SECTION 5
REPLACEMENT PARTS LIST
SAFETY PRECAUTION
Parts identified by the ! symbol are critical for safety. Replace only with specified part numbers.
5.1 EXPLODED VIEW
5.1.1 PACKING AND ACCESSOR Y ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.
INSTRUCTION ASS'Y
810
CABLE SET ASS'Y
808
BATTERY
(Optional Parts)
803
PACKING ASS'Y
804
SHEET CUSHION
801
900
REMOCON
802
BOX CARTON
5-1
5.1.2 FINAL ASSEMBLY <M2>
BEWARE OF BOGUS PARTS
Parts that do not meet specifications may
cause trouble in regard to safety and performance. We recommend that genuine JVC
parts be used.
OPTIONAL PARTS
457
462
250
A42
A00
A49
261
260
464
462
457
320
A46
300
5-2
280
283
A43
284
330
452
5.1.3 MECHANISM ASSEMBLY <M4>
103
031
079
117
A24
011
402
110
002A
115
017
116
401
105
100
032
022
003
001
002
402
012
024
117
A01
112
405
004
023
106
008
406
107
102
006
016
013
007
A21
113
A03
409
014
405
010
114
A04
015
054A
009
019
054
A23
A22
058
018
109
025
051
020
027
026
028
029
056
[ TOP VIEW ]
OPTIONAL PARTS
030
021
052
517
061
078
A11
[ BOTTOM VIEW ]
067
066
065
A12
064
077
068
069
070
518
055
052A
076
032
060
410
5-3
MODEL MARK
HR-P55A A
5.2 REPLACEMENT PARTS LIST
# REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABC NSP
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
******************************
P ACKING AND ACCESSOR Y ASSEMBLY <M1>
801 LG-3835RP0075T INSTRUCTION ASSEMBLY(EN,AR,RU) ELJ102W NA3RJJ/NA3RJJB ABC
802 LG-3890R-H782S BOX ELJ102W NA3RJJ SW3-A 0.797 1 F ABC
803 LG-3920R-E047A PACKING,CASING LV-N72 0.02 75 EPS 5 1260 2490 ABC
804 LG-3880R-H001A BAG HDPE 500 500 0.03 VCR MIDI ABC NSP
806 LG-6850R-CAA26 CABLE,COAXIAL 1200M/M PAL-PAL DOUBLE SHIELD ABC
808 - BATTERY,MANGANESE AAAM(R03) SEOTONG 1-5 V - 1PA ABC
810 LG-6851RP0003A CABLE ASSY,RF CABLE ASSY ,RF/SCAR T/RCA USING ABC
900 LG-6711R1P041B REMOTE CONTROLLER ASSEMBLY P9 EDJ102W JVC ABC
******************************
FINAL ASSEMBLY <M2>
A00 LG-6721RF0710A DECK ASSEMBLY,VIDEO D35(N) DI (2HD, NP, VCR) ABC NSP
A43 LG-3721R-F253R PANEL ASSEMBL Y,FRONT[NORMAL PAELJ102W (HR-P55A) AB
A43 LG-3721R-F253S PANEL ASSEMBL Y,FRONT[NORMAL PAELJ102W (HR-P56A) C
A46 LG-3501R-6321K BOARD ASSEMBLY ELJ102W .NA3RJJ ABC
250 LG-3110R-0309A CASE TOP(V5 SIDE A288G) AB
250 LG-3110R-0309C CASE TOP(V5 SIDE Q280G) C
260 LG-3210R-0066B FRAME MAIN(V5 60HR BK) ABC NSP
280 LG-3720R-F193A PANEL,VIDEO FRONT(B589G-SLVER) AB NSP
280 LG-3720R-F193B PANEL,VIDEO FRONT (Q280G) C NSP
283 LG-3580R-V031F DOOR,CASE CST (VCR) (VCP-B589G-521) AB
283 LG-3580R-V031G DOOR,CASE CST (VCR) (VCP-Q280G-SK5872) C
284 LG-442-681A SPRING DOOR ABC
! 300 LG-6410RCHP03B POWER CORD HIT-102/H03VVH2-F (NM) HARNESS A C
! 300 LG-6410RHHV01B POWER CORD ME301N/H03VVH2-F 2X0.75 VOLE B
320 LG-3720R-D049D PANEL,VIDEO DISTRIBUTOR (V5 VCP PAL RCA MO ABC
323 LG-3300R-M070A PLATE PRE AMP(V4 PJT) ABC
330 LG-3550R-0408A COVER BOTTOM(V5 LARGE) ABC
452 LG-353-051A SCREW SPECIAL ABC
457 LG-353-051E SCREW SPECIAL (3X12) ABC
462 LG-353-136A SCREW SPECIAL(FBK) (353S353A) ABC
464 LG-4404R-0017A SCREW 3*12*12(88H-0004) ABC
******************************
HR-P55A/S B
HR-P56A C *NSP : Not service parts
REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABC NSP
#
032 LG-3141R-0040A CHASSIS ASSY D35 ABC NSP
051 LG-4400R-0005A BELT CAPSTAN ABC
052 LG-4680R-A007A MOTOR(MECH) CAPSTAN F2QVB06 SANKYO D35 ASR ABC
052A LG-4980R-0023A SUPPORTER CAPSTAN(D35) ABC
054 LG-4470R-0100A GEAR RACK F/L ABC
054 LG-4471R-0006A GEAR ASSY RACK F/L ABC
054A LG-4970R-0124B SPRING COIL D35 (RACK F/L) ABC
055 LG-4470R-0097A GEAR DRIVE(D35) ABC
056 LG-4470R-0096A GEAR CAM(D35) ABC
060 LG-4510R-0040A LEVER F/R(D35) ABC
061 LG-4265R-0006A CLUTCH ASSEMBLY D35 (N) ABC
064 LG-4470R-0098A GEAR SECTOR(D35) ABC
065 LG-4261R-0021A ARM ASSY P3 ABC NSP
066 LG-4970R-0122A SPRING COIL D35 ABC NSP
067 LG-4470R-0095A GEAR P3 ABC NSP
068 LG-4470R-0094A GEAR P2 ABC NSP
069 LG-4970R-0122A SPRING COIL D35 ABC NSP
070 LG-4261R-0020A ARM ASSY P2 ABC NSP
076 LG-4510R-0047A LEVER SPRING ABC
077 LG-3300R-M116A PLATE SLIDER ABC
078 LG-4510R-0041A LEVER TENSION ABC
