JVC DLA-VS47NV, DLA-VS45NV User Manual
.
INPUT 1
DISPLAYPORT
INPUT 2 DUAL
NATURAL
DYNAMIC
INPUT 4INPUT 3 QUAD
LENS
AP.
PIC.
ADJ.
COLOR
TEMP.
GAMMA
USER5 USER6USER4
USER2 USER3USER1
LENS
CONTROL
MOTION
ENHANCE
C.M.D.
NAME
EDIT
D-ILA Projector
DLA-VS47NV
Getting Started
INSTRUCTIONS
DLA-VS45NV
.
Set up Operate Adjust/Set Maintenance
Troubleshooting
B5A-2671-12
Others
Safety Precautions
IMPORTANT INFORMATION
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
About the installation place
Do not install the projector in a place that cannot
support its weight securely.
If the installation place is not sturdy enough, the
projector could fall or overturn, possibly causing
personal injury.
WARNING:
THIS APPARATUS MUST BE EARTHED.
CAUTION:
To reduce the risk of electric shock, do not remove
cover. Refer servicing to qualified service personnel.
This projector is equipped with a 3-blade grounding
type plug to satisfy FCC rule. If you are unable to
insert the plug into the outlet, contact your electrician.
NOISE EMISSION DECLARATION
The sound pressure level at the operator position is
equal or less than 60dB(A) according to ISO7779.
WARNING
This equipment is compliant with Class A of CISPR
32.
In residential environment this equipment may
cause radio interference.
WARNING
REMOVE THE LENS COVER BEFORE TURNING
ON THE PROJECTOR
FCC INFORMATION (U.S.A. only)
CAUTION:
Changes or modification not approved by JVC could
void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the
instruction manual, may cause harmful interference
to radio communications. Operation of this
equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at his own
expense.
Getting Started
2
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A
-
-
-
-
-
-
-
-
-
-
-
-
-
IMPORTANT SAFEGUARDS
Electrical energy can perform many useful functions.
This unit has been engineered and manufactured to
assure your personal safety. But IMPROPER USE
CAN RESULT IN POTENTIAL ELECTRICAL
SHOCK OR FIRE HAZARD. In order not to defeat
the safeguards incorporated into this product,
observe the following basic rules for its installation,
use and service. Please read these Important
Safeguards carefully before use.
All the safety and operating instructions should be read
before the product is operated.
The safety and operating instructions should be retained for
future reference.
All warnings on the product and in the operating
instructions should be adhered to.
All operating instructions should be followed.
Place the projector near a wall outlet where the plug can be
easily unplugged.
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
Do not use attachments not recommended by the product
manufacturer as they may be hazardous.
Do not use this product near water. Do not use immediately
after moving from a low temperature to high temperature,
as this causes condensation, which may result in fire,
electric shock, or other hazards.
Do not place this product on an unstable cart, stand, or
table. The product may fall, causing serious injury to a child
or adult, and serious damage to the product. The product
should be mounted according to the manufacturer’s
instructions, and should use a mount recommended by the
manufacturer.
When the product is used on a cart,
care should be taken to avoid quick
stops, excessive force, and uneven
surfaces which may cause the product
and cart to overturn, damaging
equipment or causing possible injury to
the operator.
Slots and openings in the cabinet are
provided for ventilation. These ensure reliable operation of
the product and protect it from overheating. These
openings must not be blocked or covered. (The openings
should never be blocked by placing the product on bed,
sofa, rug, or similar surface. It should not be placed in a
built-in installation such as a bookcase or rack unless
proper ventilation is provided and the manufacturer’s
instructions have been adhered to.)
To allow better heat dissipation, keep a clearance between
this unit and its surrounding as shown below. When this unit
is enclosed in a space of dimensions as shown below, use
an air-conditioner so that the internal and external
temperatures are the same. Overheating can cause
damage.
-
-
-
-
-
-
-
-
a)
b)
c)
d)
e)
f)
When the power supply cord or plug is damaged.
If liquid has been spilled, or objects have fallen on the
product.
