JVC GR-DVX User Manual
DIGITAL VIDEO CAMERA
GR-DVX
Please visit our CyberCam Homepage on
the World Wide Web and answer our
Consumer Survey (in English only):
http://www.jvc-victor.co.jp/index-e.html
ENGLISH
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial
No. which is located on the bottom of
cabinet. Retain this information for
future reference.
Model No.
Serial No.
LYT0002-0V8A
EN
2 EN
Dear Customer,
Thank you for purchasing this Digital Video
Camera. Before use, please read the safety
information and precautions contained in the
following pages to ensure safe use of this product.
Using This Instruction Manual
• All major sections and subsections are listed in the
Table Of Contents (
• Notes appear after most subsections. Be sure to read
these as well.
• Basic and advanced features/operation are separated
for easier reference.
Z pg. 9).
It is recommended that you . . .
...... refer to “Controls, Indications and Connectors”
Z pgs. 75 – 80) and familiarize yourself with
(
button locations, etc. before use.
...... read thoroughly the Safety Precautions and Safety
Instructions that follow. They contain extremely
important information regarding the safe use of
your new camcorder.
You are recommended to carefully read the
cautions on pages 81 and 82 before use.
SAFETY
PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
NO USER-SERVICEABLE PARTS INSIDE.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
The AA-V90U AC Power Adapter/Charger should
be used with:
AC 120 V`, 60 Hz in the USA and Canada,
AC 110 – 240 V`, 50/60 Hz in other countries.
CAUTION (applies to the AA-V90U)
TO PREVENT ELECTRIC SHOCK MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION (s'applique à l'AA-V90U)
POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA
FICHE DANS LA BORNE CORRESPONDANTE DE
LA PRISE ET POUSSER JUSQU'AU FOND.
WARNING:
TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR
MOISTURE.
Warning on lithium cell battery (for remote
control unit)
The battery used in this device may present a fire or
chemical burn hazard if mistreated. Do not
recharge, disassemble, heat above 100°C (212°F) or
incinerate.
Replace battery with Panasonic (Matsushita
Electronic), Sanyo or Maxell CR2025; use of another
battery may present a risk of fire or explosion.
n Dispose of used battery properly.
n Keep away from children.
n Do not disassemble and do not dispose of in fire.
CAUTION (applies to the Docking Station):
TO REDUCE THE RISK OF FIRE,
DO NOT REMOVE COVER (OR
BACK). NO USER–SERVICEABLE
PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
NOTES:
●
The rating plate (serial number plate) and safety
caution are on the bottom and/or the back of the
main unit.
●
The rating plate (serial number plate) of the AC
Power Adapter/Charger is on its bottom.
This Class B digital apparatus meets all requirements of the Canadian Interference – Causing
Equipment Regulations.
“Cet appareil numérique de la classe B respecte
toutes les exigences du Règlement sur le matériel
brouilleur du Canada.”
This camcorder is designed to be used with NTSCtype color television signals. It cannot be used for
playback with a television of a different standard.
However, live recording and LCD monitor/
viewfinder playback are possible anywhere. Use
the BN-V907U battery pack and, to recharge it, the
provided multi-voltage AC Power Adapter/Charger
AA-V90U. (An appropriate conversion adapter
may be necessary to accommodate different
designs of AC outlets in different countries.)
IMPORTANT PRODUCT
SAFETY INSTRUCTIONS
Electrical energy can perform many useful functions.
But improper use can result in potential electrical shock
or fire hazards. This product has been engineered and
manufactured to assure your personal safety. In order
not to defeat the built-in safeguards, observe the
following basic rules for its installation, use and
servicing.
ATTENTION:
Follow and obey all warnings and instructions marked
on your product and its operating instructions. For your
safety, please read all the safety and operating
instructions before you operate this product and keep
this manual for future reference.
INSTALLATION
1. Grounding or Polarization
(A) Your product may be equipped with a polarized
alternating-current line plug (a plug having one
blade wider than the other). This plug will fit into
the power outlet only one way. This is a safety
feature.
If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should still
fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of
the polarized plug.
(B) Your product may be equipped with a 3-wire
grounding-type plug, a plug having a third
(grounding) pin. This plug will only fit into a
grounding-type power outlet. This is a safety
feature.
If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the
grounding-type plug.
2. Power Sources
Operate your product only from the type of power
source indicated on the marking label. If you are not
sure of the type of power supply to your home, consult
your product dealer or local power company. If your
product is intended to operate from battery power, or
other sources, refer to the operating instructions.
3. Overloading
Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a
risk of fire or electric shock.
4. Power Cord Protection
Power supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point
where they exit from the product.
EN 3
5. Ventilation
Slots and openings in the cabinet are provided for
ventilation. To ensure reliable operation of the product
and to protect it from overheating, these openings must
not be blocked or covered.
•Do not block the openings by placing the product on
a bed, sofa, rug or other similar surface.
•Do not place the product in a built-in installation
such as a bookcase or rack unless proper ventilation
is provided or the manufacturer’s instructions have
been adhered to.
6. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling
only as recommended by the manufacturer.
ANTENNA INSTALLATION
INSTRUCTIONS
1. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to
the product, be sure the antenna or cable system is
grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810
of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding
of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge
unit, connection to grounding electrodes, and
requirements for the grounding electrode.
2. Lightning
For added protection for this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and
power-line surges.