079 LG-3040R-0056A BASE TENSION(D35) ABC
100 LG-3301R-M022A PLATE ASSEMBLY TOP ABC
102 LG-4970R-0130A SPRING COIL D35 (STOPPER) ABC
103 LG-4930R-0276A HOLDER,SHELF SIDE(L) ABC NSP
105 LG-4930R-0274A HOLDER,SHELF CST ABC NSP
106 LG-4930R-0275A HOLDER,SHELF SIDE(R) ABC NSP
107 LG-4510R-0044A LEVER STOPPER ABC NSP
109 LG-5870R-0004A OPENER DOOR ABC
110 LG-4260R-0035A ARM F/L(L) ABC NSP
112 LG-3070R-0002A BODY F/L ABC NSP
11 3 LG-4970R-0127A SPRING COIL D35 (F/L(R)) ABC NSP
11 4 LG-4260R-0036A ARM F/L(R) ABC NSP
11 5 LG-4510R-0042A LEVER SWITCH ABC
11 6 LG-4970R-0138A SPRING COIL D35 SWITCH ABC
117 LG-3300R-M137A PLATE SPRING CST ABC
401 LG-1MEC0261518 SCREW MACHINE,PAN HEAD SPR W #NAME? ABC
402 LG-1MPC0261418 SCREW MACHINE,PAN HEAD D 2.6 L 4.0 MSWR3/FZY ABC
405 LG-1SZZR-0031B SCREW,DRAWING + 1 D2.6 L5.8 SWRCH16A/FZY TAP ABC
406 LG-1MEC0302018 PAN HEAD MACHINE SCREW S/W + D 3.0 L 6.0 MSWR3/FZY ABC
409 LG-1SZZR-0032B SCREW,DRAWING + 1 D2.6 L5.0 SWRCH18A/FZY TAP ABC
410 LG-1APF0262218 SCREW TAP TITE(B),PAN HEAD #NAME? ABC
MECHANISM ASSEMBLY <M4>
A01 LG-6723R-0401B DRUM(CIRC) ASSEMBLY D35-2CH SP/EP (8M2) ABC
A03 LG-4261R-0025A ARM ASSY CLEANER ABC
A04 LG-481 1RF0038A BRACKET ASSEMBLY L/D(S) ABC
A11 LG-4471R-0005A GEAR ASSY P3 ABC
A12 LG-4471R-0004A GEAR ASSY P2 ABC
A21 LG-4931R-0047A HOLDER ASSY CST ABC
A23 LG-4261R-0023A ARM ASSY F/L ABC
A24 LG-4510R-0046A LEVER ASSY SWITCH ABC
001 LG-6723R-0304B DRUM(CIRC) ASSEMBLY SUB D35-2CH (8M2) ABC NSP
002 LG-4680R-B005A MOTOR(MECH) DRUM I2OAL05 SEJIN-SANKYO ICLE ABC
002A LG-5202R00002C BRUSH,CARBON ASSY D33 (TIP+2 SPRING) 1.4, ABC
003 LG-4930R-0284A HOLDER,SHELF FPC(6CH) ABC
004 LG-5006R-0034A CAP FPC ABC
006 LG-4580R-0004A ROLLER CLEANER ABC NSP
007 LG-4260R-0039A ARM CLEANER ABC NSP
008 LG-6850R-HG18Z CABLE,FLAT P=1.25 FFC UL2896(0.05X0.8) 7 ABC
009 LG-4260R-0038A ARM T/UP(D35) ABC
011 LG-4261R-0022A ARM ASSY TENSION(D35) ABC
012 LG-3041R-0037A BASE ASSY P2 ABC
013 LG-3041R-0038A BASE ASSY P3 ABC
014 LG-3041R-0039A BASE ASSY P4 ABC
015 LG-5870R-0005A OPENER LID(D35) ABC
016 LG-3041R-0036A BASE ASSEMBLY A/C HEAD (ALPS) ABC
017 LG-4408R-0003A REEL S ABC
018 LG-4970R-0140A SPRING COIL RS D35 ABC
019 LG-4421R-0008A BRAKE ASSEMBLY RS ABC
020 LG-4970R-0128A SPRING COIL D35 (TB) ABC
021 LG-4421R-0006A BRAKE ASSY T ABC
022 LG-6520D00002A HEAD(CIRC) D35 FE ST FE HEAD ABC
023 LG-3040R-0057A BASE LOADING ABC
024 LG-4261R-0029A ARM ASSEMBLY IDLER (N) ABC
025 LG-4810R-0118A BRACKET L/D(S) ABC NSP
026 LG-4680R-D002A MOTOR(MECH) LOADING MDB2B66 SANKYO D35 ASP ABC
027 LG-4470R-0093A GEAR WHEEL ABC NSP
028 LG-4408R-0004A REEL T ABC
029 LG-4261R-0019A ARM ASSY PINCH ABC
030 LG-4510R-0043A LEVER T/UP ABC
031 LG-4970R-0123A SPRING COIL TENSION(D35) ABC
5-4
MODEL MARK
HR-P55A A
HR-P55A/S B
HR-P56A C *NSP : Not service parts
# REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABC NSP
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
******************************
MAIN BOARD ASSEMBLY <03>
PBM00 LG-6871R-6321K PWB(PCB) ASSEMBLY,T OT AL ELJ102W .NA3RJJ ABC NSP
IC101 STR-A6351 IC,POWER MANAGEMENT STR-A6351 SANKEN 8 DIP ST SMPS ABC
! IC102 LTV-817B SENSOR LTV-817B,PHOTO COUPLER(LITEON) ABC
IC103 LG-0IKE431000A IC,KEC KIA431 3 PIN TP ABC
IC301 LG-0IHI118717B IC,HITACHI HA118717F 100QFP BK AVCP1CHIP ABC
IC501 LG-0IMCRHY054A IC,MICRO CONTROLLER GMS3977R-BB46F HYUNDAI 100 QFP ABC
IC504 LG-0IKE703100A IC,KEC KIA7031P 3P 3.1V RESET(TAPING) ABC
IC505 LG-0IKE704200B IC,KEC KIA7042P 3P 4.2V RESET(TAPING) ABC
Q155 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABC
Q156 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK T O92 ABC
Q157 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABC
Q301 LG-0TR534409AA TRANSISTOR 2SC5344Y TP ABC
Q302 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABC
Q303 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK T O92 22K,22K ABC
Q304 LG-0TR198009CA TRANSISTOR 2SA1980G TP AUK TO92 ABC
Q305 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK T O92 ABC
Q306 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK T O92 ABC
