JVC CA-EXD11 User Manual
COMPACT COMPONENT SYSTEM
SYSTEME DE COMPOSANTS COMPACT
EX-D11
Consists of CA-EXD11 and SP-EXD11
Composée du CA-EXD11 et du SP-EXD11
INSTRUCTIONS
MANUEL D’INSTRUCTIONS
GNT0066-002A
[C]
Warnings, cautions and others
Mises en garde, précautions et indications diverses
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ATTENTION
Afin d’éviter tout risque d’électrocution, d’incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas
ouvrir le coffret de l’appareil.
2. Ne pas exposer l’appareil à la pluie ni à l’humidité.
CAUTION — (Standby/on) button!
Disconnect the mains plug to shut the power off completely
(the STANDBY lamp goes off). When installing the apparatus,
ensure that the plug is easily accessible.
The
disconnect the mains line.
• When the system is on standby, the STANDBY lamp
• When the system is turned on, the STANDBY lamp
The power can be remote controlled.
ATTENTION—Touche (attente/sous tension)
Déconnectez la fiche secteur pour mettre l’appareil
complètement hors tension (le témoin STANDBY l
s’éteint). Lors de l’installation de l’appareil, assurez-vous
que la fiche soit facilement accessible.
La touche
quelle position ne déconnecte pas l’appareil du secteur.
• Quand l’appareil est en mode d’attente, le témoin
• Quand l’appareil est sous tension, le témoin STANDBY
L’alimentation ne peut pas être commandée à distance.
Note to CATV system installer:
This reminder is provided to call the CATV system
installer’s attention to Section 820-40 of the NEC which
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building, as
close to the point of cable entry as practical.
Caution
Changes or modifications not approved by JVC could
void the user’s authority to operate the equipment.
Attention
Des changements ou modifications non approuvés par
JVC pourront invalider l’autorité de l’utilisateur à opérer
cet appareil.
(Standby/on) button in any position does not
lights red.
goes off.
(attente/sous tension) dans n’importe
STANDBY est allumé en rouge.
s’éteint.
[European Union only]
[
Union européenne seulement]
G-1
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE
CLASS B LIMITS FOR RADIO NOISE EMISSIONS
FROM DIGITAL APPARATUS AS SET OUT IN THE
INTERFERENCE-CAUSING EQUIPMENT STANDARD
ENTITLED “DIGITAL APPARATUS”, ICES-003 OF THE
DEPARTMENT OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES
DE BRUITS RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMIRIQUES DE CLASSE B PRESCRITES
DANS LA NORME SUR LE MATERIEL BROUILLEUR:
“APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
Declaration of Conformity:
Trade Name: JVC
Model Number: EX-D11
Responsible Party: JVC American Corp.
Address: 1700 Valley Road, Wayne
Telephone Number: 973-317-5000
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no
user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION:
(For U.S.A.) Visible and/or invisible class II laser
radiation when open. Do not stare into beam.
(For Canada) Visible and/or invisible class 1M laser
radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL,
PLACED INSIDE THE UNIT.
IMPORTANT POUR PRODUITS LASER
1. PRODUIT LASER CLASSE 1
2.
ATTENTION: N’ouvrez pas le couvercle supérieur. Il
n’y a aucune pièce réparable par l’utilisateur à
l’intérieur de l’appareil; confiez toute réparation à un
personnel qualifié.
3.
ATTENTION:
(Pour les Etats-Unis) Radiation laser de classe II
visibles et/ou invisible si l’appareil est ouvert. Ne
regardez pas le rayon.
(Pour le Canada)
invisible de classe 1M une fois ouvert. Ne pas regarder
directement avec des instruments optiques.
4. REPRODUCTION DE L’ÉTIQUETTE: ÉTIQUETTE DE
PRÉCAUTION PLACÉE À L
New Jersey 07470
Rayonnement laser visible et/ou
’
INTERIEUR DE L’APPAREIL.
Table of contents
Introduction
Special cautions ..............................................2
Notes on handling............................................... 2
Supplied accessories.......................................... 2
About discs......................................................3
Playable disc types............................................. 3
Disc structure...................................................... 4
Description of parts .........................................5
Front panel.......................................................... 5
Display window................................................... 5
Rear panel .......................................................... 5
Getting started
Using the remote control .................................6
Putting the batteries in the remote control.......... 6
Operating the TV using the remote control......... 7
Connecting up .................................................8
Connecting antennas.......................................... 8
Connecting speakers.......................................... 9
Connecting other devices................................. 10
Connecting with TV........................................... 11
Connecting the power cord............................... 11
Basic operations
Playing discs .................................................12
Playback ........................................................... 12
To switch the display ........................................ 13
Select an item on the disc by using the number
buttons....................................................... 14
To stop playback............................................... 14
To pause playback............................................ 14
To advance picture frame-by-frame.................. 14
Fast reverse/Fast forward search..................... 14
Playing back from a position 10 seconds before
(One Touch Replay) .................................. 15
Slow Motion Playback....................................... 15
Skip to the beginning of the selection............... 15
To change the brightness of the display window
(DIMMER).................................................. 16
Adjusting the volume ........................................ 16
Adjusting sound quality..................................... 16
Turning off the sound temporarily (MUTING) ... 16
Playing audio/video files................................16
Playback ........................................................... 17
Repeat playback............................................... 17
Resume Playback .........................................18
Select the scene to be played .......................19
Select the scene from the menu....................... 19
Designate the time (Time search)..................... 20
Other convenient functions............................24
Selecting the subtitles........................................24
Selecting the audio language............................24
Selecting a view angle.......................................24
Enlarging the picture (ZOOM) ...........................25
Adjusting the picture quality (VFP) ....................25
Making dialogues clear (CLEAR VOICE)..........25
Creating realistic sound (3D PHONIC)..............26
Adjusting playback level (DVD LEVEL).............26
Enjoying better pictures (SCAN MODE)............26
Functions specific to DVD AUDIO.................27
Playing the Bonus Group...................................27
Browsable Still Pictures (B.S.P.) .......................27
Using the menu bar....................................... 28
Preferences................................................... 29
Basic operations................................................29
LANGUAGE.......................................................29
PICTURE...........................................................29
AUDIO ...............................................................30
OTHERS............................................................30
Listening to the radio
Listening to a radio broadcast .......................31
Selecting a station.............................................31
Presetting stations.............................................31
Tuning in to a preset station..............................31
Convenient functions
Playing Back from the PC .............................32
Listening to the sound of other audio device
Listening to the sound of external audio device .... 33
Listening to the sound of portable audio device
Adjusting the audio input level...........................34
....33
....33
Setting the Various Timer..............................34
Setting the built-in clock.....................................34
Setting the daily timer........................................35
Auto Standby.....................................................36
Sleep Timer .......................................................36
Tray Lock.......................................................36
Reference
Troubleshooting.............................................37
Language codes............................................38
Specifications ................................................39
Advanced operations
Program/Random Playback ..........................20
Play the disc in the desired order (Program
Playback)................................................... 20
Playing the disc in a random order (Random
Playback)................................................... 21
Repeat Playback ...........................................22
Playing the title/chapter/group/track/all tracks
repeatedly (REPEAT)................................ 22
Playing the designated part repeatedly (A-B
Repeat Playback) ...................................... 23
1
Special cautions
Notes on handling
7 Important cautions
Installation of the system
• Select a place which is level, dry and neither too hot
nor too cold; between 5°C and 35°C.