3. Power Lines
An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light
or power circuits, or where it can fall into such power
lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from
touching such power lines or circuits as contact with
them might be fatal.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN WIRE
GROUND CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION
ELECTRIC SERVICE
EQUIPMENT
POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC ART 250. PART H)
NEC – NATIONAL ELECTRICAL CODE
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
4 EN
USE
1. Accessories
To avoid personal injury:
• Do not place this product on an unstable cart, stand,
tripod, bracket or table. It may fall, causing serious
injury to a child or adult, and serious damage to the
product.
• Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer or sold with the
product.
• Use a mounting accessory recommended by the
manufacturer and follow the manufacturer’s
instructions for any mounting of the product.
• Do not try to roll a cart with small casters across
thresholds or deep-pile carpets.
2. Product and Cart Combination
A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to
overturn.
3. Water and Moisture
Do not use this product near water—for example, near
a bath tub, wash bowl, kitchen sink or laundry tub, in a
wet basement, or near a swimming pool and the like.
PORTABLE CART WARNING
(Symbol provided by RETAC)
4. Object and Liquid Entry
Never push objects of any kind into this product
through openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the
product.
5. Attachments
Do not use attachments not recommended by the
manufacturer of this product as they may cause
hazards.
6. Cleaning
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
7. Heat
The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
SERVICING
1. Servicing
If your product is not operating correctly or exhibits a
marked change in performance and you are unable to
restore normal operation by following the detailed
procedure in its operating instructions, do not attempt
to service it yourself as opening or removing covers
may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
2. Damage Requiring Service
Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into
the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often require
extensive work by a qualified technician to restore
the product to its normal operation.
e. If the product has been dropped or damaged in any
way.
f. When the product exhibits a distinct change in
performance—this indicates a need for service.
3. Replacement Parts
When replacement parts are required, be sure the
service technician has used replacement parts specified
by the manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may result
in fire, electric shock or other hazards.
4. Safety Check
Upon completion of any service or repairs to this
product, ask the service technician to perform safety
checks to determine that the product is in safe
operating condition.
SAFETY PRECAUTIONS
Do not point the lens or the viewfinder directly into
the sun. This can cause eye injuries, as well as lead
to the malfunctioning of internal circuitry. There is
also a risk of fire or electric shock.
CAUTION! The following notes concern possible
physical damage to the camcorder and to the user.
When carrying, be sure to always attach and use
the provided hand strap. Hold the camcorder firmly
in your hand, with the strap securely around your
wrist. Carrying or holding the camcorder by the
viewfinder and/or the LCD monitor can result in
dropping the unit, or in a malfunction.
Take care not to get your finger caught in the
cassette cover. Do not let children operate the
camcorder, as they are particularly susceptible to
this type of injury.
Do not use a tripod on unsteady or unlevel surfaces.
It could tip over, causing serious damage to the
camcorder.
CAUTION! Attaching the camcorder to the Docking
Station, connecting cables (AUDIO/VIDEO,
S-VIDEO, Editing, DC) and leaving the unit on top
of the TV is not recommended, as tripping on the
cables will cause the camcorder to fall, resulting in
damage.
EN 5
About Batteries
DANGER! Do not attempt to take the batteries
apart, or expose them to flame or excessive heat, as
there is a risk of fire or explosion.
WARNING! Do not allow the battery terminals, or
the battery itself, to come in contact with metals, as
this can result in a short circuit and possibly start a
fire.
•When transporting, make sure the provided
battery cap is attached to the battery. If you
misplace the battery cap, carry the battery in a
plastic bag.
The Benefits Of Lithium-Ion Batteries
Lithium-ion battery packs are small but possess a
large power capacity. However, when the battery
pack becomes cool in an environment subject to
cold temperatures (below 10°C/50°F), the battery
pack has a characteristic that its usage time
becomes shorter and may cease to function. If this
happens, place the battery pack in your pocket or
other warm, protected place for a short time, then
re-attach it to the camcorder. As long as the battery
pack itself is not cold, it should not affect performance.
(If you’re using some kind of heating pad, make
sure the battery pack does not come in direct
contact with the pad.)
n This camcorder is designed exclusively for
the
cassettes marked
digital video cassette. Only
can be used with this
unit.
Before recording an important scene . . .
..... make sure you only use cassettes with the Mini
DV mark.
..... remember that this camcorder is not compatible
with other digital video formats.
..... remember that this camcorder is intended for
private consumer use only. Any commercial use
without proper permission is prohibited. (Even if
you record an event such as a show, performance or exhibition for personal enjoyment, it is
strongly recommended that you obtain
permission beforehand.)
Lithium-ion is vulnerable in colder temperatures.
6 EN
PROVIDED ACCESSORIES
Adapter/Charger AA-V90U
AC Power
Hand strap
VIDEO/AUDIO cable
(Docking Station to TV or VCR,
RCA plug 4 RCA plug)
Soft camera case
Battery pack BN-V907U
VIDEO/AUDIO cable
(camcorder to TV or VCR,
ø 3.5 mini-plug 4 RCA plug)
S-VIDEO cable DC cord
Editing cable
(ø 3.5 mini-plug, 2 poles)
TW
EN 7
Docking StationRemote control unit RM-V711U
MiniDV Cassette Tape 30 min (DVM-30)
M-DV30ME
Lithium battery CR2025
(for remote control unit)
Power Pack CU-V900U
Cleaning cloth
Grip strap
8 EN
The digital video camera converts incoming audio and video signals into digital form for recording.
