Portable Stereo MP3 CD Player with AM/FM Radio
MODEL: CD-575
USER MANUAL
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT
AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE
WARNING
TO PREVENT FIRE OF SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The Caution Marking is located at the bottom enclosure of the apparatus.
The Rating plate is located at the bottom enclosure of the apparatus
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that product heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket,
manufacturer, or sold with the product. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for a long
period of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
or table recommended by the
15. This appliance shall not be exposed to dripping or splashing water and that no object filled
with liquids such as vases shall be placed on the apparatus.
16. Do not overload wall outlet. Use only power source as indicated.
17. Use replacement part as specified by the manufacturer.
18. Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks.
19. Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operating instruction.
20. Object and Liquid Entry - Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could result
in a fire or electric shock. Never spill liquid of any kind on the product.
21. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the
adjustment of other controls may result in damage and will often require extensive
work by a qualified technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for
service.
22. Mains plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the mains
plug should be disconnected from the mains socket outlet completely.
23. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
24. Excessive sound pressure from earphones and headphone can cause hearing loss.
25. Minimum distances of 4 inches around the apparatus for sufficient ventilation.
26. The ventilation should not be impeded by covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
27. No naked flame sources, such as lighted candles, should be placed on the apparatus.
28. The use of apparatus in moderate climates.
29. Attention should be drawn to the environmental aspects of battery disposal.
This symbol indicates that this product incorporates
between hazardous mains voltage and
CAUTION:
TO PREVENT E
PLUG TO WIDE SLOT. FULLY INSERT THE PLUG TO MAIN
POWER SOCKET.
LECTRIC SHOCK, MATCH WIDE BLADE OF
accessible parts.
us
er
operating instructions as an improper
le
doub
insulation
SAVE THESE INSTRUCTIONS
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
CAUTION
Follow the advice below for safe operations.
ON PROTECTION AGAINST LASER ENERGY EXPOSURE
§ As the laser beam used in this compact disc player is harmful to the eyes, do not attempt to
disassemble the casing.
§ Stop operation immediately if any liquid or solid object should fall into the cabinet.
§ Do not touch the lens or poke at it. If you do, you may damage the lens and the player may
not operate properly.
§ Do not put anything in the safety slot. If you do, the laser diode will be ON when the CD
door is still open.
§ If the unit is not to be used for a long period of time, make sure that all power sources are
disconnected from the unit. Remove all batteries from the battery compartment.
§ This unit employs a laser. The use of controls or adjustment or performance of procedures
other than those specified here may result in exposure to hazardous radiation.
Should any trouble occur, remove the power source and refer servicing to qualified personnel.
PROTECT YOUR FURNITURE
This system is equipped with non-skid rubber ‘feet’ to prevent the product from moving
when
you
operate the controls. These ‘feet’ are made from non-migrating rubber material
specially
formulated
to avoid leaving any marks or stains on your furniture. However certain
types of oil based
furniture
polishes, wood preservatives, or cleaning sprays may cause the
rubber ‘feet’ to soften, and
leave
marks or a rubber residue on the
furniture.
To prevent any damage to your furniture we strongly recommend that you purchase small
self-
adhesive felt pads, available at hardware stores and home improvement centers
everywhere
and
apply these pads to the bottom of the rubber ‘feet’ before you place the
product on fine
wooden furniture.
DEAR JENSEN® CUSTOMER
Selecting fine audio equipment such as the unit you've just purchased is only the start of
your
musical enjoyment. Now it's time to consider how you can maximize the fun and
excitement
your
equipment offers. This manufacturer and the Electronic Industries
Association's
Consumer
Electronics Group want you to get the most out of your equipment
by playing it at a safe level.
One
that lets the sound come through loud and clear without
annoying blaring or distortion and,
most
importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time
your
hearing "comfort level" adapts to higher volumes
of sound. So what sounds "normal" can
actually
be loud and harmful to your hearing.
Guard against this by setting your equipment at a safe
level
BEFORE your hearing
adapts.
To
establish
a safe level:
• Start your volume control at a low
setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
• Once you have
established a comfortable sound level:
Set the dial and leave it
there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After
all, we want you listening for a
lifetime.
We Want You
Listening
For a Lifetim
e
Used wisely, your new sound equipment will provide a lifetime
of
fun and enjoyment. Since hearing damage from loud noise
is
often undetectable until it is too late, this manufacturer and
the
Electronic Industries Association's Consumer Electronics Group
recommend you avoid prolonged exposure to excessive
noise.
