TECHNICAL M
A
NUAL
Of
AMD Hudson E1/D1 Chipset
Based
for AMD Brazos APU Mini-ITX M/B
NO.G03-NF81-F
Revision：2.0
Release date: April, 2011
Trademark:
* Specifications and Information contained in this docume ntation ar e furnishe d for inf ormation use only , and ar e
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED
OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN
PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIES AN D WE
DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME
WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY
KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL
DAMAGES (INCLUDING DAMANGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,
INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE
USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT
INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
2.0 Second Edition April, 2011
Item Checklist
5
Motherboard
5
User’s Manual
5
DVD for motherboard utilities
5
Cable(s)
5
I/O Back panel shield
i
Environmental Safety Instruction
z Avoid the dusty, humidity and temperature extremes. Do not place the product in
any area where it may become wet.
z 0 to 60 centigrade is the suitable temperature. (The figure differs from the request
of the main chipset)
z Generally speaking, dramatic changes in temperature may lead to contact
malfunction and crackles due to constant thermal expansion and contraction from
the welding spots’ that connect components and PCB. Computer should go
through an adaptive phase before it boots when it is moved from a cold
environment to a warmer one to avoid condensation phenomenon. These water
drops attached on PCB or the surface of the components can bring about
phenomena as minor as computer instability resulted from corrosion and oxidation
from components and PCB or as major as short circuit that can burn the
components. Suggest starting the computer until the temperature goes up.
z The increasing temperature of the capacitor may decrease the life of computer.
Using the close case may decrease the life of other device because the higher
temperature in the inner of the case.
z Attention to the heat sink when you over-clocking. The higher temperature may
decrease the life of the device and burned the capacitor.
ii
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.
iii
TABLE OF CONTENT
USER’S NOTICE .......................................................................................................................i
MANUAL REVISION INFORMATION.......................................................................................i
ITEM CHECKLIST.....................................................................................................................i
ENVIRONMENTAL SAFETY INSTRUCTION...........................................................................ii
ENVIRONMENTAL PROTECTION ANOUNCEMENT..............................................................iii
CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD
1-1 FEATURE OF MOTHERBOARD................................................................................1
1-2 SPECIFICATION.........................................................................................................2
1-3 LAYOUT DIAGRAM....................................................................................................4
CHAPTER 2 HARDWARE INSTALLATION
2-1 JUMPER SETTING.....................................................................................................8
2-2 CONNECTORS AND HEADERS................................................................................10
2-2-1 CONNECTORS .............................................................................................10
