

Press [5] or [∞] to adjust. (–15 to +15; Initial 00)

♦

Bright

♦

Contrast

♦

Color

♦

Tint

: Adjust if the picture is too bright or too dark.
: Adjust the contrast.
: Adjust the color of the picture—lighter or darker.
: Adjust the tint if the human skin color is unnatural,

only when color system setting is <NTSC>.
( 13)

1

*

The ILLUMINATION CONTROL lead connection is required. (See the Installation/Connection Manual.)

*2 Adjustable only when the source is “

DISC/USB/ iPod

” (the media must contain pictures or videos) or “

DISC/USB/

AV-IN

.”

12

Menu item Selectable setting/item

Aspect *

Display

Language *

3

You can change the aspect ratio of the picture.

Aspect ratio of the incoming signal

4:3 16:9

Regular:

For 4:3 original pictures

Full:

For 16:9 original pictures

Panorama:

For viewing 4:3 pictures
naturally on the wide screen

Auto: • For “

DISC

”: Aspect ratio is automatically

selected to match the incoming signals.

• For the other video sources: Aspect ratio is

fixed to <Regular>.

4

Select the indication language shown on the screen.

♦

English, Español, Français, Deutsch, Italiano, Nederlands, Svenska,

Dansk, Руccĸий, Português, , , ,

, Türkçe, ,

• The characters you can enter for assigning the titles also change according to
the language selected. ( 48)

NTSC/PAL *

Time Set
Time Format

Clock

OSD Clock

Menu Language *
Audio Language *

Disc

Subtitle *

4

Select the color system of the external monitor connected.

♦

NTSC, PAL

Initial 1:00AM (

10)

Select either 12-hour system or 24-hour system. (

♦

12 Hours, 24 Hours

♦

Off

♦

On

5

Select the menu language; Initial English ( 50)

5

Select the audio language; Initial English ( 50)

5

Select the subtitle language or erase the subtitle <Off>.; Initial English

: Cancels.
: The clock time is displayed on the playback picture.

( 50)

3

*

Not adjustable when no picture is shown.

*4 Turn off then on the power so that your setting takes effect.
*5 Selectable only for “

DISC/USB

” (Playback stops when you change the setting.)

10)

Continued on the next page

13AV MENU

Menu item Selectable setting/item

Monitor Type *

16:9 4:3LB

4:3PS

OSD Position *

File Type *

6

6

Select the monitor type to watch a wide screen picture on the external
monitor.

♦

16:9

: Select when the aspect ratio of the external

monitor is 16:9.

♦

4:3LB

(Letterbox)/

: Select when the aspect ratio of the external

monitor is 4:3.

4:3PS (Pan Scan)

6

Select the position of the on-screen bar. ( 33)

♦

♦

1
2

: Higher position.
: Lower position.

Select the playback file type when a disc/USB contains different types of
files. You can store this setting separately for each source—
“

DISC/USB

♦

Audio

♦

Still Picture

♦

Video

♦

Audio&Video

.” *

7

: Plays back audio files.
: Plays back JPEG files.
: Plays back DivX/MPEG1/MPEG2 files.
:

Plays back audio files and DivX/MPEG1/MPEG2 files.

DivX Regist.

Disc

(Registration) *

6

iPod Artwork *

D. (Digital) Audio Output *

7, *8

This unit has its own Registration Code. Once you have played back a file
with which the Registration Code recorded, this unit’s Registration Code
is overwritten for copyright protection.

While playing back a track (in “HEAD MODE”), Artwork recorded for the
track is displayed on the monitor.

♦

♦

Off
On

: Cancels.
: Activates Artwork display. To display the artwork,

press DISP repeatedly.

• It takes 5 seconds or more to display an
Artwork and no operations are available while
loading it.

6

Select the signal format emitted through the DIGITAL OUT (optical)
terminal. ( 49)

♦

PCM

: Select this when connecting an amplifier or a

decoder incompatible with Dolby Digital or MPEG
Audio, or when connecting to a recording device.

♦

Dolby D

: Select this when connecting an amplifier or a

decoder compatible with Dolby Digital.

♦

Stream

:

Select this when connecting an amplifier or a decoder
compatible with Dolby Digital or MPEG Audio.

*6 Selectable only for “
*7 For

KW-AVX726/KW-AVX725/KW-AVX724

DISC/USB

*8 Skip the track so that your setting takes effect.

14

.” (Playback stops when you change the setting.)

.

Menu item Selectable setting/item

Down Mix *

Disc

D. (Dynamic)
Range Compres.
(Compression) *

IF Band Width

Tuner

AV Input *

Input

10

9

When playing back a multi-channel disc, this setting affects the signals
reproduced through the LINE OUT jacks.

♦

Dolby Surr.

: Select this to enjoy multi-channel surround audio

by connecting an amplifier compatible with Dolby
Surround.

♦

Stereo

: Normally select this.

You can enjoy a powerful sound at a low volume level while playing Dolby
Digital software.

9

♦

Auto

: Select to apply the effect to multi-channel encoded

software.

♦

On

♦

Auto

: Select to always use this function.
: Increases the tuner selectivity to reduce interference

noises between adjacent stations. (Stereo effect may be
lost.)

♦

Wide

: Subject to the interference from adjacent stations, but

sound quality will not be degraded and the stereo effect
will remain.

You can determine the use of LINE IN and VIDEO IN jacks. ( 41)

♦

Off

: Select when no component is connected (“

AV-IN

” is

skipped while selecting the source).

♦

iPod (Off) *

11

: Select when connecting the iPod/iPhone using the USB

Audio and Video cable for iPod/iPhone. ( 39)

♦

Audio&Video

♦

Audio

: Select when connecting an AV component such as a VCR.
: Select when connecting an audio component such as a

portable audio player.

♦

Camera *

12

: Select when connecting a rear view camera to display

the picture (as it is taken).

♦

Navigation

: Select when connecting a Navigation System. ( 42)

9

Selectable only for “

*
*10 Not selectable when “
*11 For

KW-AVX726/KW-AVX725/KW-AVX724

DISC/USB

AV-IN

” is selected as the source.

*12 The REVERSE GEAR SIGNAL lead connection is required. See Installation/Connection Manual. The rear view through

the camera appears on the screen in <Full> aspect ratio (regardless of the aspect ratio setting) when you shift the
gear to the reverse (R) position. When you press DISP on the monitor panel, or when you shift the gear to another
position other than the reverse (R) position, the rear view screen is cleared.

.” (Playback stops when you change the setting.)

.

Continued on the next page

15AV MENU

Menu item Selectable setting/item

External Input *

13, *14

For connecting an external component to the CD changer jack on the rear.

♦

Changer/iPod *

♦

External

15

: CD changer, (

38), iPod, ( 40).

: Any other than the above, ( 42).

Input

Beep

Telephone Muting *

Illumination You can turn off the screen and the light of the buttons on the monitor panel

♦

Off

♦

On

16

♦

Off

♦

Muting1,

Muting2

while turning on the unit.

: Cancels.
: Activates the key-touch tone.

: Cancels.
: Select either one which mutes the sounds while

using the cellular phone.

( 6)

Buttons on the

monitor panel

Normal: Always lights. Always lights.

Screen

Proximity/Motion: Lights up when your

Always lights.
hand moves close to
the buttons.

Others

Proxi/Motion-LCD: Lights up when your

hand moves close to
the buttons.

Touch Panel: Lights up when your

Lights up when your

hand moves close to

the buttons.

Always lights.
finger touches the
buttons or touch panel.

Touch Panel-LCD: Lights up when your

finger touches the
buttons or touch panel.

Motion Sensitiv. Change the sensitivity of the sensor for <

♦

Low, Mid, High

Illumination> above.

Lights up when your

finger touches the

buttons or touch panel.

Initialize Initialize all settings you have made in <AV Menu>. Press and hold [Enter]

to initialize the settings, then reset the unit. (

3)

13

Not required for Bluetooth. They are automatically detected.

*
*14 Not selectable when the component connected to the CD changer jack is selected as the source.
*15 The name of the component detected through the CD changer jack is shown.
*16 The TEL MUTING lead connection is required. See Installation/Connection Manual.

16

Selects a preset sound mode suitable to the music
genre.

♦

Flat (Initial), Hard Rock, R&B, Pop, Jazz, Dance,

Country, Reggae, Classic, User1, User2, User3

1 Display <AV Menu> screen.

or

2 Adjust the settings, then store.

Equalizer

Back Edit

2 Display <Equalizer> screen.

AV Menu

3 Select a sound mode.

Equalizer

Back Edit

Moves to the other 6 sound modes.

Ex.: When <Hard Rock> is selected

BAND

Makes adjustments by moving each bar directly.

User Store

User1
User2
User3

Back

Ex.: When storing into <

User2>.

Preset equalizing values

Sound

mode

60 Hz

150 Hz

Flat 00 00 00 00 00 00 00
Hard Rock +03 +03 +01 00 00 +02 +01
R&B +03 +02 +02 00 +01 +01 +03
Pop 00 +02 00 00 +01 +01 +02
Jazz +03 +02 +01 +01 +01 +03 +02
Dance +04 +02 00 –02 –01 +01 +01

1 kHz

400 Hz

2.5 kHz

6.3 kHz

15 kHz

Storing your own adjustments

You can store your adjustments into <User1>,
<User2>, and <User3>.

1 Perform steps 1 and 2 above to enter the

<Equalizer> screen.

Country +02 +01 00 00 00 +01 +02
Reggae +03 00 00 +01 +02 +02 +03
Classic +02 +03 +01 00 00 +02 00
User1/2/3 00 00 00 00 00 00 00

17AV MENU

Menu item Selectable setting/item

Fader/Balance Fader : Adjust the front and rear speaker output balance.

• When using a two-speaker system, set the fader level to “0.”

♦

F6 to R6; Initial 0

Balance : Adjust the left and right speaker output balance.

♦

L6 to R6; Initial 0

Press [

5/∞/2/3 ] to adjust.

Initial: Underlined

Volume Adjust *

1

Subwoofer Level *

High Pass Filter *

Crossover *

2

Fader/Balance

Back

Reset

Fader 0
Balance 0

Adjust and store the auto-adjustment volume level for each source, comparing
to the FM volume level. The volume level will automatically increase or decrease
when you change the source.

• <Fix> appears if “

♦

–12 to +12; Initial 00

2

2

Adjust the subwoofer output level.

♦

–06 to +08; Initial 00

♦

Through

♦

On

TUNER/Bluetooth PHONE

” is selected as the source.

: Select when the subwoofer is not connected.
: Select when the subwoofer is connected.

Select the crossover frequency between the front/rear speakers and the
subwoofer.

♦

80Hz, 120Hz, 150Hz

Amplifier Gain *

1

*

For “

DISC/USB

3

”: You can make the adjustments separately depending on the audio format—Dolby digital/MPEG

Audio and the others.

*2 For

KW-AVX726/KW-AVX725/KW-AVX724

*3 The volume level automatically changes to “VOL 30” if you change to <Low> with the volume level set higher than

“VOL 30.”

18

You can change the maximum volume level of this unit.

♦

♦

Off
Low

: Deactivates the built-in amplifier.
: VOL 00 to 30 (Select this if the maximum power of the

speakers is less than 50 W.)

♦

High

: VOL 00 to 50

.

Initial: Underlined

Selectable items when the source is:

•

TUNER

•

DISC, USB, CD-CH, iPod

•

iPod

•

AV-IN, EXT-IN

: Mono, SSM, Title Entry

: Repeat, Random

1, *2

*

: Repeat, Random, Audiobooks

: Title Entry

Menu item Selectable setting/item

Mono When an FM stereo broadcast is hard to receive, activate monaural mode for better

reception. The MONO indicator lights up.

♦

♦

ON

OFF

: Activate monaural mode to improve FM reception, but stereo effect

will be lost. The MONO indicator lights up.

: Restore the stereo effect.

SSM (Strong-station
Sequential Memory)

You can automatically preset 6 stations for each FM band.

• Local FM stations with the strongest signals are searched and stored automatically in the
FM band.

Mode

Mono
SSM
Title Entry

Back

Back

Start
Enter

Title Entry You can assign titles (up to 16 characters) to 30 station frequencies (FM and AM),

and

EXT-IN

. (For available characters, 48.)

Press [Enter] to show the <Title Entry> screen.

@

;

/

Back

AV-IN

,

[Store] : Confirm the entry.
[2/3] : Move the cursor.
[BS] : Erase the character before the cursor.
[Del] : Erase the character on the cursor.
[Cap] : Change the letter case (upper/lower).
[A = 0 = Ä] : Change the character set.
[Space] : Enter a space.

1

For

KW-AVX726/KW-AVX725/KW-AVX724

*
*2 Not applicable in “iPod MODE.” ( 39)

.

Continued on the next page

19AV MENU

Menu item Selectable setting/item

Repeat *

3

Available items depend on the loaded disc type and playback file.

Source

Repeat
Chapter

Title
Program
Disc
Folder
Track
One
All
Off

♦

Chapter

♦

Title

♦

Program

♦

Disc

♦

Folder

♦

Track

♦

One

♦

All

♦

Off

Disc/file type

: Repeats current chapter.
: Repeats current title.
: Repeats current program (for DVD-VR, not available during Playlist playback).
: Repeats all tracks of the current disc.
: Repeats all tracks of the current folder.
: Repeats current track. (For VCD: When PBC is not in used.)
: Functions the same as “Repeat One” of the iPod.
: Functions the same as “Repeat All” of the iPod.
: Cancels.

DVD-Video

DISC USB

DVD-VR

DivX/MPEG/

MP3/WMA/

WAV

JPEG

VCD/CD

4

*

MPEG/MP3/

WMA/WAV

CD-CH iPod iPod

JPEG

CD

MP3

—

—

4

*

Random

3

*

Available items depend on the loaded disc type and playback file.

Source

Disc/file type

Random
Folder

Disc/USB (All)
All
Song
Album
Off

♦

Folder

♦

Disc/USB

DISC USB

DivX/MPEG/

MP3/WMA/

WAV

VCD/CD

: Randomly plays all tracks of the current folder, then tracks of the next folders.
: Randomly plays all tracks. (For VCD: When PBC is not in used.)

4

*

MPEG/MP3/

WMA/WAV

(All)

♦

All

♦

Song

♦

Albums

♦

Off

3

Not applicable in “iPod MODE.” ( 39)

*
*4 For

KW-AVX726/KW-AVX725/KW-AVX724

: Randomly plays all tracks of all loaded discs.
: Functions the same as “Shuffle Songs” *6 of the iPod.
: Functions the same as “Shuffle Albums” of the iPod.
: Cancels.

.

*5 Not applicable for video file.
*6 You can activate <Shuffle Songs> in <Search Mode> menu. ( 22)

CD-CH iPod iPod

CD

MP3

—

4,

5

*

*

—

20

Menu item Selectable setting/item

Audiobooks *

7

*

For

7,

*8You can select the playback speed of the “Audiobook” audio file in your iPod.

♦

Normal

♦

Faster

♦

Slower

: Plays at normal speed.
: Plays faster.
: Plays slower.

KW-AVX726/KW-AVX725/KW-AVX724

.

*8 Not applicable in “iPod MODE.” ( 39)

Source Operation/setting

TUNER • Storing a preset station manually

1 Press [BAND], then [ / ] to tune in to the station you want to preset.
2 Select <List> from the <AV Menu>.
3 Press and hold a preset number.

List

FM1
FM2
FM3

The station selected in step

1 is now stored in preset

number 4.

DISC/USB *

Back

Back

• Selecting a preset station on the list

List

FM1
FM2
FM3

Back

Back

1

Selecting a track on the list

If the device contains folders, you can display the Folder/Track (File) Lists, then start playback.

1 Current folder list number/

List

Back

Back

Folder 01
Folder 02
Folder 03
Folder 04
Folder 05
Folder 06

0003/00990005/0035

Track001.mp3
Track002.mp3
Track003.mp3
Track004.mp3
Track005.mp3
Track006.mp3

total folder list number

2 Current track list number/total

track list number of the
current folder

* Press: Skips the list up or down.

Drag: Scrolls the list up or down.

*1 For

KW-AVX726/KW-AVX725/KW-AVX724

.

