JVC GR-DX106, GR-DX76 Instruction Manual

DIGITAL VIDEO CAMERA

ENGLISH

CONTENTS

GR-DX106 GR-D X76

Please visit our Homepage on the World Wide Web for Digital Video Camera:

http://www.jvc-victor.co.jp/english/cyber/

For Accessories:

http://www.jvc-victor.co.jp/english/accessory/

AUTOMATIC DEMONSTRATION

GETTING STARTED 7 – 11

TAPE RECORDING & PLAYBACK

MEMORY CARD RECORDING & PLAYBACK

ADVANCED FEATURES

REFERENCES 45 – 59

12 – 16

17 – 24

25 – 44

INSTRUCTIONS

ENLYT1164-001A

SAFETY PRECAUTIONS 3 PROVIDED ACCESSORIES 5 HOW TO ATTACH THE LENS CAP 5 HOW TO ATTACH THE CORE FILTER 6 AUTOMATIC DEMONSTRATION 6

GETTING STARTED

Power ............................. 7 – 8

Grip Adjustment ........................... 8

Viewfinder Adjustment ...................... 8

Tripod Mounting ........................... 9

Loading/Unloading A Cassette ............... 9 – 10

Date/Time Settings........................ 10

Recording Mode Setting ..................... 10

Loading A Memory Card ..................... 11

Picture Quality/Image Size Setting .............. 11

TAPE RECORDING & PLAYBACK

TAPE RECORDING ................. 12 – 14

Basic Recording ..................... 12 – 13

Zooming ............................ 13

Time Code ........................... 14

TAPE PLAYBACK .................. 14 – 16

Normal Playback .................... 14 – 15

Blank Search .......................... 15

Connections .......................... 16

MEMORY CARD RECORDING & PLAYBACK

MEMORY CARD RECORDING .......... 17 – 18

Basic Shooting (Snapshot) ............... 17 – 18

MEMORY CARD PLAYBACK ........... 18 – 19

Normal Playback ....................... 18

Auto Playback ......................... 19

Index Playback ........................ 19

Viewing File Information ................... 19

Removing On-Screen Display ................ 19

ADVANCED FEATURES ............... 20 – 24

Protecting Files ........................ 20

Deleting Files .......................... 20

NAVIGATION Function ................. 21 – 22

E-Mail Clip Recording ..................... 22

Dubbing Still Images Recorded

On A Tape To A Memory Card ............... 23

Setting Print Information (DPOF Setting) ........ 23 – 24

Making A New Folder..................... 24

Initialising A Memory Card .................. 24

ADVANCED FEATURES

FOR RECORDING .................. 25 – 31

Snapshot Flash ......................... 25

Flash Brightness Adjustment ................. 25

Self-Timer (GR-DX106 only) ................ 26

5-Second Recording (GR-DX106 only) ........... 26

Night-Scope .......................... 27

Programme AE With Special Effects............. 27

Fade/Wipe Effects ...................... 28

Snapshot (For Tape Recording) ............... 29

Auto Focus ........................... 29

Manual Focus ......................... 30

Exposure Control ....................... 30

Iris Lock ............................. 31

White Balance Adjustment .................. 31

Manual White Balance Operation .............. 31

USING MENUS FOR DETAILED ADJUSTMENT .. 32 – 36

For Recording Menu ................... 32 – 35

For Playback Menu ................... 35 – 36

DUBBING .......................37 – 38

Dubbing To Or From A VCR ................. 37

Dubbing To Or From A Video Unit Equipped

With A DV Connector (Digital Dubbing) ......... 38

USING THE REMOTE CONTROL UNIT ....... 39 – 43

Slow-Motion Playback .................... 39

Frame-By-Frame Playback .................. 39

Playback Special Effects ................... 39

Playback Zoom ........................ 39

Audio Dubbing ......................... 40

Insert Editing .......................... 40

Random Assemble Editing [R.A.Edit] ......... 41 – 43

For More Accurate Editing .................. 43

SYSTEM CONNECTIONS ................. 44

Connection To A Personal Computer ............ 44

REFERENCES

TROUBLESHOOTING ................ 45 – 47

CAUTIONS ...................... 48 – 50

SPECIFICATIONS...................... 51

INDEX ........................ 52 – 57

Controls, Connectors And Indicators ......... 52 – 53

LCD Monitor/Viewfinder Indications ......... 54 – 57

TERMS ........................ 58 – 59

Refer to the diagrams on page 52 and 54 while reading the instruction manual as all the controls, connectors, indicators and indications are numbered on the diagrams and those corresponding numbers are used throughout this manual unless specified.

None

Dear Customer,

Thank you for purchasing this digital video camera. Before use, please read the safety information and precautions (墌 pgs. 3 and 4) to ensure safe use of this product.

SAFETY PRECAUTIONS

WARNING: TO PREVENT FIRE OR SHOCK HAZARD,

DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTIONS:

● If you notice smoke or a peculiar smell coming from the camcorder or AC Adapter, shut it down and unplug it immediately. Continue using the camcorder or AC Adapter under these conditions could lead to fire or electric shock. Contact your JVC dealer. Do not attempt to repair the malfunction yourself.

● To prevent shock, do not open the cabinet. No user serviceable parts inside. Refer servicing to qualified personnel.

● When you are not using the AC Adapter for a long period of time, it is recommended that you disconnect the power cord from AC outlet.

NOTES:

● The rating plate (serial number plate) and safety caution are on the bottom and/or the back of the main unit.

● The rating information and safety caution of the AC Adapter are on its upper and lower sides.