2-2-2 HEADERS .....................................................................................................11
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP.....................................................................................................17
3-2 BIOS MENU SCREEN ................................................................................................18
3-3 FUNCTION KEYS .......................................................................................................19
3-4 GETTING HELP ..........................................................................................................19
3-5 MAIN BAR...................................................................................................................20
3-6 MAIN MENU................................................................................................................20
3-7 ADVANCED MENU.....................................................................................................22
3-8 CHIPSET MENU..........................................................................................................26
3-9 BOOT MENU...............................................................................................................28
3-10 SECURITY MENU.......................................................................................................29
3-11 SAVE & EXIT MENU...................................................................................................30
iv
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard
z AMD Hudson E1 Chipset and AMD Brazos eOntario G-Series APU (NF81 series)
z AMD Hudson D1 Chipset and AMD Brazos Zacate E-Series APU (NC85 series)
z Low power consumption but high performance
z Support DirectX 11 3D Graphics Acceleration
z Support SO-DIMM DDRIII 1066 up to 8GB
z Integrated with VIA VT1705 6-CH HD Audio CODEC
z Integrated with Realtek RT8111E Gigabit LAN chip
z Support USB 2.0 data transport demands
z Support PCI slot, Mini-PCIE x1 slot
z Support Mini-SATA slot (NF81 series)
z Support CPU Smart FAN
z Compliance with ErP standard
1
1-2 Specification
Spec Description
6 layers Mini-ITX form factor ; PCB size: 17.0x17.0cm
Design
Chipset
APU
Memory Socket
Expansion Slot
Integrated LAN
Audio
BIOS
Multi I/O
z
Hudson D1 Chipset (NC85 series)
z
Hudson E1 Chipset (NF81 series)
z
AMD Brazos Zacate E-Series APU (NC85 series)
z
AMD Brazos eOntario G-Series APU (NF81 series)
z
204-pin DDRIII SODIMM socket x2
z
Support DDRIII 1066 MHz DDRIII SODIMM expandable to
z
8GB
PCI slot x1
z
Mini-PCIE x1 slot x1
z
Mini SATAIII slot x1 (NF81 series)
z
Integrated one Realtek RTL8111E PCI-E Gigabit LAN chip
z
(NC85 series)
Integrated dual Realtek RTL8111E PCI-E Gigabit LAN chip
z
(NF81 series)
Support Fast Ethernet LAN function of providing
z
10Mb/100Mb/1000Mb Ethernet data transfer rate
VIA VT1705 6-Channel HD Audio CODEC
z
Audio driver and utility included
z
AMI 16MB SPI Flash ROM
z
PS/2 keyboard connector x 1
z
HDMI connector x 1
z
DVI connector x1 (HDMI Connector and DVI Connector can
z
not be used at the same time)
VGA connector x1
z
USB port connector x 6 and USB header x2
z
RJ-45 LAN connector x1(NC85 series)
z
RJ-45 LAN connector x2(NF81 series)
z
2
Audio connector x1 (Line-in, Line-out, MIC)
z
SATAII connector x 4 (NC85 series)
z
SATAIII connector x 5(NF81 series)
z
Front panel audio header x1
z
Serial port header x1
z
GPIO header x1
z
Front panel header x1
z
CIR header x1
z
Speaker header x1
z
24-bit Dual CH LVDS header x1 (NF81 series)
z
18-bit single channel LVDS header x1 (NC85 series)
z
3
1-3 Layout Diagram
Rear IO Back Panel for NF81 series:
DVI
Connector
RJ-45 LAN Ports
PS/2
Keyboard
USB
Connectors
HDMI
Connector
VGA
Connector
Rear IO Back Panel for NC85 series:
