John Deere 4420 Service Manual

HP1488 -UN-01JAN94

1A2

COMBINE - 4420

JOHN DEERE 4420 COMBINE WITH 215 PLATFORM

(SPECIFICATIONS AND DESIGN SUBJECT TO CHANGE WITHOUT NOTICE)

COMBINE - 4420 PC1745 (12-JAN-82) 10-1

PN=1

1A3

COMBINE - 4420

NOTE

FOR 200 SERIES PLATFORM PARTS INFORMATION, REFER TO JOHN DEERE 200 SERIES PLATFORM PARTS
CATALOG - PC-1558.

FOR 40 SERIES CORN HEAD PARTS INFORMATION, REFER TO JOHN DEERE 40 SERIES CORN HEAD PARTS
CATALOG - PC-1223.

FOR 50 SERIES ROW-CROP HEAD PARTS INFORMATION, REFER TO JOHN DEERE 50 SERIES ROW-CROP
HEAD PARTS CATALOG - PC-1549.

FOR 50A SERIES ROW-CROP HEAD PARTS INFORMATION, REFER TO JOHN DEERE 50A SERIES ROW-CROP
HEAD PARTS CATALOG - PC-1747.

FOR THREE-ROLLER BELT PICKUP PARTS INFORMATION, REFER TO JOHN DEERE THREE-ROLLER BELT PICKUP
PARTS CATALOG - PC-1189.

IMPORTANT

THIS PARTS CATALOG CONTAINS PARTS INFORMATION FOR THE 4420 COMBINE. MACHINE VINTAGE
IS DETERMINED BY THE COMBINE SERIAL NUMBER OR THE PRODUCT IDENTIFICATION NUMBER (PIN).
IT IS IMPORTANT THAT THE CORRECT NUMBERS BE USED WHEN ORDERING PARTS.

10-2 COMBINE - 4420 PC1745 (28-MAR-84)

PN=2

1A4

COMBINE - 4420

SERIAL NUMBER AND PRODUCT IDENTIFICATION NUMBER (PIN) PLATES

USE ALL NUMBERS, LETTERS AND SPACES SHOWN ON THE SERIAL NUMBER PLATE OR THE PRODUCT
IDENTIFICATION NUMBER PLATE IN WARRANTY CORRESPONDENCE.

COMBINES ( -550000)
ON THESE COMBINES, THE SERIAL NUMBER PLATE IS LOCATED ON THE REAR LEFT-HAND UPRIGHT.
AN EXAMPLE OF THE SERIAL NUMBER ON THIS PLATE IS:

E4420550000H

E - EQUIPMENT
4420 - COMBINE MODEL
550000 - COMBINE SEPARATOR SERIAL NUMBER
H - MANUFACTURING UNIT (HARVESTER WORKS)

COMBINES (550001- )
ON THESE COMBINES, THE PRODUCT IDENTIFICATION PLATE (PIN) IS LOCATED NEAR THE RIGHT-HAND

SIDE OF THE TOOL BOX. AN EXAMPLE OF THE TWO-LINES ON THIS PIN PLATE IS:

H04420X550001

COMBINE

(FIRST LINE)
H0 - MANUFACTURING UNIT (HARVESTER WORKS)
4420 - MODEL IDENTIFIER
X - CONFIGURATION CODE/MODEL IDENTIFIER SUFFIX
550001 - SEQUENTIAL NUMBER USED IN SERIAL NO. COLUMN

(SECOND LINE)
COMBINE - TYPE OF PRODUCT

COMBINE - 4420 PC1745 (28-MAR-84) 10-3

PN=3

1A5

ENGINE SERIAL NUMBER

THE ENGINE SERIAL NUMBER PLATE IS LOCATED ON THE RIGHT-HAND SIDE OF THE ENGINE BLOCK.
ENGINES ( -XXXXXX)
AN EXAMPLE OF THE ONE-LINE, FIFTEEN-DIGIT NUMBER ON THIS SERIAL NUMBER PLATE IS:
6329DH03XXXXXXT
6 - NUMBER OF CYLINDERS

329 - CUBIC INCH DISPLACEMENT
D - FUEL TYPE
H - MANUFACTURING UNIT OF MACHINE (HARVESTER WORKS)
03 - ENGINE VERSION
XXXXXX - ENGINE SERIAL NUMBER
T - MANUFACTURING UNIT OF ENGINE (JOHN DEERE DUBUQUE WORKS)

ENGINES (XXXXXX- )
AN EXAMPLE OF THE TWO-LINE NUMBER ON THIS SERIAL NUMBER PLATE IS:

COMBINE - 4420

T06329DXXXXXX
6329DH03

(FIRST LINE)
T0 - MANUFACTURING UNIT (JOHN DEERE DUBUQUE WORKS)
6 - NUMBER OF CYLINDERS
329 - CUBIC INCH DISPLACEMENT
D - CONFIGURATION CODE/MODEL IDENTIFIER SUFFIX
XXXXXX - SEQUENTIAL NUMBER USED IN SERIAL NO. COLUMN

(SECOND LINE)
6 - NUMBER OF CYLINDERS
329 - CUBIC INCH DISPLACEMENT
D - FUEL TYPE (NON-TURBOCHARGED DIESEL)
H - MANUFACTURING UNIT OF MACHINE (HARVESTER WORKS)
03 - ENGINE VERSION

PARTS LISTING INFORMATION

SERIAL NUMBER OR PRODUCT IDENTIFICATION NUMBER (PIN) INFORMATION SHOWS ON WHICH MACHINES A
PART MAY BE USED. FOR EXAMPLE:

- THE PART CAN BE USED ON ALL MACHINES.

-000000 THE PART CAN BE USED ON ALL MACHINES UP TO AND INCLUDING THE SERIAL NUMBER LISTED.
000000- THE PART CAN BE USED ON ALL MACHINES BEGINNING WITH THE SERIAL NUMBER LISTED.
000000-000000 THE PART CAN BE USED ON ALL MACHINES BETWEEN AND INCLUDING THE SERIAL NUMBERS

LISTED.
WHEN XXXXXX’S ARE LISTED IN PLACE OF A SERIAL NUMBER, A SERIAL NUMBER WAS MADE, BUT THE

EXACT SERIAL NUMBER WAS NOT AVAILABLE WHEN THE CATALOG WAS PRINTED.

10-4 COMBINE - 4420 PC1745 (28-MAR-84)

PN=4

1A6

COMBINE - 4420

DIRECTION ARROW

ARROWS ARE USED WITH ILLUSTRATIONS TO INDICATE THE FRONT OF THE UNIT. "RIGHT-HAND" AND "LEFT­HAND" SIDES ARE DETERMINED BY FACING IN THE DIRECTION OF MACHINE FORWARD TRAVEL.

BOX-ENCLOSED ILLUSTRATIONS

A KEY NUMBER, SHOWN IN THE PARTS LIST, IS ASSIGNED TO A BOX ENCLOSING ALL PARTS SOLD AS A
SERVICE ASSEMBLY. A BOX NOT KEYED INCLUDES NON-CURRENT PARTS.

KITS

KIT INFORMATION WILL BE FOUND IMMEDIATLEY FOLLOWING THE STORY IN WHICH IT IS USED.
THE ILLUSTRATION IS REPEATED WITH ONLY THE KIT PARTS CALLED OUT AND WITH ALL OTHER
PARTS SHOWN IN PHANTOM FOR RELATIONSHIP.

JDM REMANUFACTURED COMPONENTS

THE SERVICE PARTS LISTED IN THIS CATALOG ARE INTENDED FOR THE REPAIR OF ORIGINAL
EQUIPMENT COMPONENTS. ALTHOUGH MOST SERVICE PARTS MAY BE USED TO REPAIR REMANUFACTURED
COMPONENTS, THE REMANUFACTURED DESIGN MAY CHANGE PARTS SUFFICIENTLY SO THAT SERVICE
PARTS ARE INADEQUATE OR NOT USABLE.

BOLT AND CAP SCREW STRENGTH IDENTIFICATION

BOLTS AND CAP SCREWS REQUIRED TO HAVE HIGH-STRENGTH QUALITIES EQUIVALENT TO SAE GRADE 8 ARE
IDENTIFIED THROUGHOUT THIS CATALOG BY THE DESCRIPTION HS SAE 8. ALL STANDARD BOLTS AND CAP
SCREWS ARE SAE GRADE 5 OR LOWER.

COMPLETE GOODS LISTINGS

COMPLETE GOODS ARE LISTED IN BOLD FACE TYPE. ORDER SEPARATELY. DO NOT INCLUDE ON
REPLACEMENT PARTS ORDER.

SI UNITS OF MEASURE

METRIC DIMENSIONS ARE GIVEN, WHERE APPLICABLE, THROUGHOUT THIS PARTS CATALOG.

TRADEMARKS

THROUGHOUT THIS PARTS CATALOG, YOU WILL FIND THE FOLLOWING DEERE & COMPANY TRADEMARKS:
DIAL-A-MATIC™ TORQ-GARD SUPREME®

HARVESTRAK™ QUIK-TATCH™

CHANGE INDICATOR LINE

CHANGES AFFECTING THE ORDERING OF PARTS ARE IDENTIFIED BY VERTICAL LINES MARKED IN THE LEFT-HAND
MARGIN OF REVISED PARTS LISTING IMAGES. A LINE IS ALSO AT THE LEFT-HAND EDGE OF THE SAME
PART NUMBER IN THE NUMERICAL INDEX TO SHOW THE LOCATION OF REVISED INFORMATION.

COMBINE - 4420 PC1745 (06-SEP-85) 10-5

PN=5

1A7

SECTIONAL INDEX

SECTION

GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

BASIC ENGINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

FUEL AND AIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

ELECTRICAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

POWER TRAIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

STEERING AND BRAKES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

HYDRAULICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

SEPARATOR SHELL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

OPERATOR’S STATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

COMBINE - 4420

HEADERS - REFER TO INDIVIDUAL HEADER PARTS CATALOGS . . . . . . . . . . . . . . . . . . . . . 100

FEEDER HOUSE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

SEPARATOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

GRAIN TANK AND UNLOADING AUGER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

MAJOR DRIVES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

HEADER HEIGHT CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

DECALS, BELTS AND CHAINS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

NUMERICAL INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

10-6 COMBINE - 4420 PC1745 (28-MAR-84)

PN=6

1A8

COMBINE - 4420

ALPHABETICAL INDEX

GRID PAGE GRID PAGE

A 1H18 AXLE, FINAL DRIVE (HEAVY-DUTY).................................. 50

1I24 AXLE, REAR .......................................................................... 60 - 18

1F3 ACCUMULATOR PRESSURE GAUGE ................................ 40 - 10 1I25 AXLE, REAR .......................................................................... 60 - 19

2C11 ACCUMULATOR, NAMEPLATE............................................ 70 - 45 1H6 AXLE, SPACERS .................................................................. 50 - 4

2C11 ACCUMULATOR,PRESS.CTL.VALVE AND MTG.BKT. ...... 70 - 45 1H5 AXLE, WHEEL, DRIVE.......................................................... 50 - 3

2K12 ACTUATOR SWITCH AND MOUNTING.............................. 160 -8

1I25 ADJUSTABLE REAR AXLE .................................................. 60 - 19

1D5 AID, COLD WEATHER STARTING ...................................... 30 - 9 B

1E15 AIR CLEANER ...................................................................... 30 - 44

2E11 AIR COND. COMPR. MOUNTING AND SUPPORTS.......... 90 - 30 1H25 BALL JOINT,RELATIVE GRD. SPD. INDICATOR .............. 50 - 23

2E12 AIR COND. COMPRESSOR MTG. & SUPTS. .................... 90 - 31 2H4 BAR, CYLINDER SHEAR...................................................... 120 -25

2E13 AIR COND. CONDENSER AND RECEIVER-DRIER .......... 90 - 33 2I6 BAR, FINGER, CHAFFER FRAME ...................................... 120 -54

2E13 AIR CONDITIONER .............................................................. 90 - 33 1F8 BATTERY BOOT .................................................................. 40 - 15

2E14 AIR CONDITIONER LINES .................................................. 90 - 34 1F8 BATTERY, BRACKETS AND CABLES ................................ 40 - 15

2E14 AIR CONDITIONER, LO PRESSURE SWITCH .................. 90 - 34 1F7 BATTERY, BRACKETS, CABLES, AND SHIELDS.............. 40 - 14

1F12 AIR CONDITIONING WIRING ON ENGINE ........................ 40 - 20 1H17 BEARING CAP AND FINAL DRIVE HOUSING .................. 50 - 15

1F13 AIR CONDITIONING WIRING ON ENGINE ........................ 40 - 21 1B12 BEARING, MAIN .................................................................... 20 - 19

2E16 AIR CONDITIONING, O-RING KIT ...................................... 90 - 36 1B13 BEARING, MAIN .................................................................... 20 - 20

2I11 AIR DUCTS, CLEANING FAN.............................................. 120 -59 1H18 BEARINGS, FINAL DRIVE (HEAVY-DUTY) ........................ 50 - 16

2E4 AIR INTAKE AT REAR OF OPERATOR’S CAB .................. 90 - 23 2G23 BEATER AND TACHOMETER DRIVE ................................ 120 -20

1B25 AIR INTAKE MANIFOLD ...................................................... 20 - 32 2H1 BEATER AND TACHOMETER DRIVE ................................ 120 -22

1E16 AIR INTAKE TUBE................................................................ 30 - 45 3B3 BEATER DRIVE SHEAVES AND BELTS ............................ 170 -12

2J6 AIR INTAKE TUBE COVER .................................................. 130 -4 3A25 BELT AND SHEAVES, SECONDARY COUNTERSHAFT .. 170 -9

1E14 AIR INTAKE TUBES .............................................................. 30 - 43 1C17 BELT TIGHTENER, RADIATOR FAN DRIVE...................... 20 - 49

1D20 AIRTEX FUEL TRANSFER PUMP ASSEMBLY .................. 30 - 24 1G5 BELT, ALTERNATOR ............................................................ 40 - 38

1G5 ALTERNATOR SHEAVE AND BELT .................................... 40 - 38 3A21 BELT, ENGINE R.H. SIDE .................................................... 170 -3

1G7 ALTERNATOR SUPPORTS, FRONT AND REAR .............. 40 - 41 1C16 BELT, RADIATOR FAN ........................................................ 20 - 48

1G6 ALTERNATOR, COMPLETE, 90 AMP ................................ 40 - 39 3A22 BELT, ROTARY SCREEN .................................................... 170 -5

1G1 ALTERNATOR, 72 AMP ........................................................ 40 - 34 3B4 BELT, SHOE GRAIN SUPPLY AUGERS DRIVE ................ 170 -13

1G3 ALTERNATOR, 90 AMP ........................................................ 40 - 36 3B2 BELTS AND CHAINS, FEEDER HOUSE DRIVE ................ 170 -11

2K15 AMPLIFIER AND CIRCUIT BOX .......................................... 160 -11 3B3 BELTS AND SHEAVES, BEATER DRIVE .......................... 170 -12

1F23 ANTENNA, RADIO ................................................................ 40 - 32 3B10 BELTS AND SHEAVES, LOADING AUGER DRIVE............ 170 -21

1G8 ARMATURE ASSEMBLY, STARTER MOTOR .................... 40 - 42 2G23 BELTS, BEATER AND TACHOMETER DRIVE .................. 120 -20

1G11 ARMATURE, STARTING MOTOR........................................ 40 - 45 2H1 BELTS, BEATER AND TACHOMETER DRIVE .................. 120 -22

2D21 ARMRESTS .......................................................................... 90 - 15 3B10 BELTS, CLEAN GRAIN ELEVATOR .................................... 170 -21

2J12 AUGER COUNTERSHAFT, UNLOADING ............................ 130 -10 3A24 BELTS, PRIMARY ................................................................ 170 -7

2J16 AUGER DR.TIGHTENER,AUXILIARY UNLOADING ............ 130 -14 2H17 BLADE, STRAW CHOPPER ................................................ 120 -38

2J10 AUGER DRIVE CONTROL, UNLOADING............................ 130 -8 2H22 BLADE, STRAW SPREADER .............................................. 120 -43

3B9 AUGER DRIVE SHEAVES AND SPROCKETS .................. 170 -19 1F21 BLADE, WINDSHIELD WIPER ............................................ 40 - 30

2I25 AUGER DRIVE TIGHTENER, UPPER TAILINGS................ 120 -74 2K10 BLOCK, CHECK (AUTO HEIGHT)........................................ 160 -6

3B12 AUGER DRIVES, UNLOADING............................................ 170 -23 1A22 BLOCK, CYLINDER .............................................................. 20 - 4

2J17 AUGER HINGE AND SWING, UNLOADING........................ 130 -15 1A24 BLOCK, CYLINDER .............................................................. 20 - 6

2J18 AUGER HOUSING, OUTER UNLOADING .......................... 130 -16 2K6 BLOCK, VALVE, MAIN (AUTO HEIGHT) ............................ 160 -2

2H24 AUGER HOUSING, SHOE GRAIN SUPPLY........................ 120 -45 2F2 BOTTOM, FEEDER HOUSE FALSE .................................... 110 -9

2K9 AUGER SWING .................................................................... 160 -5 2C20 BOX, TOOL............................................................................ 80 - 7

2B7 AUGER SWING CONTROL VALVE, UNLOADING ............ 70 - 12 2C19 BRACE, CROSS, SEPARATOR .......................................... 80 - 6

2B6 AUGER SWING CONTROL, HYDRAULIC .......................... 70 - 11 1F9 BRACKET AND CIRCUIT BREAKERS ................................ 40 - 17

2B11 AUGER SWING HOSES AND LINE, UNLOADING ............ 70 - 17 1F21 BRACKET AND WINDSHIELD WIPER ................................ 40 - 30

2B9 AUGER SWING HYDRAULIC CYLINDER,UNLOADING .... 70 - 15 2C11 BRACKET,MTG.,ACCUMULATOR,AND PRES.CTL.

2B12 AUGER SWING LINE, UNLOADING .................................... 70 - 18 VALVE .............................................................................. 70 - 45

2I12 AUGER, CLEAN GRAIN ...................................................... 120 -60 1H25 BRACKET,RELATIVE GROUND SPEED INDICATOR ........ 50 - 23

2J15 AUGER, INNER UNLOADING .............................................. 130 -13 2D16 BRACKETS, OPERATOR’S CAB MOUNTING .................... 90 - 10

2I20 AUGER, LOWER TAILINGS ................................................ 120 -69 2C8 BRACKETS, PLATFORM LIFT ............................................ 70 - 42

2J17 AUGER, OUTER UNLOADING ............................................ 130 -15 1I10 BRAKE LINES ...................................................................... 60 - 3

2I24 AUGER, UPPER TAILINGS .................................................. 120 -73 1I12 BRAKE MASTER CYLINDER .............................................. 60 - 5

2J20 AUGERS, GRAIN TANK AUXILIARY UNLOADING ............ 130 -18 1I9 BRAKE PEDALS AND LINKAGE.......................................... 60 - 2

2H25 AUGERS, SHOE GRAIN SUPPLY ...................................... 120 -47 1I13 BRAKE SLAVE CYLINDER .................................................. 60 - 6

1E2 AUTOMATIC ADVANCE ...................................................... 30 - 31 1I14 BRAKE SLAVE CYLINDER .................................................. 60 - 7

2K9 AUTOMATIC HEADER HEIGHT LINES .............................. 160 -5 1I15 BRAKE SLAVE CYLINDER KIT............................................ 60 - 9

2B13 AUX. UNLDG. AUG. HYD. DR. SELECTOR VALVE .......... 70 - 19 1I8 BRAKE, PARKING ................................................................ 60 - 1

2B13 AUX. UNLDG. AUG. HYD. DR. VALVE SUPPORT ............ 70 - 19 1I11 BRAKES AND HOUSING...................................................... 60 - 4

2B14 AUX. UNLDG. AUGER HYD. DRIVE OIL LINES ................ 70 - 20 2I22 BUCKET, TAILINGS ELEVATOR ........................................ 120 -71

2J11 AUXILIARY UNLDG. AUGER HYD. DR. CONTROL .......... 130 -9 1F3 BULB, ACCUMULATOR PRESSURE GAUGE .................... 40 - 10

2J16 AUXILIARY UNLOADING AUG. DRIVE TIGHTENER ........ 130 -14 2D16 BUSHINGS, OPERATOR’S CAB MOUNTING .................... 90 - 10

2J16 AUXILIARY UNLOADING AUGER DR.MOTOR SUPT. ...... 130 -14

2B15 AUXILIARY UNLOADING AUGER HYD. DR. MOTOR ...... 70 - 21

2J21 AUXILIARY UNLOADING AUGERS DRIVE SHAFT ............ 130 -19

COMBINE - 4420 PC1745 (18-APR-00) 10-7

- 16

PN=7

1A9

COMBINE - 4420

ALPHABETICAL INDEX - CONTINUED

GRID PAGE GRID PAGE

C 2E9 COMPRESSOR, HI PRESSURE SWITCH .......................... 90

2G17 CONCAVE ADJUSTING CONTROLS.................................. 120 -13

2D23 CAB BODY, OPERATOR’S .................................................. 90 - 17 2G16 CONCAVE ADJUSTING SHAFT .......................................... 120 -12

2E2 CAB ROOF ............................................................................ 90 - 21 2G11 CONCAVE, OPEN-BAR........................................................ 120 -7

2E2 CAB ROOF RECIRCULATING FILTERS ............................ 90 - 21 2G16 CONCAVE, SECTOR ............................................................ 120 -12

1F12 CAB, OPERATOR’S .............................................................. 40 - 20 2G14 CONCAVE, SPIKE-TOOTH .................................................. 120 -10

1F13 CAB, OPERATOR’S .............................................................. 40 - 21 2E13 CONDENSER AND RECEIVER-DRIER, AIR COND. .......... 90 - 33

2F13 CABLE, FLOAT SPRING INDICATOR ................................ 110 -20 1A21 CONDITIONER, COOLANT AND STOP LEAK .................... 20 - 3

1I8 CABLE, PARKING BRAKE .................................................. 60 - 1 1F3 CONNECTOR, ACCUMULATOR PRESSURE GAUGE ...... 40 - 10

1H25 CABLE, RELATIVE GROUND SPEED INDICATOR............ 50 - 23 1G17 CONNECTOR, ELECTRICAL, SERVICE KIT...................... 40 - 52

1G15 CABLE, WIRING.................................................................... 40 - 50 1G21 CONNECTORS, SUPPLEMENTARY TERMINALS.............. 40 - 56

1F8 CABLES, BATTERY AND BRACKETS ................................ 40 - 15 2D22 CONSOLE AND INSTRUMENT PANEL .............................. 90 - 16

1B17 CAMSHAFT ............................................................................ 20 - 24 2A23 CONTROL VALVE, HYDRAULIC .......................................... 70 - 4

1B12 CAP, MAIN BEARING .......................................................... 20 - 19 2B1 CONTROL VALVE, HYDRAULIC .......................................... 70 - 6

1F23 CAPACITOR, RADIO ............................................................ 40 - 32 2B7 CONTROL VALVE, UNLOADING AUGER SWING ............ 70 - 12

1B13 CAPS, MAIN BEARING ........................................................ 20 - 20 2B8 CONTROL VALVE, UNLOADING AUGER SWING ............ 70 - 13

2I4 CHAFFER AND SIEVE.......................................................... 120 -51 2K14 CONTROL, DIAL-A-MATIC HEADER HEIGHT .................... 160 -10

2I6 CHAFFER FRAME, UPPER SHOE ...................................... 120 -54 2K15 CONTROL, DIAL-A-MATIC HEADER HEIGHT .................... 160 -11

2F10 CHAIN GUIDES, DRIVE, FEEDER CONVEYOR ................ 110 -17 2B6 CONTROL, HYDRAULIC AUGER SWING .......................... 70 - 11

2I14 CHAIN, CLEAN GRAIN ELEVATOR CONVEYOR .............. 120 -62 2F24 CONTROL, PLATFORM VARIABLE BELT DRIVE .............. 110 -31

2F8 CHAIN, CONVEYOR, FEEDER............................................ 110 -15 2J10 CONTROL, UNLOADING AUGER DRIVE............................ 130 -8

3A24 CHAIN, PRIMARY.................................................................. 170 -7 2C11 CONTROL,PRES.VALVE,ACCUMULATOR AND MTG.

