COMPACT COMPONENT SYSTEM

CA-MXK1R/CA-MXK3R

RM-SMXK1A REMOTE CONTROL

1 2 3

4 5 6

7 8 9

10 +10

FM MODE

CD1CD2CD3CD

PROGRAM

/RANDOM

REPEAT TAPE A/B

/RANDOM

DISPLAY

1 1 SELECT

SOUND

MODE

ACTIVE

VOLUME

BASS EX.

3-CD

STANDBY/ON

SLEEP

AUX

FM /AM

TAPE

MODE

PTY/EON

FADE

MUTING

COMPACT COMPONENT SYSTEM

STANDBY/ON

STANDBY

PHONES

AUX

REPEAT PROGRAM RANDOM

FM/AM

DISPLAY MODE

EJECT

PLAY

PLAY & EXCHANGE

MX-K1R

CANCEL SET

/ DEMO

TUNNIG

TAPE

REC START

/STOP REC START DUBBING

CLOCK

TAPE

/TIMER

A/B

SELECT

PTY / EON

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

1 BIT

DUAL D/A

CONVERTER

PRESET

CD-R/RW PLAYBACK

ACTIVE

BASS EX.

SOUND

REC/PLAY

EJECT

DISC SKIP

CD CONTROL

MODE

CD 2CD

RM-SMXK3A REMOTE CONTROL

1 2 3

4 5 6

7 8 9

10 +10

CD1CD2CD3CD

PROGRAM

REPEAT TAPE A/B

/RANDOM

1 1 SELECT

SOUND MODE

ACTIVE

VOLUME

BASS EX.

STANDBY/ON

SLEEP

AUX

FM /AM

FM MODE

TAPE

DISPLAY

MODE

PTY/EON

FADE

MUTING

COMPACT COMPONENT SYSTEM

STANDBY/ON

STANDBY

PHONES

AUX

REPEAT PROGRAM RANDOM

FM/AM

DISPLAY MODE

PTY / EON

EJECT

PLAY

3-CD

PLAY & EXCHANGE

MX-K3R

CANCEL SET

/ DEMO

REC START

SELECT

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

TUNNIG

TAPE

/STOP REC START DUBBING

CLOCK /TIMER

1 BIT

DUAL D/A

CONVERTER

PRESET

TAPE A/B

CD-R/RW PLAYBACK

ACTIVE

BASS EX.

SOUND MODE

DISC SKIP

CD CONTROL

CD 2CD

EJECT

REC/PLAY

CA-MXK3RCA-MXK1R

INSTRUCTIONS

For Customer Use:

Enter below the Model No. and Serial No. which are located either on the rear, bottom or side of the cabinet. Retain this information for future reference.

Model No. Serial No.

LVT0686-009B

[B]

Warnings, Cautions and Others

15 cm

IMPORTANT for the U.K. DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a p ower point, then obtain an appropriat e safety approved extension lead or consult your dealer.

BE SURE to replace the fuse only with an identical approved type, as originally fitted.

If nontheless the mains plug is cut off ensure to remove the fuse and dispose of the plug immediately, to avoid a possible shock hazard by inadvertent connection to the mains supply.

If this product is not supplied fitted with a mains plug then follow the instructions given below:

IMPORTANT: DO NOT make any connection to the terminal which is marked with

the letter E or by the safety earth symbol or coloured green or green-and-yellow.

The wires in the mains lead on this product are coloured in accordance with the following code:

Blue : Neutral Brown : Live

As these colours may not correspond with the coloured markings identifying the terminals in your plug proceed as follows:

The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.

Caution — switch!

Disconnect the mains plug to shut the power off completely. The switch in any position does not disconnect the mains line. The power can be remote controlled.

Caution: Proper Ventilation

To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows: 1 Front: No obstructions and open spacing. 2 Sides/ Top/ Back: No obstructions should be placed in the areas

shown by the dimensions below.

3 Bottom: Place on the level surface. Maintain an ade-

quate air path for ventilation by placing on a stand with a height of 10 cm or more.

IMPORTANT FOR LASER PRODUCTS

REPRODUCTION OF LABELS

1 CLASSIFICATION LABEL, PLACED ON EXTERIOR SURFACE

2 WARNING LABEL, PLACED INSIDE THE UNIT

1 CLASS 1 LASER PRODUCT 2 CAUTION: Invisible laser radiation when open and interlock failed

or defeated. Avoid direct exposure to beam.

CAUTION:

parts inside the Unit; leave all servicing to qualified service personnel.

SAFETY PRECAUTIONS

Prevention of Electric Shocks, Fire Hazards and Damage 1 Do not use this apparatus in a bathroom or places with water.

Also do not place any containers filled with water or liquids (such as cosmetics or medicines, flower vases, potted plants, cups, etc.) on top of this apparatus.

2 Do not block the ventilation opcnings or holes. (If the ventilation

openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

3 Do not place any naked flame sources, such as lighted candles, on

the apparatus.

4 When discarding batteries, environmental problems must be con-

sidered and local rules or laws governing the disposal of these batteries must be followed strictly.

Do not open the top cover. There are no user serviceable

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1 Do not remove screws, covers or cabinet. 2 Do not expose this appliance to rain or moisture.

Front view

15 cm

3-CD

PLAY & EXCHANGE

1 BIT

DUAL D/A CONVERTER

PRESET

CANCEL SET

/ DEMO

TUNING

TAPE

REC START

/STOP REC STARTDUBBING

CLOCK

TAPE

/TIMER

A/B

SELECT

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

CD-R/RW PLAYBACK

ACTIVE

BASS EX.

SOUND MODE

DISC SKIP

1 cm1 cm

CD CONTROL

CD 2CD

EJECT

REC/PLAY

15 cm

STANDBY

PHONES

COMPACT COMPONENT SYSTEM

STANDBY/ON

AUX

REPEAT PROGRAMRANDOM

FM/AM

DISPLAY

PTY / EON

MODE

EJECT

PLAY

Side view

15 cm

10 cm

G-1

SAFETY INSTRUCTIONS

“SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT”

This equipment has been disigned and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.

✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮

Do read the operating instructions before you attempt to use the equipment. Do ensure that all electrical connections (including the mains plug, extension leads and interconnections between pieces of

equipment) are properly made and in accordance with the manufacturer’s instr uctions. Switch off and withdraw the mains plug when making or changing connections.

Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment. Do be careful with glass panels or doors on equipment.

✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮

DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way–switch off, withdraw the mains plug and consult your dealer.

DON’T remove any fixed cover as this may expose dangerous voltages. DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended opera-

tion or has a standby mode. Switch off using the switch on the equipment and make sure that your family know how to do this.

Special arrangements may need to be made for infirm or handicapped people. DON’T use equipment such as personal stereos or radios so that you are distracted from the requirements of traffic safety. It is

illegal to watch television whilst driving. DON’T listen to headphones at high volume as such use can permanently damage your hearing. DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings. Overheating will cause damage and shorten the life of the equipment. DON’T use makeshift stands and NEVER fix legs with wood screws — to ensure complete safety always fit the manufacturer’s

approved stand or legs with the fixings provided according to the instructions. DON’T allow electrical equipment to be exposed to rain or moisture. ABOVE ALL

— NEVER let anyone, especially children, push anything into holes, slots or any other opening in the case -this could result

in a fatal electrical shock.;

— NEVER guess or take chances with electrical equipment of any kind — it is better to be safe than sorry!

G-2

Introduction

Thank you for purchasing the JVC Compact Component System. We hope it will be a valued addition to your home, giving you years of enjoyment.

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Be sure to read this instruction manual carefully before operating your new stereo system. In it you will find all the information you need to set up and use the system. If you have a query that is not answered by the manual, please contact your dealer.

Features

Here are some of the things that make your System both powerful and simple to use. ❏The controls and operations have been redesigned to make them very easy to use, freeing you to just enjoy the

music.

• With JVC’s COMPU PLAY you can turn on the System and automatically start the Radio, Cassette Deck, or CD Player with a single touch.

❏The great SEA (Sound Effect Amplifier) effects Rock, Pop and Classics are provided. ❏The Active Bass EX. (Extension) circuitry faithfully reproduces low frequency sounds. ❏A 45-station preset capability (30 FM and 15 AM (MW/LW)) in addition to auto-seek and manual tuning. ❏CD changer function can operate 3 discs.

• Discs can be changed during play using the Carrousel tray (rotational tray).

• Continuous, random or program play of 3 discs.

❏Two Decks enabling tape dubbing. ❏Timer functions; Daily Timer, REC (Recording) Timer, and Sleep Timer. ❏You can connect various external units, such as an MD recorder.

How This Manual Is Organized

• Basic information that is the same for many different functions - e.g. setting the volume - is given in the section “Basic Operations”, and not repeated under each function.

• The names of buttons/controls and display messages are written in all capital letters: e.g. FM/AM, “NO DISC”.

• If the button names on the Unit and the Remote Control are the same, the description on where the button is used will be omitted.

• System functions are written with an initial capital letter only: e.g. Normal Play.

Use the table of contents to look up specific information you require. We have enjoyed making this manual for you, and hope it serves you in enjoying the many features built into your System.

IMPORTANT CAUTIONS

Installation of the System

• Select a place which is level, dry and neither too hot nor too cold. (Between 5°C and 35°C or 41°F and 95°F.)

• Leave sufficient distance between the System and a TV.

• Do not use the System in a place subject to vibrations.

Power cord

• Do not handle the power cord with wet hands!

• Some power is always consumed as long as the power cord is connected to the wall outlet.

• When unplugging the System from the wall outlet, always pull the plug, not the power cord.

Malfunctions, etc.

• There are no user serviceable parts inside. In case of system failure, unplug the power cord and consult your dealer.

• Do not insert any metallic object into the System.