Q307 LG-0TR220309AF TRANSISTOR SRA2203 TP AUK TO92 22K,22K ABC
Q308 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK T O92 22K,22K ABC
Q309 LG-0TR198009CA TRANSISTOR 2SA1980G TP AUK TO92 ABC
Q504 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK T O92 22K,22K ABC
Q505 LG-0TR198009CA TRANSISTOR 2SA1980G TP AUK TO92 ABC
Q514 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK T O92 22K,22K ABC
Q515 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK T O92 22K,22K ABC
Q5P3 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABC
Q5P6 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABC
Q5V1 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABC
Q701 LG-0TR198009CA TRANSISTOR 2SA1980G TP AUK TO92 ABC
Q702 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK T O92 ABC
BD101 S1WBA60 DIODE S1WBA60(1A 600V) SHIDENKEN ABC
D102 EG01CW DIODE,RECTIFIER EG01CW(R-FORM 5MM) TP SANKEN ABC
D103 LG-0DR180209AA DIODE,RECTIFIER ERA18-02KFRB TP FUJI DO204AL 2 ABC
D104 1SS133DIODE,SWITCHING 1SS133 DETECT,SW TP ABC
D106 1N5822DIODE,RECTIFIER 1N5822 BK RECTRON DO201AD 40V ABC
D108 LG-0DR202000AB DIODE,RECTIFIER HER202 BK RECTRON NON 100V 2A ABC
D151 LG-0DR104009AB DIODE,RECTIFIER RL104 R. TP GULF SEMICONDUCTOR ABC
D152 LG-0DR104009AB DIODE,RECTIFIER RL104 R. TP GULF SEMICONDUCTOR ABC
D3M1 1SS133DIODE,SWITCHING 1SS133 DETECT,SW TP ABC
D3M2 1SS133DIODE,SWITCHING 1SS133 DETECT,SW TP ABC
D503 1SS133DIODE,SWITCHING 1SS133 DETECT,SW TP ABC
D509 1SS133DIODE,SWITCHING 1SS133 DETECT,SW TP ABC
DJ03 1SS133DIODE,SWITCHING 1SS133 DETECT,SW TP ABC
DJ10 1SS133DIODE,SWITCHING 1SS133 DETECT,SW TP ABC
DJ14 1SS133DIODE,SWITCHING 1SS133 DETECT,SW TP ABC
ZD503 LG-0DZ627729AA DIODE,ZENER MTZ6.2A T-77(26MM) TP ABC
ZD503 LG-0DZ627729AA DIODE,ZENER MTZ6.2A T-77(26MM) TP ABC
R101 LG-614-007A RESIST OR 2.7/2W CEMENT SMPS V ABC
R102 QRD161J-184Y RESISTOR,FIXED CARBON FILM 180K OHM 1/6 W 5.00% TA26 ABC
R103 QRD161J-470Y RESISTOR,FIXED CARBON FILM 47 OHM 1/6 W 5.00% TA26 ABC
R104 LG-0RS5602K619 RESISTOR,FIXED METAL OXIDE FIL 56K OHM 2 W 5.00% TR ABC
R106 QRD161J-184Y RESISTOR,FIXED CARBON FILM 180K OHM 1/6 W 5.00% TA26 ABC
R109 LG-0RS0350K619 RESISTOR,FIXED METAL OXIDE FIL 0.35 OHM 2 W 5.00% TR ABC
R116 QRD161J-221Y RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5.00% TA26 ABC
R117 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5.00% TA26 ABC
R118 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R119 LG-0RN3301F408 RESISTOR,FIXED METAL FILM 3.3K OHM 1/6 W 1.00% TA26 ABC
R120 LG-0RN2701F408 RESISTOR,FIXED METAL FILM 2.7K OHM 1/6 W 1.00% TA26 ABC
R121 QRD161J-271Y RESISTOR,FIXED CARBON FILM 270 OHM 1/6 W 5.00% TA26 ABC
R125 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R126 QRD161J-681Y RESISTOR,FIXED CARBON FILM 680 OHM 1/6 W 5.00% TA26 ABC
R156 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R157 QRD161J-331Y RESISTOR,FIXED CARBON FILM 330 OHM 1/6 W 5.00% TA26 ABC
R161 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R170 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R171 QRD161J-331Y RESISTOR,FIXED CARBON FILM 330 OHM 1/6 W 5.00% TA26 ABC
R301 QRD161J-334Y RESISTOR,FIXED CARBON FILM 330K OHM 1/6 W 5.00% TA26 ABC
R302 QRD161J-123Y RESISTOR,FIXED CARBON FILM 12K OHM 1/6 W 5.00% TA26 ABC
R303 QRD161J-181Y RESISTOR,FIXED CARBON FILM 180 OHM 1/6 W 5.00% TA26 ABC
R304 QRD161J-273Y RESISTOR,FIXED CARBON FILM 27K OHM 1/6 W 5.00% TA26 ABC
R305 QRD161J-183Y RESISTOR,FIXED CARBON FILM 18K OHM 1/6 W 5.00% TA26 ABC
R306 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5.00% TA26 ABC
R308 QRD161J-470Y RESISTOR,FIXED CARBON FILM 47 OHM 1/6 W 5.00% TA26 ABC
R309 QRD161J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5.00% TA26 ABC
R310 QRD161J-272Y RESISTOR,FIXED CARBON FILM 2.7K OHM 1/6 W 5.00% TA26 ABC
R311 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R312 QRD161J-473Y RESISTOR,FIXED CARBON FILM 47K OHM 1/6 W 5.00% TA26 ABC
R313 QRD161J-123Y RESISTOR,FIXED CARBON FILM 12K OHM 1/6 W 5.00% TA26 ABC
R314 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABC NSP