PS/2
Keyboard
USB
Connectors
HDMI
Connector
DVI
Connector
VGA
Connector
Line-In
/Optical SPDIF Out
Line-Out
MIC-IN
USB
Connectors
RJ-45 LAN Port
Line-In
/Optical SPDIF Out
Line-Out
MIC-IN
USB
Connectors
4
r
r
(
)
Internal Motherboard Diagram for NF81 series:
PS2 Keyboard
Over USB Ports
HDMI Port
DVI over
VGA port
RJ-45 over
USB Port
RJ-45 over
USB Port
Audio
Connecto
Front Panel
Audio Header
COM1 Header
Inverter Header
JP1
JP1
JP3
AMD APU
Gigabit
PCI-E LAN Chip
PCI-E LAN Chip
HD Audio Codec
JP2
JBAT
Gigabit
Mini-PCIE Slot
LVDS Header
Hudson E1 Chipset
SYS FAN1
GPIO Header
CPU FAN
SATAIII Connectors
SATA 1~SATA 4
Mini-SATA III Slot
Front Panel Header
SODIMM1/ SODIMM2
(DDRIII SO-DIMM 1066 MHz)
SYS FAN2
ATX Powe
Connector
SpeakHeader
CIR Header
USB Headers
PCI Slot
SATA Power Connector
SATAII/III Connector
(SATA5)
5
6
r
r
(
)
r
Internal Motherboard Diagram for NC85 series:
PS2 Keyboard
Over USB Ports
HDMI Port
DVI over
VGA port
RJ-45 over
USB Port
USB Ports
Audio
Connecto
Front Panel
Audio Header
COM1 Header
Inverter Header
JP1
JP1
JP3
AMD APU
Gigabit
PCI-E LAN Chip
HD Audio Codec
JP2
JBAT
LVDS Header
Hudson D1 Chipset
SYS FAN1
Mini-PCIE Slot
GPIO Header
CPU FAN
SATAII Connectors
SATA 1~SATA 4
Front Panel Header
Speak Heade
SODIMM1/ SODIMM2
(DDRIII SO-DIMM 1066 MHz)
SYS FAN2
ATX Powe
Connector
CIR Header
USB Headers
PCI Slot
7
Jumper
Jumper Name Description
JBAT CMOS RAM Clear Function Setting 3-pin Block
JP1 Inverter12V/5V Select 3-pin Block
JP2 LVDS PVCC 5V/3.3V Select 3-pin Block
JP4 KB/MS/USB Power on Function Setting 3-pin Block
Connectors
Connector Name Description
ATXPWR ATX Power Connector 24-pin Connector
KB from UK1 PS2 Keyboard Connector 6-pin Female
HDMI1 High-Definition Multimedia Interface 19-pin Connector
DVI1 Digital Visual Interface 24-pin Connector
VGA1 Video Graphic Attach Connector 15-pin Female
SATA1/SATA2/
SATA3/SATA4(SATA5)
USB
from UK1/UL1/UL2
LAN from UL1(/UL2) RJ-45 LAN Connector 8-pin Connector
CN2 AUDIO Connector 3 Phone Jack
Serial ATAII Connector (NC85 series)
7-pin Connector
/SATAIII Connector (NF81series)
USB Port Connector 4-pin Connector
Headers
Header Name Description
AUDIO1 Front panel audio Headers 9-pin block
USB1, USB2 USB Headers 9-pin Block
COM1 Serial Port Header 9-pin Block
JW_FP1
CIR CIR Header 4-pin Block
SPEAK1 Speaker Header 4-pin Block
LVDS1 LVDS Header 36-pin Block
INVERTER1 LVDS Inverter Connector 7-pin Block
GPIO1 GPIO header 10-pin Block
Front Panel Header (PWR LED/ HD LED/
/Power Button /Reset)
9-pin Block
Chapter 2
Hardware Installation
2-1 Jumper Setting
(1) JBAT(3-pin): Clear CMOS
JBAT
1-2 Short ： Normal
1
JBAT
2-3 Short： CMOS Clear
(2) Inverter 5V/12V Select (3-pin):JP1
JP1
JP1
13
1
8
1-2 Closed：
INVERTEL POWER 12V Selected
2-3 Closed：
INVE RT EL POWE R 5V Selec ted
(3) LVDS PVCC 5V / 3.3V Function setting (3-pin): JP2
JP2
1
JP2
1-2 Closed：
LVDS PVCC 5V Selected
2-3 Closed：
LVDS PVCC 3.3 V Se lected
(4) KB/MS/USB Power on Function Enabled/Disabled (3-pin): JP3
1-2 Closed: KB/MS/USB POWER-ON Di sacled(default)
2-3 closed: KB/MS/ USB POWER-ON Enabled
1
JP3
JP3
9
p
(Op
)
2-2 Connectors and Headers
2-2-1 Connectors
(1) Rear Panel Connectors
DVI Connector
RJ-45 LAN Port
RJ-45 LAN Port
tional
PS/2
Keyboard
Line-In/
O
tical SPDIF Out
Line-Out
USB
Connectors
MIC-IN
HDMI Connector
VGA Connector
(2) Serial-ATAII/III Port connector: SATA1/SATA2/SATA3/SATA4/SATA5 (NF81
Series)
These connectors support the provided SATA hard disk cable to connect the
motherboard and SATA hard disk drives. SATA connectors from NC85 series are
high-speed SATA 3Gb/s connectors. SATA connectors from NF81 series are
high-speed SATA 6Gb/s connectors.
SATA 3
SATA 1 SATA 2
USB Connectors
SATA 4
(Optional)
SATA 5
Seria l - ATA III Co nne ctors
10
D
Y
Notice!
