Jensen BTM15 Owner's Manual

Owner's Manual

BTM15

Bluetooth Handsfree Accessory
Accesorio Bluetooth de

Manos Libres
Accessoire mains libres

de Bluetooth

Manual del Propietario
Instructions pour le propriétaire

The Jensen BTM15 offers effortless wireless connectivity in a sleek, convenient design,
allowing you to focus on driving.

Features

=Bluetooth 2.1 specification compliant
=Supports pairing with pin code (NAME: BTM15, PIN: 1234)
=A2DP handsfree compatibility
=Small and easy to integrate into vehicle interior
=Up to 10 meters connection with Bluetooth devices

High quality stereo audio

COMPLIANCE STATEMENT: This device is verified to comply with Part 15.19 (a) (3) of
the FCC Rules. Operation subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

INTRODUCTION

PAGE 1

CAUTION: Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.

NOTE: When using a BTM15 with a Jensen voice control head unit, the 3.5mm male

connector must be connected to the microphone input on the back of the head unit.

1. Before using Bluetooth functions, you must connect the BTM15 to the BT BUS cable
on the back of your BTM15 compatible head unit.

2. Attach the BTM15 to your vehicle's sun visor

using the clip on the back of the BTM15.

Installation Instructions

PAGE 2

Main Unit

BTM15

Bluetooth Bus

Visor Clip

UV10, VM9214, VM9224, VM9213, VM9223, VM9313, VM9413, VM9423,
VM9314, VM9324, VM9414, VM9424 and VM8514 Head Units

1. Press the SRC button to access the Source Menu.

2. Select the Bluetooth source (BT).

3. Press the Bluetooth Connect Icon ( ) to begin the pairing process.

4. Make sure Bluetooth is enabled on your phone and search for new devices.

5. Select your head unit model number from the device list.

6. The password for pairing is "1234". During the pairing process, the head unit
model number appears on your mobile phone.

For all other compatible head units, please see the Owner's Manual that came
with your radio for pairing instructions.

Pairing your Phone to the BTM15

PAGE 3

Operation

PAGE 4

Bluetooth operation is dependent upon your compatible head unit and
remote control. Operation specific to the BTM15 is listed below:

! To answer an incoming call, press the TALK button on the BTM15.
! To end a call, press the TALK button.

Using your BTM15 with a Jensen voice controlled head unit

There are two microphones built into the BTM15; one
microphone is for Bluetooth and the second is designed to be
used in conjunction with the PTT (Push To Talk) button found on
the Jensen voice control head units. When using the BTM15, the microphone that
was included with your voice control head unit is no longer needed and can be
removed. The "Talk" button is for Bluetooth only, not voice control.

As with all Bluetooth devices, some features are limited by the mobile phone's
compatibility. Please refer to the Owner's Manual that came with your head unit
for additional Bluetooth Operating Instructions and instructions specific to voice
control operations.