#
R315 QRD161J-272Y RESISTOR,FIXED CARBON FILM 2.7K OHM 1/6 W 5.00% TA26 ABC
R316 QRD161J-752Y RESISTOR,FIXED CARBON FILM 7.5K OHM 1/6 W 5.00% TA26 ABC
R317 QRD161J-752Y RESISTOR,FIXED CARBON FILM 7.5K OHM 1/6 W 5.00% TA26 ABC
R318 QRD161J-123Y RESISTOR,FIXED CARBON FILM 12K OHM 1/6 W 5.00% TA26 ABC
R319 QRD161J-393Y RESISTOR,FIXED CARBON FILM 39K OHM 1/6 W 5.00% TA26 ABC
R322 QRD161J-682Y RESISTOR,FIXED CARBON FILM 6.8K OHM 1/6 W 5.00% TA26 ABC
R324 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5.00% TA26 ABC
R325 QRD161J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5.00% TA26 ABC
R327 QRD161J-682Y RESISTOR,FIXED CARBON FILM 6.8K OHM 1/6 W 5.00% TA26 ABC
R328 QRD161J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5.00% TA26 ABC
R330 QRD161J-823Y RESISTOR,FIXED CARBON FILM 82K OHM 1/6 W 5.00% TA26 ABC
R332 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R333 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5.00% TA26 ABC
R334 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R336 QRD161J-681Y RESISTOR,FIXED CARBON FILM 680 OHM 1/6 W 5.00% TA26 ABC
R338 QRD161J-271Y RESISTOR,FIXED CARBON FILM 270 OHM 1/6 W 5.00% TA26 ABC
R340 QRD161J-2R2 RESISTOR,FIXED CARBON FILM 2.2 OHM 1/6 W 5.00% TA26 ABC
R341 QRD161J-2R2 RESISTOR,FIXED CARBON FILM 2.2 OHM 1/6 W 5.00% TA26 ABC
R342 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5.00% TA26 ABC
R346 QRD161J-225Y RESISTOR,FIXED CARBON FILM 2.2M OHM 1/6 W 5.00% TA26 ABC
R352 QRD161J-104Y RESISTOR,FIXED CARBON FILM 100K OHM 1/6 W 5.00% TA26 ABC
R353 QRD161J-182Y RESISTOR,FIXED CARBON FILM 1.8K OHM 1/6 W 5.00% TA26 ABC
R503 QRD161J-683Y RESISTOR,FIXED CARBON FILM 68K OHM 1/6 W 5.00% TA26 ABC
R504 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R505 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R506 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R507 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R508 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R509 QRD161J-122Y RESISTOR,FIXED CARBON FILM 1.2K OHM 1/6 W 5.00% TA26 ABC
R510 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R511 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R512 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R513 QRD161J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5.00% TA26 ABC
R514 QRD161J-563Y RESISTOR,FIXED CARBON FILM 56K OHM 1/6 W 5.00% TA26 ABC
R515 QRD161J-271Y RESISTOR,FIXED CARBON FILM 270 OHM 1/6 W 5.00% TA26 ABC
R516 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
R518 QRD161J-121Y RESISTOR,FIXED CARBON FILM 120 OHM 1/6 W 5.00% TA26 ABC
R519 QRD161J-273Y RESISTOR,FIXED CARBON FILM 27K OHM 1/6 W 5.00% TA26 ABC
R521 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R522 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R523 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R524 QRD161J-274Y RESISTOR,FIXED CARBON FILM 270K OHM 1/6 W 5.00% TA26 ABC
R525 QRD161J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5.00% TA26 ABC
R526 QRD161J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5.00% TA26 ABC
R527 QRD161J-561Y RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5.00% TA26 ABC
R528 QRD161J-122Y RESISTOR,FIXED CARBON FILM 1.2K OHM 1/6 W 5.00% TA26 ABC
R530 QRD161J-224Y RESISTOR,FIXED CARBON FILM 220K OHM 1/6 W 5.00% TA26 ABC
R531 QRD161J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5.00% TA26 ABC
R534 QRD161J-105Y RESISTOR,FIXED CARBON FILM 1M OHM 1/6 W 5.00% TA26 ABC
R535 QRD161J-474Y RESISTOR,FIXED CARBON FILM 470K OHM 1/6 W 5.00% TA26 ABC
R536 QRD161J-473Y RESISTOR,FIXED CARBON FILM 47K OHM 1/6 W 5.00% TA26 ABC
R540 QRD161J-151Y RESISTOR,FIXED CARBON FILM 150 OHM 1/6 W 5.00% TA26 ABC
R543 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5.00% TA26 ABC
R544 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R545 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5.00% TA26 ABC
R546 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5.00% TA26 ABC
R547 QRD161J-123Y RESISTOR,FIXED CARBON FILM 12K OHM 1/6 W 5.00% TA26 ABC