If the product has been exposed to rain or water.
If the product does not operate normally by following the
operating instructions. Adjust only those controls that
are covered by the Operation Manual, as an improper
adjustment of controls may result in damage and will
often require extensive work by a qualified technician to
restore the product to normal operation.
If the product has been dropped or damaged in any
way.
When the product exhibits a distinct change in
performance, this indicates a need for service.
Power source indicated on the label. If you are not sure of
the type of power supply to your home, consult your
product dealer or local power company.
This product is equipped with a three-wire plug. This plug
will fit only into a grounded power outlet. If you are unable
to insert the plug into the outlet, contact your electrician to
install the proper outlet. Do not defeat the safety purpose of
the grounded plug.
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or
against them. Pay particular attention to cords at doors,
plugs, receptacles, and the point where they exit from the
product.
For added protection of this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the cable system. This will prevent damage to
the product due to lightning and power line surges.
Do not overload wall outlets, extension cords, or
convenience receptacles on other equipment as this can
result in a risk of fire or electric shock.
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltages
and other hazards. Refer all service to qualified service
personnel.
Unplug this product from the wall outlet and refer service to
qualified service personnel under the following conditions:
Front
150 mm
and above
200 mm
and above
300 mm
and above
300 mm
and above
150 mm and above
Getting Started
3
-
-
-
-
-
-
-
-
-
-
-
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or with same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
The product should be placed more than one foot away
from heat sources such as radiators, heat registers, stoves,
and other products (including amplifiers) that produce heat.
When connecting other products such as VCR’s, and DVD
players, you should turn off the power of this product for
protection against electric shock.
Do not place combustibles behind the cooling fan. For
example, cloth, paper, matches, aerosol cans or gas
lighters that present special hazards when over heated.
Do not ceiling-mount the projector to a place which tends to
vibrate; otherwise, the attaching fixture of the projector
could be broken by the vibration, possibly causing it to fall
or overturn, which could lead to personal injury.
Use only the accessory cord designed for this product to
prevent shock.
For health reasons, please take a break of about 5-15
minutes every 30-60 minutes and let your eyes rest. Please
refrain from watching any 3D-images when you feel tired,
unwell or if you feel any other discomfort. Moreover, in case
you see a double image, please adjust the equipment and
software for proper display. Please stop using the unit if the
double image is still visible after adjustment.
Once every three years, please perform an internal test.
This unit is provided with replacement parts needed to
maintain its function (such as cooling fans). Estimated
replacement time of parts can vary greatly depending on
frequency of use and the respective environment. For
replacement, please consult your dealer, or the nearest
authorized JVC service center.
When fixing the unit to the ceiling, Please note that we do
not take any responsibility, even during the warranty period,
if the product is damaged due to use of metal fixtures used
for fixation to the ceiling other than our own or if the
installation environment of said metal fixtures is not
appropriate. If the unit is suspended from the ceiling during
use, please be careful in regard to the ambient temperature
of the unit. If you use a central heating, the temperature
close to the ceiling will be higher than normally expected.
Video images can burn into the electronic component parts.
Please do not display screens with still images of high
brightness or high contrast, such as found in video games
and computer programs. Over a long period of time it might
stick to the picture element. There is no problem with the
playback of moving images, e.g. normal video footage.
-
-
-
-
-
-
Not using the unit for a long time can lead to malfunction.
Please power it on and let it run occasionally. Please avoid
using the unit in a room where cigarettes are smoked. It is
impossible to clean optical component parts if they are
contaminated by nicotine or tar. This might lead to
performance degradation.
Please watch from a distance three times the height of the
projected image size. Persons with photosensitivity, any
kind of heart disease, or weak health should not use 3D
glasses.
Watching 3D-images might be cause of illness. If you feel
any change in your physical condition, please stop
watching immediately and consult a physician if necessary.
When watching 3D images, it is recommended to take
regular breaks. As the length and frequency of the required
breaks differ for every person, please judge according to
your own condition.