SATA5, SATA power connector and Mini-SATA slot depend on the
model you select. Please refer to the product you purchase for actual
specification.
2-2-2 Headers
(1) Front panel audio (9-pin): AUDIO1
AUDIO
Pin 1
(2) USB Port Headers (9-pin): USB1/USB2
Line-O ut, M IC Head ers
MIC2-JD
KE
AUDIO-GN
2
MIC2-L
VCC
LINE2-JD
Audio-JD
10
9
-R
MIC2-R
Sense-FB
Lineout2
Lineout2-L
NC
GND
-DATA
+DATA
Pin 1
VCC
GND
-DATA
+DATA
USB Port Header
11
P
D
C
(3) Serial Port Header: COM1
DSR
Pin6
in1
Pin1Pin1
DCD
RI
RTS
CTS
Pin5
TXD
RXD
GND
DTR
S erial COM Port 9-pin Block
(4) Front Panel Header: JW-FP1
PWRBTN
PWR LED
GND
GN
PWRBTN
JW_FP
Pin 1
System Case Connectio n s
(11) CIR Header: CIR
This 4-pin CIR header is to receive remote control signal.
PWRLED
GND
VCC5
RSTSW
HDDL ED
RESET
HDLED
N
12
_
G
C
RX
ND
5VSB
1 4
CIR LED
CIR
(5) Speaker connector: SPEAK1
This 4-pin connector connects to the case-mounted speaker. See the figure below.
CIR Header
SPEAK
Pin 1
NC
N
VCC
SPEAK
13
_
G
O
33
10
(7) FAN Speed Headers: CPUFAN (4-pin), SYSFAN1/SYSFAN2 (3-pin)
CPUFAN
CPUFAN
+12
GND
(10) GPIO Header (10-pin): GPIO1
31
PI
GPIO
2
GPIO1
Pin 1
GPIO_30
GPIO_32
GPIO Connector
CPUFAN
SYSFAN2
SYSFAN1
GPIO_35
GPIO_37
GPIO_34
GPIO_36
1
FAN He a d er s
VCC
9
GND
1
3
3
1
4
GND
+12V Fan Power
Fan Clock
Fan Clock
+12V Fan Power
GND
14
(12) LVDS Headers（36 Pin）: LVDS1
Pin NO. Pin Define Pin NO. Pin Define
Pin 1
Pin 3
Pin 5
Pin 7
Pin 9
Pin 11
Pin 13
Pin 15
Pin 17
Pin 19
Pin 21
Pin 23
Pin 25
Pin 27
Pin 29
Pin 31
Pin 33
Pin 35
LVDSB_DATAN3
LVDSB_CLKBN
LVDSB_DATAN2
LVDSB_DATAN1
LVDSB_DATAN0
LVDS_DDC_DATA
GND
GND
LVDSA_DATAP3
LVDS_CLKAP
LVDSA_DATAP2
LVDSA_DATAP1
LVDSA_DATAP0
PVDD
PVDD
GND
+5V
+12V
(Reserved)
Pin 2 LVDSB_DATAP3
Pin 4
Pin 6
Pin 8
Pin 10
Pin 12
Pin 14
Pin 16
Pin 18
Pin 20
Pin 22
Pin 24
Pin 26
Pin 28
Pin 30
Pin 32
Pin 34
Pin 36
LVDSB_DATABP
LVDSB_DATAP2
LVDSB_DATAP1
LVDSB_DATAP0
LVDS_DDC_CLK
GND
GND
LVDSA_DATAN3
LVDS_CLKAN
LVDSA_DATAN2
LVDSA_DATAN1
LVDSA_DATAN0
PVDD
PVDD
GND
N/A
+3V
15
6
Pin 1
Pin 2
(13) LVDS Inverter headers: INVERTER1
Pin 1 and pin2: VCC of inverter
Pin3, pin4 and pin6: GND
Pin5: Backlight
Pin7: Brightness
Pin 1
LVDS Header
VCC
VCC
GND
GND
Backlight
GND
Brightness
1
7
Chapter 3
Introducing BIOS
Notice!