3B2 CHAINS AND BELTS, FEEDER HOUSE DRIVE ................ 170 -11 BKT. .................................................................................. 70 - 45

2K10 CHECK BLOCK (AUTO HEIGHT) ........................................ 160 -6 2B4 CONTROL,VARIABLE SPEED CYLINDER-SEP.SIDE ........ 70 - 9

2H15 CHOPPER CURTAIN AND SHIELDS, STRAW .................. 120 -36 2J11 CONTROLS, AUXILIARY UNLDG. AUG. HYD. DR............. 130 -9

2H9 CHOPPER HOUSING, STRAW ............................................ 120 -30 1I8 CONTROLS, BRAKE, PARKING.......................................... 60 - 1

2H11 CHOPPER, STRAW .............................................................. 120 -32 2G17 CONTROLS, CONCAVE ...................................................... 120 -13

2H13 CHOPPER, STRAW, PLATES AND FINS............................ 120 -34 1H3 CONTROLS, GEARSHIFT .................................................... 50 - 1

2K15 CIRCUIT BOX AND AMPLIFIER .......................................... 160 -11 1H24 CONTROLS, GROUND SPEED............................................ 50 - 22

1F9 CIRCUIT BREAKERS AND BRACKET ................................ 40 - 17 1H24 CONTROLS, GROUND SPEED INDICATOR...................... 50 - 22

1H25 CLAMP, RELATIVE GROUND SPEED INDICATOR .......... 50 - 23 1I8 CONTROLS, HYDROSTATIC DRIVE REEL ........................ 60 - 1

2I12 CLEAN GRAIN AUGER AND HOUSING ............................ 120 -60 2D9 CONTROLS, PIVOTING LADDER ........................................ 90 - 3

3B10 CLEAN GRAIN ELEVATOR .................................................. 170 -21 2B16 CONTROLS, REEL LIFT ...................................................... 70 - 22

3B10 CLEAN GRAIN ELEVATOR BELTS .................................... 170 -21 2J1 CONTROLS, SEPARATOR DRIVE ...................................... 120 -75

2I14 CLEAN GRAIN ELEVATOR CONVEYOR CHAIN................ 120 -62 1I1 CONTROLS, SPEED, SELECTIVE GROUND .................... 50 - 24

2I14 CLEAN GRAIN ELEVATOR CONVEYOR SHAFT .............. 120 -62 1D4 CONTROLS, THROTTLE ...................................................... 30 - 8

2I14 CLEAN GRAIN ELEVATOR CONVEYOR SHEAVE ............ 120 -62 2K1 CONTROLS, VARIABLE SPEED CLEANING FAN ............ 140 -4

2I14 CLEAN GRAIN ELEVATOR CONVEYOR SPROCKETS .... 120 -62 2B5 CONTROLS, VARIABLE SPEED CYLINDER ...................... 70 - 10

2I17 CLEAN GRAIN ELEVATOR DRIVE IDLER.......................... 120 -65 1C9 COOLANT HEATER, ENGINE .............................................. 20 - 41

2I16 CLEAN GRAIN ELEVATOR DRIVE TIGHTENER................ 120 -64 1B22 COOLER, OIL, ENGINE ........................................................ 20 - 29

2I13 CLEAN GRAIN ELEVATOR HOUSING ................................ 120 -61 1B23 COOLER, OIL, ENGINE ........................................................ 20 - 30

3B10 CLEAN GRAIN ELEVATOR SHEAVES ................................ 170 -21 1I4 COUNTERSHAFT SHEAVE, PROPULSION DRIVE............ 50 - 27

2I12 CLEAN GRAIN LOWER AUGER AND HOUSING .............. 120 -60 2I15 COUNTERSHAFT, CLEAN GRAIN ELEVATOR DRIVE...... 120 -63

1E15 CLEANER, AIR...................................................................... 30 - 44 2F21 COUNTERSHAFT, PLAT. LOWER VAR. DR. BELT .......... 110 -28

2I9 CLEANING FAN .................................................................... 120 -57 2F22 COUNTERSHAFT, PLATFORM UPPER CHAIN DRIVE .... 110 -29

3B5 CLEANING FAN .................................................................... 170 -15 2J24 COUNTERSHAFT, PRIMARY .............................................. 140 -2

2I11 CLEANING FAN AIR DUCTS .............................................. 120 -59 3A24 COUNTERSHAFT, PRIMARY .............................................. 170 -7

2K1 CLEANING FAN DRIVE ADJUSTMENT .............................. 140 -4 1I5 COUNTERSHAFT, PROPULSION DRIVE............................ 50 - 28

2I10 CLEANING FAN HOUSING AND SHIELD .......................... 120 -58 2K1 COUNTERSHAFT, SEPARATOR, SECONDARY ................ 140 -4

3B5 CLEANING SHOE AND STRAW WALKER DRIVES .......... 170 -15 1H12 COUNTERSHAFT, TRANSMISSION .................................... 50 - 10

2D14 CLOSURE, ENGINE POWERSHAFT .................................. 90 - 8 2J12 COUNTERSHAFT, UNLOADING AUGER ............................ 130 -10

1H22 CLUTCH AND HOUSING, DRIVE WHEEL .......................... 50 - 20 2E21 COUPLER AND SHIELDS, QUIK-TATCH ............................ 110 -1

1H23 CLUTCH INPUT SHAFT AND HOUSING ............................ 50 - 21 2B23 COUPLERS AND HOSES .................................................... 70 - 32

1H21 CLUTCH PEDAL AND LINKAGE.......................................... 50 - 19 1F3 COVER, ACCUMULATOR PRESSURE GAUGE ................ 40 - 10

2E9 CLUTCH, COMPRESSOR .................................................... 90 - 28 2J6 COVER, AIR INTAKE TUBE ................................................ 130 -4

1F2 CLUTCH, PLATFORM ELECTROMAGNETIC...................... 40 - 9 2J8 COVER, EXTENSION SHEETS, GRAIN TANK .................. 130 -6

2E8 CLUTCH, PULLEY, AND COMPRESSOR COIL ................ 90 - 27 1E6 COVER, FUEL INJECTION PUMP ...................................... 30 - 35

1G10 COIL ASSEMBLY, STARTING MOTOR .............................. 40 - 44 2J13 COVER, INNER UNLOADING AUGER ................................ 130 -11

2E8 COIL, CLUTCH, PULLEY, AND COMPRESSOR ................ 90 - 27 1B10 COVER, ROCKER ARM ...................................................... 20 - 17

2K11 COIL, SOLENOID CONTROL VALVE (AUTO HGT.) .......... 160 -7 1B11 COVER, ROCKER ARM ...................................................... 20 - 18

1D5 COLD WEATHER STARTING AID ...................................... 30 - 9 2J7 COVER, SIDE SHEETS, GRAIN TANK .............................. 130 -5

2E9 COMPRESSOR CHARGE LABEL........................................ 90 - 28 1B4 COVER, TIMING GEAR........................................................ 20 - 11

2E9 COMPRESSOR CLUTCH...................................................... 90 - 28 2J9 COVER, TOP SHEETS, GRAIN TANK................................ 130 -7

2E8 COMPRESSOR COIL, CLUTCH, AND PULLEY ................ 90 - 27 2J20 COVERS, GRAIN TANK AUXILIARY UNLOADING ............ 130 -18

2E10 COMPRESSOR HARDWARE SET ...................................... 90 - 29 2G17 CRANK, CONCAVE CONTROL............................................ 120 -13

2E11 COMPRESSOR, AIR COND., MTG. & SUPTS. .................. 90 - 30 2I8 CRANK, SHOE PITMAN ...................................................... 120 -56

2E12 COMPRESSOR, AIR COND., MTG. & SUPTS. .................. 90 - 31 1B14 CRANKSHAFT AND IDLER GEARS.................................... 20 - 21

10-8 COMBINE - 4420 PC1745 (18-APR-00)

- 28

PN=8

1A10

COMBINE - 4420

ALPHABETICAL INDEX - CONTINUED

GRID PAGE GRID PAGE

1B15 CRANKSHAFT AND IDLER GEARS.................................... 20 - 22 2J10 DRIVE CONTROL, UNLOADING AUGER............................ 130 -8

1B16 CRANKSHAFT KIT, UNDERSIZE ........................................ 20 - 23 2H18 DRIVE IDLER, STRAW CHOPPER ...................................... 120 -39

2H6 CRANKSHAFT, STRAW WALKER ...................................... 120 -27 2J21 DRIVE SHAFT, AUXILIARY UNLOADING AUGERS .......... 130 -19

2H7 CRANKSHAFT, STRAW WALKER ...................................... 120 -28 2I16 DRIVE TIGHTENER, CLEAN GRAIN ELEVATOR .............. 120 -64

2H15 CURTAIN AND SHIELDS, STRAW CHOPPER .................. 120 -36 2G19 DRIVE TIGHTENER, CYLINDER.......................................... 120 -15

2H4 CURTAINS, SEPARATOR .................................................... 120 -25 2H18 DRIVE TIGHTENER, STRAW CHOPPER............................ 120 -39

2D20 CUSHIONS, SEAT ................................................................ 90 - 14 2I25 DRIVE TIGHTENER, UPPER TAILINGS AUGER................ 120 -74

1A22 CYLINDER BLOCK ................................................................ 20 - 4 2J16 DRIVE TIGHTENER,AUXILIARY UNLOADING AUG........... 130 -14

1A24 CYLINDER BLOCK ................................................................ 20 - 6 1H4 DRIVE WHEEL AND SPACERS .......................................... 50 - 2

2B4 CYLINDER CONTROL,VARIABLE SPEED-SEP.SIDE ........ 70 - 9 1H5 DRIVE WHEEL AXLE............................................................ 50 - 3

2G19 CYLINDER DRIVE TIGHTENER .......................................... 120 -15 1H22 DRIVE WHEEL CLUTCH AND HOUSING .......................... 50 - 20

1B7 CYLINDER HEAD .................................................................. 20 - 14 1H7 DRIVE WHEELS, FENDERS................................................ 50 - 5

1B8 CYLINDER HEAD .................................................................. 20 - 15 1E4 DRIVE, FUEL INJECTION PUMP ........................................ 30 - 33

1B9 CYLINDER HEAD OVERHEAT WARNING SENSOR ........ 20 - 16 1G9 DRIVE, STARTING MOTOR ................................................ 40 - 43

1B20 CYLINDER LINER KIT .......................................................... 20 - 27 3B7 DRIVES, STRAW CHOPPER .............................................. 170 -17

1A21 CYLINDER LINER PACKING LUBRICANT .......................... 20 - 3 3B7 DRIVES, STRAW SPREADER ............................................ 170 -17

2G21 CYLINDER SHAFT SHEAR HUB AND SHEAVE ................ 120 -17 3B5 DRIVES, STRAW WALKER .................................................. 170 -15

2G15 CYLINDER TACHOMETER, VARIABLE SPEED ................ 120 -11 3B12 DRIVES, UNLOADING AUGER............................................ 170 -23

1I14 CYLINDER, BRAKE .............................................................. 60 - 7 2K7 DROP RATE VALVE (AUTO HEIGHT) ................................ 160 -3

1I14 CYLINDER, BRAKE ROD .................................................... 60 - 7 2F7 DRUM, FEEDER.................................................................... 110 -14

1I13 CYLINDER, BRAKE SLAVE.................................................. 60 - 6 2I11 DUCTS, CLEANING FAN AIR.............................................. 120 -59

1I2 CYLINDER, HYD., SELECTIVE GROUND SPEED ............ 50 - 25

1I12 CYLINDER, HYDRAULIC, BRAKE-MASTER ...................... 60 - 5

2C6 CYLINDER, HYDRAULIC, FDR. HSE. VAR. DR. ................ 70 - 40 E

1I23 CYLINDER, HYDRAULIC, POWER STEERING.................. 60 - 17

2C8 CYLINDER, PLATFORM LIFT .............................................. 70 - 42 1F21 ELECTRIC MOTOR, WINDSHIELD WIPER ........................ 40 - 30

2G9 CYLINDER, RASP-BAR ........................................................ 120 -5 1D11 ELECTRIC SHUT-OFF KIT, FUEL INJECTION

2G18 CYLINDER, SEP., DR. INTERMEDIATE SHAFT ................ 120 -14 PUMP ................................................................................ 30 - 15

2H4 CYLINDER, SEPARATOR, SHEAR BAR ............................ 120 -25 1G17 ELECTRICAL CONNECTOR SERVICE KIT ........................ 40 - 52

2G13 CYLINDER, SPIKE-TOOTH .................................................. 120 -9 1F2 ELECTROMAGNETIC CLUTCH, PLATFORM...................... 40 - 9

2B9 CYLINDER,UNLOADING AUGER SWING HYDRAULIC .... 70 - 15 2I16 ELEVATOR DRIVE TIGHTENER, CLEAN GRAIN .............. 120 -64

2I13 ELEVATOR, CLEAN GRAIN ................................................ 120 -61

3B10 ELEVATOR, CLEAN GRAIN ................................................ 170 -21

D 2I21 ELEVATOR, TAILINGS.......................................................... 120

3B9 ELEVATOR, TAILINGS.......................................................... 170 -19

3B17 DECALS ................................................................................ 170 -28 2C22 ENGINE COMPARTMENT REAR SHEET .......................... 80 - 9

3B16 DECALS, FRONT AND REAR .............................................. 170 -27 2D2 ENGINE COMPARTMENT WALKWAY ................................ 80 - 14

3B14 DECALS, R.H. AND L.H. ...................................................... 170 -25 1C9 ENGINE COOLANT HEATER .............................................. 20 - 41

1F16 DIAL-A-MATIC HDR. HEIGHT CONTROL SWITCH............ 40 - 25 1A25 ENGINE FRONT PLATE ...................................................... 20 - 7

2K14 DIAL-A-MATIC HEADER HEIGHT CONTROL .................... 160 -10 1B1 ENGINE FRONT PLATE ...................................................... 20 - 8

2K15 DIAL-A-MATIC HEADER HEIGHT CONTROL .................... 160 -11 1B22 ENGINE OIL COOLER .......................................................... 20 - 29

1D3 DIESEL FUEL FILTER, EXPORT ........................................ 30 - 7 1B23 ENGINE OIL COOLER .......................................................... 20 - 30

1C23 DIESEL FUEL LINES AND FILTER .................................... 30 - 2 1A25 ENGINE OIL FILTER AND DIPSTICK .................................. 20 - 7

1D2 DIESEL FUEL LINES, EXPORT .......................................... 30 - 6 1B1 ENGINE OIL FILTER AND DIPSTICK .................................. 20 - 8

1H15 DIFF. GEARS, SHAFTS, AND BEARINGS .......................... 50 - 13 1B24 ENGINE OIL PUMP .............................................................. 20 - 31

1H11 DIFFERENTIAL AND TRANSMISSION ................................ 50 - 9 1A20 ENGINE OIL, TORQ-GARD SUPREME .............................. 20 - 1

1H15 DIFFERENTIAL GEARS AND BEARINGS .......................... 50 - 13 1C1 ENGINE OVERHAUL GASKET SET .................................... 20 - 33

1H15 DIFFERENTIAL GEARS AND SHAFTS .............................. 50 - 13 1C3 ENGINE OVERHAUL GASKET SET .................................... 20 - 35

1H14 DIFFERENTIAL PINION SHAFT AND GEARS .................... 50 - 12 2J23 ENGINE POWERSHAFT ...................................................... 140 -1

1G1 DIODE RING, ALTERNATOR, 72 AMP................................ 40 - 34 2D14 ENGINE POWERSHAFT CLOSURE .................................... 90 - 8

1G3 DIODE TRIO ASSEMBLY, ALTERNATOR, 90 AMP .......... 40 - 36 3A21 ENGINE R.H. SIDE SHEAVES ............................................ 170 -3

1A25 DIPSTICK, ENGINE OIL ...................................................... 20 - 7 3A21 ENGINE R.H. SIDE TIGHTENERS ...................................... 170 -3

1B1 DIPSTICK, ENGINE OIL ...................................................... 20 - 8 3A21 ENGINE R.H. SIDE-BELT .................................................... 170 -3

3A22 DISK, ROTARY SCREEN .................................................... 170 -5 1B10 ENGINE ROCKER ARM COVER ........................................ 20 - 17

1C13 DISPLACER, ROTARY SCREEN DRIVE BELT .................. 20 - 45 1B11 ENGINE ROCKER ARM COVER ........................................ 20 - 18

2D4 DOOR SEALS, ROTARY SCREEN ...................................... 80 - 16 1C8 ENGINE SUPPORTS ............................................................ 20 - 40

2I13 DOOR, CLEAN GRAIN ELEVATOR .................................... 120 -61 1F18 ENGINE TACH-HOUR METER ............................................ 40 - 27

2G7 DOOR, CYLINDER................................................................ 120 -3 1C4 ENGINE TUNE-UP GASKET SET ........................................ 20 - 36

2C24 DOOR, ENGINE COMPARTMENT, MIDDLE ...................... 80 - 11 1C5 ENGINE TUNE-UP GASKET SET ........................................ 20 - 37

2C23 DOOR, ENGINE COMPARTMENT, UPPER ........................ 80 - 10 1A20 ENGINE VALVE STEM LUBRICANT.................................... 20 - 1

2D5 DOOR, OIL RESERVOIR ...................................................... 80 - 17 1B10 ENGINE VENTILATOR TUBE .............................................. 20 - 17

2C18 DOOR, REAR HOOD ............................................................ 80 - 5 1B11 ENGINE VENTILATOR TUBE .............................................. 20 - 18

2G7 DOOR, REMOTE DUMP STONE TRAP.............................. 120 -3 1F6 ENGINE WIRING HARNESS ................................................ 40 - 13

2D3 DOOR, ROTARY SCREEN .................................................. 80 - 15 2C24 ENGINE, MIDDLE DOOR FRAME........................................ 80 - 11

2G11 DOOR, STONE TRAP .......................................................... 120 -7 2D1 ENGINE, SEALS AND RUBBER CUSHIONS ...................... 80 - 13

2I21 DOOR, TAILINGS ELEVATOR ............................................ 120 -70 2C23 ENGINE, UPPER DOOR FRAME AND HINGES ................ 80 - 10

2D25 DOORS FOR OPERATOR’S CAB........................................ 90 - 19 1B25 EXHAUST MANIFOLD .......................................................... 20 - 32

COMBINE - 4420 PC1745 (18-APR-00) 10-9

-70

PN=9

1A11

COMBINE - 4420

ALPHABETICAL INDEX - CONTINUED

GRID PAGE GRID PAGE

1E17 EXHAUST PIPES AND MUFFLER ...................................... 30 - 46 1H20 FINAL DRIVE PINION, HEAVY-DUTY ................................ 50 - 18

2J9 EXTENSION, TOP SHEETS, GRAIN TANK COVER .......... 130 -7 1H20 FINAL DRIVE SHAFT, HEAVY-DUTY .................................. 50 - 18

2J5 EXTENSIONS, GRAIN TANK .............................................. 130 -3 2I4 FINGER, BAR, CHAFFER FRAME ...................................... 120 -51

2I6 FINGER, BAR, CHAFFER FRAME ...................................... 120 -54

2H11 FINS, STRAW CHOPPER .................................................... 120 -32

F 2H13 FINS, STRAW CHOPPER .................................................... 120

1I24 FIXED REAR AXLE .............................................................. 60 - 18

2I11 FAN AIR DUCTS, CLEANING.............................................. 120 -59 1C10 FLAT ROTARY SCREEN ...................................................... 20 - 42

1C17 FAN DRIVE BELT TIGHTENER, RADIATOR...................... 20 - 49 2F13 FLOAT SPRING, INDICATOR .............................................. 110 -20

1G1 FAN, ALTERNATOR, 72 AMP.............................................. 40 - 34 2F12 FLOAT SPRINGS .................................................................. 110 -19

1G3 FAN, ALTERNATOR, 90 AMP.............................................. 40 - 36 2D12 FLOOR MATS, OPERATOR’S PLATFORM ........................ 90 - 6

2I9 FAN, CLEANING .................................................................. 120 -57 2D12 FLOORBOARD AND SHLDS,OPERATOR’S PLATFORM .. 90 - 6

3B5 FAN, CLEANING .................................................................. 170 -15 2K8 FLOW CONTROL PLUG (AUTO HEIGHT).......................... 160 -4

1C16 FAN, SHEAVE, AND SUPPORT .......................................... 20 - 48 2B16 FLOW CONTROL VALVE KNOB ........................................ 70 - 22

2K1 FAN, SPEED CONTROLS, CLEANING................................ 140 -4 2B25 FLOW CONTROL VALVE,HYDROSTATIC DR.REEL ........ 70 - 34

2F16 FDR.HSE.VAR.DR.MIDDLE BELT TIGHTENER.................. 110 -23 1B2 FLYWHEEL HOUSING ASSEMBLY .................................... 20 - 9

2F19 FDR.HSE.VARIABLE BELT DRIVE LOWER SHAFT .......... 110 -26 1B3 FLYWHEEL HOUSING ASSEMBLY .................................... 20 - 10

2G1 FDR.HSE.VARIABLE DR.LOWER BELT TIGHTENER ........ 110 -33 1H11 FORK, TRANSMISSION........................................................ 50 - 9

2G7 FEED PLATE ........................................................................ 120 -3 2C15 FRAME AND SHEETS, SEPARATOR R.H. SIDE .............. 80 - 2

2F8 FEEDER CONVEYOR CHAIN.............................................. 110 -15 2F3 FRAME, FEEDER HOUSE.................................................... 110 -10

2F9 FEEDER CONVEYOR CHAIN DRIVE TIGHTENER............ 110 -16 2F5 FRAME, FEEDER HOUSE.................................................... 110 -12

2F10 FEEDER CONVEYOR DRIVE CHAIN GUIDES .................. 110 -17 2I5 FRAME, LOWER SHOE, SIEVE .......................................... 120 -53

2G2 FEEDER CONVEYOR DRIVE TIGHTENER, L.H. .............. 110 -34 2C16 FRAME, SEPARATOR .......................................................... 80 - 3

2F11 FEEDER CONVEYOR, DRIVE CHAIN GUIDES.................. 110 -18 2C16 FRAME, SEPARATOR L.H. .................................................. 80 - 3

2F7 FEEDER CONVEYOR, IDLER SHAFT ................................ 110 -14 2I6 FRAME, UPPER SHOE, CHAFFER .................................... 120 -54

2G2 FEEDER HOUSE CHAIN DRIVE TIGHTENER, L.H. .......... 110 -34 1G7 FRONT AND REAR ALTERNATOR SUPPORTS ................ 40 - 41

3B2 FEEDER HOUSE DRIVE BELTS AND CHAINS ................ 170 -11 2C25 FRONT ENGINE COMPARTMENT PANEL ........................ 80 - 12

2F20 FEEDER HOUSE DRIVE CHAIN LOWER SHAFT.............. 110 -27 1E20 FRONT WIRING HARNESS.................................................. 40 - 2

3B2 FEEDER HOUSE DRIVE SHEAVES .................................... 170 -11 1C25 FUEL FILTER ........................................................................ 30 - 4

3B2 FEEDER HOUSE DRIVE SPROCKETS .............................. 170 -11 1D1 FUEL FILTER ........................................................................ 30 - 5

2F2 FEEDER HOUSE FALSE BOTTOM .................................... 110 -9 1D8 FUEL INJECTION LINES ...................................................... 30 - 12

2C3 FEEDER HOUSE OIL LINES,VARIABLE DRIVE ................ 70 - 37 1D22 FUEL INJECTION NOZZLE .................................................. 30 - 27

2F17 FEEDER HOUSE SPROCKETS AND SLIP CLUTCH ........ 110 -24 1E11 FUEL INJECTION NOZZLE .................................................. 30 - 40

2E24 FEEDER HOUSE TOP SHEETS.......................................... 110 -5 1D21 FUEL INJECTION NOZZLE ASSEMBLY ............................ 30 - 25

2F25 FEEDER HOUSE UPPER DRIVE TIGHTENER .................. 110 -32 1D8 FUEL INJECTION PUMP ...................................................... 30 - 12

2F17 FEEDER HOUSE UPPER SHAFT........................................ 110 -24 1D24 FUEL INJECTION PUMP ...................................................... 30 - 29

2F19 FEEDER HOUSE VARIABLE BELT DRIVE SHEAVE ........ 110 -26 1D12 FUEL INJECTION PUMP AUTOMATIC ADVANCE

2C6 FEEDER HOUSE VARIABLE DRIVE HYD. CYL. ................ 70 - 40 GROUP.............................................................................. 30 - 16

2F7 FEEDER HOUSE, DRUM...................................................... 110 -14 1E6 FUEL INJECTION PUMP COVER ........................................ 30 - 35

2F3 FEEDER HOUSE, FRAME.................................................... 110 -10 1E4 FUEL INJECTION PUMP DRIVE .......................................... 30 - 33

2F5 FEEDER HOUSE, FRAME.................................................... 110 -12 1D14 FUEL INJECTION PUMP DRIVE GROUP .......................... 30 - 18

2F14 FEEDER HOUSE, R.H. SHIELD .......................................... 110 -21 1D10 FUEL INJECTION PUMP ELEC. SHUT-OFF GROUP ........ 30 - 14

2E23 FEEDER HOUSE, SHEETS, FRONT .................................. 110 -4 1D11 FUEL INJECTION PUMP ELECTRIC SHUT-OFF

2F3 FEEDER HOUSE, SHEETS, SIDE ...................................... 110 -10 KIT .................................................................................... 30 - 15

2F5 FEEDER HOUSE, SHEETS, SIDE ...................................... 110 -12 1D19 FUEL INJECTION PUMP GASKET KIT .............................. 30 - 23

2F14 FEEDER HOUSE, SHIELDS, LEFT-HAND .......................... 110 -21 1E10 FUEL INJECTION PUMP GASKET KIT .............................. 30 - 39

1H7 FENDER, DRIVE WHEEL .................................................... 50 - 5 1D15 FUEL INJECTION PUMP GOVERNOR GROUP ................ 30 - 19

1F20 FIELD LIGHTS ...................................................................... 40 - 29 1D16 FUEL INJECTION PUMP HEAD .......................................... 30 - 20

1D3 FILTER, DIESEL FUEL, EXPORT ........................................ 30 - 7 1E4 FUEL INJECTION PUMP HEAD .......................................... 30 - 33

1C23 FILTER, DIESEL LINES ........................................................ 30 - 2 1D13 FUEL INJECTION PUMP HOUSING .................................... 30 - 17

1A25 FILTER, ENGINE OIL ............................................................ 20 - 7 1E2 FUEL INJECTION PUMP HOUSING .................................... 30 - 31

1B1 FILTER, ENGINE OIL ............................................................ 20 - 8 1D17 FUEL INJECTION PUMP LINKAGE GROUP ...................... 30 - 21

1C25 FILTER, FUEL ...................................................................... 30 - 4 1D16 FUEL INJECTION PUMP ROTOR........................................ 30 - 20

1D1 FILTER, FUEL ...................................................................... 30 - 5 1E4 FUEL INJECTION PUMP ROTOR ........................................ 30 - 33

1D3 FILTER, FUEL ...................................................................... 30 - 7 1D18 FUEL INJECTION PUMP TRANSFER GROUP .................. 30 - 22

2A20 FILTER, OIL RESERVOIR .................................................... 70 - 1 1D6 FUEL INJECTION SYSTEM.................................................. 30 - 10

2E2 FILTERS, RECIRCULATING, CAB ROOF .......................... 90 - 21 1D8 FUEL INJECTION SYSTEM.................................................. 30 - 12

1H16 FINAL DRIVE ........................................................................ 50 - 14 1D24 FUEL INJECTION SYSTEM.................................................. 30 - 29

1H18 FINAL DRIVE AXLE (HEAVY-DUTY) .................................. 50 - 16 1C23 FUEL LINES .......................................................................... 30 - 2

1H19 FINAL DRIVE AXLE, GEAR, AND BEARINGS.................... 50 - 17 1D2 FUEL LINES, DIESEL, EXPORT .......................................... 30 - 6

1H19 FINAL DRIVE AXLE, HEAVY-DUTY .................................... 50 - 17 1C22 FUEL TANK AND SUPPORTS ............................................ 30 - 1