CAUTION:

To avoid electric shock or damage to the unit, first firmly insert the small end of the power cord into the AC Adapter until it is no longer wobbly, and then plug the larger end of the power cord into an AC outlet.

CAUTIONS:

● This camcorder is designed to be used with PAL-type colour television signals. It cannot be used for playback with a television of a different standard. However, live recording and LCD monitor/viewfinder playback are possible anywhere.

● Use the JVC BN-V107U/V114U battery packs and, to recharge them or to supply power to the camcorder from an AC outlet, use the provided multi-voltage AC Adapter and Power Cord. (An appropriate conversion adapter may be necessary to accommodate different designs of AC outlets in different countries.)

When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear).

Do not block the ventilation holes. (If the ventilation holes are blocked by a newspaper, or cloth etc. the heat may not be able to get out.)

No naked flame sources, such as lighted candles, should be placed on the apparatus.

When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.

The apparatus shall not be exposed to dripping or splashing.

Do not use this equipment in a bathroom or places with water. Also do not place any containers filled with water or liquids (such as cosmetics or medicines, flower vases, potted plants, cups etc.) on top of this unit. (If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

NoneNone

Do not point the lens or the viewfinder directly into the sun. This can cause eye injuries, as well as lead to the malfunctioning of internal circuitry. There is also a risk of fire or electric shock.

CAUTION!

The following notes concern possible physical damage to the camcorder and to the user.

Do not carry or hold the camcorder by the viewfinder and/or the LCD monitor as this can result in dropping the unit, or in a malfunction.

Take care not to get your finger caught in the cassette holder cover. Do not let children operate the camcorder, as they are particularly susceptible to this type of injury.

Do not use a tripod on unsteady or unlevel surfaces. It could tip over, causing serious damage to the camcorder.

CAUTION!

Connecting cables (Audio/Video, S-Video, etc.) to the camcorder and leaving the unit on top of the TV is not recommended, as tripping on the cables will cause the camcorder to fall, resulting in damage.

䡲 This camcorder is designed exclusively for the digital video cassette, SD Memory Card and MultiMediaCard. Only

cassettes marked “ ” and memory cards marked “ ” or “ ” can be used with this unit.

Before recording an important scene . . .

..... make sure you only use cassettes with the Mini DV mark .

..... make sure you only use memory cards with the mark or .

..... remember that this camcorder is not compatible with other digital video formats.

..... remember that this camcorder is intended for private consumer use only. Any commercial use without proper

permission is prohibited. (Even if you record an event such as a show, performance or exhibition for personal enjoyment, it is strongly recommended that you obtain permission beforehand.)

None

PROVIDED ACCESSORIES

AC Adapter AP-V13A or AP-V11E, AP-V13E

Memory Card 8 MB (Already inserted in the camcorder)

AAA (R03) Battery x 2 (for remote control unit)

Remote Control Unit RM-V717U

Power Cord

Tab

Battery Pack BN-V107U or BN-V107U-S

Grip Belt (Already attached to the camcorder)

AAA (R03) Battery x 2

–

Lens Cap (See below for attachment)

CD-ROM

S-Video/Audio/ Video/Editing Cable

Editing Extension Cable

USB Cable

Core Filter (for provided USB Cable 墌 pg. 6 for attachment)

Core Filter x 2 (for provided S-Video/Audio/ Video/Editing Cable and AC Adapter’s cord for attachment)

墌 pg. 6

NOTE:

In order to maintain optimum performance of the camcorder, provided cables may be equipped with one or more core filter. If a cable has only one core filter, the end that is closest to the filter should be connected to the camcorder.

HOW TO ATTACH THE LENS CAP

To protect the lens, attach the provided lens cap to the camcorder as shown in the illustration.

NOTE:

To confirm the lens cap is on correctly make sure the cap is flush to the camera.

None

HOW TO ATTACH THE CORE FILTER

Attach the Core Filter(s) to the provided AC Adapter’s cord, S-Video/Audio/Video/Editing cable and USB cable. The Core Filter reduces interference.

1 Release the

stoppers on both ends of the Core Filter.

Stopper

䡲 When connecting cables, attach the end with the Core Filter to the camcorder.

2 1) Run the cable through the Core Filter, leaving approx. 3 cm of cable between

the cable plug and the Core Filter. If using the AC Adapter’s cord or USB cable, be sure to wind the cable once around the outside of the Core Filter as shown in the illustration. Wind the cable so that it is not slack.

NOTE: Take care not to damage the cable.

2) Close the Core Filter until it clicks shut.

3 cm

For the AC Adapter’s cord and USB cable

Wind once

For the S-Video/Audio/Video/Editing cable

3 cm

AUTOMATIC DEMONSTRATION

Automatic Demonstration takes place when “DEMO MODE” is set to “ON” (factory-preset).

䡲 Automatic Demonstration starts when there is no operation for

about 3 minutes after the Power Switch @ is set to “ ” or “ ” and no cassette is in the camcorder.

䡲 Performing any operation during the demonstration stops the

demonstration temporarily. If no operation is performed for more than 3 minutes after that, the demonstration will resume.

䡲 “DEMO MODE” remains “ON” even if the camcorder power is

turned off.

䡲 To cancel Automatic Demonstration:

1. Set the Power Switch @ to “ ” while pressing down the Lock Button $ located on the switch and press MENU 4. The Menu Screen appears.

