Technical Manual
Of
Intel Bay Trail Series CPU
Based Mini-ITX M/B
NO.G03-NF9M-F
Revision: 1.0
Release date: March 12, 2014
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.
ii
TABLE OF CONTENT
ENVIRONMENTAL SAFETY INSTRUCTION...........................................................................iv
USER’S NOTICE .......................................................................................................................v
MANUAL REVISION INFORMATION .......................................................................................v
ITEM CHECKLIST .....................................................................................................................v
CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD
1-1 FEATURE OF MOTHERBOARD ................................................................................1
1-2 SPECIFICATION .........................................................................................................2
1-3 LAYOUT DIAGRAM ....................................................................................................3
CHAPTER 2 HARDWARE INSTALLATION
2-1 JUMPER SETTING .....................................................................................................8
2-2 CONNECTORS AND HEADERS................................................................................14
2-2-1 CONNECTORS .............................................................................................14
2-2-2 HEADERS .....................................................................................................16
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP .....................................................................................................25
3-2 BIOS MENU SCREEN ................................................................................................26
3-3 FUNCTION KEYS .......................................................................................................26
3-4 GETTING HELP ..........................................................................................................27
3-5 MEMU BARS...............................................................................................................27
3-6 MAIN MENU ................................................................................................................28
3-7 ADVANCED MENU .....................................................................................................29
3-8 CHIPSET MENU..........................................................................................................39
3-9 SECURITY MENU .......................................................................................................42
3-10 BOOT MENU...............................................................................................................43
3-11 SAVE & EXIT MENU...................................................................................................44
iii
Environmental Safety Instruction
Avoid the dusty, humidity and temperature extremes. Do not place the product in
any area where it may become wet.
0 to 60 centigrade is the suitable temperature. (The figure comes from the request
of the main chipset)
Generally speaking, dramatic changes in temperature may lead to contact
malfunction and crackles due to constant thermal expansion and contraction from
the welding spots’ that connect components and PCB. Computer should go
through an adaptive phase before it boots when it is moved from a cold
environment to a warmer one to avoid condensation phenomenon. These water
drops attached on PCB or the surface of the components can bring about
phenomena as minor as computer instability resulted from corrosion and oxidation
from components and PCB or as major as short circuit that can burn the
components. Suggest starting the computer until the temperature goes up.
The increasing temperature of the capacitor may decrease the life of computer.
Using the close case may decrease the life of other device because the higher
temperature in the inner of the case.
Attention to the heat sink when you over-clocking. The higher temperature may
decrease the life of the device and burned the capacitor.
iv
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED
OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN
PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIES AND WE
DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME
WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY
KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL
DAMAGES (INCLUDING DAMANGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,
INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE
USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT
INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
1.0 First Edition March 12, 2014
Item Checklist
Motherboard
User’s Manual
CD for motherboard utilities
Cable(s)
v
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard
Onboard Intel® Bay Trail Series Processor, with low power consumption never
denies high performance
Support 2 * DDRIIIL SO-DIMM 1066/1333 MHz up to 8GB
Support Mini-PCIE connector
Support m-SATA connector
Support 2 * SATAII device
Integrated with 1 * 24-bit dual channel LVDS header
Support DVI-I output
Support USB 3.0 data transport demand
Support CPU Smart FAN
Compliance with ErP standard
Support Watchdog function
1
1-2 Specification
Spec
Design
Embedded CPU
Memory Slot
Expansion Slot
LAN Chip
Storage
BIOS
Rear I/O
Description
6 layers; PCB size: 17x 17 cm
NF9M-2930 Series: Intel® Bay Trail-M N2930 SoC CPU
NF9M-3827 Series: Intel® Bay Trail-I E3827 SoC CPU
2 * DDRIIIL SODIMM Slot for un-buffered dual channel DDRIIIL
1333 MHz SDRAM, expandable to 8GB
1* Half-size Mini-PCIE slot
1* PCIE x1 slot
Integrated with dual Realtek RTL8111G PCI-E Gigabit LAN chips
Support Fast Ethernet LAN function of providing
10/100/1000Mbps Ethernet data transfer rate
2* SATAII port
1* mSATA slot
AMI 64MB Flash ROM
1* DC 9V~36V power-in connector
1* USB 3.0 port
3* USB 2.0 port
1* DVI-I port
1* COM port
1* RJ-45 LAN port
Audio Line Out port x1
2* SATAII 3Gb/s port
1* SATA Power connector
1* CPU FAN header
Internal I/O
2* SYSFAN header
1* Front panel audio header
1* SPDIF Out header
2
Out Port
USB 2.0 Ports
USB 3.0 Port
USB 2.0 Port
I Port
COM1 Port
1* SPEAK_CON header
1* Parallel port header
3* Serial port header
1* USB 2.0 header (Expansible to 2* USB 2.0 ports)
1* USB 3.0 header (Expansible to 2* USB 3.0 ports)
1* Power LED & speaker header
1* Front panel header
1* GPIO_CON header
1* PS2KBMS header
1* SMBUS header
1* LAN LED activity header
1* LVDS header
1* LVDS inverter
1-3 Layout Diagram
Rear IO Panel Diagram:
DVI-
9V~36V
DC Power-in
Connector
Line-
RJ-45 LAN Port
3
9V~36V Internal
Power connector
CPUFAN Header
Front Panel
Audio Header
Front Panel Header
LVDS Inverter
Serial Port Headers
(COM2/3/4)
GPIO Header
SATA Hard Disk
Power-Out Connector
Speaker
Connector
USB 3.0 Header
LVDS Header
SATAII Ports
SYSFAN2 Header
SYSFAN1 Header
Parallel Port Header
PS2KBMS Header
SMBUS Header
Power LED Header
Half-size
9V ~36V DC
Power-in Connector
M-SATA Slot
USB 3.0 Port
Over USB 2.0 Port
DVI-I Port
COM1 Port
USB 2.0 Ports
RJ-45 LAN Port
Line-Out Port
USB 2.0 Header
Motherboard Internal Diagram
Intel CPU
Mini-PCIE Slot (MPE)
DDR3L SODIMM Slot
(SODIMM1)
LAN_LED Header
DDR3L SODIMM Slot
(SODIMM2)
& Speaker Header
PCI Express x1 Slot
4
JP1
JP3
JP4
JBAT
COPEN
AT-MODE
ME_RTC
SYSFAN-DET
JP5
JP6
JP7
JP2
Jumper Position:
5
Jumper
Jumper Name Description
JBAT CMOS RAM Clear Function Setting 2-Pin Block
ME_RTC Clear ME RTC Function Setting 2-Pin Block
COPEN Case Open Message Display Function 2-Pin Block
AT_MODE AT Mode Function Select 2-Pin Block
SYSFAN_DET SYSFAN1/SYSFAN2 R.P.M. Select 3-Pin Block
JP1 Security Measure Function Select 2-Pin Block
JP3 LVDS PVCC 5V/3.3V /12V Select 4-Pin Block
JP4 LCD Back Light 5V/12V/DCIN Select 4-Pin Block
JP2 COM1 Port Pin9 Function Select 4-Pin Block
JP5 COM2 Header Pin9 Function Select 4-Pin Block
JP6 COM3 Header Pin9 Function Select 4-Pin Block
JP7 COM4 Header Pin9 Function Select 4-Pin Block
Connectors
DCIN DC 9V~36V Power–in Connector
SATA1/SATA2 SATAII Port Connector
SATAPW SATA Power out Connector
CPUFAN CPUFAN Connector
SYSFAN1/SYSFAN2 SYSFAN Connector X2
USB20/USB30(Top) USB 2.0 Port Connector X3
USB30(Bottom) USB 3.0 Port Connector
LAN RJ-45 LAN Port Connector
DVI-I DVI-I Port Connector
COM1 Serial port
LINE_OUT Audio Line Out Connector
Connector Name
6
7
Front Panel Header(PWR LED/
Headers
Header Name Description
FP_AUDIO Front Panel Audio Header 9-pin Block
SPDIF SPDIF Out Header 2-pin Block
SPEAK_CON Speaker Header 4-pin Block
LPT Parallel Port Header 25-pin Block
COM2/3/4 Serial Port Header X3 9-pin Block
GPIO_CON GPIO Header 10-pin Block
FP_USB20 USB 2.0 Header 9-pin Block
FP_USB30 USB 3.0 Header 19-pin Block
SPK-LED Power LED & Speaker Header 7-pin Block
JW_FP
PS2KBMS PS/2 Keyboard & Mouse Header 6-pin Block
SMBUS SMBUS Header 4-pin Block
LAN_LED LAN Activity LED Header 2-pin Block
LVDS LVDS Header 30-pin Block
INVERTER LVDS Inverter 8-pin Block
HDD LED/Power Button /Reset)
9-pin Block
Chapter 2
Hardware Installation
2-1 Jumper Setting
(1) JBAT (2-pin): Clear CMOS Setting
JBAT
1
1-2 Open: Normal；
CMOS Clear Setting
1-2 Closed： Clear CMOS
(2)ME_RTC (2-pin): Clear ME_RTC Function Setting
ME_RTC
1-2 Open: Normal；
8
1
1-2 Closed：Clear ME_RTC.
CMOS ME_RTC Setting
(3)COPEN (2-pin): Case Open Message Display Function Select
COPEN
1 2
1-2 Open: Normal;
1 2
1-2 Closed: Case Open
Function Selected (One Touch).