R548 QRD161J-104Y RESISTOR,FIXED CARBON FILM 100K OHM 1/6 W 5.00% TA26 ABC
R549 QRD161J-151Y RESISTOR,FIXED CARBON FILM 150 OHM 1/6 W 5.00% TA26 ABC
R550 QRD161J-221Y RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5.00% TA26 ABC
R553 QRD161J-221Y RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5.00% TA26 ABC
R555 QRD161J-221Y RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5.00% TA26 ABC
R556 QRD161J-223Y RESISTOR,FIXED CARBON FILM 22K OHM 1/6 W 5.00% TA26 ABC
R557 QRD161J-273Y RESISTOR,FIXED CARBON FILM 27K OHM 1/6 W 5.00% TA26 ABC
R558 QRD161J-223Y RESISTOR,FIXED CARBON FILM 22K OHM 1/6 W 5.00% TA26 ABC
R559 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R560 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R563 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5.00% TA26 ABC
R564 QRD161J-273Y RESISTOR,FIXED CARBON FILM 27K OHM 1/6 W 5.00% TA26 ABC
R565 QRD161J-682Y RESISTOR,FIXED CARBON FILM 6.8K OHM 1/6 W 5.00% TA26 ABC
R567 QRD161J-821Y RESISTOR,FIXED CARBON FILM 820 OHM 1/6 W 5.00% TA26 ABC
R568 QRD161J-684Y RESISTOR,FIXED CARBON FILM 680K OHM 1/6 W 5.00% TA26 ABC
R569 QRD161J-105Y RESISTOR,FIXED CARBON FILM 1M OHM 1/6 W 5.00% TA26 ABC
R570 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R575 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R576 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R577 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R578 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R579 QRD161J-563Y RESISTOR,FIXED CARBON FILM 56K OHM 1/6 W 5.00% TA26 ABC
R581 QRD161J-683Y RESISTOR,FIXED CARBON FILM 68K OHM 1/6 W 5.00% TA26 ABC
R586 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5.00% TA26 ABC
R589 QRD161J-105Y RESISTOR,FIXED CARBON FILM 1M OHM 1/6 W 5.00% TA26 ABC
R5B1 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
5-5
MODEL MARK
HR-P55A A
HR-P55A/S B
HR-P56A C *NSP : Not service parts
# REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABC NSP
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
R5B3 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R5B4 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R5B5 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5.00% TA26 ABC
R5C1 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5.00% TA26 ABC
R5C5 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R5C6 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R5C7 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R5C9 QRD161J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5.00% TA26 ABC
R5E7 QRD161J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5.00% TA26 ABC
R5E8 QRD161J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5.00% TA26 ABC
R5P3 QRD161J-331Y RESISTOR,FIXED CARBON FILM 330 OHM 1/6 W 5.00% TA26 ABC
R5P6 QRD161J-331Y RESISTOR,FIXED CARBON FILM 330 OHM 1/6 W 5.00% TA26 ABC
R5R1 QRD161J-331Y RESISTOR,FIXED CARBON FILM 330 OHM 1/6 W 5.00% TA26 ABC
R5T1 QRD161J-182Y RESISTOR,FIXED CARBON FILM 1.8K OHM 1/6 W 5.00% TA26 ABC
R5T2 QRD161J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5.00% TA26 ABC
R5T3 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5.00% TA26 ABC
R5T4 QRD161J-272Y RESISTOR,FIXED CARBON FILM 2.7K OHM 1/6 W 5.00% TA26 ABC
R5T5 QRD161J-392Y RESISTOR,FIXED CARBON FILM 3.9K OHM 1/6 W 5.00% TA26 ABC
R5T7 QRD161J-182Y RESISTOR,FIXED CARBON FILM 1.8K OHM 1/6 W 5.00% TA26 ABC
R5T8 QRD161J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5.00% TA26 ABC
R5T9 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5.00% TA26 ABC
R5V1 QRD161J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5.00% TA26 ABC
R706 QRD161J-183Y RESISTOR,FIXED CARBON FILM 18K OHM 1/6 W 5.00% TA26 ABC
R707 QRD161J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5.00% TA26 ABC
R708 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R709 QRD161J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5.00% TA26 ABC
R710 QRD161J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5.00% TA26 ABC
R711 QRD161J-750Y RESISTOR,FIXED CARBON FILM 75 OHM 1/6 W 5.00% TA26 ABC