A video signal is composed of a luminance signal (Y) and color signals (R-Y and B-Y). These signals are
identified and recorded digitally (Digital Component Recording). The A/D (Analog to Digital) converter
samples the Y signal at 13.5 MHz, and R-Y and B-Y at 3.375 MHz, and changes them to an 8-bit quantum signal.
Sound sampled at 48 kHz is changed to a 16-bit quantum signal, and sound sampled at 32 kHz is converted
to a 12-bit signal.
ABOUT DV
NOTE:
The data recorded on a tape is digital, but the output of this camcorder is analog.
VIDEO
Lens
Chrominance (C)
AUDIO
Mic
This camcorder separates the data into blocks, writing one block of each data type on each track of the tape.
Head tracking direction
Luminance Signal (Y)
Color Difference
Signal (R-Y)
Chromatic
Analysis
Color Difference
Signal (B-Y)
conversion
conversion
conversion
conversion
Sub-Code Area
10 tracks/frame
A/D
A/D
A/D
A/D
Tape direction
Video Area
compression
Audio Area
ITI Area
Signal
Recording by
rotating head
helical scan
5.24 mm / 1/5"
6.35 mm / 1/4"
1 Sub-Code Area
The Time Code and Date/Time data are
written here, separate from the video
data. This enables you to display the date
and time during playback, even if they
weren’t displayed while recording.
2 Video Area
The digital video signal is recorded here.
3 Audio Area
The digital audio signal is recorded here.
4 ITI (Insert and Tracking
Information) Area
Insert editing and post-recording editing
tracking signals are recorded here.
CONTENTS
PROVIDED ACCESSORIES
ABOUT DV
GETTING STARTED
Charging The Battery Pack .................................................................. 10
Installing The Battery Pack ................................................................. 11
Indoor Use..................................................................................... 12
Using The Power Pack ....................................................................... 12
Date/Time Settings .......................................................................... 13
Loading/Unloading A Cassette ............................................................. 14
Recording Mode Setting ..................................................................... 15
Hand Strap Attachment...................................................................... 16
Using The Soft Camera Case ................................................................ 16
Grip Strap Attachment....................................................................... 17
Tripod Mounting .............................................................................. 17
Diopter Adjustment .......................................................................... 18
Remote Control Unit ......................................................................... 19
Operation Mode .............................................................................. 20
RECORDING
Basic Recording ............................................................................... 21
Advanced Features ........................................................................... 27
PLAYBACK
Basic Playback ................................................................................ 51
Advanced Features ........................................................................... 52
Playback Menu................................................................................ 54
Basic Connections............................................................................. 56
EDITING
Dubbing ........................................................................................ 60
Brand Setting ................................................................................. 61
Random Assemble Editing ................................................................... 62
For More Accurate Editing ................................................................... 65
Audio Dubbing ................................................................................ 67
Insert Editing.................................................................................. 68
TROUBLESHOOTING
AFTER USE
CONTROLS, INDICATIONS AND CONNECTORS
Camcorder ..................................................................................... 75
Docking Station ............................................................................... 77
LCD Monitor/Viewfinder Indications During Recording ................................. 78
LCD Monitor Indications During Playback ................................................. 79
Warning Indications .......................................................................... 80
CAUTIONS
SPECIFICATIONS
GLOSSARY OF TERMS
INDEX
EN 9
6
8
10
21
51
60
69
74
75
81
83
84
85
10 EN
Charging The Battery Pack
You can charge one battery pack at a time, or two consecutively.
ATTACH
To AC outlet
Power lamp
Charger indicator 1
Battery pack BN-V907U
AC Power
Adapter/Charger
DC jack
Charger indicator 2
GETTING STARTED
Power cord
DETACH
SUPPLY POWER TO CHARGER
1
Plug the AC Adapter/Charger’s power cord in
to an AC outlet. The power lamp comes on.
ATTACH BATTERY/BATTERIES
2
Remove the battery pack’s protective cap and
attach while making sure the marks are
facing down and aligned with the corresponding marks on the AC Power Adapter/Charger.
•The Charger Indicator (1 or 2) begins blinking
to indicate charging has started.
CONFIRM STATUS
3
When the charger indicator stops blinking but
stays lit, charging is finished.
•If two batteries are attached to the charger,
they will be charged in the order that they
were attached.
DETACH BATTERY/BATTERIES
4
Slide the battery or batteries in the direction of
the arrow and lift off.
•Remember to unplug the AC Adapter/
Charger’s power cord from an AC outlet.
CHARGING TIME**
BATTERY ONE TWO
BN-V907U approx. 100 min. approx. 200 min.
EN 11
NOTES:
●
If you connect the camcorder’s DC cord to the adapter during battery charging, power is supplied to the
camcorder and charging stops.
●
When using the AC Power Adapter/Charger, be sure to use the supplied power cord only.
●
The AC Power Adapter/Charger is for use with the BN-V907U Battery Pack only.
●
When charging the Battery Pack for the first time or after a long storage period, the Charger Indicator may
not light. In this case, remove the Battery Pack from the AC Power Adapter/Charger, then try charging
again.
●
Since the AC Power Adapter/Charger processes electricity internally, it becomes warm during use. Be sure
to use it only in well-ventilated areas.
●
If the battery operation time remains extremely short even after having been fully charged, the battery is
worn out and needs to be replaced. Please purchase a new one.
** Charging Environment
Perform charging where the temperature is between 10° and 35°C. (20°–25°C is the ideal temperature range for
charging.) If the environment is too cold, charging may be incomplete.
Continuous Shooting
Continuous shooting is possible (See table below for recording time) under the following conditions:
•A BN-V907U Battery Pack is in use
•The temperature is approximately 20°C/68°F
However, . . .