Continued on the next page

21AV MENU

Source Operation/setting

Bluetooth PHONE Selecting a preset phone number on the list to make a call

List

Phone Number

Back

Back

CD-CH Selecting a disc on the list

iPod *

2, *3

Disc List

Back

Back

Disc 01

Disc 02

Disc 03

Disc 04

MP3 Disc

Disc 06

To go to the other list

Selecting a track/video from <Search Mode>

Search Mode

Music
Videos
Shuffle Songs

Back

Back

List

Playlists
Artists
Albums
Songs
Podcasts
Genres

Back

Back

Playlists
Artists
Albums
Songs
Podcasts
Genres

0003/0099

Track 01
Track 02
Track 03
Track 04
Track 05
Track 06

If an MP3 disc is selected, Folder/
Track List appear. Select a track to
start playback.

♦

Music : Playlists, Artists, Albums,

Songs, Podcasts, Genres, Composers,
Audiobooks

♦

Videos : Video Playlists, Movies,

Music Videos, TV shows, Video
Podcasts

♦

Shuffle Songs : Playback starts if

this is selected.

Current track (video) number/total track
(video) number

2

For

KW-AVX726/KW-AVX725/KW-AVX724

*
*3 Not applicable in “iPod MODE.” ( 39)

22

.

Select “

Bluetooth PHONE

” or “

Bluetooth AUDIO

” as the source for operations.

• Firstly, use <Open> or <Search> to register and establish the connection with a device.

Menu item Selectable setting/item

Dial Menu *

1

Select the method to make a call.

♦

Redial

♦

Received Calls

♦

Phonebook

♦

Missed Calls

♦

Phone Number

: Shows the list of the phone numbers you have dialed.
: Shows the list of the received calls.
: Shows the phone book of the connected cellular phone.
: Shows the list of the missed calls.
: Shows the phone number entry screen.

Phone Number

Back

Back

[BS] : Erase the character before the cursor.
[Del] : Erase the character on the cursor.
[Preset] : Goes to Preset List. You can preset the entered

number by selecting a preset number.

[Dial] : Calls the entered number.

♦

Voice Dialing

: Only when the connected cellular phone has the voice

recognition system: = Speak the name you want to call.

Message *

2

If <Message Info> is set to <Manual>... ( 25)

Access the message list to read messages.

♦

Unread

♦

Read

♦

Unsent

♦

Sent

• The number of messages in each history is also shown.

1

Only for the device connected for “

*
*2 Selectable only when the source is “

(Short Message Service).

: Messages you have not read.
: Messages you have read.
: Messages you have not sent.
: Messages you have sent.

Bluetooth PHONE

Bluetooth PHONE

.”

” and the connected cellular phone is compatible with SMS

Continued on the next page

23AV MENU

Menu item Selectable setting/item

Open Preparation:

• Operate the Bluetooth device to turn on its Bluetooth function.

• Make sure “NEW DEVICE” is selected. If not, press [ 5 ] or [ ∞ ] to select it.

1 Press <Open> on the <Bluetooth> menu.
2 Enter a PIN (Personal Identification Number) *

• You can enter any number you like (1-digit to 16-digit number).

3

.

PIN Code

Back

Back

3 Operate the Bluetooth device to connect while “Open...” is displayed on the screen.

Enter the same PIN code (as entered in the above step) on the device to be connected.

Now connection is established and you can use the device through the unit.

• The device remains registered even after you disconnect the device. Use <Connect> or
activate <Auto Connect> to connect the same device the next time.

Search Preparation:

• Make sure “NEW DEVICE” is selected. If not, press [

1 Press <Search> on the <Bluetooth> menu.

The unit searches for available devices and displays the list of them. (If no available

device is detected, “Device Unfound” appears.)

2 Select a device you want to connect.
3 Enter the specific PIN code of the device to the unit.

• Refer to the instructions supplied with the device to check the PIN code.

4 Operate the Bluetooth device to connect while “Connecting...” is displayed on the

screen.

You can enter [0] – [9] only.
[BS] : Erases the character

before the cursor.

[Del] : Erases the character on

the cursor.

[Enter] : Confirms the entry.

5 ] or [ ∞ ] to select it.

Now connection is established and you can use the device through the unit.

3

Some devices have their own PIN code. Enter the specified PIN code to the unit.

*

24

Menu item Selectable setting/item

Special Device Only for “NEW DEVICE.”

Select a device you want to connect from the list of Bluetooth devices which require
some special procedure to establish the Bluetooth connection. Then, use <Open> or
<Search> to connect.

• Once the connection is established, it is registered in the unit. You can connect the unit

and the device by using <Connect> the next time.

Connect Only for the registered devices.

Select a device from the list of registered devices, establish the connection with it.

Disconnect Only for the connected devices.

Disconnect the current device before connecting another device.

Delete Pairing Only for the registered devices.

Press <Yes> to confirm delete the registered devices.

Settings
Initial: Underlined

Auto Connect *

Auto Answer *

Message Info *

MIC Setting *

5

4

When the unit is turned on, the connection is established
automatically with...

♦

Off

♦

Last

♦

Order

: No Bluetooth device.
: The last connected Bluetooth device.
: The available registered Bluetooth device found

first.

5

♦

Off

: The unit does not answer the calls automatically.

Answer the calls manually.

♦

On

: The unit answers the incoming calls

automatically.

♦

Reject

5

♦

Auto

: The unit rejects all incoming calls.
: The unit informs you of the arrival of a message

by ringing and displaying “Receiving Message.”
To read the message, 37.

♦

Manual

: The unit does not inform you of the arrival of a

message.

Adjust the volume of the microphone connected to the Bluetooth
adapter.

♦

01/02/03

Version The Bluetooth software and hardware versions are shown.

4

*

Selectable only for “

Bluetooth PHONE

*5 Only for the cellular phone connected for “

.”

Bluetooth PHONE

.” Not selectable when “NEW DEVICE” is selected.

25AV MENU

Listening to the radio

SOURCE

Band

TUNER

Preset number

1FM1 87. 5 MHz

Sound mode

Tuner indicator

FLAT

ST

3:00

ABC Radio

AM

BAND

Assigned station name

( 19)

• If no name is
assigned, “No Name”
appears.

~ Press [SOURCE], then press [TUNER].
Ÿ Press [BAND].
! Press [ ] or [ ] to search for a station—Auto Search.

• Manual Search: Hold either [ ]or [ ] until “Manual Search” appears on the screen, then press it
repeatedly.

• The ST indicator lights up when receiving an FM stereo broadcast with sufficient signal strength.

Selecting a preset station

• Directly from the touch panel

SOURCE

TUNER

FLAT

ST

1FM1 87. 5 MHz

ABC Radio

Changing the display information

( 50)

AM

3:00

You can also select a preset station using the remote
controller ( 8, 9) and from the Preset List ( 21).

You can display the Preset List by pressing [ ] or
holding [5/∞].

26

BAND

• To improve the FM reception, 19.

• To automatically preset stations into memory,

19.

• To manually preset stations into memory, 21.

• To assignning titles to stations, 19.

Disc operations

The disc type is automatically detected, then playback starts (for some discs, the top menu of the disc appears).

If a disc does not have any disc menu, all tracks on it will be played repeatedly until you change the source or eject
the disc.

” appears on the screen, the unit cannot accept the operation you have tried to do.

If “

• In some cases, without showing “ ,” operations will not be accepted.

~ Open the monitor panel.

<Open/Tilt> menu is displayed.

• By pressing and holding the button, you can
open the monitor panel and eject the disc.

Ÿ

Open/Tilt

! Insert a disc.

Label side

Monitor panel closes automatically.
If not, press [Close].

Caution:

Do not place your finger behind the monitor panel.

Prohibiting disc ejection

You can lock a disc in the loading slot.

Back

To cancel the prohibition, repeat the same
procedure to select <EJECT OK?>.

• Discs can be forcibly ejected. ( 3)

When playing back a multi-channel encoded disc,
the multi-channel signals are downmixed.

• You can fully enjoy multi-channel sound by
connecting an amplifier or a decoder compatible
with these multi-channel sources. ( 49)

• To select the playback mode, 20.

• To select tracks on the list, 21.

Continued on the next page

27OPERATIONS

Changing the display information

Each time you press the button, the display changes to show the different
information. ( 50)

Ex.: While playing a DVD Video

SOURCE

DVD

FLAT

CHAP. RPT

AM

3:00

1 Audio format—Dolby Digital, MP3, WMA, WAV
2 Disc type—DVD, DVD-VR, VCD, CD
3 Video format—DivX, MPEG, VR-PRG (program),

VR-PLAY (playlist), PBC

4 [5 / ∞]

• DVD Video/DVD-VR: Selects title/program/
playlist.

• DivX/MPEG/JPEG/MP3/WMA/WAV:

– Selects folder
– Displays Folder/Track List (Hold)

5 • DVD Video: Title no./Chapter no./Playing time

• DVD-VR: Program no. (or Playlist no.)/
Chapter no./Playing time

• DivX/MPEG/MP3/WMA/WAV: Folder no./Track
no./Playing time

• JPEG: Folder no./Track no.

• VCD/CD: Track no./Playing time

6 [6 ]

Starts playback/pauses

7 Indicates the button pressed ( / 8 / 7)
8 Sound mode ( 17)
9

Playback mode ( 20)

p

Disc/track information

• DVD Video/DVD-VR: Sampling frequency/Bit
rate/Recorded signal channel no.

• DivX/MPEG/JPEG: Folder name/file name

• CD Text: Title/artist name/album name

– “No Name” appears for conventional CDs or if

not recorded

• MP3/WMA/WAV: Current folder name/current
file name/tag data (current track title/artist
name/album title) if it is recorded

q Stops playback
w [4 / ¢]

• DVD Video/DVD-VR: Selects chapter.

• DivX/MPEG/JPEG/VCD/CD/MP3/WMA/WAV:
Selects track.

• DVD Video/DVD-VR/DivX/MPEG/VCD/CD/MP3/
WMA/WAV: Reverse/forward search (Hold)

28

Operation buttons on the screen

You can display the following operation buttons while watching the playback pictures on the screen.

• If no operation is done for about 5 seconds, the operation buttons disappear (except when a disc menu is
displayed).

A

[SOURCE] Displays <Source Menu> screen
[5 ∞] 28
[3 / 8] Starts playback/pause
[4 ¢] • Selects tracks

• Reverse/forward search (Hold)

Touch the screen (center portion).

Touch [KEY].

[ ] Displays <AV Menu> screen
[7] Stops playback

• The above buttons also work when they are not
shown on the screen (while watching the playback
picture).

B

For DVD/VCD menu operation playback
[5 ∞ 2 3] Selects the menu items
[ENTER] Confirms the selection
[TOP MENU] Displays the disc menu
[MENU] Displays the disc menu
[RETURN] Returns to the previous menu or

displays the menu (only for VCD with
PBC)

KEY].

Touch [

Touch [

KEY].

To end the operations, touch the screen again.

C

For entering the numbers
[0]–[9]=[ENTER] Enters numbers
[Direct/CLR] • Switches between chapter/track

entry and title/folder entry

• Erases the last entry when you

enter a wrong number

Ex.: To enter “105,” press [1], [0], [5], then [ENTER]

*1 While a disc menu is played back for DVD, [KEY] is

automatically displayed. On the disc menu, you can
select a menu item directly by touching it on the
screen

*2 Displays Short Cut icons. ( 7)
*3 Playback time. ( 28)

29OPERATIONS

Operations using the remote controller (RM-RK252)

Button

/

Stop play Stop play

Start play/Pause (if pressed during play) • DivX/MPEG: Start play/Pause (if pressed

during play)

• JPEG: • Start play (Slide show: Each file is
shown for a few seconds.)

• Pause (if pressed during play).

• Reverse/forward chapter search *1 (No sound

can be heard.)

• DivX/MPEG: Reverse/forward track search *

(No sound can be heard.)

• Slow motion *2 during pause (No sound can

be heard.)

– DVD-VR: Reverse slow motion does not work.

• Select chapter (during play or pause)

• Reverse/fast-forward chapter search *3 (No

sound can be heard.) (Hold)

• DivX/MPEG: • Select track

• Reverse/fast-forward track

search *5 (No sound can be
heard.) (Hold)

• JPEG: Select file

4

• DVD-Video: Select title (during play or pause)

• DVD-VR: • Select program

• Select playlist (during play or
pause)

—

Select aspect ratio Select aspect ratio

1

*

Search speed:

*2 Slow motion speed:
*3 Search speed:
*4 Search speed:
*5 Search speed:

Using menu driven features... (DVD-Video)

1 Enter the menu screen.

or

2 Select an item you want to start play.

Select folder

• DivX/MPEG: Skip back or forward the scenes
by about 5 minutes

Canceling the PBC playback... (VCD)

During stop...

1

2

Number buttons

(0 – 9)

30

• To resume PBC, press TOP M/MENU.

Button

Stop play Stop play Stop play

Start play/Pause (if pressed
during play)

Reverse/forward track search *

• Forward slow motion *7

during pause. (No sound can
be heard.)

– Reverse slow motion does not

work.

• Select track

• Reverse/fast-forward track

search *8 (No sound can be
heard.) (Hold)

Select aspect ratio

6

Search speed:

*
*7 Slow motion speed:
*8 Search speed:

—

Start play/Pause (if pressed
during play)

6

Reverse/forward track search *6Reverse/forward track search *

• Select track

• Reverse/fast-forward track

search *8 (Hold)

Start play/Pause (if pressed
during play)

• Select track

• Reverse/fast-forward track

search *8 (Hold)

Select folder

—

——

6

Searching for an item directly

1 While holding SHIFT, press DIRECT repeatedly to

select the desired search mode.

DVD-Video:

DVD-VR:

DivX/MPEG:

JPEG:

MP3/WMA/
WAV:

VCD/CD:

2 While holding SHIFT, press the number buttons (0

– 9) to enter the desired number.

3 Press ENT (enter) to confirm.

• For DivX/MPEG/JPEG/MP3/WMA/WAV, track is
searched within the same folder.

• For DVD-VR, program/playlist search is possible
during Original program playback (PG)/Playlist
playback (PL).

• To erase a misentry, press CLR (clear) while holding
SHIFT.

• To return to the previous screen, press RETURN.

Continued on the next page

31OPERATIONS

Using the list screens... (DVD-VR)

1 Display the Original Program screen.

Operations using the

on-screen bar

(DVD/DVD-VR/DivX/MPEG/JPEG/VCD)

Display the Playlist screen.

2 Select an item you want to start play.

Original Program/Playlist screen

• Original Program

• Playlist

These operations are possible on the monitor using the
remote controller.

1 Show the on-screen bar ( 33).

(twice)

2 Select an item.

3 Make a selection.

If pop-up menu appears...

• To cancel pop-up menu, press RETURN.

• For entering time/numbers, see the following.

Entering time/numbers

Press % / fi to change the number, then press @ / # to
move to the next entry.

• Each time you press % / fi, the number increases/
decreases by one value.

• After entering the numbers, press ENT (enter).

• It is not required to enter the zero and tailing zeros
(the last two digits in the example below).

1 Original Program/Playlist number
2 Recording date
3 Recording source (TV station, the input terminal of

the recording equipment, etc.)

4 Start time of recording
5 Title of the program/playlist *
6 Highlight bar (current selection)
7 Creating date of playlist
8 Total number of chapters included in the playlist
9 Playback time

* The title of the original program or playlist may not be

displayed depending on the recording equipment.

32

Ex.: Time search
DVD: _:_ _:_ _ (Ex.: 1:02:00)
Press

% once, then # twice to go to the third entry, %

twice, then press ENT (enter).

Removing the on-screen bar

On-screen bar

Ex.: DVD-Video

Information

Operation

1 Disc type
2 • DVD-Video: Audio signal format type and

channel

• VCD: PBC

3 Playback mode *

1

DVD-Video: T. RPT: Title repeat
C. RPT: Chapter repeat
DVD-VR: C. RPT: Chapter repeat
PG. RPT: Program repeat
DivX/MPEG Video: T. RPT: Track repeat
F. RPT: Folder repeat
A. RND: All (Disc) random
F. RND: Folder random
JPEG: F. RPT: Folder repeat
VCD *2: T. RPT: Track repeat
A. RND: All (Disc) random

4 Playback information

Current title/chapter

5 Time indication

Current program/chapter

Current playlist/chapter

Current track

Current folder/track

Current folder/file

Elapsed playing time of the disc

(For DVD-Video, elapsed playing
time of the current title/program/
playlist.)