Customer's Record:
The serial number of this product is found on its bottom cover. You should note the serial
number
of this unit in the space provided as a permanent record of your purchase to aid in
identification
in the
event of theft of
loss.
Model Number: CD-575 Serial Number:
LOCATION OF CONTROLS
1 2
3 4 5 6 7
8 9 10 11
12 13 1415
16
16
17 18
19
1 FUNCTION SWITCH 11 CHARGE INDICATOR
2 VOLUME CONTROL 12 LCD DISPLAY
3 CD DOOR 13 PROG/MEM BUTTON
4 FM ANTENNA 14 STOP BUTTON
5 CARRYING HANDLE 15 PLAY/PAUSE BUTTON
6 TUN- / TUN+ 16 SPEAKER
7 BAND SELECTOR SWITCH 17 EARPHONES JACK
8 FOLDER-/10-/M- BUTTON 18 AUX IN JACK
9 FOLDER+/10+/M+ BUTTON 19 AC IN JACK
10 REPEAT BUTTON
POWER SOURCE
The CD-575 operates using standard 120V~ 60Hz AC household power or internal
rechargeable battery.
AC POWER OPERATION
1. Insert one end of power cord to the AC IN
JACK (#19) at the back of the CD-575.
2. Connect the power cord to AC power
source.
AC I N~
BATTERY (build-in) OPERATION
Unplug the AC power cord, the CD-575 will enter Battery Operating mode automatically.
Remark:
1. When the build-in battery power remains around 5%, the CHARGE INDICATOR (#11) will
light Red and flash.
2. The CHARGE INDICATOR (#11) will turn from Red to Green when the built-in battery is
fully charged.
WARNING: Do not dispose of batteries in fire, batteries may explode or leak.
RADIO OPERATION
1. Slide the FUNCTION SWITCH (#1) to RADIO position.
2. Slide the BAND SELECTOR SWITCH (#7) to select either the AM or FM band. The station
frequency will show on the LCD display.
3. Rotate and tap the TUN- /TUN+ dial (#6) to tune the radio manually,
Rotate and hold the TUN- /TUN+ dial (#6) to search to previous/next available
station.
4. Adjust the VOLUME CONTROL (#2) to obtain the desired sound level.
Setting the Radio Station Presets
The unit allows you to store up to 20 FM stations and 20 AM stations for easy recall at any
time.
1. Slide the FUNCTION SWITCH (#1) to RADIO position.
2. Slide the BAND SELECTOR SWITCH (#7) to select either the AM or FM band. The station
frequency will show on the LCD display.
3. Tune to the radio station you want to store in memory.
4. Tap the PROG/MEM BUTTON (#13). The preset channel number “P01” will be flashing on
the LCD DISPLAY (#12).
5. Tap the FOLDER -/10-/M – BUTTON (#8) or FOLDER +/10 +/M + BUTTON (#9) to select
the preset location (P01 – P20).
6. Tap the PROG/MEM BUTTON (#13) to confirm.
7. To store up to 20 FM station presets and 20 AM station presets, repeat steps 2-5 above
RECALL PRESET STATION
In AM/FM mode, tap the FOLDER -/10-/M – BUTTON (#8) or FOLDER +/10 +/M + BUTTON
o select the preset channel.
(#9) t
TIPS FOR BEST RADIO RECEPTION
AM - The AM antenna is built inside the radio. If AM reception is weak, change the position of
the unit until the internal antenna picks up the strongest signal.
FM – To obtain the best FM reception, fully extend the FM ANTENNA (#4). Avoid close to the
speakers or other electrical appliance.
CD OPERATION
PLEASE READ THIS IMPORTANT INFORMATION:
CD mechanisms used in devices like this are designed to fully read all commercial CDs. They
will also read self-compiled CD-R/CD-RW discs but it may take up to 10 seconds for playback
to start. If playback does not start, it is likely due to the quality of the CD-R/RW disc and/or
the compatibility of the CD compilation software. Manufacturer is not responsible for the
playback quality of CD-R/RW discs.
Do not attach a label or seal to either side of the CD-R/RW disc. It may cause a malfunction.
1. Slide the FUNCTION SWITCH (#1) to CD/MP3 position.
2. Open the CD door and carefully place an audio CD/MP3 CD with its label side upward in
the CD compartment and close the CD door.