Pin 1-2 Closed: When Case open function pin short to GND, the Case open function
was detected. When Used, needs to enter BIOS and enable ‘Case Open Detect’
function. In this case if your case is removed, next time when you restart your computer,
a message will be displayed on screen to inform you of this.
(4)AT_MODE (2-pin): AT Mode Function Select
AT_MODE
1 2
1-2 Open: ATX Mode Selected;
1 2
1-2 Closed: AT Mode Selected.
9
Pin 1-2 closed: AT_MODE function is enabled. User needs to restart the system for
the settings to take effect. In this case your computer will automatically turns on when
power supply resumes.
(5) SYSFAN_DET (3-pin): SYSFAN1/SYSFAN2 R.P.M. Select
SYSFAN_DET
1-2 Closed：
SYSFAN1 R.P.M. Selected;
3
1
3
1
2-3 Closed：
SYSFAN2 R.P.M. Selected.
(6)JP1 (2-pin): Security Measure Function Select
JP1
1
1-2 Open:Enable Security Measures
in the Flash Descriptor(Default);
1
1-2 Closed: Disable Security Measures
in the Flash Descriptor(Override).
10
(7) JP3 (4-pin): LVDS PVCC 3.3V/5V/12V Function Select
JP3→ LVDS PVCC
6
4
2
2-4 Closed:
VCC=3.3V;
5
3
1
6
4
2
3-4 Closed:
VCC= 5V;
(8) JP4 (4-pin): LCD Back Light VCC 3.3V/5V/12V Select
JP4→ LCD Back Light
6
4
2
2-4 Closed:
VCC=5V;
5
3
1
3-4 Closed:
VCC= 12V;
11
5
3
1
6
4
2
5
3
1
6
4
2
4-6 Closed:
VCC= 12V.
4-6 Closed:
VCC= DCIN.
5
3
1
6
4
2
5
3
1
(9) JP2 (4-pin): COM1 Port Pin9 Function Select
JP2→COM1
6 4 2
1
3
5
2-4 Closed:
RI=RS232;
(10) JP5 (4-pin): COM2 Header Pin9 Function Select
2 4
6
1
3 5
3-4 Closed:
RI= 5V;
2 4 6
1 3
5
4-6 Closed:
RI= 12V.
JP5→ COM2 Header
6
4
2
2-4 Closed:
RI=RS232;
5
3
1
6
4
2
3-4 Closed:
RI= 5V;
5
3
1
6
4
2
4-6 Closed:
RI= 12V.
5
3
1
12
(11) JP6 (4-pin): COM3 Header Pin9 Function Select
JP6→ COM3 Header
6
4
2
2-4 Closed:
RI=RS232;
5
3
1
(12) JP7 (4-pin): COM4 Header Pin9 Function Select
JP7→ COM4 Header
6
4
2
2-4 Closed:
RI=RS232;
5
3
1
6
4
2
3-4 Closed:
RI= 5V;
6
4
2
3-4 Closed:
RI= 5V;
5
3
1
5
3
1
6
4
2
4-6 Closed:
RI= 12V.
6
4
2
4-6 Closed:
RI= 12V.
5
3
1
5
3
1
13
Out Port
USB 2.0 Ports
USB 3.0 Port
USB 2.0 Port
I Port
COM1 Port
2-2 Connectors and Headers
2-2-1 Connectors
(1) Rear I/O Connectors
DVI-
9V~36V
DC Power-in
Connector
(2) SATAII Port connector: SATA1/SATA2
These are high-speed SATAII ports that support 3GB/s transfer rate.
Pin No. Definition
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
RJ-45 LAN Port
Line-
14
+5V
GND
+12V
GND
Control
GND
(3)SATA Power Connector (4-pin): SATAPW
Pin 1
(4) CPUFAN/SYSFAN1/SYSFAN2 (4-pin): Fan Connectors
+12V Fan Power
Fan Speed
Pin1
CPUFAN/ SYSFAN1/SYSFAN2
15
16
Line-Out, MIC Header
SPDIF
GND
2-2-2 Headers
(1) FP_AUDIO (9-pin): Line-Out, MIC-In Header
This header connects to Front Panel Line-out, MIC-In connector with cable.
