Unique truck concept with
front seat and side-mounted
mast
Unrestricted view of forks, load
and travel route
High flexibility through
modular design and RFID
technology
High level of eciency:
Double benefit of energy
regeneration and eective
energy management
EFX 410/413
Electric front seat/tri-lateral stacker (1,000/1,250 kg)
The tri-lateral stackers EFX 410 and EFX
413 with 48 V 3-phase AC technology,
1000 to 1250 kg capacity and lift heights
up to 7000 mm represent versatility and
excellent flexibility in the narrow aisle
warehouse. The EFX can be used in
either guided mode or as a free-ranging
truck. The advantage: Combined operation in narrow aisles, wide aisles and the
apron area.
The EFX operator benefits: Thanks to
comfortable entry and exit, the vibrationabsorbing comfort seat which can be
adjusted to the operator’s weight and
height and automotive pedal arrangement as in a car. Large storage areas,
clear contours and the latest ergonomic
operational devices make work significantly more pleasant and thus faster.
The focal point is the unique truck concept with a front seat and side-mounted
mast for an unrestricted view of forks,
load and travel route. The performance-enhancing operating concept also
features a control panel with infinitely
variable height and distance adjust-
ment and the large display. With a whole
range of innovative features, this system
represents the very latest in ergonomics:
• Ergonomic controls with thumb-activated control of hydraulic functions for
lifting, lowering, turning and reaching.
• Integrated soft-feel steering wheel to
aid precise, safe handling.
• Information is transmitted via graphic
display. Important operating data is displayed rapidly and clearly in icon form.
• Outstanding visibility and unrestricted
view of forks, load and travel route.
EFX 410/413
l 2
h4
h3
h2
s
r
b8
b12
Ast
b
b7
l 6
Q
5
c
l
m1
3
l
l
8
b3
b
14
e
Standard values for working aisle widths (mm)
with rail guidance
Pallet size Stacking
depth
AST* Ast
theoretical
/VDI
3
AST3** prac-
tical
1200 x 800 1200 1740 3187 +500
1200 x 1200 1200 1740 3486 +500
800 x 1200 800 1390 3401 +500
h1
Pallet size Stacking
h6
1200 x 800 1200 1810 3187 +1000
with wire guidance
depth
Ast Ast
theoretical
/VDI
3
AST3** prac-
tical
1200 x 1200 1200 1810 3486 +1000
800 x 1200 800 1460 3401 +1000
* to h3 = 4000 mm / for + 20 for h3 > 4000 – 6000 mm /+ 70 mm for h3 > 6000 mm
h7
m2
x
Ast 3
y
l 1
b2
a/2
z
b1
b
6
Wa
** The practical intersecting aisle width is a guide value.
Standard mast types EFX 410/413
Lift
h
3
Lowered mast height
h
1
(mm) (mm) (mm) (mm)
Duplex ZT
3000
2305 66 3772
1)
3250 2430 66 4022
3500 2555 66 4272
3750 2680 66 4522
4000 2805 66 4772
4250 2930 66 5022
4500 3055 66 5272
4750 3250 66 5592
5000 3375 66 5842
5250 3500 66 6092
5500 3625 66 6342
5750 3750 66 6592
6000 3875 66 6842
Triplex DZ
4000
4250
4500
1)
1)
2100 1410 4690
2190 1500 4940
2280 1590 5190
1)
4750 2370 1680 5440
5000 2460 1770 5690
5250 2550 1860 5940
5500 2640 1950 6190
5750 2730 2040 6440
6000 2820 2130 6690
6250 2910 2220 6940
6500 3000 2310 7190
6750 3090 2400 7440
7000 3180 2490 7690
1)
Attention: Overhead guard height 2277 mm or 2370 mm with strobe light on overhead guard
Free lift
h
2
Extended mast height
h
4
Issue: 03/2013
Technical data in line with VDI 2198
1.1 Manufacturer (short form) Jungheinrich
1.2 Model EFX 410 EFX 413
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation tri-lateral stacker
1.5 Load capacity/rated load Q t 1 1.25
1.6 Load centre distance c mm 600
1.8 Load distance x mm 168
Identification
1.9 Wheelbase y mm 1577
1.10 Centre of drive wheel/counterweight z mm 270
2.1.1 Net weight incl. battery (see row 6.5) kg 5080 5360
2.2 Axle load, w. load, front / rear kg 4860 / 1300 5370 / 1320
2.3 Axle load, w.o. load, front / rear kg 3230 / 1850 3340 / 2020
Weights
3.1 Tyres Vulkollan
3.2 Tyre size, at front mm Ø 295 x 144
3.3 Tyre size, at rear mm Ø 343 x 110
chassis
3.5 Wheels, number front/rear (× = driven wheels) 2 / 1x
Wheels /
3.6 Track width, front b
4.2 Mast height (lowered) h1 mm 2805
4.2.1 Total height h15 mm
4.3 Free lift h
4.4 Lift h
4.5 Extended mast height h
4.7 Height of overhead guard h
4.8 Seat height/stand height h
4.19.2 total length (without load) mm 3135
4.20 Length incl. back of forks l
4.21 Total width b
4.22 Fork dimensions s/e/l mm 40 / 100 / 1200
4.23 Fork carriage ISO 2328, class/type A, B 2B
