MP5000

Owner’s Manual

PUSH

ON/OFF





VOL











LOUD





















JENSEN

AUX



AUD



A

B

C



MUTE





+





SPEAKER







MEDIA PRO 5000























UP











ON/OFF





















ALARM



























TUN/











SET



MP





TRK















3





















CD-RW





DN











T/F

























AM/FM

1

2



3

4





5

6

AS/PS

















ENTER













LANG

MENU









INT

RPT

RDM



STOP





































DVD

DVD/CD/MP3 PLAYER

AUX





A/V IN





Thank You!

Thank you for choosing a Jensen product. We hope you will find the instructions in this owner’s manual clear and easy to follow. If you take a few minutes to look through it, you’ll learn how to use all the features of your new Jensen receiver for maximum enjoyment.

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Basic Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Tuner Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

CD Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

DVD Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Features

Features of the Jensen MP5000 mobile audio system include:

Digital AM/FM Tuner

Skip Protected Disc Mechanism

CD-R/RW and MP3 Compatible

Time/Alarm Clock

Backlit Controls

Auxiliary Audio/Video Input

Headphone Output

3 Zone / 6 Speaker Output (75W)

Wireless Remote Included

2

MP5000

Installation

Select Mounting Location

Select a mounting location, taking care to avoid the following:

Places exposed to heat-radiating appliances such as electric heaters

Adjacent to other equipment that radiates heat

Poorly-ventilated or dusty places

Moist or humid locations

Preparing the Opening

Use the mounting hole diagram (below) to measure and cut a mounting hole, and mount the unit using the four 3x20min self-tapping screws provided.

Note: Before cutting the mounting hole, make sure the area behind the mounting location is clear of wires and fuel, vacuum and or brake lines.

Mounting Hole Diagram

3/16”









3/16”





























Mounting the Radio

Route power, speaker and antenna cables through the hole, and connect them to the unit as outlined in the wiring diagram. After ensuring correct connections, test operation.

3

Wiring

The wiring diagram depicts all the wiring connections required for proper operation of the unit.

4

MP5000

Basic Operation

1. Power / Volume Control

Press the power button (1) to turn the unit on or off. This button also serves as the volume control knob; rotate clockwise or counterclockwise to increase or decrease the volume output.

2. Mute / Loudness

Press MUTE (2) momentarily to silence the audio output in tuner, CD, DVD or auxiliary input mode. Press MUTE again to resume the previous volume level. This button is also used to access the Loudness function; press and hold MUTE to toggle the Loudness function on and off.

3. Liquid Crystal Display (LCD)

The liquid crystal display (LCD) panel (3) displays the frequency, time and activated functions. Note:

When subjected to cold temperatures for an extended period of time, LCD panels will take longer to illuminate and the display visibility may slightly decrease. Optimal LCD operation will return to normal when the temperature increases to a normal range.







Basic Operation









5

1

4

3



9





2











PUSH























ON/OFF























VOL











LOUD





























AUX



AUD

A

B

C



MUTE

JENSEN















+





SPEAKER







MEDIA PRO 5000































































8b

7



UP











ON/OFF





















ALARM























8a





TUN/











SET



MP





TRK















CD-RW



















3







DN











T/F





























AM/FM



1

2

3



4



5

6

AS/PS

6































ENTER













LANG

MENU











INT

RPT



RDM

STOP























DVD







DVD/CD/MP3 PLAYER



AUX







































A/V IN















5
