JET JSG-96 Operating Instructions and Parts Manual
This .pdf document is bookmarked
Operating Instructions and Parts Manual
Benchtop Disc/Belt Sander
Model JSG-96
JET
427 New Sanford Road
LaVergne, Tennessee 37086 Part No. M-708595
Ph.: 800-274-6848 Revision H1 11/2018
www.jettools.com Copyright © 2015 JET
(shown with optional closed stand 708597)
Warranty and Service
JET warrants every product it sells against manufacturers’ defects. If one of our tools needs service or repair, please
contact Technical Service by calling 1-800-274-6846, 8AM to 5PM CST, Monday through Friday.
Warranty Period
The general warranty lasts for the time period specified in the literature included with your product or on the official
JET branded website.
JET products carry a limited warranty which varies in duration based upon the product. (See chart below)
Accessories carry a limited warranty of one year from the date of receipt.
Consumable items are defined as expendable parts or accessories expected to become inoperable within a
reasonable amount of use and are covered by a 90 day limited warranty against manufacturer’s defects.
Who is Covered
This warranty covers only the initial purchaser of the product from the date of delivery.
What is Covered
This warranty covers any defects in workmanship or materials subject to the limitations stated below. This warranty
does not cover failures due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear,
improper repair, alterations or lack of maintenance. JET woodworking machinery is designed to be used with Wood.
Use of these machines in the processing of metal, plastics, or other materials outside recommended guidelines may
void the warranty. The exceptions are acrylics and other natural items that are made specifically for wood turning.
Warranty Limitations
Woodworking products with a Five Year Warranty that are used for commercial or industrial purposes default to a
Two Year Warranty. Please contact Technical Service at 1-800-274-6846 for further clarification.
How to Get Technical Support
Please contact Technical Service by calling 1-800-274-6846. Please note that you will be asked to provide proof
of initial purchase when calling. If a product requires further inspection, the Technical Service representative will
explain and assist with any additional action needed. JET has Authorized Service Centers located throughout the
United States. For the name of an Authorized Service Center in your area call 1-800-274-6846 or use the Service
Center Locator on the JET website.
More Information
JET is constantly adding new products. For complete, up-to-date product information, check with your local distributor
or visit the JET website.
How State Law Applies
This warranty gives you specific legal rights, subject to applicable state law.
Limitations on This Warranty
JET LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH PRODUCT.
EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
JET SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR FOR
INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR
PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
JET sells through distributors only. The specifications listed in JET printed materials and on official JET website are
given as general information and are not binding. JET reserves the right to effect at any time, without prior notice,
those alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason
whatsoever. JET
Product Listing with Warranty Period
90 Days – Parts; Consumable items
1 Year – Motors; Machine Accessories
2 Year – Metalworking Machinery; Electric Hoists, Electric Hoist Accessories; Woodworking Machinery used
for industrial or commercial purposes
5 Year – Woodworking Machinery
Limited Lifetime – JET Parallel clamps; VOLT Series Electric Hoists; Manual Hoists; Manual Hoist
Accessories; Shop Tools; Warehouse & Dock products; Hand Tools; Air Tools
NOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries,
Inc., or any of its successors in interest to the JET brand.
®
branded products are not sold in Canada by JPW Industries, Inc.