If your child watches while wearing 3D glasses, it should be
accompanied by its parents or an adult guardian. The adult
guardian should be careful to avoid situations where the
child’s eyes might become tired, as responses to tiredness
and discomfort, etc., are hard to detect, and it is possible
for the physical condition to deteriorate very quickly. As the
visual sense is not yet fully developed in children under the
age of 6, please consult a physician in regard to any
problem concerning 3D-images if necessary.
Note that when using the 3D feature, the video output may
appear different from the original video image due to image
conversion on the device.
* DO NOT allow any unqualified person to
install the unit.
Be sure to ask your dealer to install the unit
(e.g.attaching it to the ceiling) since special
technical knowledge and skills are required for
installation. If installation is performed by an
unqualified person, it may cause personal injury or
electrical shock.
-
-
-
-
-
-
-
Do not use optical instruments (such as magnifying glass or
reflector) viewing the laser output. It may pose an eye
hazard.
When turning on the projector, ensure that no one is looking
into the projection lens.
Do not look into the lens and openings when the light is on.
Doing so would have serious effects on the human body.
Do not detach or attach the projection lens with the power
connected.
Attempting to disassemble, repair or modify the projector
yourself may lead to serious safety issues.
Using a faulty product not only results in electrical shock or
fire hazard, it can cause visual impairment.
When abnormality occur, stop using the projector
immediately and send it to your authorized dealer for repair.
Getting Started
4
Power cord
Power cord
For European continent countries
Green-and-yellow
Blue
Brown
: Earth
: Neutral
: Live
POWER CONNECTION
WARNING:
WARNING:
Do not cut off the main plug from this
equipment.
The power supply voltage rating of this product is
AC100V – AC240V. Use only the power cord
designated by our dealer to ensure Safety and EMC.
Ensure that the power cable used for the projector is
the correct type for the AC outlet in your country.
Consult your product dealer.
If the plug fitted is not suitable for the power points
in your home or the cable is too short to reach a
power point, then obtain an appropriate safety
approved extension lead or adapter or consult your
dealer. If nonetheless the mains plug is cut off,
dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the main
supply.
THIS APPARATUS MUST BE EARTHED.
IMPORTANT (Europe only):
The wires in the mains lead on this product are
colored in accordance with the following cord:
As these colors may not correspond with the
colored making identifying the terminals in your
plug, proceed as follows:
The wire which is colored green-and-yellow must be
connected to the terminal which is marked M with
the letter E or the safety earth or colored green or
green-and-yellow. The wire which is colored blue
must be connected to the terminal which is marked
with the letter N or colored black.
The wire which is colored brown must be connected
to the terminal which is marked with the letter L or
colored red.
For USA and Canada only
Use only the following power cord.
Dear Customer,
This apparatus is in conformance with the valid
European directives and standards regarding
electromagnetic compatibility and electrical safety.
European representative of
JVCKENWOOD Corporation is:
JVCKENWOOD Deutschland GmbH
Konrad-Adenauer-Allee 1-11,
61118 Bad Vilbel,
GERMANY
Getting Started
5
ENGLISH
Information for Users on Disposal of Old Equipment and Batteries
[European Union only]
These symbols indicate that equipment with these symbols should not be disposed
of as general household waste. If you want to dispose of the product or battery,
please consider the collection systems or facilities for appropriate recycling.
Notice:
The sign Pb below the symbol for batteries indicates that this battery contains lead.
Benutzerinformationen zur Entsorgung alter Geräte und Batterien
[Nur Europäische Union]
Diese Symbole zeigen an, dass derartig gekennzeichnete Geräte nicht als normaler
Haushaltsabfall entsorgt werden dürfen. Wenden Sie sich zur Entsorgung des
Produkts oder der Batterie an die hierfür vorgesehenen Sammelstellen oder
Einrichtungen, damit eine fachgerechte Wiederverwertung möglich ist.
Hinweis:
Notification:
Das Zeichen Pb unterhalb des Batteriesymbols gibt an, dass diese
Batterie Blei enthält.
