JVC GM-P420E, GM-P420PCE, GM-P421PCE Operating Instructions Manual

OPERATING INSTRUCTIONS

GM-P420PCE GM-P421PCE

GM-P420E

ENGLISH

DEUTSCH

PLASMA DISPLAY MONITOR

BEDIENUNGSANLEITUNG : PLASMABILDSCHIRM MANUEL D'INSTRUCTIONS : MONITEUR DE VISUALISATION PLASMA MANUALE D'ISTRUZIONI : MONITOR CON SCHERMO AL PLASMA MANUAL DE INSTRUCCIONES : MONITOR DISPLAY DE PLASMA

PLASMA DISPLAY MONITOR

GM-P420E

GM-P420PCE

GM-P421PCE

GM-P420E

INSTRUCTIONS

FRANÇAIS

ITALIANO

ESPAÑOL

MENU INPUT POWER

LCT1150-001B

Apr. 2002 No. 51953

GM-P420PCE

GM-P421PCE

GM-P420E

1-2

No.51953

Safety Precautions

EUROPE EMC STANDARD NOTICE

■ GM-P420E/GM-P420PCE

Warning: This is a class A product. In a domestic environment this product may cause radio interference in which case the

user may be required to take adequate measure.

IMPORTANT INFORMATION

WARNING:

TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

IMPORTANT SAFEGUARDS

Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order not to defeat the safeguards incorporated into this product, observe the following basic rules for its installation, use and service. Please read these “Important Safeguards” carefully before use.

– All the safety and operating instructions should be read before the product is operated. – The safety and operating instructions should be retained for future reference. – All warnings on the product and in the operating instructions should be adhered to. – All operating instructions should be followed. – Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp

cloth for cleaning.

– Use a vacuum cleaner to get rid of the dust around the intakes (all the

openings) on the rear. If a vacuum is not available, use a cloth and wipe it off. Failure to do so will cause internal heat buildup and, therefore, cause damage to the product.

– Do not use attachments not recommended by the product manufacturer as they

may be hazardous.

– Do not use this product near water. Do not use immediately after moving from a

low temperature to high temperature, as this causes condensation, which may result in fire, electric shock, or other hazards.

– Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious injury to a child or

adult, and serious damage to the product. The product should be mounted according to the manufacturer’s instructions, and should use a mount recommended by the manufacturer.

– When the product is used on a cart, care should be taken to avoid quick stops, excessive force, and

uneven surfaces which may cause the product and cart to overturn, damaging equipment or causing possible injury to the operator.

– Slots and openings in the cabinet are provided for ventilation. These ensure reliable operation of the

product and protect it from overheating. These openings must not be blocked or covered. (The openings should never be blocked by placing the product on bed, sofa, rug, or similar surface. It should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided and the manufacturer’s instructions have been adhered to.)

For proper ventilation, separate the product from other equipment, which may prevent ventilation and keep distance more than 10 cm.

– This product should be operated only with the type of power source indicated on the label. If you are not sure of the

type of power supply to your home, consult your product dealer or local power company.

POWERAC INOPTIONAUDIO

OUT

RGB A

AUDIO

REMOTE

RS-232C

WIRED

MAKE

SPEAKER OUT

VIDEO A

AUDIO

VIDEO

INOUT

MONO/L

VIDEO B

AUDIO

VIDEO

IN Y/C IN

MONO/L

COMPONENT/RGB B

AUDIO

VIDEO

Y/G Pb/B Pr/R HD/Cs VD

MONO/L

ENGLISH

INSTRUCTIONS

Model GM-P420E GM-P420PCE GM-P421PCE

Thank you for purchasing this JVC Monitor. Before using the monitor, read this manual carefully so that you know how to use the Monitor correctly. Refer to this manual whenever questions or problems about operation arise. Be sure to read and observe the safety precautions. Keep this manual where the user can see it easily. * Installation and removal require special expertise.

Consult your product dealer for details.