DVD-Video/DVD-VR: Remaining

title/program/playlist time

VCD: Remaining disc time

Elapsed playing time of the current

chapter/track *

3

Remaining time of the current

chapter/track *

6 Playback status

3

Play
Forward/reverse search
Forward/reverse slow-motion
Pause
Stop

7 Operation icons

Change time indication (see 5)
Time Search (Enter the elapsed

playing time of the current title/
program/playlist or of the disc.)

Title Search (by its number)

Repeat play *
Random play *

Chapter Search (by its number)

Track Search (by its number)

1

1

Change the audio language, audio

stream, or audio channel

Change or turn off the subtitle

language

Change the view angle

*1 For repeat play/random play, 20.
*2 While PBC is not in use.
*3 Not applicable for DVD-VR.

33OPERATIONS

USB operations (for KW-AVX726/KW-AVX725/KW-AVX724)

You can connect a USB mass storage class device such as a USB memory, Digital Audio Player, portable HDD, etc. to
the unit.

• You can also connect the iPod to the USB terminal of the unit. For details of the operations, 39, 40.

USB cable from the rear of the unit

This unit can play JPEG/MPEG1/MPEG2/MP3/WMA/
WAV files stored in USB mass storage class device.

• You can operate the USB device in the same way you
operate the files on discs.

• All tracks in the USB device will be played repeatedly
until you change the source.

• Playback starts from where it has been stopped
previously when you reconnect the same USB device
again.

• To select the playback mode, 20.

• To select tracks on the list, 22.

Changing the display information

( 50)

Cautions:

• Avoid using the USB device if it might hinder your
safety driving.

• Do not pull out and attach the USB device repeatedly
while “Now Reading” is shown on the screen.

• Do not start the car engine if a USB device is
connected.

• This unit may not be able to play the files depending
on the type of USB device.

• Operation and power supply may not work as
intended for some USB devices.

• You cannot connect a computer to the USB input
terminal of the unit.

• Make sure all important data has been backed up to
avoid losing the data.

• Do not leave a USB device in the car, expose to direct
sunlight, or high temperature to avoid deformation
or cause damages to the device.

• Some USB devices may not work immediately after
you turn on the power.

• For more details about USB operations, 46.

34 OPERATIONS

Using the Bluetooth® devices

For Bluetooth operations, it is required to connect the Bluetooth adapter, KS-BTA200 (not supplied) to the CD
changer jack on the rear of this unit.

• Refer also to the instructions supplied with the Bluetooth adapter and the Bluetooth device.

• Refer to the list (included in the box) to check the countries where you may use the Bluetooth ® function.

To use a Bluetooth device through the unit (“
you need to establish Bluetooth wireless connection between the unit and the device.

• Once the connection is established, it is registered in the unit even if you reset your unit. Up to five devices can be
registered in total.

• Only one device can be connected at a time for each source (“

Bluetooth PHONE

” and “

Bluetooth PHONE

Bluetooth AUDIO

” and “

”) for the first time,

Bluetooth AUDIO

”).

Connecting a new Bluetooth device

Registration (Pairing) methods

Use either of the following items in <Bluetooth> menu to register and establish the connection with a device.

• Select “

Open Make the unit ready to establish a new Bluetooth connection. The connection is established by

Search Make the unit ready to establish a new Bluetooth connection. The connection is established by

Bluetooth PHONE

operating the Bluetooth device.

operating this unit.

” or “

Bluetooth AUDIO

” as the source to operate <Bluetooth> menu.

• To register a device using <Open> or <Search>,

• To connect a special device, 25.

• To connect/disconnect/delete a device, 25.

24.

Changing the display information

( 50)

Bluetooth Information:

If you wish to receive more information about Bluetooth, visit the following JVC web site:
<http://www.jvc.co.jp/english/car/> (English website only).

Continued on the next page

35EXTERNAL DEVICES

Using the Bluetooth cellular phone

Status of the device

• Signal strength/Battery remainder (only when
the information comes from the device).

SOURCE

FLAT

AM

3:00

Activates <
function. (Hold)

Voice Dialing>

Display <

• Appears on any source information screen
when the Bluetooth adapter is connected.

[5 / ∞]: Selects the
other registered device.

Connected Device Name

Dial Menu> screen.

~ Press [SOURCE], then press [Bluetooth PHONE].
Ÿ Press [ ].

Connected device name

• When a cellular phone with audio function is
registered/connected,

Bluetooth icon

• Lights up when the Bluetooth adapter
is connected.

appears.

! Press [Bluetooth].
⁄ Establish the connection with a device, then make a call (or settings using <Bluetooth>

menu). (

When a call comes in...

The source is changed to “
automatically.

Name and phone number (if acquired)

When <Auto Answer> is activated...

The unit answers the incoming call automatically.
( 25)

When <Auto Answer> is deactivated...
To answer the incoming call

• Press the message displayed on the touch panel.

• Press any button on the monitor panel (except
or VOL +/–).

23 – 25)

Bluetooth PHONE

To end the call

”

• Hold the message displayed on the touch panel.

• Hold any button on the monitor panel (except
or VOL +/–).

• You can adjust the microphone volume, 25.

To make a call, use <Dial Menu>. ( 23)

36

When an SMS comes in...

If the cellular phone is compatible with SMS (Short
Message Service), you can read the messages on the
screen.

• You cannot edit or send a message through the unit.

When <Message Info> is set to <Auto>...

The unit rings and the following screen is displayed to
inform you of a message arrival. (

Device Name

Receiving Message

Read ?

Yes No

To read the message, press [Yes].
The source is changed to “Bluetooth PHONE.”

25)

Jack

Presetting the phone

numbers

You can preset up to 6 phone numbers.

1 Select the phone number you want to

preset from <Phonebook>, <Redial>,
<Received Calls>, or <Missed Calls>.

( 23)

2 Select a telephone number to store.

Dial Menu

Back

Back

3 Select a preset number.

To read the message later, press [No].

• The message is stored into <Message> =
<Unread>. ( 23)

When <Message Info> is set to <Manual>...

Access the message list to read messages, 23.

To stop ringing (canceling the outgoing call)

Hold any button on the monitor panel (except
or VOL +/–).

Dial Menu

Back

Back

Now “Tom” is stored into preset no. 1.

To call a preset number, 22.

Continued on the next page

37EXTERNAL DEVICES

Using the Bluetooth audio player

Starts playback/pause

SOURCE

Indicates the button pressed.

• It may be different from the operation status.

FLAT

AM

3:00

[4 / ¢]: Reverse/forward search [5 / ∞]: Selects the other registered device. Stops playback

Connected Device Name

~ Press [SOURCE], then press [Bluetooth AUDIO].
Ÿ Start playback.

If playback does not start automatically, operate the Bluetooth audio player to start playback.

Listening to the CD changer

It is recommended to use a JVC MP3-compatible CD changer with your unit.

• You can play only CDs (CD-DA) and MP3 discs.

Preparation:

Make sure <Changer> is selected for <External Input>. (

16)

Ex.: While playing an MP3 disc

• [4 / ¢]: Selects track

• [4 / ¢]: Reverse/forward search (Hold)

SOURCE

CD-CH

DISC 1

FLAT

REPEAT

AM

3:00

Tag data (if it is recorded) Folder no./Track no./Playing time

[5 / ∞]: Displays Disc List.

Current Folder Name
Current File Name.mp3

Current Track Title
Artist Name
Album Title

~ Press [SOURCE], then press [CD-CH].
Ÿ Press [ ].
! Press [List].

⁄ Select a disc to start playing.

To select the playback mode, 20.

38

Listening to the iPod/iPhone

You can connect the iPod/iPhone using the following cable or adapter:

To Cable/adapter To operate

Listen to the
music

KW-AVX726/KW-AVX725/KW-AVX724:

USB 2.0 cable (accessory of the iPod/iPhone) to the

See “When connected with the USB
cable” below.

USB cable from the rear of the unit.

Watch the video

Interface Adapter for iPod, KS-PD100 (not supplied) to
the CD changer jack on the rear of the unit.

KW-AVX726/KW-AVX725/KW-AVX724:

USB Audio and Video cable for iPod/iPhone, KS-U30
(not supplied) to the USB cable from the rear of the
unit.

See “When connected with the
interface adapter” on page 40.

See “When connected with the USB
cable” below.

• Make sure <iPod (Off)> is selected
for <AV Input>, 15.

When connected with the USB cable

There are 2 control modes in ”

• “HEAD MODE” : Control by this unit.

• “iPod MODE” : Control by the connected iPod/iPhone.
KS-U30: Make sure <iPod (Off)> is selected for <AV Input>, 15.

• Press and hold to switch between “HEAD MODE” and “iPod MODE.”
The operation explained below are under “HEAD MODE.”

iPod

“ source.

• [5 / ∞]: Moves to the previous/next item of a category

• Enters <Search Mode> menu (Hold) *2 ( 22 )

SOURCE

Indicates the controlling
unit for playback

• [4 / ¢]: Selects a track/video

• [4 / ¢]:Reverse/forward search (Hold)

HEAD MODE

FLAT

REPEAT

3:00

iPod

AM

Current Track Title
Artist Name
Album Title

Track no./Playing time Stops playback

1

*

Starts playback/pause

*1 [5 / ∞] may not function depending on how you select the current track/video.
*2 Not applicable in “iPod MODE.”

Continued on the next page

39EXTERNAL DEVICES

~ Press [SOURCE], then press [iPod ].

Playback starts automatically.

• When you connect the iPod to the USB
terminal, “
and playback starts automatically.

iPod

” is selected as the source

The following operations/settings are only
available in “HEAD MODE.”

• To display the <iPod Artwork>,

• To select track/video from <Search Mode>,

22.

• To select the playback mode, 20.

Ÿ Press [4] or [¢] to select a track/

video.

• To change the play speed of the audio books,

21.

You cannot resume playback for video sources.

When connected with the interface adapter

14.

Enters main menu

SOURCE

iPod

FLAT

REPEAT

Song Name
Artist Name

AM

3:00

• [4 / ¢]: Reverse/forward search (Hold)

Album Title

Starts playback/pause• [4 / ¢]: Selects tracks

Preparation:
Make sure <iPod> is selected for <External Input>. ( 16)

~ Press [SOURCE], then press [iPod].

Playback starts automatically.

Track no./Playing time

Ÿ Press [4] or [¢] to select a track.

40

Selecting a track from the main

3 Press [3 / 8] to confirm the selection.

menu

1 Press [SEARCH] to enter the main menu.

“SEARCH” flashes on the screen during menu

operations.

• This mode will be canceled if no operations are
done for about 5 seconds.

2 Press [4] or [¢] to select the desired

item.

• Skips 10 items at a time if there are more than
10 items. (Hold)

Playlists Ô Artists Ô Albums Ô Songs

Ô Genres Ô Composers Ô (back to the

beginning)

4 Repeat steps 2 and 3 to select a track.

• When a track is selected finally, playback starts.

• To return to the previous menu, press [SEARCH].

To select the playback mode,

Changing the display information

20.

( 50)

Using other external components

AV-INPUT

You can connect an external component to the LINE IN/VIDEO IN jacks.

Assigned title ( 19)

SOURCE

AV-IN

FLAT

AM

3:00

~ Press [SOURCE], then press [AV-IN].

For

KW-AVX626/KW-AVX625/KW-AVX624

: You can also press AV-IN on the monitor panel.

Ÿ Turn on the connected component and start playing the source.

To display the operation buttons while watching the playback picture, 29.

Continued on the next page

41EXTERNAL DEVICES

Navigation screen

You can also connect a Navigation System to the VIDEO IN jack so that you can watch the navigation screen.

Preparation:
Make sure <Navigation> is selected for <AV Input>. ( 15)

To view the navigation screen

Press DISP on the monitor panel repeatedly. ( 50)

• The aspect ratio of the navigation screen is fixed to <Full> regardless of the <Aspect> setting. ( 13)

When <Navigation> is selected for <AV Input> ( 15)

• You can use the source “

AV-IN

” for listening to an audio source connected to the LINE IN jacks.

EXT-INPUT

You can connect an external component to the CD changer jack on the rear using the Line Input Adapter, KS-U57 (not
supplied) or AUX Input Adapter, KS-U58 (not supplied).

Assigned title ( 19)

SOURCE

EXT-IN

FLAT

AM

3:00

Preparation:
Make sure <External> is selected for <External Input>. ( 16)

~ Press [SOURCE], then press [EXT-IN].
Ÿ Turn on the connected component and start playing the source.

Changing the display information

42 EXTERNAL DEVICES

( 50)

Maintenance

Caution on cleaning the unit

Do not use any solvent (for example, thinner, benzine,
etc.), detergent, or insecticide. This may damage the
monitor or the unit.

Recommended cleaning method:

Gently wipe the panel with a soft, dry cloth.

Moisture condensation

Moisture may condense on the lens
inside the unit in the following cases:

• After starting the heater in the car.

• If it becomes very humid inside the
car.

Should this occur, the unit may malfunction. In this
case, eject the disc and leave the unit turned on for a
few hours until the moisture evaporates.

Center holder

To keep discs clean

A dirty disc may not play correctly.
If a disc does become dirty, wipe it with
a soft cloth in a straight line from center
to edge.

• Do not use any solvents (for example, conventional
record cleaner, spray, thinner, benzine, etc.) to clean
discs.

To play new discs

New discs may have some rough spots
around the inner and outer edges. If
such a disc is used, this unit may reject
the disc.
To remove these rough spots, rub the edges with a
pencil or ball-point pen, etc.

Do not use the following discs:

Single CD (8 cm disc) Warped disc

How to handle discs

When removing a disc from its case, press down the

center holder of the case and lift the disc out, holding it
by the edges.

• Always hold the disc by the edges. Do not touch its
recording surface.

When storing a disc in its case, gently insert the
disc around the center holder (with the printed surface
facing up).

• Make sure to store discs in cases after use.

Sticker and sticker residue Stick-on label

C-thru Disc (semi-

Unusual shape

Transparent or semi-

transparent parts on its

recording area

transparent disc)

43REFERENCES

More about this unit

General

Turning on the power

• By pressing SOURCE on the monitor panel, you
can also turn on the power. If the source is ready,
playback starts.

Tuner (FM only)

Storing stations in memory

• When SSM is over, received stations are preset in no.
1 (lowest frequency) to no. 6 (highest frequency).

Disc

General

• In this manual, words “track” and “file” are
interchangeably used.

• This unit can only play back audio CD (CD-DA) files
if different type of audio files (MP3/WMA/WAV) are
recorded on the same disc.

• This unit can recognize a total of 25 characters for
file/folder names.

• Some discs or files may not be played back due to
their characteristics or recording conditions.

Playing DVD-VR

• For details about DVD-VR format and playlist, refer
to the instructions supplied with the recording
equipment.

File playback

Playing DivX files

• This unit can play back DivX files with the extension
code <.divx>, <.div>, or <.avi> (regardless of the
letter case—upper/lower).

• Audio stream should conform to MP3 or Dolby Digital.

• The file encoded in the interlaced scanning mode
may not be played back correctly.

• The maximum bit rate for video signals (average) is
4 Mbps.

Inserting a disc

• When a disc is inserted upside down or has no
playable files, “Cannot play this disc Check the disc”
appears on the screen. Eject the disc.

Ejecting a disc

• If “No Disc“ appears after removing a disc, insert a
disc or select another playback source.

• If the ejected disc is not removed within 15 seconds,
the disc is automatically inserted again into the
loading slot to protect it from dust.

Playing Recordable/Rewritable discs

• This unit can recognize a total of 5 000 files and 250
folders (a maximum of 999 files per folder).

• Use only “finalized” discs.

• This unit can play back multi-session discs; however,
unclosed sessions will be skipped while playing.

Playing MPEG1/MPEG2 files

• This unit can play back MPEG1/MPEG2 files with the
extension code <.mpg>, <.mpeg>, or <.mod>*.

* <.mod> is an extension code used for the MPEG2 files

recorded by JVC Everio camcorders. The MPEG2 files
with the <.mod> extension code cannot be played
back when stored on a USB mass storage class device.

• The stream format should conform to MPEG system/
program stream.