Informations relatives à l’élimination des appareils et des piles usagés, à l’intention des utilisateurs
[Union européenne seulement]
Si ces symboles figurent sur les produits, cela signifie qu’ils ne doivent pas être jetés
comme déchets ménagers. Si vous voulez jeter ce produit ou cette pile, veuillez
considérer le système de collecte des déchets ou les centres de recyclage appropriés.
La symbole Pb en dessous du symbole des piles indique que cette
pile contient du plomb.
Informatie voor gebruikers over het verwijderen van oude apparatuur en batterijen
[Alleen Europese Unie]
Deze symbolen geven aan dat apparatuur met dit symbool niet mag worden
weggegooid als algemeen huishoudelijk afval. Als u het product of de batterij wilt
weggooien, kunt u inzamelsystemen of faciliteiten voor een geschikte recycling
gebruiken.
Opmerking:
Het teken Pb onder het batterijsymbool geeft aan dat deze batterij lood bevat.
Battery
Products
Batterie
Produkte
Pile
Produits
Batterij
Producten
DEUTSCH
FRANÇAIS
NEDERLANDS
Información para los usuarios sobre la eliminación de baterías/pilas usadas
[Sólo Unión Europea]
Estos símbolos indican que el equipo con estos símbolos no debe desecharse
con la basura doméstica. Si desea desechar el producto o batería/pila, acuda
a los sistemas o centros de recogida para que los reciclen debidamente.
Atención: La indicación Pb debajo del símbolo de batería/pila indica que ésta
contiene plomo.
Baterías/pilas
Productos
ESPAÑOL / CASTELLANO
ITALIANO
Informazioni per gli utenti sullo smaltimento delle apparecchiature e batterie obsolete
[Solo per l’Unione Europea]
Questi simboli indicano che le apparecchiature a cui sono relativi non devono
essere smaltite tra i rifiuti domestici generici. Se si desidera smaltire questo
prodotto o questa batteria, prendere in considerazione i sistem i o le strutture di
raccolta appropriati per il riciclaggio corretto.
Nota:
Il simbolo Pb sotto il simbolo delle batter ie indica che questa batteria contiene piombo.
Batteria
Prodotti
Getting Started
6
Use of controls or adjustments or performance of
procedures other than those specified herein may result
in hazardous radiation exposure.
This Projector is classified as a CLASS 3R LASER
PRODUCT.
This CLASS 3R LASER PRODUCT label and Caution
label is located on the Rear Side surface of the projector.
For the customers In the U.S.A. and Canada
CAUTION
The APERTURE LABEL is located on the top cover.
APERTURE LABEL
APERTURE LABEL
IEC62471-5 LABEL
LASER RADIATION AVOID DIRECT EYE EXPOSURE CLASS 3R LASER PRODUCT.
Do not look into the lens while in use.
Light source specifications
30 W Laser diodes ×6
Wavelength 450 - 460 nm
Maximum output is 64.12 W
WARNING
Beam divergence angle from lens of this unit
Laser emission port
Wide : α=71°
Tele : α=39°
α
CAUTION
Location information of the labels
LASER CAUTION LABEL
LASER RADIATION
AVOID DIRECT EYE
EXPOSURE
CLASS 3R LASER PRODUCT
WAVE LENGTH : 453nm
MAX OUTPUT : 83.56mW
RAYONNEMENT LASER
EVITER L’EXPOSITION
DIRECTE DES YEUX
PRODUIT LASER DE CLASSE 3R
LONGUEUR D'ONDE : 453nm
SORTIE MAX : 83.56mW
RADIACION LASER
EVITAR LA EXPOSICION
DIRECTA DE LOS OJOS
CLASE 3R PRODUCTO LASER
LONGGITUD DE ONDA : 453nm
SALIDA MAX : 83.56mW
IEC/EN60825-1：2007
LASER RADIATION
AVOID DIRECT EYE
EXPOSURE
CLASS 3R LASER PRODUCT
WAVE LENGTH : 453nm
MAX OUTPUT : 83.56mW
RAYONNEMENT LASER
EVITER L’EXPOSITION
DIRECTE DES YEUX
PRODUIT LASER DE CLASSE 3R
LONGUEUR D'ONDE : 453nm
SORTIE MAX : 83.56mW
RADIACION LASER
EVITAR LA EXPOSICION
DIRECTA DE LOS OJOS
CLASE 3R PRODUCTO LASER
LONGGITUD DE ONDA : 453nm
SALIDA MAX : 83.56mW
IEC/EN60825-1：2007
LASER APERTURE
LASER APERTURE
Getting Started
7
Use of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
For the customers In other countries
CLASS 1 LASER PRODUCT
Location information of the labels
LASER CAUTION LABEL
Do not look into the lens while in use.