• Leave sufficient distance between the system and the
TV.
• Do not use the system in a place subject to vibration.
Power cord
• Do not handle the power cord with wet hands.
• A small amount of power is always consumed while
the power cord is connected to the wall outlet.
• When unplugging the power cord from the wall outlet,
always pull on the plug, not the power cord.
To prevent malfunctions of the system
• There are no user-serviceable parts inside. If anything
goes wrong, unplug the power cord and consult your
dealer.
• Do not insert any metallic object into the system.
• Do not use any non-standard shape disc (like a heart,
flower or credit card, etc.) available on the market,
because it may damage the system.
• Do not use a disc with tape, stickers, or paste on it,
because it may damage the system.
Label sticker
Sticker
Paste
If water gets inside the system
Turn the system off and disconnect the power cord plug
from the wall outlet, then call the store where you made
your purchase. Using the system in this condition may
cause fire or electrical shock.
7 When condensation or water drops adhere to the
lens
In any of the following cases, condensation or water
drops may adhere to the lens to prevent the system from
working properly:
• Immediately after starting to heat the room
• When the system is installed in a steamy or damp
space
• When the system is suddenly moved from a cold place
to a warm space
In any of these cases, leave the system turned on for 1 or
2 hours before use.
Supplied accessories
Check to be sure you have all of the supplied
accessories.
The number in parentheses is the quantity of the pieces
supplied. If anything is missing, contact your dealer
immediately.
• Remote control (1)
• Batteries (2)
• FM antenna (1)
• AM loop antenna (1)
• Power cord (1)
• Composite video cord (1)
• Speaker cords (2)
Note about copyright laws
Check the copyright laws in your country before
recording from DVDs, VCDs, SVCDs, and CDs.
Recording of copyrighted material may infringe copyright
laws.
Note about copy guard system
DVDs are protected by copy guard system. When you
connect the system to your VCR directly, the copy guard
system activates and the picture may not be played back
correctly.
7 Safety precautions
Avoid moisture, water and dust
Do not place the system in moist or dusty places.
Avoid high temperatures
Do not expose the system to direct sunlight and do not
place it near a heating device.
When you are away
When away on travel or for other reasons for an extended
period of time, disconnect the power cord plug from the
wall outlet.
Do not block the vents
Blocking the vents may damage the system.
Care of the cabinet
When cleaning the system, use a soft cloth and follow the
relevant instructions on the use of chemically-coated
cloths. Do not use benzene, thinner or other organic
solvents including disinfectants. These may cause
deformation or discoloring.
How to read this manual
• Operations are described by mainly using the
remote control buttons. If there are the same
marks on the main unit, the buttons on the main
unit can also be used.
• The following marks tell you for which type of the
discs the operation can be made.
• The illustrations and TV screens may be different
between the actual case and the description.
• “DVD VR” means a DVD recorded in DVD Video
Recording (DVD VR) format.
• “VCD” is an abbreviation of “Video CD”.
• “SVCD” is an abbreviation of “Super Video CD”.
2
About discs
Playable disc types
Discs you can play:
*3
*3
Video
Format
NTSC
—
–
–
Playable
Playable
*1
*2
*3
*3
Disc Type Mark (Logo)
DVD
VIDEO
DVD
AUDIO
AUDIO
VCD NTSC
SVCD NTSC
CD —
The “Playable” in the following list shows available disc
types and recording formats.
Disc type
Recording
CD-R/-RW*1DVD-R*1DVD-RW
format
DVD Video
DVD Audio
*2
DVD V R
VCD/SVCD Playable
Audio CD Playable
MP3/WMA/
JPEG
MPEG1/
MPEG2
• A DVD VR formatted DVD-ROM is also playable.
*1 This system can play finalized discs only.
*2 Only when a DVD-R/-RW is compatible with CPRM
(Content Protection for Recordable Media), DVD VR
format can be used.
*3 Recorded with UDF Bridge format.
However, some discs may not be played back because of
their disc characteristics, recording conditions, or
damage or stain on them.
Only sounds can be played back from the following discs:
MIX-MODE CD CD-G
CD-EXTRA CD TEXT
–
– Playable Playable
–
Playable Playable
Playable Playable
Playable Playable
Playable*2Playable
–
–
is a trademark of DVD Format/Logo
Licensing Corporation.
Introduction
Caution for DualDisc playback
The non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore,
the use of Non-DVD side of a DualDisc on this product
may not be recommended.
Note on Region Code
DVD VIDEO players and DVD VIDEO discs have their
own Region Code numbers. This system can play back
DVD VIDEO discs whose Region Code numbers include
the system’s Region Code, which is indicated on the rear
panel.
