SECTION 5
PARTS LIST
SAFETY PRECAUTION
Parts identified by the ! symbol are critical for safety. Replace only with specified part numbers.
5.1 CABINET AND CHASSIS ASSEMBLY
<M2>
BEWARE OF BOGUS PARTS
Parts that do not meet specifications may cause
trouble in regard to safety and performance. We
recommend that genuine JVC parts be used.
509
510
516
505
505F
505E
508
507
507
505D
505C
505H
525
506
505B
505A
505G
WR1
A
K
518
518B
518A
518C
K
510
B
WR2
515
522
DEMOD BOARD
ASSY <14>
(HR-J770KR)
MAIN BOARD
ASSY <03>
512
503
522
524
504
502
503
H
H
R.PAUSE BOARD
ASSY <06>
B
A
C
(Incl.<03>)
517
501C
MECHANISM
ASSY <M4>
516
D
501A
501B
514
513
501
D
MINI FRONT
BOARD ASSY <28>
523
WR3
C
SPEC OF BARCODE
511
5-1
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
******************************
CABINET AND CHASSIS ASSEMBLY <M2>
!
501 LP10289-036B FRONT PANEL ASSY,J770KR
!
501A LP20868-014A CASSETTE DOOR
501B PQ46448 TORSION SPRING
501C LP20869-050A DISPLAY WINDOW,J770KR
!
502 LP10013-031C TOP COVER
503 QYTDSF3010R SCREW,X2 TOP COVER(SIDE)
504 QYTDSF3010M SCREW,TOP COVER(REAR)
505 LP20617-001A DRUM SUB ASSY
505A LP20616-001A UPPER DRUM ASSY
505B PDM4439 CAP
505C PDM4444-19-2 WASHER
505D LP40572-001A COLLAR ASSY
505E LP40323-001A CONTACT
505F LP30004-014A COMPRESSION SPRING
505G LP40174-001B FPC PLATE
505H LP20615-001A LOWER DRUM ASSY
506 PDZ0179-1-4 ROTOR ASSY
507 QYSPSP3006Z SCREW,X2
!
508 QAR0119-001 STATOR ASSY
509 QYSPSPH2606Z SCREW,X2
510 QYTDST2610Z SCREW,X3 DRUM
!
511 LP10108-002D BOTTOM CHASSIS
512 QYTDSF3010Z SCREW,MAIN
513 LP30312-001B BRACKET(CHASSIS)
514 QYTDSF3010Z SCREW,X2
515 QYTDSF4012Z SCREW,MECHA
516 QYTDSF3010Z SCREW,X2 MECHA
!
517 PQ21730N POWER CORD,J770KR
!
518 LP40369-001D CLEANER ASSY
518A PQ46418-1-2 CLEANER ROLLER
518B PQ46419-1-2 CLEANER
518C LP30407-001D CLEANER ARM
522 LP40226-001A PC SUPPORT,X2
523 LP40628-001B PC SUPPORT
524 LP40253-001B STOPPER
525 PQ40413 SPECIAL SCREW,MECHA
WR1 QUQ212-0518CG FFC WIRE,DRUM CN3002
WR2 WJT0005-002A E-CARD WIRE,A/C HEAD CN2001
WR3 QUQ112-0914CG FFC WIRE,FRONT CN7001
LP10289-041B FRONT PANEL ASSY,J2010T
LP20869-059A DISPLAY WINDOW,J2010T
QMP73J0-170 POWER CORD,J2010T
5-2
5.2 ELECTRICAL PARTS LIST
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
******************************
DEMOD BOARD ASSEMBLY <14>
PW1 PB11091A DEMOD BOARD ASSY
IC1501 KA2268 IC
Q1501 2SC1740S/QRS/-T TRANSISTOR
or 2SC3199(G) TRANSISTOR
Q1502 DTC144WS TRANSISTOR
R1501 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R1502 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1503 NRSA02J-822X MG RESISTOR 8.2kØ,1/10W
R1504 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R1505 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R1506 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R1507 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1508 NRSA02J-273X MG RESISTOR 27kØ,1/10W
R1509 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R1510 NRSA02J-563X MG RESISTOR 56kØ,1/10W
R1511 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R1512 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R1513 NRSA02J-123X MG RESISTOR 12kØ,1/10W
R1514 NRSA02J-123X MG RESISTOR 12kØ,1/10W
R1515 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R1516 NRSA02J-273X MG RESISTOR 27kØ,1/10W
R1517 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R1518 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1520 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1521 NRSA02J-471X MG RESISTOR 470Ø,1/10W
VR1501 QVPA606-103Z V RESISTOR,SEPARATION
VR1502 QVP0039-683Z V RESISTOR,PILOT VCO
C1501 NCB21EK-473X CAPACITOR 0.047µF,25V
C1502 QEKC1CM-106 E CAPACITOR 10µF,16V
C1503 NCB21HK-471X CAPACITOR 470pF,50V
C1505 NDC21HJ-470X CAPACITOR 47pF,50V
C1506 NDC21HJ-470X CAPACITOR 47pF,50V
C1507 NCB21EK-104X CAPACITOR 0.1µF,25V
C1508 QFV11HJ-124 F CAPACITOR 0.12µF,50V
C1509 NCB21EK-104X CAPACITOR 0.1µF,25V
C1510 NCB21EK-473X CAPACITOR 0.047µF,25V
C1512 NCB21EK-683X CAPACITOR 0.068µF,25V
C1513 QEKC1EM-475 E CAPACITOR 4.7µF,25V
C1514 QEKC1EM-475 E CAPACITOR 4.7µF,25V
C1515 QFLC1HJ-683Z F CAPACITOR 0.068µF,50V
C1516 NCB21EK-473X CAPACITOR 0.047µF,25V
C1517 QETC1CM-227 E CAPACITOR 220µF,16V
C1518 QEKC1CM-106 E CAPACITOR 10µF,16V
C1519 QEKC1CM-106 E CAPACITOR 10µF,16V
C1520 QEKC1CM-106 E CAPACITOR 10µF,16V
C1522 QEKC1CM-106 E CAPACITOR 10µF,16V
C1523 NCB21HK-332X CAPACITOR 0.0033µF,50V
C1524 QETC1CM-227 E CAPACITOR 220µF,16V
C1526 NDC21HJ-470X CAPACITOR 47pF,50V
C1527 NDC21HJ-470X CAPACITOR 47pF,50V
C1528 QEKC1CM-106 E CAPACITOR 10µF,16V
C1530 NCB21EK-473X CAPACITOR 0.047µF,25V
L1501 QQL01BJ-680Z COIL 68µH
CF1501 PEVB0685 CERAMIC FILTER
CF1502 PEVB0686 CERAMIC FILTER
CF1503 PEVB0688 CERAMIC FILTER
T1501 PELN1238 IF.TRANSFORMER,SUB DET
T1502 PELN1239 IF.TRANSFORMER,MAIN DET
BK1 LP40077-001A BRACKET(BOARD)
CN1501 QGG2502K1-09 HEADER PIN
(Sanwa)-V13D1E. & O. E. No. 82817
5-3