3. The player will start reading TOC of the disc.
4. The total number of tracks on the CD will appear on the LCD DISPLAY (#12) after a few
seconds. MP3 CD will take some more time.
5. Tap the PLAY/PAUSE BUTTON (#15) to start to play.
6. Adjust the VOLUME CONTROL (#2) to obtain the desired sound.
7. To suspend playing, tap the PLAY/PAUSE BUTTON (#15) again. To resume playing,
tap the PLAY/PAUSE BUTTON (#15) again.
8. You can choose to play your favorite track directly by rotate and tap the TUN- /TUN+
dial (#6). The LCD Display (#12) will indicate the correct track number selected.
9. To locate a particular section within a track, rotate and hold the TUN- /TUN+ dial
(#6) until the section is found.
10. To repeat a particular track, tap the REPEAT BUTTON (#10) repeatedly until the
REP 1 indicator lights on the LCD DISPLAY (#12).
11. To repeat the entire CD, tap the REPEAT BUTTON (#10) repeatedly until the
ALL indicator lights on the LCD DISPLAY (#12).
Note: To repeat the entire folder of the MP3 CD, tap the REPEAT BUTTON
repeatedly until the FLODER indicator lights on the LCD DISPLAY (#12).
12. To stop playing, tap the STOP BUTTON (#14).
13. Slide the FUNCTION SWITCH (#1) to OFF position to turn off the unit.
PROGRAM OPERATION
This function allows the tracks to be played in a programmed sequence. Programs can be set
in STOP mode.
1. Tap the PROG/MEM BUTTON (#13) once. The PROG Indicator will light and program
Channel Number "P01" will blink on the LCD DISPLAY (#12).
2. Rotate and tap the TUN- /TUN+ dial (#6) to select the track to be programmed.
The track number 01 (001 for MP3 CD) will blink on the LCD DISPLAY (#12) to prompt for
input.
3. Tap the PROG/MEM BUTTON (#13) again to store selection. The Program Channel No.
will change to P02.
4. You may repeat steps 2 - 3 to program as many as 20 tracks.
(#10)
5. Tap the PLAY/PAUSE BUTTON (#15) to start the programmed play.
6. You may tap the REPEAT BUTTON (#10) repeatedly to select repeat 1 or all
programmed tracks.
7. Tap STOP
BUTTON (#14) once to stop playback.
8. Tap the PLAY/PAUSE BUTTON (#15) to resume programmed play.
9. To cancel programmed play and, press the STOP BUTTON (#14) twice.
AUX IN OPERATION
You can play other music sources (iPod, MP3 or other digital audio players) through the
speakers of the CD-575 by connecting the AUX IN JACK (#18) to your external player’s audio
out jack or headphone jack.
1. Plug one end of an audio cable (not included) into the AUX IN JACK (#18) and the other
end of the cable to the headphone jack of your digital audio player.
2. Slide the FUNCTION SWITCH (#1) to the AUX position.
3. AU will show on the LCD DISPLAY (#12).
4. Turn on and start playing the external device you plugged into t
he AUX IN JACK (#18).
5. Slowly adjust both the volume controls of your CD-575 and the external device until you
reach a comfortable listening level.
Notes:
• If you connect the CD-575 to the Line-Out Jack of your external device, you only need to
adjust the VOLUME CONTROL (#2) of your CD-575. If you connect to the Headphone
Jack of your external device, you may need to adjust both the volume controls of your
external device and the CD-575 to obtain the desirable listening level.
• Remember to turn off the CD-575 when you have finished listening. Don't forget to switch
off the power of your external audio device as well.
EARPHONES CONNECTION
Connect the plug of the stereo earphone (not included) into the EARPHONES JACK (#17).
CAUTION
• Avoid excessive volume levels for long period of time when using the earphones.
Prolonged use at high levels may impair your hearing.
• Do not use earphones while operating a motorized vehicle, as it may create a traffic
hazard and is illegal in many areas
RE SE TTI NG TH E U NI T
In case of malfunction due to electrostatic discharge, reset the unit by slide the FUNCTION
SWITCH (#1) to the “OFF” position. Wait for 2-3 minutes before returning on the unit.
CARE AND MAINTENANCE
1. Clean your unit with a damp (never wet) cloth. Solvent or detergent should never be used.
2. Avoid leaving your unit in direct sunlight or in hot, humid or dusty places.
3. Keep your unit away from heating appliances and sources of electrical noise such as
fluorescent lamps or motors.
