SERVICE MANUAL

CD RECEIVER

MA392<Rev.002>20087SERVICE MANUAL

KD-APD89J, KD-PDR80J, KD-PDR61E,

KD-PDR61EX, KD-PDR61EY, KD-G844UI,

KD-G845U, KD-G845UN, KD-G845UT,

KD-G845UH, KD-G847EE, KD-PDR89UR,

KD-PDR62E, KD-PDR62EX, KD-PDR62EY

COPYRIGHT © 2008 Victor Company of Japan, Limited

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)

1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-27

5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-31

COPYRIGHT © 2008 Victor Company of Japan, Limited

(KD-APD89)
(KD-PDR80)

(KD-PDR89)

(KD-APD89)
(KD-PDR80)

(KD-PDR89)

TABLE OF CONTENTS

(KD-APD89)
(KD-PDR80)

(KD-PDR89)

(KD-PDR61)

(KD-G847)

(KD-PDR62)

No.MA392<Rev.002>

2008/7

SPECIFICATION

KD-APD89/KD-PDR80/KD-PDR89

AUDIO AMPLIFIER SECTION

Power Output 20 W RMS × 4 Channels at 4 Ω and < or = 1% THD+N
Signal-to-Noise Ratio 80 dBA (reference: 1 W into 4 Ω)
Load Impedance 4 Ω (4 Ω to 8 Ω allowance)

Tone Control Range Bass ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz)

Mid-range ±12 dB (500 Hz, 1.0 kHz, 1.5 kHz, 2.5 kHz)
Treble ±12 dB (10.0 kHz, 12.5 kHz, 15.0 kHz, 17.5 kHz)

Frequency Response 40 Hz to 20 000 Hz

Line-Out Level/Impedance KD-APD89 5.0 V/20 kΩ load (full scale)

KD-PDR80 2.5 V/20 kΩ load (full scale)

Subwoofer-Out Level/Impedance

Output Impedance 1 kΩ

Other Terminal

Frequency Range FM

FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)

AM Tuner Sensitivity 20 µV

Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format: (MPEG1/2 Audio Layer 3) Max. Bit Rate: 320 kbps
WMA (Windows Media® Audio) Decoding Format Max. Bit Rate: 192 kbps

USB Standards USB 1.1, USB 2.0
Data Transfer Rate Full Speed Maximum 12 Mbps

Compatible Device Mass storage class
Compatible File System FAT 32/16/12
Playable Audio Format MP3/WMA/WAV
Max. Current 500 mA/5 V

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground

Allowable Operating Temperature 0°C to +40°C (32°F to 104°F)
Dimensions (W × H × D):

(approx.)

Mass 1.4 kg (3.1 lbs) (excluding accessories)

Design and specifications are subject to change without notice.

KD-APD89 5.0 V /20 kΩ load (full scale)
KD-PDR80 2.5 V/20 kΩ load (full scale)

CD changer jack, AUX (auxiliary) input jack, USB input jack, Steer­ing wheel remote input (only for KD-APD89), Antenna input

TUNER SECTION

with channel interval set to 100 kHz or 200 kHz: 87.5 MHz to 107.9 MHz
with channel interval set to 50 kHz: 87.5 MHz to 108.0 MHz

AM with channel interval set to 10 kHz: 530 kHz to 1 710 kHz

with channel interval set to 9 kHz: 531 kHz to 1 602 kHz

50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)

Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 35 dB

Selectivity 35 dB

CD PLAYER SECTION

USB SECTION

Low Speed Maximum 1.5 Mbps

GENERAL

Installation Size 182 mm × 52 mm × 160 mm (7-3/16” × 2-1/16” × 6-5/16”)
Panel Size 188 mm × 58 mm × 6 mm (7-7/16” × 2-5/16” × 1/4”)

1-2 (No.MA392<Rev.002>)

KD-PDR61/KD-PDR62

AUDIO AMPLIFIER SECTION

Maximum Power Output Front/Rear 50 W per channel

Continuous Power Output (RMS) Front/Rear 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no

more than 0.8% total harmonic distortion

Load Impedance 4 Ω (4 Ω to 8 Ω allowance)

Tone Control Range Bass ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz)

Mid-range ±12 dB (500 Hz, 1.0 kHz, 1.5 kHz, 2.5 kHz)

Treble ±12 dB (10.0 kHz, 12.5 kHz, 15.0 kHz, 17.5 kHz)

Frequency Response 40 Hz to 20 000 Hz

Signal to Noise Ratio 70 dB

Audio Output Level Line-Out Level/Impedance 2.5 V/20 kΩ load (full scale)

Output Impedance 1 kΩ

Subwoofer-Out Level/Impedance

2.5 V /20 kΩ load (full scale)

Other Terminals CD changer jack, AUX (auxiliary) input jack, USB input

jack, Aerial input, Steering wheel remote input

TUNER SECTION

Frequency Range FM 87.5 MHz to 108.0 MHz

AM MW: 522 kHz to 1 620 kHz

LW: 144 kHz to 279 kHz

FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)

50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)

Alternate Channel Selectivity (400 kHz)

65 dB

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 30 dB

MW Tuner Sensitivity/Selectivity 20 µV/35 dB
LW Tuner Sensitivity 50 µV

CD PLAYER SECTION

Type Compact disc player

Signal Detection System Non-contact optical pickup (semiconductor laser)

Number of Channels 2 channels (stereo)

Frequency Response 5 Hz to 20 000 Hz

Dynamic Range 96 dB

Signal-to-Noise Ratio 98 dB

Wow and Flutter Less than measurable limit

MP3 Decoding Format: (MPEG1/2 Audio Layer 3)

WMA (Windows Media® Audio) Decoding Format

Max. Bit Rate 320 kbps

Max. Bit Rate 320 kbps

USB SECTION

USB Standard USB 1.1, USB 2.0

Data Transfer Rate (Full Speed) Full Speed Max. 12 Mbps

Low Speed Max. 1.5 Mbps

Compatible Device Mass storage class

Compatible File System FAT 32/16/12

Playable Audio Format MP3/WMA/WAV

Max. Current 500 mA/5V

GENERAL

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)

Grounding System Negative ground

Allowable Operating Temperature 0°C to +40°C
Dimensions (W × H × D) Installation Size (approx.) 182 mm × 52 mm × 160 mm

Panel Size (approx.) 188 mm × 58 mm × 12 mm

Mass (approx.) 1.4 kg (excluding accessories)

Design and specifications are subject to change without notice.

(No.MA392<Rev.002>)1-3

KD-G844

AUDIO AMPLIFIER SECTION

Maximum Power Output Front/Rear 50 W per channel

Continuous Power Output (RMS) Front/Rear 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no

more than 0.8% total harmonic distortion.

Load Impedance 4 Ω (4 Ω to 8 Ω allowance)

Tone Control Range Bass ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz)

Mid-range ±12 dB (500 Hz, 1.0 kHz, 1.5 kHz, 2.5 kHz)

Treble ±12 dB (10.0 kHz, 12.5 kHz, 15.0 kHz, 17.5 kHz)

Frequency Response 40 Hz to 20 000 Hz

Signal-to-Noise Ratio 70 dB

Line-Out and Subwoofer-Out Level/Impedance 2.5 V/20 kΩ load (full scale)
Output Impedance 1 kΩ

Other Terminal CD changer jack, AUX (auxiliary) input jack, USB input

jack, Antenna input

TUNER SECTION

Frequency Range FM 87.5 MHz to 108.0 MHz

AM 531 kHz to 1 602 kHz

FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)

50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)

Alternate Channel Selectivity (400 kHz)

65 dB

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 30 dB

AM Tuner Sensitivity/Selectivity 20 µV/35 dB

CD PLAYER SECTION

Type Compact disc player

Signal Detection System Non-contact optical pickup (semiconductor laser)

Number of Channels 2 channels (stereo)

Frequency Response 5 Hz to 20 000 Hz

Dynamic Range 96 dB

Signal-to-Noise Ratio 98 dB

Wow and Flutter Less than measurable limit

MP3 Decoding Format: (MPEG1/2 Audio Layer 3)

WMA (Windows Media® Audio) Decoding Format

Max. Bit Rate 320 kbps

Max. Bit Rate 192 kbps

USB SECTION

USB Standard USB 1.1, USB 2.0

Data Transfer Rate Full Speed: Max. 12 Mbps

Low Speed: Max. 1.5 Mbps

Compatible Device Mass storage class

Compatible File System FAT 32/16/12

Playable Audio Format MP3/WMA/WAV

Max. Current 500 mA/5 V

GENERAL

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)

Grounding System Negative ground

Allowable Operating Temperature 0°C to +40°C
Dimensions (W × H × D): (approx.) Installation Size 182 mm × 52 mm × 160 mm

Panel Size 188 mm × 58 mm × 6 mm

Mass 1.4 kg (excluding accessories)

Design and specifications are subject to change without notice.

1-4 (No.MA392<Rev.002>)

KD-G845

AUDIO AMPLIFIER SECTION

Maximum Power Output Front/Rear 50 W per channel

Continuous Power Output (RMS) Front/Rear 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no

more than 0.8% total harmonic distortion.

Load Impedance 4 Ω (4 Ω to 8 Ω allowance)

Tone Control Range Bass ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz)

Mid-range ±12 dB (500 Hz, 1.0 kHz, 1.5 kHz, 2.5 kHz)

Treble ±12 dB (10.0 kHz, 12.5 kHz, 15.0 kHz, 17.5 kHz)

Frequency Response 40 Hz to 20 000 Hz

Signal-to-Noise Ratio 70 dB

Line-Out and Subwoofer-Out Level/Impedance 2.5 V/20 kΩ load (full scale)
Output Impedance 1 kΩ

Other Terminal CD changer jack, AUX (auxiliary) input jack, USB input

jack, Antenna input

TUNER SECTION

Frequency Range FM 87.5 MHz to 108.0 MHz

AM 531 kHz to 1 602 kHz

FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)

50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)

Alternate Channel Selectivity (400 kHz)

65 dB

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 30 dB

AM Tuner Sensitivity/Selectivity 20 µV/35 dB

CD PLAYER SECTION

Type Compact disc player

Signal Detection System Non-contact optical pickup (semiconductor laser)

Number of Channels 2 channels (stereo)

Frequency Response 5 Hz to 20 000 Hz

Dynamic Range 96 dB

Signal-to-Noise Ratio 98 dB

Wow and Flutter Less than measurable limit

MP3 Decoding Format: (MPEG1/2 Audio Layer 3)

WMA (Windows Media® Audio) Decoding Format

Max. Bit Rate 320 kbps

Max. Bit Rate 192 kbps

USB SECTION

USB Standard USB 1.1, USB 2.0

Data Transfer Rate Full Speed: Max. 12 Mbps

Low Speed: Max. 1.5 Mbps

Compatible Device Mass storage class

Compatible File System FAT 32/16/12

Playable Audio Format MP3/WMA/WAV

Max. Current 500 mA/5 V

GENERAL

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)

Grounding System

Allowable Operating Temperature

0°C to +40°C

Dimensions (W × H × D): (approx.) Installation Size 182 mm × 52 mm × 160 mm

Panel Size 188 mm × 58 mm × 6 mm

Mass 1.4 kg (excluding accessories)

Design and specifications are subject to change without notice.

(No.MA392<Rev.002>)1-5

KD-G847

AUDIO AMPLIFIER SECTION

Maximum Power Output Front/Rear 50 W per channel

Continuous Power Output (RMS) Front/Rear 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no

more than 0.8% total harmonic distortion

Load Impedance 4 Ω (4 Ω to 8 Ω allowance)

Tone Control Range Bass ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz)

Mid-range ±12 dB (500 Hz, 1.0 kHz, 1.5 kHz, 2.5 kHz)

Treble ±12 dB (10.0 kHz, 12.5 kHz, 15.0 kHz, 17.5 kHz)
Frequency Response 40 Hz to 20 000 Hz
Signal to Noise Ratio 70 dB

Audio Output Level Line-Out Level/Impedance 2.5 V/20 kΩ load (full scale)

Output Impedance 1 kΩ

Subwoofer-Out Level/Impedance

2.5 V /20 kΩ load (full scale)

Other Terminals CD changer jack, AUX (auxiliary) input jack, USB input

jack, Aerial input

TUNER SECTION

Frequency Range FM1/FM2 87.5 MHz to 108.0 MHz

FM3 65.00 MHz to 74.00 MHZ

AM MW: 522 kHz to 1 620 kHz

LW: 144 kHz to 279 kHz

FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)

50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)

Alternate Channel Selectivity (400 kHz)

65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 30 dB

MW Tuner Sensitivity/Selectivity 20 µV/35 dB
LW Tuner Sensitivity 50 µV

CD PLAYER SECTION

Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format: (MPEG1/2 Audio Layer 3)
WMA (Windows Media® Audio) Decoding Format

Max. Bit Rate 320 kbps
Max. Bit Rate 320 kbps

USB SECTION

USB Standard USB 1.1, USB 2.0
Data Transfer Rate (Full Speed) Full Speed Max. 12 Mbps

Low Speed Max. 1.5 Mbps

Compatible Device Mass storage class
Compatible File System FAT 32/16/12
Playable Audio Format MP3/WMA/WAV
Max. Current 500 mA/5V

GENERAL

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground

Allowable Operating Temperature 0°C to +40°C
Dimensions (W × H × D) Installation Size (approx.) 182 mm × 52 mm × 160 mm

Panel Size (approx.) 188 mm × 58 mm × 12 mm

Mass (approx.) 1.4 kg (excluding accessories)

Design and specifications are subject to change without notice.

1-6 (No.MA392<Rev.002>)

1.2 Preventing static electricity

Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.

1.2.1 Grounding to prevent damage by static electricity

Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
Be careful to use proper grounding in the area where repairs are being performed.

(1) Ground the workbench

Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.

(2) Ground yourself

Use an anti-static wrist strap to release any static electricity built up in your body.

(caption)
Anti-static wrist strap

1M

Conductive material
(conductive sheet) or iron plate

(3) Handling the optical pickup

• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)

• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.

1.3 Handling the traverse unit (optical pickup)

(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the

replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a

time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) It is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.

1.4 Attention when traverse unit is decomposed

*Please refer to "Disassembly method" in the text for the pickup unit.

• Apply solder to the short land before the card wire is disconnected from the connector on the pickup unit.
(If the card wire is disconnected without applying solder, the pickup may be destroyed by static electricity.)

• In the assembly, be sure to remove solder from the short land after connecting the card wire.

Pickup

Wires

b

B

Push switch

Base board

1-8 (No.MA392<Rev.002>)

e

C

Frame

CD mechanism

d

assembly

Flexible wire

Connector

Pickup

c

1.5 Important for laser products

1.CLASS 1 LASER PRODUCT

2.CAUTION :

(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.

3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.

4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.

5.CAUTION : If safety switches malfunction, the laser is able
to function.

6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.

!

Please use enough caution not to

see the beam directly or touch it

in case of an adjustment or operation

check.

REPRODUCTION AND POSITION OF LABELS and PRINT

WARNING LABEL and PRINT

(No.MA392<Rev.002>)1-9

SECTION 2

SPECIFIC SERVICE INSTRUCTIONS

This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

SECTION 3

DISASSEMBLY

3.1 Main body (Used figure are KD-APD39)

3.1.1 Removing the Bottom chassis (See Fig.1)

(1) Remove the four screws A, two screws B attaching the

heat sink.
(2) Remove the one screw C attaching the Bottom chassis.
(3) Slide to backward, and then take out the Bottom chassis.

AABA

ABC

3.1.2 Removing the Front chassis (See Fig.2, 3)

(1) Remove the two screws D attaching the Front chassis.

(See Fig.2)
(2) Remove the two screws E attaching the both side of Front

chassis. (See Fig.3)
(3) Disengage four hooks a engaged both side of Front chassis.

(See Fig.3)

Fig.1

D

Fig.2

hook a

E

hook a

1-10 (No.MA392<Rev.002>)

Fig.3

3.1.3 Removing the Sub board (See Fig.4)

(1) Disconnect the connector CN741

connector CN701

of the Main board.

of the Sub board from the

Main board

CN701

Sub board

CN741

Fig.4

(No.MA392<Rev.002>)1-11

3.1.4 Removing the Main board (See Fig.5 to 7)

(1) Remove the two screws F and one screw G attaching the

Heat sink. (See Fig.5)
(2) Remove the two screws H and one screw J attaching the

Main board. (See Fig.6)
(3) Remove the two screws K attaching the Main board. (See

Fig.7)
(4) Disconnect the connector CN501

(See Fid.7)

connected to CD mechanism.

G

F

Fig.5

H

J

Fig.6

CN501

K

Fig.7

1-12 (No.MA392<Rev.002>)

3.1.5 Removing the CD mechanism (See Fig.8)

(1) Remove the three screws L attaching the CD mechanism.

3.1.6 Removing the Switch board (See Fig.9, 10)

(1) Remove the volume knob.
(2) Remove the one screw M attaching the Rear cover. (See

Fig.9)

(3) Remove the four screws N attaching the Rear cover. (See

Fig.10)

(4) Disengage nine hooks b engaged Rear cover. (See Fig.10)

L

L

Fig.8

M

Fig.9

hook

b

hook

NN

hook

N

b

hook

b

Fig.10

b

N

(No.MA392<Rev.002>)1-13

3.2 CD mechanism assembly

A

3.2.1 Removing the top cover
(See Figs.1 and 2)

(1) From the both side of the CD mechanism assembly, remove

the four screws A attaching the top cover. (See Fig.1.)

(2) Lift the front side of the top cover and move the top cover

backward to release the two joints a. (See Figs.1 and 2.)

Top cover

A

a

A

A

Fig.1

a

Top cover

Fig.2

1-14 (No.MA392<Rev.002>)

3.2.2 Removing the push switch

(See Figs.3)

(1) From the bottom side of the CD mechanism assembly, remove

the screw B attaching the push switch.

(2) Take out the push switch from the CD mechanism assembly.

Reference:

Remove the wires from soldered sections b of the push switch
as required.

3.2.3 Removing the base board

(See Figs.3 and 4)

Caution:

Solder the short land c before the flexible wire is disconnected from
the connector on the pickup. If the flexible wire is disconnected
without applying solder, the pickup may be destroyed by static
electricity. (See Fig.3.)
(1) From the bottom side of the CD mechanism assembly, remove

the screw C attaching the base board. (See Figs.3 and 4.)
(2) Solder the short land c on the pickup. (See Fig.3.)
(3) Disconnect the flexible wire from the connector on the pickup.

(See Fig.3.)
(4) Remove the base board from the joints d of the frame in the

direction of the arrow. (See Figs.3 and 4.)

Reference:

Remove the wires from the soldered sections e on the base
board as required. (See Fig.3.)

Caution:

When reattaching the base board, be sure to remove solder
from the short land c after connecting the flexible wire. (See
Fig.3.)

e

C

Base board

Frame

Wires

B

b

d

Push switch

Flexible wire

Connector

Fig.3

Pickup

CD mechanism
assembly

Pickup

c

C

Base board

Flexible wire

Frame

d

Fig.4

(No.MA392<Rev.002>)1-15

3.2.4 Removing the chassis unit
(See Figs.5 and 6)

• Remove the top cover and base board.

(1) From the top side of the CD mechanism assembly, remove

the front suspension springs and rear suspension springs
attaching the chassis unit to the frame. (See Fig.5.)

(2) Remove the chassis unit from the dampers on the frame in

an upward direction. (See Fig.6.)

Note:

• Pay attention to misuse and loss of each spring. (See Fig.5.)

• When reassembling, make sure that the three shafts on the
underside of the chassis unit are inserted to the dampers
certainly. (See Fig.6.)

Chassis unit

Front suspension spring

Front suspension spring

Frame

Rear suspension spring Rear suspension spring

Fig.5

Chassis unit

Shaft

Shaft

Damper F

Damper F

Damper R

Frame

Shaft

Fig.6

1-16 (No.MA392<Rev.002>)

3.2.5 Removing the clamper assembly
(See Figs.7 and 8)

• Remove the top cover.

Move the clamper assembly in the direction of the arrow to release
the joints f from the chassis unit.

Chassis unit

f

Clamper assembly

Clamper assembly

Chassis unit

f

Fig.7

f

f

Fig.8

(No.MA392<Rev.002>)1-17

3.2.6 Removing the loading/feed motor assembly
(See Fig.9)

• Remove the top cover, base board and chassis unit.

From the bottom side of the chassis unit, remove the screw D
and take out the loading/feed motor assembly in the direction of
the arrow.

Reference:

Remove the wires from the soldered sections g of the loading/
feed motor assembly as required.

Loading/feed motor assembly

g

Chassis unit

Loading/feed
motor
assembly

D

Fig.9

1-18 (No.MA392<Rev.002>)

3.2.7 Removing the pickup

(See Figs.10 to 12)

• Remove the top cover, base board and chassis unit.

(1) From the bottom side of the chassis unit, remove the screw

E attaching the pu. shaft holder B and pull the pu. shaft out
of the pu. shaft holder A. (See Fig.10.)

(2) Remove the screw F attaching the pu. shaft holder A. (See

Fig.10.)

(3) Take out the pickup with pu. shaft holder A and feed screw

assembly from the chassis unit. (See Fig.11.)

(4) Remove the section h of the pu. shaft holder A in the direction

of the arrow. (See Fig.11.)

(5) Remove the feed screw assembly from the section j of the

pickup in the direction of the arrow. (See Fig.11.)

(6) Remove the screw G attaching the feed screw holder to the

pickup. (See Fig.12.)

Reference:

Remove the feed nut spring from the feed screw holder
as required. (See Fig.12.)

(7) Release the claw k in the direction of the arrow to remove

the feed sub holder. (See Fig.12.)

Pickup

Feed screw assembly

Feed screw holder

Pu. shaft holder A

Fig.11

G

h

j

Feed screw
holder

3.2.8 Reattaching the pickup

(See Figs.10 to 13)

(1) Reattach the feed sub holder to the pickup. (See Fig.12.)
(2) Reattach the feed screw holder to the pickup using the

screw G. (See Fig.12.)

(3) Reattach the feed screw assembly and pu. shaft holder A

to the pickup as before. (See Fig.11.)

(4) Set the section m of the pickup to the rail of the chassis unit

at first and attach the pickup to the chassis unit with the

screw F as before. (See Figs.10 and 13.)
(5) Attach the pu. shaft to the pickup as before. (See Fig.10.)
(6) Attach the pu. shaft holder B to the chassis unit with the

screw E as before. (See Fig.10.)

Chassis unit

Pu. shaft holder A

Pu. shaft

F

Pickup

k

Feed sub holder

Pickup

Rail

Feed nut
spring

Fig.12

m

F

Pickup

E

Pu. shaft holder B

Fig.10

Chassis unit

Fig.13

(No.MA392<Rev.002>)1-19

3.2.9 Removing the trigger arm
(See Fig.14)

• Remove the top cover, base board, chassis unit and clamper

assembly.
(1) From the top side of the chassis unit, remove the trigger

arm spring from the sections (n, p).

(2) From the bottom side of the chassis unit, release the claws q

of the trigger arm base in the direction of the arrow to remove
them from the sections r of the chassis unit to the other side.

Note:

When releasing the claws q, take care not to break them.

(3) From the top side of the chassis unit, move the select arm R

and select lock arm in the direction of the arrow to remove
the trigger arm base from the section s in the direction of the
arrow.

(4) Remove the trigger arm from the section t.

3.2.10 Removing the top plate assembly
(See Fig.15)

• Remove the top cover, base board, chassis unit, clamper assembly

and trigger arm.
(1) Remove the screw H attaching the top plate assembly.
(2) Move the top plate assembly in the direction of the arrow to

release the joints (u, v).

Reference:

Remove the wires from the soldered sections w of the top plate
assembly as required.

Note:

When reassembling, solder the wires as before.

Select lock arm

Trigger arm
spring

u

v

Select arm R

s

n

t

p

Chassis unit

Top plate assembly

Chassis unit

Trigger arm base

Trigger arm

q

r

Fig.14

H

w

Wire(Red)

1-20 (No.MA392<Rev.002>)

Wire(White)

Wire(Brown)

Fig.15

3.2.11 Removing the mode switch

(See Fig.16)

• Remove the top cover, base board, chassis unit, clamper assembly,

trigger arm and top plate assembly.
(1) From the top side of the top plate assembly, remove the

link gear spring from the sections x of the link gear L and
link gear R.

(2) Remove the link gear L in an upward direction while releasing

the claws y of the link gear L in the direction of the arrow.

(3) Move the mode switch in the direction of the arrow 1 to remove

the sections z of the top plate assembly.

(4) Move the mode switch in the direction of the arrow 2 and

remove the mode switch from the sections (aa, ab).

Note:

When reattaching the link gear L, attach it after aligning the
hole ac of the link gear L to the hole ac of the link gear R.

Reference:

When reassembling, reverse the above removing procedure.

Top plate assembly

Link gear spring

Link gear R

Link
gear R

ac ac

Link gear L

Link
gear L

aa

Fig.16

Mode switch

x

1

2

z

y

y

ab

(No.MA392<Rev.002>)1-21

3.2.12 Removing the select arm R and select lock arm
(See Figs.17 and 18)

• Remove the top cover, base board, chassis unit, clamper assembly,

trigger arm and top plate assembly.
(1) From the top side of the top plate assembly, remove the

link gear spring from the sections ad of the link gear L and
link gear R. (See Fig.17.)

(2) Remove the link gear R in an upward direction while releasing

the claws ae of the link gear R in the direction of the arrow.
(See Fig.17.)

(3) Move the select arm R in the direction of the arrow 1 to remove

the sections af of the top plate assembly. (See Fig.17.)

(4) Move the select arm R in the direction of the arrow 2 and

remove the select arm R from the sections ag. (See
Fig.17.)

(5) From the bottom side of the top plate assembly, remove

the select lock arm spring from the section ah. (See
Fig.18.)

(6) From the top side of the top plate assembly, remove the section

aj of the select lock arm from the top plate assembly at first and
remove the sections (ak, am) of the select lock arm from the top
plate assembly. (See Fig.18.)

Note:

• When removing the select lock arm spring, be careful not to
lose it. (See Fig 18.)

• When reattaching the link gear R, attach it after aligning the
hole an of the link gear R to the hole an of the link gear L.
(See Fig.17.)

Reference:

When reassembling, reverse the above removing procedure.

ak

ae

1

2

af

ae

Select arm R

ad

ag

Link gear R

Select lock arm

aj

Link gear spring

Top plate assembly

Link gear L

Link
gear R

an an

Fig.17

Top plate assembly

Link
gear L

1-22 (No.MA392<Rev.002>)

Select lock
arm spring

ah

am

Fig.18

3.2.13 Removing the loading roller assembly
(See Figs.19 to 21)

• Remove the top cover, base board, chassis unit, clamper assembly

and top plate assembly.
(1) From the left side of the chassis unit, remove the screw J

attaching the lock arm assembly. (See Fig.19.)

(2) Remove the projection ap of the lock arm assembly from

the joint aq while opening the cam plate R in the direction
of the arrow. (See Fig.19.)

(3) Remove the lock arm assembly from the projection ar of

the chassis unit. (See Fig.19.)

(4) Remove the projection as of the lock arm assembly from

the joint at of the cam plate L assembly. (See Fig.19.)

(5) From the right side of the lock arm assembly, remove the

loading roller spring L from the section au. (See Fig.20.)

(6) From the top side of the lock arm assembly, remove the loading

roller spring R in the direction of the arrow and remove the loading
roller assembly. (See Fig.20.)

(7) Remove the roller guide R, HL washer and roller guide L

from the both ends of the loading roller assembly. (See
Fig.21.)

aq

J

ap

Lock arm assembly

Loading roller assembly

Cam plate R

Fig.19

Chassis unit

Cam plate L assembly

ar

Loading roller spring R

at

as

Lock arm assembly

Loading roller
spring L

au

Fig.20

Roller guide L Roller guide R

HL washer

Loading roller assembly

Fig.21

(No.MA392<Rev.002>)1-23

3.2.14 Removing the loading gear 1, loading gear 2, loading gear 3 and feed gear 1
(See Fig.22)

• Remove the top cover, base board and chassis unit.

(1) From the bottom side of the chassis unit, pull out the loading

gear 1.
(2) Take out the loading gear 2.
(3) Pull out the loading gear 3.
(4) Pull out the feed gear 1.

3.2.15 Removing the loading gear 4, loading gear 5 and
loading gear 6
(See Fig.22)

• Remove the top cover, base board and chassis unit.

(1) From the bottom side of the chassis unit, remove the screw

K attaching the loading gear bracket.

(2) Take out the loading gear bracket and remove the loading

gear 5 and loading gear 6 from the loading gear bracket.

(3) Pull out the loading gear 4.

Loading gear bracket

Loading gear 3

Feed gear 2

Loading gear 6

Loading gear
bracket

Loading gear 4

Loading gear 1

Loading
gear 5

K

3.2.16 Removing the change gear 2, change gear 3A and
change gear 3B
(See Figs.22 and 23)

• Remove the top cover, base board and chassis unit.

(1) From the bottom side of the chassis unit, pull out the loading

gear 1. (See Fig.22.)
(2) Pull out the change gear 2. (See Fig.22.)
(3) Pull out the change arm. (See Fig.22.)
(4) Move the change gear plate rivet assembly in the direction

of the arrow 2 to remove the section av of the change gear

plate rivet assembly from the chassis unit while moving the

change lock lever in the direction of the arrow 1. (See

Fig.23.)
(5) Pull out the change gear 3A and change gear 3B from the

change gear plate rivet assembly. (See Fig.23.)

3.2.17 Removing the cam plate L assembly
(See Fig.24)

• Remove the top cover, base board, chassis unit, clamper assembly,

top plate assembly and loading roller assembly.
(1) From the left side of the chassis unit, slide the cam plate L

assembly in the direction of the arrow.

(2) Remove the cam plate L assembly from the slots aw of the

chassis unit.

Feed gear 1

Chassis unit

Change gear plate rivet assembly

Change gear 3B

1

Chassis unit

Change lock lever

Chassis unit

Change arm

Fig.22

2

Fig.23

Loading gear 2

Change gear plate
rivet assembly

Change
gear 3A

Change gear 3B

Change gear 3A

av

aw

1-24 (No.MA392<Rev.002>)

aw

Cam plate L assembly

Fig.24

3.2.18 Removing the cam plate R

(See Fig.25)

• Remove the top cover, base board, chassis unit, clamper assembly,

top plate assembly and loading roller assembly.
From the right side of the chassis unit, remove the cam plate R
from the slots ax of the chassis unit.