R712 QRD161J-750Y RESISTOR,FIXED CARBON FILM 75 OHM 1/6 W 5.00% TA26 ABC
R713 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5.00% TA26 ABC
R714 QRD161J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5.00% TA26 ABC
R715 QRD161J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5.00% TA26 ABC
VR501 LG-613-032W RESISTOR,DRAWING RH063MCJ5R (220K) ABC
! C101 LG-624-088L CAPACITOR,DRA WING 435D SUNIL ELECTRONICS 0.1UF/2 ABC
! C102 LG-624-088L CAPACITOR,DRA WING 435D SUNIL ELECTRONICS 0.1UF/2 ABC
C103 LG-0CE686CV610 CAPACITOR,AL.ELECTROLYTIC 68UF SHL,SD 450V M FL BULK ABC
C105 LG-0CQ1031Y519 CAPACITOR,POLYESTER 0.01UF D 630V K PE NI TP ABC
C106 LG-624-087B CAPACITOR HIGH-VOL 100P/1KV SMPS SAMHWA ABC
C109 QET41HM-106 CAPACITOR,FIXED ELECTROLYTIC 10M SRA 50V M FM5 TP(5) ABC
! C112 LG-0CG3320U630 CAPACITOR,SEMI CERAMIC 3300 PF 400V M E R(NK,AD,SD) ABC
! C113 LG-0CG1010U510 CAPACITOR,SEMI CERAMIC 100 PF 400V K B R (NK,AD,SD) ABC
C114 LG-0CQ4732K409 CAPACITOR,FIXED FILM 0.047UF S 50V J PE TP ABC
C116 LG-0CE108BF630 CAPACITOR,FIXED ELECTROLYTIC 1000UF KME 16V M FM5 BULK ABC
C117 LG-0CE3376D638 CAPACITOR,ELECTROLYTIC 330UF SMS 10V M FM5 TP5 ABC
C120 LG-0CE477BH630 CAPACITOR,AL.ELECTROLYTIC 470UF KME TYPE 25V M FM5 BULK ABC
C121 LG-0CE227CH618 CAPACITOR,FIXED ELECTROLYTIC 220UF SHL,SD 25V 20% FL TP 5 ABC
C127 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABC
C129 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABC
C135 LG-0CN4710K518 CAPACITOR TUBULA(HIGH DIELE) 470P 50V K B TA26 ABC
C301 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C302 QET41CM-226 CAPACITOR,ELECTROLYTIC 22M SRA 16V M FM5 TP(5) ABC
C303 LG-0CN1220F668 CAPACITOR TUBULA(HIGH DIELE) 1200P 16V M X TA26 ABC
C304 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABC
C305 LG-0CN2220F668 CAPACITOR,TUBULAR(HIGH DIELEC) 2200P 16V M X TA26 ABC
C306 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABC
C307 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C309 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C311 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C312 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C313 LG-0CQ1032K409 CAPACITOR,POLYESTER(MYLAR) 0.01UF S 50V J PE TP ABC
C314 LG-0CQ3332K409 CAPACITOR,FIXED FILM 0.033UF S 50V J PE TP ABC
C315 QET41CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABC
C317 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C318 LG-0CN1510K518 CAPACITOR TUBULA(HIGH DIELE) 150P 50V K B TA26 ABC
C319 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C320 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C321 LG-0CX3300K408 CAPACITOR TUBULA(T.C) 33P 50V J SL TA26 ABC
C322 LG-0CK104AK945 CAPACITOR,CERAMIC (HIGH DIELEC 0.1UF S 50V Z F TR ABC
C323 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C324 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C325 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C326 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C327 QET41HM-335 CAPACITOR,FIXED ELECTROLYTIC 3.3UF SRA,SS 50V 20% FM5 TP 5 ABC
C328 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C330 QET41HM-225 CAPACITOR,FIXED ELECTROLYTIC 2.2UF SRA,SS 50V 20% FM5 TP 5 ABC
C331 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABC
C333 LG-0CN3310K518 CAPACITOR TUBULA(HIGH DIELE) 330P 50V K B TA26 ABC
C334 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) ABC
C335 QET41CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABC
C336 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C337 LG-0CK104AK945 CAPACITOR,CERAMIC (HIGH DIELEC 0.1UF S 50V Z F TR ABC
C338 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C339 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABC NSP
#
C340 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C341 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C342 QET41CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABC
C344 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABC
C345 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABC
C346 LG-0CC0500K015 CAPACITOR,CERAMIC(TEMP COMP) 5P 50V C NP0 TR ABC