2
Table of Contents
Warranty and Service ............................................................................................................................................ 2
Table of Contents .................................................................................................................................................. 3
Warning ................................................................................................................................................................. 4
Grounding Instructions .......................................................................................................................................... 6
Introduction ........................................................................................................................................................... 6
Specifications ........................................................................................................................................................ 7
Dimensions ........................................................................................................................................................... 8
Unpacking ............................................................................................................................................................. 9
Assembly ............................................................................................................................................................... 9
Open Stand Assembly (Optional) ...................................................................................................................... 9
Closed Stand Assembly (Optional) ................................................................................................................. 10
Sander Assembly ............................................................................................................................................ 10
Adjustments ........................................................................................................................................................ 11
Sanding Belt Table Adjustment ....................................................................................................................... 11
Horizontal Sanding Workstop .......................................................................................................................... 12
Sanding Belt Replacement .............................................................................................................................. 12
Belt Tracking Adjustment ................................................................................................................................ 13
Disc Table Adjustment .................................................................................................................................... 13
Sanding Disc Replacement ............................................................................................................................. 14
Center Point .................................................................................................................................................... 14
On/Off Switch .................................................................................................................................................. 14
Dust Collection ................................................................................................................................................ 15
Maintenance ........................................................................................................................................................ 15
Lubrication ....................................................................................................................................................... 15
Optional Accessories .......................................................................................................................................... 15
Troubleshooting .................................................................................................................................................. 16
Replacement Parts .............................................................................................................................................. 16
Disc Sander Assembly Breakdown ................................................................................................................. 17
Parts List for the Disc Sander Assembly ......................................................................................................... 18
Belt Sander Assembly Breakdown .................................................................................................................. 20
Parts List for the Belt Sander Assembly .......................................................................................................... 21
Open Stand Assembly (Optional) .................................................................................................................... 23
Closed Stand Assembly (Optional) ................................................................................................................. 24
Parts List for Closed Stand (Optional) ............................................................................................................. 25
JSG-96 Wiring Diagram ...................................................................................................................................... 25
3
Warning
Wear eye protection.
Always keep guards in place and in proper operating condition. Do not operate the machine without the
guards for any reason.
This disc/belt sander is intended to be used with wood and wood products only. Use of this disc/belt
sander and a dust collector with metal products is a potential fire hazard.
Support the workpiece adequately at all times during operation; maintain control of the work at all
times.
This disc/belt sander is designed and intended for use by properly trained and experienced
personnel only. If you are not familiar with the proper and safe operation of a disc/belt sander, do
not use until proper training and knowledge have been obtained.
REMOVE ADJUSTING KEYS AND WRENCHES. Form a habit of checking to see that keys and
adjusting wrenches are removed from the machine before turning it on.
KEEP THE WORK AREA CLEAN. Cluttered areas and benches invite accidents.
DON’T USE IN A DANGEROUS ENVIRONMENT. Don’t use power tools in damp or wet locations,
or expose them to rain. Keep work area well lighted.
KEEP CHILDREN AWAY. All visitors should be kept a safe distance from the work area.
MAKE THE WORKSHOP KIDPROOF with padlocks, master switches, or by removing starter keys.
DON’T FORCE THE MACHINE. It will do the job better and safer at the rate for which it was
designed.
USE THE RIGHT TOOL. Don’t force a machine or attachment to do a job for which it was not
designed.
USE THE PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When
using an extension cord, be sure to use one heavy enough to carry the current your machine will
draw. An undersized cord will cause a drop in the line voltage resulting in power loss and
overheating. The table following shows the correct size to use depending on the cord length and
nameplate ampere rating. If in doubt, use the next heavier gauge. Remember, the smaller the gauge
number, the heavier the cord.
Volts Total Length of Cord in Feet
120V 25 50 100 150
AWG
16 16 14 12
WEAR PROPER APPAREL. Do not wear loose clothing, gloves, neckties, rings, bracelets, or other
jewelry which may get caught in moving parts. Nonslip footwear is recommended. Wear protective
hair covering to contain long hair.
ALWAYS USE SAFETY GLASSES. Also use face or dust masks if the cutting operation is dusty.
Everyday eyeglasses only have impact resistant lenses; they are not safety glasses.
DON’T OVERREACH. Keep proper footing and balance at all times.
MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest performance.
Follow instructions for lubricating and changing accessories.
4
ALWAYS DISCONNECT THE MACHINE FROM THE POWER SOURCE BEFORE SERVICING.