Reference:

When a slide hook rivet assembly and a trigger rack spring have

come off from the chassis unit, attach them before attaching the

cam plate R.

3.2.19 Removing the trigger rack plate

(See Figs.25 and 26)

• Remove the top cover, base board, chassis unit, clamper assembly,

top plate assembly, loading roller assembly and cam plate R.

(1) Remove the slide hook rivet assembly and trigger rack

spring from the chassis unit. (See Fig.25.)

(2) From the bottom side of the chassis unit, pull out the loading

gear 1. (See Fig.26.)

(3) Remove the trigger control spring from the sections (ay,

az). (See Fig.26.)

(4) Take out the trigger rack plate from the chassis unit. (See

Fig.26.)

Reference:

When attaching the trigger rack plate, insert the projection a'

of the chassis unit in the slot b' on the bottom side of the trigger

rack plate as before. (See Fig.26.)

Chassis unit

ax

Cam plate R

b'

Trigger rack spring

Slide hook rivet assembly

ax

Fig.25

Trigger control spring

az

a'

Trigger
rack plate

Trigger rack plate

Loading gear 1

ay

Chassis unit

Fig.26

(No.MA392<Rev.002>)1-25

3.2.20 Removing the spindle motor assembly
(See Figs.27 and 28)

• Remove the top cover, base board, chassis unit and clamper

assembly.
(1) From the top side of the chassis unit, turn the turn table from

side to side and remove the two screws M attaching the
spindle motor assembly through the hole of the turn table.
(See Fig.27.)

(2) From the bottom side of the chassis unit, turn the change

gear 2 in the direction of the arrow 2 while pulling the trigger
arm in the direction of the arrow 1 and let the pickup move
in the direction of the arrow 3. (See Fig.28.)

(3) Slide the spindle motor assembly in the direction of the arrow

and take out it in an upward direction from the chassis unit.
(See Fig.28.)

Reference:

Remove the wires from the soldered sections c' on the base
board and remove them from the sections (d', e') on the chassis
unit as required.

Chassis unit

Wire(black)

Wire(red)

M

Fig.27

Spindle motor assembly

d'

Turn table

e'

Change gear 2

c'

Base board

3

Pickup

2

1

Trigger arm

Chassis unit

Fig.28

1-26 (No.MA392<Rev.002>)

SECTION 4

ADJUSTMENT

4.1 Test instruments required for adjustment

(1) Digital oscilloscope (100MHz)
(2) Electric voltmeter
(3) Digital tester
(4) Tracking offset meter
(5) Test Disc JVC :CTS-1000
(6) Extension cable for check

EXTSH002-22P x 1

4.2 Standard measuring conditions

Power supply voltage DC14.4V(10.5 to 16V)
Load impedance 20K.(2 Speakers connection)
Output Level Line out 2.5V (Vol. MAX)

4.5 How to connect the extension cable for adjusting

Caution:

Be sure to attach the heat sink and rear bracket onto the power amplifier IC and regulator IC respectively, before supply the power.
If voltage is applied without attaching these parts, the power amplifier IC and regulator IC will be destroyed by heat.

4.3 Standard volume position

Balance and Bass &Treble volume : lndication"0"
Loudness : OFF

4.4 Dummy load

Exclusive dummy load should be used for AM,and FM.
For FM dummy load, there is a loss of 6dB between SSG output
and antenna input.
The loss of 6dB need not be considered sincedirect reading of
figures are applied in this working standard.

Extension cable
EXTSH002-22P

(No.MA392<Rev.002>)1-27

4.6 Service mode

Service mode setting

(1) Push POWER BUTTON (Power ON)
(2) Set to service mode
Keep this state more 2 seconds while connecting pressing the [SEL] button, [STANDBY/ON ATTENUATOR] button
and [SOURCE] button sequentially.
(3) Select the menu with [ ] button and [ ] button, and decide it with [1] button.
(4) When the [3] button is pushed, it returns to the former menu.

Service mode (MENU)

Service Mode
ROM Correction
Data Clear
Tuner Service Mode
CD Service mode
Bluetooth Version
HD Service Mode

Service Mode

Version
Error Read
CD Data Read

ROM Correction

MAIN Data Clear
VER MAIN ***

Version

MAIN **** Panel V***
HD V*** USB V***
CH V***

Error Read

OK: Function

CD Data Read

OK: Function

CD Error Read
USB Error Read
CH Error Read

Total Error :****
E1 ****** E3 ******
E2 ******
1 ****** 4 ******
2 ****** 5 ******
3 ******

ADJ NOW
ADJ INT
OTHERS

FEB *** FEO*** TEB***
FGA *** TEO*** TGA***
RFG ***

IOP TEMP I**T
TEMP MAX*** IOP INT**
P TOTAL ****H

ADJ NOW
ADJ INT

OTHERS

Data Clear

Initialize All
Name Clear
CD Error Clear
USB Error Clear
CH Error Clear
Init Bluetooth
Init HD Radio

1-28 (No.MA392<Rev.002>)

Tuner Service Mode

TU=M***
D/****** SPI=****
PI =**** **.*
SM=*.**V SQ=*.**V
PI =**** **.**
TP/TA=*/* FSTR=***
MS/DI=*/* DEV=**
AJCH=*** ISS=***
PTY=**** No Name
VER=****
AF
** ** ** **
** ** ** **
** ** ** **

RDS Engineer Mode

SYNC =*
PIC =*s

OK: Function

AFC =*s
SMTH1=*.**
SMTH2=*.**
SQ =**H
SM L =**H
SMM1 =**H
SMM2 =**H
ERR1 =**H
SYNC =***
AFSYN=***
TUR =** **
TUW =** **

CD Service Mode

FEBC =** FGADD=**
TEBC =** TGADD=**
FEOF =*** TEOF =***
RFGC=**

Bluetooth Version (It is displayed in Bluetooth adaptor connection.)

SW BT_CORE ***
HW BT_MODULE ***
SW BT_MODULE ***
SW HIDEAWAY ***
ADR-*******

HD Service Mode (It is displayed in HD Radio Tuner connection.)

SM **
IDM V***
MP **
ADJ **
IFBW *
IF ******
QI **
SNR **
BCNT *
AGAIN **

(No.MA392<Rev.002>)1-29

DSP Tuner Adjust

Auto Adjust
Manual Adjust

Auto Adjust Only the factory setup.

No use.

Manual Adjust

1.FM DAA

87.5 40dBuV 0%
Press OK

1.FM DAA

87.5 40dBuV 0%
No signal

2.FM DAA

97.9 40dBuV 0%
Press OK

3.FM DAA

108.0 40dBuV 0%
Press OK

4.FM S Meter

97.9 30dBuV 0%
Press OK

5.FM S Meter

97.9 60dBuV 0%
Press OK

6.FM Full Sepa

97.9 70dBuV
Lch Press OK

7.FM IF Counter

97.9 70dBuV 0%
Press OK

2.FM DAA

97.9 40dBuV 0%
No signal

3.FM DAA

108.0 40dBuV 0%
No signal

4.FM S Meter

97.9 30dBuV 0%
High or Low or No signal

5.FM S Meter

97.9 60dBuV 0%
High or Low or No signal

6.FM Full Sepa

97.9 70dBuV
Adjust NG or No signal

7.FM IF Counter

97.9 70dBuV 0%
Adjust NG or No signal

8.AM S Meter
999 26dBuV 0%
Press OK

9.AM S Meter
999 56dBuV 0%
Press OK

10.AM IF Counter
999 56dBuV 0%
Press OK

Manual Adjust
COMPLETED

1-30 (No.MA392<Rev.002>)

8.AM S Meter
999 26dBuV 0%
High or Low or No signal

9.AM S Meter
999 56dBuV 0%
High or Low or No signal

10.AM IF Counter
999 56dBuV 0%
Adjust NG or No signal

POWER

POWER OFF
(Adjust Mode FINISH)

5.1 16 PIN CORD DIAGRAM (for KD-APD89)

SECTION 5

TROUBLESHOOTING

8

7

6

5

4

3

2

1

8

16

5

BK

RD

NC

BL/WH

WH

GN

VI

GY

BK

YL

BL/WH

YL

OR/WH

NC

BR

WH/BK

GN/BK

VI/BK

GY/BK

16

15

14
13

12

11

10

9

BK

RD

BL

WH White

GN

Black

Red

Blue

Green

VI

GY

YL

OR

BR

Violet

Gray

Yellow

Orange

Brown

15

7

13

3

11

2

10

4

12

1

OR/WH

RD

BR

GN

GN/BK

VI

VI/BK

WH

WH/BK

GY

GY/BK

9

(No.MA392<Rev.002>)1-31

5.2 16 PIN CORD DIAGRAM (for KD-PDR80)

BK

RD

BL

WH

OR

Black

Red

Blue

White

Orange

8

7

6

5

BL/WH

4

WH

3

2

1

BK

RD

NC

GN

VI

GY

GN

VI

GY

YL

YL

OR/WH

NC

NC

WH/BK

GN/BK

VI/BK

GY/BK

Green

Violet

Gray

Yellow

16

15

14
13

12

11

10

9

8

16

15

5

3

11

10

4

7

2

BK

YL

RD

OR/WH

BL/WH

GN

GN/BK

VI

VI/BK

WH

WH/BK

12

GY

1

GY/BK

9

1-32 (No.MA392<Rev.002>)

5.3 16 PIN CORD DIAGRAM (for KD-PDR61, KD-G847, KD-PDR62)

8

7

6

BL/WH

5

4

3

2

1

7 RD

16 YL

15 OR/WH

8 BK

6 BL/WH

13 BR

BK

RD

NC

WH

GN

VI

GY

YL

OR/WH

NC

BR

WH/BK

GN/BK

VI/BK

GY/BK

16

15

14

13

12

11

10

9

ACC

MEMORY

ILL

GND

REMOTE

TEL

BK

RD

BL

WH

BR

Black

Red

Blue

White

Brown

GN

VI

GY

YL

OR

Green

Violet

Gray

Yellow

Orange

RD

1

3

5

7

RD 7

YL 4

6

8

5

2

NC

NC

BL/WH

RD

BR

YL

OR/WH

BK

2

4

6

8

RR

FR

FL

3 GN

11 GN/BK

2 VI

10 VI/BK

4 WH

12 WH/BK

1 GY

9 GY/BK

Rear Right

Front Right

Front Left

RL+

RL-

RR+

RR-

FL+

FL-

FR+

FR-

ANT

ACC

TEL

Auto Antenna

ACC Line

Telephone Muting

7

8

1

2

5

6

3

4

VI/BK

GY/BK

WH/BK

GN/BK

2

4

6

8

VI

1

3

GY

5

WH

GN

7

RL

REMOTE

ILL

Rear Left

Remote

Illuminations Control

GND

MEMORY

Ground

Memory Backup Battery+

(No.MA392<Rev.002>)1-33

5.4 16 PIN CORD DIAGRAM (for KD-G844, KD-G845)

BK

8

7

RD

YL

16

15

OR/WH

BK

Black

GN

Green

6
5

4
3

2

1

BL

BL/WH

WH

GN

VI

GY

16 YL

8 BK

7 RD

15 OR/WH

3 GN

11 GN/BK

2 VI

14

NC

NC

13

WH/BK

12

GN/BK

11

10

VI/BK

GY/BK

9

MEMORY

GND

ACC

ILL

RL+

RL-

RR+

RD

BL

Red

Blue

WH White

VI Violet

GY

YL

Gray

Yellow

OR Orange

GND

RR

FR

FL

RL

REMOTE

10 VI/BK

4 WH

12 WH/BK

1 GY

9 GY/BK

5 BL/WH

6 BL

Rear Right

Front Right

Front Left

Rear Left

Remote out

RR-

FL+

FL-

FR+

FR-

REMOTE

ANT

ANT

ACC

ILL

GND

MEMORY

REMOTE

OUTPUT

ONLY

POWER

ANTENNA

Auto Antenna

ACC Line

Illuminations Control

Ground

Memory Backup Battery+

1-34 (No.MA392<Rev.002>)

5.5 16 PIN CORD DIAGRAM

8
7

6
5

4
3

2

1

BL/WH

BK

RD

NC

WH

GN

VI

GY

7 RD

16 YL

15 OR/WH

8 BK

5 BL/WH

YL

OR/WH

NC

NC

WH/BK

GN/BK

VI/BK

GY/BK

16
15
14

13

12

11
10

9

ACC

MEMORY

ILL

GND

REMOTE

BK

RD

BL

Black

Red

Blue

WH White

OR

Orange

GN

VI

GY

YL

Green

Violet

Gray

Yellow

RD

1

3

5

7

NC

NC

BL/WH

RD

RD 7

YL 4

NC

YL

OR/WH

BK

6

8

5

2

4

6

8

3 GN

11 GN/BK

2 VI

10 VI/BK

4 WH

12 WH/BK

1 GY

9 GY/BK

RR

FR

FL

RL

Rear Right

Front Right

Front Left

Rear Left

RL+

RL-

RR+

RR-

FL+

FL-

FR+

FR-

REMOTE

ACC

MEMORY

GND

ILL

Remote out

ACC Line

Memory Backup Battery+

Ground

Illuminations Control

7

8

1

2

5

6

3

4

VI

1

GY

3

WH

5

GN

7

VI/BK

GY/BK

WH/BK

GN/BK

2

4

6

8

(No.MA392<Rev.002>)1-35

SCHEMATIC DIAGRAMS

CD RECEIVER

KD-APD89J, KD-PDR80J, KD-PDR61E

KD-PDR61EX, KD-PDR61EY, KD-G844UI

KD-G845U, KD-G845UN, KD-G845UT

KD-G845UH, KD-G847EE, KD-PDR89UR

KD-PDR62E, KD-PDR62EX, KD-PDR62EY

DVD-ROM No.SML2008Q2

(KD-APD89)
(KD-PDR80)

(KD-PDR89)

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)

Contents

Block diagram
Standard schematic diagrams
Printed circuit boards

COPYRIGHT 2008 Victor Company of Japan, Limited.

(KD-APD89)
(KD-PDR80)

(KD-PDR89)

(KD-APD89)
(KD-PDR80)

(KD-PDR89)

2-1
2-2
2-7 to 8

(KD-PDR61)

(KD-G847)

(KD-PDR62)

No.MA392SCH<Rev.002>

2008/7

2-1

SAOUT SAOUT (LEVELM)

Block diagram

MEMORY

TU1,Q1

FM/AM

TUNER

IC71
RDS

DETECTOR

FSU, SSTOP, TUSDA, TUSCL, Q-OUT, AFS

RDSDA
RDSCL

MUX

X71

4.332MHz

Used for KD-PDR61,KD-G847

AUX
INPUT

AUX.L/R

ACC5V

RED
GREEN

CN741

CN742

CN601

PJ601

CN603

CN701

D650

POWER LED

ILM.10V

IC604,Q603,Q604

LCD REG.

LCD, AUX/USB Jack & Key control section Sub section

D640 to D647,D660 to D671

Q640 to Q643

LIGHTING DISPLAY

ILM.10V

ILM.10V

EJECT

S2441

EJECT

SW

D2441

to

D2443

LED

S601 to S616,Q601,Q602

KEY MATRIX

KEY0
KEY2
KEYIN

KEY1

VOL1
VOL2

KEYDATA
DISPDATA
DISPCE
DISPCLK

KEYDATA
DISPDATA
DISPCE
DISPCLK
SRST (RST)
REMOCON
OPEN_SW (OPEN)

Q610 to Q621

LED DRIVER

IC601

LCD

MICON

A0, D0 to 7
LCDRD, LCDWR, LCDCS, LCDRST

COLOR1
COLOR2
COLOR3

IC603

REMOCON

LCD

MODULE

D648,D649

LCD

LIGHTING

IC541

D.SERVO

& DSP

IC581

CD L.P.F.

IC491
IC492

DAC

IC401,X401

CLOCK GEN.

VF1
VF2
VT1
VT2
MD

BUS0 to 3
BUCK
/CCE
REQ
RFOK
SRAMSTB

CN602

LEVELM
AUX.L/R

LEVELM
AUX.L/R

IC701

CPU

IC161

E.VOLUME

Q891

TEL MUTE

IC301

POWER AMP.

IC901

REGULATOR

EACH BLOCK

TU.L/R

TU.L/R

STEERING

OUTLF/RF
OUTL2/R2

FL/FROUT
RL/RROUT

FL+/­FR+/­RL+/­RR+/-

VOLDA
VOLCK
VOLMUTE

J1
ANT

SPK
BATTERY

CN901

KEYDATA
DISPDATA, DISPCE, DISPCLK
REMOCON
OPEN, EJECT

REMOCON

S617

OPEN SW

OPEN_SW

OUTL/R

/DACMS
DACMC
DACMD
DACSEL

CD.L/R

CD.L/R

EN601

ENCODER / POWER SW

SRST

IC602

RESET

CH.L/R

CH.L/R

3.3V,SW5V,ACC5V,VDD5V,CD8V,9V,ILM.10V

ACC, REMOTE

MEMORY

ANTCNTL
POWER

ILLUMINATION

ILM.ADJ

Used for KD-APD89

Used for
KD-PDR80, KD-APD89

Used for KD-APD89, KD-PDR61

Used for KD-APD89, KD-PDR61, KD-G847

Used for except KD-APD89

IC801,IC802

JVC BUS

BUSSO
BUSSI
BUS-I/O
BUSINT
BUSSCK

SI/SO
BUSCK

J801J321

CHANGER
CONTROL

CD servo control section

TELMUTE

TELMUTE

Q976,Q977

PS2

Q701

D724,D729

DISPRST

PS2

DISPRST

RST

Q881

DIMMER INPUT

DIMIN

DIMOUT

AMPKILL

Q901,Q902

DIMMER

CONTROL

CDON CTRL

Q711,Q712

X702

32.768kHz

CD_BCK
CD_LRCK
CD_DATA

MUTE

MUTE

1B1

D851

POWER

ANTENNA

Used for
KD-G844, KD-G845

ANT ANT

X701

20MHz

IC361

4V AMP.

REAR/
SUB WOOFER

FRONT

CN702
STEERING
REMOTE

Q781,Q782,Q784
MUTE CONTROL

Q321,Q331

LINE OUT

MUTING

IC501,Q502
CD DRIVER

FMO, DMO, TRO, FOO

LM0, LM1

FEED+/­SPINDLE+/­FOCUS+/­TRACKING+/-

PSW
SW1, SW2

CDON

1.5V VDD

1.5V SRAM VDD

VDD_5V

IC461,Q481,Q482

1.5V REG.

VDD_5V5V

Q491,Q492
VDD5V SW

X601

16MHz

SWREG

USB_5V

USB_5V

D+/-

D+/-

USB

LOAD/FEED

MOTOR

POSITION

SET SWITCH

SPINDLE

MOTOR

SW1, SW2

PSW

SW1
SW2

FEED+/-

SPINDLE+/-

PICK UP

VF1, VF2
VT1, VT2
LD, MD

FOCUS &

TRACKING

COIL

TRACKING+/­FOCUS+/-

CN001

CN501

IC931
IC691

Q933,Q934

5V REG.

S701

DETACH SW

DETACH

BZ841,Q841

BUZZER

Q571

BUZZER

IC771

EEPROM

EEPROMCK
EEPROMDI

S703

RESET

RESET

TRST

TRST
MUTECTL

MUTECTL

WE
XD0 to 15
XA0 to 11
XA13 to 16

RESET

1.8V

3.3V

XA20, XA21
SD_CS
SD_CLK
SD_CKE

XA12
XA17 to 19
OE, NOR_CS
MODE0

DAO, MCLK, LRCK, BCLK
UTX, URX, D+/-

CN602

CN602

CN601

CN601

X602

12MHz

X603

32.768kHz

IC601

USB DECODER

IC641

FLASH ROM

IC692

1.8V REG.

IC642

SDRAM

IC602

IPOD DECODER

USB
section

CP_READY
IPODRST
/IPOD IIC SCL
/IPOD IIC SDA

SUBMUTE

Q785

UART_TX
UART_RX

Main amplifier & System control section

LD LDO

/RST

LINE OUT

OUTLR/RR

DAO, MCLK, LRCK, BCLK

VDD5V

VDD3.3V

IC703

3.3V REG.

SW5V

3.3V

IC72

TU3.3V REG.

2-2

Standard schematic diagrams

DGND

DGND

DGND

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

3.3V

3.3V

2.8V

5.0V

5.0V

5.0V

0V

0V

4.0V

4.0V

4.0V

4.0V

4.0V

4.0V

0V

0V

3.3V

3.3V

3.3V

3.3V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

5.0V

USED

USEDUSED

USED

USED

USED

N/A

USED

USED

USED

N/A

USED FOR KD-PDR61E & KD-G847EE

*

3.9k

CRS03-W

CRS03-W

CRS03-W

CRS03-W

CRS03-W

CRS03-W

CRS03-W

CRS03-W

( )

( )

( )

( )

( )

( )

( )

( )

1SS355W-X

5.0V

( )

( )

( )

3.3V

( )

( )

( )

RT1N141C-X

RT1N141C-X

3.3k

0.1

100k

1SS355W-X

S-80824CNNB-G-W

2.2k

270

0

RT1N141C-X

NOT USED

1k

0

0

0

0

2k

2k

*

TO CD SECTION

QNN0490-001

QNN0815-001

QNN0815-001

QNN0815-001QNN0815-001

J321

*

*

*

*

*

4.7kohms

4.7kohms

4.7kohms

5.1kohms5.1kohms

24kohms

24kohms

12kohms

12kohms

12kohms

QAU0485-001

QAU0484-001

QAU0484-001QAU0484-001

QAU0484-001

R82 & R92

R81 & R91

TU1

*

*

CN601

N/A

USED

N/A

N/A

CN602

CN741

USED

TO SUB-BOARD CONNECTOR

N/A

N/A

N/A

UPD78F1167GC1Q

R795

R757

10k

10k

N/A

QAM0569-002

USED

N/A

10k

10k

2700/16

USED

C841,R841,Q841

BZ841 USED

QAM1087-001

QAM0306-003

EEPROM

QAM0569-002

( )

100/6.3

100/6.3

( )

( )

4.7K

0.0047

0.0047

0.0047

0.0047

QAM1044-001

N/A

47K

47K

QTE1H64-225Z

47K

1000p

1000p

0.022

100p

100p

100p

100p

100p

100p

100p

100p

N/A

N/A

N/A

N/A

N/A

5V REGULATOR

3.2V

3.3V

2.6V

5.1V

0V

0V

NC

GND

ILM.10V

VDD

N/A

N/A

N/A

N/A

N/A

0V

5.1V

GND

GND

D-

D+

AUX.G

STATIC GND

AUX.L

AUX.G

OUTB

GND

ILM.ADJ

3.3V0VANT.CTRL

ANT

0.1V

0.4V

MEMORY IN

SW5V

0.4V

EXT

(

0V

CD8V

10.1V

CTRL

(8.0V)0.1V

(

(

USBRX

5.1V

3V

3V

3.2V

0V

0V

USBTX

USBRST

USBMUTE_CTRL

0V

BUSIO

BUSSO

BUSSI

0V

QUAL

T57

OSCO

BUSCLK

DISPCE

0V

0.6V

AFS

(4.9V)2.8V

9.2V

SSTOP

0V

5.2V

5.1V

QUALYOUT

FSU

(

5.0V

4.4V

STAGE1

2.3V

4.2V

(

DIMOUT

NC

OSCI

LEVEL(NC)

TEST

TEMP(NC)

NC

(

(

NC

(

(

0.7V

0V

(

NC

(

MODE

NC

(

(

GND

AVREF0

(

(

MUX

3.2V

CIN

( )

0.1V

3.2V

0V

0V

0V

0V

SCOUT

0V

0V

3.3V

3.2V

3.2V

3.3V

VDD5V

3.2V

0V

3.2V

3.2V

0V

0V

0V

DACSEL

OPEN

AVREF

DISPCK

3.2V

3.2V

Vref

5.6V

5.0V

5.6V

0V

0V

NC

0V

0V

5.1V

DATA

Vdd

GND

CLK

DISPDATA

NC

(1/8W)

(1/8W)

(1/4W)

NC

REQ

KEYDATA

REMOTE

SWREG

10/16

Vdd

A0

A1A2WPIN

MUTING

GND

PSW

GND

NOTES

ALL E.CAPACITORS ARE SHOWN IN THE FORM OF CAPACITANCE(uF)/RATED VOLTAGE(V)

ALL CAPACITANCE VALUES ARE IN uF(P=pF)

ALL RESISTANCE VALUES ARE IN OHM.

ALL CAPACITORS ARE 50V OR 25V CERAMIC CAPACITOR.

ALL RESISTORS ARE 1/16W 5% METAL GLAZE RESISTOR.

UNLESS OTHERWISE SPECIFIED.2.

CONDITION---FM MODE. AM MODE. ( )CD MODE.

1. VOLTAGES ARE DC-MEASURED WITH A DIGITAL VOLT METER WITHOUT INPUT SIGNAL

MPX-OUT

AFS

SW2

3.2V

3.2V

0.1V0V0V

0V

0V

3.2V

3.2V

3.2V

3.2V

3.2V

0V(3.2V)

3.2V

3.2V

3.3V

3.2V

3.2V

3.3V

3.3V

2.5V

1.1V

1.1V

1.1V

1.4V

NC

3.3V

QUALIOUT

VCC_8.5V

0V

0V

3.2V

(0V)

(0V)

(3.2V)

3.3V

(3.2V)

(3.2V)

(3.2V)

L-OUT

(0.3V)

3.3V

(3.2V)

(3.2V)

(3.2V)

R-OUT

(3.2V)

(3.2V)

(3.2V)

(3.2V)

(0V)

(0V)

3.3V

MOTORSEL

(0V)

0V

0V

LM

SCL

SDA

SSTOP

GND

BUS3

BUS2

FSU

BUS1

GND

FM-ANT

AM-ANT

BUS0

VDD

SW1

RST

CCE

BUCK

SFSY

SRAMSTB

DACMD

0V

0V(3.2V)

0V

0V

4.4V

0V

0V0V0V

0V

0V

0V

0V

0V

0V

ACC.IN

ACC5V

9V

N/A

DACMC

DACMS

0V

MUTE

GND

VOLCK

VOLDA

0V

0V

0V

8.0V

8.0V

8.5V

3.2V

N/A

N/A

5.1V

0V

4.3V

0V

3.3V

3.3V

0V

3.2V

9.2V

NC

USED

3.3V

VOLMUTE

CDON

3.2V

3.2V

8.5V

0V

GND

GND

REAR/SUBWOOFER R

8.3V

8.5V

1.2V

0.3V

8.3V8.5V

REAR/SUBWOOFER L

FRONT L

FRONT R

13.7V

0V

0V

BUZZER

RT6N430C-X

GND

5p

9.0V

8.0V

3.2V

3.2V

4.8V

3.2V

3.3V

(

N/A

N/A

QTE1H64-225Z

0V

USED

USED

R771,C771,R772

USED

3.2V

8.0V

9.0V

1.0V

VDD

USED

0V

OUTA

0V

FB4

POWER

.

.

5p

3.3V

TO USB MODULE

5.0V

5.0V

3.3V

3.3V

3.3V

0V

USED

USED

0V

7.0V

0V

0V

POWER CORD ASS'Y

0V

3.3V

*

FUSE 15A

5.1V

3.3V

0.01

( )

( )

( )

0V

7.0V

14.4V

14.4V

5.1V

4.6V

3.3V

CIN1

RLOUT

AUX.R

0V

( )

2.4V

2.5V

5.1V

3.2V

0V

3.3V

2.4V

3.3V

0V

2.5V

2.4V

7.0V

0V

2.4V

3.2V

RDS DETECTOR

2.4V

7.0V

7.0V

7.0V

3V

3V

2.4V

5.1V

0.4V

0.4V

0.1V

0V

0V

0V

0V

7.1V

7.1V

7.0V

7.0V

7.1V

7.1V

10.1V

7.1V

7.1V

0V

PS1

PS2

STEERING

ANTCTRL

TELMUTE

TELMOUT(NC)

DIMIN

0V

0V

10.1V

0V

0V

0V

0V

SUBMUTE

AMPSW

TUSDA

TUSCL

VDD

1.3V

ANTENNA

VDD(XTAL)

GND

3.3V

FB2

GND(XTAL)

RLIN

V+

REGC

X1

X2

FLMDO

CRS03-W

CTRL

XT1

XT2

RESET

DEBUGDA

RRIN

DEBUGCLK

RDSDA

RROUT

NC

NC

BUZZER

RDSSCK

REMOCON

BUSINT

EPROMDO

EPROMDI

47/16

CIN2

FLAG

FLAG

0V

5.0V

1.0V

1.0V

1.0V

5.1V

14.4V

5.0V

KD-G847EEKD-PDR61E

KD-G844UI

KD-G845U

KD-APD89JKD-PDR80J

( )

USED

10/16

4V AMP

USED

0V

REGULATOR

LINE OUTPUT

RESET

3.3V

IC701 (MICON)

PRE-GND

*

( )

( )

LINE OUT

DET OFFSET

( )

1000p

D903

5.1V

*

( )

1/8W

STBY

RT

EN

GND

GND

100/10

( )

INV

CPU

FB

SW

VIN

NC

GND

VIN

( )

VOUT

USED

47/6.3

STBY

GND

VIN

VOUT

MAIN PWB: GEB10238A

( )

TO USB MODULE

*

1000p

N/A

(1/10W)

N/A

(1/10W)

( )

N/A

(1/10W)

CTRL

( )

B

0V

A

SCL

SDA

E.VOLUME

SE2R

SE1L

VDD

MUTE

VREF

JVC BUS

POWER AMP.

OUTLF

WIN_IN

1.3V

OUTLR

TELMUTE

STEERING

14.4V

OUTRR

OUTRF

TUNER

FM/AM

13.7V

13.7V

EPROMCK

OUTL2

GNDCREF

COMPONENTS IN () INDICATE NOT USE.