Examples:
If a DVD VIDEO with an improper Region Code number
is loaded, “REGION CODE ERROR!” appears on the TV
screen and playback cannot start.
• On some DVD VIDEOs, DVD AUDIOs, VCDs or SVCDs,
their actual operation may be different from what is
explained in this manual. This is due to the disc
programming and disc structure, not a malfunction of
this system.
Notes on CD-R and CD-RW
• This system supports “multi-session” discs (up to 20
sessions).
• This system cannot play “packet write” (UDF format)
discs. Some discs may not be played back because of
their disc characteristics, recording conditions, or
damage or stain on them.
Discs that cannot be played back
• DVD-RAM, CD-ROM, CD-I (CD-I Ready), Photo CD,
SACD, etc.
Playing back these discs will generate noise and
damage the speakers.
Damaged discs and discs in an extraordinary shape
(other than a disc of 12 cm or 8 cm (5 inches or 3 inches)
in diameter) cannot be played back.
Notes on all files
• The system can only recognize and play files with one
of the following extensions, which can be in any
combination of upper and lower case;
• MP3: “.mp3”
• WMA: “.wma”
• JPEG: “.jpg”, “.jpeg”
• MPEG1/MPEG2: “.mpg”, “.mpeg”
• If a character other than single byte English characters
is used in the file name, the track/file name will not be
displayed correctly.
• The system recognizes up to 150 tracks (files) per
group, 99 groups per disc, and the total number of the
tracks (files) that the system can play is 4 000.
• Since the unit ignores the tracks/files whose numbers
are exceeding 150 and the groups whose numbers are
exceeding 99, they cannot be played back.
• Some files may not be played back normally because
of their disc characteristics or recording conditions.
• It is possible to playback finalized +R/+RW (DVD Video
Format only) discs, “DVD” lights on the front display
panel when a +R/+RW disc is loaded.
3
About discs (continued)
For MP3/WMA files
• An off-the-shelf MP3 disc may be played in an order
different from that indicated on the label attached to
the disc.
• The system supports MP3/WMA files recorded with a
bit rate of 32 – 320 kbps and a sampling frequency of
16 kHz, 22.05 kHz, 24 kHz (WMA only), 32 kHz, 44.1
kHz, or 48 kHz.
• If the tag information (album name, artist, and track
title, etc.) is recorded on a disc, it appears in the file
control display on the TV screen.
• We recommend to record each piece of material
(song) at a sample rate of 44.1 kHz and at a data
transfer rate of 128 (96 for WMA only) kbps.
• This system cannot play back files encoded with
Multiple Bit Rate (MBR). (MBR is a format to encode a
file content at several different bit rates.)
For JPEG files
• We recommend to record a file at 640 x 480 resolution.
• This system can play a baseline JPEG file, excluding
monochromatic JPEG files.
• This system can play JPEG data taken with a digital
camera conforming to the DCF (Design Rule for
Camera File System) standard (when a function is
applied such as the automatic rotation function of a
digital camera, data goes beyond the DCF standard,
so the image may not be displayed).
• If data has been processed, edited and restored with
PC image editing software, the data may not be
displayed.
• This system cannot play animations such as MOTION
JPEG, or still images (TIFF etc.) other than JPEG, and
image data with sound.
• An image with a resolution of more than 8 192 x 7 680
pixels cannot be displayed.
For MPEG-1/MPEG-2 files
• The stream format should conform to MPEG system/
program stream.
• 720 x 576 pixels (25 fps)/720 x 480 pixels (30 fps) is
recommended for the highest resolution.
• This system also supports the resolutions of 352 x
576/ 480 x 576/ 352 x 288 pixels (25 fps) and 352 x
480/ 480 x 480/ 352 x 240 pixels (30 fps).
• The file format should be MP@ML (Main Profile at
Main Level)/SP@ML (Simple profile at Main Level)/
MP@LL (Main Profile at Low Level).
• Audio streams should conform to MPEG1 Audio layer2 or MPEG2 Audio Layer-2.
Disc structure
DVD VIDEO/DVD VR
A DVD VIDEO consists of “titles” and each title
may be divided into “chapters”.
A DVD VR consists of “original programs” or
“playlists” and each original program/playlist may
be divided into “chapters”.
Title 1/Original program 1/
Play list 1
Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2
DVD AUDIO
A DVD AUDIO consists of “groups” and each group
may be divided into “tracks”.
Some discs include a “bonus group” that requires a
password for playing (page 27).
Group 1 Group 2
Track 1 Track 2 Track 3 Track 1 Track 2
VCD/SVCD/CD
VCD, SVCD and CD consist of “tracks”.
In general, each track has its own track number.
(On some discs, each track may also be further
divided by indexes.)
Track 1 Track 2 Track 3 Track 4 Track 5
MP3/WMA/JPEG/MPEG1/MPEG2 discs
On an MP3/WMA/JPEG/MPEG1/MPEG2 disc,
each still picture (material) is recorded as a track/
file. Tracks/Files are usually grouped into a folder.
Folders can also include other folders, creating
hierarchical folder layers.
This unit simplifies the hierarchical construction of
a disc and manages folders by “groups”.
Title 2/Original
program 2/ Play list 2
4
Group 1 Group 2
Track 1
[File 1]
• If there is any type of files other than
JPEG/MPEG1/MPEG2
Track 2
[File 2]
Group 3 Group 4 Group 5
MP3/WMA/
files in a folder, those
files are also counted in the total file number.
Description of parts
The numbers represent the page numbers.
Front panel
Introduction
See “Display
window” below.
STANDBY lamp
STANDBY
14
Top of the unit
14
15
15
16
In the door
11
32
12
PHONESAUX 1 USB AUDIO
DVD/CD
12
*
USB
FM/AM
31 32
12
* Connect headphones (not supplied) with a stereo mini plug. If the headphones are connected, the
speakers and subwoofer will not produce any sound.