The file format should be MP@ML (Main Profile at

Main Level)/SP@ML (Simple Profile at Main Level)/
MP@LL (Main Profile at Low Level).

• Audio streams should conform to MPEG1 Audio
Layer-2 or Dolby Digital.

• The maximum bit rate for video signals (average) is
4 Mbps.

44

Playing JPEG files

Disc/file information shown on the

• This unit can play back JPEG files with the extension
code <.jpg>, or <.jpeg>.

• This unit can play back JPEG files that are at 32 × 32
to 8 192 × 7 680 resolution.

It may take time to display the file depending on its

resolution.

• This unit can play back baseline JPEG files.
Progressive JPEG files or lossless JPEG files cannot be
played.

Playing MP3/WMA/WAV files

• This unit can play back files with the extension code
<.mp3>, <.wma>, or <.wav> (regardless of the
letter case—upper/lower).

• This unit can play back the files meeting the
conditions below:

– Bit rate:
MP3/WMA: 32 kbps — 320 kbps
– Sampling frequency:
48 kHz, 44.1 kHz, 32 kHz (for MPEG1)
24 kHz, 22.05 kHz, 16 kHz (for MPEG2)
48 kHz, 44.1 kHz, 32 kHz, 22.05 kHz (for WMA)

44.1 kHz (for WAV)

• This unit can show ID3 Tag Version

1.0/1.1/2.2/2.3/2.4 (for MP3).

• This unit can also show WAV/WMA Tag.

• This unit can play back files recorded in VBR (variable
bit rate).

• Files recorded in VBR have a discrepancy in elapsed
time indication.

• This unit cannot play back the following files:

– MP3 files encoded with MP3i and MP3 PRO format.
– MP3 files encoded with Layer 1/2.
– WMA files encoded with lossless, professional, and

voice format.

– WMA files which are not based upon Windows

Media® Audio.
– WMA files copy-protected with DRM.
– Files which have the data such as AIFF, ATRAC3,

etc.

external monitor

The following screens appear only on the external
monitor.

• CD

T. RPT

Track : 6 / 14

Cloudy
Fair
Fog
Hail
Indian summer

Track Information

Album
Four seasons
Artist
Robert M. Smith
Title
Rain

Rain

Shower
Snow
Thunder
Typhoon
Wind
Winter sky

1 Selected playback mode
2 Elapsed playing time of the current track
3 Operation status
4 Current track number/total number of tracks on

the disc

5 Track information
6 Track list
7 Current track (highlighted bar)

TIME 00:14

Continued on the next page

45REFERENCES

• DivX/MPEG1/MPEG2/JPEG/MP3/WMA/WAV

1 Current folder (highlighted bar)
2 Current folder number/total folder number
3 Folder list
4 Selected playback mode
5 Elapsed playing time of the current track (not

displayed for JPEG)

6 Operation status
7 Current track number/total number of tracks in the

current folder (total number of tracks on the disc)

8 Track information (only for MP3/WMA/WAV)
9 Track list
p Current track (highlighted)

* If tag data includes “Jacket Picture” (baseline JPEG), it

will be displayed.

• This unit may be unable to play back some USB
devices or some files due to their characteristics or
recording conditions.

• USB devices equipped with special functions such as
data security functions cannot be used with the unit.

• Do not use a USB device with two or more partitions.

• Depending on the shape of the USB devices and
connection ports, some USB devices may not be
attached properly or the connection might be loose.

• When connecting a USB device, refer also to its
instructions.

• Connect only one USB device to the unit at a time. Do
not use a USB hub.

• This unit may not recognize a USB device connected
through a USB card reader.

• When connecting with a USB cable, use the USB 2.0
cable.

• This unit may not play back files in a USB device
properly when using a USB extension cord.

• This unit cannot assure proper functions or supply
power to all types of the devices.

• This unit can recognize a total of 5 000 files and 250
folders (a maximum of 999 files per folder).

• This unit can recognize a total of 25 characters for
file/folder names.

• For MPEG1/2 files: The maximum bit rate for video
signals (average) is 2 Mbps.

Bluetooth operations

USB operations

(for

KW-AVX726/KW-AVX725/KW-AVX724

• If “No USB Device“ appears after removing a device,
reattach a device or select another playback source.

• When the USB device has no playable files, or has not
been formatted correctly, “Cannot play this device
Check the device” appears on the screen.

• This unit cannot recognize a USB device whose rating
is other than 5 V and exceeds 500 mA.

• While playing from a USB device, the playback order
may differ from other players.

46

General

• While driving, do not perform complicated operation

)

such as dialing the numbers, using phone book, etc.
When you perform these operations, stop your car in
a safe place.

• Some Bluetooth devices may not be connected to
this unit depending on the Bluetooth version of the
device.

• This unit may not work for some Bluetooth devices.

• Connecting condition may vary depending on
circumstances around you.

• When the unit is turned off, the device is
disconnected.

Warning messages for Bluetooth operations

iPod/iPhone operations

• Connection Error:
The device is registered but the connection has failed.

Use <Connect> to connect the device again.
( 25)

• Error:
Try the operation again. If “Error” appears again,

check if the device supports the function you have
tried.

• Device Unfound:
No available Bluetooth device is detected by

<Search>.

• Loading:
The unit is updating the phone book or SMS.

• Please Wait...:
The unit is preparing to use the Bluetooth function. If

the message does not disappear, turn off and turn on
the unit, then connect the device again (or reset the
unit).

• Reset08:
Check the connection between the adapter and this

unit.

Icons for phone types

• These icons indicate the phone type set on the device.

: Cellular phone

: Household phone

: Office

: General

: Other than above

• You can control the following types of iPod/iPhone:
(A) Connected with the USB cable:

(for

KW-AVX726/KW-AVX725/KW-AVX724

– iPod with video (5th Generation) *
– iPod classic *
– iPod nano *
– iPod nano (2nd Generation) *
– iPod nano (3rd Generation) *
– iPod nano (4th Generation) *
– iPod Touch *
– iPod Touch (2nd Generation) *
– iPhone/iPhone 3G *

1, *2

2, *3

2

1, *2

1, *2

1, *2

1, *2

1, *2

1, *2, *3

)

(B) Connected with the interface adapter:
– iPod with Click Wheel (4th Generation)
– iPod mini
– iPod photo
– iPod with video (5th Generation)
– iPod classic
– iPod nano
– iPod nano (2nd Generation)
– iPod nano (3rd Generation)
– iPod nano (4th Generation) *

4

*1 To watch the video with its audio, connect the iPod/

iPhone using USB Audio and Video cable (KS-U30, not
supplied).

*2 “iPod MODE” is available, 39.
*3 To listen to the sound in “iPod MODE,” connect

the iPod/iPhone using USB Audio and Video cable
(KS-U30, not supplied).

*4 It is not possible to charge the battery through this

unit.

CD changer

• If you select a folder, which does not include any
music files, on the list (
Select another folder including music files.

22), you will hear a beep.

• If the iPod does not play correctly, update your iPod
software to the latest version. For details about
updating your iPod, visit <http://www.apple.com>.

• When you turn on this unit, the iPod is charged
through the unit.

• The text information may not be displayed correctly.

Continued on the next page

47REFERENCES

• The text information scrolls on the monitor. This
unit can display up to 40 characters when using the
interface adapter and up to 128 characters when
using the USB 2.0 cable or USB Audio and Video
cable, KS-U30.

Notice:

When operating an iPod/iPhone, some operations
may not be performed correctly or as intended. In
this case, visit the following JVC web site:
<http://www.jvc.co.jp/english/car/> (English
website only)

For the USB connection:

When <iPod Artwork> is set to <On>:
Do not press any keys during the first 5 seconds
or more of playing back any track containing an
Artwork*. It takes 5 seconds or more to display
an Artwork and no operations are available while
loading it.

* The picture displayed on the iPod’s/iPhone’s screen

while playing back a track.

Characters you can enter for titles

In addition to the roman alphabet (A – Z, a – z), you
can use the following characters to assign titles. (

19)

• When <Руccĸий> is selected for <Language>.

( 13)

Upper and lower cases

Numbers and symbols

• When any language other than <Руccĸий> is
selected for <Language>. (

13)

Menu settings

• If you change the <Amplifier Gain> setting from
<High> to <Low> while the volume level is set
higher than “30,” the unit automatically changes the
volume level to “VOL 30.”

• After you change any of <Menu Language/Audio
Language/Subtitle> settings, turn off then on the
power, and re-insert the disc (or insert another disc)
so that your setting takes effect.

• When you select <16:9> for a picture whose aspect
ratio is 4:3, the picture slightly changes due to the
process for converting the picture width.

• Even if <4:3PS> is selected, the screen size may
become <4:3LB> for some discs.

JVC bears no responsibility for any loss of data
in an iPod/iPhone and/or USB mass storage
class device while using this unit.

Upper and lower cases

Numbers and symbols

48

Sound signals emitted through the rear terminals

Through the analog terminals (Speaker out/LINE OUT)

2-channel signal is emitted. When playing multi-channel encoded disc, multi-channel signals are downmixed.

• DTS sound cannot be reproduced.

Through the DIGITAL OUT terminal

Digital signals (Linear PCM, Dolby Digital, MPEG Audio) are emitted.

• DTS sound cannot be emitted.

• To reproduce the multi-channel sounds such as Dolby Digital and MPEG Audio, connect an amplifier or a decoder

compatible with these multi-channel sources to this terminal, and set <D. Audio Output> correctly. ( 14)

<D. Audio Output>

Playback disc

48 kHz, 16/20/24 bits Linear PCM 48 kHz, 16 bits stereo Linear PCM*

96 kHz, Linear PCM 48 kHz, 16 bits stereo Linear PCM

DVD

with Dolby Digital Dolby Digital bitstream

with MPEG Audio MPEG bitstream 48 kHz, 16 bits stereo Linear PCM

Audio CD, Video CD

DivX/
MPEG

MP3/WMA 32/44.1/48 kHz, 16 bits Linear PCM
WAV 44.1 kHz, 16 bits Linear PCM

* Digital signals may be emitted at 20 or 24 bits (at their original bit rate) through the DIGITAL OUT terminal if the discs

with Dolby Digital Dolby Digital bitstream

with MPEG Audio 32/44.1/48 kHz, 16 bits Linear PCM

are not copy-protected.

<Stream> <Dolby D> <PCM>

44.1 kHz, 16 bits stereo Linear PCM /
48 kHz, 16 bits stereo Linear PCM

Output signals

48 kHz, 16 bits stereo

Linear PCM

48 kHz, 16 bits stereo

Linear PCM

Continued on the next page

49REFERENCES

Language codes (for DVD/DivX language selection)

Code

Language Code Language Code Language Code Language Code Language

AA Afar FA Persian KK Kazakh NO Norwegian ST Sesotho
AB Abkhazian FI Finnish KL Greenlandic OC Occitan SU Sundanese
AF Afrikaans FJ Fiji KM Cambodian OM (Afan) Oromo SW Swahili
AM Ameharic FO Faroese KN Kannada OR Oriya TA Tamil
AR Arabic FY Frisian KO Korean (KOR) PA Panjabi TE Telugu
AS Assamese GA Irish KS Kashmiri PL Polish TG Tajik
AY Aymara GD Scots Gaelic KU Kurdish PS Pashto, Pushto TH Thai
AZ Azerbaijani GL Galician KY Kirghiz QU Quechua TI Tigrinya
BA Bashkir GN Guarani LA Latin RM

Rhaeto-Romance

TK Turkmen
BE Byelorussian GU Gujarati LN Lingala RN Kirundi TL Tagalog
BG Bulgarian HA Hausa LO Laothian RO Rumanian TN Setswana
BH Bihari HI Hindi LT Lithuanian RW Kinyarwanda TO Tonga
BI Bislama HR Croatian LV
BN

Bengali, Bangla

HU Hungarian MG Malagasy SD Sindhi TS Tsonga

Latvian, Lettish

SA Sanskrit TR Turkish

BO Tibetan HY Armenian MI Maori SG Sangho TT Tatar
BR Breton IA Interlingua MK Macedonian SH Serbo-Croatian TW Twi
CA Catalan IE Interlingue ML Malayalam SI Singhalese UK Ukrainian
CO Corsican IK Inupiak MN Mongolian SK Slovak UR Urdu
CS Czech IN Indonesian MO Moldavian SL Slovenian UZ Uzbek
CY Welsh IS Icelandic MR Marathi SM Samoan VI Vietnamese
DZ Bhutani IW Hebrew MS Malay (MAY) SN Shona VO Volapuk
EL Greek JA Japanese MT Maltese SO Somali WO Wolof
EO Esperanto JI Yiddish MY Burmese SQ Albanian XH Xhosa
ET Estonian JW Javanese NA Nauru SR Serbian YO Yoruba
EU Basque KA Georgian NE Nepali SS Siswati ZU Zulu

Display information

• Available display information varies among the playback sources.

Ex.: When the playback source is a DVD video disc

SOURCE

DVD

Playback picture screen
(only for video sources)

1

When the source is “

*

While MP3/WMA file is played, “Jacket picture” is shown if the file has the tag data including “Jacket picture.”

*2 When <Navigation> is selected for <AV Input>. ( 15)

50

Source information screen Playback picture and source

iPod

,” the Artwork of the song is shown if the song has an Artwork data. ( 14)

Each time you press DISP, the display changes to show the various information.

SOURCE

DVD

FLAT

CHAP. RPT

3:00

AM

FLAT

AM

3:00

information screen

Navigation screen *

1

*

2

• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby
Laboratories.

• “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation registered in the US, Japan and other
countries.

• DivX® is a registered trademark of DivX, Inc., and is used under license.

• Plays DivX® video:

• ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is an official DivX Certified or DivX Ultra
Certified device that plays DivX video.

• ABOUT DIVX VIDEO-ON-DEMAND: This DivX® Certified device must be registered in order to play DivX Video-on­Demand (VOD) content. First generate the DivX VOD registration code for your device and submit it during the
registration process. [Important: DivX VOD content is protected by a DivX DRM (Digital Rights Management)
system that restricts playback to registered DivX Certified devices. If you try to play DivX VOD content not
authorized for your device, the message “Authorization Error” will be displayed and your content will not play.]
Learn more at www.divx.com/vod.

• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.

• The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Victor
Company of Japan, Limited (JVC) is under license. Other trademarks and trade names are those of their respective
owners.

• “Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod and has been
certified by the developer to meet Apple performance standards.

• “Works with iPhone” means that an electronic accessory has been designed to connect specifically to iPhone and
has been certified by the developer to meet Apple performance standards.

• Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.

• iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

• iPhone is a trademark of Apple Inc.

• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended
for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or
disassembly is prohibited.

51REFERENCES

Troubleshooting

What appears to be trouble is not always serious. Check the following points before calling a service center.

• For operations with the external components, refer also to the instructions supplied with the adapters used for the
connections (as well as the instructions supplied with the external components).

• Messages (enclosed in “ ”) in the tables below are shown in the language selected on <Language>. ( 13)
Messages described here are in the language of this manual.

Symptom Remedy/Cause

• No sound comes out of the speakers. • Adjust the volume to the optimum level.

• Check the cords and connections.

• The screen is not clear and legible. Sunshine from the windshield may cause this symptom.

Adjust <Bright>. (

12)

• “Position Error Push Open Key”
appears on the screen.

• “Mecha Error Push Reset” appears on
the screen, and the panel does not
move.

• “No Signal” appears. • Change the source.

General

• The buttons on the monitor panel do
not work.

• The unit does not work at all.

• The touch panel does not respond
properly.

• <Illumination> function does not
work properly.

The monitor panel angle has been forcibly adjusted, or its
adjustment has been interrupted while opening or closing.
Press [OPEN/TILT].

Reset the unit. ( 3)

• Start the playback on the external component connected to
VIDEO IN jack.

• Check the cords and connections.

• Signal input is too weak.

When the monitor panel is open, only VOL +/– and
work. The other buttons do not function.

Reset the unit. (

• Keep your hands and the touch panel clean and dry.

• Eliminate static electricity and do not place magnetic items
near the unit.

• Leave the unit until the temperature becomes stable in the
car.

• A rubber mat on the floor may cause this symptom. In this
case, do not use the rubber mat.

3)

• SSM automatic presetting does not
work.