This instruction manual refers to the GM-P420E, GM-P420PCE, and GM-P421PCE. The explanations and illustrations used in this instruction manual are of the GM-P420E unless otherwise stated. The differences between each model are as follows:

Contents

Page

Safety Precautions .................................................... 2

Parts Identification.....................................................4

• Remote Control ...................................................4

• Monitor: Front View .............................................5

• Monitor: Rear Views ............................................ 6

Preparations..............................................................8

• Checking the Accessories ................................... 8

• Installing the Batteries .........................................8

Installation ................................................................. 9

• Precautions .........................................................9

Connections ............................................................10

• Precautions .......................................................10

• Available Signals ............................................... 10

• Connection Diagrams........................................ 11

Basic Operations .....................................................14

• Daily Operations................................................14

• Changing the Aspect Ratio............................... 15

Video Adjustments ..................................................16

• Adjusting the Picture Quality ............................ 16

• Adjusting the Screen Size and Position............ 17

• Adjusting the Color Temperature...................... 19

• Adjusting the White Balance............................. 19

• Changing the Picture Mode .............................. 21

• Changing the Aspect Ratio............................... 21

• Setting the Receivable Signal Types ................ 22

• Setting the COMPONENT/RGB B Input........... 23

•

Resetting the Function Selection Menu Settings ..

Page

Other Convenient Functions.................................... 24

• Showing On-screen Display ............................. 24

• Confirming the Use Time and Model Name...... 25

• Showing the On-screen When Changing

the Input Mode .................................................. 25

• Prohibiting the Monitor’s Button Operations ..... 25

• Setting the Remote-Controllable Input ............. 26

• Setting the High-Definition Signal Types .......... 27

• Using the Pixel Shift Function........................... 27

• Using the Power Save Function ....................... 28

• Preventing the Afterimage Effect...................... 28

• Refreshing the Screen....................................... 29

• Resetting All the Setup Menu Settings ............. 29

• Resetting All the Menu Settings ....................... 30

Menu Classifications ...............................................31

• Main Menu ........................................................ 31

• Setup Menu .......................................................33

Troubleshooting....................................................... 34

• Self-diagnostic Indication ..................................35

Specifications .......................................................... 36

*1These inputs will be available with the separately-purchased video input unit (IF-C422P1G).

Ask your dealer to install the video input unit.

GM-P420E

Available Available Available

GM-P420PCE/GM-P421PCE

Not available*

Inputs VIDEO A

VIDEO B COMPONENT/RGB B

GM-P420PCE

GM-P421PCE

GM-P420E

1-3

No.51953

ENGLISH

– For United Kingdom: This product is equipped with a three-wire plug. This plug will fit only into a grounded power

outlet. If you are unable to insert the plug into the outlet, contact your electrician to install the proper outlet. Do not defeat the safety purpose of the grounded plug.

– Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or

against them. Pay particular attention to cords at doors, plugs, receptacles, and the point where they exit from the product.

– For added protection of this product during a lightning storm, or when it is left unattended and unused for long periods

of time, unplug it from the wall outlet and disconnect the cable system. This will prevent damage to the product due to lightning and power line surges.

– Do not overload wall outlets, extension cords, or convenience receptacles on other equipment as this can result in a

risk of fire or electric shock.

– Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short

out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

– Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltages

and other hazards. Refer all service to qualified service personnel.

– Unplug this product from the wall outlet and refer service to qualified service personnel under the following conditions:

a)When the power supply cord or plug is damaged. b)If liquid has been spilled, or objects have fallen on the product. c)If the product has been exposed to rain or water. d)If the product operated normally by following the operating instructions. Adjust only those controls that are covered

by the Operation Manual, as an improper adjustment of controls may result in damage and will often require

extensive work by a qualified technician to restore the product to normal operation. e)If the product has been dropped or damaged in any way. f) When the product exhibits a distinct change in performance – this indicates a need for service.

