Jensen SMPV-2GBUB, SMPV-xGBUB User Manual

DIGITAL MEDIA PLAYER

PLEASE READ THIS OPERATING MANUAL COMPLETELY BEFORE OPERATING THIS UNIT

AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE

USER MANUAL

SMPV-2GBUB

DEAR JENSEN® CUSTOMER

Selecting fine audio equipment such as the unit you've just purchased is only

the start of your musical enjoyment. Now it's time to consider how you can

maximize the fun and excitement your equipment offers. This manufacturer and

the Electronic Industries Association's Consumer Electronics Group want you to

get the most out of your equipment by playing it at a safe level. One that lets the

sound come through loud and clear without annoying blaring or distortion and,

most importantly, without affecting your sensitive hearing. Sound can be

deceiving. Over time your hearing "comfort level" adapts to higher volumes of

sound. So what sounds "normal" can actually be loud and harmful to your

hearing. Guard against this by setting your equipment at a safe level BEFORE

your hearing adapts.

To establish a safe level:

- Start your volume control at a low setting.

- Slowly increase the sound until you can hear it comfortably and clearly and

without distortion.

1

Once you have established a comfortable sound level:

- Set the dial and leave it there.

Taking a minute doing this now will help to prevent hearing damage or loss in

the future. After all, we want you listening for a lifetime.

We Want You Listening For a Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and

enjoyment. Since hearing damage from loud noise is often undetectable until it

is too late, this manufacturer and the Electronic Industries Association's

Consumer Electronics Group recommend you avoid prolonged exposure to

excessive noise.

Customer's Record:

The serial number of this product is found on the unit. You should note the

serial number of this unit in the space provided as a permanent record of your

purchase to aid in identification in the event of theft of loss.

Model Number: SMPV-2GBUB Serial Number:

2

NOTE

z Do not throw the product into fire to avoid danger of explosion.

z Do not immerse into water or get soaked since the battery charging function

will be lost.

z Please fully charge the battery before using this device.

z When charging the battery the Power Switch should be in the ON position.

z Do not charge rechargeable batteries longer than 4 hours.

z Do not take the batteries apart.

z Overcharging & over-discharging the rechargeable batteries may shorten

their life span.

z Recharge battery when you experience the following:

- Low battery

- System automatically turns off

- Operation keys do not work

z When the "copying Files" window appears on your PC please don’t unplug

the USB cable from the computer.

z Do not unplug the USB cable during file downloading as it may cause

3

malfunction to your PC and Player.

z Do not plug in an earphone or audio cable during file downloading.

z Downloading can be delayed if there are too many folders or files.

z The order of music files displayed on the Windows Explorer is not the order

of actual music playback.

z When the Player is connected to the PC, it will start charging.

z Do not attempt to open the Player in any way as this will void your guarantee.

z Please make sure that the version of the Direct X in the computer is Direct X

9.0 or above when converting the format of the video file. For the update of

DirectX, please visit www.microsoft.com and read the concerned information

carefully.

z Please make sure the version of the media player is media player 10.0.

4

FEATURES

z Supports MP3, WMA, WAV format music

z View JPEG formatted pictures

z Supports AMV video format. (conversion program included).

z Built in MIC

z Energy Saver mode, auto off function

z Various EQ, repeat modes

z Support multi-languages

z Plug and Play for Win2000, Win XP & Vista, Mac OS 9.xx and above

5

COMPLIANCE WITH FCC

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference

that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

6

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the party

responsible for compliance could void the user ’s authority to operate the

equipment.

7

LOCATION OF CONTROLS

8

LCD DISPLAY

9

Downloading Music, Movie & image to Your SMPV-2GBUB Player

Connecting to your Personal Computer:

1. Connect the unit to your computer USB port using the provided USB cable.

2. The unit will turn itself on automatically.

3. “CONNECT” will appear on the LCD screen indicating the connection with

the computer was established successfully.

For Windows XP/Vista users, once the unit is connected to your computer, it

appears as a removable disk in “My Computer”. You can now move, copy, paste

and delete files (music or voice recording files, etc.) between your computer and

the Players internal memory.

To download music files to the Player:

1. Select the track(s) you want to transfer from your computer.

2. Right-click on the file(s), a menu pops up and click “Copy”.

3. Under My Computer or Windows Explorer, double-click the Removable Disk

to open the drive. The Removable Disk window appears.

4. Right-click on the Removable Disk window and click “Paste” in the menu.

Removing the Player from the computer:

Note: Please follow these steps carefully to avoid data loss or unit

damage.

10

1. Click on the “Safely Remove Hardware” icon (green arrow) in the lower right

corner of system tray of your Windows desktop to bring up the list of USB

Mass Storage Device attached to your computer.

2. From the device list, choose the Drive designator that corresponds to the

Player, for example Drive (H :).

3. Click on the chosen device to unload it from your computer system.

4. Wait for the “Safe To Remove Hardware” system message window that will

pop up telling you that the Player can now be safely removed from the

system.

5. Disconnect the Player from the USB port of your computer.

11

OPERATION INSTRUCTIONS

Buttons used for “MENU” and “PLAY / PAUSE” functions can be

controlled in 3 different ways:

1. Tap - press the button briefly then release it immediately.

2. Press - press and hold the button for about 2 seconds then release it.

3. Press and Hold- press and keep holding the button while in operation.

1. Turning unit on/off

IMPORTANT: Before first use, we recommend you fully charge the Player by

connecting it to your computer’s USB port for about 3 hours.

1. To turn the Player on, slide the POWER Switch to the ON position.

2. Press and hold the PLAY Button to turn on the Player when the Power

Switch is in the ON position.

3. Press and hold the PLAY Button to turn off the Player and then slide the

Power switch to the OFF position.

12

2. Listening To Music

1. After turning on the Player, the Player will enter Music Mode.

2. Tap the MODE Button once to initialize the music play function and then tap

the PLAY Button to start playback. The

playback screen is displayed.

3. Tap VOL+/VOL- key to increase/decrease

the volume.

4. Tap the PLAY Button to pause and again to

resume PLAY.

/ to skip to the next or previous

5. Tap