TUNER

• Static noise while listening to the
radio.

52

Store stations manually. (

Connect the antenna firmly.

21)

Symptom Remedy/Cause

• Disc can be neither recognized nor

Eject the disc forcibly. (

played back.

• Disc cannot be ejected.

• Recordable/Rewritable discs cannot
be played back.

• Tracks on the Recordable/Rewritable

Unlock the disc. (

• Insert a finalized disc.

• Finalize the discs with the component which you used for
recording.

27)

discs cannot be skipped.

• Playback does not start. • Insert the disc correctly again.

• The format of files is not supported by the unit.

• The playback picture is not clear and

Adjust items in <Picture Adjust> menu. (

legible.

• Sound and pictures are sometimes
interrupted or distorted.

• Stop playback while driving on rough roads.

• Change the disc.

Disc in general

• No playback picture is shown and
“Parking Brake” appears on the

Parking brake lead is not connected properly.

See Installation/Connection Manual.
screen, even when the parking brake
is engaged.

3)

12)

• No picture appears on the external
monitor.

• “Eject Error” or “Loading Error”

• Connect the video cord correctly.

• Select the correct input on the external monitor.

Change the source by pressing SOURCE.

appears on the screen.

• “Region code error” appears on the

Region code is not correct. (

4)

screen when you insert a DVD Video.

• Disc cannot be played back. • Change the disc.

• Record the tracks using a compliant application on the
appropriate discs. ( 4)

• Add appropriate extension codes to the file names.

• Noise is generated. The track played back is not a playable file format. Skip to
another file.

• Tracks are not played back as you

have intended them to play.

Playback order may differ from the one played back using other
players.

• Elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how
the tracks are recorded.

• “Not Support” appears on the screen

DivX/MPEG1/MPEG2/MP3/WMA/WAV

and track skips.

The track is unplayable.

Continued on the next page

53REFERENCES

Symptom Remedy/Cause

)

• Noise is generated. The track played back is not a playable file format. Skip to another
file.

• Tracks cannot play back as you

have intended them to play.

• “Now Reading...” keeps flashing

on the screen.

• “Cannot play this device Check the

device” appears on the screen.

• Correct characters are not

KW-AVX726/KW-AVX725/KW-AVX724

displayed (e.g. album name).

• While playing a track, sound is

USB (for

sometimes interrupted.

• Bluetooth device does not detect

the unit.

• The unit does not detect the

Bluetooth device.

Playback order may differ from the one played back using other
players.

• Readout time varies depending on the USB device.

• Do not use too many hierarchy and folders.

• Turn off the power then on again.

No tracks are stored. Copy tracks to the USB device.

For available characters,

48.

The tracks are not properly copied into the USB device. Copy tracks
again, and try again.

This unit can be connected with one Bluetooth cellular phone and
one Bluetooth audio player at a time.
While connected to a device, this unit cannot be detected from
another device. Disconnect currently connected device and search
again.

• Check the Bluetooth setting of the device.

• Search from the Bluetooth device.

• The unit does not make pairing

with the Bluetooth device.

• Enter the same PIN code for both the unit and target device. If

the PIN code of the device is not indicated on its instructions,
try “0000” or “1234.”

• Select the device name from <Special Device>, then try to

connect again. (

25)

• Echo or noise occurs. Adjust the microphone unit (supplied with Bluetooth Adapter)
position.

Bluetooth

• Phone sound quality is poor. • Reduce the distance between the unit and the Bluetooth

cellular phone.

• Move the car to place where you can get a better signal reception.

• The sound is interrupted or

skipped while using a Bluetooth
audio player.

• Reduce the distance between the unit and the Bluetooth audio

player.

• Disconnect the device connected for “

Bluetooth PHONE

• Turn off, then turn on the unit.

• (When the sound is not yet restored,) connect the player again.

• “NEW DEVICE” cannot be selected

Bluetooth AUDIO

for “

.”

Bluetooth audio player is already connected. To select “NEW
DEVICE,” disconnect it. ( 25)

.”

• The connected audio player

cannot be controlled.

54

Check whether the connected audio player supports AVRCP (Audio
Video Remote Control Profile).

Symptom Remedy/Cause

• “No Disc” appears on the screen. Insert a disc into the magazine.

• “No Magazine” appears on the screen. Insert the magazine.

• “Cannot play this disc Check the disc” appears
on the screen.

Current disc does not include playable files. Replace
the disc with one including playable files.

• “Reset08” appears on the screen. Connect this unit and the CD changer correctly and

CD changer

press the reset button of the CD changer.

• “Reset01” – “Reset07” appears on the screen. Press the reset button of the CD changer.

• The CD changer does not work at all.

• The iPod/iPhone does not turn on or does not
work.

Reset the unit. (

3)

• Check the connecting cable and its connection.

• Update the firmware version of the iPod/iPhone.

• Charge the battery of the iPod/iPhone.

• Check whether “HEAD MODE” or “iPod MODE” is
correctly selected. ( 39)

• Reset the iPod/iPhone.

• Sound is distorted. Deactivate the equalizer either on this unit or the
iPod/iPhone.

• “Disconnect” appears on the screen. Check the connection.

• Playback stops. The headphones are disconnected during playback.
Restart playback.

• “Cannot play this device Check the device”

No tracks are stored. Import tracks to the iPod/iPhone.

appears on the screen.

iPod/iPhone

• No operations are available when playing back

Operate the unit after the Artwork is loaded. (

a track containing Artwork.

• “Reset01” – “Reset07” appears on the screen. Disconnect the adapter from both this unit and iPod.
Then, connect them again.

• “Reset08” appears on the screen. Check the connection between the adapter and this
unit.

• The iPod’s controls do not work after

Reset the iPod.

disconnecting from this unit.

• “Restricted Device” appears on the screen. Check whether the connected iPod is compatible with
this unit. (

47)

• No picture appears on the screen. • Turn on the video component if it is not on.

• Connect the video component correctly.

AV-IN

• Playback picture is not clear and legible.

Adjust items in <Picture Adjust> menu. (

14)

12)

55REFERENCES

Specifications

AMPLIFIER

Maximum Power Output: Front/Rear: 50 W per channel

Continuous Power Output
(RMS):

Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)

Equalizer Control Range: Frequencies: 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz,

Signal-to-Noise Ratio: 70 dB

Audio Output Level:

• LINE OUT (REAR)

• SUBWOOFER (for

KW-AVX725/KW-AVX724

Color System: NTSC/PAL

Video Output (composite): 1 Vp-p/75 Ω

KW-AVX726/

Front/Rear: 20 W per channel into 4 Ω, 40 Hz to

20 000 Hz at no more than 1.0% total
harmonic distortion

15 kHz

Level: ±10 dB

Line-Out Level/
Impedance:

)

Output Impedance: 1 kΩ

2.5 V/20 kΩ load (full scale)

Other Terminals: Input: • LINE IN, VIDEO IN, Antenna input

• USB input (for

KW-AVX724

Output: VIDEO OUT

Others: CD changer, DIGITAL OUT (optical), POSITION

OUT

KW-AVX726/KW-AVX725/

)

56

FM/AM TUNER

Frequency Range: FM: 87.5 MHz to 108.0 MHz

AM: 531 kHz to 1 602 kHz

FM Tuner: Usable Sensitivity: 9.3 dBf (0.8 μV/75 Ω)

50 dB Quieting Sensitivity: 16.3 dBf (1.8 μV/75 Ω)

Alternate Channel Selectivity (400 kHz): 65 dB

Frequency Response: 40 Hz to 15 000 Hz

Stereo Separation: 40 dB

AM Tuner: Sensitivity/Selectivity: 20 μV/40 dB

DVD/CD

Signal Detection System: Non-contact optical pickup (semiconductor laser)

Frequency Response: DVD, fs=48 kHz/96 kHz: 16 Hz to 22 000 Hz

VCD/CD: 16 Hz to 20 000 Hz

Dynamic Range: 96 dB

Signal-to-Noise Ratio: 98 dB

Wow and Flutter: Less than measurable limit

USB (for

USB Standards: USB 2.0 Full Speed

Data Transfer Rate Full Speed: Maximum 12 Mbps

Compatible Device: Mass storage class

Compatible File System: FAT 32/16/12

Max. Current: DC 5 V

KW-AVX726/KW-AVX725/KW-AVX724

Low Speed: Maximum 1.5 Mbps

500 mA

)

Continued on the next page

57REFERENCES

MONITOR

Screen Size: 7 inch wide liquid crystal display

Number of Pixel: 336 960 pixels: 480 × 3 (horizontal) × 234 (vertical)

Drive Method: TFT (Thin Film Transistor) active matrix format

Color System: NTSC/PAL

Aspect Ratio: 16:9 (wide)

GENERAL

Power Requirement: Operating Voltage: DC 14.4 V (11 V to 16 V allowance)

Grounding System: Negative ground

Allowable Storage Temperature: –10°C to +60°C

Allowable Operating Temperature: 0°C to +40°C

Dimensions (W × H × D): Installation Size (approx.): 178 mm × 100 mm × 160 mm

Panel Size (approx.): 184 mm × 112 mm × 23 mm

Mass (approx.):

Design and specifications are subject to change without notice.

Required space for installation and the monitor ejection

Dashboard

20

4

CAUTION: When ejecting the monitor, leave an
open space for the monitor to come out. If you
do not, the monitor may obstruct the steering
wheel and gearshift lever operations, and this

100

may result in a traffic accident.

Unit: mm

2.7 kg

160 91.3

58

Operation index

General

Reset ..................................................................3, 5

Volume .............................................................. 5, 6

AV Menu ........................................................ 5, 11

Source ................................................................ 5, 6

Short Cut .............................................................. 7

RM-RK252 ...................................... 7, 8, 9, 30, 31

Clock .............................................................10, 13

Display demonstration ...........................10, 12

Tuner

Listen to the radio (FM/AM) ...............5, 9, 26

Auto/manual search .................................. 8, 26

Select preset station ........................... 8, 21, 26

Store station

(automatically/manually) ................... 19, 21

Improve FM reception ...................................19

Assign title .........................................................19

Disc

Open/close ................................................... 6, 27

Eject .................................................................... 3, 6

Lock/unlock disc ..............................................27

Playable disc type ............................................. 4

Display information ........................................28

Repeat/random play ......................................20

Select track/folder ........................ 8, 21, 30, 31

Select title/program/playlist .................. 8, 30

Start/stop/pause/resume

playback .............................................. 9, 30, 31

Search/skip ........................................8, 9, 30, 31

OSD ...............................................................32, 33

PBC playback ............................................... 9, 30

USB

Attach/detach ...................................................34

Start/pause playback ..............................13, 34

Repeat/random play ......................................20

Bluetooth

Connect/disconnect/delete ..........24, 25, 35

Make a call ..................................................22, 23

Answer/end call ................................... 9, 25, 36

Read SMS .....................................................23, 37

Microphone volume .......................................25

Preset phone number ....................................37

CD changer

Start playback ............................................22, 38

Repeat/random play ......................................20

iPod

Connect .......................................................39, 40

Start/pause playback ................................ 9, 39

Head Mode/iPod Mode ............................ 5, 39

Repeat/random play ......................................20

Audiobooks ....................................................... 21

Select track ..................................... 8, 22, 39, 40

External component

AV-INPUT ............................................................ 41

EXT-INPUT .......................................................... 42

59REFERENCES

Having TROUBLE with operation?

Please reset your unit

Refer to page of How to reset your unit

KW-AVX726/KW-AVX725/
KW-AVX626/KW-AVX625

Installation/Connection Manual

GET0605-007A

[U/UT]

ENGLISH

This unit is designed to operate on 12 V DC, NEGATIVE ground elec trical systems. If your vehicle does
not have this system, a voltage inverter is required, which can be purchased at JVC car audio dealers.

安裝/連接手冊

0109DTSMDTJEIN

© 2009 Victor Company of Japan, Limited

EN, CT

中文

本機僅可使用直流 12 V 、負極接地的電源系統。如果您的車輛沒有這一電源系統，則需要一個電
壓變換器，可以在

JVC 汽車音響分銷商處買到。.

WARNINGS

• DO NOT install any unit or wire any cable in a location where;
– it may obstruct the steering wheel and gearshift lever operations, as this may result in a traffic accident.
– it may obstruct the operation of safety devices such as air bags, as this may result in a fatal accident.
– it may obstruct visibility.

• DO NOT operate any unit while manipulating the steering wheel, as this may result in a traffic accident.

• The driver must not watch the monitor while driving. It may lead to carelessness and cause an accident.

• If you need to operate the unit while driving, be sure to look around carefully or you may be involved in
a traffic accident.

• If the parking brake is not engaged, “Parking Brake” appears on the monitor, and no playback picture
will be shown.
– This warning appears only when the parking brake wire is connected to the parking brake system built

in the car.

To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all
electrical connections before installing the unit.

• Be sure to gr ound this unit to the car’s chass is again after installat ion.

Notes on elec trical connections :

• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio
dealer.

• It is recommended to connect speakers with maximum power of more than 50 W (both at the rear and
at the front, with an impedance of 4  to 8 Ω).

If the maximum power is less than 50 W, change <Amplifier Gain> setting to prevent the speakers from

being damaged (see page 18 of the INSTRUCTIONS).

• To prevent short circuits, cover the terminals of the UNUSED leads with insulating tape.

• The heat sink becomes very hot after use. Be careful not to touch it when removing this unit.

Heat sink

散熱片

警告

• 切勿在以下位置安裝本機或連接電纜；
– 可能會妨礙操作方向盤和變速排檔桿的位置，否則可能引發交通事故。
– 可能會妨礙操作安全裝置，如安全氣袋等的位置，否則可能引發致命的交通事故。
– 可能會妨礙視野的位置。

•

切勿在操作方向盤的過程中操作本機，否則可能引發交通事故。

• 駕駛時，駕駛員切勿緊盯顯示器。這可能會導致疏忽並引發事故。

• 在駕駛過程中若需要操作本機，切記要密切注意前方，否則可能引發交通事故。

• 若手剎車末嚙合，“Parking Brake”字樣在顯示器上出現，且無法播放圖片。
– 僅當手剎車導線與汽車內置的手剎車系統相連接時此警告信息才會出現。

為防止短路，建議在安裝本機之前，拔開電池的負極，並把所有電路都連接好。

• 安裝完畢後務必將本機的地線重新接至車身。

進行電路連接時注意：

• 把保險絲更換為額定負荷值的保險絲。如果保險絲經常燒壞，請向 JVC 汽車音響分銷商詢問。

•

後置和前置揚聲器的最大輸入功率應大於
如果最大功率少於
書的第 18 頁

• 為防止電源短路，請用絕緣帶包住未使用電線的端子。

• 本機使用後，散熱片會很熱。因此，在移出本機時，小心不要觸摸散熱片。

50 W

，請調校

)

。

50 W

<Amplifier Gain>

，其阻抗為

4  – 8 。

設定值，以防止揚聲器損壞。(參閱使用說明

Parts list for installation and connection

If any item is missing, consult your JVC car audio dealer immediately.

Main unit

主機

Flat head screws (M5 × 8 mm)
平頭螺絲（M5 × 8 mm）

Power cord

電路連接用的配線束

Round head screws (M5 × 8 mm)
圓頭螺絲（M5 × 8 mm）

用於安裝和連接的零件清單

若發現缺少任何一件零件，請即刻聯絡您的 JVC 汽車音響分銷商。

Plate for use with a Nissan car

用於日產汽車的框

Remote controller

遙控器

1

Batteries

電池

Crimp connector

夾子接頭

INSTALLATION (IN-DASH MOUNTING)

The following illustration shows a typical installation. However, you should make adjustments
corresponding to your specific car. If you have any questions or require information regarding installation
kits, consult your JVC car audio dealer or a company supplying kits.

• If you are not sure how to install this unit correctly, have it installed by a qualified technician.

安裝（裝設、固定在儀表板內）

下面的圖解表示了典型的安裝程序。但是在實際安裝時，您應該根據您的汽車作適當的調整。如果
您有問題，或需要有關配套元件的資料，請向 JVC 汽車音響分銷商或配套元件供應公司詢問。

• 如果您不能確定如何正確地安裝本機，應請合格的技術人員來安裝。

Before installing the unit

• When mounting the unit, be sure to use the screws provided, as instructed. If other screws are used,
parts could become loose or damaged.

