ENGLISH
1 THANK YOU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 ABOUT YOUR JABRA SP5050. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3 WHAT YOUR NEW SPEAKERPHONE CAN DO . . . . . . . . . . . . . . . . 3
4 GETTING STARTED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
5 HOW TO…. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6 WHAT THE LIGHTS MEAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
7 TAKING CARE OF YOUR SPEAKERPHONE . . . . . . . . . . . . . . . . . . . . 7
8 TROUBLESHOOTING & FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
9 NEED MORE HELP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
10 WARNING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
11 WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
12 CERTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
13 GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Partnumber 32-00116 RevA
Jabra SP5050 Speakerphone
1
1 THANK YOU
Thank you for purchasing the Jabra SP5050 Bluetooth Speakerphone. We hope you enjoy it! This instruction manual will get you
started and ready to make the most of your Speakerphone.
Speakerphones are capable of delivering sounds at loud volumes
and high pitched tones. Exposure to such sounds can result in permanent hearing loss damage. The volume level may vary based
on conditions such as the phone you are using, its reception and
volume settings, and the environment. Please read the safety
guidelines below prior to using this headset.
2 ABOUT YOUR JABRA SP5050
1
Answer/end button
2
Volume up button
3
Volume down button
4
Charge connector
5
Power on indicator light
6
Connecting status indicator
7
Call Status indicator
8
Low battery indicator
4
Fig. 1
812
7
6
5
3
Fig. 2
Jabra SP5050 Speakerphone
2
3 WHAT YOUR NEW SPEAKERPHONE CAN DO
Your Jabra SP5050 lets you do all this:
• Answer calls
• End calls
• Reject calls*
• Voice Dialing*
• Last number redialing*
• Mute
• Night driving mode
* Phone dependent
In Night Driving Mode all icons will shut o in order to allow you
to concentrate on the most important thing while driving – trac.
Specications
• Talk time up to 12 hours/standby time up to 200 hours
• Internal rechargeable battery charged by provided car charger
• Weight 75 grams
• Operating range up to 33 feet (10 meters)
• Headset and hands-free Bluetooth proles
• Bluetooth specication (see glossary) version 2.0
4 GETTING STARTED
The Jabra SP5050 is easy to operate. The answer/end button on
the Speakerphone performs the dierent functions depending on
how long you press it.
Instructions Duration of press
Tap Press briey
Press
Press and hold Approx: 5 second
Approx: 1 second
Jabra SP5050 Speakerphone
3
1. Charge your headset
Make sure that your Jabra SP5050 Speakerphone is fully charged
for two hours before you start using it. Use only the charger
provided in the box – do not use chargers from any other devices
as this might damage your Jabra SP5050.
Connect your Speakerphone as shown in g 2. When the LED indicator light is solid red on the car charger, your headset is charging.
When the LED indicator light is green, it is fully charged.
2. Turning your Speakerphone on and o
Press the answer / end button to turn on your Speakerphone
(see g 1).
The power on indicator light will turn on. The connecting status
indicator light will blink twice every 2 second until the Jabra
SP5050 is connected to your mobile phone – then it will turn solid
blue.
To turn o your Speakerphone press the answer/end button until
you see a burst of ashes.
With Jabra AutoO, your Speakerphone will automatically turn o
15 minutes after it has lost the connection to your mobile phone.
So it doesn’t matter if you don’t turn o your SP5050 when you
leave the car – SP5050 will take care of that for you.
3. Pair it with your phone
Before you can use your Jabra SP5050, you need to pair it with
your mobile phone.
1. With Jabra Autopairing, your Speakerphone will automati-
cally enter pairing mode the rst time you turn it on.
2. Set your Bluetooth phone to ‘discover’ the Jabra SP5050.
Follow your phone’s instruction guide. This usually involves
going to a ‘setup,’ ‘connect’ or ‘Bluetooth’ menu on your phone
and selecting the option to ‘discover’ or ‘add’ a Bluetooth
device.* (See example from a typical mobile phone in g 3).