2. Press + or – 5 to select “ (SYSTEM)” and press SELECT/SET 3.

3. Press + or – 5 to select “DEMO MODE” and press SELECT/SET 3. The Sub Menu appears.

EMO MODED–

4. Press + or – 5 to select “OFF” and press SELECT/SET 3.

5. Press + or – 5 to select “ RETURN”, and press SELECT/SET 3 twice. The normal screen appears.

RETURN

NOTE:

If you do not detach the Lens Cap, you cannot see the actual changes of the Automatic Demonstration activated on the LCD monitor or viewfinder.

Sub Menu

SYSTE

OFF

@3$4 5

None

Power

CHARGING THE BATTERY PACK

1 Insert the terminal end of the battery pack into the

battery pack mount battery pack in the direction of the arrow until it locks into place as shown in the illustration.

y, then firmly push the end of the

2 Set the Power Switch @ to “OFF”. Connect the AC

Adapter to the camcorder, then connect the Power Cord to the AC Adapter.

3 Plug the Power Cord into an AC outlet. The Power

lamp 0 on the camcorder blinks to indicate charging has started.

4 When the Power lamp 0 goes off, charging is

finished. Unplug the Power Cord from the AC outlet. Disconnect the AC Adapter from the camcorder.

To Detach The Battery Pack: While sliding BATT. RELEASE W up, detach it.

Battery pack

BN-V107U

BN-V114U (optional)

Charging times are for a fully discharged battery pack.

USING THE BATTERY PACK

Perform step 1 of “CHARGING THE BATTERY PACK”.

Approximate recording time

Battery pack

BN-V107U

BN-V114U (optional)

BN-V840U (optional)

BN-V856U (optional)

LCD monitor on

1 hr. 5 min.

2 hrs. 10 min.

5 hrs. 50 min.

8 hrs. 20 min.

USING AC POWER

Connect the AC Adapter to the camcorder as shown in the following illustration.

• The provided AC Adapter features automatic voltage selection in the AC range from 110 V to 240 V.

Charging time

approx. 1 hr. 30 min.

approx. 3 hrs.

Viewfinder on

1 hr. 25 min.

2 hrs. 55 min.

7 hrs. 50 min.

11 hrs. 10 min.

To D C connector

AC Adapter

y @

To AC outlet

Battery pack

ATTENTION

Before detaching the power source, make sure that the camcorder’s power is turned off. Failure to do so can result in a camcorder malfunction.

INFORMATION

The extended-use battery pack kit is a set composed of a battery pack and AC Power Adapter/Charger:

VU-V840 KIT : BN-V840U battery pack & AA-V15 AC

VU-V856 KIT : BN-V856U battery pack & AA-V80 AC

Read the kit's instruction manual before using. Also, by using the optional JVC VC-VBN856U DC Cord, it will be possible to connect BN-V840U or BN-V856U battery packs to the camcorder and supply power directly to the camcorder.

Power Adapter/Charger

NOTES:

● If the protective cap is attached to the battery pack, remove it first.

● During charging, the camcorder cannot be operated.

● Charging is not possible if the wrong type of battery is

used.

● When charging the battery pack for the first time or after a long storage period, the Power lamp Remove the battery pack from the camcorder, then try charging again.

● If a fully-charged battery’s operation time remains extremely short, the battery is worn out. Please purchase a new one.

● Recording time is reduced significantly when Zoom or Record-Standby mode is engaged repeatedly or the LCD monitor is used repeatedly.

● Before extended use, it is recommended that you prepare enough battery packs to cover 3 times the planned shooting time.

0 may not light.

Continued on next page.

GETTING STARTED

● Since the AC Adapter processes electricity internally, it becomes warm during use. Be sure to use it only in well-ventilated areas.

● The following operation stops charging:

• Set the Power Switch

• Disconnect the AC Adapter from the camcorder.

@ to “ ”, “ ” or “ ”.

• Unplug the AC Adapter from the AC outlet.

• Detach the battery from the camcorder.

●

This camcorder will be automatically turned off if its power is supplied from the AC adapter and about 5 minutes pass since it has entered into the recording standby mode with a cassette inserted. If, under those conditions, the battery is attached to the camcorder, its charging will start.

● Using the optional AA-V100 AC Power Adapter/Charger, you can charge the BN-V107U/V114U battery pack without the camcorder. However, it cannot be used as an AC adapter.

● To avoid interference with reception, do not use the AC Adapter near a radio.

● Perform charging where the temperature is between 10°C and 35°C. 20°C to 25°C is the ideal temperature range for charging. If the environment is too cold, charging may be incomplete.

● Charging time varies according to the ambient temperature and the status of the battery pack.

About Batteries

DANGER! Do not attempt to take the batteries apart, or

expose them to flame or excessive heat, as it may cause a fire or explosion.

WARNING! Do not allow the battery or its terminals to come in contact with metals, as this can result in a short circuit and possibly start a fire.

The Benefits Of Lithium-Ion Batteries

Lithium-ion battery packs are small but have a large power capacity. However, when one is exposed to cold temperatures (below 10°C), its usage time becomes shorter and it may cease to function. If this happens, place the battery pack in your pocket or other warm, protected place for a short time, then re-attach it to the camcorder. As long as the battery pack itself is not cold, it should not affect performance.

(If you’re using a heating pad, make sure the battery pack does not come in direct contact with it.)

Grip Adjustment

1 Separate the Velcro strip. 2 Pass your right hand through the loop and grasp the

grip.

3 Adjust your thumb and fingers through the grip, to

easily operate the Recording Start/Stop button ! and Power Switch @ and Power Zoom (SHUTTLE SEARCH) Ring #. Be sure to fasten the Velcro strip to your preference.

Viewfinder Adjustment

1 Set the Power Switch @ to “ ” or “ ” while

pressing down the Lock Button $ located on the switch.