1H18 FINAL DRIVE BEARINGS (HEAVY-DUTY) .......................... 50 - 16 1E12 FUEL TRANSFER PUMP ...................................................... 30 - 41

1H19 FINAL DRIVE BEARINGS, HEAVY-DUTY .......................... 50 - 17 1E13 FUEL TRANSFER PUMP ...................................................... 30 - 42

1H20 FINAL DRIVE BEARINGS, HEAVY-DUTY .......................... 50 - 18 1E12 FUEL TRANSFER PUMP KIT .............................................. 30 - 41

1H18 FINAL DRIVE GEAR (HEAVY-DUTY).................................. 50 - 16 1E22 FUEL, GAUGE SENDING UNIT .......................................... 40 - 4

1H19 FINAL DRIVE GEAR, HEAVY-DUTY.................................... 50 - 17 1E22 FUEL, PUMP ........................................................................ 40 - 4

1H17 FINAL DRIVE HOUSING AND BEARING CAP .................. 50 - 15

10-10 COMBINE - 4420 PC1745 (18-APR-00)

-34

PN=10

1A12

COMBINE - 4420

ALPHABETICAL INDEX - CONTINUED

GRID PAGE GRID PAGE

G 2B20 HOSES, REEL DRIVE OIL .................................................. 70

2C4 HOSES, VARIABLE DRIVE FEEDER HOUSE .................... 70 - 38

1E10 GASKET KIT .......................................................................... 30 - 39 1I11 HOUSING AND BRAKES...................................................... 60 - 4

1D19 GASKET KIT, FUEL INJECTION PUMP .............................. 30 - 23 1H23 HOUSING AND CLUTCH INPUT SHAFT ............................ 50 - 21

1C1 GASKET SET, ENGINE OVERHAUL .................................. 20 - 33 1H22 HOUSING AND CLUTCH, DRIVE WHEEL .......................... 50 - 20

1C3 GASKET SET, ENGINE OVERHAUL .................................. 20 - 35 2I18 HOUSING AND LOADING AUGER ...................................... 120 -67

1C4 GASKET SET, ENGINE TUNE-UP ...................................... 20 - 36 1G1 HOUSING, ALTERNATOR, 72 AMP .................................... 40 - 34

1C5 GASKET SET, ENGINE TUNE-UP ...................................... 20 - 37 1G3 HOUSING, ALTERNATOR, 90 AMP .................................... 40 - 36

1C19 GAUGE TUBE, OIL PRESSURE .......................................... 20 - 51 2H24 HOUSING, AUGER, SHOE GRAIN SUPPLY ...................... 120 -45

1F3 GAUGE, ACCUMULATOR PRESSURE .............................. 40 - 10 2I12 HOUSING, CLEAN GRAIN AUGER .................................... 120 -60

1F17 GAUGES AND SWITCHES ON INSTRUMENT PANEL...... 40 - 26 2I13 HOUSING, CLEAN GRAIN ELEVATOR .............................. 120 -61

2I19 GEAR CASE LOADING AUGER.......................................... 120 -68 2I10 HOUSING, CLEANING FAN ................................................ 120 -58

1H18 GEAR, FINAL DRIVE (HEAVY-DUTY) ................................ 50 - 16 1H17 HOUSING, FINAL DRIVE...................................................... 50 - 15

1H14 GEARS AND DIFFERENTIAL PINION SHAFT .................... 50 - 12 1B2 HOUSING, FLYWHEEL ........................................................ 20 - 9

1H12 GEARS AND TRANSMISSION COUNTERSHAFT .............. 50 - 10 1B3 HOUSING, FLYWHEEL ........................................................ 20 - 10

1B14 GEARS, IDLER AND CRANKSHAFT .................................. 20 - 21 1D13 HOUSING, FUEL INJECTION PUMP .................................. 30 - 17

1B15 GEARS, IDLER AND CRANKSHAFT .................................. 20 - 22 1E2 HOUSING, FUEL INJECTION PUMP .................................. 30 - 31

1H3 GEARSHIFT CONTROLS...................................................... 50 - 1 2I20 HOUSING, LOWER TAILINGS ............................................ 120 -69

2D24 GLASS, OPERATOR’S CAB ................................................ 90 - 18 2J18 HOUSING, OUTER UNLOADING AUGER .......................... 130 -16

1D15 GOVERNOR ASSEMBLY...................................................... 30 - 19 1G10 HOUSING, STARTING MOTOR .......................................... 40 - 44

2H25 GRAIN SUPPLY AUGERS, SHOE ...................................... 120 -47 2H9 HOUSING, STRAW CHOPPER ............................................ 120 -30

2J3 GRAIN TANK ........................................................................ 130 -1 2H10 HOUSING, STRAW CHOPPER ............................................ 120 -31

2J20 GRAIN TANK AUXILIARY UNLOADING AUGERS ............ 130 -18 2H22 HOUSING, STRAW SPREADER .......................................... 120 -43

2J20 GRAIN TANK AUXILIARY UNLOADING COVERS ............ 130 -18 2I13 HOUSING, STRAW SPREADER .......................................... 120 -61

2J8 GRAIN TANK COVER EXTENSION SHEETS .................... 130 -6 2I21 HOUSING, TAILINGS ELEVATOR ...................................... 120 -70

2J7 GRAIN TANK COVER SIDE SHEETS ................................ 130 -5 2I24 HOUSING, UPPER TAILINGS AUGER ................................ 120 -73

2J9 GRAIN TANK COVER TOP SHEETS.................................. 130 -7 1H25 HOUSING,RELATIVE GROUND SPEED INDICATOR ........ 50 - 23

2J5 GRAIN TANK EXTENSIONS ................................................ 130 -3 2G21 HUB, SHEAR, CYLINDER SHAFT, AND SHEAVE ............ 120 -17

2J13 GRAIN TANK INNER UNLOADING AUG. COVER ............ 130 -11 2B6 HYDRAULIC AUGER SWING CONTROL ............................ 70 - 11

2J4 GRAIN TANK SKIRTS .......................................................... 130 -2 2A23 HYDRAULIC CONTROL VALVE .......................................... 70 - 4

2J7 GRAIN TANK, SIDE SHEETS, COVER .............................. 130 -5 2B1 HYDRAULIC CONTROL VALVE .......................................... 70 - 6

2J14 GRASS SEED UNLOADING ATTACHMENT ...................... 130 -12 2B23 HYDRAULIC HOSE .............................................................. 70 - 32

2F13 GROUND SPEED, CONTROL LEVER ................................ 110 -20 2A21 HYDRAULIC PUMP .............................................................. 70 - 2

1H24 GROUND SPEED, INDICATOR............................................ 50 - 22 2B3 HYDRAULIC PUMP LINES, MAIN ........................................ 70 - 8

2H20 GUARD AND MOUNTING, STRAW SPREADER ................ 120 -41 2A22 HYDRAULIC PUMP TORQUE ARM AND SUPPORT ........ 70 - 3

1H8 GUARD, TRANSMISSION SHEAVE .................................... 50 - 6 2B18 HYDRAULIC PUMP, HYDROSTATIC DRIVE REEL............ 70 - 25

2F11 GUIDE, FEEDER CONVEYOR DRIVE CHAIN .................... 110 -18 2B25 HYDROSTATIC DR. REEL FLOW CONTROL VALVE........ 70 - 34

2K3 GUIDES, SEPARATOR AUGER DRIVE BELT .................... 140 -6 2B18 HYDROSTATIC DRIVE REEL HYDRAULIC PUMP ............ 70 - 25

2K3 GUIDES, UNLOADING AUGER DRIVE BELT .................... 140 -6 2B19 HYDROSTATIC DRIVE REEL PUMP MOUNTING .............. 70 - 27

1I8 HYDROSTATIC DRIVE REEL, CONTROL KNOB .............. 60 - 1

- 28

H

I

2D12 HANDRAILS, OPERATOR’S PLATFORM ............................ 90 - 6

1F6 HARNESS, ENGINE WIRING .............................................. 40 - 13 2H18 IDLER, STRAW CHOPPER DRIVE ...................................... 120 -39

1E20 HARNESS, FRONT WIRING ................................................ 40 - 2 2F13 INDICATOR, FLOAT SPRING .............................................. 110 -20

1F21 HARNESS, WIPER................................................................ 40 - 30 1F5 INDICATOR, LOW SHAFT SPEED...................................... 40 - 12

2K13 HARNESS, WIRING .............................................................. 160 -9 1H25 INDICATOR, RELATIVE GROUND SPEED ........................ 50 - 23

2K14 HARNESS, WIRING .............................................................. 160 -10 1E11 INJECTION NOZZLE, FUEL ................................................ 30 - 40

1E21 HARNESS, WIRING, MIDDLE .............................................. 40 - 3 1E10 INJECTION PUMP GASKET KIT .......................................... 30 - 39

1E22 HARNESS, WIRING, REAR .................................................. 40 - 4 1D6 INJECTION SYSTEM, FUEL ................................................ 30 - 10

1E22 HARNESS, WIRING, TAIL LAMP ........................................ 40 - 4 2J15 INNER UNLOADING AUGER .............................................. 130 -13

1B7 HEAD, CYLINDER ................................................................ 20 - 14 1H13 INPUT SHAFT, TRANSMISSION.......................................... 50 - 11

1B8 HEAD, CYLINDER ................................................................ 20 - 15 2D22 INSTRUMENT PANEL AND CONSOLE .............................. 90 - 16

1D16 HEAD, FUEL INJECTION PUMP.......................................... 30 - 20 2C22 INSTRUMENT WALL, ENGINE COMPARTMENT .............. 80 - 9

1E4 HEAD, FUEL INJECTION PUMP .......................................... 30 - 33 1B25 INTAKE MANIFOLD, AIR ...................................................... 20 - 32

1F24 HEADPHONE, RADIO .......................................................... 40 - 33 2E4 INTAKE, AIR, REAR OF OPERATOR’S CAB ...................... 90 - 23

2E17 HEATER AND HOSES .......................................................... 90 - 37 2G22 INTERMEDIATE SHAFT, CYL. DR., SLOW SPEED .......... 120 -19

1C9 HEATER, COOLANT, ENGINE ............................................ 20 - 41 2G18 INTERMEDIATE SHAFT, CYLINDER DRIVE...................... 120 -14

2E9 HI PRESSURE SWITCH, COMPRESSOR .......................... 90 - 28

2J17 HINGE AND SWING, UNLOADING AUGER........................ 130 -15

2D25 HINGES FOR OPERATOR’S CAB ...................................... 90 - 19 K

2C18 HOOD, REAR........................................................................ 80 - 5

1F14 HORNS, SIGNAL .................................................................. 40 - 23 1A21 KIT FOR OFF SEASON STORAGE .................................... 20 - 3

1F3 HOSE, ACCUMULATOR PRESSURE GAUGE.................... 40 - 10 2C2 KIT, ADJUSTING SCREW.................................................... 70 - 36

2B23 HOSES AND COUPLERS .................................................... 70 - 32 1I15 KIT, BRAKE SLAVE CYLINDER .......................................... 60 - 9

2E17 HOSES AND HEATER .......................................................... 90 - 37 2E10 KIT, COMPRESSOR HARDWARE ...................................... 90 - 29

COMBINE - 4420 PC1745 (18-APR-00) 10-11

PN=11

1A13

COMBINE - 4420

ALPHABETICAL INDEX - CONTINUED

GRID PAGE GRID PAGE

1B20 KIT, CYLINDER LINER ........................................................ 20 - 27 2B3 MAIN HYDRAULIC PUMP LINES ........................................ 70 - 8

1G17 KIT, ELECTRICAL CONNECTOR SERVICE........................ 40 - 52 2K6 MAIN VALVE BLOCK (AUTO HEIGHT) .............................. 160 -2

1D11 KIT, FUEL INJECTION PUMP ELECTRIC SHUT- 1B25 MANIFOLD, EXHAUST.......................................................... 20 - 32

OFF.................................................................................... 30 - 15 1C7 MANIFOLD, WATER.............................................................. 20 - 39

1D19 KIT, FUEL INJECTION PUMP GASKET .............................. 30 - 23 1F18 METER, TACH-HOUR, ENGINE .......................................... 40 - 27

1E10 KIT, FUEL INJECTION PUMP GASKET.............................. 30 - 39 1F4 MICRO SWITCH, STRAW WALKER SENSING UNIT ........ 40 - 11

1E12 KIT, FUEL TRANSFER.......................................................... 30 - 41 1E21 MIDDLE WIRING HARNESS ................................................ 40 - 3

2C1 KIT, HYDRO. DR. REEL FLOW CONTROL VALVE .......... 70 - 35 2D24 MIRROR, OPERATOR’S CAB.............................................. 90 - 18

1G15 KIT, TERMINAL AND WIRING ............................................ 40 - 50 2E5 MIRROR, RIGHT-HAND ........................................................ 90 - 24

2E16 KIT,O-RING, AIR CONDITIONING........................................ 90 - 36 2B15 MOTOR, HYD. DR. AUXILIARY UNLDG. AUGER.............. 70 - 21

2B10 KIT,UNLOADING AUGER SWING HYD.CYLINDER............ 70 - 16 2B17 MOTOR, REEL ...................................................................... 70 - 23

2H16 KNIFE AND SUPPORT, STRAW CHOPPER ...................... 120 -37 1G7 MOTOR, STARTING.............................................................. 40 - 41

2B16 KNOB, FLOW CONTROL VALVE ........................................ 70 - 22 1G9 MOTOR, STARTING.............................................................. 40 - 43

2D18 KNOB, OPERATOR’S PLATFORM SEAT............................ 90 - 12 1G11 MOTOR, STARTING.............................................................. 40 - 45

1F21 MOTOR, WINDSHIELD WIPER............................................ 40 - 30

2K12 MOUNTING AND ACTUATOR SWITCH.............................. 160 -8

L 2H20 MOUNTING AND GUARD, STRAW SPREADER ................ 120

2E11 MOUNTING., COMPRESSOR, AIR COND. ........................ 90 - 30

2E9 LABEL, COMPRESSOR CHARGE ...................................... 90 - 28 2E12 MOUNTING., COMPRESSOR, AIR COND. ........................ 90 - 31

2D8 LADDER AND LANDING, OPERATOR’S PLATFORM........ 90 - 1 1I24 MOUNTING, REAR AXLE .................................................... 60 - 18

2D9 LADDER, PIVOTING CONTROLS ........................................ 90 - 3 2B9 MOUNTING,UNLOADING AUGER SWING HYDRAULIC.... 70 - 15

2C19 LADDER, SEPARATOR........................................................ 80 - 6 1H9 MUD SHIELD, TRANSMISSION DRIVE .............................. 50 - 7

2D25 LATCHES FOR OPERATOR’S CAB.................................... 90 - 19 1E17 MUFFLER AND EXHAUST PIPES ...................................... 30 - 46

1I8 LEVER, PARKING BRAKE .................................................. 60 - 1

2D9 LEVER, PIVOTING LADDER ................................................ 90 - 3

1D4 LEVER, THROTTLE .............................................................. 30 - 8 N

2B5 LEVER, VAR. SPEED CYL. ON OPER. PLATFORM ........ 70 - 10

2C8 LIFT BRACKETS, PLATFORM ............................................ 70 - 42 2C11 NAMEPLATE, ACCUMULATOR............................................ 70 - 45

2C8 LIFT CYLINDER, PLATFORM .............................................. 70 - 42 1D21 NOZZLE, FUEL INJECTION ................................................ 30 - 25

2B16 LIFT, PLATFORM.................................................................. 70 - 22 1D22 NOZZLE, FUEL INJECTION ................................................ 30 - 27

1F20 LIGHTS, FIELD...................................................................... 40 - 29 1E11 NOZZLE, FUEL INJECTION ................................................ 30 - 40

1E23 LIGHTS, WARNING .............................................................. 40 - 5

2B11 LINE AND HOSES, UNLOADING AUGER SWING ............ 70 - 17

2B12 LINE, UNLOADING AUGER SWING .................................... 70 - 18 O

1B20 LINER, PISTON .................................................................... 20 - 27

1B21 LINER, PISTON .................................................................... 20 - 28 2E16 O-RING KIT, AIR CONDITIONING ...................................... 90 - 36

2E14 LINES, AIR CONDITIONER .................................................. 90 - 34 1B22 OIL COOLER, ENGINE ........................................................ 20 - 29

2K9 LINES, AUTOMATIC HEADER HEIGHT.............................. 160 -5 1B23 OIL COOLER, ENGINE ........................................................ 20 - 30

1I10 LINES, BRAKE ...................................................................... 60 - 3 2B20 OIL HOSES, REEL DRIVE .................................................. 70 - 28

1C23 LINES, FUEL ........................................................................ 30 - 2 2B14 OIL LINES, AUX UNLDG. AUGER HYD. DRIVE ................ 70 - 20

1D8 LINES, FUEL INJECTION .................................................... 30 - 12 2C7 OIL LINES, PLATFORM LIFT .............................................. 70 - 41

2B14 LINES, OIL, AUX. UNLDG. AUGER HYD. DR. .................. 70 - 20 2B22 OIL LINES, REEL LIFT ........................................................ 70 - 31

2C7 LINES, OIL, PLATFORM LIFT .............................................. 70 - 41 2C9 OIL LINES, REEL LIFT ........................................................ 70 - 43

2B3 LINES, PUMP, MAIN HYDRAULIC ...................................... 70 - 8 1I3 OIL LINES, SELECTIVE GROUND SPEED ........................ 50 - 26

2C9 LINES, REEL LIFT OIL ........................................................ 70 - 43 1I19 OIL LINES, STEERING ........................................................ 60 - 13

1I3 LINES, SELECTIVE GROUND SPEED OIL ........................ 50 - 26 1I21 OIL LINES, STEERING ........................................................ 60 - 15

1I20 LINES, STEERING LOWER OIL-FRONT ............................ 60 - 14 1I20 OIL LINES, STEERING LOWER-FRONT ............................ 60 - 14

1I22 LINES, STEERING LOWER OIL-REAR .............................. 60 - 16 1I22 OIL LINES, STEERING LOWER-REAR .............................. 60 - 16

2C3 LINES,OIL,VARIABLE DRIVE FEEDER HOUSE ................ 70 - 37 2C3 OIL LINES,VARIABLE DRIVE FEEDER HOUSE ................ 70 - 37

1I9 LINKAGE AND BRAKE PEDALS.......................................... 60 - 2 1B5 OIL PAN, ENGINE ................................................................ 20 - 12

1H21 LINKAGE AND CLUTCH PEDAL.......................................... 50 - 19 1B6 OIL PAN, ENGINE ................................................................ 20 - 13

2E14 LO PRESSURE SWITCH, AIR CONDITIONER .................. 90 - 34 1C19 OIL PRESSURE GAUGE TUBE .......................................... 20 - 51

2I18 LOADING AUGER AND HOUSING ...................................... 120 -67 1B24 OIL PUMP, LUBRICATING, ENGINE .................................. 20 - 31

3B10 LOADING AUGER DRIVE SHEAVES AND BELTS ............ 170 -21 2A20 OIL RESERVOIR .................................................................. 70 - 1

2E3 LOUVERS AND PANELS, OPERATOR’S CAB .................. 90 - 22 2D5 OIL RESERVOIR DOOR ...................................................... 80 - 17

1F5 LOW SHAFT SPEED INDICATOR ...................................... 40 - 12 1A20 OIL, ENGINE, TORQ-GARD SUPREME .............................. 20 - 1

2I20 LOWER TAILINGS AUGER .................................................. 120 -69 2G11 OPEN-BAR CONCAVE.......................................................... 120 -7

2I23 LOWER TAILINGS AUGER DRIVE TIGHTENER................ 120 -72 1F12 OPERATOR’S CAB .............................................................. 40 - 20

2I20 LOWER TAILINGS HOUSING.............................................. 120 -69 1F13 OPERATOR’S CAB .............................................................. 40 - 21

1A21 LUBRICANT, PACKING, CYLINDER LINER ........................ 20 - 3 2D23 OPERATOR’S CAB BODY.................................................... 90 - 17

1A20 LUBRICANT, STEM, ENGINE VALVE ................................ 20 - 1 2E7 OPERATOR’S CAB COMPRESSOR AND VALVE .............. 90 - 26

2D25 OPERATOR’S CAB DOORS ................................................ 90 - 19

1F11 OPERATOR’S CAB ELECTRICAL SWITCHES .................. 40 - 19

M 1F11 OPERATOR’S CAB ELECTRICAL WIRING ........................ 40

2D25 OPERATOR’S CAB HINGES ................................................ 90 - 19

1B12 MAIN BEARING CAPS AND BEARINGS ............................ 20 - 19 2D25 OPERATOR’S CAB LATCHES ............................................ 90 - 19

1B13 MAIN BEARING CAPS AND BEARINGS ............................ 20 - 20 2D16 OPERATOR’S CAB MOUNTING BRACKETS .................... 90 - 10

10-12 COMBINE - 4420 PC1745 (18-APR-00)

-41

- 19

PN=12

1A14

COMBINE - 4420

ALPHABETICAL INDEX - CONTINUED

GRID PAGE GRID PAGE

2D16 OPERATOR’S CAB MOUNTING BUSHINGS ...................... 90 - 10 1E6 PUMP COVER, FUEL INJECTION ...................................... 30 - 35

2D16 OPERATOR’S CAB MOUNTING SEALS ............................ 90 - 10 1E22 PUMP, FUEL ........................................................................ 40 - 4

2E3 OPERATOR’S CAB PANELS AND LOUVERS .................... 90 - 22 1D8 PUMP, FUEL INJECTION .................................................... 30 - 12

2E6 OPERATOR’S CAB PRESSURIZER .................................... 90 - 25 1D24 PUMP, FUEL INJECTION .................................................... 30 - 29

2E1 OPERATOR’S CAB SOUND INSULATION AND SEAL ...... 90 - 20 1D20 PUMP, FUEL TRANSFER .................................................... 30 - 24

2D25 OPERATOR’S CAB TOOL POCKET .................................... 90 - 19 1E12 PUMP, FUEL TRANSFER .................................................... 30 - 41

2E4 OPERATOR’S CAB, AIR INTAKE, REAR............................ 90 - 23 1E13 PUMP, FUEL TRANSFER .................................................... 30 - 42

2D24 OPERATOR’S CAB, GLASS ................................................ 90 - 18 2A21 PUMP, HYDRAULIC .............................................................. 70 - 2

2D24 OPERATOR’S CAB, MIRROR.............................................. 90 - 18 2B18 PUMP, HYDROSTATIC DRIVE REEL .................................. 70 - 25

2D12 OPERATOR’S PLATFORM FLOOR MATS .......................... 90 - 6 1I17 PUMP, STEERING................................................................ 60 - 11

2D12 OPERATOR’S PLATFORM HANDRAILS ............................ 90 - 6 1E8 PUMP, TRANSFER .............................................................. 30 - 37

2D8 OPERATOR’S PLATFORM LADDER AND LANDING ........ 90 - 1

2D17 OPERATOR’S PLATFORM SEAT SUPPORTS .................. 90 - 11

2D18 OPERATOR’S PLATFORM SEAT SUPPORTS .................. 90 - 12 Q

2D12 OPERATOR’S PLATFORM SHLDS AND FLOORBOARD .. 90 - 6

2J18 OUTER UNLOADING AUGER HOUSING ............................ 130 -16 2E21 QUIK-TATCH COUPLER AND SHIELDS ............................ 110 -1

P R

2I22 PADDLE, TAILINGS ELEVATOR.......................................... 120 -71 1C14 RADIATOR ............................................................................ 20 - 46

1B5 PAN, OIL, ENGINE ................................................................ 20 - 12 1C15 RADIATOR ............................................................................ 20 - 47

1B6 PAN, OIL, ENGINE ................................................................ 20 - 13 1C17 RADIATOR FAN DRIVE BELT TIGHTENER ...................... 20 - 49

2C25 PANEL, COMPARTMENT, FRONT ENGINE ...................... 80 - 12 1F22 RADIO .................................................................................... 40 - 31

2E3 PANELS AND LOUVERS, OPERATOR’S CAB .................. 90 - 22 1F23 RADIO .................................................................................... 40 - 32

1H25 PIN, RELATIVE GROUND SPEED INDICATOR ................ 50 - 23 1F24 RADIO, HEADPHONES ........................................................ 40 - 33

1B20 PISTON LINER...................................................................... 20 - 27 2D18 RAIL, OPERATOR’S PLATFORM SEAT .............................. 90 - 12

1B21 PISTON LINER...................................................................... 20 - 28 1H11 RAIL, SHIFTER, TRANSMISSION ........................................ 50 - 9

1B20 PISTONS AND CONNECTING RODS ................................ 20 - 27 2D2 RAILING, SAFETY ................................................................ 80 - 14

1B21 PISTONS AND CONNECTING RODS ................................ 20 - 28 2G9 RASP-BAR CYLINDER.......................................................... 120 -5

2I8 PITMAN, SHOE .................................................................... 120 -56 1I24 REAR AXLE MOUNTING ...................................................... 60 - 18

2D9 PIVOTING LADDER CONTROLS ........................................ 90 - 3 1J1 REAR AXLE SPINDLES........................................................ 60 - 20

2G7 PLATE, FEED........................................................................ 120 -3 1I25 REAR AXLE, ADJUSTABLE ................................................ 60 - 19

2H11 PLATE, STRAW CHOPPER.................................................. 120 -32 1I24 REAR AXLE, FIXED .............................................................. 60 - 18

2H13 PLATE, STRAW CHOPPER.................................................. 120 -34 1J2 REAR AXLE, TIE ROD, STEERING .................................... 60 - 21

2F16 PLATF.VAR.DR.MIDDLE BELT TIGHTENER ...................... 110 -23 2C18 REAR HOOD ........................................................................ 80 - 5

2G1 PLATF.VARIABLE DR.LOWER BELT TIGHTENER ............ 110 -33 1J3 REAR WHEELS .................................................................... 60 - 22

2G2 PLATFORM CHAIN DRIVE TIGHTENER, L.H. .................... 110 -34 2B20 REEL DRIVE OIL HOSES .................................................... 70 - 28

1F2 PLATFORM ELECTROMAGNETIC CLUTCH ...................... 40 - 9 2B25 REEL FLOW CONTROL VALVE,HYDROSTATIC DR. ........ 70 - 34