WARNING
CAUTION
LASER CAUTION LABEL
IEC62471-5
Location information of the labels
As with any bright light source, do not stare into the beam, RG2 IEC 62471-5:2015
Getting Started
8
For the customers In China
Getting Started
9
Contents
Getting Started
Getting Started
Safety Precautions .................................................. 2
Accessories/Optional Accessories ........................ 11
Check the Accessories ...................................... 11
Controls and Features ........................................... 12
Main Unit - Front ................................................ 12
Main Unit - Bottom ............................................. 12
Main Unit - Rear ................................................. 13
Main Unit - Input Terminals ................................ 14
Remote Control ................................................. 15
Loading Batteries into the Remote Control ........ 16
Effective Range of Remote Control Unit ............ 16
Menu ................................................................. 17
Set up
Installing the Projector ........................................... 18
Precautions during Installation ........................... 18
Precautions during Mounting ............................. 19
Adjusting the Position ........................................ 21
Connecting the Projector ....................................... 22
Connecting to the DisplayPort Terminals ........... 22
Connecting to the LAN Terminal ........................ 22
Connecting to the RS-232C Terminal ................ 23
Connecting to the REMOTE Terminal ............... 23
Connecting the Power Cord (Supplied Accessory)
Operate
Viewing Videos ...................................................... 24
...... 23
Maintenance
Maintaining the Cabinet and Remote Control ........ 48
Cleaning and Replacing the Filter ......................... 48
About the Lens ...................................................... 49
Mounting the Lens ............................................. 49
Troubleshooting
Troubleshooting .................................................... 52
When the Following Messages Appear... .............. 55
Others
External Control .................................................... 56
RS-232C Specifications ..................................... 56
TCP/IP Connection ............................................ 56
Command Format .............................................. 57
Remote Control Code ........................................ 58
Communications Example ................................. 59
Specifications ........................................................ 60
Index ..................................................................... 71
Symbols used in this manual
v indicates a function that is supported by DLAVS47NV.
w indicates a function that is supported by DLAVS45NV.
Items not marked with any of the above symbols are
supported by all models.
Adjust/Set
Adjustments and Settings in the Menu .................. 26
List of Menu Items ............................................. 26
Picture Adjust ........................................... 28
Input Signal ............................................... 35
Installation ................................................ 36
Display Setup ........................................... 44
Function .................................................... 45
Information ................................................ 47
10
Accessories/Optional Accessories
Check the Accessories
Remote control ....................................................................... 1 piece
AAA-size batteries (for operational check) ............................ 2 pieces
Power cord (for USA) (about. 2 m) ......................................... 1 piece
Power cord (for EU) (about 2 m) ............................................. 1 piece
Lens spacer ............................................................................ 1 piece
Getting Started
Screw ................................................................................... 4 pieces
Sponge ................................................................................... 1 piece
Front base .............................................................................. 1 piece
0
Other items include the instruction manual, warranty, and other printed materials.
0
Be sure to read the “Safety Precautions” before using this projector.
11
Controls and Features
A
B
C
D D
E
Getting Started
Main Unit - Front
A
Lens (sold separately)
Zoom lens or short focal length lens is optional.
B
Remote Sensor (front)
Please aim the remote control at this area when using
it.
* There is also a remote sensor at the rear.
Main Unit - Bottom
E
C
Indicator
Refer to “Indicator Display on the Main Unit”P. 68.
D
Exhaust vent
Warm air is discharged to cool down the internal
temperature.