2 Pull out the viewfinder fully and adjust it manually for

best viewability.

3 Slide the Dioptre Adjustment Control o until the

indications in the viewfinder are clearly focused.

PAUSE

Lithium-ion is vulnerable in colder temperatures.

GETTING STARTED

Tripod Mounting

CAUTION

When attaching the camcorder to a tripod, extend its legs to stabilise the camcorder. It is not advised to use small sized tripods. This may cause damage to the unit by falling over.

1 To attach the camcorder to a tripod, align the screw

to the mounting socket p on the camcorder. Then tighten the screw clockwise. Some tripods are not equipped with studs.

Loading/Unloading A Cassette

The camcorder needs to be powered up to load or eject a cassette.

1 Slide and hold OPEN/EJECT E in the direction of

the arrow then pull the cassette holder cover open until it locks. The cassette holder opens automatically.

• Do not touch internal components.

2 Insert or remove a tape and press “PUSH HERE” to

close the cassette holder.

• Once the cassette holder is closed, it recedes automatically. Wait until it recedes completely before closing the cassette holder cover.

• When the battery’s charge is low, you may not be able to close the cassette holder cover. Do not apply force. Replace the battery with a fully charged one before continuing.

3 Close the cassette holder cover firmly until it locks

into place.

To Protect Valuable Recordings:

Slide the erase protection tab on the back of the tape in the direction of “SAVE”. This prevents the tape from being recorded over. To record on this tape, slide the tab back to “REC” before loading it.

Make sure the window side is facing out.

Cassette holder

Cassette holder cover

Be sure to press only the section labeled “PUSH HERE” to close the cassette holder; touching other parts may cause your finger to get caught in the cassette holder, resulting in injury or product damage.

Approximate recording time

Tape

30 min. 30 min. 45 min.

60 min. 60 min. 90 min.

80 min. 80 min. 120 min.

NOTES:

● The cassette holder cannot be opened unless a power

supply is attached.

Recording mode

SP LP

Continued on next page.

GETTING STARTED

● It takes a few seconds for the cassette holder to open. Do not apply force.

● There may be a delay after you open the cassette holder cover until the cassette holder opens. Do not use force.

● If you wait a few seconds and the cassette holder does not open, close the cassette holder cover and try again. If the cassette holder still does not open, turn the camcorder off then on again.

● If the tape does not load properly, open the cassette holder cover fully and remove the cassette. A few minutes later, insert it again.

● When the camcorder is suddenly moved from a cold place to a warm environment, wait a short time before opening the cassette holder cover.

● Once the cassette holder is closed, it recedes automatically. Wait until it recedes completely before closing the cassette holder cover.

● Closing the cassette holder cover before the cassette holder comes out may cause damage to the camcorder.

● Even when the camcorder is switched off, a cassette can be loaded or unloaded. After the cassette holder is closed with the camcorder switched off, however, it may not recede. It is recommended to turn the power on before loading or unloading.

● When resuming recording, once you open the cassette holder cover a blank portion will be recorded on the tape or a previously recorded scene will be erased (recorded over) regardless of whether the cassette holder came out or not. See page 14 for information about recording from the middle of a tape.

Date/Time Settings

The date/time is recorded onto the tape at all times, but its display can be turned on or off during playback (墌 pg. 34).

1 Set the Power Switch @ to “ ” while pressing

down the Lock Button $ located on the switch, and open the LCD monitor fully or pull out the viewfinder fully. The Power lamp 0 lights and the camcorder is turned on.

2 Press MENU 4 to access the Menu Screen. 3 Press + or – 5 to select “ (CAMERA DISPLAY)”

and press SELECT/SET 3.

4 Press + or – 5 to select “CLOCK ADJ.”. Press

SELECT/SET 3 and “day” is highlighted. Press + or –

5 to input the day. Press SELECT/SET 3. Repeat to

input the month, year, hour and minute. Press + or – 5 to select “ RETURN”, and press SELECT/SET 3 twice. The Menu Screen closes.

NOTES:

● Even if you select “CLOCK ADJ.”, if the parameter is not highlighted the camcorder’s internal clock continues to operate. Once you move the highlight bar to the first date/ time parameter (day), the clock stops. When you finish setting the minute and press SELECT/SET and time begin operation from the date and time you just set.

墌 pg. 49, “Built-in Clock’s Rechargeable Lithium Battery”.

●

3, the date

RE NEON SC

IMETDATE / TIME CODE

CLOCK

ADJ .

RETURN

ISPLAY

AREMACD

–

LCD/ TV

UAOT

–

FFO

–

2.025 .113 30:7

CLOCK

ADJ .

ISPLAY

AREMACD

2.025 .113 30:7

@3$4 5

Recording Mode Setting

Set the tape recording mode depending on your preference.

1 Set the Power Switch @ to “ ” while pressing

down the Lock Button $ located on the switch, and open the LCD monitor fully or pull out the viewfinder fully. The Power lamp 0 lights and the camcorder is turned on.

2 Press MENU 4. The Menu Screen appears. 3 Press + or – 5 to select “ (CAMERA)” and press

SELECT/SET 3.

4 Press + or – 5 to select “REC MODE” and press

SELECT/SET 3. The Sub Menu appears. Select “SP” or “LP” by pressing + or – 5 and press SELECT/SET

3. Press + or – 5 to select “ RETURN”, and press

SELECT/SET 3 twice. The Menu Screen closes.

• Audio Dubbing and Insert Editing (墌 pg. 40) are

possible on tapes recorded in the SP mode.

• “LP” (Long Play) is more economical, providing

1.5 times the recording time.