LINE_OUT_JD
DETECT
MIC_JD
GND
2
Pin 1
MIC2-L
LINE OUT-R
MIC2-R
SENSE
LINE OUT-L
(2) SPDIF (2-pin): SPDIF Out Header
Pin1
17
(3)SPEAK_CON (4-pin): Speaker Connector
Pin No. Definition
1 L-
2 L+
3 R+
4 R-
Pin1
(4) LPT (25-pin): Parallel Port Header
Pin 14
Pin 1
GND
Pin NO. Pin Definition Pin NO. Pin Definition
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
STBPRD0
PRD1
PRD2
PRD3
PRD4
PRD5
PRD6
Pin 14
Pin 15
Pin 16
Pin 17
Pin 18
Pin 19
Pin 20
Pin 21
AFDERRINITSLINGND
GND
GND
GND
Pin 9 PRD7 Pin 22 GND
Pin 10 ACK- Pin 23 GND
Pin 11 BUSY Pin 24 GND
Pin 12 PE Pin 25 GND
Pin 13 SLCT
(5) COM2/COM3/COM4 (9-pin): Serial Port Headers
Pin6
Pin1
DSR
RTS CTS
RI
DCD
SIN
SOUT
DTR
18
GPIO52
VCC
GPIO53
2
GPIO50
VCC
GND
VCC
GND
(6) GPIO_CON (10-pin): GPIO Header
GPIO57
GPIO55
GPIO51
GND
GPIO56
GPIO54
Pin 1
(7) FP_USB20 (9-pin): USB 2.0 Port Header
19
+DATA
Pin 1
-DATA
NC
-DATA
+DATA
D1+
NC
Pin 1
SPK-
(8) FP_USB30 (19-pin): USB 3.0 Port Header
SSRX1
SSRX1
SSTX1+
SSTX1-
GND0
VBUS
-
+
GND1
D1-
Pin 1
19
SSRX2
SSRX2
GND3
VBUS
-
+
(9) SPK-LED (7-pin): Speaker Header & PWR LED Header
PWRLED+
PWRLED-
2
SPK+
NC
10
11
GND2
D2-
SSTX2+
SSTX2-
D2+
PWRLED-
NC
20
RESET
GND
VCC
PWRBT
GND
MS_DATA
VCC
MS_CLK
(10) JW_FP (9-pin): Front Panel Header
Pin 1
PWR LED
PWRBTN
PWRLED+
PWRLED-
2
GND
RSTSW
HDDLED-
HDDLED+
HDLED
(11) PS2KBMS (6-pin): PS/2 Keyboard & Mouse Header
KB_DATA
KB_CLK
Pin1
21
NC
GND
LED+
LED-
(12) SMBUS (4-Pin): SM BUS Header
(13)LAN_LED (2-pin): LAN Activity LED Header
Pin1
Pin1
SMBUS_DATA
SMBUS_CLK
22
(14) LVDS (30-pin): 24-bit Dual Channel LVDS Header
Pin 1
Pin2
Pin NO. Pin Define Pin NO. Pin Define
Pin 1 LVDSB_DATAN3 Pin 2 LVDSB_DATAP3
Pin 3 LVDS_CLKBN Pin 4 LVDS_CLKBP
Pin 5 LVDSB_DATAN2 Pin 6 LVDSB_DATAP2
Pin 7 LVDSB_DATAN1 Pin 8 LVDSB_DATAP1
Pin 9 LVDSB_DATAN0 Pin 10 LVDSB_DATAP0
Pin 11 NC Pin 12 NC
Pin 13 N/A Pin 14 GND
Pin 15 GND Pin 16 GND
Pin 17 LVDSA_DATAP3 Pin 18 LVDSA_DATAN3
Pin 19 LVDS_CLKAP Pin 20 LVDS_CLKAN
Pin 21 LVDSA_DATAP2 Pin 22 LVDSA_DATAN2
Pin 23 LVDSA_DATAP1 Pin 24 LVDSA_DATAN1
Pin 25 LVDSA_DATAP0 Pin 26 LVDSA_DATAN0
Pin 27 PVDD Pin 28 N/A
Pin 29 PVDD Pin 30 PVDD
Pin 31 GND Pin 32 GND
23
(15) INVERTER (8-pin): LVDS Inverter Connector
Pin 1
Pin No. Definition
1 Backlight Enable
2 Backlight PWM
3 Backlight VCC
4 Backlight VCC
5 GND
6 GND
7 Backlight Up SW
8 Backlight Down SW
24
Chapter 3
Introducing BIOS
Notice! The BIOS options in this manual are for reference only. Different
configurations may lead to difference in BIOS screen and BIOS
screens in manuals are usually the first BIOS version when the board is
released and may be different from your purchased motherboard.
Users are welcome to download the latest BIOS version form our
official website.
The BIOS is a program located on a Flash Memory on the motherboard. This program
is a bridge between motherboard and operating system. When you start the computer,
the BIOS program will gain control. The BIOS first operates an auto-diagnostic test
called POST (power on self test) for all the necessary hardware, it detects the entire
hardware device and configures the parameters of the hardware synchronization.
Only when these tasks are completed done it gives up control of the computer to
operating system (OS). Since the BIOS is the only channel for hardware and software
to communicate, it is the key factor for system stability, and in ensuring that your
system performance as its best.