Display window
13
18 26 27
27 13
AUX
33
12
PRGM. AL L SLEEP 3D PHONICA. STANDBYA-B 12 31RANDOM
Rear panel
RESUME
20 21 17, 22 35
8
AUX 2
AM
EXT
AM
LOOP
10
R
8
10
10
L
PCM/
STREAM
DVD OPTICAL
DIGITAL OUT
SUB-
WOOFER
OUT
FM75
Ω
COAXIAL
ANTENNA
COMPONENT
YPBP
11
BONUS B. S . P. ST AUTOPROGRESSIVESVCDVD-A
36 36 31
SPEAKERS
CAUTION:
SPEAKER IMPEDANCE
4Ω-16Ω
RL
VIDEO
R
S-VIDEO
VIDEO OUT
26
25
9
11
These holes discharge heat
generated inside the unit.
Do not cover up these holes.
11
11
5
Using the remote control
The numbers represent the page numbers.
26
7
13, 16
12
Putting the batteries in the remote control
7
32
31
15, 17, 27
7
7
15, 31
14
14,18
19
19, 28
29
24
24
27
34, 35
33
35
36
36
20
16
16
USB FM/AM
12
33
16
15
16
16
Remote control
mode selector
15, 31
12, 14, 17,
18, 21
14
14
19
20, 23, 28
24
25
25, 26
13
25, 26
7, 15
31
17, 22
31
23
10
Batteries
If the range or effectiveness of the remote control
decreases, replace the batteries. Use two R6
(SUM-3)/AA(15F) type dry-cell batteries.
6
CAUTION
•Do not use a used battery and a new battery
together.
• Do not use different types of batteries at the
same time.
• Take out the batteries if the remote control is not
to be used for a long time. Otherwise it may
cause a leakage.
Remote control operation
When operating the remote control, point it
towards the front panel of the main unit. If the
remote control is operated from a direction that is
extremely oblique or when there is an obstacle in
the way, signals may not be transmitted.
If the remote control sensor is exposed to a strong
light such as direct sunlight, correct operation may
not be carried out.
Getting started
This page is for when operating your TV using the
remote control of this product.
Operating the TV using the remote control
Manufacturer Code Manufacturer Code
JVC 01 Samsung 12
Hitachi 10 Sanyo 13, 14
Magnavox 02 Sharp 06
Mitsubishi 03 Sony 07
Panasonic 04, 11 Toshiba 08
Philips 15 Zenith 09
RCA 05
NOTE
Manufacturer’s codes may be changed without notice.
You may not be able to operate a TV produced by the
manufacturer shown above.
5 Release TV.
For TV operation
Operate the remote control by pointing it towards
the TV.
Turn ON/OFF the power.
Change channels.
Setting the manufacturer’s code
1 Slide the remote control mode
selector to the TV side.
2 Keep pressing down TV.
NOTE
Keep pressing down TV until Step 4 is complete.
3 Press ENTER.
4 Press number buttons (1-9, 0).
Ex.:
For a Hitachi TV: Press 1, then 0.
For a Toshiba TV: Press 0, then 8.
If there are more than one manufacturer’s codes,
try them in turn and select the one that causes the
product to work properly.
Adjust volume.
9
100+
Alternates between the
previously selected channel
and the current channel.
Switch TV and video input.
*1 Make sure to slide the remote control mode
selector to the TV side in advance.
NOTE
When the batteries are replaced, perform the
manufacturer’s code setting again.
Select channels.
*1
7
Connecting up
– Do not turn on the power until the connection is complete –
Connecting antennas
Connecting AM loop antenna (supplied)
1 Set up the AM loop antenna.
2 Connect antenna cords.
Main unit (rear panel)
AM
EXT
AM
LOOP
If the antenna
cord is covered
with vinyl on the
tip, twist and pull
the vinyl off and
remove.
Connect the end of the
antenna cord as shown
above.
3 Turn the AM loop antenna to the direction of the
best radio reception.
Locate the AM loop antenna as far away from
the main unit as possible.
• Do not locate the AM loop antenna on a metallic
table or close to a TV, personal computer, etc.
Otherwise it may result in bad radio reception.
7 When good radio reception cannot be obtained
with the supplied AM loop antenna
Electric wire: 3 - 5 m (not supplied)
Connecting FM antenna (supplied)
Main unit
(rear panel)
FM antenna
FM75Ω
COAXIAL
Put the antenna up straight in the direction where
the best radio reception can be obtained, and fix
by using tape.
7 When good radio reception cannot be obtained
with the supplied antenna or when using a
communal antenna
Communal
antenna terminal
Outdoor FM
antenna
(not supplied)
Coaxial cable
(not supplied)
Main unit
(rear panel)
FM75Ω
COAXIAL
Antenna cord (not
supplied)
or
Converter
(not supplied:
compatible with
300
Ω/75 Ω)
Electric wire
Twist
LOOP
AM loop
antenna
AM
EXT
AM
Main unit
(rear panel)
Extend an electric wire
horizontally, preferably
in a high place such as
above a window or
outdoors.
Connect the AM loop
antenna cords together with
the electric wire.
When positioning the antenna, find the best
position for reception while listen to an actual radio
program (refer to “Listening to a radio broadcast”
on page 31).
8
Depending on the radio reception
conditions, an FM feeder antenna (not
supplied: compatible with 300
used. In the case, a converter (not
supplied) is required.
Ω) can be
For details of connecting a separately sold
antenna, refer to the user guide for the antenna
or converter.
Getting started
Connecting speakers
There is no difference between the left and right
speakers.
Speaker terminal
Speaker cord
Speaker cord
(supplied)
Without
black line
With
black line
Right speaker
(rear panel)
SPEAKERS
RL
Main unit
(rear panel)
Speaker cord
(supplied)
Without
black line
With
black line
Left speaker
(rear panel)
CAUTION
• DO NOT connect more than one speaker to one
speaker terminal.
• The speakers of this product are magnetically
shielded, but color irregularities may occur on
the TV depending on how the speakers are
installed. Keep in mind the following.
1. Turn off the main power of your TV before
installing the speakers. Wait for about 30
minutes before turning on the TV again.
2. If color irregularity occurs in pictures, keep a
distance of more than 10 cm between the TV
and the speakers.