• When tightening screws or bolts, be careful not to pinch any connection cord.

• Make sure not to block the fan on the rear to maintain proper ventilation when installing the unit.

1 Remove the audio system originally installed in the car, together with its mounting brackets.

Note: Be sure to keep all the screws and parts removed from your car for future use.

2 Attach the mounting brackets (removed from the car), to this unit (see below).
3 Do the required electrical connections.

• See pages 3 – 6.

4 Install this unit using the screws removed in step 1.

The following example is for installation in a Toyota car. For more details, consult your JVC car audio
dealer.

Mounting bracket removed from the car

從汽車拆卸的裝配架

Mounting bracket removed from the car

從汽車拆卸的裝配架

安裝本機之前

• 當裝上本機時，必須按照指示使用配備的螺絲釘。如果使用其它的螺絲釘，相關零件可能會鬆
脫或損壞。

• 當鎖緊螺絲釘或螺栓時，切記不要壓擠到任何連接電線。

• 當安裝上後，切記不要阻擋到後面板的風扇以維持適當的通風。

1 拆卸原本安裝在汽車內的音響系統，以及其裝配架。

注意：請務必保留所有從您汽車拆卸的螺絲和零件做日後使用。

2 將 (從汽車拆卸的) 裝配架安上本機 (參閱下圖)。
3 執行必要的電路連接。

• 參閱第 3 至 6 頁。

4 使用在步驟 1 拆卸的螺絲安裝本機。

以下以豐田（Toyota）汽車安裝為例。請聯絡您的 JVC 汽車音響分銷商有關更多細節。

Supplied screws

配備螺絲

Supplied screws

配備螺絲

Select the appropriate type fitting to your audio
system space.

選擇適合您的音響系統安裝空間的型號。

Note : When installing the unit on the mounting bracket, make sure to use the supplied screws

(M5 × 8 mm). If longer screws are used, they could damage the unit.

注意： 安裝本機進裝配架時，請務必使用配備的螺絲（M5 × 8 mm）。若使用比較長的螺絲，

有關螺絲可能會損壞本機。.

Required space for installation and the monitor ejection

安裝和顯示器退出所需的空間

20

4

Dashboard

儀表盤

Screws removed from the car in step
在步驟 1從汽車拆卸的螺絲

1

If necessary, restore the protruding tabs.

若有必要，請重新裝上凸緣。

When installing the unit in a Nissan car

當安裝本機於日產汽車時

Plate for use with a Nissan car

用於日產汽車的框

Install the unit at an angle of less than 30˚, taking it into account that the monitor would eject
when in use.

將本機安裝在少於 30˚ 的角度，您必須考慮到屏幕可以在使用時退出。

160 91.3

100

Unit: mm
單位：mm（毫米）

30˚

2

ELECTRICAL CONNECTIONS

Typical connections / 典型的接線方法

Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious

damage to this unit.
The leads of the power cord and those of the connector from the car body may be different in color.

1 Connect the colored leads of the power cord in the order specified in the illustration below.
2 Connect the antenna cord.
3 Finally connect the wiring harness to the unit.

Antenna terminal

天線端子

DIGITAL OUT

（see diagram

Rear ground terminal

本機後背接地端子

/ 參閱圖表 ）

This terminal is used for controlling an external device by using the touch panel of this unit. This unit outputs the positional
information detected on the touch panel through the POSITION OUT terminal. Refer to the instruction manual of the external
device for details. JVC does not guarantee proper operations for the external device connected to the POSITION OUT terminal.

該端子使用本機的觸摸屏來控制外接裝置。本機從 POSITION OUT 端子輸出位置訊息，並在觸摸屏上被檢測到。關於
詳情，參閱外接裝置的使用手冊。JVC 不保證連接至 POSITION OUT 端子的外接裝置是否能正常操作。

Position data output / 位置數據輸出

（see diagram

/ 參閱圖表 ）

SUBWOOFER—Only for KW-AVX726/KW-AVX725 / 僅對應 KW-AVX726/KW-AVX725

（see diagram

Fan

風扇

電路連接

接線前：仔細檢查汽車內的線路。不正確的接線會導致本機嚴重損壞。

電力線的引線和車身的連接器引線在顏色上可能有所不同。

1 依照下圖所示之次序連接電源線的顏色導線。
2 將天線的電線連接起來。
3 最後，把配線束的插頭插在本機上。

/ 參閱圖表 ）

VIDEO IN

（see diagram
參閱圖表 ）

LINE IN

（see diagram
參閱圖表

REAR OUT

（see diagram
參閱圖表

VIDEO OUT

（see diagram
參閱圖表 ）

/

）

/

）

15 A fuse
15 A 保險絲

To external components
(see diagram

接至外接裝置
（參閱圖表 ）

)

/

/

Black

黑色

Yellow *2

2

黃色

*

Red

紅色

Blue

藍色

Blue with white stripe

藍色帶有白色條紋

Orange with white stripe

橙色帶有白色條紋

Brown

褐色

Light green

淺綠色

To metallic body or chassis of the car

接至金屬體或汽車底盤

To a live terminal in the fuse block connecting to the car battery (bypassing
the ignition switch) (constant 12 V)

接至保險絲單元內的帶電端子，保險絲單元與車裝電池相連接（用於
旁路點火開關）（恆定 12 V）

To an accessory terminal in the fuse block

接至保險絲單元內的附屬端子

To automatic antenna if any (250 mA max.)
接至自動天線（若有裝設）（最大 250 mA）

To the remote lead of other equipment (200 mA max.)
連接至其他裝置的遙控導線（最大 200 mA）

To car light control switch

連接至汽車車燈控制開關

To cellular phone system

連接至流動電話系統

To parking brake (see diagram

接至手剎車導線（參閱圖表

Crimp connector

夾子接頭

Ignition switch

點火開關

Fuse block

保險絲單元

)

）

White with black stripe

白色帶有黑色條紋

1

*

Not supplied for this unit.

2

*

Before checking the operation of this unit prior to installation, this lead must be connected, otherwise power

cannot be turned on.

White

白色

Left speaker (front)

左揚聲器

Gray with black stripe

(前置)

灰色帶有黑色條紋

Gray

灰色

Right speaker (front)
右揚聲器 (前置)

Green with black stripe

綠色帶有黑色條紋

1

*

不隨本機提供。

2

*

本機未安裝時，進行工作狀況檢查之前，必須把這導線接上，否則不能開啟電源。

Green

綠色

Left speaker (rear)
左揚聲器 (後置)

Purple with black stripe

紫色帶有黑色條紋

3

Purple

紫色

Right speaker (rear)
右揚聲器 (後置)

中文 ENGLISH

PRECAUTIONS on p ower supply and speaker conne ctions:

• DO NOT conne ct the speaker leads of the p ower cord to the car batter y; otherwise, the uni t
will be serious ly damaged.

• BEFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in
your car.

Connecting the parking brake lead / 連接至手剎車導線

A

Parking brake

手剎車

Parking brake switch (inside the car)

手剎車開關（位於車內）

Crimp connector

夾子接頭

電源和揚聲器接線注意事項：

• 切勿把揚聲器導線接頭接至電池，否則本機將會嚴重損壞。

• 在把揚聲器導線接頭接至揚聲器之前，檢查您汽車上的揚聲器線路。

Parking brake lead (light green)

手剎車導線（淺綠色）

To metallic body or chassis of the car

接至金屬體或汽車底盤

B

Connecting the reverse gear signal lead (for rear view camera) / 連接反向變速器信號導線（對應後視照相機）

Locate the reverse lamp lead in the trunk.

找出後車箱的倒車信號燈導線。

1

*

1

To car battery

連接至汽車電池

Reverse lamp lead

倒車信號燈導線

1

*

不隨本機提供。

Crimp connector *

1

夾子接頭 *

1

To reverse lamp

連接至倒車信號燈

Reverse lamps

倒車信號燈

Purple with white stripe

紫色帶有白色條紋

1

*

Not supplied for this unit.

Extension lead
延長線 *

4

Connecting the external amplifier and/or subwoofer / 連接至外接功率放大器和 / 或重低音揚聲器

C

You can connect an amplifier to upgrade your car stereo system.

• Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it
can be controlled through this unit.

• Disconnect the speakers from this unit, connect them to the amplifier. Leave the speaker
leads of this unit unused.

2

Remote lead *

2

遙控導線 *

您可以連接功率放大器以提昇尊車的音響系統。

•

將遙控導線（藍色帶有白色條紋）和其他裝置上的遙控導線連接起來，以便可以從本機進行
控。

• 將揚聲器和本機拔開，再接上功率放大器。將本機的揚聲器接線放置不用。

Y-connector *
Y-型連接導線 *

遙

2

2

Rear speakers

後置揚聲器

JVC Amplifier

JVC

功率放大器

Connecting the external components / 連接其他外接裝置

D

AV amplifier or decoder
AV

功率放大器或譯碼器

Digital optical cable *

2

數位光纜 *

External component

外接裝置

Remote lead (blue with white stripe)

遙控導線（藍色帶有白色條紋）

2

To the remote lead of other equipment or automatic antenna if any

連接至其他裝置上的遙控導線或自動天線（若有裝設）

Only for KW-AVX726/KW-AVX725 / 僅對應 KW-AVX726/KW-AVX725

JVC Amplifier

JVC 功率放大器

Front speakers

前置揚聲器

2

Video cord *

2

影像線 *

External monitor

外接顯示器

Subwoofer

重低音揚聲器

Only for KW-AVX726/KW-AVX725 / 僅對應 KW-AVX726/KW-AVX725

USB cable (approx. 1.2 m)
USB 電纜（大約 1.2 m）

You cannot connect a computer to the USB ( ) terminal of the unit.
您無法將電腦連接至本機的 USB（

2

*

Not supplied for this unit.

3

*

Signal cord (not supplied for this unit).

4

*

Audio cord (not supplied for this unit).

5

*

Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with paint

(if coated with paint, remove the paint before attaching the wire). Failure to do so may cause damage to the
unit.

6

*

When using the cable, make sure <iPod (Off)> is selected for <AV Input> (see page 15 of the INSTRUCTIONS).

）端子。

USB device
USB 裝置

2

Video cord

*

2

影像線*

Rear view camera

Connecting the iPod/iPhone to the USB terminal / 連接 iPod/iPhone 至 USB 端子Connecting the USB devices / 連接 USB 裝置

You can connect the iPod/iPhone to the USB terminal using the following cables:

• To listen to the music: USB 2.0 cable (supplied with the iPod/iPhone)

• To watch the video: USB Audio and Video cable for iPod/iPhone—KS-U30 (not supplied) *
您可以使用下列電纜連接 iPod/iPhone 至 USB 端子：

• 想要聆聽音樂： USB 2.0 電纜（隨 iPod/iPhone 附帶）

• 想要觀看視訊：iPod/iPhone 的 USB 聲音和影像電纜—KS-U30（另購）*

USB 2.0 cable
USB 2.0 電纜

iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

是 Apple Inc.（蘋果公司）在美國及其他國家註冊的商標。

iPod

2

*

不隨本機提供。

3

*

信號導線（不隨本機提供）。

4

*

聲音導線（不隨本機提供）。

5

*

將地線與金屬車體或者汽車底盤緊密連接，連接處應該沒有被油漆覆蓋（如果已塗上油漆，在連接電線

前，將油漆刮去）。如果不這樣做，可能會損壞本機。

6

*

當使用電纜時，確定為

<AV Input> 選擇 <iPod (Off)>

5

KS-U30

（參閱使用說明書的第

6

Apple iPod/iPhone
Apple iPod/iPhone

Apple iPod/iPhone
Apple iPod/iPhone

iPhone is a trademark of Apple Inc.
iPhone 是 Apple Inc.（蘋果公司）的商標。

KV-CM1*

後視照相機

6

15

2

頁）。

E

Connecting the external components to the CD changer jack / 連接外接裝置至 CD 換碟器插孔

When connecting the external components, refer also to the manuals supplied for the components and
adapter.

CAUTION:

Before connecting the external components, make sure that the unit is turned off.

You can connect the following JVC components to the CD changer jack.

JVC component Model name

CD changer (CD-CH) CH-X1500, etc.

You can also connect the following components through the various JVC adapters.

• Connection cords may need to be purchased separately.

連接外接裝置時，另請參閱裝置及轉換器之使用手冊。

小心：

連接外接裝置之前，請確定關閉本機。

您可以將以下 JVC 裝置連接到 CD 換碟器插孔。

JVC 裝置

CD 換碟器（CD-CH） CH-X1500，等

您也可透過各種 JVC 轉換器連接以下裝置。

• 連接線可能需要單獨購置。

型號名稱

Component Adapter Model name

Bluetooth device Bluetooth adapter KS-BTA200

iPod Interface adapter for iPod KS-PD100

Portable audio player with line output jacks Line input adapter KS-U57

Portable audio player with 3.5 mm stereo mini jack AUX input adapter KS-U58

When connecting more than one component (maximum: two), it is recommended that you connect the
components in series as explained below.

When connecting two components in series

當串聯兩個裝置時

7

*

CD changer jack / CD 換碟器插孔

A KS-BTA200

7

B*

CD -CH / KS-PD100 / KS- U57 / KS-U58

7

*

To use these components, set the external input setting correctly (see page 16 of the INSTRUCTIONS). *7 要使用這些裝置，請正確設定外接輸入（參閱使用說明書的第 16 頁）。

裝置 轉換器 型號名稱

藍牙裝置 藍牙轉換器

iPod

帶線性輸出插孔的手提式音頻播放器 線性輸入轉換器

帶 3.5 mm 立體聲迷你型插孔的手提式音頻播放器 AUX 輸入轉換器

當連接多個裝置時（最多︰2），建議您依下方所示串聯裝置。

To disconnect the con nector / 拆開連接器

Hold the connector top tightly (

抓緊連接器上部（

iPod 介面轉換器

1 ), then pull it out ( 2 ).

1），然後將之拉出（ 2 ）。

KS-BTA200

KS-PD100

KS-U57

KS-U58

TROUBLESHOOTING

• The fuse blows.

* Are the red and black leads connected correctly?

• Power cannot be turned on.

* Is the yellow lead connected?

• No sound from the speakers.

* Is the speaker output lead short-circuited?

• Sound is distorted.

* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?

• Noise interfere with sounds.

* Is the rear ground terminal connected to the car’s chassis using shorter and thicker cords?

• This unit becomes hot.

* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?

• This unit does not work at all.

* Have you reset your unit?

故障排除

• 保險絲燒斷。

* 檢查紅色導線接頭和黑色導線接頭是否接觸正確？

• 電源不能接通。

* 檢查黃色導線接頭是否接上？

• 揚聲器沒有聲訊。

* 檢查揚聲器輸出導線接頭是否短路？

• 聲訊失真。

* 檢查揚聲器輸出端子是否接地？
* 檢查揚聲器的左（L）， 右（R）端子的負極“–”是否共同接地？

• 噪音干擾音響。

* 後接地端子與車身是否使用較短和較厚的電線連接？

• 本機發熱。

* 檢查揚聲器輸出端子是否接地？
* 檢查揚聲器的左（L）， 右（R）端子的負極“–”是否共同接地？

• 本機完全不能正確操作。

* 您有沒有重置本機？

6

1

KW-AVX726/KW-AVX725/
KW-AVX626/KW-AVX625

Installation/Connection Manual
Manual Pemasangan/Penyambungan

Daftar bagian-bagian untuk pemasangan dan penyambungan

Jika a da item yang hilang, segera hubungi dealer audio mobil JVC anda.

Parts list for installation and connection

If any item is missing, consult your JVC car audio dealer immediately.

INDONESIA

Unit in i didesain untuk beroperasi hanya pada sistem listrik 12 V DC yan g d i-ground NEGATIVE. Jika
kendaraan Anda tidak dilengkapi sistem ini, maka diperlukan alat pembalik tegangan yang dapat dibeli di
penyalur-penyalur audio mobil JVC.

PERINGATAN

• JANGAN menginstal unit apa pun atau menjalin kabel apa pun pada lokasi di mana;
– unit dapat menghalangi pengoperasian roda kemudi dan tuas persneling, karena dapat mengakibatkan

kecelakaan lalu lintas.