Introduction ...................................................................................................................1

Features.................................................................................................................................................... 1

How This Manual Is Organized...............................................................................................................1

IMPORTANT CAUTIONS.....................................................................................................................1

Table of Contents..........................................................................................................2

Getting Started ..............................................................................................................3

Accessories..............................................................................................................................................3

How To Put Batteries In the Remote Control.......................................................................................... 3

Using the Remote Control....... .................................. .................................. ............................................3

Connecting the FM Antenna....................................................................................................................4

Connecting the AM (MW/LW) Antenna................................................................................................. 5

Connecting the Speakers .........................................................................................................................5

Connecting External Equipment..............................................................................................................6

Connecting to the Wall Outlet.................................................................................................................6

DEMO Mode........................................................................................................................................... 6

COMPU Play...........................................................................................................................................6

Basic Operations...........................................................................................................7

Turning the Power On and Off................................................................................................................7

ECO Mode (ECO)...................................................................................................................................7

Adjusting the Volume..............................................................................................................................7

Fade-out Muting (FADE MUTING).......................................................................................................8

Reinforcing the Bass Sound (ACTIVE BASS EX.)................................................................................8

Selecting the Sound Mode (SOUND MODE)......................................................................................... 8

Entering the Number with the Remote Control (Numeric Keys)............................................................8

Using the Tuner.............................................................................................................9

Tuning In a Station..................................................................................................................................9

Presetting Stations .................................................................................................................................10

To Change the FM Reception Mode.....................................................................................................10

Receiving FM Stations with RDS ......................................................................................................... 11

Using the CD Player....................................................................................................14

To Load CDs ............................................ .................................. ................................. ..........................15

To Unload CDs................................ .................................. .................................. ..................................15

Basics of Using the CD Player-Normal Play......................................................................................... 16

Programming the Playing Order of the Tracks...................................................................................... 17

Random Play..........................................................................................................................................18

Repeating Tracks...................................................................................................................................18

Tray Lock Function...............................................................................................................................18

Using the Cassette Deck (Listening to a Tape) ........................................................19

Playing a Tape.......................................................................................................................................19

Using the Cassette Deck (Recording) ......................................................................20

Standard Recording ..................................... ................................. .................................. .......................21

CD Synchro Recording.......................................................................................................................... 21

Tape to Tape Recording (DUBBING)................................................................................................... 21

Using an External Equipment ....................................................................................22

Listening to the External Equipment..................................................................................................... 22

Using the Timers .........................................................................................................23

Setting the Clock ...................................................................................................................................23

Setting the Daily Timer ......................................................................................................................... 24

Setting the REC (Recording) Timer......................................................................................................25

Setting the SLEEP Timer ...................................................................................................................... 27

Timer Priority...................................................... .................................. ... .............................................27

Care And Maintenance................................................................................................28

Troubleshooting...........................................................................................Back cover

Specifications...............................................................................................Back cover

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Getting Started

Accessories

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Make sure that you have all of the following items, which are supplied with the System.

AM (MW/LW) Loop Antenna (1) Remote Control (1) Batteries (2) FM Wire Antenna (1)

If any of these items are missing, contact your dealer immediately.

How To Put Batteries In the Remote Control

Match the polarity (+ and –) on the batteries with the + and – markings in the battery compartment.

R6P(SUM-3)/AA(15F)

CAUTION:

• Handle batteries properly.

❏To avoid battery leakage or explosion:

• Remove batteries when the Remote Control will not be used for a long time.

• When you need to replace the batteries, replace both batteries at the same time with new ones.

• Do not use an old battery with a new one.

• Do not use different types of batteries together.

Using the Remote Control

The Remote Control makes it easy to use many of the functions of the System from a distance of up to 7m (23 feet) away. You need to point the Remote Control at the remote sensor on the System’s front panel.

3-CD

Remote sensor

COMPACT COMPONENT SYSTEM

STANDBY/ON

STANDBY

PHONES

AUX

REPEAT PROGRAM RANDOM

DISPLAY

MODE

FM/AM

PTY / EON

CANCEL SET

/ DEMO

REC START

SELECT

PLAY & EXCHANGE

TUNING

TAPE

/STOP REC START DUBBING

CLOCK /TIMER

1 BIT

DUAL D/A CONVERTER

PRESET

TAPE A/B

ACTIVE

BASS EX.

CD-R/RW PLAYBACK

SOUND MODE

DISC SKIP

CD CONTROL

CD 2CD

EJECT

PLAY

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

REC/PLAY

EJECT

CAUTION:

• Make all connections before plugging the System into an AC power outlet.

Connecting the FM Antenna

Using the Supplied Wire Antenna

AUX IN ANTENNA

CAUTION:

SPEAKER IMPEDANCE 6 16 OHMS.

SPEAKERS

LEFT

RIGHT

EXT

LEFT

FM75 COAXIAL

LOOP

RIGHT

GND

FM wire antenna (supplied)

Getting Started

Using the Coaxial Type Connector (Not supplied)

A 75-ohm antenna with coaxial type connector (IEC or DIN45 325) should be connected to the FM 75-ohm COAXIAL terminal.

If reception is poor, connect the outdoor antenna.

FM outdoor antenna

(Not supplied)

Coaxial cable

• Before attaching a 75 ohm coaxial lead (the kind with a round wire going to an outdoor antenna), disconnect the supplied FM Wire Antenna

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Getting Started

Connecting the AM (MW/LW) Antenna

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Rear Panel of the Unit

AM (MW/LW) loop antenna (Supplied)

ANTENNA

AUX IN ANTENNA

CAUTION:

SPEAKER IMPEDANCE 6 16 OHMS.

SPEAKERS

LEFT

RIGHT

EXT

LEFT

FM75

COAXIAL

AM LOOP

RIGHT

GND

• Even when connecting an outside AM (MW/LW) antenna, keep the indoor AM (MW/LW) loop connected.

LOOP

GND

EXT

FM 75

COAXIAL

AM (MW/LW) antenna wire (not supplied) If reception is poor, connect the outside antenna.

Turn the loop until you have the best reception.

Attach the AM (MW/LW) loop to its base by snapping the tabs on the loop into the slot in the base.

CAUTION:

• To avoid noise, keep antennas away from the System, the connecting cord and the AC power cord.

Connecting the Speakers

1. Open each of the terminals to connect the speaker wire leads.

2. Connect the speaker cords to the Speaker terminals of the Unit. Connect the red (+) and black (–) wires of the right side speaker to the red (+) and black (–) terminals marked RIGHT on the System. Connect the red (+) and black (–) wires of the left side speaker to the red (+) and black (–) terminals marked LEFT on the System.

3. Close each of the terminals to securely connect the cords.

Right side (rear view) Left side (rear view)

Red

Black

CAUTION:

SPEAKER IMPEDANCE 6 16 OHMS.

SPEAKERS

RIGHT

LEFT

Red

Black

CAUTIONS:

• A TV may display irregular colors if located near the speakers. If this happens, set the speakers away from the TV.

• Use speakers with the correct impedance only. The correct impedance is indicated on the rear panel.

Getting Started

Connecting External Equipment

Connect a signal cord (not supplied) between the System’s AUX-IN terminals and the output terminals of the external MD recorder, tape deck, etc. You can then listen to the external source through the System.

AUX IN

LEFT

Signal cord (not supplied)

MD recorder, tape deck, etc. (not supplied)

RIGHT

Pin-plug x 2Pin-plug x 2

Connecting to the Wall Outlet

Plug the AC power cord into the wall outlet. Now, your System is at your command!

DEMO Mode

When the System is connected to the wall outlet, a DEMO mode displaying some of the system’s features automatically starts.

To turn the DEMO display off, To turn the DEMO display on,

• The DEMO display will automatically turn on again if no button operation is made for 2 minutes. To cancel this auto DEMO display function, press the CANCEL button on the Unit during DEMO display.

press any of the operation buttons. The DEMO display automatically stops. press the DEMO button on the Unit for more than 2 seconds.

CANCEL

/ DEMO

(For 2 seconds)

COMPU Play

JVC’s COMPU PLAY feature lets you control the most frequently used System functions with a single touch. With One Touch Operation you can play a CD, a tape, turn on the radio, or listen to an external equipment with a single press of the play button for that function. One Touch Operation turns the power on for you, then starts the function you have specified. If the System is not ready (no CD or tape in place), the System still powers on so you can insert a CD or tape. How One Touch Operation works in each case is explained in the section dealing with that function. The COMPU PLAY buttons are:

On the Unit

CD 6 button FM/AM button TAPE 3 button AUX button CD1, CD2 and CD 3 buttons CD Open/Close 0 button

On the Remote Control

CD 6 button FM/AM button TAPE 3 button AUX button CD1, CD2 and CD 3 buttons

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Basic Operations

CAUTION:

)

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Numeric keys

SOUND MODE

ACTIVE BASS EX.

REMOTE CONTROL

1 2 3

4 5 6

7 8 9

10 +10

FM MODE

CD1CD2CD3CD

PROGRAM

REPEAT TAPE A/B

/RANDOM

DISPLAY

MODE

1 1 SELECT

SOUND MODE

ACTIVE

VOLUME

BASS EX.

STANDBY/ON

SLEEP

AUX

FM /AM

TAPE

PTY/EON

FADE

MUTING

3-CD

PLAY & EXCHANGE

Display

STANDBY indicator

ECO

PHONES

VOLUME +,–

FADE MUTING

COMPACT COMPONENT SYSTEM

STANDBY/ON

STANDBY

PHONES

AUX

REPEAT PROGRAM RANDOM

EJECT

PLAY

CANCEL SET

/ DEMO

TUNING

TAPE

FM/AM

REC START

/STOP REC START DUBBING

DISPLAY

MODE

PTY / EON

CLOCK /TIMER

SELECT

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

1 BIT

DUAL D/A CONVERTER

PRESET

TAPE

A/B

Various information

BASS

S.MODE

Level bar

Status bar (Indicates various statuses.)

* When the System is in use, the display shows other items as well.

For simplicity, we show here only the items described in this section.

CD-R/RW PLAYBACK

ACTIVE

BASS EX.

REC/PLAY

EJECT

SOUND MODE

DISC SKIP

CD CONTROL

CD 2CD

ACTIVE BASS EX.

SOUND MODE

VOLUME

BASS indicator Sound Mode indicator

Turning the Power On and Off

Turning the System On

Press the

The display comes on and “WELCOME” is displayed once. The STANDBY indicator goes out. The System comes on ready to continue in the mode it was in when the power was last turned off.

• For example, if the last thing you were doing was listening to a CD, you are now ready to listen to a CD again. If you wish, you can change to another source.

• If you were listening to the Tuner last, the Tuner comes on playing the station it was last set to.

Turning the System Off

Press the % button again.

“GOOD BYE” is displayed and the display goes out, except for the clock display. The STANDBY indicator lights up. (The display is dimmed.)