The BIOS options in this manual are for reference only. Different
configurations may lead to difference in BIOS screen and BIOS
screens in manuals are usually the first BIOS version when the board is
released and may be different from your purchased motherboard.
Users are welcome to download the latest BIOS version form our
official website.
The BIOS is a program located on a Flash Memory on the motherboard. This program
is a bridge between motherboard and operating system. When you start the computer,
the BIOS program will gain control. The BIOS first operates an auto-diagnostic test
called POST (power on self test) for all the necessary hardware, it detects the entire
hardware device and configures the parameters of the hardware synchronization.
Only when these tasks are completed done it gives up control of the computer to
operating system (OS). Since the BIOS is the only channel for hardware and software
to communicate, it is the key factor for system stability, and in ensuring that your
system performance as its best.
3-1 Entering Setup
Power on the computer and by pressing <Del> immediately allows you to enter Setup.
If the message disappears before your respond and you still wish to enter Setup,
restart the system to try again by turning it OFF then ON or pressing the “RESET”
button on the system case. You may also restart by simultaneously pressing <Ctrl>,
<Alt> and <Delete> keys. If you do not press the keys at the correct time and the
system does not boot, an error message will be displayed and you will again be asked
to
Press <Del> to enter Setup
1
r
3-2 BIOS Menu Screen
The following diagram show a general BIOS menu screen:
Menu Ba
General Help Items
Menu Items
Current Setting Value
Function Keys
BIOS Menu Screen
18
3-3 Function Key
In the above BIOS Setup main menu, you can see several options. We will explain
these options step by step in the following pages of this chapter, but let us first see a
short description of the function keys you may use here:
Press←→ (left, right) to select screen;
z
Press ↑↓ (up, down) to choose the item you want to confirm or to modify in the
z
main menu.
Press <Enter> to select.
z
Press <+>/<–> key when you want to modify the BIOS parameters for the active
z
option.
[F1]: Press to general help information.
z
[F2]: Press to load previous value.
z
[F3]: Press to load optimized defaults.
z
[F4]: Save and Exit.
z
Press <Esc> to quit the BIOS Setup.
z
3-4 Getting Help
Main Menu
The on-line description of the highlighted setup function is displayed at the top right
corner the screen.
Status Page Setup Menu/Option Page Setup M enu
Press [F1] to pop up a small help window that describes the appropriate keys to use
and the possible selections for the highlighted item. To exit the Help Window, press
<Esc>.
19
3-5 Menu Bar
There are six menu bars on top of BIOS screen:
Main To change system basic configuration
Advanced To change system advanced configuration
Chipset To change chipset configuration
Boot To change boot settings
Security Password settings
Save & Exit Save setting, loading and exit options.
User can press the ←/→ (left, right) arrow key on the keyboard to switch from menu
bar. The selected one is highlighted.
3-6 Main Menu
Main menu screen includes some basic system information. Highlight the item and
then use the <+> / <-> key or numerical keyboard keys to select the value you want in
each item.
20
System Date
Set the date. Please use TAB to switch between data elements.
System Time
Set the time. Please use TAB to switch between time elements.
21
3-7 Advanced Menu
Onboard Lan 1/Onboard Lan 2 (Optional for NF81 series)
Use the above items to enable or disable onboard LAN 1/2.
Onboard PCIE Lan (Optional for NC85 series)
Use the above items to enable or disable onboard PCIE LAN.
Onboard Lan BootROM
Use this item to enable or disable boot option for legacy network devices.
Wake Up By Pcie(WOL)
22
Use this item to enable or disable system to wake up by PCIE LAN (WOL) function.
► ACPI Settings
Enable ACPI Auto Configuration
Use this item to enable or disable BIOS ACPI auto configuration.
Enable Hibernation
Use this item to enable or disable system ability to hibernate (OS/S4 Sleep State).
This option may be not effective with some OS.