( )

SE1R

SE2L

11.0V

3.

(1/10W)

0V

SE5R

SE5L

A-GND

0.01

SE4R

*

1/50

SE3R

COUT2

RST

( )

N/A

BUZZER

IC771,

OUTFL-

GND

GND

*

3.3V

10/16

0V

0.01

VCC_8.5V

Y2

Y2

A1

A1

G

G

A2

A2

Y1

0V

NC

N.C

0V

EPROM

GND

RT1P141C-X

( )

VDD

0V

GND

( )

FROUT

Parts are safety assurance parts.

1/50

(1/8W)

N.C

INFL

OUTFL+

OUTRL+

OUTRL-

MUTE

INRL

RIPPLE

GND

OUTFR-

GND

OUTFR+

INFR

INRR

OUTRR-

GND

VCC3/4

GND

TAB

OUTRR+

VCC1/2

AC-GND

STBY

Y1

G

G

MEMORY.IN

SI/SO

N.C

( )

USED FOR KD-APD89J

( )

( )

GND

Vdd

SCL

( )

FB3

FRIN

3.3V

REF

( )

FLIN

( )

FB1

(1/8W)

UN2211

FOR

FLOUT

0V

DOMESTIC

USED

DIMMER INPUT

UN2111

sure to use the specified one.

When replacing those parts make

2.2K

SE3L

( )

VCC

VCC

CHANGER CONTROL

( )

DiffGnd

*

*

NOT USED

SDA

DiffL

*

SE4L

*

DiffR

( )

LMOUT

POWER CORD

*

UPD78F1167GC1QUPD78F1167GC1P

DGND

COUT1

TELMUTE

POWER

GND

( )

& QAM0686-001

CN702,D712,C718

( )

( )

( )

STEERING REMOTE

OUTR2

ANT

4.7K

GND

A

REAR LEFT(+)

DETACH

( )

( )

N/A

FRONT LEFT(+)

C851,&C852

D851,D852,R851,

AUTO ANTENNA

& R17

FRONT RIGHT(+)

*

REAR RIGHT(+)

RDS COMPONENTS

REAR LEFT(-)

FRONT LEFT(-)

FRONT RIGHT(-)

REAR RIGHT(-)

UPD78F1167GC1P

* REMARKS

ACC

REMOTE

GND

ILLUMINATION

UPD78F1167GC1P

R371~R374

*

NOT USED

4V AMP CIRCUIT

*

( )

(1/8W)

NC

NC

DETACH

EJECT

.

NOT

RT1N141C-X

GND

DGND

MEMORY

TELMUTE

3.3V

BCLK

TRST

UART_RX

UART_TX

LRCK

SUBWOOFER OUTPUT

MCLK

&

DAO

MUTE CTL

USED FOR KD-PDR61E & KD-G847EE

D+

( )

DIMMER CONTROL

USB GND

( )

( )

( )

( )

D-

( )

( )

FR-

RR-

RL-

FL-

RR+

RDSDA

AUX.R

AUX.G

AUX.L

POWER

EEPROMDI

USBTX

USBRX

BUSINT

FL-

OPEN

FL+

KEYDATA

RL-

RL+

TUSDA

TUSCL

RR+

FSU

CD_8V

AMPKILL

BUS-I/O

BUSSO

BUS3

VOLMUTE

SW2

REQ

AUX.R

AUX.L

RDSCL

AUX.G

RR-

RDSDA

FR+

TU.L

FL+

CD.R

CD.L

RDSCL

CH.R

FR+

RL+

BUCK

/CCE

FR-

EEPROMDI

SW1

SSTOP

MUTE_CTL

BUS2

TUSCL

SRAMSTB

DISPCE

BUS1

BUS0

AMPKILL

RFOK

SUBMUTE

VOLCK

VOLDA

BUZZER

D-

CH.L

EEPROMCK

VDD3.3V

RST

CH.R

BUSSI

BUSSO

BUSSCK

BUS-I/O

LM1

TU.R

AFS

ACC5V

CDON

TUSDA

SSTOP

BUZZER

VOLMUTE

SUBMUTE

REMOCON

Q-OUT

BUSSCK

BUSSI

DAO

MCLK

LRCK

BCLK

USBTX

USBRX

BCLK

LRCK

MCLK

DACSEL

DAO

EJECT

SWREG

LEVELM

REMOCON

D+

EEPROMCK

KEYDATA

DACSEL

BUSINT

9V

STEERING

LM0

STEERING

URST

BUZZER

PSW

LEVELM

USB_5V

MUTE

DIMOUT

VDD_5V

DISPRST

SRAMSTB

CDON

REQ

/RST

10V

/CCE

BUCK

OPEN

MUTE

SUBMUTE

DIMIN

BUS3

MUTE_CTL

FSU

RFOK

DISPRST

DISPCK

/RST

/DACMS

BUS2

DACMC

BUS1

DACMD

CH.L

/DACMS

DACMC

DACMD

SWREG

BUS0

Q-OUT

DISPCE

DISPDATA

DISPDATA

VOLCK

DISPCK

LM1

VOLDA

LM0

URST

SW2

SW1

CD.L

PSW

AFS

CD.R

DIMOUT

QMFZ063-150J1

1234567

8

9

1011121314

15

16

C729

0.47

R737

20K

C730

0.47

R6

3.3k

R7

33k

L932

NQLE74M-100X

43

21

IC72

NJM2878F4-33-X

43

21

IC703

NJM2878F4-33-X

C991

0.015

C721

0.01

R243

C723

QEKJ1CM-106Z

C318

4.7/50

C14

0.047

C13

10/16

C12

10/16

R270R28 NI

R765

470

C714

0.01

R786

0

R242

NI

Q702

R751
47K

3

1

2

D729

MC2838-X

-

R749

1K

R750

1K

3

1

2

D728

MC2838-X

-

R748

47k

R747

47k

R746

47k

R306

R308

R305

4.7k

R307

27k

Q301

C932
220/6.3

C931

470/25

R938

47k

C938

0.1

R762

270

Q933

2SA1365/F/-X

R931
47k

R932

1K

Q934

RT1N141C-X

R785

0

C936

0.01

R933

0

R934

0

C852

0.22

R851

10K

C851

10/16

R4

68k

R3

1K

R9

10k

R15

1K

R1047k

R13

4.7k

R14

330

R11

4.7k

R12

330

R722 22K

R736

100

C163

1/50

R779

39K

C781

C173

1/50

16151413121110987654321

IC901
AN34001A

R371

R373

R372

R374

R383

47k

R387

47k

R363

47k

R367

47k

C386

4.7/50

C365

4.7/50
C385

4.7/50

C366

4.7/50

C161

QTE1H57-105Z

C171

QTE1H57-105Z

C168

QTE1A57-107Z

C167

0.0047

C177

QTE1C67-106Z

R165 2.2K

R166

2.2K

C162

2.2/50

C172

2.2/50

R169

10K

R22

12

C4

0.1

C77

47/6.3

R75

C73

2.2/50

R71

0

R73

2.2k

R72

2.2K

X71

QAX0926-001Z

C74

33p

C75

33p

C71

560p

C76

0.01

C72

0.022

R74
100

R21

12

D2 1SS355W-X

D1

1SS355W-X

12345678

910111213141516

IC71

LC72725KM-X

C1

220/10

C2

47/16

R92

4.7k

C78

0.01

R81
12k

C3

0.01

R82

4.7k

R91

12k

R163 330

R168

10K

C990

NI

R725

100

R726

10k

23

8

654

7

1

J801

QNZ0095-001

R732 10k

R881

47K

R701

4.3k

C771

0.047

R772

270

R771

270

1234

5678

IC771

S-24CS16A0Z-G-X

R752 47k

R710

100

S703

QSW0648-001Z

D714 UDZW5.6B-X

Q881

RT1N141C-X

C881

22/16

D971

CRS03-W

C712

0.47

R706

10M

R707

0

C341

NI

C971

0.1

D713

C709

NI

R711

R882

4.7K

R773

0

R705

47k

C705

0.047

C708

0.047

R733

47k

R777

22k

R776

2.2k

R727

47k

C915

0.1

C904

NI

C307
47/16

Q891

RT1N141C-X

Q976

RT1N141C-X

D782

1SS355W-X

Q784

RT1P141C-X

R756

47k

2

J1
QNB0190-001

R753

10k

R343

100

R353

100

R754

10k

R351

2.2k
R341

2.2k

R342

820

R352

820

Q781

RT1P141C-X

C784

100/16

R901

1k

R902

9.1k

R903

4.7k

D901

1N5401-F64

C325

NI

C324

NI

C323

NI

C322

NI

L702

4.7u

C309

4.7/50

R721

8.2K

Q782

2SC3928A/QR/-X

C320

0.022

C713

0.01

C782

C912

0.01

D784

UDZW11B-X

C717

0.1

C315

1/50

R971 2.2k

R723 100

R724 100

D991 NI

D992 NI

D993 NI

D994 NI

D712
UDZW6.2B-X

D708

NI

C382

4.7/50

D706NID704NID702

UDZW6.2B-X

D709

NI

C362

4.7/50

C302

QFV91HJ-474Z

Q977

ISA1530AC1/R/-X

C361

4.7/50

C372

0.0015

C370

0.0015

C371

0.1

R381

33k

R382

22k

D707

UDZW6.2B-X

D705

UDZW6.2B-X

R365

33k

C707

0.47

C317

QTE1C57-476Z

R806

1K

R802

10K

C909

330/6.3

C908

220/10

R819

47k

R385
33k

R386
22k

R366
22k

C710

NI

R362

22k

R361

33k

C381

4.7/50

C913

10/16

191817161514131211

10

987654321

CN901

QNZ0611-001

C367

220/10

12345678910

11 12 13 14 15 16 17 18 19 20

IC361

NJM2792V-X

C369

47/6.3

C368

220/10

C180
1/50

C179

1/50

65432

1

J321

R841

3.3K

C178

1/50

R180

47K

R708

123456789101112131415161718192025 24 23 22 21

IC301

TDA7851F

C961
NI
C962
NI
C963
NI

D903

GS1J-X

R976
27k

R977
12k

Q711

RT1P141C-X

C964
NI
C965
NI

C967
NI

C966
NI

C968
NI

R241 2.2K

R892

47k

R891

1k

C891

0.1

R795

10k

R794

NI

R793

47k

R937

270

C928

4700P

C718

100P

R928

150K

C937

0.1

D995 NI

7654321

IC931

BD9781HFP-W

R929

120K

C704NIC703

NI

321

X701

QAX0916-001Z

D996 NI

D997 NI

C316

4.7/50

C702

27P

C701

22P

R972

2.2k

X702

QAX0401-001

R25

NI

R709

47k

C176

0.22

R26

NI

R761

100

D998 NI

L2

NQL553J-27NX

L3

NQL553J-27NX

C9

NI

R939

15k

C8

NI

R940

62k

C301

QFV91HJ-474Z

L931

NQL71EM-330X

D931

RB051L-40-X

C11

NI

C901

QEZ0870-278

C10

NI

RESET

Q712

RT1N141C-X

R759 100

R764
NI

D719

C706

0.047

X1

R763

0

Q785
RT1P141C-X

3

4

2

1

S701

QSW0451-001

C326

0.022

C92

NI

C82

NI

C93

NI

R715 0

R712
NI

FLMDO

R739 47k

R714 22K

C803

0.047

R718 20K

R720

5.6K

R719 1.2k

R713

47k

65

4

321

Q321

IMX9-W

R783

10K

C308

47/16

3

2

1

D724

MC2836-X

R704

47k

R703

47k

R181

47K

C725

0.47

2

3

1

D891

MC2836-X

D783

MC2836-X

C182

0.0047

Q701

2SC3928A/QR/-X

1234

5678

IC802

TC7WT241FU-X

65

4

321

Q331

IMX9-W

C907

220/10

D972

MA22D39-X

R757 10k

R734

47K

R760 100

TEST

Q841

RT1N141C-X

C319

0.022

R758 NI

R745

100k

1234567891011121314

15 16 17 18 19 20 21 22 23 24 25 26 27 28

IC161
TDA7719-X

BZ841

QAN0023-001Z

C841

1/50

R743

NI

R935

15k

1234

5678

IC691

BD6516F-X

C919

NI

C181

0.0047

R775
1K

R164

0

R798

82K

R741

10k

R742

2.2K

D703

NI

R735

NI

C720

0.015

R893

R782

4.7K

R314

0

C892

R3130

C903

47/16

R303

0

R716 270

Q892

R774

R936

0

R717

270

L701

4.7u

C310

NI

C728

0.047

C321

0.022

R323

100

R333

100

C727
10/16

C391

NBZ0009-127X

R321

2.2k

R331

2.2k

C726

10/16

R322

820

R332

820

43

21

IC702

R744
470k

C765

0.1

C724

0.33

C911

0.1

C905

47/16

C910

10/16

R729

100

R728

100

L122

NQR0007-002X

222120

19181716

1514

13121110

987654321

TU1

3

2

1

D321

MC2836-X

-

R730

100

C802

NI

R731 100

R799

82K

L121

NQR0007-002X

L120

NQR0007-002X

D720

UDZW6.2B-X

D721

UDZW6.2B-X

D722

UDZW6.2B-X

28

27

26

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

CN701

QGB1004K1-28

D723

UDZW6.2B-X

3

2

1

CN702
QNS0283-001

R811

6.8K

R805

0

C801

0.047

R809

47k

R813

1K

R814

100

R807

100K

R930

0

R804

3.9K

R803

6.8K

R801

10K

C304
100p

C303
100p

C314

100p

R808

100

C902

2.2/50

C785

NI

R702

10k

R796

NI

R906

12k

C916

0.47

C929

0.47

R907

1k

D3

NI

R304

0

R905

6.8k

C313

100p

C716

0.1

R812

100K

R5

8.2k

D726

UDZW6.2B-X

R781

47K

D725

NI

100

99

98

97

96

95

94

93

92

91

90

89

88

87

86

85

84

83

82

81

80

79

78

77

76

75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51

50

49

48

47

46

45

44

43

42

41

40

39

38

37

36

35

34

33

32

31

30

29

28

27

26

25242322212019181716151413121110987654321

IC701

R24

NI

R738

2.2k

R740

2.2k

Q901

RT1P141C-X

Q902

RT1N141C-X

C906

0.01

R16

3.3k

3

2

1

D331

MC2836-X

-

C5

0.1

D851

CRS03-W

D701

UDZW6.2B-X

C91

QTE1H57-105Z

C81

QTE1H57-105Z

R797

22k

C83

NI

R18

L1

4.7u

R17

0

R767

2.2k

R120

100

C311

QFV91HJ-474Z

L901

QQR1809-001

R121

100

R769

4.7k

D852

MA22D39-X

R770

4.7k

C711

330/6.3

DEBUGCLK

C6

0.1

R810 3.9K

R768

0

C783
NI

1234

5678

IC801

TC7WT241FU-X

C312

QFV91HJ-474Z

C7

0.22
Q1

RT1N141C-X

C914

100/16

DEBUGDA

Main section

2-3

CD section

9V

0V

0V

1.0V

1.0V

1.6V

1.6V

1.6V

1.6V

1.6V

1.6V

STBY

3A

3B2

3B1

4A

4B2

4B1

OE

VCC

GND

2A

2B2

2B1

1A

1B2

RT1P141C

RT1N141C

10K

10K

10K

10K

MECHA:

TRACKING+

FOCUS+

FOCUS-

TRACKING-

VR

MD

GND

VT1

VF1

VT2

VCC

VF2

LD

GND

VREF

GND

SW1

SW2

TRACKING COILFOCUS COIL

GND

TN2007 QAL0812-004

GND

VREF

VT1

TRACKING-

TRACKING+

FOCUS+

MD

1K

LD

VREF

FOCUS-

VF1

VR

VF2

GND

VT2

VCC

SW2

SW1

1

0.1

0.1

PICK UP

OPTIMA-727A

CN001

HOE

HDU-110

VR001

C003

C002

C001

GND

SPINDLE+

SPINDLE-

SW1

FEED+

FEED-

SPINDLE

LOAD&FEED

MOTOR

MOTOR

POSITION

SW2

SET SWITCH

SW2

SW1

GND GND

PSW

1.5M

20K

1B1

0

0V

22p

22p

22p

22p

( )

22/16

S

DACSEL

BCLK

QTE0J57-107Z

QTE1C57-106Z

100/16

47/6.3

47/6.3

4.7/25

4.7/25

1.6V

0.2V

0V

1.6V

1.6V

0V

0V

0.1V

0V

0V

0V

0V

0.1V

0.1V0V0V0V0V

1.5V

1.8V

0V

2.6V

3.3V

0V

0V

0V

3.3V

0V

0V

0V

( )

( )

( )

( )

( )

1.5V

0V

( )

( )

4.6V

4.6V

4.6V

9.2V

4.6V

4.6V

4.6V

0.8

1.5V

1.5V

5.0V

1.5V

3.7V

3.7V

1.6V

1.7V

1.6V

1.7V

3.3V

1.6V

1.5V

1.7V

1.6V

5.1V

5.0V

4.3V

5.0V

0V

1.7V

1.7V

1.7V

0V

0V

5V

5V

5.0V

2.5V

2.4V

2.4V

5.6V

3.4V

4.9V

1.2V

1.6V

7.2V

3.4V

3.1V

3.5V

3.0V

3.3V

3.2V

3.2V

3.3V

7.2V

1.6V

1.6V

1.6V

1.6V

1.6V

4.9V

1.3V

7.2V

1.6V

5V

0V

0V

1.6V

1.6V

1.6V

1.8V

1.9V

3.3V

1.7V

1.6V

LRCK

MCLK

DAO

1.4V

3.2V

1.3V

1.6V

1.6V

1.6V

1.6V

1.6V

3.2V

1.6V

1.6V

2.1V

1.6V

1.9V

1.2V

1.9V

1.8V

1.8V

1.6V

1.9V

3.2V

1.3V

1.6V

1.6V

1.6V

1.6V

ZEROR

OUTL

1.6V

OUTR

VCOM

1.6V

AGND

VCC

1.6V

NC

1.6V

0V

NCLRCK

1.0V

BCK

DATA

SCKMDMC

/MS

ZEROL

1.6V

1.6V

1.5V

1.6V

1.6V

3.2V

1.5V

1.4V

0.1V

0V

0.1V

1.7V

1.7V

1.7V

0V

3.3V

0V

0V

3.3V

0V

3.3V0V3.3V

0.1V

0.1V

0V

0.1V

3.3V

3.3V

3.3V

3.3V

3.3V

3.3V

3.3V

0V

1.5V

1.4V

3.3V

0V

0V

3.3V

A

1/8W

0V

MAIN PWB: GEB10238A

RFOK

1/8W

GND

0V

VIN

DACMD

DACMC

0V

/DACMS

1.5V VDD

1.5V SRAM VDD

( )

GND

REQ

/CCE

BUCK

BUS3

BUS2

BUS1

SRAMSTB

BUS0

PSW

SW1

SW2

8.2K

LM0

0V

3.3V

/RST

LM1

/RST

TOP VIEW

TOP VIEW

TOP VIEW

3.3V

TO MAIN SECTION

Parts are safety assurance parts.

VOUT

sure to use the specified one.

ALL INDUCTANCE VALUES ARE IN uH

ARE IN OHM

ARE IN uF(p=pF).

1.

ALL E. CAPACITORS ARE SHOWN IN THE FORM OF CAPACITANCE(uF)/RATED VOLTAGE(V

ALL CAPACITANCE VALUES

ALL RESISTANCE VALUES

--- CD MODE.

ALL RESISTOR ARE 1/16W 5%METAL GLAZE RESISTOR.

CONDITIONSIGNAL

1.5V REGULATOR

CD L.P.F.

INPUTWITHOUTVOLTMETER

UNLESS OTHERWISE SPECIFIED.

2.

)

VOLTAGE ARE DC-MEASURED WITH A DIGITAL

GND

Vcc

When replacing those parts make

( )

( )

NOTES:

ALL CAPACITOR ARE 50V OR 25V CERAMIC CAPACITOR.

LPFO

PVREF

VCOF

PVSS3

SLCO

RFI

RFRPI

RFEQO

VRO

RESIN

VMDIR

TESTR

AGCI

RFO

RVDD3

LDO

MDI

RVSS3

FNI2

FNI1

FPI2

FPI1

TPI

TNPC

TNI

PIO2

VCC

PIO1

PIO0

AOUT2(PO5)

AOUT3(PO4)

IRQ

TEST

/CCE

BUCK(CLK)

BUS3(SI)

BUS2(SO)

BUS1

BUS0

/RST

SRAMSTB

VDDM1

VIN1

VIN1-B

VIN1+B

S-GND

VIN-SW

MUTE

VREFIN

VCC-S

REG-OUT

REG-IN

VIN2G

VIN2

VIN3G

VIN3

VIN1+A

VCCP1

VO1+

VO1-

VDD1-2

VO2+

VO2-

VO3+

VO3-

VO4+

VSS1-2

VDDT3-1

VO4-

VIN4G

VIN4

VCCP2

VIN1-A

PIO3

VSS1-3

VDDT3-2

SBSY

SBOK

IPF

SFSY

ZDET

GPINMSDOUT(PO6)

AOUT1(PO7)

BCK(PO8)

LRCK(PO9)

AIN(PI4)

BCKI(PI5)

LRCKI(PI6)

VDD1-3

VSS1-4

AWRC

PVDD3

PDO

TMAXS

TMAX

LPFN

DVSS3-2

LO

DVR

DVDD3

R0

DVSS3-1

XVDD3

X0

X1

XVSS3

IO1(/UHS0)

IO0(/HS0)

FGIN

VSS1-1

VDD1-1

VDDP3

VCOI

VSSP3

DMO

FMO

VREF

TRO

FOO

AVDD3

TEZI

TEI

FEI

SBAD/RFDC

RFRP

RFZI

AVSS3

FMO

DMO

DACMD

VDD_5V

DACMC

/DACMS

SEL_LRCK

DACMC

/DACMS

DACMD

CDON

MD

SEL_BCLK

SEL_DATA

VT1

VT2

RFOK

TRACKING-

TRACKING+

MD

FOCUS+

VREF

FOCUS-

SPINDLE+

LD

SPINDLE-

VF1

VT1

VT2

FEED+

VF2

VF1

LM1

VREFVREFVREF

TRACKING+

TRACKING-

FOCUS-

FOCUS+

SPINDLE-

FEED-

FEED+

SPINDLE+

REQ

/CCE

BUCK

GND

BUS3

BUS2

BUS1

/RST

PSW

CD.R

CD8V

SRAMSTB

CD.L

SW1

TRACKING-

TRACKING+

MD

LD

LM1

FOCUS+

VREF

FOCUS-

SPINDLE+

LD

SPINDLE-

VR

PSW

VF1

SW2

VT1

SW1

VT2

GND

VCC

FEED+

VF2

GND

SW1

FEED-

SW2

GND

SEL_BCLK

BCLK

SEL_LRCK

CD_BCK

TRO

DMO

PSW

LRCK

SW2

CD_LRCK

FOO

VR

SEL_DATA

DAO

SEL_CLK

TRO

REQ

CD_DATA

CD_DATA

CD_BCK

SEL_CLK

CD_LRCK

BUS3

BUS2

MCLK

DACSEL

DACSEL

DAO

MCLK

BUS1

LRCK

FEED-

BCLK

BUS0

BUS0

/RST

FMO

VF2

SRAMSTB

/CCE

BUCK

LM0

LM0

RFOK

FOO

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

2

1

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

-+

12345

109876

-+

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

4

3

2

1

4

3

2

1

C495

0.1

L492

NQL79GM-470X

43

21

IC461

NJM2878F4-15-X

R485

0

R483

0

R484

0

Q481

2SA1365/F/-X

C464

0.1

C463

0.1

C462

100/6.3

C465

100/6.3

C471

100/6.3

C481

100/6.3

C482 0.01

Q482
RT1N141C-X

C461 0.1

C472 0.01

L471 47u

C401 0.1

R493 100

R492 100

R491 100

R531

1M

L491
47u

R490

1.2k

Q492

RT1N141C-X

R494 47

R496 47

R495 47

C491

100/6.3

C493

10/16

C492

0.1

C494

0.1

12345678

910111213141516

IC491

PCM1780-X

C553

0.01

C540

NI

C579

NI

C538

47/16

C594
820p

R546 100k

C584
820p

R583

24k

R593

24k

C597

0.1

R497

47

C596

QTE1C57-107Z

C583

QTE0J57-476Z

C590

QTE1E57-475Z

C580

QTE1E57-475Z

R561 10k

R567 10k

R553 22k

C559

47/16

R542

10k

R541

100

R543

100

R568

10k

D501 1A3G-T1

C582

150p

C550 0.1

C592

150p

R596

8.2k

RFDC

R595 30k

R588 10k

C593

QTE0J57-476Z

C526

NI

C525

NI

C560 0.1

C524

NI

C523

NI

L403

1.8u

L402

1.8u

C505

0.1

L401 47

R499

47k

R562 10k

R401

NI

R576

NI

R405 1K

1234567

8 9 10 11 12 13 14

IC401
TC74VHCU04FT-X

X401
QAX0927-001Z

L532

47u

C403
15p

C402
12p

L531

47u

R404

1M

R563 100

R564 100

R565 100

C531 0.001

R598 10k

C578 0.01

R599

1.5k

R587 10k

R589

1.5k

R585 30k

R586

8.2k

1234

8765

IC581

NJM4580E-X

R597 10k

R591

0

R581

0

R566 100

R552

15k

R482

1k

PIO2

PIO1

PO5

PO4

C573 0.033

R481 47K

R462 100

R461 100

R535

3.3k

C517

120p

C591
100p

R524
150

VREF

ARF

R554

0

R555

0

Q491

2SA1365/F/-X

R557

0

Q571

2SA1708/ST/-T

C575

100/6.3

C574

0.01

R556

0

R57822R577

22

C552 0.1

C551

0.1

R575 2.2k

C547
47/16

C549 NI

C548 0.1

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

CN501

QGB2027M4-22S

C546

0.1

12345678

910111213141516

IC492

TC7MBL3257AFK-X

C539 0.0056

IO1

IO0

R545

100k

C545 0.1

C544

0.1

C536

0.1

C537

2200p

R532
220

C535 0.018

C534 0.027

R544

100

C533 270p

Q502

2SA1705/ST/-T

C556

0.1

C513 0.01

R514

10k

R513

3.3k

R512 7.5k

R511 10k

C503

220/6.3

R505

5.1k

R504

8.2k

C518 0.01

R517

NI

R515 6.8k

R502 27

R503 27

R520 8.2K

R521 1.5k

R522 100

C504

0.01

R518 3K

C511 0.01

C514

0.047

PIO3

SBSY

SBOK

IPF

SFSY

ZDET

R560 100k

R547 4.7k

L481

47u

C519

0.047

R519 12K

29

301234567 891011121314

1516171819202122232425262728

IC501

LA6242H-X

C512 0.01

C516

0.047

100

99

98

97

96

95

94

93

92

91

90

89

88

87

86

85

84

83

82

81

80

79

78

77

76

75747372717069686766656463626160595857565554535251

50

49

48

47

46

45

44

43

42

41

40

39

38

37

36

35

34

33

32

31

30

29

28

27

26

25242322212019181716151413121110987654321

IC541

TC94A70FG-005A

C581
100p

C515

0.047

R516

NI

C502 100/16

DOUT

AOUT1

BCK

LRCK

AIN

BCKI

LRCKI

C554

0.1

C555

0.1

C561 0.1

C562
47/6.3

C557
47/16

R550 330k

C532 180p

R549 150k

C572
47p

C558 0.1

R551 47k

R548 5.6k

C571

0.015

FEI

C569 0.01

C568 0.0047

C543

0.1

C542

0.033

C567 0.1

C541

0.033

C565 0.015

C564
68p

C563

0.1

C566 0.1

C570 0.01

2-4

USB section

TO MAIN BOARD

TO MAIN BOARD

3.2V

3.2V

3.2V/0V

1.8V

0V

0V

0V

0V

0V

3.2V

0V

1.8V

3.2V 3.2V

3.2V

3.2V

3.2V

3.2V

3.2V

1.6V

2.5V

DGND

DGND

( )

( )

3.2V

BCLK

LRCK

( )

H=AACON

L=AACOFF

H=NODAC

VCC

VSS

#RST/NMI

NC

NC

NC

NC

NC

CLOCK_OUT

SYS_CLOCK_OUT

NC

NCNCNC

NCNCNC

3.2V

NC

NC

0V

L=DAC

( )

DGND

3.3V

D+

2.1V

2.1V

2.1V

2.0V

1.8V

3.2V

3.2V

0V

3.2V

1.8V

0V

3.2V

3.2V

3.2V

3.2V

0V

0V

3.2V

3.2V

1.8V

0V

1.6V

1.6V

1.6V

3.2V

3.2V

0V

3.0V

0V

0V

3.2V

0V

1.2V

1.8V

0V

3.2V

0V

3.2V

3.2V

0V

0V

1.8V

0.9V

0.9V

2.8V

2.9V

3.1V

2.9V

3.2V

1.6V

2.5V

2.5V

1.8V

2.5V

2.6V

0.1V

2.8V

2.8V

1.6V

1.8V

0V

2.0V

2.1V

2.1V

2.1V

2.2V

1.8V

0V

3.2V

2.1V

2.0V

2.1V

2.0V

2.1V

2.1V

2.1V

1.8V

2.4V

0.6V

1.6V

2.2V

1.6V

1.5V

1.8V

0V

3.2V

1.6V

1.8V

0V

0.1V

0.3V

SPI_UCLK

0.1V

2.4V

0.6V

2.2V

1.5V

0.3V

2.1V

1.6V

1.6V

1.6V

1.6V

1.6V

1.8V

1.8V

1.8V

2.9V

2.8V

2.8V

3.1V

2.5V

2.5V

2.1V

2.1V

2.1V

2.1V

2.1V

2.1V

2.1V

2.1V

2.1V

2.1V

2.1V

2.0V

2.0V2.0V

2.0V

3.2V

3.2V

3.2V

3.2V

3.2V

3.2V

3.2V

GPIOA14/EXINT2

GPIOA11/SCL

GPIOA10/SDA

GPIOA2/CLRCK

GPIOA1/CBCLK

nTRST_JTAG

VDDUSB

USBH1D+

USBH1D-

USBH0D+

USBH0D-

VSSADC

VDDADC

ADIN0

2.8V

3.2V

3.2V

0V

2.1V

2.1V

2.1V

2.1V

2.1V

2.0V

2.1V

2.0V

2.1V

2.0V

2.1V

2.1V

2.1V

2.1V

2.2V

2.0V

2.9V

0V

2.8V

1.8V

3.1V

3.2V

3.2V

0.2V

1.4V

1.5V

1.6V

2.4V

0.6V

2.2V

1.6V

1.6V

0.1V

2.6V

0V

2.5V

1.8V

0V

0.1V

0.3V

0V

1.8V

1.6V

2.8V

SPI_SOMI

SPI_SIM0

SPI_NSS

ROSC

0V

0V

3.2V

0V

0V

0V

0V

0V

0V

0V

( )