NOTES:

● If the recording mode is switched during recording, the playback picture will be blurred at the switching point.

● It is recommended that tapes recorded in the LP mode on this camcorder be played back on this camcorder.

● During playback of a tape recorded on another camcorder, blocks of noise may appear or there may be momentary pauses in the sound.

GETTING STARTED

Loading A Memory Card

The provided memory card is already inserted in the camcorder when you receive the camcorder.

1 Make sure the camcorder’s power is off. 2 Open the card cover (MEMORY CARD) 8. 3 Insert the memory card clipped edge first.

• Do not touch the terminal on the reverse side of the label.

4 Close the card cover 8.

To Unload A Memory Card:

In step 3 push the memory card, which then comes out of the camcorder automatically. Pull it out and close the card cover 8.

Clipped edge

Label

Memory card

NOTES:

● Be sure to use only SD Memory Cards marked “ ”

or MultiMediaCards marked “

● Some brands of memory cards are not compatible with

this camcorder. Before purchasing a memory card , consult its manufacturer or dealer.

● Before using a new memory card, it is necessary to

FORMAT the card.

墌 pg. 24.

ATTENTION

Do not insert/remove the memory card while the camcorder is turned on, as this may cause the memory card to be corrupted or cause the camcorder to become unable to recognize whether or not the card is installed.

”.

Picture Quality/Image Size Setting

The Picture Quality/Image Size can be selected to best match your needs. Refer to the chart on page 18 for your selection.

1 Set the VIDEO/MEMORY Switch t to “MEMORY”,

then set the Power Switch @ to “ ” while pressing down the Lock Button $ located on the switch. The Power lamp 0 lights and the camcorder turns on.

2 Press MENU 4. The Menu Screen appears. 3 Press + or – 5 to select “ (DSC)” and press

SELECT/SET 3.

4 Press + or – 5 to select “QUALITY” and press

SELECT/SET 3. The Sub Menu appears. Press + or –

5 to select the desired mode and press SELECT/SET

5 Press + or – 5 to select “IMAGE SIZE” and press

SELECT/SET 3. The Sub Menu appears. Press + or –

5 to select the desired mode and press SELECT/SET

6 Press + or – 5 to select “ RETURN”, and press

SELECT/SET 3 twice. The Menu Screen closes.

4 5

Display

DSC

–

TYQUAL I

FINE

–

IMAGE SI ZE

REC S ELEC T

–

021X7486

RETURN

GETTING STARTED

Basic Recording

Perform the procedures listed below before continuing.

● Power (墌 pg. 7)

● Grip Adjustment (墌 pg. 8)

● Viewfinder Adjustment (

● Load A Cassette (

墌 pg. 8)

墌 pg. 9)

● Recording Mode Setting (墌 pg. 10)

1 Remove the lens cap.

Pull on bottom end Q of LCD monitor to open and set the VIDEO/MEMORY Switch t to “VIDEO”.

2 Set the Power Switch @ to “ ” or “ ” while

pressing down the Lock Button $ located on the switch.

Shooting while using the LCD monitor: Open the LCD monitor fully.

Shooting while using the viewfinder: Pull out the viewfinder fully.

• The Power lamp 0 lights and the camcorder enters the Record-Standby mode. “PAUSE” 8 is displayed.

• The image will not appear simultaneously on the LCD monitor and the viewfinder. See “PRIORITY” in the SYSTEM Menu (墌 pg. 34).

3 Press the Recording Start/Stop Button !. “ ”

4, 8 appears and the tally lamp ^ lights while

recording is in progress.

•To Stop Recording, press the Recording Start/Stop Button !. The camcorder re-enters the RecordStandby mode.

To Adjust The Brightness Of The Display

..... press MONITOR BRIGHT + or – 5 until the bright

level indicator o on the display moves and the appropriate brightness is reached.

• It is also possible to adjust the brightness of the viewfinder. Pull out the viewfinder, set “PRIORITY” in the SYSTEM Menu to “FINDER” (墌 pg. 34) and adjust as described above.

During shooting

Display

Tape remaining time indicator (Approximate)

NOTES:

● If the Record-Standby mode continues for 5 minutes, the camcorder’s power shuts off automatically. To turn the camcorder on again, push back and pull out the viewfinder again or close and re-open the LCD monitor.

● When a blank portion is left between recorded scenes on the tape, the time code is interrupted and errors may occur when editing the tape. To avoid this, refer to “RECORDING FROM THE MIDDLE OF A TAPE”

墌 pg. 14).

(

● To turn the tally lamp

墌 pg. 34.

● When you use the LCD monitor outdoors in direct

sunlight, the LCD monitor may be difficult to see. If this happens, use the viewfinder instead.

● Black spots or bright spots of light (red, green or blue) may appear constantly on the LCD monitor or the viewfinder (

● When the Recording Start/Stop button may take a few seconds before actual recording starts. “ starts recording.

● The time required to calculate and display the remaining tape length, and the accuracy of the calculation, may vary according to the type of tape used.

● “TAPE END” appears when the tape reaches its end, and the power goes off automatically if left in this condition for 5 minutes. “TAPE END” also appears when a cassette at its end is loaded.

墌 pg. 47).

” 4 starts rotating when the camcorder actually

^ or beep sounds off,

1h30m

1h29m

0h03m

0h02m

0h01m

0h00m

(Now calculating)

(Blinking)

! is pressed, it

TAPE RECORDING

Journalistic Shooting

In some situations, different shooting angles may provide more dramatic results. Hold the camcorder in the desired position and tilt the LCD monitor in the most convenient direction. It can rotate 270° (90° downward, 180° upward).

