Jensen AWM914 User Manual

AWM914

Owner’s Manual

AWM914

Table of Contents

Installation ........................................................................................... 2

Wiring ................................................................................................... 3

Basic Operation .................................................................................. 4

Tuner Operation .................................................................................. 6

Bluetooth Operation ........................................................................... 7

Specifications ...................................................................................... 9

ii

AWM914

AWM914

Thank You!

Thank you for choosing a Jensen product. We hope you will find the

instructions in this owner’s manual clear and easy to follow. If you take
a few minutes to look through it, you’ll learn how to use all the features

of your new Jensen receiver for maximum enjoyment.

Features

Features of the Jensen AWM914 mobile audio system include:

• Backlit Controls and Display

• Electronic AM/FM Tuner

• Bluetooth Ready with A2DP / AVRCP streaming Audio

• Time/Alarm Clock

• Front Aux Audio Input

• 4 Speaker Output (2 zones)

Packing List

Precautions

• Use the Proper Power Supply.
This product is designed to operate with a 12 volt DC, negative
ground battery system (the standard system in a North American
vehicle).

• Use Authorized Service Centers.
Do not attempt to disassemble or adjust this precision product;
contact a professional for assistance.

• Avoid Moisture.
To reduce the risk of fire or electric shock, do not expose this
equipment to rain or moisture.

• Avoid Cleaning Products.
The front of this unit should only be cleaned with a slightly damp
cloth. Do not use cleansers.

• Use Recommended Accessories.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND
ANNOYING INTERFERENCE, USE ONLY THE
RECOMMENDED ACCESSORIES.

1

AWM914

INSTALLATION

It’s a good idea to read all of the instructions before beginning the

installation. We recommend having your JENSEN AWM914 installed
by a reputable RV dealership.

Tools and Supplies

You will need these tools and supplies to
install your AWM914:

• Phillips screwdriver

• Wire cutters and strippers

• Tools to remove existing radio

(screwdriver, socket wrench set or
other tools)

• Electrical tape

• Crimping tool

• Volt meter/test light

• Crimp connections

• 16 gauge wire for power connections

• 16 – 18 gauge speaker wire

heaters

• Adjacent to other equipment that radiates heat

• Poorly-ventilated or dusty places

• Moist or humid locations

Preparing the Opening

Use the mounting hole diagram (below) to measure and cut a mounting
hole, and mount the unit using the M3x20mm self-tapping screws.

Disconnecting the Battery

To prevent a short circuit, be sure to turn off the ignition and remove
the negative (-) battery cable prior to installation.

NOTE: If the AWM914 is to be installed in a vehicle equipped with
an on-board drive or navigation computer, do not disconnect the
battery cable. If the cable is disconnected, the computer memory
may be lost. Under these conditions, use extra caution during
installation to avoid causing a short circuit.

Select Mounting Location

Select a mounting location, taking care to avoid the following:

• Places exposed to heat-radiating appliances such as electric

NOTE: Before cutting the mounting hole, make sure the area
behind the mounting location is clear of wires and fuel, vacuum
and or brake lines.

Mounting the Radio

Route power, speaker and antenna cables through the hole, and
connect them to the unit as outlined in the wiring diagram. After
ensuring correct connections, test operation.

2