•If the temperature is below 10°C/50°F, or
•If zoom or Record-Standby are engaged or LCD monitor is used repeatedly, continuous shooting capability
is reduced significantly. Before extended use, it is recommended that you prepare enough battery packs to
cover 3 times the planned shooting time.
Installing The Battery Pack
The battery pack does not charge while in the camcorder. Before installation, make sure the battery pack has
been charged fully.
1 2 3
1
2
OPEN BATTERY COVER
1
Slide the battery cover.
1
2 Pull open the battery cover in the direction
of the arrow.
INSERT BATTERY
2
Insert the mark end of the battery first.
CLOSE BATTERY COVER
3
Close the battery cover while pulling it and
slide it in the direction of the arrow.
Battery cover
Battery
RECORDING TIME
BATTERY LCD monitor off/ LCD monitor on/
BN-V907U approx. 45 min. approx. 40 min.
NOTES:
●
To remove the battery pack, turn off the
camcorder, open the battery cover and slide the
battery pack out.
●
Be careful not to drop the battery pack.
mark
Viewfinder on Viewfinder off
12 EN
Indoor Use
When using the camcorder indoors, you can use
the AC Adapter instead of a battery.
GETTING STARTED
(Cont.)
Using The Power Pack
For extended use, prepare the Power Pack, which
can be loaded with two battery packs.
To AC outlet Power cord
Power lamp
When power is
supplied, the power
lamp lights.
DC cord
Core Filter
SUPPLY POWER TO ADAPTER
1
Plug the AC Adapter/Charger’s power cord in
to an AC outlet.
SUPPLY POWER TO CAMCORDER
2
Connect the AC Adapter to the camcorder.
AC Power
Adapter/Charger
DC-IN
Connector is
under this cover
NOTE:
When using the provided DC cord, make sure you
connect the end of the cable with the core filter to
the camcorder. The core filter improves performance of equipment.
mark
Knob
Battery cover
DC input jack
DC cord
Screw
INSERT BATTERY
1
Open the battery cover while pressing the
knob and insert the end of the battery
first. Close the battery cover.
ATTACH TO CAMCORDER
2
Attach the camcorder to the Power Pack in the
direction of the arrow. Turn the spring-loaded
screw inward and turn it clockwise to attach.
SUPPLY POWER
3
Connect the Power Pack DC cord to the
camcorder DC input jack.
NOTES:
●
When the battery remaining power indicator
appears as , that means the battery power is
close to nil. When the battery power is exhausted,
power turns off automatically.
●
When using the Power Pack, the battery pack
installed in the camcorder does not supply power.
●
After the battery packs in the Power Pack are
exhausted, the battery pack in the camcorder
does not begin to supply power. Detach the
Power Pack and turn off the camcorder to use the
battery pack installed in the camcorder.
EN 13
Date/Time Settings
Date and time will automatically be recorded on tape at all times. It is your choice to display it or not during
playback (Z pg. 54).
To set date and time follow the instructions from 1 to 4.
LCD monitor
REC MODE
WIDE MODE OFF
ZOOM
DIS
GAIN UP
FLASH
4
TO DATE / TIME MENU
TO SYSTEM MENU
END
Recording Menu
SP
20X
OFF
AGC
AUTO
Power Dial
Power lamp
M
Lock button
5S
A
P
L
A
Y
OFF
ON SCREEN OFF
4
DATE / TIME
RETURN
Date/Time Menu
ONDISPLAY
DEC 25 ’ 97
PM 5 : 30
SELECT OPERATION MODE
1
Set the Power Dial to “M” while pressing
down the lock button located on the dial, and
open the LCD monitor fully.
•The power lamp comes on and the camcorder
is turned on.
•The LCD monitor can be tilted upward up to
180 degrees and downward up to 90 degrees.
ACCESS RECORDING MENU
2
Press MENU. The Recording Menu appears.
ACCESS DATE/TIME MENU
3
Move the pointer and highlight bar to “TO
DATE/TIME MENU” by rotating the Select Dial.
Press the Select Dial and the Date/Time Menu
appears.
INPUT DATE AND TIME
4
Move the pointer and highlight bar to “DATE/
TIME” by rotating the Select Dial. Press the
Select Dial and “month” is highlighted and
begins blinking.
Rotating the Select Dial (rotate it upward to
increase and downward to decrease), input the
month. Press the Select Dial. Repeat the
procedure to input the day, year, hour and
minute.
•Press the Select Dial twice when the pointer
and highlight bar are set to “RETURN” to exit.
Select Dial
MENU
MENU button
Regarding Built-in Rechargeable Battery
To store the date/time in memory, a rechargeable
clock lithium battery is integrated in the camcorder.
While the camcorder is connected to an AC outlet
using the AC Power Adapter/Charger, or while the
battery pack installed in the camcorder continues to
supply power to the camcorder, the clock lithium
battery is always charged. However, if the
camcorder is not used for approx. 3 months, the
clock lithium battery will become discharged and
the date/time stored in memory will be lost. When
this occurs, first connect the camcorder to an AC
outlet using the AC Power Adapter/Charger etc. for
over 24 hours to charge the clock lithium battery.
Then perform the date/time setting before using the
camcorder.
It is also possible to use the camcorder without the
date/time setting.
NOTE:
If you don’t exit the Date/Time Menu, the clock
display will not move but the camcorder’s internal
clock continues to operate. Once you close the
menu, the date and time begin operation from the
current date and time, with no delay or loss.