ACPI Sleep State
Use this item to select the highest ACPI sleep state the system will enter when the
suspend button is pressed.
► S5 RTC Wake Settings
This item will enable system to wake up from S5 using RTC alarm.
Press [Enter] to go into sub-item:
Wake System with Fixed Time.
The optional settings are: [Enabled]; [Disabled]. When set as Enabled, system will
wake on the hour/minute/second specified. Please follow onscreen instructions.
► CPU Configuration
PSTATE Adjustment
This item is provided to adjust startup P-state level.
PPC Adjustment
This item is provided to adjust _PPC object.
Virtualization Mode
Use this item to enable or disable CPU SVM virtualization. The optional settings
are: [Disabled]; [Enabled].
23
C6 Mode
The optional settings are: [Disabled]; [Enabled].
► SATA Configuration
Press [Enter] to make specified settings for available SATA device.
► Super I/O Configuration
► Serial Port 0 Configuration
Press [Enter] and set parameter of the following sub-items for serial port:
Serial Port
Use this item to enable or disable serial port (COM).
Change Settings
Use this item to select an optimal setting for super IO device.
Wake-up by PS/2 keyboard
Use this item to enable or disable PS/2 keyboard wake-up from S3/S4/S5.
Wake-up by PS/2 mouse
Use this item to enable or disable PS/2 mouse wake-up from S3/S4/S5.
EUP Support
Use this item to enable or disable EUP support.
PWRON after PWR-Fail
The optional settings are: [Former-Sts]; [Power On]; [Power Off].
WatchDog Function
Use this item to enable or disable Watchdog Timer Control. When set as Enabled,
the following sub-items shall appear:
WatchDog Timer Unit
The optional settings are: [Sec];[Min].
24
WatchDog Timer Value
User can set a value in the range of 0 to 255.
► H/W Monitor
Press [Enter] to view hardware health status. User can also make settings to the
smart fan mode.
CPUFAN1/SYSFAN1/SYSFAN2 Smart Mode
When set as [Enabled], the following sub-items shall appear:
CPUFAN1 (SYSFAN1 /SYSFAN2) Highest Speed Temp/ Idle Temp/ Second
Speed Setting/Idle Setting
Make settings to the above sub-items by typing in number in the specified range to
control working temperature of the board.
► Shutdown Temperature Configuration
Use this item to select system shutdown temperature.
The optional settings are: Disabled; 60C/140F; 65C/149F; 70C/158F; 75C/167F.
► Voltage Settings
Use this item select settings for DRAM voltage.
25
6
3-8 Chipset Menu
► North Bridge
LVDS Mode
Use this item to enable or disable LVDS mode.
LVDS Panel Select
Use this item to select configuration for NON-EDID LVDS panel.
HDMI Audio
Use this item to enable or disable HDMI audio function.
2
7
IOMMU Mode
IOMMU is supported on Linux based systems to convert 32 bit I/O to 64 bit MMIO.
Memory Clock
This option allows user to select different memory clock.
Integrated Graphics
Use this item to enable integrated graphics controller. The optional settings are:
Auto; Disabled; Force.
► South Bridge
OnChip SATA Channel
The optional settings are: [Enabled]; [Disabled].
OnChip SATA Type
Use this item to select onchip SATA type.
SATA IDE Combined Mode (Optional for NF81 series)
The optional settings are: [Enabled]; [Disabled].
Onboard Audio Device
The optional settings are: [Enabled]; [Disabled].
► SB USB Configuration
Press [Enter] to further setting USB port configuration.
2
3-9 Boot Menu
Setup Prompt Timeout
Use this item to set number of seconds to wait for setup activation key.
Bootup Numlock State
Use this item to select keyboard NumLock state. The optional settings are: [On]; [Off].
28
3-10 Security Menu
Security menu allow users to change administrator password and user password
settings.
29
3-11 Save & Exit Menu
Save & Exit menu allows user to load optimal defaults, save or discard your changes
to BIOS items.
30
Loading...
