JVC KD-SV3105 User Manual

VCD/CD RECEIVER KD-SV3105

KD-SV3105

ATT

BAND

SOURCE

REV FWD

VOL.

DOWN

VIDEO CD

PBCENTER

RETURN

123

OSD

456

AUDIO

7809

For canceling the display demonstration, see page 9.

ENGLISH

For installation and connections, refer to the separate manual.

INSTRUCTIONS

GET0262-001A

[U/UH]

Thank you for purchasing a JVC product.

Please read all instructions carefully before operation, to ensure your complete understanding and to

obtain the best possible performance from the unit.

ENGLISH

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION : Do not open the top cover. There are no user serviceable parts inside the unit; leave

all servicing to qualified service personnel.

3. CAUTION : Visible and invisible laser radiation when open and interlock failed or defeated.

Avoid direct exposure to beam.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.

WARNING:

• DO NOT install any unit in locations where;

– it may obstruct the steering wheel

and gearshift lever operations, as this may result in a traffic accident.

– it may obstruct the operation of safety

devices such as air bags, as this may result in a fatal accident.

– it may obstruct visibility.

• DO NOT operate any unit while manipulating the steering wheel, as this may result in a traffic accident.

• The driver must not watch the monitor while driving.

If the driver watches the monitor while

driving, it may lead to carelessness and cause an accident.

• If you need to operate the unit while driving, be sure to look ahead carefully or you may be involved in a traffic accident.

• If the parking brake is not engaged, “PARKING” flashes on the display, and no playback picture will be shown on the monitor.

– This warning appears only when

the parking brake wire is connected to the parking brake system built in the car (refer to the Installation/ Connection Manual).

How to reset your unit

This will reset the microcomputer. Your preset adjustments will also be erased.

How to forcibly eject a disc

If a disc cannot be recognized by the unit or cannot be ejected, ejects the disc as follows.

• If this does not work, reset your unit.

• Be careful not to drop the disc when it ejects.

How to reset your unit ........................... 2

How to forcibly eject a disc ................... 2

How to read this manual ........................ 4

How to use the MODE button ............... 4

Control panel — KD-SV3105 ...... 5

Parts identification ................................. 5

Remote controller — RM-RK120

Main elements and features ................... 7

... 6

Getting started ....................... 8

Basic operations .................................. 8

Canceling the display demonstrations ... 9

Setting the clock .................................... 9

Radio operations ................... 10

Listening to the radio ........................... 10

Storing stations in memory .................... 11

Listening to a preset station ................... 12

Disc operations ...................... 13

Playing a disc in the unit ...................... 13

Playing a disc in the CD changer ........... 15

Playback Control (PBC) operations ...... 17

On-Screen (OSD) information ............... 18

Selecting the audio channel ................... 18

MP3/WMA control screen operations ... 18

Changing the display information ......... 19

Selecting the playback modes ................ 20

Sound adjustments ................ 21

Selecting preset sound modes

(C-EQ: custom equalizer) .................. 21

Adjusting the sound ............................... 22

ENGLISH

General settings — PSM ......... 23

Basic procedure ..................................... 23

Detaching the control panel .... 25

External component

operations ........................... 26

Playing an external component ............ 26

Maintenance .......................... 27

More about this unit ............... 28

Troubleshooting ..................... 30

Specifications ......................... 33

For safety....

• Do not raise the volume level too much, as this will block outside sounds, making driving dangerous.

• Stop the car before performing any complicated operations.

Temperature inside the car....

If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.

How to read this manual

The following methods are used to make the explanations simple and easy-to-understand:

• Some related tips and notes are explained in

ENGLISH

“More about this unit” (see pages 28 and 29).

• Button operations are mainly explained with the illustrations as follows:

Press briefly.

Press repeatedly.

Press either one.

Press and hold until your desired response begins.

How to use the MODE button

If you press MODE, the unit goes into functions mode, then the number buttons and

¢/4 buttons work as different

function buttons.

Ex.: When number button 2 works as

MO (monaural) button.

Time countdown indicator

To use these buttons for original functions again after pressing MODE, wait for

5 seconds without pressing any of these buttons until the functions mode is cleared.

• Pressing MODE again also clears the functions mode.

Press and hold both buttons at the same time.

The following marks are used to indicate...

: Built-in VCD/CD player

operations.

: External CD changer operations.

Control panel — KD-SV3105

Parts identification

Display window

1 +/– buttons 2 DISP (display) button 3 Remote sensor 4 Loading slot 5 Display window 6 MODE button 7 0 (eject) button

¢/4 buttons

8 9 p SEL (select) button q MO (monaural) button w SSM (Strong-station Sequential Memory)

button

e SOURCE button r • BAND button

• 6 (play/pause) button

t RPT (repeat) button y RND (random) button u EQ (equalizer) button i o Number buttons

(standby/on/attenuator) button

(control panel release) button

Display window

; Tuner reception indicators—

MO (monaural), ST (stereo)

a Disc type indicators—WMA, MP3 s CH (CD changer) indicator d CD indicator f Playback mode / item indicators—

RND (random), RPT (repeat)

g LOUD (loudness) indicator h EQ (equalizer) indicator j Sound mode (C-EQ: custom equalizer)

indicators—ROCK, CLASSIC, POPS, HIP HOP, JAZZ, USER

•

k Disc information indicators—

l Main display / Source display / Volume level indicator z Tr (track) indicator

also works as the time countdown

indicator.