2D8 PLATFORM LADDER AND LANDING, OPERATOR’S........ 90 - 1 2B16 REEL LIFT CONTROLS ........................................................ 70 - 22

2B16 PLATFORM LIFT AND REEL LIFT CONTROLS ................ 70 - 22 2B22 REEL LIFT OIL LINES .......................................................... 70 - 31

2C8 PLATFORM LIFT BRACKETS.............................................. 70 - 42 2C9 REEL LIFT OIL LINES.......................................................... 70 - 43

2C8 PLATFORM LIFT CYLINDER .............................................. 70 - 42 2B17 REEL MOTOR ...................................................................... 70 - 23

2C7 PLATFORM LIFT OIL LINES ................................................ 70 - 41 1E23 REFLECTORS ...................................................................... 40 - 5

2C8 PLATFORM LIFT SAFETY STOP ........................................ 70 - 42 2G7 REINFORCEMENT, CYLINDER DOOR .............................. 120 -3

2D12 PLATFORM SHLDS AND FLOORBOARD,OPERATOR’S .. 90 - 6 1H25 RELATIVE GROUND SPEED INDICATOR .......................... 50 - 23

2F25 PLATFORM UPPER DRIVE TIGHTENER............................ 110 -32 2G7 REMOTE DUMP STONE TRAP .......................................... 120 -3

2K8 PLUG, FLOW CONTROL (AUTO HEIGHT) ........................ 160 -4 2A20 RESERVOIR, OIL.................................................................. 70 - 1

1I23 POWER STEERING CYLINDER .......................................... 60 - 17 1B19 ROCKER ARM AND VALVES .............................................. 20 - 26

1I18 POWER STEERING, CONTROL VALVE ............................ 60 - 12 1B18 ROCKER ARMS AND VALVES ............................................ 20 - 25

1I21 POWER STEERING, OIL LINES .......................................... 60 - 15 2D3 ROD, SAFETY ...................................................................... 80 - 15

2D14 POWERSHAFT CLOSURE, ENGINE .................................. 90 - 8 1B20 RODS, CONNECTING AND PISTON .................................. 20 - 27

2J23 POWERSHAFT, ENGINE ...................................................... 140 -1 1B21 RODS, CONNECTING AND PISTON .................................. 20 - 28

1E14 PRECLEANER ...................................................................... 30 - 43 2E2 ROOF, CAB .......................................................................... 90 - 21

2C11 PRESS.CTL.VALVE AND MTG.BKT,ACCUMULATOR........ 70 - 45 2H3 ROTARY DEFLECTOR DRIVE TIGHTENER ...................... 120 -24

1F3 PRESSURE GAUGE, ACCUMULATOR .............................. 40 - 10 3A22 ROTARY SCREEN DISK, BELT, AND TIGHTENERS ........ 170 -5

2E6 PRESSURIZER, OPERATOR’S CAB .................................. 90 - 25 2D3 ROTARY SCREEN DOOR AND SAFETY ROD .................. 80 - 15

3A24 PRIMARY BELTS .................................................................. 170 -7 2D4 ROTARY SCREEN DOOR SEALS ...................................... 80 - 16

3A24 PRIMARY CHAIN .................................................................. 170 -7 1C13 ROTARY SCREEN DRIVE BELT DISPLACER.................... 20 - 45

2J24 PRIMARY COUNTERSHAFT ................................................ 140 -2 1C13 ROTARY SCREEN DRIVE BELT TIGHTENERS ................ 20 - 45

3A24 PRIMARY COUNTERSHAFT................................................ 170 -7 1C18 ROTARY SCREEN DRIVE BELT TIGHTENERS ................ 20 - 50

2J25 PRIMARY CTR’SHAFT. CYL. DRIVE SHEAVE .................. 140 -3 1C12 ROTARY SCREEN DRIVE SHAFT ...................................... 20 - 44

3A24 PRIMARY SHEAVES ............................................................ 170 -7 1C10 ROTARY SCREEN, FLAT .................................................... 20 - 42

3A24 PRIMARY SPROCKETS ...................................................... 170 -7 1G1 ROTOR, ALTERNATOR, 72 AMP ........................................ 40 - 34

3A24 PRIMARY TIGHTENERS ...................................................... 170 -7 1G3 ROTOR, ALTERNATOR, 90 AMP ........................................ 40 - 36

1I4 PROPULSION DRIVE COUNTERSHAFT SHEAVE ............ 50 - 27 1D16 ROTOR, FUEL INJECTION PUMP ...................................... 30 - 20

1C6 PUMP ASSEMBLY, WATER ................................................ 20 - 38 1E4 ROTOR, FUEL INJECTION PUMP ...................................... 30 - 33

COMBINE - 4420 PC1745 (18-APR-00) 10-13

PN=13

1A15

COMBINE - 4420

ALPHABETICAL INDEX - CONTINUED

GRID PAGE GRID PAGE

2H17 ROTOR, STRAW CHOPPER ................................................ 120 -38 3B2 SHEAVES, FEEDER HOUSE DRIVE .................................. 170 -11

3A24 SHEAVES, PRIMARY ............................................................ 170 -7

2J25 SHEAVES,DRIVE,PRIMARY CTR’SHAFT CYL. .................. 140 -3

S 3B4 SHEAVES,SHOE GRAIN SUPPLY AUGERS DRIVE .......... 170

2J8 SHEET, EXTENSION, GRAIN TANK COVER .................... 130 -6

2D2 SAFETY RAILING.................................................................. 80 - 14 2E23 SHEET, FEEDER HOUSE, FRONT .................................... 110 -4

2D3 SAFETY ROD AND ROTARY SCREEN DOOR .................. 80 - 15 2F3 SHEET, FEEDER HOUSE, SIDE ........................................ 110 -10

2C8 SAFETY STOP, PLATFORM LIFT ...................................... 70 - 42 2F5 SHEET, FEEDER HOUSE, SIDE ........................................ 110 -12

1E22 SAFETY SWITCH, NEUTRAL .............................................. 40 - 4 2C16 SHEET, SEPARATOR, SIDE ................................................ 80 - 3

1C10 SCREEN ROTARY, FLAT .................................................... 20 - 42 2C14 SHEET, SEPARATOR, TOP ................................................ 80 - 1

2G7 SEAL, CYLINDER DOOR...................................................... 120 -3 2J9 SHEET, TOP, GRAIN TANK COVER .................................. 130 -7

2D1 SEALS, ENGINE COMPARTMENT ...................................... 80 - 13 2C15 SHEETS AND FRAME, SEPARATOR R.H. SIDE .............. 80 - 2

2E1 SEALS, OPERATOR’S CAB ................................................ 90 - 20 2G7 SHEETS, SEPARATOR FRONT .......................................... 120 -3

2D16 SEALS, OPERATOR’S CAB MOUNTING ............................ 90 - 10 2E24 SHEETS, TOP, FEEDER HOUSE........................................ 110 -5

2D4 SEALS, ROTARY SCREEN DOOR ...................................... 80 - 16 2I10 SHIELD AND CLEANING FAN HOUSING .......................... 120 -58

2D19 SEAT BACKREST SUPPORTS ............................................ 90 - 13 2F15 SHIELD, DRIVE, VARIABLE BELT ...................................... 110 -22

2D20 SEAT CUSHIONS.................................................................. 90 - 14 2E23 SHIELD, FEEDER DRUM .................................................... 110 -4

2D17 SEAT SUPPORTS, OPERATOR’S PLATFORM .................. 90 - 11 2F14 SHIELD, FEEDER HOUSE LEFT-HAND.............................. 110 -21

2K1 SECONDARY COUNTERSHAFT .......................................... 140 -4 2E22 SHIELD, LOWER, L.H., SPECIAL ........................................ 110 -3

2K2 SECONDARY COUNTERSHAFT DR.TIGHTENER ............ 140 -5 1H9 SHIELD, MUD, TRANSMISSION DRIVE.............................. 50 - 7

3A25 SECONDARY COUNTERSHAFT SHEAVES AND BELT .... 170 -9 2E23 SHIELD, PLATFORM AUGER .............................................. 110 -4

2G16 SECTOR, CONCAVE ............................................................ 120 -12 2F14 SHIELD, R.H., FEEDER HOUSE.......................................... 110 -21

1I1 SELECTIVE GROUND SPEED CONTROLS ...................... 50 - 24 2C20 SHIELD, R.H., SEPARATOR................................................ 80 - 7

1I2 SELECTIVE GROUND SPEED CYLINDER ........................ 50 - 25 2H19 SHIELD, SHEAVE, STRAW CHOPPER .............................. 120 -40

1I3 SELECTIVE GROUND SPEED OIL LINES.......................... 50 - 26 2H7 SHIELD, STRAW SPREADER .............................................. 120 -28

2B13 SELECTOR VALVE, AUX. UNLOADING AUGER .............. 70 - 19 2E21 SHIELDS AND COUPLER, QUIK-TATCH ............................ 110 -1

1F4 SENSING UNIT, STRAW WALKER, PLUGGING ................ 40 - 11 2H15 SHIELDS AND CURTAIN, STRAW CHOPPER .................. 120 -36

1B9 SENSOR CYLINDER HEAD OVERHEAT WARNING ........ 20 - 16 1F7 SHIELDS, CABLES, BRACKETS, AND BATTERY.............. 40 - 14

2K3 SEPARATOR AUGER DRIVE BELT GUIDES .................... 140 -6 2H23 SHIELDS, STRAW SPREADER .......................................... 120 -44

2C19 SEPARATOR CROSS BRACE ............................................ 80 - 6 2D12 SHLDS AND FLOORBOARD,OPERATOR’S PLATFORM .. 90 - 6

2H4 SEPARATOR CURTAINS...................................................... 120 -25 2H8 SHOE AND STRAW WALKER DRIVE TIGHTENER .......... 120 -29

2J1 SEPARATOR DRIVE CONTROLS........................................ 120 -75 2I3 SHOE GR.SUPPLY AUGERS DR.TIGHTENER.................. 120 -50

2G7 SEPARATOR FRONT SHEETS ............................................ 120 -3 2H24 SHOE GRAIN SUPPLY AUGER HOUSING ........................ 120 -45

2C16 SEPARATOR L.H. FRAME .................................................. 80 - 3 2H25 SHOE GRAIN SUPPLY AUGERS........................................ 120 -47

2C16 SEPARATOR L.H. SIDE SHEETS........................................ 80 - 3 2I3 SHOE GRAIN SUPPLY AUGERS DR. SHIELD.................. 120 -50

2C19 SEPARATOR LADDER ........................................................ 80 - 6 3B4 SHOE GRAIN SUPPLY AUGERS DRIVE BELT ................ 170 -13

2C20 SEPARATOR R.H. SHIELD .................................................. 80 - 7 2I1 SHOE GRAIN SUPPLY AUGERS DRIVE SHAFT .............. 120 -48

2C15 SEPARATOR R.H. SIDE SHEETS AND FRAME ................ 80 - 2 2I1 SHOE GRAIN SUPPLY AUGERS DRIVE SHEAVE ............ 120 -48

2C14 SEPARATOR TOP SHEET .................................................. 80 - 1 3B4 SHOE GRAIN SUPPLY AUGERS DRIVE SHEAVES ........ 170 -13

2K1 SEPARATOR, SECONDARY COUNTERSHAFT ................ 140 -4 2I8 SHOE PITMAN AND SHAFT ................................................ 120 -56

1G17 SERVICE KIT, ELECTRICAL CONNECTOR........................ 40 - 52 2I4 SHOE, CHAFFER AND SIEVE ............................................ 120 -51

2F19 SHAFT AND SHEAVE, FDR.HSE.VAR.BELT DRIVE.......... 110 -26 2I6 SHOE, CHAFFER FRAME, UPPER .................................... 120 -54

2I8 SHAFT AND SHOE PITMAN ................................................ 120 -56 3B5 SHOE, CLEANING ................................................................ 170 -15

2J21 SHAFT, AUXILIARY UNLOADING AUGERS DRIVE .......... 130 -19 2I4 SHOE, SIEVE AND CHAFFER ............................................ 120 -51

2I14 SHAFT, CLEAN GRAIN ELEVATOR CONVEYOR .............. 120 -62 2I5 SHOE, SIEVE FRAME, LOWER .......................................... 120 -53

1H23 SHAFT, CLUTCH INPUT ...................................................... 50 - 21 2I4 SIEVE AND CHAFFER.......................................................... 120 -51

2G16 SHAFT, CONCAVE ADJUSTING.......................................... 120 -12 2I5 SIEVE FRAME, LOWER SHOE............................................ 120 -53

1C12 SHAFT, DRIVE, ROTARY SCREEN .................................... 20 - 44 1F14 SIGNAL HORNS.................................................................... 40 - 23

2F17 SHAFT, UPPER, FEEDER HOUSE...................................... 110 -24 1E24 SIGNAL, TURN ...................................................................... 40 - 7

2I1 SHAFT,DRIVE,SHOE GRAIN SUPPLY AUGERS................ 120 -48 2J4 SKIRTS, GRAIN TANK.......................................................... 130 -2

2F20 SHAFT,LOWER,FEEDER HOUSE DRIVE CHAIN .............. 110 -27 1I13 SLAVE CYLINDER, BRAKE.................................................. 60 - 6

1H15 SHAFTS AND BEARINGS.................................................... 50 - 13 2F17 SLIP CLUTCH AND SPROCKETS, FEEDER HOUSE........ 110 -24

1H15 SHAFTS, BRGS., AND DIFFERENTIAL GEARS ................ 50 - 13 2G22 SLOW SPD.CYL.DRIVE INTERMEDIATE SHAFT .............. 120 -19

2G21 SHEAVE AND CYLINDER SHAFT SHEAR HUB ................ 120 -17 2K5 SOLENOID CONTROL VALVE (AUTO HEIGHT) ................ 160 -1

1G5 SHEAVE, ALTERNATOR ...................................................... 40 - 38 1G12 SOLENOID SWITCH STARTER MOTOR ............................ 40 - 46

2I14 SHEAVE, CLEAN GRAIN ELEVATOR CONVEYOR .......... 120 -62 1H6 SPACER, AXLE .................................................................... 50 - 4

1I4 SHEAVE, PROPULSION DRIVE COUNTERSHAFT............ 50 - 27 1H4 SPACERS AND DRIVE WHEEL .......................................... 50 - 2

2H19 SHEAVE, ROTOR, STRAW CHOPPER .............................. 120 -40 2G14 SPIKE-TOOTH CONCAVE.................................................... 120 -10

2I1 SHEAVE,DRIVE,SHOE GRAIN SUPPLY AUGERS ............ 120 -48 2G13 SPIKE-TOOTH CYLINDER .................................................. 120 -9

3A25 SHEAVES AND BELT, SECONDARY COUNTERSHAFT .. 170 -9 1J1 SPINDLES, REAR AXLE ...................................................... 60 - 20

3B3 SHEAVES AND BELTS, BEATER DRIVE .......................... 170 -12 1F15 SPOTLIGHT .......................................................................... 40 - 24

3B10 SHEAVES AND BELTS, LOADING AUGER DRIVE............ 170 -21 2H23 SPREADER SHIELDS, STRAW .......................................... 120 -44

3B9 SHEAVES AND SPROCKETS, AUGER DRIVE .................. 170 -19 2H20 SPREADER, STRAW, MOUNTING AND GUARD .............. 120 -41

2G23 SHEAVES, BEATER AND TACHOMETER DRIVE.............. 120 -20 2D18 SPRING, OPERATOR’S PLATFORM SEAT ........................ 90 - 12

2H1 SHEAVES, BEATER AND TACHOMETER DRIVE.............. 120 -22 2F12 SPRINGS, FLOAT ................................................................ 110 -19

3B10 SHEAVES, CLEAN GRAIN ELEVATOR .............................. 170 -21 3B9 SPROCKETS AND SHEAVES, AUGER DRIVE .................. 170 -19

3A21 SHEAVES, ENGINE R.H. SIDE ............................................ 170 -3 2F17 SPROCKETS AND SLIP CLUTCH, FEEDER HOUSE........ 110 -24

10-14 COMBINE - 4420 PC1745 (18-APR-00)

-13

PN=14

1A16

COMBINE - 4420

ALPHABETICAL INDEX - CONTINUED

GRID PAGE GRID PAGE

3B2 SPROCKETS, FEEDER HOUSE DRIVE .............................. 170 -11 2B11 SWING HOSES AND LINE, UNLOADING AUGER ............ 70 - 17

3A24 SPROCKETS, PRIMARY ...................................................... 170 -7 2B12 SWING LINE, UNLOADING AUGER .................................... 70 - 18

2I14 SPROCKETS,CLEAN GRAIN ELEVATOR CONVEYOR .... 120 -62 2K9 SWING, AUGER.................................................................... 160 -5

1G8 STARTER MOTOR ARMATURE ASSEMBLY .................... 40 - 42 1F4 SWITCH, MICRO, STRAW WALKER SENSING UNIT........ 40 - 11

1G8 STARTER MOTOR DRIVE MOTOR .................................... 40 - 42 1E22 SWITCH, NEUTRAL SAFETY .............................................. 40 - 4

1G12 STARTER MOTOR SOLENOID SWITCH ............................ 40 - 46 1G14 SWITCH, SOLENOID, STARTER ........................................ 40 - 49

1G14 STARTER SOLENOID SWITCH .......................................... 40 - 49 1G13 SWITCH, SOLENOID, STARTING MOTOR ........................ 40 - 47

1G7 STARTING MOTOR .............................................................. 40 - 41 1F16 SWITCH,DIAL-A-MATIC HDR.HEIGHT CONTROL.............. 40 - 25

1G9 STARTING MOTOR .............................................................. 40 - 43 1F17 SWITCHES AND GAUGES ON INSTRUMENT PANEL...... 40 - 26

1G11 STARTING MOTOR .............................................................. 40 - 45 1F11 SWITCHES, OPERATOR’S CAB ELECTRICAL .................. 40 - 19

1G11 STARTING MOTOR ARMATURE ........................................ 40 - 45 1D24 SYSTEM, FUEL INJECTION ................................................ 30 - 29

1G9 STARTING MOTOR DRIVE .................................................. 40 - 43

1G10 STARTING MOTOR HOUSING AND COIL ASSEMBLY .... 40 - 44

1G13 STARTING MOTOR SOLENOID SWITCH .......................... 40 - 47 T

1G1 STATOR, ALTERNATOR, 72 AMP ...................................... 40 - 34

1G3 STATOR, ALTERNATOR, 90 AMP ...................................... 40 - 36 1F18 TACH-HOUR METER, ENGINE............................................ 40 - 27

1I16 STEERING COLUMN AND WHEEL .................................... 60 - 10 2H1 TACHOMETER AND BEATER DRIVE ................................ 120 -22

1I18 STEERING CONTROL VALVE ............................................ 60 - 12 2G23 TACHOMETER DRIVE AND BEATER ................................ 120 -20

1I21 STEERING LOWER OIL LINES (MIDDLE) .......................... 60 - 15 2G15 TACHOMETER, VARIABLE SPEED CYLINDER ................ 120 -11

1I20 STEERING LOWER OIL LINES-FRONT .............................. 60 - 14 2I20 TAILINGS AUGER, LOWER ................................................ 120 -69

1I22 STEERING LOWER OIL LINES-REAR................................ 60 - 16 3B9 TAILINGS ELEVATOR .......................................................... 170 -19

1I17 STEERING PUMP ................................................................ 60 - 11 2I22 TAILINGS ELEVATOR BUCKET .......................................... 120 -71

1J2 STEERING TIE RODS .......................................................... 60 - 21 2I22 TAILINGS ELEVATOR CONVEYOR CHAIN ........................ 120 -71

1I19 STEERING UPPER OIL LINES............................................ 60 - 13 2I21 TAILINGS ELEVATOR HOUSING........................................ 120 -70

1I23 STEERING, CYLINDER ........................................................ 60 - 17 2I22 TAILINGS ELEVATOR, PADDLE.......................................... 120 -71

1I19 STEERING, OIL LINES ........................................................ 60 - 13 2I20 TAILINGS HOUSING, LOWER ............................................ 120 -69

2G11 STONE TRAP AND DOOR .................................................. 120 -7 2I24 TAILINGS, AUGER, UPPER ................................................ 120 -73

2G7 STONE TRAP, REMOTE DUMP .......................................... 120 -3 1E23 TAILLIGHTS .......................................................................... 40 - 5

1A21 STOP LEAK AND COOLANT CONDITIONER .................... 20 - 3 2J3 TANK, GRAIN ........................................................................ 130 -1

1H25 STOP, RELATIVE GROUND SPEED INDICATOR.............. 50 - 23 1G15 TERMINAL AND WIRING KIT.............................................. 40 - 50

2C8 STOP, SAFETY, PLATFORM LIFT ...................................... 70 - 42 1G21 TERMINALS, SUPPLEMENTARY, AND CONNECTORS.... 40 - 56

1A21 STORAGE KIT ...................................................................... 20 - 3 1C7 THERMOSTAT AND WATER MANIFOLD .......................... 20 - 39

3B7 STRAW CHOPPER AND STRAW SPREADER DRIVES .... 170 -17 1D4 THROTTLE CONTROL.......................................................... 30 - 8

2H15 STRAW CHOPPER CURTAIN AND SHIELDS .................... 120 -36 1J2 TIE RODS, STEERING ........................................................ 60 - 21

2H18 STRAW CHOPPER DRIVE IDLER ...................................... 120 -39 1C17 TIGHTENER, BELT, RADIATOR FAN DRIVE .................... 20 - 49

2H18 STRAW CHOPPER DRIVE TIGHTENER ............................ 120 -39 2I16 TIGHTENER, CLEAN GRAIN ELEVATOR DRIVE .............. 120 -64

2H9 STRAW CHOPPER HOUSING ............................................ 120 -30 2F16 TIGHTENER, DR., F.H. VAR. DR. MIDDLE ........................ 110 -23

2H10 STRAW CHOPPER HOUSING ............................................ 120 -31 2F25 TIGHTENER, DR., FDR.HSE. AND PLAT.UPPER .............. 110 -32

2H16 STRAW CHOPPER KNIFE AND SUPPORT........................ 120 -37 2F16 TIGHTENER, DR., PLAT. VAR. DR. MIDDLE .................... 110 -23

2H11 STRAW CHOPPER PLATES AND FINS ............................ 120 -32 2K2 TIGHTENER, DR., SECONDARY COUNTERSHAFT .......... 140 -5

2H13 STRAW CHOPPER PLATES AND FINS ............................ 120 -34 2I3 TIGHTENER, DR., SHOE GRAIN SUPPLY AUGER .......... 120 -50

2H17 STRAW CHOPPER ROTOR AND BLADES ........................ 120 -38 2I23 TIGHTENER, DRIVE, LOWER TAILINGS AUGER.............. 120 -72

2H19 STRAW CHOPPER ROTOR SHEAVE ................................ 120 -40 1C18 TIGHTENER, DRIVE, RADIATOR FAN................................ 20 - 50

2H19 STRAW CHOPPER SHIELD ................................................ 120 -40 2G2 TIGHTENER, FEEDER CONVEYOR DRIVE, L.H. .............. 110 -34

2H22 STRAW SPREADER ............................................................ 120 -43 2F9 TIGHTENER, FEEDER CONVEYOR DRIVE, R.H............... 110 -16

3B7 STRAW SPREADER AND STRAW CHOPPER DRIVES .... 170 -17 2G2 TIGHTENER, PLATFORM CHAIN DRIVE, L.H. .................. 110 -34

2H22 STRAW SPREADER BLADE ................................................ 120 -43 1C18 TIGHTENER, RADIATOR FAN DRIVE BELT...................... 20 - 50

2H22 STRAW SPREADER HOUSING .......................................... 120 -43 2H18 TIGHTENER, STRAW CHOPPER DRIVE............................ 120 -39

2H20 STRAW SPREADER MOUNTING AND GUARD ................ 120 -41 2I25 TIGHTENER, UPPER TAILINGS AUGER DRIVE................ 120 -74

2H23 STRAW SPREADER SHIELDS ............................................ 120 -44 2J16 TIGHTENER,AUXILIARY UNLOADING AUG.DRIVE .......... 130 -14

3B5 STRAW WALKER DRIVES AND CLEANING SHOE .......... 170 -15 2G1 TIGHTENER,FDR.HSE.VARIABLE DR.LOWER BELT ........ 110 -33

2H6 STRAW WALKER FRONT CRANKSHAFT.......................... 120 -27 2G1 TIGHTENER,PLATF.VARIABLE DR.LOWER BELT ............ 110 -33

2H7 STRAW WALKER REAR CRANKSHAFT ............................ 120 -28 2G19 TIGHTENERS, DRIVE, CYLINDER ...................................... 120 -15

1F4 STRAW WALKER, PLUGGING SENSING UNIT ................ 40 - 11 2G20 TIGHTENERS, DRIVE, INTERMEDIATE SHAFT ................ 120 -16

2H5 STRAW WALKERS .............................................................. 120 -26 2H3 TIGHTENERS, DRIVE, ROTARY DEFLECTOR.................. 120 -24

1H25 STRIP, RELATIVE GROUND SPEED INDICATOR ............ 50 - 23 1C18 TIGHTENERS, DRIVE, ROTARY SCREEN ........................ 20 - 50

1G21 SUPPLEMENTARY TERMINALS AND CONNECTORS...... 40 - 56 2H8 TIGHTENERS, DRIVE, SHOE AND STRAW WALKER...... 120 -29

2A22 SUPPORT AND HYDRAULIC PUMP TORQUE ARM ........ 70 - 3 3A21 TIGHTENERS, ENGINE R.H. SIDE ...................................... 170 -3

2J16 SUPPORT,AUXILIARY UNLDG.AUGER DR.MOTOR.......... 130 -14 3A24 TIGHTENERS, PRIMARY...................................................... 170 -7

1C22 SUPPORTS AND FUEL TANK ............................................ 30 - 1 3A22 TIGHTENERS, ROTARY SCREEN ...................................... 170 -5

2E11 SUPPORTS., COMPRESSOR, AIR COND. ........................ 90 - 30 1C13 TIGHTENERS, ROTARY SCREEN DRIVE BELT................ 20 - 45