• Some power is always consumed even though power is turned off (called Standby mode).

• To switch off the System completely, unplug the AC power cord from the wall outlet. When you unplug the AC power cord, the clock will be reset to 0:00 immediately.

STANDBY

button.

STANDBY/ON

ECO Mode (ECO)

The System has three energy modes; power on, power off (Standby) and ECO. In ECO mode, the display goes off and the least power is consumed.

To enter ECO mode,

press the ECO button on the Unit in Standby mode (while the STANDBY indicator lights up). “ECO MODE” appears on the display, then the display goes off. The STANDBY indicator remains lit.

To cancel ECO mode and turn on the power,

press the

button for a second.

To cancel ECO mode and enter Standby mode,

press the

ECO button again for a second.

Adjusting the Volume

Turn the VOLUME control on the Unit clockwise to increase the volume or turn it counterclockwise to decrease the volume. Press the VOLUME + button on the Remote Control to increase the volume or press the VOLUME – button to decrease the volume.

You can set the volume level to MIN, 1-31, or MAX.

• DO NOT turn on the System and/or start playing

any source without first setting the VOLUME control to minimum, as a sudden blast of sound could damage your hearing, speakers and/or headphones.

Basic Operations

For private listening

Connect a pair of headphones to the PHONES jack. No sound comes out of the speakers. Be sure to turn down the volume before connecting or putting on headphones.

Fade-out Muting (FADE MUTING)

You can mute the output with one touch operation.

To mute the output

Remote Control. The output is faded out.

To release muting

again. The output is faded in to the previous level.

• After Fade-out Muting, turning the VOLUME control on the unit or pressing the VOLUME button on the Remote Control will increase the volume from MIN. setting.

, press the FADE MUTING button on the

, press the FADE MUTING button once

Reinforcing the Bass Sound (ACTIVE BASS EX.)

The richness and fullness of the bass sound is maintained regardless of how low you set the volume. You can use this effect only for playback.

To get the effect

button. The “BASS” indicator lights up and “ACTIVE BASS EXTENSION” appears on the display.

To cancel the effect

The “BASS” indicator goes out and “OFF” appears on the display.

, press the ACTIVE BASS EX. (Extension)

, press the button again.

Selecting the Sound Mode (SOUND MODE)

You can select one of 3 SEA (Sound Effect Amplifier) modes. You can use this effect only for playback.

On the Unit

To get the effect

POP, or CLASSIC. The selected Sound Mode name “ROCK”, “POP”, or “CLASSIC” appears on the display. The “S.MODE” indicator also lights up on the display.

To cancel the effect

again. When the effect is canceled, the “S.MODE” indicator goes out. For example, if the current Sound Mode is ROCK, press the ROCK button again. “FLAT” appears on the display, showing that no sound effect is applied.

ROCK POP

CLASSIC FLAT

On the Remote Control

Press the SOUND MODE button until Sound Mode you want appears on the display. The “S.MODE” indicator lights up on the display. Each time you press the button, the Sound Mode changes as follows:

ROCK = POP = CLASSIC = FLAT = (back to the beginning)

To cancel the effect,

“FLAT” appears on the display. The “S.MODE” indicator goes out.

, press one of the Sound Mode buttons, ROCK,

, press the currently selected mode button

Boosts low and high frequencies. Good for acoustic music. Good for vocal music. Set for wide and dynamic sound stereo systems. No sound effect applies.

press the SOUND MODE button until

Entering the Number with the Remote Control (Numeric Keys)

You will use the number keys on the Remote Control to enter numbers for presetting stations, recalling the preset stations, or programming the playing tracks on CDs. How to enter the number with the number keys is explained here.

Examples:

• To enter number 5, press 5.

• To enter number 15, press +10, then 5.

• To enter number 20, press +10, then 10.

• To enter number 25, press +10, +10, then 5.

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Using the Tuner

(After 2 seconds)

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

REMOTE CONTROL

1 2 3

4 5 6

7 8 9

10 +10

FM MODE

CD1CD2CD3CD

PROGRAM

REPEAT TAPE A/B

/RANDOM

DISPLAY

MODE

1 1 SELECT

SOUND MODE

ACTIVE

VOLUME

BASS EX.

STANDBY/ON

SLEEP

AUX

FM /AM

TAPE

PTY/EON

FADE

MUTING

Numeric keys

FM/AM FM MODE

DISPLY MODE

PTY/EON

SELECT +, –

Band display, Frequency display, Preset channel

RDS indications

SET

FM/AM

22 ¡

RDS EON MONO

TANEWS INFO

COMPACT COMPONENT SYSTEM

STANDBY/ON

STANDBY

PHONES

CANCEL SET

/ DEMO

AUX

FM/AM

REPEAT PROGRAM RANDOM

DISPLAY

MODE

SELECT

PTY / EON

EJECT

PLAY

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

FM mode indicators

PLAY & EXCHANGE

TUNING

TAPE

REC START

/STOP REC START DUBBING

kHz MHz

3-CD

1 BIT

DUAL D/A CONVERTER

PRESET

CLOCK

TAPE

/TIMER

A/B

ACTIVE

BASS EX.

EJECT

REC/PLAY

CD-R/RW PLAYBACK

SOUND MODE

DISC SKIP

CD CONTROL

CD 2CD

* When the System is in use, the display shows other items as well.

For simplicity, we show here only the items described in this section.

You can listen to FM and AM (MW/LW) stations. Stations can be tuned in manually, automatically, or from preset memory storage.

❏Before listening to the radio:

• Make sure that both the FM and AM (MW/LW) antennas are correctly connected. (See pages 4 and 5).

One Touch Radio

Just press the FM/AM button to turn on the System and start playing the station you were last tuned to.

❏You can switch from any other sound source to the radio by

pressing the FM/AM button.

Tuning In a Station

Press the FM/AM button.

The Band and Frequency you were last tuned to appear on the display. (If the last station was selected using the preset number, the preset number appears first.) Each time you press the button, the band alternates between FM and AM (MW/LW).

FM /AM

FM/AM

(on the Unit)

Select a station using one of the following

methods.

(on the Remote Control)

• Manual Tuning

Briefly press the 22 or ¡ button on the Unit to move from frequency to frequency until you find the station you want.

• Auto Tuning

If you hold down the 22 or ¡ button on the Unit for 0.5 second or more and then release it, the frequency changes down, or up, automatically until a station is found.

• Preset Tuning (Possible only after presetting stations) Preset tuning using the Unit:

Select the preset number you want, using the 4 or ¢ button.

Example:

Press the ¢ button until the preset number “P-12” appears on the display. After 2 seconds, the display will show the preset number’s band and frequency.

PRESET

kHz MHz

Preset tuning using the Remote Control:

Enter the preset number you want to recall using the numeric keys. See “Entering the Number with the Remote Control” on page 8.

Example:

Press +10, then 2 to recall the preset number 12. After 2 seconds, the display will show the preset number’s band and frequency.

Using the Tuner

CAUTION:

•In AM (MW/LW) broadcast, reception sensitivity will be

changed by turning the AM loop antenna. Turn the AM (MW/LW) loop antenna for best reception.

Presetting Stations

You can preset up to 30 FM stations and up to 15 AM (MW/LW) stations.

• Preset numbers may have been set to factory test frequencies prior to shipment. This is not a malfunction. You can preset the stations you want into memory by following one of the presetting methods below.

• During presetting stations, if no button operation is made for 5 seconds, the display returns to the band/frequency display. In this case, repeat steps from the beginning.

TUNING

FM/AM

When changing the Band

SET SET

FM=30, AM=15

• Even if the System is unplugged or if the power failure occurs, the preset stations will be stored for a few days. However, in case the preset stations are erased, you will need to preset the stations again.

To Change the FM Reception Mode

When you are tuned in to an FM stereo broadcast, the “ST (Stereo)” indicator lights up and you can hear stereo effects. If an FM stereo broadcast is hard to receive or noisy, you can select Monaural mode. Reception improves, but you lose stereo effect.

Press the FM MODE button on the Remote Control so that the “MONO” indicator lights up on the display.

FM MODE

ST MONO

To restore the stereo effect

the Remote Control so that the “MONO” indicator goes off.

, press the FM MODE button on

Using the Unit

Select a band by pressing the FM/AM button.

Press the

station. Press the SET button.

“SET” will blink for 5 seconds.

Press the

preset number.

: Increases the preset number by 1.

: Decreases the preset number by 1.

Press the SET button.

“STORED” appears and, after 2 seconds, the display returns to the band/frequency display.

Repeat above steps 1 to 5 for each station

you want to store in memory with a preset number.

To change the preset stations

above.

• In step 4, you can select the preset number using the numeric keys on the Remote Control. See “Entering the Number with the Remote Control” on page 8.

button to tune in a

button to select the

, repeat the same steps as

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Using the Tuner

Receiving FM Stations with

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

RDS

You can use the RDS (Radio Data System) by using the buttons on the Unit or the Remote Control. RDS allows FM stations to send additional signals with their regular program signals. For example, the stations send their station names, and information about what type of program they broadcast, such as sports or music, etc. This unit can receive the following types of RDS signals:

PS (Program Service):

shows commonly known station names.

PTY (Program Type):

shows types of broadcast program.

RT (Radio Text):

shows text messages the station sends.

What information can RDS signals provide?

The display shows RDS signal information that the station sends.

To show the RDS signals on the display

Press the DISPLAY MODE button while listening to an FM station.

Each time you press the button, the display changes to show information in the following order:

DISPLAY

MODE

or PS PTY RT Frequency

PS (Program Service):

While searching, “PS” alternately appear on the display. Then, the RDS indicator lights up and the station name appears. “NO PS” appears if no signal is sent.

PTY (Program Type):

While searching, “PTY” alternately appear on the display. Then, the RDS indicator lights up and the broadcast program type appears. “NO PTY” appears if no signal is sent.

RT (Radio Text):

While searching, “RT” alternately appear on the displa y. Then, the RDS indicator lights up and a text message sent by the station appears. “NO RT” appears if no signal is sent.

Station Frequency:

Station frequency (non-RDS service)

• If searching finishes at once, “PS”, “PTY” and “RT” will not appear on the display.

• If you press the DISPLAY MODE button while listening to an AM (MW/LW) station, the display only shows station frequency.