– unit dapat menghalangi pengoperasian alat keselamatan seperti kantung udara, karena hal ini dapat

mengakibatkan kecelakaan yang fatal.

– ini dapat menghalangi pandangan.

• JANGAN mengoperasikan unit apa pun sewaktu mengendalikan roda kemudi, karena hal ini dapat
mengakibatkan kecelakaan lalu lintas.

• Pengemudi tidak boleh menonton ke monitor sewaktu mengemudi. Ini dapat mengakibatkan kecerobohan
dan menyebabkan kecelakaan.

• Jika Anda harus mengoperasikan unit selagi mengemudi, pastikan Anda melihat ke sekeliling dengan
cermat, karena kalau tidak, Anda bisa terlibat kecelakaan lalu lintas.

• Jika rem parkir tidak bekerja, terlihat tulisan “Parking Brake” muncul pada monitor dan tidak ada
pemutaran gambar yang akan ditunjukkan.
– Peringatan ini hanya muncul apabila kabel rem parkir terhubung ke sistem rem parkir yang terpasang

dalam mobil.

Untuk menceg ah hubungan pendek, kami menyarankan anda memutuskan sambungan terminal negatif baterai
dan membuat semua sambungan-sambungan listrik sebelum memasang unit.

• Pastikan untuk mentanahkan unit ini ke casis mobil kembali setelah pemasangan.

Catatan mengenai sambungan listrik:

• Ganti sekring dengan voltase yang sudah ditetapkan. Jika sekring sering meledak, konsultasikan pada
penyalur audio mobil JVC anda.

• Disarankan untuk menghubungkan speaker-speaker dengan maksimum power lebih dari 50 W (keduanya
di belakang dan di depan, dengan sebuah impedansi 4 Ω sampai 8 Ω).

Jika maksimum power kurang dari 50 W, ganti pengaturan <Amplifier Gain> (“PENAMBAH

PENGUAT”) untuk mencegah speaker-speaker dari kerusakan (lihat halaman 18 dari BUKU
PETUNJUK).

• Untuk mencegah hubungan pendek, tutup ujung-ujung terminal-terminal TIDAK DIGUNAKAN dengan
pita isolasi.

• Pendingin menjadi sangat panas setelah digunakan. Hati-hati untuk tidak menyentuhnya ketika
memindahkan unit ini.

ENGLISH

This unit is designed to operate on 12 V DC , NEGATIVE ground electrical s ystems. If your vehicle does
not have this system, a voltage inverter is required, which can be purchased at JVC car audio dealers.

WARNINGS

• DO NOT install any unit or wire any cable in a location where;
– it may obstruct the steering wheel and gearshift lever operations, as this may result in a traffic accident.
– it may obstruct the operation of safety devices such as air bags, as this may result in a fatal accident.
– it may obstruct visibility.

• DO NOT operate any unit while manipulating the steering wheel, as this may result in a traffic accident.

• The driver must not watch the monitor while driving. It may lead to carelessness and cause an accident.

• If you need to operate the unit while driving, be sure to look around carefully or you may be involved in
a traffic accident.

• If the parking brake is not engaged, “Parking Brake” appears on the monitor, and no playback picture
will be shown.
– This warning appears only when the parking brake wire is connected to the parking brake system built

in the car.

To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all
electrical connections before installing the unit.

• Be sure to gr ound this unit to the car’s chass is again after installat ion.

Notes on electrical connections:

• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio
dealer.

• It is recommended to connect speakers with maximum power of more than 50 W (both at the rear and
at the front, with an impedance of 4 Ω to 8 Ω).

If the maximum power is less than 50 W, change <Amplifier Gain> setting to prevent the speakers from

being damaged (see page 18 of the INSTRUCTIONS).

• To prevent short circuits, cover the terminals of the UNUSED leads with insulating tape.

• The heat sink becomes very hot after use. Be careful not to touch it when removing this unit.

Main unit

Unit utama

Power cord

Kabel listrik

Round head screws (M5 × 8 mm)

Sekrup-sekrup kepala bulat (M5 × 8 mm)

Flat head screws (M5 × 8 mm)

Sekrup-sekrup kepala datar (M5 × 8 mm)

Crimp connector

Konektor kerut

Remote controller

Remote kontrol

Batteries

Baterai

Plate for use with a Nissan car

Pelat untuk digunakan dengan mobil Nissan

Heat sink

Endapan panas

GET0605-009A

[UN]

0109DTSMDTJEIN

EN, IN

© 2009 Victor Company of Japan, Limited

2

160 91.3

100

30˚

Dashboard

Dashboard

20

4

INSTALLATION (IN-DASH MOUNTING)

The following illustration shows a typical installation. However, you should make adjustments
corresponding to your specific car. If you have any questions or require information regarding installation
kits, consult your JVC car audio dealer or a company supplying kits.

• If you are not sure how to install this unit correctly, have it installed by a qualified technician.

Before installing the unit

• When mounting the unit, be sure to use the screws provided, as instructed. If other screws are used,
parts could become loose or damaged.

• When tightening screws or bolts, be careful not to pinch any connection cord.

• Make sure not to block the fan on the rear to maintain proper ventilation when installing the unit.

1 Remove the audio system originally installed in the car, together with its mounting brackets.

Note: Be sure to keep all the screws and parts removed from your car for future use.

2 Attach the mounting brackets (removed from the car), to this unit (see below).
3 Do the required electrical connections.

• See pages 3 – 6.

4 Install this unit using the screws removed in step 1.

The following example is for installation in a Toyota car. For more details, consult your JVC car audio
dealer.

If necessary, restore the protruding tabs.

Jika perlu, pasang kembali tab yang menonjol keluar.

Supplied screws

Sekrup-sekrup yang disediakan

Note : When installing the unit on the mounting bracket, make sure to use the supplied screws

(M5 × 8 mm). If longer screws are used, they could damage the unit.

Catatan : Apabila memasang unit pada braket montasi, pastikan Anda menggunakan sekrup-sekrup yang

disediakan (M5 × 8 mm). Jika menggunakan sekrup-sekrup yang lebih panjang, bisa merusak
unit.

PEMASANGAN (DALAM BINGKAI TEMPATNYA)

Ilustrasi berikut menunjukkan pemasangan yang khas. Namun, Anda harus melakukan penyesuaian pada mobil
tertentu. Jika ada pertanyaan atau perlu infor masi mengenai kit pemasangan, tanyakan kepada penyalur audio
mobil JVC atau perusahaan yang menyediakannya.

• Jika Anda tidak tahu pasti cara memasang unit ini dengan benar, serahkan pemasangan kepada teknisi
yang memenuhi syarat.

Sebelum memasang unit

• Apabila memasang unit, pastikan Anda menggunakan sekrup-sekrup yang tersedia sebagaimana yang
diinstruksikan. Jika menggunakan sekrup lain, komponen bisa menjadi longgar atau rusak.

• Sewaktu mengencangkan sekrup-sekrup atau baut, hati-hati, jangan sampai menjepit kabel sambungan
yang manapun.

• Pastikan tidak ada yang menghalangi kipas pada panel belakang untuk menjaga aliran udara yang baik
apabila kipas ini dipasang.

1 Copot sistem audio yang aslinya terpasang dalam mobil berikut braket montasi.

Catatan: Pastikan Anda menyimpan semua sekrup-sekrup dan komponen yang dilepaskan dari mobil

untuk penggunaan di kemudian hari.

2 Pasangkan braket montasi (yang dilepaskan dari mobil) ke unit ini (lihat di bawah).
3 Lakukan koneksi listrik yang diperlukan.

• Lihat halaman 3 – 6.

4 Pasang unit ini dengan menggunakan sekrup-sekrup yang dilepaskan pada langkah 1.

Berikut adalah contoh pemasangan pada mobil Toyota. Untuk rincian lebih lanjut, tanyakan kepada penyalur
audio mobil JVC.

When installing the unit in a Nissan car
Apabila memasang unit dalam mobil Nissan

Install the unit at an angle of less than 30˚, taking it into account that the monitor would eject
when in use.

Pasang unit tersebut pada sudut kurang dari 30˚, perhitungkan bahwa monitor akan keluar ketika
sedang digunakan.

Required space for installation and the monitor ejection
Diperlukan ruang untuk penginstalan dan pengeluaran monitor

Unit: mm

Unit: mm

Mounting bracket removed from the car

Braket montasi dilepaskan dari mobil

Screws removed from the car in step

1

Sekrup-sekrup yang dilepaskan dari mobil pada langkah 1

Supplied screws

Sekrup-sekrup yang disediakan

Select the appropriate type fitting to your audio
system space.

Pilih tipe sambungan yang sesuai untuk ruang
sistem audio Anda.

Mounting bracket removed from the car

Braket montasi dilepaskan dari mobil

Plate for use with a Nissan car

Pelat untuk digunakan dengan mobil Nissan

3

ELECTRICAL CONNECTIONS SAMBUNGAN-SAMBUNGAN LISTRIK

Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious
damage to this unit.
The leads of the power cord and those of the connector from the car body may be different in color.

1 Connect the colored leads of the power cord in the order specified in the illustration below.
2 Connect the antenna cord.
3 Finally connect the wiring harness to the unit.

Sebelum penyambungan: Cek perkabelan dalam mobil dengan hati-hati. Penyambungan yang tidak benar
mungkin menyebabkan kerusakan serius pada unit.
Ujung dari kabel power dan beberapa konektor dari bodi mobil mungkin berbeda dalam warna.

1 Sambungkan ujung berwarna dari kabel power dalam urutan spesifikasi pada ilustrasi di bawah.
2 Sambungkan kabel antena.
3 Akhirnya sambungkan dudukan kabel ke unit.

Typical connections / Ciri khas sambungan-sambungan

*

1

Not supplied for this unit.

*

2

Before checking the operation of this unit prior to installation, this lead must be connected, otherwise power

cannot be turned on.

*

1

Tidak disediakan untuk unit ini.

*

2

Sebelum pengecekan pengoperasian dari unit ini sebelum pemasangan, ujung ini harus sudah dihubungkan, selain

itu power tidak dapat dihidupkan.

15 A fuse

Sekring 15 A

Fan

Kipas

Ignition switch

Saklar kontak

To a live terminal in the fuse block connecting to the car battery (bypassing
the ignition switch) (constant 12 V)

Ke terminal aktif dalam blok sekring yang menghubungkan ke baterai mobil
(tanpa melalui kunci kontak) (konstant 12 V)

To metallic body or chassis of the car

Ke besi bodi atau casis dari mobil tersebut

To an accessory terminal in the fuse block

Ke terminal aksesori dalam blok sekring

To the remote lead of other equipment (200 mA max.)

Ke ujung jauh dari peralatan lain (maksimum 200 mA.)

To automatic antenna if any (250 mA max.)

Ke antena otomatis jika ada (maksimum 250 mA.)

Fuse block

Blok sekring

To cellular phone system

Ke sistem telepon selular

To car light control switch

Ke saklar kontrol lampu mobil

Crimp connector

Konektor kerut

To parking brake (see diagram

)

Ke rem parkir (lihat diagram )

Yellow *2
Kuning

*

2

Red

Merah

Orange with white stripe

Oranye dengan strip putih

Black

Hitam

Light green

Hijau muda

Brown

Cokelat

Blue with white stripe

Biru dengan strip putih

Blue

Biru

Left speaker (rear)

Speaker kiri (belakang)

Right speaker (front)

Speaker kanan (depan)

Left speaker (front)

Speaker kiri (depan)

Right speaker (rear)

Speaker kanan (belakang)

Gray with black stripe

Abu-abu dengan strip hitam

White

Putih

White with black stripe

Putih dengan strip hitam

Green with black stripe

Hijau den gan strip hitam

Gray

Abu-abu

Green

Hijau

Purple with black stripe

Ungu dengan strip hitam

Purple

Ungu

Rear ground terminal

Terminal tanah belakang

To external components
(see diagram

)

Ke komponen eksternal

(lihat diagram )

VIDEO IN

(see diagram

/

lihat diagram )

DIGITAL OUT

(see diagram

/ lihat diagram )

LINE IN

(see diagram

/

lihat diagram )

REAR OUT

(see diagram

/

lihat diagram )

(see diagram

/ lihat diagram )

Position data output / Keluaran data posisi

SUBWOOFER—Only for KW-AVX726/KW-AVX725 / Hanya untuk KW-AVX726/KW-AVX725
(see diagram

/ lihat diagram )

VIDEO OUT

(see diagram

/

lihat diagram )

Antenna terminal

Terminal antena

This terminal is used for controlling an external device by using the touch panel of this unit. This unit outputs the positional
information detected on the touch panel through the POSITION OUT terminal. Refer to the instruction manual of the external
device for details. JVC does not guarantee proper operations for the external device connected to the POSITION OUT terminal.

Terminal ini digunakan untuk mengendalikan sebuah perangkat eksternal dengan menggunakan panel sentuh unit ini. Unit
ini mengeluarkan informasi posisi yang terdeteksi di panel sentuh melalui terminal POSITION OUT. Lihat panduan instruksi
perangkat eksternal untuk mengetahui detailnya. JVC tidak menjamin operasi perangkat eksternal yang tepat yang tersambung ke
terminal POSITION OUT.

4

INDONESIA ENGLISH

A

Connecting the parking brake lead / Menyambung kabel rem parkir

Parking brake lead (light green)

Kabel rem parkir (hijau muda)

To metallic body or chassis of the car

Ke logam body atau casis mobil

Parking brake switch (inside the car)

Saklar rem parkir (di dalam mobil)

Parking brake

Rem parkir

Connecting the reverse gear signal lead (for rear view camera) / Menghubungkan timbal sinyal persneling mundur (untuk kamera tampilan
belakang)

Locate the reverse lamp lead in the trunk.

Tem p at k an kabel kamera belakang ke dalam bagasi mobil.

To car battery

Ke baterai

Extension lead

*

1

Kabel sambungan *

1

Crimp connector *

1

Konektor kerut *

1

Purple with white stripe

Ungu dengan strip putih

*

1

Not supplied for this unit.

*

1

Tidak disediakan untuk unit ini.

Reverse lamps

Lampu mundur

To reverse lamp

Ke lampu mundur

Reverse lamp lead

Ujung lampu mundur

PRECAUTIONS on p ower supply and speaker conne ctions:

• DO NOT conne ct the speaker leads of th e power cord to the car batter y; otherwise, the unit
will be seriously damaged.

• BEFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in
your car.

TINDAKAN-TINDAKAN PENCEGAHAN pada suplai power dan sambungan-sambungan
speaker:

• JANGAN sambu ngkan ujung-ujung speaker d ari kabel power ke baterai mobil ; sebaliknya,
unit tersebut akan secara serius rusak.

• SEBELUM menyambung ujung-ujung speaker dari kabel power ke speaker-speaker, cek perkabelan
speaker dalam mobil Anda.

B

Crimp connector

Konektor kerut

5

C

Connecting the external amplifier and/or subwoofer / Penyambungan penguat eksternal dan/atau subwoofer

You can connect an amplifier to upgrade your car stereo system.

• Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it
can be controlled through this unit.

• Disconnect the speakers from this unit, connect them to the amplifier. Leave the speaker
leads of this unit unused.

Anda dapat menyambungkan penguat untuk meningkatkan sistem stereo mobil anda.

• Sambungkan ujung jauh (biru dengan strip putih) ke ujung jauh dari peralatan lain sehingga dapat
dikontrol melalui unit ini.

• Putuskan sambungan speaker-speaker dari unit ini, sambungkan ini ke penguat. Biarkan
ujung speaker dari unit ini tidak digunakan.

Rear speakers

Speaker-speaker belakang

JVC Amplifier

Pengua t JVC

Remote lead *

2

Ujung jauh *

2

Y-connector *

2

Konektor Y *

2

Remote lead (blue with white stripe)

Ujung jauh (biru dengan strip putih)

To the remote lead of other equipment or automatic antenna if any

Ke ujung jauh dari peralatan lain atau antena otomatis jika ada

Front speakers

Speaker-speaker depan

Subwoofer

Subwoofer

JVC Amplifier

Pengua t JVC

*

2

Not supplied for this unit.

*

3

Signal cord (not supplied for this unit).

*

4

Audio cord (not supplied for this unit).

*

5

Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with paint

(if coated with paint, remove the paint before attaching the wire). Failure to do so may cause damage to the
unit.