Jabra SP5050 Speakerphone
4
3. Your phone will nd the Jabra SP5050.
Your phone then asks if you want to pair with it. Accept by
pressing ‘Yes’ or ‘OK’ on the phone and conrm with the pass key or PIN = 0000 (4 zeros). Your phone will conrm when pair
ing is complete.
4. In case of unsuccessful pairing, repeat steps 1 to 3.
You can manually put your Jabra SP5050 into pairing mode, if
you want to pair with a new phone:
1. Make sure the Speakerphone is o.
2. Press and hold the answer/end button for approx 7 sec.
until the connection status indicator light starts blink
continuously.
3. Set your Bluetooth phone to discover your Speakerphone
like described above
5 HOW TO…
Answer a call
• Tap the answer/end button
End a call
• Tap the answer/end button
Make a call
• When you make a call from your mobile phone, the call will
(subject to phone settings) automatically transfer to your
Speakerphone. If your phone does not allow this feature, press
on the Jabra SP5050’s answer/end button to transfer the call to
the Speakerphone.
Reject a call*
• Press the answer/end button when the phone rings to reject an
incoming call. Depending on your phone settings, the person
who called you will either be forwarded to your voice mail or
hear a busy signal.
Activate voice dialling*
• Press the answer/end button. For best results, record the voice dialling tag through your Speakerphone. Please consult your
phone’s user manual for more information about using this
feature.
Jabra SP5050 Speakerphone
* Phone dependent
5
Redial last number*
• Double-tap the answer/end button.
Adjust sound and volume
• Tap the volume up or down to adjust the volume.
• To mute, press both volume up and down at the same time.
A low beep alert plays during a muted call.
• To un-mute, tap either of the volume buttons.
Transfer a call
• Press the answer / end button to transfer the call from the
SP5050 to the mobile phone (or back to the Speakerphone)
Bring the SP5050 in night driving mode
• When the Speakerphone is on and in standby mode, you
press both the volume up and down button at the same time.
The light will then turn o. You can turn the lights back on with
another press. The Speakerphone will always power on with
the lights turned on.
* Functions marked with * are dependent on your phone supporting these features. Check your phone’s user manual for further
information.
6 WHAT THE LIGHTS MEAN
What you see What does it mean?
Power on is solid red The Jabra SP5050 is turned on
The connecting indicator
Blink twice every 2 second
The connecting indicator is
blinking continuously
The connecting indicator is
solid blue
The call status indicator is
solid blue
The battery status indicator
blinks every second
The Jabra SP5050 is in
standby mode without being
connected to your phone
The Jabra SP5050 is in pairing
mode
The Jabra SP5050 is connected to your mobile phone
The call is in the Jabra SP5050
There is less than one hours of
talk time left
Jabra SP5050 Speakerphone
6
7 TAKING CARE OF YOUR SPEAKERPHONE
• Always store the Jabra SP5050 with the power o and safely
protected.
• Avoid storage at extreme temperatures (above 45°C/113°F – in
cluding direct sunlight – or below -10°C/14°F). This can shorten
battery life and may aect operation. High temperatures may
also degrade performance.
• Do not expose the Jabra SP5050 to rain or other liquids.
8 TROUBLESHOOTING & FAQ
I hear crackling noises
• For the best audio quality, have your mobile phone in line of
sight of the Jabra SP5050
I cannot hear anything in my Speakerphone
• Increase the volume on the Speakerphone.
• Ensure that the Speakerphone is paired with the phone.
• Make sure that the phone is connected to the Speakerphone
– if it does not connect either from the phone’s Bluetooth
menu or by tapping the answer/end button, follow the pairing
procedure (See section 3).
I have pairing problems even though my phone indicates
otherwise
• You may have deleted your headset pairing connection in your
mobile phone. Follow the pairing instructions in section 3.
Will the Jabra SP5050 work with other Bluetooth equipment?
• The Jabra SP5050 is designed to work with Bluetooth mobile
phones. It can also work with other Bluetooth devices that are
compliant with Bluetooth version 1.1, 1.2 or 2.0 and support a
headset and/or handsfree prole.