• RDS is not available for AM (MW/LW) broadcasts.

On characters displayed

When the display shows PS, PTY or RT signals:

• The display shows upper case letters only.

• The display cannot show accented letters; For example, “A” may represent accented “A’s” like “Á, Â, Ã, À, Ä and Å”.

[Example of characters displayed]

Using the Tuner

To search for a program by PTY codes

One of the advantages of the RDS service is that you can locate a particular kind of program by specifying the PTY codes.

To search for a program using PTY codes:

On the Unit

PTY / EON PTY / EON

On the Remote Control

PTY/EON PTY/EON

Press the PTY/EON button once while listen-

ing to an FM station.

“PTY” and “SELECT” alternately appear on the display.

Select the PTY code using the SELECT + or –

button within 10 seconds.

Each time you press the button, the display shows a category in the following order:

NEWS

↔↔↔↔

POP M SICS CHILDREN

↔↔↔↔

TIONAL NEWS

↔↔↔↔

DRAMA

↔↔↔↔

OTHER M

TRAVEL

SELECT

AFFAIRS

↔↔↔↔

CULTURE

ROCK M

↔↔↔↔

SOCIAL A

↔↔↔↔

LEISURE

↔↔↔↔

OLDIES

↔↔↔↔

INFO

↔↔↔↔

M.O.R. M

↔↔↔↔

WEATHER

↔↔↔↔

JAZZ

↔↔↔↔

FOLK M

↔↔↔↔

SPORT

SCIENCE

↔↔↔↔

LIGHT M

↔↔↔↔

RELIGION

↔↔↔↔

COUNTRY

↔↔↔↔

DOCUMENT

↔↔↔↔

EDUCATE

↔↔↔↔

VARIED

↔↔↔↔

CLAS-

FINANCE

↔↔↔↔

PHONE IN

↔↔↔↔

NA-

↔↔↔↔ ↔↔↔↔

↔↔↔↔

CHILDREN: SOCIAL: RELIGION:

PHONE IN: TRAVEL: LEISURE: JAZZ M:

COUNTRY: NATION M:

OLDIES: FOLK M: DOCUMENT:

Entertainment programs for children Programs on social activities Programs dealing with any aspect of belief or faith, or the nature of existence or ethics Programs where people can express their views either by phone or in a public form Programs about travel destinations, package tours, and travel ideas and opportunities Programs concerned with recreational activities such as gardening, cooking, fishing, etc. Jazz music Country music Current popular music from another nation region, in that country’s language Classic pop music Folk music Programs dealing with factual matters, presented in an investigative style

Press the PTY/EON button within 10 seconds

again.

While searching, “SEARCH” and the sele cted PTY code alternately appear on the display. The unit searches 30 preset stations and stops when it finds a station of the category you have selected, then tunes into that station.

To continue searching after the first stop,

press the PTY/EON button again while the display indications blink. If no program is found, “NOT” and “FOUND” alternately appear on the display.

To stop searching at any time during the process,

press the PTY/EON button to stop search operation.

Descriptions of the PTY Codes NEWS:

AFFAIRS: INFO: SPORT:

EDUCATE: DRAMA: CULTURE: SCIENCE: VARIED: POP M: ROCK M: M.O.R M:

LIGHT M: CLASSICS: OTHER M: WEATHER: FINANCE:

News Topical programs expanding on the current news or affairs Programs on medical service, weather forecasts, etc. Sports events Educational programs Radio plays Programs on national or regional culture Programs on natural sciences and technology Other programs like comedies or ceremonies Pop music Rock music Middle-of-the road music (usually called “easy listening”) Light music Classical music Other music Weather information Reports on commerce, trading, the Stock Market, etc.

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Using the Tuner

CAUTION:

To temporarily switch to a broadcast program of your choice

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

EON (Enhanced Other Networks) is another convenient RDS service that allows this unit to switch temporarily to a broadcast program of your choice (NEWS, TA or INFO) from the currently selected station, except if you are listening to a non-RDS station (all AM (MW/LW) stations or some FM stations).

• The EON function is only applicable to the preset stations. See page 10.

• If an FM station does not broadcast EON information, EON cannot be activated.

To select a program type

On the Unit

PTY / EON PTY / EON

(twice)

On the Remote Control

PTY/EON PTY/EON

(twice)

Press the PTY/EON button twice while listen-

ing to an FM station.

“EON” and “SELECT” alternately appear on the display.

Select the program type using the SELECT +

or – button within 10 seconds.

The display shows a program type in the following order:

TA NEWS INFO OFF

TA: Traffic Announcement NEWS: News INFO: Programs on medical service, weather forecast, etc. OFF: EON off

SELECT

To stop listening to the program selected by EON

Press the PTY/EON button so that the program type (TA, NEWS or INFO) indicator goes off.

• In EON standby mode, if you change the source or turn off the power, EON standby mode is canceled temporarily.

• When the EON is being operated (i.e. the selected program type is being received from the broadcast station) and if the DISPLAY MODE or SELECT button is operated, the station will not switch back to the current selected station even after the program ends. The program type indicator remains in the display, indicating that the EON is in standby mode.

• When the EON is in standby mode and a radio broadcast is being recorded, be careful because the EON may be activated and a different program than the intended one may be recorded. When the EON mode is not required, release the EON mode.

• When the alarm signal is detected by EON, the station broadcasting alarm is received with priority. “ALARM!” is not displayed.

• When the sound alternated intermittently between the station tuned in by the EON function and the current selected station, canc el the EON mode. This does not constitute malfunction of the unit.

Press the PTY/EON button within 10 seconds

again to set the selected program type.

The selected program type indicator lights up on the display, and the unit enters EON Standby mode.

• The EON indicator lights up when tuned to a station which provides EON information.

Case 1: If there is no station broadcasting the type of

program you have selected

The broadcast station being currently heard will continue to be heard.

When a station starts broadcasting the program you have selected, this unit automatically switches to the station. The program type (TA, NEWS or INFO) indicator starts blinking.

When the program is over, this unit goes back to the currently selected station, but still remains in EON Standby mode.

Case 2: If there is a station broadcasting the type of pro-

gram you have selected

This unit tunes to the station broadcasting the program. The program type (TA, NEWS or INFO) indicator starts blinking.

When the program is over, this unit goes back to the currently selected station, but still remains in EON Standby mode.

Using the CD Player

)

Numeric keys

CD1-CD3 PROGRAM /RANDOM

REMOTE CONTROL

1 2 3

4 5 6

7 8 9

10 +10

FM MODE

CD1CD2CD3CD

PROGRAM

REPEAT TAPE A/B

/RANDOM

DISPLAY

MODE

1 1 SELECT

SOUND

MODE

ACTIVE

VOLUME

BASS EX.

STANDBY/ON

SLEEP

AUX

FM /AM

TAPE

PTY/EON

FADE

MUTING

CD 6

REPEAT

SET

CANCEL

STANDBY

CD 6

PHONES

22 ¡

Track number, Playing time, Program number, etc.

RANDOM ALL 1CD

Play mode indicator

COMPACT COMPONENT SYSTEM

STANDBY/ON

AUX

FM/AM

REPEAT PROGRAM RANDOM

DISPLAY MODE

PTY / EON

EJECT

PLAY

PRGMREPEAT

Repeat indicator

3-CD

PLAY & EXCHANGE

1 BIT

DUAL D/A CONVERTER

PRESET

CANCEL SET

/ DEMO

TUNING

TAPE

REC START

/STOP REC START DUBBING

SELECT

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

CLOCK

TAPE

/TIMER

A/B

Disc indicators

1 2 3

ACTIVE

BASS EX.

EJECT

REC/PLAY

CD-R/RW PLAYBACK

SOUND MODE

DISC SKIP

CD CONTROL

CD 2CD

7 4 ¢

DISC SKIP CD Open/

Close 0

CD1-CD3

* When the System is in use, the display shows other items as well.

For simplicity, we show here only the items described in this section.

The CD Player has the rotational disc tray that can accommodate 3 CDs. You can use Normal, Program, Random, or Repeat Play.

Normal Play:

Can continuously play all the tracks on all the CDs.

Program Play:

Can play all the programmed tracks on all the CDs in the programmed order.

Random Play:

Can play all the tracks on all the CDs in random order.

Repeat Play:

Can repeat all the tracks on all the CDs, the tracks on one of the CDs, or just one of tracks on one CD.

Here are the basic things you need to know to play CDs and locate the different tracks on them.

About the Disc Indicator

Disc Number indicator

Selected Disc indicator

Disc Rotation indicator

The Disc indicator consists of the following three kinds of indicators:

Disc Number indicator: Selected Disc indicator:

Lights all the time. Lights for the currently selected

disc number.

Disc Rotation indicator:

Runs when the selected CD is playing or paused. This indicator goes out if a CD is not loaded for the selected disc number. Once the tray is ejected, the Disc Rotation indicators for all disc numbers are lit. However, when the empty disc number is selected, the Disc Rotation indicator for the disc number goes out.

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Using the CD Player

Example of indication:

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

When CD door has ejected once and then CD-1 is pressed. (DISC1 is selected)

Shows that this disc number is selected.

1 2 3

Shows that the disc is rotating.

One Touch Play

The power comes on, and operations are done automatically. ❏By pressing the CD 6 button, the System will come on, and if

a CD is loaded for the disc number that was lastly selected, it will start playing from the first track.

❏By pressing the CD1 -CD3 button, the System will come on, and

if a CD is already loaded for the selected disc number, it will start play from the first track.

• If no CD is loaded for the selected disc number, the next disc

number will be automatically selected.

To Load CDs

❏When you use an 8 cm (3'') CD, place it on the inner circle of the

tray.

❏You can load CDs while listening to the other source. ❏When power is turned off with the tray opened, the tray is auto-

matically closed.

❏If the CD cannot be read correctly (because it is scratched, for

example), “ 0 0:00” appears on the display.

To Unload CDs

Take out the CD as shown below.

While the CD Player is stopped, press the CD

Open/Close tray.

Remove the CD, then press the DISC SKIP

button on the Unit.

The tray turns for the next CD.

Repeat step 2 to remove all the CDs.

Press the CD Open/Close 0 button on the

Unit to close the tray.

