Jabra JX20 User Manual
G e t t i n G s t a r t e d
enGlish
THANK YOU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
ABOUT YOUR JABRA JX20 PURA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
WHAT YOUR HEADSET DOES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CHARGE YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
TURNING YOUR HEADSET ON AND OFF . . . . . . . . . . . . . . . . . . . . . . . . 5
PAIRING IT WITH YOUR PHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
WEARING STYLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
WHAT THE LIGHTS MEAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
MULTIPOINT FUNCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TROUBLESHOOTING & FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
NEED MORE HELP?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
TAKING CARE OF YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
WARNING! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
CERTIFICATION AND SAFETY APPROVALS . . . . . . . . . . . . . . . . . . . . .14
GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
enGlish
JABRA J X20 PURA
1
thank you
Thank you for purchasing the Jabra JX20 PURA headset. We hope
you enjoy it! This user manual will get you started and ready to
make the most of your headset.
about your Jabra JX20 Pura
JX20 PURA headset:
1
Light indicator (LED)
2
Charging socket
3
On/o switch
(rotate earpiece 90 degrees)
Fig. 1
1
JX20 PURA deskstand:
1
Light indicator
2
Charging socket
Fig. 2
1
Accessories:
Eargel
Fig. 3
4
2
3
2
Earhooks
4
Answer/end buttom
5
Volume up & down
6
Earhook connection
6
5
enGlish
JABRA J X20 PURA
2
What your headset does
Your Jabra JX20 PURA lets you do all this:
• Answer calls
• End calls
• Reject calls*
• Voice dialing*
• Last number redialing*
• Call waiting*
• Put call on hold*
• Multipoint - connect to two Bluetooth devices at the same time
Specications:
• Up to 6 hours talk time/standby time up to 200 hours
• Rechargeable battery with charging option from AC power
supply, PC via USB cable, or deskstand
• Less than 12 grams
• Operating range up to 10 meters (approx. 33 feet)
• Headset and hands-free Bluetooth proles
• Bluetooth specication (see glossary) version 2.0
GettinG started
You should follow three steps before using your headset:
1. Charge your headset.
2. Activate Bluetooth on your mobile phone (refer to the
manual for your mobile phone).
3. Pair your headset to your mobile phone.
The Jabra JX20 PURA is easy to operate. The answer/end button
on the headset performs dierent functions depending on how
long you press it.
enGlish
* Phone dependent
JABRA J X20 PURA
3
Instruction Duration of press
Tap Press briey
Press Approx. 1 seconds
Press and hold More than 3 seconds
CharGe your headset
Make sure that your Jabra JX20 Pura headset is fully charged
before you start using it. Use the AC adapter to charge from a
power socket, or charge directly from your PC with the USB cable
provided.
Please note: The lifetime of the battery will be signicantly reduced
if your device is left uncharged for a long period. We therefore
recommend that you recharge your device at least once a month.
1. Charging from your deskstand:
• Connect your USB cable/AC adapter to the deskstand. Place
your JX20 Pura headset in the deskstand as shown in g. 2.
2. Battery status indicators:
• When the headset is charging, it will indicate the amount of
power in the battery.
Charging your headset from AC adapter or USB cable:
What you see What this means
LED ashes once
LED ashes twice
LED ashes three times
LED ashes four times 75%-100% charged
LED soild white Fully charged
0-25% charged
25-50% charged
50-75% charged
enGlish
JABRA J X20 PURA
4
Charging your headset from your deskstand:
What you see What this means
LED o No device in deskstand
1st. LED solid Device in deskstand
1st. LED solid, 2nd. LED pulsing
1+2 LED solid, 3rd. LED pulsing
1+2+3 LED solid, 4th. LED pulsing
1+2+3 +4 LED solid, 5th. LED pulsing 75-100% charged
All LED´s solid Fully charged
Check Battery status:
• When you are not in a call, tap either volume button.The LED
will ash in accordance with the AC adapter/USB charger
sequence above.
0-25% charged
25-50% charged
50-75% charged
turninG your headset on and off
• Gently turn the earpiece 90° clockwise to turn on the headset
(see g. 1).
• Gently turn the earpiece 90° anti-clockwise to turn o the
headset (see g. 1).
PairinG it With your Phone
The rst time you turn on your Jabra JX20 Pura it will automatically
enter pairing mode. In this case skip directly to point 2 below.
When pairing with a second device, or if you need to pair
manually, start with point 1 below.
1. Put the headset in pairing mode:
• Turn the headset on.
• Press and hold the answer / end button until the LED on the
back shines continuously.
enGlish
JABRA J X20 PURA
5