– When replacement parts are required, be sure the service technician has used replacement parts specified by the

manufacturer or with same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

– Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to

determine that the product is in proper operating condition.

– The product should be placed more than 30 cm away from heat sources such as radiators, heat registers, stoves, and

other products (including amplifiers) that produce heat.

– When connecting other products such as VCR’s, and personal computers, you should turn off the power of this product

for protection against electric shock.

– Do not place combustibles behind the cooling fan. For example, cloth, paper, matches, aerosol cans or gas lighters

that present special hazards when over heated.

– Use only the accessory cord designed for this product to prevent shock. – Do not touch the handles on the rear soon after many hours of continuous use. They are so hot and will cause a burn

on the hand. If you need to touch the handles, for example, to move the product, wait until the handles are cooled enough.

–

Option terminal: This terminal is intended exclusively to be used to drive the fan motor.

Do not connect any plugs to the terminal other than JVC’s recommended optional parts.

Polarity of terminal

POWER CONNECTION

The power supply voltage rating of this product is AC 230 V. The power cords attached conform to the following power supply voltage and countries. Use only the power cord designated to ensure Safety and EMC regulations of each country.

Note for the United Kingdom power cord only

The plug on the United Kingdom power cord has a built-in fuse. When replacing the fuse, be sure to use only a correctly rated approved type, re-fit the fuse cover. (Consult your dealer or qualified service personnel.)

How to replace the fuse

Open the fuse compartment with the blade screw driver, and replace the fuse.

Fuse

For United Kingdom: AC 230 V

For European countries: AC 230 V

Parts Identification

Remote Control

5 MENU/EXIT button

Use this button to display or erase menus. While a sub-menu is displayed, pressing this button will move you one screen back to the preceding menu.

6 Remote signal transmission window

7 ASPECT button (page 15)

Use this button to switch between aspect ratios. Each time you press the button, the aspect ratio changes as follows:

8 POWER button (page 14)

Use this button to turn on/off the power.

9 VOLUME + / – buttons (page 14)

Use these buttons to adjust the volume level.

• The VOLUME – button can be also used to display the Setup Menu (see page 25).

p 2 / 3 / 5 / ∞ buttons

Use these buttons to select menu items or make adjustments.

1 Remote control cable jack (page 11)

Connect the remote control cable (not supplied) when using this remote control as a wired remote control.

2 DISPLAY button (page 14)

Use this button to display the input terminal, color system (for VIDEO A or VIDEO B input), scan system (for COMPONENT input) and horizontal/vertical frequency (for RGB A and RGB B input). Pressing the button again will make the display disappear.

3 VIDEO A, VIDEO B, COMPO./RGB B and RGB A buttons

(page 14)

Use these buttons to switch between inputs. To select the COMPONENT or RGB B input, you have to set “RGB/COMPO.” correctly on the menu (see page 23).

• Only for GM-P420PCE and GM-P421PCE: Only RGB A input can be used. To reproduce images through the other inputs, you need to install video input unit (IF-C422P1G), which is separately purchased.

4 MUTING button (page 14)

Use this button to turn off the volume immediately. Pressing the button again will resume the previous volume level.

DISPLAY ASPECT POWER

RGB A

COMPO.

VIDEO BVIDEO A

MUTING

MENU/EXIT

RM-C576 REMOTE CONTROL UNIT

VOLUME

RGB B

REGULAR FULL

ZOOMPANORAMIC

GM-P420PCE

GM-P421PCE

GM-P420E

1-4

No.51953

ENGLISH

Monitor: Front View

1 Remote sensor/power lamp

Point the front end of the wireless remote control toward here. When the Monitor is turned on, the power lamp glows green. It glows orange in standby mode.

2 Self-diagnostic lamps (page 35)

These lamps light/flash if something abnormal occurs with the Monitor.

3 2 / 3 / 5 / ∞ buttons

Use these buttons to select menu items and to make adjustments.