C347 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABC
C348 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C349 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABC
C350 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABC
C351 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C352 QET41HM-225 CAPACITOR,FIXED ELECTROLYTIC 2.2UF SRA,SS 50V 20% FM5 TP 5 ABC
C353 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C354 LG-0CQ2232L559 CAPACITOR,POLYESTER 0.022UF S 63V K PP NI TP5 ABC
C356 LG-0CE3344K638 CAPACITOR,ELECTROLYTIC 0.33M SRA 50V M FM5 TP(5) ABC
C357 LG-0CN3330K518 CAPACITOR,FIXED TUBULAR(High d 0.033UF 50V K B TA26 ABC
C358 QET41HM-335 CAPACITOR,FIXED ELECTROLYTIC 3.3UF SRA,SS 50V 20% FM5 TP 5 ABC
C359 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C360 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C361 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C362 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C363 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C365 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C370 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABC
C371 LG-0CN6810K518 CAPACITOR TUBULA(HIGH DIELE) 680P 50V K B TA26 ABC
C383 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABC
C3M1 LG-0CX5600K408 CAPACITOR,TUBULAR(T.C) 56P 50V J SL TA26 ABC
C3M2 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABC
C501 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C502 LG-0CE4764C638 CAPACITOR,ELECTROLYTIC 47M SRA 6.3V M FM5 TP(5) ABC
C504 LG-0CE4775C618 CAPACITOR,AL.ELECTROLYTIC 470UF SR,SV 6.3V M FL TP 5 ABC
C505 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C508 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C509 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABC
C510 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C512 LG-0CN1810K518 CAPACITOR,FIXED TUBULAR(High d 180P 50V K B TA26 ABC
C513 LG-0CK104AK945 CAPACITOR,CERAMIC (HIGH DIELEC 0.1UF S 50V Z F TR ABC
C518 LG-0CN1010K418 CAPACITOR,TUBULAR(HIGH DIELEC) 100PF 50V J B TA26 ABC
C519 LG-0CN1210K418 CAPACITOR,TUBULAR(HIGH DIELEC) 120PF 50V J B TA26 ABC
C521 LG-0CX4700K408 CAPACITOR TUBULA(T.C) 47P 50V J SL TA26 ABC
C524 QET41CM-336 CAPACITOR,ELECTROLYTIC 33M SRA 16V M FM5 TP(5) ABC
C525 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C526 LG-0CE4764J638 CAPACITOR,AL.ELECTROLYTIC 47UF SRA,SS 35V M FM5 TP 5 ABC
C527 LG-0CN1210K418 CAPACITOR,TUBULAR(HIGH DIELEC) 120PF 50V J B TA26 ABC
C530 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABC
C531 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABC
C533 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABC
C534 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABC
C535 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABC
C540 LG-0CN3330K518 CAPACITOR,FIXED TUBULAR(High d 0.033UF 50V K B TA26 ABC
C541 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABC
C542 LG-0CN6810K518 CAPACITOR TUBULA(HIGH DIELE) 680P 50V K B TA26 ABC
C543 LG-0CN2220F668 CAPACITOR,TUBULAR(HIGH DIELEC) 2200P 16V M X TA26 ABC
C544 LG-0CQ4732K409 CAPACITOR,FIXED FILM 0.047UF S 50V J PE TP ABC
C545 LG-0CN3330K518 CAPACITOR,FIXED TUBULAR(High d 0.033UF 50V K B TA26 ABC
C551 LG-0CQ3332K409 CAPACITOR,FIXED FILM 0.033UF S 50V J PE TP ABC
C552 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C556 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C557 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C561 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C564 LG-0CN3310K518 CAPACITOR TUBULA(HIGH DIELE) 330P 50V K B TA26 ABC
C567 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABC
C570 LG-0CC1500K415 CAPACITOR,CERAMIC(TEMP COMP) 15P 50V J NP0 TS ABC
C571 LG-0CC1500K415 CAPACITOR,CERAMIC(TEMP COMP) 15P 50V J NP0 TS ABC
C574 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABC
C575 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABC
C576 LG-0CC1400K415 CAPACITOR,FIXED CERAMIC(Temp.c 14PF 50V J NP0 TR ABC
C577 LG-0CC1500K415 CAPACITOR,CERAMIC(TEMP COMP) 15P 50V J NP0 TS ABC