3-1 Entering Setup
Power on the computer and by pressing <Del> immediately allows you to enter Setup.
If the message disappears before your respond and you still wish to enter Setup,
restart the system to try again by turning it OFF then ON or pressing the “RESET”
button on the system case. You may also restart by simultaneously pressing <Ctrl>,
<Alt> and <Delete> keys. If you do not press the keys at the correct time and the
system does not boot, an error message will be displayed and you will again be asked
to
Press <Del> to enter Setup
25
26
Menu Bar
* When system POST boots, you may press “H” or “C” key to change display device.
Press <H> key to switch HDMI/DVI display first.
Press <C> key to switch CRT/DVI display first.
3-2 BIOS Menu Screen
The following diagram show a general BIOS menu screen:
General Help Items
Current Setting Value
Menu Items
Function Keys
BIOS Menu Screen
3-3 Function Keys
In the above BIOS Setup main menu of, you can see several options. We will explain
these options step by step in the following pages of this chapter, but let us first see a
short description of the function keys you may use here:
27
Press (left, right) to select screen;
Press (up, down) to choose, in the main menu, the option you want to confirm
or to modify.
Press <Enter> to select.
Press <+>/<–> keys when you want to modify the BIOS parameters for the active
option.
[F1]: General help.
[F2]: Previous value.
[F3]: Optimized defaults.
[F4]: Save & Reset.
Press <Esc> to quit the BIOS Setup.
3-4 Getting Help
Main Menu
The on-line description of the highlighted setup function is displayed at the top right
corner the screen.
Status Page Setup Menu/Option Page Setup Menu
Press F1 to pop up a small help window that describes the appropriate keys to use
and the possible selections for the highlighted item. To exit the Help Window, press
<Esc>.
3-5 Menu Bars
There are six menu bars on top of BIOS screen:
Main To change system basic configuration
Advanced To change system advanced configuration
Chipset To change chipset configuration
Security Password settings
Boot To change boot settings
Save & Exit Save setting, loading and exit options.
User can press the right or left arrow key on the keyboard to switch from menu bar.
The selected one is highlighted.
3-6 Main Menu
Main menu screen includes some basic system information. Highlight the item and
then use the <+> or <-> and numerical keyboard keys to select the value you want in
each item.
System Date
Set the date. Please use [Tab] to switch between data elements.
System Time
Set the time. Please use [Tab] to switch between time elements.
28
3-7 Advanced Menu
ERP Function
The optional settings: [Auto]; [Disabled].
This item should be set as [Disabled] if you wish to have all active wake-up functions.
OS Selection
The optional settings: [Windows 8.X]; [Windows 7].
ACPI Settings
Press [Enter] to make settings for the following sub-item:
ACPI Settings
29
ACPI Sleep State
Use this item to select the highest ACPI sleep state the system will enter when the
suspend button is pressed.
The optional settings are: [Suspend Disabled]; [S3 (Suspend to RAM)].
Wakeup Function Settings
Press [Enter] to make settings for the following sub-items:
Wake System with Fixed Time
Use this item to enable or disable system wake on alarm event. When set as
[Enabled], system will wake on the hour/min/sec specified.
PS2 KB/MS Wakeup
Use this item to enable or disable PS2 KB/MS wakeup from S3/S4/S5 state. This
function is only supported when ERP function is disabled.
*This item will only show when ‘ERP Support’ is set as [Disabled].
Super I/O Configuration
Press [Enter] to make settings for the following sub-items:
Super IO Configuration
Serial Port 1 Configuration
Press [Enter] to make settings for the following items:
Serial Port
Use this item to enable or disable serial port (COM).
Change Settings
Use this item to select an optimal setting for super IO device.
Transmission Mode Select
The optional settings are: [RS422]; [RS232]; [RS485].
Mode Speed Select
The optional settings are: [RS232/RS422/RS485=250kbps]; [RS232=1Mbps,
RS422/RS485=10Mbps].
Serial Port FIF0 Mode
The optional settings are: [16-Byte FIF0]; [32-Byte FIF0]; [64-Byte FIF0]; [128-Byte
FIF0].
30
Serial Port 2 Configuration/ Serial Port 3 Configuration/ Serial Port 4
Configuration
Press [Enter] to make settings for the following items:
Serial Port
Use this item to enable or disable serial port (COM).
Change Settings
Use this item to select an optimal setting for super IO device.
Serial Port FIF0 Mode
The optional settings are: [16-Byte FIF0]; [32-Byte FIF0]; [64-Byte FIF0]; [128-Byte
FIF0].
Parallel Port Configuration
Press [Enter] to make settings for the following items:
Parallel Port
Use this item to enable or disable parallel port (LPT/LPTE).
Change Settings
Use this item to select an optimal setting for super IO device.