• When no menu is displayed, you can use the 2 / 3

buttons to adjust the volume level.

4 MENU button

Use this button to display or erase menus. While a sub-menu is displayed, pressing this button will move you one screen back to the preceding menu.

5 INPUT button (page 14)

Use this button to switch between inputs. To select the COMPONENT or RGB B input, you have to set “RGB/COMPO.” correctly on the menu (see page 23).

• Only for GM-P420PCE and GM-P421PCE: Only RGB A input can be used. To reproduce images through the other inputs, you need to install video input unit (IF-C422P1G), which is separately purchased.

6 POWER button (page 14)

Use this button to turn on and off the Monitor.

MENU INPUT POWER

MENUINPUT POWER

3456

Bottom View

Parts Identification

(Continued)

Monitor: Rear Views

1 RGB A input terminals (page 11)

• D-sub, 15 pin

Connect to the video output terminal of a personal computer.

• AUDIO IN (stereo mini jack)

Connect to the audio output terminal of a personal computer.

2 REMOTE terminals (pages 11 and 13)

• RS-232C (D-sub, 9 pin)

Connect to the RS-232C terminal of a personal computer. For the control method using this terminal, consult an authorized JVC dealer.

• MAKE terminal (mini DIN 4pin)

Connect an external control unit. (See page 13.)

• WIRED terminal (stereo mini jack)

Connect a wired remote control unit to this terminal.

Note:

• When the above three terminals are used at the same time, transmitted commands through the MAKE terminal have priority over those through the other terminals.

3 AUDIO OUT terminals (pin jack) (page 11)

Connect to the audio input terminals of external equipment such as an amplifier.

4 OPTION terminal (page 13)

Connect the power cord of the Cooling Fan Unit (not supplied) when installing the Monitor vertically.

5 AC IN terminal (page 11)

Connect the supplied power cord to this terminal.

POWER switch (page 14)

Setting this switch to

ON will put the Monitor into standby mode, allowing you to turn on and off the power using the POWER button either on the remote control or on the Monitor.

7 SPEAKER OUT L/R terminals (page 11)

Connect external speakers.

POWERAC INOPTION

SPEAKER OUT

AUDIO

OUT

RGB A

AUDIO

REMOTE

RS-232C

WIRED

MAKE

9( 9(

SPEAKER OUT

1 2 3 4 5 6

GM-P420PCE

GM-P421PCE

GM-P420E

1-5

No.51953

Preparations

Checking the Accessories

The following accessories are included with the Monitor. Check for them. If any item is missing, please contact the dealer where you purchased the Monitor.

• Remote control (RM-C576) x 1

• Power cord x 2 (Use the one matching the wall outlet.)

• Batteries (AA/R6P) x 2

Installing the Batteries

Put the batteries in the remote control as follows. If the remote control has become erratic in operation, change the batteries.

Remove the back cover.

While pushing the release lever on the cover, remove the cover in the direction of the arrow.

Place the batteries.

Put the two supplied batteries (AA/R6P), noting the ª and · markings, as shown.

Replace the back cover as illustrated.

Make sure the release lever on the cover is locked in place correctly.

Precautions for using batteries

If batteries are used improperly, the liquid could leak out, causing a fire, injury, etc. or dirtying the vicinity. Take notice of the following:

• Do not mix old and new batteries.

• Do not mix different types of battery as different types may have different characteristics.

• Place the batteries according to the ª and · markings indicated on the battery compartment.

• When installing the batteries, insert the · end first to avoid a short circuit.

• Use only the specified batteries.

• When you are not using the remote control for a long time, remove the batteries.

• When the batteries have reached the end of their life, replace them with new ones immediately. Otherwise, the liquid may leak out, or malfunction may be caused by the leaked liquid. If the leaked liquid contacts your skin, wipe off the liquid with a soft cloth. If the affected skin is left as is, you may get a rough skin.

• Do not throw the batteries into fire or try recharging them.