❏You can remove CDs while listening to the other source.

button on the Unit to open the

Press the CD Open/Close 0 button on the

Unit to open the tray. Place a CD, with its label side up, onto the

tray.

Be sure that the CD is securely seated on the disc tray.

With the label side up

Press the DISC SKIP button on the Unit and

place the next CD.

When you press the button, the tray turns for the next CD.

Repeat step 3 for the last CD.

Press the CD Open/Close 0 button on the

Unit.

The tray is closed.

• You can also remove the CDs during playback. However, in this case, you can only remove the CDs that are not being played back.

Basics of Using the CD PlayerNormal Play

To Play CDs

Load CDs.

Press one of the Disc button (CD1-CD3) you

want to play.

The selected disc number (e.g. “CD-1” ) appears on the display. The first track of the selected CD begins playing. When the first CD finishes playing, the next and the third CDs are continuously played back. When the last CD has finished playing, the CD Player automatically stops.

Examples:

CD1 = CD2 = CD3 = (stop) CD2 = CD3 = CD1 = (stop)

❏You can start to play the currently selected disc by simply press-

ing the CD 6 button.

While playing the CD, the following will appear on the display.

1 2 3

Using the CD Player

• Removing/changing the CDs during playback

While playing back a CD (e.g. CD-1), you can remove or change the other CDs (e.g. CD-2 and CD-3) by pressing the CD Open/ Close 0 button. After removing or changing, press the same but- ton to close the tray.

To Select a Track

During playback (using the 4 or ¢ button):

Briefly press the 4 or ¢ button to select the track you want to play. By pressing the button, you can skip to the next track or skip back to the previous track.

• The selected track starts playing.

•Press the ¢ button once to skip to the beginning of the next track. (You can skip to the next CD (e.g. CD-1 = CD-2 = CD-3).)

•Press the 4 button to skip to the beginning of the current track. Press twice quickly to skip to the beginning of the previous track. (You cannot skip back to the previous CD.)

In Stop mode (using the 4 or ¢ button):

By briefly pressing the 4 or ¢ button, the CD Player operates in the same way as during playback, except the following points.

• The buttons are effective only for the currently selected CD.

Using the numeric keys on the Remote Control:

Using the numeric keys, you can directly select the track on the currently selected CD.

• The selected track starts playing.

For example, press +10, then 5 to play back the track number 15. See “Entering the Number with the Remote Control” on page 8.

Track number

• When the Disc button (CD1-CD3) is pressed with the tray opened, the tray is closed and the selected CD automatically begins playing.

To stop playing the CD

formation for the CD is displayed.

Total track number Total playing time

(After 5 seconds)

Track number Playing time

To pause

blinks on the display.

To cancel pause

from the point where it was paused.

To remove the CD

0 button on the Unit.

Tips:

• Playing back the CD using the DISC SKIP button

You can also play the CDs using the DISC SKIP button. During playback, each time you press the button, the next CD is automatically played back. If the next disc tray is empty, the disc tray is automatically skipped.

, press the CD 6 button. The playing time indication

, press the 7 button. The following in-

, press the CD 6 button again. Play continues

, stop playing and press the CD Open/Close

Elapsed playing time

CD is playing.

1 2 3

Search Play

Holding down the following buttons, during playback, will fast forward/backwards the CD so you can quickly find a particular passage in the track you are listening to.

• 22 or ¡ button on the Unit

• 4 or ¢ button on the Remote Control

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Using the CD Player

Programming the Playing Order

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

of the Tracks

You can program the playing order of the tracks on all the CDs. Note that you can only make a program when the CD Player is stopped.

❏You can program up to 32 tracks in any desired order including

the same tracks.

To Make a Program

Load CDs

In Stop mode, set the CD Player in Program

Play mode.

On the Unit

Press the PROGRAM button to light the “PRGM” indicator on the display. At the same time, “PROGRAM” appears on the display.

On the Remote Control

Press the PROGRAM/RANDOM button until “PROGRAM” appears on the display. The “PRGM” indicator also lights up on the display. Each time you press the button, the display changes as follows: PROGRAM = RANDOM = Blank display (Normal Play) = (back to the beginning)

• If a program is already made, the last step of the program will be displayed.

Press one of the Disc button (CD1-CD3) to

select the CD you want to program.

The display will change to the Program Entry display.

Select the track you want to program.

Using the Unit

While the display is blinking, press the 4 or ¢ button to select the track, then press the SET button within 5 seconds. The program order number will be assigned from P-1.

PRESET

Disc number Track number

Repeat steps 3 and 4 to program other tracks

on the same CD or the other CD. To play the program, Press the CD

but-

ton.

For details, see “To Play the Program You Have Made” mentioned below.

To delete all the tracks in the program

is stopped, press the 7 button.

To Modify the Program

the CANCEL button, the last track in the program is deleted. To add new tracks to the end of the program, repeat above steps 3 and

• If you try to program a track number that does not exists on the CD, your entry will be ignored.

• If you try to program the 33rd track, “FULL” appears on the display.

, while the CD Player is stopped, press

, while the CD Player

To Play the Program You Have Made

Press the CD 6 button. The System plays the tracks in the order you have programmed them.

• To use Repeat Play for Program Play, press the REPEAT button to select “ALL” or “1” before starting playback. For details, see “Repeating Tracks” on page 18.

❏You can skip to a particular program track by pressing the 4

or ¢ button during Program Play.

❏To stop playing, press the 7 button once. If you press the 7 but-

ton, while the CD Player is stopped, the program is deleted.

To Exit and Re-enter Program Play

The program you have made is stored in memory. So, you can exit Program Play temporarily or re-enter Program Play unless you delete the program.

To exit the program mode once

stopped, press the PROGRAM button on the Unit or the PROGRAM/RANDOM button on the Remote Control to light off the “PRGM” indicator. By changing the source to the other (e.g. Tuner), the CD Player also exits Program Play mode.

To re-enter Program Play mode

PROGRAM/RANDOM button until the “PRGM” indicator lights up again.

, while the CD Player is

, press the PROGRAM or

Disc number Track number

SET

Program order number

Using the Remote Control

Press the numeric keys to directly enter the track number. Then, the program order number will be assigned from P-1.

• To delete the current program step, press the CANCEL button on the Unit.

• Even when the power is turned off (standby or ECO mode), the programmed tracks are not deleted. So, you can re-enter Program Play mode.

Using the CD Player

Random Play

The tracks of all the CDs will play in no special order when you use this mode.

• To use Repeat Play for Random Play, press the REPEAT button to select “ALL” or “1” before starting playback. For details, see “Repeating Tracks”mentioned below.

In Stop mode, set the CD Player in Random

Play mode.

On the Unit

Press the RANDOM button to light the “RANDOM” indicator. At the same time, “RANDOM” appears on the display.

On the Remote Control

Press the PROGRAM/RANDOM button until the “RANDOM” appears on the display. The “RANDOM” indicator also lights up on the display. Each time you press the button, the display changes as follows: PROGRAM = RANDOM = Blank display (Normal Play) = (back to the beginning)

Press the CD

The tracks on all the CDs are played in random order.

To stop playing To skip a track during playback

jump to the next track in the random sequence.

To exit Random Play mode

press the RANDOM button on the Unit or the PROGRAM/RANDOM button on the Remote Control again to light off the “RANDOM” indicator. Normal Play resumes.

button.

, press the 7 button.

, while the CD Player is stopped,

, press the ¢ button to

Tray Lock Function

In order to safely keep the CD in the CD Player, the tray can be electronically locked. When the electronic lock is on, the tray cannot be opened even if the CD Open/Close 0 button on the Unit is pressed.

Locking the Tray

Turn on the System and enter CD mode.

While pressing down the 7 button, press the

CD Open/Close

“LOCKED” appears on the display.

• If you try to open the tray by pressing the 0 button, “LOCKED” appears on the display to let you know that the tray has been locked.

Unlocking the Tray

Repeat above steps 1 and 2. “UNLOCKED” appears on the display.

Now, you can use the tray normally.

button on the Unit.

Repeating Tracks

You can repeat all tracks or individual track, as many times as you like.

Press the REPEAT button.

The Repeat indicator changes with each press of the button, as follows: ALL= 1CD = 1 = Blank display = (back to the beginning)

REPEAT ALL:

REPEAT 1CD: REPEAT 1:

To stop playing

other (e.g. Tuner) will also stop playing.

To exit Repeat mode

peat indicator on the display goes out. ❏Repeat mode remains in effect during the following Play Mode

changing: a. PROGRAM PLAY MODEÔNORMAL PLAY MODE

b. RANDOM PLAY MODE ÔNORMAL PLAY MODE c. PROGRAM PLAY MODEÔRANDOM PLAY MODE

In Normal Play mode, repeats all the tracks on all the CDs. In Program Play mode, repeats all the tracks in the program. In Random Play mode, repeats all the tracks on all the CDs in random order.

Repeats all tracks on one CD. (Selectable in Normal Play only)

Repeats one track.

, press the 7 button. Changing the source to the

, press the REPEAT button until the Re-

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Using the Cassette Deck (Listening to a Tape)

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

3-CD

REMOTE CONTROL

FM MODE

REPEAT TAPE A/B

DISPLAY

MODE

VOLUME

STANDBY/ON

SLEEP

AUX

FM /AM

TAPE

PTY/EON

FADE

MUTING

TAPE

TAPE A/B

TAPE

EJECT

(Deck A)

COMPACT COMPONENT SYSTEM

STANDBY/ON

STANDBY

PHONES

AUX

FM/AM

REPEAT PROGRAM RANDOM

DISPLAY

MODE

PTY / EON

EJECT

PLAY

: Tape indicator

1 2 3

4 5 6

7 8 9

10 +10

CD1CD2CD3CD

PROGRAM /RANDOM

1 1 SELECT

SOUND MODE

ACTIVE

BASS EX.

PLAY & EXCHANGE

1 BIT

DUAL D/A CONVERTER

PRESET

CANCEL SET

/ DEMO

TUNING

TAPE

REC START

/STOP REC START DUBBING

SELECT

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

CLOCK

TAPE

/TIMER

A/B

ACTIVE

BASS EX.

EJECT

REC/PLAY

CD-R/RW PLAYBACK

SOUND MODE

DISC SKIP

CD CONTROL

CD 2CD

EJECT

(Deck B)

TAPE A/B

Deck indicators

* When the System is in use, the display shows other items as well.