I cannot use redial or voice dialling
• These functions are dependent on your phone supporting
them.
Please check you phone’s manual for further details.
My Speakerphone does not respond to any button presses
• Reset you Jabra SP5050 – by gently inserting a paper clip into
the reset cavity on the back side of the device
Jabra SP5050 Speakerphone
7
I want to clear the list of paired devices on SP5050?
• Press and hold Volume up and down together with the
answer/end button for 7 sec.
9 NEED MORE HELP?
visit us at www.jabra.com
10 WARNING
Speakerphones are capable of delivering sounds at loud volumes
and high pitched tones. Exposure to such sounds can result in permanent hearing loss damage. The volume level may vary based
on conditions such as the phone you are using, its reception and
volume settings, and the environment. Please read the safety
guidelines below prior to using this headset.
Safety guidelines
1. Prior to using this product follow these steps:
• Before using the speakerphone, turn the volume control to its
lowest level,
• Use the speakerphone in conversation, and then
• Slowly adjust the volume control to a comfortable level.
2. During the use of this product
• Keep the volume at the lowest level possible and avoid using
the speakerphone in noisy environments where you may be
inclined to turn up the volume;
• If increased volume is necessary, adjust the volume control
slowly; and
• If you experience discomfort or ringing in your ears, immedi ately discontinue using the speakerphone and consult a physi cian.
With continued use at high volume, your ears may become accustomed to the sound level, which may result in permanent damage
to your hearing without any noticeable discomfort.
Drive safely
Several studies have shown that cell phone usage while driving
creates a distraction to the driver which may increase the likelihood of an accident. This distraction potential is not eliminated
by the use of a hands-free phone. Hands-free phones have not
Jabra SP5050 Speakerphone
8
been shown to be safer than hand-held phones with respect to
driver distraction. When using the phone while driving, keep conversations short and resist any temptation to make notes or read
documents. Before answering calls consider your circumstances.
Pull o the road and park before making or answering calls when
driving conditions require (e.g. bad weather, high trac density,
presence of children in the car, dicult junctions or manoeuvres)
REMEMBER; DRIVING COMES FIRST, NOT THE CALL!
Abide by local laws.
Please check if the local laws where you live restrict the use of
mobile phones while driving. It is the owner’s responsibility to
use this product in compliance with the laws of the place where
you live.
WARNING!
Keep out of reach of children: The plastic bags the product and
its parts are wrapped in are not toys for children. The bags themselves or the many small parts they contain may cause choking if
ingested.
WARNING!
ACA TS028 – Ignition of ammable atmospheres: Do not use the
Headset in environments where there is a danger of ignition of
ammable gases.
11 WARRANTY
Limited One (1) -Year Warranty
GN Netcom A/S, warrants this product to be free from defects in
materials and workmanship (subject to the terms set forth below)
for a period of two (2) year from the date of purchase (“Warrenty
Period”). During the Warranty Period, GN will repair or replace (at
GN’s discretion) this product or any defective parts (“Warrenty
Service”). If repair or replacement is not commercially practicable
or cannot be timely made, GN may choose to refund to you the
purchase price paid for the aected product. Repair or replacement under the terms of this warranty does not give right to any
extension or a new beginning of the period of warranty.
Claims under the Warranty
To obtain Warranty Service, please contact the GN dealer from
which you purchased this product or visit www.gnnetcom.com or
www.jabra.com for further information about customer support.
Jabra SP5050 Speakerphone
9
You will need to return this Product to the dealer or ship it to the
dealer or to GN (if so indicated on www.gnnetcom.com or www.
jabra.com) in either its original packaging or packaging aording
an equal degree of protection.
You will bear the cost of shipping the product to GN. If the Product is covered by the warranty, GN will bear the cost of shipping
product back to you after the completion of service under this
warranty. Return shipping will be charged to you for products not
covered by the warranty or requiring no warranty repair.