• The service life of batteries is six months to one year for normal use. The supplied batteries are only for checking the operation and their life may be shorter. When the remote control operation becomes erratic, replace with new batteries.

The instruction below applies only to the use in Holland.

Gebruike batterijen:

ENGLISH

8 VIDEO A terminals (page 12)*

• VIDEO IN terminal (BNC)

Connect this terminal to the video output terminal of a VCR, etc.

• VIDEO OUT terminal (BNC)

Connect this terminal to the video input terminal of another Monitor.

• AUDIO (L/MONO, R) input terminals (pin jack)

Connect these terminals to the audio input terminals of a VCR, etc.

Note:

• Since the video output terminals on this Monitor are loop-though terminals, the devices connected to this video output terminal should be correctly terminated. Otherwise, pictures become abnormally bright or the Monitor screen gets affected abnormally.

9 VIDEO B terminals (page 12)*

• Y/C (S video) IN terminal (mini DIN 4pin) Connect this terminal to the S-video output terminal of a VCR, etc.

• VIDEO IN terminal (pin jack) Connect this terminal to the video output terminal of a VCR, etc.

• AUDIO (L/MONO, R) input terminals (pin jack) Connect these terminals to the audio output terminals of a VCR, etc.

Note:

• When both the video and S-video terminals are connected, the S-video terminal will have priority.

p COMPONENT/RGB B input terminals (page 12)*

• R, G, B, HD/Cs, VD (VIDEO) input terminals (BNC)

Connect these terminals to the following output terminals of a personal computer or other equipment: – Analog RGB signal output terminals – Horizontal sync (HD) signal or composite (Cs) signal

output terminal

– Vertical sync (VD) signal output terminal

Notes:

• External sync signals are automatically detected when they come in.

• When both horizontal (HD)/vertical (VD) sync and composite (Cs) sync are connected, HD/VD sync signals will be used.

• Y, Pb, Pr (VIDEO) input terminals (BNC)

Connect these terminals to the component signal output terminals of NTSC or high-vision equipment.

Note:

• When these terminals are used as the component terminals (Y, Pb, Pr)—see “Setting the COMPONENT/ RGB B Input” on page 23, external sync signals (HD/Cs, VD) cannot be used.

• AUDIO (L/MONO, R) input terminals (pin jack) Connect these terminals to the audio output terminals of the other equipment.

Note:

* GM-P420PCE and GM-P421PCE do not have

the following input terminals—VIDEO A, VIDEO B, and COMPONENT/RGB B. To input video, S-video, and component signals, you need to install video input unit (IF-C422P1G), which is separately purchased.

VIDEO A

AUDIO

VIDEO

IN OUT

L/MONO

VIDEO B

AUDIO

VIDEO

IN Y/C IN

L/MONO

COMPONENT/RGB B

AUDIO

VIDEO

Y/G Pb/B Pr/R HD/Cs VD

L/MONO

8 9 p

GM-P420PCE

GM-P421PCE

GM-P420E

1-6

No.51953

Precautions

• Before making connections, turn off all the equipment.

• Plugs should be firmly inserted; poor connection could cause noise.

• To unplug a cord, be sure to grasp its plug and pull it out.

• Connect the power cord after having finished all other connections.

• Refer also to the user manual of each piece of equipment.

Available Signals

Video signals

The following signals can be input to this Monitor:

• VIDEO A and VIDEO B terminals accept — PAL, PAL60, NTSC, NTSC4.43, and SECAM signals.

• COMPONENT/RGB B terminals accept — 480i, 576i, 480p, 720p, and 1080i (1035i) signals. (You need to set “RGB/COMPO.”

to “COMPO.” on the menu (see page 23). (For GM-P420PCE and GM-P421PCE, to input the above signals, you need to install the video input unit (IF-C422P1G), which is separately purchased.)

Computer signals (Preset)

This Monitor has 13 preset video modes for the most popular industrial standard, and the signals of the following image resolutions can be input to the RGB input terminals.

