JENSEN BT250

BBlluueettooootthh CCaarr KKiitt UUsseerr’’ss MMaannuuaall

Installation and User Manual

Preface

This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer.

Version 2.0, March 2009

Trademarks

Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies.

Limitation of Liability

While reasonable efforts have been made to ensure the accuracy of this manual, the manufacturer and distributor assume no liability resulting from errors or omissions in this manual, or from the use of the information contained herein.

Bluetooth Car Kit User Manual

Preface....................................................................................................................i

Installation ..............................................................................................................1

Identifying components......................................................................................1

Installing the junction box..................................................................................2

Installing the Components..................................................................................5

Installing the microphone, control, & speaker .............................................5

Introduction.............................................................................................................6

Product overview and features ...........................................................................6

Pairing phones..............................................................................................8

Turning off the BT250 & the Blue LED light..............................................9

Operation with multiple paired phones ........................................................9

Resetting the Car Kit..................................................................................10

Transferring calls .......................................................................................10

Notes on using voice recognition ...............................................................10

Updating the Bluetooth Software...............................................................11

Troubleshooting .........................................................................................12

Warranty Information..........................................................................................13

BBlluueettooootthh WWiirreelleessss CCaarr KKiitt

This section demonstrates how to set up and install the Bluetooth Wireless Car Kit into a vehicle.

Identifying components

Unpack the Car Kit package and ensure the following items are included.

Wired Remote Part # 31092000

Microphone Part # 31092440

Installation

Junction box Part # 31092100

Speaker Part # 31092430

Some items may vary slightly from the picture shown.

If any item is missing or damaged, contact your dealer.

Power Cable Part # 31092160

Fuse & Hardware Set Part # 31092010

Bluetooth Car Kit User Manual

Installing the junction box

This Car Kit is designed to work with a 12/24-volt vehicle power supply. Refer to the following to install the junction box in a vehicle.

1. Locate a suitable place inside the car to mount the junction box. Select a dry place that avoids excessive heat and mechanical vibration. Ideally, the junction box should be hidden from view, but still easily accessible.

Note: Make sure that the cables are long enough to support

the location of the junction box. If the cables are not long enough, do not lengthen the cables; relocate the junction box.

2. Use two screws (not included) to fasten the junction box in place.