The speakers employ natural wood for the
diaphragm and the cabinet in order to
reproduce the original sound faithfully.
The appearance will therefore be different
for each unit.
Speaker grille can be detached.
Speaker grille
NOTE
• Impedance of speaker that can be connected to the
main unit is within a range of 4
• In order to have a sufficient cooling effect, leave a
space of more than 1 cm between the main unit and
the speakers or other objects.
Ω
to 16 Ω.
9
Connecting up (continued)
– Do not turn on the power until the connection is complete –
Connecting other devices
This page is for when connecting the main unit
with other devices.
Connecting subwoofer
With an amplifier-built-in subwoofer (not supplied),
you can enjoy a more dynamic bass sound.
Refer to the manual of the subwoofer for details.
Audio cord (not supplied)
(If an audio cord comes with the
amplifier-built-in subwoofer,
you can use the cord.)
Connecting with other audio device
Output
Other audio
device
Audio cord (not supplied)
WhiteRed
SUB-
WOOFER
OUT
Amplifier-built-in subwoofer
(not supplied)
Main unit
When you want to hear sound from the subwoofer,
press S.WFR OUT on the remote control to display
“SUBWOOFER” on the display window on the
main unit. Each time you press the button, the
display toggles between “SUBWOOFER” and
“OFF”.
NOTE
When “SUBWOOFER” is selected, bass sound from
the left and right speakers will be automatically
lowered and the bass sound will be emitted mainly
from the subwoofer.
AUX 2
Input
L
Main unit
R
Connecting with a digital device
Input
Output
Main unit
Digital audio signals are output from this system
only when DVD/CD is selected as the source.
CAUTION
• For details of signals to be output, refer to page
30.
• If connecting the main unit with equipment with the
function of a Dolby Digital decoder, the setting in
“D. RANGE COMPRESSION” of “AUDIO” (page 30)
will be invalid regarding sound from the digital
audio output of the main unit.
Digital device
(MD recorder etc.)
To digital input terminal
Optical digital cord
(not supplied)
PCM/
STREAM
DVD OPTICAL
DIGITAL OUT
10
Getting started
Connecting with a portable audio device
Stereo mini plug cord
(not supplied)
In the door of the
front panel
AUX 1
• By using QP Link (Quick Portable Link), you can
easily start playing back a portable audio device
on this unit. See page 33 for details.
• If an external device is not equipped with a
stereo mini plug audio output, use a plug
adaptor to convert the stereo mini plug to the
corresponding plug of the audio output.
Portable
audio device
Connecting with TV
Supplied composite video cord
Main unit
COMPONENT
YPB PR
VIDEO
VIDEO OUT
S-VIDEO
CAUTION
Connect the main unit directly with a TV (or a
monitor) without routing through a VCR.
Otherwise it may cause picture distortion while
playing.
TV
Connecting by using the component video
cord
You can enjoy better quality pictures than when
using the S-Video cord.
TV
Component video cord
(not supplied)
Blue
Green
COMPONENT
YPB PR
VIDEO OUT
Main unit
CAUTION
Use either the S-Video cord or the component
video cord. If both cords are used, pictures may
not be played properly.
Red
VIDEO
S-VIDEO
Main unit
Connecting directly
TV (or
monitor)
Also, when connecting the main unit to a TV with
a VCR built in, there may be picture distortion
while playing.
You can enjoy pictures of better quality using the
following cord instead of the supplied video cord.
Connecting by using the S-Video cord
Main unit
COMPONENT
YPB PR
VIDEO
VIDEO OUT
S-Video cord (not
supplied)
S-VIDEO
TV
NOTE
• In order to enjoy pictures with Progressive mode
(page 26), the TV is required to have Progressive
video input.
• If the component video input jacks of your TV are
BNC type, use a plug adapter (not supplied) to
convert the plugs.
Connecting the power cord
AC outlet
Supplied power cord
• Connect the power cord after all other
connections are complete.
• The STANDBY lamp (on the front panel) will be
lit.
Main unit
11
Playing discs
Playback
(Refer also page 17 for playing MP3/WMA/JPEG/MPEG1/
MPEG2.)
page 5
Press AUDIO.
1
• The power will be turned on and the STANDBY lamp will go off.
• Press AUDIO again to turn off the power.
Press 0OPEN/CLOSE to open the disc
2
Place a disc with the label side
facing up.
• Place an 8 cm (3 inches)
disc in to the hollow part in
the center.
tray to load a disc.
Press DVD/CD 3.
3
The disc tray will close and playback will start.
• The power will be turned on when any of DVD/
CD 3, USB, FM/AM, AUX, or 0 on the main
unit and DVD/CD 3, USB, FM/AM, AUX, or
0OPEN/CLOSE on the remote control is
pressed while the power is off.
• If any button other than 0 or 0OPEN/CLOSE is
pressed, the source will also be changed (if
there is a disc loaded, playback will start by
pressing the DVD/CD 3 on the main unit or the
remote control).
NOTE
• A menu screen may be displayed on the TV after
starting playback of a DVD/VCD/SVCD. In this
case, select a desired item to playback by using the
following buttons on the remote control.
• Select a desired item using cursor
and press
• Select a desired item using the number buttons.
• Depending on the disc, actual operation may be
different from the description.
ENTER.
5/K/2/3
Screens displayed on the TV when the power is turned ON.
The following messages appear depending on the status of the system.
(When FM, AM, USB or AUX is selected as a source, the messages do not appear.)
NOW READING Appears when the system is reading the disc information. Wait for a while.
REGION CODE
ERROR!
NO DISC Appears when no disc is loaded.
OPEN Appears when opening the disc tray.
CLOSE Appears when closing the disc tray.
CANNOT PLAY THIS
DISC
Appears when the Region Code of the DVD VIDEO does not match the code
the system supports. (page 3)
Appears when trying to playback an unplayable disc.
12
Display window during disc playback
Ex.: When a DVD VIDEO is played
Basic operations
Ex.: When an MP3/WMA/MPEG1/MPEG2 file is
played
SVCDVD-A
Track number
Ex.: When an JPEG file is played
SVCDVD-A
Disc type
Chapter number
Elapsed
playing time
When a DVD VR is played back, PG (original
program) /PL (play list) number is displayed.
