JBT UPF-100 User Manual
Finisher, Model UPF-100
Finisher, Model UPF-100
Overview
The JBT FoodTech UPF100 Finisher, a paddle
finisher, has capabilities for a full range of citrus
processing, including juice finishing (separating
juice from pulp), oil finishing (separating frit
from the oil water emulsion), recovery of soluble
solids (pulp wash) core wash and pulp
packaging.
Features
• Constructed all of stainless steel
• Adaptable intake to meet customer
requirements
• Drive fully enclosed and guarded
Application Capacity Motor Motor RPM Shaft RPM
Primary Juice 120-180 gpm 15 hp 1800 400-800
Optional Controls
JBT FoodTech offers an optional finisher
process controls package designed to provide
processors with the maximum yield at the
lowest cost automatically.
Automated Screen
Unblinding:
The Automatic Spray Ring (ASR) automates
the process of screen unblinding. This option
allows for uniform and consistent screen
unblinding without the need for human
intervention.
Core Wash 65 gpm 15 hp 1800 400-800
Pulp Wash 75 gpm 15 hp 1800 400-800
Oil Recovery 115 gpm 15 hp 1800 800
Packaging 30-50 gpm 15 hp 1800 200-400