REDUCE THE RISK OF UNINTENTIONAL STARTING. Make sure the switch is in the off position
before plugging in.
USE RECOMMENDED ACCESSORIES. The use of accessories and attachments not
recommended by JET may cause hazards or risk of injury to persons.
NEVER STAND ON A MACHINE. Serious injury could occur if the machine is tipped.
CHECK DAMAGED PARTS. Before further use of the machine, a guard or other part that is
damaged should be carefully checked to determine that it will operate properly and perform its
intended function - check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting, and any other conditions that may affect its operation. A guard or other part that is
damaged should be properly repaired or replaced.
NEVER LEAVE THE MACHINE RUNNING UNATTENDED. TURN POWER OFF. Don’t leave the
machine until it comes to a complete stop.
DO NOT operate tool while under the influence of drugs, alcohol or any medication.
AVOID kickback by sanding in accordance with directional arrows. Sand on downward side of disc.
Sanding on the upward side could cause the workpiece to fly up causing injury.
SAND with the grain of the wood.
DO NOT sand pieces of material that are too small to be safely supported.
WHEN sanding a large workpiece, provide additional support at table height.
ADDITIONAL INFORMATION regarding the safe and proper operation of this product is available
from the the National Safety Council, 1121 Spring Lake Drive, Itasca, IL 60143-3201, in the Accident
Prevention Manual for Industrial Operations and also in the safety Data Sheets provided by the NSC.
Please also refer to the American National Standards Institute
ANSI 01.1 Safety Requirements for
Woodworking Machinery and the U.S. Department of Labor OSHA 1910.213 Regulations.
SAVE THESE INSTRUCTIONS refer to them often and use them to instruct others.
WARNING: This product can expose you to chemicals including lead which is known to the
State of California to cause cancer and birth defects or other reproductive harm. For more
information go to http://www.p65warnings.ca.gov.
WARNING: Drilling, sawing, sanding or machining wood products generates wood dust and
other substances known to the State of California to cause cancer. Avoid inhaling dust generated
from wood products or use a dust mask or other safeguards for personal protection.
Wood products emit chemicals known to the State of California to cause birth defects or other
reproductive harm. For more information go to http://www.p65warnings.ca.gov/wood.
Familiarize yourself with the following safety notices used in this manual:
This means that if precautions are not heeded, it may result in minor injury and/or
possible machine damage.
This means that if precautions are not heeded, it may result in serious or even fatal
injury.
5
Grounding Instructions
Electrical connections must be made by a qualified electrician in compliance with all
relevant codes. This machine must be properly grounded to help prevent electrical shock and possible
fatal injury.
In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to
reduce the risk of electric shock. This tool is equipped with an electric cord having an equipment-grounding
conductor and a grounding plug. The plug must be plugged into a matching outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
Do not modify the plug provided. If it will not fit the outlet, have the proper outlet installed by a qualified
electrician.
Improper connection of the equipment-grounding conductor can result in a risk of electric shock. The
conductor, with insulation having an outer surface that is green with or without yellow stripes, is the equipmentgrounding conductor. If repair or replacement of the electric cord or plug is necessary, do not connect the
equipment-grounding conductor to a live terminal.
Check with a qualified electrician or service personnel if the grounding instructions are not completely
understood, or if in doubt as to whether the tool is properly grounded. Use only three wire extension cords that
have three-prong grounding plugs and three-pole receptacles that accept the tool’s plug.
Repair or replace a damaged or worn cord immediately.
115 Volt Operation
As received from the factory, your sander is ready to run at 115 volt operation. This sander, when wired for 115
volt, is intended for use on a circuit that has an outlet and a plug that looks like the one illustrated in (A). A
temporary adapter, which looks like the adapter as illustrated in (B), may be used to connect this plug to a twopole receptacle, as shown in (B) if a properly grounded outlet is not available. The temporary adapter should
only be used until a properly grounded outlet can be installed by a qualified electrician. This adapter is not
applicable in Canada. The green colored rigid ear, lug, or tab, extending from the adapter, must be
connected to a permanent ground such as a properly grounded outlet box, as shown in (B).