For simplicity, we show here only the items described in this section.

The Cassette Deck allows you to play, record, and dub audio tapes. ❏Listening to type I, II tape is suitable for this Cassette Deck.

The use of tapes longer than 120 minutes is not recommended, since characteristic deterioration may occur and these tapes easily jam in the pinch-rollers and the capstans.

One Touch Play

By pressing the TAPE 3 button, the System will come on, and if a tape is in the deck, it will start to play. If no tape is loaded, “NO TAPE” appears on the display, the System will come on and wait for you to insert a tape, or select another function.

Playing a Tape

You can use either Deck A or Deck B at a time for playback.

Press the 0 EJECT part for the deck you

want to use. When the cassette holder opens, put a cas-

sette in, with the exposed part of the tape down, toward the base of the Unit.

The tape will travel from the left to right.

Tape travelling direction

• If the cassette holder does not open, turn the System off, then back on and press the 0 EJECT part again.

Close the cassette holder gently.

When both Deck A and Deck B contain a tape, the last deck to have a tape inserted is selected. The selected Deck is shown by the Deck indicator “A” or “B”. For example, when the Deck A is selected, the Deck indicator “A” lights up.

• To change the deck, press the TAPE A/B button. Each time you press the button, Deck A or Deck B is alternately selected.

Press the TAPE 3 button.

The Tape indicator (3) blinks on the display and the tape is played back. The Cassette Deck automatically stops when one side of the tape has finished playing.

To stop playing To remove the tape

, press the 7 button.

, stop the tape, and press the 0 EJECT part

to open the Cassette Holder.

To Fast-Wind A Tape

During playback or in Stop mode, press the ¡ (FF) button on the Unit to fast-wind the tape onto the right side of the cassette without playing. During playback or in Stop mode, press the 22 (REW) button on the Unit to fast-wind the tape onto the left side of the cassette without playing. During fast-winding the tape, the Tape indicator (3) goes out.

• The Cassette Deck automatically stops when one side of the tape has finished playing.

❏During fast-winding the tape, you can change the tape travelling

direction by pressing the ¡ (FF) or 22 (REW) button.

Using the Cassette Deck (Recording)

CAUTION:

REMOTE CONTROL

FM MODE

REPEAT TAPE A/B

DISPLAY

MODE

VOLUME

STANDBY/ON

SLEEP

AUX

FM /AM

TAPE

PTY/EON

FADE

MUTING

TAPE 3

TAPE A/B

REC START/STOP

CD REC START

TAPE 3

PROGRAM

DUBBING

0 EJECT

COMPACT COMPONENT SYSTEM

STANDBY/ON

STANDBY

PHONES

AUX

REPEAT PROGRAM RANDOM

DISPLAY

EJECT

MODE

FM/AM

CANCEL SET

/ DEMO

PTY / EON

1 2 3

4 5 6

7 8 9

10 +10

CD1CD2CD3CD

PROGRAM /RANDOM

1 1 SELECT

SOUND MODE

ACTIVE

BASS EX.

TAPE

REC START

/STOP REC START DUBBING

SELECT

TUNING

3-CD

PLAY & EXCHANGE

CLOCK

/TIMER

CD-R/RW PLAYBACK

1 BIT

ACTIVE

DUAL D/A

BASS EX.

CONVERTER

PRESET

TAPE

A/B

DISC SKIP

CD CONTROL

EJECT

SOUND

MODE

CD 2CD

(Deck A)

PLAY

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

REC/PLAY

0 EJECT

(Deck B)

TAPE A/B

REC indicator

3: Tape indicator

REC

Deck indicators

* When the System is in use, the display shows other items as well.

For simplicity, we show here only the items described in this section.

Recording onto a cassette from any of the sound sources is simple. Just place a tape in Deck B, have the source ready, make one or two settings, and you’re ready to record. For each source, the procedure is a little bit different so we explain each separately. But first, here are a few things to make your recordings better.

Things To Know Before You Start Recording

❏❏❏❏

It may be unlawful to record or play back copyrighted material without the consent of the copyright owner.

❏The recording level, which is the volume at which the new tape

is being made, is automatically set correctly, so it is not affected by the VOLUME Control on the System. Also, it is not affected by adjusting the sound effects. Thus, during recording, you can adjust the sound you are actually listening to without affecting the recording level.

❏Two small tabs on the back of the cassette tape, one for side A

and one for side B, can be removed to prevent accidental erasure or recording.

Adhesive tape

• At the start and end of cassette tapes, there is leader tape which cannot be recorded onto. Thus, when recording CDs, radio broadcasts, etc., wind on the leader tape first to ensure getting the beginning of the recording.

• If a recording you make has excessive noise or static, the Unit may have been too close to a TV which was on during the recording. Either turn off the TV or increase the distance between the TV and the Unit.

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

❏To record on a cassette with the tabs removed, you must cover

the holes with adhesive tape first.

❏Type I tape can be used for recording.

Using the Cassette Deck (Recording)

(When finished)

Standard Recording

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

This is the basic method for recording any source. The System also has special ways for recording CD to tape, and tape to tape, which save you time and effort, as well as give you some special effects. However, when you need to add a selection to a tape you have made, or are combining selections from several sources on one tape, use the method described below; just substitute the source you want into this procedure, such as a tape in Deck A, a CD, or the Tuner. You can also record from an external equipment with this procedure.

Insert a blank or erasable tape into the Deck

B and wind past the tape leader. Press the CD REC START button on the Unit.

“CD REC” appears on the display and the “REC” indicator lights up. Then, the System begins CD Synchro Recording and the tracks on the CD are recorded on the tape. When recording of the tracks of all CDs is finished, “CD REC FINISHED” scrolls on the display and the CD Player and Cassette Deck stop.

REC START

To Record Any Sound Source to Tape

Follow these steps to record from any sound source onto a tape in Deck B.

Insert a blank or erasable tape into the Deck

B and wind past the tape leader.

Tape travelling direction

Prepare the source, by, for example, tuning

in a radio station, loading CDs, or turning on connected equipment.

• For CD recording, see “CD Synchro Recording” mentioned below.

• For dubbing, see “Tape to Tape Recording (Dubbing)” described below.

Press the REC START/STOP button on the

Unit.

The “REC” indicator lights up and the System begins recording. The Tape indicator (3) blinks on the display.

• If the tab of the cassette tape on the Deck B is removed to prevent erasure or recording, "NO REC" will appear on the display.

To stop during recording

ton on the Unit, or press the 7 button.

, press the REC START/STOP but-

Recording an AM Station to Tape (Beat Cut)

When recording an AM broadcast, beats may be produced which are not heard when listening to the broadcast. If this happens, press the PROGRAM button on the Unit to eliminate the beats.

Set to AM station and start recording.

Press the PROGRAM button on the Unit to

eliminate the beats.

Each time you press the button, the display changes as shown below: CUT 1= CUT 2 = CUT 3= CUT 4 = (back to the beginning)

• If the tab of the cassette tape on the Deck B is removed to prevent erasure or recording, "NO REC" will appear on the display.

• After the CD Player has played the entire CD or all the programmed tracks, the tape automatically stops.

To stop at any time during the recording process

the REC START/STOP button on the Unit or the 7 button. “CD REC FINISHED” scrolls on the display and the CD Player and Cassette Deck stop.

• When making SLEEP timer settings while doing CD Synchro recording, set enough time to allow for the CD to finish playing, otherwise the power will go off before recording is completed.

, press

Tape to Tape Recording (DUBBING)

Recording from one tape to another is called dubbing. You can dub tapes simply, with just a single button.

Press the TAPE

7777

button.

Insert the source cassette you want to copy

from into Deck A for playback. Insert a blank or erasable cassette you want

to copy onto into Deck B for recording. Press the DUBBING button on the Unit.

Deck A and Deck B will start simultaneously and the "REC" indicator lights up. During dubbing, the Deck indicators "A" and "B" light up alternately.

• If no tape is inserted into Deck A, "NO TAPE" will appear on the display.

• If no tape is inserted into Deck B, "NO TAPE" will appear on the display.

To stop dubbing

Unit or the 7 button.

3333

button, and then press the

, press the REC START/STOP button on the

CD Synchro Recording

Everything on the CD goes onto the tape in the order it is on the CD, or according to the order you have set in a program.

Prepare CDs. (See page 15.)

Press the CD1-3 button (that you want to make recording), and then press the 7 button.

• If you want to record specific tracks only, you need to program the tracks beforehand. (See page 17.)

• During dubbing, you can hear sound effects through the speakers or headphones. However, the sound is dubbed without sound effects.

Using an External Equipment

REMOTE CONTROL

FM MODE

REPEAT TAPE A/B

DISPLAY

MODE

VOLUME

STANDBY/ON

SLEEP

AUX

FM /AM

TAPE

PTY/EON

FADE

MUTING

3-CD

PLAY & EXCHANGE

AUX

COMPACT COMPONENT SYSTEM

STANDBY/ON

STANDBY

PHONES

AUX

REPEAT PROGRAM RANDOM

EJECT

1 BIT

ACTIVE

DUAL D/A

BASS EX.

CONVERTER

PRESET

CANCEL SET

/ DEMO

TUNING

TAPE

FM/AM

REC START

/STOP REC START DUBBING

DISPLAY

MODE

SELECT

PTY / EON

CLOCK

TAPE

/TIMER

A/B

1 2 3

4 5 6

7 8 9

10 +10

CD1CD2CD3CD

PROGRAM /RANDOM

1 1 SELECT

SOUND MODE

ACTIVE

BASS EX.

CD-R/RW PLAYBACK

SOUND MODE

DISC SKIP

CD CONTROL

EJECT

CD 2CD

Listening to the External Equipment

You can listen to the external equipment such as MD recorder, cassette deck, or other auxiliary.

❏First, make sure that the external equipment is properly connect-

ed to the System. (See page 6.)

Set the volume level to the minimum posi-

tion. Press the AUX button.

“AUX” appears on the display.

Start playing the external equipment.

Adjust the volume level to the level you want

listen to. Apply sound effects, if you wish.

• Press the ACTIVE BASS EX. to reinforce the bass sound.

• Select the Sound Mode. (See page 8.)

To exit AUX mode

, select other source (e.g. Tuner).