1 PC98 640 400 24.8 56.4 Non-interlace

2 VGA400-70 640 400 31.5 70.1 Non-interlace

3 VGA480-60 640 480 31.5 59.9 Non-interlace

4 VGA480-72 640 480 37.9 72.8 Non-interlace

5 VGA480-75 640 480 37.5 75.0 Non-interlace

6 MAC13” 640 480 35.0 66.7 Non-interlace

7 SVGA-56 800 600 35.2 56.3 Non-interlace

8 SVGA-60 800 600 37.9 60.3 Non-interlace

9 SVGA-72 800 600 48.1 72.2 Non-interlace

10 XGA-60 1024 768 48.4 60.0 Non-interlace

11 XGA-70 1024 768 56.5 70.1 Non-interlace

12 RGB15K-60 — — 15.7 59.9 Interlace

13 RGB15K-50 — — 15.6 50.0 Interlace

Notes:

• When a signal other than listed above is input, a part of the screen may become void or an unnecessary picture may appear.

• Signals, though they are within the acceptable range of frequencies, may not be displayed normally, depending on the signal

type.

• Depending on the connected equipment, the Monitor may not be compatible with composite sync (Cs) or G on sync signals.

• When a preset mode signal is input, the vertical frequency displayed on the screen will have an “*” shown at its right top

position.

• When No. 7 to No. 11 signals are input, lines will become thin if their signal frequencies are higher than the screen resolution.

Connections

Screen resolution

Horizontal

Vertical

Horizontal

Frequency (kHz)

Vertical

Frequency (Hz)

Signal name Scan systemNo.

ENGLISH

Installation

Precautions

• When mounting the Monitor vertically, consult your dealer. (See also page 13).

• When installing the Monitor, be sure to use a dedicated Stand Unit, Wall Mounting Unit, or Monitor Hanger Unit, depending on a particular case. Ask your dealer for installation.

• When installing the Monitor, refer also to the user manual for each option to use. Do not tilt the Monitor rightward, leftward, or backward.

• Route the power cord and connection cables along wall or floor corners to avoid walking on them.

• For good heat dissipation, try to leave the following distances of space (minimum) around the Monitor.

• The ambient temperature of the installation place should be within the range of 0˚C to 40˚C.

• When installing the Monitor in a place, such as near the ceiling, the remote control may not work correctly because of possible effects from the surroundings. If this happens, use the remote control as a wired remote control or move the Monitor where it is free from these effects.

When installing the Monitor on a stand

When mounting the Monitor on the wall

Notes:

• Do not allow the same image (pattern) to be continuously displayed on the screen for a long time; otherwise, the area on the screen corresponding to the image may vary in brightness, leaving an afterimage on the screen. To reduce the afterimage, you can use the Refresh function (see page 28).

• The Monitor is manufactured using very high-precision technology, allowing for more than 99.99% active pixels, however, be aware that only a slight number of pixels may be deficient or lit at all times.

• Do not install the Monitor in such a way that the Monitor and other AV equipment affect each other adversely. (For example, if a disturbed image or noise due to electromagnetic interference occurs, or if the infrared remote control malfunctions, change the installation place.)

Front View

200

MENUINPUT POWER

100

Side View

Unit: mm

200

When hanging the Monitor from the ceiling

Side View

Take measures against the Monitor from overturning:

To protect against abnormal events such as earthquakes and to prevent unexpected accidents, take appropriate measures for preventing the Monitor from overturning; should it overturn, this could lead to personal injury. For detailed information, refer to the manual supplied for the stand.

Wall

Unit: mm

200

150

MENUINPUT POWER

150

Front View

Side View

GM-P420PCE

GM-P421PCE

GM-P420E

1-7

No.51953

AV connections

Connections

(Continued)

These terminals are not available for GM-P420PCE and GM-P421PCE. To use them, you need to install video input unit (IF-C422P1G), which is separately purchased.