Device Mode
The optional settings are: [STD Printer Mode]; [SPP Mode]; [EPP-1.9 and SPP
Mode]; [EPP-1.7 and SPP Mode]; [ECP Mode]; [ECP and EPP 1.9 Mode]; [ECP
and EPP 1.7 Mode].
WatchDog Timer
Use this item to enable or disable WatchDog Timer Control. When set as
[Enabled], the following sub-items shall appear:
WatchDog Timer Value
User can set a value in the range of 4 to 255.
WatchDog Timer Unit
The optional settings are: [Sec.]; [Min.].
WatchDog Wake-up Timer in ERP
This item support WDT wake-up while ERP function is set as [Enabled].
The optional settings are: [Enabled]; [Disabled].
31
When set as [Enabled], the following sub-items shall appear:
WatchDog Timer Value in ERP
User can set a value in the range of 10 to 4095.
WatchDog Timer Unit
The optional settings are: [Sec.]; [Min.].
ATX Power Emulate AT Power
This item support Emulate AT power function, MB power On/Off control by power
supply. Use needs to select ‘AT or ATX Mode’ on MB jumper at first (ATX Mode &
AT Mode Select).
Case Open Detect
This item controls detect case open function.
The optional settings are: [Enabled]; [Disabled].
SmartFan Configuration
Press [Enter] to make settings for SmartFan Configuration:
CPUFAN / SYSFAN1/2 Smart Mode
When set as [Enabled], the following sub-items shall appear:
CPUFAN / SYSFAN1/2 Full-Speed Temperature
Use this item to set CPUFAN/SYSFAN1/2 full speed temperature. Fan will run at
full speed when above this temperature.
CPUFAN / SYSFAN1/2 Full-Speed Duty
Use this item to set CPUFAN/SYSFAN1/2 full speed duty. Fan will run at full speed
when above the pre-set duty.
CPUFAN / SYSFAN1/2 Idle-Speed Temperature
Use this item to set CPUFAN/SYSFAN1/2 idle speed temperature. Fan will run at
idle speed when below this temperature.
CPUFAN / SYSFAN1/2 Idle-Speed Duty
Use this item to set CPUFAN/SYSFAN1/2 idle speed duty.. Fan will run at idle
speed when below the pre-set duty.
32
PC Health Status
Press [Enter] to view current hardware health status.
Shutdown Temperature Configuration
Use this item to select system shutdown temperature.
The optional settings are: [Disabled]; [70C/158F]; [75C/167F]; [80C/176F];
[85C/185F].
Serial Port Consol Redirection
Press [Enter] to make settings for serial port redirection settings:
COM1
Console Redirection
The optional settings are: [Enabled]; [Disabled].
When set as [Enabled], user can make further settings in:
Console Redirection Settings
The settings specify how the host computer and the remote computer (which the
user is using) will exchange data. Both computers should have the same or
compatible settings.
Press [Enter] to make settings for the following sub-items.
Terminal Type
The optional settings are: [VT100]; [VT100+]; [VT-UTF8]; [ANSI].
Bits per second
The optional settings are: [9600]; [19200]; [38400]; [57600]; [115200].
Data Bits
The optional settings are: [7]; [8].
Parity
The optional settings are: [None]; [Even]; [Odd];[Mark]; [Space].
Stop Bits
The optional settings are: [1]; [2].
Flow Control
The optional settings are: [None]; [Hardware RTS/CTS].
VT-UTF8 Combo Key Support
33
The optional settings are: [Enabled]; [Disabled].
Recorder Mode
The optional settings are: [Enabled]; [Disabled].
Resolution 100x31
The optional settings are: [Enabled]; [Disabled].
Legacy OS Redirection Resolution
The optional settings are: [80x24]; [80x25].
Putty Keypad
The optional settings are: [VT100]; [LINUX]; [XTERMR6]; [SCO]; [ESCN];
[VT400].
Redirection After BIOS POST
The optional settings are: [Always Enable]; [BootLoader].
Serial Port for Out-of-Band Management
/Windows Emergency Management Services (EMS)
Console Redirection
The optional settings are: [Enabled]; [Disabled].
When set as [Enabled], user can make further settings in ‘Console Redirection
Settings’:
Console Redirection Settings
The settings specify how the host computer and the remote computer (which the
user is using) will exchange data. Both computers should have the same or
compatible settings.
Press [Enter] to make settings for the following sub-items.
Out-of-Band Mgmt Port
This item may or may not show up, depending on different configuration.
Terminal Type
The optional settings are: [VT100]; [VT100+];[VT-UTF8];[ANSI].
Bits per second
The optional settings are: [9600]; [19200]; [57600]; [115200].
Flow Control
34
The optional settings are: [None] ; [Hardware RTS/CTS]; [Software Xon/Xoff].
Data Bits
The default setting is: [8].