4. If drop-outs or interruptions occur in the music during CD play,
or if the CD fails to play at all, its bottom surface may require
cleaning. Before playing, wipe the disc from the center
outwards with a good soft cleaning cloth.
TROUBLE SHOOTING GUIDE
If you experience difficulties in the use of the CD-575, please check the following or call 1800-777-5331 for Customer Service and support
Symptom
Possible Caus
e
Solution
Noise or sound
distorted on AM or
FM broadcast
Station not tuned properly for AM
or FM.
FM: Telescopic antenna is not
fully extended.
AM: Internal antenna is not
positioned correctly
Fine tune the AM or FM
broadcast station.
FM: Fully extend the FM
Telescopic antenna.
AM: Reposition the unit until
the best reception is obtained.
AM or FM no sound
Unit not in Tuner mode, AM or FM
band.
Volume at minimum
Slide function switch to select
RADIO.
Increase Volume level.
CD player will not
play
Unit not in CD function mode.
CD is installed incorrectly.
If the CD is self-compiled, the
media used may not be
compatible with the player.
Select function switch to
CD/MP3.
Insert CD with label side up.
Use better quality blank media
and retest.
CD skips while
playing
Disc is dirty or scratched.
Wipe CD with clean cloth or
use another disc.
Intermittent sound
from CD Player
Dirty or defective disc.
Dirty pick up lens.
Player is subject to excessive
shock or vibration
Clean or replace the defective
disc.
Use a CD-lens cleaning disc
to clean the lens.
Relocate the player away
from shock or vibration
SPECIFICATION
Power: AC120V ~ 60Hz 19W
Built-in Li-ion Battery: 7.4V, 600mAh
FM: 87.5 – 108 MHz
AM: 520 – 1710 KHz
At Spectra, environmental and social responsibility is a core value
of our business. We are dedicated to continuous implementation
of responsible initiatives with an aim to conserve and maintain the
environment through responsible recycling.
Please visit us at http://www.spectraintl.com/green.htm for more information on Spectra’s
green initiatives or to find a recycler in your area.
90 DAY LIMITED WARRANTY AND SERVICE
VALID IN THE U.S.A. ONLY
SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from
defective materials or
factory workmanship for a period of 90 days from the date of original
customer purchase and provided the
product is utilized within the U.S.A. This warranty is
not assignable or transferable. Our obligation under this
warranty is the repair or
replacement of the defective unit or any part thereof, except batteries, when it is
returned
to the SPECTRA Service Department, accompanied by proof of the date of original consumer
purchase, such as a duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SPECTRA for warranty
service. If the product is repaired or replaced under warranty, the return charges will be at
SPECTRA’s expense. There are no other express warranties other than those stated herein.
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SPECTRA product only while:
a. It remains in the possession of the original purchaser and proof of purchase is
demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage outside
the descriptions and warnings covered within the user manual or non-SPECTRA
approved modifications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by electrical wiring not
in compliance with
electrical codes or SPECTRA user manual specifications, or
failure to provide reasonable care and
necessary maintenance as outlined in the user
manual.
3. Warranty of all SPECTRA products applies to residential use only and is void when products are
used in nonresidential environment or installed outside the United States.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state. TO OBTAIN SERVICE please remove all batteries (if any) and pack the
unit carefully and send it freight prepaid to SPECTRA at the address shown below. IF THE
UNIT IS RETURNED WITHIN THE WARRANTY PERIOD
shown above, please include a
proof of purchase (dated cash register receipt) so that we may establish your
eligibility for
warranty service and repair of the unit without cost. Also include a note with a description
explaining
how the unit is defective. A customer service representative may need to contact
you regarding the status of your repair, so please include your name, address, phone
number and email address to expedite the process.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check for $20.00 to
cover the cost of repair, handling and return postage. All out of warranty returns must be sent
prepaid.
It is recommended that you contact SPECTRA first at 1-800-777-5331 or by email at
custserv@spectraintl.com for updated information on the unit requiring service. In some
cases, the model you have may be discontinued, and SPECTRA reserves the right to offer
alternative options for repair or replacement.
SPECTRA MERCHANDISING INTERNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL60634, USA. 1-800-777-5331
To register your product, visit the link on the website below to enter your information.
http://www.spectraintl.com/wform.htm
0118 Printed in China
Loading...