*

6

When using the cable, make sure <iPod (Off)> is selected for <AV Input> (see page 15 of the INSTRUCTIONS).

*

2

Tidak disediakan untuk unit ini.

*

3

Kabel sinyal (tidak disediakan untuk unit ini).

*

4

Kabel audio (tidak disediakan untuk unit ini).

*

5

Pasangkan dengan kuat kabel tanah ke bodi besi atau ke casis dari mobil—pada tempat yang tidak dilapisi cat

(jika dilapisi cat, hilangkan cat sebelum memasang kabel). Kegagalan melakukan ini mungkin menyebabkan
kerusakan pada alat penerima tersebut.

*

6

Bila menggunakan kabel, pastikan <iPod (Off)> yang dipilih untuk <AV Input> (lihat halaman 15 dari BUKU

PETUNJUK).

External component

Komponen ek sternal

D

Connecting the external components / Menyambung komponen eksternal

AV a mp li fier or decoder

Amplifie r AV a tau decoder

Digital optical cable *

2

Kabel optik digital *

2

Video cord *

2

Kabel video *

2

External monitor

External monitor

KV-CM1

*

2

Rear view camera

Kamera tampilan belakang

Video cord

*

2

Kabel video *

2

USB cable (approx. 1.2 m)

Kabel USB (kira-kira 1,2 m)

USB device

Perangkat USB

Only for KW-AVX726/KW-AVX725 / Hanya untuk KW-AVX726/KW-AVX725

You cannot connect a computer to the USB ( ) terminal of the unit.

Anda tidak dapat menghubungkan komputer ke terminal USB (

) pada

unit.

Only for KW-AVX726/KW-AVX725 / Hanya untuk KW-AVX726/KW-AVX725

Connecting the iPod/iPhone to the USB terminal / Menghubungkan iPod/iPhone ke
terminal USB

Connecting the USB devices / Menghubungkan
Perangkat USB

You can connect the iPod/iPhone to the USB terminal using the following cables:

• To listen to the music: USB 2.0 cable (supplied with the iPod/iPhone)

• To watch the video: USB Audio and Video cable for iPod/iPhone—KS-U30 (not supplied) *

6

Anda dapat menghubungkan iPod/iPhone ke terminal USB dengan menggunakan kabel berikut ini:

• Untuk mendengarkan musik: Kabel USB 2.0 (disediakan untuk iPod/iPhone)

• Untuk menonton video: Kabel Audio dan Video USB untuk iPod/iPhone—KS-U30 (tidak disediakan) *

6

Apple iPod/iPhone

Apple iPod/iPhone

KS-U30

USB 2.0 cable

Kabel USB 2.0

iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

iPod adalah merek dagang dari Apple Inc., terdaftar di Amerika Serikat dan di
negara-negara lain.

iPhone is a trademark of Apple Inc.

iPhone adalah merek dagang dari Apple Inc.

Apple iPod/iPhone

Apple iPod/iPhone

6

Bila menghubungkan komponen eksternal, rujuk juga buku petunjuk yang dibekalkan untuk komponen dan
adaptor.

PERINGATAN:

Sebelum menyambungkan komponen eksternal, pastikan bahwa unit sudah dimatikan.

Anda dapat menghubungkan komponen JVC berikut ini ke jack CD changer.

Komponen JVC Nama model

CD changer (CD-CH) CH-X1500, dsb.

Anda juga dapat menghubungkan komponen berikut ini melalui berbagai adaptor JVC.

• Kabel koneksi mungkin harus dibeli secara terpisah.

Komponen Adaptor Nama model

Perangkat Bluetooth Adaptor Bluetooth KS-BTA200

iPod Adaptor interface untuk iPod KS-PD100

Audio player portabel dengan jack line output Adaptor line input KS-U57

Audio player portabel dengan jack stereo mini 3,5 mm

Adaptor AUX input KS-U58

Bila menghubungkan beberapa komponen (maksimum: dua), dianjurkan agar anda menghubungkan
komponen dalam rangkaian seperti dijelaskan di bawah.

Connecting the external components to the CD changer jack / Menghubungkan komponen eksternal ke jack CD changer

When connecting the external components, refer also to the manuals supplied for the components and
adapter.

CAUTION:

Before connecting the external components, make sure that the unit is turned off.

You can connect the following JVC components to the CD changer jack.

JVC component Model name

CD changer (CD-CH) CH-X1500, etc.

You can also connect the following components through the various JVC adapters.

• Connection cords may need to be purchased separately.

Component Adapter Model name

Bluetooth device Bluetooth adapter KS-BTA200

iPod Interface adapter for iPod KS-PD100

Portable audio player with line output jacks Line input adapter KS-U57

Portable audio player with 3.5 mm stereo mini jack AUX input adapter KS-U58

When connecting more than one component (maximum: two), it is recommended that you connect the
components in series as explained below.

E

To d isc onn ect the connector / Untuk memutusk an konektor

Hold the connector top tightly (

1 ), then pull it out ( 2 ).

Pegang erat konektor (

1 ) lalu tarik keluar ( 2 ).

When connecting two components in series
Bila menghubungkan dua komponen dalam rangkaian

A KS-BTA200
B*

7

CD -CH / KS-PD100 / KS-U57 / KS- U58

CD changer jack / Konector CD changer

*

7

To use these components, set the external input setting correctly (see page 16 of the INSTRUCTIONS). *7 Untuk menggunakan komponen ini, lakukan pengaturan masukan eksternal yang benar (lihat halaman 16

dari BUKU PETUNJUK

).

TROUBLESHOOTING

• The fuse blows.

* Are the red and black leads connected correctly?

• Power cannot be turned on.

* Is the yellow lead connected?

• No sound from the speakers.

* Is the speaker output lead short-circuited?

• Sound is distorted.

* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?

• Noise interfere with sounds.

* Is the rear ground terminal connected to the car’s chassis using shorter and thicker cords?

• This unit becomes hot.

* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?

• This unit does not work at all.

* Have you reset your unit?

PEMECAHAN MASALAH

• Sekring meledak.

* Apakah ujung-ujung merah dan hitam tersambung dengan benar?

• Power tidak dapat dihidupkan.

* Apakah ujung kuning sudah tersambung?

• Tidak ada suara dari speaker.

* Apakah ujung keluaran speaker terhubung pendek?

• Suara terdistorsi.

* Apakah ujung keluaran speaker sudah ditanahkan?
* Apakah terminal-terminal “–” dari speaker-speaker L dan R sudah ditanahkan secara umum?

• Berisik yang mengganggu suara-suara.

* Apakah terminal tanahan belakang tersambung ke casis mobil menggunakan kabel-kabel terpendek dan

tertebal?

• Unit menjadi panas.

* Apakah ujung keluaran speaker sudah ditanahkan?
* Apakah terminal-terminal “–” dari speaker-speaker L dan R sudah ditanahkan secara umum?

• Unit ini tidak bekerja secara keseluruhan.

* Apakah anda sudah reset (memasang kembali) unit anda?

*

7

1

To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all
electrical connections before installing the unit.

• Be sure to gr ound this unit to the car’s chass is again after installat ion.

Notes on electrical connections:

• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio

dealer.

• It is recommended to connect speakers with maximum power of more than 50 W (both at the rear and

at the front, with an impedance of 4 Ω to 8 Ω).

If the maximum power is less than 50 W, change <Amplifier Gain> setting to prevent the speakers from

being damaged (see page 18 of the INSTRUCTIONS).

• To prevent short circuits, cover the

terminals of the UNUSED leads with
insulating tape.

• The heat sink becomes very hot after use.

Be careful not to touch it when removing
this unit.

KW-AVX726/KW-AVX724/
KW-AVX626/KW-AVX624

Installation/Connection Manual

Parts list for installation and connection

If any item is missing, consult your JVC car audio dealer immediately.

This unit is designed to operate on 12 V DC , NEGATIVE ground electrical s ystems. If your vehicle does not have this system, a voltage inverter is required, which can be purchased at JVC car audio dealers.

WARNINGS

Main unit Power cord

Round head screws (M5 × 8 mm)

Flat head screws (M5 × 8 mm)

Crimp connector

Remote controller

Batteries

Plate for use with a Nissan car

160 91.3

100

30˚

Dashboard

20

4

INSTALLATION (IN-DASH MOUNTING)

1 Remove the audio system originally installed in the car, together with its mounting brackets.

Note: Be sure to keep all the screws and parts removed from your car for future use.

2 Attach the mounting brackets (removed from the car), to this unit (see below).
3 Do the required electrical connections.

• See pages 2 – 4.

4 Install this unit using the screws removed in step 1.

The following example is for installation in a Toyota car. For more details, consult your JVC car audio dealer.

If necessary, restore the protruding tabs.

Note : When installing the unit on the mounting bracket, make sure to use the supplied

screws (M5 × 8 mm). If longer screws are used, they could damage the unit.

When installing the unit in a Nissan car

Install the unit at an angle of less than 30˚, taking it into
account that the monitor would eject when in use.

Required space for installation and the
monitor ejection

Unit: mm

Supplied screws

Mounting bracket removed from the car

Screws removed from the car in step

1

Supplied screws

Select the appropriate
type fitting to your
audio system space.

Mounting bracket removed from the car

Plate for use with a Nissan car

GET0605-010A

[A/UI]

0109DTSMDTJEIN

EN

© 2009 Victor Company of Japan, Limited

Heat sink

• DO NOT install any unit or wire any cable in a location where;
– it may obstruct the steering wheel and gearshift lever operations, as this may result in a traffic accident.
– it may obstruct the operation of safety devices such as air bags, as this may result in a fatal accident.
– it may obstruct visibility.

• DO NOT operate any unit while manipulating the steering wheel, as this may result in a traffic accident.

• The driver must not watch the monitor while driving. It may lead to carelessness and cause an accident.

• If you need to operate the unit while driving, be sure to look around carefully or you may be involved in
a traffic accident.

• If the parking brake is not engaged, “Parking Brake” appears on the monitor, and no playback picture
will be shown.
– This warning appears only when the parking brake wire is connected to the parking brake system built

in the car.

The following illustration shows a typical installation. However, you should make adjustments
corresponding to your specific car. If you have any questions or require information regarding installation
kits, consult your JVC car audio dealer or a company supplying kits.

• If you are not sure how to install this unit correctly, have it installed by a qualified technician.

Before installing the unit

• When mounting the unit, be sure to use the screws provided, as instructed. If other screws are used,
parts could become loose or damaged.

• When tightening screws or bolts, be careful not to pinch any connection cord.

• Make sure not to block the fan on the rear to maintain proper ventilation when installing the unit.

2

ELECTRICAL CONNECTIONS

Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious damage to this unit.
The leads of the power cord and those of the connector from the car body may be different in color.

1 Connect the colored leads of the power cord in the order specified in the illustration below.
2 Connect the antenna cord.
3 Finally connect the wiring harness to the unit.

Typical connections

*

1

Not supplied for this unit.

*

2

Before checking the operation of this unit prior to installation, this lead must be connected, otherwise power cannot be turned on.

15 A fuse

Fan

Ignition switch

To a live terminal in the fuse block connecting to the car battery (bypassing
the ignition switch) (constant 12 V)

To metallic body or chassis of the car

To an accessory terminal in the fuse block

To the remote lead of other equipment (200 mA max.)

To automatic antenna if any (250 mA max.)

Fuse block

To cellular phone system

To car light control switch

Crimp connector

To parking brake (see diagram

)

Yellow *2

Red

Orange with white stripe

Black

Light green

Brown

Blue with white stripe

Blue

Left speaker (rear)Right speaker (front)Left speaker (front)

Right speaker (rear)

Gray with black stripeWhiteWhite with black stripe Green with black stripeGray Green Purple with black stripe Purple

Rear ground terminal

To external components
(see diagram

)

VIDEO IN

(see diagram

)

DIGITAL OUT (see diagram

)

LINE IN

(see diagram

)

REAR OUT

(see diagram

)

(see diagram

)

Position data output

SUBWOOFER—Only for KW-AVX726/KW-AVX724 (see diagram

)

VIDEO OUT

(see diagram

)

Antenna terminal

PRECAUTIONS on p ower supply and speaker conne ctions:

• DO NOT conne ct the speaker leads of the p ower cord to the car batter y; otherwise, the unit w ill be seriously damaged.

• BEFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in your car.

This terminal is used for controlling an external device by using the touch panel of this unit. This unit outputs the positional
information detected on the touch panel through the POSITION OUT terminal. Refer to the instruction manual of the external
device for details. JVC does not guarantee proper operations for the external device connected to the POSITION OUT terminal.

3

A

Connecting the parking brake lead

Parking brake lead (light green)

To metallic body or chassis of the car

Parking brake switch (inside the car)

Parking brake

Connecting the reverse gear signal lead (for rear view camera)

Locate the reverse lamp lead in the trunk.

To car battery

Extension lead

*

1

Crimp connector *

1

Purple with white stripe

*

1

Not supplied for this unit.

*

2

Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with paint (if coated with paint, remove the paint before attaching the wire). Failure to do so may cause damage to the unit.

Reverse lamps

To reverse lamp

Reverse lamp lead

B

C

Connecting the external amplifier and/or subwoofer

You can connect an amplifier to upgrade your car stereo system.

• Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it can be controlled through this unit.

• Disconnect the speakers from this unit, connect them to the amplifier. Leave the speaker leads of this unit unused.

Rear speakers

JVC Amplifier

Remote lead *

1

Y-connector *

1

Remote lead (blue with white stripe)

To the remote lead of other equipment or automatic antenna if any

Front speakers

Subwoofer

JVC Amplifier

Only for KW-AVX726/KW-AVX724

Crimp connector

Signal cord

*

1

Audio cord *

1

TROUBLESHOOTING

• The fuse blows.

* Are the red and black leads connected correctly?

• Power cannot be turned on.

* Is the yellow lead connected?

• No sound from the speakers.

* Is the speaker output lead short-circuited?

• Sound is distorted.

* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?

• Noise interfere with sounds.

* Is the rear ground terminal connected to the car’s chassis using shorter and thicker cords?

• This unit becomes hot.

* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?

• This unit does not work at all.

* Have you reset your unit?

4

*

3

Not supplied for this unit.

*

4

When using the cable, make sure <iPod (Off)> is selected for <AV Input> (see page 15 of the INSTRUCTIONS).

*

5

To use these components, set the external input setting correctly (see page 16 of the INSTRUCTIONS).

External component

D

Connecting the external components

AV a mp li fier or decoder

Digital optical cable *

3

Video cord *

3

External monitor

KV-CM1

*

3

Rear view camera

Video cord

*

3

USB cable (approx. 1.2 m)

USB device

Only for KW-AVX726/KW-AVX724

You cannot connect a computer to the USB ( ) terminal of the unit.

Connecting the iPod/iPhone to the USB terminalConnecting the USB devices

You can connect the iPod/iPhone to the USB terminal using the following cables:

• To listen to the music: USB 2.0 cable (supplied with the iPod/iPhone)

• To watch the video: USB Audio and Video cable for iPod/iPhone—KS-U30 (not supplied) *

4

iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

iPhone is a trademark of Apple Inc.

Apple iPod/iPhone

KS-U30

USB 2.0 cable

Apple iPod/iPhone

Connecting the external components to the CD changer jack

When connecting the external components, refer also to the manuals supplied for the components and
adapter.

CAUTION:

Before connecting the external components, make sure that the unit is turned off.

You can connect the following JVC components to the CD changer jack.

JVC component Model name

CD changer (CD-CH) CH-X1500, etc.

You can also connect the following components through the various JVC adapters.

• Connection cords may need to be purchased separately.

Component Adapter Model name

Bluetooth device Bluetooth adapter KS-BTA200

iPod Interface adapter for iPod KS-PD100

Portable audio player with line output jacks Line input adapter KS-U57

Portable audio player with 3.5 mm stereo mini jack AUX input adapter KS-U58

E

To d isc onn ect the connector

Hold the connector top tightly (

1 ), then pull it out ( 2 ).

When connecting two components in series

A KS-BTA200
B*

5

CD -CH / KS-PD100 / KS-U57 / KS- U58

CD changer jack

*

5

When connecting more than one component (maximum: two), it is recommended that you connect the
components in series as explained below.

Signal cord *

3