The Following information must be presented to obtain Warranty
Service: (a) the product, and (b) proof of purchase, which clearly
indicates the name and address of the seller, the date of purchase
and the product type, which is evidence that this product is within
the Warranty Period. Please further include (c) your return address.
(d) daytime telephone number, and (e) reason for return.
As part of GN/Jabra’s eorts to reduce environmental waste you
understand that the product may consist of reconditioned equipment that contains used components, some of which have been
reworked. The used components all live up to GN/Jabra’s high
quality standards and comply with the GN product performance
and reliability specications. You understand that replaced parts
or components will become the property of GN.
Limitation of Warranty
This warranty is only valid for the original purchaser and will automatically terminate prior to expiration if this product is sold or
otherwise transferred to another party. The warranty provided by
GN in this statement applies only to products purchased for use,
and not for resale. It does not apply to open box purchases, which
are sold “as is” and without any warranty.
Specically exempt from warranty are limited-life consumable
components subject to normal wear and tear, such as microphone
windscreens, ear cushions, modular plugs, ear tips, decorative
nishes, batteries, and other accessories.
This warranty is invalid if the factory-applied serial number, date
code label, or product label has been altered or removed from this
product.
This Warranty does not cover cosmetic damage or damage due to
misuse, abuse, negligence, Acts of Nature, accident, disassembling
or modication of, or to any part of, the product. This Warranty
does not cover damage due to improper operation, maintenance
or installation, or attempted repair by anyone other than GN or
Jabra SP5050 Speakerphone
10
a GN dealer which is authorized to do GN warranty work. Any
unauthorized repairs will void this warranty.
REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS WARRANTY ARE THE EXCLUSIVE REMEDY OF THE CONSUMER. GN
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY
ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY
LAW, THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER
EXPRESS AND IMPLIED WARRANTIES WHATSOEVER, INCLUDING
BUT NOT LIMITED TO THE WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PRACTICAL PURPOSE.
NOTE! This warranty gives you specic legal rights. You may
have other rights which vary from location to location. Some
jurisdictions do not allow the exclusion or limitation of incidental
or consequential damages or implied warranties, so the above
exclusions may not apply to you. This warranty does not aect
your legal (statutory) rights under your applicable national or local
laws.
12 CERTIFICATION AND SAFETY APPROVALS
CE
This product is CE marked according to the provisions of the R &
TTE Directive (99/5/EC). Hereby, GN Netcom, declares that this
product is in compliance with the essential requirements and
other relevant provisions of
Directive 1999/5/EC.
For further information please consult www.jabra.com
Within the EU this device is intended to be used in Austria,
Belgium, Cyprus,
Czech Republic, Denmark, Estonia, Finland, France, Germany,
Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg,
Malta, Poland, Portugal, Slovakia, Slovenia, Spain, Sweden, The
Netherlands, United Kingdom, and within EFTA in Iceland, Norway
and Switzerland.
Bluetooth
The Bluetooth® word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by GN Netcom is under license.
Other trademarks and trade names are those of their respective
owners.
Jabra SP5050 Speakerphone
11
13 GLOSSARY
1 Bluetooth is a radio technology that connects devices, such
as mobile phones and headsets, without wires or cords over
a short distance (approx. 30 feet). Get more information at
www.bluetooth.com
2 Bluetooth proles are the dierent ways that Bluetooth devic es communicate with other devices. Bluetooth phones support
either the headset prole, the hands-free prole or both. In
order to support a certain prole, a phone manufacturer must
implement certain mandatory features within the phone’s
software.
3 Pairing creates a unique and encrypted link between two
Bluetooth devices and lets them communicate with each other.
Bluetooth devices will not work if the devices have not been
paired.
4 Passkey or PIN is a code that you enter on your Bluetooth
enabled device (e.g. a mobile phone) to pair it with your
Jabra SP5050. This makes your device and the Jabra SP5050
recognize each other and automatically work together.
5 Standby mode is when the Jabra SP5050 is passively waiting
for a call. When you ‘end’ a call on your mobile phone; the
headset goes into standby mode.
Jabra SP5050 Speakerphone
12
Loading...