Do not block the vents.
Feet
The height and angle of the projector can be adjusted by turning the
foot. (0 to 5 mm) (P. 21)
When the foot is removed, it can be used as the mounting hole for the
ceiling mount bracket.
12
Main Unit - Rear
I
J
H
F G
[MENU]: Displays the menu
[BACK]: Returns to the previous menu
[JKH I] keys: Selects an item
[OK]: Confirms a selection
[J INPUT K]: Switches the input
A: Turns “on”/“off” the
power
Getting Started
F
Input terminals
For details on the terminals, refer to “Main Unit - Input
Terminals”P. 14.
G
Operation panel
For more details, please refer to the “Operation
panel” in the diagram below.
H
Remote Sensor (rear)
Please aim the remote control at this area when using
it.
* There is also a remote sensor at the front.
Operation panel
I
Power input terminal
Connect the supplied power cord to this terminal.
J
Air Inlets
The inlets take in air to cool down the internal
temperature.
Do not block the inlet. Do not blow hot air on the inlet.
Doing so may cause the unit to malfunction.
13
A B C D GE F H I
Enlarged View of Rear Face
Getting Started
Main Unit - Input Terminals
A
[SYNC OUT] terminal
For synchronizing with other equipment.
B
[SERVICE] terminal
For updating the software using a commercially
available USB flash drive.
C
[RS-232C] terminal (D-sub 9-pin
male)
The projector can be controlled by connecting a PC to
this terminal.
D
[LAN] terminal (RJ-45)
The projector can be controlled by connecting it to a
PC through the computer network for control
commands to be sent to the projector.
E
[DisplayPort 1] input terminal
F
[DisplayPort 2] input terminal
G
[DisplayPort 3] input terminal
H
[DisplayPort 4] input terminal
(20-pin male)
For connecting to devices that support DisplayPort
output. (P. 22)
I
[REMOTE CONTROL] terminal
(stereo mini jack)
Outputs L and R sync signals during 3D signal input.
(P. 45)
This terminal is used to connect the remote control
directly to the projector with the cable.
14
Remote Control
INPUT 1
DISPLAYPORT
INPUT 2 DUAL
NATURAL
DYN AMIC
INPUT 4INPUT 3 QUAD
LENS
AP.
PIC.
ADJ.
COLOR
TEMP.
GAMMA
USER5 USER6USER4
USER2 USER3USER1
LENS
CONTROL
MOTION
ENHANCE
C.M.D.
NAME
EDIT
A
M
O
P
Q
E
H
B
C
D
F
G
I
J
K
L
N
Getting Started
A
B [STANDBY]
Turns off the power. (P. 25)
B
C [ON]
Turns on the power. (P. 24)
C
[DISPLAYPORT]
Switches the input to [DisplayPort 1]
to [DisplayPort 4], [Dual] or [Quad].
(P. 24)
D
[LENS CONTROL]
For adjusting focus, zoom, and shift.
(P. 36)
E
[C.M.D.]
For setting frame processing.
(P. 34)
0
Pressing the button each time
switches the mode in the following
sequence: “Off” " “Mode 1” "
“Mode 2” " “Mode 3”...
F
[MOTION ENHANCE]
Switches the Motion Enhance
setting. (P. 34)
G
[HIDE]
Hides the image temporarily.
(P. 24)
H
[LIGHT]
Illuminates the buttons on the
remote control.
I
[JKH I] keys
For selecting an item.
J
[OK]
Confirms a selected item.
K
[MENU]
Displays the menu, or hides the
menu if it is displayed.
L
[BACK]
Returns to the previous menu.
M
[PICTURE MODE]
Switches the picture mode. (P. 28)
0
Press [NATURAL], [DYNAMIC] or
[USER1] to [USER6] to switch to the
respective picture mode.
0
Pressing [NAME EDIT] enables the
name of the picture mode from
[USER1] to [USER6] to be edited.
N
[GAMMA]
Switches the gamma. (P. 31)
0
Pressing the button each time
switches the configurable gamma in
sequence.