*This item may or may not show up, depending on different configuration.
Parity
The default setting is: [None].
*This item may or may not show up, depending on different configuration.
Stop Bits
The default setting is: [1].
*This item may or may not show up, depending on different configuration.
CPU Configuration
Press [Enter] to view current CPU configuration and make settings for the following
sub-items:
Limit CPUID Maximum
The optional settings: [Disabled]; [Enabled].
This item should be set as [Disabled] for Windows XP.
Execute Disable Bit
The optional settings: [Disabled]; [Enabled].
Hardware Prefetcher
The optional settings are: [Disabled]; [Enabled].
Use this item to turn on/off the Mid Level Cache (L2) streamer prefetcher.
Adjacent Cache Line Prefetch
The optional settings are: [Disabled]; [Enabled].
Use this item to turn on/off prefetching of adjacent cache lines.
Intel Virtualization Technology
The optional settings: [Enabled]; [Disabled].
When set as [Enabled], a VMM can utilize the additional hardware capabilities
provided by Vanderpool Technology.
Power Technology
The optional settings: [Disabled]; [Energy Efficient].
35
PPM Configuration
Press [Enter] to make settings for PPM Configuration:
PPM Configuration:
EIST
The optional settings: [Enabled]; [Disabled].
Use this item to enable or disable Intel SpeedStep.
CPU C Status Report
Use this item to enable or disable CPU C status report to OS.
The optional settings: [Disabled]; [Enabled].
When set as [Enabled], the following sub-items shall appear:
Enhanced C state
Use this item to enable or disable CPU C state.
Max CPU C-state
The optional settings: [C7]; [C6]; [C1].
SATA Configuration
Press [Enter] to make settings for the following sub-items:
SATA Configuration
SATA Port
The optional settings: [Disabled]; [Enabled].
SATA Mode
The optional settings are: [IDE Mode]; [AHCI Mode].
SATA Speed Support
The item is for user to set the maximum speed the SATA controller can support.
The optional settings are: [Gen1]; [Gen2].
SATA ODD Port
The optional settings are: [Port1 ODD]; [Port2 ODD]; [No ODD].
SATA Port1
The optional settings are: [Enabled]; [Disabled].
SATA Port2
The optional settings are: [Enabled]; [Disabled].
36
37
Network Stack Configuration
Press [Enter] to go to ‘Network Stack’ screen to make further settings.
Network Stack
The optional settings are: [Enabled]; [Disabled].
When set as [Enabled], the following sub-items shall appear:
Ipv4 PXE Support
The optional settings are: [Disabled]; [Enabled].
Use this item to enable Ipv4 PXE Boot Support. When set as [Disabled], Ipv4 boot
optional will not be created.
Ipv6 PXE Support
The optional settings are: [Disabled]; [Enabled].
Use this item to enable Ipv6 PXE Boot Support. When set as [Disabled], Ipv4 boot
optional will not be created.
PXE boot wait time
Use this item to set wait time to press [ESC] key to abort the PXE boot.
CSM Configuration
Press [Enter] to make settings for the following sub-items:
Compatibly Support Module Configuration
Option ROM Message
The optional settings are: [Force BIOS]; [Keep Current].
INT19 Trap Response
The optional settings are: [Immediate]; [Postponed].
Option ROM execution order
Network
This item controls the execution of UEFI and legacy PXE OpROM.
The optional settings are: [Do not launch]; [UEFI only]; [Legacy only].
Storage
This item controls the execution of UEFI and Legacy Storage OpROM.
The optional settings are: [Do not launch]; [UEFI only]; [Legacy only]; [Legacy first];
[UEFI first].
Other PCI devices
This item determines OpROM execution policy for devices other than Network,
storage or video.
The optional settings are: [UEFI first]; [Legacy Only].
USB Configuration
Press [Enter] to make settings for the following sub-items:
USB Configuration
Legacy USB Support
The optional settings are: [Enabled]; [Disabled]; [Auto].
[Enabled]: To enable legacy USB support.
[Disabled]: To keep USB devices available only for EFI specification,
[Auto]: To disable legacy support if no USB devices are connected.
XHCI Hand-off
This is a workaround for OSes without XHCI hand-off support. The XHCI
ownership change should be claimed by XHCI driver.
The optional settings are: [Enabled]; [Disabled].
EHCI Hand-off
This is a workaround for OSes without EHCI hand-off support. The EHCI
ownership change should be claimed by EHCI driver.
The optional settings are: [Disabled]; [Enabled].
USB Mass Storage Driver Support
The optional settings are: [Disabled]; [Enabled].
USB hardware delay and time-outs:
USB Transfer time-out
Use this item to set the time-out value for control, bulk, and interrupt transfers.
The optional settings are: [1 sec]; [5 sec]; [10 sec]; [20 sec].