( )

0V

FLAG/

/CTRL

nCS3/ND_nOE3/GPIOB5

nCS2/ND_nOE2/GPIOB4

0V

0V

ND_nWE/GPIOB7

GPIOB6/IIDE_nCS

MODE2

I2C_SDA

NC

MODE1

MODE0

CP_READY

I2C_ADDR2

0V

I2C_ADDR1

0V

0V

A11

VSS

I2C_ADDR0

0V

0V

GPIOD21/MUTECRTL

MCLK

GPIOA0/SPDIFTX

TDO

TCK

TMS

TDI

D16/SDA/AAC

GPIOD15/UART1CTSn

VDDI

GPIOB25/DAI

VDDPLL1

ADIN2

ADIN4

UART0RX/GPIOB9

UARTOTX/GPIOB8

VSS

VDDI

nCS0/ND_nOE0/GPIOB2

SD_nCS/GPIOB1

SD_CLK

VDDIO

XA21/DQM(0)

XA13/SD_BA(0)

XA14/SD_BA(1)

XA15/SD_nCAS

XA16/SD_nRAS/ND_ALE

XA18/DQM(0)

XA19/DQM(1)

VDDI

XFILT1

D-

MUTE_CONTROL

TRST

UART_RX

UART_TX

3.3V

VDD

VSS

A3 A4

A5

A6

A7

A8

A9

CKE

CLK

UDQM

N.C/RFU

DQ8

VDDQ

DQ9

DQ10

VSSQ

DQ11

DQ12

SDRAM

VDDQ

DQ13

DQ14

VSSQ

DQ15

VSS

A2

A1

A0

A10/AP

N.C

BA1

CS

RAS

CAS

WE

LDMQ

DQ7

VSSQ

DQ6

DQ5

VDDQ

DQ4

DQ3

VSSQ

DQ2

DQ1

VDDQ

DQ0

VDD

FLASH ROM

A0

A9

A10

A11

A12

A13

A14

A15 A16

A17

VSS

D15

D7

D14

D6

D13

D5

D12

D4

VCC

D11

D3

D10

D2

D9

D1

D8

D0

/OE

VSS

/CEA1A2

A3

A4

A5

A6

A7

A8

*/BYTE

NC(A20)

NC(R//B)

NC

NC(VPP)

NC(/RST)

A18

A19

/WE

DGND

VSS

VDDI

GPIOA8/SDA

GPIOA13/EXINT1

GPIOA7/SDI1

GPIOA5/SCK1

GPIOA3/CDAI

GPIOD17/SCL

UART_1TX

/IPOD IIC SCL

/IPOD IIC SDA

/IPOD RST

/Cp_READY

no use

( )

I2C_SCL

( )

DGND

STBY

GND

VIN

VOUT

nCS1/ND_nOE1/GPIOB3

nOE

nWE

NC

NC

CLOCK_ENB

BA0

VDD

XOUT

XIN

VCC

0.5%

GPIOA15/EXINT3/P.DET

UART_1RX

GPIOA9/SCL/BW SD_CKE/GPIOB0

XA7

XD15

XD14

XD13

XD12

XD11

XD10

XD9

XD8

XD7
XD6

XD5

XD4

XD3

XD2

XD1

XD0

XA11

XA10

XA9

XA8

VDDIO

XA6

XA5

XA4

XA3

XA2

XA1

XA0

XA12

VSS

VSS

GPIOD20/UART1CTSn

GPIOB23/MCLK

VDDI

GPIOA12/EXINT0

VSS

0V

VSS

VDDIO

VSS

GPIOB21/BCLK/BM0

VDDIO

VSS

nRESET

VSSPLL

GPIOB24/DAO/BM2

VDDIO

XA17/ND_CLE

GPIOA6/FRM1

MODE1

VDDIO

GPIOA4/SDO1

GPIOB22/LRCK/BM1

XA20/DQM(1)

VDDI

VDDI

XFILT

VDDPLL

XOUT

XIN

VSSPLL1

XTOUT

DAO

GEB10239A

USB PLUS

XTIN

12MHz

DAC SELECTION STAGE

0V

READY/MODE0

( )

JTAG

DGND

16VOR

OR1/10W

1/4WOR

WITHOUT INPUT SIGNAL.

/RATED VOLTAGE (V).CAPACITANCE( F)

IN OHM( ).ALL RESISTANCE VALUES ARE

MYLAR CAPACITOR.50VCERAMIC CAPACITOR50V OR 25V

METAL GLAZE RESISTOR.5%1/8W

OF

ALL E.CAPACITORS ARE SHOWN IN THE FORM

ALL CAPACITANCE VALUES ARE IN F(P=pF).

ALL RESISTORS ARE

OR

ALL CAPACITORS ARE

UNLESS OTHERWISE SPECIFIED.2.

CONDITION ---

VOLT METERVOLTAGES ARE DC-MEASURED WITH A DIGITAL

USB MODE

1.

NOTES

1K

Parts are safety assurance parts.

sure to use the specified one.

When replacing those parts make

4.7K

XA0

WE

XA16

XA15

XA14

XA13

XA12

XA11

XA10

XA9

XA8

XA19

XA18

XA17

XA7

XA6

XA5

XA4

NOR_CS

XA3

XA2

XA1

OE

RESET

MODE0

XD0

XD8

XD1

XD9

XD2

XD10

XD3

XD11

XD4

XD12

XD5

XD13

XD6

XD14

XD7

NOR_CS

XD6

XD7

XA21

WE

XA15

XA16

SD_CS

XA13

XA14

XA10

XA0

XA1

XA2

XA3

XD15

XD14

XD13

XD12

XD11

XD10

XD9

XD8

XD5

XD4

XD3

XD15

SD_CLK

SD_CKE

XD2

XA11

XA9

XA8

XA7

XA6

XA5

XD0

XA4

TMS

TCK

XD0

XD1

XD2

XD3

XD4

XD5

XD6

XD7

XD8

TDO

XD9

XD10

XD11

XD12

XD13

XD14

XA21

XA19

XA18

XA17

XA16

XA15

XA14

XA11

XA10

XA9

XA8

XA7

XA6

XA5

XA4

XA3

XA2

XA1

XA0

XA20

OE

WE

XA20

XA13

TDI

XD1

MODE0

XA12

XD15

RESET

SD_CS

IPODRST

IPODRST

D1.8v

CP_READY

CP_READY

SD_CLK

SD_CKE

URX

URX

D3.3V

MCLK1

UTX

DAO1

MCLK1

UTX

BCLK1

LRCK1

LRCK1

BCLK1

DAO1

R652

0

R694

10K

R693

10K

R696 100K

R690

100

R684

0

R683

NI

R699

33

R698

33

R681

NI

R682

NI

R680

5.1M

R628

0

R627

1K

R610 0

R640

47K

R646

4.7K

R6399

100

R653 0

C683

22P

C684

22P

X603
NAX0966-001X

L6398

NQL093K-1R8X

L608

NQL093K-R12X

L607

NQL093K-1R8X

L602

NQL093K-R12X

C643

0.1/16

C647

0.1/16

C646

0.1/16

C645

0.1/16

C642

22/6.3

C644

0.1/16

K641

NQR0502-001X

C649

0.1/16

C641

0.1/16

R648

47K

R647

0

R645NI

123456789101112131415161718192021222324

25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48

IC641

SA16D90TFI011G

C682 0.1

C681

0.1

R621

4.7K

R635

4.7K

R606

4.7K

R605

4.7K

R604 4.7K

1

2

3

4

8

7

6

5

RA601

NRZ0065-472X

C680

47/10

TRST

TDO

TCK

C691

4.7/16

TMS

C692

0.1/16

L603

NQL093K-R12X

C648

22/6.3

TDI

C621

0.1

C605

0.0012

R6394

47

R6396

47

R6397

47

R626

0

C640 0.15

40

39

38

37

36

35

34

33

32

31

30292827262524232221

20

19

18

17

16

15

14

13

12

11

10987654321

IC602

MFT341S2094-X

1

234

8

7

6

5

RA680

NRZ0065-102X

R688

4.7K

C612

0.1

C606

0.1

C610 0.1

C609

0.1

C619

0.1

C602

0.1

C616

0.1

C614

0.1

C620

0.1

C618

0.1

C603

0.1

C617 0.1

C6150.1

C613 0.1

R609

1k

C604

0.1

C650

0.1/16

R641

1k

C611 330p

C608

27P

C607

27P

X602

NAX0975-001X

R611

1.5K

5453

1234567891011121314151617181920212223242526

52515049484746454443424140393837363534333231302928

27

IC642
K4S641632K-UC75

R643

0

L601

NQL38DK-330X

10

9

8

7

6

5

4

3

2

1

CN602

QGZ2512M1-10

43

21

IC692

NJM2878F4-18-W

R612

1M

R650

15K

R614

47

R644

NI

R651

15K

8765432

1

CN601
QGZ2512M1-08

128127126125124123122121120119118117116115114113112111110109108107106105104103102101100

999897

96

95

94

93

92

91

90

89

88

87

86

85

84

83

82

81

80

79

78

77

76

75

74

73

72

71

70

69

68

67

66

65

64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33

32

31

30

29

28

27

26

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

IC601

TCC8600

2-5

Sub board section

SUB-BOARD PWB: GEB10237A

NSW0246-001X

USB_5V

ACC5V

VDD3.3V

10V

USB_5V

RST

USB_5V

CD

STATIC

USB_GND

AM MODE.

NI STANDS FOR NOT INSERTED PARTS3.

F --- FILM CAPACITOR

ALL E.CAPACITORS ARE SHOWN IN THE FORM OF CAPACITANCE(uF)/RATED VOLTAGE(V)

ALL CAPACITANCE VALUES ARE IN uF(P=pF )

ALL RESISTANCE VALUES ARE IN OHM.

ALL CAPACITORS ARE 50V OR 25V CERAMIC CAPACITOR.

ALL RESISTORS ARE 1/10W +5% METAL GLAZE RESISTOR.

UNLESS OTHERWISE SPECIFIED.2.

1. VOLTAGES ARE DC-MEASURED WITH A DIGITAL VOLT METER WITHOUT INPUT SIGNAL

CD

( ) FM MODE,CONDITION --- CD MODE,

CN701

EJECT

EJECT

( )

( )

( )

( )

TO MAIN BOARD

TO PANEL

CHASSIS GND

VCC5V

VCC5V

D-

D+

USB_GND

USB_GND

GND

AUX.L

AUX.G

AUX.R

KEYDATA

SACLK

SAOUT

DISPCLK

DISPDATA

DISPCE

VDD3.3V

OPEN_SW

REMOCON

GND

GND

10V

ACC5V

USB_GND

EJECT

GND

GND

USB_5V

USB_5V

USB_D-

USB_D+

USB_GND

USB_GND

GND

AUX.R

AUX.G

AUX.L

AUX.G

GND

GND

OPEN

KEYDATA

GND

LEVELM

DISPCK

DISPDATA

DISPCE

REMOCON

ACC5V

VDD3.3V

10V

CN601

RST

RST

REMOCON

OPEN

DISPDATA

DISPCE

LEVELM

DISPCLK

KEYDATA

AR

GND

AL

AGND

AV

D-

SACLK

D+

VDD3.3V

RST

OPEN

AGND

AL

AGND

AR

D+

D-

AV

KEYDATA

LEVELM

DISPCK

DISPDATA

DISPCE

REMOCON

SACLK

10V

R2447

0

D2443

LHQ74/LM/-X

2

1

S2441

D2442

LHQ74/LM/-X

D2441

LHQ74/LM/-X

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

CN742

QGZ1201L1-25

R2444 0

R2446 0

R2443

820

R2442

680

R2445 0

R2441

0

28

27

26

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

CN741

QGB1004J2-28X

2-6

LCD & Key control section

0V

0V

330

330

4.7K

4.7K

3.27V

3.27V

4.7K

6.95V

7.12V

8.21V

7.07V

7.17V

3.208V

2.974V

0V

0V

3.26V

3.26V

10.08V

10.08V

9.36V

9.37V

10.03V

10.03V

3.25V

3.25V

3.28V

3.28V

3.27V

3.27V

3.27V

1.32V

3.22V

3.18V

3.18V

3.17V

3.17V

3.16V

3.17V

3.21V 3.17V

3.23V

3.28V

0V

3.27V

3.27V

3.28V

3.26V

3.26V

3.26V

3.26V

3.28V

1.6V

1.62V

3.26V

3.28V

0V

3.28V

0V0V0V0V0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V

0V0V0V

0V

3.26V

3.26V

3.28V

3.28V

3.28V

LCDVOUT

0V

3.258V

0V

5.1V

200

200

5.08V

0V

2.57V

-2.48V

5.08V

UDZW3.98-X

UDZW3.98X

UDZW3.98X

UDZW3.98X

UDZW3.98X

UDZW3.98X

UDZW3.98X

UDZW3.98X

NCB20JM-475X

( )

( )

7p

7p

0.01

0.022

0.022

0.047

0.047

0.047

47K

47K

22K

47K

-5.02V

SWITCH PWB: GEB10236A

1%

1%

1M

CN742

15K

15K

( )

( )

0

NVP0021-683X

0.01

4.7uF

( )

( )

( )

( )

( )

( )

( )

|<<

>>|

LCDWR

( )

CNVSS

( )

( )

( )

0

( )

( )

( )

( )

( )

( )

( )

( )

( )

4.7/6.3

( )

B

A

COM

COM

SW

( )

34 2

LED

( )

REMOCON

POWER

POWER

POWER

POWER

UP

NC

GND RST

VDD

E8_EPM

E8_BUSY

PTTX

PTRX

PTCK

E8_BUSY

KEYDATA

DISPDATA

GEB10236A2

DISPCLK

OUT

GND

VCC

PWR/ATT

NC

NC

PTCKNCPTAX

0V

( )

( )

DISP

15MODE

4.96V

5.16V

SEL

0V

SRC

BANDEQ

E8_EPM

|<<DOWN

10V

DISPDATA

GND

KEYDATA

SACLK

PTTX

DISPCLK

DISPCE

VDD3.3V

GND

ACC5V

SAOUT

REMOCON

VDD

RST

0V

0V

0V

3.28V

NC

NC

LCDRD

NC

LCDWR

NC

LCDCS

FLASHCS

NC

NC

AVCC

VREF

AVSS

RY/BY

KEY0

KEY1

KEY2

3.28V

THERMAL

ANA

NC

MEMRST

D0

3.28V

3.27V

3.27V

D1

D2

D3

D4

D5

D6

3.27V

D7

A19

A18

A17

A16

A15

GND

A14

3.265V

TO SUB-BOARD CONNECTOR

A13

A12

A11

A10

A9

VCC2

A8

VSS

A7A6A5A4A3A2A1

P17

P16

P15

P14

P13

P12

P11

P10

NC

NC

NC

NC

SACLKNCNC

NC

( )

LCDRST

KEY_IN

DISPCENCNMI

VCC1

XIN

VSS

S601-S616: NSW0206-001X

XOUT

RESET

XCOUT

RESET

MICON IC601

FOR PROGRAMMING

INK002AU1-X

UDZW3.98X

IRS

6

3.277V

3.28V

XCIN

VR

V5

V4

V3

V2

V1

C2+

C2-

C1-

C1+

EQ

OPEN

SEL12

3

456

MODE

DISP

BAND

C3-

VOUT

VSS2

VSS

VDD

D7

D6

D5

D4

D3

D2

D1

D0

RDb

UDZW3.98X

WRb

A0

RESb

CS1b

( )

( )

( )

( )

VCC

D-

D+

GND

( )

( )

( )

2.765V

2.54V

2.514V

AUX IN

PWR / ATT

DOWN

UP

2.748V

2.974V

3.208V

2.963V

( )

Chassis GND

2.0V

8.25V

VCC5V

VCC5V

D-

D+

USB GND

USB GND

6.95V

GND

7.07V

2.146V

1.914V1.898V

2.13V

2.514V

1.92V

7.12V

8.21V

7.17V

2.963V

2.518V

1.92V

8.25V

( )

CNVSS

BYTE

VOL1

VOL2

GREEN

CN010G

RED

COLOR3

AUX.L

COLOR1

TO LCD

AUX.G

COLOR2

CL

Parts are safety assurance parts.

sure to use the specified one.

A0

|<<

AUX.R

OPEN_SW

When replacing those parts make

10k

KEYIN

C2C1C3

COLOR1

KEY1

KEY2

LCDRD

LCDCS

SAOUT

KEYDATA

DISPDATA

DISPCLK

OPEN_SW

SRST

D6

D5

D4

D3

D2

D1

D0

KEY0

KEYDATA

D+

SAOUT

DISPDATA

10V

D7

D6

D5

D4

D3

D2

D1

D0

LCDRD

LCDWR

A0

LCDRST

C3C2C1

COLOR2

COLOR1

KEYIN

DISPCLK

COLOR3

COLOR2

COLOR3

SRST

E8_EPM

E8_BUSY

PTCK

PTRX

PTTX

PTTX

PTRX

ACC5V

OPEN_SW

LCDCS

D7

RED

COLOR2

PTCK

LCDWR

LCDVOUT

E8_BUSY

E8_EPM

D-

GREEN

VOL1

VOL2

LCDVOUT

SACLK

A0

GREEN

REMOCON

DISPCE

LCDRST

VOL2

VOL1

RED

10V

LCDWR

CNVSS

CNVSS

KEY0

COLOR3

KEY2

KEY1

SACLK

COLOR1

REMOCON

VDD3.3V

DISPCE

R6021

NI

R6052

0

R6050

0

R698

NI

R6039

68k

D626

UDZW5.1B-X

R677

1k

R6046

NI

R6037

0

R672

1.3k

R671

1.3k

R670

1.3k

R669

1.3k

Q604

RT1N141C-X

D624

MA22D23-X

C611

1uF

C617
1uF

D625

MA22D23-X

R6051

0

D645

NECBB205/WPQR/X

C612
1uF

D646

NECBB205/WPQR/X

C613
1uF

D647

NECBB205/WPQR/X

C610

4.7
C608

4.7

C609

4.7

C681

NCJ11EK-106X-R

C614
1uF

C615
1uF

C618

NI

D622

MA22D23-X

D623

MA22D23-X

Q603

RT1P141C-X

R637

0

R636

NI

54

321

IC604

MAX829EUKG-X

Q605

NI

R6032

3.9K

D650

SML-D12V8W/PQ-X

T3-10

T3-9

R6024

27k

R633 10k

R632NI

R635

0

R631

NI

C635
NI

R6020
0

R6045
0

Q641

2SA1365/F/-X

R675

4.7K

R676

4.7K

Q643

RT1N141C-X

Q640

2SA1365/F/-X

R673

4.7K

R674

4.7K

Q642

RT1N141C-X

2

3

4

1

PJ601

QNS0215-001

R641

1.3k

R640

1.3k

R645

1.3k

R644

1.3k

R647

NI

R646

560

R653

1.3k

R652

1.3k

R655NIR654

560

R657

1.3k

R656

1.3k

R659

NI

R658

560

R650

560

R651

NI

R618 330

R619

330

R620

330

R613 10K

R660

1.3k

R661

1.3k

R662

560

R663

NI

4

D670

CL-165HR/HG5-X

4

D671

CL-165HR/HG5-X

4

D661

CL-165HR/HG5-X

4

D660

CL-165HR/HG5-X

4

D663

CL-165HR/HG5-X

4

D662

CL-165HR/HG5-X

4

D665

CL-165HR/HG5-X

4

D664

CL-165HR/HG5-X

4

D667

CL-165HR/HG5-X

4

D666

CL-165HR/HG5-X

C6560.47

C6550.47

4

D668

CL-165HR/HG5-X

R6029

10k

C6540.47

R691

1.5k

21

S614

R685

1.5k

21

S607

C621 NI

C620 NI

R692

300

R608

47k

R6051k

R6041k

C633

0.1

1

2

3

X601

NAX0752-001X

D601 NI

D603 NI

D644

NECBB205/WPQR/X

D643

NECBB205/WPQR/X

R616

10k

3

4

1

2

5

EN601

QSW1231-001

R697

1.3k

R665

1.3k

R664

1.3k

43

21

IC602

S-80824CNNB-G-W

5

6

7

8

4

3

2

1

RA604

NRZ0065-331X

5

6

7

8

4

3

2

1

RA605

NRZ0065-331X

4

D669

CL-165HR/HG5-X

R643NIR642

560

R649

1.3k

R617

10k

R611 10k

R680

300

2

1

S601

R681

270

R648

1.3k

2

1

S602

C603

NI

C602

NI

D608 NI

D609 NI

D607 NI

D606 NI

D605 NI

D602 NI

D604 NI

C6530.47

R6027

47k

R6026

2.2k
D618

1SS355W-X

C642

0.047

C641

0.047

C640

0.047

432

1

1608

D648

NSCM315C/Z/-W

C630

0.047

C605

0.047

C6010.047

C631

4.7/6.3

C607

10/6.3

TH601

NAD0028-103X

R622 1k

R6044
0

R6038NI

R6002 390

R627 1.5k

R615

15k

5

6

7

8

4

3

2

1

RA601

NRZ0065-472X

567

8

432

1

RA602

NRZ0065-472X

R628 1.5k

R629 1.5k

R601

100k

R603100k

R602

100k

5

6

7

8

4

3

2

1

RA603

NRZ0065-472X

T1-5

T1-6

T1-7

R668

220

C634

NI

R6030

470

T2-7

T2-6

T2-5

R696

470k

Q602
ISA1530AC1/R-X

R693

270

R686
300

R687

270

R689

560

R688
390

R690

820

R684

820

R682
390

C645

0.047

C644

0.047

C643

0.047

R679

1.3k

R699

0

R695
47k

R694
47k

R6004 560

R6005 560

R6006 560

R6008 390

R6003 390

R6001 390

R6007 390

R6017

390

R6009 390

Q610

2SC3928A/QR/-X

Q611

2SC3928A/QR/-X

Q612

2SC3928A/QR/-X

Q613

2SC3928A/QR/-X

D612

UDZW6.2B-X

D610

UDZW6.2B-X

D611

UDZW6.2B-X

R6013 560

R6014

560

R6015

560

R6011

390

R6012

390

R6010

390

R6016

390

T2-4

R6018

390

Q614

2SC3928A/QR/-X

Q615

2SC3928A/QR/-X

T2-8

T2-9

T2-10

Q616

2SC3928A/QR/-X

Q617

2SC3928A/QR/-X

T1-4

T1-8

T1-9

T1-10

R6036

0

R6031

NI

R626

10k

Q618

2SC3928A/QR/-X

Q619

2SC3928A/QR/-X

R6028

0

T3-8

T3-7

R6047NIR6048NIR6049

NI

D613

UDZW6.2B-X

D614

UDZW6.2B-X

D615

UDZW6.2B-X

T3-6

432

1

D649

NSCM315C/Z/-W

Q620

2SC3928A/QR/-X

T3-4

3

1

2

D621

MC2838-X

Q621

2SC3928A/QR/-X

T3-3

2

1

S617

NSW0308-001

321

IC603

NJL29H380A

C624

10/6.3

L601
47u

T3-2

T3-1

C604

0.047

R667

NI

D642

NECBB205/WPQR/X

R6023

130k

R6022

1M

C616
1uF

R612 330

T3-5

D640

NECBB205/WPQR/X

R609

2.2K

C660

4.7/6.3

3

1

2

D620

MC2838-X

21

S60321S604

21

S615

2

1

S612

2

1

S613

R610 68

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

CN602

QGF0522F3-30W

C622

NI

C606

0.047

D641

NECBB205/WPQR/X

C6571

C659

0.047

R60610K

R625 10k

R624 10k

R6043
0

R623 10k

C623

NI

R6035

NI

R6033NIR6034

NI

R614 NI

R666

NI

C672

NI

21

S611

21

S606

R630 10K

2

1

S61621S608

21

S609

2

1

S610

R683
560

Q601
ISA1530AC1/R-X

3

41

2

L602

NQR0536-001X

R6041NIR6040

NI

C671

NI

2

1

S605

D617

UDZW5.1B-X

6

5

4

3

2

1

CN603

QNZ0962-001

R607

47k

D616

UDZW5.1B-X

R621 330

100

99

98

97

96

95

94

93

92

91

90

89

88

87

86

85

84

83

82

81

80

79

78

77

76

75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51

50

49

48

47

46

45

44

43

42

41

40

39

38

37

36

35

34

33

32

31

30

29

28

27

26

25242322212019181716151413121110987654321

IC601

M3030RFGPGP

C658

0.47

C670

NI

D619

NI

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

CN601

QGZ1201M1-25W

2-7

Main board

Printed circuit boards

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)

Switch board

(Switch board) (Switch board)

(LED board) (LED board)

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)

F1A

S1A

A

C

E

E

D

D

C

B

B

A

A

GEA10238-

R737

IC802

IC801

PbF

MARK

UL

L932

C765

C495

C723

IC492

C309

R765

R739

R27

R28

C12

C13

IC72

C714

R786

C785

C781

B2

B1

X702

X701

X401

X71

TU1

S703

S701

R977

R972

R971

R940

R939

R937

R934

R933

R932

R931

R929

R928

R715

R906

R903

R902

R901

R893

R881

R841

R802

R819

R814

R813

R812

R811

R810

R809

R808

R807

R806

R805

R804

R803

R801

R799

R798

R783

R782

R781

R775

R773

R772

R771

R770

R769

R768

R767

R762

R761

R760

R759

R754

R753

R750

R749

R745

R744

R743

R742

R741

R740

R738

R736

R735

R732

R731

R730

R729

R728

R726

R725

R724

R723

R722

R720

R719

R714

R712

R711

R710

R709

R707

R706

R705

R702

R701

R935

R596

R595

R593

R591

R586

R585

R583

R581

R578

R577

R576

R568

R567

R566

R565

R564

R563

R562

R561

R560

R557

R556

R555

R554

R553

R552

R551

R550

R549

R548

R547

R545

R544

R543

R542

R541

R532

R531

R522

R521

R520

R519

R518

R516

R514

R512

R511

R505

R504

R499

R493

R492

R491

R490

R482

R481

R405

R401

R386

R385

R382

R381

R374

R373

R372

R371

R366

R365

R362

R361

R351

R341

R331

R321

R314

R313

R308

R306

R305

R304

R303

R181

R180

R169

R168

R166

R165

R163

R121

R120

R92

R91

R82

R81

R75

R74

R73

R72

R71

Q977

Q976

Q934

Q933

Q902

Q901

Q892

Q891

Q881

Q841

Q785

Q784

Q782

Q781

Q712

Q711

Q702

Q571

Q502

Q492

Q491

Q482

Q481

Q331

Q321

Q301

L931

L901

L702

L701

L532

L531

L491

L481

L471

L403

L401

L122

L121

L120

L1

J801

J321

J1

IC931

IC901

C803

IC771

IC703

IC702

IC701

IC691

IC581

IC541

IC501

IC491

IC461

IC401

IC361

IC301

IC161

IC71

D998

D997

D996

D995

D994

D993

D992

D991

D972

D971

B3

D931

D901

D891

D852

D851

D783

D782

D729

D728

D726

D724

D723

D722

D721
D720

D713

D706

D704

D703

D501

D331

D321

10PIN

8PIN

CN901

CN702

CN701

CN501

C971

C968

C967

C966

C965

C964

C963

C962

C961

R797

C938

C937

C936

C932

C931

R796

C928

C919

C914

C913

C910

C909

C908

C907

C905

C904

C903

C902

C901

C892

C891

C881

C851

C841

C801

C784

C783

C771

C727

C726

C725

C711

C710

C709

C708

C597

C596

C594

C593

C592

C591

C590

C584

C583

C581

C580

C578

C575

C573

C572

C571

C568

C567

C566

C564

C563

C562

C561

C559

C557

C555

C554

C553

C552

C550

C549

C548

C547

C546

C542

C541

C539

C538

C537

C536

C531

C519

C517

C516

C515

C514

C513

C512

C511

C505

C503

C502

C493

C492

C491

C481

C471

C465

C462

C401

C391

C386

C385

C382

C381

C372

C371

C370

C369

C368

C367

C366

C365

C362

C361

C318

C317

C316

C315

C314

C313

C312

C311

C308

C307

C304

C303

C302

C301

C182

C181

C180

C179

C178

C177

C173

C172

C171

C168

C163

C162

C161

C92

C91

C82

C81

C78

C77

C76

C73

C72

C71

C2

C1

BZ841

P1A

DATA

TxM

T1A

RxM

F

F

A

TD

GEB10238A

FLMDO

RST

3.3V

GND

A

C729

C730

R7

R6

C991

R243

R485

R484

R483

R497

L492

C723

C309

C14

C12

C13

R785

R5

R242

C785

C781

X702

X701

X401

X71

X1

VREF

TU1

TEST

S703

S701

R976

R938

R936

R930

R907

R905

R901

R892

R891

R882

R851

C721

R795

R794

R793

R779

R777

R776

R774

R764

R763

R758

R757

R756

R752

R751

R748

R747

R746

R734
R733

R727

R721

R718

R717

R716

R713

R708

R704

R703

R599

R598

R597

R589

R588

R587

R575

R546

R535

R524

R517

R515

R513

R503

R502

R496

R495

R494

R462

R461

R404

R387

R383

R367

R363

R353

R352

R343

R342

R333

R332

R323

R322

R307

R241

R164

R26

R25

R24

R22

R21

R18

R17

R16

R15

R14

R13

R12

R11

R10

R9

R4

R3

Q701

Q571

Q502

Q1

L901

L402

L3

L2

L1

J801

J321

J1

IC901

IC301

DEBUGCLK

D903

D901

D784

D725

D719

D714

D712

D709

D708

D707

D705

D702

D701

D501

D3

D2

D1

10PIN

8PIN

CN901

CN702

CN701

CN501

C990

C932

C931

C929

C919

C916

C915

C914

C913

C912

C911

C910

C909

C908

C907

C906

C905

C904

C903

C902

C901

C881

C852

C851

C841

C802

C784

C782

C728

C727

C726

C724

C720

C718

C717

C716

C713

C712

C711

C710

C707

C706

C705

C704

C703

C702

C701

C596

C593

C590

C583

C582

C580

C575

C574

C570

C569

C565

C562

C560

C559

C558

C557

C556

C551

C549

C547

C545

C544

C543

C538

C535

C534

C533

C532

C526

C525

C524

C523

C518

C504

C503

C502

C494

C493

C491

C482

C481

C472

C471

C465

C464

C463

C462

C461

C403

C402

C386

C385

C382

C381

C369

C368

C367

C366

C365

C362

C361

C341

C326

C325

C324

C323

C322

C321

C320

C319

C318

C317

C316

C315

C312

C311

C310

C308

C307

C302

C301

C180

C179

C178

C177

C176

C173

C172

C171

C168

C167

C163

C162

C161

C93

C91

C83

C81

C77

C75

C74

C73

C11

C10

C9

C8

C7

C6

C5

C4

C3

C2

C1

BZ841

ARF

F1A

S1A

GEA10247-

A1

D626

R677

D614

D615

D611

D613

IC603

D612

D650

R697

R679

R635

D610

S616

S615

S614

S613

S612

S611

S610

S609

S608

S607

S606

S605S604

S603

S602

S601

RA605

RA604

RA601

R658

R696

R695

R694

R693

R692

R691

R690

R689

R688

R687

R686

R685

R684

R683

R682

R681

R680

R676
R675

R674
R673

R672

R671

R670

R669

R668

R665

R664

R663

R662

R661

R660

R659

R657

R656

R655

R654

R653

R652

R651

R650

R649

R648

R647

R646

R645

R644

R643

R642

R641

R640

R621

Q643

Q642

Q641

Q640

Q602

Q601

EN601

D671

D670

D669

D668

D667

D666

D665

D664

D663

D662

D661

D660

D

64

7

D

64

6

D
64

5

D

644

D643

D642

D641

D640

D621

D620

PJ601

CN603

R636

P1A

GEB10247A1

V5

T1A

R6052

R6051

R6050

R6049

R6048

R6047

R6046

C618

TEST

D616

IC603

D625

C609

C610

C608

D617

MARK

UL

PbF

R6020

C635

LCDWR

CNVSS

R6045

R6044

R6043

D624

R6024

R637

R633

R632

R631

X601

TH601

E8-EPM

E8-BUSY

PTCK

PTRX

PTTX

VDD

GND

RST

C612

C617

Q603

R6032

Q604

Q605

T1-10

T1-9

T1-8

T1-6

T1-5

T1-7

T1-4

S617

RA603

RA602

IC604

R6041

R6040

R6036

R6035

R6034

R6033

R6031

R6030

R6029

R6028

R6027

R6026

R6023

R6022

R6021

R6018

R6017

R6016

R6015

R6014

R6013

R6012
R6011
R6010

R6009
R6008

R6007

R6006

R6005

R6004

R6003
R6002

R6001

R667

R666

R630

R629

R628

R627

R626

R625

R624

R623

R622

R620

R619

R618

R617

R616

R615

R614

R613

R612

R611

R610

R609

R608

R607

R606

R605
R604

R603

R602

R601

Q621

Q620

Q619

Q618

Q617

Q616

Q615

Q614

Q613

Q612

Q611
Q610

L602

L601

IC602

IC601

EN601

D618

C681

D619

R

69

8

D623

D622

R699

R6039

CN601

PJ601

R6037

D609

D608

D607

D606

D605

D604

D603

D602

D601

CN603

CN602

R6038

C672

C671

C670

C660

C659

C658

C657

C656

C655

C654

C653

C616

C613

C611

C615

C614

C634

C633

C631

C630

C624

C623

C622

C621

C620

C607

C606

C605

C604

C603

C602

C601

forward side reverse side

forward side reverse side

C640

C641

C642

C643

C644

C645

D648

D649

2-8

USB board

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)