14 EN
Loading/Unloading A Cassette
The camcorder needs to be powered up to load or eject a cassette.
OPEN/EJECT
switch
Make sure the window
side is facing out.
Erase protection switch**
GETTING STARTED
Cassette holder
PUSH HERE
Cassette cover
(Cont.)
OPEN CASSETTE COVER
1
Turn on the power, then slide the OPEN/EJECT
switch in the direction of the arrow. The
cassette cover releases. Open the cover in the
direction of the arrow until it locks. The holder
opens automatically.
•Do not touch internal components.
INSERT/REMOVE TAPE
2
Insert or remove a tape and press “PUSH
HERE” to close the cassette holder.
•Once the cassette holder is closed, it recedes
automatically. Wait until it recedes
completely before closing the cassette cover.
•When the battery’s charge is low, you may
not be able to close the cover. Do not apply
force. Replace the battery with a fully
charged one before continuing.
RECORDING TIME
TAPE RECORDING MODE
SP LP
DVM-30 Approx. 30 min. Approx. 45 min.
DVM-60 Approx. 60 min. Approx. 90 min.
NOTES:
●
It takes a few seconds for the cassette holder to
open. Do not apply force.
●
If you wait a few seconds and the cassette holder
does not open, close the cassette cover and try
again.
●
Be careful not to get your fingers caught in the
holder when it’s closing. If this happens, the
holder will open automatically after a few
seconds.
●
When the camcorder is suddenly moved from a
cold place to a warm environment, wait a short
time before opening the cover.
●
Closing the cassette cover before the cassette
holder comes out may cause damage to the
camcorder.
●
When shooting again after already shooting a
scene, a blank portion is recorded on the tape or
a previously recorded scene is erased (recorded
over) if you open the cassette cover, regardless of
whether the cassette holder comes out or not. See
page 22 for information about recording from the
middle of a tape.
** To protect valuable recordings . . .
..... slide the erase protection switch on the back of
the tape in the direction of “SAVE”. This prevents
this tape from being recorded over. If you decide
later that you do want to record on this tape, slide
the switch back to “REC” before loading the tape.
Recording Mode Setting
Set depending on your preference.
LCD monitor
Recording Menu
4
REC MODE
WIDE MODE OFF
ZOOM
DIS
GAIN UP
FLASH
TO DATE / TIME MENU
TO SYSTEM MENU
END
4
REC MODE
WIDE MODE OFF
ZOOM
DIS
GAIN UP
FLASH
TO DATE / TIME MENU
TO SYSTEM MENU
END
SP
20X
OFF
AGC
AUTO
SP
20X
OFF
AGC
AUTO
MENU button
Recording mode indicator
SP SP LP
Power dial
Power lamp
Select Dial
EN 15
Lock button
5S
M
A
P
L
A
Y
OFF
SELECT OPERATION MODE
1
Set the Power Dial to “M” while pressing
down the lock button located on the dial.
OPEN LCD MONITOR
2
Open the LCD monitor fully.
The power lamp comes on and the camcorder
is turned on.
•The LCD monitor turns on/off automatically
when it is opened/closed at approx. 90 degrees
while the Power Dial is set to any operation
mode (except “OFF”).
•The LCD monitor can be tilted upward up to
180 degrees and downward up to 90 degrees.
ACCESS RECORDING MENU
3
Press MENU. The Recording Menu appears.
SET RECORDING MODE
4
First move the pointer and highlight bar to
“REC MODE” by rotating the Select Dial. Press
the Select Dial and the parameter “SP” or “LP”
is highlighted. Select “SP” or “LP” by rotating
the Select Dial. Press the Select Dial to exit
from the Recording Menu.
•Insert Editing or Audio Dubbing is impossible
on a tape recorded in the LP mode.
•“LP” (Long Play) is more economical,
recording at 2/3 the speed of “SP” (Standard
Play).
NOTES:
●
If the recording mode is switched during
recording, the playback picture will be blurred at
the switching point.
●
It is recommended that tapes recorded in the LP
mode on this camcorder be played back on this
camcorder.
●
During playback of a tape recorded on another
camcorder, blocks of noise may appear or there
may be momentary pauses in the sound.
16 EN
2
Hand Strap Attachment
The provided Hand Strap helps you to keep a firm
hold on the camcorder. Make sure you never hold
the camcorder without using the Hand Strap.
GETTING STARTED
(Cont.)
Using The Soft Camera Case
Keep the camcorder in the soft camera case when
transporting it.
2
2
3
1
Velcro Flap
Eyelet
1
Hand strap
Loop
ATTACH HAND STRAP
1
Thread the strap through the eyelet 1, then
thread the loop through the end of the strap 2.
Pull firmly to ensure secure attachment.
During transporting ...
Thread your belt through the
soft camera case's loop for nohands carrying.
Loop
Flap
When putting the
camcorder with the Power
Pack attached into the soft
camera case ...
Close the flap loosely, attaching
it to the velcro on the soft
camera case.
OPEN FLAP
1
PUT CAMCORDER IN
2
Insert with lens side down. By doing this, you
can begin shooting as soon as you take out the
camcorder from the soft camera case.
CLOSE FLAP
3
Grip Strap Attachment
Before attaching the grip strap, detach the hand strap from the camcorder (Z pg. 16).
EN 17
Hand strap eyelet
Loop
ATTACH GRIP STRAP TO HAND
1
STRAP EYELET
Thread the end of the grip strap through the
hand strap eyelet, then thread the other end of
the grip through the loop. Pull firmly to ensure
secure attachment.