2E12 SUPPORTS., COMPRESSOR, AIR COND. ........................ 90 - 31 1B4 TIMING GEAR COVER ........................................................ 20 - 11

2D19 SUPPORTS, BACKREST, SEAT .......................................... 90 - 13 2C20 TOOL BOX ............................................................................ 80 - 7

1C8 SUPPORTS, ENGINE .......................................................... 20 - 40 2D25 TOOL POCKET FOR OPERATOR’S CAB .......................... 90 - 19

2D18 SUPPORTS, OPERATOR’S PLATFORM SEAT .................. 90 - 12 1A20 TORQ-GARD SUPREME ENGINE OIL ................................ 20 - 1

2D17 SUPPORTS, SEAT, OPERATOR’S PLATFORM ................ 90 - 11 1E8 TRANSFER PUMP ................................................................ 30 - 37

2J17 SWING AND HINGE, UNLOADING AUGER........................ 130 -15 1E12 TRANSFER PUMP, FUEL .................................................... 30 - 41

COMBINE - 4420 PC1745 (18-APR-00) 10-15

PN=15

1A17

COMBINE - 4420

ALPHABETICAL INDEX - CONTINUED

GRID PAGE GRID PAGE

1E13 TRANSFER PUMP, FUEL .................................................... 30 - 42 1B11 VENTILATOR TUBE, ENGINE .............................................. 20 - 18

1H10 TRANSMISSION .................................................................... 50 - 8 1G3 VOLTAGE REGULATOR, ALTERNATOR, 90 AMP ............ 40 - 36

1H11 TRANSMISSION AND DIFFERENTIAL ................................ 50 - 9 1G1 VOLTAGE REGULATOR,ALTERNATOR,72 AMP .............. 40 - 34

1H12 TRANSMISSION COUNTERSHAFT AND GEARS .............. 50 - 10

1H9 TRANSMISSION DRIVE MUD SHIELD................................ 50 - 7

1H13 TRANSMISSION INPUT SHAFT .......................................... 50 - 11 W

2G7 TRAP, REMOTE DUMP STONE .......................................... 120 -3

1E16 TUBE, AIR INTAKE .............................................................. 30 - 45 2H5 WALKERS, STRAW .............................................................. 120 -26

1C19 TUBE, GAUGE, OIL PRESSURE ........................................ 20 - 51 2D2 WALKWAY, ENGINE COMPARTMENT .............................. 80 - 14

1E14 TUBES, AIR INTAKE ............................................................ 30 - 43 1E23 WARNING LIGHTS ................................................................ 40 - 5

1E24 TURN SIGNALS .................................................................... 40 - 7 1B9 WARNING SENSOR, CYLINDER HEAD OVERHEAT ........ 20 - 16

1C7 WATER MANIFOLD AND THERMOSTAT .......................... 20 - 39

1C6 WATER PUMP ASSEMBLY .................................................. 20 - 38

U 1J3 WEIGHT, REAR WHEEL ...................................................... 60

1I16 WHEEL AND STEERING COLUMN .................................... 60 - 10

1B16 UNDERSIZE CRANKSHAFT KIT .......................................... 20 - 23 1H4 WHEEL, DRIVE .................................................................... 50 - 2

2J14 UNLOADING ATTACHMENT, GRASS SEED ...................... 130 -12 1H22 WHEEL, DRIVE, CLUTCH AND HOUSING ........................ 50 - 20

2J16 UNLOADING AUG.DRIVE TIGHTENER,AUXILIARY .......... 130 -14 1H7 WHEEL, FENDER.................................................................. 50 - 5

2J12 UNLOADING AUGER COUNTERSHAFT ............................ 130 -10 1J3 WHEEL, REAR...................................................................... 60 - 22

2J16 UNLOADING AUGER DR.MOTOR SUPT.,AUXILIARY ...... 130 -14 1J3 WHEEL, WEIGHTS .............................................................. 60 - 22

2K3 UNLOADING AUGER DRIVE BELT GUIDES ...................... 140 -6 1F21 WINDSHIELD WIPER AND BRACKET ................................ 40 - 30

2J10 UNLOADING AUGER DRIVE CONTROL ............................ 130 -8 1F21 WIPER HARNESS ................................................................ 40 - 30

3B12 UNLOADING AUGER DRIVES ............................................ 170 -23 1G15 WIRING AND TERMINAL KIT.............................................. 40 - 50

2J17 UNLOADING AUGER HINGE AND SWING ........................ 130 -15 1G15 WIRING CRIMPING TOOL .................................................. 40 - 50

2J18 UNLOADING AUGER HOUSING, OUTER .......................... 130 -16 2K13 WIRING HARNESS .............................................................. 160 -9

2B7 UNLOADING AUGER SWING CONTROL VALVE .............. 70 - 12 2K14 WIRING HARNESS .............................................................. 160 -10

2B8 UNLOADING AUGER SWING CONTROL VALVE .............. 70 - 13 1F6 WIRING HARNESS, ENGINE .............................................. 40 - 13

2B11 UNLOADING AUGER SWING HOSES AND LINE .............. 70 - 17 1E20 WIRING HARNESS, FRONT ................................................ 40 - 2

2B10 UNLOADING AUGER SWING HYD.CYLINDER KIT .......... 70 - 16 1E21 WIRING HARNESS, MIDDLE .............................................. 40 - 3

2B9 UNLOADING AUGER SWING HYDRAULIC CYLINDER .... 70 - 15 1E22 WIRING HARNESS, REAR .................................................. 40 - 4

2B9 UNLOADING AUGER SWING HYDRAULIC MOUNTING .. 70 - 15 1E22 WIRING HARNESS, TAIL LAMP.......................................... 40 - 4

2B12 UNLOADING AUGER SWING LINE .................................... 70 - 18 1F12 WIRING ON ENGINE, AIR CONDITIONING........................ 40 - 20

2J11 UNLOADING AUGER, AUXILIARY, DR. CONTROL .......... 130 -9 1F13 WIRING ON ENGINE, AIR CONDITIONING........................ 40 - 21

2J15 UNLOADING AUGER, INNER .............................................. 130 -13 1G15 WIRING STRIPPING TOOL .................................................. 40 - 50

2J13 UNLOADING AUGER, INNER COVER ................................ 130 -11 1F11 WIRING, OPERATOR’S CAB ELECTRICAL........................ 40 - 19

2J17 UNLOADING AUGER, OUTER ............................................ 130 -15 1G21 WIRING, SUPPLEMENTARY TERMINALS AND

2J21 UNLOADING AUGERS DRIVE SHAFT, AUXILIARY .......... 130 -19 CONNECTORS ................................................................ 40 - 56

2I25 UPPER AUGER DRIVE TIGHTENER, TAILINGS................ 120 -74

2F17 UPPER SHAFT, FEEDER HOUSE ...................................... 110 -24

2I24 UPPER TAILINGS AUGER AND HOUSING ........................ 120 -73

2I25 UPPER TAILINGS AUGER DRIVE TIGHTENER ................ 120 -74

- 22

V

2E7 VALVE AND COMPRESSOR, OPERATOR’S CAB ............ 90 - 26

2B13 VALVE SUPPORT ................................................................ 70 - 19

2B13 VALVE, AUX. UNLDG. AUGER SELECTOR ...................... 70 - 19

2K5 VALVE, CONTROL, SOLENOID (AUTO HEIGHT).............. 160 -1

2K7 VALVE, DROP RATE (AUTO HEIGHT) .............................. 160 -3

2E13 VALVE, EXPANSION, AIR CONDITIONER ........................ 90 - 33

2A23 VALVE, HYDRAULIC CONTROL .......................................... 70 - 4

2B1 VALVE, HYDRAULIC CONTROL .......................................... 70 - 6

2B25 VALVE, HYDROSTATIC DR.REEL FLOW CONTROL ........ 70 - 34

1I18 VALVE, STEERING CONTROL ............................................ 60 - 12

2B7 VALVE, UNLOADING AUGER SWING CONTROL ............ 70 - 12

2B8 VALVE, UNLOADING AUGER SWING CONTROL ............ 70 - 13

2C11 VALVE,PRES.CTL.AND MTG.BKT,ACCUMULATOR .......... 70 - 45

1B18 VALVES AND ROCKER ARMS ............................................ 20 - 25

1B19 VALVES AND ROCKER ARMS ............................................ 20 - 26

2E9 VALVES, SERICE, COMPRESSOR CLUTCH .................... 90 - 28

2F15 VARIABLE BELT DRIVE SHIELD ........................................ 110 -22

2C4 VARIABLE DRIVE FEEDER HOUSE HYD. HOSES .......... 70 - 38

2C3 VARIABLE DRIVE FEEDER HOUSE OIL LINES................ 70 - 37

2B4 VARIABLE SPEED CYLINDER CONTROL-SEP.SIDE ........ 70 - 9

2G15 VARIABLE SPEED CYLINDER TACHOMETER .................. 120 -11

1B10 VENTILATOR TUBE, ENGINE .............................................. 20 - 17

10-16 COMBINE - 4420 PC1745 (18-APR-00)

PN=16

1A20

X3377 -UN-07NOV94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

.. AR63980 OIL 1 (237 ML) (SAE 5W/20)
.. AR63979 OIL 1 (237 ML) (SAE 30)
.. AR63228 OIL 1 (946 ML) (SAE 5W/20)
.. AR63223 OIL 1 (946 ML) (SAE 10W/20)
.. AR63218 OIL 1 (946 ML) (SAE 30)
.. AR63229 OIL 1 (18.9 L) (SAE 5W/20)
.. AR63224 OIL 1 (18.9 L) (SAE 10W/20)
.. AR63219 OIL 1 (18.9 L) (SAE 30)
.. AR63230 OIL 1 (208.5 L) (SAE 5W/20)
.. AR63227 OIL 1 (208.5 L) (SAE 10W/20)
.. AR63222 OIL 1 (208.5 L) (SAE 30)

T14906 -UN-01JAN94

TORQ-GARD SUPREME ENGINE OIL

ENGINE VALVE STEM LUBRICANT

ENGINE

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR44402 OIL 1 (0.9 L) CAN

COMBINE - 4420 PC1745 (19-DEC-85) 20-1

PN=17

MEMORANDA

ENGINE

20-2 COMBINE - 4420 PC1745 (06-SEP-85)

PN=18

1A21

ENGINE

CYLINDER LINER PACKING LUBRICANT

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

.. AR54749 LUBRICANT 1 (0.9 L) CAN

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

.. AR41785 KIT 1 KIT, OFF-SEASON STORAGE, FOR ENGINE POWERED
EQUIPMENT, THIS KIT CONTAINS QUART (0.9L)
CAN OF INTERNAL CORROSION INHIBITOR, 1 ROLL
OF TAPE AND 6 PLASTIC BAGS, (SUB FOR
AR41870)

STOP LEAK AND COOLANT CONDITIONER

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

.. RE12842 COOLANT 1 .91 KG (32 OZ.) (SUB FOR T19566)
.. T11847 SEALANT 1 (NO LONGER AVAILABLE)

(NOT ILLUSTRATED)

KIT FOR OFF-SEASON STORAGE

(NOT ILLUSTRATED)

(NOT ILLUSTRATED)

COMBINE - 4420 PC1745 (19-DEC-85) 20-3

PN=19

TP11006 -UN-01JAN94

1A22

ENGINE

CYLINDER BLOCK

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R54802 ORIFICE 6
2 R48685 DOWEL PIN 2 (SUB FOR R26241, THIS APPLICATION)
3 AR64406 CYLINDER BLOCK 1 -566498 WITH MAIN BEARING CAPS, NIPPLE, SLEEVE,
BUSHING, DOWEL PINS, PIPE PLUGS, STUDS,
PISTON COOLING ORIFICES, CAP SCREWS AND
WASHERS, (MARKED R55012, R55037 OR R72968)
(SUB RE19872, R46625, R73139 AND R73140)
RE19872 CYLINDER BLOCK 1 566499- WITH MAIN BEARING CAPS, NIPPLE, SLEEVE,
BUSHING, DOWEL PINS, PIPE PLUGS, STUDS,
PISTON COOLING ORIFICES, CAP SCREWS AND
WASHERS, (MARKED R80405) (SUB FOR AR97027,
MARKED R72968)
4A AT13740 DRAIN VALVE 1
4B R55233 PIPE PLUG 1
5 15H275 PIPE PLUG 1 1/4"
6 T18891 CAP 2
7 R26493 BUSHING 1
8 R26650 DOWEL PIN 2
9 15H563 PIPE PLUG 1 3/8"
10 R48685 DOWEL PIN 2 (SUB FOR A120R)
11 15H515 PIPE BUSHING 1
12 15H584 PIPE PLUG 1 1/2"
13 15H665 PIPE PLUG AR 3/4"
15H562 PIPE PLUG AR 1"
14 R32042 STUD 1

ENGINE

20-4 COMBINE - 4420 PC1745 (19-DEC-85)

THIS PARTS LISTING IS CONTINUED

PN=20

1A23

ENGINE

CYLINDER BLOCK - CONTINUED

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

15 15H558 PIPE PLUG 7 1/8", (SUB FOR RE12310)
16 R39741 DRAIN PLUG 1
17 U13639 O-RING 1
18 T33279 STUD 1
19 R73139 VALVE 1 566499-
20 R46625 SPRING 1 566499-
21 R75892 O-RING AR (OIL PUMP TUBE)
.. AR64413 SHORT BLOCK ASSEMBLY 1 -566498 WITH CYLINDER BLOCK ASSEMBLY, CRANKSHAFT,
CAMSHAFT, PISTONS, CONNECTING RODS,
BEARINGS, CYLINDER LINERS, FRONT PLATE,
IDLER COVERS, TAPPETS AND OVERHAUL GASKET
SET, (SUB RE19873) (ALSO ORDER R81514)
.. RE19873 SHORT BLOCK ASSEMBLY 1 WITH CYLINDER BLOCK ASSEMBLY, CRANKSHAFT,
CAMSHAFT, PISTONS, CONNECTING RODS,
BEARINGS, CYLINDER LINERS, FRONT PLATE,
IDLER GEARS, TAPPETS, BYPASS VALVE, BYPASS
SPRING AND OVERHAUL GASKET SET, (SUB FOR
AR97040) (ALSO ORDER R81514)

(6329DH)

COMBINE - 4420 PC1745 (19-DEC-85) 20-5

PN=21

HP2542 -UN-01JAN94

1A24

ENGINE

CYLINDER BLOCK

(6359DH)

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R54802 ORIFICE 6
2 R26241 DOWEL PIN 2
3 RE19371 CYLINDER BLOCK 1 WITH MAIN BEARING CAPS, NIPPLE, SLEEVE,
BUSHING, DOWEL PINS, PIPE PLUGS, STUDS,
PISTON COOLING ORIFICES, CAP SCREWS AND
WASHERS
4 AT13740 DRAIN VALVE AR
5 15H275 PIPE PLUG 1 1/4"
6 T18891 CAP 2
7 R26493 BUSHING 1
8 R26650 DOWEL PIN 2
9 15H255 PIPE PLUG 1 3/8"
10 R48685 DOWEL PIN 2
11 15H515 PIPE BUSHING 1
12 15H584 PIPE PLUG 1 1/2"
13 15H665 PIPE PLUG 1 3/4"
14 R32042 STUD 1
15 15H558 PIPE PLUG 7 1/8"
16 R39741 DRAIN PLUG 1
17 U13639 O-RING 1
18 T33279 STUD 1
19 R73139 VALVE 1
20 R46625 SPRING 1
21 R75892 O-RING 1 (OIL PUMP TUBE)
22 R55233 PIPE PLUG 1
.. RE19372 SHORT BLOCK ASSEMBLY 1 WITH CYLINDER BLOCK ASSEMBLY, CRANKSHAFT,
CAMSHAFT, PISTONS, CONNECTING RODS,
BEARINGS, CYLINDER LINERS, FRONT PLATE,
IDLER GEARS, TAPPETS, BYPASS VALVE, BYPASS
SPRING AND OVERHAUL GASKET SET

20-6 COMBINE - 4420 PC1745 (06-SEP-85)

PN=22

1A25

ENGINE OIL FILTER AND DIPSTICK

T24162 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AT23141 DIPSTICK 1
2 T19044 OIL FILTER 1
3 T23435 THREADED NIPPLE 1
4 R49824 DIPSTICK TUBE 1
5 14H826 NUT 1 1/2"
6 R27976 O-RING 1

T16883 -UN-01JAN94

(6329DH)

ENGINE FRONT PLATE

(6329DH)

ENGINE

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T24965 GASKET 1 -566498 (SUB R73140)
R73140 GASKET 1
2 AT21191 SET SCREW 5
AT22919 SET SCREW 2
3 12H324 WASHER 5 3/8"
4 T20166 SCREW 5
5 R56736 PLATE 1 (ALSO ORDER FIVE AT21191 SET SCREWS AND TWO
AT22919 SET SCREWS)

COMBINE - 4420 PC1745 (19-DEC-85) 20-7

PN=23

1B1

ENGINE OIL FILTER AND DIPSTICK

T24162 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AT23141 DIPSTICK 1
2 T19044 OIL FILTER 1
3 T23435 THREADED NIPPLE 1
4 R49824 DIPSTICK TUBE 1
5 R10093 O-RING 1
6 14H826 NUT 1 1/2"

T16883 -UN-01JAN94

(6359DH)

ENGINE FRONT PLATE

(6359DH)

ENGINE

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R73140 GASKET 1
2 AT21191 SET SCREW 8
AT22919 SET SCREW 2
3 12H324 WASHER 5 3/8"
4 T20166 SCREW 5
5 R75470 PLATE 1 (ALSO ORDER (8) AT21191 SET SCREWS AND (2)
AT22919 SET SCREWS)

e

20-8 COMBINE - 4420 PC1745 (06-SEP-85)

PN=24

TP11557 -UN-01JAN94

1B2

ENGINE

FLYWHEEL HOUSING

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 19H2735 CAP SCREW 4 1/2" X 2"
2 T32230 HUB 1
3 AR52725 FLYWHEEL 1
4 T20088 GEAR 1 (142 TEETH)
5 19H2545 CAP SCREW 8 3/8" X 1-3/8"
6 T25115 HOUSING 1
7 T20089 COVER 1
8A T20090 SCREW 1 (SUB 19H2351)
8B 19H2351 CAP SCREW 1 1/2" X 1/2"
9 R70483 GASKET 1 (SUB FOR R49516, THIS APPLICATION)
10 RE17831 SEAL 1 (SUB FOR AT22965 AND AR92893)
11 T22536 GEAR 1
12 H1058R WASHER 1
13 T22537 FITTING 1

COMBINE - 4420 PC1745 (19-DEC-85) 20-9

PN=25

1B3

FLYWHEEL HOUSING

T34057 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 19H2735 CAP SCREW 4 1/2" X 2"
2 T32230 HUB 1
3 AR52725 FLYWHEEL 1
4 T20088 GEAR 1 (142 TEETH)
5 19H2545 CAP SCREW 8 3/8" X 1-3/8"
6 T25115 HOUSING 1
7 T20089 COVER 1
8 T20090 SCREW 1
9 R70483 GASKET 1
10 AR92893 SEAL 1
11 T22536 GEAR 1
12 H1058R WASHER 1
13 T22537 FITTING 1

(6359DH)

ENGINE

e

20-10 COMBINE - 4420 PC1745 (06-SEP-85)

PN=26

T34058 -UN-01JAN94

1B4

ENGINE

TIMING GEAR COVER

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T20155 GASKET 1
2 24H1304 WASHER 18 13/32" X 23/32" X 0.120"
3 19H1765 CAP SCREW 2 3/8" X 1-3/4"
4 T33279 STUD 2
5 AR67821 COVER 1 (ALSO ORDER T20272 COVER, T20273 GASKET, (3)
19H2284 CAP SCREWS, 19H1726 CAP SCREW, (4)
24H1304 WASHERS AND 15H275 PIPE PLUG)
6 19H1801 CAP SCREW 6 3/8" X 2"
7 R78366 GASKET 1 (SUB FOR R69260)
8 T20362 COVER 1
9 19H2284 CAP SCREW 2 3/8" X 7/8"
10 T20273 GASKET 1
11 T20272 COVER 1
12 24H1304 WASHER 4 13/32" X 23/32" X 0.120"
13 19H2284 CAP SCREW 3 3/8" X 7/8"
14 19H246 CAP SCREW 1 3/8" X 1-3/4"
15 T27657 FITTING PLUG 1
16 A4827R WASHER 1
17 24H1290 WASHER 1 21/64" X 3/4" X 0.035"
18 T27658 SPRING 1
19 19H2023 CAP SCREW 1 3/8" X 3-1/4"
20 15H275 PIPE PLUG 1 1/4"
21 19H268 CAP SCREW 2 3/8" X 2-1/2"
22 R83169 VALVE 1 (SUB FOR R51516)
23 19H1801 CAP SCREW 1 3/8" X 2"
24 19H1134 CAP SCREW 1 3/8" X 3/4"
25 T23260 COVER 1
26 T20336 GASKET 1
27 14H812 NUT 2 3/8"

COMBINE - 4420 PC1745 (19-DEC-85) 20-11

PN=27

H32727 -UN-01JAN94

1B5

ENGINE

OIL PAN

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T20205 GASKET 1
2 T19935 CLAMP 1 FUEL LINE
3 T31219 OIL PAN 1
4 12H304 LOCK WASHER 36 3/8"
5 19H1800 CAP SCREW 6 3/8" X 1-1/2"
6 AU11672 HOSE 1 -421411 (SUB AR80532 AND 15H584)
7 15H3 FITTING 1 1/2"
8 19H2552 CAP SCREW 29 3/8" X 1-1/8"
19H1800 CAP SCREW 29 3/8" X 1-1/2"
9 15H584 PIPE PLUG 1 1/2"
10 AR80532 HYDRAULIC HOSE 1 1/2" X 1 168 MM (46") X 1/2"

20-12 COMBINE - 4420 PC1745 (19-DEC-85)

PN=28

HP2543 -UN-01JAN94

1B6

ENGINE

OIL PAN

(6359DH)

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T20205 GASKET 1
2 T19935 CLAMP 1 FUEL LINE
3 T31219 OIL PAN 1
4 12H304 LOCK WASHER 36 3/8"
5 19H1800 CAP SCREW 6 3/8" X 1-1/2"
6 15H584 PIPE PLUG 1 1/2"
7 AR80532 HYDRAULIC HOSE 1
8 19H2552 CAP SCREW 29 3/8" X 1-1/8"
19H1800 CAP SCREW 29 3/8" X 1-1/2"

COMBINE - 4420 PC1745 (06-SEP-85) 20-13

PN=29

TP10260 -UN-01JAN94

1B7

ENGINE

CYLINDER HEAD

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T26509 STRAP 1
2 R53223 CAP SCREW 23 1/2" X 4-1/4"
R53219 CAP SCREW 3 1/2" X 5", (USED WITH BLOCK MARKED R53260)
3 T20168 WASHER 23
4 19H1134 CAP SCREW 2 3/8" X 3/4"
5 R56725 COVER 1
6 R54641 GASKET 1
7 T26508 STRAP 1
8 19H1815 CAP SCREW 1 1/2" X 1-1/4"
9 12H301 LOCK WASHER 2 1/2"
10 A3910R CAP 2
11 15H559 PIPE PLUG 1 1/4"
12 AR65596 CYLINDER HEAD 1 (MARKED R55950) (ALSO ORDER AR87693 SWITCH
BELOW COMBINE SERIAL NO. 600000)
13 R80243 ENGINE CYLINDER HEAD GASKET 1 (SUB FOR R59449)
14 19H1895 CAP SCREW 1 1/2" X 3/4"

20-14 COMBINE - 4420 PC1745 (19-DEC-85)

PN=30

TP10260 -UN-01JAN94

1B8

ENGINE

CYLINDER HEAD

(6359DH)

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T26509 STRAP 1
2 T20182 CAP SCREW 23 1/2" X 4-1/4"
R53219 CAP SCREW 3 1/2" X 5", (USED WITH WATER MANIFOLD)
3 T20168 WASHER 23
4 19H1134 CAP SCREW 2 3/8" X 3/4"
5 R56725 COVER 1
6 R54641 GASKET 1
7 T26508 STRAP 1
8 19H1815 CAP SCREW 1 1/2" X 1-1/4"
9 12H301 LOCK WASHER 2 1/2"
10 A3910R CAP 2
11 15H559 PIPE PLUG 1 1/4"
12 RE18931 CYLINDER HEAD 1 (MARKED R81067)
13 R59449 GASKET 1
14 19H444 CAP SCREW 1 1/2" X 1"

COMBINE - 4420 PC1745 (06-SEP-85) 20-15

PN=31

HP2239 -UN-01JAN94

1B9

ENGINE

CYLINDER HEAD OVERHEAT WARNING SENSOR

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR87693 SWITCH 1 TEMPERATURE

20-16 COMBINE - 4420 PC1745 (06-SEP-85)

PN=32

1B10

ENGINE VENTILATOR TUBE AND ROCKER ARM COVER

T39577 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 M19356 HOSE CLAMP 1
2 AT25192 FITTING 1
3 R56463 O-RING 1 (SUB FOR R495R, THIS APPLICATION)
4 T20328 GASKET 1
5 T20294 CAP 1
6 AR100124 SCREW, WITH WASHER 11 (SUB FOR AR45530, THIS APPLICATION)
12H302 LOCK WASHER 11 1/4"
12H302 LOCK WASHER 11 1/4"
7 AT18188 VALVE COVER 1 (SUB FOR AT30694)
8 AR102260 KIT 1 (SUB FOR T20467)
9 37H14 SCREW 1 NO. 10 X 1/2"
10 AM2985T CLIP 1
11 H94255 TUBE 1

(6329DH)

ENGINE

COMBINE - 4420 PC1745 (19-DEC-85) 20-17

PN=33

1B11

ENGINE VENTILATOR TUBE AND ROCKER ARM COVER

T39577 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 M19356 HOSE CLAMP 1
2 AT25192 FITTING 1
3 R56463 O-RING 1 (SUB FOR R495R, THIS APPLICATION)
4 T20328 GASKET 1
5 T20294 CAP 1
6 AR100124 SCREW, WITH WASHER 12
7 AT18188 VALVE COVER 1
8 AR102260 KIT 1
9 37H14 SCREW 1 NO. 10 X 1/2"
10 AM2985T CLIP 1
11 H94255 TUBE 1