TAG (ID3 Tag),

(disc), (folder),

(folder), (track/file)

ENGLISH

Remote controller — RM-RK120

Installing the lithium coin battery

(CR2025)

ENGLISH

• Aim the remote controller directly at the remote sensor on the unit. Make sure there is no obstacle in between.

Caution:

• Do not leave the remote controller in a place (such as dashboard) exposed to direct sunlight for a long time.

Warning:

• Do not install any battery other than CR2025 or its equivalent; otherwise, it may explode.

• Store the battery in a place where children cannot reach to avoid risk of accident.

• To prevent the battery from over-heating, cracking, or starting a fire: – Do not recharge, short, disassemble, or

heat the battery or dispose of it in a fire.

– Do not leave the battery with other

metallic materials.

– Do not poke the battery with tweezers or

similar tools.

– Wrap the battery with tape and insulate

when throwing away or saving it.

Remote sensor

• DO NOT expose the remote sensor to strong light (direct sunlight or artificial lighting).

Main elements and features

ATT

VOL.

1 SOURCE button

• Selects the playback source. 2

(standby/on attenuator) button

• Turns on and off the power and also attenuates the sound.

3 2 REV / FWD 3 buttons

• Searches for stations if pressed briefly.

• Fast-forwards or reverses the track if pressed and held.

• Changes the tracks/files of the disc.

4 VOL. + / – buttons

• Adjusts the volume level.

5 ENTER and number buttons

• Selects a track/file directly.

– Press the number button(s), then press

ENTER.

• Selects an item from the menu while playing back a Video CD (VCD) in Playback Control (PBC) function.

– Press the number button(s), then press

ENTER.

BAND

SOURCE

REV FWD

DOWN

VIDEO CD

123

456

7809

PBCENTER

RETURN

OSD

AUDIO

• Selects the discs while operating the CD changer.

– To select disc number 1 – 6, press

number button 1 – 6 briefly.

– To select disc number 7 – 12, press and

hold number button 1 (7) – 6 (12).

6 EQ (equalizer) button

• Selects the sound mode (C-EQ: custom equalizer).

7 BAND 6 button

• Changes the FM/AM bands.

• Stops disc playback temporarily. To resume playback, press the button again.

– Not used for CD changer operations. – While playing a VCD, the playback

scene at the moment stops and remain stills.

8 5 UP / DOWN ∞ buttons

• Changes the preset stations.

• Changes the folder of the MP3/WMA discs if pressed briefly.

• Changes the disc while operating the CD changer if pressed and held.

9 PBC (Playback Control) button

• Activates or deactivates the PBC function.

RETURN button

• Returns to the previous menu while playing a VCD in PBC function.

q OSD (On-Screen Display) button

• Turn on and off the OSD on the monitor.

w AUDIO button

• Selects the audio channel for VCD playback.

ENGLISH

Getting started

ENGLISH

Basic operations

You cannot select some sources if they are not ready.

! For FM/AM tuner

⁄ Adjust the volume.

Volume level appears.

@ Adjust the sound as you want.

(See pages 21 and 22.)

To drop the volume in a moment (ATT)

To restore the sound, press

it again.

To turn off the power

Caution on volume setting:

Discs produce very little noise compared with other sources. Lower the volume before playing a disc to avoid damaging the speakers by the sudden increase of the output level.

Volume level indicator

Canceling the display

demonstrations

If no operations are done for about 20 seconds, display demonstration starts.

[Initial: DEMO ON]—see page 24.

Setting the clock

ENGLISH

Finish the procedure.

2 Set the hour and minute.

1 Select “CLOCK H” (hour), then

adjust the hour.

2 Select “CLOCK M” (minute),

then adjust the minute.

3 Finish the procedure.

To check the current clock time when the power is turned off

To activate the display demonstration

In step 3 above...

Radio operations

ENGLISH

Listening to the radio

Lights up when receiving an FM stereo broadcast with sufficient signal strength.

Selected band appears.

! Start searching for a station.

When a station is received, searching stops. To stop searching, press the same button again.

To tune in to a station manually

In step ! on the left... 1

2 Select the desired station frequencies.

When an FM stereo broadcast is hard to receive

Lights up when monaural mode is activated.

Reception improves, but stereo effect will be lost.

Storing stations in memory

You can preset six stations for each band.

FM station automatic presetting —

SSM (Strong-station Sequential Memory)

2 Select the FM band (FM1 – FM3)

you want to store into.

ENGLISH

To restore the stereo effect, repeat the same procedure. “MONO OFF” appears and the MO indicator goes off.

“SSM” flashes, then disappears when automatic presetting is over.

Local FM stations with the strongest signals are searched and stored automatically in the FM band.

Manual presetting

Ex.: Storing FM station of 92.5 MHz into the

preset number 4 of the FM1 band.

ENGLISH

Listening to a preset station

Preset number flashes for a while.

3 Select the preset station (1 – 6) you

want.

To check the current clock time while listening to an FM or AM station