Self-Recording

You can shoot yourself while viewing your own image in the LCD monitor. Open the LCD monitor and tilt it upward 180° so that it faces forward, then point the lens toward yourself and start recording.

Operation Mode

Choose the appropriate operation mode according to your preference using the Power Switch @ and VIDEO/

MEMORY Switch t.

Power Switch Position

Allows you to set various recording functions using the Menus. If you want more creative capabilities than Full Auto recording, try this mode.

(Full Auto):

Allows you to record using NO special effects or manual adjustments. Suitable for standard recording.

OFF:

Allows you to switch off the camcorder.

PLAY:

• Allows you to play back a recording on the tape.

• Allows you to access data stored on the memory card or to transfer still/moving images stored on the memory card to a computer.

Zooming

To produce the zoom in/out effect, or an instantaneous change in image magnification.

Zoom In

Turn the Power Zoom (SHUTTLE SEARCH) Ring

clockwise.

Zoom Out

Turn the Power Zoom (SHUTTLE SEARCH) Ring # counterclockwise.

䡲 The further you turn the Power Zoom Ring # the

quicker the zoom action.

NOTES:

● Focusing may become unstable during Zooming. In this case, set the zoom while in Record-Standby, lock the focus by using the manual focus ( in or out in Record mode.

● Zooming is possible to a maximum of 800X, or it can be switched to 10X (GR-DX106) or 16X (GR-DX76) magnification using the optical zoom (

● Zoom magnification of over 10X (GR-DX106) or 16X (GR-DX76) is done through Digital image processing, and is therefore called Digital Zoom.

● During Digital zoom, the quality of image may suffer.

● Digital zoom cannot be used when the VIDEO/MEMORY

t is set to “MEMORY” (墌 “VIDEO/MEMORY

Switch Switch Position”).

● Macro shooting (as close as approx. 5 cm to the subject) is possible when the Power Zoom Ring the way clockwise. Also see “TELE MACRO” in the Menu Screen on page 33.

墌 pg. 30), then zoom

墌 pg. 32).

# is turned all

VIDEO/MEMORY Switch Position

VIDEO:

• Allows you to record on a tape or play back a tape. If “REC SELECT” is set to “ Menu Screen, still images are recorded on the memory card as well.

• Zoom magnification over 10X (GR-DX106) or 16X (GR-DX76) is available (墌 pg. 13, 32).

MEMORY:

Allows you to record on a memory card or access data stored on a memory card.

/ ” in the DSC

Power-Linked Operation

When the Power Switch @ is set to “ ” or “ ”, you can also turn on/off the camcorder by opening/closing the LCD monitor or pulling out/pushing in the viewfinder.

TAPE RECORDING

Time Code

During recording, a time code is recorded on the tape. This code is to confirm the location of the recorded scene on the tape during playback. If recording starts from a blank portion, the time code begins counting from “00:00:00” (minute:second:frame). If recording starts from the end of a previously recorded scene, the time code continues from the last time code number.

To perform Random Assemble Editing (墌 pg. 41 – 43), time code is necessary. If during recording a blank portion is left partway through the tape, the time code is interrupted. When recording is resumed, the time code starts counting up again from “00:00:00”. This means the camcorder may record the same time codes as those existing in a previously recorded scene. To prevent this, perform “RECORDING FROM THE MIDDLE OF A TAPE” in the following cases;

• When shooting again after playing back a recorded tape.

• When power shuts off during shooting.

• When a tape is removed and re-inserted during shooting.

• When shooting using a partially recorded tape.

• When shooting on a blank portion located partway through the tape.

• When shooting again after shooting a scene then opening/closing the cassette holder cover.

Display

Minutes

Seconds

Frames

12: 34 :24

Frames are not displayed during recording.

(25 frames = 1 second)

RECORDING FROM THE MIDDLE OF A TAPE

1 Play back a tape or use Blank Search (墌 pg. 15) to

find the spot at which you want to start recording, then engage the Still Playback mode (墌 pg. 14, “Normal Playback”).

2 Set the Power Switch @ to “ ” or “ ” while

pressing down the Lock Button $ located on the switch, then start recording.

NOTES:

● The time code cannot be reset.

● During fast-forwarding and rewinding, the time code

indication does not move smoothly.

● The time code is displayed only when “TIME CODE” is

set to “ON” (

墌 pg. 35).

Normal Playback

1 Load a tape (墌 pg. 9). 2 Set the VIDEO/MEMORY Switch t to “VIDEO”,

then set the Power Switch @ to “ ” while pressing down the Lock Button $ located on the switch. To start playback, press 4/6 !.

•To stop playback temporarily (Still Playback), press

/6 !.

•To stop playback, press 5 7.

•Turn the SHUTTLE SEARCH Ring #

counterclockwise (2) and release to rewind, or clockwise (3) and release to fast-forward the tape during Stop mode.

• High-speed picture search (Shuttle Search) is

possible by turning the SHUTTLE SEARCH Ring # counterclockwise (2) or clockwise (3) during playback (holding the SHUTTLE SEARCH Ring # continues search until released).

• Press the Zoom Button T Y on the remote control to zoom in (up to 50X*/80X**), or W T to zoom out. You can also magnify a particular part of an image (墌 pg. 39).

* GR-DX76 only **GR-DX106 only

• At any time, pressing 4/6 ! resumes normal playback.

Slow-Motion Playback/Playback Special Effects/ Playback Zoom:

Available only with the remote control (墌 pg. 39)

To Control The Speaker Volume:

..... press VOL. + e to turn up the volume, or – w to

turn down the volume.