forward side

Sub board

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)

forward side

reverse sidereverse side

1P1A

S1A

A

GEA10239-

R653

PbF

X602

TRST

TMS

TDO

TDI

TCK

R6399

L6398

R648

R647

R646

R645

R627

R612
R611

R609

L608
L607
L602
L603

L601

R652

IC641

IC601

CN602

CN601

C648

C641

C621

C620

C619

C618

C617

C616

C615

C614

C613

C612

C611
C610

C609

C608
C607

C606

C604

C603

C602

4P1A

T1A

8 PINS

10 PINS

GEB10239A

R614

IC692

MARK

UL

R651R650

X603

RA680

RA601

R6397
R6396

R6394

R699

R698

R696

R694

R693

R690
R688

R684

R683

R682

R681

R680

R644

R643

R641

R640

R635

R628

R626

R621

R610

R606

R605

R604

K641

IC642

IC602

CN602

CN601

C692

C691

C684

C683

C682

C681

C680

C650

C649

C647

C646

C645

C644C643

C642

C640
C605

F2A

S2A

25

1

GEA10237-

A

PbF

MARK

UL

D2443

S2441

D2442

D2441

CN742

P2A

T2A

GEB10237A

28

1

R2447

R2446

R2445

R2444

R2443

R2442

R2441

CN741

< MEMO >

Victor Company of Japan, Limited

Mobile Entertainment Business Group Mobile Entertainment Category 10-1,1chome,Ohwatari-machi,Maebashi-city,Gumma-ken,371-8543,Japan

(No.MA392SCH<Rev.002>)

Printed in Japan

VPT

PARTS LIST

KD-APD89J,KD-PDR80J,KD-PDR61E

KD-PDR61EX,KD-PDR61EY,KD-G844UI

KD-G845U,KD-G845UN,KD-G845UT

KD-G845UH,KD-G847EE, KD-PDR89UR

KD-PDR62E,KD-PDR62EX,KD-PDR62EY

* All printed circuit boards and its assemblies are not available as service parts.

- Contents -

Exploded view of general assembly and parts list (Block No.M1)

CD mechanism assembly and parts list (Block No.MB)

Electrical parts list (Block No.01~04)
Packing materials and accessories parts list (Block No.M3)

MA392PAR<Rev.002>

3- 2
3- 6
3-11
3-26

3-1

Exploded view of general assembly and parts list

6

n

a

Block No.

M

M

1

M

15

14

14

13

20

17

31

26

19

2

33

24

18

7

35

Fu
bo

6

16

1

B

Except KD-PDR89UR

KD-PDR62E,EX,EY

38

39

48

55

54

59

64

57

57

57

58

D

68

66

7

47

60

37

50

42

7

41

40

53

43

Switch
board

44

45

52

36

56

D

73

51

46

49

3-2

69

71

C

Only KD-APD89J
KD-PDR61E,EX,EY
KD-PDR62E,EX,EY

74

70

B

35

Function
board

29

57

21

22

23

72

19

30

34

8

Main board

8

28

32

25

27

9

10

5

20

3

9

9

C

12

11

63

58

D

62

65

68

66

61

Only KD-APD89J
KD-PDR61E,EX,EY
KD-PDR62E,EX,EY

4

3

67

3-3

General Assembly

Block No. [M][1][M][M]



Symbol No. Part No. Part Name Description Local

1 GE10227-003A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE32823-003A HEAT SINK APD89J,PDR61E,PDR61EX , PDR61EY,PDR62E,PDR62E

3 GE32823-004A HEAT SINK PDR80J,G844UI,G845U,G845UN,G845UT,G845UH,G84
4 GE20242-001A BOTTOM COVER

5 GE33080-001A INSULATOR
6 GE40395-001A SIDE PANEL
7 QYSDST2604ZA TAP SCR EW M2.6 x 4mm(x3)
8 GE40377-002A SCREW (x2)
9 GE40377-001A SCREW (x4)
10 QYSDST2610ZA TAP SCREW M2.6 x 10mm
11 QYSDST2610ZA TAP SCREW M2.6 x 10mm
12 QYSDSF2606ZA TAP SCREW M2.6 x 6mm
13 QYSDSF2606ZA TAP SCREW M2.6 x 6mm(x2 )
14 GE40377-002A SCREW (x2)
15 QYSDST2608ZA TAP SCREW M2.6 x 8mm
16 QYSDST2604ZA TAP SCREW M2.6 x 4mm
17 QYSDST2606ZA TAP SCREW M2.6 x 6mm
18 GE40425-001A SCREW (x2)
19 QYSDST2004ZA TAP SCREW M2 x 4mm(x2)
20 GE40218-084A SHEET (x2)
21 GE33102-001A F.CHASSIS ASSY APD89J,PDR 80J,PDR61E,PDR61EX,P D R6 1EY,G844UI,

21 GE33102-005A F.CHASSIS ASSY PDR89UR,PDR62E,PDR62EX,PDR62EY
22 GE33085-001A OPEN LEVER
23 GE33082-001A EJECT LEVER APD89J,PDR80J,PDR61E,PDR61EX,PDR61E Y,G844UI,

23 GE33082-002A EJECT LEVER PDR62E,P DR 62EX,PDR62EY
24 GE33086-001A DETACH LEVER
25 GE33083-001A LOCK LEVER( R)
26 GE33084-001A LOCK LEVER( L)
27 GE40154-001A GEAR
28 QZW0108-002 OIL DAMPER
29 GE40419-001A TORSION SPRING
30 GE40420-004A TORSION SPRING
31 GE40422-003A TORSION SPRING
32 GE40421-003A TORSION SPRING
33 GE40202-023A COMPRESSION SPRING
34 QYSDSF2006ZA TAP SCREW M2 x 6mm
35 GE40433-001A BLIND
36 GE33101-070A FRONT PANEL ASSY APD89J
36 GE33101-058A FRONT PANEL ASSY PDR80J
36 GE33101-057A FRONT PANEL ASSY PDR61E,PDR 61EX,PDR61EY
36 GE33101-053A FRONT PANEL ASSY G844UI
36 GE33101-054A FRONT PANEL ASSY G845U,G8 45UN,G845UT,G845UH
36 GE33101-055A FRONT PANEL ASSY G847EE
36 GE33101-121A FRONT PANEL ASSY PDR89UR
36 GE33101-0D8A FRONT PANEL ASSY PDR62E,PDR62EX,PDR62EY
37 GE33073-013A FINDER AS SY APD89J
37 GE33073-014A FINDER AS SY PDR80J
37 GE33073-006A FINDER AS SY PDR61E, PDR61EX,PD R 61EY,PDR 62E,PDR62EX,PDR6

37 GE33073-004A FINDER AS SY G844UI,G845U,G845UN,G845UT,G845UH
37 GE33073-007A FINDER AS SY G847EE
37 GE33073-012A FINDER AS SY PDR89UR
38 GE40407-001A SEARCH BTN LENS
39 GE33079-003A SEARCH BTN COV APD89J,PDR89UR
39 GE33079-004A SEARCH BTN COV PDR80J,G847EE
39 GE33079-001A SEARCH BTN COV PDR61E,PDR61EX,PDR61EY,G844UI,G845U,G845UN,

39 GE33079-002A SEARCH BTN COV PDR62E,PDR62EX,PDR62EY
40 GE33069-001A SEARCH BTN BASE
41 GE33070-003A UP DOWN BUTTO N APD89J,PDR89 UR
41 GE33070-004A UP DOWN BUTTON PDR80J,G847EE
41 GE33070-001A UP DOWN BUTTO N PDR61E,PDR61E X,PDR61EY,G844UI,G845U,G845UN,

41 GE33070-002A UP DOWN BUTTO N PDR62E,PDR62E X,PDR62EY
42 GE33071-003A POWER BUTTON APD89J,PDR80J,PDR89UR,PDR62E,PDR62EX,PDR62

42 GE33071-001A POWER BUTT ON PDR61E,PDR 61EX,PDR61EY,G844UI,G845 U ,G845UN,
42 GE33071-005A POWER BUTT O N G847EE

43 GE20241-003A PRESET BU TTON APD89J,PDR89UR,PD R62E,PDR62EX,PDR62E Y

X,PDR62EY
7EE,PDR89UR

G845U,G845UN,G845UT,G845UH,G847 EE

G845U,G845UN,G845UT,G845UH,G847EE,PDR89UR

2EY

G845UT,G845UH

G845UT,G845UH

EY
G845UT,G845UH

3-4



Symbol No. Part No. Part Name Descript i on Local

43 GE20241-001A PRESET BUTTON PDR80J,PDR 6 1E,PDR61EX, PDR61EY,G844UI,G845U,G
43 GE20241-005A PRESET BUTTON G847EE

44 FSYH4036-069 SHEET (x3)
45 GE33074-004A EQ BUTTON APD89J,PDR 8 0J
45 GE33074-002A EQ BUTTON PDR61E,PDR6 1EX,PDR61EY
45 GE33074-001A EQ BUTTON G844UI,G845U,G845UN,G845UT,G845UH
45 GE33074-013A EQ BUTTON G847EE
45 GE33074-019A EQ BUTTON PDR89UR
45 GE33074-018A EQ BUTTON PDR62E,PDR6 2EX,PDR62EY
46 GE33075-003A OPEN BUTTON APD89J,PDR80J,PDR89U R, PD R62E,PDR62EX, PDR62

46 GE33075-001A OPEN BUTTON PDR61E,P DR 6 1EX,PDR61EY,G844UI,G845U,G 84 5U N,
46 GE33075-005A OPEN BUTTON G847EE

47 GE33076-003A RIM COVER APD89J,PDR89UR
47 GE33076-004A RIM COVER PDR80J,G 847EE
47 GE33076-001A RIM COVER PDR61E,P DR 61EX,PDR61E Y,G844UI,G845U,G 845UN,

47 GE33076-002A RIM COVER PDR62E,PDR 6 2EX,PDR62EY
48 GE33077-001A RIM LENS
49 GE33068-003A SIDE COV RIGHT APD89J,PDR89UR
49 GE33068-004A SIDE COV RIGHT PDR80J,G84 7EE
49 GE33068-001A SIDE COV RIGHT PDR61E,PDR 61EX,PDR61E Y,G844UI,G845U,G 845UN,

49 GE33068-002A SIDE COV RIGHT PDR62E,PDR6 2EX,PDR62EY
50 GE40403-001A JVC BADGE
51 GE40202-012A COMPRESSION SP RI N G
52 VK Z4777-011 MINI SCR EW
53 GE40431-001A REMOTE SHEET
54 GE40398-003A VOL KNOB ASSY APD89J,PDR89UR
54 GE40398-004A VOL KNOB ASSY PDR80J,G847EE
54 GE40398-002A VOL KNOB ASSY PDR61E,PDR61EX,PDR61EY,G844UI,G845U,G845UN,

54 GE40398-001A VOL KNOB ASSY PDR62E,PDR62EX,PDR62EY
55 GE40127-005A KNOB SPRING
56 GE10226-007A REAR COVER APD89J,PDR8 0J,PDR61E,PD R61EX,PDR61E Y,G844UI,

56 GE10226-010A REAR COVER PDR89UR
56 GE10226-009A REAR COVER PDR62E,PDR 62EX,PDR62E Y
57 VKZ4777-010 MINI SC REW (x4 )
58 VK Z4777-011 MINI SCR EW
59 GE40218-089A SHEET APD89J,PDR80J,PDR61E , PD R61EX,PDR61 EY,G844UI,

60 GE40218-093A SHEET APD89J,PDR80J,PDR61E , PD R61EX,PDR61 EY,G844UI,
61 GE40218-094A SHEET APD89J,PDR80J,PDR61E , PD R61EX,PDR61 EY,G844UI,
62 GE33066-001A LCD LENS

63 GE33063-001A LENS CASE APD8 9J,PDR80J,PDR61E,PDR61E X, PDR61EY,G844UI,
63 GE33063-002A LENS CASE PDR8 9U R,PDR62E,PDR 62EX,PDR62EY

64 GE33060-001A LCD CASE
65 GE40411-001A LIGHTING SHEET APD89J,PDR80J,PDR61E,PDR61E X, PDR61EY,G844UI,

65 GE40411-002A LIGHTING SHEET PDR89UR,PDR62E,PDR62EX,PDR62EY
66 GE40218-085A SHEET (x2)
67 GE33103-002A NAME PLATE APD89J
67 GE33106-001A NAME PLATE PDR80J
67 GE33115-001A NAME PLATE PDR61E,PDR61EX,PDR61E Y
67 GE33112-002A NAME PLATE G844UI
67 GE33109-002A NAME PLATE G845U,G845UN,G845UT,G845UH
67 GE33118-001A NAME PLATE G847EE
67 GE33334-001A NAME PLATE PDR62E,PDR 62EX,PDR62E Y
68 QLD0511-001 LCD MODULE



69 QMFZ063-150-J1 FUSE 15A
70 GE40396-002A REG BRACKET
71 GE40354-001A IC BRACKET
72 GE33091-002A CON PWB BRACKET
73 GE40416-001A USB HOLDER
74 GE40424-001A OE HOLDING BKT APD89J,PD R61E,PDR61E X, PDR61EY,PDR62E,PDR62E

845UN,G845UT,G845UH

EY
G845UT,G845UH

G845UT,G845UH

G845UT,G845UH

G845UT,G845UH

G845U,G845UN,G845UT,G845UH,G847EE

G845U,G845UN,G845UT,G845UH,G847EE
G845U,G845UN,G845UT,G845UH,G847EE
G845U,G845UN,G845UT,G845UH,G847EE

G845U,G845UN,G845UT,G845UH,G847EE

G845U,G845UN,G845UT,G845UH,G847EE

X,PDR62EY

3-5

CD mechanism assembly and parts list

TN2007-1026

120

Block No.

M

M

B

M

42

A

124

44

52

127

15

33

24

102

36

50

62

51

123

25

26

10

63

14

13

16

112

122

4

120

48

47

12

20

27

79

105

101

43

61

11

35

125

B

64

99

104

45

11

46

106

21

111

121

12

49

59

A

B

80

32

28

86

23

93

87

81

78

130

76

3-6

74

75

71

64

62

a

126

63

a

72

100

120

89

1

120

110

120

92

124

58

77

108

91

90

22

88

2

The parts without symbol number are not service.

3

CD mechanism



Symbol No. Part No. Part Name Descript i on Local

1 30350101T FRAME
2 30350103T DAMPER F (x2)
3 30350104T DAMPER R
4 30350107T TOP COVER
10 30 320513T CLA M PER SUB SPG
11 30 35 0505T FRONT SUS SPG (x2)
12 30 350506T REA R SU S SPRING (x2)
13 30 350508T FEE D N UT SPP
14 30 350509T FEED SCREW HLDR
15 30 350525T PU SH AFT HLDR B
16 30 350528T LOC K LEVER
20 30 350529T LOC K PLATE
21 30 350581T CHA N GE G EAR2
22 30 350582T CHA N GE G EAR 3A
23 30 350583T CHA N GE G EAR 3B
24 30 350535T FEED SU B HOLDER
25 30 350536T PU SH AFT HLDR A
26 30 350539T FD TH RU ST SPP
27 30 350542T CHANGE ARM
28 30 350580T FEE D G EAR 1
32 30 350554T LOC K LEVER SP
33 30 350555T PU SH AFT
35 64 010418T PUS H SW P389-01
36 69 011629T PICK UP OPTIMA-727AD
42 30 350801T TOP P LATE
43 30 350802T SELECT ARM R
44 30 350803T MO DE SWICH
45 30 350806T SELECT LOCK ARM
46 30 350807T SPRING
47 30 350808T TRIGGER ARM
48 30 350809T TRG A RM BASE
49 30 350810T TRIGGER ARM SPR
50 30 350811T LINK G EAR L
51 30 350812T LINK GEAR R
52 30 350813T LINK GEAR SPR
58 19 501403T WIR E CLUMPER
59 30 321013T WIRE C LAMPER
61 30 351001T WIRE C LAMPER
62 30 351008T MO DE SW WIRE
63 30 351003T REST SW WIRE
64 30 351004T LD W I RE
71 30 321137T LDG R O LLER (x2)
72 30 321143T COLLAR SCREW
74 30 351101T LOCK ARM
75 30 351102T LD RO LLER SPR R
76 30 351103T LD RO LLER SPR L
77 30 351105T ROL LER GUIDE R
78 30 351106T ROL LER GUIDE L
79 30 351116T CAM PLATE R (N)
80 30 351111T TR C ONTROL SPR
81 30 351113T SPRING
86 30 351122T LOA DI N G GEAR 1
87 30 351123T LOA DI N G GEAR 2
88 30 351128T LOA DI N G GEAR 3
89 30 351129T LOA DI N G GEAR 4
90 30 351140T LOA DI N G GEAR 5
91 30 351131T LOADING GEAR 6
92 30 351133T LD GEAR BRACKET
93 30 351135T PLATE
99 30 3505309T MORTER ASSY
100 303505302T SPINDLE MOTOR
101 303505303T CLAMPER ASSY
102 303505304T FEED SCREW ASSY
104 303505501T CHASSIS RIVET
105 303505502T CLAMPER ARM RVT
106 303505503T RIVET ASSY
108 303510304T BASE BOARD ASSY
1 1 0 3035113 01T ROLLER SHAF T
111 303511302T CAM PLATE L
112 303511501T SLIDE HOOK RVT
120 9P0420037T SCREW (x5)
121 9C0117187T SCREW (x2)
122 9C0120207T SCREW
123 9C4517506T SCREW

Block No. [M][B][M][M]

3-7



Symbol No. Part No. Part Name Description Local

124 9P0420047T SCREW (x2)
125 9P0420067T SCREW
126 9P0420087T SCREW
127 9C0420257T SCREW
130 9W0513060 T HL WASH ER

3-8

Grease point 1/2

grease

TNG-87
TN-4456

TNS-925R
GP-501MK

back side

1

4

back side

back side

two sides

104

101

44

43

74

3-9

Grease point 2/2

T

grease

TNG-87
TN-4456

TNS-925R
G-322

102

111

26

out side

33

106

79

27

25

16

90

92

99

105

3-10

50

93

back side
TR CONTROL SPR

side
CHF LOCK PL

51

Electrical parts list

Main board

Block No. [0][1]



Symbol

Part No. Part Name Description Local

No.



IC71 LC72725KM-X IC PDR61E,PDR61

IC72 NJM2878F4-33-X IC
IC161 TDA7719-X IC



IC301 TDA7851F IC
IC361 NJM2792V-X IC APD89J
IC401 TC74VHCU04FT-X IC
IC461 NJM2878F4-15-X IC
IC491 PCM1780-X IC
IC492 TC7MBL3257AFK-X IC



IC501 LA6242H-X IC



IC541 TC94A70FG-005A IC
IC581 NJM4580E-X IC
IC691 BD6516F-X IC



IC701 UPD78F1167GC1P IC(PROGRAMED) APD89J,PDR80J



IC701 UPD78F1167GC1Q IC(PROGRAMED) PDR61E,PDR61

IC703 NJM2878F4-33-X IC
IC771 S-24CS16A0I-G-X IC PDR61E,PDR61

IC801 TC7WT241FU-X IC
IC802 TC7WT241FU-X IC



IC901 AN 34001A REGULATOR IC



IC931 BD9781HFP-W IC
Q1 RT1N141C-X DIGI TRANSISTOR

Q1 or UN2211-X TRANSISTOR APD89J,PDR80J

Q321 IMX9-W PAIR
Q331 IMX9-W PAIR
Q481 2SA1365/F/-X TRANSISTOR

Q482 RT1N141C-X DIGI TRANSISTOR
Q482 or UN2211-X TRANSISTOR APD89J,PDR80J

Q491 2SA1365/F/-X TRANSISTOR
Q492 RT1N141C-X DIGI TRANSISTOR
Q492 or UN2211-X TRANSISTOR APD89J,PDR80J

Q502 2SA1705/ST/-T T RANSISTOR
Q571 2SA1708/ST/-T T RANSISTOR

TRANSISTOR
TRANSISTOR

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

,G844UI,G845U,
G845UN,G845U
T,G845UH,PDR8
9UR

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY



Symbol

Part No. Part Name De scription Local

No.

Q701 2SC3928A/QR/-X TRANSISTOR APD89J,PD R80J

Q701 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR80J

Q701 2SD601A/QR/-X TRANSISTOR PDR89UR
Q711 RT1P141C- X DIGI TRANSISTOR
Q711 or UN2111-X TRANSISTOR APD89J,PDR80J

Q712 RT1N141C - X DIGI TRANSISTOR
Q712 or UN2211-X TRANSISTOR APD89J,PDR80J

Q781 RT1P141C - X DIGI TRANSISTOR
Q781 or UN2111-X TRANSISTOR APD89J,PDR80J

Q782 2SC3928A/QR/-X TRANSISTOR APD89J,PD R80J

Q782 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR80J

Q782 2SD601A/QR/-X TRANSISTOR PDR89UR
Q784 RT1P141C - X DIGI TRANSISTOR
Q784 or UN2111-X TRANSISTOR APD89J,PDR80J

Q785 RT1P141C - X DIGI TRANSISTOR
Q785 or UN2111-X TRANSISTOR APD89J,PDR80J

Q841 RT1N141C - X DIGI TRANSISTOR AP D 8 9J,PDR80J
Q841 or UN2211-X TRANSISTOR APD89J,PDR80J

Q881 RT1N141C - X DIGI TRANSISTOR

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR89UR

3-11



Symbol

Part No. Part Name Description Local

No.



Symbol

Part No. Part Name Description Local

No.

Q881 or UN2211-X TRANSISTOR APD89J,PDR80J

Q891 RT1N141 C- X DIGI TRANSISTOR APD89J,PDR61

Q891 or UN2211-X TRANSISTOR APD89J,PDR61

Q901 RT1P141C - X DIGI TRANSISTOR
Q901 or UN2111-X TRANSISTOR APD89J,PDR80J

Q902 RT1N141 C- X DIGI TRANSISTOR
Q902 or UN2211-X TRANSISTOR APD89J,PDR80J

Q933 2SA1365/F/-X TRANSISTOR
Q934 RT1N141 C- X DIGI TRANSISTOR
Q934 or UN2211-X TRANSISTOR APD89J,PDR80J

Q976 RT1N141 C- X DIGI TRANSISTOR
Q976 or UN2211-X TRANSISTOR APD89J,PDR80J

Q977 ISA1530AC1/R/-X TRANSISTOR
Q977 or 2SB709A/QR/-X TRANSISTOR APD89J,PDR80J

D1 1SS355W-X DIODE APD89J,PDR80J

D1 or MA111-X SI DIODE APD89J,PDR80J

D1 MA111-X SI DIODE PDR89UR

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

E,PDR61EX,PD
R61EY,G847EE,
PDR62E,PDR62
EX,PDR62EY

E,PDR61EX,PD
R61EY,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

D2 1SS355W-X DIODE APD89J,PDR80J

D2 or MA111-X SI DIODE APD89J,PDR80J

D2 MA111-X SI DIODE PDR89UR
D321 MC2836-X DIODE
D321 or MA152WA-X DIODE APD89J,PDR80J

D331 MC2836-X DIODE
D331 or MA152WA-X DIODE APD89J,PDR80J

D501 1A3G-T1 SI DIODE
D701 UDZW 6.2 B-X Z DIODE APD89J,PDR80J

D701 or MA8062/M/- X Z DIODE APD89J,PDR80J

D701 MA8062/M/-X Z DIODE PDR89UR
D702 UDZW 6.2 B-X Z DIODE APD89J,PDR80J

D702 or MA8062/M/- X Z DIODE APD89J,PDR80J

D702 MA8062/M/-X Z DIODE PDR89UR
D705 UDZW 6.2 B-X Z DIODE APD89J,PDR80J

D705 or MA8062/M/- X Z DIODE APD89J,PDR80J

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

3-12



Symbol

Part No. Part Name Description Local

No.



Symbol

Part No. Part Name De scription Local

No.

D705 MA8062/M/-X Z DIODE PDR89UR
D707 UDZW6.2B-X Z DI O DE APD89J,PDR80J

D707 or MA8062/M /-X Z DIODE APD89J,PDR80J

D707 MA8062/M/-X Z DIODE PDR89UR
D712 UDZW6.2B-X Z DI OD E APD89J,PDR61

D712 or MA8062/M /-X Z DIODE APD89J,PDR61

D714 UDZW5.6B-X Z DI O DE APD89J,PDR80J

D714 or MA8056/M /-X Z DIODE APD89J,PDR80J

D714 MA8056/M/-X Z DIODE PDR89UR
D720 UDZW6.2B-X Z DI O DE APD89J,PDR80J

D720 or MA8062/M /-X Z DIODE APD89J,PDR80J

D720 MA8062/M/-X Z DIODE PDR89UR
D721 UDZW6.2B-X Z DI O DE APD89J,PDR80J

D721 or MA8062/M /-X Z DIODE APD89J,PDR80J

D721 MA8062/M/-X Z DIODE PDR89UR

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

E,PDR61EX,PD
R61EY,PDR62E,
PDR62EX,PDR6
2EY

E,PDR61EX,PD
R61EY,PDR62E,
PDR62EX,PDR6
2EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

D722 UDZW6.2B-X Z DIODE APD89J,PDR80J

D722 or MA8062/M/-X Z DIODE APD89J,PDR80J

D722 MA8062/M/-X Z DIODE PDR89UR
D723 UDZW6.2B-X Z DIODE APD89J,PDR80J

D723 or MA8062/M/-X Z DIODE APD89J,PDR80J

D723 MA8062/M/-X Z DIODE PDR89UR
D724 MC2836-X DIODE
D724 or MA152WA-X DIODE APD89J,PDR80J

D726 UDZW6.2B-X Z DIODE APD89J,PDR80J

D726 or MA8062/M/-X Z DIODE APD89J,PDR80J

D726 MA8062/M/-X Z DIODE PDR89UR
D728 MC2838-X DIODE
D728 or MA152WK-X SI DIODE AP D89J,PDR80J

D729 MC2838-X DIODE
D729 or MA152WK-X SI DIODE AP D89J,PDR80J

D782 1 SS355W-X DIODE APD89J,PDR80J

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

3-13



Symbol

Part No. Part Name Description Local

No.