Introduction
This manual is provided by JET, covering the safe operation and maintenance procedures for a JET Model
JSG-96 Disc/Belt Sander. This manual contains instructions on installation, safety precautions, general
operating procedures, maintenance instructions and parts breakdown. This machine has been designed and
constructed to provide consistent, long-term operation if used in accordance with instructions set forth in this
manual. If there are any questions or comments, please contact either your local supplier or JET. JET can also
be reached at our web site: www.jettools.com.
6
Specifications
Model Number ............................................................................................................................................. JSG-96
Stock Number ............................................................................................................................................. 708595
Sanding Belt .......................................................................................................................................... 6”W x 48”L
Disc Diameter ....................................................................................................................................................... 9”
Table Tilt (down) ....................................................................................................................................... 90 - 45
Dust Chute Diameter ............................................................................................................................................ 4”
Belt Table ........................................................................................................................................ 5-1/2"W x 11"L
Abrasive Belt Provided ................................................................................................................................. 80 Grit
Platen Size ............................................................................................................................................ 7”W x 15”L
Disc Table ........................................................................................................................................... 10"W x 12”L
Abrasive disc provided ................................................................................................................................. 80 Grit
Motor ................................................................................................................ 3/4HP, 115V, 60Hz, 1PH, 4P, 11A
Power Cord Length ..................................................................................................................................... 6-1/2 ft.
Belt Speed (SFPM) ........................................................................................................................................ 2,258
Disc Speed (RPM) ......................................................................................................................................... 1,725
Overall Dimensions ................................................................................................................ 16"Lx31”Wx28-3/4”H
Net Weight (approx.) ................................................................................................................................... 91 Lbs.
Gross Weight (approx.) ............................................................................................................................. 100 Lbs.
The above specifications were current at the time this manual was published, but because of our policy of
continuous improvement, JET reserves the right to change specifications at any time and without prior notice,
without incurring obligations.
7
Dimensions
8
Unpacking
Open shipping container and check for shipping
damage. Report any damage immediately to your
distributor and shipping agent. Do not discard any
shipping material until the Sander is assembled
and running properly.
Compare the contents of your container with the
following parts list to make sure all parts are intact.
Missing parts, if any, should be reported to your
distributor.
Contents of Main Carton (708595)
1 Sander
1 Sanding Belt
1 Sanding Disc
2 Tables
1 Center Point
3 Handles
2 5/16” Flat Washers
1 Miter Gauge
1 Owner's Manual
1 Warranty Card
Tools Required for Assembly
1 13mm Wrench or socket (for stand)
1 12mm Wrench or socket (for stand)
Assembly
Main Carton Contents #708595
Open Stand Contents #708596 (optional)
Read and understand the
entire contents of this manual before
attempting assembly or operation of the
disc/belt sander. Failure to comply may cause
serious injury.
Consult the breakdown drawings at the back of this
manual if further clarification is needed on
assembly instructions.
Open Stand Assembly (Optional)
1. Match the hole patterns in the stand legs with
the hole patterns in the stand top pieces.
Mount the legs to the outside of the top pieces
using sixteen 5/16”x5/8” carriage bolts and
sixteen 5/16” lock nuts. Do not tighten until the
stand has been assembled and is sitting level
on the floor. Note: Flange of long top pieces
overlap flange of short top pieces.
2. Install the leveling pads in the bottom hole of
legs with eight 3/8” hex nuts and eight 3/8” flat
washers.
3. Mount the belt rack to the stand by inserting
the 90° bend through the stand and securing
the rack in place with a 3/8”x3/4” hex cap bolt,
two 3/8” flat washers and a 3/8” hex nut.
Closed Stand Contents #708597 (optional)
9
Loading...