PLAY

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

REC/PLAY

• For operation of the external equipment, refer to its Instructions.

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Using the Timers

CAUTION:

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

REMOTE CONTROL

1 2 3

4 5 6

7 8 9

10 +10

FM MODE

CD1CD2CD3CD

PROGRAM

REPEAT TAPE A/B

/RANDOM

DISPLAY

MODE

1 1 SELECT

SOUND

MODE

ACTIVE

VOLUME

BASS EX.

STANDBY/ON

SLEEP

AUX

FM /AM

TAPE

PTY/EON

FADE

MUTING

3-CD

PLAY & EXCHANGE

COMPACT COMPONENT SYSTEM

SLEEP

STANDBY/ON

SET

STANDBY

PHONES

CLOCK/TIMER

CANCEL SET

/ DEMO

AUX

REPEAT PROGRAM RANDOM

DISPLAY

EJECT

PLAY

TAPE

FM/AM

REC START

/STOP REC START DUBBING

MODE

SELECT

PTY / EON

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

TUNING

1 BIT

DUAL D/A CONVERTER

PRESET

CLOCK

TAPE

/TIMER

A/B

ACTIVE

BASS EX.

REC/PLAY

EJECT

CD-R/RW PLAYBACK

SOUND MODE

DISC SKIP

CD CONTROL

CD 2CD

SLEEP indicator

DAILY Timer indicator

SLEEP DAILY REC

REC (Recording) Timer indicator

Timer indicator

* When the System is in use, the display shows other items as well.

For simplicity, we show here only the items described in this section.

The timers lets you control recording and listening functions automatically. Three types of timers are available:

DAILY Timer

Use this timer to set wake up everyday to

music from any source, instead of an alarm clock.

REC (Recording) Timer

Unattended recording of radio broadcasts. You can set the starting time and length of the recording.

SLEEP Timer

Fall asleep and have your System turn off

automatically after a certain length of time.

Setting the Clock

When you plug the AC power cord into the wall outlet, the time indication “0:00” blinks on the display. You can set the clock whether the System is on or off.

• The clock must be correctly set for the timers to work.

• Each setting step must be completed within approx. 2 minutes. Otherwise, the setting is cleared and must be repeated from the beginning.

• The clock may gain or lose one to two minutes per month.

Using the Unit

Press the CLOCK/TIMER button.

The hour digit of the time indication blinks on the display.

• If the clock is already set and “0:00” is not blinking, press the CLOCK/TIMER button repeatedly until clock setting display appears on the display. In the clock setting display, the hour digits of the current clock blink on the display. Each time you press the CLOCK/TIMER button, the display

changes as follows: DAILY = ON TIME = REC = ON TIME = Clock setting display = Canceled = (back to the beginning)

Press the

Pressing the ¢ button moves the time forwards and pressing the 4 button moves it backwards. Holding down the button moves the hour rapidly.

Press the SET button.

The minute digits of the time indication blink on the display.

• To return to the hour setting, press the CANCEL button.

Press the

minute. Press the SET button.

“CLOCK OK” appears on the display. Then, th e sele cted time is set and the seconds start counting from 0.

button to set the hour.

button to set the

• If there is a power failure, the clock loses its setting immediately. “0:00” blinks on the display and the clock must be reset.

Setting the Daily Timer

DAIL Y

After 2 seconds

DAIL Y

Once you have set the Daily Timer, the timer will be activated at the same time every day. The Timer indicator ( ) on the display shows that the Daily Timer you have set is in effect. You can set the Daily Timer whether the System is turned on or off.

• Perform each setting within 30 seconds. Otherwise, setting will be cleared and the procedure must be repeated from the beginning.

• If you have made a mistake while setting the timer, press the CANCEL button on the Unit. However, this does not always cancel the current setting. If the CANCEL button does not work, press the CLOCK/TIMER button on the Unit repeatedly until the display returns to the original display, and start from the first step.

Using the Unit

Press the % button to turn on the System.

Press the CLOCK/TIMER button until “ON

TIME” immediately after “DAILY” appears on the display.

At this time, “DAILY” indicator blinks and the Timer indicator ( ) lights up on the display. Each time you press the button, the display changes as follows: DAILY = ON TIME* = REC = ON TIME = Clock setting display = Canceled = (back to the beginning)

* : This item should be selected for the Daily Timer setting.

Using the Timers

2. Press the ¢ or 4 button to set the minute, then press the SET button.

“OFF TIME” appears for 2 seconds, and the System enters OFF-time setting mode. The current OFF time appears on the display, and the hour digits blink.

DAILY

Setting the OFF time (Example: PM 13:15).

1. Press the ¢ or 4 button to set the hour you want the System to come on, then press the SET button. The minute digits of the ON time blink on the display.

DAIL Y

2. Press the ¢ or 4 button to set the minute, then press the SET button.

After 2 seconds, the System enters ON-time setting mode. The current ON time appears on the display and the hour digits blink.

After 2 seconds

Setting the ON time (Example: 10:15).

1. Press the ¢ or 4 button to set the hour you want the System to come on, then press the SET button. The minute digits of the ON time blink on the display. Pressing the ¢ button moves the time forwards and pressing the 4 button moves it backwards. Holding down the button moves the time rapidly.

DAILY

The System enter Music Source Selecting mode and “TUNER FM” appears on the display.

DAIL Y

Selecting the music source.

Press the ¢ or 4 button to select the music source you want to listen to, then press the SET button. Each time you press the ¢ or 4 button, the display changes as shown below: TUNER FM = TUNER AM = – CD – – – = TAPE = AUX = (back to the beginning) According to the music source you have selected, the next operation differs.

TUNER FM TUNER AM – CD – – – TAPE AUX

: Tunes in to the specified preset FM station.

: Tunes in to the specified preset AM station.

: Plays the specified track on the specified CD.

: Plays a tape in the selected Deck (A or B).

: Plays an external source.

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Using the Timers

CAUTION:

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Preparation for each music source:

Perform the following operation according to the music source you have selected. Then, the System enters Volume Setting mode.

When selecting TUNER FM or TUNER AM:

Press the ¢ or 4 button to select the preset station number, then press the SET button.

When selecting – CD – – –:

1. Press the ¢ or 4 button to select the disc number, then press the SET button. Each time you press the button the disc number changes as follows: – CD – – – = 1CD – – –= 2CD – – – = 3CD – – – = (back to the beginning)

2. Press the ¢ or 4 button to select the track number, then press the SET button. For example: 2CD – 12 (Disc number 2, Track number 12)

When selecting TAPE:

Be sure that the Deck indicator (“A” or “B”) is lit for the tape you want to play.

When selecting AUX:

Prepare the external equipment so that it will turn on at the ON time set by the System. To allow this, the equipment should have the timer function.

Setting the volume level.

Press the ¢ or 4 button to select the volume level.

– – – : The current volume level will be used.

VOL VOL-5, -10, or -15

will be automatically set to the selected level.

: When the timer is turned on, the Volume

Turning the Daily Timer On and Off

Once you have set the Daily Timer, it is stored in memory. So, the Daily Timer will be activated at the same time every day until it is canceled.

To cancel the Daily Timer temporarily:

Press the CLOCK/TIMER button on the Unit

repeatedly until the “DAILY” appears on the display.

Press the CANCEL button on the Unit.

The “DAILY” indicator goes out and “OFF” appears on the display. The Timer indicator ( ) and “DAILY” indicator go out and the Daily Timer is canceled temporarily.

To activate the cancelled Daily Timer:

Press the CLOCK/TIMER button on the Unit

repeatedly until the “DAILY” appears on the display.

The “DAILY” indicator blinks and the Timer indicator ( ) lights up on the dispaly.

Press the SET button on the Unit.

The “DAILY” indicator remains lit. Each setting already made appears on the display in the order of ON time, OFF time, music source and volume, and then the display returns to the original display.

DAILY

Press the SET button.

The timer setting is completed, and the “DAILY” indicator stops blinking and remains lit. Each setting you have made appears on the display in the order of ON time, OFF time, music source and volume. Then, the display returns to the display before you set the Timer.

Press the

The Timer indicator ( ) and “DAILY” indicator are lit on the display, showing that the Daily Timer is set to on.

To change the timer setting

the beginning.

When the timer ON-time comes:

The following operation will be automatically repeated every day.

• When the timer ON-time comes, and the System automatically turns on. The music source you have set is played. The Timer

indicator ( ) blinks during timer operation.

• When the timer OFF-time comes, “OFF” blinks on the display just before the OFF-time and the System automatically turns

off. Then, the Timer indicator ( ) remains lit on the display.

• If the System is already on when the timer ON-time comes, the Daily Timer does not work.

button to turn off the System.

%%%%

, repeat the setting procedure from

• If the System is unplugged, or a power failure occurs, the timer setting will be lost in a few days. You will need to reset the clock first, then the timer.

Setting the REC (Recording) Timer

With the Recording Timer, you can make a tape of a radio broadcast automatically whether or not you are home.

• You can set the REC Timer whether the System is on or off.

• The volume level is automatically set to MIN when REC Timer is used.

• Perform each setting within 35 seconds. Otherwise, setting will be cleared and the procedure must be repeated from the beginning.

Using the Timers

CAUTION:

Using the Unit

You can set the time in the same way as for setting the Daily Timer.

Insert a blank or erasable tape into the Deck

B and wind past the tape leader. Press the CLOCK/TIMER button until “ON

TIME” immediately after “REC” appears on the display.

Then, the "REC" indicator blinks on the display. Each time you press the button, the display changes as follows: DAILY = ON TIME = REC = ON TIME* = Clock setting display = Canceled = (back to the beginning)

* : This item should be selected for the REC Timer setting.

After 2 seconds, the System enters ON-time setting mode. The current ON time appears on the display and the hour digits blink.

After 2 seconds

Setting the ON time you want the System to

REC

turn on.

1. Press the 4 or ¢ button to set the hour, then press the SET button.

2. Press the 4 or ¢ button to set the minute, then press the SET button.

“OFF TIME” appears for 2 seconds, and the System enters OFF-time setting mode. The current OFF time appears on the display, and the hour digits blink.

Setting the OFF time you want the System to

turn off.

1. Press the 4 or ¢ button to set the hour, then press the SET button.

2. Press the 4 or ¢ button to set the minute, then press the SET button.

The System enter Preset Station Entering mode.