C581 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C582 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C588 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABC
C591 LG-0CE4764H638 CAPACITOR,FIXED ELECTROLYTIC 47M SRA 25V M FM5 TP(5) ABC
C596 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABC
C5G1 LG-0CE4775C618 CAPACITOR,AL.ELECTROLYTIC 470UF SR,SV 6.3V M FL TP 5 ABC
C5R1 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C5V1 LG-0CX5600K408 CAPACITOR,TUBULAR(T.C) 56P 50V J SL TA26 ABC
C704 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C705 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C706 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABC
C709 LG-0CE4775C618 CAPACITOR,AL.ELECTROLYTIC 470UF SR,SV 6.3V M FL TP 5 ABC
C7M1 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABC
C7M3 LG-0CX5600K408 CAPACITOR,TUBULAR(T.C) 56P 50V J SL TA26 ABC
C7M5 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABC
5-6
MODEL MARK
HR-P55A A
HR-P55A/S B
HR-P56A C *NSP : Not service parts
# REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABC NSP
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABC NSP
#
C7M7 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABC
FL301 LG-633-032N COIL,IFT BIAC OSC DEO-010 KWANGSUNG ABC
! L102 LG-616-145N FILTER(CIRC),DRAWING LFS2020V4-04350B SAMWAH TECOM ABC
L103 LG-633-088G COIL,CHOKE CHOCK(22MH) 5MM TOKO TP ABC
L104 LG-633-088G COIL,CHOKE CHOCK(22MH) 5MM TOKO TP ABC
L301 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP ABC
L303 LG-0LA2700K018 INDUCTOR AXIAL LEAD 270U K 2.3X3.4 L5 TP ABC
L304 LG-0LR1000J0N5 INDUCTOR,RADIAL LEAD 100UH 5% TP 3X5 TR5 ABC
L305 LG-0LR1000J0N5 INDUCTOR,RADIAL LEAD 100UH 5% TP 3X5 TR5 ABC
L306 LG-0LA0122K018 INDUCTOR AXIAL LEAD 12M K 2.3X3.4 L5 TP ABC
L311 LG-0LA1000K018 INDUCTOR AXIAL LEAD 100M K 2.3X3.4 L5 TP ABC
L501 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP ABC
L503 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP ABC
L505 LG-0LR0102K035 INDUCTOR RADIAL LEAD 10M K 6X6 L5 TP ABC
L506 LG-0LR0681K035 INDUCTOR RADIAL LEAD 6.8M K 6X6 L5 TP ABC
L5G1 LG-0LR4700K035 INDUCTOR RADIAL LEAD 470M K 6X6 L5 TP ABC
L5V1 LG-0LA0332K018 INDUCTOR AXIAL LEAD 33M K 2.3X3.4 L5 TP ABC
L701 LG-0LR0222K035 INDUCTOR RADIAL LEAD 22M K 6X6 L5 TP ABC
L7M1 LG-0LR1000J025 INDUCTOR,RADIAL LEAD 100UH 5 4X5 TR5 ABC
L7M2 LG-0LA1000K018 INDUCTOR AXIAL LEAD 100M K 2.3X3.4 L5 TP ABC
L7M3 LG-0LA1000K018 INDUCTOR AXIAL LEAD 100M K 2.3X3.4 L5 TP ABC
! F101 LG-585-011T FUSE,SLOW BLOW 1600MA 250 V 5.2X20 CY/GL SEMK ABC
! FH01 LG-586-008B HOLDER FUSE CLIP TP SINSUNG ABC
! FH02 LG-586-008B HOLDER FUSE CLIP TP SINSUNG ABC
JK701 LG-6612R-C011B JACK,RCA RCA-412-1 YUQIU ABC
LD501 LG-4931R-0017C HOLDER ASSY LED(DI-CKD)LOCAL ABC
LED502 LG-6301R2U001G LED ASSEMBLY TOH-30M-G--R- OASIS UNIVERSAL ABC
RS501 LG-6500RAB003A SENSOR SG-260 KODENSHI D33 REEL SENSO ABC
RS502 LG-6500RAB003A SENSOR SG-260 KODENSHI D33 REEL SENSO ABC
CS501 LG-6600M000002 SWITCH,PUSH MPU11810MLB0 MIC DC 5V 1MA D-3 ABC
MS501 LG-6600JB8005B SWITCH,MODE NON 5V 1MA VERTICAL -G ABC
SW5T0 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABC
SW5T1 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABC
SW5T3 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABC
SW5T4 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABC
SW5T5 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABC
SW5T6 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABC
SW5T7 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABC
SW5T8 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABC
SW5T9 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABC
! T101 LG-642-015G TRANSFORMER,SMPS SJE-015G/SHT-015G SJ/SH/CS/LSE ABC
X503 LG-6202R31771E RESONATOR,CRYSTAL 25PPM SSANG TAE 17-734476MHZ ABC
X302 LG-6202R-AJ07E RESONATOR,CRYSTAL H49U SSANG TAE 4433783HZ 15P ABC
X501 LG-6212AA2100C RESONATOR,CRYSTAL HC-49S BUBANG 10MHZ +/- 30 PPM ABC
X301 LG-6212AA2357F RESONATOR,CRYSTAL HC-49U KITELCO 3.579620MHZ +/- ABC
E. & O. E. No.82939 (VP)-V15P1
5-7
Loading...