Symbol

Part No. Part Name Description Local

No.

D782 or MA111-X S I DIODE APD89J,PDR80J

D782 MA111-X SI DIODE PDR89UR
D783 MC2836-X DIODE
D783 or MA152WA-X DIODE APD89J,PDR80J

D784 UDZW11B-X Z DIODE APD89J,PDR80J

D784 or MA8110/M/-X Z DIODE APD89J,PDR80J

D784 MA81 10/M/-X Z DIODE PDR89UR
D851 or CRS03-W SB DIODE G844UI,G845U,

D851 or RB160M-30-X SB DIODE G844UI,G845U,

D851 MA22D23-X SB DIODE G844UI,G845U,

D852 MA22D39-X SB DIODE G844UI,G845U,

D891 MC2836-X DIODE APD89J,PDR61

D891 or MA152WA-X DIODE APD89J,PDR61



D901 1N5401-F64 SI DIODE



D901 or 1N5401-TU - 15 SI DIODE APD89J,PDR8 0J

D903 GS1J-X DIODE PDR 61E,PDR61

D931 RB051L-40-X S B D I O DE
D971 or CRS03-W SB DIODE APD89J,PDR80J

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

G845UN,G845U
T,G845UH

G845UN,G845U
T,G845UH

G845UN,G845U
T,G845UH

G845UN,G845U
T,G845UH

E,PDR61EX,PD
R61EY,G847EE,
PDR62E,PDR62
EX,PDR62EY

E,PDR61EX,PD
R61EY,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

EX,PDR61EY,P
DR62E,PDR62E
X,PDR62EY

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

D971 or RB160M-30-X SB DIODE APD89J,PDR80J

D971 MA22D23-X SB DIODE
D972 MA22D39-X SB DIODE

C1 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C2 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C3 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C4 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C12 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C13 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C14 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C71 NDC31HJ-561X C CAPACITOR 560pF 50V J PDR61E,PDR61

C72 NCB31EK-223X C CAPACITOR 0.022uF 25V K PDR61E,PDR61

C73 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M PDR61E,PDR61

C74 NDC31HJ-330X C CAPACITOR 33pF 50V J PDR61E,PDR61

C75 NDC31HJ-330X C CAPACITOR 33pF 50V J PDR61E,PDR61

C76 NCB31HK-103X C CAPACITOR 0.01uF 50V K PDR61E,PDR61

C77 QEKJ0JM-476Z E CAPACITOR 47 uF 6.3V M PDR61E,PDR61

C78 NCB31HK-103X C CAPACITOR 0.01uF 50V K PDR61E,PDR61

C81 QTE1H57-105Z E CAPACITOR 1uF 50V
C91 QTE1H57-105Z E CAPACITOR 1uF 50V
C161 QTE1H57-105Z E CAPACITOR 1uF 50V
C162 QTE1H64-225Z E CAPACITOR 2.2uF 50V
C163 QEKJ1HM-105Z E CAPACITOR 1u F 50V M
C167 NCB31HK-472X C CAPACITOR 4700pF 50V K
C168 QTE1A57-107Z E CAPA CITOR 100uF 10V
C171 QTE1H57-105Z E CAPACITOR 1uF 50V
C172 QTE1H64-225Z E CAPACITOR 2.2uF 50V
C173 QEKJ1HM-105Z E CAPACITOR 1u F 50V M
C176 NCB 31AK- 2 24X C CAPACITOR 0.22uF 10V K
C177 QTE1C57-106Z E CAPACITOR 10uF 16V
C178 QEKJ1HM-105Z E CAPACITOR 1u F 50V M
C179 QEKJ1HM-105Z E CAPACITOR 1u F 50V M
C180 QEKJ1HM-105Z E CAPACITOR 1u F 50V M
C181 NCB31HK-472X C CAPACITOR 4700pF 50V K
C182 NCB31HK-472X C CAPACITOR 4700pF 50V K
C301 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C302 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C303 NDC 31HJ-1 01 X C CAPA CITOR 100pF 50V J
C304 NDC 31HJ-1 01 X C CAPA CITOR 100pF 50V J

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

3-14



Symbol

Part No. Part Name Description Local

No.



Symbol

Part No. Part Name De scription Local

No.

C307 QEKJ1CM-476Z E CAPACITOR 47u F 16 V M
C308 QEKJ1CM-476Z E CAPACITOR 47u F 16 V M
C309 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C311 QFV91HJ-474Z M F C APACITOR 0.47uF 50V J
C312 QFV91HJ-474Z M F CAPACITOR 0.4 7u F 50V J
C313 NDC31HJ-101X C CAPA CI TO R 100pF 50V J
C314 NDC31HJ-101X C CAPA CI TO R 100pF 50V J
C315 QEKJ1HM-105Z E CAPACITOR 1uF 5 0V M
C316 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C317 QTE1C57-476Z E CAPACITOR 47uF 16V
C318 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C319 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C320 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C321 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C326 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C361 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M APD89J
C362 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M APD89J
C365 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C366 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C367 QEKJ1AM-227Z E CAPACITOR 220uF 10V M APD89J
C368 QEKJ1AM-227Z E CAPACITOR 220uF 10V M APD89J
C369 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M APD8 9J
C370 NCB31HK-152X C CAPACITOR 1500pF 50V K APD 89J
C371 NCB31EK-104X C CAPACITOR 0.1uF 25V K APD89J
C372 NCB31HK-152X C CAPACITOR 1500pF 50V K APD 8 9J
C381 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M APD89J
C382 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M APD89J
C385 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C386 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C391 NBZ0009-127X E. CAPACITOR 120uF
C401 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C402 NDC31HJ-120X C CAPACI TO R 12pF 50V J
C403 NDC31HJ-150X C CAPACI TO R 15pF 50V J
C461 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C462 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C463 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C464 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C465 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C471 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C472 NCB31HK-103X C CAPACITOR 0 .0 1u F 50V K
C481 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C482 NCB31HK-103X C CAPACITOR 0 .0 1u F 50V K
C491 QTE0J57-107Z E CAPACITOR 100uF 6.3V
C492 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C493 QTE1C57-106Z E CAPACITOR 10uF 16V
C494 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C495 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C502 QEKJ1CM-107Z E CAPACITOR 100 uF 16V M
C503 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C504 NCB31HK-103X C CAPACITOR 0 .0 1u F 50V K
C505 NCB31CK-104X C CA PACITOR 0 .1 uF 16V K
C511 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C512 NCB31HK-103X C CAPACITOR 0 .0 1u F 50V K
C513 NCB31HK-103X C CAPACITOR 0 .0 1u F 50V K
C514 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C515 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C516 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C517 NDC31HJ-121X C CAPA CI TO R 120pF 50V J
C518 NCB31HK-103X C CAPACITOR 0 .0 1u F 50V K
C519 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C531 NCB31HK-102X C CAPACITOR 1 000pF 50V K
C532 NDC31HJ-181X C CAPA CI TO R 180pF 50V J
C533 NDC31HJ-271X C CAPA CI TO R 270pF 50V J
C534 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C535 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C536 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C537 NCB31HK-222X C CAPACITOR 2 200pF 50V K
C538 QEKJ1CM-476Z E CAPACITOR 47u F 16 V M
C539 NCB31HK-562X C CAPACITOR 5 600pF 50V K
C541 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C542 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C543 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C544 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C545 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C546 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C547 QERF1CM-476Z E CAPAC I TOR 47uF 16V M
C548 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C550 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C551 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C552 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C553 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C554 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C555 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C556 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C557 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C558 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C559 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C560 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C561 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C562 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C563 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C564 NDC31HJ-680X C CAPACITOR 68pF 50V J
C565 NCB31EK-15 3X C CAPACITOR 0.015uF 25V K
C566 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C567 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C568 NCB31HK-472X C CAP AC I TOR 4700pF 50V K
C569 NCB31HK-103X C CAPAC I TOR 0.01uF 50V K
C570 NCB31HK-103X C CAPAC I TOR 0.01uF 50V K
C571 NCB31EK-15 3X C CAPACITOR 0.015uF 25V K
C572 NDC31HJ-470X C CAPACITOR 47pF 50V J
C573 NCB31EK-33 3X C CAPACITOR 0.033uF 25V K
C574 NCB31HK-103X C CAPAC I TOR 0.01uF 50V K
C575 QERF0JM-107Z E CAPACI TOR 100uF 6. 3V M
C578 NCB31HK-103X C CAPAC I TOR 0.01uF 50V K
C580 QTE1E57-475Z E CAPACITOR 4.7uF 25V
C581 NDC31HJ-101X C CAPACITOR 100pF 50V J
C582 NDC31HJ-151X C CAPACITOR 150pF 50V J
C583 QTE0J57-476Z E CAPACITOR 47uF 6.3V
C584 NDC31HJ-821X C CAPACITOR 820pF 50V J
C590 QTE1E57-475Z E CAPACITOR 4.7uF 25V
C591 NDC31HJ-101X C CAPACITOR 100pF 50V J
C592 NDC31HJ-151X C CAPACITOR 150pF 50V J
C593 QTE0J57-476Z E CAPACITOR 47uF 6.3V
C594 NDC31HJ-821X C CAPACITOR 820pF 50V J
C596 QTE1C57-107Z E CAPACITOR 100uF 16V
C597 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C701 NDC31HJ-220X C CAPACITOR 22pF 50V J
C702 NDC31HJ-270X C CAPACITOR 27pF 50V J
C705 NCB31EK-47 3X C CAPACITOR 0.047uF 25V K
C706 NCB31EK-47 3X C CAPACITOR 0.047uF 25V K
C707 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C708 NCB31EK-47 3X C CAPACITOR 0.047uF 25V K
C711 QERF0JM-337Z E CAPACITOR 330uF 6. 3V M
C712 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C713 NCB31HK-103X C CAPAC I TOR 0.01uF 50V K
C714 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C716 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C717 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C718 NDC31HJ-101X C CAPACITOR 100pF 50V J APD89J,PDR61

C720 NCB31HK-153X C CAP AC I TOR 0.015uF 50V K
C721 NCB31HK-103X C CAPAC I TOR 0.01uF 50V K
C723 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C724 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C725 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C726 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C727 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C728 NCB31EK-47 3X C CAPACITOR 0.047uF 25V K
C729 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C730 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C765 NCB31EK-10 4X C CAPACITOR 0.1uF 25V K
C771 NCB31EK-47 3X C CAPACITOR 0.047uF 25V K PDR61E,PDR 61

C784 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C801 NCB31EK-47 3X C CAPACITOR 0.047uF 25V K
C803 NCB31EK-47 3X C CAPACITOR 0.047uF 25V K
C841 QEKJ1HM-105Z E CAPACITOR 1uF 50V M APD89J,PDR80J

E,PDR61EX,PD
R61EY,PDR62E,
PDR62EX,PDR6
2EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

,PDR89UR

3-15



Symbol

Part No. Part Name Description Local

No.



Symbol

Part No. Part Name Description Local

No.

C851 QEKJ1CM-106Z E CAPACITOR 10uF 16V M G844UI,G845U,

C852 NCB31CK-224X C CAPACITOR 0.22uF 16V K G844UI,G845U,

C881 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C891 NCB31EK-10 4X C CAPACITO R 0.1uF 25V K APD89J,PDR61

C901 QEZ0870-278 E CAPACITOR 2700uF
C902 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C903 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C905 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C906 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C907 QEKJ1AM-227Z E CAPAC I TOR 220uF 10V M
C908 QEKJ1AM-227Z E CAPAC I TOR 220uF 10V M
C909 QERF0JM-337Z E CAPACITOR 330uF 6.3V M
C910 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C911 NCB31CK-104X C CAPACI TOR 0.1uF 16V K
C912 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C913 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C914 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C915 NCB31CK-104X C CAP AC I TOR 0.1uF 16V K
C916 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C928 NCB31HK-472X C CAP AC I TOR 4700pF 50V K
C929 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C931 QEZ0595-477Z E CAPACITOR 470uF 25V M
C932 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C936 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C937 NCB31CK-104X C CAP AC I TOR 0.1uF 16V K
C938 NCB31EK-10 4X C CAPACITO R 0.1uF 25V K
C971 NCB31EK-10 4X C CAPACITO R 0.1uF 25V K
C991 NCB31HK-153X C CAP AC I TOR 0.015uF 50V K

Ω

R3 NRSA63J-102X MG RESISTOR 1k
R4 NRSA63J-683X MG RESISTOR 68k
R5 NRSA63J-822X MG RESISTOR 8.2k
R6 NRSA63J-332X MG RESISTOR 3.3k
R7 NRSA63J-333X MG RESISTOR 33k
R9 NRSA63J-103X MG RESISTOR 10k
R10 NRSA63J-473X MG RESISTOR 47k
R11 NRSA63J-472X MG RESISTOR 4.7k
R12 NRSA63J-331X MG RESISTOR 330
R13 NRSA63J-472X MG RESISTOR 4.7k
R14 NRSA63J-331X MG RESISTOR 330
R15 NRSA63J-102X MG RESISTOR 1k
R16 NRSA63J-332X MG RESISTOR 3.3k
R17 NRSA63J-0R0X MG RESISTOR 0

R21 NRS181J-120X MG RESISTOR 12
R22 NRS181J-120X MG RESISTOR 12
R27 NRS181J-0R0X MG RESISTOR 0
R71 NRSA63J-0R0X MG RESISTOR 0

R72 NRSA63J-222X MG RESISTOR 2.2k

R73 NRSA63J-222X MG RESISTOR 2.2k

R74 NRSA02J-101X MG RESISTOR 100

R81 NRSA63J-243X MG RESISTOR 24k

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J PDR61E,PDR61

Ω

1/8W J

Ω

1/8W J

Ω

1/8W J

Ω

1/16W J PDR61E,PDR61

Ω

Ω

Ω

1/10W J PD R61E,PDR61

Ω

1/16W J APD89J,PDR80J

G845UN,G845U
T,G845UH

G845UN,G845U
T,G845UH

E,PDR61EX,PD
R61EY,G847EE,
PDR62E,PDR62
EX,PDR62EY

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

1/16W J PDR61E,PDR61

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

1/16W J PDR61E,PDR61

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

,PDR89UR

R81 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J PDR61E,PDR61

R82 NRSA63J-512X MG RESISTOR 5.1k
R82 NRSA63J-472X MG RESISTOR 4.7k

R91 NRSA63J-243X MG RESISTOR 24k
R91 NRSA63J-123X MG RESISTOR 12k

R92 NRSA63J-512X MG RESISTOR 5.1k
R92 NRSA63J-472X MG RESISTOR 4.7k

R120 NRSA63J-101X MG RESISTOR 100
R121 NRSA63J-101X MG RESISTOR 100
R163 NRSA63J-331X MG RESISTOR 330
R164 NRS181J-0R0X MG RESISTOR 0
R165 NRSA63J-222X MG RESISTOR 2.2k
R166 NRSA63J-222X MG RESISTOR 2.2k
R168 NRSA63J-103X MG RESISTOR 10k
R169 NRSA63J-103X MG RESISTOR 10k
R180 NRSA63J-473X MG RESISTOR 47k
R181 NRSA63J-473X MG RESISTOR 47k
R241 NRSA63J-222X MG RESISTOR 2.2k
R303 NRSA63J-0R0X MG RESISTOR 0
R304 NRSA63J-0R0X MG RESISTOR 0
R305 NRSA63J-472X MG RESISTOR 4.7k
R307 NRSA63J-273X MG RESISTOR 27k
R313 NRSA63J-0R0X MG RESISTOR 0
R314 NRSA63J-0R0X MG RESISTOR 0
R321 NRSA63J-222X MG RESISTOR 2.2k
R322 NRSA63J-821X MG RESISTOR 820
R323 NRSA63J-101X MG RESISTOR 100
R331 NRSA63J-222X MG RESISTOR 2.2k
R332 NRSA63J-821X MG RESISTOR 820
R333 NRSA63J-101X MG RESISTOR 100
R341 NRSA63J-222X MG RESISTOR 2.2k
R342 NRSA63J-821X MG RESISTOR 820
R343 NRSA63J-101X MG RESISTOR 100
R351 NRSA63J-222X MG RESISTOR 2.2k
R352 NRSA63J-821X MG RESISTOR 820
R353 NRSA63J-101X MG RESISTOR 100
R361 NRSA63J-333X MG RESISTOR 33k
R362 NRSA63J-223X MG RESISTOR 22k
R363 NRSA63J-473X MG RESISTOR 47k
R365 NRSA63J-333X MG RESISTOR 33k
R366 NRSA63J-223X MG RESISTOR 22k
R367 NRSA63J-473X MG RESISTOR 47k
R371 NRSA63J-0R0X MG RESISTOR 0

Ω
Ω

Ω

1/16W J APD89J,PDR80J

Ω

1/16W J PDR61E,PDR61

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J APD89J

Ω

1/16W J APD89J

Ω

1/16W J

Ω

1/16W J APD89J

Ω

1/16W J APD89J

Ω

1/16W J

Ω

1/16W J PDR80J,PD R61

EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

1/16W J APD89J,PDR80J

,PDR89UR

1/16W J PDR61E,PDR61

EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR89UR
EX,PDR61EY,G8

44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

1/16W J APD89J,PDR80J

,PDR89UR

1/16W J PDR61E,PDR61

EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,G847EE,
PDR62E,PDR62
EX,PDR62EY

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

E,PDR61EX,PD
R61EY,G844UI,
G845U,G845UN,
G845UT,G845U
H,G847EE,PDR
89UR,PDR62E,P
DR62EX,PDR62
EY

3-16



Symbol

Part No. Part Name Description Local

No.



Symbol

Part No. Part Name De scription Local

No.

R372 NRSA63J-0R0X MG RES IS TOR 0Ω 1/16W J PDR80J,PDR6 1

R373 NRSA63J-0R0X MG RES IS TOR 0

R374 NRSA63J-0R0X MG RES IS TOR 0

R381 NRSA63J-333X MG RES IS TOR 33k
R382 NRSA63J-223X MG RES IS TOR 22k
R383 NRSA63J-473X MG RES IS TOR 47k
R385 NRSA63J-333X MG RES IS TOR 33k
R386 NRSA63J-223X MG RES IS TOR 22k
R387 NRSA63J-473X MG RES IS TOR 47k
R404 NRSA63J-105X MG RES IS TOR 1M
R405 NRSA63J-102X MG RES IS TOR 1k
R461 NRSA63J-101X MG RES IS TOR 100
R462 NRSA63J-101X MG RES IS TOR 100
R481 NRSA63J-473X MG RES IS TOR 47k
R482 NRSA63J-102X MG RES IS TOR 1k
R483 NRSA63J-0R0X MG RES IS TOR 0
R484 NRSA63J-0R0X MG RES IS TOR 0
R485 NRSA63J-0R0X MG RES IS TOR 0
R490 NRSA63J-122X MG RES IS TOR 1.2k
R491 NRSA63J-101X MG RES IS TOR 100
R492 NRSA63J-101X MG RES IS TOR 100
R493 NRSA63J-101X MG RES IS TOR 100
R494 NRSA63J-470X MG RES IS TOR 47
R495 NRSA63J-470X MG RES IS TOR 47
R496 NRSA63J-470X MG RES IS TOR 47
R497 NRSA63J-470X MG RES IS TOR 47
R499 NRSA63J-473X MG RES IS TOR 47k
R502 NRS181J-270X MG RESIS TOR 27
R503 NRS181J-270X MG RESIS TOR 27
R504 NRSA63J-822X MG RES IS TOR 8.2k
R505 NRSA63J-512X MG RES IS TOR 5.1k
R511 NRSA63J-103X MG RESIS TOR 10k
R512 NRSA63J-752X MG RES IS TOR 7.5k
R513 NRSA63J-332X MG RES IS TOR 3.3k
R514 NRSA63J-103X MG RES IS TOR 10k
R515 NRSA63J-682X MG RES IS TOR 6.8k
R518 NRSA63J-302X MG RES IS TOR 3k
R519 NRSA63J-123X MG RES IS TOR 12k
R520 NRSA63J-822X MG RES IS TOR 8.2k
R521 NRSA63J-152X MG RES IS TOR 1.5k
R522 NRSA63J-101X MG RES IS TOR 100
R524 NRSA63J-151X MG RES IS TOR 150
R531 NRSA63J-105X MG RES IS TOR 1M
R532 NRSA63J-221X MG RES IS TOR 220
R535 NRSA63J-332X MG RES IS TOR 3.3k
R541 NRSA63J-101X MG RES IS TOR 100
R542 NRSA63J-103X MG RES IS TOR 10k
R543 NRSA63J-101X MG RES IS TOR 100
R544 NRSA63J-101X MG RES IS TOR 100
R545 NRSA63J-104X MG RES IS TOR 100 k
R546 NRSA63J-104X MG RES IS TOR 100 k
R547 NRSA63J-472X MG RES IS TOR 4.7k
R548 NRSA63J-562X MG RES IS TOR 5.6k
R549 NRSA63J-154X MG RES IS TOR 150 k
R550 NRSA63J-334X MG RES IS TOR 330 k
R551 NRSA63J-473X MG RES IS TOR 47k

Ω

1/16W J PDR80J,PDR6 1

Ω

1/16W J PDR80J,PDR6 1

Ω

1/16W J APD89J

Ω

1/16W J APD89J

Ω

1/16W J

Ω

1/16W J APD89J

Ω

1/16W J APD89J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/8W J

Ω
Ω

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω
Ω
Ω

Ω

Ω

Ω

1/16W J

1/16W J

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J
1/16W J
1/16W J

1/16W J

1/16W J

E,PDR61EX,PD
R61EY,G844UI,
G845U,G845UN,
G845UT,G845U
H,G847EE,PDR
89UR,PDR62E,P
DR62EX,PDR62
EY

E,PDR61EX,PD
R61EY,G844UI,
G845U,G845UN,
G845UT,G845U
H,G847EE,PDR
89UR,PDR62E,P
DR62EX,PDR62
EY

E,PDR61EX,PD
R61EY,G844UI,
G845U,G845UN,
G845UT,G845U
H,G847EE,PDR
89UR,PDR62E,P
DR62EX,PDR62
EY

R552 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R553 NRSA63J-223X MG RESISTOR 22k
R554 NRSA63J-0R0X MG RESISTOR 0
R555 NRSA63J-0R0X MG RESISTOR 0
R556 NRSA63J-0R0X MG RESISTOR 0
R557 NRSA63J-0R0X MG RESISTOR 0
R560 NRSA63J-104X MG RESISTOR 100k
R561 NRSA63J-103X MG RESISTOR 10k
R562 NRSA63J-103X MG RESISTOR 10k
R563 NRSA63J-101X MG RESISTOR 100
R564 NRSA63J-101X MG RESISTOR 100
R565 NRSA63J-101X MG RESISTOR 100
R566 NRSA63J-101X MG RESISTOR 100
R567 NRSA63J-103X MG RESISTOR 10k
R568 NRSA63J-103X MG RESISTOR 10k
R575 NRSA63J-222X MG RESISTOR 2.2k
R577 NRSA02J-220X MG RESISTOR 22
R578 NRSA02J-220X MG RESISTOR 22
R581 NRSA63J-0R0X MG RESISTOR 0
R583 NRSA63J-243X MG RESISTOR 24k
R585 NRSA63J-303X MG RESISTOR 30k
R586 NRSA63J-822X MG RESISTOR 8.2k
R587 NRSA63J-103X MG RESISTOR 10k
R588 NRSA63J-103X MG RESISTOR 10k
R589 NRSA63J-152X MG RESISTOR 1.5k
R591 NRSA63J-0R0X MG RESISTOR 0
R593 NRSA63J-243X MG RESISTOR 24k
R595 NRSA63J-303X MG RESISTOR 30k
R596 NRSA63J-822X MG RESISTOR 8.2k
R597 NRSA63J-103X MG RESISTOR 10k
R598 NRSA63J-103X MG RESISTOR 10k
R599 NRSA63J-152X MG RESISTOR 1.5k
R701 NRSA63J-432X MG RESISTOR 4.3k
R702 NRSA63J-103X MG RESISTOR 10k
R703 NRSA63J-473X MG RESISTOR 47k
R704 NRSA63J-473X MG RESISTOR 47k
R705 NRSA63J-473X MG RESISTOR 47k
R706 NRSA63J-106X MG RESISTOR 10M
R707 NRSA63J-0R0X MG RESISTOR 0
R709 NRSA63J-473X MG RESISTOR 47k
R710 NRSA63J-101X MG RESISTOR 100
R713 NRSA63J-473X MG RESISTOR 47k
R714 NRSA63J-223X MG RESISTOR 22k
R715 NRSA63J-0R0X MG RESISTOR 0
R716 NRSA63J-271X MG RESISTOR 270
R717 NRSA63J-271X MG RESISTOR 270
R718 NRSA63J-203X MG RESISTOR 20k
R719 NRSA63J-122X MG RESISTOR 1.2k
R720 NRSA63J-562X MG RESISTOR 5.6k
R721 NRSA63J-822X MG RESISTOR 8.2k
R722 NRSA63J-223X MG RESISTOR 22k
R723 NRSA63J-101X MG RESISTOR 100
R724 NRSA63J-101X MG RESISTOR 100
R725 NRSA63J-101X MG RESISTOR 100
R726 NRSA63J-103X MG RESISTOR 10k
R727 NRSA63J-473X MG RESISTOR 47k
R728 NRSA63J-101X MG RESISTOR 100
R729 NRSA63J-101X MG RESISTOR 100
R730 NRSA63J-101X MG RESISTOR 100
R731 NRSA63J-101X MG RESISTOR 100
R732 NRSA63J-103X MG RESISTOR 10k
R733 NRSA63J-473X MG RESISTOR 47k
R734 NRSA63J-473X MG RESISTOR 47k
R736 NRSA63J-101X MG RESISTOR 100
R737 NRSA63J-203X MG RESISTOR 20k
R738 NRSA63J-222X MG RESISTOR 2.2k
R739 NRSA63J-473X MG RESISTOR 47k
R740 NRSA63J-222X MG RESISTOR 2.2k
R741 NRSA63J-103X MG RESISTOR 10k
R742 NRSA63J-222X MG RESISTOR 2.2k
R744 NRSA63J-474X MG RESISTOR 470k
R745 NRSA63J-104X MG RESISTOR 100k
R746 NRSA63J-473X MG RESISTOR 47k
R747 NRSA63J-473X MG RESISTOR 47k
R748 NRSA63J-473X MG RESISTOR 47k
R749 NRSA63J-102X MG RESISTOR 1k
R750 NRSA63J-102X MG RESISTOR 1k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/10W J

Ω

1/10W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J
1/16W J

1/16W J

1/16W J
1/16W J
1/16W J

1/16W J
1/16W J
1/16W J

1/16W J
1/16W J

3-17



Symbol

Part No. Part Name Description Local

No.



Symbol

Part No. Part Name Description Local

No.