(6359DH)

ENGINE

20-18 COMBINE - 4420 PC1745 (06-SEP-85)

PN=34

1B12

MAIN BEARING CAPS AND BEARINGS

T14504 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AT21139 BEARING 1 STANDARD REAR (SET OF (2) T23215)
AT21130 BEARING 1 0.05 MM (.002") UNDERSIZE, REAR (SET OF (2)
T23574)
AT21132 BEARING 1 0.25 MM (.010") UNDERSIZE, REAR (SET OF (2)
T23576)
AT21134 BEARING 1 0.51 MM (.020") UNDERSIZE, REAR (SET OF (2)
T23578)
AT21136 BEARING 1 0.76 MM (.030") UNDERSIZE, REAR (SET OF (2)
T23580)
2 AT21140 BEARING 6 STANDARD, PLAIN (SET OF (2) T23214)
AT21108 BEARING 6 0.05 MM (.002") UNDERSIZE, PLAIN (SET OF (2)
T23552)
AT21110 BEARING 6 0.25 MM (.010") UNDERSIZE, PLAIN (SET OF (2)
T23554)
AT21112 BEARING 6 0.51 MM (.020") UNDERSIZE, PLAIN (SET OF (2)
T23556)
AT21114 BEARING 6 0.76 MM (.030") UNDERSIZE, PLAIN (SET OF (2)
T23558)
3 AT21226 CAP 6 -402787 FRONT AND CENTER, WITH SHIMS AND SET GAUGE,
(SUB R65215)
R65215 BEARING CAP 6 FRONT AND CENTER, (SUB FOR AR82294)
4 T20168 WASHER 14
5 T23474 CAP SCREW 14
6 AT21227 CAP 1 -402787 REAR, WITH SHIMS AND SET GAUGE, (SUB R79089)
R79089 CAP 1 REAR, (SUB FOR AR82295)

(6329DH)

ENGINE

COMBINE - 4420 PC1745 (19-DEC-85) 20-19

PN=35

1B13

MAIN BEARING CAPS AND BEARINGS

T14504 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AT21139 BEARING 1 (SET OF TWO T23215)
AT21130 BEARING 1 (0.05 MM) UNDERSIZE, REAR (SET OF TWO T23574)
AT21132 BEARING 1 (0.25 MM) UNDERSIZE, REAR (SET OF TWO T23576)
AT21134 BEARING 1 (0.51 MM) UNDERSIZE, REAR (SET OF TWO T23578)
AT21136 BEARING 1 (0.76 MM) UNDERSIZE, REAR (SET OF TWO T23580)
2 AT21140 BEARING 6 (SET OF TWO T23214)
AT21108 BEARING 6 (0.05 MM) UNDERSIZE, PLAIN (SET OF TWO
T23552)
AT21110 BEARING 6 (0.25 MM) UNDERSIZE, PLAIN (SET OF TWO
T23554)
AT21112 BEARING 6 (0.51 MM) UNDERSIZE, PLAIN (SET OF TWO
T23556)
AT21114 BEARING 6 (0.76 MM) UNDERSIZE, PLAIN (SET OF TWO
T23558)
3 R65215 BEARING CAP 6
4 T20168 WASHER 14
5 T23474 CAP SCREW 14
6 R79089 CAP 1 (REAR)

(6359DH)

ENGINE

e

20-20 COMBINE - 4420 PC1745 (06-SEP-85)

PN=36

1B14

CRANKSHAFT AND IDLER GEARS

T40885 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

(6329DH)

ENGINE

1 RE17831 SEAL 1 (SUB FOR AT22965 AND AR92893)
2 T26565 DOWEL PIN 1
3 26H72 SHAFT KEY 1 1/8" X 5/8"
4 T20094 GEAR 1 (24 TEETH)
5 AT22562 CRANKSHAFT 1 (MARKED T23266 OR T23267)
6 T26324 THRUST WASHER 2
7 T26323 SHAFT 2
8 34H283 SPRING PIN 1 3/16" X 1-1/8"
9 T20034 BUSHING 1
10 AR91660 GEAR 1 (MARKED R70182) (55 TEETH) (SUB FOR AT18009,
THIS APPLICATION) (MARKED T20029)
11 T26326 THRUST WASHER 2
12 T26327 SCREW 1
13 T20046 OIL SLINGER 1
14 AR67942 SEAL 1
15 T23270 BUSHING 1
16 R56788 SHEAVE 1
17 T20217 WASHER 1
18 19H1721 CAP SCREW 1 1/2" X 1-1/2"
19 T26325 SCREW 2
20 T26321 BUSHING 1
21 AT24252 GEAR 1 (MARKED T26322) (45 TEETH)
22 34H286 SPRING PIN 1 3/16" X 1-1/2"
23 R42364 WASHER 1
24 26H27 SHAFT KEY 1 5/16" X 1-1/8"
25 R42364 WASHER 1
26 RE12823 PULLEY, WITH DAMPENER 1 (SUB FOR AR67820)
27 T20168 WASHER 2
28 19H456 CAP SCREW 2 1/2" X 1-3/8"

COMBINE - 4420 PC1745 (19-DEC-85) 20-21

PN=37

1B15

CRANKSHAFT AND IDLER GEARS

T40885 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

(6359DH)

ENGINE

e

1 AR92893 SEAL 1
2 T26565 DOWEL PIN 1
3 26H72 SHAFT KEY 1 1/8" X 5/8"
4 T20094 GEAR 1 (24 TEETH)
5 AT22562 CRANKSHAFT 1 (MARKED T23266 OR T23267)
6 T26324 THRUST WASHER 2
7 T26323 SHAFT 2
8 34H283 SPRING PIN 1 3/16" X 1-1/8"
9 T20034 BUSHING 1
10 AR91660 GEAR 1 (55 TEETH) (MARKED R70182)
11 T26326 THRUST WASHER 2
12 T26327 SCREW 1
13 T20046 OIL SLINGER 1
14 AR67942 SEAL 1
15 T23270 BUSHING 1
16 R56788 SHEAVE 1
17 T20217 WASHER 1
18 19H1721 CAP SCREW 1 1/2" X 1-1/2"
19 T26325 SCREW 2
20 T26321 BUSHING 1
21 AT24252 GEAR 1 (MARKED T26322) (45 TEETH)
22 34H286 SPRING PIN 1 3/16" X 1-1/2"
23 R42364 WASHER 1
24 26H27 SHAFT KEY 1 5/16" X 1-1/8"
25 R42364 WASHER 1
26 RE12823 PULLEY, WITH DAMPENER 1 (SUB FOR AR67820)
27 T20168 WASHER 2
28 19H456 CAP SCREW 2 1/2" X 1-3/8"

20-22 COMBINE - 4420 PC1745 (06-SEP-85)

PN=38

TP11999 -UN-01JAN94

1B16

ENGINE

UNDERSIZE CRANKSHAFT AND BEARING KIT

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T26565 DOWEL PIN 1

2 .................. CRANKSHAFT 1 0.25 MM (.010") UNDERSIZE, (MARKED T23266)

(SUB DD13896)
3 26H72 SHAFT KEY 1 1/8" X 5/8"
4 AR76129 BEARING 6 0.25 MM (.010") UNDERSIZE (SET OF (2) R62073)
5 T20094 GEAR 1 (24 TEETH)
6 AT21110 BEARING 6 (0.25 MM (.010") UNDERSIZE (SET OF (2)
T23554)
7 AT21132 BEARING 1 0.25 MM (.010") UNDERSIZE (SET OF (2) T23576)
8 DD13896 KIT 1 (A)

(A) UNDERSIZE CRANKSHAFT AND RELATED PARTS SUBJECT TO AVAILABILITY.

COMBINE - 4420 PC1745 (19-DEC-85) 20-23

PN=39

TP15586 -UN-01JAN94

1B17

ENGINE

CAMSHAFT

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T22535 SHAFT 1 (12 TEETH) (USE WITH AT25185)
2A AT25185 CAMSHAFT 1 (MARKED T20464) (SUB R82821 AND R81514)
2B R82821 CAMSHAFT 1
3 T28041 SHAFT KEY 1
4 T20072 PLATE 1
5 19H218 CAP SCREW 2 3/8" X 1"
6 T20070 GEAR 1 (48 TEETH)
7 R81514 GEAR 1 (12 TEETH) (USE WITH R82821)

20-24 COMBINE - 4420 PC1745 (19-DEC-85)

PN=40

1B18

ROCKER ARMS AND VALVES

T39568 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R54565 PLUG 2
2 R54986 SHAFT 1
3 T20316 WASHER 2
4 T20314 SPRING 5
5 T20073 TAPPET 12
6 19H268 CAP SCREW 6 3/8" X 2-1/2"
7 R42729 WASHER 6
8 T20129 CAP 12
9 T20077 RETAINER 24
10 T20176 RETAINER 6
11 R26125 SPRING 12
12 R52252 EXHAUST VALVE 6
R57333 EXHAUST VALVE 6 (0.08 MM) OVERSIZE STEM
R57335 EXHAUST VALVE 6 (0.38 MM) OVERSIZE STEM
R57337 EXHAUST VALVE 6 (0.76 MM) OVERSIZE STEM
13 T20310 PIN 12
14 T20315 SUPPORT 6
15 R52251 INTAKE VALVE 6
R57332 INTAKE VALVE 6 (0.08 MM) OVERSIZE STEM
R57334 INTAKE VALVE 6 (0.38 MM) OVERSIZE STEM
R57336 INTAKE VALVE 6 (0.76 MM) OVERSIZE STEM
16 T32213 SCREW 1 (SUB RE19031)
17 RE19031 ROCKER ARM 12 (SUB FOR AT31250 AND AR103769)
18 T20176 RETAINER 6
19 T22537 FITTING 1
20 H1058R WASHER 1
21 T22536 GEAR 1

(6329DH)

ENGINE

COMBINE - 4420 PC1745 (19-DEC-85) 20-25

PN=41

1B19

ROCKER ARMS AND VALVES

T39568 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R54565 PLUG 2
2 R54986 SHAFT 1
3 T20316 WASHER 2
4 T20314 SPRING 5
5 T20073 TAPPET 12
6 19H268 CAP SCREW 6 3/8" X 2-1/2"
7 R42729 WASHER 6
8 T20129 CAP 12
9 T20077 RETAINER 24
10 T20176 RETAINER 6
11 R26125 SPRING 12
12 R52252 EXHAUST VALVE 6
R57333 EXHAUST VALVE 6 (0.08 MM) OVERSIZE STEM
R57337 EXHAUST VALVE 6 (0.76 MM) OVERSIZE STEM
13 T20310 PIN 12
14 T20315 SUPPORT 6
15 R52251 INTAKE VALVE 6
R57332 INTAKE VALVE 6 (0.08 MM) OVERSIZE STEM
R57336 INTAKE VALVE 6 (0.76 MM) OVERSIZE STEM
16 T32213 SCREW 1 SUB. AT31250
17 AT31250 ROCKER ARM 12
18 T20176 RETAINER 6
19 T22537 FITTING 1
20 H1058R WASHER 1
21 T22536 GEAR 1

(6359DH)

ENGINE

e

20-26 COMBINE - 4420 PC1745 (06-SEP-85)

PN=42

TP2835 -UN-01JAN94

1B20

ENGINE

PISTONS, CYLINDERS, LINERS AND CONNECTING RODS

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T20009 CAP SCREW 12 -530518 (SUB R74194)
R74194 SCREW 12 (USE WITH AR55978)
R80033 SCREW 12 (USE WITH RE16495 AND RE21076)
2 R55647 BUSHING 6
3 RE21076 CONNECTING ROD 6 (SUB FOR AR55978 AND RE16495)
4 M41029 SNAP RING 12
5 R51731 PISTON PIN 6
6 AR55759 PISTON RING KIT 1 (A) (SET OF 3 RINGS) (6 SETS USED)
7 AR77762 PISTON 6 (A)
8 T32343 CYLINDER LINER 6
9 AR71618 KIT 6
10 AR78041 PISTON-LINER KIT 6
11 AT21138 BEARING 6 (SET OF (2) T20011)
AT21122 BEARING 6 (0.05 MM) UNDERSIZE (SET OF (2) T23566)
AT21124 BEARING 6 (0.25 MM) UNDERSIZE (SET OF (2) T23568)
AT21126 BEARING 6 (0.51 MM) UNDERSIZE (SET OF (2) T23570)
AT21128 BEARING 6 (0.76 MM) UNDERSIZE (SET OF (2) T23572)
.. AR54749 LUBRICANT 1 (USED FOR CYLINDER LINER PACKING
INSTALLATION)

COMBINE - 4420 PC1745 (19-DEC-85) 20-27

PN=43

TP2835 -UN-01JAN94

1B21

ENGINE

PISTONS, CYLINDERS AND CONNECTING RODS

(6359DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R80033 CAP SCREW 12
2 R55647 BUSHING 6
3 RE16495 CONNECTING ROD 6
4 M41029 SNAP RING 12
5 R51731 PISTON PIN 6
6 RE15674 PISTON RING KIT 6 (SUB FOR DD11831) (SET OF 3 RINGS)

7 .................. PISTON AR (A) (ORDER RE18694)

.................. PISTON AR (B) (ORDER RE18697)

8 R51726 CYLINDER LINER 6
9 AR65507 O-RING KIT 6
10 RE18694 KIT AR (A) (SUB FOR RE11509)
RE18697 KIT AR (B) (SUB FOR RE11510)
11 AT21138 BEARING 6 (SET OF TWO T20011)
AT21122 BEARING 6 (0.05 MM) UNDERSIZE (SET OF TWO T23566)
AT21124 BEARING 6 (0.25 MM) UNDERSIZE (SET OF TWO T23568)
AT21126 BEARING 6 (0.51 MM) UNDERSIZE (SET OF TWO T23570)
AT21128 BEARING 6 (0.76 MM) UNDERSIZE (SET OF TWO T23572)
.. AR54749 LUBRICANT 1 (USED FOR CYLINDER LINER PACKING
INSTALLATION)

(A) PISTON MARKED "B"
(B) PISTON MARKED "H"

20-28 COMBINE - 4420 PC1745 (06-SEP-85)

PN=44

T48652 -UN-01JAN94

1B22

ENGINE

ENGINE OIL COOLER

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR21837 CLAMP 2 (SUB FOR AR21839, THIS APPLICATION)
2 R57700 HOSE 1
3 R57699 HOSE 1
4 AR21837 CLAMP 6
5 R57698 TUBE 1
6 28H2547 SPACER 1 3/8" X 1"
7 19H2023 CAP SCREW 1 3/8" X 3-1/4"
8 14H785 NUT 1 5/16"
9 R55128 FLANGE 1
10 R55127 HOSE 2
11 R55434 WASHER 1
12 R56947 DRAIN PLUG 1
13 AT31093 VALVE 1 (USE WITH AR64415)
R77332 RELIEF VALVE 1 (USE WITH RE10869)
14 RE10869 OIL COOLER 1 (SUB FOR AR64415)
15 T31306 THREADED NIPPLE 1
16 21H1312 SCREW 1 0.190" X 1"
17 12H295 LOCK WASHER 2 0.190"
18 24H1304 WASHER 1 13/32" X 23/32" X 0.120"
19 R55129 HALF CLAMP 1
20 R57697 TUBE 1

COMBINE - 4420 PC1745 (19-DEC-85) 20-29

PN=45

T48652 -UN-01JAN94

1B23

ENGINE

ENGINE OIL COOLER

(6359DH)

c

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR21837 CLAMP 2
2 R57700 HOSE 1
3 R57699 HOSE 1
4 AR21837 CLAMP 6
5 R57698 TUBE 1
6 28H2547 SPACER 1 3/8" X 1"
7 19H2023 CAP SCREW 1 3/8" X 3-1/4"
8 14H785 NUT 1 5/16"
9 R55128 FLANGE 1
10 R55127 HOSE 2
11 R70956 WASHER 1
12 R56947 DRAIN PLUG 1
13 R77332 RELIEF VALVE 1
14 RE10869 OIL COOLER 1
15 T31306 THREADED NIPPLE 1
16 21H1312 SCREW 1 0.190" X 1"
17 12H295 LOCK WASHER 2 0.190"
18 24H1304 WASHER 1 13/32" X 23/32" X 0.120"
19 R55129 HALF CLAMP 1
20 R57697 TUBE 1

20-30 COMBINE - 4420 PC1745 (06-SEP-85)

PN=46

1B24

T39576 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 M3853T GROOVE PIN 1
2 AR62978 PINION 1 (B)
3 T20298 GEAR 1 (33 TEETH)
4 14H826 NUT 1 1/2"
5 T20091 DOWEL PIN 1
6 AR62979 HOUSING 1 (B) (MARKED R54615)
7 R54614 GEAR 1 (B) (7 TEETH)
8 R53382 COVER 1 (C) (B)
9 R74354 O-RING 1 (C) (B) (SUB FOR R27166, THIS APPLICATION)
10 R61871 O-RING 1 (C) (B) (SUB FOR A4730R, THIS APPLICATION)
11 AR59621 OIL PUMP INTAKE 1 (C) (B) INTAKE
12 T20050 OIL TUBE 1
13 R59409 CAP SCREW 2 (D) (A)
14 12H304 LOCK WASHER 4 (B) 3/8"
15 R57059 CAP SCREW 2 (B)

LUBRICATING OIL PUMP

ENGINE

(C) ASSEMBLY LISTED BELOW CONTAINS ALL PARTS IDENTIFIED BY (C):

.. AR67673 KIT 1 KIT, OIL PUMP PICKUP

(A) ASSEMBLY LISTED BELOW CONTAINS ALL PARTS IDENTIFIED BY (A):

.. AR67077 OIL PUMP 1

COMBINE - 4420 PC1745 (19-DEC-85) 20-31

PN=47

1B25

H23226 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR52217 INTAKE MANIFOLD 1 (INCLUDES (2) 15H638 AND 15H255)
2 15H638 PIPE PLUG 2 1/8", (AIR CLEANER INDICATOR HOLE)
3 19H1732 CAP SCREW 4 3/8" X 1-1/4"
4 12H304 LOCK WASHER 4 3/8"
5 R81275 GASKET 2 (SUB FOR T20159, THIS APPLICATION)
6 R47160 NOZZLE HOLDER 1
15H255 PIPE PLUG 1 3/8", (WITHOUT STARTING AID)
7 R28583 NOZZLE 1
8 AT25983 AIR RESTRICTION INDICATOR 1
9 AR44361 FITTING 1 (WITH RESTRICTION INDICATOR)

T17705 -UN-01JAN94

AIR INTAKE MANIFOLD

EXHAUST MANIFOLD

ENGINE

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T20006 GASKET 6
2 T25701 STUD 4
3 T29809 EXHAUST MANIFOLD 1
4 M1112T STUD 2
5 14H812 NUT 2 3/8"
6 19H1912 CAP SCREW 3 3/8" X 3-1/2"
7 24H1304 WASHER 12 13/32" X 23/32" X 0.120"
8 19H988 CAP SCREW 8 3/8" X 1-1/4"

20-32 COMBINE - 4420 PC1745 (19-DEC-85)

PN=48

T49298 -UN-01JAN94

1C1

ENGINE

ENGINE OVERHAUL GASKET SET

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T24965 GASKET 1 (SUB R73140)
R73140 GASKET 1
2 T20155 GASKET 1
3 R34764 WASHER 6
4 R74354 O-RING 1 (SUB FOR R27166, THIS APPLICATION)
5 R48000 WASHER 6
6 R56463 O-RING 1 (SUB FOR R495R, THIS APPLICATION)
7 T23002 GASKET 3
8 T20328 GASKET 1
9 R26919 WASHER 2
10 R70483 GASKET 1 (SUB FOR R49516, THIS APPLICATION)
11 R48768 WASHER 6
12 T20205 GASKET 1
13 T20467 GASKET 1
14 T20273 GASKET 1
15 T23132 GASKET 1
16 T20336 GASKET 1
17 R27285 GASKET 1
18 R81275 GASKET 2 (SUB FOR T20159, THIS APPLICATION)
19 T24932 GASKET 1
20 T20006 GASKET 6
21 R78366 GASKET 1 (SUB FOR R69260)
22 R80243 ENGINE CYLINDER HEAD GASKET 1 (SUB FOR R59449)
23 T20243 GASKET 1
.. AR79927 GASKET KIT 1 (C) (INCLUDES ALL GASKETS SHOWN ABOVE EXCEPT
CYLINDER HEAD GASKET AND R48768 CYLINDER
LINER PACKING) (ALSO ORDER R80243 HEAD
GASKET) (SUB AR97194)
.. AR97194 GASKET KIT 1 (C) (INCLUDES ALL GASKETS SHOWN ABOVE EXCEPT
CYLINDER HEAD GASKET AND R48768 CYLINDER
LINER PACKING) (ALSO ORDER R80243 HEAD
GASKET)

(C) NOTE: WHEN AR79927 OR AR97194 ARE ORDERED, ALSO ORDER SIX AR71618 CYLINDER LINER PACKINGS KITS

COMBINE - 4420 PC1745 (19-DEC-85) 20-33

PN=49

TP9762 -UN-01JAN94

1C2

ENGINE

ENGINE OVERHAUL GASKET SET

(6359DH)

20-34 COMBINE - 4420 PC1745 (06-SEP-85)

THIS PARTS LISTING IS CONTINUED

PN=50

1C3

ENGINE OVERHAUL GASKET SET-CONTINUED

(6359DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R73140 GASKET 1 CYLINDER BLOCK PLATE
2 T24460 GASKET 1 (ROTO-DIESEL) INJECTION PUMP
R77126 GASKET 1
3 T20155 GASKET 1 TIMING GEAR COVER
4 R56461 O-RING 1 BYPASS THERMOSTAT (SUB FOR R47144)
5 R48000 WASHER 6 NOZZLE, LOWER
6 R56463 O-RING 1 VENT TUBE
7 T23002 GASKET 3 WATER OUTLET MANIFOLD
8 T20328 GASKET 1 OIL FILLER CUP
9 R26919 WASHER 2 OIL COOLER TO PAN
10 R74354 O-RING 1 OIL PUMP OUTLET
11 R60746 WASHER 6 NOZZLE, UPPER
12 R53543 O-RING 1 OIL COOLER
13 R70956 WASHER 1
14 R54641 GASKET 1 WATER OUTLET
15 R70483 GASKET 1 FLYWHEEL HOUSING
16 T20273 GASKET 1 TIMING GEAR COVER
17 R55509 GASKET 1 TURBOCHARGER EXHAUST
18 T20336 GASKET 1 OIL FILLER INLET
19 R27285 GASKET 1 FUEL PUMP OPENING
20 T24932 GASKET 1 THERMOSTAT COVER
21 R69260 GASKET 1 INJECTION PUMP COVER
22 R59449 GASKET 1 CYLINDER HEAD
23 T20006 GASKET 6 EXHAUST MANIFOLD
24 T20159 GASKET 2 AIR INLET
25 AR65507 O-RING KIT 6 KIT, O-RING CYLINDER LINER
26 R43416 GASKET 1 TURBOCHARGER, OIL OUTLET
27 R43413 GASKET 1 TURBOCHARGER, OIL INLET
28 T20243 GASKET 1 WATER PUMP
29 R54229 SEAL 1 (ROOSA-MASTER) INJECTION PUMP
30 AR102260 KIT 1 ROCKER ARM COVER
31 R54638 GASKET 1 THERMOSTAT COVER
32 T20205 GASKET 1 OIL PAN
R56933 GASKET 1 (WITH CAST OIL PAN)
33 AR102286 GASKET KIT 1 (ALSO ORDER (6) AR65507 CYLINDER LINER
PACKING KITS)

ENGINE

COMBINE - 4420 PC1745 (06-SEP-85) 20-35

PN=51

1C4

ENGINE TUNE-UP GASKET SET

T40831 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR102260 KIT 1 ROCKER ARM COVER, (SUB FOR T20467) (ALSO
ORDER (12) AR100124)
2 R48000 WASHER 6 NOZZLE, LOWER
3 R34764 WASHER 6 NOZZLE, UPPER
4 R56463 O-RING 1 VENT TUBE, (SUB FOR R495R, THIS APPLICATION)
5 T23002 GASKET 3 WATER OUTLET MANIFOLD
6 T24932 GASKET 1 THERMOSTAT COVER
7 T20006 GASKET 6 EXHAUST MANIFOLD
8 R81275 GASKET 2 AIR INLET, (SUB FOR T20159, THIS APPLICATION)
9 R80243 ENGINE CYLINDER HEAD GASKET 1 CYLINDER HEAD, (SUB FOR R59449)
10 R54641 GASKET 1 THERMOSTAT HOUSING
.. RE16924 GASKET KIT 1 (INCLUDES ALL GASKETS SHOWN ABOVE EXCEPT
CYLINDER HEAD GASKET) (SUB FOR AR102267)

(6329DH)

ENGINE

20-36 COMBINE - 4420 PC1745 (19-DEC-85)

PN=52

TP9763 -UN-01JAN94

1C5

ENGINE

ENGINE TUNE-UP GASKET SET

(6359DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR102260 KIT 1 ROCKER ARM COVER
2 R48000 WASHER 6 NOZZLE LOWER
3 R54638 GASKET 1 THERMOSTAT COVER
4 R60746 WASHER 6 NOZZLE, UPPER
5 R56463 O-RING 1 VENT TUBE
6 T23002 GASKET 3 WATER OUTLET MANIFOLD
7 T24932 GASKET 1 THERMOSTAT COVER
8 T20006 GASKET 6 EXHAUST MANIFOLD
9 T20159 GASKET 2 AIR INLET
10 R55509 GASKET 1 TURBOCHARGER EXHAUST
11 R54641 GASKET 1 WATER OUTLET
12 R43416 GASKET 1 TURBOCHARGER, OIL OUTLET
13 R43413 GASKET 1 TURBOCHARGER, OIL INLET
14 R47144 O-RING 1 BYPASS, THERMOSTAT
15 R59449 GASKET 1 CYLINDER HEAD
16 R34764 WASHER 6 UPPER
17 AR102267 GASKET KIT 1