Ex.: When a DVD AUDIO is played
SVCDVD-A
Track number
If “BONUS” or “B.S.P.” is displayed during a DVD
AUDIO playback, refer to page 27.
Ex.: When an SVCD or VCD is played
S VCDVD-A
Track number
• When playing an SVCD, the SVCD indicator
lights instead of the VCD indicator.
• PBC (Play Back Control): A signal recorded in a
VCD (version 2.0) for controlling playback. It is
possible to enjoy interactive software or software
with a search function using a menu screen
recorded in a PBC compatible VCD. To play a
disc with the PBC function OFF, carry out the
following operations.
• Designate the track number using the number
buttons while the disc is stopped.
• Designate the track number using x while
the disc is stopped, and then press DVD/CD
3.
• Press RETURN to go back to the upper layer
during the PBC playback of a VCD or SVCD.
Ex.: When a CD is played
SVCDVD-A
Track number
Group number
File number
To switch the display
Press DISPLAY.
Each time you press the button, the display
indication changes temporarily as follows:
• For DVD VIDEO
SVCDVD-A
Title number
• For DVD VR
SVCDVD-A
PG/PL number
• For DVD AUDIO
SVCDVD-A
Group number
• For MP3/WMA
EX.: When an MP3 is played
SVCDVD-A
Group number Track number
• When playing a WMA track, “WMA” appears
instead of “MP3”.
• For MPEG1/MPEG2
Group number Track number
• For SVCD/VCD/CD/JPEG
The clock time indication appears on the display
window.
• Before setting the clock (page 34), “AM 12:00”
appears.
• When the unit is turned off, pressing DISPLAY
turns off the clock indication to save the power
consumption.
Chapter number
Chapter number
Track number
13
Playing discs (continued)
To stop playback
Press 7 during playback.
To pause playback
Press 8 during playback.
To start normal playback again, press DVD/CD 3.
• For JPEG slide-show, pressing DVD/CD 3
starts playback from the next file.
To advance picture frame-by-frame
Select an item on the disc by using the number buttons
NOTE
• Set the remote control mode selector to
AUDIO before using the number buttons.
• For a VCD or SVCD, this operation can be
carried out when the disc is stopped, or during
playback without the PBC function.
• For a DVD AUDIO, CD, MP3/WMA or JPEG, this
operation can also be carried out when the disc is
stopped.
• For a DVD VIDEO, you can select the title before
playing, and you can select chapter while playing.
• This operation may not be carried out for some
discs.
Use number buttons to select the
item you want to play.
• Refer to “How to use the number buttons” on
page 15.
Press 8 during pause.
• Each time you press the button, picture will be
advanced frame-by-frame.
Fast reverse/Fast forward search
Press 1 or y during playback.
• Each time you press the button, the speed
increases (X2, X5, X10, X20, X60). To restore
the normal speed, press DVD/CD 3.
NOTE
• For MP3 and WMA discs/files, the search speed
shown on the TV is different from described above.
• While playing moving pictures, no sound comes out
during Fast reverse/Fast forward search.
• For a CD or DVD AUDIO, sound is intermittent
during Fast reverse/Fast forward search.
14
Basic operations
Playing back from a position 10 seconds before (One Touch Replay)
Press during playback.
NOTE
• This function may not be available for some discs.
• It is not possible to go back to the previous title.
Slow Motion Playback
Press SLOW or SLOW during
pause.
• Each time you press the button, the playback
speed increases ( ×1/32, ×1/16, ×1/8, ×1/4,
×1/2).
• Press DVD/CD 3 to start normal playback
again.
NOTE
• No sound will be produced.
• The picture motion in the reverse direction may not
be smooth.
• For a VCD, SVCD and DVD VR, Slow Motion
Playback can be carried out in the forward direction
only.
Skip to the beginning of the selection
Press 4 or x during playback*.
•Press x to skip the next chapter or track.
•Press 4 once to skip back to the beginning of
the chapter or track currently being played
(except for JPEG).
•Press GROUP/TITLE
or group.
• During playback of a MP3/WMA/JPEG discs,
press x or cursor K to play the next file, or
press 4 or cursor 5 to play the previous file.
NOTE
* For a VCD or SVCD, this operation can be carried
out during playback without the PBC function.
• Except for a DVD VIDEO, this operation can also be
carried out while the disc is stopped.
• This operation may not be carried out for some
discs.
or to select the title
How to use the number buttons
Ex.:
5:
20:
Guide icons displayed on the TV screen (On-screen guide)
: Play
: Pause
: Fast reverse/Fast forward search
: Slow Motion Playback (reverse/
forward directions)
15:
25:
126:
: Containing multi-angle views
(page 24)
: Containing multi-audio languages
(page 24)
: Containing multi-subtitle languages
(page 24)
: The disc cannot accept the operation you
have attempted.
15
Playing discs (continued)
To change the brightness of the display window (DIMMER)
Press DIMMER repeatedly.
• Each time you press the button, the dimmer
mode changes as follows:
AUTO DIMMER:During the video source
playback, the display window
dims and the illumination
automatically turns off.
Playing audio/video files
DIMMER ON: The display window and the
DISPLAY OFF: The display window and the
DISPLAY ON: Cancels the dimmer function.
• When the unit is turned off, pressing DISPLAY
turns off the clock indication to save the power
consumption. At this time, QP Link will be
canceled automatically.
The items above can be carried out for all sources.
illumination dim.
illumination turn off.
Adjusting the volume
Press AUDIO VOL +/–.
NOTE
The volume can be also adjusted by turning the
VOLUME control on the main unit.
Adjusting sound quality
NOTE
Set the remote control mode selector to
AUDIO before using the number buttons.
Bass: Press BASS +/–.
Treble: Press TREBLE +/–.
• Adjustable range: –5 to +5
Turning off the sound temporarily (MUTING)
Press MUTING.
• No sound will come out from the speakers,
headphones and the subwoofer.
• Press MUTING again to restore the sound.