VCR 1

(used as the playback source)

VCR 2

(used as the playback source)

DVD player, etc

(used as the playback source)

To video output

To audio output

To video output

To audio output

To video output

To S-video output

To HD/Cs output

To R output

To B output

To G output

To VD output

To audio output

Personal computer

(used as the playback source)

Notes:

• You can connect another VCR or Monitor to the VIDEO A OUT terminal. However, when connecting a VCR to the VIDEO A terminals, do not connect both IN and OUT terminals to the same VCR.

• When connecting a VCR to the VIDEO B terminals, you can use either the video or S-video terminals. If the both terminals are used, S-video terminal will have priority.

When connecting another PC to the COMPONENT/RGB B terminals, set the “RGB/COMPO.” setting to “RGB” (see page 23).

VIDEO A

AUDIO

VIDEO

IN OUT

L/MONO

VIDEO B

AUDIO

VIDEO

IN Y/C IN

L/MONO

COMPONENT/RGB B

AUDIO

VIDEO

Y/G Pb/B Pr/R HD/Cs VD

L/MONO

ENGLISH

Connection Diagrams

Typical connections

DISPLAY ASPECT POWER

RGB A

RGB B

COMPO.

VIDEO B

VOLUME

VIDEO A

MUTING

MENU/EXIT

RM-C576 REMOTE CONTROL UNIT

SPEAKER OUT

POWERAC INOPTIONAUDIO

OUT

RGB A

AUDIO

REMOTE

RS-232C

WIRED

MAKE

Amplifier, etc.

Power cord

(supplied)

To a wall outlet

To audio input

Left speaker

Right speaker

External speaker connection

To speaker input terminals

Personal computer

(used as the playback source)

To monitor output

To RS-232C

To audio output

Personal computer

(used to control the Monitor)

Remote control

(supplied)

For connection, see page 13

Cable with stereo mini jacks

(not supplied)

GM-P420PCE

GM-P421PCE GM-P420E

Connecting an external control unit

When connecting the external control unit to the MAKE terminal, you can operate the following functions through the MAKE terminal;

• Turn on or off the Monitor.

• Select the input.

Notes:

• There is no remote control on/off switch. When a plug is inserted to the MAKE terminal, remote control through the

• When the other REMOTE terminals are used at the same time, transmitted commands through the MAKE terminal have

• MAKE terminal

Preparation: The

POWER switch on the rear must be set to ON (so that the Monitor is in standby mode).

Preparation: “REMOTE SWITCH” should be set correctly to select your desired input (see page 26).

external control unit is automatically activated.

priority over those through the other terminals.

• External control unit

6 4 2

Pin number Signal name

5 3 1

1 GND 2 GND 3 SW2 4 SW1 5 SW DET 6 GND

transmitted

○○○○

Signals

TTL level

H: Power OFF L: Power ON

H: Input A* L: Input B*

H: Not connected L: Connected

* Input A and Input B will be determined by the “REMOTE

SWITCH” setting.

ENGLISH

IMPORTANT:

External control unit is not commercially available in the market. When you need it, consult your dealer.

Connecting the Cooling Fan Unit (not supplied)

When installing this Monitor vertically, it is required to attach the Cooling Fan Unit. Note: If you install the Monitor in such a way not instructed in this manual (for example, installing it diagonally), the

Cooling Fan Unit may not be able to cool down the internal heat enough to make the Monitor operate; therefore, reinstallation or another method for cooling will be required.

• For more detailed connection, refer to the manual supplied with the Cooling Fan Unit.

Cooling Fan Unit

OPTION

POWERAC INOPTIONAUDIO

OUT

MAKE

WIRED

RS-232C

REMOTE

SPEAKER OUT

AUDIO

RGB A

1-8

IMPORTANT:

When installing the Monitor vertically, consult your dealer.

No.51953

+ 16 hidden pages

JVC GM-P420E, GM-P420PCE, GM-P421PCE Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