COMBINE - 4420 PC1745 (06-SEP-85) 20-37

PN=53

TP6537 -UN-01JAN94

1C6

ENGINE

WATER PUMP

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR40148 PULLEY 1
2 19H2545 CAP SCREW 3 3/8" X 1-3/8"
3 T32853 STRAP 1
4 15H584 PIPE PLUG 1 1/2"
5 AR26732 ELBOW FITTING 1
6 T25485 GASKET 1
7 JD9257 BALL BEARING 1
8 T27261 SEAL 1
9 AR41691 INSERT 1
10 R40979 IMPELLER 1
11 T25484 COVER 1
12 T20243 GASKET 1
13 T25701 STUD 1
14 14H812 NUT 1 3/8"
15 19H1912 CAP SCREW 2 3/8" X 3-1/2"
16 R34985 LINE 2
17 AR80113 HOUSING 1 (MARKED R62902)
18 19H1801 CAP SCREW 3 3/8" X 2"
19 R62371 HUB 1 (THIS APPLICATION ONLY)
20 19H2284 CAP SCREW 4 3/8" X 7/8", (USE WITH R62371)
21 24H1682 WASHER 4 13/32" X 7/8" X 0.120", (USE WITH R62371)
22 AR77682 WATER PUMP 1

20-38 COMBINE - 4420 PC1745 (19-DEC-85)

PN=54

1C7

T45371 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T24934 COVER 1
2 AR21839 CLAMP 2
3 R53219 CAP SCREW 3
4 T25479 HOSE 1
5 AR26732 ELBOW FITTING 1
6 AR74154 MANIFOLD 1 (MARKED R61178)
7 T20168 WASHER 3
8 T23002 GASKET 3
9 AR77411 THERMOSTAT 1 (91° C)
10 T24932 GASKET 1
11 19H2549 CAP SCREW 3 3/8" X 1-7/8"
12 AT13740 DRAIN VALVE 1 -450000 (SUB AH109183, THIS APPLICATION)
AH109183 VALVE 1

WATER MANIFOLD AND THERMOSTAT

ENGINE

COMBINE - 4420 PC1745 (19-DEC-85) 20-39

PN=55

HP1138 -UN-01JAN94

1C8

ENGINE

ENGINE SUPPORTS

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 H75748 SUPPORT 1
2 19H1847 CAP SCREW 3 5/8" X 2-1/2"
12H294 LOCK WASHER 3 5/8"
3 H80197 BUSHING 6
4 H80989 SUPPORT 1
5 19H1936 CAP SCREW 6 3/8" X 3/4"
14H812 NUT 3 3/8"
6 H75747 SUPPORT 1
7 19H1824 CAP SCREW 2 5/8" X 2-1/4"
12H294 LOCK WASHER 2 5/8"
8 H80988 SUPPORT 1
9 19H1815 CAP SCREW 1 1/2" X 1-1/4"
12H301 LOCK WASHER 1 1/2"
10 H91710 RAIL 1 -401580 (SUB H103269)
H103269 RAIL 1
11 H85481 BUSHING 4
12 P50456 WASHER 4
13 19H1863 CAP SCREW 3 5/8" X 3"
12H294 LOCK WASHER 3 5/8"
14H760 NUT 3 5/8"
14 P50456 WASHER 1
15 19H1732 CAP SCREW 3 3/8" X 1-1/4"
14H812 NUT 3 3/8"
16 H80198 ISOLATOR 2
17 H78855 BRACKET 1
18 H78856 RETAINER 2
19 19H1731 CAP SCREW 3 3/8" X 1"
14H812 NUT 3 3/8"
20 H78857 BRACKET 1
21 24H1305 WASHER AR 13/32" X 13/16" X 0.065"
22 H83347 STRAP 1

20-40 COMBINE - 4420 PC1745 (19-DEC-85)

PN=56

HP2469 -UN-01JAN94

1C9

ENGINE

ENGINE COOLANT HEATER

a

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR50411 WIRING LEAD 1
2 R54510 CAP 1
3 R54511 NUT 1
4 R54123 ADAPTER 1
5 R47693 GASKET 1
6 U13639 O-RING 1
7 AR62399 COOLANT HEATER 1
8 AR62492 COOLANT HEATER 1
9 AH77279 CLIP 1

COMBINE - 4420 PC1745 (06-SEP-85) 20-41

PN=57

HP1980 -UN-01JAN94

1C10

ENGINE

FLAT ROTARY SCREEN

e

20-42 COMBINE - 4420 PC1745 (06-SEP-85)

THIS PARTS LISTING IS CONTINUED

PN=58

1C11

FLAT ROTARY SCREEN - CONTINUED

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 H96344 BOLT 1
2 24H1136 WASHER 1 11/32" X 11/16" X 0.065"
3 E46219 SPACER 1
4 H100596 WASHER 1
5 H97355 THRUST WASHER 1
6 H574B SPRING 1
7 AH96050 ISOLATOR 1
8 AH81161 BALL BEARING 1 -600000 (SUB AH115444)
AH115444 BALL BEARING 1
9 AH95373 SCREEN 1
10 E54809 LOCK NUT 1
11 AH92662 SEAL 1
12 H118698 RETAINER 1 (USE WITH EXISTING SCREWS)
13 H86918 SCREW 2
14 H95507 BLADE 1
15 H86259 BELT 1
16 37H149 SCREW 11 1/4" X 3/8"
17 AH108368 SHIELD 1
18 37H148 SCREW 11 1/4" X 5/8"
R54057 SCREW 1 (USE WITH 24H1436)
19 24H1917 WASHER 1 21/64" X 1-15/32" X 7/64"
20 24H1436 WASHER AR 15/16" X 1-3/4" X 0.134"
21 H97175 SHROUD 1
22 R53677 LOCK NUT 9
23 37H148 SCREW 2 1/4" X 5/8"
N10217 LOCK NUT 2
24 H95324 BLADE 1
25 H92012 AIR DUCT 1
26 H97103 COVER 1

ENGINE

COMBINE - 4420 PC1745 (06-SEP-85) 20-43

PN=59

1C12

H32012F -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 E10018 PRESSED FLANGED HOUSING 4
2 JD9246 BALL BEARING 2
3 19H1936 CAP SCREW 6 3/8" X 3/4"
12H304 LOCK WASHER 6 3/8"
4 22H897 SET SCREW 2 1/4" X 1/4"
5 JD8551 ECCENTRIC LOCKING COLLAR 2
6 H86262 SHEAVE 1 181 MM (7-1/8") DIA.
7 H86263 HUB 1
8 14H732 NUT 2 3/8"
9 22H817 SET SCREW 2 3/8" X 3/4"
10 H86260 SHEAVE 1 168 MM (6-5/8") DIA. (CAB WITHOUT AIR
CONDITIONER AND LESS CAB)
H86262 SHEAVE 1 181 MM (7-1/8") DIA. (CAB WITH AIR
CONDITIONER)
11 19H1906 CAP SCREW 4 5/16" X 1-1/2"
N10213 LOCK NUT 4

12 .................. KEY 1 (6 MM X 38 MM) (CUT FROM H64374 IN AH64587

KEY STOCK KIT)
13 H94705 COUNTERSHAFT 1 -400000 (USE WITH H96509 AND 19H3427) (SUB H103319)
H103319 SHAFT 1
14 H96509 SHEAVE 1 POLY-V
15 19H3427 SCREW 1 5/16" X 2"
16 H87784 SHIM 2

ROTARY SCREEN DRIVE SHAFT

ENGINE

20-44 COMBINE - 4420 PC1745 (06-SEP-85)

PN=60

HP597 -UN-01JAN94

1C13

ENGINE

ROTARY SCREEN DRIVE BELT TIGHTENERS AND DISPLACER

c

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AH89678 HANDLE 1 (A)
2 28H1914 BUSHING 3 1/4" X 7/8"
3 H88458 PLATE 1 (A)
4 AH92661 SEAL 1 (A)
5 19H1936 CAP SCREW 4 3/8" X 3/4"
12H304 LOCK WASHER 4 3/8"
6 24H1312 WASHER 4 13/32" X 1-3/8" X 0.105"

7 .................. PLATE 1 (A) (SUB AH93325)

8 H88457 WASHER 1 (A)
9 19H1875 CAP SCREW 2 5/16" X 1-3/4"
M40699 NUT 2 (A)
10 H100197 PIN 1 (A)
11 19H1949 CAP SCREW 1 5/16" X 2-1/2"
12 H86280 SPRING 1
13 H91788 BUSHING 1 (USE WITH AH95281)
14 AH95281 ARM 1
15 H94562 BOLT 1
16 AH87929 SHEAVE 2 78 MM (3-1/16") DIA.
17 19H1732 CAP SCREW 2 3/8" X 1-1/4"
18 R28473 PLUG 1 (A)
19 N10215 LOCK NUT 1 (A)

KIT LISTED BELOW CONSISTS OF ALL PARTS IDENTIFIED BY AN (A):

.. AH93325 DEVICE 1 KIT, DISPLACER ASSEMBLY

COMBINE - 4420 PC1745 (06-SEP-85) 20-45

PN=61

HP2240 -UN-01JAN94

1C14

ENGINE

RADIATOR

(USE WITH AIR CONDITIONER)

a

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 H92599 TANK 1 (WITH DECAL)
2 AR48236 CLAMP 2
3 H92726 HOSE 1
4 N71292 SELF-LOCKING SCREW 3
N10213 LOCK NUT 2
5 AN110020 CAP 1
6 AR21839 CLAMP 2
7 H86772 HOSE 1
8 N10212 SELF-LOCKING SCREW 1
9 H92849 RADIATOR HOSE 1
10 24H1224 WASHER 1 11/32" X 1" X 1/16"
11 19H1900 CAP SCREW 1 5/16" X 3/4"
N10213 LOCK NUT 1
12 24H1311 WASHER 1 13/32" X 1-1/4" X 0.220"
13 AT13740 DRAIN VALVE 1
14 N71292 SELF-LOCKING SCREW 3
15A AH87737 SWITCH 1 -600000
15B H87663 PLUG 1 600001-
16 AH92498 RADIATOR 1
17 AR21840 CLAMP 2
18 AR21999 HOSE CLAMP 2
19 H120438 RADIATOR HOSE 1 LOWER
20 H76064 CLIP 2
21 H87279 HOSE 1 UPPER
22 R45440 TIE BAND 1

20-46 COMBINE - 4420 PC1745 (06-SEP-85)

PN=62

H32739 -UN-01JAN94

1C15

ENGINE

RADIATOR

(USE WITHOUT AIR CONDITIONER)

a

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AH87560 TANK 1
2 H86401 CAP 1
3 H86772 HOSE 1
4 AH87561 CAP 1
5 AH88817 RADIATOR 1
6 24H1224 WASHER 1 11/32" X 1" X 1/16"
7 19H1900 CAP SCREW 1 5/16" X 3/4"
N10213 LOCK NUT 1
8 AR21840 CLAMP 2
9 H87279 HOSE 1 UPPER
10 AH87737 SWITCH 1 -600000
15H624 PIPE PLUG 1 600001- 1/2"
11 N71292 SELF-LOCKING SCREW 3
12 AR21999 HOSE CLAMP 2
13 AT13740 DRAIN VALVE 1
14 AR21836 CLAMP 1
15 24H1136 WASHER 2 11/32" X 11/16" X 0.065"
16 N10219 SELF-LOCKING SCREW 2
N10213 LOCK NUT 2
17 H79784 BUSHING 2
18 24H1311 WASHER 1 13/32" X 1-1/4" X 0.220"
19 R45440 TIE BAND 1
20 H93310 HOSE 1 LOWER

COMBINE - 4420 PC1745 (06-SEP-85) 20-47

PN=63

HP844 -UN-01JAN94

1C16

ENGINE

FAN, SHEAVE, AND SUPPORT

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 24H1224 WASHER 4 11/32" X 1" X 1/16"
2 03H1709 BOLT 4 5/16" X 1"
N10213 LOCK NUT 4
3 AH90839 SUPPORT 1
4 JD9294 BALL BEARING 1
5 H92056 HOUSING 1
6 H84556 HUB 1
7 AH85041 SHEAVE 1 196 MM (7-23/32") DIA.
8 H86271 BELT 1 (CAB WITHOUT AIR CONDITIONER AND LESS CAB)
H94373 BELT 1 (CAB WITH AIR CONDITIONER)
9 AH87533 FAN 1
10 19H1731 CAP SCREW 4 3/8" X 1"
11 24H1305 WASHER 3 13/32" X 13/16" X 0.065"
12 N14822 SELF-LOCKING SCREW 3

20-48 COMBINE - 4420 PC1745 (06-SEP-85)

PN=64

HP1936 -UN-01JAN94

1C17

ENGINE

RADIATOR FAN DRIVE BELT TIGHTENER

c

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 24H1653 WASHER 2 13/32" X 1-1/4" X 0.120"
2 03H1557 BOLT 2 3/8" X 1-1/4"
12H304 LOCK WASHER 2 3/8"
14H812 NUT 2 3/8"
3 H96424 CAP 1
4 AH90288 BRACKET 1 - 450000 (SUB H109215)
H109215 BRACKET 1
5 H86839 SNAP RING 1
6 24H1362 WASHER 1 41/64" X 1" X 0.075"
7 H91788 BUSHING 2
8 AH95011 HUB 1
9 H96251 WASHER 1
10 H86264 TORSION SPRING 1 L.H. TORSION
11 03H1764 BOLT 1 1/2" X 1-3/4"
12H301 LOCK WASHER 1 1/2"
14H1040 NUT 1 1/2"
12 AH96492 ARM 1
13 B31498 WASHER 1 - 600000 (SUB H88355)
H88355 WASHER 1
14 AH77172 IDLER 1 102 MM (4") DIA.
15 H86886 NUT 1
16 03H1937 BOLT 3 5/16" X 1-1/4"
N10213 LOCK NUT 3

COMBINE - 4420 PC1745 (06-SEP-85) 20-49

PN=65

HP1937 -UN-01JAN94

1C18

ENGINE

RADIATOR FAN AND ROTARY SCREEN SHAFT DRIVE BELT TIGHTENER

c

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 H96424 CAP 1
2 H86776 BRACKET 1
3 19H1936 CAP SCREW 2 3/8" X 3/4"
12H304 LOCK WASHER 2 3/8"
4 24H1305 WASHER 2 13/32" X 13/16" X 0.065"
5 H86839 SNAP RING 1
6 24H1362 WASHER 1 41/64" X 1" X 0.075"
7 H91788 BUSHING 2
8 AH95011 HUB 1
9 H96251 WASHER 1
10 H86265 TORSION SPRING 1 R.H. TORSION
11 H86886 NUT 1
12 AH96492 ARM 1
13 AH77172 IDLER 1 102 MM (4") DIA.
14 H86514 BOLT 1
12H301 LOCK WASHER 1 1/2"
14H1040 NUT 1 1/2"
15 B31498 WASHER 1 - 600000 (SUB H88355)
H88355 WASHER 1
16 03H1524 BOLT 3 5/16" X 1"
N10213 LOCK NUT 3

20-50 COMBINE - 4420 PC1745 (06-SEP-85)

PN=66

1C19

H16861 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AT25265 FITTING 1

2 .................. TUBE 1 (1067 MM) (42") LONG (CUT FROM H86108)

3 AT25264 FITTING 1

OIL PRESSURE GAUGE TUBE

ENGINE

COMBINE - 4420 PC1745 (06-SEP-85) 20-51

PN=67

MEMORANDA

ENGINE

20-52 COMBINE - 4420 PC1745 (06-SEP-85)

PN=68

HP2026 -UN-01JAN94

1C22

FUEL AND AIR

FUEL TANK AND SUPPORTS

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AH97868 CAP 1 -451640 NON-VENTED, (SUB AH110230)
AH110230 CAP 1 VENTED
2 21H1310 SCREW 2 1/4" X 1/2"
14H786 NUT 2 1/4"
3 AH83337 FILLER NECK 1
4 AR21999 HOSE CLAMP 2
5 H76165 HOSE 1
6 H76162 BRACKET 1 UPPER
7 19H1813 CAP SCREW 2 -450000 5/16" X 5/8"
14H785 NUT 2 -450000 5/16"
N10212 SELF-LOCKING SCREW 2 450001-
N10213 LOCK NUT 2 450001-
8 H76139 SCREW 2 SELF-TAPPING
9 AH93230 FUEL TANK 1
10 H105967 GASKET 1
11 AH75543 SUPPORT 1 LOWER
12 19H1907 CAP SCREW 2 5/16" X 2-3/4"
14H812 NUT 2 3/8"
13 24H1136 WASHER 4 -450000 11/32" X 11/16" X 0.065"
14 19H2127 CAP SCREW 4 5/16" X 7/8"
14H785 NUT 4 5/16"
15 AH20936 VALVE 1
16 15H638 PIPE PLUG 1 1/8"
17 AH96547 BREATHER 1
18 H99234 COVER 1 -600000
19 AH97869 LINK CHAIN 1
20 H99897 RETAINER 2
21 19H2127 CAP SCREW 2 -450000 5/16" X 7/8"
14H785 NUT 2 -450000 5/16"
N10212 SELF-LOCKING SCREW 2 450001-
N10213 LOCK NUT 2 450001-

COMBINE - 4420 PC1745 (28-MAR-84) 30-1

PN=69

HP2520 -UN-01JAN94

1C23

FUEL AND AIR

FUEL LINES AND PUMP

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 U45538 ELBOW FITTING 2 90°, (SUB FOR H81734)
2 M66044 TIE BAND 3

3 .................. HOSE 1 6 MM X 2591 MM (1/4" X 112") LONG (CUT FROM

H83966)
4 H79481 GROMMET 1
5 R27296 NUT 1
6 AR35981 ELBOW FITTING 1
7 AH83462 FUEL LINE 1 UPPER
8 R27346 FITTING 2
9 T13254 CLAMP 2
10 AH77279 CLIP 3
11 AH80244 FUEL LINE 1 MIDDLE (WITH AUXILIARY FUEL FILTER)
12 R50201 FITTING 1
13 H83287 HOSE FITTING 1 90°
14 AH77277 FUEL LINE 1 MIDDLE
15 H101158 TRANSISTOR 1
16 AH107362 PUMP 1 (SUB FOR H80665)
17 19H1227 CAP SCREW 2 -450000 1/4" X 1/2"
14H786 NUT 2 -450000 1/4"
N14820 SELF-LOCKING SCREW 2 450001-
N10217 LOCK NUT 2 450001-

18 .................. HOUSING 1

19 AH98799 VALVE 1 ("T" HANDLE)
AA4298R SHUT-OFF VALVE 1 ("L" HANDLE)
20 AH96221 SCREEN 1

30-2 COMBINE - 4420 PC1745 (06-SEP-85)

THIS PARTS LISTING IS CONTINUED

PN=70

1C24

FUEL AND AIR

FUEL LINES AND PUMP - CONTINUED

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

21 C1778R GASKET 1
22 AA4507R SEDIMENT BOWL 1
23 AA517R BAIL 1
24 R21752 NUT 1
25 AH97859 FUEL FILTER 1 -450000 ("T" HANDLE) (SUB AH106484 AND AH106982)
AH106484 FUEL FILTER 1 ("T" HANDLE) (USE WITH AH106982)
26A AH105136 SCREEN 1 400001-450000
26B AH106982 SCREEN 1 450001-
27 R10093 O-RING 1 400001-450000
28 AH80242 FUEL LINE 1 (WITH AUXILIARY FUEL FILTER)
AH77926 FUEL LINE 1
29 T32231 CLAMP 2
30 19H1900 CAP SCREW 2 5/16" X 3/4"
14H785 NUT 2 5/16"
31 AR26674 ELBOW FITTING 2
32 AH75547 FUEL LINE 1

COMBINE - 4420 PC1745 (06-SEP-85) 30-3

PN=71

T34065 -UN-01JAN94

1C25

FUEL AND AIR

FUEL FILTER

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R56832 BRACKET 1
2 19H1134 CAP SCREW 2 3/8" X 3/4"
3 T24945 ELBOW FITTING 1
4 AR50040 HOUSING 1
5 AR67858 FUEL LINE 1 (FUEL FILTER TO INJECTION PUMP)
6 R34447 WASHER 2
7 R48071 DRAIN PLUG 2
8 R27346 FITTING 1
9 AR67860 FUEL LINE 1 (FUEL FILTER TO FUEL TRANSFER PUMP)
10 T30738 ELBOW FITTING 1
11 AR86745 FILTER ELEMENT 1 (SUB FOR AR50041)
12 R66821 CLAMP 1 (SUB FOR R57258)
13 19H2284 CAP SCREW 2 3/8" X 7/8"
14 15H558 PIPE PLUG 1 1/8"
15 12H304 LOCK WASHER 2 3/8"
16 14H812 NUT 2 3/8"
17 R48008 ELBOW FITTING 1

30-4 COMBINE - 4420 PC1745 (19-DEC-85)

PN=72

HP2301 -UN-01JAN94

1D1

FUEL AND AIR

FUEL FILTER AND LINES

(6359DH)

c

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR63954 FUEL LINE 1 (FUEL FILTER TO INJECTION PUMP)
2 T30738 ELBOW FITTING 1
3 AR50040 HOUSING 1
4 R26287 O-RING 2
5 R48071 DRAIN PLUG 2
6 R27346 FITTING 1
7 AR84732 FUEL LINE 1 (FUEL FILTER TO FUEL TRANSFER PUMP)
8 AR86745 FILTER ELEMENT 1 (SUB FOR AR50041)
9 R66821 CLAMP 1
10 19H1731 CAP SCREW 2 3/8" X 1"
11 24H1303 WASHER 2 13/32" X 11/16" X 0.065"
12 15H558 PIPE PLUG 1 1/8"

COMBINE - 4420 PC1745 (19-DEC-85) 30-5

PN=73

HP1140 -UN-01JAN94

1D2

FUEL AND AIR

FUEL LINES

(FOR EXPORT USE ONLY)

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AH80244 FUEL LINE 1
2 H81734 ELBOW FITTING 2 90°
3 AH80242 FUEL LINE 1

30-6 COMBINE - 4420 PC1745 (28-MAR-84)

PN=74

HP551 -UN-01JAN94

1D3

FUEL AND AIR

FUEL FILTER

(FOR EXPORT USE ONLY)

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 19H1936 CAP SCREW 4 3/8" X 3/4"
2 24H1136 WASHER 2 11/32" X 11/16" X 0.065"
3 H88949 BRACKET 1
4 H81528 SCREW 2 -317200 (SUB N10212, THIS APPLICATION)
N10212 SELF-LOCKING SCREW 2
H77210 NUT 2
5 P53007 BLEED SCREW 2
6 P53005 COVER 1
7 P53022 WASHER 1
8 P54602 SCREW 1 (USE WITH 14H253)
9 14H253 NUT 1 5/16"
10 AP27684 BOWL 1
11 AP27685 EXTENSION SPRING 1
12 AP27686 ADAPTER 1
13 P53006 GASKET 1
14 AP27010 FILTER ELEMENT 1 -400987 (SUB AP27688)
AP27688 FILTER ELEMENT 1

COMBINE - 4420 PC1745 (28-MAR-84) 30-7

PN=75

1D4

H32792 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 H87467 KNOB 1
2 AH97872 LEVER 1
3 34H290 SPRING PIN 1 3/16" X 2"
4 11H218 COTTER PIN 1 3/16" X 1-1/2"
5 H78110 WASHER 2
6 H574B SPRING 1
7 H78111 RETAINER 2
8 H77243 ARM 1
9 R26524 CLIP 1 CLEVIS, R.H.
10 H77240 PIN 1 THROTTLE, UPPER
11 AH76121 BRACKET 1
12 R26501 CLIP 2 CLEVIS, L.H.
13 H83348 ROD 1 -450000 (SUB H110199)
H110199 ROD 1 -600000 INJECTION PUMP (DOUBLE BEND)
H121847 HOOK BOLT 1 600001-
14 24H1287 WASHER 1 9/32" X 5/8" X 0.065"
15 H28108 SWIVEL 1
16 11H206 COTTER PIN 1 3/32" X 3/4"
17 H77244 PIN 1
18 11H206 COTTER PIN 1 3/32" X 3/4"

THROTTLE CONTROLS

FUEL AND AIR

a

30-8 COMBINE - 4420 PC1745 (28-MAR-84)

PN=76

HP890 -UN-01JAN94

1D5

FUEL AND AIR

COLD WEATHER STARTING AID

e

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR27814 STARTING FLUID 1
2 H76139 SCREW 2
3 H89659 BRACKET 1 -401580 (SUB H103273)
H103273 BRACKET 1
4 T32231 CLAMP 1 INSULATED
5 H86108 LINE 1 STARTING FLUID
6 AT25266 ELBOW FITTING 2
15H638 PIPE PLUG 2 1/8"
7 R47160 NOZZLE HOLDER 1
8 R28583 NOZZLE 1
9 M66044 TIE BAND 3
10 AT57288 BAIL 1
11 T46726 GASKET 1

12 .................. SOLENOID 1 (SUB AT39623)

13 AT39623 SOLENOID 1

COMBINE - 4420 PC1745 (28-MAR-84) 30-9

PN=77

H32730 -UN-01JAN94

1D6

FUEL AND AIR

FUEL INJECTION SYSTEM

(6329DH)

(ROOSA-MASTER NO. JDB635MD3055)

(ENGINE SERIAL NO. -505383)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R48599 NUT 1
2 R48600 LOCK WASHER 1
3 26H10 SHAFT KEY 1 5/32" X 5/8"
4 AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)
5 T13201 ELBOW FITTING 1
6 AR49907 WIRING LEAD 1 (INJECTION PUMP SHUT-OFF TERMINAL)
7 AR68962 FUEL LINE 1 (FUEL INJECTION NO. 1)
8 T13913 CLIP 1
9 R64764 WASHER 1 (SUB FOR L186T)
10 12H302 LOCK WASHER 1 1/4"
11 19H2036 CAP SCREW 1 1/4" X 7/8"
12 R56830 TUBE 1
13 AT27622 CAP 6

14 .................. HOSE 5 (CUT FROM AT32064)

15 AR68963 FUEL LINE 1 (FUEL INJECTION NO. 2)
16 AR68964 FUEL LINE 1 (FUEL INJECTION NO. 3)
17 AR88239 INJECTION NOZZLE 6 (ROOSA-MASTER NO. 22042)
18 AR68966 FUEL LINE 1 (FUEL INJECTION NO. 5)