ATTENTION

During Shuttle Search, parts of the picture may not be clearly visible, particularly on the left side of the screen.

TAPE RECORDING

TAPE PLAYBACK

Speaker

w e

# !

NOTES:

● If Stop mode continues for 5 minutes when power is supplied from a battery, the camcorder shuts off automatically. To turn on again, set the Power Switch @ to “OFF”, then to “ ”.

● The playback picture can be viewed in the LCD monitor, viewfinder or on a connected TV (

● You can also view the playback picture on the LCD monitor with it flipped over and pushed against the camera body.

● LCD monitor/viewfinder indications: When power is supplied from a battery: the “ pack remaining power indicator is displayed. When power is supplied from an AC outlet: “ ” does not appear.

● When a cable is connected to the AV connector, the sound is not heard from the speaker.

● If still playback continues for more than about 3 minutes, the camcorder’s Stop mode is automatically engaged.

● When

/6 ! is pressed to engage still playback, the

image may not pause immediately while the camcorder stabilises the still image.

墌 pg. 16).

” battery

Blank Search

Helps you find where you should start recording in the middle of a tape to avoid time code interruption (墌 pg. 14).

1 Load a tape (墌 pg. 9). 2 Set the VIDEO/MEMORY Switch t to “VIDEO”,

then set the Power Switch @ to “ ” while pressing down the Lock Button $ located on the switch.

3 Press BLANK SEARCH r.

• “BLANK SEARCH” U appears and the camcorder

automatically starts reverse or forward shuttle search, then stops at the spot which is about 3 seconds of tape before the beginning of the detected blank portion.

To cancel Blank Search midway . . .

..... press 5 7.

NOTES:

● In step 3, if the current position is at a blank portion the

camcorder searches in the reverse direction, and if the current position is at a recorded portion the camcorder searches in the forward direction.

● Blank Search does not work if “HEAD CLEANING REQUIRED. USE CLEANING CASSETTE” has appeared with the tape.

● If the beginning or end of the tape is reached during Blank Search, the camcorder stops automatically.

● A blank portion which is shorter than 5 seconds of tape may not be detected.

● The detected blank portion may be located between recorded scenes. Before you start recording, make sure there is no recorded scene after the blank portion.

TAPE PLAYBACK

Connections

1 Make sure all units are turned off. 2 Connect the camcorder to a TV or VCR as shown

in the illustration.

If using a VCR . . . go to step 3. If not . . . go to step 4.

3 Connect the VCR output to the TV input, referring to

your VCR’s instruction manual.

4 Turn on the camcorder, the VCR and the TV. 5 Set the VCR to its AUX input mode, and set the TV

to its VIDEO mode.

To choose whether or not the following displays appear on the connected TV . . .

• Date/Time

..... set “DATE/TIME” to “AUTO”, “ON” or “OFF” in the

Menu Screen (墌 pg. 34, 36). Or, press DISPLAY U on the remote control to turn on/off the date indication.

• Time Code

..... set “TIME CODE” to “ON” or “OFF” in the Menu

Screen (墌 pg. 35, 36).

• Indications other than date/time and time code

..... set “ON SCREEN” to “LCD”, “LCD/TV” or “OFF” in

the Menu Screen (墌 pg. 34, 36).

NOTES:

● It is recommended to use the AC Adapter as the

power supply instead of the battery pack (

● To monitor the picture and sound from the camcorder

without inserting a tape or memory card, set the camcorder’s Power Switch your TV to the appropriate input mode.

● Make sure you adjust the TV sound volume to its

minimum level to avoid a sudden burst of sound when the camcorder is turned on.

● If you have a TV or speakers that are not specially

shielded, do not place the speakers adjacent to the TV as interference will occur in the camcorder playback picture.

● If no image is displayed or no sound is heard from the TV,

set “S/AV INPUT” to “OFF” in the Menu Screen

墌 pg. 35).

(

● While the S-Video/Audio/Video/Editing cable is connected

to the S/AV connector &, sound cannot be heard from the speaker.

@ to “ ” or “ ”, then set

墌 pg. 7).

Connector

To S/AV &

S-Video/Audio/ Video/Editing cable (provided)

To S-Video IN

Not connected

To TV or VCR

* When connecting the cables, open this cover. ** The audio connection is not required for watching still

images only.

*** Connect when the S-Video connection is not used.

Yellow to VIDEO IN***

VCR

cover*

Red to AUDIO R IN**

White to AUDIO L IN**

TAPE PLAYBACK

Basic Shooting (Snapshot)

You can use your camcorder as a digital still camera for taking snapshots.

Perform the procedures listed below before continuing.

● Power (墌 pg. 7)

● Grip Adjustment (墌 pg. 8)

● Viewfinder Adjustment (墌 pg. 8)

● Loading A Memory Card (墌 pg. 11)

● Picture Quality/Image Size Setting (墌 pg. 11)

1 Set the VIDEO/MEMORY Switch t to “MEMORY”,

then set the Power Switch @ to “ ” or “ ” while pressing down the Lock Button $ located on the switch. Open the LCD monitor fully or pull out the viewfinder fully.

2 Press SNAPSHOT 9. “PHOTO” Q appears while

the snapshot is being taken. The image is recorded on the memory card.

• Still images are recorded in the snapshot mode with no frame.

To Delete Unwanted Still Images . . .

..... when unwanted still images are stored in the

memory card or its memory is full, refer to “Deleting Files” (墌 pg. 20) and delete unwanted still images.

To Remove The Shutter Sound . . .