R751 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R752 NRSA63J-473X MG RESISTOR 47k
R753 NRSA63J-103X MG RESISTOR 10k
R754 NRSA63J-103X MG RESISTOR 10k
R756 NRSA63J-473X MG RESISTOR 47k
R757 NRSA63J-103X MG RESISTOR 10k

R759 NRSA63J-101X MG RESISTOR 100
R760 NRSA63J-101X MG RESISTOR 100
R761 NRSA63J-101X MG RESISTOR 100
R762 NRSA63J-271X MG RESISTOR 270
R763 NRSA63J-0R0X MG RESISTOR 0
R765 NRSA63J-471X MG RESISTOR 470
R767 NRSA63J-222X MG RESISTOR 2.2k
R768 NRSA63J-0R0X MG RESISTOR 0
R769 NRSA63J-472X MG RESISTOR 4.7k
R770 NRSA63J-472X MG RESISTOR 4.7k
R771 NRSA63J-271X MG RESISTOR 270

R772 NRSA63J-271X MG RESISTOR 270

R773 NRSA63J-0R0X MG RESISTOR 0
R775 NRSA63J-102X MG RESISTOR 1k
R776 NRSA63J-222X MG RESISTOR 2.2k
R777 NRSA63J-223X MG RESISTOR 22k
R779 NRSA63J-393X MG RESISTOR 39k
R781 NRSA63J-473X MG RESISTOR 47k
R782 NRSA63J-472X MG RESISTOR 4.7k
R783 NRSA63J-103X MG RESISTOR 10k
R785 NRSA63J-0R0X MG RESISTOR 0
R786 NRSA63J-0R0X MG RESISTOR 0
R793 NRSA63J-473X MG RESISTOR 47k
R795 NRSA63J-103X MG RESISTOR 10k

R797 NRSA63J-223X MG RESISTOR 22k
R798 NRSA63J-823X MG RESISTOR 82k
R799 NRSA63J-823X MG RESISTOR 82k
R801 NRSA63J-103X MG RESISTOR 10k
R802 NRSA63J-103X MG RESISTOR 10k
R803 NRSA63J-682X MG RESISTOR 6.8k
R804 NRSA63J-392X MG RESISTOR 3.9k
R805 NRSA63J-0R0X MG RESISTOR 0
R806 NRSA63J-102X MG RESISTOR 1k
R807 NRSA63J-104X MG RESISTOR 100k
R808 NRSA63J-101X MG RESISTOR 100
R809 NRSA63J-473X MG RESISTOR 47k
R810 NRSA63J-392X MG RESISTOR 3.9k
R811 NRSA63J-682X MG RESISTOR 6.8k
R812 NRSA63J-104X MG RESISTOR 100k
R813 NRSA63J-102X MG RESISTOR 1k
R814 NRSA63J-101X MG RESISTOR 100
R819 NRSA63J-473X MG RESISTOR 47k
R841 NRSA63J-332X MG RESISTOR 3.3k

R851 NRSA63J-103X MG RESISTOR 10k

R881 NRSA63J-473X MG RESISTOR 47k
R882 NRSA63J-472X MG RESISTOR 4.7k
R891 NRSA63J-102X MG RESISTOR 1k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J APD89J,PDR61

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J PD R61E,PDR61

Ω

1/16W J PD R61E,PDR61

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J APD89J,PDR80J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J APD89J,PD R80J

Ω

1/16W J G844UI,G845U,

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J APD89J,PDR61

E,PDR61EX,PD
R61EY,G844UI,
G845U,G845UN,
G845UT,G845U
H,PDR62E,PDR
62EX,PDR62EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

,G847EE,PDR89
UR

,PDR89UR
G845UN,G845U

T,G845UH

E,PDR61EX,PD
R61EY,G847EE,
PDR62E,PDR62
EX,PDR62EY

R892 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J APD89J,PDR61

R901 QRE142J-102X C RESISTOR 1k
R902 NRSA02J-912X MG RESISTOR 9.1k
R903 NRSA02J-472X MG RESISTOR 4.7k
R905 NRSA63J-682X MG RESISTOR 6.8k
R906 NRSA63J-123X MG RESISTOR 12k
R907 NRSA63J-102X MG RESISTOR 1k
R928 NRSA63J-154X MG RESISTOR 150k
R929 NRSA63D-124X MG RESISTOR 120k
R930 NRSA63J-0R0X MG RESISTOR 0
R931 NRSA63J-473X MG RESISTOR 47k
R932 NRSA63J-102X MG RESISTOR 1k
R933 NRSA63J-0R0X MG RESISTOR 0
R934 NRSA63J-0R0X MG RESISTOR 0
R935 NRSA63J-153X MG RESISTOR 15k
R936 NRSA63J-0R0X MG RESISTOR 0
R937 NRS181J-271X MG RESISTOR 270
R938 NRSA63J-473X MG RESISTOR 47k
R939 NRSA63D-153X MG RESISTOR 15k
R940 NRSA63D-623X MG RESISTOR 62k
R971 NRS181J-222X MG RESISTOR 2.2k
R972 NRS181J-222X MG RESISTOR 2.2k
R976 NRSA02J-273X MG RESISTOR 27k
R977 NRSA02J-123X MG RESISTOR 12k

L1 QQL244J-4R7Z P COIL 4.7u H J
L2 NQL553J-27NX COIL 27nH J
L3 NQL553J-27NX COIL 27nH J
L120 NQR0007-002X FERRITE BEA DS
L121 NQR0007-002X FERRITE BEA DS
L122 NQR0007-002X FERRITE BEA DS
L401 NQL79GM-470X COIL 47uH M
L402 NQL093K-1R8X COIL 1.8uH K
L403 NQL093K-1R8X COIL 1.8uH K
L471 NQL79GM-470X COIL 47uH M
L481 NQL79GM-470X COIL 47uH M
L491 NQL79GM-470X COIL 47uH M
L492 NQL79GM-470X COIL 47uH M
L531 NQL79GM-470X COIL 47uH M
L532 NQL79GM-470X COIL 47uH M
L701 NQL79GM-4R 7X COIL 4.7uH M
L702 NQL79GM-4R 7X COIL 4.7uH M
L901 QQR1809-001 CHOKE COIL
L931 NQL71EM-330X COIL 33uH M
L932 NQLE74M-100X COIL 10uH M

BZ841 QAN0023-001Z BUZZER APD89J,PDR80J
CN501 QGB2027MD-22 CONNECTOR B-B (1-22)

CN701 QGB1004K1-28 CONNECTOR B-B (1-28)
CN702 QNS0283-001 STEERING

CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0190-001 CAR ANT JACK
J321 QNN0490-001 PIN JACK APD89J
J321 QNN0815-001 PIN JACK PDR80J,PDR61

J801 QNZ0095-001 CONNECTOR
S701 QSW0451-001 DETECT SW
S703 QSW0648-001Z TACT SWITCH

REMOTE

Ω

1/4W J

Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W D

Ω
Ω

Ω

1/10W J

Ω

1/10W J

1/10W J
1/10W J
1/16W J

1/16W J
1/16W D

1/8W J
1/8W J

E,PDR61EX,PD
R61EY,G847EE,
PDR62E,PDR62
EX,PDR62EY

,PDR89UR

APD89J,PDR61
E,PDR61EX,PD
R61EY,PDR62E,
PDR62EX,PDR6
2EY

E,PDR61EX,PD
R61EY,G844UI,
G845U,G845UN,
G845UT,G845U
H,G847EE,PDR
89UR,PDR62E,P
DR62EX,PDR62
EY

3-18



Symbol

Part No. Part Name Description Local

No.



TU1 QAU0484-001 TUNER PACK APD89J,PDR80J



TU1 QAU0485-001 TUNER PACK G847EE
X71 QAX0926-001Z CRYSTAL PDR61E,PDR61

X401 QAX0927-001Z CRYSTAL
X701 QAX0916-001Z CRYSTAL
X702 QAX0401-001 CRYSTAL 32.768KHz

,PDR61E,PDR61
EX,PDR61EY,G8
44UI,G845U,G8
45UN,G845UT,G
845UH,PDR89U
R,PDR62E,PDR
62EX,PDR62EY

EX,PDR61EY,G8
47EE,PDR62E,P
DR62EX,PDR62
EY

Switch board

Block No. [0][2]



Symbol
No.



IC601 M3030RFGPGP1A IC(PROGRAMED)



IC602 S-80824CNNB-G-W IC



IC602 or IC-PST3424U-X IC APD89J,PDR

IC603 NJL29H380A REMOCON RCV
IC604 MAX829EU KG - X REMOCON RCV

Q601 ISA1530AC1/R/-X TRANSISTOR
Q601 or 2SB709A/QR/-X TRAN SISTOR APD89J,PDR

Q602 ISA1530AC1/R/-X TRANSISTOR
Q602 or 2SB709A/QR/-X TRAN SISTOR APD89J,PDR

Q603 RT1P141C-X DIGI TRANSISTOR
Q603 or UN2111-X TRANSISTOR APD89J,PDR

Q604 RT1N141C-X DIGI TRANSISTOR

Part No. Part Name Description Local

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY



Symbol
No.

Q604 or UN2211-X TRANSISTOR APD89J,PDR

Q610 2SC3928A/QR/-X TRANSISTOR APD89J,PDR

Q610 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR

Q610 2SD601A/QR /-X TRANSISTOR PDR89UR
Q611 2SC3928A/QR/-X TRANSISTOR APD89J,PDR

Q611 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR

Q611 2SD601A/QR /-X TRANSISTOR PDR89UR
Q612 2SC3928A/QR/-X TRANSISTOR APD89J,PDR

Q612 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR

Q612 2SD601A/QR /-X TRANSISTOR PDR89UR
Q613 2SC3928A/QR/-X TRANSISTOR APD89J,PDR

Part No. Part Name Description Local

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

3-19



Symbol
No.

Part No. Part Name Description Local



Symbol
No.

Part No. Part Name Description Local

Q613 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR

Q613 2SD601A/QR /-X TRANSISTOR PDR89UR
Q614 2SC3928A/QR/-X TRANSISTOR APD89J,PDR

Q614 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR

Q614 2SD601A/QR /-X TRANSISTOR PDR89UR
Q615 2SC3928A/QR/-X TRANSISTOR APD89J,PDR

Q615 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR

Q615 2SD601A/QR /-X TRANSISTOR PDR89UR
Q616 2SC3928A/QR/-X TRANSISTOR APD89J,PDR

Q616 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR

Q616 2SD601A/QR /-X TRANSISTOR PDR89UR
Q617 2SC3928A/QR/-X TRANSISTOR APD89J,PDR

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

Q617 or 2 SD6 01 A/QR/- X TRA NSISTOR APD89J,PDR

Q617 2SD601A/QR/-X TRANSISTOR PDR89UR
Q618 2SC3928A/QR/-X TR ANSISTOR APD89J,PDR

Q618 or 2 SD6 01 A/QR/- X TRA NSISTOR APD89J,PDR

Q618 2SD601A/QR/-X TRANSISTOR PDR89UR
Q619 2SC3928A/QR/-X TR ANSISTOR APD89J,PDR

Q619 or 2 SD6 01 A/QR/- X TRA NSISTOR APD89J,PDR

Q619 2SD601A/QR/-X TRANSISTOR PDR89UR
Q620 2SC3928A/QR/-X TR ANSISTOR APD89J,PDR

Q620 or 2 SD6 01 A/QR/- X TRA NSISTOR APD89J,PDR

Q620 2SD601A/QR/-X TRANSISTOR PDR89UR
Q621 2SC3928A/QR/-X TR ANSISTOR APD89J,PDR

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

3-20



Symbol
No.

Part No. Part Name Description Local



Symbol
No.

Part No. Part Name Description Local

Q621 or 2SD601A/QR/-X TRANSISTOR APD89J,PDR

Q621 2SD601A/QR/-X TRANSISTOR PDR89UR
Q640 2SA1365/F/-X TRANSISTOR
Q641 2SA1365/F/-X TRANSISTOR
Q642 RT1N141C-X DIGI TRANSISTOR
Q642 or UN2211-X TRANSISTOR APD89J,PDR

Q643 RT1N141C-X DIGI TRANSISTOR
Q643 or UN2211-X TRANSISTOR APD89J,PDR

D610 UDZW6.2B-X Z DIODE APD89J,PDR

D610 or MA8062/M/-X Z DIODE APD89J,PDR

D610 MA8062/M/-X Z DIODE PDR8 9U R
D611 UDZW6.2B-X Z DIODE APD89J,PDR

D611 or MA8062/M/-X Z DIODE APD89J,PDR

D611 MA8062/M/-X Z DIODE PDR8 9U R

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

D612 UDZW6.2B-X Z DIODE APD89J,PDR

D612 or MA8062/M/-X Z DIODE APD89J,PDR

D612 MA8062/M/-X Z DIODE P DR89UR
D613 UDZW6.2B-X Z DIODE APD89J,PDR

D613 or MA8062/M/-X Z DIODE APD89J,PDR

D613 MA8062/M/-X Z DIODE P DR89UR
D614 UDZW6.2B-X Z DIODE APD89J,PDR

D614 or MA8062/M/-X Z DIODE APD89J,PDR

D614 MA8062/M/-X Z DIODE P DR89UR
D615 UDZW6.2B-X Z DIODE APD89J,PDR

D615 or MA8062/M/-X Z DIODE APD89J,PDR

D615 MA8062/M/-X Z DIODE P DR89UR

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

3-21



Symbol
No.

Part No. Part Name Description Local



Symbol
No.

Part No. Part Name Description Local

D616 UDZW5.1B-X SB DIODE APD89J, PDR

D616 or MA8051/M/-X Z DIODE APD89J,PDR

D616 MA8051/M/-X Z DIODE P DR 89UR
D617 UDZW5.1B-X SB DIODE APD89J, PDR

D617 or MA8051/M/-X Z DIODE APD89J,PDR

D617 MA8051/M/-X Z DIODE P DR 89UR
D618 1SS355W-X DIODE APD89J,PDR

D618 or MA111-X SI DIODE APD8 9J,PDR

D618 MA111-X SI DIODE PDR89UR
D620 MC2838-X DIODE
D620 or MA152WK-X SI DIODE APD89J,PDR

D621 MC2838-X DIODE
D621 or MA152WK-X SI DIODE APD89J,PDR

D622 MA22D2 3- X SB DIODE

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

D622 o r CRS03-W SB DIODE APD89J,PDR

D622 or RB160M-30-X SB DI O DE APD89J ,P DR

D623 MA22D23-X SB DIODE
D623 o r CRS03-W SB DIODE APD89J,PDR

D623 or RB160M-30-X SB DI O DE APD89J ,P DR

D624 MA22D23-X SB DIODE
D624 o r CRS03-W SB DIODE APD89J,PDR

D624 or RB160M-30-X SB DI O DE APD89J ,P DR

D625 MA22D23-X SB DIODE
D625 o r CRS03-W SB DIODE APD89J,PDR

D625 or RB160M-30-X SB DI O DE APD89J ,P DR

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

3-22



Symbol
No.

Part No. Part Name Description Local



Symbol
No.

Part No. Part Name Description Local

D626 UDZW5.1B-X SB DIODE APD89J,PDR

D626 or MA8051/M/-X Z DIODE APD89J,PDR

D626 MA8051/M/-X Z DIODE PDR8 9U R
D640 LBQ39G/L2N2/-X LED
D641 NECBB205/WPQR/X LED
D642 NECBB205/WPQR/X LED
D643 NECBB205/WPQR/X LED
D644 NECBB205/WPQR/X LED
D645 NECBB205/WPQR/X LED
D646 NECBB205/WPQR/X LED
D647 NECBB205/WPQR/X LED
D648 NSCM315C/Z/-W LED
D649 NSCM315C/Z/-W LED
D650 SML-D12V8W/PQ-X LED
D660 CL-165HR/HG5-X LED
D661 CL-165HR/HG5-X LED
D662 CL-165HR/HG5-X LED
D663 CL-165HR/HG5-X LED
D664 CL-165HR/HG5-X LED
D665 CL-165HR/HG5-X LED
D666 CL-165HR/HG5-X LED
D667 CL-165HR/HG5-X LED
D668 CL-165HR/HG5-X LED
D669 CL-165HR/HG5-X LED
D670 CL-165HR/HG5-X LED
D671 CL-165HR/HG5-X LED

C601 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C604 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C605 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C606 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C607 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C608 NBE20JM- 47 5X TA E CAPACITOR 4.7uF 6.3V M
C609 NBE20JM- 47 5X TA E CAPACITOR 4.7uF 6.3V M
C610 NBE20JM- 47 5X TA E CAPACITOR 4.7uF 6.3V M
C611 NCB31CK-105X C CAPACITOR 1uF 16V K
C612 NCB31CK-105X C CAPACITOR 1uF 16V K
C613 NCB31CK-105X C CAPACITOR 1uF 16V K
C614 NCB31CK-105X C CAPACITOR 1uF 16V K
C615 NCB31CK-105X C CAPACITOR 1uF 16V K
C616 NCB31CK-105X C CAPACITOR 1uF 16V K
C617 NCB31CK-105X C CAPACITOR 1uF 16V K
C624 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C630 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C631 NBE20JM- 47 5X TA E CAPACITOR 4.7uF 6.3V M
C633 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C640 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C641 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C642 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C643 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C644 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C645 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C653 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C654 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C655 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C656 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C657 NCJ31CK- 1 05X-A C CAPACITOR 1uF 16V K
C658 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C659 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C660 NBE20JM- 47 5X TA E CAPACITOR 4.7uF 6.3V M
C681 NCJ11EK-106X-R C CAPACITOR 10uF 2 5V

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

80J,PDR61E,
PDR61EX,PD
R61EY,G844U
I,G845U,G845
UN,G845UT,G
845UH,G847
EE,PDR62E,P
DR62EX,PDR
62EY

R601 NRSA63 J- 104X MG RE SI STOR 1 00 kΩ 1/16W J
R602 NRSA63 J- 104X MG RE SI STOR 1 00 k
R603 NRSA63 J- 104X MG RE SI STOR 1 00 k
R604 NRSA63 J- 102X MG RE SI STOR 1 k
R605 NRSA63 J- 102X MG RE SI STOR 1 k
R606 NRSA63 J- 103X MG RE SI STOR 1 0k
R607 NRSA63 J- 473X MG RE SI STOR 4 7k
R608 NRSA63 J- 473X MG RE SI STOR 4 7k
R609 NRSA63 J- 222X MG RE SI STO R 2. 2k
R610 NRSA63 J- 680X MG RE SI STOR 6 8
R611 NRSA63 J- 10 3X MG RESISTO R 10k
R612 NRSA63 J- 331X MG RE SI STOR 3 30
R613 NRSA63 J- 103X MG RE SI STOR 1 0k
R615 NRSA63 J- 153X MG RE SI STOR 1 5k
R616 NRSA63 J- 103X MG RE SI STOR 1 0k
R617 NRSA63 J- 103X MG RE SI STOR 1 0k
R618 NRSA63 J- 331X MG RE SI STOR 3 30
R619 NRSA63 J- 331X MG RE SI STOR 3 30
R620 NRSA63 J- 331X MG RE SI STOR 3 30
R621 NRSA63 J- 331X MG RE SI STOR 3 30
R622 NRSA63 J- 102X MG RE SI STOR 1 k
R623 NRSA63 J- 103X MG RE SI STOR 1 0k
R624 NRSA63 J- 103X MG RE SI STOR 1 0k
R625 NRSA63 J- 103X MG RE SI STOR 1 0k
R626 NRSA63 J- 103X MG RE SI STOR 1 0k
R627 NRSA63 J- 152X MG RE SI STO R 1. 5k
R628 NRSA63 J- 152X MG RE SI STO R 1. 5k
R629 NRSA63 J- 152X MG RE SI STO R 1. 5k
R630 NRSA63 J- 103X MG RE SI STOR 1 0k
R633 NRSA63 J- 103X MG RE SI STOR 1 0k
R635 NRSA63 J- 0R0X MG RESISTOR 0
R637 NRSA63 J- 0R0X MG RESISTOR 0
R640 NRSA63 J- 132X MG RE SI STO R 1. 3k
R641 NRSA63 J- 132X MG RE SI STO R 1. 3k
R642 NRSA63 J- 561X MG RE SI STOR 5 60
R644 NRSA63 J- 132X MG RE SI STO R 1. 3k
R645 NRSA63 J- 132X MG RE SI STO R 1. 3k
R646 NRSA63 J- 561X MG RE SI STOR 5 60
R648 NRSA63 J- 132X MG RE SI STO R 1. 3k
R649 NRSA63 J- 132X MG RE SI STO R 1. 3k
R650 NRSA63 J- 561X MG RE SI STOR 5 60
R652 NRSA63 J- 132X MG RE SI STO R 1. 3k
R653 NRSA63 J- 132X MG RE SI STO R 1. 3k
R654 NRSA63 J- 561X MG RE SI STOR 5 60
R656 NRSA63 J- 132X MG RE SI STO R 1. 3k
R657 NRSA63 J- 132X MG RE SI STO R 1. 3k
R658 NRSA63 J- 561X MG RE SI STOR 5 60
R660 NRSA63 J- 132X MG RE SI STO R 1. 3k
R661 NRSA63 J- 132X MG RE SI STO R 1. 3k
R662 NRSA63 J- 561X MG RE SI STOR 5 60
R664 NRSA63 J- 132X MG RE SI STO R 1. 3k
R665 NRSA63 J- 132X MG RE SI STO R 1. 3k
R668 NRSA63 J- 221X MG RE SI STOR 2 20
R669 NRSA63 J- 132X MG RE SI STO R 1. 3k
R670 NRSA63 J- 132X MG RE SI STO R 1. 3k
R671 NRSA63 J- 132X MG RE SI STO R 1. 3k
R672 NRSA63 J- 132X MG RE SI STO R 1. 3k
R673 NRSA63 J- 472X MG RE SI STO R 4. 7k
R674 NRSA63 J- 472X MG RE SI STO R 4. 7k
R675 NRSA63 J- 472X MG RE SI STO R 4. 7k
R676 NRSA63 J- 472X MG RE SI STO R 4. 7k
R677 NRSA63 J- 102X MG RE SI STOR 1 k
R679 NRSA63 J- 132X MG RE SI STO R 1. 3k
R680 NRSA63 J- 301X MG RE SI STOR 3 00
R681 NRSA63 J- 271X MG RE SI STOR 2 70
R682 NRSA63 J- 391X MG RE SI STOR 3 90
R683 NRSA63 J- 561X MG RE SI STOR 5 60
R684 NRSA63 J- 821X MG RE SI STOR 8 20
R685 NRSA63 J- 152X MG RE SI STO R 1. 5k
R686 NRSA63 J- 301X MG RE SI STOR 3 00
R687 NRSA63 J- 271X MG RE SI STOR 2 70
R688 NRSA63 J- 391X MG RE SI STOR 3 90
R689 NRSA63 J- 561X MG RE SI STOR 5 60
R690 NRSA63 J- 821X MG RE SI STOR 8 20
R691 NRSA63 J- 152X MG RE SI STO R 1. 5k
R692 NRSA63 J- 301X MG RE SI STOR 3 00

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1/16W J
1/16W J

3-23



Symbol
No.

R693 NRSA63 J- 271X MG RE SI STO R 270Ω 1/16W J
R694 NRSA63 J- 473X MG RE SI STO R 47k
R695 NRSA63 J- 473X MG RE SI STO R 47k
R696 NRSA63 J- 474X MG RE SI STO R 470k
R697 NRSA63 J- 132X MG RE SI STO R 1.3k
R699 NRSA63 J- 0R0X MG RESISTOR 0
R6001 N RSA63J-391X MG RESISTOR 390
R6002 N RSA63J-391X MG RESISTOR 390
R6003 N RSA63J-391X MG RESISTOR 390
R6004 N RSA63J-561X MG RESISTOR 560
R6005 N RSA63J-561X MG RESISTOR 560
R6006 N RSA63J-561X MG RESISTOR 560
R6007 N RSA63J-391X MG RESISTOR 390
R6008 N RSA63J-391X MG RESISTOR 390
R6009 N RSA63J-391X MG RESISTOR 390
R6010 N RSA63J-391X MG RESISTOR 390
R6011 N RSA63J-391X MG RESISTOR 390
R6012 N RSA63J-391X MG RESISTOR 390
R6013 N RSA63J-561X MG RESISTOR 560
R6014 N RSA63J-561X MG RESISTOR 560
R6015 N RSA63J-561X MG RESISTOR 560
R6016 N RSA63J-391X MG RESISTOR 390
R6017 N RSA63J-391X MG RESISTOR 390
R6018 N RSA63J-391X MG RESISTOR 390
R6020 N RS1 81 J-0R 0X MG RESISTOR 0
R6022 N RSA63F-105X MG RESISTOR 1M
R6023 NRSA63F-134X MG RESISTO R 130k
R6024 N RSA63J-273X MG RESISTOR 27k
R6026 N RSA63J-222X MG RESISTOR 2.2k
R6027 N RSA63J-473X MG RESISTOR 47k
R6028 N RSA63J-0R0X MG RESISTOR 0
R6029 N RSA63J-103X MG RESISTOR 10k
R6030 N RSA63J-471X MG RESISTOR 470
R6032 N RSA63J-392X MG RESISTOR 3.9k
R6036 N RSA63J-0R0X MG RESISTOR 0
R6037 N RSA63J-0R0X MG RESISTOR 0
R6039 NVP0021-683X TRIM RE SISTOR 68k
R6043 N RSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R6044 N RSA63J-0R0X MG RESISTOR 0
R6045 N RSA63J-0R0X MG RESISTOR 0
R6050 N RSA02J-0R0X MG RESISTOR 0
R6051 N RSA02J-0R0X MG RESISTOR 0
R6052 N RSA02J-0R0X MG RESISTOR 0
RA601 NRZ0065-472X MG RESISTOR 4.7k
RA602 NRZ0065-472X MG RESISTOR 4.7k
RA603 NRZ0065-472X MG RESISTOR 4.7k
RA604 NRZ0065-331X NET RESISTOR 330
RA605 NRZ0065-331X NET RESISTOR 330

L601 NQL79GM-470 X COIL 47uH M
L602 NQR0536-001X CHO KE C OIL

CN601 QGZ1201M1-25W CONNECTOR (1-25)
CN602 QGF0522F3-30W CONNECTOR FFC/FPC (1-30)
CN603 QNZ0962-001 U SB JACK
EN601 QSW1231-001 ROTARY

PJ601 QNS0215-001 3.5 JACK
S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH
S604 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 N S W 0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S613 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S615 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0308-001X OPE N SWITCH
TH601 NAD0028-103X N THERMISTOR 10k
X601 NAX0752-001X RESONATOR

Part No. Part Name Description Local

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W F

Ω

1/16W F

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω
Ω

Ω
Ω
Ω

ENCODER

Ω

Function board

Block No. [0][ 3 ]



Symbol No.

D2441 LHQ974/LM/-X LED
D2442 LHQ974/LM/-X LED
D2443 LHQ974/LM/-X LED

R2442 NRSA63J-681X MG RESISTOR 680
R2443 NRSA63J-821X MG RESISTOR 820
R2447 NRSA63J-0R0X MG RESISTOR 0

CN741 QGB1004J2-28X CONNECTOR B-B (1-28)
CN742 Q G Z1201L1-25 CONNECTOR (1-25)
S2441 NSW0246-001X TACK SW

Part No. Part Name Description Local

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

USB board

Block No. [0][ 4 ]



Symbol No.



IC601 TCC8600 IC



IC602 MFI341S2094-X IC(MCU)
IC641 SA16D90TFI011G IC (PROGRAMED)
IC642 K4S641632K-UC75 IC APD89J,PDR8

IC642 M12L64164A-7TG IC PDR89UR,PD

IC692 NJM2878F4-18-X IC
C602 NCB31CK-104 X C CAPACITOR 0.1uF 16V K

C603 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C604 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C605 NCB31HK-122X C CAPACITOR 1200pF 50V K
C606 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C607 NDC31HJ-270X C CAPACITOR 27pF 50V J
C608 NDC31HJ-270X C CAPACITOR 27pF 50V J
C609 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C610 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C611 NDC31HJ-331X C CAPACITOR 330pF 50V J
C612 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C613 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C614 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C615 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C616 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C617 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C618 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C619 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C620 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C621 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C640 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C641 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C642 NBE20JM-226X TA E CAPACITOR 22uF 6 .3 V M
C643 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C644 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C645 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C646 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C647 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C648 NBE20JM-226X TA E CAPACITOR 22uF 6 .3 V M
C649 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C650 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C680 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C681 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C682 NCB31CK-104 X C CAPACITOR 0.1uF 16V K
C691 N BE21CM-475X TA E CAPACITOR 4.7uF 16V M
C692 NCB31CK-104 X C CAPACITOR 0.1uF 16V K

R604 NRSA63J-47 2X MG RESISTOR 4.7k
R605 NRSA63J-47 2X MG RESISTOR 4.7k

Part No. Part Name Descript ion Local

0J,PDR61E,PD
R61EX,PDR61
EY,G844UI,G8
45U,G845UN,
G845UT,G8 45
UH,G847EE

R62E,PDR62E
X,PDR62EY

Ω

1/16W J

Ω

1/16W J

3-24



Symbol No.

Part No. Part Name Description Local

R606 NRSA63J-472 X M G R ESISTOR 4.7kΩ 1/16W J
R610 NRS A63J-0R0X MG RESISTOR 0
R611 NRSA63J-152X MG RESISTOR 1.5k
R612 NRSA63J-105 X M G R ESISTOR 1M
R614 NRSA63J-470 X M G R ESISTOR 47
R621 NRSA63J-472 X M G R ESISTOR 4.7k
R626 NRS A63J-0R0X MG RESISTOR 0
R628 NRS A63J-0R0X MG RESISTOR 0
R635 NRSA63J-472 X M G R ESISTOR 4.7k
R640 NRSA63J-473 X M G R ESISTOR 47k
R641 NRSA63J-102 X M G R ESISTOR 1k
R643 NRS A63J-0R0X MG RESISTOR 0
R646 NRSA63J-472 X M G R ESISTOR 4.7k
R647 NRS A63J-0R0X MG RESISTOR 0
R648 NRSA63J-473 X M G R ESISTOR 47k
R650 NRSA63J-153 X M G R ESISTOR 15k
R651 NRSA63J-153 X M G R ESISTOR 15k
R652 NRS A63J-0R0X MG RESISTOR 0
R653 NRS A63J-0R0X MG RESISTOR 0
R684 NRS A63J-0R0X MG RESISTOR 0
R688 NRSA63J-472 X M G R ESISTOR 4.7k
R690 NRSA63J-101 X M G R ESISTOR 100
R693 NRSA63J-103 X M G R ESISTOR 10k
R694 NRSA63J-103 X M G R ESISTOR 10k
R696 NRSA63D-104X MG RESISTOR 100k
R698 NRSA63J-330 X M G R ESISTOR 33
R699 NRSA63J-330 X M G R ESISTOR 33
R6394 NRSA63J-470X MG RESISTOR 47
R6396 NRSA63J-470X MG RESISTOR 47
R6397 NRSA63J-470X MG RESISTOR 47
R6399 NRSA63J-101X MG RESISTOR 100
RA601 NRZ0065-472X MG RESISTOR 4.7k
RA680 NRZ0065-102X NET RESISTOR 1kΩ 1/16W J

L601 NQL38DK-330X COIL 33uH K
L602 NQL093K-R12X COIL 0.12uH K
L603 NQL093K-R12X COIL 0.12uH K
L607 NQL093K-1R8X COIL 1.8uH K
L608 NQL093K-R12X COIL 0.12uH K
L6398 NQL093K-1R8X COIL 1.8uH K

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

CN601 QGZ2512M1-08 CONNECTOR (1-8)
CN602 Q G Z2512M1-10 CONNEC TOR (1-10)
K641 NQR0502-001X FERRITE BEADS
X602 NAX0975-001X CRYSTAL
X603 NAX0966-001X C RESONATOR

3-25

Packing materials and accessories parts list

No additional / supplemental order of WARRANTY CARDs are available.

Only J ver.

P3

KIT : A13,A14,A15
A16,A17

P7

A21

Block No.

3

M

M

M

A1,A4,A7,A8,A9
A10

Only U ver.

P3

A1,A2,A3,A4,A5
A6,A7

Only UH,UN,UT,UI
ver.

P3

A20

A19

A12

A11

P2

P4

A18

P5

P6

P2

A1,A4,A7

Only E,EX,EY ver.

P3 P3

A1,A2,A4,A5,A7
A9,A22

3-26

Only EE ver.

A1,A4,A7,A9

P1

The parts without symbol number are not service.