19 .................. HOSE 2 35.6 MM (1.40") (CUT FROM AT32064)

20 AR49915 FUEL LINE 1 (FUEL INJECTION PUMP LEAK-OFF)
21 R34760 CLAMP 6
22 R34761 SPACER 6 (SUB (6) RE13887, THIS APPLICATION)
R60745 SPACER 6 (K)
23 R48000 WASHER 6
24 R60746 WASHER 6 (K) (USE WITH AR88239) (USE AFTER RE13887 HAS
BEEN INSTALLED)
25 AR68967 FUEL LINE 1 (FUEL INJECTION NO. 6)
26 AR76704 SCREW 6
27 R59297 HALF CLAMP 2
R59298 STRAP 2
R61145 STRAP 2
28 R59297 HALF CLAMP 2
29 AR68965 FUEL LINE 1 (FUEL INJECTION NO. 4)
30 T20055 WASHER 12
31 R26726 FITTING 6
32 14H812 NUT 2 3/8"
33 12H304 LOCK WASHER 2 3/8"

(K) KIT RE13887

30-10 COMBINE - 4420 PC1745 (19-DEC-85)

PN=78

1D7

FUEL INJECTION SYSTEM - CONTINUED

(6329DH)

(ROOSA-MASTER NO. JDB635MD3055)

(ENGINE SERIAL NO. -505383)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

34 24H1303 WASHER 2 13/32" X 11/16" X 0.065"
35 T20052 STUD 2
36 T20165 GEAR 1
37 R64810 CLAMP 1
R59298 STRAP 1
R61145 STRAP 1
38 AR48236 CLAMP 1
39 R64810 CLAMP 1

FUEL AND AIR

COMBINE - 4420 PC1745 (19-DEC-85) 30-11

PN=79

TP241 -UN-01JAN94

1D8

FUEL AND AIR

FUEL INJECTION SYSTEM

(6329DH)

(ROOSA-MASTER NO. JDB635MD3055)

(ENGINE SERIAL NO. 505384- )

30-12 COMBINE - 4420 PC1745 (19-DEC-85)

THIS PARTS LISTING IS CONTINUED

PN=80

1D9

FUEL AND AIR

FUEL INJECTION SYSTEM - CONTINUED

(ROOSA-MASTER NO. JDB635MD3055)

(ENGINE SERIAL NO. 505384- )

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R71742 TUBE 1 (SUB FOR R56830, THIS APPLICATION)
2 R51937 TUBE NUT 13
3 R51936 PACKING 12
4 AR85618 CAP 6 (SUB (6) R79604, (6) R79605 AND (6) R79606)
5 R66090 TUBE 5
6 R34760 CLAMP 6
7 R34761 SPACER 6 -608907 (SUB (6) RE13887, THIS APPLICATION)
R60745 SPACER 6 608908- (K)
8 AR89960 FUEL LINE 1
9 R48000 WASHER 6
10 R60746 WASHER 6 (K) (USE WITH AR88239) (USE AFTER RE13887 HAS
BEEN INSTALLED)
R34764 WASHER 6 -608907 (USE WITH AR89564) (SUB (6) RE13887, THIS
APPLICATION)
11 AR76704 SCREW 6
12 R64810 CLAMP 1
R59298 STRAP 1
13 R64810 CLAMP 1
R61145 STRAP 1
14 AR68967 FUEL LINE 1 (NO. 6)
15 AR68966 FUEL LINE 1 (NO. 5)
16 R59297 HALF CLAMP 2
R61145 STRAP 2
17 R59297 HALF CLAMP 2
R59298 STRAP 2
18 AR68965 FUEL LINE 1 (NO. 4)
19 AR88239 INJECTION NOZZLE 6 -575164 (SUB AR89564)
AR89564 INJECTION NOZZLE 6
20 AR68964 FUEL LINE 1 (NO. 3)
21 AR68963 FUEL LINE 1 (NO. 2)
22 AR68962 FUEL LINE 1 (NO. 1)
23 T13201 ELBOW FITTING 1
24 T20055 WASHER 12
25 R26726 FITTING 6
26 14H812 NUT 2 3/8"
27 12H304 LOCK WASHER 2 3/8"
28 24H1303 WASHER 2 13/32" X 11/16" X 0.065"
29 T20052 STUD 2
30 T20165 GEAR 1
31 R48599 NUT 1
32 R48600 LOCK WASHER 1
33 26H10 SHAFT KEY 1 5/32" X 5/8"
34 AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635M03055)
35 AR49907 WIRING LEAD 1
36 T13913 CLIP 1
37 L186T WASHER 1
38 12H302 LOCK WASHER 1 1/4"
39 19H2036 CAP SCREW 1 1/4" X 7/8"

(6329DH)

(K) KIT RE13887

COMBINE - 4420 PC1745 (19-DEC-85) 30-13

PN=81

T20527 -UN-01JAN94

1D10

FUEL AND AIR

FUEL INJECTION PUMP ELECTRIC SHUT-OFF

(6329DH)

(ROOSA- MASTER)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T19977 LOCK NUT 2 (B) (C)
2 R47049 WASHER 3 (B) (C) (SUB AR90601)
3 R66593 STRAP 1 (GROUNDING) (SUB FOR AR49542) (SUB AR50874)
4 R47077 LOCK WASHER 1
5 T11938 NUT 2 (SUB AR90601)
6 T11936 WASHER 2 (B) (C) (SUB AR90601)
7 R37139 COVER 1 (B)
8 T11918 GASKET 1 (A) (B)
9 AR48219 SOLENOID 1 (B) (C) (SUB AR90340, THIS APPLICATION)
10 12H295 LOCK WASHER 1 0.190"
11 T11937 INSULATOR 2 (B) (C)
12 R48795 SLEEVE 1
13 T11935 SPRING 1 (B) (C)
14 AT11524 ARM 1 (B) (C) (SUB AR90340, THIS APPLICATION)
.. AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)

KIT LISTED BELOW CONSISTS OF ALL PARTS IDENTIFIED BY AN (A) ON THIS PAGE AND PAGES 30-4, 30-7,
30-10, 30-14, 30-20, AND 30-21.

.. AR34612 GASKET KIT 1 OVERHAUL GASKET

ASSEMBLY LISTED BELOW CONSISTS OF ALL PARTS IDENTIFIED BY A (B).

.. AR49543 COVER 1 (SUB AR90340, THIS APPLICATION)

ASSEMBLY LISTED BELOW CONSISTS OF ALL PARTS IDENTIFIED BY A (C).

.. AR87068 KIT 1 (SUB FOR AR51796) (SUB AR90340, THIS
APPLICATION)

30-14 COMBINE - 4420 PC1745 (19-DEC-85)

PN=82

TP3066 -UN-01JAN94

1D11

FUEL AND AIR

FUEL INJECTION PUMP ELECTRIC SHUT-OFF KIT

(6329DH)

(ROOSA-MASTER)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T19977 LOCK NUT 2

2 .................. WASHER 1 (SUB AR90601)

3 AR90601 KIT 1 NUT AND WASHER
4 R47077 LOCK WASHER 1

5 .................. STRAP 1 (SUB AR50874)

6 12H295 LOCK WASHER 1 0.190"

7 .................. WASHER 1 (SUB AR50874)

8 AR50874 KIT 1 GROUND STRAP
9 R48795 SLEEVE 1
10 T11935 SPRING 1
11 T11937 INSULATOR 2

12 .................. SOLENOID 1

13 AR90340 KIT 1
.. AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)

COMBINE - 4420 PC1745 (19-DEC-85) 30-15

PN=83

T34066 -UN-01JAN94

1D12

FUEL AND AIR

FUEL INJECTION PUMP AUTOMATIC ADVANCE

(6329DH)

(ROOSA-MASTER)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T17117 CAP 1
2 T17122 NUT 1
3 R76578 O-RING 1 (K) (SUB FOR T11915)
4 T17123 SET SCREW 1
5 T17126 PLUG 1
6 T15710 O-RING 2 (K)
7 T17125 GUIDE 1
8 T24415 SPRING 1 (COLORED RED)
9 R49238 SPRING 1 (COLORED BLACK AND BROWN)
10 R74325 PISTON 1 (SUB FOR T17120, THIS APPLICATION)
11 T15705 WASHER 2
12 AR67675 HOUSING 1
13 R74310 PLUG 1 (SUB FOR R49212, THIS APPLICATION)
14 R49211 WASHER 1
15 R34635 WASHER 1 (K)
16 T19863 PISTON 1
17 T11899 O-RING 2 (K)
18 R48604 PLUG 1 (SUB AR51712)
19 T17137 BALL 1 (SUB AR51712)
20 R48601 SPRING 1 (SUB AR51712)
21 R48603 WASHER 1 (SUB AR51712)
22 R48602 SCREW 1 (SUB AR51712)
23 AR51712 SCREW 1
24 R36646 SCREW 1
25 T15712 O-RING 1 (K)
26 R40707 PLUG 1 (SUB FOR T15711, THIS APPLICATION)
27 R56396 O-RING 2
.. AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)

(K) KIT AR34612

30-16 COMBINE - 4420 PC1745 (19-DEC-85)

PN=84

T29540 -UN-01JAN94

1D13

FUEL AND AIR

FUEL INJECTION PUMP HOUSING

(6329DH)

(ROOSA-MASTER)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T11877 WIRE 4
2 T15715 WASHER 3
3 12H295 LOCK WASHER 3 0.190"
4 T15721 SCREW 3
R71851 SCREW 2
5 T17953 CAP SCREW 1
6 T11921 NUT 1
7 T17947 WASHER 1
8 R34812 O-RING 1 (A) (SUB FOR T17951 AND T11906)
9 R36535 CHECK VALVE 1
10 R37139 COVER 1
11 R48493 BUSHING 2
12 R30714 BOLT 2
13 AR67675 HOUSING 1
14 T11878 WASHER 1 (A)
15 T11930 SCREW 1
16 T11876 SCREW 2
17 T11875 IDENTIFICATION PLATE 1
18 T11884 SCREW 4
19 T11882 COVER 2
20 T11883 GASKET 2 (A)
21 T11918 GASKET 1 (A)
.. AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)

KIT LISTED BELOW CONSISTS OF ALL PARTS IDENTIFIED BY AN (A) ON THIS PAGE AND PAGES 30-4, 30-7,
30-10, 30-14, 30-15, AND 30-21.

.. AR34612 GASKET KIT 1 OVERHAUL GASKET

COMBINE - 4420 PC1745 (19-DEC-85) 30-17

PN=85

1D14

FUEL INJECTION PUMP DRIVE

T29294 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

(6329DH)

(ROOSA-MASTER)

FUEL AND AIR

1 T19855 PIN 1
2 R36540 SPRING 1
3 26H10 SHAFT KEY 1 5/32" X 5/8"
4 R36538 DRIVE SHAFT 1
5 T11290 SEAL 2 (A)
6 T19865 BUSHING 1
7 T19854 O-RING 1 (A)
8 AR67675 HOUSING 1
.. AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)

KIT LISTED BELOW CONSISTS OF ALL PARTS IDENTIFIED BY AN (A) ON THIS PAGE AND PAGES 30-4, 30-7,
30-10, 30-14, 30-15, AND 30-20.

.. AR34612 GASKET KIT 1 OVERHAUL GASKET

30-18 COMBINE - 4420 PC1745 (19-DEC-85)

PN=86

T20274 -UN-01JAN94

1D15

FUEL AND AIR

FUEL INJECTION PUMP GOVERNOR

(6329DH)

(ROOSA-MASTER)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T11932 NUT 2
2 R34812 O-RING 2 (A)
3 T11925 SHAFT 1
4 T16602 ARM 1
5 T11953 SPRING 1 (COLORED RED AND GREEN)
6 T17952 WASHER 1
7 T11924 RETAINER 1
8 T11913 SPRING 1
9 T11914 GUIDE 1
10 R74312 ARM 1 (SUB FOR AR30736, THIS APPLICATION)
11 T11943 WASHER 1 (A)
12 T11923 STUD 1
13 R30732 SHIM 1
14 R48500 VALVE 1
15 R58422 SPRING 1
16 R42483 RING 1 (A)
17 AR63213 HUB 1
18 AR63212 RETAINER 1
19 AR51959 RETAINER 1
20 T11931 RING 1
21 T11910 WEIGHT 6
22 T11909 WASHER 1
23 R74472 SLEEVE 1 (SUB FOR T16601)
.. AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)

KIT LISTED BELOW CONSISTS OF ALL PARTS IDENTIFIED BY AN (A) ON THIS PAGE AND PAGES 30-4, 30-7,
30-10, 30-14, 30-15, 30-20, AND 30-21.

.. AR34612 GASKET KIT 1 OVERHAUL GASKET

COMBINE - 4420 PC1745 (19-DEC-85) 30-19

PN=87

TP919 -UN-01JAN94

1D16

FUEL AND AIR

FUEL INJECTION PUMP HEAD AND ROTOR GROUP

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R48494 RING 1
2 T11891 O-RING 1 (A)
3 R30725 SCREW 2 HYDRAULIC HEAD PLUG
4 R48495 WIRE 1 (DH-01, DN-03)
R49346 DOWEL PIN 1 (DH-02)
5 T11926 SET SCREW 1
6 T32238 PLUNGER 2 (ROTOR A)
T32239 PLUNGER 2 (ROTOR B)
T32240 PLUNGER 2 (ROTOR C)
T32241 PLUNGER 2 (ROTOR D)
7 R30727 RETAINER 1

8 .................. ROTOR 1 (SUB AR52269)

9 AR52269 HYDRAULIC HEAD, AND ROTOR 1 HEAD AND ROTOR ASSEMBLY
10 T31129 VALVE 1 (DH-01, DH-02, DN-03) (SUB FOR R30762, THIS
APPLICATION)
R31125 VALVE 1 (OVERSIZE) (DH-01, DN-03)
11 R30735 SPRING 1 DELIVERY VALVE
12 T26223 STOP 1
13 R30737 SCREW 1
14 T11890 RETAINER 2
15 T11889 SNAP RING 1
16 T20055 WASHER 12 (A)
17 R26726 FITTING 6
18 T11886 NEEDLE ROLLER 2
19 R56483 SHOE 1
20 T11887 SCREW 1
21 R30724 LEAF SPRING 1
22 T31124 SHIM AR 0.13 MM (0.005")
T31125 SHIM AR 0.16 MM (0.006")
T31126 SHIM AR 0.18 MM (0.007")
T31127 SHIM AR 0.20 MM (0.008")
T31128 SHIM AR 0.23 MM (0.009")
.. AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)

30-20 COMBINE - 4420 PC1745 (19-DEC-85)

PN=88

T24406 -UN-01JAN94

1D17

FUEL AND AIR

FUEL INJECTION PUMP LINKAGE

(6329DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R59079 SHAFT 1
2 T15720 WASHER 2 (A)
3 R76578 O-RING 2 (A) (SUB FOR T11915)
4 T11927 LEVER 1
5 T19858 LEVER 1
6 R70513 SCREW 1 (SUB FOR T19859, THIS APPLICATION)
7 T17950 RETAINER 1
8 T17949 SPRING 1
9 T19860 STRAP 1
10 T11917 SCREW 1
11 T19861 SPACER 1
12 T11920 SCREW 1
13 T19862 NUT 1
14 R36542 SHAFT 1
15 T11929 CLIP 1
16 AR28602 LINK 1
17 R30718 SCREW 1
18 R30719 LOCK WASHER 1
19 T15699 HOOK 1
20 AT11520 HOOK 1
21 T11911 SPRING 1
.. AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)

KIT LISTED BELOW CONSISTS OF ALL PARTS IDENTIFIED BY AN (A) ON THIS PAGE AND PAGES 30-4, 30-7,
30-14, 30-15, 30-20, AND 30-21.

.. AR34612 GASKET KIT 1 OVERHAUL GASKET

COMBINE - 4420 PC1745 (19-DEC-85) 30-21

PN=89

H32732 -UN-01JAN94

1D18

FUEL AND AIR

FUEL INJECTION PUMP TRANSFER GROUP

(6329DH)

(ROOSA-MASTER)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T26238 SLEEVE 1
2 R34630 SPRING 2
3 AR73828 KIT 1 TRANSFER PUMP BLADE, WITH SPRINGS (STANDARD
SIZE)
AR73829 KIT 1 TRANSFER PUMP BLADE, WITH SPRINGS (OVERSIZE)
4 34H240 SPRING PIN 1 1/8" X 1/4"
5 R34623 PLUG 1
6 R34622 SLEEVE 1
7 R33259 O-RING 1 (A)
8 R34625 STRAINER 1
9 R34632 WASHER 1 (A)
10 T11899 O-RING 1 (A)
11 R49209 SPRING 1 (COLORED BLACK BOTH ENDS)
12 T11900 DOWEL PIN 1
13 T25142 SEAL 1 (A)
14 R34624 PLATE 1
15 R48496 CLIP 4
16 R48497 STRAP 2
17 R48498 BOLT 4
18 T30607 DRAIN PLUG 1 (SUB FOR R34629, THIS APPLICATION)
19 T26256 O-RING 1 (A)
20 R34631 PLATE 1
21 T11894 O-RING 1 (A)
.. AR79462 FUEL INJECTION PUMP 1 (ROOSA-MASTER NO. JDB635MD3055)

KIT LISTED BELOW CONSISTS OF ALL PARTS IDENTIFIED BY AN (A)

.. AR34612 GASKET KIT 1 OVERHAUL GASKET

30-22 COMBINE - 4420 PC1745 (19-DEC-85)

PN=90

TP947 -UN-01JAN94

1D19

FUEL AND AIR

FUEL INJECTION PUMP OVERHAUL GASKET KIT

(6329DH)

(ROOSA-MASTER)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR90601 KIT 1
2 R34632 WASHER 1
3 R34635 WASHER 1
4 R34812 O-RING 2
5 R42483 RING 1
6 R56396 O-RING 2
7 T11290 SEAL 2
8 T11877 WIRE 4
9 T11878 WASHER 1
10 T11883 GASKET 1
11 T11891 O-RING 1
12 T11894 O-RING 1
13 T11899 O-RING 3
14 R76578 O-RING 3 (SUB FOR T11915)
15 T11918 GASKET 1
16 R33259 O-RING 1
17 T11937 INSULATOR 2
18 T11943 WASHER 1
19 T15710 O-RING 2
20 T15712 O-RING 1
21 T15720 WASHER 2
22 T11906 O-RING 1 (SUB FOR T17951)
23 T19854 O-RING 1
24 T20055 WASHER 8
25 T25142 SEAL 1
26 T26223 STOP 1
27 T26256 O-RING 1
28 AR34612 GASKET KIT 1

COMBINE - 4420 PC1745 (19-DEC-85) 30-23

PN=91

1D20

AIRTEX FUEL TRANSFER PUMP

T24071 -UN-01JAN94

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 R27285 GASKET 1
2 R48399 WASHER 1
3 A4365R O-RING 1
4 AR52556 LEVER 1
5 AR52159 FUEL PUMP 1
6 T27860 WASHER 2 (SUB FOR R20498, THIS APPLICATION)
7 19H1849 CAP SCREW 2 5/16" X 1-1/4"
8 R27346 FITTING 1

(6329DH)

FUEL AND AIR

30-24 COMBINE - 4420 PC1745 (19-DEC-85)

PN=92

T69197 -UN-01JAN94

1D21

FUEL AND AIR

FUEL INJECTION NOZZLE

(6329DH)

(ENGINE SERIAL NO. -575164)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T29540 FITTING 1 (SUB R79604)
2 T29539 WASHER 1 (SUB R79605)
3A AT27622 CAP 1 -505383
3B AR85618 CAP 1 505384- (SUB R79604, R79605 AND R79606)
4 R47733 LOCK NUT 1
5 R47732 SCREW 1
6 R47734 SCREW 1
7 R46675 NUT 1
8 R47731 SPRING 1
9 R39886 GUIDE 1
10 R67779 CLAMP 1
11 R60746 WASHER 1
12 R48000 WASHER 1 (SUB FOR R34767)
13 T24472 PLUG 1
14 AR88239 INJECTION NOZZLE 1 (ROOSA-MASTER NO. 22042) (SUB AR89564)
15 R34760 CLAMP 1
16 R34761 SPACER 1 (SUB RE13887, THIS APPLICATION)
R60745 SPACER 1 (K) (USE AFTER RE13887 HAS BEEN INSTALLED)
17 T31174 PLUG 1 (USE FOR SERVICING FUEL INJECTION NOZZLE)

(K) KIT RE13887

COMBINE - 4420 PC1745 (19-DEC-85) 30-25

PN=93

MEMORANDA

FUEL AND AIR

30-26 COMBINE - 4420 PC1745 (28-MAR-84)

PN=94

TP10051 -UN-01JAN94

1D22

FUEL AND AIR

FUEL INJECTION NOZZLE

(6329DH)

(ENGINE SERIAL NO. 575165- )

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T29539 WASHER 1 (SUB R79605)
2 T29540 FITTING 1 (SUB R79604)
3 AT27622 CAP 1 -505383
AR85618 CAP 1 505384- (SUB R79604, R79605 AND R79606)
4 R47733 LOCK NUT 1
5 R69443 SCREW 1
6 R46675 NUT 1
7 R62984 SCREW 1
8 R62981 WASHER 1
9 R69442 SPRING 1
10 R62982 GUIDE 1

11 .................. VALVE 1 (SUB AR89564)

12 T31174 PLUG 1 (USE FOR SERVICING NOZZLE)
13 R67779 CLAMP 1
14 R34764 WASHER 1 -608907 (SUB RE13887, THIS APPLICATION)
R60746 WASHER 1 608908- (K)
15 R48000 WASHER 1
16 T24472 CAP 1
17 AR89564 INJECTION NOZZLE 1 (ROOSA-MASTER NO. 22202)
18 R79606 TEE FITTING 1
19 R79605 WASHER 1
20 R79604 TUBE NUT 1

(K) KIT RE13887

COMBINE - 4420 PC1745 (19-DEC-85) 30-27

PN=95

HP2302 -UN-01JAN94

1D23

FUEL AND AIR

FUEL INJECTION PUMP AND LINES

(ROTO-DIESEL) (6359DH)

a

30-28 COMBINE - 4420 PC1745 (28-MAR-84)

THIS PARTS LISTING IS CONTINUED

PN=96

1D24

FUEL INJECTION PUMP AND LINES - CONTINUED

(ROTO-DIESEL) (6359DH)

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 AR67737 FUEL LINE 1 NO. 1 2 AR67738 FUEL LINE 1 NO. 2 3 AR67739 FUEL LINE 1 NO. 3 4 AR67740 FUEL LINE 1 NO. 4 5 AR67741 FUEL LINE 1 NO. 5 6 AR67742 FUEL LINE 1 NO. 6 7 AR89959 LINE 1 LEAK-OFF 8 T29969 CLAMP 1 9 RE11602 BALL CHECK 1 10 T20055 WASHER 13 11 R67150 NUT 1 12 R79015 FITTING 1 13 T24619 WASHER 1 14 T29464 PEDAL 6 15 T24543 GASKET 1 16 T24542 COVER 1 17 12H295 LOCK WASHER 2 0.190" 18 T24544 SCREW 2 19 R56131 SHAFT KEY 1 20 12H317 LOCK WASHER 1 9/16" 21 R78743 NUT 1 22 RE18933 FUEL INJECTION PUMP 1 (ROTO-DIESEL NO. R3462F960) 23 14H785 NUT 3 5/16" 24 12H303 LOCK WASHER 3 5/16" 25 24H1243 WASHER 3 11/32" X 5/8" X 1/16" 26 R77126 GASKET 1 27 T22242 SWIVEL 1 28 R76964 PINION 1 (48 TEETH) 29 RE14225 SOLENOID 1 30 R67149 COVER 1 31 12H295 LOCK WASHER 1 0.190" 32 R61145 STRAP 1 (ALSO ORDER (2) AR76704) 33 R59297 HALF CLAMP 2 34 R59298 STRAP 1 35 AR76704 SCREW 1 (ALSO ORDER R61145) 36 DD13912 FLANGE 1 37 CD13870 BLADE AR (MALE)

FUEL AND AIR

(A) EITHER PART ACCEPTABLE. CHECK LOCAL AVAILABILITY.

COMBINE - 4420 PC1745 (06-SEP-85) 30-29

PN=97

TP9796 -UN-01JAN94

1E1

FUEL AND AIR

FUEL INJECTION PUMP HOUSING AND AUTOMATIC ADVANCE

(ROTO-DIESEL) (6359DH)

c

30-30 COMBINE - 4420 PC1745 (28-MAR-84)

THIS PARTS LISTING IS CONTINUED

PN=98

1E2

FUEL INJECTION PUMP HOUSING AND AUTOMATIC ADVANCE - CONTINUED

(ROTO-DIESEL) (6359DH)

FUEL AND AIR

KEY PART NO. PART NAME QTY SERIAL NO. REMARKS

1 T24550 SCREW 1
2 T24553 WASHER 2
3 RE11602 BALL CHECK 1
4 T20055 WASHER 1
5 RE13783 HOUSING 1
6 T24637 GASKET 1
7 T24623 SCREW 1
8 T24634 WASHER 1
9 T24632 STUD 1
10 T24633 FITTING 1
11 T24625 PLUG 1
12 T24652 BALL 1
13 T24636 FITTING 1
14 T24650 O-RING 1
15 T24651 O-RING 1
16 T24635 WASHER 1
17 RE11598 HOUSING 1
18 R63035 SPRING 1
19 R73027 SHIM AR 0.1 MM (.004")
T24628 SHIM AR 0.2 MM (.008")
T24629 SHIM AR 0.5 MM (.020")
T24630 WASHER AR 1 MM (.040")
T24631 WASHER AR 2 MM (.080")
20 T24626 CAP 1
21 T24627 WASHER 1
22 T24649 SCREW 1

ENGINE

COMBINE - 4420 PC1745 (28-MAR-84) 30-31

PN=99

TP9790 -UN-01JAN94

1E3

FUEL AND AIR

FUEL INJECTION PUMP HEAD, ROTOR AND DRIVE

(ROTO-DIESEL) (6359DH)

g

30-32 COMBINE - 4420 PC1745 (28-MAR-84)

THIS PARTS LISTING IS CONTINUED

PN=100