ATTACH GRIP STRAP TO SUB
2
HAND STRAP EYELET
Open the pad and thread the end of the grip
strap through the sub hand strap eyelet.
ADJUST LENGTH
3
Adjust so your thumb and fingers can easily
operate the START/STOP button and the zoom
switch 1. Position the pad so that it contacts
the back of your hand 2, then re-attach it 3.
Zoom switch
START/STOP
3
Pad
Sub hand strap eyelet
1
Tripod Mounting
Align the tripod’s screw with the mounting socket on
the bottom of the camcorder.
The camcorder can be mounted on a tripod even
with the Power Pack attached.
Bottom of the camcorder
Pad
2
NOTE:
If you want to take a snapshot (Z pg. 27) while
grasping the camcorder through the Grip strap
attached to the hand strap eyelet and the sub hand
strap eyelet, press the Sub SNAPSHOT button (3)
using your left hand. Because the SNAPSHOT
button will be covered by your right hand, pressing
it will not be possible.
18 EN
Diopter Adjustment
Adjust the viewfinder display for best viewing.
5S
M
A
OFF
Y
A
L
P
Diopter
adjust lever
GETTING STARTED
Diopter adjust
lever
PAUSE
(Cont.)
SELECT OPERATION MODE
1
Set the Power Dial to “A”, or “M”.
TURN ON CAMCORDER
2
Pull out the viewfinder fully.
ADJUST DIOPTER
3
Slide the Diopter Adjust Lever located on the
bottom of the viewfinder.
•Slide in either direction, while looking at the
viewfinder display, until it looks best to you.
EN 19
Remote Control Unit
You can use the RM-V711U to control the camcorder. When using the remote control, be sure to point it at
the remote sensor. The transmitted beam effective area for indoor use is approx. 5 m. The transmitted beam
may not be effective or may cause incorrect operation if the remote sensor is directly exposed to sunlight or
powerful lighting.
START/STOP Button (Z pg. 68)
PAUSE IN connector (Z pg. 62)
Zoom Buttons (
DISPLAY Button (Z pg. 67)
SHIFT Button (Z pg. 52)
SLOW Rewind/Forward
Buttons (Z pg. 51)
FADE/WIPE Button
(
EFFECT ON/OFF Button
(
Z pg. 53)
Knob
Z pg. 52)
Left/Right Buttons
(
Z pg. 52)
Z pg. 63)
EFFECT Button
Z pg. 53)
(
TW
R.A. EDIT Buttons (Z pg. 63)
Installing The Battery
The RM-V711U uses one lithium battery (CR2025).
PULL OUT BATTERY HOLDER
1
Pull out in the direction of the arrow while
pressing the knob as shown.
INSERT BATTERY IN HOLDER
2
Insert the battery in the holder, and be sure to
have the “+” mark visible.
RE-INSERT HOLDER
3
Slide the holder back in until you hear a click.
•Read the caution concerning lithium batteries
(Z pg. 2).
AUDIO MONITOR Button
(Z pg. 67)
MBR SET Button (
A. DUB Button (Z pg. 67)
Down Button (Z pg. 52)
INSERT Button (
Up Button (Z pg. 52)
Operation Buttons
(Z pg. 52, 68)
Z pg. 61)
Z pg. 68)
20 EN
GETTING STARTED
(Cont.)
Operation Mode
Tuning the Power Dial allows you to choose the appropriate operation mode among the following modes:
Full Auto mode (A), Manual mode (M), 5 second mode recording (5S), Self-Timer mode ( ) and “PLAY”.
According to the Power Dial position you have
selected, “F.AUTO” or “MANUAL” appears in the
upper left corner.
When set to
M
”, “5S” or “ ”When set to “A”
“
F . AUTO
PAUSE
MANUAL
PAUSE
Power Dial Position Function
Full Auto:
Manual:
5 second mode recording: 5S
Self-Timer:
Playback: PLAY
A
Allows you to record using NO special effects or manual adjustments. Suitable for standard recording.
M
Allows you to set various recording functions using the Menus. If
you want more creative capabilities than Full Auto recording, try
this mode.
Allows you to record in 5-second clips to keep the action moving.
Other menu settings are the same as Full Auto mode, however
manually adjusted White Balance Adjustment settings are
effective.
Allows you (camcorder operator) to become part of the scene
once the camcorder is set. This mode is similar to the Self-Timer
on film cameras.
Allows you to play back a recording, Z pg. 51 – 59.
To turn on the camcorder, first
turn the Power Dial to any
operation mode except “OFF”,
then pull out the viewfinder fully
or open the LCD monitor. When
turning the Power Dial from
“OFF” to “
from “OFF” to “PLAY”, press and
hold the lock button located on
the dial.
A
Power lamp
” or when turning it
Lock button
5S
M
A
OFF
Y
A
L
P
RECORDING
EN 21
Basic Recording
You should already have performed the necessary preparations (Z pgs. 10 – 18). Set the Power Dial to “A”
and try recording that way before attempting to use more advanced features.
NOTE:
Before starting recording, make sure you set the date and time (Z pg. 13). Even if they don’t appear during
recording, you can display them during playback (Z pg. 55).
IND. ON/OFF
SELECT OPERATION MODE
1
Set the Power Dial to “A” while pressing down
the lock button located on the dial.
PULL OUT VIEWFINDER OR OPEN
2
LCD MONITOR
Pull out the viewfinder fully or open the LCD
monitor to approx. 90° degrees.