O
[COLOR TEMP.]
Switches the color temperature.
(P. 30)
0
Pressing the button each time
switches the configurable color
temperature in sequence.
P
[LENS AP.]
For setting the aperture. (P. 28)
Q
[PIC. ADJ.]
Displays the picture quality
adjustment gauge. (P. 34)
0
Pressing the button each time
displays the adjustment gauge in the
following sequence: “Contrast” "
“Brightness” " “Color” " “Tint” "
“Sharpness” " “LD Current”" “IR
Current”" “LD Gain” " “IR Gain” "
“Aperture” " “Picture Tone” " “Dark
Level” " “Bright Level”.
15
30°
30°
20°
20°
Remote Control
This unit
A
B
30°
30°
20°
20°
20°
20°
20°
20°
Screen
Remote Control
This unit
Getting Started
Loading Batteries into the Remote Control
Loading the batteries
Removing the batteries
Effective Range of Remote Control Unit
0
If the remote control has to be brought closer to the unit
to operate, it means that the batteries are wearing out.
Replace the batteries with new ones (AAA).
0
Insert the batteries according to the t s marks.
Be sure to insert the s end first.
When removing the battery, do so from the t end.
0
If an error occurs while using the remote control,
remove the batteries and wait for five minutes. Load
the batteries again and operate the remote control.
When aiming the remote control toward the sensor on this
unit (front or rear), ensure that the distance to the sensor
is within 7 m.
If the remote control fails to work properly, move closer
to this unit.
Control through reflection off a screen, etc.
Ensure that the total of distance A (between this unit and
the screen) and distance B (between the remote control
and the screen) is within 7 m.
* As the efficiency of signals reflected from the remote
control unit varies with the type of screen used, the
operable distance may decrease.
CAUTION
0
Do not put the remote control in a place with an exposure to direct sun light or high temperature. It may deformed
due to heat, or the internal components may be adversely affected resulting in fire hazard.
0
Remove the batteries from the remote control when storing the remote control. Storing the remote control for a
prolonged period without removing the batteries can cause battery leakage.
16
Menu
A B C D E F
Select the icon at the top of the menu to display its corresponding
setting item as shown below.
A
Picture Adjust
B
Input Signal
C
Installation
D
Display Setup
Getting Started
E
Function
F
Information
17
Installing the Projector
Front
150 mm
and above
200 mm
and above
300 mm
and above
300 mm
and above
150 mm and above
Screen
Front
Precautions during Installation
Please read the following carefully before installing this
unit.
When carrying this unit
This unit is heavy in weight. Please ensure that there are
at least two persons carrying it.
Set up
Do not install at the following
This unit is a precision device. Please refrain from
installing or using it at the following locations. Otherwise,
it may cause fire or malfunction.
0
Dusty, wet and humid places
0
Places subject to oily smoke or cigarette smoke
0
On top of a carpet or bedding, or other soft surfaces
0
Places exposed to direct sunlight
0
Places with a high or low temperature
0
Do not install this unit in a room that is oily or subject
to cigarette smoke. Even a small quantity of smoke or
oiliness can have a long-term impact on this unit.
* This unit produces a great amount of heat, and is
designed to take in cool air to cool its optical
components. Using the unit at the above locations
may cause dirt to attach to the light path, thereby
resulting in dark images or dull colors.
* Dirt that sticks to the optical components cannot be
removed.
Maintain clearance from the wall, etc.
As the unit discharges a large amount of heat, install it
with adequate clearance from the surroundings as shown
below.
Leave the front area of the unit unblocked.
If there is any obstructing object in front of the exhaust
vent, hot air will flow back to the unit and cause it to heat
up. Hot air flowing out of the unit may cast shadows on
the screen (heat haze phenomenon).
Installing the screen
Install the unit and the screen such that they are
perpendicular to each other.
Using the projector
There is no particular limitation on the positioning of the
projector during installation.
You can install at your preferred angle.
18
0
Please choose a screen material with non-uniform
patterns. Uniform patterns such as checks may cause
interference patterns to occur.