When the timer ON-time comes:

• When the timer ON-time comes, the System automatically turns on. The station you have set is played. The Timer indica-

tor ( ) blinks during timer operation. To stop timer recording, press the 7 button.

• When the timer OFF-time comes, “OFF” blinks on the display just before the OFF-time and the System automatically turns off.

• The REC Timer works even if the System is turned on.

Turning the REC (Recording) Timer On and Off

Once you have set the REC Timer to record a source, the timer setting is stored in memory. So, though the REC Timer turns off once it is used, you can recall it at any time.

To cancel the REC Timer temporarily:

Press the CLOCK/TIMER button on the Unit

repeatedly until “REC” appears on the display.

Press the CANCEL button on the Unit.

“OFF” appears and the “REC” indicator goes out.

To activate the cancelled REC Timer:

Press the CLOCK/TIMER button on the Unit

repeatedly until “REC” appears on the display.

The “REC” indicator also blinks on the display.

Press the SET button on the Unit.

The “REC” indicator remains lit. Each setting already made appears on the display in the order of ON time, OFF time, and the preset number, and then the display returns to the original display.

• If the System is unplugged, or a power failure occurs, the timer setting will be lost in a few days. You will need to reset the clock first, then the timer.

Select the preset station for recording.

1. Press the 4 or ¢ button to set the band (TUNER FM or

2. Press the 4 or ¢ button to set the preset number, then

The REC indicator stops blinking and remains lit.

• Each setting you have made appears on the display in the

Press the

necessary.

To change the timer setting

the beginning.

TUNER AM), then press the SET button.

press the SET button.

order of ON time, OFF time, radio band and the preset number.

button to turn off the System, if

%%%%

, repeat the setting procedure from

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Using the Timers

22:00 22:30 23:00

REC Timer

SLEEP Timer

Setting

ON OFF

OFF

ON OFF

22:00 22:30

Operation

REC Timer

SLEEP Timer

The REC Timer has priorty.

22:00 22:30 23:0021:30

REC Timer

DAILY Timer

Setting

ON OFF

OFF

ON OFF

22:3021:30

Operation

REC Timer

DAILY Timer

The REC Timer has priorty.

Setting the SLEEP Timer

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Use the Sleep Timer to turn the System off after a certain number of minutes when it is playing. By setting the Sleep Timer, you can fall asleep to music and know that your System will turn off by itself rather than play all night.

• You can only set the Sleep Timer when the System is on.

Using the Remote Control

During playback a source, press the SLEEP

button.

The “SLEEP” indicator starts blinking on the display.

Set the length of time you want the source to

play before shutting off.

Each time you press the SLEEP button, the time length changes as follows: 10 = 20 = 30 = 60 = 90 = 120 = Cancelled = (back to the beginning)

SLEEP

Wait for 5 seconds.

The “SLEEP” indicator stops blinking and remains lit, and the display returns to the original one before setting the Sleep Timer. The System is now set to turn off after the number of minutes you have set.

Timer Priority

Since each timer can be set independently, you may wonder what happens if the settings overlap. Here are the priorities for each timer: The REC Timer always has priority. This means that:

• If other timer is set to come on during a time when the REC Timer is operating, the other timer just won’t come on at all, so you will always get the entire program on a tape.

• If the REC Timer is set to come on while other timer is operating, the other timer will turn off just before the REC Timer is set to turn on, and the REC Timer will then take over.

❏If the SLEEP Timer is set while DAILY Timer is ope rating, the

DAILY Timer settings are cancelled. However, if DAILY Timer is set to come on while the SLEEP Timer is operating, the SLEEP Timer setting will be cancelled and the System will use the settings from the DAILY Timer.

Example 1

To Confirm the Sleep Time:

When the SLEEP button on the Remote Control is pressed, the remaining sleep time is displayed. Wait until the display returns to the original display.

To Cancel the SLEEP Timer Setting:

Press the SLEEP button on the Remote Control until the “SLEEP” indicator goes out on the display.

• Turning off the System also cancels the SLEEP Timer.

Example 2

Care And Maintenance

Heads

Pinch-roller

Capstan

Handle your CDs and tapes carefully, and they will last a long time.

Compact Discs

• Only CDs bearing this mark can be used with this System. However, continued use of irregular shape CDs (heart-shape, octagonal, etc.) can damage the System.

• Remove the CD from its case by holding it at the edges while pressing the case’s center hole lightly.

• Do not touch the shiny surface of the CD, or bend the CD.

• Put the CD back in its case after use to prevent warping.

• Be careful not to scratch the surface of the CD when placing it back in the case.

• Avoid exposure to direct sunlight, temperature extremes, and moisture.

• A dirty CD may not play correctly. If a CD does become dirty, wipe it with a soft cloth in a straight line from center to edge.

Cassette Tapes

• If the tape is loose in its casse tte, take up the slack by inserting a pencil in one of the reels and rotating.

• If the tape is loose, it may get stretched, cut, or caught in the cassette.

• Do not touch the tape surface.

• Do not store the tape:

- In dusty places

- In direct sunlight or heat

- In moist areas

- On a TV or speaker

- Near a magnet

Cassette Deck

• If the heads, capstans, and pinch-rollers of the Cassette Deck become dirty, the following will occur:

- Loss of sound quality

- Discontinuous sound

-Fading

- Incomplete erasure

- Difficulty recording

• Clean the heads, capstans, and pinch-rollers using a cotton swab moistened with alcohol.

CAUTION:

• Do not use any solvent (for example, conventional record cleaner, spray thinner, benzine, etc.) to clean a CD.

General Notes

In general, you will have the best performance by keeping your CDs and the mechanism clean.

• Store CDs in their cases, and keep them in cabinets or on shelves.

• Keep the System’s Top Cover closed when not in use.

Moisture Condensation

Moisture may condense on the lens inside the System in the following cases:

• After turning on heating in the room.

• In a damp room.

• If the System is brought directly from a cold to a warm place.

Should this occur, the System may malfunction. In this case, leave the System turned on for a few hours until the moisture evaporates, unplug the AC power cord, and then plug it in again.

• If the heads become magnetized, the Unit will produce noise or lose high frequencies.

• To demagnetize the heads, turn off the Unit, and use a head demagnetizer (available at electronics and record shops).

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

Troubleshooting

• If you are having a problem with your System, check this list for a possible solution before calling for service.

• If you cannot solve the problem from the hints given here, or the System has been physically damaged, call a qualified person, such as

EnglishEnglishEnglishEnglishEnglishEnglishEnglish

your dealer, for service.

Symptom Possible Cause Action

No sound is heard. • Connections are incorrect, or loose.

• Headphones are connected.

Poor radio reception • The antenna is disconnected.

• The AM Loop Antenna is too close to the System.

• The FM Wire Antenna is not properly extended and positioned.

The disc tray does not open.

The CD skips. The CD is dirty or scratched. Clean or replace the CD. (See page 28.) The CD does not play. The CD is upside down. Put the CD in with the label side up. The cassette holder cannot be opened. During tape playing, the power cord

Unable to record. Cassette record protect tabs are re-

Unable to operate the Remote Control.

Operations are disabled. The built-in microprocessor has mal-

• The AC power cord is not plugged in.

• Tray is locked.

was unplugged.

moved.

• The path between the Remote Contro l and the sensor on the Unit is blocked.

• The batteries have lost their charge.

functioned due to external electrical interference.

• Check all connections and make corrections. (See pages 4 to 6.)

• Disconnect the headphones.

• Reconnect the antenna securely.

• Change the position and direction of the AM Loop Antenna.

• Extend FM Wire Antenna to the best reception position.

• Plug the AC power cord.

• Unlock the tray. (See page 18.)

Plug in the power cord, and turn on the System.

Cover holes on back edge of cassette with tape.

• Remove the obstruction.

• Replace the batteries.

Unplug the System then plug it back in.

Specifications

Amplifier

Input Sensitivity/Impedance (1 kHz)

Cassette Deck Section

CD Player

Signal-To-Noise Ratio 90 dB

Tuner

Output Power

CA-MXK3R 50 W per channel, min. RMS, at 6 Ω,

with no more than 10% total harmonic

CA-MXK1R 30 W per channel, min. RMS, at 6 Ω,

AUX IN 300 mV/50 kΩ

Speaker terminals 6 - 16 Ω

Phones 32 Ω - 1 kΩ

Frequency Response

Type I (NORMAL) 63 - 12,500 Hz

Type II (CrO

Wow And Flutter 0.15% (WRMS)

CD Capacity 3 CDs

Dynamic Range 85 dB

Wow And Flutter Unmeasurable

FM Tuner

Tuning Range 87.5 - 108.0 MHz

distortion with no more than 10% total harmonic

distortion

15 mW/ch output into 32 Ω

) 63 - 12,500 Hz

AM Tuner

Tuning Range (MW) 522 - 1,629 kHz

(LW) 144 - 288 kHz

Unit

Accessories

Power Specifications

Power Requirements AC 230 V ~ , 50 Hz

Power Consumption

Design and specifications are subject to change without notice.

Dimensions

CA-MXK3R CA-MXK1R

CA-MXK3R Approx. 7.3 kg (16.1 lbs) CA-MXK1R Approx. 6.8 kg (15.1 lbs)

CA-MXK3R 105 W (power on mode) CA-MXK1R 70 W (power on mode)

270 mm ✕ 305 mm ✕ 438.5 mm (W/H/D) (10-2/5"

270 mm ✕ 305 mm ✕ 386 mm (W/H/D) (10-2/5"

Mass

AM (MW/LW) Loop Antenna (1) Remote Control (1) Batteries R6P (SUM-3)/AA (15F) (2) FM Wire Antenna (1)

Approx. 1 W (in ECO mode) Approx. 1 W (in ECO mode)

12" ✕ 17-5/16")

12" ✕ 15-1/4")

VICTOR COMPANY OF JAPAN, LIMITED

0401TTMCREHIT

JVC CA-MXK3R, CA-MXK1R User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual

Warnings, Cautions and Others

Introduction

Table of Contents

Getting Started

Basic Operations

Using the Tuner

Using the CD Player

Using the Cassette Deck (Listening to a Tape)

Using the Cassette Deck (Recording)

Using an External Equipment

Using the Timers

Care And Maintenance

Troubleshooting

Specifications