•The lens cover opens, the power lamp comes
on and the scene you're aimed at appears.
•The Record-Standby mode is engaged.
START RECORDING
3
When “PAUSE” appears, press START/STOP. A
beep signals the start of recording.
STOP RECORDING
4
Press START/STOP again to stop recording.
•The camcorder re-enters Record-Standby mode.
END RECORDING
5
When you’re finished recording, push back the
viewfinder or close the LCD monitor until it
clicks; the lens cover closes and the power
lamp goes out.
•When transporting, make sure the viewfinder
is pushed back and the LCD monitor is
closed and locked.
•To turn power on again, pull out the
viewfinder or open the LCD monitor.
OR
Set the Power Dial to “OFF”.
•When turning to “OFF”, it is not necessary to
press down the lock button.
Power lamp
5S
M
A
OFF
Y
START/STOP button
Lock button
Power Dial
A
L
P
NOTES:
●
The image will not appear simultaneously in the
LCD monitor and the viewfinder. No image
appears on the LCD monitor when the viewfinder
is pulled out. It is not possible to shoot using both
LCD monitor and viewfinder.
●
If 5 minutes elapse in the Record-Standby mode,
power shuts off automatically to conserve energy
and protect the heads. To turn the camcorder on
again, push back and pull out the viewfinder
again or close and re-open the LCD monitor. As
long as you don’t take out the tape you were
using or play it back, you can continue from
where you left off with no noticeable brake on the
recorded video.
●
When a blank portion is left between recorded
scenes on the tape, the time code is interrupted
and errors may occur when editing the tape.
Continue recording from where you stop so there
are no gaps by following "Recording from the
middle of a tape" (
●
Recored-Standby means that a tape is loaded and
the camcorder is ready to record.
●
During recording, sound is not heard from the
speaker. If you want to hear the sound, connect
optional headphones to the headphones jack. The
sound volume at this point is the same as the level
it was adjusted during playback.
●
To make the indications disappear, press and hold
the IND.ON/OFF button for more than approx. 1
second. However, it is impossible to remove the
tape running indicator “
indications and so on (
●
Use the viewfinder when under direct sunlight or
when reflections make it difficult to see the LCD
monitor.
Record-Standby
During recording
Z
pg. 22).
444
Z
pg. 78).
Display
PAUSE
Display
” and warning
REC
444
22 EN
RECORDING
(Cont.)
Recording From The Middle Of A Tape
When removing a tape on which you were recording, or when you resume recording on a tape after playing
back the recording previously made (without taking the tape out between recordings), perform this
procedure.
M
A
5S
OFF
Y
A
L
M
A
P
OFF
5S
Y
A
L
P
Lock button
Power Dial
MENU
REWSTOP
FF
PLAY/PAUSE
SELECT OPERATION MODE
1
Turn the Power Dial to “PLAY” while pressing
down the lock button located on the dial.
PULL OUT VIEWFINDER OR OPEN
2
LCD MONITOR
Pull out the viewfinder fully or open the LCD
monitor to approx. 90° degrees.
•The lens cover opens, the power lamp comes
on.
START SEARCH
3
Press 4/6, then press 2 or 3. Watch in the
viewfinder or the LCD monitor for the spot
where you want to begin recording.
ENGAGE STILL MODE
4
Once you find the spot at which you want to
start recording, press 4/6 to engage the Still
mode.
START/STOP Button
START RECORDING
5
Turn the Power Dial to any operation mode
except “PLAY” and “OFF”, then press START/
STOP.
•Start recording from a point prior to the end
of the last recording. A few seconds of the
end of the last recording will be erased.
NOTE:
If you start recording from the end of the previous
recording leaving no blank space, there may be
situations where a clean transition is not possible.
EN 23
Time Code
During recording, a time code is recorded on the tape. This code is to confirm the location of the
recorded scene on the tape during playback.
If recording starts from a blank portion, the time code begins counting from “00:00:00”
(minute:second:frame). If recording starts from the end of a previously recorded scene, the time code
continues from the last time code number.
To perform Random Assemble Editing (Z pg. 62), time code is necessary. If during recording a blank
portion is recorded partway through the tape, the time code is interrupted. When recording is resumed,
the time code starts counting up again from “00:00:00”. This means the camcorder may record the same
time codes as those existing in a previously recorded scene. To prevent leaving a blank portion on a
tape, perform the procedure in “Recording From The Middle of A Tape” (Z pg. 22) in the following
cases;
•After playing back the recorded tape, when
you shoot again.
•When power shuts off during shooting.
•When a tape is removed and re-inserted
during shooting.
•When shooting using a partially recorded tape.
•When shooting on a blank portion located
partway through the tape.
•When shooting again after already shooting a
scene and opening/closing the cassette cover.
TC 12 : 34 : 29
Display
Time code is displayed
during playback.
Minutes
Seconds
Frames
(30 frames = 1 second)
NOTES:
●
The Time Code cannot be reset.
●
During fast-forwarding and rewinding, time code indication does not move smoothly.
When blank portion is recorded on a tape
Time code
00:00:00
Time code
05:43:21
Time code
00:00:00
Tape
Shooting start point
Proper recording
Time code
00:00:00
Tape
Shooting start point
Time code
05:43:21
Newly recorded sceneBlankAlready recorded scene
Shooting start pointShooting stop point
Time code
05:44:00
Latest sceneNew sceneAlready recorded scene
Shooting start pointShooting start point
24 EN
RECORDING
(Cont.)