Device reset time-out
Use this item to set USB mass storage device start unit command time-out.
The optional settings are: [10 sec]; [20 sec]; [30 sec]; [40 sec].
Device power-up delay
Use this item to set maximum time the device will take before it properly reports
itself to the host controller. ‘Auto’ uses default value: for a root port it is 100 ms, for
38
a hub port the delay is taken from hub descriptor.
The optional settings: [Auto]; [Manual].
Select [Manual] you can set value for the following sub-item: ‘Device Power-up
delay in seconds’.
Device Power-up delay in seconds
The delay range is from 1 to 40 seconds, in one second increments.
Reltek PCIe GBE Family Controller (MAC:XX:XX:XX:XX:XX:XX)
Use this item to get driver information and configure Realtek ethernet controller
parameter.
3-8 Chipset Menu
39
North Bridge
Press [Enter] to view current using memory information and make settings for the
following sub-items:
Intel IGD Configuration
IGD Turbo Enable
The optional settings are: [Enabled]; [Disabled].
Spread Spectrum Clock
The optional settings are: [Enabled]; [Disabled].
IGD Boot Type
Use this item to select preference display interface used when system boot.The
optional settings are: [DVI/CRT]; [CRT]; [HDMI/DVI].
Active LFP
The optional settings are: [Disabled]; [Enabled].
[Disable]: VBIOS does not enable LVDS.
[Enable]: VBIOS enable LVDS driver by integrated encoder.
*When set as ‘Enabled’, user can make further settings in ‘LVDS Panel Type’
LVDS Panel Type
Use this item to select LVDS panel resolution.
The optional setting are: [640 x 480 18bit Single]; [800 x 480 18bit Single]; [800x
600 18bit Single]; [1024 x 600 18bit Single]; [1024 x 768 24bit Single]; [1280 x 720
18bit Single]; [1280 x 1024 24bit Dual]; [1366 x 768 18bit Single]; [1366 x 768
24bit Single]; [1440 x 900 18bit Dual]; [1440 x 900 24bit Dual]; [1400 x 1050 24bit
Dual]; [1600 x 900 24bit Dual]; [1680 x 1050 24bit Dual]; [1600 x 1200 24bit Dual];
[1920 x 1080 24bit Dual].
South Bridge
Press [Enter] to further setting USB device configuration.
Azalia HD Audio
Press [Enter] to further setting USB device configuration.
Audio Configuration
Audio Controller
40
The optional settings are: [Disabled]; [Enabled]
.Azalia Internal HDMI Codec
Use this item to enable or disable internal HDMI codec for Azalia.
The optional settings are: [Disabled]; [Enabled].
USB Configuration
Press [Enter] to make settings for the following sub-items:
USB Configuration
USB 3.0 Support
The optional settings are: [Auto]; [Disabled].
USB 3.0 Link Power Management
The optional settings are: [Enabled]; [Disabled].
USB 2.0 Support
The optional settings are: [Auto]; [Disabled].
*This item may or may not show up, depending on different configuration.
PCI-E Slot Speed
The optional settings are: [Auto]; [Gen2]; [Gen1].
Onboard Lan1 Controller
The optional settings are: [Enabled]; [Disabled].
Asmedia USB 3.0 Controller
The optional settings are: [Enabled]; [Disabled].
Mini PCIE
The optional settings are: [Enabled]; [Disabled].
Speed
The optional settings are: [Auto]; [Gen2]; [Gen1].
Restore AC Power Loss
Use this item to select AC power state when power is re-applied after a power
failure. The optional settings are: [Power Off]; [Power On]; [Last State].
41
3-9 Security Menu
Security menu allow users to change administrator password and user password
settings.
42
3-10 Boot Menu
Boot Configuration
Setup Prompt Timeout
Use this item to set number of seconds to wait for setup activation key.
Bootup Numlock State
Use this item to select keyboard numlock state.
The optional settings are: [On]; [Off].
Quiet Boot
The optional settings are: [Disabled]; [Enabled].
43
Boot Option Priorities
Boot Option
The optional settings are: [UEFI: Built-in EFI Shell]; [Disabled].
3-11 Save & Exit Menu
Save Changes and Reset
This item allows user to reset the system after saving the changes.
Discard Changes and Reset
This item allows user to reset the system without saving any changes.
Restore Defaults
44
Use this item to restore /load default values for all the setup options.
Save as User Defaults
Use this item to save the changes done so far as user defaults.
Restore User Defaults
Use this item to restore defaults to all the setup options.
Lauch EFI Shell from filesystem device
Use this item to launch EFI shell application (shell.efi) from one of the available
filesystem device.
Reset System with ME disable Mode
Press [Enter] for ME to run into the temporary disable mode. Ignore if ME Ignition FM.
45
Loading...