In this function, the sound will not be restored by
following operations.
• Turn off the system directly.
•Press AUDIO VOL +/– directly.
16
Playback
Display of an MP3/WMA disc is described here as
an example.
For a JPEG disc, read “track” as “file”.
NOTE
When playing a disc containing both MP3/WMA/
MPEG1/MPEG2 and JPEG files, set one of them to be
played, then turn on the system again (page 29).
Basic operations
5 Press DVD/CD 3 or ENTER.
NOTE
• GROUP/TITLE can also be used in Step 2.
• The number buttons can also be used in Step
this case, Step
number buttons, refer to page 15.)
• 4 or
5 is not needed. (For how to use the
x can also be used in Step 4.
Repeat playback
4. In
1 Load a disc.
Current group/total
group number
Tag information (for
MP3/WMA)
Current group
Current track (file) / total track
(file) number on current group
Playback mode (PROGRAM,
RANDOM, REPEAT)
Elapsed playing time of
current track (except
for JPEG)
Current track
(file)
Total track (file)
number on disc
Playback status
2 Press cursor 5/K to select a
group.
1 Press REPEAT.
• Each time you press the button, the Repeat
mode and its indication change as follows:
Repeat items On the TV On the display
Current track
(except for JPEG)
Current group REPEAT
Entire disc
All tracks during
Program/Random
play (MP3/WMA
only)
Current track
during Program/
Random play
(MP3/WMA only)
Cancel REPEAT
REPEAT
TRACK
GROUP
REPEAT
ALL
REPEAT
STEP
OFF
window
2 Press DVD/CD 3.
NOTE
• The Repeat types can be changed during playback.
• The Repeat mode will be automatically canceled if
there is a file that cannot be played (page 3).
3 Press cursor 3 to move to the
track list.
• Press cursor 2 to go back to the group list.
4 Press cursor 5/K to select a
track.
Slide-Show Playback
• In Step 5, for a JPEG disc, when DVD/CD 3 is pressed, files will be continuously played from the
selected file (Slide-Show Playback), and when ENTER is pressed, only a selected file will be played.
• Display time for a file in Slide-Show Playback is about 3 seconds.
• When all files are played through, the playback will be automatically stopped.
17
Resume Playback
This system can store the stop point, and when
you start playback again by pressing DVD/CD 3
(even while on standby), it starts from the position
where you have stopped—Resume Play. The
RESUME indicator lights on the display window
when you stop playback.
To suspend playback
Perform any of the following operations during
playback.
Press 7 once.*
Press AUDIO to turn off the power.
Change the source to USB, FM/AM or AUX.*
* Even if the power is turned off by pressing
AUDIO after this, the position where
playback has been stopped will be stored.
NOTE
Set the remote control mode selector to
AUDIO before using the number buttons.
To start playback from the stored
position
Press DVD/CD 3.
NOTE
• This function does not work in Program Playback or
Random Playback.
• The position where playback starts again may be a
little different from the stopped position.
• When a disc menu is displayed, the Resume
function may not work.
• The system also stores the settings of the audio
language, the subtitle language, and the angle
selected when playback is stopped.
• To stop completely while Resume is set to ON,
press 7 twice. (To cancel Resume, see
on page 30)
• At the time of purchase, Resume is set to ON.
Resume can be set to OFF (page 30).
• If you open the tray, the stored position will be
erased.
“RESUME”
18
Select the scene to be played
NOTE
Set the remote control mode selector to
AUDIO before using the number buttons.
Basic operations
1 While the disc is stopped or
during playback, press TOP
MENU/PG to display the original
program or press MENU/PL to
display the play list.
7 Original program
No Date Ch Time Title
1
03/04/06 12:15L 1
09/04/06
2
L 1
L 1
3 18/04/06 08:17
L 1
4 20/04/06 07:47
L 1
5 25/04/06 19:38 Mr. Lawrence
L 1
6 28/04/06 14:20
Channel information
La fleur
23:05
The last struggle
free flyer
BOOM!
Satisfy U
Title name
Recording time
Select the scene from the menu
1 Press MENU/PL or TOP MENU/
PG while the disc is stopped or
during playback*1.
• The disc menu screen will be displayed.
• To display the disc menu while playing back
a VCD or SVCD with PBC function, press
RETURN repeatedly.
•Only TOP MENU/PG can be used for DVD
AUDIOs.
2 Press cursor 5/K/2/3 (only
for a DVD VIDEO or DVD AUDIO)
or the number buttons to select
the scene to be played.
• Refer to “How to use the number buttons”
(page 15).
• When the menu screen has a couple of
pages, press 4 or
page (only for a VCD and SVCD).
x to change the
3 Press ENTER.
NOTE
*1For a VCD and SVCD, this operation can be carried
out only when the PBC function is off.
• This operation cannot be carried out for a disc
without a menu screen.
• Playback may start for some discs without pressing
ENTER.
Recording date
7 Play list
No Date Chap Length Title
1 03/04/06 2 0:23:24 Nebula G.
2 15/04/06 4 1:04:39
3 24/04/06 13 0:41:26
4 27/04/06 17 0:09:08
Recording
date
Number of chapters
included in the title
• The play list will not appear when a play list
has not been recorded to the disc.
CDJ
Secret Garden
S. Walker
Total playback time for the
title
2 Press 5/K to select the
desired title.
3 Press ENTER.
• When you have selected the original
program by pressing TOP MENU/PG in
step 1, playback will start from the selected
title to the following titles.
• When you have selected the play list by
pressing MENU/PL in step 1, only the
selected title will be played back.
19
Designate the time (Time search)
1 Press ON SCREEN twice during
playback*2.
The menu bar will be displayed (page 28).
2 Press cursor 2/3 to select
.
3 Press ENTER.
Program/Random Playback
4 Input the time
*3
using the
number buttons (1-9, 0).
Ex.: When you want to play a DVD VIDEO
from the position of (0 hour) 23
minutes 45 seconds, press the
buttons in the order:
2
• If you input wrong numbers, press cursor 2
to delete the numbers and re-input.