4.24 Fork carriage width b
4.25 Width over forks b
4.27 width over guide rollers mm 1600
4.29 reach, sideways mm 1370
Basic dimensions
4.30 reach, sideways from centre of truck mm 420
4.31 Floor clearance with load under mast m
4.32 Floor clearance centre wheelbase m
4.33.6 Aisle width for pallets 1200 × 1200 Ast mm 1740
4.35 Turning radius W
4.38 distance swivelling fork pivot point mm 843
4.38.3 distance swivelling forks pivot-point to steering rack mm 675
4.38.4 pallet width mm 1200
4.38.5 pallet length mm 1200
4.38.9 Width of swivel reach frame mm 1540
4.38.11 distance swivelling forks pivot-point to back of forks mm 267
5.1 Travel speed, w. / w.o. load km/h 9 / 9
5.2 Lift speed, w. / w.o. load m/s 0.41 / 0.41
5.3 Lower speed, w. / w.o. load m/s 0.44 / 0.44
5.4 Traverse speed w. / w.o. load m/s 0.2 / 0.2
data
5.10 Service brake regenerative
Performance
5.11 parking brake electric spring-loaded
6.1 Drive motor rating S2 60 min. kW 6.9
6.2 Lift motor rating at S3 25% kW 9.5
6.3 Battery according to DIN 43531/35/36 A,B,C, no 5 PzS 625 6 PzS 750
6.4 Battery voltage/nominal capacity K5 V/Ah 48 / 625 48 / 750
Electrics
6.5 Battery weight kg 855 1010
8.1 Type of drive control AC Control
8.4 Sound pressure level at operator’s ear according to EN 12053 dB (A) 66.5
Misc.
8.6 Steering electric
mm 1406
10
mm 66
2
mm 4000
3
mm 4772
4
mm 2277
6
mm 1205
7
mm 2957
2
mm 1210 / 1550
1/b2
mm 890
3
mm 850
5
mm 120
1
mm 85
2
mm 1847
a
3)
2)
1)
1)
with performance pack up to 0.3 m/s
2)
with performance pack up to 0.45 m/s
3)
with transponder reader 45 mm
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Benefit from the advantages
Folding battery cover Control panel
Pioneers of 3-phase AC technology
Over 150 000 Jungheinrich 3-phase
AC trucks are in use all over the world.
This depth of knowledge is reflected in
today’s drive and control technology:
• High throughput levels.
• Low energy consumption.
Steuerungs- und CAN-Bus-System
• Alle Bewegungen sind parametrierbar.
Cost-eective energy management
• Doubled energy recovery through regenerative braking and lowering.
• Longer operating times on a single
battery charge (up to 2 shifts).
• Active energy / battery management.
• Longer battery life.
• Shorter charging times.
RFID ground control (optional)
• Truck control with transponder technology.
• Permanent route measuring for precise
identification of all warehouse areas.
• High degree of flexibility in terms of
switching functions (end of aisle control, lift/travel cut-outs, travel speed
reductions).
• Drive speeds optimised according to
the floor topology.
Jungheinrich warehouse navigation
(optional)
• EFX is linked to a Warehouse Management System (WMS) by a radio data
terminal or scanner.
• Direct loading of the destination in
narrow aisles via the truck computer.
• Automatic vertical and horizontal
positioning.
• Eective twin cycles.
• RFID location detection prevents trucks
travelling to incorrect destinations.
• High level of flexibility in the warehouse with adaptation to existing WMS.
• Throughput improved by up to 25%.
Ergonomic benefits and comfort
• Ample entry room.
• Outstanding view of the load and travel
route.
• Cushioned comfort seat absorbs vibrations.
• Operating console with adjustable
height and distance from the operator.
• Soft keys with numeric keypad.
• Limit position / transition damping for
all hydraulic functions.
Commissioning and maintenance
• Quick and reliable commissioning
through teach-in process.
• Maintenance interval of 1000 operating
hours.
• Electronics with wear-free sensor
system.
Reliable operation – high availability
• 70% fewer cables and plugs due to
CAN-Bus system.
• Robust and maintenance-free threephase AC drive systems - no wearing
parts.
Additional equipment
• Mechanical rail guidance.
• Inductive guidance for precise control
in the aisle with no mechanical loading
of components.
• Radio with CD player and MP3 interface.
• Synchronised traverse.
• Modular system for lift and travel cutouts as well as speed reduction.
• Jungheinrich radio data terminals with
mechanical and electrical interface for
material flow management systems.
• Jungheinrich ISM Online: Information
system for truck management.
Integrated Jungheinrich personnel
protection system (PPS)
• On-site integration with the safety
computer.
• Project planning, commissioning and
maintenance by Jungheinrich.