Packing and Accessories

Block No. [M][3][M][M]



Symbol No. Part No. Part Name Description Local

A 1 GET0519-001A INST BOOK E N G SPA FRE APD89J,PDR80J
A 1 GET0524-001A INST BO O K GER FRE ITA PDR61E
A 1 GET0524-003A INST BO O K ENG FRE P D R61EX
A 1 GET0524-006A INST BO O K ENG GER RUS PDR61EY
A 1 GET0523-001A INST BO O K ENG G844UI
A 1 GET0498-001A INST BOOK ENG THA G845U,G845UH
A 1 GET0498-004A INST BO O K ENG INA G845U N
A 1 GET0498-005A INST BO O K ENG CHI(TAIWAN) G845 UT
A 1 GET0525-001A INST BO O K ENG RUS UKR G847EE
A 1 GET0524-001B INST BO O K GER FRE ITA PDR62E
A 1 GET0524-003B INST BO O K ENG FER P D R62EX
A 1 GET0524-006B INST BO O K ENG GER RUS PDR62EY
A 2 GET0524-002A INST BOOK S PA GRE POR PDR6 1E
A 2 GET0524-004A INST BO OK DUT SWE DAN FIN PDR61EX
A 2 GET0524-007A INST BO O K POL CZE HUN PDR61EY
A 2 GET0498-002A INST BOOK K O R CHI(TAIWAN) ARA PER G845U
A 2 GET0524-002B INST BO O K SPA GER POR PDR62E
A 2 GET0524-004B INST BO OK DUT SWE DAN FIN PDR62EX
A 2 GET0524-007B INST BO O K POL CZE HUN PDR62EY
A 3 GET0498-003A INST BO O K RUS G845 U
A 4 GET0519-002A INST.MANUAL ENG SPA FRE APD89J,PDR8 0J
A 4 GET0524-008A INST.MANUAL GER FRE ITA PDR61E
A 4 GET0524-010A INST.MANUAL ENG FRE P DR 6 1EX
A 4 GET0524-013A INST.MANUAL ENG GER RUS PDR6 1EY
A 4 GET0523-002A INST.MANUAL E NG G844UI
A 4 GET0498-006A INST.MANUAL ENG THA G845U,G845UH
A 4 GET0498-009A INST.MANUAL EN G I N A G845UN
A 4 GET0498-010A INST.MANUAL ENG C HI(TAIWAN) G845UT
A 4 GET0525-002A INST.MANUAL ENG RUS UKR G847EE
A 4 GET0524-009C INST.MANUAL GER FRE ITA PDR62E
A 4 GET0524-010C INST.MANUAL ENG FRE PDR62EX
A 4 GET0524-013C INST.MANUAL ENG GER RUS PDR62EY
A 5 GET0524-009A INST.MANUAL SPA GRE POR PDR 61E
A 5 GET0524-011A INST.MANUA L DUT SWE DAN FIN PDR61EX
A 5 GET0524-014A INST.MANUAL POL CZE HUN PDR61EY
A 5 GET0498-007A INST.MANUAL KOR CHI(TAIWAN) ARA PER G8 45 U
A 5 GET0524-008C INST.MANUAL SPA GER POR PDR62E
A 5 GET0524-011C INST.MANUAL DUT SWE DAN FIN PDR62EX
A 5 GET0524-014C INST.MANUAL POL CZE HUN PDR62EY
A 6 GET0498-008A INST.MANUAL R US G845U
A 7 LVT1672-002A INST SHEET APD89J,PDR80J,PDR61E,PDR61EX, PDR61E

A 8 BT-51041-1 REG IS.C ARD A PD8 9J ,PDR80J
A 9 ------------ WARRANTY CARD BT-51029-3 APD89J
A 9 ------------ WARRANTY CARD BT-51018-5 PDR80J
A 9 ------------ WARRANTY CARD B T-54032-1 PDR61E,PDR61EX,PDR61EY,G847EE
A 9 ------------ WARRANTY CARD BT-54035-1 PDR62E,PDR62EX,PDR62EY
A 10 ------------ WARRANTY CARD BT-52007-1 A PD89J,PDR80J
A 11 GE20137-003A MOUNTING SLEEVE
A 12 GE20235 - 001A TRIM PL ATE APD89J,PDR80J , PD R89UR
A 12 GE20218 - 00 3A TRIM PLATE PDR 61E,PDR61EX, PDR61EY
A 12 GE20235 -004A TRIM PLATE G844UI ,G 845U,G845UN,G845UT,G845UH
A 12 GE20218 - 009A TRIM PL ATE G847EE
A 12 GE20218 - 002A TRIM PL ATE PDR62E,PDR62EX,PDR62EY
A 13 VKZ4027- 20 2 PLU G NUT
A 14 GE40426 - 002A MOUN T BO LT
A 15 VKZ4328- 003 LOCK NUT
A 16 QYWWS53 A0 08ZA WASHER 0mm/5.3mm x
A 17 GE40130 - 002A HOOK (x2)
A 18 GE32320 - 00 1A HARD CASE ASSY
A 19 RM-RK50C REMOCON APD89J,PDR80J,PDR61E,PDR61EX,PD R61 E

A 20 ------------ BATTERY 3V APD89J,PDR80J,PDR61E,PDR61EX,PDR61E

A 20 ------------ BATTERY PDR62E,PDR62EX,PDR62EY
A 21 QAM1044-001 16P CORD ASSY APD89J
A 21 QAM0306-003 16P CORD ASSY PDR80J
A 21 QAM0569-002 16P CORD ASSY PDR61E,PDR61EX,PDR61EY,G847EE,PDR62

A 21 QAM1087-001 16P CORD ASSY G844UI,G845U,G845UN,G 845UT,G845UH
A 21 QAM0531-002 16P CORD ASSY PDR89UR

Y,G844UI,G845U,G845UN,G845UT,G845UH,G
847EE,PDR62E,PDR62EX,PDR62EY

Y,G844UI,G845U,G845UN,G845UT,G845UH,G
847EE,PDR62E,PDR62EX,PDR62EY

Y,G844UI,G845U,G845UN,G845UT,G845UH,G
847EE

E,PDR62EX,PDR62EY

3-27



Symbol No. Part No. Part Name Description Local

A 22 VND3050-002 IDENTITY CARD PDR61E,PDR61EX,PDR61EY,PD R62 E,PDR62
KIT SRW-MA372 SCREW PARTS KIT A13 A14 A15 A1 6 A17

P 1 GE33104-001A CARTON APD89J
P 1 GE33107-001A CARTON PDR80J
P 1 GE33116-001A CARTON PDR61E,PDR61EX ,P DR6 1EY
P 1 GE33113-001A CARTON G844UI
P 1 GE33110-001A CARTON G845U,G845UN,G845UT,G845UH
P 1 GE33119-001A CARTON G847EE
P 1 GE33335-001A CARTON PDR62E,PDR62EX ,P DR6 2EY
P 2 GE10228-001A EPS CUSHION APD89J,PDR 8 0J,G844UI,G8 45U,G845UN,G 84

P 2 GE10232-001A EPS CUSHION PDR61E,PDR61EX,PDR61EY,G8 47 EE
P 2 GE10232-002A EPS CUSHION PDR62E,PDR62EX,PDR6 2EY
P 3 FSPG4002-001 POLY BAG APD89J,PDR80J,PDR6 1E,PDR61EX,PDR61E

P 4 QPC03004315PB POLY BAG 30cm x 43cm APD89J,PDR8 0J,PDR61E,PDR61EX,PDR61E

P 5 QPA01003003 POLY BAG 10cm x 30cm APD89J,PDR8 0J ,P D R61E,PDR61E X, PDR61E

P 6 QPC01002515 POLY BAG 10cm x 25cm APD89J,PDR80J,P DR 61E,PDR61EX, PD R61E

P 7 QPA00801205 POLY BAG 8cm x 12cm APD89J,P DR 8 0J,PDR61E,PDR 61EX,PDR61E

EX,PDR62EY

5UT,G845UH

Y,G844UI,G845U,G845UN,G845UT,G845UH,G
847EE,PDR62 E ,PDR62EX,PD R62EY

Y,G844UI,G845U,G845UN,G845UT,G845UH,G
847EE,PDR62 E ,PDR62EX,PD R62EY

Y,G844UI,G845U,G845UN,G845UT,G845UH,G
847EE,PDR62 E ,PDR62EX,PD R62EY

Y,G844UI,G845U,G845UN,G845UT,G845UH,G
847EE,PDR62 E ,PDR62EX,PD R62EY

Y,G844UI,G845U,G845UN,G845UT,G845UH,G
847EE,PDR62 E ,PDR62EX,PD R62EY

3-28

SERVICE MANUAL

MY00820079SERVICE MANUAL

CD MECHANISM

TN2007-1026

COPYRIGHT © 2007 Victor Company of Japan, Limited

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

TABLE OF CONTENTS

1 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19

5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19

COPYRIGHT © 2007 Victor Company of Japan, Limited

No.MY008

2007/9

1.1 Safety Precautions

SECTION 1

PRECAUTIONS

!

!

Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.

Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.

1-2 (No.MY008)

1.2 Preventing static electricity

Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.

1.2.1 Grounding to prevent damage by static electricity

Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
Be careful to use proper grounding in the area where repairs are being performed.

(1) Ground the workbench

Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.

(2) Ground yourself

Use an anti-static wrist strap to release any static electricity built up in your body.

(caption)
Anti-static wrist strap

1M

Conductive material
(conductive sheet) or iron plate

(3) Handling the optical pickup

• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)

• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.

1.3 Handling the traverse unit (optical pickup)

(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the

replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a

time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) It is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.

1.4 Attention when traverse unit is decomposed

*Please refer to "Disassembly method" in the text for the CD pickup unit.

• Apply solder to the short land before the flexible wire is disconnected from the connector on the CD pickup unit.
(If the flexible wire is disconnected without applying solder, the CD pickup may be destroyed by static electricity.)

• In the assembly, be sure to remove solder from the short land after connecting the flexible wire.

Pickup

Wires

Push switch

Base board

Frame

Flexible wire

Connector

CD mechanism
assembly

Pickup

(No.MY008)1-3

1.5 Important for laser products

1.CLASS 1 LASER PRODUCT

2.CAUTION :

(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.

3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.

4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.

5.CAUTION : If safety switches malfunction, the laser is able
to function.

6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.

!

Please use enough caution not to

see the beam directly or touch it

in case of an adjustment or operation

check.

1-4 (No.MY008)

SECTION 2

SPECIFIC SERVICE INSTRUCTIONS

This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

(No.MY008)1-5

SECTION 3

A

DISASSEMBLY

3.1 CD mechanism assembly

3.1.1 Removing the top cover
(See Figs.1 and 2)

(1) From the both side of the CD mechanism assembly, re-

move the four screws A attaching the top cover. (See
Fig.1.)

(2) Lift the front side of the top cover and move the top cover

backward to release the two joints a. (See Figs.1 and 2.)

Top cover

A

a

A

A

Fig.1

a

Top cover

Fig.2

1-6 (No.MY008)

3.1.2 Removing the push switch

(See Figs.3)

(1) From the bottom side of the CD mechanism assembly, re-

move the screw B attaching the push switch.

(2) Take out the push switch from the CD mechanism assem-

bly.

Reference:

Remove the wires from soldered sections b of the push switch
as required.

3.1.3 Removing the base board

(See Figs.3 and 4)

Caution:

Solder the short land c before the flexible wire is disconnected
from the connector on the pickup. If the flexible wire is discon­nected without applying solder, the pickup may be destroyed
by static electricity. (See Fig.3.)
(1) From the bottom side of the CD mechanism assembly, re-

move the screw C attaching the base board. (See Figs.3

and 4.)
(2) Solder the short land c on the pickup. (See Fig.3.)
(3) Disconnect the flexible wire from the connector on the pick-

up. (See Fig.3.)
(4) Remove the base board from the joints d of the frame in the

direction of the arrow. (See Figs.3 and 4.)

Reference:

Remove the wires from the soldered sections e on the base
board as required. (See Fig.3.)

Caution:

When reattaching the base board, be sure to remove solder
from the short land c after connecting the flexible wire. (See
Fig.3.)

e

C

Base board

Frame

Wires

B

b

d

Push switch

Flexible wire

Connector

Fig.3

Pickup

CD mechanism
assembly

Pickup

c

C

Base board

Flexible wire

Frame

d

Fig.4

(No.MY008)1-7

3.1.4 Removing the chassis unit
(See Figs.5 and 6)

• Remove the top cover and base board.

(1) From the top side of the CD mechanism assembly, remove

the front suspension springs and rear suspension springs
attaching the chassis unit to the frame. (See Fig.5.)

(2) Remove the chassis unit from the dampers on the frame in

an upward direction. (See Fig.6.)

Note:

• Pay attention to misuse and loss of each spring. (See Fig.5.)

• When reassembling, make sure that the three shafts on the
underside of the chassis unit are inserted to the dampers
certainly. (See Fig.6.)

Chassis unit

Front suspension spring

Front suspension spring

Frame

Rear suspension spring Rear suspension spring

Fig.5

Shaft

Damper F

Damper F

Chassis unit

Shaft

Damper R

Frame

Shaft

Fig.6

1-8 (No.MY008)

3.1.5 Removing the clamper assembly
(See Figs.7 and 8)

• Remove the top cover.

Move the clamper assembly in the direction of the arrow to re­lease the joints f from the chassis unit.

Chassis unit

f

Clamper assembly

Clamper assembly

Chassis unit

f

Fig.7

f

f

Fig.8

(No.MY008)1-9

3.1.6 Removing the loading/feed motor assembly
(See Fig.9)

• Remove the top cover, base board and chassis unit.

From the bottom side of the chassis unit, remove the screw D
and take out the loading/feed motor assembly in the direction of
the arrow.

Reference:

Remove the wires from the soldered sections g of the loading/
feed motor assembly as required.

Loading/feed motor assembly

g

Chassis unit

Loading/feed
motor
assembly

D

Fig.9

1-10 (No.MY008)

3.1.7 Removing the pickup

(See Figs.10 to 12)

• Remove the top cover, base board and chassis unit.

(1) From the bottom side of the chassis unit, remove the screw

E attaching the pu. shaft holder B and pull the pu. shaft out
of the pu. shaft holder A. (See Fig.10.)

(2) Remove the screw F attaching the pu. shaft holder A. (See

Fig.10.)

(3) Take out the pickup with pu. shaft holder A and feed screw

assembly from the chassis unit. (See Fig.11.)

(4) Remove the section h of the pu. shaft holder A in the direc-

tion of the arrow. (See Fig.11.)

(5) Remove the feed screw assembly from the section j of the

pickup in the direction of the arrow. (See Fig.11.)

(6) Remove the screw G attaching the feed screw holder to the

pickup. (See Fig.12.)

Reference:

Remove the feed nut spring from the feed screw holder
as required. (See Fig.12.)

(7) Release the claw k in the direction of the arrow to remove

the feed sub holder. (See Fig.12.)

Pickup

Feed screw assembly

Pu. shaft holder A

Fig.11

G

h

j

Feed screw
holder

3.1.8 Reattaching the pickup

(See Figs.10 to 13)

(1) Reattach the feed sub holder to the pickup. (See Fig.12.)
(2) Reattach the feed screw holder to the pickup using the

screw G. (See Fig.12.)

(3) Reattach the feed screw assembly and pu. shaft holder A

to the pickup as before. (See Fig.11.)

(4) Set the section m of the pickup to the rail of the chassis unit

at first and attach the pickup to the chassis unit with the

screw F as before. (See Figs.10 and 13.)
(5) Attach the pu. shaft to the pickup as before. (See Fig.10.)
(6) Attach the pu. shaft holder B to the chassis unit with the

screw E as before. (See Fig.10.)

Chassis unit

Pu. shaft holder A

Pu. shaft

F

Feed screw holder

Pickup

k

Feed sub holder

Pickup

Rail

Feed nut
spring

Fig.12

m

F

Pickup

E

Pu. shaft holder B

Fig.10

Chassis unit

Fig.13

(No.MY008)1-11

3.1.9 Removing the trigger arm
(See Fig.14)

• Remove the top cover, base board, chassis unit and clamper

assembly.
(1) From the top side of the chassis unit, remove the trigger

arm spring from the sections (n, p).

(2) From the bottom side of the chassis unit, release the claws

q of the trigger arm base in the direction of the arrow to re­move them from the sections r of the chassis unit to the
other side.

Note:

When releasing the claws q, take care not to break them.

(3) From the top side of the chassis unit, move the select arm

R and select lock arm in the direction of the arrow to re­move the trigger arm base from the section s in the direc­tion of the arrow.

(4) Remove the trigger arm from the section t.

Select lock arm

s

n

Trigger arm
spring

t

Select arm R

p

Trigger arm base

Chassis unit

r

Chassis unit

Trigger arm

q

3.1.10 Removing the top plate assembly
(See Fig.15)

• Remove the top cover, base board, chassis unit, clamper as-

sembly and trigger arm.
(1) Remove the screw H attaching the top plate assembly.
(2) Move the top plate assembly in the direction of the arrow to

release the joints (u, v).

Reference:

Remove the wires from the soldered sections w of the top plate
assembly as required.

Note:

When reassembling, solder the wires as before.

Fig.14

Top plate assembly

u

H

w

v

Fig.15

Wire(Red)

Wire(White)

Wire(Brown)

1-12 (No.MY008)

3.1.11 Removing the mode switch

(See Fig.16)

• Remove the top cover, base board, chassis unit, clamper as-

sembly, trigger arm and top plate assembly.

(1) From the top side of the top plate assembly, remove the

link gear spring from the sections x of the link gear L and
link gear R.

(2) Remove the link gear L in an upward direction while releas-

ing the claws y of the link gear L in the direction of the ar­row.

(3) Move the mode switch in the direction of the arrow 1 to re-

move the sections z of the top plate assembly.

(4) Move the mode switch in the direction of the arrow 2 and

remove the mode switch from the sections (aa, ab).

Note:

When reattaching the link gear L, attach it after aligning the
hole ac of the link gear L to the hole ac of the link gear R.

Reference:

When reassembling, reverse the above removing procedure.

Top plate assembly

Link gear spring

Link gear R

Link
gear R

Link
gear L

ac ac

aa

Link gear L

Fig.16

Mode switch

x

1

2

z

y

y

ab

(No.MY008)1-13

3.1.12 Removing the select arm R and select lock arm
(See Figs.17 and 18)

• Remove the top cover, base board, chassis unit, clamper as-

sembly, trigger arm and top plate assembly.
(1) From the top side of the top plate assembly, remove the

link gear spring from the sections ad of the link gear L and
link gear R. (See Fig.17.)

(2) Remove the link gear R in an upward direction while releas-

ing the claws ae of the link gear R in the direction of the ar­row. (See Fig.17.)

(3) Move the select arm R in the direction of the arrow 1 to re-

move the sections af of the top plate assembly. (See
Fig.17.)

(4) Move the select arm R in the direction of the arrow 2 and

remove the select arm R from the sections ag. (See
Fig.17.)

(5) From the bottom side of the top plate assembly, remove

the select lock arm spring from the section ah. (See
Fig.18.)

(6) From the top side of the top plate assembly, remove the

section aj of the select lock arm from the top plate assem­bly at first and remove the sections (ak, am) of the select
lock arm from the top plate assembly. (See Fig.18.)

Note:

• When removing the select lock arm spring, be careful not to
lose it. (See Fig 18.)

• When reattaching the link gear R, attach it after aligning the
hole an of the link gear R to the hole an of the link gear L.
(See Fig.17.)

Reference:

When reassembling, reverse the above removing procedure.

ae

1

2

af

ae

Select arm R

ad

ag

Link gear R

Select lock arm

aj

Link gear spring

Top plate assembly

Link gear L

Link
gear R

an an

Fig.17

Top plate assembly

Link
gear L

ak

Select lock

arm spring

ah

am

Fig.18

1-14 (No.MY008)

3.1.13 Removing the loading roller assembly
(See Figs.19 to 21)

• Remove the top cover, base board, chassis unit, clamper as-

sembly and top plate assembly.

(1) From the left side of the chassis unit, remove the screw J

attaching the lock arm assembly. (See Fig.19.)

(2) Remove the projection ap of the lock arm assembly from

the joint aq while opening the cam plate R in the direction
of the arrow. (See Fig.19.)

(3) Remove the lock arm assembly from the projection ar of

the chassis unit. (See Fig.19.)

(4) Remove the projection as of the lock arm assembly from

the joint at of the cam plate L assembly. (See Fig.19.)

(5) From the right side of the lock arm assembly, remove the

loading roller spring L from the section au. (See Fig.20.)

(6) From the top side of the lock arm assembly, remove the

loading roller spring R in the direction of the arrow and re­move the loading roller assembly. (See Fig.20.)

(7) Remove the roller guide R, HL washer and roller guide L

from the both ends of the loading roller assembly. (See
Fig.21.)

J

Lock arm assembly

ap

aq

Cam plate R

Fig.19

Chassis unit

Cam plate L assembly

ar

at

as

Loading roller assembly

Lock arm assembly

Loading roller
spring L

au

Roller guide L Roller guide R

Loading roller assembly

Loading roller spring R

Fig.20

HL washer

Fig.21

(No.MY008)1-15

3.1.14 Removing the loading gear 1, loading gear 2, loading gear 3 and feed gear 1
(See Fig.22)

• Remove the top cover, base board and chassis unit.

(1) From the bottom side of the chassis unit, pull out the load-

ing gear 1.
(2) Take out the loading gear 2.
(3) Pull out the loading gear 3.
(4) Pull out the feed gear 1.

3.1.15 Removing the loading gear 4, loading gear 5 and
loading gear 6
(See Fig.22)

• Remove the top cover, base board and chassis unit.

(1) From the bottom side of the chassis unit, remove the screw

K attaching the loading gear bracket.

(2) Take out the loading gear bracket and remove the loading

gear 5 and loading gear 6 from the loading gear bracket.

(3) Pull out the loading gear 4.

3.1.16 Removing the change gear 2, change gear 3A and
change gear 3B
(See Figs.22 and 23)

• Remove the top cover, base board and chassis unit.

(1) From the bottom side of the chassis unit, pull out the load-

ing gear 1. (See Fig.22.)
(2) Pull out the change gear 2. (See Fig.22.)
(3) Pull out the change arm. (See Fig.22.)
(4) Move the change gear plate rivet assembly in the direction

of the arrow 2 to remove the section av of the change gear

plate rivet assembly from the chassis unit while moving the

change lock lever in the direction of the arrow 1. (See

Fig.23.)
(5) Pull out the change gear 3A and change gear 3B from the

change gear plate rivet assembly. (See Fig.23.)

Loading gear bracket

Loading gear 3

Feed gear 2

Feed gear 1

Change gear plate rivet assembly

Chassis unit

Fig.22

Loading gear 6

Loading gear
bracket

Change arm

Change gear plate
rivet assembly

Loading
gear 5

K

Loading gear 4

Loading gear 1

Loading gear 2

3.1.17 Removing the cam plate L assembly
(See Fig.24)

• Remove the top cover, base board, chassis unit, clamper as-

sembly, top plate assembly and loading roller assembly.
(1) From the left side of the chassis unit, slide the cam plate L

assembly in the direction of the arrow.

(2) Remove the cam plate L assembly from the slots aw of the

chassis unit.

Change gear 3B

Change lock lever

Chassis unit

2

1

Chassis unit

Fig.23

aw

Cam plate L assembly

Change
gear 3A

Change gear 3B

Change gear 3A

av

aw

1-16 (No.MY008)

Fig.24

3.1.18 Removing the cam plate R

(See Fig.25)

• Remove the top cover, base board, chassis unit, clamper as-

sembly, top plate assembly and loading roller assembly.
From the right side of the chassis unit, remove the cam plate R
from the slots ax of the chassis unit.

Reference:

When a slide hook rivet assembly and a trigger rack spring
have come off from the chassis unit, attach them before at­taching the cam plate R.

3.1.19 Removing the trigger rack plate

(See Figs.25 and 26)

• Remove the top cover, base board, chassis unit, clamper as-

sembly, top plate assembly, loading roller assembly and cam

plate R.

(1) Remove the slide hook rivet assembly and trigger rack

spring from the chassis unit. (See Fig.25.)

(2) From the bottom side of the chassis unit, pull out the load-

ing gear 1. (See Fig.26.)

(3) Remove the trigger control spring from the sections (ay,

az). (See Fig.26.)

(4) Take out the trigger rack plate from the chassis unit. (See

Fig.26.)

Reference:

When attaching the trigger rack plate, insert the projection a'
of the chassis unit in the slot b' on the bottom side of the trigger
rack plate as before. (See Fig.26.)

Chassis unit

ax

Cam plate R

b'

Trigger rack spring

Slide hook rivet assembly

ax

Fig.25

Trigger control spring

az

a'

Trigger
rack plate

Trigger rack plate

Loading gear 1

ay

Chassis unit

Fig.26

(No.MY008)1-17

3.1.20 Removing the spindle motor assembly
(See Figs.27 and 28)

• Remove the top cover, base board, chassis unit and clamper

assembly.
(1) From the top side of the chassis unit, turn the turn table

from side to side and remove the two screws M attaching
the spindle motor assembly through the hole of the turn ta­ble. (See Fig.27.)

(2) From the bottom side of the chassis unit, turn the change

gear 2 in the direction of the arrow 2 while pulling the trigger
arm in the direction of the arrow 1 and let the pickup move
in the direction of the arrow 3. (See Fig.28.)

(3) Slide the spindle motor assembly in the direction of the ar-

row and take out it in an upward direction from the chassis
unit. (See Fig.28.)

Reference:

Remove the wires from the soldered sections c' on the base
board and remove them from the sections (d', e') on the chas­sis unit as required.

Chassis unit

Wire(black)

Wire(red)

M

Fig.27

Spindle motor assembly

d'

Turn table

e'

Change gear 2

c'

Base board

3

Pickup

2

1

Trigger arm

Chassis unit

Fig.28

1-18 (No.MY008)

SECTION 4

ADJUSTMENT

This service manual does not describe ADJUSTMENT.

SECTION 5

TROUBLESHOOTING

This service manual does not describe TROUBLESHOOTING.

(No.MY008)1-19

Victor company of Japan, Limited
Mobile Entertainment Business Group Mobile Entertainment Category 10-1,1chome,Ohwatari-machi,Maebashi-city,Gumma-ken, 371-8543,Japan

(No.MY008)

Printed in Japan

VPT

PARTS LIST

TN2007-1026

* All printed circuit boards and its assemblies are not available as service parts.

- Contents -

CD mechanism assembly and parts list (Block No.MB)

MY008

3-2

3-1

CD mechanism assembly and parts list

TN2007-1026

120

Block No.

M

M

B

M

42

A

124

44

52

127

15

33

24

102

36

50

62

51

123

25

26

10

63

14

13

112

122

4

120

48

47

12

20

27

79

105

101

43

61

11

35

125

B

64

99

104

45

11

46

106

21

111

121

12

49

59

A

80

16

32

93

87

81

B

28

86

23

78

130

71

76

74

75

3-2

64

62

a

126

63

a

72

100

120

110

124

120

92

58

77

108

91

90

22

88

2

89

1

3

120

CD mechanism



Symbol No. Part No. Part Name Description Local

1 30350101T FRAME
2 30350103T DAMPER F (x2)
3 30350104T DAMPER R
4 30350107T TOP COVER
10 30320513T CLAMPER SUB SPG
11 30350505T FRONT SUS SPG (x2)
12 30350506T REAR SUS SPRING (x2)
13 30350508T FEED NUT SPP
14 30350509T FEED SCREW HLDR
15 30350525T PU SHAFT HLDR B
16 30350528T LOCK LEVER
20 30350529T LOCK PLATE
21 30350581T CHANGE GEAR2
22 30350582T CHANGE GEAR 3A
23 30350583T CHANGE GEAR 3B
24 30350535T FEED SUB HOLDER
25 30350536T PU SHAFT HLDR A
26 30350539T FD THRUST SPP
27 30350542T CHANGE ARM
28 30350580T FEED GEAR 1
32 30350554T LOCK LEVER SP
33 30350555T PU SHAFT
35 64010418T PUSH SW P389-01
36 69011629T PICK UP OPTIMA-727AD
42 30350801T TOP PLATE
43 30350802T SELECT ARM R
44 30350803T MODE SWICH
45 30350806T SELECT LOCK ARM
46 30350807T SPRING
47 30350808T TRIGGER ARM
48 30350809T TRG ARM BASE
49 30350810T TRIGGER ARM SPR
50 30350811T LINK GEAR L
51 30350812T LINK GEAR R
52 30350813T LINK GEAR SPR
58 19501403T WIRE CLUMPER
59 30321013T WIRE CLAMPER
61 30351001T WIRE CLAMPER
62 30351008T MODE SW WIRE
63 30351003T REST SW WIRE
64 30351004T LD WIRE
71 30321137T LDG ROLLER (x2)
72 30321143T COLLAR SCREW
74 30351101T LOCK ARM
75 30351102T LD ROLLER SPR R
76 30351103T LD ROLLER SPR L
77 30351105T ROLLER GUIDE R
78 30351106T ROLLER GUIDE L
79 30351116T CAM PLATE R (N)
80 30351111T TR C ONTR O L SPR
81 30351113T SPRING
86 30351122T LOADING GEAR 1
87 30351123T LOADING GEAR 2
88 30351128T LOADING GEAR 3
89 30351129T LOADING GEAR 4
90 30351140T LOADING GEAR 5
91 30351131T LOADING GEAR 6
92 30351133T LD GEAR BRACKET
93 30351135T PLATE
99 303505309T MORTER ASSY
100 303505302T SPINDLE MOTOR
101 303505303T CLAMPER ASSY
102 303505304T FEED SCREW ASSY
104 303505501T CHASSIS RIVET
105 303505502T CLAMPER ARM RVT
106 303505503T RIVET ASSY
108 303510304T BASE BOARD ASSY
110 303511301T ROLLER SHAFT
111 303511302T CAM PLATE L
112 303511501T SLIDE HOOK RVT
120 9P0420037T SCREW (x5)
121 9C0117187T SCREW (x2)
122 9C0120207T SCREW
123 9C4517506T SCREW

Block No. [M][B][M][M]

3-3



Symbol No. Part No. Part Name Description Local

124 9P0420047T SCREW (x2)
125 9P0420067T SCREW
126 9P0420087T SCREW
127 9C0420257T SCREW
130 9W0513060T HL WASHER

3-4

Grease point 1/2

grease

TNG-87
TN-4456

TNS-925R
GP-501MK

back side

1

4

back side

back side

two sides

104

101

44

43

74

3-5

Grease point 2/2

grease

TNG-87
TN-4456

TNS-925R
G-322

102

111

26

out side

33

106

79

27

25

16

90

92

99

105

3-6

50

93

back side
TR CONTROL SPR

side
CHF LOCK PLT

51