4
3
5
5 Press ENTER.
To remove the menu bar, press ON SCREEN.
NOTE
• This function does not work for a DVD VIDEO with
no time information recorded.
• This function does not work during Program or
Random Playback.
2
*
For a VCD and an SVCD, the operation can be
carried out when the disc is stopped or during
playback without the PBC function.
3
*
Time search for a DVD VIDEO is from the beginning
of the title, for a DVD AUDIO from the beginning of
the track being played. Time search for a VCD, an
SVCD and a CD is as follows:
• When the disc is stopped, time search is from the
beginning of the disc.
• When the disc is being played, time search is
within the track currently being played.
NOTE
Set the remote control mode selector to
AUDIO before using the number buttons.
Play the disc in the desired order (Program Playback)
It is possible to program a maximum of 99 chapters
or tracks. The same chapter or track can be
programmed more than once.
1 While the disc is stopped, press
PLAY MODE repeatedly to
display “PROGRAM” on the
display window on the main
unit.
TV screen
20
Program
screen
2 Create a program following the
description on the TV screen.
Refer to “How to use the number buttons”
(page 15).
• The input content varies depending on the
disc type.
• DVD VIDEO: Titles and chapters
• VCD, SVCD, CD: Tracks
• DVD AUDIO, MP3/WMA:
Groups and tracks
• To select a DVD AUDIO bonus group, carry
out the operations of “Playing the Bonus
Group” on page 27 in advance to erase the
display “BONUS”.
• If the input number of chapters or tracks is
greater than 99, “MEM FULL” will be
displayed.
To program on the display window on the main
unit, operate as follows:
(1) Select a title/group using the number buttons.
(2) Designate a chapter/track number using the
number buttons.
• Refer to “How to use the number buttons”
(page 15).
• The program number will be displayed on
the display window (Ex.: “P2”).
(3) Repeat the above operations (1) and (2) to
complete the program. Then, advance to
Step
3.
Advanced operations
Playing the disc in a random order (Random Playback)
1 Press PLAY MODE repeatedly
to display “RANDOM” on the
display window on the main unit
while the disc is stopped.
• “RANDOM” will also be displayed on the TV
screen.
2 Press DVD/CD 3.
• The same chapter or track will not be
played twice.
• To resume normal playback, press PLAY
MODE repeatedly to show the playback
indication on the display window on the
main unit while the disc is stopped.
• Random Playback will also be canceled by
carrying out the following operations:
• Open the disc tray
• Turn off the power
• The previous track will not be returned to
even if 4 is pressed repeatedly during
Random Playback (the beginning of the
current chapter or track will be returned to).
NOTE
• The group/title number flashes on the display
window after making each program step.
• Only for a DVD VIDEO, DVD AUDIO, or an MP3/
WMA: If you press ENTER instead of designating a
track/chapter number,
the tracks/chapters in the selected group/title are
programmed.
“ALL” is displayed and all of
3 Press DVD/CD 3.
• To resume normal playback, press PLAY
MODE repeatedly to show the playback
indication on the display window on the
main unit while the disc is stopped. The
program content will not be erased.
• The following operations erase the program
content:
•Press CANCEL repeatedly (Programs
will be erased one by one)
•Press
• Open the disc tray
• Turn off the power
7 while the disc is stopped
21
Repeat Playback
Refer to page 17 for Repeat Playback of MP3/
WMA/JPEG/MPEG1/MPEG2 files.
Playing the title/chapter/ group/track/all tracks repeatedly (REPEAT)
Press REPEAT during playback.
• Each time you press the button, the Repeat
mode and its indication change as follows:
For DVD VIDEO
Repeat items On the TV On the display
Current chapter
CHAP
window
SET/QP LINK
Current title
Cancel
TITLE
OFF
For DVD VR
Repeat items On the TV On the display
Current chapter
Current original
program
All original
programs
Current play list
Cancel
CHAP
PG
ALL
PL
OFF
window
For DVD AUDIO
Repeat items On the TV On the display
Current track
Current group
TRACK
GROUP
window
22
Cancel
OFF
For CD/VCD/SVCD
Repeat items On the TV On the display
Current track
TRACK
window
Advanced operations
Playing the designated part repeatedly (A-B Repeat Playback)
All tracks
Cancel
NOTE
• For a VCD and SVCD, the operation can be carried
out only when the disc is stopped or during playback
without the PBC function.
• It is possible to set Repeat mode on the menu bar.
For how to operate, refer to “Playing the designated
part repeatedly (A-B Repeat Playback)” (See the
right column).
• For a DVD VIDEO and DVD AUDIO, if the source is
switched to FM, AM, USB or AUX, the Repeat mode
will be canceled.
ALL
OFF
Repeat Playback during Program or
Random Playback
Repeat items On the TV On the display
Current chapter/
track
All tracks during
Program/Random
play
Cancel
STEP
or REPEAT
STEP
ALL
or REPEAT
ALL
OFF
or no
indication
window
1 Press ON SCREEN twice during
playback.
The menu bar (page 28) will be displayed.
2 Press cursor 2/3 to select
OFF
.
3 Press ENTER.
4 Press cursor 5/K to display
OFF
A B
.
Other Repeat modes can be selected here.
For other Repeat modes, refer to “Playing the
title/chapter/group/track/all tracks repeatedly
(REPEAT)”
(page 22).
5 Press ENTER at the start point
of the part to be repeated
(designating A point).
• The icon on the menu bar will be .
A-
6 Press ENTER at the end point of
the part to be repeated
(designating B point).
• The icon on the menu bar will be
and the part between A and B points will be
played repeatedly.
• A-B Repeat Playback will be canceled by
carrying out the following operations:
•Press 7.
• Select and press ENTER twice.
• Change the current track/file.
A-B
A-B
NOTE
• A-B Repeat Playback is possible only within the
same title or track. A-B Repeat Playback cannot be
carried out during PBC playback, Program
Playback, Random Playback and Repeat Playback.
• You can use the A-B Repeat Playback using the
REPEAT A-B button on the remote control.
• For some DVD discs, A-B Repeat Playback does
not work.
23
Loading...