..... when you do not want to hear the shutter sound,

set “BEEP” to “OFF” in the Menu Screen (墌 pg. 34). The sound is no longer heard from the speaker.

NOTES:

● Even if “DIS” is set to “ON” (墌 pg. 33), the Stabiliser will

be disabled.

● If Snapshot recording is not possible, “PHOTO” Q blinks

when SNAPSHOT

● If Programme AE with special effects (

engaged, certain modes of Programme AE with special effects are disabled during Snapshot recording. In such a case, the icon blinks.

● If shooting is not performed for approx. 5 minutes when

the Power Switch supplied from the battery pack, the camcorder shuts off automatically to save power. To perform shooting again, close the LCD monitor and re-open it. When using the viewfinder, push back it in and pull it out again.

● The Motor Drive mode (

VIDEO/MEMORY Switch

● When a cable is connected to the S/AV connector

shutter sound is not heard from the speaker, however it is recorded onto the tape.

● Still images taken are compliant to DCF (Design rule for

Camera File system). They do not have any compatibility with devices which are not compliant to DCF.

9 is pressed.

墌 pg. 27) is

@ is set to “ ” or “ ” and power is

墌 pg. 29) is disabled when the

t is set to “MEMORY”.

&, the

$ 9

Image Size

To Protect Valuable Files (available only for SD Memory Card) . . .

..... slide the write/erase protection tab on the side

墌 pg. 11

Shooting icon

1024

Display

Write/erase protection tab

of the memory card in the direction of “LOCK”. This prevents the memory card from being recorded over. To record on this memory card, slide the tab back to the position opposite to “LOCK” before loading it.

墌 pg. 54, 55

Card icon

Remaining number of shots

墌 pg. 54, 55

(Approximate Number of Storable Images

Picture Quality

墌 pg. 54, 55

墌 pg. 18)

墌 pg. 11

MEMORY CARD RECORDING

Approximate Number of Storable Images

: SD Memory Card

: MultiMediaCard

<GR-DX76>

Image Size/ Picture Quality

1024 x 768/ FINE

1024 x 768/ STANDARD

640 x 480/ FINE

640 x 480/ STANDARD

8MB**

160

190

Memory Card

16MB***

145

160

105

295

320

32MB***

100

310

320

205

215

625

645

64MB***

190

605

405

1215

<GR-DX106>

Image Size/ Picture Quality

1600 x 1200/ FINE

1600 x 1200/ STANDARD

1280 x 960/ FINE

1280 x 960/ STANDARD

1024 x 768/ FINE

1024 x 768/ STANDARD

640 x 480/ FINE

640 x 480/ STANDARD

** SD Memory Card (8 MB) [ provided with GR-DX106.

MultiMediaCard (8 MB) [ provided with GR-DX76.

*** Optional

8MB**

160

190

Memory Card

16MB***

105

145

160

105

295

320

32MB***

130

135

205

215

100

310

320

205

215

625

645

64MB***

275

125

425

200

640

425

1285

Normal Playback

1 Load a memory card (墌 pg. 11). 2 Set the VIDEO/MEMORY Switch t to

“MEMORY”, then set the Power Switch @ to “ ” while pressing down the Lock Button $.

•A stored file is displayed.

3 Select the type of file as necessary (IMAGE or

E-MAIL CLIP): Press SELECT/SET 3. Press + or – 5 to select the type of file, then press SELECT/SET 3 again.

4 IMAGE: Turn the SHUTTLE SEARCH Ring #

clockwise (3) to display the next image, or counterclockwise (2) to display the previous image. E-MAIL CLIP: Press 4/6 ! to view video clips. To stop video clip playback, press 5 7.

To Magnify The Stored Images

Press the Zoom Button T Y on the remote control to zoom in (up to 50X*/80X**), or W T to zoom out. You can also magnify a particular part of an image (墌 pg. 39).

• By pressing 4/6 !, INDEX 1, INFO 6 or turning

the SHUTTLE SEARCH Ring 2/3 # magnification is cancelled.

* GR-DX76 only. ** GR-DX106 only.

To Adjust The Brightness Of The Display

See “To Adjust The Brightness Of The Display” on page 12.

NOTES:

● Pressing INFO 6 gives you details on the displayed file

(

墌 pg. 19, “Viewing File Information”).

● You can also overview several files at a time

墌 pg. 19, “Index Playback”).

(

● You can turn off the on-screen playback display

(墌 pg. 19, “Removing On-Screen Display”).

● Images shot in a file size that is not compatible with this camcorder will be displayed as reduced-size thumbnail images. These thumbnail images cannot be transferred to a PC.

●Images shot with devices (such as JVC GR-DVX70) that are not compatible with DCF cannot be viewed with this camcorder; “UNSUPPORTED FILE!”will be displayed.

To display the next image

[For Normal Playback: IMAGE]

To display the previous image

NOTE:

The number of storable images depends on the selected picture quality as well as the composition of the subjects in the images and the type of memory card being used.

10 0- 0 011100- 001110 0- 0 010100- 0010

Display

[For Auto Playback: IMAGE]

MEMORY CARD PLAYBACKMEMORY CARD RECORDING

+ 42 hidden pages

JVC GR-DX106, GR-DX76 Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

CONTENTS

PROVIDED ACCESSORIES

HOW TO ATTACH THE LENS CAP

HOW TO ATTACH THE CORE FILTER

AUTOMATIC DEMONSTRATION

GETTING STARTED

TAPE RECORDING

TAPE PLAYBACK

MEMORY CARD RECORDING

MEMORY CARD PLAYBACKMEMORY CARD RECORDING