Tape Remaining Indicator
The time remaining on the tape is automatically monitored and displayed (Z pg. 78). When the tape ends,
“TAPE END” appears. If the indications are turned off, the tape remaining indicator appears when remaining
time reaches 2 minutes.
Display
89 min 3 min 2 min
blinking
1 min0 min
blinkingblinking
BRIGHT
– – – – – – – – – –
6
90 min
REC
MENU
IND.ON/OFF button
Brightness Control
You can adjust the brightness of the LCD monitor by
rotating the Select Dial.
ADJUST BRIGHTNESS
1
If you want to brighten the image...
Rotate the Select Dial upward until the
brightness indicator moves and the LCD
monitor reaches its appropriate brightness.
If you want to darken the image...
Rotate the Select Dial downward until the
brightness indicator moves and the LCD
monitor reaches its appropriate brightness.
•The brightness indication appears in the LCD
monitor.
Select Dial
LCD Monitor/Viewfinder Indications
You can make the LCD monitor/Viewfinder
indications appear/disappear.
PRESS IND.ON/OFF BUTTON
1
When you do not want the indications to
appear, press the IND.ON/OFF button
for longer than approximately 1 second.
Certain indications disappear.
Press again for longer than approx. 1 second to
make the indicaitons reappear.
NOTE:
It is impossible to make the tape running indicator
and warnings etc. disappear from the LCD monitor
or the viewfinder. For the indications that can be
removed, Z pg. 78
EN 25
Journalistic shooting
In some situations different angles of shooting may
be required for more dramatic results.
OPEN LCD MONITOR
1
Make sure the viewfinder is pushed back and
the LCD monitor is fully open (approx. 90°).
TILT LCD MONITOR
2
Tilt the LCD monitor in the most convenient
direction.
•The LCD monitor can rotate almost full circle
(270°: 90° downward, 180° upward).
Interface Shooting
You can shoot yourself while viewing your own
image in the LCD monitor.
TILT LCD MONITOR UPWARD
1
Open the LCD monitor and tilt it upward to
180 degrees so that it faces forward.
START RECORDING
2
Point the lens towards yourself and start
recording.
•During Interface Shooting, the “Tape Running”
indicator and warning indications
(Z pg. 80) are the only ones that will be
shown; they will appear horizontally
reversed in the display, but are not reversed
in the recording.
NOTE:
The tape remaining indicator does not appear
during interface shooting. However, when the
remaining time reaches 2 minutes, the indicator
appears showing the remaining time:
(blinking)
– –
(blinking)
–
– – –
(blinking)
26 EN
RECORDING
(Cont.)
Zoom
Select any one of the three powers of magnification and get “closer” to the subject (Z pg. 34).
Simply set the zoom switch to either zoom in (towards “T”) or zoom out (towards “W”). The zoom speed is
variable — the quicker you set the zoom switch, the quicker the zoom action.
NOTES:
●
Zoom magnification of over 10X is done through Digital image processing, and is therefore called Digital
Zoom.
●
During Digital Zoom, the quality of image may suffer.
●
Digital zoom cannot be used while the Video Echo effect (Z pg. 45), Snapshot Dissolve, the Picture
Wipe/Dissolve function (Z pg. 40) or the 5SD mode (Z pg. 30) are activated.
●
Macro shooting (as close as approx. 3 cm to the subject) is possible when the zoom switch is set all the
way to “W”.
D
Digital
zoom zone
T
Zoom in (T: Telephoto)
D
T
W
D
T
W
Zoom switch
D
T
W
10X (optical)
zoom zone
W
Zoom display
D
T
W
Zoom out (W: Wide angle)
RECORDING
Advanced Features
Snapshot
Use your camcorder like a regular camera and take a snapshot, or several of them in succession.
EN 27
Flash
Sub SNAPSHOT
Press SNAPSHOT during recording (Snapshot dissolve)
SNAPSHOT
Press SNAPSHOT during Record-Standby mode
SELECT OPERATION MODE
1
First turn the Power Dial to any operation
mode except “PLAY” and “OFF”, make sure
the viewfinder is pulled out or the LCD
monitor is open fully.
TAKE SNAPSHOT
2
Press SNAPSHOT.
If you press during Record-Standby...
.... “PHOTO” appears and a still image will be
recorded for approx. 5 seconds, then the
camcorder re-enters the Record-Standby
mode.
If you press during Recording...
.... “PHOTO” appears and a still image will be
recorded for approx. 5 seconds. The next
image then gradually overlaps the
snapshot and normal recording resumes.
•The sound effect of a shutter closing is
recorded together with the image.
SNAPSHOT
5S
M
A
OFF
Y
During snapshot
Lock button
A
L
P
Power Dial
Display
Flash Ready Indicator
PAUSE
Snapshot Flash:
The flash automatically lights at the subject when
it's dark (flash ready indicator appears in the
viewfinder or the LCD monitor) when taking a
snapshot in Record-Standby (Z pg. 28)
Motor Drive mode:
Keeping SNAPSHOT pressed provides an effect
similar to serial photography. (The interval between
the still pictures: approx. 0.7 seconds.)
Changing the Snapshot Setting:
•Still image with no frame can also be recorded
(Z pg. 36).
•When you don't want to hear the shutter sound,
set BEEP/TALLY to “OFF” in the system menu
(Z pg. 36). Though the sound is not heard from
the speaker, it is recorded on the tape.
NOTE:
When the grip strap is fastened to both the strap
eyelet and the sub-strap eyelet, use the Sub
SNAPSHOT button to take a snapshot.
Loading...