0
In this case, you can change the size of the screen to
make the interference patterns less noticeable.
Using the projector at a high altitude
When using this unit at a location that is higher than 900
m above sea level (low air pressure), set the “High
Altitude Mode” to “On”. (P. 44)
Precautions during Mounting
C
A
B
D
4 Locations
Securing (mounting) the projector
0
When this unit is to be mounted to a fixed position for
use, install it horizontally.
0
Make sure to secure the main unit to prevent accidents
such as during an earthquake.
Securing with screws
Set up
Remove the four feet at the bottom, and fasten using the
screws (M5 screws, 15 to 25 mm).
* Using screws other than those designated may cause
the unit to break down.
* Do not use 2 adjacent locations (A+B, B+C, C+D)
only.
19
Securing the projector (ceiling mount)
A
Rear
Front
Rear
Front
0
Be sure to ask your dealer to install the unit for you.
Set up
Installing the unit on your own may cause the unit to
fall resulting in injury.
0
Take the necessary actions to prevent the main unit
from falling off such as during an earthquake.
0
Regardless of the warranty period, JVC is not liable for
any product damage caused by mounting the unit with
non-JVC ceiling fittings or to an environment that is not
suited for ceiling mount.
0
When using the unit with it suspended from a ceiling,
pay attention to the surrounding temperature. When a
heater is in use, the temperature around the ceiling
may be higher than expected.
0
To attach the unit to the ceiling mount bracket, set the
torque between the range of 1.5N m to 2.0N m.
Tightening with torque exceeding the above range
may cause damage to the unit, which may result the
unit to fall.
0
When reusing the ceiling mount bracket of an old
model, consult the specialist to check if there are any
issues with the surrounding space and increase in
weight.
0
Install the outlet at an accessible height to unplug from
the wall. Or install the circuit breaker at an accessible
height to shut down the projector. If you need
information, please consult your authorized dealer or
specialist.
Installing the ceiling mounting bracket
A
Remove the rear foot (x2).
0
It is not necessary to remove the front feet.
However, it will not pose any usage problems even
when they are removed.
B
Install the ceiling mounting brackets to the screw holes
indicated by the arrows.
0
Use screws that meet the specification.
0
For details, contact your authorized dealer.
20
Adjusting the Position
Contract
Extend
Feet
4 Locations
Adjusting the elevation angle of the projector
The height and inclination of the unit (0 to 5 mm) can be
adjusted by turning the feet.
Lift the unit and adjust the four feet.
Set up
21
Connecting the Projector
DisplayPort Terminal
This Unit
PC, etc.
DisplayPort Cable (Sold Separately)
To [DisplayPort 1] to [DisplayPort 4]
Input Terminals
Desktop PC, etc.
Server
Hub
Network
Connection Cable
(Sold Separately)
This Unit
To [LAN] Terminal
0
Do not turn on the power until connection is complete.
0
The connection procedures differ according to the device used. For details, please refer to the instruction manual of
the device to be connected.
0
This projector is used for projecting images. To output the audio of connected devices, please connect a separate
audio output device, such as an amplifier or speaker.
0
Some cables cannot be connected to this unit due to the size of their connector cover.
Connecting to the DisplayPort Terminals
Set up
0
For single-channel input signals, connect to one of the [DisplayPort 1], [DisplayPort 2], [DisplayPort 3] or [DisplayPort
4] input terminals.
0
For two-channel input signals, connect to the [DisplayPort 1] and [DisplayPort 3] input terminals.
0
For four-channel input signals, connect to the [DisplayPort 1] to [DisplayPort 4] input terminals.
Æ “Types of Possible Input Signals” (P. 63)
0
Video images may not appear if a cable that does not support HBR2 is used. Use a cable that supports HBR2.
0
When disconnecting the DisplayPort cable, make sure to release the latch and unplug the cable.
Connecting to the LAN Terminal
0
The network is used to control this unit. It is not used for sending or receiving video signals.
0
Please contact your network administrator for information concerning the network connection.
0
For more information on control, please refer to “External Control”P. 56.
22
Loading...
